AEG WTGL3VI200 User Manual [no]

WTGL3VIT200

................................................ .............................................

EN WASHER DRYER USER MANUAL 2 DE WASCH-TROCKNER BENUTZERINFORMATION 33

2 electrolux

Electrolux. Thinking of you.

Share more of our thinking at www.electrolux.com

CONTENTS

Safety information 2 Safety instructions 3 Environment concerns 5 Technical information 5 Product description 6 Control panel 7 Washing programmes 9 DRYING PROGRAMMES 11 Consumption values 11

First use 12 Daily use - Washing 12 Daily use - Drying 15 Helpful hints and tips 16 Care and cleaning 18 Troubleshooting 22 Installation 25 Building in 31

Subject to change without notice.

SAFETY INFORMATION

Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes injuries and damages. Always keep the instructions with the appliance for future reference.

CHILDREN AND VULNERABLE PEOPLE SAFETY

Warning! Risk of suffocation, injury or permanent disability.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

• Do not let children play with the appliance.

• Keep all packaging away from children.

• Keep all detergents away from children.

• Keep children and pets away from the appliance door when it is open.

• If the appliance has a child safety device, we recommend you activate it.

• Cleaning and user maintenance shall not be made by children without supervision.

electrolux 3

GENERAL SAFETY

• Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.

• Do not change the specification of this appliance.

• Obey the maximum load volume of 7 kg (refer to the “Programme chart” chapter).

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

• The operating water pressure (minimum and maximum) must be between 0,5 bar (0,05 MPa) and 8 bar (0,8 MPa)

• The ventilation openings in the base (if applicable) must not be obstructed by a carpet.

• The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused.

SAFETY INSTRUCTIONS

INSTALLATION

• Remove all the packaging and the transit

bolts.

• Keep the transit bolts. When you move

the appliance again you must block the drum.

• Do not install or use a damaged appli-

ance.

•Do not install or use the appliance where

the temperature is less than 0 °C or where it is exposed to the weather.

• Obey the installation instruction supplied

with the appliance.

• Make sure that the floor where you install

the appliance is flat, stable, heat resistant and clean.

• Do not install the appliance where the ap-

pliance door can not be fully opened.

• Always be careful when you move the

appliance because it is heavy. Always wear safety gloves.

• Make sure that there is air circulation be-

tween the appliance and the floor.

• Adjust the feet to have the necessary space between the appliance and the carpet.

Electrical connection

Warning! Risk of fire and electrical

shock.

• The appliance must be earthed.

• Make sure that the electrical information on the rating plate agrees with the power supply. If not, contact an electrician.

• Always use a correctly installed shockproof socket.

• Do not use multi-plug adapters and extension cables.

• Make sure not to cause damage to the mains plug and to the mains cable. Should the appliance power supply cable need to be replaced, this must be carried out by our Service Centre.

• Connect the mains plug to the mains socket only at the end of the installation. Make sure that there is access to the mains plug after the installation.

4 electrolux

• Do not pull the mains cable to disconnect the appliance. Always pull the mains plug.

• Do not touch the mains cable or the mains plug with wet hands.

• This appliance complies with the E.E.C. Directives.

Water connection

• Make sure not to cause damage to the water hoses.

• The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused.

• Before you connect the appliance to new pipes or pipes not used for a long time, let the water flow until it is clean.

• The first time you use the appliance, make sure that there is no leakage.

USE

Warning! Risk of injury, electrical

shock, fire, burns or damage to the appliance.

• Use this appliance in a household only.

• Do not change the specification of this appliance.

• Do not put flammable products or items that are wet with flammable products in, near or on the appliance.

• Do not touch the glass of the door while a programme operates. The glass can be hot.

• Make sure that you remove all metal objects from the laundry.

• The final part of the drying cycle occurs without heat (cool down cycle) to ensure that the items will not be damaged. If you stop the appliance before the end of the drying cycle, immediately remove and spread out all items, so that the heat can dissipate.

• If you use detergent, fabric softener or similar products, obey the instructions on the packaging.

• Wipe away lint that has accumulated around the appliance.

• Do not dry the damaged items which contain padding or fillings .

• Do not dry items such as foam rubber (latex foam), shower caps, waterproof textiles and rubber backed articles.

• Before drying items that have been in contact with substances such as cooking oil, acetone, alcohol , petrol, kerosene, spot removers, turpentine, waxes and wax removers, wash them in hot water with an extra amount of detergent.

• Do not dry items if industrial chemicals have been used for cleaning.

