L10
Enterprise Tablet
User Guide
™
for Android
8.1.0 Oreo
MN-003414-03EN
Copyright
ZEBRA and the stylized Zebra head are trademarks of Zebra Technologies Corporation, registered in many
jurisdictions worldwide. Google, Android, Google Play and other marks are trademarks of Google LLC; Oreo is a
trademark of Mondelez International, Inc. group. All other trademarks are the property of their respective owners.
©2021 Zebra Technologies Corporation and/or its affiliates. All rights reserved.
COPYRIGHTS & TRADEMARKS: For complete copyright and trademark information, go to zebra.com/copyright.
WARRANTY: For complete warranty information, go to zebra.com/warranty.
END USER LICENSE AGREEMENT: For complete EULA information, go to zebra.com/eula.
Terms of Use
• Proprietary Statement
This manual contains proprietary information of Zebra Technologies Corporation and its subsidiaries
(“Zebra Technologies”). It is intended solely for the information and use of parties operating and
maintaining the equipment described herein. Such proprietary information may not be used, reproduced,
or disclosed to any other parties for any other purpose without the express, written permission of Zebra
Technologies.
• Product Improvements
Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are
subject to change without notice.
• Liability Disclaimer
Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals are
correct; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and
disclaims liability resulting therefrom.
• Limitation of Liability
In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the
accompanying product (including hardware and software) be liable for any damages whatsoever
(including, without limitation, consequential damages including loss of business profits, business
interruption, or loss of business information) arising out of the use of, the results of use of, or inability to
use such product, even if Zebra Technologies has been advised of the possibility of such damages. Some
jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
Revision History
Changes to the original guide are listed below:
Change Date Description
01 Rev. A 07/01/19 Initial release
02 Rev. A 12/2020 Update data capture section to reflect Zebra scan engine.
03 Rev. A 10/2021 Update GMS Restricted section.
2
Contents
Copyright ........................................................................................................................................... 2
Terms of Use .................................................................................................................................... 2
Revision History ................................................................................................................................ 2
About the Tablet .................................................................................................................................... 8
Introduction to the L10 Tablet ........................................................................................................... 8
L10 Configurations ............................................................................................................................ 8
Key Features Overview ..................................................................................................................... 8
Optional Features ............................................................................................................................. 9
Software Versions ............................................................................................................................. 9
Chapter Descriptions ...................................................................................................................... 10
Notational Conventions ................................................................................................................... 10
Related Documents and Software .................................................................................................. 10
Service Information ......................................................................................................................... 11
Getting Started .................................................................................................................................... 12
Introduction ..................................................................................................................................... 12
Unpacking the Tablet ...................................................................................................................... 12
Overview of the XSLATE Tablet ..................................................................................................... 13
Front of the XSLATE L10 .......................................................................................................... 13
Overview of the XPAD L10 Tablet .................................................................................................. 17
Front of the XPAD L10 .............................................................................................................. 17
Back of the XPAD L10 .............................................................................................................. 18
Left Side of the XPAD L10 ........................................................................................................ 19
Top Side of the XPAD L10 ........................................................................................................ 20
Preparing the L10 Tablet for First Use ............................................................................................ 21
Inserting a SIM Card ................................................................................................................. 21
Powering Up the Tablet ............................................................................................................. 22
Pens for the L10 Tablets ................................................................................................................. 23
Capacitive Pens ........................................................................................................................ 23
Active Digitizer Pens ................................................................................................................. 23
Optional Setup Tasks ...................................................................................................................... 23
Attaching the Pen Tether .......................................................................................................... 23
Connecting the Tablet to an External Monitor ........................................................................... 24
Battery Management ....................................................................................................................... 24
Monitoring Battery Usage .......................................................................................................... 24
1
Table of Contents
Low Battery Notification ............................................................................................................ 25
Battery Optimization .................................................................................................................. 26
Back of Battery Charge Indicators ...................................................................................... 26
Removing and Replacing the Battery ........................................................................................ 27
Removing the Battery .......................................................................................................... 27
Replacing the Battery .......................................................................................................... 27
Hot Swapping the Battery ................................................................................................... 28
Using the Device ................................................................................................................................. 29
Introduction ..................................................................................................................................... 29
Google Mobile Services .................................................................................................................. 29
Home Screen .................................................................................................................................. 30
Status Bar ................................................................................................................................. 31
Status Icons ........................................................................................................................ 31
Notification Icons ....................................................................................................................... 32
Managing Notifications .................................................................................................................... 33
Quick Settings ................................................................................................................................. 34
Application Shortcuts and Widgets ................................................................................................. 35
Adding an Application or Widget to the Home Screen .............................................................. 35
Moving Items on the Home Screen ........................................................................................... 35
Removing an App or Widget from the Home Screen ................................................................ 35
Folders ...................................................................................................................................... 35
Using the Touchscreen ................................................................................................................... 35
Setting Screen Rotation ............................................................................................................ 36
Using the On-screen Keyboard ................................................................................................. 36
Editing Text ......................................................................................................................... 36
Entering Numbers, Symbols, and Special Characters ........................................................ 37
Using the Cameras ......................................................................................................................... 37
Front Camera ............................................................................................................................ 37
Rear Camera ............................................................................................................................. 37
Rear Camera Tips ............................................................................................................... 37
Using the Built-in Microphones ....................................................................................................... 38
Using the SD Card Reader ............................................................................................................. 38
Inserting a microSD Card .......................................................................................................... 38
Removing a microSD Card ....................................................................................................... 38
Using the XPAD Programmable Function Buttons ......................................................................... 39
Applications ..................................................................................................................................... 39
Accessing Applications ....................................................................................................... 42
Switching Between Recent Applications ............................................................................. 43
Unlocking the Screen ...................................................................................................................... 43
Suspend Mode ................................................................................................................................ 46
Restarting the L10 ........................................................................................................................... 47
Soft Reset ................................................................................................................................. 47
Hard Reset ................................................................................................................................ 47
Transferring Files with USB ............................................................................................................ 48
Transferring Files with a Host Computer by USB ..................................................................... 48
Transferring Files ...................................................................................................................... 48
Transferring Photos ................................................................................................................... 49
Disconnecting from the Host Computer .................................................................................... 50
2
Table of Contents
Applications ........................................................................................................................................ 51
Introduction ..................................................................................................................................... 51
Battery Manager ............................................................................................................................. 51
Contacts .......................................................................................................................................... 54
Adding a Contact ....................................................................................................................... 54
Editing Contacts .................................................................................................................... 54
Deleting ................................................................................................................................. 54
DataWedge Demonstration ............................................................................................................. 55
Files ................................................................................................................................................ 57
Device Central ................................................................................................................................ 58
Peripherals Tab ......................................................................................................................... 58
My Device ................................................................................................................................. 60
Paging an RS6000 Ring Scanner ............................................................................................. 60
Diagnostic Tool ............................................................................................................................... 60
Settings in the Diagnostic Tool .................................................................................................. 64
Battery Test Information ............................................................................................................ 65
GPS Test Information ................................................................................................................ 65
System Test Information ........................................................................................................... 66
WLAN Test Information ............................................................................................................. 66
WWAN Test Information ........................................................................................................... 66
Bluetooth Test Information ........................................................................................................ 66
Camera ........................................................................................................................................... 67
Camera Features ...................................................................................................................... 67
Taking a Photo .......................................................................................................................... 68
Taking a Panoramic Photo ........................................................................................................ 69
Recording a Video ..................................................................................................................... 70
Photo Settings ........................................................................................................................... 71
Front Camera ...................................................................................................................... 71
Rear Camera ....................................................................................................................... 71
Video Settings ........................................................................................................................... 72
Front Video Camera ............................................................................................................ 72
Rear Video Camera ............................................................................................................ 73
Photos ............................................................................................................................................. 73
PTT Express Voice Client ............................................................................................................... 74
PTT Audible Indicators .............................................................................................................. 74
Notification Icons ....................................................................................................................... 76
Enabling PTT Communication .................................................................................................. 76
PTT Communication ................................................................................................................. 77
Creating a Group Call ............................................................................................................... 77
Responding with a Private Response ....................................................................................... 77
Disabling PTT Express Voice Client Communication ............................................................... 77
Sound Recorder .............................................................................................................................. 78
Wireless ............................................................................................................................................... 79
Introduction ..................................................................................................................................... 79
Wireless Wide Area Networks ........................................................................................................ 79
Configuring the Access Point Name ......................................................................................... 79
Locking the SIM Card ................................................................................................................ 80
Monitoring Data Usage ............................................................................................................. 80
Turning on the Data Saver .................................................................................................. 80
3
Table of Contents
Setting Data Usage Warning ............................................................................................... 81
Setting a Data Limit ............................................................................................................. 83
Viewing Mobile Data Usage ................................................................................................ 85
Wireless Local Area Networks ........................................................................................................ 85
Scanning and Connecting to a Wi-Fi Network .......................................................................... 86
Removing a Wi-Fi Network ....................................................................................................... 87
Configuring a Wi-Fi Network ..................................................................................................... 87
Manually Adding a Wi-Fi Network ............................................................................................. 88
Configuring for a Proxy Server .................................................................................................. 89
Configuring the Device to Use a Static IP Address ................................................................... 90
Wi-Fi Preferences ..................................................................................................................... 90
Additional Wi-Fi Settings ........................................................................................................... 91
Wi-Fi Direct ............................................................................................................................... 91
WPS Pin Entry .......................................................................................................................... 92
WPS Push Button ..................................................................................................................... 92
Wi-Fi Advanced Features .......................................................................................................... 93
Zebra Mobility Extensions ......................................................................................................... 93
Bluetooth ......................................................................................................................................... 94
Adaptive Frequency Hopping .................................................................................................... 94
Bluetooth Security ..................................................................................................................... 95
Bluetooth Profiles ...................................................................................................................... 95
Bluetooth Power States ............................................................................................................. 96
Bluetooth Radio Power ............................................................................................................. 96
Enabling Bluetooth .............................................................................................................. 96
Disabling Bluetooth ............................................................................................................. 97
Discovering Bluetooth Device(s) ............................................................................................... 97
Changing the Bluetooth Name .................................................................................................. 98
Connecting to a Bluetooth Device ............................................................................................. 98
Selecting Profiles on the Bluetooth Device ......................................................................... 98
Unpairing a Bluetooth Device .................................................................................................... 99
Using the NFC Reader .................................................................................................................... 99
Data Capture ...................................................................................................................................... 100
Introduction ................................................................................................................................... 100
Devices for Data Capture ........................................................................................................ 100
Operational Modes .................................................................................................................. 100
Scanning Considerations .............................................................................................................. 101
Range ...................................................................................................................................... 101
Angle ....................................................................................................................................... 101
Imaging ................................................................................................................................... 101
Using the Barcode Scanner (XPAD Only) .................................................................................... 102
Barcode Symbologies ............................................................................................................. 103
RS507x Hands-Free Imager ......................................................................................................... 103
Barcode Capture Using the RS507x ....................................................................................... 104
Barcode Capture with the RS6000 Bluetooth Hands-free Scanner .............................................. 105
Barcode Capture with Zebra Scanner ........................................................................................... 106
Connecting a USB Scanner .......................................................................................................... 107
Connecting Using Simple Serial Interface ............................................................................... 107
Connecting Using HID Mode ................................................................................................... 108
Pairing the RS507x/RS6000 Hands-Free Scanners ..................................................................... 108
4
Table of Contents
Pairing Scanners by Using Simple Serial Interface (SSI) ....................................................... 108
Pairing Scanners by Using Human Interface Device (HID) ..................................................... 109
Pairing a DS3678 Scanner ........................................................................................................... 110
Pairing a DS3678 Scanner Using Simple Serial Interface (SSI) ............................................. 110
Pairing a DS3678 Scanner Using Human Interface Device (HID) .......................................... 111
DataWedge ................................................................................................................................... 111
Enabling DataWedge .............................................................................................................. 111
Disabling DataWedge ............................................................................................................. 111
Accessories ....................................................................................................................................... 112
Introduction ................................................................................................................................... 112
Docking Solutions ................................................................................................................... 112
Power ...................................................................................................................................... 113
Input Devices .......................................................................................................................... 114
Input Devices: Optional Modules ............................................................................................ 115
Carrying Accessories .............................................................................................................. 115
Display Maintenance ............................................................................................................... 117
Settings .............................................................................................................................................. 118
Introduction ................................................................................................................................... 118
Setting the Date and Time ............................................................................................................ 118
Display Setting .............................................................................................................................. 119
Setting the Screen Brightness ................................................................................................. 119
Setting Screen Timeout ........................................................................................................... 119
Setting Font Size ..................................................................................................................... 119
Setting Screen Rotation .......................................................................................................... 120
General Sound Setting ............................................................................................................ 120
Setting Screen Lock ...................................................................................................................... 122
Setting Screen Lock Using PIN ............................................................................................... 122
Setting Screen Unlock Using Password .................................................................................. 123
Setting Screen Unlock Using a Pattern ................................................................................... 124
Passwords ............................................................................................................................... 125
System Language Usage .............................................................................................................. 125
Adding Languages .................................................................................................................. 125
Selecting a Language ............................................................................................................. 126
Removing a Language ............................................................................................................ 126
Adding Words to the Dictionary ............................................................................................... 126
Virtual Keyboard Settings ............................................................................................................. 127
Enterprise Keyboard Configuration ......................................................................................... 127
Enabling Keyboards ................................................................................................................ 127
Configuring the Gboard Keyboard .......................................................................................... 127
Configuring the Enterprise Keyboard ...................................................................................... 127
Key Programmer ........................................................................................................................... 128
Remapping a Button ............................................................................................................... 128
About Phone ................................................................................................................................. 129
Application Deployment ................................................................................................................... 130
Introduction ................................................................................................................................... 130
5
Table of Contents
Security ......................................................................................................................................... 130
Secure Certificates ........................................................................................................................ 130
Installing a Secure Certificate ....................................................................................................... 130
Configuring Credential Storage Settings ................................................................................. 131
Development Tools ....................................................................................................................... 132
Android .................................................................................................................................... 132
Opening Developer Options .................................................................................................... 132
Enterprise Mobility Developer Kit for Android ......................................................................... 133
StageNow ................................................................................................................................ 133
GMS Restricted ............................................................................................................................. 133
ADB USB Setup ............................................................................................................................ 133
Enabling USB Debugging ............................................................................................................. 134
Application Installation .................................................................................................................. 134
Installing Applications Using a microSD Card ......................................................................... 134
Installing Applications Using the Android Debug Bridge (ADB) .............................................. 136
Uninstalling an Application ...................................................................................................... 136
Performing a System Update ........................................................................................................ 137
Downloading the System Update Package ............................................................................. 137
Using the microSD Card ......................................................................................................... 137
Using ADB ............................................................................................................................... 137
Verifying System Update Installation ...................................................................................... 138
Performing an Enterprise Reset .................................................................................................... 138
Downloading the Enterprise Reset Package ........................................................................... 139
Using a microSD Card ............................................................................................................ 139
Using ADB ............................................................................................................................... 139
Performing a Factory Reset .......................................................................................................... 140
Downloading the Factory Reset Package ............................................................................... 140
Using a microSD Card ............................................................................................................ 140
Using ADB ............................................................................................................................... 141
Storage ......................................................................................................................................... 141
Random Access Memory ........................................................................................................ 142
Internal Storage ....................................................................................................................... 142
External Storage ..................................................................................................................... 144
Formatting a microSD Card .................................................................................................... 144
Enterprise Folder ..................................................................................................................... 145
App Management .......................................................................................................................... 146
Viewing App Details ...................................................................................................................... 147
Managing Downloads ................................................................................................................... 147
Maintenance and Troubleshooting ................................................................................................. 148
Introduction ................................................................................................................................... 148
Maintaining the L10 ....................................................................................................................... 148
Operating the Tablet in Cold Ambient Temperatures ................................................................... 148
Battery Safety Guidelines ............................................................................................................. 149
Long-term Battery Storage ...................................................................................................... 149
Disposing of Used Batteries .................................................................................................... 149
Cleaning ........................................................................................................................................ 150
Materials Required for Cleaning .............................................................................................. 150
Cleaning the L10 ..................................................................................................................... 150
Housing ............................................................................................................................. 150
6
Table of Contents
Display .............................................................................................................................. 150
Power Connector .............................................................................................................. 150
Cleaning the Cradle Connector ............................................................................................... 150
Caring for the Display ................................................................................................................... 151
Caring for the Pen ......................................................................................................................... 151
Traveling with Your L10 Tablet ..................................................................................................... 152
Troubleshooting ............................................................................................................................ 153
Specifications .................................................................................................................................... 154
Technical Specifications ............................................................................................................... 154
Physical Characteristics ........................................................................................................ 154
Performance Characteristics ................................................................................................. 155
Data Capture ......................................................................................................................... 155
Ruggedness and Environment .............................................................................................. 155
Wireless Communications ..................................................................................................... 156
Sensors ................................................................................................................................. 156
Printers .................................................................................................................................. 157
Index ....................................................................................................................................................... 1
7
About the Tablet
Introduction to the L10 Tablet
This guide provides information about using the L10 tablet and accessories.
NOTE:
Screens and windows pictured in this guide are samples and can differ from actual screens.
L10 Configurations
There are three models in the L10 platform.
Each is different from the other two as follows:
• XPAD™ L10 is distinguished by its integrated hard handle.
The handle has space for an integrated barcode reader option, two programmable buttons,
and a front facing speaker.
• XSLATE™ L10 has no handle but is otherwise like the XPAD.
• XBOOK™ L10 is the same as the XSLATE, but includes a companion keyboard and a KickStrap
(combination of a kickstand and a hand strap).
IMPORTANT:
For all important safety information about your tablet, it is necessary to read the L10 Regulatory Guide.
Refer to
http://zebra.com/l10-info and navigate to the L10 User Documentation.
All Android features that are documented in this user guide are based on the interface of Android 8.1.0 Oreo.
Key Features Overview
The L10 platform is a rugged tablet that provides a range of computing power and a variety of integrated features
to support any mobile work flow. The L10 supports the following features:
• Qualcomm SDM660 Platform (CPU).
• 4 or 8 GB of system memory (RAM)
• 64 GB – 128 GB memory storage
• Adreno 512 graphics processor (GPU)
• 10.1” wide viewing angle display with WUXGA resolution (1920 x 1200); 500 Nit brightness standard,
option for 1000 Nit View Anywhere
®
display for viewing in bright sunlight.
8
About the Tablet
• Capacitive display with 10-point touch input
There are three touch modes in Settings > Display > Advanced > Touch panel mode:
• Finger and Wet
• Finger and Glove
• Finger and Passive Stylus (default)
• Corning Gorilla Glass 3 for increased display damage resistance;
Capacitive Touch Panel with Multi-Touch operation with optional Active Digitizer
• Integrated 13 MP rear camera and 5 MP front camera
• Two USB 2.0 Type A ports, one USB Type-C port, and a microSD card slot
• Dual Nano SIM (4FF) port
• 9-Axis MEMS sensor (Accelerometer, eCompass, Gyroscope) and ambient light sensor
• Hot-swappable battery, 36 Whr standard battery or 98 Whr long-life battery packs
• Integrated 802.11a/g/n/ac, MuMIMO Wi-Fi, Bluetooth 5.0
• Android 8.1.0 Oreo operating system
• Integrated high-frequency NFC
Optional Features
The following features are optional and must be ordered with the tablet at the time of purchase:
• A high-performance barcode scanner is available and is integrated into the handle of the XPAD L10 tablet.
• Integrated, active Wacom-digitizer display that provides precision pen input and hover features
See also Input Devices: Optional Modules on page 115. The items in that section must be ordered at time of
purchase because they must be factory installed.
Software Versions
To determine the current software versions:
1. Swipe down from the Status bar to open the Quick Settings bar.
2. Touch > System > About phone.
3. Scroll to view the following information:
• Model
• Android version
• Kernel version
• Build number
To determine the device serial number:
1. Touch System > About phone > Status.
2. Note the Serial number.
9
Chapter Descriptions
Topics covered in this guide are as follows:
• Getting Started on page 12 provides information on getting the tablet up and running for the first time.
• Using the Device on page 29 explains how to use the tablet. This includes instructions for powering on and
resetting the tablet, entering and capturing data.
• Applications on page 51 provides information on using applications installed on the L10.
• Wireless on page 79
• Data Capture on page 100 explains how to capture data using the optional scanners.
• Accessories on page 112 describes the accessories available for the tablet.
• Settings on page 118 describes some basic settings for configuring the device.
• Application Deployment on page 130 describes Android procedures for including new security features,
how to package applications, and procedures for deploying applications on the device.
• Maintenance and Troubleshooting on page 148 includes instructions on cleaning and storing the tablet,
and provides troubleshooting solutions for potential problems during tablet operation.
• Specifications on page 154 includes a table listing the technical specifications for the tablet.
About the Tablet
explains how to perform Bluetooth functionality on the tablet.
Notational Conventions
The following conventions are used in this document:
• Tablet refers to any of the three L10 Android tablets.
• Bold text is used to highlight the following:
• Dialog box, window and screen names
• Drop-down list and list box names
• Check box and radio button names
• Icons on a screen
• Key names on a keypad
• Button names on a screen.
• Bullets (•) indicate:
• Action items
• Lists of alternatives
• Lists of required steps that are not necessarily sequential.
• Sequential lists (step-by-step procedures) appear as numbered lists.
Related Documents and Software
The following documents provide more information about the L10 tablets.
• L10 Quick Reference Guide, p/n MN-003429-xx
• RS507x Hands-free Imager Product Reference Guide, p/n 72E-120802-xx
For the latest version of this guide and all guides, go to: z
ebra.com/support.
10
Service Information
If you have a problem with your equipment, contact Zebra Global Customer Support for your region. Contact
information is available at: z
When contacting support, please have the following information available:
• Serial number of the unit
• Model number or product name
• Software type and version number.
About the Tablet
ebra.com/support.
Zebra support responds to calls by email, telephone,
If your problem cannot be solved by Zebra Customer Support, you might need to return your equipment for
servicing and will be given specific directions. Zebra is not responsible for any damages incurred during shipment if
the approved shipping container is not used. Shipping the units improperly can possibly void the warranty.
If you purchased your Zebra business product from a Zebra business partner, contact that business partner for
support.
or fax within the time limits set forth in support agreements.
11
Getting Started
Introduction
This chapter explains how to set up the Zebra®L10 device for the first time.
Unpacking the Tablet
Carefully remove all protective material from around the L10 and save the shipping container for later storage and
shipping.
Verify that you received all equipment listed below:
• Tablet with lithium-ion battery
• Regulatory Guide.
• Stylus
• Power supply
Inspect the equipment for damage. If you are missing any equipment or if you find any damaged equipment,
contact the Zebra Support Center immediately. See Service Information on page 11 for support information.
IMPORTANT:
touch Tablets > L10 Series Tablets > Warranty Information.
For warranty information, refer to the web site, zebra.com/support. Under Support and Downloads,
12
Getting Started
Overview of the XSLATE Tablet
The following photos show the location of the external features on the XSLATE™ L10 tablet. Most of these features
are on the XPAD™ tablet in the same place, except for the handle of the XPAD tablet.
Front of the XSLATE L10
Figure 1 XSLATE Android Front Side
2 3
1 1
4
5
6
7
8
Table 1 XSLATE Front Features
Item Description
1 Two digital microphones make up the microphone array facing forward
2 The ambient light sensor (ALS) detects the amount of ambient light, and the device adjusts the
screen brightness
3 The front 5-megapixel camera has FHD resolution if enabled in the settings. You can adjust size and
quality of picture.
4 The Power LED indicates the current power state of the tablet
5 The Battery LED indicates the charging status of the battery.
6 The Reset switch lets you force the tablet to power down.
7 The touchscreen is the standard means for interacting with the operating system and software.
8 The Home button displays the Home screen.
13
Figure 2 XSLATE Back Side
Getting Started
1
2 3 4 5
6
7
89
Table 2 XSLATE Back Features
Item Description
1 The pen holder holds the short, capacitive pen when not in use.
2 The battery latch releases the battery when you slide the latch to the left.
3 This light is a flash for the rear camera and can be used as a flashlight.
4 The rear 13-megapixel camera has Full HD resolution.
5 The Kensington lock slot is a metal-reinforced hole for use with a cable and lock to secure the tablet.
6 Near Field Communication (NFC) allows devices to exchange information by placing them next to
one another.
7 The expansion port cover is removed when connecting certain optional accessories to the tablet.
8 This speaker provides sound when no headset or external speakers are in use.
9 The battery powers the tablet when it is not plugged in or docked.
14
Getting Started
Figure 3 Right Side of the XSLATE L10
Table 3 Right Side Features
Item Description
1 Power input connection for the external power adapter
2 Ethernet jack RJ45 port for LAN connectivity
3 Volume control button
4 The round button is a toggle between screen-rotation lock and auto-rotation of the screen.
5 The oval Power button turns on the tablet. When the tablet is on, press to enter and exit sleep mode.
2 3 4 51
Figure 4 Left Side of the XSLATE L10
1 2
3 4
5
Table 4 Left Side Features
Item Description
1 The memory card slot reads and writes microSD cards.
2 The USB type-C port provides access to USB 3.1 and DisplayPort output through a type-C
connector.
3 Two USB 2.0 type-A ports let you connect devices such as a mouse, keyboard, or external storage.
4 The 3.5 mm audio jack supports stereo output for headset and mono input for an external
microphone.
5 This locking door covers the ports on the L10. When the tablet is shipped, the door is locked and the
latch shows green. Slide the lock to reveal red and open the door to access the ports. To secure the
door for travel or storage, close it firmly and slide the lock until the green appears.
15
Getting Started
Figure 5 Bottom S
Table 5 Docking Connectors
Item Description
1 The docking connectors interface to docks.
ide of XSLATE and XPAD Tablets
1
16
Getting Started
Overview of the XPAD L10 Tablet
The following photos show the locations of the external features on the XPAD™ L10 tablet. In these photos, most of
the features are the same on the XSLATE as on the XPAD. Most of the differences are in the handle.
Front of the XPAD L10
Figure 6 XPAD Front
3 4 5
2
1
Table 6 XPAD Front Features
6
1
7
8
9
10
11
Item Description
1 Two digital microphones make up the microphone array facing forward.
2 Programmable function buttons, P1 and P2.
3 The ambient light sensor (ALS) detects the amount of light, and adjusts the screen brightness.
4 Pen holder for the long pen, built in to the handle of the XPAD.
5 The 5-megapixel camera has Full HD resolution.
6 The built-in speaker provides sound when no headset or external speakers are in use.
7 The Power LED indicates the current power state of the tablet
8 The Battery LED indicates the charging status of the battery.
9 The Reset switch lets you force the tablet to shut down, in case nothing else works.
17
Getting Started
Table 6 XPAD Front Features (Continued)
Item Description
10 The touchscreen is the standard means for interacting with the operating system and software.
11 The Home button displays the Home screen.
Back of the XPAD L10
Figure 7 XPAD Back
1
8
7
32
4
5
6
Table 7 XPAD Back Features
Item Description
1 The tether post for a pen secures the pen to the tablet by a tether.
2 The camera light functions as a flash for the rear camera as well as a torch light.
3 The rear 13-megapixel camera has Full HD resolution.
4 The Kensington lock slot is a metal-reinforced hole for use with a cable and lock to secure the tablet.
18
Getting Started
Table 7 XPAD Back Features (Continued)
Item Description
5 Near Field Communication (NFC), is an optional technology that lets devices exchange information.
6 The expansion port cover is removed when connecting certain optional accessories to the tablet.
7 The hot-swappable battery powers the tablet when it is not plugged in or docked.
8 The battery latch releases the battery when you slide the latch to the left.
Left Side of the XPAD L10
Figure 8 XPAD Left Side
2 3 4 51
Table 8 Left Side Features
Item Description
1 The barcode scanner is the built-in optical interface for reading barcodes.
2 The memory card slot reads and writes microSD cards.
3 The USB type-C port provides access to USB 3.1 and DisplayPort output through a type-C
connector.
4 Two USB 2.0 ports (type-A) let you connect devices, such as a mouse, keyboard, or external
storage.
5 The 3.5 mm audio jack supports stereo output for headset and mono input for an external
microphone.
6 This locking door covers the ports on the L10. When the tablet is shipped, the door is locked and
shows green. Slide the lock to reveal red and open it.
6
19
Getting Started
Figure 9 Right Side of the XPAD L10
4 521 3
Table 9 Right Side Features
Item Description
1 Power input connection for the external power adapter
2 Ethernet jack RJ45 port for LAN connectivity
3 Volume control button
4 The round button is a toggle between screen-rotation lock and auto-rotation of the screen.
5 The oval Power button turns on the tablet. When the tablet is on, press to enter or exit sleep mode.
Top Side of the XPAD L10
Figure 10 XPAD Top Side
1 2
Table 10 XPAD Top Side
Item Description
1 Use the pen holder in the handle to hold the long pen when it is not in use
2 Press the scanner button to activate the barcode scanner (if installed).
20
Getting Started
Preparing the L10 Tablet for First Use
The following sections explain how to insert a SIM card and power up the tablet.
Inserting a SIM Card
IMPORTANT: Before you can connect to a mobile broadband network, you must have an active account with a cellular
network provider, and a SIM card in your tablet for mobile broadband access. This SIM card works like the SIM card in
your cell phone that connects you to a network provider.
The SIM card holder accommodates two Nano SIM (4FF) cards, for use with the mobile broadband option. If
inserting only one SIM card, place it in the holder labeled SIM1. If inserting two SIM cards, put the card for the
primary carrier in SIM1 and the card for the secondary carrier in SIM2.
1. Turn off the tablet.
2. If you have already put the battery in the tablet, remove it.
The SIM card(s) fit into a tray in the battery bay.
3. Find and gently remove the SIM holder tray so the slot is empty.
Figure 11 Two SIM Cards in Holder
Notched corners
Figure 12 SIM Card Slot with Holder
SIM card slot
with holder
4. Place the SIM card into the holder so that it is close to flush with the holder. Make sure that the SIM contacts
(gold) are facing down and the notched corner is on the right side as shown in this drawing and in the graphic
inside the battery bay of the tablet.
5. Carefully align the SIM holder with the opening of the SIM holder connector. Gently slide the SIM holder tray
into the connector until it stops.
6. Put the battery in the tablet. See Replacing the Battery on page 27.
21
Getting Started
Powering Up the Tablet
This section explains installing the battery, connecting the tablet to external power, and powering up the tablet.
1. If you have not yet inserted the battery, remove it from the packaging. On the back of the tablet, insert the
bottom of the battery into the bay. Tilt the tray as shown and press it down until it clicks securely into place.
Figure 13 Installing the Battery
Insert this end of the battery
first.
2. The external power has two parts: the part that plugs into the power source and the adapter with a cord that
plugs into your tablet. Join the two parts by plugging the power cord into the adapter to form one long cord.
3. To connect external power to the tablet, open the port door to expose the power adapter port. Plug the AC
adapter into this port on your tablet.
Figure 14 Power Adapter Port
Power adapter port
4. Plug the power cord into an outlet.
The battery charging indicator on the front of the L10 tablet blinks amber to indicate that the battery is charging.
It is solid green when fully charged
5. Press and release the oval Power button in the center of the right side of the tablet to turn it on.
Figure 15 Power Button
Power button
6. Keep the tablet on AC power until the battery is fully charged. However, you Do not have to wait until the tablet
is fully charged to turn it on. The L10 will charge while you use it.
22
Pens for the L10 Tablets
All L10 tablets support touch input with your finger. In addition, a pen or stylus is provided with your tablet, and is
compatible with the screen configuration that you order. Many people use a pen for more convenience or precision.
The pen is particularly effective for precise data entry and navigation.
The XSLATE and XBOOK tablets come with short pens that fit into the pen holder on these devices. The XPAD
tablet includes a longer, thicker pen. If you want a longer pen for the XSLATE or XBOOK tablet, a handle
accessory can be ordered with the longer pen.
Capacitive Pens
Getting Started
Capacitive pens work with the tablet’s touchscreen and are sometimes called
pen does not need a battery. The long capacitive pen uses a AAAA battery. These two pens do not require a pen
digitizer in the tablet. They work with the tablet’s touchscreen directly.
Figure 16 Capacitive Pens
Long Capacitive ePen w/batteryShort Capacitive Pen
passive
pens. The short capacitive
Active Digitizer Pens
If the tablet is ordered with an active Wacom digitizer built in to the screen, you will receive one of the two pens
pictured below. These Wacom-compatible pens allow for a large range of pressure sensitivity, tilt detection, and
hover capability. Hover lets you see where the pen is pointing before the tip touches the display. These pens are
frequently called active pens. These active pens use all three modes of the touch screen:
• Finger and Wet
• Finger and Glove
• Finger and Passive Stylus (default)
Figure 17 Digitizer Pens
Optional Setup Tasks
Attaching the Pen Tether
The pen comes with a tether so that you can attach it to your tablet to avoid misplacing it.
1. Slip one end of the tether through the hole at the end of the pen, and pull the pen through the loop until it is
tight.
2. Slip the other end of the tether through the attach point on the tablet, then pull the pen through the loop until it
is tight.
Long Active Digitizer PenShort Active Digitizer Pen
23
Getting Started
Connecting the Tablet to an External Monitor
There is no dedicated port for an external monitor on the L10 tablet. The tablet has a USB Type-C connector which
includes a DisplayPort output capability. You need a dongle that supports USB Type-C DisplayPort and converts it
to the port necessary to attach the external monitor, which can have one or more of the following ports: HDMI, DVI,
DisplayPort, or VGA.
For instance, to connect a monitor with an HDMI port to your tablet, you need a USB Type-C DisplayPort to HDMI
output dongle.
NOTE:
interface. Care must be taken to ensure the USB Type-C dongle specifically supports USB Type-C DisplayPort input.
Look for a dongle that states it is plug-n-play and that no software or drivers are required.
Some dongles use USB to Video conversion and these use software to enable the external display over USB
Battery Management
NOTE: Prior to checking the battery charge level, remove the device from any AC power source (cradle or cable).
1. To check the charge status of the main battery, touch and then touch System.
2. Touch About phone > Battery Information.
3. The Battery Manager displays details about the battery.
Alternately, swipe up from the bottom of the screen and touch to open the Battery Manager application.
Touch Advanced info.
Battery present status indicates if the battery is present and Battery level shows the battery charge (as a
percentage of fully charged). The battery percentage can also be viewed next to the battery icon on the Status bar
at the top of the screen, on the Quick Settings bar, and on the Quick Access panel. Swipe down with two fingers
from the status bar to open the Quick Access panel.
IMPORTANT:
In cold temperatures, see Operating the Tablet in Cold Ambient Temperatures on page 148.
Monitoring Battery Usage
The Battery screen provides battery charge details, power management options, and a list of apps that consume
the most battery power.
Use the power management options to extend battery life, or touch an app to display details about its power
consumption. Different apps display different information. Some apps include buttons that open screens with
settings to adjust power use. Use the DISABLE or FORCE STOP buttons to turn off apps that consume too much
power.
1. Swipe down from the Status bar to open the Quick Settings bar and then touch .
2. Touch Battery to display the Battery screen.
24
Figure 18 Battery Screen
Getting Started
Low Battery Notification
When the battery is low on power, the L10 tablet notifies you as follows:
• When the battery charge drops below 10%, the tablet displays a notice to connect the device to power. Put
another battery into the tablet or connect the device to a power source. Charge the battery using one of the
charging accessories.
• When the battery charge drops below 5%, the tablet displays a notice to connect the device to power.
Charge the battery using one of the charging accessories.
• When the battery charge drops below 3%, the device turns off. You must charge the battery using one of
the charging accessories.
NOTE:
vice might turn off earlier than a remaining charge of 5%.
Figure 19 Low Battery Notification
9% remaining
Under conditions of heavy load (scanning quickly and often, RF communication, and other functions.) the de-
25
Getting Started
Battery Optimization
When the battery is low and recharging is not possible, you can use the following battery saving tips:
• Disable DataWedge Launcher profile. See Disabling DataWedge on page 111
• Set the screen to turn off after a short period of disuse.
• Reduce screen brightness.
• Turn off all wireless functions when not in use.
• Turn off automatic syncing for Email, Calendar, Contacts, and other apps.
• Minimize use of apps that keep the device from suspending, such as music and video apps.
Back of Battery Charge Indicators
You can check the charge of a battery when it is out of the tablet by pressing the battery check button on the back
side.
IMPORTANT:
tablet running. If you need to remove it for a longer period, be sure to save your files. Then shut down or plug in to a
power source.
If you have a battery out of the tablet, you can check the charge by looking at the back side and pressing the button
to the left of the lights to view the charge level.
Figure 20 Battery Check Button
If you remove the battery while the tablet is running, you only have one minute to replace it to keep the
Battery charge indicators
Battery check button
The five lights on the back of the battery indicate the current level of charge—from one light (20% charged) to five
lights (100% charged).
26
Getting Started
Removing and Replacing the Battery
Before removing the battery, save your files and power off the tablet, or plug in the AC adapter and continue
working while the battery charges. However, if you are hot swapping the battery, you can do so while the tablet is
on and running only on battery power. See Hot Swapping the Battery on page 28.
Removing the Battery
To remove the battery:
1. Save files and shut down the tablet.
2. With the back of the tablet facing you, slide the battery latch to the left until the latch stays open and the battery
pops out slightly. A red is displayed instead of the green dot.
3. Insert your finger under the finger tab and pull to remove the battery from the battery compartment.
Figure 21 Battery Removal
21
Table 11 Battery Removal
Item Description
1 Sliding battery latch
2 Pull-out battery tab
Replacing the Battery
1. Place the tabbed end of the battery into the battery compartment as shown here.
2. Press the battery down until it snaps into place.
Figure 22 Battery Replacement
Insert this end of the
battery first.
27
Getting Started
Hot Swapping the Battery
Replacing a battery while the tablet is on is called hot swapping. You can hot swap a battery only if you have a
second, charged battery to replace it with.
IMPORTANT:
one minute, the tablet goes into Sleep mode.
1. Remove the battery.
2. Insert the new battery.
While hot swapping the battery, notice the following behaviors:
• The tablet display gets dimmer. When the charged battery is in the tablet, the display brightens again.
• The battery status LED turns blue when the system is on and no main battery is present. When you put a
charged battery in the tablet, the LED lights turn green again.
• The power button is disabled. (The power button is disabled at any time the tablet has no battery and is not
running on AC power through the power adapter.)
You have approximately one minute to hot swap the battery. If you have not replaced the battery within
28
Using the Device
Introduction
This chapter describes the screens, status, notification icons, and controls on the tablet, and provides basic
instructions for using the Zebra L10 tablet.
Google Mobile Services
NOTE: This section only applies to L10 configurations with Google™ Mobile Services (GMS).
The L10 tablet with GMS contains applications and services that provide additional functionality to the tablet. GMS
includes:
• Applications – GMS adds a variety of Google™ applications and associated widgets including Chrome,
Gmail, Drive, and Maps.
• Services:
• Speech to Text – Allows for free format speech to text, in many languages for both connected and
disconnected network. Launch by touching the microphone icon on the keyboard.
• TalkBack Service – Provides spoken feedback on many parts of the user interface. To enable this
spoken feedback, touch Settings > Accessibility.
• Network Location Provider – Adds a location provider, which uses mobile network tower information
and Wi-Fi access point information to provide a location without using GPS.
To enable, go to Settings > Security & Location > Location.
• Widevine DRM – Enables the digital rights management so that protected content can be played.
Enable via DRM Info from the Play Store.
• Google Cloud Messaging – Lets you send data from your server to your tablet and also lets you
receive messages from devices on the same connection.
• Backup and Restore – Lets you back up your settings and applications to a Google server and then
restore them from that server after a factory reset.
29
Home Screen
If you need to unlock the tablet upon startup, See Unlocking the Screen on page 43.
The Home screen displays when the L10 starts up. Depending upon the configuration, the Home screen might
appear to be different. Contact your system administrator for more information.
After a suspend or screen time-out, the Lock screen displays. Slide up to unlock the screen if no security is set. For
screen locking information see Unlocking the Screen on page 43.
Figure 23 Home Screen
Using the Device
Widget
Status Bar
Home Recent App ButtonBack Button
NOTE:
The Home screen provides four additional screens for placement of widgets and shortcuts. Swipe the screen left or
right to view the additional screens.
You can configure the Home screen icons and the screen might look different than shown.
30
Using the Device
Status Bar
The Status bar displays the time, notification icons (left side) and status icons (right side).
If there are more notifications than can fit in the Status bar, displays indicating that more notifications exist. Open
the Notifications panel to view all notifications and status.
Status Icons
Table 12 Status Icons
Icon Description
Indicates that the Alarm is active.
Indicates that the ringer is silenced.
Indicates that the main battery is fully charged.
Indicates that the main battery is partially drained.
Indicates that the main battery charge is low.
Indicates that the main battery charge is very low.
Indicates that the main battery is charging.
All sounds, except media and alarms, are silenced and vibrate mode is active.
Do Not Disturb mode active.
Indicates that the Airplane Mode is active. All radios are turned off.
Indicates that Bluetooth is on.
The device is connected to a Bluetooth device.
Indicates the tablet is connected to a Wi-Fi network.
Not connected to a Wi-Fi network or no Wi-Fi signal.
Indicates that the tablet is connected to an Ethernet network.
Portable Wi-Fi hotspot is active.
Indicates that all sounds except media and alarms are silenced.
31
Using the Device
Table 12 Status Icons
Icon Description
Indicates that a Bluetooth headset is connected to the tablet.
Indicates that Do Not Disturb Alarm only or Priority only mode is enabled.
Indicates that Do Not Disturb Total Silence mode is enabled.
Connected to a 4G LTE/LTE-CA network.
Connected to a DC-HSPA, HSDPA, HSPA+, HSUPA, LTE/LTE-CA or WCMDMA network.
Connected to a WCDMA network.
Connected to a DC - HSPA, HSDPA, HSPA+ or HSUPA network.
Roaming from a network.
No SIM card installed.
Notification Icons
Table 13 Notification Icons
Icon Description
Indicates that more notifications are available for viewing.
Indicates that data is syncing.
Indicates an upcoming event.
Indicates that an open Wi-Fi network is available.
Indicates that a song is playing. (L10 with GMS).
Indicates that a problem with sign-in or sync has occurred.
Indicates that the tablet is uploading data.
Indicates that the tablet is downloading data when animated and download is complete when
static.
Indicates that the tablet is connected via USB cable.
Indicates that the tablet is connected to or disconnected from virtual private network (VPN).
32
Table 13 Notification Icons (Continued)
Icon Description
Preparing Internal Storage.
Indicates that USB debugging is enabled on the L10.
Indicates that a Expansion Pack is installed and in HID Mode.
Indicates that the RxLogger application is running and capturing data.
Indicates that the RS507x is connected to the L10.
Indicates that user attention is required.
Managing Notifications
Using the Device
Notification icons report the arrival of new messages, calendar events, and alarms, as well as ongoing events.
When a notification occurs, an icon may appear in the Status bar with a brief description. See Notification Icons on
page 32 for a list of possible notification icons and their description. Open the Notifications panel to view a list of all
the notifications.
To open the Notification panel, drag the Status bar down from the top of the screen.
Figure 24 Notification Panel
To respond to a notification, open the Notifications Panel and then touch a notification. The Notifications Panel
closes and the subsequent activity is dependent on the notification.
To clear all notifications, open the Notifications Panel and then touch CLEAR ALL. All event-based notifications
are removed.
Ongoing notifications remain in the list.
To close the Notification Panel, swipe the Notifications Panel up.
33
Quick Settings
Use the Quick Access panel to get to frequently used settings, like turning on Airplane mode. To open the Quick
Access panel, swipe down from the top of the screen with two fingers,
Figure 25 Quick Access Panel
Using the Device
or twice with one finger.
To change a setting, just touch the icon:
• Display brightness: Slide to lower or increase the brightness of the screen.
• Wi-Fi network: Turn Wi-Fi on or off. To open Wi-Fi settings, touch the Wi-Fi network name.
• Bluetooth settings: Turn Bluetooth on or off. To open Bluetooth settings, touch the Bluetooth.
• Do not disturb: Control how and when to receive notifications.
• Flashlight: Turn camera flash on and off.
• Battery saver: Turn on or off.
• Mobile data: Turn on or off.
• Airplane mode: Turn airplane mode on or off. Airplane mode means device will not connect to Wi-Fi or
Bluetooth.
• Cast: Displays tablet screen on another device.
• Night Light: Turns screen to night time frequency (to cut blue light frequency). Toggles between day and
night screen.
34
Using the Device
Application Shortcuts and Widgets
Application shortcuts placed on the Home screen allow quick and easy access to applications. Widgets are
self-contained applications placed on the Home screen to access frequently used features.
Adding an Application or Widget to the Home Screen
1. Go to the Home screen that displays your app.
2. Swipe right, if necessary, to find the application icon or widget.
3. Touch and hold the icon or widget until the Home screen appears.
4. Position the icon on the screen and then release.
Moving Items on the Home Screen
1. Touch and hold the item until it floats on the screen.
2. Drag the item to a new location. Pause at the edge of the screen to drag the item onto an adjacent Home
screen.
3. Lift finger to place the item on the Home screen.
Removing an App or Widget from the Home Screen
1. Go to the Home screen where the item resides.
2. Touch and hold the application shortcut or widget icon until it floats on the screen.
3. Drag the icon to X Remove at the top of the screen and then release.
Folders
Use Folders to organize similar applications together. Tap the folder to open and display items in the folder.
Using the Touchscreen
Use the multitap sensitive screen to operate the device.
• Touch – Use a finger to
• select items on the screen
• type letters and symbols using the on-screen keyboard
• press on-screen buttons
• Touch and Hold – Press and hold your finger on
• an item on the Home screen to move it to a new location or to the trash
• an item in Apps to create a shortcut on the Home screen
• the Home screen to open a menu for customizing the Home screen
• an empty area on the Home screen until the menu appears
• Drag – Touch and hold an item for a moment and then move your finger on the screen until reaching the
new position.Lift your finger to leave the icon in the new position.
35
Using the Device
• Swipe – Move finger up and down or left and right on the screen to:
• unlock the screen
• view additional Home screens
• view additional application icons in the Launcher window
• view more information on an application’s screen.
• Double-touch – Touch twice on a web page, map, or other screen to zoom in and out.
• Pinch – In some applications, zoom in and out by placing two fingers on the screen and pinching them
together (to zoom out) or spreading them apart (to zoom in).
• There are three touch modes in Settings > Display > Advanced > Touch panel mode:
• Finger and Wet
• Finger and Glove
• Finger and Passive Stylus (default)
The
act i ve pen works i n all t hree modes.
Setting Screen Rotation
By default, screen rotation is enabled. To disable screen rotation, follow this procedure:
1. On the Home screen, touch the Settings icon.
2. Touch Display > Advanced to view the Display menu.
3. Touch Auto-rotate screen to turn auto-rotate on or off.
You can also press the round button on the right side of the tablet to lock or unlock the automatic rotation of the
screen. See Table 3 on page 15.
4. Touch the Home button, , to return to the Home screen.
Using the On-screen Keyboard
Use the on-screen keyboard to enter text in a text field. To configure the keyboard settings, touch and hold the
comma key and select and then select Android Keyboard Settings.
Figure 26 On-screen Keyboard
Editing Text
Edit entered text and use menu commands to cut, copy, and paste text within or across applications. Some
applications do not support editing some or all of the text they display; others might offer a different way to select
text.
36
Entering Numbers, Symbols, and Special Characters
To enter numbers and symbols, experiment with these instructions:
• Touch and hold one of the top-row keys until a menu appears. Then select a number.
• Touch and hold the Shift key with one finger, touch one or more capital letters or symbols to enter them,
and then lift both fingers to return to the lowercase keyboard.
• Touch the Shift key twice to lock capital letters. Touch Shift again to return to the lowercase keyboard.
• Touch ?123 to switch to the numbers and symbols keyboard.
• Touch the =\< key on the numbers and symbols keyboard to view additional symbols.
• Touch the key to switch to the emoji keyboard.
To enter special characters, touch and hold a number or symbol key to open a menu of additional symbols. A
larger version of the key displays briefly over the keyboard.
Using the Cameras
The L10 tablet includes front and back cameras.
Using the Device
It is necessary to use an application to enable either of the cameras. Applications that record video or perform
video conferencing will recognize these cameras and enable them as required.
For details about the Camera application, see Camera on page 67 of the Applications chapter.
Front Camera
The front camera is a 5-megapixel camera that supports color images and streaming video. It’s on the front of the
tablet so it can be used for web-based audio/video communication, such as the Skype
®
application.
Rear Camera
Use the rear camera to take pictures or videos and save them to your hard drive. The rear camera is a
13-megapixel, autofocus camera. The camera lens is on the back of the tablet and includes a light to illuminate the
subject.
Rear Camera Tips
• Hold the camera steady and give it a few seconds to focus.
• If your pen is tethered, ensure that the tether is not in front of the camera lens.
• If a soft handle is attached, ensure it is being held away from the camera lens.
• Make sure you have adequate lighting to take your photo. If not, use the flash.
37
Using the Device
Using the Built-in Microphones
Use the built-in array microphones to record audio, dictate notes, and use voice commands. The two microphones
work together to optimize sound detection for speech recognition and voice recording. It is necessary to use an
application to enable the microphones. Applications that record video, sound or perform video conferencing
recognize these microphones and enable them.
By default, the device routes audio through the 3.5 mm jack when an audio device is plugged in to the audio jack
on the left side of the tablet.
Using the SD Card Reader
The L10 tablet includes a card slot for adding a microSD memory card. The memory card provides extra storage
for media files from your camera, videos, downloaded files, and data from other devices.
Figure 27 microSD Card Slot
microSD card slot
Inserting a microSD Card
1. Turn off the tablet.
2. Open the port cover of the left side of the tablet and locate the microSD card slot.
3. Push the SD card with the contacts facing down into the slot until it clicks into place.
4. Resume using the tablet.
Removing a microSD Card
1. Turn off the tablet.
2. Open the port cover.
3. Push the card in slightly until it pops out.
4. Close the port cover. Press the power button to turn on the tablet.
38
Using the Device
Using the XPAD Programmable Function Buttons
Use the programmable function buttons on the front of the XPAD L10 tablet to open files and to perform many
functions without having to use the pen. You can customize these buttons by modifying their functions.
Figure 28 Programmable Function Buttons
Button 1 Button 2
These two buttons have default functions as shown in this table.
Table 14 XPAD Programmable Buttons
Button Default Function
P1 Displays the Home screen.
P2 Displays the screen for accessing images (photos, screenshots), videos, and
You can customize these buttons to provide other functions. See Key Programmer on page 128.
Applications
The APPS screen displays icons for all installed applications. This table below lists the applications installed on the
L10 platform. Refer to the L10 Integrator Guide for information on installing and removing applications.
Table 15 Applications
Icon Description of Application
audio.
Battery Manager– Displays information about the battery, including charge level, time left before
empty, voltage, temperature, serial number, status, capacity, and wear level.
Bluetooth Pairing – Use to pair the RS507 Hans-free Imager with the L10 by scanning a bar
code.
Calculator – Provides the basic and scientific arithmetic functions.
Calendar – Use to manage events and appointments. L10 with GMS only.
39
Using the Device
Table 15 Applications
Icon Description of Application
Camera – Use to take photos and record videos. Use the camera application to control this
apparatus and to take advantage of camera features. For details about the Camera application,
see Camera on page 67 of the Applications chapter.
Chrome – Use to access the Internet or intranet. L10 with GMS only.
Clock – Use to schedule alarms for appointments or as a wake-up.
Contacts – Use to manage contact information.
DataWedge – Enables data capture using the imager.
Device Central– Displays detailed information about the L10 and connected peripherals.
Diagnostic Tool – Use to diagnose the device. See Diagnostic Tool on page 60 for more
information.
Drive – Upload photos, videos, documents, and other files to personal storage site. L10 with GMS
only.
DWDemo – Provides a way to demonstrate the data capture features using the imager. See
DataWedge Demonstration on page 55 for more information.
Duo – Makes high-quality video calls over Wi-Fi or Data connections.
Files – Organize and manage files on the L10. See Files on page 57 for more information.
Gmail – Use to send and receive email using a Google email account. L10 with GMS only.
Google – Launches Google search application. L10 with GMS only.
40
Using the Device
Table 15 Applications
Icon Description of Application
Keep Notes – Use to create, edit, view, and share notes. L10 with GMS only.
License Manager – Use to manage software licenses on the device, including sources and
notifications.
Maps – Use to see you location on a map (with public transit, traffic or satellite overlays). Search
for any business or place of interest. Provides turn-by-turn navigation with voice guidance and
traffic-avoidance and alternate routes, for drivers, cyclist, walkers and users of public
transportation. L10 with GMS only.
Messaging – Use to create, edit, view, and share notes. L10 with GMS only. WAN devices only.
Send SMS and MMS messages.
MSRN – Mobile Station Roaming Number (MSRN) is a telephone number temporarily assigned to
a mobile station which roams into another numbering area. Use to verify authenticity of a paired
device.
Phone – Use to dial a phone number when used with some Voice over IP (VoIP) clients
(VoIP telephony ready only). WAN devices only.
Photos – Use to sync photos with Google account. L10 with GMS only.
Play Movies & TV – View movies and video on your device. L10 with GMS only.
Play Music – Use to listen to music. L10 with GMS only.
Play Store – Download music, movies, books, and Android apps and games from the Google
Play™store L10 with GMS only.
PTT Express – Use to launch PTT Express client for VoIP communication.
RxLogger – Use to diagnose device and application issues. See the L10 Integrator Guide for more
information.
RxLoggerUtility – This utility is a data monitoring application for viewing logs in the device while
RxLogger is running. Access the logs and RxLogger Utility features in the App View or the Overlay
View.
41
Using the Device
Table 15 Applications
Icon Description of Application
Settings – Use to configure the tablet.
Sound Recorder – Use to record audio.
StageNow – Allows the L10 to stage a device for initial use by initiating the deployment of settings,
firmware and software.
WorryFree WiFi – Use to Use to diagnose surrounding area and display network stats, such as
coverage hole detection, or AP in vicinity. Refer to the Worry Free Wi-Fi Analyzer Administrator
Guide for Android.
YouTube – Use to view videos on the YouTube web site. L10 with GMS only.
Zebra Bluetooth – Use to configure Bluetooth logging.
Accessing Applications
All applications installed on the device are accessed using the APPS window.
1. Go to the Home screen, by touching the Home button. .
Figure 29 APPS Window
2. Slide the APPS window up and down to view more application icons. Touch an icon to open the application.
42
Using the Device
Switching Between Recent Applications
1. Touch at the bottom of the screen.
A window appears on the screen with icons of recently used applications.
Figure 30 Recently Used Applications
2. Slide the window up and down to view all recently used applications.
3. Swipe left or right to remove application from the list and force close the application.
4. Touch an icon to open it, or touch (at bottom of the screen) to return to the current screen.
Unlocking the Screen
Use the Lock screen to protect access to data on the L10. Some email accounts require locking the screen. To set
up the locking feature, see Setting Screen Lock on page 122.
When locked, a pattern, PIN or password is required to unlock the device. Press the Power button to lock the
screen. The device also locks after a predefined time-out.
1. Press and release the Power button to wake the device.
The Lock screen appears.
2. Swipe up to unlock the screen.
3. If the PIN, password, or pattern screen unlock feature is enabled, then enter the PIN, password, or pattern
after unlocking the screen.
43
Figure 31 Lock Screen
Using the Device
Figure 32 PIN Screen
Lock icon
44
Figure 33 Pattern Screen
Using the Device
Figure 34 Password Screen
45
Suspend Mode
The L10 goes into suspend mode when you press the Power button or after a period of inactivity (set in the Display
settings).
1. To wake the L10 from Suspend mode, press the Power button.
The Lock screen displays.
2. Swipe up to unlock the screen.
Using the Device
NOTE:
If the you forget the PIN, password, or pattern, contact the system administrator.
Figure 35 Lock Screen
If you enter the PIN, password, or pattern incorrectly five times, you must wait 30 seconds before trying again.
46
Restarting the L10
There are two reset features on the L10: Restart and a hard reset switch.
Soft Reset
Reboot the device if applications stop responding.
1. Press the Power button until a small menu appears.
Figure 36 Power Off or Restart Menu
Using the Device
2. Touch Restart.
The device restarts.
Hard Reset
If the L10 is not responsive, you can use the reset switch on the face of the tablet. See the photo of the reset switch
in Figure 38 on page 48. This switch turns the power off immediately.
CAUTIONPerforming a hard reset with a microSD card installed in the L10 can cause damage or data corruption to the
memory card, causing all data on the microSD card to be lost.
1. If you have a microSD card installed in the tablet, remove it before you use the reset switch.
To access the microSD card, open the port cover on the left side of the tablet and remove the microSD card.
This removal will preserve the data on the memory card.
Figure 37 microSD Card Slot
microSD Card Slot
2. Use the stylus tip on the tablet pen and insert it into the reset hole to press the recessed button until the tablet
shuts down. (You can also use a paper clip and unbend it to form a pin.)
47
Figure 38 Reset Switch on Front of Tablet
Hard Reset Button
3. Restart the tablet by pressing the Power button.
4. Return the microSD card to the slot in the tablet.
Transferring Files with USB
Using the Device
Transferring Files with a Host Computer by USB
Connect the device to a host computer using a USB cable to transfer files between the device and the host
computer.
When connecting the device to a host computer, follow the host computer’s instructions for connecting and
disconnecting USB devices, to avoid damaging or corrupting files.
