Anritsu MS2602A Calibration Procedure

Download
T.O. 33K3-4-3119-1
TECHNICAL MANUAL
CALIBRATION PROCEDURE
FOR
SPECTRUM ANALYZER
MS2602A OPT05
(ANRITSU CORP.)
Destruction Notice - For unclassified, limited documents, destroy by any method that will prevent disclosure of the contents or reconstruction of the document.
Published under Authority of the Secretary of the Air Force
30 APRIL 1997
T.O. 33K3-4-3119-1
LIST OF EFFECTIVE PAGES
INSERT LATEST CHANGED PAGES. DESTROY SUPERSEDED PAGES.
NOTE: The portion of the text affected by the changes is indicated by a vertical line in the outer
margins of the page. Changes to illustrations are indicated by miniature pointing hands. Changes to wiring diagrams are indicated by shaded areas.
Dates of issue for original and changed pages are:
Original..................................0............................30 April 1997
TOTAL NUMBER OF PAGES IN THIS PUBLICATION IS 36, CONSISTING OF THE FOLLOWING:
Page * Change Page * Change Page *Change
No. No. No. No. No. No.
Title .................................... 0
A......................................... 0
1 - 34................................... 0
A USAF
*Zero in this column indicates an original page
T.O. 33K3-4-3119-1
SPECTRUM ANALYZER
MS2602A OPT05
(ANRITSU CORP.)
1 CALIBRATION DESCRIPTION:
Table 1.
Test Instrument (TI) Performance Test Characteristics Specifications Method
Reference Oscillator Range: 10 MHz TI compared to a
Frequency Standard
Accuracy: ≤±2 X 10-8 Per Day
Center Frequency Range: 100 Hz to 8.5 GHz TI compared to a signal of
known frequency Accuracy: ±(Indicated frequency X reference frequency accuracy + span X span accuracy)
Frequency Span Range: 0 Hz, 100 Hz to 8.5 GHz TI SPAN compared to a
signal of known frequency
Accuracy: ±2.5% (span ≥ 1 kHz) ± 5% (100 Hz to 1 kHz)
Resolution Bandwidth and Range: 10 Hz to 3 MHz TI RES BW is measured on Selectivity the TI CRT
Accuracy: Resolution Bandwidth: ±20%; Selectivity: ≤15:1 (100 kHz to 3 MHz) ≤12:1 (10 Hz to 30 kHz)
Sideband Noise Range: 1 MHz to 4 GHz Sidebands are measured 10,
50, 100 kHz from carrier Accuracy: ≤-105 dBc/Hz (at 10 kHz offset) frequency
≤-115 dBc/Hz (at 50 kHz offset) ≤-120 dBc/Hz (at 100 kHz offset)
Frequency Measurement Range: 100 Hz to 8.5 GHz Measured at 500 MHz
Accuracy: ≤ Readout frequency X Reference Oscillator accuracy ± ( 1 count)
Resolution: 1 Hz, 10 Hz, 100 Hz, 1 kHz
1
T.O. 33K3-4-3119-1
Table 1. (Cont.)
Test Instrument (TI) Performance Test Characteristics Specifications Method
Amplitude Scale Linearity Range: LOG 10 dB/Div, 5 dB/Div, 2 dB/Div TI display compared to a
and 1 dB/Div signal of known amplitude
Accuracy: ±1.5 dB from 0 to -90 dB (RBW ≤10 kHz); ±1.0 dB from 0 to -70 dB (RBW ≤100 kHz); ±0.3 dB from 0 to -20 dB (RBW ≤1 MHz)
Frequency Response Range: 100 Hz to 8.5 GHz TI display compared to a signal of known amplitude
Accuracy: ±0.5 dB, (100 Hz to 2.0 GHz, band 0) ±1 dB, (at 1.7 GHz to 8.5 GHz, band 1
-
, band 1+)
Reference Level Range: +30 to -90 dBm TI compared to a signal
of known amplitude
Accuracy: +30 to 0 dBm: ≤0.75 dB; 0 to -50 dBm: ≤±0.3 dB;
-50 to -70 dBm:≤ ±0.75 dB;
-70 to -90 dBm:≤±1.5 dB
Average Noise Level Range: 100 Hz to 8.5 GHz With no input into the TI
the noise level is
measured
Accuracy: ≤ -135 dBm (1 MHz to 7.5 GHz) on the TI CRT ≤-130 dBm (7.5 to 8.5 GHz)
Second Harmonic Distortion Range: 5 MHz to 4.5 GHz Measure Amplitude of
Second Harmonic
Accuracy: ≤ -70 dBc (at 5 to 800 MHz)
≤ -80 dBc (at 800 to 850 MHz) ≤-100 dBc (at 850 MHz to 4.25 GHz)
Resolution Bandwidth Range: 10 Hz to 3 MHz Measure Amplitude at Switching Error Bandwidth change
Accuracy: ±0.3 dB
LOG/LIN Switching Error Range 100 MHz Measure Amplitude when
switched from LOG to
Accuracy: ± 0.3 dB LIN
Input Attenuator Range: 0 to 55 dB Compared to a known Switching Error signal
Accuracy: ±0.3 dB
2
T.O. 33K3-4-3119-1
Table 1. (Cont.)
Test Instrument (TI) Performance Test Characteristics Specifications Method
Sweep Time and Range: 20 ms to 2000 seconds Compared to a signal Time Span of known frequency
Sweep Time Accuracy: ±10% (20 ms to 200
seconds)
