For Measuring Signals of Digital Mobile Communication Systems in North America, Europe and Japan
The MG3670B/C, MG3671A/B and MG3672A are digital modulation
signal generators equipped with a high-performance quadrature
modulator. They output the signals needed to develop, test, and
evaluate digital mobile communications equipment and related devices with expansion units.
The MG3670B/C operates from 300 kHz to 2.25 MHz; the
MG3671A/B and MG3672A operate 300 to 2.75 MHz. Both provide
a stable and precise output as well as spectrum purity up to +13
dBm, even with modulation. In addition to testing receiver sensitivity
and excess input, they can be used for testing IF stage performance
and for evaluating device quality. A CMOS-level mode is provided for
I/Q signal input. The input frequency band covers the CDMA spread
spectrum band, expanding the range of applications.
The MG3670C/3671B/3672A can be expanded by rear panel extension connectors to use for auxiliary signal output functions special
to communication system. MG3670B/C, MG3671A/B and MG3672A
can be used in combination with up to eight modulation units and a
burst function unit simultaneously.
The MG0301C/0302A/0305A/0307A/0311A modulation units have
a continuous data generator capable of generating arbitrarily-programmable data signals and ITU-T specification PN9/15 stage
PRBS signals. They also have band-limiting filters and can output
I/Q baseband signals.
The MG0303A Burst Function Unit uses the frame and slot configuration stipulated by various communication systems and has a
modulation pattern generator function and a function for ramp control
of carrier burst signals. It can also handle data editing and scrambling.
The MG0310A Modulation Unit generates SS + QPSK/OQPSK
modulated (1.2288 Mcps) I/Q baseband signals, supporting the
CDMA system (TIA/EIA/IS-95) used in US Digital Cellular Systems
and the US Personal Communications Service (PCS).
Anritsu-developed DSP and ASIC technology is used in the
MG0310A to achieve superior waveform quality factor (ρ) and spurious emission characteristics. Channel multiplexed signals are supported for both forward and reverse links. With two MG0310A units
mounted in the MG3670C/3671B/3672A, all the test signals required
to conform to TIA/EIA/IS-95, -97, and -98 can be generated.
Simultaneous outputs from the rear extension connectors using long
and short codes, etc., support a wide range of applications including
RF related tests, IF stage performance tests, and device and module quality evaluation. (Option 25 is required to install the MG0310A
in the MG3670B/3671A. The auxiliary signal output function is not installed, so long/short codes cannot be output.)
The MG0312A QPSK Modulation Unit generates QPSK/OQPSK
modulated I/Q baseband signals at 8 high-speed bit rates between
500 kbps and 2.4576 Mbps. Built-in modulation data includes PN7/
PN9/PN15/PN23 pseudorandom patterns. Use over a wide range is
supported by multiple baseband filters and the Phase Encoding function, which allows modulation data to be voluntarily phase mapped
onto a constellation. At the 2.4576 Mbps rate, the evaluation of transmission section devices and modules can be performed such as RF
power amplifier for CDMA mobile stations.
The MG0314A Modulation Unit generates DS + QPSK modulated
(4.096/1.024 Mcps) I/Q baseband signals, supporting the W-CDMA
system specification. The various test signals required for W-CDMA
system experimentation can be generated by mounting the
MG0314A unit (it shares two slots) in the MG3672A.
DIGITAL MODULATION SIGNAL GENERATOR
MG3670B/C, MG3671A/B, MG3672A
300 kHz to 2.25/2.75 GHz
Communication systems
Units
PHS, PDC, PDC_H, MG0301C
NADC, TFTS π/4 DQPSK Modulation Unit
GSM, PCN (DCS1800),
MG0302A
CT2
GMSK Modulation Unit
DECT
MG0305A MG0303B
GFSK Modulation Unit Burst Function Unit
PACS, WCPE, PHS
MG0307A
π/4 DQPSK Modulation Unit
TETRA
MG0311A
π/4 DQPSK Modulation Unit
IS-95
MG0310A CDMA Modulation Unit
MG0312A QPSK Modulation Unit
W-CDMA
*
1
MG0314A W-CDMA Modulation Unit (only MG3672A)
*
1: Corresponds to the specification for W-CDMA system experimentation
Features
•
Compatible with communication system measurement signals of
Japan, North America and Europe
• High modulation accuracy (≤1.8% rms vector error)
•
Outputs modulation signals suited to each communication system
•
Internal pattern generator with data-editing and scrambling functions
• Outputs IS-95 channel multiplex signal
• Outputs W-CDMA channel multiplexes signal (only for MG3672A)
• Wide range (30 MHz, 3 dB) I/Q Input (only for MG3672A)
For product ordering information, see pages 4-7. www.anritsu.com 291
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
6
Basic performance
•
I/Q input supporting wide range of applications (only for
MG3672A)
The MG3672A is equipped with wide-band I/Q input from DC to 30
MHz (3 dB) so that wide-band quadrature modulation can be performed. This ensures that the MG3672A will remain fully compatible
with communication systems for which band expansion is planned in
the future.
Output level frequency characteristics
(50 Ω/0.5 Vrms mode)
30 k 100 k 300 k 1 M 10 M3 M
0
–1
–2
–3
Level (dB)
I/Q signal input frequency (Hz)
Frequency response for I/Q external modulation (typical values)
• I/Q signal I/O over broad frequency range (only for MG3670B/C,
MG3671A/B)
A quadrature modulator is built in, and external I/Q signals can be input to enable use with a variety of digital modulation modes, including QPSK, 8PSK, and M16QAM. The modulation band for I/Q input
signals is broad, covering the CDMA spread spectrum bandwidth.
Further, by adding an expansion unit, I/Q signal output can be ob-
tained from the internal data generator. Either 50 Ω or CMOS-level
compatibility can be selected for I/Q signals. Functions for adjusting
the level balance, offset, and phase are also provided for greater utility in evaluating modulators/demodulators and other devices.
Frequency response for I/Q external modulation (typical values)
• Excellent spectral purity
The SSB phase noise characteristic is an excellent –120 dBc/Hz or
less (100 kHz offset). The adjacent channel power characteristic excels as the interference signal source during modulation.
Output level accuracy at 1.9 GHz
• High modulation accuracy
A vector error of less than 1.8%rms is assured for output levels up to
+5 dBm over the entire operating frequency range. This high modulation accuracy is also achieved when the expansion units are used.
Even when the MG0301C and MG0303B units are installed and π/4
DQPSK modulation burst signals are generated, the vector error is
less than 1.8%rms. The MG3670B/C, MG3671A/B and MG3672A
enable measurement and quality evaluation of receivers and other
devices with more than adequate precision.
SSB phase noise at 1.9 GHz
• Large output level
Through use of new AGC circuitry, the MG3670B/C, MG3671A/B,
and MG3672A produce a highly precise output at levels down to
–143 dBm with stable frequency characteristics, not only for output
of unmodulated signals but also with π/4 DQPSK modulation accompanied by amplitude fluctuations and when outputting burst signals.
The MG3670B/C, MG3671A/B and MG3672A can generate a high
output level of up to +13 dBm over a broad range of frequencies, so
amplifiers are not needed even when testing receivers for excess
input and in testing other devices.
