LS3008
Product Reference Guide
LS3008
Product Reference Guide
72E-86092-04
Revision A
February 2015
ii LS3008 Product Reference Guide
© 2015 Symbol Technologies, Inc.
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means,
without permission in writing from Zebra. This includes electronic or mechanical means, such as photocopying,
recording, or information storage and retrieval systems. The material in this ma nual is subject to change
without notice.
The software is provided strictly on an "as is" basis. All sof tware, including firmware, furnished to the user is on
a licensed basis. Zebra grants to the user a non-transferable and non-exclusive license to use each software
or firmware program delivered hereunder (licensed program) . Except as n oted below, such license may not be
assigned, sublicensed, or otherwise tran sfe rr e d by th e user without prior written consent of Zebra. No right to
copy a licensed program in whole or in part is granted, exce pt as permitted unde r copyright law. The user shall
not modify , merge, or incorporate any for m or portion of a licensed program with other pro gram material, create
a derivative work from a licensed program , or us e a li censed program in a network without written permission
from Zebra. The user agrees to maintain Zebra's copyright notice on the licensed programs delivered
hereunder , and to include the same on any authorized copies it makes, in whole or in part. The user agrees not
to decompile, disassemble, decode, or reverse engineer any licensed program delivered to the user or any
portion thereof.
Zebra reserves the right to make changes to any software or product to improve reliability, function, or design.
Zebra does not assume any product liability arising out of, or in connection with, the application or use of any
product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any Zebra Techn ologies
Corporation, intellectual property rights. An implied license only exists for equipment, circuits, and subsystems
contained in Zebra products.
Zebra and the Zebra head graphic are registered trademarks of ZIH Corp. The Symbol logo is a registered
trademark of Symbol Technologies, Inc., a Zebra Technologies company.
Zebra Technologies Corporation
Lincolnshire, IL U.S.A.
http://www.zebra.com
Warranty
For the complete Zebra hardware product warranty statement, go to:
http://www.zebra.com/warranty.
Revision History
Changes to the original manual are listed below:
Change Date Description
-01 Rev A 6/2006 Initial release.
-02 Rev A 9/2007 Motorola rebranding, add new UPC/EAN Supplemental options and Bookland ISBN
-03 Rev A 10/2012 Updated ambient light tolerance.
-04 Rev A 2/2015 Zebra Re-Branding
iii
format, change RSS references to GS1 DataBar.
iv LS3008 Product Reference Guide
Table of Contents
About This Guide
Introduction.................................................................................................................... xi
Chapter Descriptions..................................................................................................... xi
Notational Conventions.................................................................................................. xii
Related Documents....................................................................................................... xiii
Service Information........................................................................................................ xiii
Chapter 1: Getting Started
Introduction ................................................................................................................... 1-1
Unpacking ..................................................................................................................... 1-2
Setting Up the Scanner ................................................................................................. 1-3
Installing the Interface Cable .................................................................................. 1-3
Removing the Interface Cable ................................................................................ 1-4
Connecting a Synapse Cable Interface .................................................................. 1-4
Connecting Power (if required) ............................................................................... 1-4
Configuring the Scanner ......................................................................................... 1-5
Chapter 2: Scanning
Introduction ................................................................................................................... 2-1
Beeper Definitions ........................................................................................................ 2-2
LED Definitions ............................................................................................................. 2-3
Scanning in Hand-Held Mode ....................................................................................... 2-4
Aiming ..................................................................................................................... 2-5
Scanning in Hands-Free Mode ..................................................................................... 2-7
Assemble the Stand ................................................................................................ 2-7
Scanning with Intellistand ....................................................................................... 2-8
Decode Zone ................................................................................................................ 2-9
Chapter 3: Maintenance, Troubleshooting & Specifications
Introduction ................................................................................................................... 3-1
Maintenance ................................................................................................................. 3-1
vi LS3008 Product Reference Guide
Troubleshooting ............................................................................................................ 3-2
Technical Specifications ............................................................................................... 3-5
Scanner Signal Descriptions ......................................................................................... 3-7
Chapter 4: User Preferences
Introduction ................................................................................................................... 4-1
Scanning Sequence Examples ..................................................................................... 4-1
Errors While Scanning .................................................................................................. 4-2
User Preferences Parameter Defaults .......................................................................... 4-2
User Preferences .......................................................................................................... 4-3
Default Parameters ................................................................................................. 4-3
Beeper Tone ........................................................................................................... 4-4
Beeper Volume ....................................................................................................... 4-4
Power Mode ............................................................................................................ 4-5
Scan Pattern ........................................................................................................... 4-6
Scan Line Width ...................................................................................................... 4-7
Laser On Time ........................................................................................................ 4-7
Beep After Good Decode ........................................................................................ 4-8
Chapter 5: Keyboard Wedge Interface
Introduction ................................................................................................................... 5-1
Connecting a Keyboard Wedge Interface ..................................................................... 5-2
Keyboard Wedge Parameter Defaults .......................................................................... 5-3
Keyboard Wedge Host Parameters .............................................................................. 5-4
Keyboard Wedge Host Types ................................................................................. 5-4
Keyboard Wedge Country Types (Country Codes) ................................................ 5-5
Ignore Unknown Characters ................................................................................... 5-6
Keystroke Delay ...................................................................................................... 5-7
Intra-Keystroke Delay ............................................................................................. 5-7
Alternate Numeric Keypad Emulation ..................................................................... 5-8
Caps Lock On ......................................................................................................... 5-8
Caps Lock Override ................................................................................................ 5-9
Convert Wedge Data .............................................................................................. 5-9
Function Key Mapping ............................................................................................ 5-10
FN1 Substitution ..................................................................................................... 5-10
Send Make and Break ............................................................................................ 5-11
Keyboard Maps ............................................................................................................. 5-12
ASCII Character Set for Keyboard Wedge ................................................................... 5-13
Chapter 6: RS-232 Interface
Introduction ................................................................................................................... 6-1
Connecting an RS-232 Interface .................................................................................. 6-2
RS-232 Parameter Defaults .......................................................................................... 6-3
RS-232 Host Parameters .............................................................................................. 6-4
RS-232 Host Types ................................................................................................. 6-6
Baud Rate ............................................................................................................... 6-7
Parity ....................................................................................................................... 6-8
Stop Bit Select ........................................................................................................ 6-9
Data Bits (ASCII Format) ........................................................................................ 6-9
Check Receive Errors ............................................................................................. 6-10
Hardware Handshaking .......................................................................................... 6-10
Software Handshaking ............................................................................................ 6-12
Host Serial Response Time-out .............................................................................. 6-14
RTS Line State ........................................................................................................ 6-15
Beep on <BEL> ....................................................................................................... 6-15
Intercharacter Delay ................................................................................................ 6-16
Nixdorf Beep/LED Options ...................................................................................... 6-17
Ignore Unknown Characters ................................................................................... 6-17
ASCII Character Set for RS-232 ................................................................................... 6-18
Chapter 7: USB Interface
Introduction ................................................................................................................... 7-1
Connecting a USB Interface ......................................................................................... 7-1
USB Parameter Defaults .............................................................................................. 7-3
USB Host Parameters .................................................................................................. 7-4
USB Device Type .................................................................................................... 7-4
USB Country Keyboard Types (Country Codes) .................................................... 7-5
USB Keystroke Delay ............................................................................................. 7-7
USB CAPS Lock Override ...................................................................................... 7-7
USB Ignore Unknown Characters ........................................................................... 7-8
Emulate Keypad ...................................................................................................... 7-8
USB Keyboard FN 1 Substitution ............................................................................ 7-9
Function Key Mapping ............................................................................................ 7-9
Simulated Caps Lock .............................................................................................. 7-10
Convert Case .......................................................................................................... 7-10
ASCII Character Set for USB ........................................................................................ 7-11
Table of Contents vii
Chapter 8: IBM Interface
Introduction ................................................................................................................... 8-1
Connecting to an IBM 468X/469X Host ........................................................................ 8-1
IBM Parameter Defaults ............................................................................................... 8-2
IBM 468X/469X Host Parameters ................................................................................. 8-3
Port Address ........................................................................................................... 8-3
Convert Unknown to Code 39 ................................................................................. 8-4
Chapter 9: Wand Emulation Interface
Introduction ................................................................................................................... 9-1
Connecting Using Wand Emulation .............................................................................. 9-2
Wand Emulation Parameter Defaults ........................................................................... 9-3
Wand Emulation Host Parameters ............................................................................... 9-4
Wand Emulation Host Types .................................................................................. 9-4
Leading Margin (Quiet Zone) .................................................................................. 9-5
Polarity .................................................................................................................... 9-6
Ignore Unknown Characters ................................................................................... 9-6
viii LS3008 Product Reference Guide
Convert All Bar Codes to Code 39 .......................................................................... 9-7
Convert Code 39 to Full ASCII ............................................................................... 9-8
Chapter 10: Scanner Emulation Interface
Introduction ................................................................................................................... 10-1
Connecting Using Scanner Emulation .......................................................................... 10-2
Scanner Emulation Parameter Defaults ....................................................................... 10-3
Scanner Emulation Host ............................................................................................... 10-4
Scanner Emulation Host Parameters ........................................................................... 10-4
Beep Style ............................................................................................................... 10-4
Parameter Pass-Through ........................................................................................ 10-5
Convert Newer Code Types .................................................................................... 10-6
Module Width .......................................................................................................... 10-6
Convert All Bar Codes to Code 39 .......................................................................... 10-7
Code 39 Full ASCII Conversion .............................................................................. 10-7
Transmission Timeout ............................................................................................. 10-8
Ignore Unknown Characters ................................................................................... 10-9
Leading Margin ....................................................................................................... 10-9
Check For Decode LED .......................................................................................... 10-10
Chapter 11: 123Scan
Introduction ................................................................................................................... 11-1
Communication with 123Scan ...................................................................................... 11-1
123Scan Parameter ...................................................................................................... 11-1
Chapter 12: Symbologies
Introduction ................................................................................................................... 12-1
Scanning Sequence Examples ..................................................................................... 12-1
Errors While Scanning .................................................................................................. 12-2
Symbology Parameter Defaults .................................................................................... 12-2
UPC/EAN ...................................................................................................................... 12-5
Enable/Disable UPC-A/UPC-E ............................................................................... 12-5
Enable/Disable UPC-E1 .......................................................................................... 12-6
Enable/Disable EAN-13/EAN-8 ............................................................................... 12-7
Enable/Disable Bookland EAN ............................................................................... 12-8
Decode UPC/EAN/JAN Supplementals .................................................................. 12-9
User-Programmable Supplementals ....................................................................... 12-12
UPC/EAN/JAN Supplemental Redundancy ............................................................ 12-13
Transmit UPC-A Check Digit .................................................................................. 12-13
Transmit UPC-E Check Digit .................................................................................. 12-14
Transmit UPC-E1 Check Digit ................................................................................ 12-14
UPC-A Preamble .................................................................................................... 12-15
UPC-E Preamble .................................................................................................... 12-16
UPC-E1 Preamble .................................................................................................. 12-17
Convert UPC-E to UPC-A ....................................................................................... 12-18
Convert UPC-E1 to UPC-A ..................................................................................... 12-18
EAN-8/JAN-8 Extend .............................................................................................. 12-19
Table of Contents ix
Bookland ISBN Format ........................................................................................... 12-20
UCC Coupon Extended Code ................................................................................. 12-21
Code 128 ...................................................................................................................... 12-22
Enable/Disable Code 128 ....................................................................................... 12-22
Enable/Disable UCC/EAN-128 ............................................................................... 12-22
Enable/Disable ISBT 128 ........................................................................................ 12-23
Code 39 ........................................................................................................................ 12-23
Enable/Disable Code 39 ......................................................................................... 12-23
Enable/Disable Trioptic Code 39 ............................................................................ 12-24
Convert Code 39 to Code 32 .................................................................................. 12-24
Code 32 Prefix ........................................................................................................ 12-25
Set Lengths for Code 39 ......................................................................................... 12-25
Code 39 Check Digit Verification ............................................................................ 12-26
Transmit Code 39 Check Digit ................................................................................ 12-27
Code 39 Full ASCII Conversion .............................................................................. 12-27
Code 39 Buffering (Scan & Store) .......................................................................... 12-28
Code 93 ........................................................................................................................ 12-30
Enable/Disable Code 93 ......................................................................................... 12-30
Set Lengths for Code 93 ......................................................................................... 12-30
Code 11 ........................................................................................................................ 12-31
Code 11 .................................................................................................................. 12-31
Set Lengths for Code 11 ......................................................................................... 12-32
Code 11 Check Digit Verification ............................................................................ 12-33
Transmit Code 11 Check Digits .............................................................................. 12-33
Interleaved 2 of 5 (ITF) ................................................................................................. 12-34
Enable/Disable Interleaved 2 of 5 ........................................................................... 12-34
Set Lengths for Interleaved 2 of 5 ........................................................................... 12-34
I 2 of 5 Check Digit Verification ............................................................................... 12-36
Transmit I 2 of 5 Check Digit ................................................................................... 12-36
Convert I 2 of 5 to EAN-13 ...................................................................................... 12-37
Discrete 2 of 5 (DTF) .................................................................................................... 12-37
Enable/Disable Discrete 2 of 5 ................................................................................ 12-37
Set Lengths for Discrete 2 of 5 ............................................................................... 12-38
Chinese 2 of 5 ............................................................................................................... 12-39
Enable/Disable Chinese 2 of 5 ................................................................................ 12-39
Codabar (NW - 7) ......................................................................................................... 12-40
Enable/Disable Codabar ......................................................................................... 12-40
Set Lengths for Codabar ......................................................................................... 12-40
CLSI Editing ............................................................................................................ 12-41
NOTIS Editing ......................................................................................................... 12-42
MSI ............................................................................................................................... 12-42
Enable/Disable MSI ................................................................................................ 12-42
Set Lengths for MSI ................................................................................................ 12-43
MSI Check Digits .................................................................................................... 12-44
Transmit MSI Check Digit(s) ................................................................................... 12-45
MSI Check Digit Algorithm ...................................................................................... 12-45
GS1 DataBar (formerly RSS, Reduced Space Symbology) ......................................... 12-46
Convert GS1 DataBar to UPC/EAN ........................................................................ 12-47
Symbology - Specific Security Levels ........................................................................... 12-48
Redundancy Level .................................................................................................. 12-48
x LS3008 Product Reference Guide
Security Level ......................................................................................................... 12-50
Bi-directional Redundancy ...................................................................................... 12-51
Symbology - Intercharacter Gap ................................................................................... 12-51
Report Version .............................................................................................................. 12-52
Chapter 13: Miscellaneous Scanner Options
Introduction ................................................................................................................... 13-1
Scanning Sequence Examples ..................................................................................... 13-1
Errors While Scanning .................................................................................................. 13-1
Miscellaneous Parameter Defaults ............................................................................... 13-2
Miscellaneous Scanner Parameters ............................................................................. 13-3
Transmit Code ID Character ................................................................................... 13-3
Prefix/Suffix Values ................................................................................................. 13-3
Scan Data Transmission Format ............................................................................ 13-4
FN1 Substitution Values ......................................................................................... 13-6
Transmit “No Read” Message ................................................................................. 13-6
Synapse Interface ................................................................................................... 13-7
Appendix A: Standard Defaults
Appendix B: Programming Reference
Symbol Code Identifiers ................................................................................................ B-1
AIM Code Identifiers ..................................................................................................... B-2
Appendix C: Sample Bar Codes
Code 39 ........................................................................................................................ C-1
UPC/EAN ...................................................................................................................... C-2
UPC-A, 100% .......................................................................................................... C-2
EAN-13, 100% ........................................................................................................ C-2
Code 128 ...................................................................................................................... C-2
Interleaved 2 of 5 .......................................................................................................... C-3
GS1 DataBar ................................................................................................................ C-3
GS1 DataBar ........................................................................................................... C-3
GS1 DataBar-14 ..................................................................................................... C-4
Appendix D: Numeric Bar Codes
Numeric Bar Codes ...................................................................................................... D-1
Cancel ........................................................................................................................... D-3
Appendix E: ASCII Character Sets
Index
Tell Us What You Think...
About This Guide
Introduction
The LS3008 Product Reference Guide provides general instructions for setting up, operating, maintaining, and
troubleshooting the LS3008 scanner.
Chapter Descriptions
•
Chapter , Introduction provides a product overview, unpacking instructions, and cable connection
information.
•
Chapter 2, Wireless IPS Scanning describes parts of the scanner, beeper and LED definitions, and how to
use the scanner in hand-held and hands-free modes.
•
Chapter 3, Maintenance, Troubleshooting & Specifications provides information on how to care for the
scanner, troubleshooting, and technical specifications.
•
Chapter 4, User Preferences provides programming bar codes for selecting user preference features for the
scanner.
•
Chapter 5, Keyboard Wedge Interface provides information for setting up the sc an ne r fo r Keyb o ar d Wedge
operation.
•
Chapter 6, RS-232 Interface provides information for setting up the scanner for RS-232 operation.
•
Chapter 7, USB Interface provides information for setting up the scanner for USB operation.
•
Chapter 8, IBM Interface provides all information for setting up the scanner with IBM 468X/469X POS
systems.
•
Chapter 9, Wand Emulation Interface provides all info rmation for setting up the scanner for Wand Emulation
operation.
•
Chapter 10, Scanner Emulation Interface provides information for setting up the scanner for Scanner
Emulation operation.
•
Chapter 11, 123Scan (PC based scanner configuration tool) provides the bar code that must be scanned to
communicate with the 123Scan program.
xii LS3008 Product Reference Guide
*Baud Rate 9600
Feature/Option
* Indicates Default
•
Chapter 12, Intrusion Protection System Symbologies describes all symbology features and provides the
programming bar codes necessary for selecting these feat ures for the scanner.
•
Chapter 13, Miscellaneous Scanner Option s includes commonly used bar codes to customize how the data
is transmitted to the host device.
•
Appendix A, Standard Defaults provides a table of all host devices and miscellaneous scanner defaults.
•
Appendix B, Programming Reference provides a table of AIM code identifiers, ASCII character conversions,
and keyboard maps.
•
Appendix C, Sample Bar Codes includes sample bar codes.
•
Appendix D, Numeric Bar Codes includes the numeric bar codes to scan for parameters requiring specific
numeric values.
•
Appendix E, ASCII Character Sets provides ASCII character value tables.
Notational Conventions
The following conventions are used in this document:
•
Italics are used to highlight the following:
- Chapters and sections in this and related documents
•
bullets (•) indicate:
- Action items
- Lists of alternatives
- Lists of required steps that are not necessarily sequential
•
Sequential lists (e.g., those that describe step-by-s te p pr oc ed ur e s) ap pe a r as nu m be re d lists.
•
Throughout the programming bar code menus, asterisks (*) are used to denote default parameter settings.
NOTE This symbol indicates something of special interest or importance to the reader. Failure to read the note
will not result in physical harm to the reader, equipment or data.
CAUTION This symbol indicates that if this information is ignored, the possiblity of data or material damage may
occur.
WARNING! This symbol indicates that if this information is ignored the possibility that serious personal
injury may occur.
Related Documents
•
LS3008 Quick Reference Guide, p/n 72-86091-xx - provides general information to help the user get started
with the scanner, including basic operation instructions and start up bar codes.
For the latest version of this guide and all guides, go to: http://www.zebra.com/support.
Service Information
If you have a problem with your equipment, contact Zebra Support for your region. Go to
http://www.zebra.com/support. If you purchased your Zebra product from a Zebra Business Partner, contact that
Business Partner for service.
Before contacting, have the model number and serial number at hand. If your problem cannot be solved by the
Zebra, you may need to return your equipment for servicing and you will be given specific directions.
Zebra is not responsible for any damages incurred during shipment if the approved shipp ing container is not used.
Shipping the units improperly can possibly void the warranty.If you have a problem using the equipment, contact
your facility's technical or systems support. If there is a problem with the equipment, they will contact the Zebra
Customer Support Center at: http://w ww.zebra.com/support.
About This Guide xiii
When contacting Zebra support, please have the following information available:
•
Serial number of the unit
•
Model number or product name
•
Software type and version number
Zebra responds to calls by e-mail, telephone or fax within the time limits set forth in service agreements.
If your problem cannot be solved by Zebra support, you may need to return your equipment for servicing and will
be given specific directions. Zebra is not responsible for any damages incurred during shipment if the approved
shipping container is not used. Shipping the units improperly can possibly void the warranty.
If you purchased your business product from a Zebra business partner, please contact that business partner for
support.
xiv LS3008 Product Reference Guide
Chapter 1 Getting Started
Introduction
The scanner combines excellent scanning performance and advanced ergonomics to provide the best value in a
lightweight laser scanner. Whether used as a hand-held scanner or in hands-free mode in a stand, the scanner
ensures comfort and ease of use for extended periods of time.
In addition to single-line laser scanning, the scanner supports multi-line rastering. Multi-line rastering allows the
scanner to capture stacked GS1 DataBar codes and increases angular tolerances, minimizing product orientation
and hand movements. Multi-line rastering also allows the scanner to read poor quality bar codes. For more
information about scanning modes and stacked GS1 DataBar codes, see Scan Pattern on page 4-6 and GS1
DataBar on page C-3.
NOTE The scanner does not currently support PDF417 bar codes and its variants.
Figure 1-1
LS3008 Scanner
1 - 2 LS3008 Product Reference Guide
This scanner supports the following interfaces:
•
Keyboard Wedge connection to a host. The host interprets scanned data as keystrokes. This interface
supports the following international keyboards (for Windows
French, French Canadian, Spanish, Italian, Swedish, UK English, Portuguese-Brazilian, and Japanese.
•
Stan dard RS-232 connection to a host. Scan bar code menus to set up pr oper communication o f the scanner
with the host.
