MP7730 Multimedia Projector

Operator’s Guide

MP7730 Projecteur multimédia Guide de l’opérateur

MP7730 Multimedia-Projektor Benutzerhandbuch

Proyector de Multimedia MP7730 Manual del Usuario

MP7730 Proiettore Multimediale Manuale dell’operatore

MP7730 Bruksanvisning för multimediaprojektor

MP7730 Multimedia Projector Gebruiksaanwijzing

P7630

T C

U D

O R

S T

N E

M U R

T S

N I

A X

E T

DLP

3M™ Multimedia Projector MP7730

Lock

3M™ Multimedia Projector MP7730

Introduction

Safeguards .................................................................................... 4

Thank You for Choosing 3M .......................................................... 6

Warranty ........................................................................................ 6

Shipping Box Contents.................................................................. 7

Optional Accessories .................................................................... 7

Part Identification .......................................................................... 8

Machine Characteristics................................................................ 9

Remote Control Identification...................................................... 10

Remote Control Features ............................................................ 11

System Setup

Screen Chart ............................................................................... 13

Digital Keystone Correction......................................................... 13

Connecting to Various Equipment ............................................... 14

System Set-Up ............................................................................ 15

Please click on any section to jump to that section

Operation

Start-up ....................................................................................... 16

Menu System .............................................................................. 17

Shutdown .................................................................................... 22

Optional Video Module ................................................................ 23

Attaching the Optional Audio/Visual Module ............................... 24

Optional Video Module Menus .................................................... 25

Maintenance

Lamp Usage ................................................................................ 29

Lamp Replacement ..................................................................... 30

Resetting Lamp Hours ................................................................ 31

Troubleshooting

Common Problems & Solutions .................................................. 32

Status Light Messages................................................................ 33

Service Information

Accessories ................................................................................. 34

Ordering Parts or Getting Information ......................................... 34

Appendix ...................................................................................... 35

3M™ Multimedia Projector MP7730

Introduction

Intended Use

Before operating the machine, please read the entire manual thoroughly. The 3M Multimedia Projector MP7730 was designed, built, and tested for use indoors, using 3M lamps, 3M ceiling mount hardware, and nominal local voltages. The use of other replacement lamps, outdoor operation, operation in environments containing heavy cigarette smoke or different voltages has not been tested and could damage the projector or peripheral equipment and/or create a potentially

unsafe operating condition.

Important Safeguards

1. Read and understand all instructions before using. Pay particular attention to areas where these symbols are shown:

WARNING

Caution

✓

Note - Used to emphasize important conditions or details.

2. Close supervision is necessary when any appliance is used by or near children. Do not leave appliance unattended while in use.

3. Never look directly into the projector lens when the lamp is on. The high pressure mercury lamp produces a strong light that could damage your eyesight.

4. Care must be taken, as burns can occur from touching hot parts.

Caution

6. Position the cord so that it will not be tripped over, pulled or placed in contact with hot surfaces.

7. If an extension cord is necessary, a cord with a current rating at least equal to that of the appliance should be used. Cords rated for less amperage than the appliance may overheat.

8. Always unplug appliance from electrical outlet before cleaning and servicing and when not in use. Grasp plug and pull to disconnect.

5. Do not operate appliance with a damaged cord or if the appliance has been

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in minor or moderate injury. It may also be used to alert against unsafe practices.

dropped or damaged, until it has been examined by a qualified service technician.

9. To reduce the risk of electric shock, do not immerse this appliance in water or other liquids.

10. To reduce the risk of electric shock, do not disassemble this appliance. Take it to a qualified technician when service or repair work is required. Incorrect reassembly can cause electric shock when the appliance is subsequently used.

11. Connect this appliance to a grounded outlet.

12. Do not expose this projector to direct sunlight or use it outside.

13. Keep all ventilation openings free of any obstructions.

14. Always open the lens shutter or remove the lens cap when the projector lamp is on.

15. Do not look directly into light beam of laser pointer. The pointer produces a strong light which could damage your eyesight.

16. The projection lamp contains mercury. Always dispose of it in a proper manner according to local regulations.

17. Always operate machine on a flat, sturdy surface.

3M™ Multimedia Projector MP7730

Introduction

Product Safety Labels

The following safety labels are used on or within the MP7730 projector to alert you to items or areas requiring your attention.

Tested To Comply With FCC Standards

Model No.: FP850

Rating:

~100-240V, 50-60Hz, 2A

9170A02007

Serial No.:

YWWXXXXXHD8312 H

Mfg. Date:

August 1999

Made in Taiwan R.O.C.

BAR CODE 39 (9170A02007YWWXXXXXHD8312)

FOR HOME OR OFFICE USE

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

XXX

LISTED 2G25 UL 1950 E144096

TUV Rheinland

N214

TUV Rheinland

geprufte Sicherheit

Gruppe

ERGONOMIE

GEPRUFT

ERGONOMICS

APPROVED

Laser

Standby/On

Source

Exit

Freeze

Blank

L-Click

Drag

+ M

agnify

u t e

Ch Down

Ch Up

Add/Erase Scan

k ic l

olume -

+ V

ute

Reverse

Caution

In some countries, the line voltage is NOT stable. This projector is designed to operate safely within a bandwidth of 110 to 230 volts ± 10 volts, but could fail if power drops or surges of ±10 volts occur. In these high-risk areas, it is recommended to install a power stabilizer unit.

Save These Instructions

The information contained in this manual will help you operate and maintain your 3M™ MP7730 Multimedia Projector.

3M™ Multimedia Projector MP7730

Introduction

Thank You for Choosing 3M

Thank you for choosing 3M multimedia projection equipment. This product has been produced in accordance with 3M’s highest quality and safety standards to ensure smooth and troublefree use in the years to come.

For optimum performance, please follow the operating instructions carefully. We hope you will enjoy using this high performance product in your meetings, presentations, and training sessions.

