IN-DASH GPS NAVIGATION RECEIVER

EN

INA-W900

FR

ES

• OWNER’S MANUAL

Please read before using this equipment.

• MODE D’EMPLOI

Veuillez lire avant d’utiliser cet appareil.

• MANUAL DE OPERACIÓN

Léalo antes de utilizar este equipo.

ALPINE ELECTRONICS MARKETING, INC.

ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD.

ALPINE ITALIA S.p.A.

1-1-8 Nishi Gotanda,

161-165 Princes Highway, Hallam

Viale C. Colombo 8, 20090 Trezzano

Shinagawa-ku,

Victoria 3803, Australia

Sul Naviglio (MI), Italy

Tokyo 141-0031, Japan

Phone 03-8787-1200

Phone 02-484781

Phone 03-5496-8231

ALPINE ELECTRONICS GmbH

ALPINE ELECTRONICS DE ESPAÑA, S.A.



ALPINE ELECTRONICS OF AMERICA, INC.

Wilhelm-Wagenfeld-Str. 1-3, 80807 München, Germany

Portal de Gamarra 36, Pabellón, 32

19145 Gramercy Place, Torrance,

Phone 089-32 42 640

01013 Vitoria (Alava)-APDO 133, Spain

California 90501, U.S.A.

ALPINE ELECTRONICS OF U.K. LTD.

Phone 945-283588

Phone 1-800-ALPINE-1 (1-800-257-4631)

ALPINE ELECTRONICS (BENELUX) GmbH

1-888-NAV-HELP (1-888-628-4357)

Alpine House



Fletchamstead Highway, Coventry CV4 9TW, U.K.

Leuvensesteenweg 510-B6,

ALPINE ELECTRONICS OF CANADA, INC.

Phone 0870-33 33 763

1930 Zaventem, Belgium

777 Supertest Road, Toronto,

ALPINE ELECTRONICS FRANCE S.A.R.L.

Phone 02-725-13 15

Ontario M3J 2M9, Canada



Phone 1-800-ALPINE-1 (1-800-257-4631)

(RCS PONTOISE B 338 101 280)



1-888-NAV-HELP (1-888-628-4357)

98, Rue de la Belle Etoile, Z.I. Paris Nord Il,





B.P. 50016, 95945 Roissy Charles de Gaulle





Cedex, France





Phone 01-48638989







Designed by ALPINE Japan





68-14470Z66-A

ENGLISH

Contents

Operating Instructions

PRECAUTIONS AND NOTICES



IMPORTANT INFORMATION .......................

5

USER AGREEMENT ......................................

6

END USER LICENSE AGREEMENT



(Microsoft) ....................................................

6

WARNING



Points to Observe for Safe Usage .........

8

WARNING .................................................

8

CAUTION ..................................................

8

PRECAUTIONS ........................................

9

Discs Playable on This Unit .................

10

Getting Started



Accessory List ................................................

14

Location of Controls ......................................

14

Turning Power On or Off ...............................

14

Inserting/Ejecting a Disc ................................

15

Inserting/Removing the SD Memory Card ....

15

Adjusting the Monitor Viewing Angle ...........

15

Adjusting the Volume .....................................

15

Lowering Volume Quickly .............................

15

How to view the Display ................................

16

Soft button operation ..................................

16

Recalling the Source ...................................

16

Displaying the Numeric Keypad



Input Screen .............................................

17

Navigation



Basic Operation ..............................................

17

Turning the Navigation System On ............

17

Navigation Main Menu ...............................

18

Map Functions ............................................

18

From the Map Display ...................................

19

Setting a Destination ...................................

19

Finding Local Places ...................................

20

Setting Waypoints .......................................

20

Input a Destination ..........................................

20

Go to Menu ..................................................

20

Set a Destination by Address .......................

21

Set a Destination by Place ...........................

22

Set a Destination by History ........................

23

Set a Destination from the



Address Book ...........................................

24

Set a Destination by Coordinates ................

24

Set a Destination by Intersection .................

24

Destination Options ........................................

25

Finding Nearby Places .................................

25

Finding Alternative Routes to the



Destination ...............................................

26

Setting a Destination as Home ....................

26

Saving a Destination into the



Address Book ...........................................

26

Setting Waypoints ........................................

26

ROUTE ...........................................................

28

Viewing Turn List During Guidance ...........

28

Finding an Alternate Route .........................

28

Finding a Detour ..........................................

28

Editing Waypoints .......................................

29

Canceling Route ..........................................

29

Home ...............................................................

29

Going Home ................................................

29

GUIDEVIEW WINDOW™ Function ............

29

Turn on the GUIDEVIEW WINDOW™



Mode ........................................................

29

GUIDEVIEW WINDOW™ Display ..........

29

Settings ............................................................

30

Settings Menu ..............................................

30

Customizing Display ...................................

31

Customizing Map ........................................

31

Customizing Navigation Tool ......................

32

Setting Audio ...............................................

32

Regional Settings .........................................

32

Information .....................................................

33

Information Menu ........................................

33

Viewing Dashboard .....................................

33

Viewing GPS Status .....................................

33

Viewing System Information .......................

34

1-EN

Radio



Listening to the Radio .....................................

34

Presetting Stations Manually ..........................

35

Presetting Stations Automatically ..................

35

Tuning to Preset Stations ................................

35

Storing the tag information



(HD Radio™ mode only) ............................

35

Changing the Display



(HD Radio™ mode only) ............................

36

Receiving a Multicast



(HD Radio™ mode only) ............................

36

CD/MP3/WMA/AAC



Playback ..........................................................

37

Repeat Play .....................................................

37

M.I.X. (Random Play) ....................................

37

Selecting Folders



(concerning MP3/WMA/AAC) ...................

37

About MP3/WMA/AAC .................................

38

DVD



Playing a Disc ................................................

39

To display the DVD mode screen ...............

40

If a menu screen appears .............................

40

Displaying the Top Menu Screen ...............

41

Displaying the Menu Screen ......................

41

Displaying the Menu Operation



Mode Screen ...........................................

41

Searching by Program ....................................

41

Searching by Playlist .....................................

41

Stopping Playback (PRE STOP) ...................

41

Stopping Playback .........................................

41

Fast-forwarding/Fast-reversing ......................

41

Finding the Beginnings of Chapters ..............

42

Playing Still Frames (Pausing) ......................

42

Forward/reverse frame-by-frame



Playback .....................................................

42

Slow Motion Playback ...................................

42

Selecting Program (SKIP) .............................

42

Selecting Playlist (SKIP) ...............................

42

Repeat Playback ............................................

42

Searching by Title/Program/Playlist ..............

43

Searching Directly by Chapter Number ........

43

Switching the Angle ......................................

43

Switching the Audio Tracks ..........................

43

2-EN



Switching the Subtitles



(Subtitle Language) ....................................

44

Switching from the disc menu .......................

44

Other Useful Features



Adjusting the Audio ........................................

44

Search Function ..............................................

45

Switching Display Modes ...............................

46

Setup



DVD Setup



DVD Setup Operation .....................................

47

Changing the language setting ....................

47

Setting of the Menu Language ....................

48

Setting of the Audio Language ...................

48

Setting of the Subtitle Language .................

48

Changing the Country Code Setting ...........

48

Setting the Rating Level



(Parental Lock) ........................................

48

Setting the TV Screen Mode .......................

49

Playing MP3/WMA/AAC Data



(File Play Mode) ......................................

49

RADIO Setup



Digital SEEK Setting



(HD Radio™ mode only) ............................

50

DISPLAY Setup



Display Setup Operation .................................

50

Visual EQ Setting Operation .......................

51

Setting the Brightness of the



Backlighting .............................................

51

Adjusting the Minimum Level of



Backlight ..................................................

52

Setting the Function Guide display



ON/OFF ...................................................

52

Switching the Font Back Display Color ......

52

Adjusting the Touch Panel ..........................

52

GENERAL Setup



General Setup Operation ................................

52

Displaying the Time ....................................

53

Sound (Beep) Guide Function .....................

53

Setting the Scroll .........................................

53

Adjusting the Dimmer of Button Lighting



at Night ....................................................

53

SYSTEM Setup



System Setup Operation .................................

53

Setting the External Device



Interrupt Mode .........................................

54

Setting the Interrupt Icon Display ...............

54

Switching the function of the remote



sensor .......................................................

