Alpine INE-NAV-60HDMI Owners Manual

IN-DASH GPS NAVIGATION RECEIVER

INE-W960HDMI

INE-NAV-60HDMI

INE-W960SHDMI

• OWNER’S MANUAL Please read before using this equipment.

• MODE D’EMPLOI Veuillez lire avant d’utiliser cet appareil.

• MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo.

• MANUAL DO PROPRIETÁRIO Leia antes de usar este equipamento.

Open only to legal US. residents./ Uniquement accessible aux personnes résidant légalement aux États-Unis./ Solo para ciudadanos residentes legalmente en EE.UU./ Aberto somente para residentes legais nos EUA.

Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by registering your product now at the following address: www.alpine-usa.com/registration You will be informed of product and software updates (if applicable), special promotions, news about Alpine, and entered for a chance to win prizes.

Merci d’avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante : www.alpine-usa.com/registration Vous serez tenu informé des mises à jour des produits et des logiciels (le cas échéant), des promotions spéciales, de l’actualité d’Alpine, et vous aurez une chance de remporter des prix.

Gracias por adquirir este producto Alpine. Con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente dirección: www.alpine-usa.com/registration Recibirá información sobre nuevos productos y software, promociones especiales, novedades sobre Alpine y participará en el sorteo de premios.

68-33122Z70-A

ALPINE ELECTRONICS MARKETING, INC.

1-7, Yukigaya-Otsukamachi, Ota-ku,

Tokyo 145-0067, JAPAN

Phone: 03-5499-4531

ALPINE ELECTRONICS OF AMERICA, INC.

19145 Gramercy Place, Torrance,

California 90501, U.S.A.

Phone 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS France S.A.R.L.

184 allée des Erables

CS 52016 - Villepinte

95 945 Roissy CDG cedex

FRANCE

Phone : + 33(0)1 48 63 89 89

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

161-165 Princes Highway, Hallam

Victoria 3803, Australia

Phone 03-8787-1200

ALPINE ELECTRONICS GmbH

Wilhelm-Wagenfeld-Str. 1-3, 80807 München,

ALPINE ELECTRONICS OF U.K. LTD.

Fletchamstead Highway, Coventry CV4 9TW, U.K.

Germany

Phone 089-32 42 640

Alpine House

www.alpine.co.uk

ALPINE ITALIA S.p.A.

Viale Cristoforo Colombo, 8

20090 Trezzano sul Naviglio MI, Italy

Phone +39 02 484781

ALPINE ELECTRONICS DE ESPAÑA, S.A.

Portal de Gamarra 36, Pabellón, 32

01013 Vitoria (Alava)-APDO 133, Spain

Phone 945-283588

ENGLISH

Contents Operating Instructions

PRECAUTIONS

IMPORTANT INFORMATION ....................... 7

WARNING

Points to Observe for Safe Usage ..................... 7

WARNING ................................................. 8

CAUTION .................................................. 8

NOTICE ..................................................... 9

Discs Playable on This Unit ................. 10

Getting Started

Accessory List ................................................ 14

Location of Controls ...................................... 14

Turning Power On or Off ............................... 14

Turning the System On ................................... 15

Initial System Start-Up ................................... 15

Inserting/Ejecting a Disc ................................ 15

Inserting the Disc ........................................ 15

Removing the Disc ...................................... 15

Adjusting the Volume ..................................... 15

Lowering Volume Quickly ............................. 15

Top banner and Bottom banner Fade Out

Setting ......................................................... 16

Switching Sources .......................................... 16

Screen Off Function .................................... 16

About Sound Menu button ............................. 16

Touch Operation ............................................. 17

Selecting an Item in a List .............................. 17

About the Indicator Display ........................... 17

Displaying Audio/Visual Information on the

Navigation screen ........................................ 18

Radio/RBDS

Listening to the Radio .................................... 19

Presetting Stations Manually .......................... 19

Presetting Stations Automatically .................. 19

Tuning to Preset Stations ................................ 19

PTY (Program Type) Tuning ..........................20

Displaying Radio Text ....................................20

CD/MP3/WMA/AAC

Playback ..........................................................21

Repeat Play .....................................................21

M.I.X. (Random Play) ....................................21

M.I.X. ALL (Shuffle Songs)