Warranty

Limited Warranty

3M warrants this product against any defects in material and workmanship, under normal usage and storage, for a period of two years from date of purchase. Exclusion to Warranty: The lamps are considered a consumable item and are warrantied for 90 days or 180 hours, whichever occurs first. claim. In the event this product is found to be defective within the warranty period, 3M’s only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects. In the USA call 1-800-328-1371 for warranty or repair service.

Limitation Of Liability

THE FOREGOING WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, AND 3M SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTIBILITY AND FITNESS FOR A PARTICULAR PURPOSE. 3M SHALL NOT BE LIABLE FOR ANY DAMAGES, DIRECT, CONSEQUENTIAL, OR INCIDENTAL, ARISING OUT OF THE USE OR INABILITY TO USE THIS PRODUCT.

Important: The above warranty shall be void if the customer fails to operate product in accordance with 3M’s written instructions. This warranty gives you specific legal rights, and you may have other rights which vary from state to state.

FCC STATEMENT - CLASS B: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can by determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

— Reorient or relocate the receiving antenna. — Increase the separation between the equipment and receiver. — Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. — Consult the dealer or an experienced radio/TV technician for help.

Proof of purchase date will be required with any warranty

Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

Caution

Core

NOTICE: This Class B digital apparatus complies with Canadian ICES-003. Pour les utilisateurs au Canada AVIS: Cet appareil numérique de la Clase B est conforme à la norme NMB-003 du Canada.

EEC STATEMENT: This machine was tested against the 89/336/EEC (European Economic Community) for EMC (Electro Magnetic Compatibility) and fulfills these requirements.

Video Signal Cables: Double shielded coaxial cables (FCC shield cable) must be used, and the outer shield must be connected to the ground. If normal coaxial cables are used, the cable must be enclosed in metal pipes or in a similar way

to reduce the interference noise radiation. Video Inputs: The input signal amplitude must not exceed the specified level.

Patents, Trademarks & Copyrights

IBM is a registered trademark of International Business Machines Corporation. Apple Macintosh and Apple Powerbook are registered trademarks of Apple Computer, Inc. Microsoft and Windows 95 and Windows 98 are registered trademarks, and Windows and Windows for Workgroups are trademarks of the Microsoft Corporation. Toshiba is a registered trademark of Toshiba Corporation. All other products are trademarks or registered trademarks

of their respective companies.

3M™ Multimedia Projector MP7730

M P 7 6

Introduction

D L P

A T E X A S I

N S T R U M E N T S

P R O D U C T

MP7730

Product Safety Guide

Shipping Box Contents

The 3M™ MP7730 Multimedia Projector is shipped with the necessary cables required for standard VCR, PC, Macintosh

™

or laptop computer connections. Carefully unpack and verify that you have all of the items shown

below. If any of these items are missing, please contact your place of purchase.

a c

d A

e rs e

n w

o D

h C

e t u

h C

+ V o

e R

y if n

-Click

g a

g ra

k ic l C

e z

e re F

n e

M y b d

an t S

Mac

Adapter

Serial

Adapter Cable

2-prong adapter

with ground

Adapter Cable

Power Cord

US, UK,

Europe

ADB Mouse

VGA

Cable

Soft-side Carrying

Case

T C U D O R P S

N E M U R T S N I

S A X E

C U

D O R

P S

T N

M U R

T S

N I

S A

X E

T A

DLP

MP7730 Multimedia

General

cable

MP7630/7730 Operator’s Guide

MP7630

k c o

Visual Systems Division

3M Austin Center

A145-5N-01

6801 River Place Blvd.

Austin, TX 78726-9000

78-6970-9035-1

Projector

Adapter Cable

MP7730 Multimedia Projector

QuickStart

k n

la B

e s a

e rc

ou S

n /O

Remote Control

Transmitter

PS/2

Operator’s Guide

(CD-ROM)

Quick Start

Guide

Product Safety

Guide

Product

Registration

Lens Cover Batteries

Card

Optional Accessories

Video Module (RCA with tuner)................................. (1)

Video Module (SCART without tuner) ....................... (1)

✓

Note: For more information on the Optional Video Module and its functions, please

see the Optional Video Module section of this manual.

✓

Note: Save the shipping box and packing materials in the event the MP7730 should require

shipping to a 3M Service Center for repair.

What’s Next?

After you have unpacked the MP7730 and identified all the parts, you are ready to set up the projector.

Please read this guide thoroughly before operating your new projector.

Be sure to check our web site (www.3m.com/meetings) regularly for updates and supplemental information. On the CD-ROM, you can link directly to the web site by clicking

right corner of the Main Menu.

here or on “3M Innovation” in the lower

3M™ Multimedia Projector MP7730

Introduction

Part Identification

MP7630

PRODUC

RUMENTS

S INST

EXA

T A

DLP

Lock

1011

Standby/On

Freeze

L-C

lick

Ch Up

Add/Erase Scan

Laser

Source

Exit

Blank

R-Click

Drag

+ M

a g

n ify

+ Volume -

etu

Ch Down

Reverse

1. Standby/On Button 8. Projection Lens

2. External Control Pad 9. Height Adjustment Feet

3. Remote Control Sensor 10. AC Power Cord Input

4. Carrying Handle 11. Serial Port Terminal Connection

5. Image Tilt Control 12. Mouse Control Port (Serial • PS/2 • ADB)

6. Kensington Lock slot 13. Remote Control Transmitter

7. Lamp Access Door (underneath unit) 14. Video Module Connection

3M™ Multimedia Projector MP7730

Introduction

Machine Characteristics

The MP7730 Multimedia Projector integrates ultra-high bright lamp and TI™ DLP™ technology into a single unit.

The MP7730 Multimedia Projector offers the following features:

• Small and portable unit • Full function remote control

• Easy to set up and use • Digital keystone correction

• XGA resolution and component video compatible • IR remote control sensor on top

• Horizontal and vertical image inverting • On screen menus in seven languages

• Horizontal and vertical image position control • Color balance control for data/video

• Ultra-high brightness projection lamp • RS-232 control capability

• Ability to display 16.7 million colors

The MP7730 Multimedia Projector offers the following optional features:

• Attachable video module • Cable television (CATV) tuner

✓

Note: The brightness of your machine will vary depending on the ambient room conditions and contrast/

brightness settings.