54

Setting the Rear Camera Input ....................

54

Setting the AUX Mode ................................

55

Adjusting the External Input



Audio Level .............................................

55

Switching the Visual Input



Signal System ..........................................

55

Setting the Picture Output ...........................

55

Setting the BLUETOOTH Connection



(BLUETOOTH IN) ..................................

55

Setting the AUX+ Mode ..............................

55

Adjusting the AUX+ Audio Level ..............

55

Setting the Rear Entertainment System .......

55

Sirius Setup



Sirius Setup Operation ....................................

56

Clearing the Lock of Channels .......................

56

Clearing the Setting of Hidden Channels .......

56

Setting the Favorite Sports Team



announcement .............................................

56

Setting the Sirius Seek (S-Seek) Alert ............

57

IMPRINT Operation (Optional)



Changing MultEQ mode .................................

58

Adjusting Sound Setting in Manual Mode .....

58

Storing Settings in the Memory ......................

61

Calling up the Preset Memory ........................

61

Setting the Subwoofer ....................................

61

About Time Correction ...................................

62

About the Crossover .......................................

63

BLUETOOTH Operation (Optional)



Setup Before Using .........................................

64

About BLUETOOTH ..................................

64

Before Using Hands-Free Function ............

64

How to connect to a BLUETOOTH



compatible device (Pairing) .....................

64

BLUETOOTH Setup ......................................

64

BLUETOOTH Setup Operation ..................

64

Hands-Free Phone Control .............................

66

About the Hands-Free Phone ......................

66

Answering a Call ............................................

66

Hanging up the Telephone ..............................

66

Adjusting the volume when receiving



a Call ...........................................................

66

Redial Function ...............................................

66

Call Switching Operation ...............................

67

Call History .....................................................

67

Redialing a Number in Dialed



Calls History ............................................

67

Dialing a Number in Received



Calls History ............................................

67

Dialing a Number in Missed



Calls History ............................................

67

Dialing a Number In the Phone Book



(Phone Book) ...........................................

67

Voice Dial Operation ...................................

68

Dialing a Number Using Direct



Dial Input .................................................

68

BLUETOOTH Audio Function ......................

68

BLUETOOTH Audio Operation .................

68

Auxiliary Device (Optional)



Operating Auxiliary Devices (Optional) ........

69

Rearview Camera Operation



(Optional)



Switching the Rear Camera Screen



(Optional) ....................................................

70

Displaying the rear view video while



the car is in reverse ..................................

70

Displaying the rear view video



manually ..................................................

70

Changer (Optional)



Controlling CD Changer (Optional) ...............

70

Multi-Changer Selection (Optional) ...............

71

SAT Radio Receiver (Optional)



Receiving Channels with the SAT Receiver



(Optional) ....................................................

71

Tuning in to Categorized Programs ................

72

Changing the Display .....................................

72

Checking the SAT Radio ID Number .............

72

Storing Channel Presets ..................................

72

Receiving Stored Channels .............................

72

Search Function (XM mode) ..........................

73

Search Function (Sirius mode) .......................

73

Selecting the Channel directly ........................

73

Receiving Weather or Traffic information from

SAT Radio ...................................................

73



3-EN

Storing the desired Song/Artist



(Sirius mode only) .......................................

74

Storing desired Sports Teams



(Sirius mode only) .......................................

74

Activating the stored Alert



(Sirius mode only) .......................................

74

Offset Playback Function



(Sirius mode only) .......................................

74

USB Memory (Optional)



BANK Function (USB memory only) ............

75

Playback ..........................................................

75

Repeat Play .....................................................

75

Random Play Shuffle (M.I.X.) .......................

76

Searching for a desired Song ..........................

76

Searching by artist name .............................

76

Selecting Playlist/Artist/Album/



Genre/Composer .........................................

76

Select the desired Folder



(Folder up/down) .........................................

77

Creating the playlist from the Artist/Album



information of the current song ...................

77

About MP3/WMA/AAC File of



USB Memory ..............................................

77

iPhone/iPod (Optional)



Playback ..........................................................

77

Searching for a desired Song ..........................

78

Searching by artist name .............................

78

Selecting Playlist/Artist/Album/Genre/



Composer/Episode/Category .......................

78

Random Play Shuffle (M.I.X.) .......................

79

Repeat Play .....................................................

79

Information



About DVDs ...................................................

79

Terminology ....................................................

80

List of Language Codes ..................................

81

List of Country Codes .....................................

82

In Case of Difficulty .......................................

84

Specifications ..................................................

89

4-EN

Installation and Connections

Warning ..................................................

90

Caution ...................................................

90

Precautions ............................................

90

Installation ......................................................

91

Connections ....................................................

94

System Example .............................................

97

LIMITED WARRANTY

Operating Instructions

PRECAUTIONS AND NOTICES

IMPORTANT INFORMATION

PLEASE READ CAREFULLY BEFORE USING THIS PRODUCT

This product is intended to provide turn by turn instructions to get you to a desired destination. Please make certain that all persons using this navigation system carefully read these precautions and the following instructions fully.

This product is not a substitute for your personal judgment. Any route suggestions made by this navigation system may never supersede any local traffic regulations or your personal judgment and/or knowledge of safe driving practices. Do not follow route suggestions if the navigation system instructs you to perform an unsafe or illegal maneuver, places you in an unsafe situation, or routes you into an area which you consider unsafe.

Glance at the screen only when necessary and safe to do so. If prolonged viewing of the screen is necessary, pull over in a safe and legal manner and location.

Do not input destinations, change settings, or access any functions requiring a prolonged view of the monitor and/or remote control while you are driving. Pull over in a safe and legal manner and location before attempting to access the system.

Do not use the navigation system to route you to emergency services. Not all locations of emergency services such as police and fire stations, hospitals and clinics are contained in the database. Please use your own judgment and ask for directions in these situations.

The map database used in the navigation system is the most recent map data available at the time of production. Because of changes in streets and neighborhoods, there may be situations where the navigation system is not able to route you to your desired destination. In these cases, use your own judgment.

The map database is designed to provide you with route suggestions and does not take into account the relative safety of a suggested route or of factors which may affect the time required to reach your destination. The system does not reflect road closures or construction, road characteristics (i.e. type of road surface, slope or grade, weight or height restrictions, etc.), traffic congestion, weather conditions, or any other factors which may affect the safety or timing of your driving experience. Use your own personal judgment if the navigation system is unable to provide you with an alternate route.

There may be situations where the navigation system displays the vehicle’s location erroneously. Use your own driving judgment in this situation, taking into account current driving conditions. Please be aware that in this situation the navigation system should correct the vehicle’s position automatically. However, there may be times where you may have to correct the position yourself. If this is the case, pull over in a safe and legal manner and location before attempting operation.

Make certain that the volume level of the navigation system is set to a level which still allows you to hear outside traffic and emergency vehicles.

If there is anything in the manual about the operation of the navigation system which you are uncertain about, please contact your local Alpine authorized navigation dealer or Alpine at 1-888-NAV-HELP (1-888-628-4357) before using the navigation system.

FCC COMPLIANCE STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide more reasonable protection against harmful interference in a residential installation, and are more stringent than “outdoor” requirements.

Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, you are encouraged to try to correct the interference by one of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult an experienced radio/TV technician.

5-EN

USER AGREEMENT

In using this Navigation System (hereinafter referred to as “System”), which includes Alpine Electronics, Inc. (“Alpine”) Specifications, Space Machine, Inc. (“Space Machine”) Software and NAVTEQ North America, LLC. (“NAVTEQ”) Database, you are bound by the terms and conditions set forth below. By breaking the seal on the System and using your copy of the System, you have demonstrated your agreement to the terms and conditions of this Agreement. You should, therefore, make sure that you read and understand the following provisions.

The System may not be copied, duplicated or otherwise modified, in whole or in part, without the express written permission of Alpine, Space Machine and NAVTEQ.

The System may not be transferred or sublicensed to any third party for profit, rent or loan or licensed for reuse in any manner. The System may not be decompiled, reverse engineered or otherwise disassembled, in whole or in part.

The System may not be used in a network or by any other manner of simultaneous use in multiple systems.

The System is intended solely for personal use (or internal use where the end-user is a business) by the consumer.

The System is not to be used for commercial purposes. Neither Alpine, Space Machine nor NAVTEQ guarantees to the customer that the System meet the specific objectives of the user.

