CORDLESS

TELEPHONE

Voxtel D210/D215

USER GUIDE

P1 P2

GHI

PQRS

ABC

TUV

DEF

MNO

JKL

WXYZ

ABC

JKL

TUV

1 2

GHI

PQRS

DEF

MNO

WXYZ

MEMO

14 15

20 21

1819

1 BECAUSE WE CARE

Thank you for purchasing this product. This product has been designed and assembled with utmost care for you and the environment. This is why we supply this product with a quick installation guide to reduce the number of paper (pages) and therefor save trees to be cut for making this paper. A full and detailed user guide with all the features descripted can be found on our website www.aegtelephones.eu. Please download the full user guide in case you want to make use of all the advanced features of your product. To save the environment we ask you not to print this full user guide. Thank you for supporting us to protect our environment.

2 IMPORTANT SAFETY INSTRUCTIONS

When using your telephone, basic safety precautions should always be followed to reduce the risk of ﬁre, electric shock and injury, including the following:

1. Read and understand all the instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug the power adapter from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

4. Keep your phone away from hot, humid conditions or strong sunlight and don’t let it get wet or use this product near water (for example, near a bath tub , kitchen sink, swimming pool).

5. Do not overload wall outlets and extension cords as this can result in the risk of ﬁre or electric shock.

6. Unplug this product from the wall outlet under the following conditions:

tWhen the power supply cord or plug is damaged. tIf the product does not operate normally by following the operating instructions. tIf the product has been dropped and the cabinet has been damaged. tIf the product exhibits a distinct change in performance.

7. NEVER use your phone outdoors during a thunderstorm-unplug the base from the telephone line and the mains socket when there are storms in your area. Damage caused by lightning is not covered by the guarantee.

8. Do not use the telephone to report a gas leak in the vicinity of the leak.

9. Use only the supplied NiMH (Nickel Metal Hydride) batteries!

10. The use of other battery types or non-rechargeable batteries/primary cells can be dangerous. These may cause interference and/or damage to the unit or surroundings. The manufacturer will not be held liable for damage arising from such non-compliance.

11. Do not use third party charging bays. Damage may be caused to the batteries.

12. Please ensure the batteries are inserted in the correct polarity.

13. Dispose of batteries safely. Do not immerse them in water, burn them, or put them where they could get punctured.

3 INTENDED USE

This telephone is intended to be connected to a public analogue telephone network or to an analogue extension of an approved compatible PBX system.

4 UNPACKING YOUR PHONE

The package contains the following items:

t$PSEFE)BOETFU t$PJMFE)BOETFU$PSE t#BTFTUBUJPO t$PSEMFTT)BOETFU t$IBSHFS1PEXJUIDPOOFDUFE"$QPXFSBEBQUFS t"$QPXFSBEBQUFSGPSUIFCBTFTUBUJPO t5FMFQIPOFMJOFDPSE t"""SFDIBSHFBCMF#BUUFSJFT t6TFSNBOVBM

Keep the packing materials in a safe place in case you later need to transport the device.

Radio signals between the cordless handset and the base unit:

To use your cordless handset and base together, you must be able to establish a radio link between them. The signal between the handset and base is in accordance with the normal standards for a DECT phone: maximum range up to 300 metres outdoors or 50 metres indoors. The signal range may decrease if there is any large metal object between the handset and the base, such as a refrigerator, a mirror, a ﬁling cabinet, metallic doors or reinforced concrete. The signal strength may also be reduced by other solid structures like walls, or by other radio or electrical interference.

5 GETTING TO KNOW YOUR PHONE

5.1 Cordless handset overview (see P1)

# Meaning

Up key

tIn idle mode: press to access the call list

tIn menu mode: press to scroll up the menu items tIn phonebook list / redial list / call list: press to scroll up the list tDuring a call: press to increase the earpiece volume tDuring ringing: press to increase the ringer volume

Right soft key (clear/back/mute/intercom)

tIn main menu mode: press to go back to idle screen tIn sub-menu mode: press to go back to previous level

tIn sub-menu mode: press and hold to go back to idle screen tIn editing / predialling mode: press to clear a character/digit tIn editing / predialling mode: press and hold to delete all the characters / digits tDuring a call: press to mute / unmute the microphone tIn idle mode: press to intercom another handset

Off / hang up key

tDuring a call: press to end a call and go back to idle screen tIn menu / editing mode: press to go back to previous menu tIn idle mode: press and hold to power off the handset tIn idle mode (when the handset is powered off): press and hold to power on the

handset

Flash key

tIn idle / predialling mode: press to insert a ﬂash tDuring a call: press to generate ﬂash signal

Speakerphone key

tDuring a call: press to turn on / off the speakerphone tCall list / phonebook entry: press to make a call with speakerphone tDuring ringing: press to answer a call with speakerphone

Down key (redial/down)

tIn idle mode: press to access the redial list

tIn menu mode: press to scroll down the menu items tIn phonebook list / redial list / call list: press to scroll down the list tDuring a call: press to decrease the earpiece volume tDuring ringing: press to decrease the ringer volume

Talk key

tIn idle / predialling mode: press to make a call tIn redial list / call list / phonebook list: press to make a call to the displayed entry tDuring ringing: Press to answer a call

Left soft key (menu/ok)

5.2 Cordless handset display (see P2)

The LCD display gives you information on the current status of the telephone.

# Meaning

tIn idle mode: press to access the main menu tIn sub-menu mode: press to conﬁrm the selection tDuring a call: press to access Intercom/phonebook/ redial list/ call list

Steady when the handset is in range of the base. Flashes when out of range of the base or not registered to the base.

Steady when an intercom call is in progress. Flashes when there is an incoming internal call.

Indicates a call is in progress on that handset.

Indicates that speakerphone is being used.

Indicates that your answering machine (TAM) is on and ﬂashes when there is a new message.

Indicates that the handset ringer is switched off.

Steady when an alarm is set. Flashes when the alarm is sounding.

Indicates that the keypad is locked.

Indicates when you have a new Voice Mail message. (This is a caller display service from the network operator.)

Indicates when the battery is fully charged. Whole icon ﬂashes when the battery is charging. Internal block icon ﬂashes when the battery is in ﬁnal charging stage.

Indicates when the battery needs charging. Flashes when low battery power level is detected.

Indicates when there are more characters or numbers in front of those being displayed.

Indicates when there are more characters or numbers after those being displayed.

Left soft key function. Press to access the main menu.

Left soft key function. Press to conﬁrm the current selection.

Indicates new TAM message / new call in TAM message list / call list.

Indicates more options available in lists, above or below.

Right soft key function. Press to start an intercom call.

Right soft key function. Press to go back to the previous menu (back) level or cancel the current action.

Right soft key function. Press the alarm, or mute/unmute the microphone during a call.

5.3 Corded Base Station

# Meaning

MEMO

Ans On/Off

In Idle: Press to switch the answering machine ON or OFF.

Repeat/OGM

In Idle mode: Press and hold to record an OGM. Press to playback the OGM. In TAM message playback mode: Press once to repeat the current message, or twice to go back to the previous message.

Play/Stop

In idle mode: Press to playback messages. During TAM message playback: Press to stop playing messages.

FWD/MEMO

In idle mode: Press and hold to record a Memo. In TAM message playback mode: Press to skip forward to play the next message.

Delete

In TAM message playback mode: Press to delete the message playing. In idle mode: Press and hold to delete all old TAM messages.

Menu/OK

In idle mode: Press to access the main menu. In sub-menu mode: Press to conﬁrm the selection. In Redial List / Call Log: Press for sub-menu.

C/Mute

In main menu mode: Press to go back to idle screen. In sub-menu mode: Press to go back to previous level. In editing / predialling mode: Press to clear a character / digit. During a call: Press to mute / unmute the microphone. During ringing: Press to silence the base ringer. In idle mode: Press to intercom handsets.

In menu mode: Press to scroll up the menu items. In Phonebook list / Redial list / Call List / Call Log: Press to scroll up the list. During a call or TAM message playback: Press to increase the volume.

Call list / right

In Idle mode: Press to access the Call List. In editing mode: Press to move the cursor one character to the right.

Redial/Down

In idle mode: Press to access the Redial List. In menu mode: Press to scroll down the menu items. In Phonebook list / Redial list / Call List / Call Log: Press to scroll down the list. During a call or TAM message playback: Press to decrease the volume.

Phonebook / left

In Idle: Press to access phonebook list. In editing mode: Press to move the cursor one character to the left.

Flash

In predial mode or during a call: Press to insert a Flash signal.

Speakerphone

Press to make a call with speakerphone.

5.4 Base Station Display

Indicates a call is in progress.

Indicates that handsfree is being used.

Indicates the time of day.

Indicates that the base ringer volume is switched off.

This will display when you are in the phonebook menu.

Indicates when you have a new Voice Mail message. (This is a network service depend on your operator).

This will display when it is a repeat call.