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
292 www.anritsu.com For product ordering information, see pages 4-7.
Pattern edit display
CDMA
MG0310A has various TIA/EIA/IS-95 frame formats and encoder
functions built-in for each channel type. For example, frame format
of signalling, communication, and Multiplex Option 1 are provided to
support Rate Set 1 (1200 ... 9600 bps) and Rate Set 2 (1800 ...
14400 bps) for the Traffic Channel. In combination with the Burst
Randomizer function, this allows system support at all rates, even for
reverse links. For internal data you can select either a PN7, 9, or 15
pseudo-random pattern, or a user settable 16-bit data repeating pattern, all fully editable. Operation can be from internal RAM user-definable sequence data or from external serial data.
Pattern setting display
W-CDMA (only for MG3672A)
MG0314A conforms to physical channel frame formats such as
Perch 1, Perch 2, DTCH, and Control, all of which correspond to the
specifications for W-CDMA system experimentation. Perch 1 enables user setting of the pilot symbol for synchronization, level, and
short code for long code masked symbol. DTCH enables setting of
the TPC Symbol at an interval of 16 time slots for each channel,
demonstrating its ability to handle many different situations and permitting greater user selection. Moreover, since the unit incorporates
the coding function for the frame formats of BCCH, FACH-L, DTCH,
and ACCH logical channels, CRC, convolution, and interleave conforming to these channels, it can be used for decoding evaluation,
etc. Other functions include the pilot symbol edit function, as well as
DTCH and ACCH transmission-off function.
Slot rise time waveform
Functions and performances with expansion unit
•
Frame structure and data
TDMA
The MG0303B incorporates TDMA frames for various kinds of communication systems, as well as modulation patterns for each time
slot. Modulation patterns for device evaluation and for up/down
communication channels are provided and are output at the timing
required by the system. Hence the MG3670B/C, MG3671A/B, and
MG3672A can generate the burst signals needed to measure various
digital communication systems.
Time slots specified for different communication systems can be
selected freely. There is considerable freedom in choosing the modulation pattern within slots; either a PN9 or PN15 TCH segment can
be chosen, and part of the data outside the TCH segment can be edited.
The pattern memory function can be used to store and recall patterns.
A data scrambling function is provided as standard, and any initial
code can be set permitting more sophisticated evaluations and diagnostics using the MG3670B/C, MG3671A/B and MG3672A as a supposed base station and mobile equipment.
The internal modulation pattern can also be driven by an external
clock, so margin tests can be conducted by varying the clock pulse.
Pattern setting display
• Excellent leakage power characteristics during carrier-off
The rising and falling edges of burst signals have a gentle waveform
with a duration equivalent to two symbols, and the leakage power
during carrier-off characteristics are excellent.
PHS
For product ordering information, see pages 4-7. www.anritsu.com 293
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
6
Frequency range 300 kHz to 2250 MHz (MG3670B/C), 300 kHz to 2750 MHz (MG3671A/B and MG3672A)
Accuracy Depends on installed reference oscillator
*
1
Frequency: 10 MHz
Carrier Internal reference Start-up characteristics: ≤1 x 10
–7
/day (after 30 min. warm-up), ≤5 x 10–8/day (after 60 min. warm-up)
frequency oscillator Aging rate: ≤2 x 10
–8
/day (after 24 h warm-up)
Temperature characteristics: ≤±5 x 10
–8
(0˚ to 50˚C)
External reference
input
10 MHz or 13 MHz (±10 ppm), 2 to 5 Vp-p, BNC connector (rear panel)
Reference output 10 MHz, 2 to 5 Vp-p, BNC connector (rear panel)
Level range
*
2
–143 to +13 dBm (resolution: 0.1 dB)
Frequency response ≤±1 dB (at 0 dBm output)
Output level/frequency ≤1000 MHz >1000 MHz
Level accuracy
*
2
–33 to +13 dBm ±1 dB ±2 dB
–123 to –33.1 dBm ±1.5 dB ±2 dB
Output –136 to –123.1 dBm ±3 dB ±4 dB
Impedance 50 Ω, N-type connector
Continuously Continuously variable output over 20 dB range (+8 to –12 dB) in 0.1 dB steps within upper and lower limits of any
variable level
*
2
output level
Level unit dBm, dBµ, µV, mV, V (dBµ, µV, mV, V selected terminate/open voltage display)
Interference ≤1 µV *Measured 25 mm from cabinet (except rear panel) with two-turn 25 mm diameter loop antenna, terminated
radiation with 50 Ω load, ≤+5 dBm output, CW
Spurious ≤–65 dBc (≥100 kHz offset, ≤±100 MHz bandwidth), ≤–50 dBc (≥100 kHz offset, full band),
Signal purity
(at ≤+5 dBm output) ≤–40 dBc [≥2.65 GHz, spurious at 5.4–Fout (carrier frequency) GHz], ≤–30 dBc (harmonics)
SSB phase noise ≤–120 dBc/Hz (100 kHz offset, CW)
Specifications (refer to the MG3670B/C, MG3671A/B, and MG3672A data sheet for more details)
• MG3670B/C, MG3671A/B, and MG3672A Digital Modulation Signal Generator
Continued on next page
• Superior spurious emission characteristics
Spurious emissions are guaranteed to be lower than –60 dBc (±900
kHz detuning, 30 kHz bandwidth) and –70 dBc (±1.98 MHz detuning,
30 kHz bandwidth) with MG0310A installed in the MG3670C/3671B/
3672A mainframe (for output level: 0dBm, baseband filter: SPEC 2).
Using this baseband filter gives a waveform quality factor (ρ) of
0.999 or better. This filter conforms to IS-95, providing 3-step switching. Selecting the best step for each evaluation item gives even higher performance. This excellent basic performance in a standard digital modulation signal generator makes it the ideal choice for the development and manufacture of digital mobile wireless equipment and
related devices/modules.
Modulation spectrum
(with MG0310A installed in the MG3670C/3671B/3672A)
• Excellent adjacent channel power ratio characteristics (only
for MG3672A)
Mounting the MG0314A on the MG3672A and setting the filter mode
to ACP (Adjacent Channel Power) yields an adjacent channel power ratio of –63 dBc (specification value) and –65 dBc (typ.) (with 0
dBm output, 1 channel output, 18˚ to 30˚C, 1.8 to 2.2 GHz). Moreover,
setting the filter mode to EVM (Error Vector Magnitude) guarantees
a modulation accuracy not exceeding EVM 5.0% (rms). The three filters are provided, enabling selection of performance according to the
evaluation items.
The baseband filter can be set in 0.05 steps, (α = 0.2 to 0.5), for
RNYQ and NYQ, as well as to α = 0.22 for RNYQ for W-CDMA system experimentation. The superior basic performance of the standard digital modulation signal generator permits development and
manufacturing of digital mobile radio equipment and related devices
and modules.
Adjacent channel power ratio at 5 MHz
(Optimizing the distortion of MS2602A Spectrum
Analyzer with MG0314A mounted into MG3672A)
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
294 www.anritsu.com For product ordering information, see pages 4-7.