•
USB connection to a host. The scanner autodetects a USB host and defaults to the HID keyboard interface
type. Select other USB interface types by scanning prog ramming bar code menu s.This interface support s the
following international keyboards (for Windows
Canadian, Spanish, Italian, Swedish, UK English, Portuguese-Brazilian, and Japanese.
•
Connection to IBM® 468X/469X hosts. Scan bar code menus to set up communication of the scanner with
the IBM terminal.
•
Wand Emulation connection to a host. The scanner is co nnected to a portable data terminal, a controller, or
host which collects the data as wand data and decodes it.
•
Scanner Emulation connection to a host. The scanner is connected to a portable data terminal, a controller
which collects the data and interprets it for the host.
®
environment): North America, German,
®
environment): North America, German, French, French
•
Synapse capability which allows connection to a wide variety of host systems using a Synapse and Synapse
adapter cable. The scanner autodetects the host.
•
Configuration via 123Scan.
Unpacking
Remove the scanner from its packing and inspect it for damage. If the scanner was damaged in transit, call the
Zebra Center . See page xiii for contact information. KEEP THE PACKING. It is the approved shipping container
and should be used if the equipment ever needs to be return for servicing.
Setting Up the Scanner
Interface cable
modular connector
To host
Cable interface
port
Interface cable modular
connector clip
Installing the Interface Cable
To connect the interface cable:
1. Insert the interface cable’s modular connector clip into the cable interface port on the bottom of the scanner
handle. (See Figure 1-2.).
2. Gently tug the cable to ensure the connector is properly secured.
3. Connect the other end of the interface cable to the host. (See the specific host chapter for information on host
connections.)
Getting Started 1 - 3
Figure 1-2
Installing the Cable
NOTE Different cables are required for different hosts. The connectors illustrated in each host chapter are
examples only. Actual connectors may be different than those illustrated, but the steps to connect the
scanner remain the same.
1 - 4 LS3008 Product Reference Guide
Synapse Adapter Cable
To Scanner
Synapse Smart
Cable
To host
Removing the Interface Cable
To remove the interface cable:
1. Unplug the installed cable’s modular connector by depressing the connector clip with the tip of a screwdriver.
2. Carefully slide out the cable.
3. Follow the steps for Installing the Interface Cable on page 1-3 to connect a new cable.
Connecting a Synapse Cable Interface
NOTE Refer to the Synapse Interface Guide provided with the Synapse cable for detailed setup instructions.
Zebra’s Synapse Smart Cables enable interfacing to a variety of hosts. The appropriate Synapse cable has the
built-in intelligence to detect the host to which it is connected.
Connecting Power (if required)
Figure 1-3
1. Plug the Synapse adapter cable (p/n 25-32463-xx) into the bottom of the scann er, as described in Installing the
Synapse Cable Connection
Interface Cable on page 1-3.
2. Align the ‘S’ on the Synapse adapter cable with the ‘S’ on the Synapse Smart Cable and plug the cable in.
3. Connect the other end of the Synapse Smart Cable to the host.
If the host does not provide power to the scanner, an external power connection to the scanner is required. To
connect power:
1. Connect the interface cable to the bottom of the scanner, as described in Installing the Interface Cable on page
1-3.
2. Connect the other end of the interface cable to the host (refer to the host manual to locate the correct port).
3. Plug the power supply into the power jack on the interface cable. Plug the other end of the power supp ly into
an AC outlet.
Getting Started 1 - 5
Configuring the Scanner
To configure the scanner, use the bar codes included in this manual, or the 123Scan configuration program.
See Chapter 4, User Preferences, Chapter 12, Intrusion Protection System Symbologies and Chapter 13,
Miscellaneous Scanner Options for information about programming the scanner using bar code menus. Also see
each host-specific chapter to set up a connection to a specific host type.
See Chapter 11, 123Scan to configure the scanner using this configuration program. A help file is available in the
program.
1 - 6 LS3008 Product Reference Guide
Chapter 2 Wireless IPS Scanning
Beeper
LED
Trigger
Scan Window
Introduction
This chapter provides beeper and LED definitions, techniqu es involved in scanning bar codes, general instructions
and tips about scanning, and decode zone diagrams.
Figure 2-1
Parts
2 - 2 LS3008 Product Reference Guide
Beeper Definitions
The scanner issues different beep sequences and patterns to indicate status. Table 2-1 defines beep sequences
that occur during both normal scanning and while programming the scanner.
Table 2-1
Standard Use
Low/medium/high beeps Power up.
Short high beeps A bar code symbol was decoded (if decode beeper is enabled).
4 long low beeps A transmission error was detected in a scanned symbol. The data
5 low beeps Conversion or format error.
Low/high/low beeps Advanced Data Formatting (ADF) transmit error. (For information
High/high/high/low beeps RS-232 receive error.
Parameter Menu Scanning
Short high beeps Correct entry scanned or correct menu sequence performed.
Low/high beeps Input error, incorrect bar code or “Cancel” scanned, wrong entry,
Beeper Definitions
Beeper Sequence Indication
is ignored. This occurs if a unit is not properly configured. Check
option setting.
about ADF programming, refer to the Advanced Data Formatting
Programmer Guide, p/n 72-69680-xx.)
incorrect bar code programming sequence; remain in program
mode.
High/low beeps Keyboard parameter selected. Enter value using bar code
keypad.
High/low/high/low beeps Successful program exit with change in the parameter setting.
Low/high/low/high beeps Out of host parameter storage space. Scan Default Parameters
on page 4-3.
Code 39 Buffering
High/low beeps New Code 39 data was entered into the buffer.
3 Beeps - long high beeps Code 39 buffer is full.
Low/high/low beeps The Code 39 buffer was erased or there was an attempt to clear
or transmit an empty buffer.
Low/high beeps A successful transmission of buffered data.
Host Specific
USB only
4 short high beeps Scanner has not completed initialization. Wait several seconds
and scan again.
Scanning 2 - 3
Table 2-1
Beeper Definitions (Continued)
Beeper Sequence Indication
Scanner gives a power-up beep after
scanning a USB Device Type.
This power-up beep occurs more
than once.
RS-232 only
1 short high beep A <BEL> character is received and Beep on <BEL> is enabled.
LED Definitions
In addition to beeper sequences, the scanner communicates with the user using a two-color LED display. Table 2-2
defines LED colors that display during scanning.
Table 2-2
Off No power is applied to the scanner, or the scanner is on and
Standard LED Definitions
Communication with the bus must be established before the
scanner can operate at the highest power level.
The USB bus may put the scanner in a state where power to the
scanner is cycled on and off more than once. This is normal and
usually happens when the host cold boots.
LED Indication
ready to scan.
Green A bar code was successfully decoded.
Red A data transmission error or scanner malfunction occurred.
2 - 4 LS3008 Product Reference Guide
Single-Line Mode Multi-Line Raster Mode
Scanning in Hand-Held Mode
Install and program the scanner (see Setting Up the Scanner on page 1-3). For assistance, contact the local
supplier or Zebra Support.
To scan in hand-held mode:
1. Ensure all connections are secure. (See the host chapter for the scanner.)
2. Aim the scanner at the bar code.
3. Press the trigger.
Figure 2-2
4. Upon successful decode, the scanner beeps and the LED turns green. (For more information about beeper
Scanning in Hand-Held Mode
and LED definitions, see Table 2-1 and Table 2-2.)
NOTE Scan line lengths vary depending on the scan line width selected (see Scan Line Width on page 4-7). A
full scan line width is the default. Medium and short scan line widths are useful for scanning menus or
pick-lists.
Scanning 2 - 5
012345
012345
012345
Aiming
On a typical UPC 100% hold the scanner between contact and 19 inches from the symbol (see Decode Zone on
page 2-9). When scanning using a single-line scan mode, ensure the scan line crosses every bar and space of the
symbol.
Figure 2-3
Acceptable and Incorrect Single-Line Aiming
When scanning using a multi-line scan mode, at least one scan line must cross every bar a nd space of the symbol.
012345
Figure 2-4
Acceptable and Incorrect Multi-Line Aiming
Regardless of the scan mode, the scan line is smaller when the scanner is closer to the symbol and larger when it
is farther from the symbol. Scan symbols with smaller bars or elements (mil size) clos er to the scanner, and those
with larger bars or elements (mil size) farther from the scanner.
Do not hold the scanner directly over the bar code. Laser light reflecting directly back into the scanner from the bar
code is known as specular reflection. This specular reflection can make decoding difficult.
NOTE Scan line lengths vary depending on the scan line width selected. A full scan line width is the default.
Medium and short scan line widths ar e use ful for scanning menus or pick-lists.
For more information about scan line widths and scanning modes, see Scan Line Width on page 4-7 and Scan
Pattern on page 4-6, respectively.
2 - 6 LS3008 Product Reference Guide
65
o
65
o
The scanner can be tilted up to 65 forward or back and achieve a successful decode ( Figure 2-5). Sim ple practice
quickly shows what tolerances to work within.
Figure 2-5
Maximum Tilt Angles and Dead Zone
Scanning in Hands-Free Mode
The optional Intellistand adds greater flexibility to scanning operation. When the scanner is seated in the stand’s
“cup,” the scanner’s built-in sensor places the scanner in hands-free mode. Wh en the scanner is removed from the
stand, it automatically switches modes to operate in its normal hand-held triggered mode.
Assemble the Stand
Scanning 2 - 7
Figure 2-6
Assembling Intellistand
2 - 8 LS3008 Product Reference Guide
Scanner Holder
Height Adjustment Knob
Angle Adjustment Knob
Cup
Scanning with Intellistand
When the scanner is placed in the Intellistand, the scan pattern selected in hand-held triggered mode continues
(see Scan Pattern on page 4-6).
To operate the scanner in Intellistand:
1. Ensure the scanner is properly connected to the host (see the ap propriate host chapter for information on h ost
connections).
2. Insert the scanner in Intellistand by placing the front of the scanner into the stand’s “cup.”
Figure 2-7
3. Use the Intellistand’s adjustment knobs to adjust the height and angle of the scanner.
4. Present the bar code.
5. Upon successful decode, the scanner beeps and the LED turns green. F or more information abou t beeper and
Inserting the Scanner in the Intellistand
NOTE When the bar code is in view, the scanner emits a full scan line. After 3 minutes, the scanner
automatically switches to a reduced scan line. After 1 hour, the scanner automatically switches to blink
mode.
LED definitions, see Table 2-1 and Table 2-2.
Decode Zone
Note: Typical performance at 73° F (23° C) on
high quality symbols in normal room light.
LS 4208
*Minimum distance determined by symbol length and scan angle
Depth of Field
*
5 mil
5.5
10 mil
29
20 mil
1.5
13 mil
19
14.5
in.
cm
0
0
5
12.7
10
25.4
15
38.1
20
50.8
25
63.5
30
76.2
35
88.9
40
101.6
W
i
d
t
h
o
f
F
i
e
l
d
00
12.7
25.4
38.1
5
10
in. cm
15
12.75
25.410
15 38.1
Scanning 2 - 9
Figure 2-8
LS3008 Decode Zone
2 - 10 LS3008 Product Reference Guide
Chapter 3 Maintenance, Troubleshooting &
Specifications
Introduction
This chapter provides suggested scanner maintenance, troubleshooting, technical specifications, and signal
descriptions (pinouts).