External Control Pad Buttons

The External Control Pad is located on top of the projector, near the back end.

The Infrared Remote Receiver allows the projector to accept signals from the remote control. For best results, be sure to aim the control toward this sensor, without any obstructions between the two, and at a distance no greater than 4 meters (13 feet).

The Menu button will display the menu system onscreen. Press Menu again to access the sub-menus. The Left and Right buttons help you navigate among choices and settings in the menus and sub-menus.

Press the Exit button to go back to the Main Menu. Press Exit again to leave the menu system.

The Lamp Status Indicator will blink or light up when the lamp needs service, cooling or replacement. See page 29 for more detailed information.

When the projector is turned on, the Standby/On Indicator will blink during warm-up and lamp ignition, then stay green to indicate the projector is ready for use.

Press the Standby/On Button to turn the projector on or off.

Infrared Remote

Receiver

Left

Right

EXIT

Exit

Lamp

Status

Indicator

Standby/On

Indicator

STANDBY/ON

Standby/On

Button

3M™ Multimedia Projector MP7730

Introduction

Remote Control Identification

Standby/On

Press STANDBY/ON button to begin projection mode (lamp on). To turn lamp off, press STANDBY/ON, then select YES on Shutdown screen. Select NO to continue running.

Source

Press button to change input source.

Standby/On

Source

Laser

Press button to turn on the Laser Pointer

Exit

Press button to exit menu screens.

Press to display the menu screen.

Freeze

Press button to turn the freeze image function ON/OFF.

L-Click

Press for left mouse button function, Mouse Mode. Press for select function, Menu Mode.

Drag

In mouse mode, press button to hold, reposition and drop an object on the screen. To MAGNIFY an area, press MAGNIFY button then press the DRAG button and change the magnifying position by moving the Disk Pad.

Magnify

Press (+) to increase or (-) to decrease the size of the displayed image.

Return

Press button to return to last menu or command.

Channel Up and Down*

Press button to increase the

channel number.

Press button to decrease the

channel number.

Freeze

L-Click

+ Magnify -

Return

Ch Up

Add/Erase Scan

Drag

+ Volume -

Ch Down

Exit

Blank

R-Click

Mute

Reverse

Add/Erase*

Add favorite channels/Erase channels which were previously added.

Menu Selection Arrows

Press buttons to change between the four menus.

Blank

Press button to turn the screen blanking function ON/OFF.

Disk Pad

Operate for normal mouse functions, Mouse Mode, to select function, Menu Mode.

R-Click

Press for right mouse button function, Mouse Mode.

Volume

Press (+) to increase or (-) to decrease speaker volume.

Mute

Press button to turn the mute function (speaker sound) ON/OFF.

Reverse*

Press to go back to previous channel.

Scan*

Scans channels which have good reception.

*✓ Note: These features are for use only with the optional video module.

3M™ Multimedia Projector MP7730

Introduction

Remote Control Features

The remote control sensor is located near the back of the projector. The distance between the sensor and the remote control unit must be shorter than 4 meters (13 feet).

Freeze

The image will be frozen when the FREEZE button is pressed. A “Pause” icon appears at the lower right of the screen for three seconds during the freeze function. A “Play” icon appears at the lower right of the screen for three seconds when the freeze function is released. To release the freeze function, press the FREEZE button or SOURCE button (when the input source is switched over during display).

Freeze button

“Pause” icon

“Play” icon

Mute

Pressing the MUTE button will mute the sound. A text box saying “Mute” appears at the lower right of the screen. Press MUTE button again or VOLUME +/- button to release the function.

Mute button

Volume

Press the VOLUME + or - buttons to adjust the loudness. The volume slide bar will disappear three seconds after the last adjustment is made.

+ Volume -

Volume button

Volume

-13-

Magnify

By pressing MAGNIFY +, the center of the picture can be magnified, doubling in size. When the button is pressed again, the picture is further magnified, up to four times the original size. By pressing MAGNIFY -, the size of the image is reduced to half its size. When the button is pressed again, the picture is further reduced until it is restored to the original size. To return to the normal display mode, press the RETURN button. (This function can be used in combination with the FREEZE function.)

+ Magnify -

Magnify button Magnify icon

3M™ Multimedia Projector MP7730

Introduction

Laser

Press this button to generate the laser beam that functions as a red pointer on the screen.

Laser button

Disk Pad

If the PS/2 (ADB) mouse cable is connected with the PC Notebook or Mac Powerbook mouse port, the Disk Pad can take over the Notebook or Powerbook mouse function. When the MAGNIFY function is activated, use the Disk Pad to move around the display areas.

Note: The mouse function is not available when the MAGNIFY function is turned on.

R-Click, L-Click

Disk Pad button

These two keys are used when the mouse function is activated after the PS/2 port is connected. They act as the right (R) and left (L) buttons of a computer mouse.

L-Click button R-Click button

Drag

This button toggles between ON and OFF for the drag function of the remote mouse.

Drag button

Blank

Press this button to activate or release the BLANK function. BLANK makes the screen go blank.

Blank button

Installing or Replacing Batteries

• Push and slide the battery compartment lid in the direction shown.

• Install two AAA batteries as indicated by the diagram inside the compartment.

• Position the lid over the compartment and snap back into place.

Caution

• Avoid excessive heat and humidity.

• Do not mix old and new batteries or different types of batteries.

3M™ Multimedia Projector MP7730

System Setup

Screen Chart

Place the projector at the required distance from the screen according to the desired picture size (see the table below).

MP7730

PROJECTOR-TO -SCREEN DISTANCES

Distance to Screen Screen Size

Minimum Maximum Diagonal Width Height

Lens center

6.0 ft.

1.8 m

9.0 ft.

2.7 m

12.0 ft.

