Aastra 51i
Exceptional Features and Value in a Basic Level IP Telephone
The Aastra 51i offers features and flexibility in an open-standards
based, carrier grade basic level IP telephone. With a sleek and elegant
design and LCD display the 51i is fully interoperable with leading IP
Telephony platforms, offering advanced XML capability to access custom
applications and support for high-quality SIP communications.
Part of the 5i Series of IP telephones, the 51i is ideally suited for light
use small and medium business applications such as lobbies, common
areas or individual user environments where single line high-quality SIP
communication is required.
IP Telephones
Key Features and Benefits:
XML Browser
»
The Aastra 51i is equipped with XML browser capabilities allowing access to
customized services and applications. Create internal service applications using
development guides available from Aastra. This feature provides unlimited
potential to customize the 51i to meet your specific business needs or vertical
applications using the display keypad.
Enhanced Call Management
»
With extensive storage capacity for personal directory, callers log, and redial list,
the Aastra 51i can improve efficiency by providing more call information with
the push of a button. Features such as shared call and bridged line appearances,
call forward, call transfer and call waiting increase call flexibility and control.
Remarkable Audio
»
All Aastra IP telephones offer full duplex speakerphone with excellent voice
clarity and delivery. With years of experience in telecommunications and
telephone design, Aastra can ensure superior voice quality on every product
we sell.
Simplified Deployment
»
From initial deployment and configuration to future enhancements and
upgrades, the Aastra family of IP telephones are designed to save your business
time and money. Dual auto-sensing switched Ethernet ports eliminate
additional wiring and simplify installations. Integrated IEEE 802.3af Powerover-Ethernet allows easy deployment with centralized powering and backup.
Easily created configuration files, using any text editor, can be used to configure
phones individually or centrally
Feature Highlights*
1 call appearance
»
Shared call and bridged line
»
appearances
Distinctive ringing, priority alerting
»
XML browser
»
Personal directory
»
Call forward, Call transfer, Call
»
waiting
Caller and calling line information
»
Callers log
»
Intercom reception with auto-
»
answer
Redial list
»
Do Not Disturb
»
Live dial pad support
»
Supports Busy Lamp Field (BLF)
»
monitoring by other end points*
Digium’s Asterisk – Bridged Line
»
Appearances (BLA), Intercom
Broadsoft’s BroadWorks Enhanced
»
SIP – supports Shared Call
Appearances, CommPilot Call
Manager, Call Park/Pickup, Priority
Alerting
Nortel’s MCS 5100/5200 SIP support
»
– Voicemail, and NAT Traversal
support
»
Sylantro’s SIP–B support - Last
Call return, Warn line and Hot Line,
Distinctive ringing, Call Park/Pickup,
and Centralized Conferencing
among others
Your Connection to the World
* Feature availability dependant on IP telephony systems
Aastra 51i Technical Specifications
www.aastratelecom.com
Physical
20.8 cm W x 23.5 cm D x 8.0 cm H (8.2”W
»
x 9.3”D x 3.2”H)
889g (31.3 oz)
»
4 positions footstand
»
Wall mountable
»
Power
Integrated IEEE 802.3af Power Over
»
Ethernet (PoE) support
AC wall adapter (sold separately)
»
Audio
Hearing aid compatible (HAC) handset
»
Full-duplex quality speakerphone
»
Display and Indicator
3 line LCD display
»
LED for call and message waiting
»
indicator
Feature Keys
1 call appearance
»
4 navigational keys
»
9 configurable speed-dial keys using
»
number keypad
9 predefined hard keys, plus 2 volume
»
keys:
