Apple iPod Touch User Manual

User’s Guide

Windows

使用手冊

Windows

English

Getting started 1

Using iPod 4

Tips and troubleshooting 9

Learning more,
service, and support 13

Safety and cleaning 15

iPod 24

21

29

33

35

Getting started

iPod for Windows works with MUSICMATCH Jukebox,included with
your iPod. Use MUSICMATCH Jukebox to organize music from your CD
collection, then transfer songs to iPod for listening on the go.Read on
to find out how to get started playing music with iPod.

Charge the battery.

Connect iPod to the iPod Power

1

Adapter using the included FireWire
cable. Plug the power adapter into a
working outlet for at least one hour to
charge the battery.iPod’s battery is
80-percent charged in about an
hour,and fully charged in 4 hours.

Getting started

11

1

Install software.

If you don’t already have MUSICMATCH Jukebox 7 with

2

the iPod plug-in software,install it using the “iPod for

Getting started

2

Windows”CD.

Connect iPod.

Start up your computer and connect iPod using the included

3

FireWire cable. If your computer has a 4-pin FireWire (IEEE

1394) port, use the included 6-pin to 4-pin adapter.

Tra nsfer music.

When MUSICMATCH Jukebox opens,it automatically transfers

4

the songs in your music library to iPod.

Play music.

Use iPod’s scroll wheel and Select button to browse for a song.

5

Then press the Play button and enjoy!

Getting started

3

Using iPod

Using iPod

4

Once you transfer songs to iPod,it’s easy to browse for and
listen to songs. Read on for tips on using iPod.You can also find
information about using iPod in iPod onscreen help and on
the Web (see “Learning more,service, and support”).

Tur nin g iPod on and off

To t urn i Pod on,press any button. If a song is paused or no song is
playing,iPod turns off automatically after two minutes.To turn iPod
off immediately,press and hold the Play button for a few seconds.

Disabling iPod’s buttons using the Hold switch

If you’re carrying iPod in your pocket and you don’t want to
press the buttons accidentally,set the Hold switch to make the
buttons inactive.

Turni ng on the backlight

To t urn i Pod ’s backlight on or off, press and hold the Menu button.

Using iPod’s controls

Use iPod’s buttons and scroll wheel to navigate through iPod’s
onscreen menus.To select a menu item,use the scroll wheel
to scroll to the item, then press the Select button (in the
center of iPod).To go back to the previous menu, press the
Menu button.

Playing a song

You c an browse for songs by artist, album,title, genre, or composer.If you
transfer playlists (songs you’ve organized into lists) from MUSICMATCH
Jukebox to iPod,you can also browse for songs in playlists.

Select Playlists or Browse in iPod’s main menu, then navigate to a song
and press the Select button to play the song.To play all the songs by an
artist, on an album,or in a playlist, press the Play button when the artist,
album, or playlist name is highlighted.

Changing the volume

If you see the Now Playing screen,which shows the title of the song
playing,you can use the scroll wheel to adjust the volume. If you don’t
see the Now Playing screen, select Now Playing in the main menu.

You c an also use the iPod Remote (available with some models)
to adjust the volume.

Using iPod

5

Tra nsferring music

By default, iPod is set to transfer music automatically when

Using iPod

you connect it to your computer.You can also transfer and
delete individual songs manually.

To c hang e iPod’s s e ttings, open MUSICMATCH Jukebox and select
“Download files to portable devices” from the File menu.Then select
iPod and click the Options button.

Using the Apple iPod Remote

To u se th e iPod Remote, connect it to iPod’s headphones
port, then connect the Apple Earphones (or another set
of headphones) to the remote.Use the remote to adjust
volume, play or pause a song, fast-forward and rewind,
and skip to the next or previous song. Set the remote’s
Hold switch to lock the remote’s buttons.

The iPod Remote is included with some models of iPod
and can be purchased separately at

6

www.apple.com/store

Importing addresses and phone numbers

You r iPo d can store up to a thousand contacts for viewing on the go.
1 Connect iPod and open your favorite email or contacts application.

Importing contacts works with such programs as Palm Desktop,
Microsoft Outlook, and Eudora.

2 Export contacts as vCard files and copy them to the Contacts folder on

iPod.You can do this by dragging contacts from the application’s
address book to iPod’s Contacts folder in Windows Explorer.iPod must
be enabled for use as a FireWire hard disk.

3 Eject and disconnect iPod.Select Extras in the main menu, then select

Contacts. For more information, see iPod Help, available in the
MUSICMATCH Jukebox Help menu.

Using iPod

7

Changing settings

Select Settings in iPod’s main menu to change settings. You can set

Using iPod

iPod to shuffle or repeat songs,change equalizer settings, set a
backlight timer,and more (see “Learning more,service, and support”
for more information).

Charging the battery

To c harge iPod’s battery, connect iPod to the iPod Power
Adapter (included) and plug the adapter into a working
outlet. iPod’s battery is 80-percent charged in about
an hour,and fully charged in 4 hours. If the battery icon
on iPod’s screen is not animated,its battery is
fully charged.

If your computer has a 6-pin FireWire port, you may be able to
charge iPod by connecting it to your computer. If iPod is charging,
the charging icon appears on its display.

Software Update

Apple periodically updates iPod software to improve performance
or add features.To download the iPod Software Updater application,
go to

www.apple.com/ipod

8

Tips and troubleshooting

Read on for advice about using and troubleshooting iPod.

What are the iPod for Windows system requirements?

You c an use iPod with a computer and software that meet the
following requirements:

•PC with 300 MHz or higher processor speed

• 96 MB RAM (128 MB for Windows XP)

•Windows ME,Windows 2000, Windows XP or later

•Built-in or compatible FireWire card (IEEE 1394) installed
For more information on compatible FireWire cards,
go to

www.apple.com/ipod

For information on installing a FireWire card,see the instructions
that came with the card or with your computer.

•MUSICMATCH Jukebox 7 or later with the iPod plug-in (included on
the “iPod for Windows” CD)

Tips and troubleshooting

9

Tips and troubleshooting

10

My iPod won’t turn on or respond.

•Make sure iPod’s Hold switch is off.

•If you’re using the Apple iPod Remote, make sure the remote’s
Hold switch is off.

•If that doesn’t work,connect iPod to the iPod Power Adapter
and connect the adapter to a working outlet.Your iPod battery
may need to be recharged.

•If that doesn’t work,your iPod may need to be reset.While the
iPod is connected to power, press and hold the Play and Menu
buttons for at least 5 seconds,until the Apple logo appears.

•If that doesn’t work,you may need to restore iPod’s software.
To d own load the iPod Software Updater application, go to

www.apple.com/ipod

My iPod isn’t playing music.

•Make sure iPod’s Hold switch is off.

•If you’re using the Apple iPod Remote, make sure the remote’s
Hold switch is off.

•Make sure the earphone connector is pushed in all the way.

•Make sure the volume is turned up.

•If that doesn’t work,push the Play/Pause button.Your iPod
may be paused.