(Concerning MP3/WMA/AAC) ..................21

Selecting Folders

(Concerning MP3/WMA/AAC) ..................22

Searching from CD Text .................................22

File/Folder Name Search

(Concerning MP3/WMA/AAC) ..................22

About MP3/WMA/AAC .................................22

DVD

Playing a Disc .................................................25

If a Menu Screen Appears ...........................25

Numeric Keypad Input Operations ..............26

Displaying the Top Menu Screen ................26

Displaying the Menu Screen .......................26

Stopping Playback (PRE STOP) .....................26

Stopping Playback ..........................................26

Fast-forwarding/Fast-reversing .......................26

Finding the Beginnings of Chapters/Tracks/

Files .............................................................26

Playing Still Frames (Pausing) ........................27

Slow Motion Playback ....................................27

Selecting Folders .............................................27

Repeat Playback ..............................................27

Searching by Title Number .............................27

Searching Directly by Chapter Number ..........28

Searching for a Desired Video File .................28

Switching the Angle ........................................28

Switching the Audio Tracks ............................28

Switching the Subtitles

(Subtitle Language) .....................................28

About DivX

..................................................29

3-EN

Setup

Setup Operation

General Setup

General Setup Operation ................................ 30

Text Display Setting .......................................30

Setting the Scroll .........................................30

Format Settings ........................................... 31

Setting the Menu Language ........................ 31

Clock Display Setting ..................................... 31

Setting Top banner and Bottom banner

Display ........................................................31

Screen/LED Customize ..................................31

Setting the Brightness of the

Backlighting ............................................. 31

Adjusting the Minimum Level of

Backlight ..................................................31

Adjusting the Dimmer of Button Lighting at

Night ........................................................32

Switching the Display Color and Wallpaper

Image (Background) ................................ 32

Visual Setting ..................................................32

Switching Display Modes ...........................32

Adjusting Brightness ...................................33

Adjusting Color of Picture .......................... 33

Adjusting Image Contrast ...........................33

About INE-W960/INE-NAV-60/

INE-W960S .................................................33

Displaying the Product Information ............ 33

Checking the DivX

Initializing the System .................................33

Installation Setup ............................................34

Demonstration Setup ...................................... 34

Setting Demo mode to Off/On .................... 34

Sound Setup

Sound Setup Operation ................................... 34

Car Specific Sound Setup ...............................35

Setting the MX (Media Xpander) ...................35

Equalizer Presets (EQ Presets) .......................36

Quick Sound Setup .........................................36

Adjusting Bass Level/Treble Level ............. 36

Adjusting the Subwoofer Level ................... 36

Setting the MX (Media Xpander) ............... 36

Setting the BASS ENGINE SQ ................... 36

Setting the BASS ENGINE Type ................37

Adjusting the BASS ENGINE Level ..........37

Adjusting the Fader/Balance ....................... 37

Adjusting the Time Correction (TCR) ............ 37

Registration ...............33

Adjusting the Crossover Settings

(X-Over) ......................................................38

Adjusting the Parametric Equalizer Curve

(Parametric EQ) ........................................... 38

Other Setting ...................................................39

Volume Setting ............................................ 39

Setting the Volume for Each Source ...........39

Rear Speaker Setting ................................... 39

Turning Subwoofer On/Off ......................... 39

Setting the Subwoofer Phase ....................... 39

Setting Defeat ................................................. 39

About Time Correction ...................................40

About the Crossover ....................................... 41

Source Setup

Source Setup Operation ..................................41

Disc Setting .....................................................42

Setting of the DVD Menu Language ........... 42

Setting of the Audio Language ................... 42

Setting of the Subtitle Language ................. 42

Changing the Language Setting ..................42

Changing the Country Code Setting ........... 42

Setting the Rating Level (Parental Lock) .... 42

Setting the TV Screen Mode ....................... 43

Radio Setting .................................................. 43

Setting the TUNER (FM) Tone Quality

(Tuner Condition) ....................................43

AUX Setting ................................................... 44

Setting the AUX Mode ................................44

Setting the Primary AUX Name

(AUX Setup) ............................................44

SiriusXM Setting

(INE-W960/INE-NAV-60 only) .................. 44

Managing Artist, Song and Sports Team

Alerts ........................................................44

Setting the Favorite Sports Team Alerts ...... 45

Setting the Parental Lock ............................45

Signal Strength Information ........................ 46

Setting the App connection method ................46

Rear Seat Entertainment Setting ..................... 46

Setting the Rear Seat Entertainment

System ...................................................... 46

BLUETOOTH Setup

BLUETOOTH Setup Operation ..................... 47

Displaying BLUETOOTH Information .......... 47

Registering the BLUETOOTH Device ...........47

Setting the Passcode .......................................48

Selecting the Output Speaker ......................... 48

4-EN

Adjusting the Caller Volume .......................... 48

Adjusting the Microphone Level .................... 48

Adjusting the Ring Tone Volume ................... 48

Deleting All the Histories ............................... 48

Changing the Phone book List Order ............. 48

Camera Setup

Camera Setup Operation ................................. 49

AUX Camera Setting ...................................... 49

Setting the Camera Input .............................49

Camera Interrupt Setting

(Power OFF Mode) ..................................... 50

About the Rear Camera Guide ........................ 50

BLUETOOTH Operation

Setup Before Using ......................................... 52

About BLUETOOTH .................................. 52

About the Hands-Free Phone ......................52

Before Using BLUETOOTH .......................52

Hands-Free Phone Control

Connecting a BLUETOOTH Device .............. 52

Disconnecting the BLUETOOTH

Connection ...............................................52

Changing the connecting BLUETOOTH

Device .......................................................... 53

Answering a Call ............................................ 53

Adjusting Ringtone Volume ........................ 53

Hanging up the Telephone ..............................53

Calling ............................................................53

Using Short Cut Dialing to Make a Call ..... 53

Dialing a Number in Call History ............... 53

Dialing a Number in the Phone Book .........54

Entering a Phone Number to Make a Call ...54

Redial Function ........................................... 54

Voice Dial Function ..................................... 54

Operations During a Conversation ................. 55

Adjusting the Speech Volume ..................... 55

Changing the Voice Output .........................55

DTMF (Touch-Tone) Function .................... 55

Muting the Speech Volume .........................55

Phone Book Function .....................................55

Synchronizing the Phone Book ................... 55

Adding the Phone Book ..............................55

Searching in the Phone Book ...................... 56

Deleting the Phone Book Entries ................ 56

Assigning as a Short Cut Dialing Number ..... 56

Call Waiting Function .....................................57

BLUETOOTH Audio

Playback ..........................................................57

Repeat Play ..................................................... 58

M.I.X. (Random Play) ....................................58

Search Function ..............................................58

Auxiliary Device (Optional)

Operating Auxiliary Devices (Optional) ........59

Operating an External DVD Player ................ 59

Change to the External DVD Mode ............ 59

About the DVD Operation Screen ............... 60

Operating an External DVD Changer ............. 60

Change to the External DVD Changer

Mode ........................................................60

About the DVD Changer Operation

Screen ...................................................... 61

Operating a TV ............................................... 61

Change to the TV Mode ..............................61

About the TV Operation Screen .................. 61

Applying TuneIt

Launching TuneIt App. ................................... 62

Facebook Notification Function ..................... 62

Camera Operation (Optional)

Rear Camera Operation ..................................63

Checking Rear Camera view ....................... 63

Displaying the Rear View Video while the Car

is in Reverse .............................................63

USB Memory (Optional)

Playback ..........................................................64

Repeat Play ..................................................... 65

Random Play (M.I.X.) ....................................65

Random Play (Shuffle Songs) ........................65

Searching for a Desired Song ......................... 65

Tag Search ...................................................65

File/Folder Name Search .............................66

Direct Up/Down Function .............................. 66

Select the Desired Folder

(Folder up/down) ......................................... 66

iPod/iPhone (Optional)

Playback ..........................................................68

Searching for a Music File .............................. 68

Searching for a Desired Video File ................. 69

Alphabet Skip Function ..................................69

Direct Up/Down Function .............................. 69

5-EN

Repeat Play .....................................................70

Random Play (Shuffle) ................................... 70

Random Play (Shuffle Songs) ........................ 70

Pandora® internet radio (optional)

(INE-W960/INE-NAV-60 only)

Listening to Pandora® ..................................... 71

“Thumbs” Feedback ....................................... 71

Searching for a Desired Station ...................... 72

Creating a New Station ................................... 72

QuickMix ........................................................72

Bookmarking a Desired Track or Artist .........72

How to Input Characters and Numbers

(Keypad) ...................................................... 73

SiriusXM Satellite Radio (Optional)

(INE-W960/INE-NAV-60 only)

Receiving Channels with the SiriusXM

Tuner ...........................................................74

Tuning Channels by Category ........................74

Changing the Display .....................................75

Checking the SiriusXM Radio ID Number .... 75

Storing Channel Presets .................................. 75

Tuning Channels Using Presets ...................... 75

Search Function ..............................................75

Selecting the Channel Directly ....................... 76

Storing the Desired Song/Artist ......................76

Receiving and Tuning to an Alert ...................76

Replay Function .............................................. 77

Parental Control Function ...............................77

Using Jump Memory and Jump Recall

Function .......................................................77

Installation and Connections

Warning .................................................. 88

Caution ................................................... 88

Precautions ............................................ 88

Installation ......................................................89

Connections ....................................................92

System Example ............................................. 94

LIMITED WARRANTY

Information

Product Software Update ................................78

About DVDs ...................................................78

List of Language Codes .................................. 79

List of Country Codes .....................................80

In Case of Difficulty ....................................... 82

If this Message Appears .................................83

Specifications ..................................................85

END USER LICENSE AGREEMENT

(Microsoft) ..................................................86

END USER LICENSE AGREEMENT

(HERE) ........................................................87

6-EN

Operating Instructions

If there is anything in the manual about the operation of

PRECAUTIONS

IMPORTANT INFORMATION

PLEASE READ CAREFULLY BEFORE USING THIS PRODUCT

This product is intended to provide turn by turn instructions to get you to a desired destination. Please make certain that all persons using this navigation system carefully read these precautions and the following instructions fully.

• This product is not a substitute for your personal judgment. Any route suggestions made by this navigation system may never supersede any local traffic regulations or your personal judgment and/or knowledge of safe driving practices. Do not follow route suggestions if the navigation system instructs you to perform an unsafe or illegal maneuver, places you in an unsafe situation, or routes you into an area which you consider unsafe.

• Glance at the screen only when necessary and safe to do so. If prolonged viewing of the screen is necessary, pull over in a safe and legal manner and location.

• Do not input destinations, change settings, or access any functions requiring a prolonged view of the monitor and/or remote control while you are driving. Pull over in a safe and legal manner and location before attempting to access the system.

• Do not use the navigation system to route you to emergency services. Not all locations of emergency services such as police and fire stations, hospitals and clinics are contained in the database. Please use your own judgment and ask for directions in these situations.

• The map database used in the navigation system is the most recent map data available at the time of production. Because of changes in streets and neighborhoods, there may be situations where the navigation system is not able to route you to your desired destination. In these cases, use your own judgment.

• The map database is designed to provide you with route suggestions and does not take into account the relative safety of a suggested route or of factors which may affect the time required to reach your destination. The system does not reflect road closures or construction, road characteristics (i.e. type of road surface, slope or grade, weight or height restrictions, etc.), traffic congestion, weather conditions, or any other factors which may affect the safety or timing of your driving experience. Use your own personal judgment if the navigation system is unable to provide you with an alternate route.

• There may be situations where the navigation system displays the vehicle’s location erroneously. Use your own driving judgment in this situation, taking into account current driving conditions. Please be aware that in this situation the navigation system should correct the vehicle’s position automatically. However, there may be times where you may have to correct the position yourself. If this is the case, pull over in a safe and legal manner and location before attempting operation.

• Make certain that the volume level of the navigation system is set to a level which still allows you to hear outside traffic and emergency vehicles.

the navigation system which you are uncertain about, please contact your local Alpine authorized navigation dealer or Alpine at 1-888-NAV-HELP (1-888-628-4357) before using the navigation system.

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide more reasonable protection against harmful interference in a residential installation, and are more stringent than “outdoor” requirements.

Operation is subjected to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult an experienced radio/TV technician.

WARNING

Points to Observe for Safe Usage

• Read this manual carefully before using this disc and the system components. They contain instructions on how to use this product in a safe and effective manner. Alpine cannot be responsible for problems resulting from failure to observe the instructions in this manual.

• This manual uses various pictorial displays to show you how to use this product safely and to alert you to potential dangers resulting from improper connections and operation. Following are the meanings of these pictorial displays. It is important to fully understand the meanings of these pictorial displays in order to use this manual and the system properly.