Goodbye
•
Services
•
Hold
•
Redial
•
Save
•
Delete
•
Swap
•
Speakerphone
•
Mute
•
Protocols / Codecs
IETF SIP (RFC3261) and associated RFC
»
drafts
G.711 μ-law / A-law
»
G.729
»
Localization
Multi-lingual support – English, French,
»
Spanish, Italian, German
Downloadable language pack
•
support for customization and
additional language translations
Country-specific call progress tones and
»
cadences
Security
User and administrator level passwords
»
Encryption of configuration files
»
HTTPS configuration download and web
»
management
Phone lock with PIN
»
TLS and SRTP*
»
Networking
Dual 10/100 Mbps switched Ethernet
»
ports
Manual or Dynamic Host Configuration
»
Protocol (DHCP) IP address setup
Time and date synchronization using
»
SNTP
Quality of Service (QOS) support
»
– IEEE 802.1 p/Q VLAN and priority
tagging, Type of Services (TOS), and
Differentiated Services Code Point
Network Address Translation (NAT)
»
support
Integrated HTTP/HTTPS server for
»
web administration and maintenance
including a built-in troubleshooting
section
Mass deployment via central
»
provisioning of user configuration files
– TFTP, FTP, HTTP, HTTPS
Redundant server support
»
DNS-SRV
•
Local backup registrar and/or proxy
•
server
Interoperability
5xi series common interoperability
»
certifications. See latest software release
notes for up to date information
Part Numbers
A1751-0131-10-01 – 51i Phone with
»
English Text Keypad, Includes English
Install Guide
A1751-0131-10-55 – 51i Phone with
»
International Symbols Keypad, Includes
Multi-language install Guides
Accessories
AC adapters, sold separately
»
D0023-0041-01-00 (North American
•
AC adapter)
D0023-1051-00-75 (Universal AC
•
adapter)
Optional midspan Power Over Ethernet
»
(POE) injector available, but not
provided, for networks that do not
supply power
D0023-0031-00-00 (North America)
•
D0023-0031-PS-00 (Universal)
•
Package Contents
Aastra 51i IP telephone
»
Handset and coil cord
»
2x Footstand
»
Ethernet cable
»
Quick reference speedial label
»
Wall Drilling template, screws and
»
anchors
Installation Guide
»
Regulatory
CE
ROHS compliant
»
WEEE (2002/96/EC)
»
CE Mark (89/336/EEC EMC Directive and
»
73/23/EEC Low Voltage Directive)
EMC
FCC Part 15 Class B
»
ICES-003 Class B
»
AS/NZS 3548 Class B
»
EN55022 Class B
»
CISPR22 Class B
»
EN55024
»
»
EN61000-4-2, 4-3, 4-4, 4-5, 4-6, 4-8, 4-11
Safety
CAN/CSA C22.2 No. 60950
»
EN 60950
»
UL 60950-1
»
Telecom
FCC Part 68 (Hearing Aid Compatibility)
»
* Feature availability dependant on IP telephony systems
COPYRIGHT (C) 2007 AASTRA TECHNOLOGIES LTD. ALL RIGHTS RESERVED. INFORMATION IN THIS DOCUMENT IS SUBJECT
TO CHANGE WITHOUT NOTICE. AASTRA TELECOM ASSUMES NO RESPONSIBILITY FOR ANY ERRORS THAT MAY APPEAR
IN THIS DOCUMENT. PRODUCT CAPABILITIES DESCRIBED IN THIS DOCUMENT PERTAIN SOLELY TO AASTRA TELECOM’S
MARKETING ACTIVITIES IN THE U.S AND CANADA. AVAILABILITY IN OTHER MARKETS MAY VARY.
Rev 07/07
AASTRA TELECOM
155 SNOW BLVD.,
CONCORD, ONTARIO, CANADA, L4K 4N9
SALES@AASTRA.COM • WWW.AASTRATELECOM.COM
Aastra 55i
Exceptional Features and Value in an Advanced Featured,
Expandable IP Telephone
The Aastra 55i offers powerful features and flexibility in a standards
based, carrier-grade advanced level expandable IP telephone. With
a sleek and elegant design, 144 x 75 pixel backlit LCD display and 6
dynamic context-sensitive softkeys, the 55i is fully interoperable with
leading IP Telephony platforms, offering advanced XML capability to
access custom applications and support for up to 9 calls simultaneously.
Part of the Aastra 5i Series of IP telephones, the 55i is ideally suited for
moderate to heavy telephone users who require more one touch feature
keys and XML based programs.
