4287A-03
S E R V I C E N O T E
Supersedes:
NONE
4287A RF LCR Meter
Serial Numbers: JP1KGxxxxx, JP2KGxxxxx, MY432xxxxx
HDD repair procedure is changed
Parts Required:
P/N Description Qty.
04287-65000 Mass Storage Disk (HDD) for service 1
ADMINISTRATIVE INFORMATION
SERVICE NOTE CLASSIFICATION:
AUTHOR: kW PRODUCT LINE: WN
ADDITIONAL INFORMATION:
This procedure must be performed by Agilent Technologies service offices
© AGILENT TECHNOLOGIES, INC. 2005
PRINTED IN U.S.A.
January 13, 2005
INFORMATION ONLY
Page 1 of 14
Page 2 of 14 4287A-03
Situation:
The new HDD (04287-65000) for repair does not include any operating system. When the HDD (04287-65000)
is used, the operating system for 4287A should be installed.
Solution/Action:
The new HDD repair procedure for the 4287A is as follows.
Required Equipment
OS Image: CD disk (Operating system for 4287A, F/w rev.1.31, Agilent service office use only)
HDD: p/n 04287-65000 (It is available for 4287A(win98), E4991A(win98), E5070/71A)
Software : Symantec Ghost
System(PC) : Windows 2000 Professional (or Windows XP Professional) with DVD drive
(or available to support external DVD drives)
LAN Cable: Cross (It enables the peer-to-peer communication between the 4287A and the PC.)
(or 2 straight cables and a hub.)
Outline of the procedure
1. Make Boot disks using Symantec Ghost ( only needs to be done one time) (5 min.)
2. Replace the defective HDD with the new HDD(p/n 04287-65000) (10 min.)
3. Connect the 4287A to your PC installed Symantec Ghost directly
4. Set up IP address and subnet mask of your PC (5 min.)
5. Set up GhostCast server (10 min.)
6. Copy the image file onto the 4287A’s HDD (10 min.)
7. Perform initial setting for the 4287A (15 min.)
™
8.0 (English version, Enterprise product)
Page 3 of 14 4287A-03
1. Make Boot disks using Symantec Ghost (Required for the first time)
1) Click Start – Programs – Symantec Ghost – Ghost Boot Wizard.
2) Select Network Boot Disk and press the Next button.
3) If HP Ethernet with LAN remote power adapter is installed in the 4287A, select AMD PCNET Family and
press the Next button.
If 3Com EtherLink is installed in the 4287A, select 3COM 3c90x and press the Next button.
Page 4 of 14 4287A-03
4) Press the Next button
5) Press the Next button.
6) Press the Next button.
Page 5 of 14 4287A-03
7) Select The IP setting ….., and enter IP address 192.168.0.1 and subnet mask 255.255.255.0. Press the Next
button.
8) Insert a floppy disk into your PC’s FDD, and the Next button.
9) Press the Next button.
In case of selecting AMD PCNET Family:
