L10
Android ™
Quick Start Guide
MN-003429-03EN Rev. A
Copyright
ZEBRA and the stylized Zebra head are trademarks of Zebra Technologies Corporation, registered in
many jurisdictions worldwide. Google, Android, Google Play and other marks are trademarks of Google
LLC. All other trademarks are the property of their respective owners. ©2020 Zebra Technologies
Corporation and/or its affiliates. All rights reserved.
COPYRIGHTS & TRADEMARKS: For complete copyright and trademark information, go to
zebra.com/copyright.
WARRANTY: For complete warranty information, go to zebra.com/warranty.
END USER LICENSE AGREEMENT: For complete EULA information, go to zebra.com/eula.
Terms of Use
Proprietary Statement
This manual contains proprietary information of Zebra Technologies Corporation and its subsidiaries
(“Zebra Technologies”). It is intended solely for the information and use of parties operating and
maintaining the equipment described herein. Such proprietary information may not be used, reproduced,
or disclosed to any other parties for any other purpose without the express, written permission of Zebra
Technologies.
L10 Android ™ Quick Start Guide
Product Improvements
Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are
subject to change without notice.
Liability Disclaimer
Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals are
correct; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and
disclaims liability resulting therefrom.
Limitation of Liability
In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the
accompanying product (including hardware and software) be liable for any damages whatsoever
(including, without limitation, consequential damages including loss of business profits, business
interruption, or loss of business information) arising out of the use of, the results of use of, or inability to
use such product, even if Zebra Technologies has been advised of the possibility of such damages. Some
jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
2
XSLATE Features
L10 Android ™ Quick Start Guide
Microphone
Ambient Light
Sensor
Home Button
Front Camera
Microphone
Power LED
Battery LED
Reset Switch
Battery
Pen Holder and
Pen
Battery Latch
Front View
Camera Flash
Rear Camera
Kensington
Lock Slot
NFC Antenna
Expansion
Port Cover
Back View
3
Speaker
L10 Android ™ Quick Start Guide
Power Input
Ethernet Jack
Access Door
Volume Control
Right View
microSD
Card Slot
Left View
Docking
Connector
Rotate Lock
USB Type-C
Port
Power Button
USB Type-A
Ports (2)
Headset Jack
Bottom View
4
XPAD Features
L10 Android ™ Quick Start Guide
Programmable
Function Buttons
Microphone
Pen Holder
Ambient Light
Sensor
Home Button
Front Camera
Speaker
Microphone
Power LED
Battery LED
Reset Switch
Stylus Tether
Post
Battery
Battery
Latch
Front View
Camera
Flash
Rear Camera
Kensington
Lock Slot
NFC Antenna
Expansion Port
Cover
5
L10 Android ™ Quick Start Guide
Power Input
Ethernet Jack
Barcode
Scanner
Volume Control
Access Door
Stylus
Rotate Lock
Right View
microSD
Card Slot
Left View
Power Button
USB Type-C
Port
Barcode Scanner
Button
USB Type-A
Ports (2)
Headset Jack
Top View
XBOOK ™ L10
The XBOOK L10 is the same as the XSLATE, but includes a companion keyboard and a KickStrap
(combination of a kickstand and a hand strap).
Preparing the Tablet for First Use
This section has steps for setting up the device for the first time.
CAUTION:
battery into the tablet and apply AC power. This is required to take the battery out of Ship mode. If this is not performed,
and a battery is later installed, the battery will not provide power to the tablet.
Inserting a SIM Card
IMPORTANT: Before you can connect to a mobile broadband network, you must have an active account with a
cellular network provider and a SIM card in your tablet for mobile broadband access. This SIM card works like the SIM
card in your cell phone that connects you to a network provider.
The SIM card holder accommodates two nano SIM (4FF) cards, for use with mobile broadband. If inserting
only one nano SIM card, place the card in the holder labeled SIM1. If inserting two SIM cards, place the
card for the primary carrier in SIM1 slot and the card for the secondary carrier in SIM2 slot.
The battery ships from the factory in Ship mode. For the first time using the tablet and battery, insert the
1. Find and gently remove the SIM holder tray.
6
L10 Android ™ Quick Start Guide
Figure 1 Empty SIM Card Slot
Figure 2 SIM Card Slot with Holder
Empty SIM
card slot
SIM card slot with holder
2. Place the nano SIM card into the holder so that it is close to flush with the holder. Make sure that the
SIM contacts (gold) are facing down and the notched corner is on the right side as shown in this
drawing and in the graphic inside the battery bay of the tablet.
Figure 3 Two SIM Cards in Holder
Notched corner
The holder can hold two nano SIM cards. If you have two nano SIM cards, insert the second one into
the holder in the same way.
3. Carefully take the SIM holder and align it with the opening of the SIM holder connector. Gently slide the
SIM holder tray into the connector until it stops.
Installing the Battery
To install the battery:
1. Place the tabbed end of the battery into the battery compartment.
7
Figure 4 Battery Replacement
2. Press the battery down until it snaps into place.
Charging the Battery
L10 Android ™ Quick Start Guide
To charge the battery:
1. Plug the AC line cord into the power supply.
2. Open the power port door.
3. Plug the power supply output connector into the power port.
Power Port
Power Port
Door
4. Plug the AC line cord into an AC outlet.
The battery charging indicator on the front of the tablet blinks amber indicating that the battery is
charging. The indicator turns solid green when the battery is fully charged.
Keep the tablet on AC power until the battery is fully charged. However, you do not have to wait until
the tablet is fully charged to turn it on. The tablet charges while in use.
5. Press and release the Power button to turn on the tablet.
Power Button
8
ATEX/IECEx
For the ATEX/IECEx related standard refer to ATEX User Guide for more information.
L10 Android ™ Quick Start Guide
9