Maintenance
Cleaning the exit window is the only maintenance required. A dirty window may affect scanning accuracy.
•
Do not allow any abrasive material to touch the window
•
Remove any dirt particles with a damp cloth
•
Wipe the window using a tissue moistened with ammonia/water
•
Do not spray water or other cleaning liquids directly into the window.
3 - 2 LS3008 Product Reference Guide
Troubleshooting
Table 3-1
Beeper Indications
The scanner emits frequent
beeps.
Scanner emits low/high/low
beeps.
Scanner emits low/high
beeps.
Troubleshooting
Problem Possible Causes Possible Solutions
No power to the scanner. Check the system power. If the
configuration requires a power supply,
re-connect the power supply.
Incorrect host interface cable is used. Verify that the correct host interface cable
is used. If not, connect the correct host
interface cable.
Interface/power cables are loose. Check for loose cable connections and
re-connect cables.
ADF transmit error. Refer to the Advanced Data Formatting
Programmer’s Guide, p/n 72-69680-xx, for
information about ADF programming.
Invalid ADF rule is detected. Refer to the Advanced Data Formatting
Programmer’s Guide, p/n 72-69680-xx, for
information about ADF programming.
Input error, incorrect bar code or
Cancel
bar code was scanned.
Scan the correct numeric bar codes within
range for the parameter programmed.
Scanner emits low/high/low
beeps.
Scanner emits
low/high/low/high beeps.
Scanner emits high/low
beeps.
Scanner emits
high/high/high/low beeps.
Scanner emits four long low
beeps.
Scanner emits four short high
beeps (USB only).
The Code 39 buffer was erased or
there was an attempt to clear or
transmit an empty buffer.
Out of host parameter storage space. Scan
Out of memory for ADF rules. Reduce the number of ADF rules or the
The scanner is buffering Code 39
data.
RS-232 receive error. Normal during host reset. Otherwise, set
A transmission error was detected in
a scanned symbol. The data is
ignored.
Scanner has not completed
initialization.
Normal when scanning the Code 39
Buffering
attempt to transmit an empty Code 39
buffer.
number of steps in the ADF rules.
Normal.
the scanner's RS-232 parity to match the
host setting.
This occurs if a unit is not properly
configured. Check option setting.
Wait several seconds and scan again.
Clear Buffer
Default Parameters on page 4-3
bar code or upon
.
Maintenance, Troubleshooting & Specifications 3 - 3
Table 3-1
Scanner emits a short
low/high/low/high beep
sequence while it is being
programmed.
Decoding Bar Codes
Scanner emits the laser, but
does not decode the bar
code.
Scanner decodes bar code,
but does not transmit the data
to the host.
Troubleshooting (Continued)
Problem Possible Causes Possible Solutions
Out of ADF parameter storage space. Erase all rules and re-program with shorter
rules.
Scanner is not programmed for the
correct bar code type.
Bar code symbol is unreadable. Scan test symbols of the same bar code
Distance between scanner and bar
code is incorrect.
The scan line is not crossing every
bar and space of the symbol.
Scanner is not programmed for the
correct host type.
Program the scanner to read that type of
bar code. See
Protection System Symbologies
type to determine if the bar code is
defaced.
Move the scanner closer to or further from
the bar code. See
2-9
.
Move the symbol until the scan line is
within the acceptable aiming pattern. See
Figure 2-3 on page 2-5
Scan the appropriate host type
programming bar code. See the chapter
corresponding to the host type.
Chapter 12, Intrusion
.
Decode Zone on page
.
Scanner emits five long low
beep after a bar code is
decoded.
Interface cable is loose. Check for loose cable connection and
re-connect cable.
Conversion or format error was
detected.
The scanner’s conversion
parameters are not properly
configured.
Conversion or format error was
detected.
An ADF rule was set up with
characters that can't be sent for the
host selected.
Conversion or format error was
detected.
A bar code was scanned with
characters that can't be sent for that
host.
Ensure the scanner’s conversion
parameters are properly configured.
Change the ADF rule, or change to a host
that can support the ADF rule.
Change the bar code, or change to a host
that can support the bar code.
3 - 4 LS3008 Product Reference Guide
Table 3-1
Troubleshooting (Continued)
Problem Possible Causes Possible Solutions
Host Displays
Host displays scanned data
incorrectly.
Trigger
Scanner is not programmed to work
with the host.
Ensure the proper host is selected.
Scan the appropriate host type
programming bar code.
For RS-232, set the scanner's
communication parameters to match the
host's settings.
For a USB HID keyboard or Keyboard
Wedge configuration, program the system
for the correct keyboard type and
language, and turn off the CAPS LOCK
key.
Program the proper editing options (e.g.,
ADF, UPC-E to UPC-A Conversion).
Check the scanner’s host type parameters
or editing options.
Nothing happens when the
trigger is pulled.
The laser does not appear
when the trigger is pulled.
NOTE If after performing these checks the symbol still does not scan, contact the distributor or contact Zebra
Support. See page xiii for contact information.
No power to the scanner. Check the system power. If the
configuration requires a power supply,
re-connect the power supply.
Interface/power cables are loose. Check for loose cable connections and
re-connect cables.
No power to the scanner. Check the system power. If the
configuration requires a power supply,
re-connect the power supply.
Incorrect host interface cable is used. Verify that the correct host interface cable
is used. If not, connect the correct host
interface cable.
Interface/power cables are loose. Check for loose cable connections and
re-connect cables.
Technical Specifications
Maintenance, Troubleshooting & Specifications 3 - 5
Table 3-2
Physical Characteristics
Dimensions 6.7 in. H x 3.7 in. L x 2.7 in. W
Weight (without cable) Approximately 6.4 oz. (181 g)
Voltage & Current 5 +/-10%VDC @ 140 mA (Stand by: <35 mA)
Color Yellow
Performance Characteristics
Light Source (Laser) 650nm laser diode
Motor Frequency 50Hz
Decode Rate 200 decodes per second
Roll Tolerance ± 35°
Pitch Tolerance ± 60°
Yaw Tolerance ± 60°
Technical Specifications
Item Description
(17 cm H x 9.3 cm L x 6.8 cm W)
Nominal Working Distance 13 mil (100% UPC/EAN): 0 to 19 in. (48.25 cm)
5 mil (Code 39): 1.5 to 5.5 in. (3.8 cm to 13.97 cm)
(See
Decode Zone on page 2-9
Print Contrast Minimum 25% minimum reflectance
Multi-Line Aiming Coverage At 5 in. reading distance: ~ 0.5 in. (1.3 cm)
At 10 in. reading distance: ~ 1 in. (2.5 cm)
Motion Tolerances Horizontal Velocity: 200 in. (508 cm) / sec
Vertical Velocity: 200 in. (508 cm) / sec
Angular Velocity: 200 in. (508 cm) / sec
Decode Capability UPC/EAN and with supplementals, Code 39, Code 39 Full ASCII, Trioptic
Code 39, GS1 DataBar Variants, UCC/EAN 128, Code 128, Code 128 Full
ASCII, Code 93, Codabar (NW1), Interleaved 2 of 5, Discrete 2 of 5 MSI,
Codell, IATA, Bookland EAN, Code 32
Interfaces Supported RS-232C (Standard, Nixdorf, ICL, & Fujitsu); IBM 468x/469x; Keyboard
Wedge; USB (Standard, IBM SurePOS, Macintosh); Laser/Wand Emulation.
Synapse Adaptive Connectivity allows for connectivity to interfa ces abo ve and
many non-standard interfaces.
)
3 - 6 LS3008 Product Reference Guide
Table 3-2
Technical Specifications (Continued)
Item Description
User Environment
Operating Temperature 32° to 122° F (0° to 50° C)
Storage Temperature -40° to 158° F (-40° to 70° C)
Humidity 5% to 95%, non-condensing
Drop Specifications 6.5 ft (1.98 m) drops to concrete at room temperature
6 ft (1.83 m) drops at 32
o
, 73o, and 122o F (0o, 23o, and 50o C)
Ambient Light Tolerance Tolerant to typical artificial indoor and natural outdoor (direct sunlight) lighting
conditions. Fluorescent, Incandescent, Mercury Vapor, Sodium Vapor, LED:
450 Ft Candles (4,844 Lux) Sunlight: 8000 Ft Candles (86,111 Lux)
Note: LED lighting with high AC ripple content can impact scanning
performance.
Beeper Volume User-selectable: three levels
Beeper Tone User-selectable: three tones
ESD 15 kV air discharge
8 kV indirect discharge
Regulatory
Electrical Safety UL1950, CSA C22.2 No. 950, EN60950/IEC950
Laser Safety CDRH Class II, IEC Class 2
EMI/RFI FCC Part 15 Class B, ICES-003 Class B, European Union EMC Directive,
Australian SMA
Scanner Signal Descriptions
Cable interface port
Interface cable
modular connector
Bottom of scanner
PIN 1PIN 10
Maintenance, Troubleshooting & Specifications 3 - 7
Figure 3-1
Scanner Cable Pin-outs
3 - 8 LS3008 Product Reference Guide
The signal descriptions in Table 3-3 apply to the connector on the scanner and are for reference only.
Table 3-3
Pin IBM Synapse RS-232
1 Reserved SynClock Reserved Reserved Reserved Jump to Pin 6
2 Power Power Power Power Power Power
3 Ground Ground Ground Ground Ground Ground
4 IBM_A(+) Reserved TxD KeyClock DBP Reserved
5 Reserved Reserved RxD TermData CTS D +
6 IBM_B(-) SynData RTS KeyData RTS Jump to Pin 1
7 Reserved Reserved CTS TermClock Reserved D 8 Reserved Reserved Reserved Reserved Reserved R eserved
9 EAS EAS EAS EAS EAS EAS
10 EAS EAS EAS EAS EAS EAS
Scanner Signal Pin-outs
Keyboard
Wedge
Wand USB
Chapter 4 User Preferences
*High Frequency
Feature/Option
* Indicates Default
Introduction
If desired, program the scanner to perform various functions, or activate different features. This chapter describes
each user preference feature and provides the programming bar codes necessary for selecting these features.
The scanner ships with the settings shown in the User Preferences Default Table on page 4-2 (also see Appendix
A, Standard Defaults for all host device and miscellaneous defaults). If the default values suit requirements,
programming may not be necessary.
To set feature values, scan a single bar co de or a sh ort b ar code sequen ce. The setting s are stored in non -vola tile
memory and are preserved even when th e sca nn e r is powered down.
If not using a Synapse or USB cable, select a host type (see each host chapter for specific host information) after
the power-up beeps sound. This is only necessary upon the first power-up when connected to a new host.
To return all features to their default values, see Default Parameters on page 4-3. Throughout the programming bar
code menus, default values are indicated with asterisks (
*).
Scanning Sequence Examples
In most cases, scanning one bar code sets the parameter value. For example, to set the beeper tone to high, scan
the High Frequency (beeper tone) bar code listed under Beeper Tone on page 4-4. The scanner issues a fast
warble beep and the LED turns green, signifying a suc c essful parameter entry.