Internal modulation Depends on installed modulation unit (MG0301C/0302A/0305A/0307A/0310A/0311A/0312A/0314A)
For MG3670B/C, MG3671A/B
Any modulation using I/Q input signal
Input frequency: DC to 1.2 MHz
*
3
Input level: √I2±Q2≤0.5 Vrms, BNC connector *I/Q ≤1.5 Vp-p (50 Ω), I/Q ≤10% to 100% of 1.5 Vp-p (CMOS)
Digital External
Vector error: ≤1.8%rms (I/Q input level: 1 Vrms/50 Ω, at ≤+5 dBm output)
modulation modulation For MG3672A
50 Ω input
Input frequency: DC to 30 MHz (BW: 3 dB, 18˚ to 30˚C), Input level:
√
I2±Q2≤1.0 Vrms, I/Q ≤1.5 Vp-p
CMOS input
Input frequency: DC to 1.2 MHz, Input level:
√
I2±Q2≤1.0 Vrms, I/Q ≤1.5 Vp-p
I/Q output Outputs I/Q signal at internal modulation (MG0301C/0302A/0305A/0307A/0310A/0311A/0312A/0314A installed)
Pulse
Input TTL level, BNC connector, polarity selectable
modulation
On/off ratio ≥40 dB (at ≥0 dBm output)
Transition time ≤2 µs, minimum pulse width: 10 µs
Memory
Frequency memory 1000 carrier frequencies (save and recall)
function
Parameter memory 100 panel settings (save and recall)
Relative display Carrier frequency, output level
I/Q signal adjustment
Variable offset, balance, phase (only output) of I/Q input/output signal (DC to 1.2 MHz)
Other Backup Last settings stored at power-off
functions
Reverse power
protection
Maximum reverse input power: 50 W (<1000 MHz), 25 W (≥1000 MHz), ±50 Vdc
GPIB
All functions except power switch and panel lock switch controlled
Interface function: SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT0, C0, E2
Operating temperature 0˚ to 50˚C
Power 100 to 120/200 to 240 Vac (switchable), 47.5 to 63 Hz, ≤550 VA
Dimensions and mass (426±5) W x (221.5±4) H x (451±5) D mm, ≤27 kg
EMC
*
4
EN55011 (1991, Group 1, Class A), EN50082-1 (1992), Harmonic current emissions EN61000-3-2 (1995)
Safety EN61010-1: 1993 (Installation Category ΙΙ, Pollution Degree ΙΙ )
*
1: Internal reference oscillator accuracy: 2 x 10–8/day (23˚ ±5˚C), calibrated after 24 h operation
*
2: Depended on the specifications of each units when MG0310A or MG0314A unit are installed.
*
3: Refer to the “Frequency response for I/Q external modulation (typical value)” on page 262 for the input frequency range. Typical values are given for refer-
ence only to assist in the use of this instrument, and are not guaranteed specifications.
*
4: Electromagnetic compatibility
MG0301C π/4 DQPSK Modulation Unit (incorporated in the MG3670B/C, MG3671A/B and MG3672A)
Applicable
communication system
PDC, PDC_H, PHS, NADC, TFTS
Modulation system π/4 DQPSK
Vector error I/Q signal: ≤1.5%rms (at 50 Ω output), RF signal: ≤1.8%rms (at ≤+5 dBm output)
Internal modulation Pseudorandom pattern: PN15, PN9
data Free 4-bit repetition pattern (ex: 1010, 1111)
DATA CLOCK: Covering ±5% of bit rate
External modulation DATA: Digital data synchronized with DATA CLOCK
data SYMBOL CLOCK: Clock specified by DATA synchronized with DATA CLOCK
TTL level, BNC connector, polarity selectable
Selectable 50 Ω or CMOS (600 Ω), BNC connector
50 Ω setting [modulation data: 0000 (TFTS: 1111)]: 1 Vp-p ±2% (MG3670A/B/C, MG3671A/B), 2 Vp-p ±2% (MG3672A)
CMOS setting [modulation data: 0000 (TFTS: 1111)]
I/Q signal output
Variable in 10% steps over range of 10% to 100% of 1 Vp-p ±2%, variable offset voltage: 0 to 4 V in 1 mV steps (MG3670A/B/C,
MG3671A/B)
Variable in 10% steps over range of 10% to 100% of 2 Vp-p ±2%, variable offset voltage: 0 to 4 V in 1 mV steps (MG3672A)
Carrier frequency range:
300 kHz to 2250 MHz
*1 (incorporated in the MG3670B/C), 300 kHz to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
PDC, PDC_H
Bit rate: 42 kbps
Baseband filter: Root Nyquist (α = 0.5), Nyquist (α = 0.5)
Carrier frequency range:
1 to 2250 MHz
*1 (incorporated in the MG3670B/C), 1 to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
PHS Bit rate: 384 kbps
Baseband filter: Root Nyquist (α = 0.5), Nyquist (α = 0.5)
Adjacent channel power ratio: ≤–74 dB (600/900 kHz offset, ±96 kHz band, ≥10 MHz)
*
2
Carrier frequency range:
300 kHz to 2250 MHz
*1 (incorporated in the MG3670B/C), 300 kHz to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
NADC
Bit rate: 48.6 kbps
Baseband filter: Root Nyquist (α = 0.35), Nyquist (α = 0.35)
Carrier frequency range:
300 kHz to 2250 MHz
*1 (incorporated in the MG3670B/C), 300 kHz to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
TFTS
Bit rate: 44.2 kbps
Baseband filter: Root Nyquist (α = 0.4), Nyquist (α = 0.4)
*
1: The upper frequency is limited by the specifications of the main frame in which this unit is installed.
*
2: Applicable when this unit is installed in MG3670B/C, MG3671A/B and MG3672A. Not applicable when this unit is installed in MG3670A.
For product ordering information, see pages 4-7. www.anritsu.com 295
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
6
Applicable communication system
GSM, DCS1800 (PCN), CT2
Modulation system GMSK
I/Q signal: ≤1˚ rms, ≤3˚ peak (at 1 Vrms/50 Ω output, 25˚ ±5˚C, after 30 min. warm-up)
Phase error
≤2˚ rms, ≤5˚ peak (at 1 Vrms/50 Ω output)
RF signal: ≤1˚ rms, ≤3˚ peak (at ≤+5 dBm output, 25˚ ±5˚C, after 30 min. warm-up)
≤2˚ rms, ≤5˚ peak (at ≤+5 dBm output)
Internal modulation data Pseudorandom pattern: PN15, PN9, free 4-bit repetition pattern (ex: 1010, 1111)
DATA CLOCK: Covering ±5% of bit rate, DATA: Digital data synchronized with DATA CLOCK
External modulation data
*
TTL level, BNC connector, polarity selectable
Selectable 50 Ω or CMOS (600 Ω), BNC connector
50 Ω setting (modulation data: 0000): 1 Vp-p ±2% (MG3670A/B/C, MG3671A/B), 2 Vp-p ±2% (MG3672A)
CMOS setting (modulation data: 0000)
I/Q signal output
Variable in 10% steps over range of 10% to 100% of 1 Vp-p ±2%, variable offset voltage: 0 to 4 V in 1 mV steps
(MG3670A/B/C, MG3671A/B), Variable in 10% steps over range of 10% to 100% of 2 Vp-p ±2%, variable offset voltage:
0 to 4 V in 1 mV steps (MG3672A)
Carrier wave frequency range:
1 to 2250 MHz
*1 (incorporated in the MG3670B/C), 1 to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
GSM/PCN (DCS1800)
Bit rate: 270.833 kbps
Baseband filter: Gaussian filter BbT = 0.3
Carrier wave frequency range: 300 kHz to 2250 MHz
*1(incorporated in the MG3670B/C),
CT2
300 kHz to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
Bit rate: 72 kbps
Baseband filter: Gaussian filter BbT = 0.5
*
1: The upper frequency is limited by the specifications of the mainframe in which this unit is installed.
