Technical data
26
Printer specifications
Type ...............Color Page Printer
Print Method ...Semiconductor Laser Xerography
Speed .............
Warm-up.........Less than 300 seconds from power on, at 20° Celsius and 60% humidity
Resolution ......600 dots per inch (dpi), or 600 dots per 15.4 mm
Paper feed......Automatic/Manual
Paper Trays....
Sheet Type Size B&W Color
A4, 8.5 x 11
Plain paper
Plain paper
Transparency or
thick paper
Feed Tray Sheet Size Quantity
Universal
Document
Tray
B4, 8.5 x 14
A3, 11 x 17 13.8 ppm 3.0 ppm
A4, 8.5 x 11
B4, 8.5 x 14
Envelope, A5, B5, A4, B4, A3, Letter,
Legal, 11 x 17 inches, 12 x 18 inches,
Custom sizes: width = 90 to 330,2 mm,
length = 139.7 to 457.2 mm
26 ppm 6 ppm
4.8 ppm 1.8 ppm
ppm = prints per minute
150 sheets
Paper Tray 1
Tray Module:
Paper Tray 2
Paper Tray 3
Xerox DocuColor 2006 26-1
B4, B5, A3, A4. Letter, Legal, 11 x 17
inches, 12 x 18 inches
B4, B5, A3, A4. Letter, Legal, 11 x 17
inches, 12 x 18 inches
250 sheets
500 sheets
per tray
26. Technical Data
Output Trays...
Output Tray Sheet Size Quantity
Top Output Tray Size: B5 or larger
250 sheets
Density: 10 gsm
Side Output Tray All sizes 150 sheets
Scanner Document Feeder
Up to 30 documents of 75 gsm, or 20 pound bond. Handles paper
weights from 28 to 128 gsm
Language .......PCL5 – US English; Adobe PostScript™ 3 – US English
Memory ..........RAM: 64 Mbyte SDRAM DIMM
Program ROM: 16Mbyte
Font ROM: 16 Mbyte
Interface .........IEEE 1284 Standard Bi-directional Centronics interface EtherNet
network connection 10BASE-5, 10BASE-t, 100BASE-TX.
Host ................IBM PC-AT with 486SX processor or greater; or equivalent DOS/V
equipment, November 1993 PC-series or later version Macintosh,
installed EtherTalk Phase 2
Host OS..........Window 95/98, Windows NT 4.0, System 7.5 or later version Mac OS 8.0
– 8.1
Basic fonts......Roman fonts: 136 PS, 46 PCL English
Roman Screen fonts: 136 PS for WIN/MAC
Noise level......Power Saver: Max 52 35.0 dB (A)
Printing: Max 35.0 dB (A)
Environment ...Temperature 5 to 32° Celsius
Condition ........ Humidity: 15 to 18% without condensation
Size: ...............Printer: 645 mm wide x 750 mm deep x 1160 mm high
*with the Document Input Tray and the Side Output Tray retracted
Scanner: 587 mm wide x 699 mm deep x 110 mm high
Weight ............ Printer: 153 pounds, 69.5 kilograms
Scanner: 77 pounds, 35 kilograms
Scanner Stand: 77 pounds, 35 kilograms
Document Feeder: 24 pounds, 11 kilograms
26-2 Xerox DocuColor 2006
26. Technical Data
Print area........
• Dark gray area = Printable area
• Light gray area = Non-assured print area
320 mm
4 mm
5 mm
4 mm
457.2 mm
Less than A3 size A3 or Larger
431.8 mm
4 mm
297 mm
4 mm
5 mm
• White area = Non-printable area
Electrical specifications
The DocuColor 2006 operates under the following conditions:
• Single phase
• 100V Input voltage = 100-120V + 10 %
• 220V Input voltage = 220-240 + 10%
• Frequency = 50 Hz + 0.5 Hz, 60 Hz + 0.5 Hz
• Power Saver Mode = 35 Watts consumption
• Copy Mode = 1400 Watts consumption
Emissions
Ozone = In accordance with the BAM (RAL-UZ 85) standard, the DocuColor
does not emit more than 0.01 ppm (parts per million).
Dust = In accordance with the BAM (RAL-UZ 85) standard, the DocuColor
does not emit more than 0.150 mg/m3 concentration of dust.
