USER MANUAL
PRO COMBI
BS730470KM
BS730472KM
EN
CONTENTS
1. SAFETY INFORMATION...................................................................................................3
2. SAFETY INSTRUCTIONS...................................................................................................4
3. PRODUCT DESCRIPTION.................................................................................................7
4. CONTROL PANEL............................................................................................................. 8
5. BEFORE FIRST USE......................................................................................................... 10
6. DAILY USE........................................................................................................................ 11
7. CLOCK FUNCTIONS.......................................................................................................14
8. AUTOMATIC PROGRAMMES........................................................................................ 16
9. USING THE ACCESSORIES............................................................................................ 17
10. ADDITIONAL FUNCTIONS.......................................................................................... 20
11. HINTS AND TIPS........................................................................................................... 22
12. CARE AND CLEANING.................................................................................................43
13. TROUBLESHOOTING...................................................................................................47
14. ENERGY EFFICIENCY...................................................................................................49
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you impeccable
performance for many years, with innovative technologies that help make life simpler
features you might not find on ordinary appliances. Please spend a few minutes
reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
www.aeg.com
2
1. SAFETY INFORMATION
Before the installation and use of the appliance,
carefully read the supplied instructions. The
manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
• If the appliance has a child safety device, this should
be activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
• Children aged 3 years and under must be kept away
from this appliance when it is in operation at all times.
1.2
General Safety
• Only a qualified person must install this appliance and
replace the cable.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements. Children less than 8
years of age shall be kept away unless continuously
supervised.
ENGLISH
3
• Always use oven gloves to remove or put in
accessories or ovenware.
• Before maintenance cut the power supply.
• Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door since they can scratch
the surface, which may result in shattering of the glass.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
• The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
• Only use the core temperature sensor recommended
for this appliance.
2.
SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instruction
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• Keep the minimum distance from the
other appliances and units.
• Make sure that the appliance is
installed below and adjacent safe
structures.
• The sides of the appliance must stay
adjacent to appliances or to units with
the same height.
2.2 Electrical connection
WARNING!
Risk of fire and electrical
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
www.aeg.com
4
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to
the mains plug and to the mains
cable. Should the mains cable need
to be replaced, this must be carried
out by our Authorised Service Centre.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• This appliance complies with the
E.E.C. Directives.
2.3 Use
WARNING!
Risk of injury, burns and
electrical shock or explosion.
• This appliance is for household use
only.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not apply pressure on the open
door.
• Do not use the appliance as a work
surface or as a storage surface.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
WARNING!
Risk of damage to the
appliance.
• To prevent damage or discoloration
to the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put aluminium foil directly
on the bottom of the appliance.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel has no
effect on the performance of the
appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
• Always cook with the oven door
closed.
• If the appliance is installed behind a
furniture panel (e.g. a door) make sure
the door is never closed when the
appliance is in operation. Heat and
moisture can build up behind a
closed furniture panel and cause
subsequent damage to the appliance,
ENGLISH
5
the housing unit or the floor. Do not
close the furniture panel until the
appliance has cooled down
completely after use.
2.4 Steam Cooking
WARNING!
Risk of burns and damage to
the appliance.
• Released Steam can cause burns:
– Be careful when you open the
appliance door when the function
is activated. Steam can release.
– Open the appliance door with
care after the steam cooking
operation.
2.5 Care and cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains
plug from the mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of
detergent.
2.6 Internal light
• The type of light bulb or halogen
lamp used for this appliance is only
for household appliances. Do not use
it for house lighting.
WARNING!
Risk of electrical shock.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
2.8 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
www.aeg.com
6
3. PRODUCT DESCRIPTION
3.1 General overview
21
10
9
5
4
3
2
1
5
4
6
7
8
3
1
Control panel
2
Electronic programmer
3
Water drawer
4
Socket for the core temperature
sensor
5
Heating element
6
Lamp
7
Fan
8
Descaling pipe outlet
9
Shelf support, removable
10
Shelf positions
3.2 Accessories
Wire shelf
For cookware, cake tins, roasts.
Baking tray
For cakes and biscuits.
Grill- / Roasting pan
To bake and roast or as a pan to collect
fat.
Trivet
For roasting and grilling.
Use the trivet only with the
Grill- / Roasting pan.
Core temperature sensor
To measure how far the food is cooked.
ENGLISH
7
Steam set
One unperforated and one perforated
food container.
The steam set drains the condensing
water away from the food during steam
cooking. Use it to prepare food that
should not be in the water during the
cooking (e.g. vegetables, pieces of fish,
chicken breast). The set is not suitable for
food that needs to soak in the water (e.g.
rice, polenta, pasta).