MG0305A GFSK Modulation Unit (incorporated in the MG3670B/C, MG3671A/B and MG3672A)
MG0302A GMSK Modulation Unit (incorporated in the MG3670B/C, MG3671A/B and MG3672A)
Applicable communication system
DECT
Modulation system GFSK
Vector error I/Q signal: ≤12 kHz (at 1 Vrms/50 Ω output), RF signal: ≤12 kHz (at ≤+5 dBm output, modulation data: FFFF)
Internal modulation data Pseudo-random pattern: PN15/PN9, Free 16-bit repetition pattern (ex: 0F0F, 00FF)
DATA CLOCK: Covering ±5% of bit rate, DATA: Digital data synchronized with DATA CLOCK
External modulation data
*
TTL level, BNC connector, polarity selectable
Selectable 50 Ω or CMOS (600 Ω), BNC connector
50 Ω setting (modulation data: 0000): 1 Vp-p ±6% (MG3670A/B/C, MG3671A/B), 2 Vp-p ±6% (MG3672A)
CMOS setting (modulation data: 0000)
I/Q signal output
Variable in 10% steps over range of 10% to 100% of 1 Vp-p ±6%, variable offset voltage: 0 to 4 V in 1 mV steps
(MG3670A/B/C, MG3671A/B), Variable in 10% steps over range of 10% to 100% of 2 Vp-p ±6%, variable offset voltage:
0 to 4 V in 1 mV steps (MG3672A)
Phase polarity Polarity reversal of frequency deviation during modulation is possible.
Carrier frequency range:
5 to 2250 MHz
*1 (incorporated in the MG3670B/C), 5 to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
DECT
Bit rate: 1152 kbps
Deviation ratio: 70% (202 kHz), 90% (259 kHz), 100% (288 kHz), 140% (403 kHz), at BbT=0.5
Baseband filter: Gaussian filter BbT = 0.4, 0.5, 0.6, at deviation ratio = 100%
*
1: The upper frequency is limited by the specifications of the mainframe in which this unit is installed.
MG0307A π/4 DQPSK Modulation Unit (incorporated in the MG3670B/C, MG3671A/B and MG3672A)
Applicable communication system
PACS, WCPE, PHS
Modulation system π/4 DQPSK
Vector error I/Q signal: ≤1.5%rms (at 1 Vrms/50 Ω output), RF signal: ≤1.8%rms (at ≤+5 dBm output)
Pseudo-random pattern: PN15, PN9
Internal data mode Free 16-bit repetition pattern (ex: 0F0F, 00FF): WCPE
Free 4-bit repetition pattern (ex: 0101, 0011): PACS, PHS
DATA CLOCK: Covering ±5% of bit rate
External data mode
DATA: Digital data synchronized with DATA CLOCK
SYMBOL CLOCK: Clock specified by DATA synchronized with DATA CLOCK
TTL level, BNC connector, polarity selectable
Selectable 50 Ω or CMOS (600 Ω), BNC connector
50 Ω setting (modulation data: 0000): 1 Vp-p ±5% (MG3670A/B/C, MG3671A/B), 2 Vp-p ±5% (MG3672A)
I/Q signal output
CMOS setting (modulation data: 0000)
Variable in 10% steps over range of 10% to 100% of 1 Vp-p ±5%, variable offset voltage: 0 to 4 V in 1 mV steps
(MG3670A/B/C, MG3671A/B), Variable in 10% steps over range of 10% to 100% of 2 Vp-p ±5%, variable offset voltage:
0 to 4 V in 1 mV steps (MG3672A)
Phase encode function Invertible phase polarity at modulation
Carrier frequency range:
1 to 2250 MHz
*
1
(incorporated in the MG3670B/C), 1 to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
PACS
Bit rate: 384 kbps
Baseband filter: Root Nyquist (α = 0.5), Nyquist (α = 0.5)
Carrier frequency range:
5 to 2250 MHz
*1 (incorporated in the MG3670B/C), 5 to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
WCPE
Bit rate: 1152 kbps
Baseband filter: Root Nyquist (α = 0.5), Nyquist (α = 0.5)
Continued on next page
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
296 www.anritsu.com For product ordering information, see pages 4-7.
PDC, PDC_H, PHS, NADC, TFTS (with MG0301C)
GSM, PCN (DCS1800), CT2 (with MG0302A)
Applicable communication system
DECT (with MG0305A)
PACS, WCPE, PHS (with MG0307A)
TETRA (with MG0311A)
Internal data mode TDMA framing specified for each system; modulation in each time slot using any internal modulation data
Pseudo-random pattern: PN15/PN9
*1 (for device)
Internal data
Specified pattern based on communication channel format specified for each system:
Up/down communication channel, VOX signal control
Modulation
TCH section consists of pseudo-random pattern PN15/PN9
*
1
signal
DATA CLOCK: Covering ±5% of bit rate
DATA: Digital data synchronized with DATA CLOCK
External data mode SYMBOL CLOCK: Clock specified by DATA synchronized with DATA CLOCK
BURST GATE: Burst signal synchronized with DATA CLOCK (on: ≥14 symbols, off: ≥8 symbols)
TTL level, BNC connector, polarity selectable
Burst wave output synchronized with trigger input signal of burst repetition rate (frame cycle) at internal modulation
Burst trigger input
Input period: ≤burst repetition rate ±1 symbol [PDC, PDC_H, PHS, NADC, GSM, PCN (DCS1800), CT2, DECT, PACS,
WCPE, TETRA], ≤burst repetition rate ±1/2 symbol (TFTS)
TTL level, BNC connector (rear panel), polarity selectable
Burst trigger output
Outputs 1-symbol wide pulse at same cycle as burst waveform output at internal modulation
TTL level, BNC connector (rear panel), polarity selectable
Following outputs selectable at internal modulation
Control PN CLOCK: Data clock corresponding to pseudo-random pattern part
signal Pattern sync output PN GATE: Gate signal corresponding to pseudo-random pattern part
output RF GATE: Signal for controlling pulse modulator in accordance with burst signal output
TTL level, BNC connector (rear panel)
Burst gate output
Outputs gate signal corresponding to burst waveform output at internal modulation
TTL level, BNC connector (rear panel), polarity selectable
Burst on/off ratio
≥80 dB (+5 dBm output, PDC, PDC_H, NADC, CT2, TFTS, TETRA), ≥75 dB (+5 dBm output, PHS, GSM, PCN, PACS),
RF output
≥70 dB (+5 dBm output, DECT, WCPE)
Rise/fall time Equivalent to 2 symbols
Memory (pattern memory) Max. 100 patterns/system (save and recall of internal modulation pattern data)
Burst repetition rate 20 ms
NADC
Slot configuration For device, up/down communication channel
Output slot select On/off selectable for any slots of slot 0 to slot 2 (excluding all slots off)
Edit function SYNC/SACCH/CDVCC: Any data, DATA: PN9, PN15
*1selectable
Carrier frequency range:
1 to 2250 MHz
*1 (incorporated in the MG3670B/C), 1 to 2750 MHz (incorporated in the MG3671A/B and MG3672A)
PHS Bit rate: 384 kbps
Baseband filter: Root Nyquist (α = 0.5), Nyquist (α = 0.5)
Adjacent channel power ratio: ≤–74 dB (600/900 kHz offset, ±96 kHz band, ≥10 MHz)
*
2
*
1: The upper frequency is limited by the specifications of the mainframe in which this unit is installed.