Indicates the sequence number of the CID record.

This will display when there is a new CID entry or if one is being viewed.

5.5 Cordless handset menu structure

tIn idle mode, press tPress tPress tPress

/ to go to other options in the menu list.

to enter a sub-menu or function.

to go back to the previous level

to go to CALL LIST, the ﬁrst option in the menu list.

tRefer to the following for the menu structure.

5.6 Text and Digit Entry

The following tables show you where each letter and punctuation character can be found, by using repeated presses of the alphanumeric keypad. This will be helpful when storing a name in the phonebook and renaming your handset. In editing mode, a cursor is displayed to indicate the current text entry position. It is positioned at the right of the last character entered.

Writing Tips:

tOnce a character is selected, the cursor will move to the next position after a short pause. tYou can move the cursor within the text with the tPress tPress and hold

to delete the last character.

to delete the entire text string.

/ keys to amend the text entry.

Using a cordless handset:

5.6.1 English Character Set

Key

Key Press

1 2ABC2 2 3DEF3 3 4GHI4 4 5 JKL55 6MNO6 6 7PQRS7 7 8TUV8 8 9WXYZ9 9 00 0 **?/\() * #°‘,-&

Alphanumeric Editing (For phonebook name editing and renaming handset)

1st 2nd 3rd 4th 5th 6th 7th 8th 9th 10th

space

-1 1

Number Editing (For phone number editing, date/time editing)

, or P (if press and hold)

Using the corded base:

5.6.2 Character table

00 1SP-1 2 ABC2АБВГДЕ 3DEF3ĆÈÉÊË 4GHI4цМНОП 5 JKL5 Ł 6MNO6Ñ 7PQRS7 8TUV8ġÙÚÛÜ 9WXYZ9ǑÝ **?/\() ##,,-.&

čď ēĕ ęěĝù

ТУФХЦ

Ǔħĩ

ĉċӀ

Ƭøư

Šß

ǉĥģ

ÆÇ

ûý

6 INSTALLING YOUR PHONE

6.1 Connecting the corded base station (see P6)

tUse the coiled cord to connect the corded handset to the base station, making sure the plugs are

inserted fully into the sockets on the handset and on the side of the base, until they click in place.

tPlug the power supply cord & phone line cord into the sockets in the back of the base station. tPlug the power adapter into a 230Vac, 50Hz mains socket and the line cord into your telephone line

socket.

Warning:

Use only the power adapter provided for the base station.

Note:

The base unit needs mains power for normal operation, and the cordless handset will not work without it. (If the mains power fails, calls can still be made or received using the corded handset.).

6.2 Installing the cordless handset and charging the batteries (see P3)

tSlide open the battery compartment cover from the back of the handset. tPlace the 2 supplied batteries into the battery compartment with the polarity markings as indicated. tSlide the battery compartment cover back until it clicks into place. tPut the cordless handset on the charger and charge for 15 hours before using the handset for the ﬁrst

time.

>The handset will give a beep when it is properly placed on the charger.

Warning:

Use only NiMH rechargeable batteries.

7 USING YOUR PHONE

Using the cordless handset:

7.1 Make a call

7.1.1 Preparatory dialling

tEnter the phone number and press

to connect to the line and dial the number.

>When entering the number, if you make a mistake, press “C” (

) to delete digits.

7.1.2 Direct dialling

tPress

to connect to the line and then enter the phone number.

Note:

If you enter a wrong digit you cannot correct it with the “C” (

7.1.3 Call from the phonebook

tPress tPress

Note:

The alphanumeric keys provide a short-cut to ﬁnd entries beginning with the corresponding letters.

7.1.4 Call from the call list (only available with caller display)

tPress tPress

7.1.5 Call from the redial list

tPress tPress

7.1.6 Call timer

Your handset automatically times the duration of every call. The call timer is displayed as soon as you answer a call or 15 seconds after dialling and remains on the screen for 5 seconds after the end of the call. It is shown in hours, minutes and seconds format (HH:MM:SS).

, ,

to dial out the selected phonebook entry.

to access the call list and press / to select the desired call list entry.

to dial out the selected call list entry.

to access the redial list and press / to select the desired redial number.

to dial out the selected redial number.

to access the phonebook and press / to select the desired phonebook entry.

) key.

7.2 Answer a call

If the handset is not on the charging cradle: tWhen the phone rings, press

Note:

If “AUTO ANSWER” is set to “ON”, then lifting the handset off the base or charger will answer the call automatically and no keys need to be pressed.

7.3 End a call

tDuring a call press

tPut the handset on the base station or charger to end the call.

7.4 Handset speakerphone

During a call, you can press

7.5 Adjust volume

There are 5 levels (“VOLUME 1” to “VOLUME 5”) to choose from for each of the earpiece and speaker volumes. During a call: tPress

>When you end the call, the setting will remain at the last selected level.

/ to select volume 1-5. The current setting is shown.

to end the call.

to answer a call.

to alternate between hands-free speakerphone and normal handset use.

7.6 Mute a call

You can talk to someone nearby without letting the caller hear you during a call. During a call: Press “C” ( Your caller cannot hear you. Press “C” (

) to mute the microphone and “MUTED” will display on the LCD.

) again to unmute the microphone.

7.7 Turn off the handset ringer

In idle, press and hold # to turn off the handset ringer. The

icon is displayed on the LCD.

Note:

The display will still ﬂash the call icon

and show “CALL” or the caller display number, when there is an incoming call, even if the ringer is turned off. To turn the ringer back on, press and hold # again.

7.8 Turn on the keypad lock

You can lock the keypad so that it cannot be used accidentally while carrying it around. tIn idle, press and hold * to turn on the keypad lock and the

icon will display.

Note:

You can still use

to answer a call when the handset is ringing.

To turn the keypad lock off, press and hold * again.

7.9 Redial the last number

You can redial any of the 5 last numbers called. If you have stored a name in phonebook to go with the number, the name will be displayed instead. The most recent last number will display at the top of the redial list.

7.9.1 Redial a number from the redial list

tIn idle mode, press

to access the redial list.

Note:

If the redial list entry shows a name, press # to view the number of this entry.

tPress tPress

/ to browse the redial list.

to dial to the selected redial number.

Note:

If there are no numbers in the redial list, the display shows “EMPTY ”.

7.9.2 Store a redial number into the phonebook

tFollow Steps 1 and 2 in section 7.9.1. tPress tPress tPress tPress tPress

and / to select “ADD TO PB“. and then enter the name you want to use in the phonebook. and then modify the number, if necessary. to show “MELODY 1“.

/ to browse the ringtone list. The respective ringtone will be played when browsing the

ringtone list.

Note

The selected melody will only be played when you receive a call if you subscribe to Caller Display and the incoming number matches the stored number.

tPress

to conﬁrm, and the entry will be stored.

7.9.3 Delete a redial number

tFollow Steps 1 and 2 in section 7.9.1. tPress tPress

and / to select “DELETE“. to conﬁrm, and the entry will be deleted.

7.9.4 Delete all redial list entries

tFollow Steps 1 and 2 in section 7.9.1. tPress tPress tPress

and / to select “DELETE ALL“. to display “CONFIRM?“. to conﬁrm. All entries will be deleted and the display will show “EMPTY“.

Using the corded base:

7.10 Make an External Call

7.10.1 Preparatory dialling

Enter the phone number and lift up the corded handset or press number, if you make a mistake, press

Note:

To insert a pause in the dialling sequence, press and hold the < 0 > button, the screen will then show a “P” in the number. Press

7.10.2 Direct dialling

Lift up the corded handset or press

7.10.3 Call from the phonebook

Press Lift the corded handset or press

7.10.4 Call from the call list

Press handset or press

to insert a ﬂash signal and the screen will show a “F”.

to access the phonebook and press / to select the desired phonebook entry.

to access the Call List and press / to select the desired Call List entry. Lift up the corded

to dial out the selected Call List number.

to delete digits.

to connect to the line and then enter the phone number.

to dial out the selected phonebook entry.

to dial the number. When entering the

7.10.5 Call from the redial list

Press or press

7.10.6 Call timer

Your base display automatically times the duration of every call. The call timer appears on the display as soon as a call is answered or about 15 seconds after dialling, and remains on the screen for a few seconds after the end of the call. It is shown in hours, minutes and seconds format (HH:MM:SS).

7.11 Answer a Call

When there is an incoming ring, pick up the handset or press

7.12 End a Call

During a call connection, put the corded handset on the base station to end the call. Or press

7.13 Adjust Earpiece and Handsfree Volume

There are 5 levels (“VOLUME 1“ to “VOLUME 5“) to choose from for each of the earpiece and speaker volumes. During a call: Press The current setting is shown. When you end the call, the settings will remain at the last selected level.

to access the redial list and press / to select the desired redial number. Lift up the handset

to dial out the selected redial number.

to answer the call.

if you have a call in handsfree mode.