• Make sure that no gas lighters or matches have been left in the pockets of the clothing.

• Only dry fabrics which are applicable to dry in the tumble dryer. Follow the instructions on the fabric label.

• Do not dry not washed items in the appliance.

• If you have washed your laundry with a stain remover start an extra rinse cycle before you start the appliance.

• Plastic items are not heat resistant. – If you use a detergent ball, remove it

before you set the drying programme.

– Do not use a detergent ball when you

set a non-stop programme.

Warning! Risk of injury or damage to the appliance.

• Do not sit or stand on the open door.

• Obey the maximum load volume.

• Do not dry dripping wet clothes in the appliance.

CARE AND CLEANING

Warning! Risk of injury or damage to

the appliance.

• Before maintenance, deactivate the appliance and disconnect the mains plug from the mains socket.

• Do not use water spray and steam to clean the appliance.

• Clean the appliance with a moist soft cloth. Only use neutral detergents. Do not use abrasive products, abrasive cleaning pads, solvents or metal objects.

DISPOSAL

Warning! Risk of injury or suffocation.

• Disconnect the appliance from the mains supply.

• Cut off the mains cable and discard it.

electrolux 5

• Remove the door catch to prevent children and pets to get closed in the appliance.

SERVICE

• Contact the Service to repair the appliance. We recommend only the use of original spare parts.

ENVIRONMENT CONCERNS

The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product.

PACKAGING MATERIALS

Recycle the materials with the symbol

Put the packaging in applicable containers to recycle it.

ECOLOGICAL HINTS

To help the environment, use less water and energy, obey these instructions:

• Set a programme without the prewash phase to wash laundry with normal soil.

• Always start a washing programme with the maximum load of laundry.

• If necessary, use a stain remover when you set a programme with a low temperature.

• To use the correct quantity of the detergent, check the water hardness of your domestic system

TECHNICAL INFORMATION

Dimensions Width / Height / Depth 600 / 820 / 630 mm

Total depth 640 mm

Electrical connection: Voltage

Level of protection against ingress of solid particles and moisture ensured by the protective cover, except where the low voltage equipment has no protection against moisture

Water supply pressure Minimum 0,5 bar (0,05 MPa)

Water supply Maximum wash load Cotton 7 kg Maximum dry load Cotton 3 kg

Spin speed Maximum 1400 rpm

1) Connect the water inlet hose to a water tap with a 3/4'' thread.

Overall power Fuse Frequency

Maximum 8 bar (0,8 MPa)

Cotton big capacity 4 kg Synthetics 2 kg

230 V

2000 W

10 A

50 Hz

IPX4

Cold water

6 electrolux

PRODUCT DESCRIPTION

Detergent dispenser

Control panel

Door handle

Rating plate

Drain pump

Feet for the appliance level

Water drain hose

Mains cable

Water inlet hose

Feet for the appliance level

1 2

7 8 9

or pets to be closed in the drum. To activate the device, turn it clockwise, until the groove is horizontal. To deactivate the device, turn it counterclockwise, until the groove is vertical.

CHILD SAFETY DEVICE

• When you activate this device, you cannot close the door. This prevents children

ACCESSORIES

1 2

Spanner

To remove the transit bolts.

Plastic caps

To close the holes on the rear side of the cabinet after the removal of the transit bolts.

Anti-flood inlet hose

To prevent possible leakage

Plastic hose guide

To connect the drain hose on the edge of a sink.

CONTROL PANEL

1 2 3 4 5 6 7 98 10

electrolux 7

A B

Programme selector dial

SPIN button (Schleudern — Essorage)

• Rinse hold position

STAIN button (Flecken — Taches)

TIME SAVING button (Zeit Sparen —

Court) EXTRA RINSE button (Spülen + — Rin-

çage +) DRYING TIME button (Trockenzeit —

Minuterie)

DISPLAY

The display shows the following information:

Duration of the set programme

When you set a programme, the display shows the duration in hours and minutes (for example 2.05). The duration is calculated automatically on the maximum load for each type of fabric. After the programme has started, the time remaining is updated every minute.

Set drying time

when you set a drying programme, the display shows the drying time in minutes and/or hours (see paragraph «Drying»). After the programme has started, the appliance updates the remaining time every minute.