*
2: Applicable when this unit is installed in MG3670B/C, MG3671A/B and MG3672A. Not applicable when this unit is installed in MG3670A.
MG0311A π/4 DQPSK Modulation Unit (incorporated in MG3670B/C, MG3671A/B and MG3672A)
Applicable communication system
TETRA
Modulation system π/4 DQPSK
Vector error I/Q signal: ≤1.5%rms (at 50 Ω output); RF signal: ≤1.8%rms (at ≤+5 dBm output)
Internal modulation data Pseudo-random pattern: PN15/PN9, Free 4-bit repetition pattern (ex: 0101, 0011)
DATA CLOCK: Covering ±5% of bit rate
External modulation data
DATA: Digital data synchronized with DATA CLOCK
SYMBOL CLOCK: Clock specified by DATA synchronized with DATA CLOCK
*
TTL level, BNC connector, polarity selectable
Selectable 50 Ω or CMOS (600 Ω), BNC connector
50 Ω setting (modulation data: 0000): 1 Vp-p ±5% (MG3670A/B/C, MG3671A/B), 2 Vp-p ±5% (MG3672A)
I/Q signal output
CMOS setting (modulation data: 0000)
Variable in 10% steps over range of 10% to 100% of 1 Vp-p ±5%, variable offset voltage: 0 to 4 V in 1 mV steps
(MG3670A/B/C, MG3671A/B), Variable in 10% steps over range of 10% to 100% of 2 Vp-p ±5%, variable offset voltage:
0 to 4 V in 1 mV steps (MG3672A)
Phase encode function Invertible phase change polarity at modulation
Carrier frequency range:
300 kHz to 2250 MHz*1 (incorporated in MG3670B/C), 300 kHz to 2750 MHz (incorporated in MG3671A/B and MG3672A)
TETRA Bit rate: 36 kbps
Baseband filter: Root Nyquist (α = 0.35), Nyquist (α = 0.35)
Adjacent channel leakage power ratio
*
2
: ≤–48 dB (25 kHz offset, ±9 kHz band), ≤–67 dB (50 kHz offset, ±9 kHz band)
*
1: The upper frequency is limited by the specifications of the mainframe in which this unit is installed.
*
2: Also applicable when this unit is installed in the MG3670A with option 11 (low adjustment channel leakage power). This unit can not be installed in the
MG3670A without option 11.
MG0303B Burst Function Unit (incorporated in the MG3670B/C, MG3671A/B and MG3672A)
Continued on next page
For product ordering information, see pages 4-7. www.anritsu.com 297
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
6
Burst repetition rate 20 ms (PPC), 40 ms (PDC_H)
PDC
Slot configuration For device, up/down communication channel, up VOX control
PDC_H
Output slot select On/off selectable for any slots of slot 0 to slot 2 (PDC)/slot 5 (PDC_H)
*
excluding all slots off
Edit function SW/CC/SACCH: Any data, TCH: PN9, PN15
*1selectable
Scramble function TCH + SF + SACCH scramble on/off, any scramble code setting
Burst repetition rate 5 ms
Slot configuration For device, up/down communication channel, VOX control
Output slot select On/off selectable for any slots of slot 1 to slot 4 (excluding all slots off)
PHS Edit function UW/SA: Any data, TCH: PN9, PN15
*1selectable
Scramble function TCH + CRC, scramble and secret scramble on/off, any scramble code setting
Adjacent channel
power leakage ratio
≤–74 dB (600/900 kHz offset, ±96 kHz band, ≥10 MHz)
*
2
Burst repetition rate 80 ms
TFTS
Slot configuration For device, up/down communication channel
Output slot select On/off selectable for any slots of slot 0 to slot 16 (Device/UP TCH: Slots 16 is off at all time, excluding all slots off)
Edit function S: Any data, DATA: PN9, PN15
*1selectable
Burst repetition rate 4.615 ms
GSM, PCN
Slot configuration For device, normal burst (communication channel)
(DCS1800)
Output slot select On/off selectable for any slots of slot 0 to slot 7 (excluding all slots off)
Edit function TS: Any data, E: PN9, PN15
*1selectable
Burst repetition rate 2 ms
CT2
Slot configuration Up/down communication channel (MUX 1.2, MUX 1.4, MUX 2)
Edit function D, B, Da, Db, CHM/SYNC data selectable
Scramble function B scramble on/off, any scramble code setting
Burst repetition rate 10 ms
Slot configuration For device, up/down communication channel
Full slot: Slot 0 to slot 11 (down channel), slot 12 to slot 23 (up channel)
Output slot select
Half slot: Slot 0-0 to slot 11-1 (down channel), slot 12-0 to slot 23-1 (up channel)
DECT Double slot: Slot 0 to slot 10 (down channel), slot 12 to slot 22 (up channel)
*
On/off selectable for any slots (excluding all slots off)
S, H, T: Any data
Edit function D: PN15/PN9
*1, all-0 or all-1 selectable (for device evaluation)
D: PN15/PN9
*
1
, TEST or REP-8 bits any data selectable (for communication channel)
Burst repetition rate 2.5 ms
Slot configuration For device, up/down communication channel
PACS Output slot select On/off selectable for any slots of slot 0 to slot 7 (excluding all slots off)
Edit function
PN: PN9, PN15
*1selectable (for device), DE/SC/R/SYC/PCC: Any data, FC: PN9
*1, PN15
*1, all-0 or all-1 selectable
(PN15 selectable only for 1 slot)
Burst repetition rate 10 ms
Slot configuration For device, up/down communication channel
WCPE
Full slot: Slot 0 to slot 11 (down), slot 12 to slot 23 (up); Half slot: Slot 0-0 to slot 11-1 (down), slot 12-0 to slot 23-1 (up);
Output slot select
Double slot: Slot 0 to slot 10 (down), slot 12 to slot 22 (up)
*
On/off selectable for any slots (excluding all slots off)
S/H/T: Any data
Edit function D: PN9
*
1
, PN15
*
1
, all-0 or all-1 selectable (for device)
D: PN9
*1, PN15
*1, TEST or REP 8-bits any data selectable (for communication channel)
Burst repetition rate 5 ms
Slot configuration For device, up/down communication channel, VOX control, sync burst
Output slot select On/off selectable for any slots of slot 1 to slot 4 (excluding all slots off)
PHS
Edit function UW/SA etc.: Any data, TCH: PN9, PN15
*1selectable
Scramble function TCH + CRC, scramble on/off, any scramble code setting
Adjacent channel
leakage power ratio
≤–74 dB (600/900 kHz offset, ±96 kHz band, ≥10 MHz)
*
2
Burst repetition rate
V + D mode: 1.02; Excluding CH13, 255 to 30000 symbols; CH13
PDO mode: 1.00; Excluding CH14, 126 to 30000 symbols; CH14
Following channel types selectable
Burst pattern V + D mode: CH1, CH2, CH3, CH4, CH13; Downlink, CH7, CH8, CH9, CH10, CH11; Uplink
TETRA
PDO mode: CH5, CH6, CH14; Downlink, CH12; Uplink
Slot configuration
V + D mode: DEVICE, NORMAL, SYNC; Downlink, DEVICE NORMAL, CONTROL; Uplink
PDO mode: NORMAL, SYNC; Downlink, START, EVEN, ODD, END; Uplink
V + D mode: On/off selectable for any slots of slot 1 to slot 4 (excluding CH13 and all slots off)
Output slot select Frame 1 to Frame 17 set to the same values
PDO mode: Variable slot numbers of slot 1 to slot 150 (excluding CH14)
Continued on next page
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
298 www.anritsu.com For product ordering information, see pages 4-7.