IP Telephones
Key Features and Benefits:
XML Browser
»
The Aastra 55i is equipped with XML browser capabilities and a large display
with dynamic softkeys to easily access customized services and applications.
Create internal service applications using development guides available from
Aastra. This feature provides unlimited potential to customize the 55i to meet
your specific business needs or vertical applications using the display and
keypad.
»
Enhanced Call Management
With extensive storage capacity for personal directories, callers logs and
redial lists and 12 programable keys, the Aastra 55i can improve efficiency by
providing more call information with the push of a button. Features such as
shared call and bridged line appearances, call forward, call transfer, call waiting,
intercom and local 3-way conference increase call flexibility and control.
Expandability
»
The Aastra 55i supports up to three Aastra 536M modules, each offering 36
keys with LED indicators to create a feature rich attendant console.
Remarkable Audio
»
All Aastra IP telephones offer full-duplex speakerphone with excellent voice
clarity and delivery. With years of experience in telecommunications and
telephone design, Aastra can ensure superior voice quality on every product
we sell.
Simplified Deployment
»
From initial deployment and configuration to future enhancements and
upgrades, the Aastra family of IP telephones are designed to save your
business time and money. Dual auto-sensing switched Ethernet ports
eliminate additional wiring and simplify installations. Integrated IEEE 802.3af
Power-over-Ethernet allows easy deployment with centralized powering and
backup. Easily created configuration files, using any text editor, can be used to
configure phones individually or centrally.
Feature Highlights*
Up to 9 call appearance lines
»
»
Shared Call and Bridged Line
Appearances
»
Multi-proxy support
»
Distinctive ringing, priority alerting
»
XML browser
»
Personal directory
»
Call forward/Call transfer/Call waiting
»
Caller and calling line information
»
Callers log
»
Local 3-way conference
»
Intercom with auto-answer
»
Redial list
»
Do Not Disturb
»
Live dial pad or pre-dial support
»
Digium’s Asterisk Business Edition
– supports Busy Lamp Field (BLF),
Intercom
»
BroadSoft’s BroadWorks enhanced
SIP – supports Shared Call
Appearances, Busy Lamp Field (BLF),
CommPilot Call Manager
»
Nortel’s MCS 5100/5200 SIP
supports – Conferencing, Voicemail,
and NAT Traversal
»
Sylantro’s SIP – supports Bridged
Line Appearances (BLA), ComСierge,
Call Park/Pickup, Conference
* Feature availability dependant on IP telephony systems
Your Connection to the World
Aastra 55i Technical Specifications
www.aastratelecom.com
Physical
23.5 cm W x 20.8 cm D x 8.0 cm H
»
(9.3”W x 8.2”D x 3.2”H)
940 g (33.0 oz)
»
4 positions footstand
»
Wall mountable
»
Power
AC wall adapter included
»
Integrated IEEE 802.3af Power Over
»
Ethernet (PoE) support
Audio
Hearing aid compatible (HAC) handset
»
Full-duplex quality speakerphone
»
Modular headset connector with built-
»
in amplifier
Non-amplified business headsets
•
are recommended
Display and Indicator
144x75 pixels graphical LCD display
»
Soft white backlight for user comfort
•
in any lighting environment
Configurable for Always On, Always
•
Off, or Auto (power saving)
»
LED for call and message waiting
indicator
Feature Keys
4 call appearance lines with LEDs
»
»
4 navigational keys
»
6 customizable softkeys with LEDs,
programmable up to 20 functions
»
6 programmable keys with LEDs
»
8 predefined hard keys
Goodbye
•
Options
•
Hold
•
Redial
•
Speakerphone/Headset toggle
•
Mute
•
2 volume keys
•
Security
User and administrator level passwords