Transferring Files
These steps show you how to use the Transfer files option to copy files between the device (internal memory or
microSD card) and the host computer.
1. Connect a USB cable to the tablet.
2. Swipe down from the Status Bar to display the Notification panel.
The panel displays a message.
Message
3. Touch the message: USB connect this device.
The Notification panel displays another message.
Message
48
Using the Device
4. Touch the message: Tap for more options.
The Use USB to dialog box appears. By default, None is selected.
Figure 39 Use USB to Dialog Box
Use to transfer between devices.
5. Touch Transfer files.
NOTE:
the USB cable is reconnected, select Transfer files again.
6. On the host computer, open a file explorer application.
7. Locate the device as a portable device.
8. Open the SD card or the Internal storage folder.
9. Copy files to and from the device or delete files as required.
After you change the setting to Transfer files, and then disconnect the USB cable, the setting reverts back. If
Transferring Photos
This section shows you how to transfer photos using Photo Transfer Protocol (PTP).
NOTE:
computer.
1. Connect USB cable to the device.
2. Swipe down from the Status Bar to display the Notification panel.
The panel displays a message.
3. Touch USB connect this device.
Use Photo Transfer Protocol to copy photos from either the microSD card or internal memory to the host
The notification panel displays Tap for more options.
4. Touch Tap for more options.
Message
Message
49
Using the Device
The Use USB dialog box appears. By default, None is selected.
Figure 40 Use USB Dialog Box
5. Touch Transfer photos (PTP).
6. On the host computer, open a file explorer application.
7. Open the SD card or the Internal storage folder.
8. Copy or delete photos as required.
Disconnecting from the Host Computer
To disconnect the device from the host computer:
CAUTION:
USB devices correctly to avoid losing information.
1. On the host computer, unmount the device.
2. Remove the USB cable from the device.
Carefully follow the host computer’s instructions to unmount the microSD card and disconnect
50
Applications
Introduction
This chapter describes these selected applications installed on the tablet:
• Battery Manager
• Contacts
• DWDemo
• Files
• Device Central
• Diagnostic Tool
• Using the Cameras
• Photos
• PTT Express Voice Client
• Sound Recorder
Battery Manager
The Battery Manager provides detailed information about the battery.
1. To open the Battery Manager, swipe up from the bottom of the Home screen and touch the Battery Manager
icon .
The icon in Battery Manager Screen on page 52 indicates the level of charge in the battery and the status of
charging.
51
Figure 41 Battery Manager Screen
Applications
2. Touch Advanced info to view more.
Table 16 Battery Icon Description
Battery
Icon
Battery charge level.
Battery charging.
Battery charge level is below 20%.
• Battery level – Shows the current battery charge level as a percentage. Displays -% when level is
unknown.
• Time until full – The amount of time until the battery is fully charged.
• Time since charging – The amount of time since the device began charging.
• Time until empty – The amount of time until the battery is empty.
• Battery status
• Not charging – The device is not .
• Charging over AC – The device is connected to AC power and charging.
• Discharging – That the battery is discharging.
• Full – That the battery is fully charged.
• Unknown – The battery status is unknown.
Description
52
Applications
• Battery health – The health of the battery. If a critical error occurs, an exclamation icon, , appears.
Touch to view the error description.
• Decommission – The battery is past its useful life and should be replaced. See system administrator.
• Good – The battery is good.
• Charge error – An error occurred while charging. See system administrator.
• Over Current – An over-current condition occurred. See system administrator.
• Dead – The battery has no charge. Replace the battery.
• Over Voltage – An over-voltage condition occurred. See system administrator.
• Below Temperature – The battery temperature is below the operating temperature. See system
administrator.
In cold temperatures, see Operating the Tablet in Cold Ambient Temperatures on page 148.
• Failure Detected – A failure has been detected in the battery. See system administrator.
• Unknown – See system administrator.
• Wear level – The health of the battery in graphical form. When the wear level exceeds 80%, the bar color
changes to red.
• Advanced info – Touch to view additional battery information.
• Battery present status – Indicates that the battery is present.
• Battery level – The battery charge level as a percentage of scale.
• Battery scale – The battery scale level used to determine battery level (100).
• Battery voltage – The current battery voltage in millivolts.
• Battery temperature – The current battery temperature in degrees Centigrade.
• Battery technology – The type of battery.
• Battery current – The average current into or out of the battery over the last second in mAh.
• Battery manufacture date – The date of manufacture.
• Battery serial number – The battery serial number. The number matches the serial number printed
on the battery label.
• Battery part number – The battery part number.
• Battery rated capacity – Lists the rated capacity of the backup battery in mAh.
• Battery decommission status – Indicates if the battery is past its life span.
• Battery Good – The battery is in good health.
• Decommissioned Battery – The battery is past its useful life and should be replaced.
• Base cumulative charge – Cumulative charge using Zebra charging equipment only.
• App version – The application version number.
53
Contacts
Use the Contacts app to manage contacts.
From a Home or Apps screen, touch Contacts to open to the main list of contacts.
Contacts are listed in alphabetical order. Swipe up or down to scroll through the list.
Adding a Contact
1. In the Contacts app, touch .
2. If there are multiple accounts in contacts, touch the one to use.
3. Type the contact’s name and other information. Touch a field to start typing, and swipe down to view all
categories.
4. To open a menu with preset labels, such as Home or Work for an email address, touch the label to the right of
the item of contact information. Or, to create your own label, touch Custom in the menu.
5. Touch the check mark next to Add New Contact.
Editing Contacts
Applications
1. In the Contacts app, touch a contact name to edit.
2. Touch .
3. Edit the contact information.
4. Touch SAVE.
Deleting
1. In the Contacts app, touch a contact name to delete.
2. Touch .
3. Touch Delete.
4. Touch DELETE to confirm.
54
DataWedge Demonstration
NOTE: DataWedge is on the Home screen. To this feature, go to the DataWedge settings and disable the
Launcher profile.
Use DataWedge Demonstration to demonstrate data capture functionality.
Figure 42 DataWedge Demonstration Window
Applications
Table 17 DataWedge Demonstration Icons
Icon Description
Illumination Imager illumination is on. Touch to turn illumination off.
Imager illumination is off. Touch to turn illumination on.
A is connected.
A is not connected.
55
Applications
Table 17 DataWedge Demonstration Icons (Continued)
Icon Description
Scan Mode Imager is in picklist mode. Touch to change to normal scan mode.
Imager is in normal scan mode. Touch to change to picklist mode.
Opens a menu to view the application information or to set the
application DataWedge profile.
1. Touch the Data Capture icon to select the data capture mode.
Figure 43 Data Capture Options Menu
2. Press the scanner trigger button or touch the on-screen yellow scan button to capture data. The data appears
in the text field below the yellow button.
56
Files
Applications
Use the Files app to view and manage files on the device.
To open Files, swipe up from the bottom of the screen and touch the Files icon .
Figure 44 Files Screen
Sort
1. Touch and hold an item to open the File Operations menu.
2. Select an option:
• – Share the file with other devices.
• – Delete the file.
• – View additional options.
• Open with – Select which app is used to open the file.
• Select all – Select all folders and files.
• Copy to... – Copy the file.
• Move to... – Move the file or folder to a new location.
• Compress – Compresses the selected file(s) into a ZIP file.
• Rename – Rename the file.
• Touch the Sort drop-down to sort files by name, type, size, or date.
• – View all file locations.
• – Search for a specific file on the device.
• / – Change the folder to display items as a list / grid.
• – Open the More options menu.
• New Window – Create a new Files window.
• New Folder – Create a new folder.
• Select all – Select all folders and files.
• Show/Hide internal storage – Show or hide internal storage.
57
Device Central
The Device Central application displays detailed information about the L10 and connected peripherals and
supports the following Zebra devices:
• RS6000 Bluetooth Ring Scanner
Device Central features include:
• Discovering and pairing with supported peripherals via Bluetooth or corded connection.
• Paging a connected RS6000 Ring Scanner.
• Updating the firmware of supported ring scanners. For information on updating ring scanner firmware
using Device Central and refer to the RS6000 User Guide.
• Displaying the connection status of peripherals.
• Displaying information for a connected peripheral in the notification bar.
Figure 45 Device Central Screen
Applications
Peripherals Tab
Displays all currently connected and previously connected peripherals. Connected peripherals display the length of
time (in minutes) that they have been connected. When an RS6000 is connected the Page button displays. See
Paging an RS6000 Ring Scanner on page 60.
1. Touch the peripheral information to display the Device Details screen.
The Device Details screen displays detailed device information for the selected peripheral.
58
Figure 46 Connected Peripherals
Applications
2. Touch the connected device icon to display details about the peripheral.
The Device Details screen appears.
Figure 47 Device Details
59
Applications
My Device
The My Device tab displays information about the L10 and the current version of Device Central.
• Device Name – displays the name assigned to the L10.
• Device Central Version – displays the Device Central application version number.
• Device Details – Opens the Phone status settings window.
• Device Battery Details – Open the Battery settings window.
Paging an RS6000 Ring Scanner
Use the Page button to easily locate the currently connected RS6000 Ring Scanner:
1. With the RS6000 Ring Scanner connected, swipe up from the bottom of the Home screen and touch the
Device Central icon .
NOTE: The RS6000 Ring Scanner must be within 10 m (32 ft) of the L10.
2. Under the RS6000 peripheral information, touch Page to begin paging the RS6000.
The paged RS6000 beeps and vibrates.
3. To stop paging, press the scan trigger of the RS6000. On a triggerless RS6000, stop paging by resetting it.
Diagnostic Tool
The Diagnostic Tool is a utility that determines the health of the L10. Use the Diagnostic Tool to troubleshoot the
device and determine issues.
By default, the Diagnostic Tool tests the system (device) and the battery subsystem. It can also run tests and
report status for other subsystems:
• GPS
• WLAN
• WWAN
• Bluetooth
1. Swipe up from the bottom of the Home screen and touch the Diagnostic Tool icon.
60
Figure 48 Diagnostic Tool
Applications
2. Touch RUN TEST.
The app tests all enabled subsystems.
NOTE: To view or run a subsystem test, you must touch RUN TEST and then touch SUBSYTEMS TESTS to see
the results of the subsystems.
See Settings in the Diagnostic Tool on page 64 to enable subsystem tests.
61
Figure 49 Test Passed Screen
Applications
Settings
Figure 50 Test Failed Screen
62
Applications
3. To view each individual subsystem test, touch Subsystem Tests.
The Subsystems screen displays all the subsystems and shows a check mark for tests that have
passed.
Figure 51 Subsystem Screen
Table 18 Subsystem Test Result Indicators
Status Icon Description
Indicates test passed.
Indicates test failed.
Indicates test not supported or not enabled.
63
Touch one of the subsystems to view details.
Figure 52 Battery Subsystem Details
Applications
Settings in the Diagnostic Tool
By default only the Battery and System tests are enabled as shown in Subsystem Screen on page 63. To enable
other tests in the Diagnostic Tool:
1. Touch > Settings in the Diagnostic Tool, as shown below, after running the test with the RUN TEST
command.
Settings
The Settings menu of the Diagnostic Tool appears.
64
Applications
2. To enable testing of the subsystems, touch to the left of the test name to select the tests.
A green box with a check mark appears.
3. Touch SAVE.
Touch Yes to confirm.
4. Touch .
5. Touch SUBSYSTEM TESTS again to see the results you checked.
Battery Test Information
The Battery Test obtains the following information:
• Battery Level – Current battery charge level
• Battery Voltage – Current battery voltage
• Status – Whether the battery is charging (on AC power) or discharging (on battery power)
• Power Source – Whether the device is receiving power from the battery or from an external source
• Temperature – Current battery temperature
• Health Percentage – Indicates the ratio of present capacity to design capacity at a discharge rate of
design capacity.
• Backup Battery Voltage – Backup battery voltage
• Manufacture Date – Manufacture date of the battery.
GPS Test Information
The GPS Test displays the following information:
• GPS Provider Enabled - Whether GPS is enabled (true) or disabled (false)
• Latitude - Current latitude position
• Longitude - Current longitude position
• Altitude - Current altitude in meters
• Bearing - Current bearing
• Speed - In meters per second
• Accuracy - GPS accuracy in meters.
65
Applications
System Test Information
Use the System Test to determine if the CPU or memory loads are too high, there are too many processes running
on the device, or that storage on the device is almost full. The System Test reports the following information:
• CPU Load – Indicates the amount of CPU being used.
• Free Physical Memory – Indicates the amount of RAM available.
• Free Storage – Indicates the amount of internal Flash memory available.
• Process Count – Indicates the number of processes currently running.
WLAN Test Information
If the Wi-Fi radio is not present or disabled the test may be skipped. Use this information to determine if the
device’s WLAN configuration is correct or whether there is any connection with an access point or network. The
WLAN Test reports the following information:
• WLAN Enabled – Indicates if the WLAN radio is enabled or disabled.
• WLAN Status – Indicates the current status of association with the access point.
• ESSID – Displays the name of the wireless network.
• BSSID – Displays the MAC address of the connected access point.
• MAC Address – Displays the device’s MAC address.
• Signal – Indicates the strength of the Wi-Fi signal (in dBm).
• IP Address – Displays the IP address of the device.
WWAN Test Information
The WWAN Test reports the following information:
• SIM State - Current state of the SIM card
• WAN Type - Data connection type
• Signal Strength - Current cellular signal strength
• Phone Number - Phone number assigned to the device
• Device ID - Device ID number.
Bluetooth Test Information
The Bluetooth Test reports the following information:
• Enabled – Indicates if the Bluetooth radio is enabled or disabled.
• Status – Indicates if the device is paired to another Bluetooth device.
• Connectable/Discoverable – Indicates if the device is discoverable or connectable.
• Address – Displays the Bluetooth radio MAC address.
• Name – Displays the Bluetooth name for the device.
66
Camera
The Camera application supports both the front and rear cameras. This section provides information for taking
photos and recording videos using the integrated digital cameras.
By default, the L10 tablet saves photos and videos on the internal storage. However, if a microSD memory card is
installed and the storage path is changed manually, then the tablet saves photos and videos on the microSD card.
NOTE: The native Google camera application is associated with a hidden DataWedge profile in which scanning is dis-
abled.
Camera Features
See Photo Settings for camera setting descriptions.
1. Swipe up from the bottom of the Home screen and touch the Camera app.
The camera app opens.
Figure 53 Basic Camera Features
Applications
1
2
3
4
5
Table 19 Camera Features
Item Description
1 Settings - Controls several features of the camera, including, flash, exposure, size, and quality.
6
7
8
2 High Dynamic Range (HDR) - Turns this range on or off. When on, HDR helps you capture greater
detail from bright and dark areas.