Neither Alpine, Space Machine nor NAVTEQ shall be responsible for any damages caused by the use of the System to the actual user and to any third party.

The warranty on the System shall not extend to an exchange or refund due to misspelling, omission of letters, or any other cosmetic discrepancy in layout found in the System.

The right to use the System shall expire either when the user destroys this software, or when any of the terms for use is violated and Alpine, Space Machine and/or NAVTEQ exercise the option to revoke the license to use this software.

The terms and conditions hereof apply to all subsequent users and owners as well as to the original purchaser.

The NAVTEQ Database may include or reflect data of licensors, including Her Majesty The Queen in right of CANADA. Such data is licensed on an “AS IS” basis. The licensors, including Her Majesty The Queen, make no guarantees, representations or warranties respecting such data, either express or implied, arising by law or otherwise, accuracy or fitness for a particular purpose.

The licensors, including Her Majesty The Queen, shall not be liable in respect of any claim, demand or action, irrespective of the nature of the cause of the claim, demand or action alleging any loss, injury or damages, direct or indirect, which may result from the use or possession of the data or the NAVTEQ database. The licensors, including Her Majesty The Queen, shall not be liable in any way for loss of revenues or contracts, or any other consequential loss of any kind resulting from any defect in the data or the NAVTEQ database.

End User shall indemnify and save harmless the licensors, including Her Majesty The Queen and the minister, and their officers, employees and agents from and against any claim, demand or action, irrespective of the nature of the cause of the claim, demand or action, alleging loss, costs, expenses, damages or injuries (including injuries resulting in death) arising out of the use or possession of the data or the NAVTEQ database.

6-EN

END USER LICENSE AGREEMENT (Microsoft)

You have acquired a device (“DEVICE”) that includes software licensed by Alpine Electronics, Inc. (collectively “ALPINE”) from an affiliate of Microsoft Corporation (collectively “MS”). Those installed software products of MS origin, as well as associated media, printed materials, and “online” or electronic documentation (“SOFTWARE”) are protected by international intellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights reserved.

IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT (“EULA”), DO NOT USE THE DEVICE OR COPY THE SOFTWARE INSTEAD, PROMPTLY CONTACT ALPINE FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND. ANY USE OF THE SOFTWARE, INCLUDING BUT NOT LIMITED TO USE ON THE DEVICE, WILL CONSTITUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATION OF ANY PREVIOUS CONSENT).

GRANT OF SOFTWARE LICENSE,

This EULA grants you the following license: You may use the SOFTWARE only on the DEVICE.

NOT FAULT TOLERANT.

THE SOFTWARE IS NOT FAULT TOLERANT. ALPINE HAS INDEPENDENTLY DETERMINED HOW TO USE THE SOFTWARE IN THE DEVEICE, AND MS HAS RELIED UPON ALPINE TO CONDUCT SUFFICIENT TESTING TO DETERMINE THAT THE SOFTWARE IS SUITALE FOR SUCH USE.

NO WARRANTIES FOR THE SOFTWARE,

THE SOFTWARE is provided “AS IS“ and with all faults. THE ENTIRE RISK AS TO SATISFACTORY QUALITY, PERFORMANCE, ACCURACY, AND EFFORT (INCLUDING LACK OF NEGALIGENCE) IS WITH YOU. ALSO, THERE IS NO WARRANTY AGAINST INTERFERENCE WTH YOUR ENJOYMENT OF THE SOFTWARE OR AGAINST INFRINGEMENT. IF YOU HAVE RECEIVED ANY WARRANTIES REGARDING THE DEVICE OR SOFTWARE THOSE WARRANTIES DO NOT ORIGINATE FROM, AND ARE NOT BINDING ON, MS.

NO LIABILITY FOR CERTAIN DAMAGES.

EXCEPTAS PROHIBITED BY LAW, MS SHALL HAVE NO LIAVILITY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL OR THE SOFTWARE. THIS LIMITATION SHALL APPLY EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE. IN NO EVENT SHALL MS BE LIABLE FOR ANY AMOUNT IN EXCESS OF U.S. TWO HUNDRED FIFTY DOLLARS (U.S. $250.00).

LIMITATIONS ON REVERSE ENGINEERING, DECOMPILATION, AND DISASSEMBLY

You may not reverse engineer, decompile, or disassemble the SOFTWARE, except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation.

ADDITIONAL SOFTWARE/SERVICES.

The SOFTWARE may permit ALPINE, MS, Microsoft Corporation or their affiliates to provide or make available to you SOFTWARE updates, supplements, add-on components, or Internet – base service components of the SOFTWARE after the date you obtain your initial copy of the SOFTWARE (“Supplemental Components”).

If ALPINE provides or makes available to you Supplemental Components and no other EULA terms are provided along with the Supplemental Components, then the terms of this EULA shall apply.

If MS, Microsoft Corporation or their affiliates make available Supplemental Components, and no other EULA terms are provided, then the terms of this EULA shall apply, except that MS, Microsoft Corporation or affiliate entity providing the Supplemental Component(s) shall be licensor of the Supplemental Component(s).

ALPINE, MS, Microsoft Corporation and their affiliates reserve the right to discontinue any Internet-based services provided to you or made available to you through the use of the SOFTWARE.

RECOVERY MEDIA.

If SOFTWARE is provided by ALPINE on separate media and labeled “Recovery Media” you may use the Recovery Media solely to restore or reinstall the SOFTWARE originally installed on the DEVICE.

UPGRADES.

If the SOFTWARE is provided by ALPINE separate from the DEVICE on separate media or via web download or other means, and is labeled “For Upgrade Purposes Only” you may install one (1) copy of such SOFTWARE onto the DEVICE as a replacement copy for the existing SOFTWARE, and use it in accordance with this EULA, including any additional EULA terms accompanying the upgrade SOFTWARE.

TERMINATION.

Without prejudice to any other rights, ALPINE or MS may terminate this EULA if you fail to comply with the terms and conditions of this EULA. In such event, you must destroy all copies of the SOFTWARE and all of its component parts.

INTELLECTUAL PROPERTY RIGHTS.

All title and intellectual property rights in and to the SOFTWARE (including but not limited to any images, photographs, animations, video, audio, music, text and “applets,” incorporated into the SOFTWARE), the accompanying printed materials, and any copies of the SOFTWARE, are owned by MS, Microsoft Corporation, their affiliates or suppliers. The SOFTWARE is licensed, not sold.

You may not copy the printed materials accompanying the SOFTWARE. All title and intellectual property rights in and to the content which may be accessed through use of the SOFTWARE is the property of the respective content owner and may be protected by applicable copyright or other intellectual property laws and treaties. This EULA grants you no rights to use such content. All rights not specifically granted under this EULA are reserved by MS, Microsoft Corporation, their affiliates and suppliers. Use of any on-line services which may be accessed through the SOFTWARE may be governed by the respective terms of use relating to such services. If this SOFTWARE contains documentation that is provided only in electronic form, you may print one copy of such electronic documentation.

TRADEMARKS.

This EULA does not grant you any rights in connection with any trademarks or service marks of ALPINE MS, Microsoft Corporation, their affiliates or suppliers.

PRODUCT SUPPORT.

Product support for the SOFTWARE is not provided by MS, its parent corporation Microsoft Corporation, or their affiliates or subsidiaries. For product support, please refer to ALPINE support number provided in the documentation for the DEVICE. Should you have any questions concerning this EULA, or if you desire to contact ALPINE for any other reason, please refer to the address provided in the documentation for the DEVICE.

SOFTWARE TRANSFER ALLOWED BUT WITH RESTRICTIONS.

You may permanently transfer rights under this EULA only as part of a permanent sale or transfer of the Device, and only if the recipient agrees to this EULA. If the SOFTWARE is an upgrade, any transfer must also include all prior versions of the SOFTWARE.

EXPORT RESTRICTION.

You acknowledge that SOFTWARE is of US-origin. You agree to comply with all applicable international and national laws that apply to the SOFTWARE, including the U.S. Export Administration Regulations, as well as end-user, end-use and country destination restrictions issued by U.S. and other governments. For additional information on exporting the SOFTWARE, see http://www.microsoft.com/exporting/

7-EN

WARNING

Points to Observe for Safe Usage

Read this manual carefully before using this disc and system components. They contain instructions on how to use this product in a safe and effective manner. Alpine cannot be responsible for problems resulting from failure to observe the instructions in this manual.