»
Encryption of configuration files
»
HTTPS configuration download and
»
web management
Phone lock with PIN
»
Interoperability
Visit www.aastratelecom.com/IPphones
»
for an up to date listing of approved
vendor/interoperability
Expansion Module
Aastra 536M – 36-keys paper label
»
module with LEDs
Scalable up to 3 modules or 108 keys
•
No additional external power
•
required; direct power from phone
Localization
Multi-lingual support – English, French,
»
Spanish, Italian, German
Downloadable language pack
•
support for customization and
additional language translations
Country-specific call progress tones and
»
cadences
Protocols / Codecs
IETF SIP (RFC3261 and associated RFCs)
»
G.711 μ-law / A-law
»
G.729
»
Networking
Dual 10/100 Mbps switched Ethernet
»
ports
»
Manual or Dynamic Host Configuration
Protocol (DHCP) IP address setup
»
Time and date synchronization using
SNTP
»
Quality of Service (QOS) support
– IEEE 802.1 p/Q VLAN and priority
tagging, Type of Services (TOS), and
Differentiated Services Code Point
»
Network Address Translation (NAT)
support
»
Integrated HTTP/HTTPS server for
web administration and maintenance
including a built-in troubleshooting
section
»
Mass deployment via central
provisioning of user configuration files
– TFTP, FTP, HTTP, HTTPS
»
Redundant server support
DNS-SRV
•
Local backup registrar and/or proxy
•
server
Accessories
Aastra 536M – 36-keys paper label
»
expansion module
A1736-0000-10-55 (Universal)
»
»
Optional midspan Power Over Ethernet
(POE) injector available, but not
provided, for networks that do not
supply power
D0023-0031-00-00 (North America)
•
D0023-0031-PS-00 (International)
•
Package Contents
Aastra 55i IP telephone
»
»
Handset and coil cord
»
2x Footstand
»
AC wall adapter
»
Network cable
»
Programmable keys label
»
Installation Guide
Wall mount kit
»
Regulatory
CE
»
ROHS compliant
»
WEEE (2002/96/EC)
»
CE Mark (89/336/EEC EMC Directive and
73/23/EEC Low Voltage Directive)
EMC
»
FCC Part 15 Class B
»
ICES-003 Class B
»
VCCI Class B
»
AS/NZS 3548 Class B
»
EN55022 Class B
»
CISPR22 Class B
»
EN55024
»
EN61000-4-2, 4-3, 4-4, 4-5, 4-6, 4-8, 4-11
Safety
»
CAN/CSA C22.2 No. 60950
»
EN 60950
»
UL 60950-1
Telecom
»
FCC Part 68 (Hearing Aid Compatibility)
»
AS/NZS S004
RF
»
FCC Part 15 Class C
EN 300-328
»
»
EN 301 489
»
AS/NZS 4771
Part Numbers
A1755-0131-10-05 – North America (120V
»
power adapter)
»
A1755-0131-10-55 – International
(Universal power adapter)
Rev 03/07
COPYRIGHT (C) 2007 AASTRA TECHNOLOGIES LTD. ALL RIGHTS RESERVED. INFORMATION IN THIS DOCUMENT IS SUBJECT
TO CHANGE WITHOUT NOTICE. AASTRA TELECOM ASSUMES NO RESPONSIBILITY FOR ANY ERRORS THAT MAY APPEAR
IN THIS DOCUMENT. PRODUCT CAPABILITIES DESCRIBED IN THIS DOCUMENT PERTAIN SOLELY TO AASTRA TELECOM’S
MARKETING ACTIVITIES IN THE U.S AND CANADA. AVAILABILITY IN OTHER MARKETS MAY VARY.
AASTRA TELECOM
155 SNOW BLVD.,
CONCORD, ONTARIO, CANADA, L4K 4N9
SALES@AASTRA.COM • WWW.AASTRATELECOM.COM
Aastra 57i
Exceptional Features and Value in a Fully Featured, Expandable IP
Telephone
The Aastra 57i offers powerful features and flexibility in a standards based, carriergrade advanced level expandable IP telephone. With a sleek and elegant design,
large 144 x 128 pixel graphical backlit LCD display and 6 dynamic context-sensitive
softkeys, the 57i is fully interoperable with leading IP Telephony platforms, offering
advanced XML capability to access custom applications and support for up to 9 calls
simultaneously. Part of the Aastra 5i Series of IP telephones, the 57i is ideally suited
for executives and heavy telephone users who require more one touch feature keys
and a large screen to take full advantage of XML based programs.