±15% (200 seconds to 2000 seconds) Time Span Accuracy: ± 0.5%
2 EQUIPMENT REQUIREMENTS:
Minimum Use Calibration Sub-
Noun Specifications Equipment Item
2.1 FREQUENCY Range: 10 MHz Austron As Available STANDARD 2100F
Accuracy: ±1 X 10
-9
2.2 SYNTHESIZED Range: 10 MHz to 8.5 GHz Hewlett-Packard As Available SWEEPER 8673D
Accuracy: Frequency: ±0.5%
2.3 FREQUENCY Range: 0.1 to 2100 MHz Hewlett-Packard As Available SYNTHESIZER 8642B
Accuracy: Spurious: -90 dBc for non-harmonic signals
2.4 POWER METER Range: 10 MHz to 8.5 GHz Hewlett-Packard As Available w/SENSOR 436A w/8481A
Accuracy: ±5.0%
2.5 FREQUENCY Range: 10 MHz Tracor As Available DIFFERENCE 527E METER Accuracy: ± 1X10
-11
2.6 STEP Range: 100 MHz Hewlett-Packard As
Available
ATTENUATOR 8496B
Accuracy: Charted to 90 dB in 10 dB Steps
3
T.O. 33K3-4-3119-1
Minimum Use Calibration Sub-
Noun Specifications Equipment Item
2.7 STEP Range: 100 MHz Hewlett-Packard As Available
ATTENUATOR 8494B
Accuracy: Charted to 10 dB in 1 dB Steps
2.8 POWER SPLITTER Range: 100 MHz to 8.5 GHz Hewlett-Packard As Available 11667A
Accuracy: ±0.25 dB
2.9 TERMINATION Range: 50 Ω Hewlett-Packard As Available 908A
Accuracy: N/A
2.10 LOW PASS Range: 10.2 MHz, 3.52 GHz SAGE As Available
FILTER L20CA072
Accuracy: ≤ 70 dB
2.11 SYNTHESIZED Range: 50 MHz Hewlett-Packard
LEVEL 3335A GENERATOR Accuracy: 0.001%
3 PRELIMINARY OPERATIONS:
3.1 Review and become familiar with entire procedure before beginning calibration process.
WARNING
Unless otherwise designated, and prior to beginning the Calibration Process, ensure that all test equipment voltage and/or current outputs are set to zero (0) or turned off, where applicable. Ensure that all equipment switches are set to the proper position before making connections or applying power.
3.2 Connect TI and test equipment to the appropiate power source, set POWER switches ON and allow a 1 hour
warm-up period.
3.3 TIME BASE AGING OFFSET CHECK:
3.3.1 TI must be plugged in for at least 24 hours before performing this test. Set TI rear panel INT OUT, EXT IN
switch to INT OUT.
3.3.2 Connect Frequency Standard 10 MHz FREQ OUT to Frequency Difference Meter (FDM) REF INPUT.
Connect TI rear panel REF (10 MHz) to the FDM SIG INPUT connector.
3.3.3 Standardize FDM as required. Set FDM METER RANGE switch as required for an on scale indication on
the Frequency Difference Meter.
4
T.O. 33K3-4-3119-1
3.3.4 If required adjust TI Oscillator FREQUENCY adjustment for the lowest possible Frequency Difference Meter Null readout. Verify Null is less than 2 X 10-8. Record the FDM reading along with the current time and date.
3.3.5 After 24 hours verify the reading on the Frequency Difference Meter is less than 2 X 10-8/day from the reading recorded in step 3.3.4.
NOTE
Adjustment of the TI Osc 10 MHz Time Base is normal due to the aging rate of the crystal. This is common to all Quartz Oscillators. NO REPAIR OR ADJUSTMENT ACTION should be entered into the Maintenance Data Collection System unless TI will not adjust to the minimum offset shown in Table 1, or step 3.3.5 fails.
3.3.6 If required, readjust TI Oscillator for the lowest possible Frequency Difference Meter Null indication and repeat step 3.3.5.
3.3.7 Disconnect Frequency Difference Meter from Frequency Standard and TI.
4 CALIBRATION PROCESS:
NOTE
Unless otherwise specified, verify the results of each test and take corrective action whenever the test requirement is not met, before proceeding.
4.1 CENTER FREQUENCY CALIBRATION:
4.1.1 Press the TI (PRESET) key.
4.1.2 Set the Frequency Synthesizer to 500 MHz at -10 dBm, and connect to the TI RF INPUT.
4.1.3 Perform frequency calibration by pressing the TI SHIFT, CAL, F3 (FREQ CAL). Wait until the message CALIBRATING disappears from the TI CRT.
4.1.4 Set the TI center frequency to 500 MHz.
4.1.5 Set the TI frequency span to 2 kHz.
4.1.6 Set the TI frequency marker to the peak of displayed signal.
4.1.7 The TI center frequency readout must indicate 499.999 95 to 500.000 05 MHz.
4.1.8 Repeat steps 4.1.4 through 4.1.7 setting the Frequency Synthesizer, TI center frequency and TI span frequency to the values listed in Table 2.
5
T.O. 33K3-4-3119-1
Synthesized TI TI Signal Generator Center Span Frequency Frequency Frequency Limits
500 MHz 500 MHz 2 kHz 499.999 95 to 500.000 05 MHz
500 MHz 500 MHz 200 kHz 499.995 to 500.005 MHz
500 MHz 500 MHz 2 MHz 499.95 to 500.05 MHz
500 MHz 500 MHz 10 MHz 499.75 to 500.25 MHz
500 MHz 500 MHz 100 MHz 497.5 to 502.5 MHz
*5 GHz 5 GHz 2 kHz 4.999 999 95 to 5.000 000 05 GHz
5 GHz 5 GHz 200 kHz 4.999 995 to 5.000 005 GHz
5 GHz 5 GHz 2 MHz 4.999 95 to 5.000 05 GHz
Table 2.
5 GHz 5 GHz 10 MHz 4.999 75 to 5.000 25 GHz
5 GHz 5 GHz 100 MHz 4.997 5 to 5.002 5 GHz
7.5 GHz 7.5 GHz 2 kHz 7.499 999 95 to 7.500 000 05 GHz
7.5 GHz 7.5 GHz 200 kHz 7.499 995 to 7.500 005 GHz
7.5 GHz 7.5 GHz 2 MHz 7.499 95 to 7.500 05 GHz
7.5 GHz 7.5 GHz 10 MHz 7.499 75 to 7.500 25 GHz
7.5 GHz 7.5 GHz 100 MHz 7.497 5 to 7.502 5 GHz
* Change the Signal Source to the Synthesized Sweeper.
4.1.9 Set the Synthesized Sweeper to minimum output.
4.2 FREQUENCY SPAN CALIBRATION:
4.2.1 Set the Synthesized Sweeper RF OUTPUT to -10 dBm.
4.2.2 Press the TI (PRESET) key.
4.2.3 Perform the frequency calibration by pressing TI SHIFT, CAL, F4 (FREQ CAL). Wait for the
CALIBRATING message to disappear from the TI CRT display.
4.2.4 Set the TI SPAN to 2 kHz and set the TI CENTER FREQ to 1000 MHz.
6
T.O. 33K3-4-3119-1
4.2.5 Set the Synthesized Sweeper to 999.999 2 MHz.
4.2.6 Adjust the Synthesized Sweeper frequency to place the spectrum peak at the 1st division from the left end of the TI CRT. Record the Synthesized Sweeper frequency.
4.2.7 Adjust the Synthesized Sweeper frequency to place the peak of the signal at the 9th division from the left end of the TI CRT. Record the Synthesized Sweeper frequency.
4.2.8 Subtract the value recorded in step 4.2.6 from the value recorded in step 4.2.7 and divide the results by 0.8. The difference must be between the corresponding values listed in the Limits column of Table 3.
4.2.9 Repeat steps 4.2.4 through 4.2.8 for the remaining values listed in Table 3.
Table 3.