3 Switch between the front or rear camera.
4 Color Effect - Provides different filters and styles to a photo.
67
Applications
Table 19 Camera Features (Continued)
Item Description
5 Scene Mode - Select the type of scene and adjusts the camera to the scene.
6 Camera Mode - Switch the mode to Panoramic, Video, or Camera.
7 Shutter - Touch to take the picture.
8 Gallery - Provides access to the photos you have taken.
Taking a Photo
See Photo Settings for camera setting descriptions.
1. Swipe up from the bottom of the Home screen and touch the Camera app.
The camera app opens.
2. If necessary, touch the Camera Mode icon and touch .
3. To switch between the rear camera and front camera, touch the Camera Switch icon .
4. Frame the subject on the screen.
5. To zoom in or out, press two fingers on the display and pinch or expand fingers.
The zoom controls appear on the screen.
6. Touch an area on the screen to focus.
The focus circle appears. The two bars turn green when in focus.
Focus Circle
7. Touch the Shutter Button .
The camera takes a photo and a shutter sound plays.
The photo momentarily displays as a thumbnail in the lower right corner.
68
Applications
Taking a Panoramic Photo
Panorama mode creates a single wide image by panning slowly across a scene.
1. Swipe up from the bottom of the Home screen and touch Camera.
Figure 54 Panoramic Mode
2. Touch the Camera Mode icon and touch the Panoramic Mode icon.
3. Frame one side of the scene to capture.
4. Touch and slowly pan across the area to capture.
A small green square appears inside the button indicating the capture is in progress.
If you are panning too quickly, the message Too fast appears.
5. Touch the Shutter Button to end the shot.
The panorama appears immediately and a progress indicator displays while it saves the image.
69
Applications
Recording a Video
1. Swipe up from the bottom of the Home screen and touch the Camera app .
2. Touch the camera mode menu and touch the Video icon .
3. To switch between the rear camera and front camera (if available), touch the Camera Switch .
4. Point the camera and frame the scene.
5. To zoom in or out, press two fingers on the display and pinch or expand fingers.
The zoom controls appear on the screen.
6. Touch to start recording.
The video time remaining appears in the top left of the screen.
7. Touch to the end recording.
The video momentarily displays as a thumbnail in the lower left corner.
Figure 55 Video Mode
1
2
3
4
Table 20 Video Features
Item Description
1 Settings - Controls several features of the video camera, including, flash, quality, stabilization, and
white balance.
5
6
7
2 Audio - Records sound or turns it off.
3 Switch between the front or the rear camera.
4 Color Effect - Provides different filters and styles to a video.
5 Camera Mode - Switches the mode to Panoramic, Video, or Camera.
6 Shutter - Starts and stops the video.
7 Gallery - Provides access to the photos you have taken.
70
Applications
Photo Settings
In Photo mode, photo settings appear on screen. Touch to display the photo settings options.
Front Camera
• Selfie Flash - Turns screen white to help produce a little extra light in dimmer settings. Options: Off (default), or
On.
• GPS location - Add GPS location information to the photo meta-data. Options: On or Off (default).
• Picture size - Set the size (in pixels) of the photo to: 5M pixels (default), 3M pixels, HD1080, 2M pixels,
HD720, 1M pixels, WVGA, VGA, or QVGA.
• Picture quality - Set picture quality setting to: Low, Standard (default), or High.
• Countdown timer - Set to: Off (default), 2 seconds, 5 seconds or 10 seconds.
• Storage – Set location to store the photo to: Phone or SD Card.
• Face Detection - Select to turn face detection Off (default) or On.
• ISO - Set how sensitive the camera is to light. Options: Auto (default), ISO Auto (HJR), ISO100, ISO200,
ISO400, ISO800 or ISO1600.
• Exposure - Touch to adjust the exposure settings. Options: +2, +1, 0 (default), -1 or -2.
• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most
natural-looking colors:
• Incandescent - Adjust the white balance for incandescent lighting.
• Fluorescent - Adjust the white balance for florescent lighting.
• Auto - Adjust the white balance automatically (default).
• Daylight - Adjust the white balance for daylight.
• Cloudy - Adjust the white balance for a cloudy environment.
• Redeye reduction - Helps eliminate redeye effect. Options: Disabled (default), or Enable.
• ZSL - Set the camera to immediately take a picture when the button is pressed (default – enabled)
• Selfie Mirror - Options: Disable (default), or Enable.
• Shutter Sound - Select to play a shutter sound when taking a photo. Options: Disable (default) or Enable.
• Anti Banding - Allows the camera to avoid problems caused by artificial light sources that are not constant.
These sources cycle (flicker) fast enough to go unnoticed to the human eye, appearing continuous. The
camera’s eye (its sensor) can still see this flicker. Options: Auto (default), 60 Hz, 50 Hz, or Off.
Rear Camera
• Flash - Select whether the camera relies on its light meter to decide whether a flash is necessary, or to turn it
on or off for all shots.
• Off - Disable flash.
• Auto - Adjust flash automatically depending upon light meter (default).
• On - Enable flash upon taking a photo.
• GPS location - Turn On or Off (default).
• Picture size - The size (in pixels) of the photo to: 13M pixels (default), 8M pixels (default), 5M pixels, 3M
pixels, HD 1080, 2M pixels, WXGA, HD720, 1M pixels, WVGA, VGA, or QVGA.
• Picture quality - Set the picture quality setting to: Low, Standard (default) or High.
71
Applications
• Countdown timer - Select Off (default), 2 seconds, 5 seconds or 10 seconds.
• Storage – Set the location to store the photo to: Phone or SD Card.
• Face Detection - Select to turn face detection Off (default) or On.
• ISO - Set camera sensitivity to light to: Auto (default), ISO Auto (HJR), ISO100, ISO200, ISO400, ISO800 or
ISO1600.
• Exposure - Set the exposure settings to: +2, +1, 0(default), -1 or -2.
• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most
natural-looking colors:
• Incandescent - Adjust the white balance for incandescent lighting.
• Fluorescent - Adjust the white balance for florescent lighting.
• Auto - Adjust the white balance automatically (default).
• Daylight - Adjust the white balance for daylight.
• Cloudy - Adjust the white balance for a cloudy environment.
• Chroma Flash - Sets the camera to take two pictures, one with flash and one without flash. The two images are
combined to produce a final image with the sharpness and clarity and bright color tones from a picture with the
flash, coupled with the natural colors of a picture without a flash. Options: Off (default) or On.
• Redeye reduction - Helps eliminate redeye effect. Options: Disabled (default), or Enable.
• ZSL - Set the camera to immediately take a picture when the button is pressed (default – enabled).
• Shutter Sound - Select to play a shutter sound when taking a photo. Options: Disable (default) or Enable.
• Anti Banding - Allows the camera to avoid problems caused by artificial light sources that are not constant.
These sources cycle (flicker) fast enough to go unnoticed to the human eye, appearing continuous. The
camera’s eye (its sensor) can still see this flicker. Options: Auto (default), 60 Hz, 50 Hz, or Off.
Video Settings
In Video mode, video settings appear on screen. Touch to display the video settings options.
Front Video Camera
• Video quality - Set video quality to: HD 1080, HD 720, SD 480p, VGA, CIF, or QVGA.
• Video duration - Set to: 30 seconds (MMS) or 30 minutes (default).
• GPS location - Turn On or Off (default).
• Storage – Set the location to store the photo to: Phone (default) or SD Card.
• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most
natural-looking colors.
• Incandescent - Adjust the white balance for incandescent lighting.
• Fluorescent - Adjust the white balance for florescent lighting.
• Auto - Adjust the white balance automatically (default).
• Daylight - Adjust the white balance for daylight.
• Cloudy - Adjust the white balance for a cloudy environment.
• Image Stabilization - Set to reduce blurry videos due to device movement. Options: On or Off (default).
72
Applications
Rear Video Camera
• Flash - Provides a steady light for recording video or not. Select whether Rear-facing Camera relies on its light
meter to decide whether a light is necessary, or to turn it on or off for all shots.
• Off - Disable flash (default).
• On - Enable flash (a steady light).
• Video quality - Set video quality to: 4k DCI, 4k UHD, HD 1080p (default), HD 720p, SD 480p, VGA, CIF, or
QVGA.
• Video duration - Set to: 30 seconds (MMS), or 30 minutes (default).
• GPS location - Turn On or Off (default).
• Storage – Set the location to store the photo to: Phone (default) or SD Card.
• White balance - Select how the camera adjusts colors in different kinds of light, to achieve the most
natural-looking colors.
• Incandescent - Adjust the white balance for incandescent lighting.
• Fluorescent - Adjust the white balance for florescent lighting.
• Auto - Adjust the white balance automatically (default).
• Image Stabilization - Set to reduce blurry videos due to device movement. Options: On or Off (default).
Photos
The Photos application supports the following:
Available on device with GMS software only.
Use the Photos app to:
• Daylight - Adjust the white balance for daylight.
• Cloudy - Adjust the white balance for a cloudy environment.
• Image formats: jpeg, gif, png, and bmp.
• Video formats: H.263, H.264 and MPEG4 Simple Profile.
• View photos
• Play videos
• Perform basic editing of photos
• Set photos as wallpaper
• Set photos as a contact photo
• Share photos and videos
The Photos app displays all photos and videos stored on internal memory.
1. To open the Photos application, swipe up from the bottom of the Home screen and touch .
By default, the Photos app opens to the Photos view.
73
Figure 56 Photos View
Applications
2. Touch Albums to view photos sorted by albums.
PTT Express Voice Client
PTT Express Voice Client creates Push-To-Talk (PTT) communication capability between disparate enterprise
devices. Leveraging existing Wireless Local Area Network (WLAN) infrastructure, PTT Express delivers simple
PTT communication without the need of a voice communication server.
• Group Call: Press and hold the Talk button to start communicating with other voice client users.
• Private Response: Double-press and the Talk button to respond to the originator of the last broadcast or
to make a Private Response.
Refer to the PTT Express User Guide at z
application.
PTT Audible Indicators
The following tones provide helpful cues when using the voice client.
• Talk Tone: Double chirp. Plays when the Talk button is depressed. This is a prompt for the user to start
talking.
• Access Tone: Single beep. Plays when another user just finished a broadcast or response. The user is
now able to initiate a Group Broadcast or Private Response.
ebra.com/support for information on configuring the PTT Express Client
74
Applications
• Busy Tone: Continuous tone. Plays when the Talk button is depressed and another user is already
communicating on the same talk group. Plays after the maximum allowed talk time is reached (60
seconds).
• Network Tone:
• Three increasing pitch beeps. Plays when PTT Express has acquired the WLAN connection and the
service is enabled.
• Three decreasing pitch beeps. Plays when PTT Express has lost the WLAN connection or the service
is disabled.
Figure 57 PTT Express Default User Interface
Notification Icons
Settings
Service Indication
Talk Groups
Enable/Disable Switch
Table 21 PTT Express Default User Interface Descriptions
Item Description
Notification Icon Indicates the current state of the PTT Express client.
Service Indication Indicates the status of the PTT Express client. Options: Service Enabled, Service
Disabled or Service Unavailable.
Talk Groups Lists all 32 Talk Groups available for PTT communication.
Settings Opens the PTT Express Settings screen.
Enable/Disable Switch Turns the PTT service on and off.
75
Applications
Notification Icons
Indicates the current state of the PTT Express Voice client.
Table 22 PTT Express Default User Interface Descriptions
Status Icon Description
Indicates that PTT Express Voice client is disabled.
Indicates that PTT Express Voice client is enabled but not connected to a WLAN.
Indicates that PTT Express Voice client is enabled, connected to a WLAN and listening on the
Talk Group indicated by the number next to the icon.
Indicates that PTT Express Voice client is enabled, connected to a WLAN and communicating
on the Talk Group indicated by the number next to the icon.
Indicates that PTT Express Voice client is enabled, connected to a WLAN and in a private
response.
Indicates that PTT Express Voice client is enabled and muted.
Indicates that the PTT Express Voice client is enabled but it is not able to communicate due to
a VoIP telephony call is in progress.
Enabling PTT Communication
1. Swipe up from the bottom of the Home screen and touch .
The PTT Express Screen appears.
2. Slide the Enable/Disable Switch to the ON position.
The button changes to an ON button. See Figure 58.
You can select one of 32 Talk Groups with the PTT Express app. However, only one talk group can be used at
a time on the device.
3. Touch one of the 32 Talk Groups.
The selected Talk Group is highlighted.
Figure 58 PTT Express Screen
76
Applications
PTT Communication
This section describes the default PTT Express client configuration. See the PTT Express V1.2 User Guide for
detailed information on using the client.
NOTE: To display the on-screen buttons, configure the PPT Express app according to the PTT Express User Guide.
Creating a Group Call
1. Press and hold the on-screen Group Call button to start communicating with other voice client users.
2. If you hear a double-chirp talk tone when the Group Call button is depressed, you can start talking.
3. If you hear a busy tone, release the button and wait a moment before making another attempt. Ensure that
PTT Express and the WLAN are enabled.
4. Start talking after the double-chirp tone is heard.
5. Release the button when finished talking.
NOTE: The busy tone is a continuous sound that plays when the Group Call button is depressed and another user is
already communicating on the same talk group. This tone also plays after the maximum allowed talk time is reached
(60 seconds).
Responding with a Private Response
The Private Response can only be initiated once a Group Call has been established. The initial Private Response
is made to the originator of the Group Call.
1. Press and hold the on-screen Private Response button to respond to the originator of the last broadcast or to
make a Private Response.
2. Wait until an access tone is heard.
3. Within 10 seconds, press and hold the Private Response button, and listen for the talk tone to play.
4. If a busy tone is heard, release the button and wait a moment before making another attempt. Ensure that PTT
Express and the WLAN are enabled.
5. Start talking after the talk tone plays.
6. Release the button when finished talking.
NOTE: If you hold the button for more than 60 seconds (default), the call is dropped allowing others to make Group calls.
Release the button when finished talking to allow others to make calls.
Disabling PTT Express Voice Client Communication
1. Swipe up from the bottom of the Home screen and touch .
2. Slide the Enable/Disable Switch to the OFF position.
The button changes to OFF.
3. Touch .
77
Sound Recorder
Use Sound Recorder to record audio messages.
Recordings are saved on the microSD card (if installed) or the internal storage and are available in the Music
application (non-GMS devices) or the Play Music application (GMS devices).
Figure 59 Sound Recorder Application
Applications
Options menu
Touch to open options menu.
• File type – Select the file type for the recording file.
• AMR
• 3GPP
• AAC
• WAV
• AMR-WB
• AMR-WB-3GPP.