Other parameters, such as Serial Response Time-Out or Data Transmission Format s, re quire scanning several
bar codes. See these parameter descriptions for this procedure.
4 - 2 LS3008 Product Reference Guide
Errors While Scanning
Unless otherwise specified, when an error is made during a scanning sequence, just re-scan the correct
parameter.
User Preferences Parameter Defaults
Table 4-1 lists the defaults for user preferences parameter s. To change any option, scan the appropriate bar
code(s) provided in the User Preferences section beginning on page 4-3.
NOTE See Appendix A, Standard Defaults for all user preferences, hosts, symbologies, and miscellaneous
default parameters.
Table 4-1
User Preferences
Set Default Parameter Restore Defaults
Beeper Tone Medium
Beeper Volume High
Power Mode Continuous On
Scan Pattern Multi-line Always
Scan Line Width Full Width
Laser On Time 3.0 Sec
Beep After Good Decode Enable
User Preferences Default Table
Parameter Default Page Number
Raster
4-3
4-4
4-4
4-5
4-6
4-7
4-7
4-8
User Preferences
Default Parameters
The scanner can be reset to two types of defaults: factory defaults or custom defaults. Scan the appropriate bar
code below to reset the scanner to its default settings and/or set the scanner’s current settings as the custom
default.
•
Restore Defaults - Resets all default parameters as follows:
• If custom default values were configured (see
for all parameters each time the
• If no custom default values were conf igured, the factory default values ar e set for all parameters e ach time
the
Restore Defaults bar code below is scanned. (For factory default values, see Table A-1 beginning on
page A-1.)
•
Set Factory Defaults - Scan the Set Factory Defaults bar code below to eliminate all custom default values and
set the scanner to factory default values. (For factory default values, see Table A-1 beginning on page A-1.)
•
Write to Custom Defaults - Custom default parameters can be configured to set unique default values for all
parameters. After changing all p arameters to the desired default values, scan the
bar code below to configure custom defaults.
User Preferences 4 - 3
Write to Custom Defaults), the custom default values are set
Restore Defaults bar code below is scanned.
Write to Custom Defaults
*Restore Defaults
Write to Custom Defaults
Set Factory Defaults
4 - 4 LS3008 Product Reference Guide
Beeper Tone
To select a decode beep frequency (tone), scan the Low Frequency, Medium Frequency, or High Frequency bar
code.
Low Frequency
*Medium Frequency
(Optimum Settings)
High Frequency
Beeper Volume
To select a beeper volume, scan the Low Volume, Medium Volume, or High Volume bar code.
Low Volume
Medium Volume
*High Volume
User Preferences 4 - 5
Power Mode
This parameter determines whether or not power remains on after a decode attempt. When in reduced power
mode, the scanner enters into a low power consumption mode to preserve battery life after each decode attempt.
When in continuous power m od e , p ow er r em a ins on a fter ea ch decode attempt.
*Continuous On
Reduced Power Mode
4 - 6 LS3008 Product Reference Guide
Scan Pattern
This parameter determines the pattern (mode) of scanning. Scan the appropriate bar code below to set the
scanning mode.
•
Single-line Only - Scan Single-line Only for a single-line scan mode. The laser has no up and down scan
line movement (no raster). (For an example of a single-line scan, see Figure 2-3 on page 2-5.)
•
Multi-line Smart Raster - Scan Multi-line Smart Raster for a scan line begins as a single line and moves
up and down (rasters) when a partial sca n of a b ar co de is de te cte d, or no ba r co de is deco ded 50 0 m s after
the trigger is pulled. Upon seeing a stacked GS1 DataBar code, the scanner immediately rasters. (For an
example of a multi-line scan, see Figure 2-4 on page 2-5.)
•
Multi-line Always Raster (default) - Scan Multi-line Always Raster for rastering (up and down scan line
movement) to begin immediately.
Single-line Only
(No Raster)
*Multi-line Always Raster
Multi-line Smart Raster
Scan Line Width
Scan a bar code below to set the scan line width.
*Full Width
User Preferences 4 - 7
Medium Width
Small Width
Laser On Time
This parameter sets the maximum time that decode processing continues during a scan attempt. It is
programmable in 0.1 second increments from 0.5 to 9.9 seconds. The default Laser On Time is 3.0 seconds.
To set a Laser On Time, scan the bar code below. Next, scan two numer ic bar codes beginning on page D-1 in
Appendix D, Numeric Bar Codes that correspond to the desired on time. Single digit numbers must have a lea ding
zero. For example, to set an On Time of 0.5 seconds, scan the bar code below, then scan the “0” and “5” bar
codes. If an error is made, or the selection needs to be changed, scan Cancel on page D-3.
Laser On Time
4 - 8 LS3008 Product Reference Guide
Beep After Good Decode
Scan a bar code below to select whether or not the scanner beeps after a good decode. If Do Not Beep After
Good Decode is selected, the beeper still operates during parameter menu scanning and indicates error
conditions.
*Beep After Good Decode
(Enable)
Do Not Beep After Good Decode
(Disable)
Chapter 5 Keyboard Wedge Interface
*North American
Feature/Option
* Indicates Default
Introduction
This chapter describes how to set up a Keyboard Wedge interface with the scanner. With this interface, the
scanner is connected between the keyboard and host compu ter, and translates bar code dat a into keystrokes. The
host computer accepts the keystrokes as if they originated from the keyboard. This mode adds bar code reading
functionality to a system designed for manual keyboard input. Keyboard keystrokes are simply passed through.
Throughout the programming bar code menus, default values are indicated with asterisks (
*).
5 - 2 LS3008 Product Reference Guide
Male DIN Connector
Female DIN Connector
Keyboard
Connector
Connecting a Keyboard Wedge Interface
Figure 5-1
Keyboard Wedge Connection with Y-cable
To connect the Keyboard Wedge interface Y-cable:
NOTE Interface cables vary depending on configuration. The connectors illustrated in Figure 5-1 are examples
only. The connectors may be different than those illustrated, but the steps to connect the scanner remain
the same.
1. Turn off the host and unplug the keyboard connector.
2. Attach the modular connector of the Y-cable to the cable interface port on the scanner. (See Installing the
Interface Cable on page 1-3.)
3. Connect the round male DIN host connector of the Y-cable to the keyboard port on the host device.
4. Connect the round female DIN keyboard connector of the Y-cable to the keyboard connector.
5. If needed, attach the optional power supply to the connector in the middle of the Y-cable.
6. Ensure that all connections are secure.
7. Turn on the host system.
8. Select the Keyboard Wedge host type by scanning the appropriate bar code from Keyboard Wedge Host
Parameters on page 5-4.
9. To modify any other parameter options, scan the appropriate bar codes in this chapter.
Keyboard Wedge Parameter Defaults
Table 5-1 lists the defaults for Keyboard Wedge host parameters. To change any option, scan the appropriate bar
code(s) in the Keyboard Wedge Host Parameters section beginning on page 5-4.
NOTE See Appendix A, Standard Defaults for all user preferences, hosts, symbologies, and miscellaneous
default parameters.
Keyboard Wedge Interface 5 - 3
Table 5-1
Keyboard Wedge Host Parameters
Keyboard Wedge Host Type
Country Types (Country Codes) North American
Ignore Unknown Characters Send
Keystroke Delay No Delay
Intra-Keystroke Delay Disable
Alternate Numeric Keypad Emulation Disable
Caps Lock On Disable
Caps Lock Override Disable
Convert Wedge Data No Convert
Function Key Mapping Disable
FN1 Substitution Disable
Keyboard Wedge Host Default Table
Parameter Default
IBM PC/AT& IBM PC Compatibles
Page
Number
1
5-4
5-5
5-6
5-7
5-7
5-8
5-8
5-9
5-9
5-10
5-10
Send and Make Break Send
1
User selection is required to configure this interface and this is the most common
selection.
5-11
5 - 4 LS3008 Product Reference Guide
Keyboard Wedge Host Parameters
Keyboard Wedge Host Types
Select the Keyboard Wedge host by scanning one of the bar codes below.
IBM PC/AT & IBM PC Compatibles
NCR 7052
1
NOTE
User selection is required to configure this interface and this is the most common selection.
1
IBM AT Notebook
Keyboard Wedge Interface 5 - 5
Keyboard Wedge Country Types (Country Codes)
Scan the bar code corresponding to the keyboard type. If the keyboard type is not listed, see Alternate Numeric
Keypad Emulation on page 5-8.
*North American
German Windows
French Windows
French Canadian Windows XP/2000
French Canadian Windows 95/98
Spanish Windows
Italian Windows
5 - 6 LS3008 Product Reference Guide
Keyboard Wedge Country Types (continued)
Swedish Windows
UK English Windows
Japanese Windows
Portuguese-Brazilian Windows
Ignore Unknown Characters
Unknown characters are characters the host does not recognize. When Send Bar Codes With Unknown
Characters is selected, all bar code data is sent except for unknown characte rs, and no erro r be eps sound on the
scanner. When Do Not Send Bar Codes With Unknown Characters is selected, bar code data is sent up to the
first unknown character, then the scanner issues an error beep.
*Send Bar Codes with Unknown Characters
Do Not Send Bar Codes with Unknown
Characters
Keyboard Wedge Interface 5 - 7
Keystroke Delay
This is the delay in milliseconds between emulated keystrokes. Scan a bar code below to increase the delay when
hosts require a slower transmission of data.
*No Delay
Medium Delay (20 msec)
Long Delay (40 msec)
Intra-Keystroke Delay
When enabled, an additional delay is inserted between each emulated key depression and release. This sets the
Keystroke Delay parameter to a minimum of 5 msec as well.
Enable Intra-Keystroke Delay
*Disable Intra-Keystroke Delay
5 - 8 LS3008 Product Reference Guide
Alternate Numeric Keypad Emulation
This allows emulation of most other country keyboard types not listed in Keyboard W ed ge Co untry Types (Country
Codes) on page 5-5 in a Microsoft
Enable Alternate Numeric Keypad
®
operating system environment.
*Disable Alternate Numeric Keypad
Caps Lock On
When enabled, the scanner emulates keystrokes as if the Caps Lock key is always pressed. Note that if both Caps
Lock On and Caps Lock Override are enabled, Caps Lock Override takes precedence
Enable Caps Lock On
*Disable Caps Lock On
Keyboard Wedge Interface 5 - 9
Caps Lock Override
When enabled, on A T or AT Notebook host s, the keyboard ignores the st ate of the Cap s Lock key. Therefore, an ‘A’
in the bar code is sent as an ‘A’ no matter what the state of the keyboard’s Caps Lock key. Note that if both Caps
Lock On and Caps Lock Override are enabled, Caps Lock Override takes precedence.
Enable Caps Lock Override
*Disable Caps Lock Override
Convert Wedge Data
When enabled, the scanner will convert all bar code data to the selected case.