This manual uses various pictorial displays to show you how to use this product safely and to alert you to potential dangers resulting from improper connections and operation. Following are the meanings of these pictorial displays. It is important to fully understand the meanings of these pictorial displays in order to use this manual and the system properly.

WARNING

This symbol means important instructions. Failure to heed them can result in serious injury or death.

INSTALL THE PRODUCT CORRECTLY SO THAT THE DRIVER CANNOT WATCH TV/VIDEO UNLESS THE VEHICLE IS STOPPED AND THE EMERGENCY BRAKE IS APPLIED.

It is dangerous (and illegal in many states) for the driver to watch TV/Video while driving a vehicle. Installing this product incorrectly enables the driver to watch TV/Video while driving. This may cause a distraction, preventing the driver from looking ahead, thus causing an accident. The driver or other people could be severely injured.

DO NOT WATCH VIDEO WHILE DRIVING.

Watching the video may distract the driver from looking ahead of the vehicle and cause an accident.

DO NOT OPERATE ANY FUNCTION THAT TAKES YOUR ATTENTION AWAY FROM SAFELY DRIVING YOUR VEHICLE.

Any function that requires your prolonged attention should only be performed after coming to a complete stop. Always stop the vehicle in a safe location before performing these functions. Failure to do so may result in an accident.

DO NOT FOLLOW ROUTE SUGGESTIONS IF THE NAVIGATION SYSTEM INSTRUCTS YOU TO PERFORM AN UNSAFE OR ILLEGAL MANEUVER, OR PLACES YOU IN AN UNSAFE SITUATION OR AREA.

This product is not a substitute for your personal judgment. Any route suggestions by this system should never supersede any local traffic regulations or your personal judgment or knowledge of safe driving practice.

8-EN

KEEP THE VOLUME AT A LEVEL WHERE YOU CAN STILL HEAR OUTSIDE NOISES WHILE DRIVING.

Excessive volume levels that obscure sounds such as emergency vehicle sirens or road warning signals (train crossings, etc.) can be dangerous and may result in an accident. LISTENING AT LOUD VOLUME LEVELS IN A CAR MAY ALSO CAUSE HEARING DAMAGE.

MINIMIZE DISPLAY VIEWING WHILE DRIVING.

Viewing the display may distract the driver from looking ahead of the vehicle and cause an accident.

DO NOT DISASSEMBLE OR ALTER.

Doing so may result in an accident, fire or electric shock.

USE ONLY IN CARS WITH A 12 VOLT NEGATIVE GROUND.

(Check with your dealer if you are not sure.) Failure to do so may result in fire, etc.

KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH OF CHILDREN.

Swallowing them may result in serious injury. If swallowed, consult a physician immediately.

USE THE CORRECT AMPERE RATING WHEN REPLACING FUSES.

Failure to do so may result in fire or electric shock.

DO NOT BLOCK VENTS OR RADIATOR PANELS.

Doing so may cause heat to build up inside and may result in fire.

USE THIS PRODUCT FOR MOBILE 12V APPLICATIONS.

Use for other than its designed application may result in fire, electric shock or other injury.

DO NOT PLACE HANDS, FINGERS OR FOREIGN OBJECTS IN INSERTION SLOTS OR GAPS.

Doing so may result in personal injury or damage to the product.

CAUTION

This symbol means important instructions. Failure to heed them can result in injury or material property damage.

HALT USE IMMEDIATELY IF A PROBLEM APPEARS.

Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing.

KEEP FINGERS AWAY WHILE THE MOTORIZED FRONT PANEL OR MOVING MONITOR IS IN MOTION.

Failure to do so may result in personal injury or damage to the product.

PRECAUTIONS

Product Cleaning

Use a soft dry cloth for periodic cleaning of the product. For more severe stains, please dampen the cloth with water only. Anything else has the chance of dissolving the paint or damaging the plastic.

Temperature

Be sure the temperature inside the vehicle is between +45°C (+113°F) and 0°C (+32°F) before turning your unit on.

Moisture Condensation

You may notice the disc playback sound wavering due to condensation. If this happens, remove the disc from the player and wait about an hour for the moisture to evaporate.

Damaged Disc

Do not attempt to play cracked, warped, or damaged discs. Playing a bad disc could severely damage the playback mechanism.

Maintenance

If you have problems, do not attempt to repair the unit yourself. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing.

Never Attempt the Following

Do not grip or pull out the disc while it is being pulled back into the player by the automatic reloading mechanism.

Do not attempt to insert a disc into the unit when the unit power is off.

New Discs

To prevent the disc from jamming, “Disc Error” is displayed if discs with irregular surfaces are inserted or if discs are inserted incorrectly. When a new disc is ejected immediately after initial loading, use your finger to feel around the inside of the center hole and outside edge of the disc. If you feel any small bumps or irregularities, this could inhibit proper loading of the disc. To remove the bumps, rub the inside edge of the hole and outside edge of the disc with a ballpoint pen or other such instrument, then insert the disc again.

Center Hole

Center Hole

New Disc



Bumps

Outside

(Bumps)



Installation Location

Make sure the INA-W900 will not be installed in a location subjected to:

Direct sun and heat

High humidity and water

Excessive dust

Excessive vibrations

Correct Handling

Do not drop the disc while handling. Hold the disc so you will not leave fingerprints on the surface. Do not affix tape, paper, or gummed labels to the disc. Do not write on the disc.

CORRECT

INCORRECT

CORRECT

Inserting Discs

Your player accepts only one disc at a time for playback. Do not attempt to load more than one disc.

Make sure the label side is facing up when you insert the disc. “Disc Error” will be displayed on your player if you insert a disc incorrectly. If “Disc Error” continues to be displayed even though the disc has been inserted correctly, push the RESET switch with a pointed object such as a ballpoint pen.

Playing a disc while driving on a very bumpy road may result in skips, but this will not scratch the disc or damage the player.

Irregular Shaped Discs

Be sure to use round shaped discs only for this unit and never use any special shaped discs.

Use of special shaped discs may cause damage to the mechanism.

Disc Cleaning

Fingerprints, dust, or soil on the surface of the disc could cause the DVD player to skip. For routine cleaning, wipe the playing surface with a clean, soft cloth from the center of the disc to the outer edge. If the surface is heavily soiled, dampen a clean, soft cloth in a solution of mild neutral detergent before cleaning the disc.

9-EN

Disc Accessories

There are various accessories available on the market for protecting the disc surface and improving sound quality. However, most of them will influence the thickness and/or diameter of the disc. Using such accessories can cause operational problems. We recommend not using these accessories on discs played in Alpine DVD players.

Transparent Sheet

Disc Stabilizer

After turning the system off, a slight ghost of the image will remain temporarily. This is an effect peculiar to LCD technology and is normal.

In cold temperature conditions, the screen may lose contrast temporarily. After a short warm-up period, it will return to normal.

Alpine products equipped with the Ai-NET bus, connected to the INA-W900, can be operated from the INA-W900. Depending on the products connected, the functions and displays will vary. For details, consult your Alpine dealer.

Operation of some of the functions of this unit is very complex. Because of this, it was deemed necessary to place these functions into a special screen. This will restrict operation of these functions to times when the vehicle is parked. This ensures the focus of the driver’s attention will be on the road and not on the INA-W900. This has been done for the safety of the driver and passengers. Audio Processor Adjustments cannot be made if the car is moving. The car must be parked and the parking brake must be engaged for the procedure described in the Owner’s Manual to be valid. The warning “CAN’T OPERATE WHILE DRIVING” will be displayed if any attempts are made to perform these operations while driving.

The INA-W900 draws minimal current even when its power switch is turned off. If the switched power (ignition) lead of the INA-W900 is connected directly to the positive (+) post of the vehicle’s battery, the battery may be discharged.

An SPST (Single-Pole, Single-Throw) switch (sold separately) can be added to simplify this procedure. Then, you can simply place it in the OFF position when you leave the vehicle. Turn the SPST switch back ON before using the INA-W900. For connecting the SPST switch, refer to the “Connection Diagram of SPST Switch (sold separately)” (page 93). If the power (ignition) lead is unswitched, it must be disconnected from the battery post should the vehicle be left unused for an extended period of time.

Discs Playable on This Unit

Playable Discs

The discs listed below can be played on this unit.