3.7 m

15.0 ft.

4.6 m

18.0 ft.

5.5 m

23.0 ft.

7.0 m

31.0 ft.

9.4 m

8.0 ft.

2.4 m

12.0 ft.

3.7 m

16.0 ft.

4.9 m

20.0 ft.

6.1 m

24.0 ft.

7.3 m

30.0 ft.

9.1 m

40.0 ft.

12.2 m

40.0 in.

101.6 cm

60.0 in.

152.4 cm

80.0 in.

203.2 cm

100.0 in.

254.0 cm

120.0 in.

304.8 cm

150.0 in.

381.0 cm

200.0 in.

508.0 cm

32.0 in.

81.3 cm

48.0 in.

121.9 cm

64.0 in.

162.6 cm

80.0 in.

203.2 cm

96.0 in.

243.8 cm

120.0 in.

304.8 cm

160.0 in.

406.4 cm

24.0 in.

61.0 cm

36.0 in.

91.4 cm

48.0 in.

121.9 cm

60.0 in.

152.4 cm

72.0 in.

182.9 cm

90.0 in.

228.6 cm

120.0 in.

304.8 cm

Note: These sizes are

1%. This is due to variations in the manufacture of the lens. If you are close to one

of the endpoints you should verify with your unit that the image is the proper size at the proper distance.

For your own customized screen chart, please click

here (on the CD-ROM) or visit our Projector to Screen

Calculator on the 3M web site (www.3m.com/meetings/screen/7630_calc.html).

Digital Keystone Correction

Keystoning is when the projected image is noticeably wider on either the top or bottom. To correct this, press MENU on the remote control or projector, then select the Display menu (first menu bar button on the left), then adjust the sliding bar labeled Keystone, as needed. Pressing the + or button will correct keystoning at the top of the image. Pressing the - or button will correct keystoning at the bottom of the image.

Keystone

Brightness

Contrast

Color Balance

128

3M™ Multimedia Projector MP7730

System Setup

Connecting to Various Equipment

It only takes a few minutes to connect the 3M™ Multimedia Projector MP7730 to your computer, VCR, or other device.

Caution

Turn off power to all devices before making connections. Never plug anything into the projector or computer while any device is in operation.

The MP7730 must be powered down when making connections. The mouse emulation may not work if the unit is not powered down before the mouse cable connections are made.

Connection Terminals

Mac

RGBPORT

ADB PS/2

SERIAL

Cable

General

cable

Power

VIDEOMOUSE

MOUSE

VIDEO

Power

3M™ Multimedia Projector MP7730

System Setup

Mouse Connection

The general cable links the projector to the proper mouse adapter

General cable

cable for your computer.

1. Attach the male Mini-DIN end of the general cable to the Mouse port on the rear of the projector.

2. Attach the female Mini-DIN end of the general cable to the end of the proper mouse adapter cable for your computer (serial, PS/2 or ADB cable). Line up the

Female Mini-DIN Male Mini-DIN

arrows on the sides of the plugs before attaching. Be sure not to bend or break the small metal pins inside the plugs.

3. Attach the other end of the mouse adapter cable to the proper port on your computer (serial, PS/2 or ADB).

Apple™ Desktop Mouse

The Macintosh operating system should recognize the MP7730 as a mouse without any drivers being loaded.

VirtualMouse for PC Computer

For IBM™ compatible computers, set the operating systems to Serial Mouse or PS/2 Mouse to recognize projector as the mouse pointer device.

To set mouse driver information:

a) Windows

™

95/Windows™ 98/Windows™ NT

1. Select Start/Settings/Control Panel.

2. Select Add New Hardware.

3. “Windows will now search for any PnP devices...” Click Next.

4. Hardware Types: Scroll down to Mouse. Click Mouse.

5. Select Manufacturer: Standard Mouse Type

6. Select Model: Standard Serial Mouse

7. Click Next, Finish, Start.

8. Restart Windows if prompted.

b) Windows

™

3.1

From Program Manager

1. Click Main

2. Click Windows Setup (make note of the current mouse driver)

3. Click Options

4. Then Change Systems Settings

5. Choose Mouse

6. It should be listed as Microsoft or IBM PS/2

✓

Note: For proper mouse operation, always turn the projector power on first and power up the computer.

For some laptop computers, you may need to disable the internal pointing device (IPD). This is done through the BIOS level set-up of the particular machine, or it could be listed in a “Utilities” program group, i.e., “Toshiba Utilities

3M™ Multimedia Projector MP7730

™

,” or “Thinkpad Features ™ .”

Operation

Startup

Ground lead

Power

✓

Note: Make all cable

connections and line hookups with the power off.

The 2-prong adapter with ground is used with older U.S. electrical outlets that only support 2-prong power cord plugs.

✓

Note: When using this adapter, the

ground lead MUST be securely fastened to the ground screw on the outlet.

Plug the 2-prong adapter into the bottom socket of the eletrical outlet. Hook the end of the ground lead firmly around the neck of the outlet’s ground screw. Tighten the screw, if necessary, to hold the ground in place. Then plug the power cord into the adapter.

Standby/ON

Standby/On

1. Plug power cord into wall socket.

2. Press the STANDBY/ON button and hold for 3 seconds.

• The ON indicator blinks green and then stays green.

• The ON indicator will blink green during warm-up and lamp ignition.

(When power is turned off, there is a 90-second reset period before the STANDBY/ON button will function again.)

3. Turn on all connected equipment.

✓

Note: If you have the Optional Video Module attached to the unit, press the Source button on the remote

to select the source of the signal to be projected onto the screen. The selected signal input is displayed at the top right of the screen. The display will show the last selected input source before power was turned off. (For more information, please refer to the Optional Video Module section of this manual.)

3M™ Multimedia Projector MP7730

Operation

Main Menu

Press “Menu” key and the main menu will display on the screen. Press “Menu” again to enter page items, and press and to select sub-menus. The main menu will go off automatically if there is no further action from user for 10 seconds. Press EXIT button to leave the current sub-menu, and press EXIT again to leave the main menu.