Carrier frequency range 4 kHz to 2250 MHz (MG3670B/C), 4 kHz to 2750 MHz (MG3671A/B and MG3672A)
–143 to +8 dBm, 0.1 dB steps (1 channel only on, PCB MUX must be off when traffic present)
RF output level –143 to +4 dBm, 0.1 dB steps (multiplex channel)
Frequency response, level accuracy: Depends on main frame (after level calibration)
Supported systems IS-95: US Digital Cellular System
Modulation format Forward link: SS + QPSK; Reverse link: SS + OQPSK
Chip rate 1.2288 Mcps
IS-95 recommended filters: SPEC 1, SPEC 2, SPEC 3, SPEC 1 + EQ, SPEC 2 + EQ, SPEC 3 + EQ
Baseband filters Nyquist filters: α = 0.2, 0.25, 0.3, 0.35, 0.4, 0.45, 0.5
Root Nyquist filters: α = 0.2, 0.25, 0.3, 0.35, 0.4, 0.45, 0.5
Multiplex channels Channels 1 to 5
CH 1: Current Pilot, Off
Supported channels CH 2 to CH 5: Nth Pilot, Sync, Paging, Traffic, OCNS, Off
(Sync available for 1 selected channel only, all channels cannot be turned off simultaneously.)
Spread code Walsh code + Short code
Point: 0, Sync: 32, Paging: 1 to 7, Traffic: 8 to 31/33 to 63, OCNS: 0 to 63
Walsh code
(Except for Pilot code, same code number cannot be set for multiple channels.)
Forward
Short code offset 0 to 3276 chips in 64 chip steps (for Current Pilot), 1 chip steps (for Nth Pilot)
link Sync 1200 bps, Paging: 4800/9600 bps, OCNS: 19200 sps, Traffic: 1200/2400/4800/9600 bps,
Data rate
1800/3600/7200/14400 bps (Single channel selection only, except for 9600/14400 bps)
(RF output level + upper limit for each no. of multiplex channels) to –20 dB in 0.1 dB steps
Channel level
Upper limit for each no. of multiplex channels: –3 dB (2 channels), –5 dB (3 channels), –6 dB (4 channels), –7 dB (5 channels)
*
Level is set automatically for channel with highest CH number, user setting not possible.
Scramble function Long code scramble on/off (for Paging/Traffic/OCNS)
Power control bit transmission on/off (for Traffic)
PCB MUX function
PCB data: Selectable 256 bit data repeating pattern
Long code mask 42 bits can be set by user in each channel (scramble On, PCB MUX On)
Multiplex channels Channels 1 to 4
CH 1: Traffic, Access, Interfered
Supported channels
CH 2 to CH 4: Traffic, Access, Interfered, Off
Spread code Long code + short code
Long code mask 42 bits can be set by user in each channel.
Reverse
Access: 4800 bps, Interfered: 28800 sps
link Data rates
Traffic: 1200/2400/4800/9600 bps, 1800/3600/7200/14400 bps (For CH1 only on, except for 9600/14400 bps)
(RF output level + upper limit for each no. of multiplex channels) to –15 dB in 0.1 dB steps,
Channel level Upper limit for each No. of multiplex channels: 0 dB (2 channels), 2 dB (3 channels), –3 dB (4 channels)
CH 1 is fixed on upper limit, user setting not possible.
Power monitor CH 1 to CH 4 composite output level, CH 2 to CH 4 composite output level (N), S/N ratio of CH 1 output level (S),
function CH 1 Eb/N (Multiplex channel only)
Frame offset 0 to 15 power control group (PCG) in 1 PCG steps
Internal frame structure Frame formats for all channel types specified by IS-95
Pseudo-random patterns: PN7, PN9, PN15
Internal modulation data Fixed pattern: User settable 16 bit data repeating pattern
Sequence data: User can set sequence data in internal RAM (2048 bits x 7 blocks) as repeating pattern of 1 to 8192 frames.
Using internal time reference clock
Data Clock: Data rate clock synched to Ref Clock and Frame Clock
Data: Digital data synched to Data Clock
ESTM Clock: 0.5 pulse/s clock synched to Ref Clock and Data Clock
Frame Clock: Channel frame clock synched to Ref Clock and ESTM Clock
External modulation data
BNC connector, TTL level, polarity switchable
Using external time reference clock
Ref Clock: ±2% of 19.6608, 9.8304, 4.9152, 2.4576 or 1.2288 MHz
Data: Digital data synched to Data Clock
ESTM Clock: 0.5 pulse/s clock synched to Ref Clock and Data Clock
Frame Clock: Channel frame clock synched to Ref Clock and ESTM Clock
BNC connector, TTL level, polarity switchable
I/Q signal output 50 Ω or CMOS (600 Ω), BNC connector
V + D mode: Downlink NORMAL; Any SB, SSB, NTS field data
SYNC; Any FC, SSB1, STS, SBB, SB2 field data
Uplink NORMAL; Any SB, NTS field data
Edit function
CONTROL; Any SCB, ETS field data
TETRA PDO mode: Downlink SYNC; Any FC, SB, STS field data
NORMAL; Any SB, NTS field data
Uplink START; Any ETS, SB field data, R bit Length
EVEN; Any NTS field data
Scramble function Any scramble code setting
*
1: The pseudorandom pattern in each slot has a different phase, and its pattern is continuous within the data field of slots.
*
2: Applicable when this unit is installed in MG3670B/C, MG3671A/B, and MG3672A. Not applicable when this unit is installed in MG3670A.