Mark (logo)

Recorded Content

Disc size































12 cm*

DVD Video











Audio + Video













8 cm



























































12 cm

Music CD











Audio





















































8 cm















(CD single)













































* Two-layer DVD disc compatible

The formatted discs listed below can be played on this unit.

CD-R/ DVD-R/ DVD+R/

CD-RW DVD-RW DVD+RW

CD Format

MP3 Format (“mp3”)

WMA Format (“wma”)

AAC Format (“aac”, “m4a”)

DVD Video Format

DVD-VR Format

• Discs that are not finalized cannot be played back.

10-EN

Discs that cannot be played

DVD-ROMs, DVD-RAMs, CD-ROMs (excluding MP3/WMA/ AAC files), photo CDs, etc.

DualDisc

This unit is not compatible with DualDisc.

Using a DualDisc may cause unit malfunction, and may cause disc damage when the disc is inserted/ejected.

DVD region number (playable region number)

This DVD player will play back any disc whose region number is 1 (or All). DVDs with a region number other than those listed below, cannot be played on this DVD player.

1 ALL

Using compact discs (CD/CD-R/CD-RW)

If you use unspecified compact discs, correct performance cannot be guaranteed.

You can play CD-Rs (CD-Recordables)/CD-RWs (CDReWritables) which have been recorded only on audio devices. You can also play CD-Rs/CD-RWs containing MP3/WMA/AAC formatted audio files.

Some of the following discs may not play on this unit: Flawed discs, discs with fingerprints, discs exposed to extreme temperatures or sunlight (e.g., left in the car or this unit), discs

recorded under unstable conditions, discs on which a recording failed or a re-recording was attempted, copy-protected CDs which do not conform to the audio CD industry standard.

Use discs with MP3/WMA/AAC files written in a format compliant with this unit. For details, see pages 38 and 39.

To customers using CD-R/CD-RW

If a CD-R/CD-RW cannot be played back, make sure the last recording session was closed (finalized).

Finalize the CD-R/CD-RW if necessary, and attempt playback again.

Tips for making your own discs

The INA-W900 plays DVD Video and Audio CD and has a built in MP3/WMA/AAC decoder.

The following information is designed to help you create your own music CDs (either Audio CD or MP3/WMA/AAC encoded CD-R/ RW files).

What is the difference between an Audio and MP3/WMA/AAC CD?

An Audio CD is the same format as the commercial CDs you buy in the store (also known as CD-DA). MP3 (MPEG-1 Audio Layer 3)/WMA (Windows Media Audio)/AAC (Advanced Audio Coding) is a data file that uses a compression scheme to reduce the size of the music file*.

Hybrid Audio CD and Data (MP3/WMA/AAC) CD-R/RW discs:

The INA-W900 can read either sector on the disc. Choose CD-DA to play the CD audio section or MP3/WMA/AAC to play the MP3/ WMA/AAC section*.

Multisession CD-R/RW:

Once a recording has been stopped, this is considered one session. If the disc is not closed (finalized), additional data may be added. Once this additional data has been recorded, this becomes a “multisession” CD. The INA-W900 can only read multisession DATA Formatted discs (MP3/WMA/AAC files - Not Audio CD files).

Properly formatted MP3/WMA/AAC Discs:

Use ISO9660 formatting to insure proper playback. You may use standard ISO naming Level 1 (8.3 DOS standard), Level 2 (32 characters) or Joliet (Windows or Macintosh long filenames) file naming conventions*.

*Please consult the Owner’s manual for additional information.

On handling compact discs (CD/CD-R/CD-RW)

Do not touch the surface.

Do not expose the disc to direct sunlight.

Do not affix stickers or labels.

Clean the disc when it is dusty.

Make sure that the disc is smooth and flat.

Do not use commercially available disc accessories.

Do not leave the disc in the car or the unit for a long time. Never expose the disc to direct sunlight.

Heat and humidity may damage the disc and you may not be able to play it again.

11-EN

Using DVD-Rs/DVD-RWs/DVD+Rs/DVD+RWs

This unit is compatible with discs recorded in the standard DVD-Video and DVD-VR (DVD-R/DVD-RW only) formats.

Note that discs not finalized (processed to enable to play on playback-only DVD players) cannot be played on this DVD player.

Some discs may not play back, depending on the recording device and disc format.

Discs or files utilizing copy protection, may not be playable. Some recording systems may not properly format copied files to enable proper playback.

In the following cases, the disc may not play on this unit:

discs recorded by certain DVD recorders, certain irregular discs, flawed discs, dirty discs, when the pickup lens of this DVD player is dirty, or when moisture condensation has occurred inside the unit.

Be sure to follow all cautions included with your DVD-Rs/ DVD-RWs/DVD+Rs/DVD+RWs discs.

Do not put stickers, seals, or tape on the label side of DVD-Rs/ DVD-RWs/DVD+Rs/DVD+RWs.

Compared to the regular discs, DVD-Rs/DVD-RWs/DVD+Rs/ DVD+RWs are more affected by heat, moisture, and direct sunlight. If left in a car, etc., damage may occur and it might not play on this unit.

The operable temperature range for disc playback is as follows: DVD-R/DVD-RW: -25 ~ +70°C

DVD+R/DVD+RW: +5 ~ +55°C

Disc terminology

Title

If titles are programmed for the DVD, these are the largest units of division of the information recorded on the disc.

Chapter

Each Title may also be divided into smaller divisions, called chapters. These can be specific scenes or musical selections.

Protecting the USB connector

Only an iPhone/iPod, USB memory or Portable audio player can be connected to the USB connector on this unit. Correct performance using other USB products cannot be guaranteed.

If the USB connector is used, be sure to use only the supplied connector cable with the unit. A USB hub is not supported.

Depending on the connected USB memory device, the unit may not function or some functions may not be performed.

The audio file format that can be played back on the unit is MP3/ WMA/AAC.

Artist/song name, etc., can be displayed. Certain, special characters may not be correctly displayed.

12-EN

CAUTION

Alpine accepts no responsibility for lost data, etc., even if data, etc., is lost while using this product.

On Handling USB Memory

This unit can control a memory storage device that supports the USB Mass Storage Class (MSC) protocol. Playable audio file formats are MP3, WMA and AAC.

USB memory function is not guaranteed. Use USB memory according to the terms of agreement. Read the USB memory Owner’s Manual thoroughly.

Avoid usage or storage in the following locations:

Anywhere in the car exposed to direct sunlight or high temperatures.

Anywhere the possibility of high humidity or corrosive substances are present.

Fix the USB memory in a location where driver operation will not be hindered.

USB memory may not function correctly at high or low temperature.

Use only certified USB memory. Note that even certified USB memory, may not function correctly depending on its type or state.

Depending on the settings of the USB memory type, memory state or encoding software, the unit may not play back or display properly.

Files protected by DRM (Digital Rights Management), cannot be played back on this unit. These include AAC formatted files purchased from the iTunes Store and WMA or other files with some form of copyright protection.

USB memory may take time to start playback. If there is a particular file other than audio in the USB memory, it may take considerable time before the file is played back or searched.

The unit can play back “mp3”, “wma” or “m4a” file extensions.

Do not add the above extensions to a file other than audio data. This non-audio data will not be recognized. The resulting playback may contain noise that can damage speakers and/or amplifiers.

It is recommended to back up important data on a personal computer.

Do not remove the USB device while playback is in progress. Change SOURCE to something other than USB, then remove the USB device to prevent possible damage to its memory.

On Handling Portable audio player

The unit can control a Portable audio player with the USB interface. Playable audio file formats are MP3 and WMA.

Portable audio player function is not guaranteed. Use Portable audio player according to the terms of agreement. Read the Portable audio player Owner’s Manual thoroughly.

Avoid usage or storage in the following locations:

Anywhere in the car exposed to direct sunlight or high temperatures.

Anywhere the possibility of high humidity or corrosive substances are present.

Fix the Portable audio player in a location where driver operation will not be hindered.

Portable audio player may not function correctly at high or low temperature.

Depending on the settings of the Portable audio player type, memory state or encoding software, the unit may not play back or display properly.

If the Portable audio player has an MSC/MTP setting, set to MTP.

A Portable audio player in which data is stored by USB Mass Storage may not be playable on the unit.

Depending on the Portable audio player settings, USB Mass Storage may be supported. For setting, refer to the Owner’s Manual of the player.