Display

START/PAUSE button (Start/Pause —

Départ/Pause) DELAY START button (Zeitvorwahl —

Départ Différé) Pilot lights:

• A – Washing phase (Waschen — Lavage)

• B – Drying phase (Trocknen- — Séchage)

• C – Door locked (Tür — Porte)

8 electrolux

Alarm codes

In the event of operating problems, some alarm codes can be displayed, for example

End of programme

When the programme has finished, the display shows a blinking zero The DOOR light C, the WASHING light A (or the DRYING light B) and the light of button 8 go out. The door can be opened.

Incorrect option selection

If you set an option which is not compatible with the wash programme, the display shows the message Err for some seconds. The yellow pilot light of button 8 light starts blinking.

Delay Start

When you press the relevant button to set the delay (20 hours max), it appears for some seconds, then the display shows the duration of the set programme. The delay time value decreases by one unit every hour. When only 1 hour remains, the time decreases every minute.

Delay Start symbol

This symbol comes on when you set the delay time.

Child safety lock

This symbol comes on when you activate the child lock function.

(see chapter «Troubleshooting»).

INDICATOR PILOT LIGHTS

ACOUSTIC SIGNALS

The machine is provided with an acoustic device, which sounds in the following cases:

• at the end of the cycle

• in the event of operating problems. By pressing the 3 and 4 buttons simultaneously for some seconds, the acoustic signal is deactivated (except for the events of operating problems). By pressing these two buttons again, the acoustic signal is reactivated.

CHILD SAFETY LOCK

This device permits you to leave the appliance unsupervised and not to worry that

After you have pressed the button 8, the WASHING light (A) comes on. The machine is operating. When you set a drying programme, the DRYING light (B) illuminate and stays on during the drying phase. The DOOR light (C) indicates when the door can be opened:

• light on: the door cannot be opened

• light blinking: the door is opening in some minutes

• light off: the door can be opened

children might be injured by or cause damage to the appliance. This function remains able also when the washing machine is not working. There are two different ways to set this option:

• Before pressing button 8: it will be im-

possible to start the machine.

• after pressing button 8: it will be impossi-

ble to change any other programme or

option. To enable or disable this option press simultaneously for about 6 seconds buttons

4 and 5 until the symbol

comes on or

disappears from the display.

WASHING PROGRAMMES

Programme Maximum and Minimum Temperature Type of Laundry Maximum Load

Koch-/Buntwäsche — Blanc/Couleur

95° - 30° Max. load 7 kg - Reduced load 3 kg

White and coloured cotton (normally soiled items).

40 Energiesparen — 40 Economique

40° Max. load 7 kg Fast coloured cotton. Slightly soiled cotton items. The appliance decreases the temperature and extends the washing time to obtain a good washing efficiency so saving energy.

Koch-/Buntwäsche + Vorwäsche — Blanc/Couleurs + Prélavage

95° - 40° Max. load 7 kg - Reduced load 3 kg

White and coloured cotton

(normally soiled items).

Pflegeleicht — Synthétiques

60° - 30° Max. load 3 kg - Reduced load 2 kg Synthetic or mixed fabrics: underwear, coloured garments, non-shrink shirts, blouses.

Leichtbügeln — Repassage Facile

40° Max. load 1 kg

Synthetic fabrics to be gentle washed and spun.

The laundry is gently washed and spun to avoid any creasing. Furthermore the machine will perform additional rinses.

Feinwäsche — Délicats

40° - 30° Max. load kg 3 - Reduced load kg 2

Delicate fabrics: acrylics, viscose, polyester.

Wolle/Seide — Laine / Soie / Handwash

30° - Cold Max. load 2 kg Machine washable wool as well as for hand washable woollens and delicate fabrics. Note: A single or bulky item may cause imbalance. If the appliance doesn’t perform the final spin phase, add more items, redistribute the load manually and then select the spinning programme.

Cycle Description

Main wash Rinses Long spin

Prewash Main wash Rinses Long spin

Main wash Rinses Short spin

electrolux 9

Options

SPIN REDUCTION RINSE HOLD

STAIN TIME SAVING

EXTRA RINSE SPIN REDUCTION

RINSE HOLD STAIN EXTRA RINSE

SPIN REDUCTION RINSE HOLD STAIN

TIME SAVING

EXTRA RINSE

SPIN REDUCTION RINSE HOLD

STAIN TIME SAVING

EXTRA RINSE SPIN REDUCTION

RINSE HOLD EXTRA RINSE

SPIN REDUCTION RINSE HOLD

STAIN TIME SAVING

EXTRA RINSE SPIN REDUCTION

RINSE HOLD

10 electrolux

Programme Maximum and Minimum Temperature Type of Laundry

Cycle Description

Options Maximum Load

Rinçage Délicat

Max. load 7 kg Programme for rinsing and spinning items which have

Rinses Long spin

SPIN REDUCTION RINSE HOLD

EXTRA RINSE been washed by hand. The machine performs some rinses, followed by a final spin. The spin speed can be reduced.