4. CONTROL PANEL
4.1 Electronic programmer
1 2 3 4 5 6 7 8 9 10
Use the sensor fields to operate the appliance.
Sensor
Field
Function Description
1
- DISPLAY Shows the current settings of the appliance.
2
ON / OFF To activate and deactivate the appliance.
3
OPTIONS To set an oven function or an automatic pro-
gramme.
4
MY FAVOURITE
PROGRAMME
To store your favourite programme. Use it to
have access to your favourite programme directly or when the appliance is deactivated.
5
TEMPERATURE /
FAST HEAT UP
To set and see the cavity temperature or the
core temperature sensor temperature (if
present). If you press and hold it for three seconds, it turns the Fast heat up function ON or
OFF. Straight access to the temperature setting
of the first oven function when the appliance is
off.
www.aeg.com8
Sensor
Field
Function Description
6
UP, DOWN To move up or down in the menu.
7
OK To confirm a selection or setting.
8
OVEN LIGHT To activate or deactivate the lamp.
9
CLOCK To set the clock functions.
10
MINUTE MINDER To set the Minute Minder.
4.2 Display
A B C
DEFG
A. Oven function symbol
B. Temperature / time of day display
C. Clock / Residual heat display /
Minute Minder
D. Residual heat indicator
E. Indicators for the clock functions
F. Heat-up indicator / Fast Heat Up
indicator
G. Number of an oven function /
programme
Other indicators of the display:
Symbol Name Description
Functions You can choose an oven function.
Automatic programme You can choose an automatic pro-
gramme.
My favourite programme The favourite programme operates.
/
kg / g An automatic programme with a weight
input operates.
/
h / min A clock function operates.
Temperature / Fast heat up The function operates.
Temperature The current temperature is indicated.
ENGLISH 9
Symbol Name Description
Temperature You can change the temperature.
Core temperature sensor The core temperature sensor is in the
core temperature sensor socket.
Light You deactivated the light.
Minute minder The minute minder function operates.
Water drawer indicator Shows the water level
4.3 Heat up indicator
If you activate an oven function, the bars
come on in the display. The bars
show that the temperature in the
appliance increases or decreases.
When the appliance is at the set
temperature, the bars go off the display.
5. BEFORE FIRST USE
WARNING!
Refer to Safety chapters.
To set the Time of day refer
to "Clock functions"
chapter.
5.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the appliance.
Refer to "Care and
cleaning" chapter.
Clean the appliance and the accessories
before first use.
Put the accessories and the removable
shelf supports back to their initial
position.
5.2 Setting the hardness level
for the water
When you connect the appliance to the
mains, you have to set the water
hardness level.
The table below explains the water
hardness range with the corresponding
Calcium deposit (mmol/l) and the quality
of the water.
Water hardness Calcium deposit
(mmol/l)
Calcium deposit
(mg/l)
Water classification
Class dH
1 0 - 7 0 - 1.3 0 - 50 Soft
2 7 - 14 1.3 - 2.5 50 - 100 Moderately
hard
3 14 - 21 2.5 - 3.8 100 - 150 Hard
4 over 21 over 3.8 over 150 Very hard
www.aeg.com10
When the water hardness exceeds the
values in the table, fill the water drawer
with bottled water.
1. Take the four colour change strip
supplied with the steam set in the
oven.
2. Put all the reaction zones of the strip
into the water for approximately 1
second.
Do not put the strip into the running
water!
3. Shake the strip to remove the excess
of the water.
4. After 1 minute check the hardness of
the water according to the table
below.
The colours of the reaction zones
continue to change after 1 minute.
Do not consider this in the
measurement.
5. Set the hardness of the water in the
settings menu. Refer to the "Using
the settings menu".
Test strip Hardness of the
water
1
2
3
4
The black squares in the table
correspond to red squares on the test
strip.
You can change the hardness level of the
water in the menu settings menu.
After a power cut you do not have to set
the hardness level of the water again.
6. DAILY USE
WARNING!
Refer to Safety chapters.
6.1 Operating the appliance
To operate the appliance you can use:
• the manual mode
• automatic programmes
6.2 Oven functions
Oven function Application
True Fan Cooking
To bake on up to three shelf positions at the same time
and to dry food. Set the temperature 20 - 40 °C lower
than for Top / Bottom Heat.
Pizza Setting To bake food on one shelf position for a more intensive
browning and a crispy bottom. Set the temperature 20
- 40 °C lower than for Top / Bottom Heat.
Slow Cooking To prepare tender, succulent roasts.
Top / Bottom
Heat
To bake and roast food on one shelf position.