• Storage location – Select the location for the recording file.
• Phone storage
• SD card.
78
Wireless
Introduction
This section provides information on the wireless features:
• Wireless Wide Area Network (WWAN)
• Wireless Local Area Network (WLAN)
• Bluetooth technology
• Near Field Communication.
Wireless Wide Area Networks
Use wireless wide area networks (WWANs) to access data over a cellular network. This section provides
information on the following topics:
• Configuring Access Point Names (APN)
• Locking a SIM card
• Monitoring data usage
Configuring the Access Point Name
NOTE: The service provider preconfigures many Access Point Name (APN) data in the device. The APN information for
all other service providers must be obtained from the wireless service provider.
The Access Point Name (APN) is the name for the settings your phone reads to set up a connection to the gateway
between your carrier's cellular network and the public Internet.
To use the data on a network, configure the APN information. Follow the steps in this procedure:
1. Swipe down with two fingers from the status bar to open the quick access panel and touch
the Settings button.
2. Touch Network & Internet > Mobile network > Advanced.
3. Touch Access Point Names.
4. Touch an APN name in the list to edit an existing APN or touch to create a new APN.
5. Touch each APN setting and enter the appropriate data obtained from the wireless service provider.
6. When finished, touch in the upper right corner and touch Save.
7. Touch the radio button next to the APN name to start using it.
8. Touch .
79
Wireless
Locking the SIM Card
Locking the SIM card requires the user to enter a PIN every time the device is turned on. If the correct PIN is not
entered, only emergency calls can be made.
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Security & location.
3. Touch SIM card lock.
4. Touch Lock SIM card.
Figure 60 Enter PIN to Lock the SIM Card
5. Enter the PIN associated with the card.
6. Touch OK.
7. Reset the device.
Monitoring Data Usage
Data usage refers to the amount of data uploaded or downloaded by the device during a given period. This is data
that is not accessed through Wi-Fi. Depending on the wireless plan, you might owe additional fees when your data
usage exceeds your plan's limit. In this section, you learn about using the data saver, setting a warning about the
amount of data used, and setting a data limit.
Turning on the Data Saver
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Network & Internet > Data usage .
Figure 61 Data Usage Form
3. Touch Data saver.
The Data saver form appears.
80
Wireless
4. Touch the button to turn the data saver function on or off.
By turning the data saver on, it helps reduce some uses of data by preventing some applications from sending
or receiving data in the background.
CAUTIONThe usage displayed on the data usage settings screen is measured by your device. Your carrier's data
usage accounting might differ. Usage in excess of your carrier plan's data limits can result in steep overage charges.
The feature described here can help you track your usage, but is not guaranteed to prevent additional charges.
Setting Data Usage Warning
Data usage settings provide these functions:
• Set the data usage warning level.
• Set a data usage limit.
• View or restrict data usage by app.
• Identify mobile hotspots and restrict background downloads that might result in extra charges.
To set a warning alert to tell you when the device has used a specific amount of mobile data, follow these
steps:
1. Swipe down from the Status bar to open the Quick Access panel.
Touch the Settings button.
2. Touch Network & Internet > Data usage .
The Data usage form appears.
Figure 62 Data Usage Form
By default, the data usage screen displays the mobile data settings.
3. Touch Billing cycle.
The Billing cycle form appears. This form shows settings that help you be aware of the data usage, limits you
have set, and the day of the month that resets the billing period.
81
Figure 63 Billing Cycle Form
4. Touch Set data warning to turn it on.
This button also turns it off.
Figure 64 Billing Cycle Form
Wireless
Data warning is on.
Data warning limit is shown.
5. Touch Data warning to set the threshold to inform you of data use.
The Set data usage warning form appears.
Figure 65 Set Data Usage Warning
Touch down arrow to switch between
MBytes and GBytes.
6. To switch between megabytes (MB) and gigabytes (GB), touch the down arrow on the right side of the warning
form.
7. Enter a number to set the warning threshold for data usage.
8. Touch SET to confirm the limit.
The Data warning field shows the amount you set.
When the usage reaches the warning threshold, you are notified.
82
Wireless
Setting a Data Limit
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Network & Internet.
The Network & Internet form appears.
Figure 66 Network & Internet Form
Data usage
3. Touch Data usage.
The Data usage form appears.
Figure 67 Data Usage Form
4. Touch Billing Cycle.
The Billing Cycle form appears.
Billing cycle
83
Wireless
Figure 68 Billing Cycle Form
5. Touch Set data limit.
6. If you see a Limiting data usage pop-up window, touch OK.
Figure 69 Message about Limiting Data Usage
The Set data usage limit form appears.
7. If no data limit has been set, touch Data limit.
The Set data usage limit form appears with an on-screen number pad.
Figure 70 The Set Data Usage Limit Form
8. Enter a number to set the limit.
To switch between megabytes (MB) and gigabytes (GB), touch the down arrow.
9. Touch Set to confirm the limit.
When the limit is reached, data automatically turns off and a notification appears.
84
Wireless
Viewing Mobile Data Usage
1. To see a summary of data usage, touch Mobile data usage.
The Mobile data usage screen displays how much data has been used, the data warning setting, and the
billing cycle dates.
Figure 71 Mobile Data Usage
Wireless Local Area Networks
NOTE: If using an external antenna, ensure correct settings.
Wireless local area networks (WLANs) allow the device to communicate wirelessly inside a building. Before using
the device on a WLAN, the facility must be set up with the required hardware to run the WLAN (sometimes known
as infrastructure). The infrastructure and the device must both be properly configured to enable this
communication.
Refer to the documentation provided with the infrastructure (access points (APs), access ports, switches, Radius
servers, etc.) for instructions on how to set up the infrastructure.
Once the infrastructure is set up to enforce the chosen WLAN security scheme, use the Wireless & networks
settings configure the device to match the security scheme.
The device supports the following WLAN security options:
• Open
• Wireless Equivalent Privacy (WEP).
• Wi-Fi Protected Access (WPA and WPA2) Pre-Shared Key (PSK).
• Extensible Authentication Protocol (EAP).
The Status bar displays icons that indicate Wi-Fi network availability and Wi-Fi status. See Status Bar for more
information.
85
Wireless
Scanning and Connecting to a Wi-Fi Network
To scan and connect to a Wi-Fi network, follow this procedure.
1. Swipe down from the Status bar to open the Quick Settings bar or the Quick Access panel.
Figure 72 Quick Access Bar Panel
Wi-Fi
2. Touch Wi-Fi to open the Wi-Fi screen.
Quick Settings bar
To display, use one finger
when you swipe down.
Quick Access panel
To display, use two fingers
when you swipe down.
The device searches for WLANs in the area and lists them.
Figure 73 Wi-Fi Screen
Wi-Fi
3. Scroll through the list and select a WLAN network.
4. For open networks, touch profile once or press and hold and then touch Connect to network or for secure
networks enter the required password or other credentials then touch Connect.
See the system administrator for more information.
86
Wireless
5. The device obtains a network address and other required information from the network using the dynamic host
configuration protocol (DHCP). To configure the device with a fixed internet protocol (IP) address, refer to the
device Integrator Guide for more information.
6. In the Wi-Fi setting field, Connected appears indicating that the device is connected to the WLAN.
Removing a Wi-Fi Network
To remove a remembered or connected network:
1. Swipe down from the status bar and then touch .
2. Touch Network & Internet > Wi-Fi.
3. In the Wi-Fi list, touch and hold the name of the network.
A menu pops up.
4. In the menu, touch Forget network.
5. Touch .
Configuring a Wi-Fi Network
To set up a Wi-Fi network:
1. Swipe down from the status bar and then touch .
2. Touch Network & Internet > Wi-Fi.
3. Slide the switch to the ON position.
4. The device searches for WLANs in the area and lists them on the screen.
5. Scroll through the list and touch the WLAN network you want.
If the network security is Open, the device automatically connects to the network.
For all other network security, a network security dialog box appears.
Figure 74 WLAN WEP Network Security Dialog Box
6. Enter the password.
7. Touch CONNECT.
The tablet connects to the Wi-Fi network.
87
Wireless
Figure 75 WLAN 802.11 EAP Network Security Dialog Box
8. If the network security is WEP or WPA/WPS2 PSK, enter the required password and then touch Connect.
9. If the network security is 802.1x EAP, follow these steps:
• Touch the EAP method drop-down list and select PEAP, TLS, TTLS, PWD, or LEAP.
• Touch the Phase 2 authentication drop-down list and select an authentication method.
• If required, touch CA certificate and select a Certification Authority (CA) certificate. Note: Certificates are
installed using the Security settings.
• If required, touch User certificate and select a user certificate.
Note: User certificates are installed using the location & security settings.
• If required, in the Identity text box, enter the username credentials.
• If you like, in the Anonymous identity text box, enter an anonymous identity username.
• If required, in the Password text box, enter the password for the given identity.
NOTE: By default, the network Proxy is set to None and the IP setting is set to DHCP. See Configuring for a Proxy
Server on page 89
on page 90 for setting the device to use a static IP address.
Touch Connect.
10.
11. Touch .
for setting connection to a proxy server. See Configuring the Device to Use a Static IP Address
Manually Adding a Wi-Fi Network
Manually add a Wi-Fi network if the network does not broadcast its name (SSID) or to add a Wi-Fi network when
out of range.
1. Swipe down from the status bar and then touch the Settings icon .
2. Touch Network & Internet > Wi-Fi.
3. Slide the Wi-Fi switch to the On position.
88
Wireless
4. Scroll down to the bottom of the window and touch Add network.
5. In the Enter the SSID text box, enter the name of the Wi-Fi network.
6. In the Security drop-down list, select the type of security. The Options include:
• None
• WEP
• WPA/WPA2 PSK
• 802.1x EAP.
7. If the network security is None, touch Save.
8. If the network security is WEP or WPA/WPA2 PSK, enter the required password and then touch Save.
9. If the network security is 802.1x EAP:
• Touch the EAP method drop-down list and select PEAP, TLS, TTLS, PWD, or LEAP.
• Touch the Phase 2 authentication drop-down list and select an authentication method.
• If required, touch CA certificate and select a Certification Authority (CA) certificate. Note: Certificates are
installed using the Security settings.
• If required, touch User certificate and select a user certificate. Note: User certificates are installed using the
Security settings.
• If required, in the Identity text box, enter the username credentials.
• If desired, in the Anonymous identity text box, enter an anonymous identity username.
• If required, in the Password text box, enter the password for the given identity.
NOTE: By default, the network Proxy is set to None and the IP settings is set to DHCP. See Configuring for a Proxy
Server on page 89
Address on page 90
Touch Save.
10.
for setting connection to a proxy server and see Configuring the Device to Use a Static IP
for setting the device to use a static IP address.
To connect to the saved network, touch and hold on the saved network and select Connect to network.
11. Touch .
Configuring for a Proxy Server
A proxy server is a server that acts as an intermediary for requests from clients seeking resources from other
servers. A client connects to the proxy server and requests some service, such as a file, connection, web page, or
other resource, available from a different server. The proxy server evaluates the request according to its filtering
rules. For example, it may filter traffic by IP address or protocol. If the request is validated by the filter, the proxy
provides the resource by connecting to the relevant server and requesting the service on behalf of the client.
It is important for enterprise customers to be able to set up secure computing environments within their companies,
making proxy configuration essential. Proxy configuration acts as a security barrier ensuring that the proxy server
monitors all traffic between the Internet and the intranet. This is normally an integral part of security enforcement in
corporate firewalls within intranets.
To configure the device for a proxy server:
1. In the network dialog box, touch a network.
2. Touch Advanced options.
3. Touch Proxy and select Manual.
4. In the Proxy hostname text box, enter the address of the proxy server.
5. In the Proxy port text box, enter the port number for the proxy server.
89
Wireless
6. In the Bypass proxy for text box, enter addresses for web sites that are not required to go through the proxy
server. Use a comma “,” between addresses. Do not use spaces or carriage returns between addresses.
7. Touch Connect.
8. Touch .
Configuring the Device to Use a Static IP Address
By default, the device is configured to use Dynamic Host Configuration Protocol (DHCP) to assign an Internet
protocol (IP) address when connecting to a wireless network.
To configure the device to connect to a network using a static IP address:
1. In the network dialog box, touch a network.
2. Touch Advanced options.
3. Touch IP settings and select Static.
4. In the IP address text box, enter an IP address for the device.
5. If required, in the Gateway text box, enter a gateway address for the device.
6. If required, in the Network prefix length text box, enter the prefix length.
7. If required, in the DNS 1 text box, enter a Domain Name System (DNS) address.
8. If required, in the DNS 2 text box, enter a DNS address.
9. Touch Connect.
10. Touch .
Wi-Fi Preferences
Use the Wi-Fi preferences to configure advanced Wi-Fi settings. From the Wi-Fi screen scroll down to the bottom
of the screen and touch Wi-Fi preferences.
• Open network notification - When enabled, notifies you when an open network is available.
• Advanced - Touch to expand options.
• Additional settings - See Additional Settings.
• Install Certificates – Touch to install certificates.
• Network rating provider - Disabled (AOSP devices). To help determine what constitutes a good
Wi-Fi network, Android supports external Network rating providers that provide information about the
quality of open Wi-Fi networks. Select one of the providers listed or None. If none are available or
selected, the Connect to open networks feature is disabled.
• Wi-Fi Direct - Displays a list of devices available for a direct Wi-Fi connection.
• WPS Push Button - Touch to connect to a network using Wi-Fi Protected Setup (WPS) push button
method.
• WPS Pin Entry - Touch to connect to a network using Wi-Fi Protected Setup (WPS) pin entry method.
• MAC address - Displays the Media Access Control (MAC) address of the device when connecting to
Wi-Fi networks.
• IP address - Displays the IP address of the device when connecting to Wi-Fi networks.
90
Wireless
Additional Wi-Fi Settings
Use the Additional Settings to configure additional Wi-Fi settings. To view the additional Wi-Fi settings, scroll to
the bottom of the Wi-Fi screen and touch Wi-Fi Preferences > Advanced > Additional settings.
NOTE: Additional Wi-Fi settings are for the device, not for a specific wireless network.
• Regulatory
• Country Selection - Displays the acquired country code if 802.11d is enabled, else it displays the
currently selected country code.
• Region code - Displays the current region code.
• Band and Channel Selection
• Wi-Fi frequency band - Set the frequency band to: Auto (default), 5 GHz only or 2.4 GHz only.
• Available channels (2.4 GHz) - Touch to display the Available channels menu. Select specific
channels and touch OK.
• Available channels (5 GHz) - Touch to display the Available channels menu. Select specific
channels and touch OK.