Pumpen — Vidange

Max. load 7 kg

Draining of wa-

ter For emptying out the water of the last rinse in programmes with the Rinse hold option set.

Schleudern — Essorage

Max. load 7 kg

Drain

Long spin

SPIN REDUCTION

Separate spin for hand washed cotton garments and after programmes with the Rinse hold option set. Turn the programme dial to Off before setting this programme. Reduce the spin speed if needed.

Trocken Pflegeleicht/Séchage Synthétiques

DRYING TIME selection. Drying synthetic programme.

Trocken Baumwolle/Séchage — Coton

DRYING TIME selection. Drying cotton programme.

Auffrischen — RafraÎchir

30° Max. load 3 kg

Main wash

Rinses

Short spin

SPIN REDUCTION

Quick wash for sport items, or cotton and synthetic items lightly soiled or worn once.

Energiesparen — Economique

60° Max. load 7 kg White and fast coloured cotton.

Main wash

Rinses

Long spin

SPIN REDUCTION RINSE HOLD STAIN

EXTRA RINSE Normally soiled cotton items. The appliance decreases the temperature and extends the washing time to obtain a good washing efficiency so saving energy.

Aus — Arrêt

For cancelling the running programme or to switch the machine off .

1) Stain option can be selected only at the temperature of 40°C or higher.

2) If you select the Super Quick option by pressing button 4, we recommend that you reduce the maximum load as

indicated. Full loading is possible however with somewhat reduced cleaning results.

3) If using liquid detergents, a programme without PREWASH must be selected.

electrolux 11

DRYING PROGRAMMES

Timed programmes

Sugges-

Degree of Drying Type of Fabric Drying Load

EXTRA DRY

Ideal for towelling materials

CUPBOARD DRY

Suitable for items to put away without ironing Suitable for items to put away without ironing

IRON DRY

Suitable for ironing

1) In compliance with EC directive EN 50229 the cotton reference programme for the data entered in the Energy

Label must be tested dividing the maximum washing load by two equal parts and drying with DRYING TIME each of them.

Cotton and linen

(bathrobes, bath towels, etc)

Cotton and linen

(bathrobes, bath towels, etc)

Synthetics and mixed fabrics

(jumpers, blouses, underwear, household linen)

Cotton and linen

(sheets, tablecloths, shirts, etc.)

4 kg 1400 160 - 180 3 kg

1.5 kg 1400 75 - 85 4 kg 3 kg

1.5 kg 1400 65 - 75 2 kg

1 kg

4 kg 3 kg

1.5 kg 1400 50 - 60

Spin

Speed

1400

1400 1400

1200

1400 1400

ted

drying

time

Minutes

110 - 120

150 - 170 100 - 110

90 - 100

55 - 65

120 - 140 80 - 90

CONSUMPTION VALUES

Programme Energy consump-

White Cottons 95° 2.2 72 Cottons 60° 1.35 67 Cotton Energy Saving Pro-

gramme 60° Cottons 40° 0.85 67 Synthetics 40° 0.55 42 Delicates 40° 0.55 63 Wool/ Handwash 30° 0.25 55

1) «Cotton Energy Saving programme » at 60°C with a load of 7 kg is the reference programme for the data entered in the energy label, in compliance with EEC 92/75 standards.

tion (KWh)

1.05 49

The consumption data shown on this chart is to be considered purely indicative, as it may vary depending on the

Water consumption (litres)

Programme duration (minutes)

For the dura-

tion of the pro-

grammes,

please refer to

the display on

the control

panel.

quantity and type of laundry, on the inlet water temperature and on the ambient temperature.

12 electrolux

FIRST USE

1. To activate the drain system, put 2 litre

of water in the main wash compartment of the detergent dispenser.

DAILY USE - WASHING

LOADING THE LAUNDRY

1. Open the appliance door.

2. Put the laundry in the drum, one item at

a time. Shake the items before you put them in the appliance. Make sure not to put too much laundry in the drum.

2. Put a small quantity of detergent in the main wash compartment of the detergent dispenser. Set and start a programme for cotton at the highest temperature without laundry. This removes all possible dirt from the drum and the tub.