/ to increase or decrease the volume level respectively.

7.14 Mute a Call

You can talk to someone nearby without letting the caller hear you during a call. During a call: Press Press and the caller will be able to hear you again.

7.15 Emergency Call without Mains Power

The corded base unit can make an emergency call with the corded handset when the mains AC power is disconnected. Pick up the corded handset and wait for the dial tone and then enter the phone number to make a call.

to mute the microphone and “MUTED ” is displayed on the display. Your caller cannot hear you. again to unmute the microphone. “MUTED“ will be replaced by “LINE IN USE” on the display,

Note:

It is not possible to dial numbers from memories or use the speakerphone when the mains power is off. When the mains power is off, you can also answer an incoming call with the corded handset. When the phone rings, pick up the corded handset to talk to the caller.

7.16 Redial

You can redial any of the last 10 numbers called. If you have stored a name in the phonebook to go with the number, the name will be displayed as well.

7.16.1 Redial a Number from the Redial List

In idle mode, press

Note:

The redial list can also be viewed using

1. Press

2. Pick up the corded handset or press

Note:

If no numbers are in the redial list, the display will show “EMPTY“.

7.16.2 Save a redial number into the phonebook

tFollow steps 1 and 2 in section 7.16.1. tPress tPress tPress tPress

/ to browse the redial list.

to show “ADD TO PB?“ and then enter the name for the phonebook entry. and then modify the number, if necessary. and then / to select a melody.

to view the redial list.

then selecting “CALL LOG“ and “DIALED“.

to dial the selected redial number.

Note:

The selected melody will only play when you receive a call if you subscribe to Caller Display and the incoming number matches the stored number.

tPress

7.16.3 Delete a Redial Number

tFollow steps 1 and 2 in section 7.16.1. tPress tPress tPress

7.16.4 Delete All Redial List Entries

tIn idle mode, press tPress tPress tPress

7.17 Find the Cordless Handset Using a cordless handset:

If you have more than one cordless handset registered to the base, press number to call the other handset, or press 9 to call all registered handsets.

to save the redial number into the phonebook.

and / to select “DELETE?“. to show “CONFIRM?“. to conﬁrm the delete.

to open the redial list. and / to select “DELETE ALL?“. to show “CONFIRM?“. to conﬁrm the delete, and brieﬂy display “EMPTY“.

and select the handset

Note:

If there is an incoming call during the intercom calling, the phone will ring with the incoming call instead of the intercom.

Using the corded base:

You can locate any cordless handsets by paging from the base unit:

tIn idle mode, press tPress

“PAGING“ will ﬂash on the base screen.

and / to select “PAGE ALL HS“.

All handsets registered to the base will produce the paging tone and “PAGING“ ﬂashes on the screen. You can stop the paging by pressing

/ / on any handset or on the base to stop paging.

7.18 Make an Internal Call

This feature allows you to make internal calls, transfer external calls. If the called base or handset is not answered within 60 seconds, the called base or handset will stop ringing and the calling one will return to standby mode.

7.18.1 Intercom

Using the cordless handset:

1. In idle mode, press “C” ( „7“ and a „9“.

2. Enter < 7 > to call the base or enter the number of the handset that you want to call, or enter „9“ to call all handsets and the base.

3. The called base rings and the corded handset must be lifted off the base to establish the internal call.

3. The called handset rings and

Note:

If only one handset is registered to the base station, pressing “C” (

Note:

If there is an external call while you are on an intercom call, you‘ll hear warning beeps, and you have to end the intercom call, before you can answer the external call.

) and all the other registered handset numbers will display, along with a

must be pressed on that handset to establish the intercom call.

) will call the base immediately.

Using the corded base:

1. In idle mode, press

2. Enter the handset number you want to call, or press “9“ to call all handsets.

3. The called handset rings. Press

Note:

If only one handset is registered to the base station, pressing

7.18.2 Call all handsets

Using the cordless handset:

tIn idle mode, press tPress the “9“ key to ring to all registered handsets and the base.

Using the corded base:

tIn idle mode, press tPress “9“ to ring to all registered handsets and the base.

7.18.3 Transfer an External Call

Using the cordless handset:

During an external call:

1. Press

2. Press you want to transfer the call to.

3. The external call is put on hold automatically and the called handset rings.

4. Press

5. Press with the external party.

6. The external call is transferred to the called handset.

to show “INTERCOM“. to show all the other registered handset numbers, plus “9”. Enter the number for the handset

on the called handset to establish an internal call.

on the calling handset or put the calling handset on the charging cradle to end the current call

and the registered handset numbers will display, along with a “9“.

on the called handset to establish the internal call.

will call the handset immediately.

and the registered handsets will display.

and the registered handset numbers will display.

Note:

If the other handset has not answered the intercom call, you can stop the intercom and return to the external call by pressing

Using the corded base:

During an external call:

1. Press

2. Enter the number for the handset you want to transfer the call to. The external call is put on hold automatically and the called handset rings.

3. Press

4. Replace the corded handset on to the base, or press call with the external party.

5. The external call is transferred to the called handset.

7.18.4 Make a 3-way conference call

The conference call feature allows one external call to be shared with the base and one handset or with two handsets . The three parties can share the conversation and no additional network subscription is required.

Using a cordless handset:

During an external call:

tFollow Steps 1 to 4 in section 7.18.3. tPress and hold the star key * on the calling handset to establish the conference call.

Either handset can exit the conference by pressing external call.

to show all the other registered handset numbers, plus a „9“.

on the called handset to establish an internal call.

if in speakerphone mode, to end the current

, leaving the other handset still connected to the

Using the corded base:

During the external call:

tFollow Steps 1 to 3 in section 7.18.3 (corded). tPress and hold the „*“ key on the calling base to establish the conference call.

Any party (base or handset) can exit the conference and leave the other party still connected to the external call.

8 PRIVATE PHONEBOOK

Your phone can store up to 50 private phonebook entries with names and numbers in each handset and 50 entries in the base. Each phonebook entry can have a maximum of 20 digits for a handset phone number or 24 digits for a base phone number, and 12 characters for the name. You can also select different ringtones for your phonebook entries. (Note: the different ringtones only play when you receive a call if you subscribe to Caller Display and the incoming number matches the stored number.) Phonebook entries are stored alphabetically by name.

Using the cordless handset:

8.1 Add a new phonebook entry

In idle:

tPress tPress tPress tPress tPress tPress

and / to select “PHONEBOOK” and then press to show “ADD”. and then enter the name. and then enter the number. and / to select the desired ringtone for your phonebook entry. to store the phonebook entry.

to access the phonebook.

8.2 Search for a Phonebook Entry

In idle:

tPress tEnter the ﬁrst letter of the name using the alphanumeric keys (e.g. if it begins with C, press the 2 key

three times), and then

and / to select “PHONEBOOK“ and then press to access the phonebook.

/ to scroll to the entry you want.

8.3 View a Phonebook Entry

In idle:

tPress tPress tPress tPress

Note:

If the number is more than 12 digits, press

8.4 Edit a Phonebook Entry

In idle:

tPress tPress tPress tPress tEdit the name and press tEdit the number and press tPress

and / to select “PHONEBOOK“ and then press to access the phonebook.

/ to select the desired phonebook entry. and / to select “VIEW“. and / to review the name, number and ringtone of the selected phonebook entry.

and / to select “PHONEBOOK“ and then press to access the phonebook.

/ to select the desired phonebook entry. and / to select “EDIT“. to display the current name.

/ to select the ringtone and press to conﬁrm.

or to view the remaining digits.

8.5 Delete a Phonebook Entry

In idle:

tPress tPress tPress tPress

8.6 Delete all Phonebook entries

tPress tPress tPress tPress

8.7 Check the Phonebook Usage

You can check how many phonebook entries are stored in your handset and how many phonebook entries are available for you to store in the phonebook.

tPress tPress tPress

entries are stored out of the total 50 available spaces.

Using the corded base:

and / to select “PHONEBOOK“ and then to access the phonebook.

/ to select the desired phonebook entry. and / to select “DELETE“. to conﬁrm, and the entry will be deleted.

and / to select “PHONEBOOK“ and then press to access the phonebook. and / to select “DELETE ALL“. to display “CONFIRM?“. to conﬁrm. All entries will be deleted and the display will show “EMPTY“.

and / to select “PHONEBOOK“ and then press to access the phonebook. and / to select “PB STATUS“.

to display how much of the phonebook is being used, for example “14/50 USED“ means 14

8.8 Add a new entry

In idle:

1. Press

2. Press

3. Press

4. Key in the name using the digit keys (maximum 12 characters). If you make any mistakes, press delete the last character.

5. Press

6. Key in the number using the digit keys (maximum 24 digits). If you make any mistakes, press the last digit.

7. Press Use

8. Press

to show “PHONEBOOK“. then / to show “ADD“ . and the display will show the cursor at the beginning of the name position.

and the cursor will move to the number position.

to show “MELODY 1“.