MG0310A CDMA Modulation Unit (incorporated in the MG3670B/C, MG3671A/B and MG3672A)
*
1
Continued on next page
For product ordering information, see pages 4-7. www.anritsu.com 299
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
6
• MG0314A W-CDMA Modulation Unit (incorporated in the MG3672A)
≤0 dBm output, CH1 only on, level control program function Off
Modulation accuracy (VEM),
VEM ≤2.5%rms, ρ≤0.9992 (With SPEC 1 baseband filter)
Waveform quality (ρ)
VEM ≤3.5%rms, ρ≤0.999 (With SPEC 2 baseband filter)
VEM ≤9.7%rms, ρ≤0.99 (With SPEC 3 baseband filter)
VEM ≤3.0%rms (With Nyquist/Root Nyquist baseband filter)
0 dBm output, 30 kHz bandwidth (Forward link/Reverse link, Default)
Spurious emissions
Level control program function Variable level in 1 dB steps from RF output level to 0 to –20 dB range in 1.25 ms units (program interval: 800 ms)
Control signal I/O
Long code trigger input, ESTM output, ESTM alignment output, data output, data clock output, frame clock output, time
reference clock output, TTL level, BNC connector (rear panel)
Auxiliary signal outputs
*
2
Long code, short code I/Q: TTL level, BNC connector (rear panel)
Long code trigger, 26.7 ms clock, 80 ms clock,TTL level, D-sub connector (rear panel)
Offset frequency
≥750 kHz ≥900 kHz ≥1.98 MHz
Baseband filter
SPEC 1 + EQ/SPEC 1 ≤–55 dBc ≤–60 dBc
SPEC 2 + EQ/SPEC 2 ≤–45 dBc ≤–60 dBc ≤–70 dBc
SPEC 3 + EQ/SPEC 3 ≤–65 dBc ≤–75 dBc
*
1: This expansion unit cannot be mounted in the MG3670A mainframe.
*
2: MG3670B/3671A can mount MG0310A fitted with Option 25, but in this case the auxiliary signal output function is not available.
MG0312A QPSK Modulation Unit (incorporated in the MG3670B/C, MG3671A/B and MG3672A)
*
1
Carrier frequency range 10 to 2250 MHz (MG3670B/C), 10 to 2750 MHz (MG3671A/B and MG3672A)
RF output level –143 to +8 dBm, 0.1 dB steps
Continuously variable level range Variable in steps of 0.1 dB in a range of 12 dB (+8 to –4 dB) from any RF output level to the upper or lower limit level.
Modulation system QPSK, OQPSK
Bit rate 0.5, 0.512, 1.0, 1.024, 1.5, 2.0, 2.048, 2.4576 Mbps
FIR filter
*
2
: FIR 1, FIR 2, FIR 3 (at a bit rate of 2.4576 Mbps)
Baseband filters Root Nyquist: α = 0.3, 0.4, 0.5 (operable at all bit rates)
Nyquist: α = 0.2, 0.3, 0.4, 0.5 (operable at all bit rates)
≤1.8%rms (bit rate: ≤1.5 Mbps), ≤3%rms (bit rate: ≥2 Mbps, Nyquist/Root Nyquist filters),
Vector error (RF output) ≤2.2%rms
*3(bit rate: 2.4576 Mbps, FIR 1 filter), ≤3%rms
*3(bit rate: 2.4576 Mbps, FIR 2 filter),
≤10%rms
*3(bit rate: 2.4576 Mbps, FIR 3 filter) *At ≤0 dBm output
Pseudo-random patterns: PN7, PN9, PN15, PN23
Internal modulation data
Fixed pattern: Iteration of any 16-bit data (Example: 2D2D
H
)
DATA CLOCK: ±5% of the bit rate
External modulation data DATA: Digital data synchronized with the data clock
SYMBOL CLOCK: Symbol definition clock synchronized with the data clock (BNC connector, TTL level, polarity selectable)
I/Q signal output Selectable between 50 Ω or CMOS (600 Ω), BNC connector
Phase encoding function The phase mapping of data on a constellation can be set.
At 2.4576 Mbps bit rate, 0 dBm output level, 30 kHz bandwidth
Spurious emissions
Offset frequency
≥900 kHz ≥1.98 MHz
Baseband filter
FIR 1 ≤–55 dBc ≤–60 dBc
FIR 2, Nyquist α = 0.2 ≤–55 dBc ≤–70 dBc
FIR 3 ≤–60 dBc ≤–75 dBc
*
1: This expansion unit cannot be mounted in the MG3670A mainframe.
Please consult your sales representative regarding the addition of expansion units to previously purchased MG3670A-11 mainframes.
*
2: Finite Impulse Response filter conforming to the TIA/EIA/IS-95 specifications
*
3: The waveform quality ρ conforming to the TIA/EIA/IS-95 specifications is ≥0.9995 (FIR 1), ≥0.999 (FIR 2), ≥0.99 (FIR 3).
Communication system W-CDMA (conforms to W-CDMA system experimental specification)
Modulation DS + QPSK
Multiplex system CDMA
Carrier frequency range 10 to 2750 MHz
Range:
–143 to +5 dBm (number of multiplex channel: 1), –143 to +1 dBm (number of multiplex channels: ≤8),
–143 to –2 dBm (number of multiplex channels: ≥9), –143 to +13 dBm (Source: Ext, or Mod off)
RF output level Accuracy:
±1.5 dB (–33.0 to +13.0 dBm, 10 to <100 MHz), ±2.0 dB (–33.0 to +13.0 dBm, ≥100 MHz), ±2.0 dB (–123 to –33.1
dBm, ≥10 MHz), ±3.5 dB (–136 to –123.1 dBm, 10 to <100 MHz), ±4.0 dB (–136 to –123.1 dBm, ≥100 MHz)
*
Number of multiplex channels: 1, long code: on, level control function: off
Chip rate 1.024, 4.096 Mcps
Root Nyquist: α = 0.2, 0.22, 0.25, 0.3, 0.35, 0.4, 0.45, 0.5
Baseband filters
Nyquist: α = 0.2, 0.22, 0.25, 0.3, 0.35, 0.4, 0.45, 0.5
Filter mode EVM, NRM, ACP selectable
Continued on next page
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
300 www.anritsu.com For product ordering information, see pages 4-7.