Frozen Foods To make convenience food like e.g. french fries, potato
wedges or spring rolls crispy.
ENGLISH 11
Oven function Application
Turbo Grilling To roast larger meat joints or poultry with bones on
one shelf position. Also to make gratins and to brown.
Grilling To grill flat food and to toast bread.
Fast Grilling To grill flat food in large quantities and to toast bread.
Keep Warm To keep food warm.
Bottom Heat To bake cakes with crispy bottom and to preserve food.
Defrost This function can be used for defrosting frozen foods,
such as vegetables and fruits. The defrosting time depends on the amount and size of the frozen food.
Moist Fan Baking To prepare baked goods in tin on one shelf position.
To save energy during cooking. This function must be
used in accordance with the cooking tables in order to
achieve the desired cooking result. To get more information about the recommended settings, refer to the
cooking tables. This function was used to define the
energy efficiency class acc. to EN 60350-1.
Bread Baking Use this function to prepare bread and bread rolls with
a very good professional-like result in terms of crispiness, colour and crust gloss.
Steam Regenerating
Food reheating with steam prevents surface drying.
Heat is distributed a gentle and even way, which allows
to recover taste and aroma of food as just prepared.
This function can be used to reheat food directly on a
plate. You can reheat more than one plate at the same
time, using different shelf positions.
Quarter Steam +
Heat
To bake bread, roast large pieces of meat or to warm
up chilled and frozen meals.
Half Steam +
Heat
For dishes with a high moisture content and for poaching fish, custard royale and terrines.
Full Steam For vegetables, fish, potatoes, rice, pasta or special
side-dishes.
The lamp may automatically
deactivate at a temperature
below 60 °C during some
oven functions.
6.3 Setting the oven function
1. Activate the appliance with or .
www.aeg.com12
The display shows the set temperature,
the symbol and the number of the oven
function.
2. Touch or to set an oven
function.
3. Touch or the appliance starts
automatically after five seconds.
If you activate the appliance
and do not set an oven
function or programme, the
appliance deactivates
automatically after 20
seconds.
6.4 Changing the temperature
Touch or to change the
temperature in steps of 5 °C.
When the appliance is at the set
temperature, an acoustic signal sounds
three times and the Heat up indicator
goes out.
6.5 Checking the temperature
You can see the temperature in the
appliance when the function or
programme operates.
1. Touch .
The Temperature / Time display shows
the temperature in the appliance.
2. Touch
to go back to the set
temperature or the display shows it
automatically after five seconds.
6.6 Fast heat up function
Do not put food in the oven
when the Fast heat up
function operates.
The Fast heat up function is not available
with every oven function. An acoustic
signal sounds if the Fast heat up function
is not available for the set function if
Faulty tone is activated in the settings
menu. Refer to "Using the settings
menu".
The Fast heat up function decreases the
heat up time.
To activate the Fast heat up function
touch and hold for more than three
seconds.
If you activate the Fast heat up function,
the bars on the display flash one by
one and comes on to show that
the function operates.
6.7 Steam cooking
The water drawer cover is in the control
panel.
WARNING!
Use only water as the liquid.
Do not use filtered
(demineralised) or distilled
water.
1.
Press the cover of the water drawer
to open it.
2. Fill the water drawer with cold water
to the maximum level (around 950
ml) until the acoustic signal sounds or
the display shows the message.
The water supply is sufficient for
approximately 50 minutes.
Do not fill the water drawer over its
maximum capacity. There is a risk of
water leakage, overflow and furniture
damages.
3. Push the water drawer to its initial
position.
4. Activate the appliance.
5. Set the steam function (refer to the
"Oven functions" table) and the
temperature.
6. If necessary, touch
to set the
DURATION
or END function
(refer to "Setting the END" or
"Setting the DURATION").
The first steam shows after
approximately 2 minutes. An acoustic
signal sounds when the appliance is at
approximately the set temperature. The
signal sounds again at the end of the
cooking time.
7. Touch to deactivate the acoustic
signal and the appliance.
ENGLISH
13
7. CLOCK FUNCTIONS
7.1 Clock functions table
Clock function Application
TIME OF DAY To show or change the time of day. You can change the
time of day only when the appliance is on.
DURATION To set how long the appliance operates.
END To set when the appliance deactivates.
TIME DELAY To combine DURATION and END function.
SET+GO To start the appliance with necessary settings with only
one touch of the sensor field any time later.
MINUTE MINDER To set a countdown time. This function has no effect on
the operation of the oven. You can set the MINUTE
MINDER at any time and also when the appliance is off.