IP Telephones
Key Features and Benefits:
XML Browser
»
The Aastra 57i is equipped with XML browser capabilities and an extra large
display with dynamic softkeys to easily access customized services and
applications. Create internal service applications using development guides
available from Aastra. This feature provides unlimited potential to customize the
57i to meet your specific business needs or vertical applications using the display
and keypad.
»
Enhanced Call Management
With extensive storage capacity for personal directories, callers logs and redial
lists and 12 programable keys, the Aastra 57i can improve efficiency by providing
more call information with the push of a button. Features such as shared call and
bridged line appearances, call forward, call transfer, call waiting, intercom and
local 3-way conference increase call flexibility and control.
»
Expandability
The Aastra 57i offers two different module extension options. It supports up to
three Aastra 536M modules, each offering 36 keys with LED indicators to create a
feature rich attendant console. Or, it will also support up to three of the advanced
Aastra 560M modules, each offering 60 keys with a screen based LCD display and
LED system.
Remarkable Audio
»
All Aastra IP telephones offer full-duplex speakerphone with excellent voice clarity
and delivery. With years of experience in telecommunications and telephone
design, Aastra can ensure superior voice quality on every product we sell.
Simplified Deployment
»
From initial deployment and configuration to future enhancements and
upgrades, the Aastra family of IP telephones are designed to save your business
time and money. Dual auto-sensing switched Ethernet ports eliminate additional
wiring and simplify installations. Integrated IEEE 802.3af Power-over-Ethernet
allows easy deployment with centralized powering and backup. Easily created
configuration files, using any text editor, can be used to configure phones
individually or centrally.
Feature Highlights*
Up to 9 call appearance lines
»
Shared Call and Bridged Line
»
Appearances
Multi-proxy support
»
Distinctive ringing, priority alerting
»
XML browser
»
Personal directory
»
Call forward/Call transfer/Call waiting
»
Caller and calling line information
»
Callers log
»
Local 3-way conference
»
Intercom with auto-answer
»
Redial list
»
Do Not Disturb
»
Live dial pad or pre-dial support
»
Digium’s Asterisk Business Edition
»
– supports Busy Lamp Field (BLF),
Intercom
BroadSoft’s BroadWorks enhanced
»
SIP – supports Shared Call
Appearances, Busy Lamp Field (BLF),
CommPilot Call Manager
Nortel’s MCS 5100/5200 SIP supports
»
Conferencing, Voicemail, and NAT
Traversal
Sylantro’s SIP – supports Bridged Line
»
Appearances (BLA), ComCierge, Call
Park/Pickup, Conference
* Feature availability dependant on IP telephony systems
Your Connection to theWorld
Aastra 57i Technical Specifications
www.aastratelecom.com
Physical
23.5 cm W x 20.8 cm D x 8.0 cm H
»
(9.3”W x 8.2”D x 3.2”H)
940 g (33.0 oz)
»
4 positions footstand
»
Wall mountable
»
Power
AC wall adapter included
»
Integrated IEEE 802.3af Power Over
»
Ethernet (PoE) support
Audio
Hearing aid compatible (HAC) handset
»
Full-duplex quality speakerphone
»
Modular headset connector with built-in
»
amplifier
Non-amplified business headsets are
•
recommended
Display and Indicator
144x128 pixels graphical LCD display
»
Soft white backlight for user comfort
•
in any lighting environment
Configurable for Always On, Always
•
Off, or Auto (power saving)
LED for call and message waiting
»
indicator
Feature Keys
4 call appearance lines with LEDs
»
4 navigational keys
»
12 customizable softkeys with LEDs,
»
programmable up to 30 functions
8 predefined hard keys
»
Goodbye
•
Options
•
Hold
•
Redial
•
Speakerphone/Headset toggle
•
Mute
•
2 volume keys
•
Interoperability
Visit www.aastratelecom.com/IPphones
»
for an up to date listing of approved
vendor/interoperability
Expansion Module
Aastra 536M – 36-keys paper label
»
module with LEDs
Scalable up to 3 modules or 108 keys.