3. Close the door.

Make sure that no laundry stays between the seal and the door. There is a risk of water leakage or damage to the laundry.

FILLING THE DETERGENT AND ADDITIVES

MAX

The detergent compartment for the prewash phase, the soak programme and for the stain function. Add the detergent for prewash, soak and stain remover before the start of the programme.

The detergent compartment for the washing phase. If you use a liquid detergent, put it immediately before you start the programme.

Liquid additives compartment (fabric conditioner, starch). Put the product in the compartment before you start the programme.

electrolux 13

This is the maximum level for the quantity of liquid additives.

Always obey the instructions that you find on the packaging of the detergent products.

SETTING THE PROGRAMME (KNOB 1 )

Turn the programme selector dial to the required programme. The programme dial determines the type of washing cycle (e.g. water level, drum movement, number of rinses) and the washing temperature according to the type of laundry. The pilot light of button 8 starts blinking. The programme dial can be turned either clockwise or anticlockwise.

= Reset programme / switching OFF of

the machine

If you turn the programme dial to another programme when the appliance is working, the yellow pilot light of button 8 blinks 3 times. The display shows the message Err to indicate a wrong selection. The machine will not perform the new set programme.

SETTING THE SPIN SPEED (BUTTON 2)

When you set the programme, the appliance automatically proposes the maximum spin speed allowed by that programme. Press this button repeatedly to change the spin speed. The relevant light will light up. RINSE HOLD : the water of the last rinse is not emptied out to prevent the fabrics from creasing. When the programme has finish-

ed the display shows a blinking

The DOOR pilot light goes on. The pilot light of button 8 is off. The door is blocked to indicate that the water must be emptied out.

To empty the water out please read chapter «At the end of the programme».

SETTING THE STAIN OPTION (BUTTON

Set this option to treat heavily soiled or stained laundry with stain remover The appliance extends the main wash phase and intensifies the stain action phase. The relevant light illuminates.

This option is not available with a temperature lower than 40°C.

If you wish to perform a programme with the stain option, pour stain remover into

compartment

SETTING THE TIME SAVING OPTION (BUTTON 4)

This option allows you to modify the washing time, automatically proposed by the appliance. Press button 4

once

DAILY The relative pilot light comes on.

The washing duration will be reduced to wash daily soiled laundry.

Press button 4 twice

SUPER QUICK

The relative pilot light remains lit. The washing duration will be reduced to wash lightly soiled laundry or items used or worn for a short time.

The display shows the decreased washing time.

SETTING THE EXTRA RINSE OPTION (BUTTON 5)

This appliance is designed for saving water. However, for people with a very delicate skin (allergic to detergents) it may be necessary to rinse the laundry using an extra quantity of water (extra rinse). The appliance will perform some additional rinses.

STARTING THE PROGRAMME (BUTTON 8)

Press the button 8 to start the programme. The corresponding red pilot light stops blinking. The pilot light A is on to indicate that the appliance starts operating. The pilot light C is on to indicate the door is locked. Press the button 8 to interrupt a pro- gramme which is running. The corresponding red pilot light starts blinking.

14 electrolux

Press the button 8 again to restart the pro-

gramme from the point at which it was interrupted If you have chosen a delayed start with button 9, the machine will begin the countdown. If you set an incorrect option, the yellow pilot light of the button 8 blinks for 3 times. The display shows the message Err for some seconds.

SETTING THE DELAY START (BUTTON

Press this button again an again to set the required delay. The display shows the set delay time value (up to 20 hours) for some seconds, then it shows the duration of the programme again. Set the delay before you press the button

8. You can delay the wash programme can be delayed from 30 min - 60 min - 90 min, 2 hours and then by 1 hour up to a maximum of 20 hours.

Adding items after you have set the delay (throughout the delay time the door will

be locked):

• Press the button 8 to put the machine in

pause

• Add the laundry, close the door .

• Press the button 8 again.

Setting the delayed start:

• Set the programme and the required options.

• Set the delay start.

• Press the button 8: the appliance starts its hourly countdown. The programme will start after the selected delay has expired.

Cancelling the delayed start:

• Press the button 8 to set the washing machine to PAUSE;

• Press the button 9 once until the display shows the symbol

’;

• Press the button 8 again to start the programme.

You can change the set delay only after you set the washing programme again.

The Delay Start can not be selected with DRAIN programme.

ALTERING AN OPTION OR A RUNNING PROGRAMME

It is possible to change some options before the programme carries it out. Before you make any change, you must press the button 8 to pause the appliance. Changing a running programme is possible only by resetting it.