7-EN

WARNING

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or electric shock.

• Operation of the system while driving is dangerous. Users

should stop vehicle before operating the software.

• Road conditions and regulations take precedence over information contained on the map display: observe actual traffic restrictions and circumstances while driving.

• This software is designed for use exclusively in the INE-W960/INE-NAV-60/INE-W960S. It cannot and may not be used in conjunction with other hardware.

WARNING

This symbol means important instructions. Failure to heed them can result in serious injury or death.

INSTALL THE PRODUCT CORRECTLY SO THAT THE DRIVER CANNOT WATCH TV/VIDEO UNLESS THE VEHICLE IS STOPPED AND THE EMERGENCY BRAKE IS APPLIED.

It is dangerous for the driver to watch TV/Video while driving a vehicle. Installing this product incorrectly enables the driver to watch TV/Video while driving. This may cause a distraction, preventing the driver from looking ahead, thus causing an accident. The driver or other people could be severely injured.

DO NOT WATCH VIDEO WHILE DRIVING.

Watching the video may distract the driver from looking ahead of the vehicle and cause an accident.

DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.

Any function that requires your prolonged attention should only be performed after coming to a complete stop. Always stop the vehicle in a safe location before performing these functions. Failure to do so may result in an accident.

DO NOT FOLLOW ROUTE SUGGESTIONS IF THE NAVIGATION SYSTEM INSTRUCTS YOU TO PERFORM AN UNSAFE OR ILLEGAL MANEUVER, OR PLACES YOU IN AN UNSAFE SITUATION OR AREA.

This product is not a substitute for your personal judgment. Any route suggestions by this system should never supersede any local traffic regulations or your personal judgment or knowledge of safe driving practice.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may result in fire, etc.

KEEP SMALL OBJECTS SUCH AS SCREWS OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a physician immediately.

USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.

Failure to do so may result in fire or electric shock.

DO NOT BLOCK VENTS OR RADIATOR PANELS.

Doing so may cause heat to build up inside and may result in fire.

USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.

Use for other than its designed application may result in fire, electric shock or other injury.

DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION SLOTS OR GAPS.

Doing so may result in personal injury or damage to the product.

CAUTION

This symbol means important instructions. Failure to heed them can result in injury or material property damage.

HALT USE IMMEDIATELY IF A PROBLEM APPEARS.

Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing.

KEEP FINGERS AWAY WHILE THE MOTORIZED FRONT PANEL OR MOVING MONITOR IS IN MOTION.

Failure to do so may result in personal injury or damage to the product.

KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE NOISES WHILE DRIVING.

Excessive volume levels that obscure sounds such as emergency vehicle sirens or road warning signals (train crossings, etc.) can be dangerous and may result in an accident. LISTENING AT LOUD VOLUME LEVELS IN A CAR MAY ALSO CAUSE HEARING DAMAGE.

MINIMIZE DISPLAY VIEWING WHILE DRIVING.

Viewing the display may distract the driver from looking ahead of the vehicle and cause an accident.

8-EN

NOTICE

Product Cleaning

Use a soft dry cloth for periodic cleaning of the product. For more severe stains, please dampen the cloth with water only. Anything else has the chance of dissolving the paint or damaging the plastic.

Temperature

Be sure the temperature inside the vehicle is between +45°C (+113°F) and 0°C (+32°F) before turning your unit on.

Moisture Condensation

You may notice the disc playback sound wavering due to condensation. If this happens, remove the disc from the player and wait about an hour for the moisture to evaporate.

New Discs

To prevent the disc from jamming, “Disc error” is displayed if discs with irregular surfaces are inserted or if discs are inserted incorrectly. When a new disc is ejected immediately after initial loading, use your finger to feel around the inside of the center hole and outside edge of the disc. If you feel any small bumps or irregularities, this could inhibit proper loading of the disc. To remove the bumps, rub the inside edge of the hole and outside edge of the disc with a ballpoint pen or other such instrument, then insert the disc again.

Center Hole

Bumps

Center Hole

New Disc

Outside (Bumps)

Damaged Disc

Do not attempt to play cracked, warped, or damaged discs. Playing a bad disc could severely damage the playback mechanism.

Maintenance

If you have problems, do not attempt to repair the unit yourself. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing.

Never Attempt the Following

Do not grip or pull out the disc while it is being pulled back into the player by the automatic reloading mechanism. Do not attempt to insert a disc into the unit when the unit power is off.

Inserting Discs

Your player accepts only one disc at a time for playback. Do not attempt to load more than one disc. Make sure the label side is facing up when you insert the disc. Playing a disc while driving on a very bumpy road may result in skips, but this will not scratch the disc or damage the player.

Irregular Shaped Discs

Be sure to use round shaped discs only for this unit and never use any special shaped discs. Use of special shaped discs may cause damage to the mechanism.

Installation Location

Make sure the INE-W960/INE-NAV-60/INE-W960S will not be installed in a location subjected to:

• Direct sun and heat

• High humidity and water

• Excessive dust

• Excessive vibrations

Correct Handling

Do not drop the disc while handling. Hold the disc so you will not leave fingerprints on the surface. Do not affix tape, paper, or gummed labels to the disc. Do not write on the disc.

CORRECT

INCORRECT CORRECT

Disc Cleaning

Fingerprints, dust, or soil on the surface of the disc could cause the DVD player to skip. For routine cleaning, wipe the playing surface with a clean, soft cloth from the center of the disc to the outer edge. If the surface is heavily soiled, dampen a clean, soft cloth in a solution of mild neutral detergent before cleaning the disc.

9-EN

Disc Accessories

There are various accessories available on the market for protecting the disc surface and improving sound quality. However, most of them will influence the thickness and/or diameter of the disc. Using such accessories can cause operational problems. We recommend not using these accessories on discs played in Alpine DVD players.

Transparent Sheet Disc Stabilizer

Operation of some of the functions of this unit is very complex. Because of this, it was deemed necessary to place these functions into a special screen. This will restrict operation of these functions to times when the vehicle is parked. This ensures the focus of the driver’s attention will be on the road and not on the INE-W960/ INE-NAV-60/INE-W960S. This has been done for the safety of the driver and passengers. Setup operations cannot be made if the car is moving. The car must be parked and the parking brake must be engaged for the procedure described in the Owner’s Manual to be valid. The warning “Unable to operate while driving.” will be displayed if any attempts are made to perform these operations while driving.

• The INE-W960/INE-NAV-60/INE-W960S draws minimal current

even when its power switch is turned off. If the switched power (ignition) lead of the INE-W960/INE-NAV-60/INE-W960S is connected directly to the positive (+) post of the vehicle’s battery, the battery may be discharged. An SPST (Single-Pole, Single-Throw) switch (sold separately) can be added to simplify this procedure. Then, you can simply place it in the OFF position when you leave the vehicle. Turn the SPST switch back ON before using the INE-W960/INE-NAV-60/INE-W960S. For connecting the SPST switch, refer to the “Connection Diagram of SPST Switch (sold separately)” (page 91). If the power (ignition) lead is unswitched, it must be disconnected from the battery post should the vehicle be left unused for an extended period of time.

Discs Playable on This Unit

Playable Discs

The discs listed below can be played on this unit.

Mark (logo)

DVD Video Audio + Video 12 cm*

Music CD Audio 12 cm

DivX

* Two-layer DVD disc compatible

The formatted discs listed below can be played on this unit.

CD Format

MP3 Format (“mp3”)

WMA Format (“wma”)

AAC Format (“m4a”)

Recorded

Content

Audio + Video 12 cm

CD-R/

CD-RW

DVD-R/

DVD-RW

Disc size

DVD+R/

DVD+RW

10-EN

DVD Video Format

DivX Format (“avi,” “divx”)

• Discs that are not finalized cannot be played back.

Discs that cannot be played

DVD-ROMs, DVD-RAMs, CD-ROMs (excluding MP3/WMA/ AAC files), photo CDs, etc.

DualDisc

This unit is not compatible with DualDisc. Using a DualDisc may cause unit malfunction, and may cause disc damage when the disc is inserted/ejected.

DVD region number (playable region number)

Region numbers supported by this unit are as follows. DVDs with a region number other than those listed below, cannot be played on this DVD player.

INE-W960/INE-NAV-60

INE-W960S

ALL

Using compact discs (CD/CD-R/CD-RW)

If you use unspecified compact discs, correct performance cannot be guaranteed. You can play CD-Rs (CD-Recordables)/CD-RWs (CDReWritables) which have been recorded only on audio devices. You can also play CD-Rs/CD-RWs containing MP3/WMA/AAC formatted audio files.

