An Introduction to the Logic Express Instruments

Logic Express provides a number of software-based instruments that include: innovative synthesizers, a powerful sampler, and authentic recreations of vintage instruments. You can use these instruments for real time playback in Logic Express.

The Logic Express instruments cover almost every sound generation need you will encounter in your day to day work with Logic Express. All instruments feature intuitive interfaces that provide access to all functions and parameters. Pristine audio quality is assured when needed, or—at the other end of the spectrum—extremely harsh and dirty sounds can be created with many of the included instruments. All instruments are highly optimized for efficient CPU usage, maximizing the real time playback potential of your computer.

This preface covers the following:

• About the Logic Express Instruments (p. 9)

• About the Logic Express Documentation (p. 10)

• Additional Resources (p. 10)

Preface

About the Logic Express Instruments

Logic Express includes a comprehensive collection of instruments that can be used in your music projects. Instruments are grouped in the following categories.

Synthesizer

Included instrumentsInstrument category

• EFM1

• ES E

• ES M

• ES P

• ES1

• ES2

• Klopfgeist

• UltrabeatDrum synthesizer

• EXS24 mkIISoftware sampler

• EVOC 20 PolySynthVocoder synthesizer

• External InstrumentUtility

GarageBand instruments

Analog Basic,Analog Mono, Analog Pad,Analog Swirl, Analog Sync, Bass, Digital Basic, Digital Mono, Digital Stepper, Drum Kits, Electric Clavinet, Electric Piano, Guitar, Horns, Hybrid Basic, Hybrid Morph, Piano, Sound Effects, Strings, Tonewheel Organ, Tuned Percussion, Voice, Woodwind (see GarageBand Instruments)

About the Logic Express Documentation

Logic Express comes with various documents that will help you get started as well as provide detailed information about the included applications.

• Logic Express User Manual: This onscreen manual provides comprehensive instructions for using Logic to set up a recording system, compose music, edit audio and MIDI files, and output audio for CD productions.

• Exploring Logic Express: This booklet provides a fast-paced introduction to the main features and tasks in Logic Express, encouraging hands-on exploration for new users.

• Logic Express Control Surfaces Support: This onscreen manual describes the configuration and use of control surfaces with Logic Express.

• Logic Express Instruments: This onscreen manual provides comprehensive instructions for using the powerful collection of instruments included with Logic Express.

• Logic Express Effects: This onscreen manual provides comprehensive instructions for using the powerful collection of effects included with Logic Express.

• Logic Express Working with Apogee Hardware: This onscreen manual describes the use of Apogee hardware with Logic Express.

Additional Resources

Along with the documentation that comes with Logic Express, there are a variety of other resources you can use to find out more.

10 Preface An Introduction to the Logic Express Instruments

Release Notes and New Features Documents

Each application offers detailed documentation that covers new or changed features and functions. This documentation can be accessed in the following location:

• Click the Release Notes and New Features links in the application Help menu.

Logic Express Website

For general information and updates, as well as the latest news on Logic Express, go to:

• http://www.apple.com/logicexpress

Apple Service and Support Websites

For software updates and answers to the most frequently asked questions for all Apple products, go to the general Apple Support webpage. You’ll also have access to product specifications, reference documentation, and Apple and third-party product technical articles.

• http://www.apple.com/support

For software updates, documentation, discussion forums, and answers to the most frequently asked questions for Logic Express, go to:

• http://www.apple.com/support/logicexpress

For discussion forums for all Apple products from around the world, where you can search for an answer, post your question, or answer other users’ questions, go to:

• http://discussions.apple.com

11Preface An Introduction to the Logic Express Instruments

ES E

The ES E synthesizer is ideal for quickly creating pad and ensemble sounds.

The 8-voice ES E (ES Ensemble) is great for adding atmospheric beds to your music, with minimal CPU overhead. While it may look simple, it is more than capable of producing rich and warm pad sounds.

The ES E produces sounds using subtractive synthesis. It features an oscillator that generates harmonically rich waveforms. You subtract (cut, or filter out) portions of these waveforms, and reshape them, to create new sounds.

If you’re totally new to synthesizers, it might be best to start off with Synthesizer Basics, which will introduce you to the terminology, and give you a great overview of different synthesis methods and how they work.

This chapter covers the following:

• Getting to Know the ES E Interface (p. 14)

• Using the ES E Oscillators (p. 15)

• Using the ES E LFO (p. 15)

• Using the ES E Filter (p. 16)

• Using the ES E Envelope (p. 17)

• Using the ES E Output Parameters (p. 17)

• Extended ES E Parameters (p. 18)

Filter parameters Output parameters

Envelope parametersLFO parameters

Oscillator parameters

Getting to Know the ES E Interface

Before you take a look at the individual parameters of the ES E, this section will familiarize you with the various elements in the ES E graphical interface.

• Oscillator parameters: The oscillator Wave and Octave parameters are shown in the area to the left. The oscillator generates the waveforms that form the basis of your sound. See Using the ES E Oscillators.