/ to scroll through the melodies (there are 10 melodies to choose from).

to conﬁrm the melody and store the entry in the phonebook.

to delete

Note:

If there is no more space in the phonebook, “PB FULL” will appear on the display.

8.9 Edit an entry

In idle:

tPress tPress tPress tScroll tPress tEdit the name, pressing tPress tEdit the number, pressing tPress tPress tPress

8.10 View an Entry

In idle:

tPress tPress tPress tPress tPress

to show ”PHONEBOOK”. and / to show ”EDIT”. and the display will show the ﬁrst phonebook entry in alphabetical order.

/ until you see the contact you want to edit.

and the cursor will appear at the end of the name.

to delete characters, if necessary.

and the cursor will appear at the end of the number.

to delete digits, if necessary.

and the display will show the current melody choice.

/ to change the melody, if required.

to save the changes.

to show ”PHONEBOOK”. to show ”VIEW”. and / to select the desired phonebook entry. to see and hear the melody for that entry.

/ to go to other entries.

8.11 Delete an Entry

In idle:

tPress tPress tPress tPress tPress

8.12 Delete All Phonebook Entries

In idle:

tPress tPress tPress tPress

8.13 View Phonebook Capacity

In idle:

tPress tPress tPress

entries are stored out of the total 50 available spaces.

to show ”PHONEBOOK”. and / to show ”DELETE”. and / to select the desired phonebook entry. to display “CONFIRM?”. to conﬁrm the delete, or to cancel the delete.

to show ”PHONEBOOK”. and / to show ”DELETE ALL”. to display “CONFIRM?”. to conﬁrm the delete, or to cancel the delete.

to show ”PHONEBOOK”. and / to show ”PB STATUS”.

to display how much of the phonebook is being used, for example ”33/50 USED“ means 33

9 CALLER DISPLAY (NETWORK DEPENDENT)

This feature is available if you have subscribed to the Caller Display service with your network service provider. Your phone can store up to 20 received calls with date/time information in the base and cordless handset Call Lists. The number will be shown on the handset and base displays when the phone is ringing. If the number matches with one of the entries in your base and/or handset Phonebook, the caller’s name stored in that phonebook will be displayed alternately with the number on the handset, and with the number on the base.

The handset and base will ring with the melody associated with that phonebook entry. If the call is from someone who withheld their number, “WITHHELD “ will display. If the call is from someone whose number is unavailable, e.g. an international call or from a private exchange,”OUT OF AREA “ will display. If you’ve got new Caller Display records, the handset will display “X NEW CALLS” in standby mode, where X is the number of new calls, and the base will show “NEW X” at the top right of the display.

Using the cordless handset:

9.1 View the call list

All received calls are saved in the call list with the latest call at the top of the list. When the call list is full, the oldest call will be replaced by a new call. Any unanswered calls which have not been viewed are marked with a tPress OR Press

tPress tPress # to view the caller’s number if applicable. tPress tPress

9.2 Store a Call List Number into the Phonebook

tFollow Steps 1 and 2 in Section 9.1. tPress tPress tPress tEdit the number if necessary. tPress tPress

icon at the centre of the bottom line of the display. to access the call list.

and / to show “CALL LIST”, then press

/ to select the desired entry.

, / to show “DETAILS”, and then

to go back to the previous screen.

to show “ADD TO PB“. and then enter the name. and the selected call list number is displayed.

and / to select the ringtone. to store the phonebook entry and return to the calls list.

to display the date and time of the call.

9.3 Delete an entry in the Call List

tFollow Steps 1 and 2 in Section 9.1. tPress tPress

9.4 Delete all Call List Entries

tFollow Steps 1 and 2 in Section 9.1. tPress tPress tPress

Using the corded base:

9.5 View the call log and/or call list

Calls are saved in the Call Log, with all calls in the RECEIVED list but only unanswered calls in the MISSED list and in the Call List, with the latest call at the top of the list. When the call list is full, the oldest call will be replaced by a new call. Any unanswered call which has not been read is marked with the viewed, and the number of new calls is shown at the top right of the screen in idle mode. tPress OR Press recent Missed call record in the Call Log, or press to see the most recent Received call in the Call Log. tPress

and / to select “DELETE“. to conﬁrm.

and / to select “DELETE ALL“. to display “CONFIRM?“. to conﬁrm. All entries will be deleted and the display will show “EMPTY“.

icon when

to see the most recent Missed call record from the Call Log.

, then / to show “CALL LOG”, then to show “MISSED”, and press to see the most

/ again to to show “RECEIVED” and then press

/ to scroll through the appropriate list.

9.6 Store a Call Log / List Number into the Phonebook

tFollow steps 1 and 2 in Section 9.5. tPress tPress tEnter the name using the keypad.

to show “ADD TO PB“. and the display will show the cursor at the beginning of the name position.

tPress to conﬁrm the name. tThe number is shown with the cursor at the end. Modify the number, if necessary, using the

digit keys.

tPress tPress tPress

call log.

9.7 Delete an Entry in the Call Log / List

tFollow steps 1 and 2 in Section 9.5. tPress tPress tPress

9.8 Delete All Call Log / List Entries

tFollow steps 1 and 2 in Section 9.5. tPress tPress tPress

to conﬁrm the number, and display “MELODY 1“.

/ to scroll through the melodies.

to conﬁrm your selection. You will hear a conﬁrmation tone, and the display will return to the

and then / to show “DELETE“. to show “CONFIRM?“. to delete the entry.

and then / to show “DELETE ALL“. to show “CONFIRM?“. to delete all entries, and display “EMPTY“.

and

10 PHONE SETTINGS

Your phone comes with a selection of settings that you can change to personalise your phone the way you like it to work.

Using the cordless handset:

10.1 Date and Time Settings

If you subscribe to Caller Display the time and date settings will be automatically updated by the network when you receive an incoming call. The Caller Display service only sends the month and date, not the year, so you may need to set the year.

10.1.1 Change the Date Format

tPress tPress tPress tPress tPress

10.1.2 Change the Time Format

tPress tPress tPress tPress tPress

and / to select “HS SETTINGS“. and / to select “DATE & TIME“. and / to select “DATE FORMAT“. and / to select your desired date format (DD-MM-YYor MM-DD-YY ). to conﬁrm.

and / to select “HS SETTINGS“. and / to select “DATE & TIME“. and / to select “TIME FORMAT“. and / to select your desired time format (12 HR or 24 HR). to conﬁrm.

10.1.3 Set the Time

tPress tPress tPress tPress tPress

Note:

By default, the current time will display, starting from 00--00 (HH--MM) on power-up.

10.1.4 Set the Date

tPress

and / to select “HS SETTINGS“. and / to select “DATE & TIME“. and / to select “SET TIME“. and then enter the time information in 24 hour format. to conﬁrm.

and / to select “HS SETTINGS“.

tPress and / to select “DATE & TIME“. tPress tPress tPress

Note:

By default, the current date will display, starting from 01--01--11 (DD--MM--YY) on power-up.

10.2 Alarm Settings

You can set an alarm time on this phone. When an alarm is set, the alarm icon display. When the alarm time is reached, the alarm icon and the alarm tone rings for 45 seconds. You can press any key to disable the alarm. If the snooze function is activated,the alarm will sound again at the end of the snooze period of seven

minutes. You can also press and hold snooze function.

Note:

and / to select “SET DATE“. and then enter the date information in the format you set in Section 10.1.1. to conﬁrm.

is shown on the handset

and “ALARM ON“ ﬂash on the handset display,

while the alarm is sounding, to stop the alarm and turn off the

>A key press will still disable the alarm even if the handset keypad is locked when the alarm rings. >The alarm volume level is the same as the settings of the handset ringer volume. If the handset ringer

is set to “VOLUME OFF“, the alarm still sounds at VOLUME 1 level.

>During an external call or internal call, if an alarm is set and when the alarm time is reached, the

and “ALARM ON” will still ﬂash. An alarm tone will be emitted from the earpiece to alert the user the alarm time is reached. Once the user presses any key or presses and holds

the display will revert to the call duration.

>During paging or ringing, the alarm will not sound when the alarm time is reached. However, if the

snooze function is enabled and there is no paging or ringing, the alarm will sound again at the end of the snooze period.

to disable the alarm,

10.2.1 Turn on/off the Alarm

tPress tPress tPress tPress

Note:

If ON is selected, you will be prompted to set the alarm time.

10.2.2 Set the Alarm Time (If Alarm time is set to be “ON“)

tFollow Steps 1 to 4 in Section 10.2.1. tEnter the alarm time in 24 hour format. tPress tPress tPress

10.3 Handset Settings

10.3.1 Set the Ringer Melody for Internal Calls

tPress tPress tPress tPress

and / to select “HS SETTINGS“. to show “ALARM“. and / to select “ON“/“OFF“. to conﬁrm.

to display “SNOOZE“. and / to select snooze “ON“ or “OFF“. to conﬁrm.

and / to select “HS SETTINGS“. and / to select “RING SETUP“. to show “INT RING“. and / to select the melody you want to hear for internal calls.

