ELECTRO NIC
PR OJECTION
S YSTEMS
3M™Multimedia Projector MP8610
The Educators’ Choice
Designed to help education and business professionals collaborate and
communicate more effectively, the affordable 3M™ Multimedia Projector
MP8610 delivers consistent brightness,
image clarity and resolution from
classroom to classroom or business to
business. Control your computer from
anywhere in the room with the
VirtualMouse remote control. Crisp SVGA resolution and 500 ANSI lumens
of light provide brilliant, uniform projection. Rich, powerful sound is
ensured by two built-in 10-watt stereo
speakers. With its easy-to-use control panel
and universal power supply, the 3M
MP8610 will captivate and educate any
audience.
KEY FEATURES
• 500 ANSI lumens of on-screen brightness
• Single panel, active-matrix TFT LCD technology with
16.7 million colors at true SVGA (800 x 600) resolution
• Rugged and durable for portability from classroom to
classroom or business to business
• VirtualMouse remote control
• RS-232 serial interface support for fixed installations
• Two 10-watt, built-in stereo speakers for superior sound
quality
• Affordable, long-life, metal halide lamp
• Kensington
(Kensington Microsaver needed)
• Optional object display camera for use in presentations
and educational settings
• Quiet operation
• Ceiling mountable
• Universal power supply for use anywhere in the world
Six Presentation Tools:
• Reveal, blank, freeze, timer, magnification, pointer — all
accessed by remote control
Computer Compatibility:
• PC-compatible — XGA, SVGA, VGA
• Apple
PowerBook
Video Compatibility:
• NTSC, PAL, SECAM, NTSC 4.43, PALM, PALN
Accessories Included:
• RGB computer cable
• RCA
stereo/audio cable
• Serial RS-232 and PS/2®mouse adapter
• Remote control
• Detachable power cords
• Multilingual operator’s guide
®
security slot for protection from theft
®
Macintosh®(II, LC, Quadra, Power Macintosh and
®
)
TM
video cable, S-VHS cable, RCA/3.5 mm
3M™Multimedia Projector MP8610
TECHNICAL SPECIFICATIONS
• LCD type: 6.4" active-matrix TFT
• Resolution: 800 (W) x 600 (H) pixels (SVGA)
• Brightness: 500 ANSI lumens
• Colors: 16.7 million (maximum)
• Contrast ratio: 200:1 ANSI
• Aspect ratio: 4:3
• Lens: Wide-angle F/5.6
• Screen size: 40" (minimum) to 300" (maximum) diagonal
• Horizontal scan: 14-75 kHz
• Vertical scan: 40-120 Hz
• Input terminals:
S-Video: (1) mini DIN 4-pin
Video: (1) RCAjack
Audio: (2) 3.5 mm stereo jack
RGB: (1) high density D-sub 15-pin
• Output terminals:
Mouse control and RS-232C: (1) D-sub 9-pin (male)
• Lamp type: user-replaceable 400-watt metal halide
• Lamp life: 1,500 hours
• Dimensions: 11" (28.0 cm) W x 7" (17.8 cm) H x 17.3" (44.0 cm) L
• Speakers: 2 x 10-watt (20 watts)
• Weight:13.4 lbs (6 kg)
• Operating temperature: 32°F (0°C) to 95°F (35°C)
• Storage temperature: -4°F (-20°C ) to 140°F (60°C)
• Power consumption: 500 watts (maximum)
• Power supply: 100-130V AC, 200-240VAC, 50/60Hz
• Regulatory approvals: FCC Part 15 Class A, CE, UL, TUVGS
• Order number: 78-9236-6432-6
Optional Accessories
• User replaceable lamp kit: 78-6970-8577-5
• Optional object display camera: 78-6969-8578-3
• MP8610 soft travel case: 78-6969-8579-1
• MP8610 shipping case: 78-6969-8580-9
• MP8610 ceiling mount: 78-6969-8581-7
• Ceiling mount extension cable kit: 78-6969-8582-5
• Macintosh cable set: DY-0205-1361-9
• Monitor splitter box: XX-0034-1736-5
• RGB cable extension: XX-0034-1131-9
1-800-328-1371
3M Visual Systems Division
Building A145-5N-01
6801 River Place Blvd.
Austin, TX 78726-9000
3M Canada
P.O. Box 5757
London, Ontario, Canada
N6A 4T1
3M Mexico, S.A. de C.V.
Apartado Postal 14-139
Mexico, D.F. 07070
Mexico
www.3M.com/meetings
Recycled paper,
40% pre-consumer,
10% post-consumer
Litho in U.S.A. © 3M 1998
78-6970-7811-7 (11820.0)LP
Specifications subject to change without notice.
Apple, Macintosh, Mac and PowerBook are registered
trademarks of Apple Computer, Inc. PS/2 is a
registered trademark of IBM Corp. RCA is a
trademark of Radio Corporation of America.
Kensington is a registered trademark of Kensington
Technology Group.