Turn the programme dial to

and then to

the new programme position. Press the 8 button again to start the new programme. The washing water in the tub will not emptied out.

INTERRUPTING A PROGRAMME

Press the button 8 to interrupt a pro- gramme which is running, the corresponding light starts blinking. Press the button again to restart the programme.

CANCELLING A PROGRAMME

Turn the selector dial to

to cancel a programme which is running. Now you can select a new programme.

OPENING THE DOOR

When the machine is working and through the delay time, the door is locked. If, for any reason, it is necessary to open it, firstly press the button 8 to set the machine to pause If the light C after a few minutes goes off, the door can be opened. If the light C stays on and the door remains locked, this means that the machine is already heating or that the water level is too high. In this case the door can not be opened. If you cannot open the door but you need

to open it, turn the programme dial to

switch the machine off. After a few minutes the door can be opened (pay attention to the water level and temperature !) . After closing the door, it is necessary to set the programme and the options again. Press button 8 to start the programme again.

AT THE END OF THE PROGRAMME

The machine stops automatically. The pilot light of button 8, the pilot lights A and C go

off. A blinking

will appear on the display.

electrolux 15

If you have set a programme or an option that ends with water in the tub, the light C remains lit. The door is locked. The water must be emptied out before opening the door. During this time the drum continues to turn at regular intervals until water drain. Follow the below instructions to empty out the water:

•

Turn the programme selector dial to

• Set the DRAIN or SPIN programme

• Reduce the spin speed, if needed

• Press the button 8 Stand by : once the programme has finished after a few minutes the energy saving system will be enabled. The brightness of

DAILY USE - DRYING

DRYING ONLY

The recommended load size is 3 kg for cottons and linen, and 2 kg for synthetic items.

It is also possible to dry up to 4 kg of cotton items (see the «Drying Programme » table).

The water tap must be open and the drain hose must be positioned in the sink or connected to the drain pipe.

1. Load the laundry.

2. Select a spin cycle at the maximum spin speed allowed for the type of laundry in order to obtain the best drying performances.

3. Set the drying programme for Cottons or Synthetic in the Drying sector of the programme dial.

4. Press button 6 to set the drying time. Press this button again and again until the time you want appears on the display. For Cottons you can set a drying time from 10 minutes to 250 minutes (hours

4.10). For Synthetic you can select a drying time from 10 minutes to 130 minutes (hours 2.10). Every time you press this button the drying time increases by 5 minutes. Note! The programme time will automatically increase by a few minutes.

• When the programme has finished the display shows a blinking

light C goes off. The door can be opened.

Turn the programme selector dial to switch the machine off. Remove the laundry from the drum and carefully check that the drum is empty. If you do not intend to carry out another wash, close the water tap. Leave the door open to prevent the formation of mildew and unpleasant smells. the display is reduced. By pressing any button the appliance will come out of the energy saving status.

5. Press button 8 to start the programme.

After the programme has started, the time remaining is updated every minute.

If you set only 10 minutes of drying phase with the timed drying button, the appliance performs only a cooling phase.

6. At the end of the drying programme,

some acoustic signals sound. A blink-

appears on the display.

ing The pilot light B, and C and the light of the button 8 go off. At this point, begins an anti-crease phase, which lasts for about 10 minutes. During this time the light C is on. The door cannot be opened.

If you need to open the door before or during the anti-crease phase or to interrupt it, press any button or turn the programme dial to any programme position (except O. The door can be opened after some minutes. (In any case do not try to open the door if it is locked!) .

7. Turn the selector dial to the O position

to switch the machine off.

8. Remove the laundry.

Note!

The different type of cottons (towelling, sheets, shirts, and so on) or any laundry items rolling up during the spinning phase may result in partial dryness.

. The pilot

16 electrolux

In the exceptional case that at the end of the cycle the laundry remains slightly wet, we suggest that you unfold the rolled up items, redistribute them evenly in the drum and select an additional drying cycle of 20-30 minutes.

NON-STOP PROGRAMME: WASHING AND TIMED DRYING

The recommended load size is 3 kg for cotton and 2 kg for synthetic.

It is also possible to dry up to 4 kg of cotton items (see the «Drying Programme » table).

Caution! Do not use a dosing device/ball when carrying out a washing and drying programme.