Note:

The respective melody will be played while browsing the ringtone list.

tPress

10.3.2 Set the Ringer Melody for External Calls

tPress

to conﬁrm.

and / to select “HS SETTINGS“.

tPress tPress tPress

Note:

The respective melody will be played while browsing the ringtone list.

tPress

10.3.3 Set the Ringer Volume

tPress tPress tPress tPress

“VOLUME OFF“).

Note:

The respective ringer volume will be played during your selection. If “VOLUME OFF“ is selected, the icon will be displayed.

tPress

10.3.4 Set Alert Tones

Three different alert tones are set on by default, but can be turned off, if desired.

Key Tone - a single beep is emitted when you press a key. Low Battery Tone - emitted while you are talking on the phone to alert you that you need to charge the

handset batteries. Out of Range Tone - emitted while you are talking on the phone to alert you to move closer to the base unit, before the call is lost.

tPress tPress tPress tPress tPress

and / to select “RING SETUP“. and / to select “EXT RING“. and / to select melody you want to hear for external calls.

to conﬁrm.

and / to select “HS SETTINGS“. and / to select “RING SETUP“. and / to select “RING VOLUME“.

and / to select the desired ringer volume (a total of 6 ringer volume levels including

to conﬁrm.

and / to select “HS SETTINGS“. and / to select “TONE SETUP“. and / to select “KEY TONE“ / “BATTERY TONE“ / “OUT OF RANGE“. and / to turn on or off these tones. to conﬁrm.

10.3.5 Set the handset language

tPress tPress tPress tPress

10.3.6 Rename the Handset

tPress tPress tPress

enter up to 10 letters for the name.

tPress

10.3.7 Choose the Information to be Displayed in Idle

You can choose to display time or handset name in your idle screen.

tPress tPress tPress tPress

Note:

If TIME is selected, but no time has been set the display still shows the time starting from 00--00 on powerup.

and / to select “HS SETTINGS”. and / to select “LANGUAGE”. and / to select the desired language. to conﬁrm.

and / to select “HS SETTINGS“. and / to select “RENAME HS“. and change the name of your handset, using to delete letters and the alphanumeric keys to

to conﬁrm.

and / to select “HS SETTINGS“. and / to select “HS DISPLAY“. and / to select “HANDSET NAME“ or “TIME“. to conﬁrm.

10.4 Set the Auto Answer

If you turn on the Auto Answer, you can answer a call automatically by just lifting the handset off the base or charger, without having to press any key.

tPress tPress tPress tPress

10.5 Base Settings

Using the cordless handset:

10.5.1 De-register a Handset

This operation should only be necessary if one of your handsets becomes faulty or lost and needs to be replaced. You will need to enter the 4-digit System PIN (Default PIN is 0000) in order to de-register a handset from the base station. A de-registered handset will have the antenna icon ﬂashing and “REGISTER” on the display.

Note:

You cannot de-register the handset that you are currently using.

and / to select “HS SETTINGS“. and / to select “AUTO ANSWER“. and / to turn on or off the auto answer feature. to conﬁrm.

tPress tPress tPress tEnter the 4-digit system PIN (default 0000). tPress tPress

want to de-register.

tPress

10.5.2 Change the dial mode

You should normally leave the dialling mode at its default setting of “TONE“ (also called DTMF) unless the phone is connected to an old exchange that only recognises “PULSE“ dialling.

Note:

If “PULSE“ dialling is set, you can press the * key to switch to “TONE“ dialling for the rest of that call.

tPress tPress tPress

right).

tPress

10.5.3 Change the Flash (Recall) Time

You may need to change the recall (ﬂash) time if your phone is connected to a PBX. The recall time options are “SHORT“ (the default value of 100ms), “MEDIUM“ (300ms) or “LONG“ (600ms).

tPress tPress tPress

setting indicated by an asterisk to the right).

tPress

and / to select “BS SETTINGS“. to show “DELETE HS“. and the display shows “PIN? ------”.

and the ﬁrst handset number is displayed.

/ to scroll through the list of registered handsets and select the number of the handset you

to conﬁrm, and the chosen handset will be de-registered.

and / to select “BS SETTINGS“. and / to select “DIAL MODE“. and / to select “TONE“ or “PULSE“ (The current setting is indicated by an asterisk to the

to conﬁrm.

and / to select “BS SETTINGS“. and / to select “FLASH TIME“. and / to select your desired ﬂash time (“SHORT“, “MEDIUM“, “LONG“, with the current

to conﬁrm.

10.5.4 Change the System PIN Code

A 4-digit system PIN code is used for changing the system settings of the base station. It is used to protect your phone against unauthorised use. The default system PIN code is “0000“.

tPress tPress

and / to select “BS SETTINGS“. and / to select “CHANGE PIN“.

tPress and the display shows “PIN?------“ tEnter the old system PIN. tPress tPress

Note:

If the new PIN entered in Step 6 is not the same as the new system PIN entered in Step 5, you must enter the new system PIN at step 5 again.

to display “NEW PIN?------“, and enter your new 4-digit system PIN. to display “CONFIRM?------“, and enter your new 4-digit system PIN again.

tPress

10.5.5 Reset your phone

You can reset your phone to the default settings. After a reset, all your personal settings, call list entries, redial list entries, and answering machine messages will be deleted but your phonebook remains unchanged:

tPress tPress tEnter the 4-digit system “PIN“ (default 0000). tPress tPress t

Using the corded base:

10.6 Set Date and Time

The date is displayed on the base in the format MM-DD, and the time is HH:MM in either 12-hour or 24hour format.

tPress tPress

formats. Otherwise press

tPress tPress tPress tPress tPress tPress tPress tPress tPress tPress tPress

to conﬁrm

and / to select “DEFAULT“. to display “PIN?-----”.

to display “CONFIRM?“ to conﬁrm, and the phone will be reset to its default settings.

and / to select “DATE & TIME“.

to show “TIME FORMAT“. Select this if you want to change between 12-hour and 24-hour

/ to select “SET CLOCK“.

and the 4-digit year is displayed with the last two digits of the year ﬂashing.

/ to set the year. and the month ﬁeld will ﬂash. to set the month. and the date ﬁeld will ﬂash.

/ to set the date. and the hour ﬁeld will ﬂash.

/ to set the hour in the set format. and the minutes ﬁeld will ﬂash.

/ to set the minutes. to conﬁrm and you will hear a beep and the display will return to the menu screen.

10.7 De-register a Handset

This operation should only be necessary if one of your handsets becomes faulty or lost and needs to be replaced. You will need to enter the 4-digit system PIN in order to de-register a handset from the base station (the default PIN is 0000). A de-registered handset will have the antenna icon ﬂashing and “REGISTER“ on the display.

tPress tPress tPress tPress tPress tPress

Note:

Press

and / to select “SETTINGS“. and / to show “DELETE HS“. and the display will show “PIN?”, enter the 4-digit PIN code (default setting is 0000). and the ﬁrst registered handset number is shown.

/ to step through the list of registered handsets and select the one you want to de-register. and the selected handset will be de-registered.

to return to the previous menu at any time.

10.8 Ringer Setup

10.8.1 Change Ringer Melody

There are 10 base ringer melodies to choose from for external calls.

tPress tPress tPress

(the current melody, where X = 1 to 10).

tPress tPress

Note:

The respective ringer melody will be played during your selection.

10.8.2 Change Ringer Volume

You can adjust the volume level of the ringer for external calls with settings from 1 (the quietest) to 5 (loudest), or turn it “OFF“.

tPress tPress tPress

step through the volume levels “OFF“, 1 to 5.

tPress

and / to select “SETTINGS“. to show “RING SETUP“. to show “EXT. RING“, then press to show “MELODY“, then press to show “MELODY X“

/ to scroll through the Melody list (from 1 to 10). to conﬁrm the setting.

and / to select “SETTINGS“. to show “RING SETUP“. to show “EXT. RING“, then press and / to select “VOLUME“, then press and / to

to conﬁrm the setting.

Note:

The respective ringer volume will be played during your selection. If “VOLUME OFF“ is selected, the icon will display.

10.9 Set the Dial Mode

You should normally leave the dialling mode at its default setting of “TONE“ (also called DTMF) unless the phone is connected to an old exchange that only recognises “PULSE“ dialling. In Idle:

tPress tPress tPress tPress

10.10 Set the Recall (Flash) Time

You may need to change the recall (ﬂash) time if your phone is connected to a PBX. The recall time options are “SHORT“ (the default value of 100ms), “MEDIUM“ (300ms) or “LONG“ (600ms). In Idle:

tPress tPress tPress tPress

and / to select “SETTINGS“. and / to select “DIAL MODE“. and / to select “TONE“ or “PULSE“. to conﬁrm.

and / to select “SETTINGS“. and / to select “FLASH TIME“. and / to select the desired ﬂash time, from “SHORT“, “MEDIUM“ and “LONG“. to conﬁrm.