• Logging
• Advanced Logging – Touch to enable advanced logging or change the log directory.
• Wireless logs - Use to capture Wi-Fi log files.
• Fusion Logger - Touch to open the Fusion Logger application. This application maintains a
history of high level WLAN events which helps to understand the status of connectivity.
• Fusion Status - Touch to display live status of WLAN state. Also provides information about the
device and connected profile.
• About
• Version - Displays the current Fusion information.
Wi-Fi Direct
Wi-Fi Direct devices can connect to each other without having to go through an access point. Wi-Fi Direct devices
establish their own ad-hoc network when required, letting you see which devices are available and choose which
one you want to connect to.
1. Swipe down from the status bar and then touch .
2. Touch Wi-Fi > Wi-Fi preferences > Advanced > Wi-Fi Direct. The device begins searching for another Wi-Fi
Direct device.
Figure 76 Wi-Fi Direct Screen
91
Wireless
3. Under Peer devices, touch the other device name.
4. On the other device, select Accept.
5. Connected appears on the device. On both devices, in their respective Wi-Fi Direct screens, the other device
name appears in the list.
WPS Pin Entry
Wi-Fi Protected Setup (WPS) is a feature allowing devices to easily connect to Wi-Fi access points without typing a
long password.
To use a PIN to connect to a wireless router:
1. Log in to the router.
2. Go to the Add WPS Client screen. Refer to the wireless router user documentation specific information.
3. On the device, swipe down from the status bar and then touch .
4. Touch Wi-Fi > Wi-Fi preferences > Advanced > WPS Pin Entry.
A dialog box displays a Pin number.
Figure 77 Pin Entry Dialog Box
5. On the router, enter the Pin number.
6. The device connects to the wireless router.
WPS Push Button
Wi-Fi Protected Setup (WPS) is a feature allowing devices to easily connect to Wi-Fi access points without typing a
long password.
To use a wireless router WPS button:
1. On the device, swipe down from the status bar and then touch .
2. Touch Wi-Fi > Wi-Fi preferences > Advanced > WPS Push Button.
A dialog box displays a pin number.
Figure 78 Pin Entry Dialog Box
92
Wireless
3. On the wireless router, locate the WPS button.
The device connects to the wireless router.
Wi-Fi Advanced Features
Some additional Wi-Fi settings cannot be accessed from the user interface. They can be configured by using Wi-Fi
(CSP). Refer to EMDK documentation for the details on the Wi-Fi settings configuration using the Wi-Fi CSP.
• Auto Time Config - Using this feature, the device can sync up its time with Zebra WLAN infrastructure.
This feature works only when the device is connected to Zebra WLAN infrastructure and the feature is
enabled on the WLAN infrastructure side. Default: disabled.
• PMKID Caching - Allows the device to skip 802.1x authentication during roaming if it had previously
connected to that AP with a full 802.1x authentication. Default: disabled. Note: disable OKC when enabling
PMKID Caching.
• Opportunistic Key Caching - Use this feature to skip 802.1x authentication during roaming. The device
will go for full 802.1x authentication for the first time it connects to the network. For subsequent roaming,
the device skips 802.1x authentication. Default: enabled.
• Cisco Centralized Key Management - Allows the device to skip 802.1x and key-handshake phases
during roaming. This feature is available only when the device is connected to a Cisco infrastructure that
supports Cisco Centralized Key Management (CCKM). Default: enabled.
• Fast Transition - Fast Transition (FT) is the fast roaming standard, 802.11r. With this feature, the device
can skip 802.1x and key-handshake phases during roam. Default: enabled.
• Fast Transition Resource Information Container - Allows the device to request TSPEC as part of
reassociation frame exchange. This helps to avoid sending a separate resource request after roaming is
completed. Default: enabled.
• Power Save - The device can be configured to work in different power save modes:
• Active - Keeps the WLAN radio always in active mode (i.e. power save mode disabled).
• Power save using WMM-PS - This is the default power save mode. Device uses WMM-PS power
save method if the AP is configured to use this. If the AP is not supporting WMM-PS, the device will
use PS-Poll power save method.
• Power save using PS-Poll - In this method, the device will use PS-Poll frames to retrieve buffered
frames from the AP.
• Null Data Power Save - In Null Data Power Save (NDP), the device will stay awake for 100 ms after
the last frame is sent or received. The device will send a Null Data packet with power management bit
cleared to retrieve buffered frames from the AP.
• 802.11k - Using 802.11k, the device can discover neighbor APs and adds support for different types of
radio resource measurements. Default: enabled.
• Band Preference - The device can be configured to prefer one band over another. Default:
disabled.Subnet Roaming - When the device roams between different sub networks, if it detects that it is
roaming to a different subnet, the device will request a fresh IP address. Default: disabled.
Zebra Mobility Extensions
Zebra Mobility Extensions make use of 802.11 specifications and Zebra proprietary extensions to achieve the
highest level of performance, efficiency and reliability. The device adds support for the following Zebra Mobility
Extensions:
• Coverage Hole Detection
The device includes enhancements to the IEEE 802.11k standard. These improvements will report gaps in
signal coverage to the Zebra wireless LAN infrastructure. Network administrators can detect and mitigate
coverage gaps present in the network for greater reliability. Default: enabled.
93
• Aggregated Fast Transition
• Scan Assist
Bluetooth
Bluetooth devices can communicate without wires, using frequency-hopping spread spectrum (FHSS) radio
frequency (RF) to transmit and receive data in the 2.4 GHz Industry Scientific and Medical (ISM) band (802.15.1).
Bluetooth wireless technology is specifically designed for short-range (10 m (32.8 ft)) communication and low
power consumption.
Devices with Bluetooth capabilities can exchange information (files, appointments, and tasks) with other Bluetooth
enabled devices such as printers, access points, and other mobile devices.
The device supports Bluetooth Low Energy. Bluetooth Low Energy is targeted at applications in the healthcare,
fitness, security, and home entertainment industries. It provides reduced power consumption and cost while
maintaining standard Bluetooth range.
Wireless
Aggregated FT improves on IEEE 802.11r, Over-the-DS fast roaming. In conjunction with Zebra wireless
LAN infrastructure, the device will achieve more reliable and consistent fast roaming. Default: enabled.
The device monitors neighbor access points and retrieves roaming related information from the Zebra
wireless LAN infrastructure without doing scans. Using this Scan Assist feature, the device improves
roaming. Default: enabled.
Adaptive Frequency Hopping
Adaptive Frequency Hopping (AFH) is a method of avoiding fixed frequency interferers, and can be used with
Bluetooth voice. All devices in the piconet (Bluetooth network) must be AFH-capable in order for AFH to work.
There is no AFH when connecting and discovering devices. Avoid making Bluetooth connections and discoveries
during critical 802.11b communications. AFH for Bluetooth consists of four main sections:
• Channel Classification - A method of detecting an interference on a channel-by-channel basis, or
predefined channel mask.
• Link Management - Coordinates and distributes the AFH information to the rest of the Bluetooth network.
• Hop Sequence Modification - Avoids interference by selectively reducing the number of hopping channels.
• Channel Maintenance - A method for periodically re-evaluating the channels.
When AFH is enabled, the Bluetooth radio “hops around” (instead of through) the 802.11b high-rate channels. AFH
coexistence allows enterprise devices to operate in any infrastructure.
The Bluetooth radio in this device operates as a Class 2 device power class. The maximum output power is 2.5
mW and the expected range is 10 m (32.8 ft). A definition of ranges based on power class is difficult to obtain due
to power and device differences, and whether in open space or closed office space.
NOTE: It is not recommended to perform Bluetooth wireless technology inquiry when high rate 802.11b operation is
required.
94
Wireless
Bluetooth Security
The current Bluetooth specification defines security at the link level. Application-level security is not specified. This
allows application developers to define security mechanisms tailored to their specific need. Link-level security
occurs between devices, not users, while application-level security can be implemented on a per-user basis. The
Bluetooth specification defines security algorithms and procedures required to authenticate devices, and if needed,
encrypt the data flowing on the link between the devices. Device authentication is a mandatory feature of Bluetooth
while link encryption is optional.
Pairing of Bluetooth devices is accomplished by creating an initialization key used to authenticate the devices and
create a link key for them. Entering a common personal identification number (PIN) in the devices being paired
generates the initialization key. The PIN is never sent over the air. By default, the Bluetooth stack responds with no
key when a key is requested (it is up to user to respond to the key request event). Authentication of Bluetooth
devices is based-upon a challenge-response transaction. Bluetooth allows for a PIN or passkey used to create
other 128-bit keys used for security and encryption. The encryption key is derived from the link key used to
authenticate the pairing devices. Also worthy of note is the limited range and fast frequency hopping of the
Bluetooth radios that makes long-distance eavesdropping difficult.
Recommendations are:
• Perform pairing in a secure environment
• Keep PIN codes private and do not store the PIN codes in the device
• Implement application-level security.
Bluetooth Profiles
The device supports the Bluetooth services listed in the table below:
Table 23 Bluetooth Profiles
Profile Description
Service Discovery Protocol
(SDP)
Serial Port Profile (SPP) Allows use of RFCOMM protocol to emulate serial cable connection
Object Push Profile (OPP) Allows the device to push and pull objects to and from a push server.
Advanced Audio Distribution
Profile (A2DP)
Audio/Video Remote Control
Profile (AVRCP)
Personal Area Network (PAN) Allows the use of Bluetooth Network Encapsulation Protocol to provide
Human Interface Device Profile
(HID)
Headset Profile (HSP) Allows a hands-free device, such as a Bluetooth headset, to place and
Hands-Free Profile (HFP) Allows car hands-free kits to communicate with the device in the car.
Handles the search for known and specific services as well as general
services.
between two Bluetooth peer devices. For example, connecting the
device to a printer.
Allows the device to stream stereo-quality audio to a wireless headset or
wireless stereo speakers.
Allows the device to control A/V equipment to which a user has access.
It may be used in concert with A2DP.
L3 networking capabilities over a Bluetooth link. Only PANU role is
supported.
Allows Bluetooth keyboards, pointing devices, gaming devices and
remote monitoring devices to connect to the device.
receive calls on the device.
95
Wireless
Table 23 Bluetooth Profiles (Continued)
Profile Description
Out of Band (OOB) Allows exchange of information used in the pairing process. Pairing is
completed using the Bluetooth radio, but requires information from the
OOB mechanism.
File Transfer Profile (FTP) Provides the capability to browse, manipulate and transfer files in file
system of another system. Uses GOEP as a basis.
Generic Attribute Profile (GATT) Provides profile discovery and description services for Bluetooth Low
Energy protocol. It defines how attributes are grouped together into sets
to form services.
HID Over GATT Profile (HOGP) Defines the procedures and features used by Bluetooth low energy HID
Devices using GATT and Bluetooth HID Hosts using GATT.
Scan Parameters Profile (ScPP) Provides devices with information to assist them in managing their
connection idle timeout and advertising parameters to optimize for
power consumption and/or reconnection latency.
Phone Book Access Profile
(PBAP)
Simple Serial Interface (SSI) Allows for communication with Bluetooth Imager.
Dial Up Networking (DUN) Provides a standard to access the Internet and other dial-up services
Generic Access Profile (GAP) GAP controls connections in Bluetooth. GAP is what makes your device
OBject EXchange (OBEX) OBEX is a communications protocol that facilitates the exchange of
PBAP is a Bluetooth profile that allows the exchange of Phone Book
Objects between a car kit and a mobile device to allow the car kit to
display the name of the incoming caller. Allows the car kit to download
the phone book so you can initiate a call from the car display.
over Bluetooth.
visible to the outside world, and determines how two devices interact
with each other. Use for device discovery and authentication.
binary objects between devices.
Bluetooth Power States
The Bluetooth radio is off by default:
• Suspend - When the device goes into suspend mode, the Bluetooth radio stays on.
• Airplane Mode - When the device is placed in Airplane Mode, the Bluetooth radio turns off. When Airplane
Mode is disabled, the Bluetooth radio returns to the prior state and is turned back on.
Bluetooth Radio Power
Turn off the Bluetooth radio to save power or if entering an area with radio restrictions, such as on an airplane.
When the radio is off, other Bluetooth devices cannot see or connect to the device.
Turn on the Bluetooth radio to exchange information with other Bluetooth devices within range.
NOTE: To achieve the best battery life, turn off radios when not in use.
Enabling Bluetooth
To enable Bluetooth:
1. Swipe down from the Status bar to open the Quick Access panel.
96
Wireless
2. Touch to turn Bluetooth on.
3. Touch .
Disabling Bluetooth
To disable Bluetooth:
1. Swipe down from the Status bar to open the Quick Access panel.
2. Touch to turn Bluetooth off.
3. Touch .
Discovering Bluetooth Device(s)
The device can receive information from discovered devices without pairing. However, once paired, the device and
a paired device exchange information automatically when the Bluetooth radio is on. To find Bluetooth devices in
the area:
1. Ensure that Bluetooth is enabled on both devices.
2. Ensure that the Bluetooth device to discover is in discoverable mode.
3. Ensure that the two devices are within 10 meters (32.8 feet) of one another.
4. Swipe down from the Status bar to open the Quick Access panel.
5. Touch the word Bluetooth below the Bluetooth symbol.
Figure 79 Quick Access Panel
6. Touch MORE SETTINGS.
The Bluetooth screen appears.
Touch this word.
97
Figure 80 Bluetooth Screen
7. Touch Pair new device.
The device begins searching for discoverable Bluetooth devices in the area and displays them under
Available devices.
8. Scroll through the list and select a device.
The Bluetooth pairing request dialog box appears.
9. Touch Pair on both devices.
The Bluetooth device is added to the Paired devices list and a trusted (“paired”) connection is established.
Changing the Bluetooth Name
Wireless
By default, the device has a generic Bluetooth name that is visible to other devices when connected.
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Connected devices > Bluetooth.
3. If Bluetooth is not on, move the switch to turn Bluetooth on.
4. Touch Device name.
5. Enter a name and touch RENAME.
6. Touch .
Connecting to a Bluetooth Device
Once paired, connect to a Bluetooth device.
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Connected devices > Bluetooth.
3. In the list, touch the unconnected Bluetooth device.
When connected, Connected appears below the device name.
Selecting Profiles on the Bluetooth Device
Some Bluetooth devices have multiple profiles. To select a profile:
1. Swipe down from the Status bar to open the Quick Access panel and then touch .
2. Touch Connected devices > Bluetooth.
3. In the Paired devices list, touch next to the device name.
4. Turn on or off a profile to allow the device to use that profile.
5. Touch .
98