TI Center Frequency TI Span Frequency Limits
1 GHz 2 kHz 1.95 to 2.05 kHz
1 GHz 20 kHz 19.5 to 20.5 kHz
1 GHz 200 kHz 195 to 205 kHz
1 GHz 2 MHz 1.95 to 2.05 MHz
1 GHz 10 MHz 9.75 to 10.25 MHz
1 GHz 100 MHz 97.5 to 102.5 MHz
1 GHz 2 GHz 1.95 to 2.05 GHz
4.25 GHz 100 MHz 97.5 to 102.5 MHz
4.25 GHz 1 GHz 0.975 to 1.025 GHz
4.25 GHz 8.5 GHz 8.2875 to 8.7125 GHz
4.2.10 Set the Synthesized Sweeper for minimum output and disconnect the test setup.
4.3 RESOLUTION BANDWIDTH AND SELECTIVITY CALIBRATION:
4.3.1 Connect the TI 10 MHz REF OUT (rear panel) connector to the Frequency Synthesizer REF INPUT connector (rear panel). Connect the Frequency Synthesizer RF OUTPUT to the TI RF INPUT.
4.3.2 Press the TI (PRESET) key.
4.3.3 Press the TI SHIFT, CAL, F1 (ALL CAL).
7
T.O. 33K3-4-3119-1
4.3.4 Set the TI controls as follows:
CENTER FREQ 100 MHz
SPAN 10 MHz
RBW (MANUAL) 3 MHz
SCALE LOG 1 dB/Div
4.3.5 Set the Frequency Synthesizer to 100 MHz at 0 dBm.
4.3.6 Press the TI Peak (→Ref) key and match the peak of the signal trace to the top line (REF LEVEL) on the TI
CRT.
4.3.7 Press the TI Single Sweep key to execute a single sweep.
4.3.8. Press the TI Measure key, then (F6), OBW MEAS (F1), and SETUP (F5) keys in that order to display the
frequency bandwidth measurement SETUP menu.
4.3.9 Select the TI X dB DOWN by pressing the (F1) key, then set 3 dB with the (F3) key.
4.3.10 Press the RETURN (F6) key to return to the OBW MEAS menu, then press the EXECUTE (F1) key.
4.3.11 The 3 dB resolution bandwidth value is displayed in the upper right hand corner of the TI CRT screen.
This value must be within the limits of Table 4. Record this value.
4.3.12 Repeat steps 4.3.4 through 4.3.11 for the remaining values in Table 4.
Table 4.
TI Resolution TI Frequency 3 dB Bandwidth Record 3 dB Bandwidth Span Limits Bandwidth
3 MHz 10 MHz 2.4 to 3.6 MHz
1 MHz 5 MHz 0.8 to 1.2 MHz
300 kHz 500 kHz 240 to 360 kHz
100 kHz 200 kHz 80 to 120 kHz
30 kHz 50 kHz 24 to 36 kHz
10 kHz 20 kHz 8 to 12 kHz
3 kHz 5 kHz 2.4 to 3.6 kHz
1 kHz 2 kHz 0.8 to 1.2 kHz
300 Hz 1 kHz 240 to 360 Hz
8
TI Resolution TI Frequency 3 dB Bandwidth Record 3 dB Bandwidth Span Limits Bandwidth
100 Hz 1 kHz 80 to 120 Hz
30 Hz 1 kHz 24 to 36 Hz
10 Hz 100 Hz 8 to 12 Hz
4.3.13 Set the TI controls as follows:
CENTER FREQ 100 MHz
SPAN 100 MHz
RBW (MANUAL) 3 MHz
SCALE LOG 10 dB/Div
T.O. 33K3-4-3119-1
Table 4. (Cont.)
VBW 100 Hz
MARKER NORMAL
ZONE WIDTH 10 MHz
4.3.14 Press the TI Peak (→Ref) key to match the peak of the signal trace to the top line (REF LEVEL) on the TI CRT.
4.3.15 Press the TI single sweep key to execute a single sweep.
4.3.16 Press the TI Measure key, then (F6), OBW MEAS (F1), and SETUP (F5) keys in that order to display the occupied frequency bandwidth measurement SETUP menu.
4.3 17 Select the TI X dB DOWN by pressing the (F1) key, then set 60 dB with the (F3) key.
4.3.18 Press the RETURN (F6) key to return to the OBW MEAS menu, then press the EXECUTE (F1) key.
4.3.19 The 60 dB resolution bandwidth value is displayed in the upper right hand corner of the TI CRT screen. Record this value under the 60 dB column of Table 5.
4.3.20 Divide the 60 dB values recorded in Table 5 by the 3 dB values recorded in Table 4. The calculated value must be ≤ 15:1 for the 100 kHz to 3 MHz bandwidth settings and ≤ 12:1 for the 10 Hz to 30 kHz bandwidth settings.
4.3.21 Repeat steps 4.3.13 through 4.3.19 for the remaining values in Table 5.
9
T.O. 33K3-4-3119-1
TI Resolution TI Frequency TI Video Record Bandwidth Span Bandwidth 60 dB Bandwidth
3 MHz 100 MHz 100 Hz
1 MHz 50 MHz 100 Hz
300 kHz 20 MHz 100 Hz
100 kHz 10 MHz 100 Hz
3 0 kHz 200 kHz 100 Hz
10 kHz 100 kHz 100 Hz
3 kHz 20 kHz 100 Hz
Table 5.
1 kHz 10 kHz 10 Hz
300 Hz 2 kHz 1 Hz
100 Hz 1 kHz 1 Hz
30 Hz 200 Hz 1 Hz
10 Hz 100 Hz 1 Hz
4.4 SIDEBAND NOISE CALIBRATION:
4.4.1 Press the TI (PRESET) key.
4.4.2 Press the TI SHIFT, CAL, F1 (ALL CAL).
4.4.3 Set the Frequency Synthesizer output to 2000 MHz and 0 dBm.
4.4.4 Set the TI controls as follows:
CENTER FREQ 2.000050 GHz
SPAN 125 kHz
REF LEVEL 0 dBm
10
ATT 15 dB
RBW 100 Hz
T.O. 33K3-4-3119-1
VBW 10 Hz
DET MODE SAMPLE
4.4.5 Press the TI (PEAK SEARCH) key to search for a peak point so that the peak point on the signal is included in the zone marker.
4.4.6 Press the TI ( → Ref) key to match the peak of the signal trace to the top line (REF LEVEL) on the TI CRT.
4.4.7 Press the TI (Measure) key, then press the (F2) key corresponding to the menu label (NOISE MEAS) to select the C/N RATIO with the (F5) key.
4.4.8 Press the TI (F1) key to measure C/N.
4.4.9 Set the zone-marker width to SPOT.
4.4.10 Press the (Marker) key, then turn the rotary knob to move the zone marker to the right so that the zone center frequency is 10.0 kHz.
4.4.11 The C/N value must be ≤ -105 dBc/Hz.
4.4.12 Ensure the C/N value is ≤ -115 dBc/Hz and ≤ -120 dBc/Hz, by turning the rotary knob so that the zone center frequency is 50 kHz and 100 kHz, respectively.