Convert to Upper Case
*No Convert
Convert to Lower Case
5 - 10 LS3008 Product Reference Guide
Function Key Mapping
ASCII values under 32 are normally sent as control key sequences (see Table 5-2 on page 5-13). When this
parameter is enabled, the keys in bold are sent in place of the standard key mapping. Table entries that do not
have a bold entry remain the same whether or not this parameter is enabled.
Enable Function Key Mapping
*Disable Function Key Mapping
FN1 Substitution
When enabled, the scanner replaces FN1 characters in an EAN128 bar code with a keystroke chosen by the user
(see FN1 Substitution Values on page 13-6).
Enable FN1 Substitution
*Disable FN1 Substitution
Send Make and Break
When enabled, the scan codes for releasing a key are not sent.
*Send Make and Break Scan Codes
Keyboard Wedge Interface 5 - 11
Send Make Scan Code Only
5 - 12 LS3008 Product Reference Guide
5001
5002
5003
5004
5005
5006
5007
5008
5009
5010
7009
7008
7013
7012
7004
7011
7003
7002
7014
5007
5008
5010
5002
5003
5004
5005 5006
1046
1045
5014
1043
5013
5015
5016
5018
5019
5001
5017
7013
5011
(7013 if double key)
(1048 if double key)
1048
5012
5009
5007
5008
5010
5002
5003
5004
5005 5006
1046
1045
5014
1043
5013
5015
5016
5018
5019
1086
1087
1088
1089
1090
5001
1066
1072
1073
1079 1080
1065
1070
1076
1077
1083 1084
1071
1078
1085
1069
5017
7013
5011
1082
1075
1068
1067
(1043 if double key)
(1048 if double key)
1048
5012
5009
1074
1081
Keyboard Maps
The following keyboard maps are provided for pr efix/suffix keystroke parameters. To program the prefix/suffix
values, see the bar codes on page 13-3.
Figure 5-2
Figure 5-3
IBM PC/AT
NCR 7052 32-KEY
Figure 5-4
NCR 7052 58-KEY
ASCII Character Set for Keyboard Wedge
NOTE Code 39 Full ASCII interprets the bar code special character ($ + % /) preceding a Code 39 character and
assigns an ASCII character value to the pair. For example, when Code 39 Full ASCII is enabled and a +B
is scanned, it is interpreted as b, %J as ?, and %V as @. Scanning ABC%I outputs the keystroke
equivalent of ABC >.
Keyboard Wedge Interface 5 - 13
Table 5-2
Keyboard Wedge ASCII Character Set
Full ASCII
ASCII Value
Code 39 Encode
Character
1001 $A CTRL A
1002 $B CTRL B
1003 $C CTRL C
1004 $D CTRL D
1005 $E CTRL E
1006 $F CTRL F
1007 $G CTRL G
1008 $H
1009 $I
CTRL H/
CTRL I/
1010 $J CTRL J
1011 $K CTRL K
1012 $L CTRL L
Keystroke
BACKSPACE
1
HORIZONTAL TAB
1
1013 $M
CTRL M/
ENTER
1014 $N CTRL N
1015 $O CTRL O
1016 $P CTRL P
1017 $Q CTRL Q
1018 $R CTRL R
1019 $S CTRL S
1020 $T CTRL T
1021 $U CTRL U
1
The keystroke in bold is sent only if Function Key Mapping is enabled.
Otherwise, the unbolded keystroke is sent.
1
5 - 14 LS3008 Product Reference Guide
Table 5-2
Keyboard Wedge ASCII Character Set (Continued)
Full ASCII
ASCII Value
Code 39 Encode
Character
1022 $V CTRL V
1023 $W CTRL W
1024 $X CTRL X
1025 $Y CTRL Y
1026 $Z CTRL Z
1027 %A
CTRL [ /
1028 %B CTRL \
1029 %C CTRL ]
1030 %D CTRL 6
1031 %E CTRL 1032 Space Space
1033 /A !
Keystroke
1
ESC
1034 /B “
1035 /C #
1036 /D $
1037 /E %
1038 /F &
1039 /G ‘
1040 /H (
1041 /I )
1042 /J *
1043 /K +
1044 /L ,
1045 - 1046 . .
1047 /O /
1048 0 0
1049 1 1
1
The keystroke in bold is sent only if Function Key Mapping is enabled.
Otherwise, the unbolded keystroke is sent.
Keyboard Wedge Interface 5 - 15
Table 5-2
Keyboard Wedge ASCII Character Set (Continued)
Full ASCII
ASCII Value
Code 39 Encode
Character
1050 2 2
1051 3 3
1052 4 4
1053 5 5
1054 6 6
1055 7 7
1056 8 8
1057 9 9
1058 /Z :
1059 %F ;
1060 %G <
1061 %H =
Keystroke
1062 %I >
1063 %J ?
1064 %V @
1065 A A
1066 B B
1067 C C
1068 D D
1069 E E
1070 F F
1071 G G
1072 H H
1073 I I
1074 J J
1075 K K
1076 L L
1077 M M
1
The keystroke in bold is sent only if Function Key Mapping is enabled.
Otherwise, the unbolded keystroke is sent.
5 - 16 LS3008 Product Reference Guide
Table 5-2
Keyboard Wedge ASCII Character Set (Continued)
Full ASCII
ASCII Value
Code 39 Encode
Character
1078 N N
1079 O O
1080 P P
1081 Q Q
1082 R R
1083 S S
1084 T T
1085 U U
1086 V V
1087 W W
1088 X X
1089 Y Y
Keystroke
1090 Z Z
1091 %K [
1092 %L \
1093 %M ]
1094 %N ^
1095 %O _
1096 %W ‘
1097 +A a
1098 +B b
1099 +C c
1100 +D d
1101 +E e
1102 +F f
1103 +G g
1104 +H h
1105 +I i
1
The keystroke in bold is sent only if Function Key Mapping is enabled.
Otherwise, the unbolded keystroke is sent.
Keyboard Wedge Interface 5 - 17
Table 5-2
Keyboard Wedge ASCII Character Set (Continued)
Full ASCII
ASCII Value
Code 39 Encode
Character
1106 +J j
1107 +K k
1108 +L l
1109 +M m
1110 +N n
1111 +O o
1112 +P p
1113 +Q q
1114 +R r
1115 +S s
1116 +T t
1117 +U u
Keystroke
1118 +V v
1119 +W w
1120 +X x
1121 +Y y
1122 +Z z
1123 %P {
1124 %Q |
1125 %R }
1126 %S ~
1
The keystroke in bold is sent only if Function Key Mapping is enabled.
Otherwise, the unbolded keystroke is sent.
Table 5-3
Keyboard Wedge ALT Key Character Set
ALT Keys Keystroke
2065 ALT A
2066 ALT B
2067 ALT C
2068 ALT D
2069 ALT E
5 - 18 LS3008 Product Reference Guide
Table 5-3
2070 ALT F
2071 ALT G
2072 ALT H
2073 ALT I
2074 ALT J
2075 ALT K
2076 ALT L
2077 ALT M
2078 ALT N
2079 ALT O
2080 ALT P
2081 ALT Q
2082 ALT R
Keyboard Wedge ALT Key Character Set (Continued)
ALT Keys Keystroke
2083 ALT S
2084 ALT T
2085 ALT U
2086 ALT V
2087 ALT W
2088 ALT X
2089 ALT Y
2090 ALT Z
Table 5-4
3000 Right Control Key
3048 GUI 0
3049 GUI 1
3050 GUI 2
3051 GUI 3
Keyboard Wedge GIU Key Character Set
GUI Keys Keystrokes
3052 GUI 4
3053 GUI 5
Keyboard Wedge Interface 5 - 19
Table 5-4
3054 GUI 6
3055 GUI 7
3056 GUI 8
3057 GUI 9
3065 GUI A
3066 GUI B
3067 GUI C
3068 GUI D
3069 GUI E
3070 GUI F
3071 GUI G
3072 GUI H
3073 GUI I
Keyboard Wedge GIU Key Character Set (Continued)
GUI Keys Keystrokes
3074 GUI J
3075 GUI K
3076 GUI L
3077 GUI M
3078 GUI N
3079 GUI O
3080 GUI P
3081 GUI Q
3082 GUI R
3083 GUI S
3084 GUI T
3085 GUI U
3086 GUI V
3087 GUI W
3088 GUI X
3089 GUI Y
3090 GUI Z
5 - 20 LS3008 Product Reference Guide
Table 5-5
5001 F1
5002 F2
5003 F3
5004 F4
5005 F5
5006 F6
5007 F7
5008 F8
5009 F9
5010 F10
5011 F 11
5012 F12
5013 F13
Keyboard Wedge F Key Character Set
F Keys Keystroke
5014 F14
5015 F15
5016 F16
5017 F17
5018 F18
5019 F19
5020 F20
5021 F21
5022 F22
5023 F23
5024 F24
Keyboard Wedge Interface 5 - 21
Table 5-6
6042 *
6043 +
6044 undefined
6045 6046 .
6047 /
6048 0
6049 1
6050 2
6051 3
6052 4
6053 5
6054 6
Keyboard Wedge Numeric Keypad Character Set
Numeric Keypad Keystroke
6055 7
6056 8
6057 9
6058 Enter
6059 Num Lock
Table 5-7
7001 Break
7002 Delete
7003 Pg Up
7004 End
7005 Pg Dn
7006 Pause
7007 Scroll Lock
Keyboard Wedge Extended Keypad Character Set
Extended Keypad Keystroke
7008 Backspace
5 - 22 LS3008 Product Reference Guide
Table 5-7
7009 Tab
7010 Print Screen
7011 Insert
7012 Home
7013 Enter
7014 Escape
7015 Up Arrow
7016 Dn Arrow
7017 Left Arrow
7018 Right Arrow
Keyboard Wedge Extended Keypad Character Set (Continued)
Extended Keypad Keystroke
Chapter 6 RS-232 Interface
*Baud Rate 57,600
Feature/Option
* Indicates Default
Introduction
This chapter describes how to set up the scanner with an RS-232 host. The RS-232 interface is used to connect
the scanner to point-of-sale devices, host computers, or other devices with an available RS-232 port (e.g., com
port).
If the host is not listed in Table 6-2, refe r to the document ation for the ho st device to set commu nication para meters
to match the host.
NOTE The scanner uses TTL RS-232 signal levels, which interface with most system architectures. For system
architectures requiring RS-232C signal levels, Zebra offers different cables providing TTL-to-RS-232C
conversion. Contact Zebra Support for more information.
Throughout the programming bar code menus, default values are indicated with asterisks (
*).
6 - 2 LS3008 Product Reference Guide
Serial Port
Connector to Host
Interface Cable
Power Supply Cable
Connecting an RS-232 Interface
This connection is made directly from the scanner to the host computer.
Figure 6-1
1. Attach the modular connector of the RS-232 interface cable to the cable interface port on the scanner (see
RS-232 Direct Connection
NOTE Interface cables vary depending on configuration. The connectors illustrated in Figure 6-1 are examples
only. The connectors may be different than those illustrated, but the steps to connect the scanner remain
the same.
Installing the Interface Cable on page 1-3).