10.11 Set the Key Tone

The Key Tone is a conﬁrmation beep when you press any key. It is set on by default, but can be turned off, if desired. In Idle:

tPress tPress tPress tPress

10.12 Set the base language

In Idle: tPress

and / to select “SETTINGS“. and / to select “KEY TONE“. and / to select “ON“ or “OFF“. to conﬁrm.

and / to select “LANGUAGE“.

tPress tPress

10.13 Change the System PIN

A 4-digit system PIN code is used for changing the system settings of the base station, and is used to protect your phone from unauthorised use. The default system PIN code is 0000.

tPress tPress tPress tThe display will show “NEW PIN”, enter the new PIN and press tThe display will show “REPEAT”, enter the new PIN again, and press

Note:

If the incorrect PIN is entered or the new PIN is not entered twice the same, an error tone will be emitted and it will return to the previous menu. If this takes a short time, press

10.14 Base default

You can reset all of your base settings to their default settings. After a reset, all your personal base settings, call list entries, redial list entries, direct memory entries, and answering messages will be deleted, but any phonebook entries will be kept:

tPress tPress tPress tPress

and / to select your desired language. to conﬁrm.

and / to select “SETTINGS“. and / to select “CHANGE PIN“. and display will show “PIN?”, enter the 4-digit PIN (default setting is 0000) and press .

to conﬁrm.

to return to the menu immediately.

and / to select “SETTINGS“. and / to select “BS DEFAULT“. and display will show “PIN?”, enter the 4-digit PIN (default setting is 0000). to conﬁrm, and base will return to the previous menu.

11 HANDSET REGISTRATION

Important:

When you purchase your phone system, all cordless handsets are already registered to your base, so you do not need to register them. Handset registration is only necessary when you buy extra cordless handsets or if a cordless handset has become faulty. You can register additional cordless handsets to have up to 5 handsets per base unit, with each handset’s number (1 to 5) shown on its display. A cordless handset can be registered to only one base at a time. To check whether a handset is registered, make sure mains power to the base unit is switched on and the handset is within range. The handset’s display should show its number and the on. If the display shows “REGISTER ”, you need to register the handset again using the following process: tOn the base station, press

station into registration mode. The base display will show “PLEASE WAIT” and the base will stay in registration mode for about 2 minutes, so the following handset sequence must be completed within this time.

tPress tPress tEnter the 4-digit system PIN (default is 0000). tPress

If the handset registration is successful, the display will change to standby mode with the new handset number and the The handset will automatically be allocated the next available handset number. If the handset registration is unsuccessful, the

and / to select “REGISTRATION“. to display “PIN?----“.

to conﬁrm, and the display will show “PLEASE WAIT“ ﬂashing.

icon will stop ﬂashing.

icon will still ﬂash.

and / to show “REGISTRATION“, and then press to put the base

icon should be steadily

12 ANSWERING MACHINE (ONLY for D215

Your phone includes a telephone answering machine that records unanswered calls when it is on. The display on the base will show the number of messages recorded. The answering machine can store up to 59 messages within the maximum recording time of up to about 18 minutes, depending on the compression rate set. As well as recording incoming messages, you can record memos for other users of your phone. If the answering machine memory is full, the Handset will display “TAM FULL“ alternately with the handset’s name or time, depending on the handset standby display mode set, and you will have to delete some messages before any new ones can be recorded. You can turn the answering machine on or off using the base or handset. When the answering machine is set to ON, calls will be answered after the set answer delay and if the Answer and Record mode is set, the caller can then leave you a message. When the answering machine is set to OFF, calls will be answered after 14 rings and the answer only message will be played to your callers. They will not be able to leave you a message.

Using the cordless handset:

12.1 Turn on/off the answering machine

You can turn the answering machine on or off using the handset. When the answering machine is set to “ON”, calls will be answered after the set answer delay and the caller can then leave you a message. When the answering machine is set to “OFF”, calls will be answered after 14 rings and the answer only message will be played to your callers. They will not be able to leave you a message.

tPress tPress tPress tPress

12.2 Listen to the messages in the answering machine

When new messages are recorded on the answering machine, the until all the new messages are played. After a new message is played it will be saved as an old message automatically unless it is deleted. Old messages will be played after all new messages are all played.

tPress tPress tPress

information of the message received.

Note:

A When a message has been played, the message again.

and / to select “ANS. MACHINE”. and / to select “TAM ON/OFF”. and / to select “ON” or “OFF”. to conﬁrm.

>If answering machine is set to “ON”, >If answering machine is set to “OFF”,

and / to select “ANS. MACHINE”. and / to select “MSG PLAYBACK”.

to start message playback through the earpiece and the screen displays the date and time

is placed at the centre of the bottom of the handset display to indicate that it is a new message.

displays on the handset LCD.

will not display on the handset LCD.

ﬂashes on the handset display

will disappear and will not be shown when you listen to this

Note:

If there are no messages, the handset display will brieﬂy show “00-00 00-00“ then return to “MSG PLAYBACK”.

tDuring message playback, press

respectively.

or to increase or decrease the message playback volume

tPress

and / to select “STOP”, “FORWARD”, “PREVIOUS”, “DELETE” to perform the following

functions during message playback.

STOP Stop the current message playback and return to the ANS. MACHINE menu. FORWARD Skip to play the next message. The date and time information of the next message

will display if there is another message.

PREVIOUS Repeat playing the current message from the beginning. The date and time

information of the current message will display.

DELETE Delete the current message and the next message will be played.

Note:

Alternatively, you can use the following shortcut keys to control different operations during message playback.

tPress key 5 to stop message playback. tPress key 4 once to skip to repeat playing the current message from the beginning. Press twice to skip

backward to play the previous message.

tPress key 6 to skip to play next message. tPress key 2 to delete the current message playback.

12.3 Delete All Messages in the Answering Machine

tPress tPress tPress tPress

and / to select “ANS. MACHINE“. and / to select “DELETE ALL“. to display “CONFIRM?“ to delete all old messages.

Note:

The handset will display “EMPTY“ brieﬂy and return back to the “DELETE ALL“ menu.

Note:

New messages will not be deleted.

12.4 Record Memo

You can record a memo message for another user. When you record a memo, the message counter will increase by one and the message can be played back in the same way as answering machine messages. Memo recording can still function even when the answering machine is turned off.

tPress tPress tPress tPress

and / to select “ANS. MACHINE“. and / to select “MEMO“. to start memo recording and “RECORDING” is displayed. to stop memo recording and save the memo.

tPress

to stop memo recording without saving and return back to the “MEMO“ menu.

12.5 Answering Machine Settings

You can use the “TAM SETTINGS“ menu through the handset to change the settings of your answering machine.

12.5.1 Set the Answer Mode

tPress tPress tPress tPress tPress

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. to show “ANSWER MODE“. and / to select “ANS & REC“ or “ANSWER ONLY“ to conﬁrm.

When your answering machine memory is full and it is in “ANS & RECORD“, the answer mode will change to “ANSWER ONLY“ automatically. It will return to “ANS & RECORD“ mode automatically after some messages have been deleted.

12.5.2 Set the Outgoing Message (OGM) Language.

The answering machine announces the outgoing message when it answers a call. There is a pre-set OGM for each of “ANS & REC“ mode or “ANSWER ONLY“ mode, which can be in English or French (Français) on this model.

tPress tPress tPress tPress tPress

12.5.3 Record Your Own Outgoing Message (OGM)

You can record your own OGM for ANS & REC mode or ANSWER ONLY mode. When you record your own OGM, it will be used when the answering machine answers the call. If your personalised OGM is deleted, the pre-set OGM will be restored automatically.

tPress tPress tPress tPress tPress tPress tPress

Your newly saved OGM will playback automatically. Alternatively, press

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “TAM LANGUAGE“. and / to select your desired OGM language. to conﬁrm.

and / to select “ANS. MACHINE”. and / to select “TAM SETTINGS”. and / to select “OGM SETTINGS”. and / to select “ANS & RECORD” or “ANSWER ONLY”. and / to select “RECORD MESS”. to start recording your personalised OGM and “RECORDING” is displayed on the screen. to stop and save your personalised OGM.

to return to previous screen without saving the personalised OGM.

12.5.4 Playback and Delete the Outgoing Message (OGM)

You can playback your own personalised OGM or the pre-set OGM for “ANS & REC“ mode or “ANSWER ONLY“ mode and choose to delete your personalised OGM during playback and record a new one whenever you want. Please note that pre-set OGM cannot be deleted.

12.5.4.1 Playback the OGM

tPress tPress tPress tPress tPress tPress tPress

Note:

If a personalised OGM has not been recorded, the pre-set OGM will be played.

