Yamaha TSX-130 User Manual

DESKTOP AUDIO SYSTEM

SYSTEME AUDIO DESKTOP

TSX-130

U

OWNER’S MANUAL

MODE D’EMPLOI

IMPORTANT SAFETY INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK DO

NOT OPEN

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE COVER

(OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

Note to CATV system installer:

This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building, as
close to the point of cable entry as practical.

IMPORTANT

Please record the serial number of this unit in the space
below.
MODEL:
Serial No.:
The serial number is located on the rear of the unit.
Retain this Owner’s Manual in a safe place for future
reference.

SERVICE PERSONNEL.

• Explanation of Graphical Symbols

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert you to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

The exclamation point within an equilateral triangle
is intended to alert you to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with dry cloth.
7 Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

8 Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including amplifiers) that
produce heat.

9 Do not defeat the safety purpose of the polarized or

grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

10 Protect the power cord from being walked on or pinched

particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.

11 Only use attachments/accessories specified by the

manufacturer.

12 Use only with the cart, stand, tripod, bracket,

or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13 Unplug this apparatus during lightning storms or when unused

for long periods of time.

14 Refer all servicing to qualified service personnel. Servicing is

required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.

i En

We Want You Listening For A Lifetime

Yamaha and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your
equipment by playing it at a safe level. One that lets the sound come through loud and clear without annoying blaring or
distortion – and, most importantly, without affecting your sensitive hearing. Since hearing damage from loud sounds is
often undetectable until it is too late, Yamaha and the Electronic Industries Association’s Consumer Electronics Group
recommend you to avoid prolonged exposure from excessive volume levels.

IMPORTANT SAFETY INSTRUCTIONS

FCC INFORMATION (for US customers)

1 IMPORTANT NOTICE: DO NOT MODIFY THIS

UNIT!

This product, when installed as indicated in the
instructions contained in this manual, meets FCC
requirements. Modifications not expressly approved by
Yamaha may void your authority, granted by the FCC, to
use the product.

2 IMPORTANT: When connecting this product to

accessories and/or another product use only high quality
shielded cables. Cable/s supplied with this product MUST
be used. Follow all installation instructions. Failure to
follow instructions could void your FCC authorization to
use this product in the USA.

3 NOTE: This product has been tested and found to comply

with the requirements listed in FCC Regulations, Part 15
for Class “B” digital devices. Compliance with these
requirements provides a reasonable level of assurance that
your use of this product in a residential environment will
not result in harmful interference with other electronic
devices.
This equipment generates/uses radio frequencies and, if
not installed and used according to the instructions found
in the users manual, may cause interference harmful to the
operation of other electronic devices.

● The name plate is located on the bottom of the unit.

Compliance with FCC regulations does not guarantee that
interference will not occur in all installations. If this
product is found to be the source of interference, which can
be determined by turning the unit “OFF” and “ON”, please
try to eliminate the problem by using one of the following
measures:

Relocate either this product or the device that is being
affected by the interference.

Utilize power outlets that are on different branch (circuit
breaker or fuse) circuits or install AC line filter/s.

In the case of radio or TV interference, relocate/reorient
the antenna. If the antenna lead-in is 300 ohm ribbon lead,
change the lead-in to coaxial type cable.

If these corrective measures do not produce satisfactory
results, please contact the local retailer authorized to
distribute this type of product. If you can not locate the
appropriate retailer, please contact Yamaha Electronics
Corp., U.S.A. 6660 Orangethorpe Ave., Buena Park, CA

90620.
The above statements apply ONLY to those products

distributed by Yamaha Corporation of America or its
subsidiaries.

CAUTION

Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.

AVERTISSEMENT

L’utilisation de commandes et l’emploi de réglages ou de
méthodes autres que ceux décrits ci-dessous, peuvent
entraîner une exposition à un rayonnement dangereux.

CAUTION INVISIBLE LASER RADIATION WHEN OPEN
AND INTERLOCKS DEFEATED. AVOID EXPOSURE TO
BEAM.

ii En

Caution: Read this before operating your unit.

1 To assure the finest performance, please read this manual

carefully. Keep it in a safe place for future reference.

2 Install this unit in a well ventilated, cool, dry, clean place

with at least 15 cm on the top, 10 cm on the left and right,
and 10 cm at the back of this unit

— away from direct

sunlight, heat sources, vibration, dust, moisture, and/or
cold.

3 Locate this unit away from other electrical appliances,

motors, or transformers to avoid humming sounds.

4 Do not expose this unit to sudden temperature changes

from cold to hot (or vice versa), and do not locate this
unit in an environment with high humidity (i.e., a room
with a humidifier) to prevent condensation inside this
unit, which may cause an electrical shock, fire, damage to
this unit, and/or personal injury.