2. Connect the other end of the RS-232 interface cable to the serial port on the host.
3. Connect the power supply to the serial connector end of the RS-232 interface cable. Plug the power supply
into an appropriate outlet.
4. Select the RS-232 host type by scanning the appropriate bar code from RS-232 Host Types on page 6-6.
5. To modify any other parameter options, scan the appropriate bar codes in this chapter.
RS-232 Parameter Defaults
Table 6-1 lists the defaults for RS-232 host parameters. If any option needs to be changed, scan the appropriate
bar code(s) provided in the Parameter Descriptions section beginning on page 6-4.
NOTE See Appendix A, Standard Defaults for all user preferences, hosts, symbologies, and miscellaneous
default parameters.
RS-232 Interface 6 - 3
Table 6-1
RS-232 Host Parameters
RS-232 Host Types Standard
Baud Rate 9600
Parity Type None
Stop Bit Select 1 Stop Bit
Data Bits (ASCII Format) 8-Bit
Check Receive Errors Enable
Hardware Handshaking None
Software Handshaking None
Host Serial Response Time-out 2 Sec
RTS Line State Low RTS
Beep on <BEL> Disable
Intercharacter Delay 0 msec
RS-232 Host Default Table
Parameter Default Page Number
6-6
6-7
6-8
6-9
6-9
6-10
6-10
6-12
6-14
6-15
6-15
6-16
Nixdorf Beep/LED Options Normal Operation
Ignore Unknown Characters Send Bar Code
6-17
6-17
6 - 4 LS3008 Product Reference Guide
RS-232 Host Parameters
Various RS-232 hosts are set up with their own parameter default settings (Table 6-2). Selecting the ICL, Fujitsu,
Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, Olivetti, Omron, or terminal sets the defaults listed below.
Table 6-2
Transmit Code ID No Yes Yes Yes Yes Yes Yes
Data Trans-
mission Format
Suffix CR/LF
Baud Rate 9600 9600 9600 9600 9600 9600 9600
Parity None Even None Odd Odd Even None
Hardware
Handshaking
Software
Handshaking
Serial Response
Time-out
Stop Bit Select One One One One One One One
Terminal Specific RS-232
Parameter
Standard
(Default)
Data as is Data/Suffix Data/Suffix Data/Suffix Data/Suffix Prefix/Data/
(7013)
None RTS/CTS
None None None None None Ack/Nak None
2 Sec. 9.9 Sec. 2 Sec. 9.9 Sec. 9.9 Sec. 9.9 Sec. 9.9 Sec.
Wincor-
ICL Fujitsu
CR (1013) CR (1013) CR (1013) CR (1013) ETX (1002) CR (1013)
None RTS/CTS
Option 3
Nixdorf
Mode A
Option 3
Wincor-
Nixdorf
Mode B/
OPOS
RTS/CTS
Option 3
Olivetti Omron
Data/Suffix
Suffix
None None
ASCII Format 8-Bit 8-Bit 8-Bit 8-Bit 8-Bit 7-Bit 8-Bit
Beep On <BEL> Disable Disable Disable Disable Disable Disable Disable
RTS Line State Low High Low Low Low = No data
to send
Prefix None None None None None STX (1003) None
*In the Nixdorf Mode B, if CTS is Low, scanning is disabled. When CTS is High, the user can scan bar
codes.
**If Nixdorf Mode B is scanned without the scanner connected to the proper host, it may appear
unable to scan. If this happens, scan a different RS-232 host type within 5 seconds of cycling power to
the scanner.
Low High
RS-232 Host Parameters (continued)
Selecting the ICL, Fujitsu, Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, OPOS terminal enables the
transmission of code ID characters listed in Table 6-3 below. These code ID characte rs are not pr ogra mmable an d
are separate from the T ransmit Code ID feature. The Transmit Code ID feature should not be enabled for these
terminals.
RS-232 Interface 6 - 5
Table 6-3
UPC-A A A A A A A
UPC-E E E C C C E
EAN-8/JAN-8 FF FF B B B FF
EAN-13/JAN-13 F F A A A F
Code 39 C <len> None M M M <len> C <len>
Codabar N <len> None N N N <len> N <len>
Code 128 L <len> None K K K <len> L <len>
I 2 of 5 I <len> None I I I <len> I <len>
Code 93 None None L L L <len> None
D 2 of 5 H <len> None H H H <len> H <len>
UCC/EAN 128 L <len> None P P P <len> L <len>
MSI None None O O O <len> None
Terminal Specific Code ID Characters
Code Type ICL Fujitsu
Wincor-
Nixdorf
Mode A
Wincor-
Nixdorf
Mode B/OPOS
Olivetti Omron
Bookland EAN F F A A A F
Trioptic None None None None None None
Code 11 None None None None None None
IATA H<len> None H H None None
Code 32 None None None None None None
6 - 6 LS3008 Product Reference Guide
RS-232 Host Types
To select an RS-232 host interface, scan one of the following bar codes.
*Standard RS-232
ICL RS-232
Wincor-Nixdorf RS-232 Mode A
Olivetti ORS4500
OPOS/JPOS
Wincor-Nixdorf RS-232 Mode B
Omron
Fujitsu RS-232
RS-232 Interface 6 - 7
Baud Rate
Baud rate is the number of bits of data transmitted per second. Set the scann er's baud rate to match the baud rate
setting of the host device. Otherwise, data may not reach the host device or may reach it in distorted form.
Baud Rate 600
Baud Rate 1200
Baud Rate 2400
*Baud Rate 9600
Baud Rate 4800
Baud Rate 19,200
Baud Rate 38,400
6 - 8 LS3008 Product Reference Guide
Parity
A parity check bit is the most significant bit of each ASCII coded character. Select the parity type according to host
device requirements.
•
Select Odd parity and the parity bit value is set to 0 or 1, based on data, to ensure that an odd number of 1
bits are contained in the coded character.
•
Select Even parity and the parity bit value is set to 0 or 1, based on dat a, to ensure that an even number of 1
bits are contained in the coded character.
•
Select Mark parity and the parity bit is always 1.
•
Select Space pari ty and the parity bit is always 0.
•
Select None when no parity bit is required.
Odd
Mark
Even
Space
*None
RS-232 Interface 6 - 9
Stop Bit Select
The stop bit(s) at the end of each transmitted character marks the end of transmission of one character and
prepares the receiving device for the next character in the serial data stream. The number of stop bits selected
(one or two) depends on the number the receiving terminal is programmed to accommodate. Set the number of
stop bits to match host device requirements.
*1 Stop Bit
2 Stop Bits
Data Bits (ASCII Format)
This parameter allows the scanner to interface with devices requiring a 7-bit or 8-bit ASCII protocol.
7-Bit
*8-Bit
6 - 10 LS3008 Product Reference Guide
Check Receive Errors
Select whether or not the parity, framing, and overrun of received characters are checked. The parity value of
received characters is verified against the parity parameter selec te d above.
*Check For Received Errors
(Enable)
Do Not Check For Received Errors
(Disable)
Hardware Handshaking
The data interface consists of an RS-232 port designed to operate either with or without the ha rdware handshaking
lines, Request to Send (RTS), and Clear to Send (CTS).
If Standard RTS/CTS handshaking is not selected, scan data is transmitted as it becomes available. If Standard
RTS/CTS handshaking is selected, scan data is transmitted according to the following sequence:
•
The scanner reads the CTS line for activity. If CTS is asserted, the scan ner waits u p to Host Serial Resp onse
Time-out for the host to de-assert the CTS line. If, after Host Serial Response Time-out, the CTS line is still
asserted, the scanner sounds a transmit error, and any scanned data is lost.
•
When the CTS line is de-asserted, the scanner asserts the R TS line and waits up to Host Serial Response
Time-out for the host to assert CTS. When the host asserts CTS, data is transmitted. If, after Host Serial
Response Time-out, the CTS line is not asserted, the scanner sounds a tran smit error, and d iscards the da t a.
•
When data transmission is complete, the scanner de-asserts RTS 10 msec after sending the last character.
•
The host should respond by negating CTS. The scanner checks for a de-asserted CTS upon the next
transmission of data.
During the transmission of data, the CTS line should be asserted. If CTS is de-asserted for mo re than 50 ms
between characters, the transmission is aborted, the scanner sounds a transmission error, and the data is
discarded.
If the above communication sequence fails, the scanner issues an error indication . In this case, the data is lost and
must be rescanned.
If Hardware Handshaking and Software Handshaking are both enabled, Hardware Handshaking takes
precedence.
RS-232 Interface 6 - 11
NOTE The DTR signal is jumpered to the active state.
•
None: Scan the bar code below if no Hardware Handshaking is desired.
•
Standard RTS/CTS: Scan the bar code below to select Standard RTS/CTS Hardware Handshaking.
•
RTS/CTS Option 1: When RTS/CTS Option 1 is selected, the scanner asserts RTS before transmitting and
ignores the state of CTS. The scanner de-asserts RTS when the transmission is complete.
•
RTS/CTS Option 2: When Option 2 is selected, RTS is always high or low (user-programmed logic level).
However, th e scanner waits for CTS to be asserted before transmitting data. If CTS is not asserted within
Host Serial Response Time-out, the scanner issues an error indication and discards the data.
•
RTS/CTS Option 3: When Option 3 is selected, the scanner asserts RTS prior to any data transmission,
regardless of the state of CTS. The scanner waits up to Host Serial Response Time-out for CTS to be
asserted. If CTS is not asserted during this time, the scanner issues an error indication and discards the
data. The scanner de-asserts RTS when transmission is complete.
*None
RTS/CTS Option 1
Standard RTS/CTS
RTS/CTS Option 2
RTS/CTS Option 3
6 - 12 LS3008 Product Reference Guide
Software Handshaking
This parameter offers control of the data transmission process in addition to, or instead of, that offered by hardwa re
handshaking. There are five options.
If Software Handshaking and Hardware Handshaking are both enabled, Hardware Handshaking takes
precedence.
•
None: When this option is selected, data is transmitted immediately. No response is expected from host.
•
ACK/NAK: When this option is selected, after transmitting data, the scanner expects either an ACK or NAK
response from the host. When a NAK is received, the scanner transmits the same data again and waits for
either an ACK or NAK. After three unsuccessful attemp ts to send dat a when NAKs are received, the scann er
issues an error indication and discards the data.
The scanner waits up to the programmable Host Serial Response T ime- out to receive an ACK or NAK. If the
scanner does not get a response in this time, it issues an error indication and discards th e data. There ar e no
retries when a time-out occurs.
•
ENQ: When this option is selected, the scanner waits for an ENQ character from the host before transmitting
data. If an ENQ is not received within the Host Serial Response Time-out, the scanner issues an error
indication and discards the data. The host must transmit an ENQ character at least every Host Serial
Response Time-out to prevent transmission errors.
•
ACK/NAK with ENQ: This combines the two previous options. For re-transmissions of data, due to a NAK
from the host, an additional ENQ is not required.