00:00 COUNT UP TIMER To set the count up, which shows how long the appli-
ance operates. This function has no effect on the operation of the appliance. It is on immediately when the oven
starts to heat. The COUNT UP TIMER is not activated if
DURATION and END are set.
7.2 Setting and changing the
time
After the first connection to the mains,
wait until the display shows and 12:00.
"12" flashes.
1. Touch or to set the hours.
2. Touch or .
3. Touch or to set the minutes.
4. Touch or .
The display shows the new time.
To change the time of day touch
again and again until starts to flash.
7.3 Setting the DURATION
1. Set an oven function and
temperature.
2. Touch
again and again until
starts to flash.
3. Use or to set the minutes for
DURATION time.
4. Touch or the DURATION time
starts automatically after 5 seconds.
5. Use or to set the hours for
DURATION time.
6. Touch . The DURATION time
starts automatically after 5 seconds.
When the set time ends, an acoustic
signal sounds for 2 minutes. and time
setting flash in the display. The appliance
deactivates.
7. Touch a sensor field or open the
oven door to stop the acoustic
signal.
8. Turn off the appliance.
7.4 Setting the END
1. Set an oven function and
temperature.
2. Touch
again and again until
starts to flash.
3. Use or to set the END and
or to confirm. First you set the
minutes and then the hours.
www.aeg.com
14
When the set time ends, an acoustic
signal sounds for 2 minutes. and the
time setting flash in the display. The
appliance deactivates automatically.
4. Touch a sensor field or open the
oven door to stop the acoustic
signal.
5. Turn off the appliance.
7.5 Setting the TIME DELAY
function
1. Set an oven function and
temperature.
2. Touch again and again until
starts to flash.
3. Use or to set the minutes for
DURATION.
4. Touch
.
5. Use or to set the hours for
DURATION.
6. Touch
, the appliance switches to
the setting of the END function.
The display shows flashing .
7. Use
or to set the END and
or to confirm. First you set the
minutes and then the hours.
Appliance turns on automatically later
on, works for the set DURATION time
and stops at the set END time. At the set
time an acoustic signal sounds for 2
minutes.
and the time setting flash in
the display. The appliance deactivates
automatically.
8. Touch a sensor field or open the
oven door to stop the acoustic
signal.
9. Turn off the appliance.
When the Time delay
function is activated, the
display shows a static
symbol of the oven function,
with a dot and . The
dot shows which clock
function is on in the Clock /
residual heat display.
7.6 Setting the SET+GO
You can use the SET+GO function only
when the DURATION is set.
1. Set an oven function (or a
programme) and temperature.
2. Set the DURATION.
3. Touch again and again until
flashes in the display.
4. Touch to set the SET+GO
function.
The display shows
and with an
indicator. This indicator shows which
clock function is activated.
5. Touch a sensor field (apart from ON /
OFF) to start the SET+GO function.
7.7 Setting the MINUTE
MINDER
1.
Touch
.
and "00" flash in the display.
2.
Use to switch between options.
First you set the seconds, then the
minutes and the hours.
3. Use
or to set the MINUTE
MINDER and to confirm.
4. Touch or the MINUTE MINDER
starts automatically after 5 seconds.
When the set time ends, an acoustic
signal sounds for 2 minutes and 00:00
and flash in the display.
5. Touch a sensor field or open the
oven door to stop the acoustic
signal.
7.8 COUNT UP TIMER
1. To reset the Count Up Timer, touch
again and again until flashes in
the display.
2. Touch until the display shows
"00:00" and the Count Up Timer
starts to count up again.
ENGLISH
15
8. AUTOMATIC PROGRAMMES
WARNING!
Refer to Safety chapters.
There are 25 automatic programmes.
Use an automatic programme or recipe
when you do not have the knowledge or
experience on how to prepare a dish.
The display shows the default cooking
times for all automatic programmes.
8.1 Automatic programmes
Programme number Programme name
1 VEGETABLES, TRADITIONAL
2 POTATO GRATIN
3 FARMER BREAD
4 ROLLS
5 FISH
6 POACHED FISH (TROUT)
7 PLUM DUMPLING
8 VEAL KNUCKLE
9 RICE
10 LASAGNE
11 DOUGH PROVING
12 BRAISED MEAT
13 ROAST PORK
14 ROAST VEAL
15 ROAST LAMB
16 ROAST GAME
17 WHOLE CHICKEN
18 PIZZA
19 QUICHE LORRAINE
20 LEMON SPONGE CAKE
21 CHEESE CAKE
22 CANNELLONI
23 CONVENIENCE CAKE
24 CONVENIENCE PIZZA
25 CONVENIENCE POTATO TYPES
www.aeg.com16
Loading...