• Some of the following discs may not play on this unit: Flawed discs, discs with fingerprints, discs exposed to extreme temperatures or sunlight (e.g., left in the car or this unit), discs recorded under unstable conditions, discs on which a recording failed or a re-recording was attempted, copy-protected CDs which do not conform to the audio CD industry standard.

• Use discs with MP3/WMA/AAC files written in a format compliant with this unit. For details, see pages 22 and 23.

To customers using CD-R/CD-RW

• If a CD-R/CD-RW cannot be played back, make sure the last recording session was closed (finalized).

• Finalize the CD-R/CD-RW if necessary, and attempt playback again.

Tips for making your own discs

The INE-W960/INE-NAV-60/INE-W960S plays DVD Video,

, Audio CD and has a built in MP3/WMA/AAC decoder.

DivX

The following information is designed to help you create your own music CDs (either Audio CD or MP3/WMA/AAC encoded CD-R/ RW files).

What is the difference between an Audio and MP3/WMA/AAC CD?

An Audio CD is the same format as the commercial CDs you buy in the store (also known as CD-DA). MP3 (MPEG Audio Layer 3)/ WMA (Windows Media Audio)/AAC (Advanced Audio Coding) is a data file that uses a compression scheme to reduce the size of the music file*.

Multisession CD-R/RW:

Once a recording has been stopped, this is considered one session. If the disc is not closed (finalized), additional data may be added. Once this additional data has been recorded, this becomes a “multisession” CD. * If the first session on a disc containing both CD-DA data and

MP3/WMA/AAC data is a CD-DA file, only CD-DA files will be played.

Properly formatted MP3/WMA/AAC Discs:

Use ISO9660 formatting to insure proper playback. You may use standard ISO naming Level 1 (8.3 DOS standard), Level 2 (32 characters) or Joliet (Windows or Macintosh long filenames) file naming conventions*.

* Please consult the Owner’s manual for additional information.

On handling compact discs (CD/CD-R/CD-RW)

• Do not touch the surface.

• Do not expose the disc to direct sunlight.

• Do not affix stickers or labels.

• Clean the disc when it is dusty.

• Make sure that the disc is smooth and flat.

• Do not use commercially available disc accessories.

Do not leave the disc in the car or the unit for a long time. Never expose the disc to direct sunlight.

Heat and humidity may damage the disc and you may not be able to play it again.

11-EN

Using DVD-Rs/DVD-RWs/DVD+Rs/DVD+RWs

• This unit is compatible with discs recorded in the standard DVD-Video format.

• Note that discs not finalized (processed to enable to play on playback-only DVD players) cannot be played on this DVD player.

• Some discs may not play back, depending on the recording device and disc format.

• Discs or files utilizing copy protection, may not be playable. Some recording systems may not properly format copied files to enable proper playback.

• In the following cases, the disc may not play on this unit: discs recorded by certain DVD recorders, certain irregular discs, flawed discs, dirty discs, when the pickup lens of this DVD player is dirty, or when moisture condensation has occurred inside the unit.

• Be sure to follow all cautions included with your DVD-Rs/ DVD-RWs/DVD+Rs/DVD+RWs discs.

• Do not put stickers, seals, or tape on the label side of DVD-Rs/ DVD-RWs/DVD+Rs/DVD+RWs.

• Compared to the regular discs, DVD-Rs/DVD-RWs/DVD+Rs/ DVD+RWs are more affected by heat, moisture, and direct sunlight. If left in a car, etc., damage may occur and it might not play on this unit.

• The operable temperature range for disc playback is as follows: DVD-R/DVD-RW: -25 ~ +70°C DVD+R/DVD+RW: +5 ~ +55°C

Disc terminology

Title

If titles are programmed for the DVD, these are the largest units of division of the information recorded on the disc.

Chapter

Each Title may also be divided into smaller divisions, called chapters. These can be specific scenes or musical selections.

Protecting the USB connector

• Only an iPod/iPhone, USB memory or Mobile Phone can be connected to the USB connector on this unit. Correct performance using other USB products cannot be guaranteed.

• If the USB connector is used, be sure to use only the supplied connector cable with the unit. A USB hub is not supported.

• Depending on the connected USB memory device, the unit may not function or some functions may not be performed.

• The audio file format that can be played back on the unit is MP3/ WMA/AAC.

• The video file format that can be played back on the unit is

DivX

• Artist/song name, etc., can be displayed. Certain, special characters may not be correctly displayed.

CAUTION

Alpine accepts no responsibility for lost data, etc., even if data, etc., is lost while using this product.

On Handling USB Memory

• This unit can control a memory storage device that supports the USB Mass Storage Class (MSC) protocol. Playable audio file formats are MP3, WMA and AAC.

• USB memory function is not guaranteed. Use USB memory according to the terms of agreement. Read the USB memory Owner’s Manual thoroughly.

• Avoid usage or storage in the following locations:

Anywhere in the car exposed to direct sunlight or high temperatures. Anywhere the possibility of high humidity or corrosive substances are present.

• Fix the USB memory in a location where driver operation will not be hindered.

• USB memory may not function correctly at high or low temperature.

• Use only certified USB memory. Note that even certified USB memory, may not function correctly depending on its type or state.

• Depending on the settings of the USB memory type, memory state or encoding software, the unit may not play back or display properly.

• Files protected by DRM (Digital Rights Management), cannot be played back on this unit. These include AAC formatted files purchased from the iTunes Store and WMA or other files with some form of copyright protection.

• USB memory may take time to start playback. If there is a particular file other than audio in the USB memory, it may take considerable time before the file is played back or searched.

• The unit can play back “mp3,” “wma” or “m4a” file extensions.

• Do not add the above extensions to a file other than audio data. This non-audio data will not be recognized. The resulting playback may contain noise that can damage speakers and/or amplifiers.

• It is recommended to back up important data on a personal computer.

• Do not remove the USB device while playback is in progress. Change SOURCE to something other than USB, then remove the USB device to prevent possible damage to its memory.

12-EN

• This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

• Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

• Windows Media, and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

• iPhone, iPod, iPod classic, iPod nano, iPod touch, and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries.

• “Made for iPod,” and “Made for iPhone,” mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, or iPhone may affect wireless performance.

• Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc., used with permission. Pandora is currently available in the U.S., Australia and New Zealand.

• This device will control Pandora when connected to a compatible Android™ or BlackBerry access to the internet, and the latest version of the Pandora application installed.

• BlackBerry related trademarks, names and logos are the property of Research In Motion Limited and are registered and/or used in the U.S. and countries around the world. Used under license from Research In Motion Limited.

• DivX Rovi Corporation or its subsidiaries and are used under license.

• The Bluetooth owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under licence. Other trademarks and trade names are those of their respective owners.

• The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries.

• “MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.”

• “Supply of this product only conveys a license for private,noncommercial use and does not convey a license nor imply any right to use this product in any commercial (i.e. revenuegeneration) real time broadcasting (terrestrial, satellite, cable and/or any other media), broadcasting/streaming via internet, intranets and/or other networks or in other electronic content distribution systems, such as pay-audio or audio-on-demand applications. An independent license for such use is required. For details, please visit http://www.mp3licensing.com”

• Android is a trademark of Google Inc.

• is a trademark of DVD Format/Logo Licensing

Corporation.

, RIM®, Research In Motion®, SureType® and

, DivX Certified® and associated logos are trademarks of

word mark and logos are registered trademarks

phone that has Bluetooth,

13-EN

Getting Started

Accessory List

• INE-W960/INE-NAV-60/INE-W960S .....................................1

• Power cable .........................................................................1

• Flush head screw (M5×8)....................................................6

• Screw (M5×8) ......................................................................8

• GPS Antenna ......................................................................1

• Antenna mounting plate ......................................................1

• CAMERA/AUX/PRE OUT cable ...........................................1

• USB extension cable ...........................................................1

• Microphone..........................................................................1

• Mounting sleeve ..................................................................1

• Face plate............................................................................1

• Bracket key ..........................................................................2

• Owner’s Manual ..............................................................1set

Remote Sensor

Point the remote control transmitter towards the remote sensor within a range of 2 meters.

Optional Remote Control Interface Box

This unit is operable using the vehicle’s secondary radio controls. An Alpine Remote Control Interface Box (optional) is required. For details, contact your Alpine dealer.