Menu Pages

UNEM

RAB

UNEM

TUOYAL

tuohtiW

lanoitpO

oediV

eludoM

caMroCP

htiw

lanoitpO

oediV

eludoM

oediV

tupnI

htiw

lanoitpO

oediV

eludoM

enotsyeK

ssenthgirB

tsartnoC

enotsyeK

ssenthgirB

tsartnoC

ssenprahS

enotsyeK

ssenthgirB

tsartnoC

suneMyalpsiD suneMegamI suneMlortnoC suneMecruoS

eziSotuA

esahPlatnoziroH

cnySlatnoziroH

ecnalaBroloC

eziSotuA

tniT

ssenprahS

oitaRegamI

ecnalaBroloC

metsyS

noitisoPlatnoziroH

noitisoPlacitreV

esahPlatnoziroH

cnySlatnoziroH

noitisoPlatnoziroH

noitisoPlacitreV

egaugnaL

rorriM

knalB

ffOotuA

teseR

egaugnaL

rorriM

knalB

ffOotuA

teseR

egaugnaL

rorriM

knalB

ffOotuA

teseR

}

)elbacilppaton(

ecruoS

emuloV

elberT

ssaB

etuM

ecruoS

emuloV

elberT

ssaB

etuM

3M™ Multimedia Projector MP7730

Operation

DLP

A TEXAS INSTRUMENTS PRODUCT

Exit

MP7630

EXIT

To Menu Items

STANDBY/ON

Keystone

Brightness

Contrast

Color Balance

Keystone

Brightness

Contrast

Exit

Color Balance

Display Menu

3M™ Multimedia Projector MP7730

Color Balance (0-2)

Keystone (0-255)

128

160

128

Brightness (0-255)

128

65 193

Contrast (0-255)

128

193

Operation

Display Menu

3M™ Multimedia Projector MP7730

H.Phase

Auto Resize

H.Size

127

H.Position

165

V.Position

105

Off On

Operation

Image Menu

To Menu Items

Auto Resize

H.Phase

H.Size

Off On

127

Auto Resize

Horizontal Phase

Horizontal Size

H.Position

Will automatically adjust image to fit onto screen.

Off On

(Auto Resize OFF)

(0-31)

(Auto Resize OFF)

V.Position

165

105

(0-255) (0-255)

Horizontal Position

193

(0-255)

(Auto Resize OFF) (Auto Resize OFF)

193

3M™ Multimedia Projector MP7730

Vertical Position

193

Operation

Operation Menu

To Menu Items

Language

DeFrEn

It Es

NeSv

Mirror

Auto Off 15

Normal

0(Stop)

H-Inv

Language English (En) French (Fr) Deutsch (De) Italian (It) Español (Es)

Swedish (Sv) Dutch (Ne)

Mirror

Will invert image to display properly according to position of projector.

Normal H-Inv (Horizontally

(Default)

Reset

Press “+” or “-” to reset

Inverted)

(Rear-screen projection)

Auto Off

Reset

Will turn off the power in 60 minutes.

00:00:00 00:60:00

Will restore the projector to factory default settings.

Off On

3M™ Multimedia Projector MP7730

Operation

Shutdown

Standby/ON

Standby/On

Wait 90 seconds

00:01:0000:00:00 00:00:30

00:01:30

Power

1. Press the STANDBY/ON button. The Shutdown screen will display. Select the YES option (press arrow

button or disk pad button) to turn off.

2. The fan will continue to run for approximately 90 seconds.

3. Disconnect power cord from wall socket.

4. Disconnect cables if moving projector to new location.

Do not unplug power cord before pressing the STANDBY/ON button. After the

Caution

STANDBY/ON button is pressed, the fan rotates for about 90 seconds to cool the projector.

3M™ Multimedia Projector MP7730

Optional Video Module

Features

The Optional Video Module makes it possible to hook the MP7730 to a laser disc, VCR, or other video devices. Two versions will be available: an NTSC Package (with RCA connectors and television tuner), and a PAL package (with a SCART connector and no television tuner).

Back of projector without Optional Video Module

Back of projector with NTSC Tuner Module

NTSC Package:

• NTSC Tuner Module

• CATV

• S-Video

• 3 RCA

PAL Package:

• PAL Video Module

• S-Video

• SCART connector

• Audio

1. Video Module Connection

2. Speaker

3. Cable Television (CATV) Connection

4. RCA Cable Connection

(a) Video (Yellow) (b) Audio (White/Red)

5. S-Video Connection

6. Headphone Jack

7. SCART Connection

Back of projector with PAL SCART Module Top view of video module

Optional Video Module Connections

Video

Audio L

OUT

Cable

Audio L

Audio R

IN IN IN

S-VHS

3M™ Multimedia Projector MP7730

OUTOUTOUT

REDWHTYEL

VCR

Audio R

OUT

Laser Disc

OUT

REDWHT

Optional Video Module

Attaching the Optional Video Module to the MP7730

Caution

Power down the projector before connecting the Optional Video Module or any other device. Failure to do so may cause serious damage.

1. Precisely align the two metal tabs on the bottom of the module and insert into the corresponding slots on the back of the projector.

2. Slowly push the module to fit with the unit. Make sure that the module plugs into the AV con nection on the projector.

3. Plug the correct cable into the corresponding jack or port in the back of the unit.

4. Select inputs by pressing SOURCE key, and select the appropriate source channel by pressing CHANNEL UP/DOWN.

N /O Y

0 3

6 7 P

U N E

I X E

UC D

O R

P S

T N

E M U

R T

S N I

S A

X E

MP7630

Lock

Switching Input Signals

Pressing the Source button on the remote control or the projector will cycle between these choices of input signals: RGB (computer), Video (composite video from a VCR), S-Video, and Tuner. The projector will then search for the selected type of signal until it is found or switched to another type.