1. Load the laundry.

2. Add detergent and fabric softener.

3. Switch the machine on: turn the selector dial to the required washing programme/fabric.

4. Press the relevant buttons to set the required options. If possible, do not set a spin speed lower than that proposed by the appliance to avoid too long a drying time therefore saving energy. In any case the lowest values you can select are 900 r.p.m. for cottons and synthetics and 700 r.p.m. for delicate fabrics. The reduction of the spin speed is only possible after selecting drying.

5. Press the button 6 to set the drying time. When selecting a «non-stop programme» the pilot lights A and B illuminate. The DRYING TIME value appears on the display for some seconds, then the entire duration of the washing and drying cycle appears.

If you set a washing programme and only 10 minutes of drying cycle by pressing the button 6, the total duration of the cycles displayed includes also the unrolling and the cooling phase.

6. Press the button 8 to start the pro-

gramme. After the programme has started, the time remaining is updated every minute.

7. At the end of the programme, follow the indications given in the previous chapter. Then, turn the selector to the O position to switch the machine off.

8. Remove the laundry.

FLUFF IN THE GARMENTS

During the WASHING AND/OR DRYING PHASE, certain types of fabric, as spongecloth, wool, sweatshirt, could release fluff. The released fluff could stick to the fabrics during the next cycle. This drawback increases with technical fabrics. To prevent the lint in your clothes, it is recommended:

• To do not wash dark fabrics after you

washed and dried light colored fabrics (new sponge, wool, sweatshirt especially) and vice versa.

• To air-dry this type of fabrics when they

are washed the first time.

• To clean the filter.

• Perform one or more rinse cycles to

wash the drum between the washing and drying of fabrics with different colors.

• After the drying phase, thoroughly clean

the empty drum, the gasket and the door with a wet rag.

HELPFUL HINTS AND TIPS

THE LAUNDRY LOAD

• Divide the laundry in: white, coloured, synthetics, delicates and wool.

• Obey the washing instructions that are on the laundry care labels.

electrolux 17

• Do not wash together white and coloured items.

• Some coloured items can discolour with the first wash. We recommend that you wash them separately for the first times.

• Button up pillowcases, close zippers, hooks and poppers. Tie up belts.

• Empty the pockets and unfold the items.

• Turn inside out multilayered fabrics, wool and items with painted illustrations.

• Remove hard stains.

• Wash with a special detergent heavy soil stains.

• Be careful with the curtains. Remove the hooks or put the curtains in a washing bag or pillowcase.

•Do not wash in the appliance : – Laundry without hems or with cuts – Underwired bras. – Use a washing bag to wash small

items.

• A very small load can cause balance problems with the spin phase. If this occurs, adjust manually the items in the tub and start the spin phase again.

STUBBORN STAINS

For some stains, water and detergent is not sufficient. We recommend that you remove these stains before you put the items in the appliance. Special stain removers are available. Use the special stain remover that is applicable to the type of stain and fabric.

• Do not mix different types of detergents.

• To help the environment, do not use more than the correct quantity of detergent.

• Obey the instructions that you find on the on packaging of these products.

• Use the correct products for the type and colour of the fabric, the programme temperature and the level of soil.

• If you use liquid detergents, do not set the prewash phase.

• If your appliance has not the detergent dispenser with the flap device, add the liquid detergents with a dosing ball.

WATER HARDNESS

If the water hardness in your area is high or moderate, we recommend that you use a water softener for washing machines. In areas where the water hardness is soft it is not necessary to use a water softener. To know the water hardness in your area, contact your local water authority. Obey the instructions that you find on the packaging of the products. Equivalent scales measure the water hardness:

• German degrees (°dH).

• French degrees (°TH).

• mmol/l (millimol for each litre - international unit for the hardness of water).

• Clarke degrees.

DETERGENTS AND ADDITIVES

• Only use detergents and additives specially made for washing machines.

Water hardness table

Level Type

1 soft 0-7 0-15 0-1.5 0-9 2 medium 8-14 16-25 1.6-2.5 10-16 3 hard 15-21 26-37 2.6-3.7 17-25 4 very hard > 21 > 37 >3.7 >25

°dH °T.H. mmol/l Clarke

DRYING HINTS

Prepare the drying cycle

Water hardness

• Do a check if the connection of the drain hose is correct. Refer to installation chapter for more information.

• Open the water tap.

18 electrolux

• For the maximum laundry load of the drying programmes, refer to the drying programmes table.