Controllable with Remote Control

This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Point the optional remote control transmitter at the remote control sensor.

About the button descriptions used in this Owner’s Manual

The buttons found on the face of the unit are expressed in bold (e.g. MUTE). The buttons found on the touch-screen display are shown in bold within brackets, [ ] (e.g. []).

Location of Controls

(Eject) button

Ejects a disc.

/ (UP/DOWN) button

Press to adjust the volume.

MUTE/C button

Press to activate /deactivate the mute mode. Press and hold for at least 3 seconds to turn the power off.

(Phone)/VOICE CTRL. button

Recalls the Telephone Menu screen. When a voice dial compatible hands-free phone is connected, press and hold for at least 3 seconds to switch to the Voice Dial screen.

/ button

This action varies according to the Audio/Visual source. (Track Up/Down, Fast reverse/Fast forward, etc.)

/ button

Each time you press this button, the Navigation mode and the Audio/Visual Source mode are changed alternately. Press and hold for at least 3 seconds to activate the Quick Sound screen. For details of navigation operations, refer to “Navigation System OM” in the website at http://www.alpine-usa.com.

DISC Slot

RESET switch

The system of this unit is reset.

Turning Power On or Off

Some of this unit’s functions cannot be performed while the vehicle is in motion. Be sure to stop your vehicle in a safe location and apply the parking brake and footbrake, before attempting these operations.

Turn the ignition key to the ACC or ON position.

The system turns on.

• When turned on, the system displays the last mode screen that

was displayed before the ignition key was turned off. For example, if the unit is in radio mode when ignition is turned off, it will remain in radio mode when ignition is turned back on.

Press and hold the MUTE button for at least 3 seconds to turn the power off.

• The unit can be turned on by pressing any button.

• The INE-W960/INE-NAV-60/INE-W960S is a precision device.

Careful handling of the unit should provide you with years of troublefree operation.

14-EN

Turning the System On

With the Alpine system, when the ignition key is turned to ACC or ON, the opening screen will be automatically displayed.

When the system is used for the first time, the language selection menu is displayed. There are 24 languages to choose from. Touch [] or [] to scroll the list, and then touch the desired language.

• You can also scroll through lists by touching the screen and

sliding your finger up and down.

Touch [OK].

The radio screen is displayed.

• Some of this unit’s functions cannot be performed while the vehicle is in motion. Be sure to stop your vehicle in a safe location and apply the parking brake before attempting these operations.

Initial System Start-Up

Inserting/Ejecting a Disc

Inserting the Disc

Insert the disc with the label side facing up.

Disc Slot

When you insert the disc up to certain point, it is automatically pulled into the unit. The unit starts to play the disc.

• Do not touch the surface of the disc directly with your fingers.

• Before inserting or removing the disc, always turn the ignition key to

ACC or ON. You cannot remove or insert the disc with the ignition key turned to OFF.

Removing the Disc

Press (Eject button).

When the disc has been ejected part way, take it out. If the disc cannot be ejected by pressing , press and hold again for at least 5 seconds.

Be sure to press the RESET switch when using the unit for the first time, after changing the car battery, etc.

Press RESET with a ballpoint pen or similar pointed object.

RESET switch

Adjusting the Volume

Adjust the volume by pressing or .

Volume decreases/increases continuously by pressing and holding or . Volume: 0 - 35

Lowering Volume Quickly

Audio Mute function instantly lowers the volume level to 0.

Press MUTE button to activate the MUTE mode.

The audio level will be 0.

Pressing MUTE button again will bring the audio back to its previous level.

15-EN

Top banner and Bottom banner Fade Out Setting

When “Top/Bottom Banner Fade Out” is set to “ON,” the Top banner and Bottom banner on the Audio/Visual Playback screen fade out after 5 seconds if no operation is performed. To display the keys again, touch the middle of the screen.

Top banner

Bottom banner

If the TuneIt App is not launched, this option is not available.

When Camera Select is set to “Off,” this option is not available.

Screen Off Function

This mode is useful if you feel the unit’s display is too bright at night. To cancel Screen Off mode, touch the screen.

• Screen Off mode is canceled when the power or ACC is turned off.

• When the gear lever is shifted to the reverse (R) position while the

rear camera is connected, the rear camera im age is displayed.

• When a call is received while a BLUETOOTH device is connected,

the incoming call screen is displayed.

About Sound Menu button

Touch [Sound] icon on the screen to change the screen to the Sound Menu screen. Refer to “Sound Setup” (page 34).

[Sound] menu icon

• For details of how to set Top/Bottom Banner Fade Out, refer to “Setting Top banner and Bottom banner Display” (page 31).

Switching Sources

During audio/visual playback, touch a source button in the top banner to switch to the desired source.

Switching Sources Using the Top banner

Touch the source button for the Top banner at the top of the Audio/ Visual Playback screen and select the desired source.

Source button

Top banner

If the source button is hidden, touch [<<] [>>].

Radio / Disc* SiriusXM*

/ USB/iPod*1 / Pandora®*

/ AUX*4 / Notification List*5 / Camera*6 / Screen Off

1, 2

/ Bluetooth Audio /

Sound Menu Screen

When no disc is inserted or no USB memory/iPod is connected, this option is not available.

INE-W960/INE-NAV-60 only.

If the SiriusXM is not connected, this option is not available (INE-

W960/INE-NAV-60 only).

When AUX In is set to “iPod Video,” this option is not available.

16-EN

Touch Operation

About the Indicator Display

You can operate the system by using the touch panel on the screen.

• Be sure to touch the onscreen button lightly with the pad of your

finger to protect the display.

• If you touch a button and there is no reaction, remove your finger from the display once, and try again.

• Onscreen buttons that cannot be operated appear dull in color.

Common onscreen buttons

[]:Returns to the previous screen. Depending on the

function, this button may cancel the operations performed on the screen.

[]:Closes the window.

Selecting an Item in a List

To scroll through a list, perform the following operations.

Touch the screen and slide your finger up and down.

The screen will scroll along with your finger movement. Also, you can touch [] and [].

The Indicator Bar at the bottom of the screen displays various types of information, like the current time.

The display will differ depending on the source. For details, refer to the display example of each source. Lights up when connected to a BLUETOOTH compatible device.

: BLUETOOTH connection to audio device

: BLUETOOTH connection to Hands Free Phone Blinks while reconnecting. Does not display when connection is set to OFF.

Indicates the battery level of the connected BLUETOOTH device.

Battery

Level

Icon

This may not be displayed depending on the connected BLUETOOTH device.

Indicates the signal strength level of the connected BLUETOOTH compatible device.

Displayed when BLUETOOTH setting is ON.

No Battery Level 1 Level 2 Level 3

0123No Service

• After touching the screen, move your finger away from the screen

before dragging and that item will be selected.

The clock display

You can switch between the 12 hour display and 24 hour display options. For details on how to set the clock display, refer to “Clock Display Setting” (page 31).

17-EN

Displaying Audio/Visual Information on the Navigation screen

You can display the currently playing information (Frequency, Track No., etc.) in the Indicator Bar of the Navigation screen.

Tou ch [].

18-EN

Radio/RBDS

The RBDS (Radio Broadcast Data System) is a radio information system. The RBDS allows you to receive a variety of information such as traffic information, station names.

Display example for Radio main screen

Presetting Stations Manually

Tune in a desired radio station you wish to store in the preset memory by manual or automatic seek tuning.

Touch and hold any one of the preset buttons for at least 2 seconds.

The selected station is stored.

Repeat the procedure to store up to 5 other stations onto the same band.

To use this procedure for other bands, simply select the desired band and repeat the procedure.

A total of 18 stations can be stored in the preset memory (6 stations for each band; FM1, FM2 or AM).

• If a preset memory has already been set in the same preset number, it

will be cleared and the new station will be memorized.

Band display Displays the band of the signal currently being received. Frequency display Displays the frequency, song name and artist name of the signal currently being received. Preset button Registers and recalls preset frequencies. Seek mode Displays the current Seek mode.

Listening to the Radio

Touch [Radio] of Top banner.

The radio mode is activated and the display changes to the Radio mode screen.

Touch [Band] of Bottom banner to select the desired radio band.

Each touch changes the bands as follows:

FM1 FM2 AM FM1

Touch [Tune] to select the tuning mode.

DX Seek Local Seek Manual

• There are two modes you can select for auto tuning, DX and

Local:

- DX (Distance) mode;

Both strong and weak stations will be tuned in.

- Local mode;

Only strong stations will be tuned in. The initial setting is DX.