The unit can play back MP3/WMA files synchronized by Windows Media Player (Ver. 10 or 11), and are then forwarded to the player. The “mp3” or “wma” extensions are playable.

If data is not synchronized by Windows Media Player and is forwarded in another way, the unit may not be able to correctly play back the files.

WMDRM10 is supported by the unit.

A file that is copy-protected (copyright protection) cannot be played back.

It is recommended to back up important data on a personal computer.

Do not remove the USB device while playback is in progress. Change SOURCE to something other than USB, then remove the USB device to prevent possible damage to its memory.

This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision. Reverse engineering or disassembly is prohibited.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued & pending. DTS is a registered trademark and the DTS logos, Symbol and DTS 2.0 Channel are trademarks of DTS, Inc. © 1996-2008 DTS, Inc. All Rights Reserved.

Windows Media, and the Windows logo are trademarks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.

iPod and iTunes are trademarks of Apple Inc., registered in the U.S. and other countries.

iPhone is a trademark of Apple Inc.

“Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod and has been certified by the developer to meet Apple performance standards.

“Works with iPhone” means that an electronic accessory has been designed to connect specifically to iPhone and has been certified by the developer to meet Apple performance standards.

Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards.

The BLUETOOTH® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Alpine Electronics, Inc. is under license.

HD Radio™ and the HD and HD Radio Ready logos are proprietary trademarks of iBiquity Digital Corp.

“MPEG Layer-3 audio coding technology licensed from Fraunhofer IIS and Thomson.”

Audyssey MultEQ XT is a registered trademark of Audyssey Laboratories Inc.

“Supply of this product only conveys a license for private, noncommercial use and does not convey a license nor imply any right to use this product in any commercial (i.e. revenuegeneration) real time broadcasting (terrestrial, satellite, cable and/or any other media), broadcasting/streaming via internet, intranets and/or other networks or in other electronic content distribution systems, such as pay-audio or audio-on-demand applications. An independent license for such use is required. For details, please visit http://www.mp3licensing.com”

©2009 NAVTEQ. All rights reserved.

Portions ©2009, Microsoft Corporation. All Rights Reserved.

13-EN



Getting Started



Accessory List



Head unit .............................................................................

1

Power cable.........................................................................

1

Mounting sleeve ..................................................................

1

Bracket key..........................................................................

2

• Flush Head Screw (M5x8) ...................................................

6

Screw (M5×8) ......................................................................

8

Face plate............................................................................

1

Mounting Position Seal ........................................................

2

GPS Antenna .......................................................................

1

Pre OUT Cable ....................................................................

1

AUX I/O Cable .....................................................................

1

AV extension cable ..............................................................

1

USB extension cable ...........................................................

1

USB 30P cable ....................................................................

1

Owner’s Manual .............................................................

1 set

Optional Remote Control Interface Box

This unit is operable using the vehicle’s secondary radio controls. An Alpine Remote Control Interface Box (optional) is required. For details, contact your Alpine dealer.

Location of Controls

button

Recalls the Eject/Tilt screen.

If the disc does not eject after touching [Eject] of Disc, press and hold for at least 3 seconds.

/ button

Press to adjust the volume.

MUTE/PHONE button

Lowers the volume by 20 dB instantly. Press the button again to cancel.

Press and hold for at least 2 seconds to display the Telephone Menu screen.

(When the optional BLUETOOTH INTERFACE (KCE-400BT) is connected and BLUETOOTH IN is set to Adapter.)

SOURCE/ button

Turns the power on. Press and hold for at least 3 seconds to turn the power off.

Recalls the SOURCE selection screen.

AUDIO button

Return to the AV main source screen that is displayed before the Setup, Navigation, Telephone, Camera mode, etc. is started.

Turn on GUIDEVIEW WINDOW™ mode (page 29) when the current screen is audio source screen (Radio, CD, iPod, etc.). Press again to turn if off.

Press and hold for at least 2 seconds to recall the weather channel or traffic channel.

(When the XM or Sirius Receiver Box is connected.)

MAP button

Recall the navigation map screen.

NAVI MENU button

Recall the navigation menu screen.

RESET switch

Be sure to press the RESET switch when using the unit for the first time, after installing the CD changer, after changing the car battery, etc.

Turn off the unit power, press RESET with a ballpoint pen or similar pointed object.

Remote Sensor

Point the optional remote control transmitter towards the remote sensor within a range of 2 meters.

Ab o u t th e b u tto n d e s c rip tio n s u s e d in th is Own e r’s Ma n u a l

The buttons found on the face of the unit are expressed in bold (e.g. SOURCE/). The buttons found on the touch-screen display are shown in bold within brackets, [ ] (e.g. [Exit]).

This Owner’s Manual explains mainly the function of soft buttons, when a soft button and a unit button have the same function.

Turning Power On or Off

Some of this unit’s functions cannot be performed while the vehicle is in motion. Be sure to stop your vehicle in a safe location and apply the parking brake, before attempting these operations.

1 Press SOURCE/ to turn on the unit.

The unit can be turned on by pressing any button.

2 Press and hold SOURCE/ for at least 3 seconds to turn off the unit.

Some operation of the unit cannot be performed while the vehicle is in motion. In this case, be sure to first stop your vehicle and apply the parking brake, then perform the operation.

The INA-W900 is a precision device. With gentle handling, its unique capabilities can be enjoyed for a long time.

14-EN

Inserting/Ejecting a Disc

1 Press on the unit.

The display changes to the Eject/Tilt screen.

2 Insert a disc:

Touch [Open] on the Eject/Tilt screen.

The movable monitor will open, then insert a disc into the disc slot. Inserting a disc will close the monitor automatically.

Disc Slot

Eject the disc:

Touch [Eject] of Disc on the Eject/Tilt screen.

The movable monitor will open. Then the disc is ejected. After remove the disc, touch [Close] to close the movable monitor.

Touching [Exit] returns to the earlier main source screen.

Do not apply shock to the movable monitor when it is open as it may result in malfunction of the unit.

The monitor may be dim during low temperature and immediately after turning on the power. The brightness will return to normal as time elapses.

The monitor will stop at the set tilt angle when closing.

CAUTION

Keep hands (or any other object) away from the monitor while it is opening or closing to avoid damage or injury. The back of the movable monitor will get very warm under normal operating conditions. This is not a malfunction. Do not touch.

Insert the SD memory card

2 Insert your SD memory card until it clicks.

Remove the SD memory card

2 Push the SD memory card that is inserted.

The SD memory card is pulled out.

3 Close the cover of SD memory card slot.

4 Close the moveable monitor.

Adjusting the Monitor Viewing Angle

Adjust the monitor’s angle for better visibility.

1 Press on the unit.

The display changes to the Eject/Tilt screen.

2 Touch [] or [] of Tilt to adjust the desired monitor angle.

The monitor angle can be adjusted in 5 stages.

3 Touch [Exit] to return to the previous screen.

If the monitor touches an obstacle while the angle is being adjusted, it will stop immediately.

The screen color will vary when viewed at certain angles. Adjust the screen angle for the best viewing position.

If the voltage of the vehicle’s battery power is low, the screen may blink when the screen angle is changed. This is normal and not a malfunction.

Inserting/Removing the SD Memory Card

You can update the software and map of navigation system by using an optional SD memory card. To insert and take out the SD memory card, follow the instructions below.

1 After opening the movable monitor, open the cover of SD memory card slot.

Adjusting the Volume

Adjust the volume by pressing or .

Volume decreases/increases continuously by pressing and holding or .

Volume: 0 - 35

Lowering Volume Quickly

Activating the Audio Mute function will instantly lower the volume level by 20 dB.

Press MUTE to activate the MUTE mode.

The audio level will decrease by about 20 dB.

Pressing MUTE again will bring the audio back to its previous level.

15-EN

How to view the Display

Soft button operation

Be sure to touch the button lightly with the pad of your finger on the display to protect the display.

If you touch a button and there is no reaction, remove your finger from the display, and try again.

About the button descriptions used in this Owner’s Manual

Soft buttons, ones found in the display, are shown in bold enclosed in brackets, [ ] (e.g. [Exit]).

Whenever a soft button and a head unit button have the same function, the explanations in this Owner’s Manual will describe the function of the soft button.

Recalling the Source

Here is an example explanation for the Radio mode display on how to recall a source.