•
No additional external power required;
•
direct power from phone
Aastra 560M – 60-keys LCD module with
»
LEDs
Scalable up to 3 modules or 180 keys.
•
No additional external power required;
•
direct power from phone
Localization
Multi-lingual support – English, French,
»
Spanish, Italian, German
Downloadable language pack support
•
for customization and additional
language translations
Country-specific call progress tones and
»
cadences
Networking
Dual 10/100 Mbps switched Ethernet ports
»
Manual or Dynamic Host Configuration
»
Protocol (DHCP) IP address setup
»
Time and date synchronization using SNTP
»
Quality of Service (QOS) support – IEEE
802.1 p/Q VLAN and priority tagging,
Type of Services (TOS), and Differentiated
Services Code Point
Network Address Translation (NAT) support
»
Integrated HTTP/HTTPS server for web
»
administration and maintenance including
a built-in troubleshooting section
»
Mass deployment via central provisioning
of user configuration files – TFTP, FTP,
HTTP, HTTPS
Redundant server support
»
DNS-SRV
•
Local backup registrar and/or proxy
•
server
Protocols / Codecs
IETF SIP (RFC3261 and associated RFCs)
»
G.711 μ-law / A-law
»
G.729
»
Security
User and administrator level passwords
»
Encryption of configuration files
»
HTTPS configuration download and web
»
management
Phone lock with PIN
»
Package Contents
57i Base
Aastra 57i IP telephone
»
Handset and coil cord
»
2x Footstand
»
AC wall adapter for base phone
»
Network cable
»
Installation Guide
»
Wall mount kit
»
Part Numbers
A1757-0131-10-05 – North America (120V
»
power adapter)
A1757-0131-10-55 – International
»
(Universal power adapter)
Regulatory
CE
ROHS compliant
»
WEEE (2002/96/EC)
»
CE Mark (89/336/EEC EMC Directive and
»
73/23/EEC Low Voltage Directive)
»
EMC
FCC Part 15 Class B
»
ICES-003 Class B
»
VCCI Class B
»
AS/NZS 3548 Class B
»
EN55022 Class B
»
CISPR22 Class B
»
EN55024
»
EN61000-4-2, 4-3, 4-4, 4-5, 4-6, 4-8, 4-11
»
Safety
CAN/CSA C22.2 No. 60950
»
EN 60950
»
UL 60950-1
»
Telecom
FCC Part 68 (Hearing Aid Compatibility)
»
AS/NZS S004
»
RF
FCC Part 15 Class C
»
EN 300-328
»
EN 301 489
»
AS/NZS 4771
»
Accessories
Aastra 536M – 36-keys paper label
»
expansion module
»
A1736-0000-10-55 (Universal)
•
Aastra 560M – 60-keys LCD expansion
»
module
»
A1760-0000-10-55 (Universal)
•
Optional midspan Power Over Ethernet
»
(POE) injector available, but not provided,
»
for networks that do not supply power
»
D0023-0031-00-00 (North America)
•
D0023-0031-PS-00 (International)
•
Rev 03/07
COPYRIGHT (C) 2007 AASTRA TECHNOLOGIES LTD. ALL RIGHTS RESERVED. INFORMATION IN THIS DOCUMENT IS SUBJECT
TO CHANGE WITHOUT NOTICE. AASTRA TELECOM ASSUMES NO RESPONSIBILITY FOR ANY ERRORS THAT MAY APPEAR
IN THIS DOCUMENT. PRODUCT CAPABILITIES DESCRIBED IN THIS DOCUMENT PERTAIN SOLELY TO AASTRA TELECOM’S
MARKETING ACTIVITIES IN THE U.S AND CANADA. AVAILABILITY IN OTHER MARKETS MAY VARY.
AASTRA TELECOM
155 SNOW BLVD.,
CONCORD, ONTARIO, CANADA, L4K 4N9
SALES@AASTRA.COM • WWW.AASTRATELECOM.COM
Loading...