Presetting Stations Automatically

The tuner can automatically seek and store 6 strong stations in the selected band in ascending order of frequency.

After selecting the desired band, touch [A.Memo] of Bottom banner.

The tuner automatically seeks and stores 6 strong stations into the preset buttons in ascending order of frequency. When automatic storing has completed, the station stored in the preset 1 is selected.

• If no stations are stored, the tuner will return to the original station

you were listening to before the automatic storing procedure began.

• You can cancel this process by touching [A.Memo] while the tuner is

automatically seeking stations. Canceling will return the tuner preset to the previous setting.

Tuning to Preset Stations

You can tune in the preset stations in memory on either band using its preset number.

Touch [Band] of Bottom banner repeatedly until the desired band is displayed.

Touch any one of the preset buttons that has a station stored to it.

The preset station is received.

• Each time you press the , buttons, you can also change

the frequency registered into the preset buttons (1 through 6).

Touch [], [], [] or [] to change the radio frequency up or down respectively.

In manual mode, touch and hold to change the frequency continuously.

19-EN

PTY (Program Type) Tuning

FM Radio mode

Touch [PTY] of Bottom banner.

The Select PTY list screen is displayed.

Touch the selected program type to start searching for a station in the type.

If no PTY station is found, “No PTY.” will be displayed.

Displaying Radio Text

Text messages from a radio station can be displayed.

Tune in a radio station that transmits text messages.

Touch [Info] in the bottom banner in FM radio mode repeatedly to switch to the desired display.

RBDS

Station Info Mode (PS/PTY/ Frequency/Song Name)

Song Info Mode (PS/Song Name/Artist Name/Album Name)

Radio Text Mode (Radio Text)

20-EN

CD/MP3/WMA/AAC

Display example for MP3/WMA/AAC main screen

Repeat Play

Touch [] to repeatedly play back.

The tracks (files) will be played repeatedly. The repeat mode switches every time the button is touched.

CD:

Repeat (OFF) Repeat

MP3/WMA/AAC:

Repeat Repeat Folder* (OFF) Repeat

Song title Artist title Album title Current song no./Total song no. Playing time

• If there is no CD text, the message “No Text” appears.

Playback

Touch [Disc] of Top banner.

The display shows the Disc mode screen.

When a disc is inserted into the disc slot of this unit, with the label side facing up, the unit starts playback of the disc.

Touch [] or [] to select the desired track (file).

Returning to the beginning of the current track (file):

Touch [].

Fast reverse :

Touch and hold [].

Advancing to the beginning of the next track (file) :

Touch [].

Fast forward :

Touch and hold [].

• The , buttons provide the same functions above.

To pause playback, touch [ / ].

[] is displayed in the middle of the screen. Touch [/] again or touch [] in the middle of the screen to start playback.

• The INE-W960/INE-NAV-60/INE-W960S can play back MP3/WMA/

AAC files saved to CD or DVD. Use a format compliant with this unit. For further information about playing or storing MP3/WMA/AAC files, refer to pages 22 and 23 before using the unit.

• Any file protected by DRM (Digital Rights Management) copy

protection, cannot be played back on this unit.

• If a disc contains both audio data and MP3/WMA/AAC data, this unit

plays back only the audio data.

• The track display for CD audio data playback shows the track

numbers recorded on the disc.

• If an MP3/WMA/AAC disc with many files and folders is played, it

may take longer than normal to start playback.

• The playback time may not be correctly displayed when a VBR

(Variable Bit Rate) recorded file is played back.

* Only files in a folder are repeatedly played back.

• If the Repeat Play mode is activated during M.I.X. playback, the

M.I.X. mode will be canceled.

M.I.X. (Random Play)

Touch [] of Bottom banner during playback.

The tracks (files) on the disc will be played back in a random sequence.

The M.I.X. mode switches every time [] is touched.

CD:

M.I.X. (OFF) M.I.X.

MP3/WMA/AAC:

M.I.X. Folder* (OFF) M.I.X. Folder*

* Only files in a folder are played back in random sequence.

• If the M.I.X. mode is activated during Repeat playback, the Repeat

Play mode will be canceled.

• If you select a track by using the search mode, the M.I.X. play mode

will be canceled.

M.I.X. ALL (Shuffle Songs) (Concerning MP3/WMA/AAC)

All files in the disc are played back in random sequence.

Touch [ (Search)] of Bottom banner during playback.

Touch [Shuffle Songs].

The indicator lights, and the songs in a folder are played back in random sequence. When all the songs in the target folder have been played, the next folder plays back.

To cancel M.I.X. play, touch [].

21-EN

Selecting Folders (Concerning MP3/ WMA/AAC)

About MP3/WMA/AAC

Touch [] or [] of Bottom banner to select the folder.

Searching from CD Text

Touch [ (Search)] of Bottom banner during playback.

The CD text search screen is displayed.

Touch the selected track name.

The selected track will be played back.

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 17).

File/Folder Name Search (Concerning MP3/WMA/AAC)

Touch [ (Search)] of Bottom banner during playback.

The folder name list screen is displayed.

Folder Name Search mode

Touch [] in the desired folder.

The first file in the selected folder is played back.

File Name Search mode

Touch the desired folder name.

The File name of the selected folder is displayed.

Touch the desired file name.

The selected file is played back.

• To return to the previous hierarchy, touch [].

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 17).

• After selecting a folder via a Folder name search, touch [] on the

main screen to display the folder search screen.

• After selecting a file via a File name search, touch [] on the

main screen to display the file search screen.

CAUTION

Except for private use, duplicating audio data (including MP3/ WMA/AAC data) or distributing, transferring, or copying it, whether for free or for a fee, without permission of the copyright holder is strictly prohibited by the Copyright Act and by international treaty.

What is MP3?

MP3, whose official name is “MPEG Audio Layer 3,” is a compression standard prescribed by the ISO, the International Standardization Organization and MPEG which is a joint activity institution of the IEC.

MP3 files contain compressed audio data. MP3 encoding is capable of compressing audio data at extremely high ratios, reducing the size of music files to as much as one-tenth their original size. This is achieved while still maintaining near CD quality. The MP3 format realizes such high compression ratios by eliminating the sounds that are either inaudible to the human ear or masked by other sounds.

What is AAC?

AAC is the abbreviation for “Advanced Audio Coding,” and is a basic format of audio compression used by MPEG2 or MPEG4.

What is WMA?

WMA, or “Windows Media™ Audio,” is compressed audio data. WMA is similar to MP3 audio data.

Method for creating MP3/WMA/AAC files

Audio data is compressed using software with MP3/WMA/AAC codecs. For details on creating MP3/WMA/AAC files, refer to the user’s manual for that software. MP3/WMA/AAC files that are playable on this device have the file extensions. MP3: “mp3” WMA: “wma” (ver. 7.x, 8.x, 9.x are supported) AAC: “m4a” WMA is not supported for the following files, Windows Media Audio Professional, Windows Media Audio 9 Voice or Windows Media Audio 9 Pro Lossless (Disc Media Only).

There are many different versions of the AAC format. Confirm that the software being used conforms to the acceptable formats listed above. It’s possible that the format may be unplayable even though the extension is valid. Playback of AAC files encoded by iTunes is supported.

22-EN

Supported playback sampling rates and bit rates

MP3

Sampling rates: 8 kHz - 48 kHz (Disc/USB) Bit rates: 8 kbps - 320 kbps (Disc/USB)

WMA

Sampling rates: 32 kHz - 48 kHz (Disc)

8 kHz - 48 kHz (USB)

Bit rates: 64 kbps - 256 kbps (Disc)

5 kbps - 384 kbps (USB)

Order of files

Files are played back in the order that the writing software writes them to the disc. Therefore, the playback order may not be what’s expected. Verity the writing order in the software’s documentation. The playback order of the folders and files is as follows. (The following numbers may differ from actually displayed numbers.)

AAC

Sampling rates: 16 kHz - 96 kHz (Disc)

Bit rates: 32 kbps - 384 kbps (Disc)

This device may not play back correctly depending on sampling rates.

ID3 tags/WMA tags

This device supports ID3 tag v1.0, v1.1, v2.2, v2.3, v2.4, and WMA tag Ver.1.x. If tag data is in an MP3/WMA/AAC file, this device can display the title (track title), artist name, and album name ID3 tag/WMA tag data (maximum 64 characters). The number of characters may be limited, or not correctly displayed, depending on the tag information.