• LFO parameters: The LFO parameters (below the oscillator Wave parameter knob) are used to modulate the sound. See Using the ES E LFO.

• Filter parameters: The section to the right of the Oscillator parameters includes the Cutoff (Frequency) and Resonance knobs. You use the filter to contour the waveforms sent from the oscillator. See Using the ES E Filter.

• Envelope parameters: The area to the right of the Filter parameters contains the Envelope parameters, which control the level of the sound over time. See Using the ES E Envelope.

• Output parameters: The areaat the extreme right houses the Volume knob, responsible for the main output level, and the Effect parameters. The effects can be used to color or thicken the sound. See Using the ES E Output Parameters.

• Extended parameters: Not shown in the image, the extended parameters are accessed by clicking the triangle at the lower left of the interface. These parameters include bend and tuning functions. See Extended ES E Parameters.

14 Chapter 1 ES E

Using the ES E Oscillators

The synthesizer oscillator generates a waveform, which is then sent to other portions of the synthesizer engine for processing or manipulation.

• Wave knob: Selects the waveform of the oscillator, which is responsible for the basic color of the tone. The leftmost setting of the Wave parameter causes the oscillators to output sawtooth signals. Across the remaining range, the oscillators output pulse waves, with the average pulse width being defined by the Wave parameter position.

• 4, 8, 16 buttons: Allow you to switch the pitch in octaves (transpose it up or down). The lowest setting is 16 feet, and the highest is 4 feet. The use of the term feet to determine octaves comes from the measurements of organ pipe lengths. The longer (and wider) the pipe, the deeper the tone.

Using the ES E LFO

The LFO (low frequency oscillator) generates a cyclic waveform that is used to modulate the ES E waveform. The behavior and effect of the LFO depend on whether a sawtooth or pulse wave is selected.

• If Wave is set to sawtooth, the LFO modulates the frequency of the waveform, resulting in a vibrato or siren effect—depending on the LFO speed and intensity.

• If Wave is set to a pulse wave, the LFO modulates the waveform’s pulse width (PWM).

• Vib/PWM knob: Defines the intensity of the LFO modulation.

• Speed knob: Sets the frequency of the LFO modulation.

15Chapter 1 ES E

Note: When the pulse width becomes very narrow, the signal sounds as if it is being interrupted (“breaking up”). Given this potential artifact, set the PWM intensity with care, and select the Wave parameter’s 12 o’clock position (50% rectangular) for the pulse width, if you want to achieve the maximum modulation range.

Using the ES E Filter

The ES E includes a lowpass filter that lets you contour the output from the oscillator.

• Cutoff knob: Controls the cutoff frequency of the ES E filter.

• Resonance knob: Boosts or cuts portions of the signal that surround the frequency defined by the Cutoff parameter.

Note: Increasing the Resonance value results in a rejection of bass (low frequency energy) when using lowpass filters.

• AR Int knob: The ES E features one simple envelope generator per voice-offering an Attack and a Release parameter (see Using the ES E Envelope). The AR Int knob defines the amount (depth) of cutoff frequency modulation applied by the envelope generator.

• VeloFilter knob: Sets the velocity sensitivity of the cutoff frequency modulation applied by the envelope generator.

Note: This parameter has no effect if AR Int is set to 0.

16 Chapter 1 ES E

Using the ES E Envelope

The AR (Attack and Release) envelope affects both the filter cutoff (AR Int) and the level of the sound over time.

• Attack slider: Determines the time that it takes for the signal to reach the initial, desired signal level (the sustain level).

• Release slider: Determines the time that it takes for the signal to fall from the sustain level to a level of zero.

Using the ES E Output Parameters

The ES E output stage consists of the Volume section and the Chorus/Ensemble buttons.

• Volume knob: Sets the overall output level of the ES E.

• Velo Volume knob: Sets the amount (depth) of velocity sensitivity to incoming MIDI note events. When it is set to higher values, each note is louder, if struck more firmly. At lower values, the dynamic response is reduced, so that there is little difference when you play a note pianissimo (soft) or forte (loud/hard).

17Chapter 1 ES E

• Chorus I, Chorus II, and Ensemble buttons: Click to switch any of these effect variations on or off.

• Chorus I and Chorus II are typical chorus effects.

• Chorus II is characterized by a stronger modulation.

• The Ensemble effect employs a more complex modulation routing, creating a fuller

and richer sound.

• If none of the buttons is active, the effects processor is turned off.

Extended ES E Parameters

The ES E offers three additional parameters that are accessed by clicking the disclosure triangle at the lower left of the interface.

• Pos.Bender Range: Changes the positive (upwards) pitch bend range in semitone steps. This allows you to use the pitch bend controller of your keyboard to bend the ES E pitch.

• Neg. Bender Range: The default Neg. Bender Range value is Pos PB (Positive Pitch Bend). In essence, this means that only positive pitch bend is available. You can adjust the negative (downwards) pitch bend range in semitone steps-up to 2 octaves (a value of

24).

• Tune: Tunes the entire instrument in cents. A cent is 1/100th of a semitone.

18 Chapter 1 ES E