12.5.4.2 Delete the Personalised OGM

tRepeat Steps 1 to 6 in Section 12.5.4.1. tPress

and the pre-set OGM is restored automatically.

Note:

If the pre-set OGM is playing, you are not allowed to delete it, so pressing and return to the previous menu.

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “OGM SETTINGS“. and / to select “ANS & REC“ or “ANSWER ONLY“. to show “PLAYBACK“. to playback your current OGM and “PLAYING OGM“ is displayed on the screen. to stop the OGM playback and return to the previous menu.

while the OGM is playing to delete your personalised OGM and return to the previous menu

will just stop the playback

12.5.5 Set the Answer Delay

You can set the number of rings before the answering machine answers and starts playing your OGM. You can set the answering machine to answer after two to eight rings or TIME SAVER. If Time Saver is set the answering machine will answer after 5 rings if there are no new messages, or after 2 rings if there is a new

message, so if you call in and you don‘t get an answer after 3 or 4 rings, you can hang up and save on call charges.

tPress tPress tPress tPress

RINGS“, “6 RINGS“, “8 RINGS“ or “TIME SAVER“. (The current selection is marked with an asterisk.)

tPress

Warning:

If the network message service (e.g. 1571) is enabled on your line, you must set the answering machine to answer calls after either 2 or 4 rings, otherwise the message service will take the call ﬁrst.

12.5.6 Set the Recording Time of Incoming Message

You can set the maximum length of the recording time of the incoming messages.

tPress tPress tPress tPress

“180S“ or “UNLIMITED“. (The current selection is marked with an asterisk.)

tPress

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “ANSWER DELAY“.

and / to select your desired answer delay from the available options “2 RINGS“, “4

to conﬁrm.

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “RECORD TIME“.

and / to select your desired recording time from the available options “60S“, “120S“,

to conﬁrm.

12.5.7 Call screening

When the answering machine is on and takes a call, you can listen to the caller leaving a message. You can then identify the caller and decide whether to take the call in person. The call can be screened at the base.

12.5.7.1 Screening at the base

By default, answering machine calls are played automatically through the base speaker and the volume can be adjusted with the VOL + and VOL -keys on the base. If you don‘t want the caller to be heard when leaving a message, the base screening can be turned off:

tPress tPress tPress tPress tPress

12.5.8 Change the Compression Rate

Three different compression rates (“HIGH“, “MEDIUM“ and “LOW“) are provided for you to select different quality levels of recording incoming message. The lower the compression rate, the higher the recording quality level attained, but the shorter the total recording time available. (“LOW“ = 8 minutes, “MEDIUM“ = 11 minutes, “HIGH“ = 18 minutes approx).

tPress tPress tPress tPress tPress

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “BS SCREENING“. and / to select “OFF“ or “ON“. (The current setting will be indicated by a *.) to conﬁrm the setting.

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “COMPRESSION“. and / to select your desired compression rate. to conﬁrm.

12.5.9 Remote Access

Your phone lets you check your messages, or otherwise operate your answering machine, by calling the answering machine when you are away from home and then dialling a 4-digit remote access PIN from a tone-dialling phone. The 4-digit remote access PIN code is used to prevent other people from unauthorised access of your answering machine.

Note:

Remote Access must be turned on if you want to be able to use this feature, see 12.5.9.2.

12.5.9.1 Change the 4-Digit Remote Access PIN

tPress tPress

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“.

tPress and / to select “CHANGE PIN“. tPress tPress tPress

Note:

If the new PIN entered in Step 6 is not the same as the new PIN entered in Step 5, you must enter the new system PIN at step 5 again.

to show “PIN?----“, then enter the Old PIN. (Default Remote Access PIN is 0000). to show “NEW PIN?----“, then enter your new 4-digit PIN. to show “CONFIRM?----“, then enter your new 4-digit PIN again.

tPress

12.5.9.2 Activate or Deactivate the Remote Access

tPress tPress tPress tPress tPress

12.5.9.3 Access Your Answering Machine Remotely

You can ring your phone from another tone-dialling phone to switch the answering machine on or off, and/ or listen to your messages remotely.

tPlace a call from a tone-dialling phone to your phone. tWhen the answering machine answers the call and starts playing the OGM, press the * key. The OGM

will stop playing

tEnter the 4-digit Remote Access PIN (default PIN is 0000). You will hear a single beep if the 4 digits are

accepted, and then will need to press 5 to start playing any messages.

Note:

The * may be entered during or after the OGM, and the 4-digit PIN should be follow without any delays.

Note:

If the 4-digit Remote Access PIN is not accepted, you will hear a multiple beep, and if it is entered incorrectly three times consecutively, the line will be released automatically.

to reconﬁrm.

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “REMOTE ACC“. and / to select “ON“ or “OFF“ to turn the remote access on or off respectively. to conﬁrm.

tPress the following keys to carry out your desired function.

Keys Functions

While message is not playing While message is playing 2 Delete the current message playing 4 Repeat playing the current message from the

beginning. Press twice to skip backward to

play the previous message 5 Play the message Stop the current message playback 6 Skip to play the next message 7 Turn on the answering machine 8 Stop the current message palyback 9 Turn off the answering machine

Note:

If your answering machine is switched off, the phone will enter into the remote access mode after 14 rings. You can then enter the <*> key and the 4-digit remote access PIN (Default Remote Access PIN is 0000) to activate the remote access feature.

Using the corded base

12.6 Switching the TAM On/Off

When the TAM is switched on, the TAM ON/OFF indicator will be turned on, and it will ﬂash if there are new messages recorded.

If the TAM is turned off, the TAM ON/OFF indicator will be off unless there are new messages.

12.6.1 Using the direct key

tFrom idle mode, press

12.6.2 Using the menu

tPress tPress tPress

12.7 Outgoing Message Settings

12.7.1 Record your Outgoing Message (OGM)

You can record your own OGM for “ANS & REC“ mode or “ANSWER ONLY“ mode. When you record your own OGM, it will be used when the answering machine answers the call. If your personal OGM is deleted, the preset OGM will be restored automatically.

12.7.1.1 Using the direct key on the base

tMake sure the TAM is set to the answer mode required, “ANS & REC“ or “ANSWER ONLY“. tPress and hold

Then speak clearly from about 30cm away from the base to record your personal OGM.

tWhen you want to end the recording, press the

The base will playback your new personal outgoing message and display “PLAYING OGM“.

and / to select “ANS. MACHINE“. and / to go to “TAM ON/OFF“ and press to select. to select “ON“ or “OFF“ then to conﬁrm the selection.

to switch the TAM on or off.

until you hear a beep and “RECORDING“ appears on the Base display.

button.

Note:

Press OGM.

12.7.1.2 Using the menu

tPress tPress tPress tPress tPress tPress tPress

Note:

Press OGM.

12.7.2 Playback the Outgoing Message (OGM)

12.7.2.1 Using the direct key

tPress

12.7.2.2 Using the Menu

tPress

tPress tPress tPress tPress tPress

at any time during recording or playback to erase your personal OGM and return to the preset

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “OGM SETTINGS“. and / to select “ANS & REC“ or “ANSWER ONLY“. and / to select “RECORD“. to start recording your personal OGM and “RECORDING” is displayed on the screen. to stop and save your personal OGM. Your newly saved OGM will playback automatically.

at any time during recording or playback to erase your personal OGM and return to the preset

brieﬂy to listen to the current OGM (“ANS & REC“ or “ANSWER ONLY“).

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “OGM SETTINGS“. and / to select “ANS & REC“ or “ANSWER ONLY“. to show “PLAYBACK“. to play your current OGM and display “PLAYING OGM“.

12.7.3 Delete a Personal OGM (Set OGM to DEFAULT)

12.7.3.1 Using the direct key

tPress tWhile it is playing, press “DELETE“ to delete your personal OGM and return to standby mode, with the

pre-set OGM restored automatically.

to play your OGM

Note:

If a pre-set OGM is playing, you are not allowed to delete it, so pressing “DELETE“ will have no effect.

12.7.3.2 Using the Menu

tPress tPress tPress tPress tPress tPress tPress

12.8 Switch between OGMs

By default, the answer machine is set in “ANS & REC“ mode which allows callers to leave a message. This mode can be changed to “ANSWER ONLY“ which does not allow callers to leave a message. In that case, your callers will be prompted to call back later. When the answering machine is switched ON, you can select “ANS & REC“ or “ANSWER ONLY“. Using the Menu:

tPress tPress tPress tPress tPress

12.9 TAM messages

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “OGM SETTINGS“. and / to select “ANS & REC“ or “ANSWER ONLY“. and / to select “DEFAULT“. to show “PIN ?“ and then enter the system PIN (default 0000). to delete your personal OGM and replace it with the preset OGM.

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. to show “ANSWER MODE“. and / to select “ANS & REC“ or “ANSWER ONLY“. to conﬁrm.