5 Avoid installing this unit where foreign object may fall

onto this unit and/or this unit may be exposed to liquid
dripping or splashing. On the top of this unit, do not
place:

– Other components, as they may cause damage and/or

discoloration on the surface of this unit.

– Burning objects (i.e., candles), as they may cause fire,

damage to this unit, and/or personal injury.

– Containers with liquid in them, as they may fall and

liquid may cause electrical shock to the user and/or
damage to this unit.

6 Do not cover this unit with a newspaper, tablecloth,

curtain, etc. in order not to obstruct heat radiation. If the
temperature inside this unit rises, it may cause fire,
damage to this unit, and/or personal injury.

7 Do not plug in this unit to a wall outlet until all

connections are complete.

8 Do not operate this unit upside-down. It may overheat,

possibly causing damage.
9 Do not use force on switches, knobs and/or cords.
10 When disconnecting the power cable from the wall outlet,

grasp the plug; do not pull the cable.
11 Do not clean this unit with chemical solvents; this might

damage the finish.
12 Only voltage specified on this unit must be used. Using

this unit with a higher voltage than specified is dangerous

and may cause fire, damage to this unit, and/or personal

injury. Yamaha will not be held responsible for any

damage resulting from use of this unit with a voltage

other than specified.
13 To prevent damage by lightning, keep the power cable

and outdoor antennas disconnected from a wall outlet or

this unit during a lightning storm.
14 Do not attempt to modify or fix this unit. Contact

qualified Yamaha service personnel when any service is

needed. The cabinet should never be opened for any

reasons.
15 When not planning to use this unit for long periods of

time (i.e., vacation), disconnect the AC power plug from

the wall outlet.
16 Be sure to read the “TROUBLESHOOTING” section on

common operating errors before concluding that this unit

is faulty.
17 Before moving this unit, press ON/OFF to set the system

to off, and disconnect the AC power plug from the wall

outlet.

18 Condensation will form when the surrounding

temperature changes suddenly. Disconnect the power
cable from the outlet, then leave this unit alone.

19 When using this unit for a long time, this unit may

become warm. Turn the system off, then leave this unit
alone for cooling.

20 Install this unit near the wall outlet and where the AC

power plug can be reached easily.

21 The batteries shall not be exposed to excessive heat such

as sunshine, fire or the like.

This unit is not disconnected from the AC power source as
long as it is connected to the wall outlet, even if this unit itself
is turned off by ON/OFF. In this state, this unit is designed to
consume a very small quantity of power.

WARNING

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

LASER SAFETY

This unit employs a laser. Due to possible eye injury, only a
qualified service person should remove the cover or attempt to
service this device.

DANGER

This unit emits visible laser radiation when open. Avoid direct
eye exposure to beam. When this unit is plugged into the wall
outlet, do not place your eyes close to the opening of the disc tray
and other openings to look into inside.

The laser component in this product is capable of emitting
radiation exceeding the limit for Class 1.

LASER

Type Semiconductor laser GaAS/GaAlAs
Wave length 780 nm
Output Power 10 mW
Beam divergence 60 degrees

FOR CANADIAN CUSTOMERS

To prevent electric shock, match wide blade of plug to wide
slot and fully insert.
This Class B digital apparatus complies with Canadian ICES-

003.

CAUTION

Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.

Taking care of the unit

When you wipe this unit, use a clean dry cloth.

iii En

CONTENTS

DESKTOP AUDIO SYSTEM
SYSTEME AUDIO DESKTOP

TSX-130

OWNER’S MANUAL

MODE D’EMPLOI

U

PREPARATION

PREPARATIONS BEFORE USING THIS UNIT

..............................................................................2

Turning on/off the system..........................................4

Adjusting the clock....................................................4

OPERATION

USING USEFUL FUNCTIONS ............................ 5

Using the alarm functions.......................................... 5

Setting sleeping mode................................................ 8

Setting Dimmer mode................................................8

Switching DSP mode................................................. 8

BASIC OPERATION............................................. 9

LISTENING TO MUSIC.....................................10

Listening to your iPod™ .........................................10

Listening to a CD..................................................... 12

Listening to a USB device .......................................13

LISTENING TO FM RADIO STATIONS ........14

Connecting antennas................................................14

Tuning radio stations............................................... 14

Presetting radio stations...........................................14

Selecting preset radio stations (Preset tuning)......... 15

ADDITIONAL INFORMATION

TROUBLESHOOTING .......................................16

General.....................................................................16

iPod™......................................................................17

Disc playback ..........................................................17

USB playback.......................................................... 18

Radio reception........................................................ 18

Remote control ........................................................18

NOTES ON DISCS AND USB DEVICES ..........19

Disc information...................................................... 19

Handling a disc ........................................................19

About MP3 or WMA files.......................................19

GLOSSARY...........................................................20

SPECIFICATIONS...............................................20

PREPARATION OPERATION

INFORMATION

ADDITIONAL

■ About this manual

• In this manual, operations that can be performed with either this unit or its remote control are explained using the unit.