1 Press SOURCE/ on the unit.

The SOURCE selection screen is displayed.

Display example for SOURCE selection screen

Changes the items of source selection list.

Changes to the Telephone Menu screen. (When the optional BLUETOOTH INTERFACE

(KCE-400BT) is connected and “BLUETOOTH IN” is set to Adapter (page 55).)

Displays the rear view camera.

(When an optional rearview camera HCE-C107D, etc. is connected and Camera IN is set to ON).

Changes to main source screen.

Displays the source selection list.

(The kind of source modes that are displayed varies depending on connection and setting).

Changes to SETUP main screen.

2 Touch [Radio].

The screen changes to the Radio mode main display.

If your desired source is not displayed on the screen, touch [] to change the items of the source selection list first. Then touch the desired source key.

16-EN

Display example for FM Radio main screen

Displays the source name, such as radio band, etc., that is selected.

Changes to the Bass*1, Treble*1 and Subwoofer*2 Level adjustment screen directly.

When an optional IMPRINT audio processor (PXA-H100) is connected to this unit, MEDIA XPANDER level may also be adjusted directly.

If the optional IMPRINT audio processor (PXA-H100) is connected, Defeat and MultEQ must be set to OFF to adjust the MEDIA XPANDER directly.

Displays the time. Function Guide:

The function guide display varies depending on each source.

The contents of the function guide change by touching [P1/2]*3, [P1/3]*3 or [P1/4]*3 on the function guide, and many other operations can be performed.

Displays the icon of current source or artwork image*4.

If the GUIDEVIEW WINDOW™ mode is activated, the information of Navigation system will be displayed in this area.

*1 Adjustment cannot be performed when DEFEAT is set to ON.

*2 Adjustment cannot be performed when SUBWOOFER is set to OFF (page 45).

*3 Display may vary depending on the connected devices.

*4 If the playing song contains artwork data, the artwork image can be displayed (Only for USB Audio and iPod mode).

Displaying the Numeric Keypad Input

Screen

The numeric keypad input screen is displayed when the DVD mode is selected for searching a title or chapter. It can also be used for entering a country code or password for DVD setup, and for selecting a channel number in the SAT Radio mode etc.

1 Touch [10KEY] on the selected source screen.

2 Touch the desired numeric key.

Display example for numeric keypad

Navigation

Basic Operation

The INA-W900 GPS Navigation Receiver provides an easy-to-use user interface, clear, easy-to-understand spoken driving instructions, and award winning design.

INA-W900 is built upon Alpine’s history of navigation success in North America. Please read this manual carefully. If you have any further questions about INA-W900’s operation, feel free to call Alpine at 1- 888-NAV-HELP (628-4357) for technical assistance.

Input screen area

Closes numeric keypad input screen

All input numbers will be deleted.

Previous number will be deleted.

Input number is confirmed.

Numeric keypad

The numeric keypad input screen closes when the area is touched while displayed.

3 Touch [Enter] to confirm your entry.

Turning the Navigation System On

With this system, every time when the ignition key is turned to the ACC or ON positions and navigation mode is activated, the opening screen will be displayed automatically.

1 Press MAP or NAVI MENU on the unit to activate the navigation system.

2 Every time you boot up the system, both the language selection menu and IMPORTANT! are displayed on the screen. Touch the desired language.

After the language has been selected, important information is displayed in each language.

Be sure to read the important information.

3 After you have read this important information, touch [I Accept].

The map or Navigation Main Menu screen is displayed.

17-EN

Alpine INA-W900 User Manual 2

Navigation Main Menu

Info Button

Touch this to check information such as:

GPS receiver status

Speed and trip information See pages 33-34.

Go to Button

Touch this to start entering a destination. See pages 20-25.

Settings Button

Press this to change system settings. See pages 30-33.

Map Button

Touch this to go to the map. See page 18.

Map Functions

Home Button

Press this to go to a saved home location. See page 29.

18-EN

Next Maneuver Arrow and Voice Prompt Button

Repeating the Announcement

Touch this icon to repeat the guide announcement.

(Same as Next Maneuver Arrow)

Route Button

Touch this icon and it will take you to the route menu.

When not in the guidance mode, only the current position can be seen. Zoom buttons, Map Orientation button and Main Menu are available.

Estimate Time Display

This icon displays Estimated Time Remaining, Estimated Time of Arrival or Direction to Destination.

See page 32 to change this setting.

The time estimates are based on the average speed. The estimate time will vary depending on vehicle speed. The arrow always points toward the destination.

Map Orientation

Touch this icon to switch between North Up, Heading Up and 3D View.

North Up

In north up view, north is always at the top of the display. This makes it easy to determine your current heading with respect to the map.

Heading Up

In heading-up view, the current direction is always pointing to the top of the display. This makes it easy to see the direction of the next turn on the map.

3D View

The 3D View offers you a more realistic perspective by tilting the map and displaying it with a horizon line. Streets are displayed as you approach them instead of from a birds-eye view.

GPS Status Bar

GPS Signal Strength

Current Position

Switch Guidance Map

You can choose between full map and arrow only in guidance mode.

Switch Arrow Only

Displays three successive arrow maneuvers all the way to your destination while providing turn-by-turn guidance prompts.

Switch Full Map

Shows a full-screen map of the area while providing turn-by-turn guidance prompts.

Zoom Out Button

Touch this icon to zoom out.

Zoom In Button

Touch this icon to zoom in.

Main Menu Button

Next Street Name

Highway Exit Button

When the vehicle is on a Highway, the screen is displayed. Highway exit information is displayed as a list in order of close proximity to current position.

You can also set a waypoint, etc., by touching the desired Highway Exit.

From the Map Display

Setting a Destination

1 Touch anywhere on map screen.

2 The vehicle arrow changes to a crosshair cursor.

Position bar

3 Move the cursor to the new desired street.

Use Map Zoom button to zoom out the map if the destination is far from the current location.

4 Touch the selected position bar on the bottom of the screen.

5 Select Set as Destination.

6 Touch [Go!] on the Confirm Destination Screen.

To use destination options on the Confirm Destination Screen, see pages 25-27 for details. To cancel, touch Previous Screen icon .

19-EN

Finding Local Places

1 Touch anywhere on map screen.

The vehicle arrow changes to a crosshair cursor.

2 Touch the selected position bar on the bottom of the screen.

3 Select Find Nearby Places.

4 Select the desired category and the desired place.

5 Touch [Go!] on the Confirm Destination Screen.

To use destination options on the Confirm Destination Screen, see pages 25-27 for details. See Find Local Places on pages 22-23 for finding places though Places menu.

Setting Waypoints

1 Touch anywhere on map screen.

2 The vehicle arrow changes to a crosshair cursor.

3 Move the cursor to the desired waypoint.

4 Touch the selected position bar on the bottom of the screen.

5 Select Set as Waypoint and the destination will automatically be added to the Waypoint List.

6 Touch [Go!].

To add another waypoint, see page 27.

20-EN

Input a Destination

Go to Menu

Go to Main Menu Go to

Address Button

Search by typing an address. See page 21.

Last 4 Streets/Last 4 Cities:

The last four street names and city names searched are stored in memory.

You can reselect a street name/city name from this list.

History Button

Select from recent destinations. See page 23.

Places Button

Select places. See pages 22-23.

Returns to the previous screen.

Page List Down

Map Button

Press this to go to the map. See page 18.

Address Book Button

Select from saved destinations. See page 24.

Intersection Button

Set destination by intersection. See pages 24-25.

Last 4 Streets/Last 4 Cities:

The last four street names and city names searched are stored in memory.

You can reselect a street name/city name from this list.

Coordinates Button

Set destination using geographic coordinates. See page 24.

Page List Up

Set a Destination by Address

There are several ways to set a destination. You can set a destination directly from the map (page 19) or select Go to from the main menu.

Go to Main Menu Go to Address

Finding a Destination by Entering Street Name First

1 Select by Street.

2 Type the street name and touch [OK].

If there are multiple matches, the system automatically displays a short list of street names.

Type only the name of the street. Prefix and suffix of the street are not necessary.

The list of applicable street names appears.

3 Select the desired street name from the list.

4 Type the address number and touch [OK].

21-EN

5 Type the desired city.

If there are multiple matches, the system lists cities containing the street name and address number that you keyed in.