Source button

Scanning Channels

The MP7730 can receive over 100 television channels. In Tuner mode (TV and CATV), press the Scan button on the remote control to view all available television channels. The message “DO YOU REALLY WANT TO SCAN? YES NO” will appear onscreen. Press either the left or right arrow buttons on the remote to reach Yes or No, then press the Menu button to enter the selected answer. The message “TUNER IS SCANNING NOW” will display for a few seconds, and then the scanned channels will appear for a few seconds each.

Scan button Left and Right buttons

3M™ Multimedia Projector MP7730

Optional Video Module

Image Sub-Menu

This menu is only available when the input signal is from Video, S-Video, TV or CATV.

}

Image Ratio

System

Color

Tint

Auto PAL-M PAL-N SECAM

4:3 (Normal)

Color

Less More

Tint

16:9 (Video)

-123-

Red Green (Source is video or S-video)

Image Ratio

4:3 (Normal) 16:9 (Video)

System

Auto PAL-M PAL-N SECAM

3M™ Multimedia Projector MP7730

Optional Video Module

Operation

1. Go into the menu system and move to the Source sub-menu. Use the Menu key on the control pad or remote control unit to scroll through items in the sub-menu. Select the Tuner items and press or keys to prompt out of the tuner menu.

}

Source

Volume

Treble

Bass

Mute

Tuner Press "<-" or "->" to select

PC Video

Off On

S-Video Tuner

2. Use the Menu key on the control pad or remote control unit to scroll through the Tuner sub-menu.

• TV/CATV: Please select the TV signal source. If the source is from CATV, please choose

CATV. Otherwise, select TV.

• Nationality:Please select the corresponding number representing the user’s country. (See

reference chart.)

✓

Note: The item “NONE Tuner” is only for the user’s information and is not a function. For

example, if current A Box is NTSC Tuner box, then “NTSC Tuner” will appear in this section.

*NONE*

TV/CATV

Nationality

Tuner

CATV

2 3 4 5 6 7 8 9

3M™ Multimedia Projector MP7730

}

Optional Video Module

3. After leaving the menu system, press the Scan button to scan all existing channels in that region.

✓

Note: Scan function must be done for the first use in certain regions to catch all the channels

in the local CATV system.

START SCANNING?

Yes No

After the “Start scanning” dialog box prompt, use the channel up/down key to select “Yes ” or “No.” Press Return key to set.

Function (Must be performed with remote control unit)

Channel Select Press the channel number button user wants to select (for example, 12), then

press Return key to set.

Channel Up/Down Go up and down through channels by pressing the Up/Down buttons. The

channel number will appear in the lower right corner of the screen. If there is no further action for three seconds, the channel number display will disappear automatically.

-123-

Scan Press the Scan button for two seconds to begin scanning TV channels.

Add/Erase Press the Add/Erase button for two seconds to add or erase the channel. To

delete channels from memory, press the button to erase the channel. A “Channel Erased” message will display. Users can also add channels to memory by pressing the button after selecting it. A “Channel Added” message will display.

Channel Erased Channel Added

Reverse Press the Reverse button to toggle between the previous and current channels.

3M™ Multimedia Projector MP7730

Optional Video Module

Source Menu

}

Source

Volume

Treble

Bass

Mute

Tuner Press "<-" or "->" to select

PC Video

Off On

S-Video Tuner

3M™ Multimedia Projector MP7730

Maintenance

Lamp

Use and Replacement of Lamp

The projector lamp has a normal operating time of approximately 1200 to 1500 hours, called the lamp life. During the normal lamp life, the picture will be bright and the colors clear. If the lamp is used beyond the normal lamp life, the picture will become dark and the colors poor. Always replace lamps with new ones. Using an old lamp in the projector could cause a malfunction. When the power is turned on, the LAMP indicator will light up red or a message will be displayed to indicate when it is time to replace the lamp. Consult your dealer.

Lamp/Temperature Status LED Indicators

Lamp Exceed Service Hours — When this LED lights red continuously, it is warning you that the lamp has exceeded 1500 service hours. Replace the projection lamp immediately.

CHANGE THE LAMP, AND RESET THE LAMP TIMER — The lamp has been operated for 1200 hours.

CHANGE THE LAMP, THE POWER WILL TURN OFF AFTER 20 HOURS — The lamp has been operated for 1479 hours, and the power will turn off after 20 more hours.

CHANGE THE LAMP! — The lamp has been operated for more than 1500 hours, and the power will turn off automatically in 10 minutes.

All of these messages will not display for more than 3 minutes, but each message will be displayed whenever you turn on the lamp again.

Lamp is not well attached — When the LED blinks rapidly, it indicates that the lamp is not attached properly.

Temperature is too high — When the projector’s internal temperature is too hot to operate safely, the LED blinks slowly for one minute and the lamp goes off automatically.

If the LED light is off, it means that the projector’s lamp and temperature are operating under normal conditions.

Caution

The LAMP indicator will light if the lamp becomes too hot. Turn off the power and let the projector cool for 45 minutes. Turn on. If the LAMP indicator still lights up red, please contact your dealer.

3M™ Multimedia Projector MP7730

Maintenance

Lamp Replacement

WARNING

To reduce the risk of electrical shock, always turn off projector and disconnect power cord before changing lamp.

1. Turn the main power switch off and disconnect the power cord from the outlet.

2. Loosen screw and remove the lamp cover. If the lamp is hot, avoid burns by waiting 45 minutes until lamp has cooled.

3. Loosen three screws designated by arrows below. (It is strongly recommended to use a magneticheaded screwdriver, if possible. Pull the handle to remove lamp housing. If the screws are not loosened completely, they could damage your fingers. Do not insert your hand into the box after the lamp is removed. If the optical parts inside are touched by hand, it could cause color unevenness, etc.

4. Replace the lamp with the new one, insert into projector, and tighten the screws. Firmly tighten the lamp screws. Loose screws may cause a bad connection, which may result in a malfunction.

5. Re-install the lamp cover and tighten the screw. Do not turn on the power with lamp cover removed. Whenever the lamp has been replaced, reset the total operation time of the lamp. Do not reset if the lamp was not replaced, as this could cause breakage.