Do no not set a drying programme for this laundry:

– Very delicate items. – Synthetic curtains. – Woollen and silk items. – Pieces of clothing with metal inserts. –Nylon stockings. – Quilts. – Bed covers. –Duvets. –Anoraks. – Sleeping bags – Fabrics with residue of hair sprays, nail

solvents or similar.

– Garments with foam-rubber or materials

similar to foam-rubber.

GARMENT LABELS

When you dry ther laundry, obey the indications on the labels of the manufacturers:

•

= The item can be tumble dried

•

= The drying cycle is at high tempera-

ture

•

= The drying cycle is at reduced tem-

perature

•

= The item can not be tumble dried.

• speed of the last spin

•dryness level

•type of laundry

• weight of the load size GENERAL TIPS Refer to the «Drying programmes» table to find the average drying times. The experience will help you to dry the laundry in a more correct way. Take note of the duration drying time of the cycles done before. To avoid the static charge at the end of the drying cycle:

• Use fabric conditioner in the washing cycle.

• Use special fabric conditioner for tumble dryers.

When the drying programme is completed remove the laundry in a short time.

ADDITIONAL DRYING

If, at the end of the drying programme, the laundry is still damp, set a short drying cycle again.

Warning! To avoid creases of fabrics or shrinks of the clothing do not over dry the laundry.

DRYING CYCLE DURATION

The drying time can change depending on:

CARE AND CLEANING

Warning!

Disconnect the appliance from the mains supply before you clean it.

DESCALING

The water we use contains limescale. If it becomes necessary, use a water softener to remove limescales. Use a special product made for washing machines. Obey the instructions that you find on the packaging of the manufacturer.

Do this separately from the laundry wash.

EXTERNAL CLEANING

Clean the appliance only with soap and warm water. Fully dry all the surfaces.

Caution! Do not use alcohol, solvents or chemical products.

DOOR SEAL

electrolux 19

Regularly examine the seal and remove all objects from the inner part.

DRUM

Regularly examine the drum to prevent limescale and rust particles. Only use special products to remove rust particles from the drum. To do this:

DETERGENT DISPENSER

To clean the dispenser:

MAX

• Clean the drum with special product for stainless steel.

• Start a short programme for cotton at the maximum temperature with a small quantity of detergent.

1. Press the lever.

2. Pull the dispenser out.

3. Remove the top part of the liquid additive compartment.

4. Clean all the parts with water.

5. Clean the dispenser recess with a brush.

6. Put back the dispenser in the recess.

20 electrolux

DRAIN PUMP

The pump should be inspected regularly and particularly if:

• the appliance does not empty and/or spin;

• the appliance makes an unusual noise during draining due to objects such as safety pins, coins etc. blocking the pump;

• a problem with water draining is detected (see chapter “Troubleshooting” for more details).

Warning! Before unscrewing the pump cover, switch the appliance off and remove the mains plug from the socket.

Proceed as follows:

1. Unplug the appliance.

2. If it is necessary, wait until the water has cooled down.

3. Place a container close to the pump to collect any spillage.

4. Release the emergency emptying hose (B), place it in the container and remove its cap cover.

5. When no more water comes out, unscrew the pump cover (A) by turning it anti-clockwise and remove the filter. Use pliers, if necessary. Always keep a rag nearby to dry up any water spillages when removing the cover. Clean the filter under a tap, to remove any traces of fluff.

6. Remove foreign bodies and fluff from the filter seat and from the pump impeller.

electrolux 21

7. Check carefully whether the pump impeller rotates (it rotates jerkily). If it doesn’t rotate, please contact your Service Centre.

8. Put the cap back on the emergency emptying hose and place the latter back in its seat.

9. Replace the filter into the pump by inserting it correctly into the special guides. Screw the pump cover firmly by turning it clockwise.

Warning!

When the appliance is in use and depending on the programme selected there can be hot water in the pump. Never remove the pump cover during a wash cycle, always wait until the appliance has finished the cycle, and is empty. When refitting the pump cover, ensure it is securely re-tightened so as to stop leaks and young children being able to remove it.

THE INLET HOSE FILTER AND THE VALVE FILTER

It could be necessary to clean the filters when:

To clean the water inlet filters:

• The appliance does not fill with water.

• The appliance fills with the water for a long time.

•

The indicator of button

flashes and the display shows the related alarm. Refer to 'Troubleshooting'.

Warning! Disconnect the mains plug from the mains socket.

1. Close the water tap.

2. Remove the water inlet hose from the water tap.

3. Clean the filter in the inlet hose with a stiff brush.

+ 47 hidden pages