Playing back MP3/WMA/AAC

MP3/WMA/AAC files are prepared, then written to a CD-R, CDRW (DVD-R/DVD-RW/DVD+R/DVD+RW) using CD-R writing software and USB memory.

• Maximum numbers of playable files / folders Disc: 2,000 files/200 folders (including Root Folder/DivX USB memory: 10,000 files/folders (including Root Folder/ DivX

Playback may not be performed if a disc exceeds the limitations described above. If a file/folder name is long, the maximum possible number of files may decrease.

• Both Audio and Video files are counted if their formats are playable on this unit.

Media supported

The media that this device can play back are CD-ROMs, CD-Rs, CD-RWs, DVD-Rs, DVD-RWs, DVD+Rs, DVD+RWs and USB memory.

Corresponding File Systems

This device supports discs formatted with ISO9660 Level 1 or Level 2, UDF1.02 and UDF1.02(ISO Bridge).

Under the ISO9660 standard, there are some restrictions to remember.

The maximum nested folder depth is 8 (including the root directory). The number of characters for a folder/file name is limited.

Valid characters for folder/file names are letters A-Z (all caps), numbers 0-9, and ‘_’ (underscore).

This device can play back discs in Joliet, Romeo, etc., and other standards that conform to ISO9660. However, sometimes the file names, folder names, etc., are not displayed correctly.

Formats supported

This device supports CD-ROM Mode1, CD-ROM XA Mode2(Form1&2), Mixed Mode CD and Multi-Session. This device cannot correctly play back discs recorded with Track At Once or packet writing.

8 kHz - 48 kHz (USB)

48 kbps - 238 kbps (USB)

file)

Root Folder

Folder MP3/WMA/AAC File

Terminology

Bit rate

This is the “sound” compression rate specified for encoding. The higher the bit rate, the higher the sound quality, but also the larger the files.

Sampling rate

This value shows how many times per second the data is sampled (recorded). For example, music CDs use a sampling rate of 44.1 kHz, so the sound is sampled (recorded) 44,100 times per second. The higher the sampling rate, the higher the sound quality, but also the larger the volume of data.

Encoding

Converting music CDs, WAVE (AIFF) files, and other sound files into the specified audio compression format.

Tag

Song information such as track titles, artist names, album names, etc., written into MP3/WMA/AAC files.

Root folder

The root folder (or root directory) is found at the top of the file system. The root folder contains all folders and files. It is created automatically for all burned discs.

23-EN

DVD

Display example for DVD Video main screen

Touch [<<], [>>]

Display example for DivX

main screen

The DVD operation screen display

Touch the screen while the DVD playback screen is displayed.

The DVD operation screen is displayed.

• The operation screen changes to the visual screen in the DVD mode

for 5 seconds after an operation has been performed.

• If you try to activate the DVD while driving, the display will show the

warning-Picture off for your safety.

• Some operations cannot be carried out depending on the disc or

playback screen.

Touch [<<], [>>]

Information display-1

DVD-Video: Title name/Chapter No.

DivX

Title name/Current File No./Total File No. in Current Folder

Information display-2

DVD-Video: Audio signal output/Subtitle/Angle

DivX

Audio signal output/Subtitle

Playing time

Disc types that can be used for each heading are represented by the following marks.

DVD Commercial Video discs (used for the distribution of movies, etc.) or a DVD-R/DVDRW, DVD+R/DVD+RW recorded in a video mode can be used.

CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/ DVD+RW discs that are recorded in the

DivX

mode can be used.

24-EN

Playing a Disc

WARNING It is dangerous for the driver to watch the DVD/TV/ Video while driving the vehicle. The driver may be distracted from looking ahead and an accident could occur.

Install the INE-W960/INE-NAV-60/INE-W960S correctly so that the driver cannot watch DVD/TV/Video unless the vehicle is stopped and the emergency brake is applied.

If the INE-W960/INE-NAV-60/INE-W960S is not installed correctly, the driver will be able to watch the DVD/TV/Video while driving the vehicle and may be distracted from looking ahead causing an accident. The driver or other people could be severely injured.

If a Menu Screen Appears

On DVD mode, menu screens may appear automatically. If this happens, perform the operation described below to start playback.

Direct Menu Operations

Touch the DVD menu directly.

• Some operations cannot be performed depending on the disc.

Menu Operations

Touch [Key].

The menu operation mode will be displayed.

Caution

• Not all functions will operate for every DVD. See the

individual DVD’s instructions for details on the features supported.

• Fingerprints on a disc may adversely affect

playback. If a problem occurs, remove the disc and check for fingerprints on the playback side. Clean the disc if necessary.

• If you switch the power or Ignition key OFF or

change sources during playback, playback will continue where you left off when you resume playback.

• If you try to perform an invalid operation (based on

the type of disc being played), the following mark is displayed on the monitor screen:

• Play Position Memory Function

Even if you turn power off or switch the Ignition key to OFF during playback or change the source, playback will continue from the point where playback stopped when the power is turned ON again.

Touch [Disc] of Top banner.

The display shows the Disc mode screen. Or insert a disc with the label side facing up. The unit starts to play the disc.

• The reverse side of a double-sided DVD will not be played

automatically. Remove the disc, turn it over, and reinsert it.

• Refer also to “Disc Setting” (page 42).

• While reading a DivX

repeat functions, etc. cannot be used.

• A DivX

file that exceeds 4GB cannot be played back.

file, the fast-forwarding/fast-reversing and

Touch [] [] to change the Key panel location from right to left or vice-versa. Touch [Return] to return to the previous display.

Select a desired menu item by touching [], [], [] or [].

• Touching [] in the operation panel returns to the screen in

step 1.

• Touching [Key] displays the Numeric Keypad Input Mode

screen. For details of the Numeric Keypad Input Mode screen, refer to “Numeric Keypad Input Operations” (page 26).

Touch [Enter] to confirm the selected item.

25-EN

Numeric Keypad Input Operations

Touch [10Key] of Bottom banner.

The numeric keypad input mode screen appears If [10Key] is not displayed, touch [<<] in the bottom banner to display [10Key].

Touch a desired number.

Touch [] to delete an entered number. Touch [Delete All] to delete all entered number.

Touch [Enter] on the numeric keypad mode screen to confirm your selection.

Touch [] to hide the keypad display.

Displaying the Top Menu Screen

When a DVD contains two or more titles, the top menu screen appears.

Touch [Top Menu] of Bottom banner.

The top menu screen appears.

• To perform necessary operations, refer to “If a Menu Screen

Appears” (page 25).

Displaying the Menu Screen

Stopping Playback

Touch and hold [] for at least 2 seconds during playback.

“ ” indicator and [] in the middle of the screen are displayed.

• Playback starts from the beginning when [/ll] or [] in the

middle of the screen is touched while playback is stopped.

Fast-forwarding/Fast-reversing

During playback, touch and hold [] (Fast-reverse) or touch and hold [] (Fast-forward).

Touch and hold for more than 1 second to forward/reverse at double speed. Every time you touch [ ]/[ ] during fast- reverse/fastforward, the speed changes as follows: 2x 4x 8x 2x.

• Fo r a D i v X

fast forward and the reverse option is not available.

• The , buttons provide the same functions above.

Touch [/] to return to normal playback.

• No sound is played back during fast-forwarding/fast-reversing.

• On DVD mode, the menu screen may reappear during fast-

forwarding/fast-reversing.

• This operation may not be possible on certain discs.

file that does not contain index information, the

Finding the Beginnings of Chapters/ Tracks/Files

With a DVD having two or more menus, a menu screen will appear for the programs available, in addition to the main programs.

Touch [Menu] of Bottom banner.

The Root menu screen appears.

• To perform necessary operations, refer to “If a Menu Screen

Appears” (page 25).

Stopping Playback (PRE STOP)

Touch the stop button during playback to stop playback. That position is stored in the memory.

Touch [] during playback.

“Pre ” indicator and [] in the middle of the screen are displayed.

Touch [/ll] in the PRE STOP mode or touch [] in the middle of the screen.

Playback starts from the position at which it was stopped.

• For some discs, the position at which playback was stopped may not

be accurate.

During playback, touch [] or [].

The chapter/track/file switches each time the button is touched, and playback of the selected chapter/track/file starts.

: Touch this to start playback from the beginning of the

current chapter, track or file.

: Touch this to start playback from the beginning of the

following chapter, track or file.

• Some DVDs do not have chapters.

• The , buttons provide the same functions above.

Supplementary explanations

“Chapters” are divisions of movies or musical selections on DVDs.