Number of multiplex Settable channels: 8
channels Maximum multiplex: 56 (limited to output level, used at Other Channel function)
Supported channels PERCH 1, PERCH 2, CONTROL, DTCH
Spread code Long code: Gold code, Short code: Layered orthogonal code sequence
Channel level 0.0 to –20.0 dB (0.1 dB steps; Maximum value varies with multiplex)
Long code setting
Down link range
00000H to 3FFFFH (initial phase variable function)
Short code for long
00H to FFH
code masked symbols
Short code setting
range
4 to 256 chip length
Encoder function CRC encoder, convolution encoder, interleaver
P-down function Variable long code masked symbol (0 to –20 dB, 0.1 dB steps)
Symbol rate 16 to 1024 ksps
Number of multiplex
Any settable channel: 8, Maximum multiplex: 8
channels
Supported channels DTCH
Spread code Long code: Gold code, Short code: Layered orthogonal code sequence
Channel level 0.0 to –20.0 dB (0.1 dB steps; Maximum value varies with multiplex)
Up link Long code setting
range
00000000000H to 1FFFFFFFFFFH
Short code setting
range
4 to 256 chip length
Encoder function CRC encoder, convolution encoder, interleaver
Symbol rate 16 to 1024 ksps
Frame offset 0 to 15 slot
Internal frame structure BCCH, FACH-L, DTCH, ACCH
I/Q signal output 50 Ω and CMOS (600 Ω) selectable, BNC connector
Vector error EVM: ≤5.0%rms (filter mode: EVM, output: 0 dBm, only 1 channel on, level control program function: off)
≤–63 dBc (specification value), ≤–65 dBc (typical)
Spurious emissions
*
5 MHz offset, 0 dBm output, only 1 channel on, 18˚ to 30˚C, 1.8 to 2.2 GHz, filter mode: ACP
Level control program function Level control resolution: 1.0 dB, Time resolution: 0.625 ms
Front panel
DATA: Input data for User CH set at External Input Channel
Auxiliary inputs TIMING CLOCK: Clock synchronized to super frame
(TTL level, BNC connector) DATA CLOCK: Input data clock set at External Input channel
Rear panel
LONG CODE TRIGGER: Long code start trigger signal
Rear panel
DATA: Data for User CH set at External Output Channel (switchable using Data Select to data before and after spread)
DATA CLOCK: Data clock corresponding to each channel setting (switchable using Data Select to Symbol or Chip use)
TIMING CLOCK: Clock synchronized to super frame
FRAME CLOCK: Clock synchronized to radio frame
Auxiliary outputs SYMBOL CLOCK: Symbol clock (switchable using Data Select to Symbol Clock and Chip Clock)
(TTL level, BNC connector) REF CLOCK: Clock of 1, 2, 4, and 8 time chip rate
Rear panel expansion output connector
LONG CODE I: Long code for in-phase component
LONG CODE Q: Long code for orthogonal component
LONG CODE TRIGGER: Long code start trigger
SLOT CLOCK: Clock synchronized to Time slot
Model Start-up characteristics Aging rate Temperature characteristic (0˚ to 50˚C)
MG3670/3671/3672 Option 01
7 x 10–8/day (after 30 min. warm-up)
3 x 10
–8
/day (after 60 min. warm-up)
5 x 10
–9
/day (after 24-h warm-up) ±5 x 10–8/day
MG3670/3671/3672 Option 02
2 x 10–8/day (after 60 min. warm-up) 2 x 10–9/day (after 24-h warm-up) ±1.5 x 10–8/day
MG3670/3671/3672 Option 03
– 5 x 10
–10
/day (after 48-h warm-up) ±5 x 10–9/day
MG3670B Option 20 RF off release function (When RF is off, level display and level setting is enabled.)
MG0301C Option 22
PHS LCCH super frame control pattern function (artificial base station signal output for field strength measurement: A PS
connection test is impossible.)
MG0302A Option 23 CT2 MUX3 control pattern function
MG3670B/3671A Option 25 Format upgrade (enables MG0310A to be used in MG3670B/3671A)
• Options
For product ordering information, see pages 4-7. www.anritsu.com 301
RADIO COMMUNICATIONS, EMI MEASURING TEST INSTRUMENTS
6
Model/Order No. Name
Options (for mainframe)
MG3670/3671/3672-01
Reference oscillator
MG3670/3671/3672-02
Reference oscillator
MG3670/3671/3672-03
Reference oscillator
MG3670-20 RF off release function
MG3670B/3671A-25
Format upgrade
Options (for expansion units)
MG0301C-22 PHS LCCH super frame control pattern
MG0302A-23 CT2 MUX3 control pattern
Optional accessories
J0127C Coaxial cord (BNC-P • RG-58A/U • BNC-P), 0.5 m
J0003A Coaxial cord (SMA-P • 3D-2W • SMA-P), 1 m
J0576D Coaxial cord (N-P • 5D-2W • N-P), 2 m
J0004 Coaxial adapter (N-P • SMA-J)
J0007 GPIB cable, 1 m
J0008 GPIB cable, 2 m
B0329D Protective cover
B0331D Front handle kit (2 pcs/set)
B0332 Joint plate (4 pcs/set)
B0333D Rack mount kit
B0334D Carrying case (with casters and protective cover)
Optional equipment
MS8604A Digital Mobile Radio Transmitter Tester
MT8801B Radio Communication Analyzer
MD1620B Signalling Tester [PDC 800 MHz, PDC 1.5 GHz
(MD1620B-01)]
MD1620C Signalling Tester (PHS 1.9 GHz)
MD6420A Data Transmission Analyzer
MP1201C Error Rate Tester
MS2602A Spectrum Analyzer
Ordering information
Please specify model/order number, name, and quantity when ordering.
Model/Order No.
Name
Mainframe
MG3670B Digital Modulation Signal Generator
MG3670C Digital Modulation Signal Generator
MG3671A Digital Modulation Signal Generator
MG3671B Digital Modulation Signal Generator
MG3672A Digital Modulation Signal Generator
Expansion units (factory installed)
MG0301C π/4 DQPSK Modulation Unit (for PDC, PDC_H, PHS,
NADC and TFTS communication systems)
MG0302A GMSK Modulation Unit [for GSM, PCN (DCS1800), and
CT2 communication systems]
MG0303B Burst Function Unit [for PDC, PDC_H, PHS, NADC, TFTS,
GSM, PCN (DCS1800), CT2, DECT, PACS and WCPE
communication systems]
MG0305A GFSK Modulation Unit (for DECT communication system)
MG0307A π/4 DQPSK Modulation Unit (for PACS, WCPE, PHS
communication systems)
MG0310A CDMA Modulation Unit (for IS-95 communication system)
MG0311A π/4 DQPSK Modulation Unit (for TETRA communication
system)
MG0312A QPSK Modulation Unit
MG0314A W-CDMA Modulation Unit
Standard accessories (for mainframe)
J0576B Coaxial cord (N-P • 5D-2W • N-P), 1 m: 1 pc
J0127A Coaxial cord (BNC-P • RG-58A/U • BNC-P), 1 m: 2 pcs
J0017F Power cord, 2.5 m: 1 pc
B0325 Shielded cover for GPIB: 1 pc
F0014 Fuse, 6.3 A (for 100 Vac power supply): 2 pcs
F0012 Fuse, 3.15 A (for 200 Vac power supply): 2 pcs
W0869AE MG3670B/C operation manual
(supplied with MG3670B/C): 1 copy
W0932AE MG3671A/B operation manual
(supplied with MG3671A/B): 1 copy
W0869BE MG3670B/C, MG3671A/B service manual
(supplied with MG3670B/C, MG3671A/B): 1 copy
W1462AE MG3672A operation manual
(supplied with MG3672A): 1 copy
Standard accessories (for expansion units)
W0872AE MG0301C/0303B operation manual
(supplied with MG0301C): 1 copy
W0691AE MG0302A/0303B operation manual
(supplied with MG0302A): 1 copy
W0851AE MG0305A/0303B operation manual
(supplied with MG0305A): 1 copy
W0949AE MG0307A/0303B operation manual
(supplied with MG0307A): 1 copy
W1183AE MG0310A operation manual
(supplied with MG0310A): 1 copy
B0405A Exchange sheet for front panel
(supplied with MG0310A): 1 pc
B0406A Exchange sheet for real panel
(supplied with MG0310A): 1 pc
W1050AE MG0312A operation manual
(supplied with MG0310A): 1 copy
W1412AE MG0314A operation manual
(supplied with MG0314A): 1 copy
B0416A Exchange front panel sheet
(supplied with MG0314A): 1 pc
B0418A Exchange rear panel sheet
(supplied with MG0314A): 1 pc
For additional units and version upgrades, consult your Anritsu sales representative.
Loading...