•
XON/XOFF: An XOFF character turns the scanner transmission off until the scanner receives an XON
character. There are two situations for XON/XOFF:
• XOFF is received before the scanner has d ata to send. When the scanner has data to send, it waits up to
Host Serial Response Time-out for an XON character before transmission. If the XON is not received
within this time, the scanner issues an error indication and discards the data.
• XOFF is received during a transmission. Data transmission then stops after sending the current byte.
When the scanner receives an XON character, it sends the rest of the data message. The scanner waits
up to 30 seconds for the XON.
Software Handshaking (continued)
*None
RS-232 Interface 6 - 13
ACK/NAK
ENQ
XON/XOFF
ACK/NAK with ENQ
6 - 14 LS3008 Product Reference Guide
Host Serial Response Time-out
This parameter specifies how long the scanner waits for an ACK, NAK, ENQ, XON, or CTS before determining that
a transmission error occurred.
*Minimum: 2 Sec
Low: 2.5 Sec
Medium: 5 Sec
Maximum: 9.9 Sec
High: 7.5 Sec
RS-232 Interface 6 - 15
RTS Line State
This parameter sets the idle state of the Serial Host RTS line. Scan a bar code below to select Low RTS or High
RTS line state.
*Host: Low RTS
Host: High RTS
Beep on <BEL>
When this parameter is enabled, the scanner issues a beep when a <BEL> character is detected on the RS-232
serial line. <BEL> is issued to gain a user's attention to an illegal entry or other important event.
Beep On <BEL> Character
(Enable)
*Do Not Beep On <BEL> Character
(Disable)
6 - 16 LS3008 Product Reference Guide
Intercharacter Delay
This parameter specifies the intercharacter delay inserted between character transmissions.
*Minimum: 0 msec
Low: 25 msec
Medium: 50 msec
Maximum: 99 msec
High: 75 msec
RS-232 Interface 6 - 17
Nixdorf Beep/LED Options
When Nixdorf Mode B is selected, this indicates when the scanner sh ould bee p and turn on it s L ED af ter a decode.
*Normal Operation
(Beep/LED immediately after decode)
Beep/LED After Transmission
Beep/LED After CTS Pulse
Ignore Unknown Characters
Unknown characters are characters the host does not recognize. When Send Bar Codes with Unknown
Characters is selected, all bar code data is sent except for unknown characte rs, and no erro r be eps sound on the
scanner. When Do Not Send Bar Codes With Unknown Characters is selected, bar code data is sent up to the
first unknown character and then an error beep sounds on the scanner.
*Send Bar Code with Unknown Characters
Do Not Send Bar Codes with Unknown
Characters
6 - 18 LS3008 Product Reference Guide
ASCII Character Set for RS-232
The values in Table 6-4 can be assigned as prefixes or suffixes for ASCII character data transmission.
Table 6-4
1000 %U NUL
1001 $A SOH
1002 $B STX
1003 $C ETX
1004 $D EOT
1005 $E ENQ
1006 $F ACK
1007 $G BELL
1008 $H BCKSPC
1009 $I HORIZ TAB
1010 $J LF/NW LN
1011 $K VT
1012 $L FF
ASCII Character Set for RS-232
ASCII Value
Code 39 Encode Character
Full ASCII
ASCII Character
1013 $M CR/ENTER
1014 $N SO
1015 $O SI
1016 $P DLE
1017 $Q DC1/XON
1018 $R DC2
1019 $S DC3/XOFF
1020 $T DC4
1021 $U NAK
1022 $V SYN
1023 $W ETB
1024 $X CAN
1025 $Y EM
1026 $Z SUB
RS-232 Interface 6 - 19
Table 6-4
1027 %A ESC
1028 %B FS
1029 %C GS
1030 %D RS
1031 %E US
1032 Space Space
1033 /A !
1034 /B "
1035 /C #
1036 /D $
1037 /E %
1038 /F &
1039 /G ‘
ASCII Character Set for RS-232 (Continued)
ASCII Value
Code 39 Encode Character
Full ASCII
ASCII Character
1040 /H (
1041 /I )
1042 /J *
1043 /K +
1044 /L ,
1045 - 1046 . .
1047 /O /
1048 0 0
1049 1 1
1050 2 2
1051 3 3
1052 4 4
1053 5 5
1054 6 6
1057 7 7
1056 8 8
6 - 20 LS3008 Product Reference Guide
Table 6-4
1057 9 9
1058 /Z :
1059 %F ;
1060 %G <
1061 %H =
1062 %I >
1063 %J ?
1064 %V @
1065 A A
1066 B B
1067 C C
1068 D D
1069 E E
ASCII Character Set for RS-232 (Continued)
ASCII Value
Code 39 Encode Character
Full ASCII
ASCII Character
1070 F F
1071 G G
1072 H H
1073 I I
1074 J J
1075 K K
1076 L L
1077 M M
1078 N N
1079 O O
1080 P P
1081 Q Q
1082 R R
1083 S S
1084 T T
1085 U U
1086 V V
RS-232 Interface 6 - 21
Table 6-4
1087 W W
1088 X X
1089 Y Y
1090 Z Z
1091 %K [
1092 %L \
1093 %M ]
1094 %N ^
1095 %O _
1096 %W `
1097 +A a
1098 +B b
1099 +C c
ASCII Character Set for RS-232 (Continued)
ASCII Value
Code 39 Encode Character
Full ASCII
ASCII Character
1100 +D d
1101 +E e
1102 +F f
1103 +G g
1104 +H h
1105 +I i
1106 +J j
1107 +K k
1108 +L l
1109 +M m
1110 +N n
1111 +O o
1112 +P p
1113 +Q q
1114 +R r
1115 +S s
1116 +T t
6 - 22 LS3008 Product Reference Guide
Table 6-4
1117 +U u
1118 +V v
1119 +W w
1120 +X x
1121 +Y y
1122 +Z z
1123 %P {
1124 %Q |
1125 %R }
1126 %S ~
1127 Undefined
7013 ENTER
ASCII Character Set for RS-232 (Continued)
ASCII Value
Code 39 Encode Character
Full ASCII
ASCII Character
Chapter 7 USB Interface
*North American Standard USB Keyboard
Feature/Option
* Indicates Default
Interface cable
USB Series A Connector
Introduction
This chapter covers the connection and setup of the scanner to a USB host. The scanner attaches directly to a
USB host, or a powered USB hub, and is powered by it. No additional power supply is required.
Throughout the programming bar code menus, default values are indicated with asterisks (
Connecting a USB Interface
*).
Figure 7-1
USB Connection
7 - 2 LS3008 Product Reference Guide
The scanner connects with USB capable hosts including:
•
Desktop PCs and Notebooks
•
Apple™ iMac, G4, iBooks (North America only)
•
IBM SurePOS terminals
•
Sun, IBM, and other network computers that support more than one keyboard.
The following operating systems support the scanner through USB:
•
Windows 98, 2000, ME, XP
•
MacOS 8.5 and above
•
IBM 4690 OS.
The scanner will also interface with other USB hosts which support USB Human Interface Devices (HID).
To set up the scanner:
NOTE Interface cables vary depending on configuration. The connectors illustrated in Figure 7-1are examples
only. The connectors may be different than those illustrated, but the steps to connect the scanner remain
the same.
1. Attach the modular connector of the USB interface cable to the cable interface port on the scanner (see
Installing the Interface Cable on page 1-3).
2. Plug the series A connector in the USB host or hub, or plug the Plus Power connector in an available port of
the IBM SurePOS terminal.
3. Select the USB device type by scanning the appropriate ba r cod e from USB Device Type on page 7-4.
4. On first installation when using Windows, the software prompts to select or install the Human Interface Device
driver. To install this driver, provided by Windows, click Next through all the choices and click Finished on the
last choice. The scanner powers up during this installation.
5. To modify any other parameter options, scan the appropriate bar codes in this chapter.
If problems occur with the system, see Troubleshooting on page 3-2.
USB Parameter Defaults
Table 7-1 lists the defaults for USB host parameters. If any option needs to be changed, scan the appropriate bar
code(s) provided in the Parameter Descriptions section beginning on page 7-4.
NOTE See Appendix A, Standard Defaults for all user preferences, hosts, symbologies, and miscellaneous
default parameters.
USB Interface 7 - 3
Table 7-1
USB Host Parameters
USB Device Type HID Keyboard Emulation
USB Country Keyboard Types (Country Codes) North American
USB Keystroke Delay No Delay
USB CAPS Lock Override Disable
USB Ignore Unknown Characters Send
Emulate Keypad Disable
USB FN1 Substitution Disable
Function Key Mapping Disable
Simulated Caps Lock Disable
Convert Case No Case Conversion
USB Host Default Table
Parameter Default Page Number
7-4
7-5
7-7
7-7
7-8
7-8
7-9
7-9
7-10
7-10
7 - 4 LS3008 Product Reference Guide
USB Host Parameters
USB Device Type
Select the desired USB device type.
NOTE When changing USB Device Types, the scanner automatically restarts. The scanner issues the standard
startup beep sequences.
*HID Keyboard Emulation
IBM Hand-Held USB
IBM Table Top USB
USB OPOS Handheld
USB Interface 7 - 5
USB Country Keyboard Types (Country Codes)
Scan the bar code corresponding to the keyboard type. This setting applies only to the USB HID Keyboard
Emulation device.
NOTE When changing USB country keyboard types the scanner automatically resets. The scanner issues the
standard startup beep sequences.
*North American Standard USB Keyboard
French Windows
French Canadian Windows 2000/XP
German Windows
French Canadian Windows 95/98
Spanish Windows
7 - 6 LS3008 Product Reference Guide
USB Country Keyboard Types (Country Codes) (continued)
Italian Windows
Swedish Windows
UK English Windows
Portuguese-Brazilian Windows
Japanese Windows (ASCII)
USB Interface 7 - 7
USB Keystroke Delay
This parameter sets the delay, in milliseconds, between emulated keystrokes. Scan a bar code below to increase
the delay when hosts require a slower transmission of data.
*No Delay
Medium Delay (20 msec)
Long Delay (40 msec)
USB CAPS Lock Override
This option applies only to the HID Keyboard Emulation device. When enabled, the case of the data is preserved
regardless of the state of the caps lock key. This setting is always enabled for the “Japanese, Windows (ASCII)”
keyboard type and can not be disabled.
Override Caps Lock Key
(Enable)
*Do Not Override Caps Lock Key
(Disable)
7 - 8 LS3008 Product Reference Guide
USB Ignore Unknown Characters
This option applies only to the HID Keyboard Emulation device and IBM device. Unknown characters are
characters the host does not recognize. When Send Bar Codes With Unknown Characters is selected, all bar
code data is sent except for unknown characters, and no error beeps sound. When Do Not Send Bar Codes With
Unknown Characters is selected, bar code data is sent up to the fir st unknown cha racter, then the scanner issue s
an error beep.
*Send Bar Codes with Unknown Characters
Do Not Send Bar Codes with Unknown
Characters
Emulate Keypad
When enabled, all characters are sent as ASCII sequences over the numeric keypad. For example ASCII A would
be sent as “ALT make” 0 6 5 “ALT Break.”
*Disable Keypad Emulation
Enable Keypad Emulation