4.5 FREQUENCY MEASUREMENT CALIBRATION:
4.5.1 Press the TI (Preset) key.
4.5.2 Set the Frequency Synthesizer to 500 MHz and -10 dBm.
4.5.3 Set the TI as follows:
CENTER FREQ 500 MHz
SPAN 5 kHz
4.5.4 Press the TI (Measure) key, then the (F1) key to set the FREQ MEAS to ON.
4.5.5 Press the TI (F5) key to set the COUNT RESOLUTION to 1 Hz, then press the (F6) and (F1) keys in that order to select COUNT ON.
4.5.6 Verify that the FREQ reading at the upper-left of the TI CRT is the RF INPUT frequency of 500 MHz ±1 Hz or less.
4.5.7 Change the TI counter resolution to 10 Hz and verify that the FREQ reading is 500 MHz ± 10 Hz or less.
4.5.8 Change the TI counter resolution to 100 Hz and verify that the FREQ reading is 500 MHz ± 100 Hz or less.
4.5.9 Change the TI counter resolution to 1 kHz and verify that the FREQ reading is 500 MHz ± 1 kHz or less.
4.5.10 Set outputs to off and disconnect equipment.
11
T.O. 33K3-4-3119-1
4.6 AMPLITUDE SCALE LINEARITY CALIBRATION:
4.6.1 Connect the Synthesized Level Generator RF OUT through the 10 dB Step Attenuator to the TI RF INPUT.
4.6.2 Press the TI (PRESET) key.
4.6.3 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait until the CALIBRATING message disappears.
4.6.4 Set the Synthesized Level Generator for a 50 MHz @ 10 dBm output. Set the Step Attenuator to 10 dB.
4.65 Set the TI controls as follows:
CENTER FREQ 50 MHz
SPAN 10 kHz
REF LEVEL 0 dBm
ATT 10 dB
RBW 3 kHz
VBW 300 Hz
4.6.6 Press the TI Peak (→CF) key to set the spectrum waveform peak to the center of the TI CRT.
4.6.7 Adjust the Synthesized Level Generator output level so that the TI marker level reading is 0.0 dBm.
4.6.8 Press the (Marker) and (F2) keys sequentially to set the marker to ∆ marker after the sweep is completed.
4.6.9 Read the current marker level when the Synthesized Level Generator OUTPUT is set to 0 dB. The error
must be within the Limits of Table 6.
4.6.10 Repeat step 4.6.9 setting the Synthesized Level Generator OUTPUT level to the applied value as listed in
Table 6. The error must be within the Limits of Table 6.
Table 6.
Applied (dBm) Limits
+10 Reference +5 ±0.3 dB 0 ±0.3 dB
12
-5 ±0.3 dB
-15 ±0.3 dB
-20 ±0.3 dB
Table 6. (Cont.)
Applied Limits
-25 ± 1.0 dB
-30 ± 1.0 dB
-35 ± 1.0 dB
-40 ± 1.0 dB
-45 ± 1.0 dB
-50 ± 1.0 dB
-55 ± 1.0 dB
-60 ± 1.0 dB
T.O. 33K3-4-3119-1
-65 ± 1.0 dB
-70 ± 1.0 dB
-75 ±1.5 dB
-80 ±1.5 dB
4.6.11 Set outputs to off and disconnect equipment.
4.7 FREQUENCY RESPONSE CALIBRATION:
4.7.1 Connect the TI 10 MHz REF OUT to the Synthesized Sweeper REF IN.
4.7.2 Connect the Synthesized Sweeper RF OUTPUT through the Power Splitter to the TI RF INPUT and the Power Sensor/ Power Meter input.
4.7.3 Set the Synthesized Sweeper as follows:
OUTPUT FREQ 100 MHz
OUTPUT LEVEL -10 dBm
4.7.4 Press the TI (PRESET) key.
4.7.5 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait until the CALIBRATING message has disappeared.
13
T.O. 33K3-4-3119-1
4.7.6 Set the TI as follows:
CENTER FREQ 100 MHz
SPAN 200 kHz
BAND 0
REF LEVEL -10 dBm
4.7.7 Press the TI Peak (→CF) key.
4.7.8 Set the TI marker mode to delta marker.
4.7.9 Set the Synthesized Sweeper output to 0 dB as read on the Power Sensor/Power Meter. The TI must read
within the Limits of Table 7.
4.7.10 Set the TI frequency band and center frequency as listed in Table 7. Set the Synthesized Sweeper to the
same frequency and adjust the output to 0 dB as read on the Power Sensor/Power Meter. The TI must read within the listed Limits.
4.7.11 Repeat step 4.7.10 for the remaining values in Table 7. Perform peaking of the preselector for bands 1- and
1+.
Table 7.
Band Center Frequency Limits
0 100 MHz ± 0.5 dB 0 200 MHz ± 0.5 dB 0 500 MHz ± 0.5 dB 0 1 GHz ± 0.5 dB 0 1.5 GHz ± 0.5 dB 0 2 GHz ± 0.5 dB
-
1
-
1
-
1
-
1
1.7 GHz ± 1 0 dB 2 GHz ± 1 0 dB 3 GHz ± 1 0 dB 4 GHz ± 1 0 dB
14
-
1
5 GHz ± 1 0 dB
-
1
Table 7. (Cont.)
Band Center Frequency Limits
-
1
-
1
+
1
+
1
+
1
+
1
+
1
4.7.12 Set outputs to off and disconnect the equipment.
T.O. 33K3-4-3119-1
6 GHz ± 1 0 dB
7 GHz ± 1 0 dB
7.5 GHz ± 1 0 dB
6.5 GHz ± 1.0 dB 7 GHz ± 1.0 dB
7.5 GHz ± 1.0 dB 8 GHz ± 1.0 dB
8.5 GHz ± 1.0 dB
4.8 REFERENCE LEVEL CALIBRATION:
4.8.1 Connect the Synthesized Level Generator RF OUTPUT through 10 dB Step Attenuator to the Power Splitter.
4.8.2 Press the TI (PRESET) key and set Step Attenuator to 10 dB.
4.8.3 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait for the CALIBRATING message to disappear from the TI CRT.
4.8.4 Set the Synthesized Level Generator to 50 MHz and adjust the output level for a 0 dBm reading on the Power Meter.
4.8.5 Set the TI as follows:
CENTER FREQ 50 MHz
SPAN 200 kHz
REF LEVEL 0 dBm
4.8.6 Press the TI PEAK (→ CF) to move the peak point of the spectrum waveform to the center of the screen.
4.8.7 Read the marker level. It must be within the Limits of Table 8.
4.8.8 Set the TI Reference Level to the settings listed in Table 8 and set the Synthesized Level Generator OUTPUT to the Appplied value listed in Table8 and read the marker level. The readings must be within the Limits of Table 8.