6 The Confirm Destination Screen appears. Touch [Go!] to calculate the route.

7 See pages 25-27, to see more details about Options on the confirmation destination screen.

Finding a Destination by City Name First

1 Select by City.

2 Type the city name and touch [OK].

If there are multiple matches, the system automatically displays a short list of city names. Select the desired city.

3 Type the characters of the street name and touch [OK].

4 The list of applicable street names appears. Select the desired street.

5 Type the address number and touch [OK].

6 The Confirm Destination Screen appears. Touch [Go!] to calculate the route.

Set a Destination by Place

You can select from approximately 6 million place locations stored inside your INA-W900 GPS Navigation System.

Go to Main Menu Go to Places

Finding a Place From Here or Near Your Destination

Last 4 names and Last 4 types takes you to a list from the last 4 places/types you have previously entered.

If you find a place near your destination:

When you arrive at a destination, a destination name (POI search), address and telephone number are displayed in the display bar.

If you want to display a trip summary, touching the arrow in the display bar, and [Summary] will display a detailed trip summary.

Display bar

By Name

1 Select by Name.

2 Type the desired place name. Touch [OK].

A list of place names appears.

22-EN

3 Use the arrow to the right of the list to scroll up and down the list.

4 Select the desired place.

For emergency locations such as Police Stations, Hospitals, etc., please verify availability before proceeding to such locations.

5 The Confirm Destination Screen appears. Touch [Go!] to calculate a route.

By Type

1 Select by Type.

2 Select a desired type.

3 There are 37 Place categories to choose from including ATMs, Banks, Gas Stations, Grocery Stores, Hotels, Parking Lots, Restaurants and more.

4 Follow steps 3 through 5 of the instructions above.

Finding a Place From City Center

1 Select From City Center.

2 Select by City.

Last 4 Cities takes you straight to the list of cities you have previously entered.

3 Type a city name and select a city.

4 You can choose by Name or by Type.

5 Follow steps from “by Name” or “by Type” on page 22.

Finding a Place along Your Route

1 Select Along Route.

2 Select the desired place type button. Touch [OK].

Highlighted button means it is selected. You can select multiple place types. Touch the button again to turn the selection on or off.

3 A list of places appears

Select the desired place.

4 Touch [Go!].

Set a Destination by History

Go to Main Menu Go to History

1 The list of recent destinations appears. Select the destination.

2 The Confirm Destination Screen appears. Touch [Go!] to calculate the route.

To use destination options on the Confirm Destination Screen, see pages 25-27 for details.

Deleting All History

Go to Main Menu History

1 Touch [Clear All].

2 Touch [Clear All] to delete all previous destinations.

23-EN

Set a Destination from the Address Book

Go to Main Menu Go to Address Book

1 Select the desired destination.

2 The Confirm Destination Screen appears. Touch [Go!] to calculate the route.

Editing Address Book

The lockout function applies to Setup Menu and Edit Address Book. To edit address book, your vehicle must be parked with the ignition key in the ACC or ON position. To do this, follow the procedures below.

1Bring your vehicle to a complete stop at a safe location. Engage the parking brake.

2Keep pushing the foot brake and release the parking brake once then engage it again.

3When the parking brake is engaged for the second time, release the foot brake.

For automatic transmission vehicles, place the transmission lever in the Park position.

Go to Main Menu Go to Address Book

1 Select the destination you would like to modify.

2 Touch to edit your entry.

3 Edit Name, Phone Number and Icon or delete the selected destination.

Select Delete All to delete all addresses saved in the address book.

Set a Destination by Coordinates

Go to Main Menu Go to Coordinates

1 Enter the Latitude of your destination. Touch [OK].

24-EN

2 Enter the Longitude of your destination. Touch [OK].

3 The Confirm Destination Screen appears. Touch [Go!] to calculate the route.

To use destination options on the Confirm Destination Screen, see pages 25-27 for details.

Set a Destination by Intersection

Go to Main Menu Go to Intersection

Finding a Intersection by Entering a Street Name First

1 Select by Street.

2 Type in the first street name. Touch [OK].

The list of applicable street names appears. Select the desired street and input the address number.

3 Input the second street name.

If there is only one street crossing with the first street, the name of the street automatically appears.

4 Confirm City name if there are more than one city with the same intersection.

5 The Confirm Destination Screen appears. Touch [Go!] to calculate the route.

To use other functions on the Confirm Destination Screen, see pages 25-27 for details.

Finding a Intersection by Entering a City Name First

If you know the city name of the intersection you are searching, select by City. The choice of the street is narrowed down automatically. This saves time in entering the street information.

1 Select by City.

2 Type the city name, then select the city from the list.

Destination Options

The Destination Options Menu allows you to find places nearby, find alternative routes to get to your destination, set a destination as your home, save a destination in the address book, and create waypoints.

To get to the Destination Options Menu, enter your desired destination by using the method on pages 20-25 in order to get to the Confirm Destination Screen.

Select Options.

Finding Nearby Places

1 Touch [Find Nearby Places].

2

3

4

Select a desired place type.

Select a desired place name.

Touch [Go!] to calculate the route.

3

4

5

Input the first street name.

Input the second street name.

The Confirm Destination Screen appears. Touch [Go!] to calculate the route.

To find local places directly from the map, go to page 20.

Last 4 Street and Last 4 Cities takes you to a list of the last 4 entries.

25-EN

Finding Alternative Routes to the

Destination

1 Touch [Change Method].

2 Select a method below.

Avoid Freeway

Avoid Toll Road

Use Time Restricted Road

Avoid Ferry

3 Select Quickest or Shortest.

4 Touch [OK].

Setting a Destination as Home

1 Touch [Set as Home].

2 Touch [OK] or type desired name and touch [OK].

3 Select desire icon. If there is no desired icon, touch [No Icon].

4 Touch [OK].

26-EN

Saving a Destination into the Address Book

1 Touch [Save to Address Book].

2 Type in desired name. Touch [OK].

3 Select an icon. If there is no desired icon, touch [No Icon].

4 Touch [OK].

Setting Waypoints

You can set up to 3 waypoints between you current location and your destination. The final destination must be set before entering any waypoints.

Adding a Waypoint

1 Touch [Set as Waypoint] and the destination is automatically added to the Waypoint List.

2 Touch [Go!] to calculate the route.

Adding another Waypoint

1 Before you touch [Go!] at the Waypoint List screen, touch [+ Add Waypoint].

2 Enter the waypoint with any method just as finding a destination. (pages 20-25)

3 Touch [Set as Waypoint] to confirm.

4 The system returns to the Waypoint List screen. Touch [Go!] to calculate the new route.

Setting a Waypoint Directly from the Map

See page 20.

Optimizing Your Route

1 Touch [Set as Waypoint]. The Waypoint List appears.

2 Touch [Options]. Waypoint options screen appears.

3 Touch [Optimize Route].

4 The system takes you back to the Waypoint List screen with optimal route. Touch [Go!] to calculate the route.

Deleting a Waypoint

1 Select the desired waypoint to delete from the list.

2 Touch [Delete].

Deleting All Waypoints

1 Touch [Options].

2 Touch [Delete All Waypoints]. Touch [Delete All] to confirm.

3 If all waypoints are deleted, will return to the waypoint list. To get back to the Map screen, touch [Map] to get back to the map.

Editing Order of Waypoints

1 Main Menu

Info Route

Edit Waypoint

or





from the Map

Route Button

Edit Waypoint

2 At the Waypoint List Screen, select the desired waypoint to edit.

3 Touch [Edit Order].

27-EN

4 Use the Up and Down buttons to move the waypoint.

5 Touch [OK] and the system returns to the Waypoint List screen.

6 Touch [Go!] to calculate the route.

ROUTE

Viewing Turn List During Guidance

You can view a list of street names and upcoming turns and streets.

Main Menu Info Route or

directly from the Map

1 Touch [View Turn List].

2 A list of upcoming streets and turns appears on the screen.

To preview a specific point, select a street name/maneuver on the list.

28-EN

Finding an Alternate Route

1 On Route screen, touch [Change Method].

You can select and re-calculate an alternate route based on Quickest Route or Shortest Route and select Avoid Freeway, Toll Road, Time Restricted Road or Ferry.

Finding a Detour

By Distance

1 On Route screen, touch [Detour].

2 Choose detour from 1/2 mile, 1 mile, 2 miles or 5 miles.

The system automatically calculates and displays a detoured route.