26-EN

Playing Still Frames (Pausing)

During playback, Touch [/] of Bottom banner.

Touch [/] or [] in the middle of the screen to resume playback.

• No sound is played during the still frame mode.

• The image or sound may stop temporarily when playback starts from

the pause mode. This is not a malfunction.

Slow Motion Playback

When [] is touched and held while in the pause mode, the 1/16th speed slow motion playback mode is set. Furthermore, when touched and held [] again, the slow motion speed switches to 1/2 the normal speed.

• The buttons provide the same functions above.

Touch [/] of Bottom banner to play back.

• No sound is played during slow motion playback.

• 1/2, 1/16 are approximate speeds. The actual speed differs from disc

to disc.

• You cannot execute reverse slow motion playback.

Selecting Folders

Touch [] or [] of Bottom banner to select the folder.

• Touch [] to play from the first file of the previous folder. Touch [] to play from the first file of the next folder.

Repeat Playback

Use this function to play the disc’s titles, chapters or tracks, etc., repeatedly.

Touch [] of Bottom banner.

The repeat mode switches every time the button is touched.

DVD Video

The chapter is played repeatedly.

The title is played repeatedly.

Playback returns to normal mode.

The file is played repeatedly.

The disc is played repeatedly.

DivX

(Chapter)

(Title)

(OFF)

(File)

(Folder) The folder is played repeatedly.

(Repeat All)

Searching by Title Number

Use this function to easily find positions on the DVD using the DVD’s titles. Perform operations while playback is stopped.

Touch [10Key] of Bottom banner.

The numeric keypad input mode screen appears. If [10Key] is not displayed, touch [<<] in the bottom banner to display [10Key].

• For DVD Video, the numeric keypad can also be displayed by

touching the Menu screen and then touching [Key] twice.

Enter a desired title by touching its number.

See page 26 for operation of the numeric keypad.

Touch [Enter].

Playback will start from the number selected.

Touch [].

• This function cannot be used on discs on which no title numbers are

recorded.

• Some disc may not accept any operation.

27-EN

Searching Directly by Chapter Number

Use this function to easily move to the beginnings of the chapters on the disc. Perform operations during playback, during PRE-STOP or while playback is paused.

Touch [10Key] of Bottom banner.

The numeric keypad input mode screen will appear. If [10Key] is not displayed, touch [<<] in the bottom banner to display [10Key].

Touch and enter the chapter number you want to play.

See page 26 for operation of the numeric keypad.

Touch [Enter] to confirm your selection.

Playback will start from the selected chapter.

Touch [].

• This function is not available for a disc on which chapters are not stored.

Searching for a Desired Video File

You can select a video file from the list screen.

Touch [ (Search)] of Bottom banner.

The search mode is activated.

Touch [Video].

The folder list screen appears.

Folder Name Search mode

Touch [] in the desired folder.

The first file in the selected folder is played back.

File Name Search mode

Touch the desired folder name.

The File name of the selected folder is displayed.

Touch the desired file name.

The selected file is played back.

• To return to the previous hierarchy, touch [].

• For details on how to scroll through the list, refer to “Selecting an

Item in a List” (page 17).

• After selecting a folder via a Folder name search, touch [] on the main screen to display the folder search screen.

• After selecting a file via a File name search, touch [] on the main screen to display the file search screen.

Switching the Angle

On DVDs in which scenes have been filmed from multiple angles, the angle can be switched during playback.

Touch [Angle] of Bottom banner.

The angle switches between the angles recorded on the disc every time the button is touched. If [Angle] is not displayed, touch [<<] or [>>] in the bottom banner to display [Angle].

• Some time may be required for the angle to change.

• Depending on the disc, the angle may switch in one of two ways.

- Seamless: The angle switches smoothly.

- Non-seamless: When the angle is switched, a still picture is

displayed first, after which the angle switches.

Switching the Audio Tracks

DVDs with multiplex audio or audio languages allow switching the sound during playback.

Touch [Audio] of Bottom banner.

The sound switches between the alternate audio tracks recorded on the disc every time the button is touched. If [Audio] is not displayed, touch [<<] or [>>] in the bottom banner to display [Audio].

• The alternate track selected becomes the default setting every time

the power is turned on or the disc is replaced. If the disc does not include that track, the disc’s default language is selected instead.

• Not all discs will allow changing the alternate audio tracks during

playback. In these cases, select audio tracks from the DVDs menu.

• There may be a delay before the selected alternate track begins to

play.

Switching the Subtitles (Subtitle Language)

With DVDs on which multiple subtitle languages are recorded, the subtitle language can be switched during playback; moreover, subtitles can be hidden.

Touch [Subtitle] of Bottom banner.

Touching this button repeatedly selects sequentially the subtitle languages recorded on the disc, and then turns the subtitles OFF. If [Subtitle] is not displayed, touch [<<] or [>>] in the bottom banner to display [Subtitle].

• There may be a delay before the selected subtitle appears.

• Not all discs will allow changing the subtitles during playback. In

these cases, select subtitles from the DVDs menu.

• The subtitle language selected becomes the default setting every time

the power is turned on or the disc is replaced. If the disc does not include that language, the disc’s default language is selected instead. However, the subtitle language may differ depending on the disc.

28-EN

About DivX

DivX® is a codec (software) to compress moving images while maintaining image quality using a highly advanced compression ratio and operating speed.

• Official DivX

ABOUT DIVX VIDEO: DivX DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX Certified more information and software tools to convert your files into DivX videos. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified must be registered in order to play purchased DivX Video-onDemand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

Certified product

is a digital video format created by

device that plays DivX video. Visit divx.com for

device

Media supported

The unit can play back CD-R/CD-RW/DVD-R/DVD-RW/DVD+R/ DVD+RW discs and USB memory device that are recorded in

the DivX

mode.

• DivX® files stored in a USB memory device and protected by

DRM (Digital Rights Management) cannot be played.

• Some DivX files stored in a USB memory cannot be operated/

played.

Corresponding extension

“avi,” “divx”

Video Codec

DivX® versions 3, 4, 5, and 6 (versions 5 handle both interlaced and progressive)

Audio Codec

MPEG1 Layer2 (MP2) 32 to 384 kbps MPEG1 Layer3 (MP3) 32 to 320 kbps MPEG2 Layer2 (MP2) 8 to 160 kbps MPEG2 Layer3 (MP3) 8 to 160 kbps Dolby Digital 32 to 448 kbps

Image bit rate

“average 4 Mbps, Peak 8 Mbps” Home Theater Profile supported

29-EN

Setup

Setup Operation

Touch the [SETUP] icon on the Audio/Visual Playback screen to display the Setup main screen.

[Setup] icon

General Setup

Touch [General].

The General Setup screen appears.

Select the desired item.

General Setup Operation

To display the General Setup Menu screen:

Your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow the procedures below.

1 Bring your vehicle to a complete stop at a safe

location. Engage the parking brake.

2 Release the parking brake (for your safety, operate

while depressing the foot brake pedal).

3 Engage the parking brake again.

• For automatic transmission vehicles, place the transmission lever

in the Park position.

Now, the locking system for the General mode operation has been released. Engaging the parking brake can reactivate the General Setup Menu, as long as the car’s ignition has not been turned off. It is not necessary to repeat the above procedure (1 through 3) of “To display the General mode screen.” Each time the ignition is turned OFF, perform the procedure of “To display the General mode screen.”

The following steps 1 to 5 are common operations to each “Setting item” of General Setup. Refer to each section for details.

Tou ch [Setup] icon of Top banner.

The Setup main screen is displayed.

Setting items: Text Display / Clock Display /

• Depending on the item, repeat step 3.

Touch [] or [] etc., to change its setting.

• When the pop-up window for setup is displayed, touch [] to

Touch [] to return to the previous screen.

• Immediately after changing the settings of General Setup (While the

system is writing data automatically) do not turn the ignition key to OFF. Otherwise, the settings may not be changed.

Top/Bottom Banner Fade Out / Screen/LED Customize / Visual / About / Installation / Demo mode

close the window after setting.

Text Display Setting

[Text Display] is selected on the General setup menu in step 3. Refer to “General Setup Operation” (page 30).

Setting the Scroll

Scroll display is available if CD text, folder name, file name or tag information is entered.

Setting item: Auto Scroll Setting contents: Off (Initial setting) / On

Off: Turns off the scroll mode. On: Turns on the Auto scroll mode. Scroll display is repeated

as long as the mode is turned on.

30-EN

+ 70 hidden pages