15
T.O. 33K3-4-3119-1
TI Reference Level Limits (dB)
Setting (dBm) Applied (dBm)
Table 8.
0 10 Reference
-10 0 ±0.3
-20 -10 ±0.3
-30 -20 ±0.3
-40 -30 ±0.3
-50 -40 ± 0.3
-60 -50 ± .75
-70 -60 ± .75
-80 -70 ± 1.5
-90 -80 ± 1.5
4.8.9 Set outputs to off and disconnect equipment.
4.9 AVERAGE NOISE LEVEL CALIBRATION:
4.9.1 Press the TI (PRESET) key.
4.9.2 Press TI SHIFT, CAL, F1 (ALL CAL). Wait for the CALIBRATING message to disappear.
4.9.3 Connect the 50 Ω Termination to the TI RF INPUT connector.
4.9.4 Set the TI controls as follows:
START FREQ 1 MHz
STOP FREQ 1 GHz
16
REF LEVEL -40 dBm
ATT 0 dB
RBW 30 kHz
T.O. 33K3-4-3119-1
VBW 3 kHz
DET MODE SAMPLE
4.9.5 Press the TI (SHIFT) key to execute a single sweep.
4.9.6 Press the TI Peak (→CF) key to set the frequency at the peak level of the spectrum to the center frequency.
4.9.7 Press the TI (SHIFT) key and then the (SINGLE) key to execute a continuous sweep.
4.9.8 Set the TI controls as follows:
SPAN 0 Hz
REF LEVEL -100 dBm
RBW 10 Hz
VBW 1 Hz
4.9.9 Press the TI Display section (TIME), (F4), (F2), (F4), (1), (6), (ENTER) keys sequentially to preset the 16­time averaging sweep.
4.9.10 Press the TI (F3) key to start the averaging, and wait until the 16-time averaging sweep is completed.
4.9.11 Press the TI (Peak Search) key to execute peak search. At this point, read the level value at the marker.
4.9.12 Verify that a reading of -135 dBm or less can be obtained at the marker.
4.9.13 Repeat steps 4.9.4 through 4.9.12 setting the TI START and STOP FREQUENCIES as listed in Table 9. The level value at the marker must be -135 dBm or less, except for START FREQ of 7.5 GHz and STOP FREQ of
8.5 GHz, must be -130 dBm.
Table 9.
Start Freq Stop Freq
1 MHz 1 GHz
1 GHz 2 GHz
1.7 GHz 7.5 GHz
7.5 GHz 8.5 GHz
4.10 SECOND HARMONIC DISTORTION:
4.10.1 Connect the Frequency Synthesizer through the Low-Pass Filter to the TI RF INPUT.
4.10.2 Press the TI (PRESET) key.
17
T.O. 33K3-4-3119-1
4.10.3 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait until the CALIBRATING message has disappeared.
4.10.4 Set the Low-Pass Filter cut-off frequency to approximately 6.4 MHz.
4.10.5 Set the Frequency Synthesizer output to 5.1 MHz and the output level to -30 dBm.
4.10.6 Set the TI controls as follows:
CENTER FREQ 5.1 MHz
SPAN 10 kHz
REF LEVEL -30 dBm
ATT 0 dB
4.10.7 Set the Frequency Synthesizer output level so that the peak of the spectrum waveform is at the TI REF
LEVEL (the top horizontal line of the TI CRT).
4.10.8 Move the marker to the peak of the spectrum waveform and make the marker the ∆ marker.
4.10.9 Set the TI center frequency to twice the fundamental wave frequency to display the second harmonic on the
TI CRT. The ∆ marker reading indicates the level difference between the fundamental wave and the second harmonic.
4.10.10 If the level difference is 70 dB or more, set the TI REF LEVEL to -50 dBm. Confirm that the TI ATT set
value is 0 dB.
4.10.11 Set the Frequency Synthesizer output to 810 MHz and the output level to -30 dBm.
4.10.12 Set the Low Pass Filter cut-off frequency to approximately 1 GHz.
4.10.13 Set the TI controls as follows:
CENTER FREQ 810 MHz
SPAN 10 kHz
REF LEVEL -30 dBm
ATT 0 dB
4.10.14 Repeat steps 4.10.7 to 4.10.9.
4.10.15 If the level difference is 80 dB or more, set the TI REF LEVEL to -50 dBm. Confirm that the TI ATT set
value is 0 dB.
4.10.16 Set the Low-Pass Filter cut-off frequency to approximately 2 GHz.
4.10.17 Set the Frequency Synthesizer output to 1.76 GHz and the output level to -20 dBm.
4.10.18 Set the TI controls as follows:
18
CENTER FREQ 1.76 GHz
SPAN 10 kHz
REF LEVEL -20 dBm
ATT 0 dB
T.O. 33K3-4-3119-1
BAND 1
4.10.19 Repeat steps 4.10.7 to 4.10.9.
4.10.20 If the level difference is 100 dB or more, set the TI REF LEVEL to -50 dBm. Confirm that the TI ATT set value is 0 dB. Set Frequency Synthesizer OUTPUT to OFF and disconnect the Low-Pass Filter from the test set­up.
4.11 RESOLUTION BANDWIDTH SWITCHING CALIBRATION:
4.11.1 Connect the Frequency Synthesizer to the TI RF INPUT.
4.11.2 Connect the TI 10 MHz REF OUT to the Frequency Synthesizer REF IN.
4.11.3 Press the TI (PRESET) key.
4.11.4 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait until the CALIBRATING message has disappeared.
4.11.5 Set the Frequency Synthesizer output to 100 MHz and the output level to 0 dBm.
4.11.6 Set the TI controls as follows:
CENTER FREQ 100 MHz
-
SPAN 15 kHz
REF LEVEL 0 dBm
RBW 3 kHz
4.11.7 Press the TI Peak (→CF) key to move the signal spectrum peak to the center.
4.11.8 Press the TI (Marker) and (F2) keys in that order to set the marker to ∆ marker. This sets the TI reference.
4.11.9 Set the TI RBW and SPAN to first settings listed in Table 10.
4.11.10 Press the TI (Peak Search) key to conduct peak search and move the current marker to the peak point of the signal spectrum.
4.11.11 Read the ∆ marker level value. This value must be within the corresponding limits of Table 10.
4.11.12 Repeat steps 4.11.9 through 4.11.11 for the remaining values listed in Table 10.
19
T.O. 33K3-4-3119-1
Table 10.