• The symbol “

☞” with page number(s) indicates the corresponding reference page(s).

• Notes contain important information about safety and operating instructions. y indicates a tip for your operation.

• This manual is printed prior to production. Design and specifications are subject to change in part as a result of
improvements, etc. In case of differences between the manual and the product, the product has priority.

■ Supplied accessories

This product includes the following accessories. Make sure you have all of the following parts.

Indoor FM antenna
(1.4 m (55-1/8”))

Owner’s manual

Remote control

English

1 En

PREPARATION

PREPARATIONS BEFORE USING THIS UNIT

1 Source buttons: USB, CD, FM, iPod (☞ P. 9)
2 ON/OFF: System on/off (☞ P. 4)
3 VOLUME: Volume control buttons (☞ P. 9)
4 Audio control buttons (☞ P. 9)
5 iPod dock (☞ P. 10)
6 USB port (☞ P. 13)
7 OPEN/CLOSE : Disc tray open/close (☞ P. 12)
8 Alarm control buttons (☞ P. 5)
9 SNOOZE/SLEEP (☞ P. 7, 8)
0 Speakers
A Disc tray (☞ P. 12)
B Front panel display (☞ P. 4)
C To the wall outlet
D FM control buttons (☞ P. 14)
E CLOCK SET (☞ P. 4)
F FUNCTION
G DISPLAY (☞ P. 11, 12, 13)
H FOLDER S/T (☞ P. 9)
I DSP: DSP mode switching (☞ P. 8)
J Infrared signal transmitter (☞ P. 3)
K SLEEP: Sleep time setting (☞ P. 8)
L MENU S/T /Center buttons* (☞ P. 10)
M RANDOM/REPEAT: Changing the playback mode for

iPod/CD/USB (☞ P. 10, 12)

* The round shaped button on the center is called Center in this

manual.

2 En

■ Before using the remote control

■ Using the remote control

Use the remote control within 6 m (20’) of this unit and point it
toward the remote control sensor.

Notes

Within 6 m
(20’)

• Do not spill liquid on the remote control.

• Do not drop the remote control.

• Do not leave the remote control in the following places:
– hot or humid places such as a bathroom or near a heater
– extremely cold places
– dusty places

PREPARATIONS BEFORE USING THIS UNIT

1 Remove the battery insulation sheet before using the remote

control.

2 Remove the transparent sheet before using the remote control.

PREPARATION

■ Replacing the battery in the remote control

Change the battery when the operation range of the remote control decreases.

Use a straight pin to remove

the cover.

Notes

• Insert the battery according to the polarity markings (+ and –).

• If the batteries run out, immediately remove them from the remote control to prevent an explosion or acid leak.

• If a battery starts leaking, dispose of it immediately. Be careful not to let the leaking battery acid touch your skin or clothing.

• Before inserting new batteries, wipe the compartment clean.

• Dispose of batteries according to your regional regulations.

Replace the battery with

a new CR2025 battery.

Close the cover.

3 En

English

PREPARATIONS BEFORE USING THIS UNIT

Turning on/off the system

1 Connect the power cable to the wall

outlet.

2 Press ON/OFF to turn on the system.

When the system is on: “Hello” appears, then clock and
other information are displayed.

Example: iPod playback mode display

When the system is off: “Good-bye” appears, then only
date and time are displayed.

y

• This unit has an auto off function, which will automatically
switch the system to off if the system is left turned on for 1 hour
without playback or any other operation being performed. This
function is not available when the source is set to FM.

• Press and hold ON/OFF on the top of the unit for more than 3
seconds to set the system to standby mode. All the information
on the front panel display is not displayed in standby mode.
This can reduce the power consumption. To cancel standby
mode, press ON/OFF.

• Even in system off/standby mode, the alarm function is
available.

• The memory back-up circuit prevents stored data such as the
time setting from being lost even in system off/standby mode.

Adjusting the clock

The clock is not set at the factory.

1 Press CLOCK SET.

2 Select each setting with MENU S/T

and confirm with Center.

You can set YEAR → MONTH → DAY → TIME.

Notes

• This operation can be performed only with the remote control.

• Time appears in 12-hour notation (AM/PM), depending on the
model. For example, “4:00PM”.

• You can switch 12-hour/24-hour notation by pressing
FUNCTION → MENU S/T → Center to select TIME
FORMAT, then pressing MENU S/T → Center to select
12H/24H.

• The time settings are lost after one week when the power cable
is disconnected from the wall outlet.

4 En