12.9.1 Play the TAM messages

If you have new messages, the base display will show e.g. “01/02 MSGS“, which means you have 1 new message out of a total of 2 messages. New messages are played ﬁrst, and then are saved as old messages, until they are deleted. Old messages are played again after all new messages are played completely.

tFrom idle, press tDuring playback, press tDuring playback, press

the previous message.

tDuring playback, press tPress

12.9.2 Delete a message on the TAM

tPress tYou will hear a tone and the current message or memo playing will be deleted. If there are more

messages, the next message will start to play.

12.9.3 Delete all messages on the TAM

12.9.3.1 Using the direct key

tIn idle mode, press and hold tYou will hear a tone and all old messages will be deleted.

to delete the current message being played.

while a message is playing.

to listen to messages and memos.

to stop the playback.

once to replay the current message from the beginning, or twice to replay

MEMO

to skip on to the next message.

for 2 seconds to delete all old messages.

Note:

New messages will not be deleted.

12.9.3.2 Using the menu

tPress tPress tPress tPress

and / to select “ANS. MACHINE“. and / to select “DELETE ALL“. and display will show “CONFIRM?“ to conﬁrm and the display will return to the previous menu.

Note:

You cannot delete New Messages, so you will have to start to play them before trying to delete them.

12.10 Record a Memo on the TAM

You can record a memo message for another user. When you record a memo, it is saved as a new message and can be played back in the same way as answering machine messages. Memo recording can still function even when the answering machine is turned off.

12.10.1 Using the direct key

MEMO

tPress and hold

and the display will brieﬂy show “MEMO“ and then “RECORDING“ and the

current recording time. Release the button and start talking.

tWhen you want to end your memo recording, press

The memo will then play back. Let it play to the end or press

again to stop the playback and save the message. OR Press

at any time to stop the memo without saving it.

12.10.2 Using the Menu

tPress tPress tPress tPress

Let it play to the end or press

and / to select “ANS. MACHINE“. and / to select “MEMO“. to start recording the memo, and “RECORDING“ and a timer are shown on the display. to end your memo recording and the memo will then play back.

again to stop the playback and save the message. OR Press

at any time to stop the memo without saving it.

Note:

If the memory becomes full, during the memo recording, you will hear a tone, the recording will stop and the memo recorded will start to play back.

12.11 Incoming Call Messages (ICM)

If the answering machine is ON and set for “ANS & REC“, when there is an incoming call, the answering machine will answer it and play the OGM, followed by a beep sound. The caller can then leave a message of up to 1, 2 or 3 minutes, or of unlimited length up to the available memory on the answering machine, as set in section 12.12.2. If the “BS SCREENING“ is ON, the caller‘s voice will also be played through the loudspeaker on the base station, to allow you to screen the call and decide if you want to leave the answering machine to record the message, or if you want to talk to the caller directly.

At any time if you want to pick up the call, you can lift up the corded handset or press

to intercept the call and talk to the caller directly. The message recording will be stopped automatically. If the answering machine is in the process of recording, the message already stored will be saved. tYou can use the corded handset, the speakerphone or the cordless handset to intercept the call to speak

to the caller during ICM recording. Then the message that is currently being recorded will be saved as a new message.

12.12 TAM Settings

12.12.1 Set the Answer Delay

You can set the number of rings before the answering machine answers and starts playing your OGM. You can set the answering machine to answer after two to eight rings or “TIME SAVER“. When you ring in to access your messages remotely, if your answering machine is set to time saver, it will answer after 2 rings if you have new messages, or after 5 rings if you do not have any new messages, so if you call in and don‘t get an answer within 3 or 4 rings, you can hang up and save on call charges.

tPress tPress tPress tPress

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “ANSWER DELAY“. and / to select the desired answer delay from the available options “2 RINGS“, “4 RINGS“,

“6 RINGS“, “8 RINGS“ or “TIME SAVER“.

tPress

to conﬁrm.

Warning:

12.12.2 Set the Maximum Recording Time for Incoming Messages

You can set the maximum length of the recording time of the incoming messages to be either 1, 2 or 3 minutes, or of unlimited length up to the available memory left on the answering machine.

tPress tPress tPress tPress

“180S“ or “UNLIMITED“.

tPress

12.12.3 Turn On or Off the Base Screening

You can select to turn on or off the call screening on the base.

tPress tPress tPress tPress tPress

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “RECORD TIME“.

and / to select your desired recording time from the available options “60S“, “120S“,

to conﬁrm.

and / to select “ANS. MACHINE“. and / to select “TAM SETTINGS“. and / to select “BS SCREENING“. and / to select “ON“ or “OFF“. to conﬁrm.

12.12.4 Activate Remote Access

You can check messages, or otherwise operate your TAM, by calling the TAM when you are away from home and dialling a 4-digit remote access PIN from a tone-dialling phone, provided the Remote Access is turned on.

tPress tPress tPress tPress tPress

12.12.5 Change the 4-Digit Remote Access PIN

You can change your 4-digit Remote Access PIN for added security to prevent other people from unauthorised access of your answering machine.

tPress tPress tPress tPress tPress tPress tPress

12.12.6 Reset TAM to Default Settings

You can reset your answering machine to the default settings, without deleting any messages.

tPress tPress tPress tPress tPress

and / to select ”ANS. MACHINE”. and / to select ”TAM SETTINGS”. and / to select ”REMOTE ACC”. and / to select ”ON” or ”OFF” to turn on or off the remote access respectively. to conﬁrm.

and / to select ”ANS. MACHINE”. and / to select ”TAM SETTINGS”. and / to select ”CHANGE PIN”. to show ”PIN ?”, and then enter the current PIN (default 0000). to show ”NEW PIN”, then enter your new 4-digit PIN. to show ”REPEAT”, then enter your new 4-digit PIN again. to conﬁrm the change.

and / to select ”ANS. MACHINE”. and / to select ”TAM SETTINGS”. and / to select ”TAM DEFAULT.” to show “PIN ?”, and then enter the system PIN code. (Default is 0000) to restore the TAM settings to default.

13 GUARANTEE AND SERVICE

The phone is guaranteed for 24 months from the date of purchase shown on your sales receipt. This guarantee does not cover any faults or defects caused by accidents, misuse, fair wear and tear, neglect, faults on the telephone line, lightning, tampering with the equipment, or any attempt at adjustment or repair other than through approved agents.

Please keep your sales (till) receipt this is your proof of guarantee.

13.1 While the unit is under Guarantee

tDisconnect the base unit from the telephone line and the mains electricity supply. tPack up all parts of your phone system, using the original package. tReturn the unit to the shop where you bought it, making sure you take your sales receipt. tRemember to include the mains adapter.

13.2 After the Guarantee has expired

If the unit is no longer under Guarantee, contact us via www.aegtelephones.eu

This product works with rechargeable batteries only. If you put nonrechargeable batteries in the handset and place it on the base, the handset will be damaged and this in NOT covered under the warranty conditions.

14 TECHNICAL DETAILS

Standard Digital Enhanced Cordless Telecommunication (DECT) Frequency range 1.88 to 1.9 GHz (bandwidth = 20 MHz) Channel bandwidth 1.728 MHz Operating range Up to 300m outdoors; Up to 50m indoors Operating time Standby: 100 hours, Talking: 10 hours

Battery charge time: 15 hours

Temperature range Operating 0° C to 40° C, Storage -20° C to 60° C Electrical power Corded Base:

Ten Pao - S004LB0600045 / S004LV0600045 input 100-240VAC 50/60Hz 150mA, output 6VDC 450mA Charger unit: Ten Pao - S004LB0600030 / S004LV0600030 input 100-240VAC 50/60Hz 150mA, output 6VDC 300mA

15 CE DECLARATION

This product is in compliance with the essential requirements and other relevant provisions of the R&TTE directive 1999/5/EC. The Declaration of conformity can be found on: www.aegtelephones.eu

16 DISPOSAL OF THE DEVICE (ENVIRONMENT)

At the end of the product lifecycle, you should not throw this product into the normal household garbage but bring the product to a collection point for the recycling of electrical and electronic equipments. The symbol on the product, user guide and/or box indicate this. Some of the product materials can be re-used if you bring them to a recycling point. By reusing some parts or raw materials from used products you make an important contribution to the protection of the environment. Please contact your local authorities in case you need more information on the collection points in your area.

Batteries must be removed before disposing of the device. Dispose of the batteries in an environmental manner according to your country regulations.

17 CLEANING AND CARE

Do not clean any part of your phone with benzene, thinners or other solvent chemicals as this may cause permanent damage which is not covered by the Guarantee.

When necessary, clean it with a damp cloth. Keep your phone system away from hot, humid conditions or strong sunlight, and don‘t let it get wet.

Subject to avaibility. Rights of modification reserved.

AEG is a registered trademark used under license from AB Electrolux (publ)

www.aegtelephones.eu

AEG Voxtel D215 combo User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