RBW Span Limits
10 Hz 100 Hz ± 0.3 dB 30 Hz 200 Hz ± 0.3 dB 100 Hz 1 kHz ± 0.3 dB 300 Hz 1.5 kHz ± 0.3 dB 1 kHz 5 kHz ± 0.3 dB
3 kHz 15 kHz Reference 10 kHz 50 kHz ± 0.3 dB 30 kHz 150 kHz ± 0.3 dB 100 kHz 500 kHz ± 0.3 dB 300 kHz 1.5 MHz ± 0.3 dB 1 MHz 5 MHz ± 0.3 dB 3 MHz 10 MHz ± 0.3 dB
4.11.13 Set outputs to zero.
4.12 LOG/LIN SWITCHING CALIBRATION:
4.12.1 Press the TI (PRESET) key.
4.12.2 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait until the CALIBRATING message has disappeared.
4.12.3 Set the TI as follows:
CENTER FREQ 100 MHz
SPAN 200 kHz
REF LEVEL -10 dBm
4.12.4 Set the Frequency Synthesizer to 100 MHz at -10 dBm.
20
T.O. 33K3-4-3119-1
4.12.5 Press the TI Peak (→CF) key to move the signal spectrum peak to the center.
4.12.6 Read the marker level value and adjust the Frequency Synthesizer output level until this value is -10 dBm ± 0.1 dB.
4.12.7 Press TI (AMPLITUDE) and (F4) keys in this order to switch the scale to linear (LIN).
4.12.8 Read the marker level value. This value must be between 68.3 mV and 73.2 mV.
4.12.9 Set outputs to zero and disconnect equipment.
4.13 INPUT ATTENUATOR SWITCHING CALIBRATION:
4.13.1 Connect the TI 10 MHz REF OUT to the Synthesized Level Generator REF IN.
4.13.2 Connect the Synthesized Level Generator RF OUTPUT through the 10 dB Step Attenuator to Power Splitter input. Connect Power Splitter outputs to the TI RF INPUT and the Power Sensor/ Power Meter input.
4.13.3 Set the Synthesized Level Generator as follows:
OUTPUT FREQ 100 MHz
OUTPUT LEVEL 0 dBm
4.13.4 Press the TI (PRESET) key and set Step Attenuator to 10 dB.
4.13.5 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait until the CALIBRATING message has disappeared.
4.13.6 Set the TI as follows:
CENTER FREQ 100 MHz
SPAN 200 kHz
4.13.7 Adjust the Synthesized Level Generator output level so that the Power Meter reads -10.0 dBm.
4.13.8 Press the TI Peak (→CF) key.
4.13.9 Set the TI reference level to -10.0 dBm and TI ATT to 55 dB.
4.13.10 Read and record the marker level.
4.13.11 Set the TI REF LEVEL, TI ATT, and the Synthesized Level Generator as shown in Table 11.
4.13.12 The TI marker level value must be within ± 0.3 dB from the recorded marker level in step 4.13.10.
Table 11.
TI REF LEVEL TI ATT Synthesized Level (dBm) (dB) Output (dBm)
21
T.O. 33K3-4-3119-1
-10 55 0 (Reference)
-15 50 5
-20 45 10
Table 11. (Cont.)
TI REF LEVEL TI ATT Synthesized Level (dBm) (dB) Output (dBm)
-25 40 15
-30 35 20
-35 30 25
-40 25 30
-45 20 35
-50 15 40
-55 10 45
-60 5 50
-65 0 55
4.13.13 Set outputs to zero and disconnect equipment.
4.14 SWEEP TIME AND TIME SPAN CALIBRATION:
4.14.1 Press the TI (PRESET) key.
4.14.2 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait until the CALIBRATING message has disappeared.
4.14.3 Connect the Frequency Synthesizer RF OUTPUT to the TI RF INPUT.
4.14.4 Set the TI as follows:
CENTER FREQ 100 MHz
SPAN 100 Hz
SWEEP TIME 20 msec
22
RBW 1 MHz
VBW 1 MHz
T.O. 33K3-4-3119-1
4.14.5 Set the Frequency Synthesizer as follows:
OUTPUT FREQ 100 MHz
OUTPUT LEVEL -16 dBm
MODULATION AM (INT) 90%
MODULATION FREQ 1 kHz
4.14.6 Press the TI Peak (→REF) key.
4.14.7 Set the TI scale to LIN.
4.14.8 Press the (SINGLE) key, then wait until a single sweep execution is completed.
4.14.9 Set the TI marker zone width to 5 Hz (ZONE WIDTH = 5 Hz).
4.14.10 Move the TI marker to the left of the screen using the knob and set the zone marker on the leftmost peak of the sign wave.
4.14.11 Set the TI marker mode to ∆ (delta), move the current marker to the right using the knob. Then set the zone marker to the 18th peak from the leftmost sine wave peak on the TI CRT.
4.14.12 Read the frequency display of the ∆ marker. The SWP TIME = Setting SWP TIME X (∆ marker reading/100 Hz). The SWP TIME must be 16.2 to 19.8 msec.
4.14.13 Repeat steps 4.14.8 through 4.14.12 for the other SWP TIME settings in Table 12.
Table 12.
TI Frequency Synthesizer Limits SWP Time Modulation Frequency
20 msec 1 kHz 16.2 to 19.8 msec
200 msec 100 Hz 162 to 198 msec
2 sec 10 Hz 1.62 to 1.98 sec
20 sec 1 Hz 16.2 to 19.8 sec
200 sec 0.1 Hz 153 to 207 sec
4.14.14 Press the TI (PRESET) key.
4.14.15 Press the TI SHIFT, CAL, F1 (ALL CAL).
4.14.16 Wait until the CALIBRATING message has disappeared.
4.14.17 Set the TI as follows:
23
T.O. 33K3-4-3119-1
CENTER FREQ 100 MHz
SPAN 100 Hz
SWEEP TIME 20 msec
RBW 1 MHz
VBW 1 MHz
4.14.18 Set the Frequency Synthesizer as follows:
OUTPUT FREQ 100 MHz
OUTPUT LEVEL -16 dBm
MODULATION AM (INT) 90%
MODULATION FREQ 100 Hz
4.14.19 Press the TI Peak (→REF) key.
4.14.20 Set the TI scale to LIN.
4.14.21 Press the (SINGLE) key, then wait until a single sweep execution is completed.
4.14.22 Set the TI display mode to TIME.
4.14.23 Set the TI TIME SPAN to 100 msec.
4.14.24 Press the (SINGLE) key, then wait until a single sweep execution is completed.
4.14.25 Set the TI marker zone width to 5 Hz (ZONE WIDTH = 5 Hz).
4.14.26 Move the TI marker to the left of the screen using the knob and set the zone marker on the leftmost peak
of the sign wave.
4.14.27 Set the TI marker mode to ∆ (delta), move the current marker to the right using the knob. Then set the
zone marker to the 18th peak from the leftmost sine wave peak on the TI CRT.
4.14.28 Read the frequency display of the ∆ marker. The TIME SPAN = Setting TIME SPAN X (∆ marker
reading/100 Hz). The TIME SPAN must be within the limits of Table 13.