✓

Note: For maximum lamp life, do not shock, handle or scratch the lamp glass when it is hot.

Also, do not use an old or previously used lamp as a replacement lamp.

Caution

To reduce the risk of cuts to fingers and/or decreasing image quality by touching the lens, do not insert hand into the empty lamp compartment when the lamp has been removed.

This lamp contains mercury. Consult your local hazardous waste regulations and dispose of this lamp in a proper manner.

To reduce the risk of severe burns, allow the projector to cool for at least 45 minutes before replacing the lamp. To reduce the risk of cuts to fingers and damage to internal components, use caution when removing lamp glass that has failed and shattered into sharp pieces.

3M™ Multimedia Projector MP7730

Maintenance

Resetting the Lamp Hours

Please do the following within 10 minutes from turning power on if you replace the lamp after 1500 hours.

1. Press the Exit button on projector or remote control for three seconds to display the total used lamp time.

2, Press MENU button on projector or remote control during the lamp hour message. Then an

adjustment message will appear.

3. Press or to select the setting. To select the default setting, select “Reset” (or “Cancel” to return to the default setting).

4. Press EXIT to leave.

3M™ Multimedia Projector MP7730

Troubleshooting

SMELBORP SNOITULOS

REWOPON

ERUTCIPON

NEERCS

✓ .telniCAehtotnidrocrewopehtgulP ✓ .telnirewopehtotnidrocrewopehtgulP ✓ .nokcabtigninruterofebrotcejorpehtffogninrutretfasetunim2tiaW

✓ .tcejorpotecruostupnireporpehtdetcelesevahuoytahtkcehC ✓ .ylreporpdetcennoceraselbacllatahterusnE ✓ .tsartnocdnassenthgirbehttsujdA ✓ .pacsnelehtevomeR

NOERAUQST'NSIEGAMI

✓ .neercsehtotelgnastievorpmiottinuehtnoitisopeR ✓ ?noitcnufenotsyekehtgnisudetcerrocylreporptesffolacitrevehtsI

ROLOCROOP

DERRULBSIEGAMI

LORTNOCETOMER

KROWT'NSEOD

DNUOSON

✓ .metsysoedivtcerrocehttceleS ✓ .noitarutasdna,tsartnoc,ssenthgirbehttsujdA

✓ .sucofehttsujdA ✓ .neercsehtotelgnastievorpmiottinuehtnoitisopeR ✓ ehtnihtiwsineercsehtdnatinuehtneewtebecnatsidehttahterusnE

✓ .snelehtfoegnartnemtsujda

✓ .senowenhtiwseirettabehtecalpeR ✓ .tinuehtdnalortnocetomerehtneewtebselcatsbooneraerehterusekaM ✓ .tinuehtfo)teef31(sretem4nihtiwlortnocetomeretarepO ✓ .daplortnocehtnoreviecerehtskcolbgnihtonerusekaM

✓ .ecruostupnioiduamorfnoitcennocelbacoiduaehtkcehC ✓ .ecruosoiduaehttsujdA ✓ .nottub)+(EMULOVsserP ✓ .nottubETUMsserP

3M™ Multimedia Projector MP7730

Troubleshooting

Status Indicator Lights and Messages

deyalpsiDegasseM )elbacilppafi,noituloSdna(gninaeM

GNIHCRAES .langistupniyfitneditonnacrotcejorP

,DETCETEDLANGISTUPNI

EGAMIOTUAGNITAVITCA

EGNARFOTUOSICNYS

DNAPMALEHTEGNAHC REMITPMALEHTTESER

,PMALEHTEGNAHC

FFONRUTLLIWREWOPEHT

.SRUOH02RETFA

!PMALEHTEGNAHC

)dergnithgilDELhtiw,gniknilb(

.s'rotcejorp

.noosdecalper

.langistupnideifitnedisahrotcejorP

ehtfoegnarehtsdeecxeycneuqerflatnozirohs'langistupniehT

ebotsdeendnasruoh0021revorofdetareponeebsahpmalehT

ffotuhslliwrewopehtdnasruoh9741rofdetareponeebsahpmalehT

.elbissopsanoossapmalehtecalpeR.sruoherom02retfa

lliwrewoP.sruoh0051revorofdetareponeebsahpmalehT

.yletaidemmipmalehtecalpeR.setunim01niffotuhsyllacitamotua

3M™ Multimedia Projector MP7730

Service Information

Accessories

Description Part Number

Power Cord (EU) ........................................................................................ DY-0205-1354-4

Power Cord (US) ........................................................................................ DY-0205-1356-9

Power Cord (UK) ....................................................................................... DY-0205-1355-1

Adapter, PS/2 Mouse.................................................................................. 78-8118-8395-4

Adapter, ADB (Apple Desktop Bus) Mouse .............................................. 78-8118-8397-0

Adapter, Serial Mouse ................................................................................ 78-8118-8396-2

General Cable ............................................................................................. 78-8118-8394-7

VGA Cable ................................................................................................. 78-8118-3401-5

Mac Adapter (switchable) .......................................................................... 78-8118-3308-2

150W Lamp ................................................................................................ 78-6969-9036-1

Remote Control .......................................................................................... 78-8118-8398-8

Soft-side Carrying Case ............................................................................. 78-6969-9034-6

Lens Cover ................................................................................................. 78-8118-8399-6

Not Included with Basic Packet

Description Part Number

NTSC Optional Video Module (RCA with Tuner) .................................... 78-6969-9038-7

PAL Optional Video Module (SCART) ..................................................... 78-6969-9104-7

3-Conductor Video/Audio Cable ................................................................ 78-8118-3234-0

Stereo Mini-Jack Cable .............................................................................. 78-8118-8290-7

S-Video Cable ............................................................................................ 78-8118-3538-1

SCART-RCA Adapter ................................................................................ DY-0205-1011-0

Ordering Parts or Getting Information

For product information, product assistance, service information, or to order accessories, please contact 3M Customer Service at the following number:

• In U.S. or Canada: 1-800-328-1371

• In other locations, contact your 3M Sales office.