4.14.29 Repeat steps 4.14.21 through 4.14.28 for the other TIME SPAN settings in Table 13.
Table 13.
24
TI Frequency Synthesizer Limits Time Span Modulation Frequency
T.O. 33K3-4-3119-1
100 msec 200 Hz 89.55 to 90.45 msec
200 msec 100 Hz 179.1 to 180.9 msec
2 sec 10 Hz 1.791 to 1.809 sec
Table 13. (Cont.)
TI Frequency Synthesizer Limits Time Span Modulation Frequency
20 sec 1 Hz 17.91 to 18.09 sec
200 sec 0.1 Hz 179.1 to 180.9 sec
4.14.30 Press the TI (PRESET) key.
4.14.31 Press the TI SHIFT, CAL, F1 (ALL CAL). Wait until the CALIBRATING message has disappeared.
4.14.32 Connect the Synthesized Sweeper RF OUTPUT to the TI RF INPUT.
4.14.33 Set the TI as follows:
CENTER FREQ 1 GHz
SPAN 0 Hz
SWEEP TIME 20 msec
RBW 1 MHz
VBW 1 MHz
4.14.34 Set the Synthesized Sweeper as follows:
CW OUTPUT FREQ 1 GHz
PULSE MODULATION INT (ON) INT RATE 5 µsec INT WIDTH 0.5 µsec
RF LEVEL -20 dBm
4.14.35 Press the TI Peak (→REF) key.
4.14.36 Set the TI TIME SPAN to 50 µsec.
4.14.37 Press the (SINGLE) key, then wait until a single sweep execution is completed.
25
T.O. 33K3-4-3119-1
4.14.38 Move the TI marker to the left of the display screen using the knob and set the zone marker on the
leftmost pulse wave peak.
4.14.39 Set the TI marker mode to ∆ (delta). Then move the current marker to the right using the knob and set the
zone marker to the 9th peak from the leftmost pulse wave peak on the TI CRT.
4.14.40 Read the frequency display of the ∆ marker. The TIME SPAN must be within the limits of Table 14.
4.14.41 Repeat steps 4.14.36 through 4.14.40 for the other TIME SPAN settings in Table 14.
Table 14.
TI Synthesized Sweeper Limits Time Span Rate Width
50 µsec 2.5 µsec 25 nsec 44.775 to 45.225 µsec 500 µsec 25 µsec 50 nsec 447.75 to 452.25 µsec 5 msec 250 µsec 500 nsec 4.4775 to 4.5225 msec 50 msec 2.5 msec 5 µsec 44.775 to 45.225 msec
4.14.42 Set all Power switches to stand by or OFF.
4.14.43 Disconnect and secure all equipment.
CALIBRATION PERFORMANCE TABLE
4.1 CENTER FREQUENCY CALIBRATION:
Applied Span Limits
500 MHz 2 kHz 499.99995 to 500.00005 MHz
500 MHz 200 kHz 499.995 to 500.005 MHz
500 MHz 2 MHz 499.95 to 500.05 MHz
500 MHz 10 MHz 499.75 to 500.25 MHz
500 MHz 100 MHz 497. to 502.5 MHz
26
5 GHz 2 kHz 4.99999995 to 5.00000005 GHz
5 GHz 200 kHz 4.999995 to 5.000005 GHz
5 GHz 2 MHz 4.99995 to 5.00005 GHz
5 GHz 10 MHz 499.99995 to 5.00025 GHz
5 GHz 100 MHz 4.9975 to 5.0025 GHz
7.5 GHz 2 kHz 7.49999995 to 7.50000005 GHz
7.5 GHz 200 kHz 7.499995 to 7.500005 GHz CALIBRATION PERFORMANCE TABLE (Cont.)
4.1 CENTER FREQUENCY CALIBRATION: (Cont.)
Applied Span Limits
7.5 GHz 2 MHz 7.49995 to 7.50005 GHz
7.5 GHz 10 MHz 7.49975 to 7.50025 GHz
7.5 GHz 100 MHz 7.4975 to 7.5025 GHz
4.2 FREQUENCY SPAN CALIBRATION:
TI Center Frequency Span Limits
T.O. 33K3-4-3119-1
1 GHz 2 kHz 1.95 to 2.05 kHz
1 GHz 20 kHz 19.5 to 20 5 kHz
1 GHz 200 kHz 195 to 205 kHz
1 GHz 2 MHz 1.95 to 2.05 kHz
1 GHz 10 MHz 1.95 to 2.05 kHz
1 GHz 100 MHz 1.95 to 2.05 kHz
1 GHz 2 GHz 1.95 to 2.05 kHz
4.25 GHz 100 MHz 97.5 to 102.5 MHz
4.25 GHz 1 GHz 0.975 to 1.025 GHz
4.25 8.5 GHz 8.2875 to 8.7125 GHz
4.3 RESOLUTION BANDWIDTH AND SELECTIVITY CALIBRATION:
TI Resolution TI Frequency Recorded 3 dB Bandwidth Span Bandwidth Limits
3 MHz 10 MHz 2.4 to 3.6 MHz
1MHz 5 MHz 0.8 to 1.2 MHz
300 kHz 500 kHz 240 to 360 kHz
27
T.O. 33K3-4-3119-1
100 kHz 200 kHz 80 to 120 kHz
30 kHz 50 kHz 24 to 36 kHz
10 kHz 20 kHz 8 to 12 kHz
CALIBRATION PERFORMANCE TABLE (Cont.)
4.3 RESOLUTION BANDWIDTH AND SELECTIVITY CALIBRATION: ( Cont.)
TI Resolution TI Frequency Recorded 3 dB Bandwidth Span Bandwidth Limits
3 kHz 5 kHz 2.4 to 3.6 kHz
1 kHz 2 kHz 0.8 to 1.2 kHz
300 Hz 1 kHz 240 to 360 Hz
100 Hz 1 kHz 80 to 120 Hz
30 Hz 1 kHz 24 to 36 Hz
10 Hz 100 Hz 8 to 12 Hz
TI Resolution TI Frequency TI Video Recorded 60 dB Bandwidth Span Bandwidth Bandwidth
3 MHz 100 MHz 100 Hz
1MHz 50 MHz 100 Hz
300 kHz 20 MHz 100 Hz
100 kHz 10 MHz 100 Hz
30 kHz 200 kHz 100 Hz
10 kHz 100 kHz 100 Hz
3 kHz 20 kHz 100 Hz
1 kHz 10 kHz 10 Hz
300 Hz 2 kHz 1 Hz
100 Hz 1 kHz 1 Hz
28
30 Hz 200 Hz 1 Hz
10 Hz 100 Hz 1 Hz
CALIBRATION PERFORMANCE TABLE (Cont.)
4.4 SIDE BAND NOISE CALIBRATION:
Center Frequency Limits
2.00005 GHz ≤-105 dBc/Hz 50 kHz ≤-115 dBc/Hz 100 kHz ≤-120 dBc/Hz
4.5 FREQUENCY MEASUREMENT CALIBRATION:
Applied Resolution Limits
T.O. 33K3-4-3119-1
500 MHz 1 Hz 500 ±1 Hz 500 MHz 10 Hz 500 ±10 Hz 500 MHz 100 Hz 500 ±100 Hz 500 MHz 1 kHz 500 ±1 kHz
4.6 AMPLITUDE SCALE LINEARITY CALIBRATION:
Step Attenuator Setting (dB) Limits (dB)
0 Reference 5 ±0.3 10 ±0.3 15 ±0.3 20 ±0.3 25 ±1.0 30 ±1.0 35 ±1.0 40 ±1.0
29
T.O. 33K3-4-3119-1
45 ±1.0 50 ±1.0 55 ±1.0 60 ±1.0
CALIBRATION PERFORMANCE TABLE (Cont.)
4.6 AMPLITUDE SCALE LINEARITY CALIBRATION: (Cont.)
Step Attenuator Setting (dB) Limits (dB) 65 ±1.0 70 ±1.0 75 ±1.5 80 ±1.5 85 ±1.5 90 ±1.5
4.7 FREQUENCY RESPONSE CALIBRATION:
Band Center Frequency Limits 0 100 MHz ±0.5 dB 0 200 MHz ±0.5 dB 0 500 MHz ±0.5 dB 0 1 GHz ±0.5 dB 0 1.5 GHz ±0.5 dB
-
1
-
1
-
1
-
1
1.7 GHz ±1.0 dB 2 GHz ±1.0 dB 3 GHz ±1.0 dB 4 GHz ±1.0 dB
30
-
1
-
1
5 GHz ±1.0 dB 6 GHz ±1.0 dB
-
1
-
1
+
1
+
1
7 GHz ±1.0 dB
7.5 GHz ±1.0 dB
6.5 GHz ±1.0 dB 7 GHz ±1.0 dB
CALIBRATION PERFORMANCE TABLE (Cont.)
4.7 FREQUENCY RESPONSE CALIBRATION: (Cont.)
Band Center Frequency Limits
+
1
+
1
+
1
7.5 GHz ±1.0 dB 8 GHz ±1.0 dB
8.5 GHz ±1.0 dB
4.8 REFERENCE LEVEL CALIBRATION:
T.O. 33K3-4-3119-1
TI Reference Level Step Attenuator Setting (dBm) Setting (dB) Limits (dB)
0 0 ±0.3
-10 10 ±0.3
-20 20 ±0.3
-30 30 ±0.3
-40 40 ±0.3
-50 50 ±0.3
-60 60 ±.75
-70 70 ±.75
-80 80 ±1.5
-90 90 ±1.5
4.9 AVERAGE NOISE LEVEL CALIBRATION:
Start Frequency Stop Frequency Limits
1 MHz 1 GHz At least -135 dBc
31
T.O. 33K3-4-3119-1
1 GHz 2 GHz At least -135 dBc
1.7 GHz 7.5 GHz At least -135 dBc
7.5 GHz 8.5 GHz At least -135 dBc
CALIBRATION PERFORMANCE TABLE (Cont.)
4.10 SECOND HARMONIC CALIBRATION:
Center Frequency 2nd Harmonic
5.1 MHz At least -70 dBc
810 MHz At least -80 dBc
1.76 GHz At least -100 dBc
4.11 RESOLUTION BANDWIDTH CALIBRATION:
Resolution Bandwidth Span Limits (dB) 10 Hz 100 Hz ±0.3 30 Hz 200 Hz ±0.3 100 Hz 1 kHz ±0.3 300 Hz 1.5 kHz ±0.3 1 kHz 5 kHz ±0.3
3 kHz 15 kHz Reference 10 kHz 50 kHz ±0.3 30 kHz 150 kHz ±0.3 100 kHz 500 kHz ±0.3 300 kHz 1.5 MHz ±0.3 1 MHz 5 MHz ±0.3 3 MHz 10 MHz ±0.3
4.12 LOG/LIN SWITCHING CALIBRATION:
32
LOG LIN
-10 dBm 68.3 to 73.2 mV
4.13 INPUT ATTENUATOR SWITCHING CALIBRATION:
TI REF LEVEL ATT TI Step Attenuator Limits
-10 dBm 55 dB 0 dB Reference
-15 dBm 50 dB 5 dB ±0.3 dB
CALIBRATION PERFORMANCE TABLE (Cont.)
4.13 INPUT ATTENUATOR SWITCHING CALIBRATION: ( Cont.)
TI REF LEVEL ATT TI Step Attenuator Limits
-20 dBm 45 dB 10 dB ±0.3 dB
-25 dBm 40 dB 15 dB ±0.3 dB
-30 dBm 35 dB 20 dB ±0.3 dB
T.O. 33K3-4-3119-1
-35 dBm 30 dB 25 dB ±0.3 dB
-40 dBm 25 dB 30 dB ±0.3 dB
-45 dBm 20 dB 35 dB ±0.3 dB
-50 dBm 15 dB 40 dB ±0.3 dB
-55 dBm 10 dB 45 dB ±0.3 dB
-60 dBm 5 dB 50 d B ±0.3 dB
-65 dBm 0 dB 55 dB ±0.3 dB
4.14 SWEEP TIME AND TIME SPAN CALIBRATION:
TI SWP Time Mod Freq Limits
20 msec 1 kHz 16.2 to 19.8 msec
200 msec 100 Hz 162 to 198 msec
2 sec 10 Hz 1.62 to 1.98 sec
20 sec 1 Hz 16.2 to 19.8 sec
200 sec 0.1 Hz 153 to 207 sec
TI Span Time Mod Freq Limits
33
T.O. 33K3-4-3119-1
100 msec 200 Hz 89.55 to 90.45 msec
200 msec 100 Hz 179.1 to 180.9 msec
2 sec 10 Hz 1.791 to 1.809 sec
20 sec 1 Hz 17.91 to 18.09 sec
200 sec 0.1 Hz 179.1 to 180.9 sec
CALIBRATION PERFORMANCE TABLE (Cont.)
4.14 SWEEP TIME AND TIME SPAN CALIBRATION: (Cont.)
TI TIME SPAN
Synthesized Sweeper
Span Rate Width Limits 50 µsec 2.5 µsec 25 nsec 44.775 to 45.225 µsec 500 µsec 25 µsec 50 nsec 447.75 to 452.25 µsec 5 msec 250 µsec 500 nsec 4.4775 to 4.5225 msec 50 msec 2.5 msec 5 µsec 44.775 to 45.225 msec
34
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