The contents of this manual are subject to revision without prior notice.

3M assumes no responsibility for the infringement of special rights of a third party or other rights that may arise out of the information contained in this manual.

Reproduction of this manual in any form without prior permission is strictly prohibited.

3M will replace the manual if any pages are missing or collated incorrectly.

3M™ Multimedia Projector MP7730

Appendix

Technical Specifications

✓

Note: All specifications are subject to change without notice.

General

Product name Multimedia Projector

Model name MP7730

Optical

Display system 1-CHIP DMD

Lens F/Number: F/2.7 – F/3.4 Focal Length: F = 72 – 108 mm (2.8 in. – 4.3 in.)

Lamp 150 W UHP lamp

Speaker 1 watt

Electrical

Power supply AC100 ~ 240V, 6.5A ~ 2.9A, 50/60 Hz (Automatic)

Power consumption 200 W (Max)

Mechanical

Dimensions 7.7 in. (W) x 2.4 in. (H) x 9.6 in. (D)

Operating

temperature range 50° ~ 104°F (10° ~ 40°C)

Weight 2.3 kg (5 lbs.)

Input/Output terminal

Video signal

input terminal S VIDEO : Mini DIN 4-pin terminal

RGB input/output

signal terminal RGB signal : D-sub 15-pin (Female)

Control terminal D-sub 9-pin (Male)

Mouse MD 9-pin (serial/PS2/ADB)

198 mm (W) x 62 mm (H) x 245 mm (D)

VIDEO : RCA Jack terminal + BNC

AUDIO : RCA Jack terminal

AUDIO : RCA Jack + BNC

3M™ Multimedia Projector MP7730

Appendix

Dimensions

246 mm ( 9.7 in )

MP7630

DLP

A TEXAS INSTRUMENTS PRODUCT

Lock

67 mm ( 2.6 in )

EXIT

202 mm ( 8 in )

STANDBY/ON

3M™ Multimedia Projector MP7730

Appendix

Preset Display Resolution Table

noituloseR )zHk(cnySH )zHk(cnySV krameR

053x0465.131.07

004x046 9.73 1.58 ASEV

004x0275.130.07

004x027 9.73 1.58 ASEV

084x0465.130.06ASEV

084x046 9.73 8.27 ASEV

084x046537.66hsotnicaM

084x046 3.34 0.58 ASEV

006x0082.533.65ASEV

006x008 9.73 3.06 ASEV

006x0089.640.57ASEV

006x008 1.84 2.27 ASEV

006x0087.351.58ASEV

426x238 7.94 5.47 hsotnicaM

867x42014.840.06ASEV

867x4201 5.65 1.07 ASEV

867x42010.060.57ASEV

867x4201 7.86 0.58 ASEV

4201x08210.460.06ASEV

3M™ Multimedia Projector MP7730

Appendix

Nationality Codes

API TV System Code Definition

NTSC Tuner Box

aerA lennahC

CSTNASU)DTS(1)CRH(2)CRI(2

CSTNnawiaT1

CSTNadanaC1

CSTNelihC1

CSTNaibmuloC1

CSTNocixeM1

CSTNureP1

CSTNaeroKhtuoS1

CSTNaleuzeneV1

CSTNnapaJ4

N-LAPanitnegrA5

N-LAPyaugaraP5

N-LAPyaugurU5

M-LAPlizarB6

3M™ Multimedia Projector MP7730

Important Notice

All statements, technical information, and recommendations related to 3M’s products are based on information believed to be reliable, but the accuracy or completeness is not guaranteed. Before using this product, you must evaluate it and determine if it is suitable for your intended application. You assume all risks and liability associated with such use. Any statements related to the product which are not contained in 3M’s current publications, or any contrary statements contained on your purchase order shall have no force or effect unless expressly set forth in a written agreement signed by an authorized officer of 3M.

Warranty and Limited Remedy. This product will be free from defects in material and manufacture for a period of two years from the date of purchase. Exclusion to Warranty: The lamps are considered a consumable item and are warrantied for 90 days or 180 hours, whichever occurs first. 3M MAKES NO

OTHER WARRANTIES, INCLUDING BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. If this product is defective within the warranty period stated above, your exclusive remedy shall be, at 3M’s option, to replace or

repair the 3M product or refund the purchase price of the 3M product.

Limitation of Liability. Except where prohibited by law, 3M will not be liable for any loss or damage arising from this 3M product, whether direct, indirect, special, incidental or consequential regardless of the legal theory asserted.

Let us help you make the most of your next presentation. We offer everything from presentation supplies to tips for better meetings. And we’re the only transparency manufacturer that offers a recycling program for your used transparencies. For late-breaking news, handy reference and free product samples, call us toll-free in the continental United States and Canada, 24 hours a day, or visit our Internet Website.

3M Austin Center

Building A145-5N-01 6801 River Place Blvd. Austin, TX 78726-9000

3M Canada

P.O. Box 5757 London, Ontario N6A 4T1

3M Mexico, S.A. de C.V.

Apartado Postal 14-139 Mexico, D.F. 07000 Mexico

3M Europe

Boulevard de l’Oise 95006 Cerge Pontoise Cedex France

3M™ Multimedia Projector MP7730

Litho in USA

78-6970-9035-1 Rev. B

3M MP7730 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Introduction

Thank You for Choosing 3M

Warranty

Shipping Box Contents

Optional Accessories

Part Identification

Machine Characteristics

Remote Control Identification

Remote Control Features

System Setup

Screen Chart

Digital Keystone Correction

Connecting to Various Equipment

Operation

Startup

Main Menu

Shutdown

Optional Video Module

Attaching the Optional Video Module to the MP7730

Maintenance

Lamp Replacement

Resetting the Lamp Hours

Troubleshooting

Service Information

Accessories

Ordering Parts or Getting Information

Appendix