BTUs = 4781 per hour
Xerox DocuColor 2006 26-3
26. Technical Data
Interface specifications
Interface = SCSI-2 Single-end, TWAIN compliant
Supported Hosts = IBM PC/AT compatibles and Macintosh
Supported Operating Systems = Windows 95/98, Windows NT 4.0, Windows
NT 4.0 with Service Pack5.0, Window 200, Mac OS 7.5 or later, and Unix
Reorder numbers
Number Description Number Description
006R90307 1Black Dry Ink
Cartridge
006R90308 1 Cyan Dry Ink
Cartridge
006R90309 1 Magenta Dry Ink
Cartridge
006R90310 1 Yellow Dry Ink
Cartridge
013R90140 1 Print/Copy
Cartridge
008R12571 1 Dry Ink Waste
Container
26-4 Xerox DocuColor 2006
Fiery Server hardware components
Component Type Configuration
Processor Single R5000 MIPs 266 MHz
Cache L2 N/A
Hard Drive EIDE 3.2 GB (TBD)
CD-ROM N/A
#DIMM slots 2 64 standard, 256MB max
26. Technical Data
SDRAM MHz 60 nanosecond in 168
Individual 64-128 MB
pin DIMMs
Flash memory Flash 1MB
ASICs 3 IX, DX3, VX+
BUS 1xPCI 64-bit @ 33 MHz (complies
with PCL spec Rev. 2.1)
Internal slots
Scanner For IEEE1394 card
32-bit PCI Token Ring (option)
64-bit PCI N/A
External Ports Video connector For copier/printer engine
SCSI-II N/A
Serial RS422 for EPSV (TBD)
RJ-45 Ethernet 10/100 BaseT
AUI N/A
Parallel (in) IEEE 1284 Type B
Parallel (out) N/A
Xerox DocuColor 2006 26-5
26. Technical Data
Font list
This section contains a list of all the fonts that are installed in the DocuColor
2006 in manufacturing.
PostScript printer fonts
Listed in this section are the 136 PostScript printer fonts installed in the
DocuColor 2006. In addition to the these fonts, two Adobe Multiple Master
fonts are included and are used for font substitution in PDF files.
For Mac OS computers, install the corresponding screen fonts from the User
Software CD. For instructions, go to the Downloading files and fonts chapter.
Adobe Type 1 Fonts
The DocuColor 2006 includes 126 Adobe Type 1 fonts:
The Mac OS column lists the name as it appears on the Font menu on a
Mac OS computer. For example, in most applications, to use Bodoni-Bold
select Bodoni Bold from the Font menu.
The Windows menu name is the name as it appears on the Font menu on a
Windows computer. The style refers to the style that must be selected in the
application to access the particular PostScript font. For example, in order to
use Bodoni-Bold select Bodoni from the Font menu and Bold from the Style
menu.
PostScript name Mac OS menu name Windows menu name,
style
AlbertusMT-Light Albertus MT Lt Albertus MT Lt
AlbertusMT Albertus MT Albertus MT
AlbertusMT-Italic Albertus MT It Albertus MT, Italic
AntiqueOlive-Roman Antique Olive Roman Antique Olive Roman
AntiqueOlive-Bold Antique Olive Bold Antique Olive Roman,
Bold
AntiqueOlive-Italic Antique Olive Italic Antique Olive Roman,
Italic
AntiqueOlive-Compact Antique Olive Compact Antique Olive Compact
Arial-BoldItalicMT Arial Bold Italic Arial, Bold Italic
Arial-BoldMT Arial Bold Arial, Bold
Arial-ItalicMT Arial Italic Arial, Italic
26-6 Xerox DocuColor 2006
26. Technical Data
PostScript name Mac OS menu name Windows menu name,
style
ArialMT Arial Arial
AvantGarde-Book Avant Garde AvantGarde
AvantGarde-Demi Avant Garde Demi AvantGarde, Bold
AvantGardeBookOblique
AvantGardeDemiOblique
Avant Garde
BookOblique
Avant Garde
DemiOblique
AvantGarde, Italic
AvantGarde, Bold Italic
Bodoni Bodoni Bodoni
Bodoni-Bold Bodoni Bold Bodoni, Bold
Bodoni-Italic Bodoni Italic Bodoni, Italic
Bodoni-BoldItalic Bodoni BoldItalic Bodoni, Bold Italic
Bodoni-Poster Bodoni Poster Bodoni Poster
BodoniPosterCompressed
Bodoni
PosterCompressed
Bodoni
PosterCompressed
Bookman-Light Bookman Bookman
Bookman-Demi Bookman Demi Bookman, Bold
Bookman-LightItalic Bookman LightItalic Bookman, Italic
Bookman-DemiItalic Bookman DemiItalic Bookman, Bold Italic
Carta Carta Carta
Clarendon-Light Clarendon Light Clarendon Light
Clarendon Clarendon Clarendon
Clarendon-Bold Clarendon Bold Clarendon, Bold
CooperBlack Cooper Black Cooper Black
CooperBlack-Italic Cooper Black Italic Cooper Black, Italic
Copperplate-
Copperplate33bc Copperplate33bc
ThirtyThreeBC
Copperplate-
Copperplate32bc Copperplate32bc
ThirtyTwoBC
Coronet-Regular Coronet Coronet
Courier Courier Courier
Xerox DocuColor 2006 26-7
26. Technical Data
PostScript name Mac OS menu name Windows menu name,
Courier-Bold Courier Bold Courier, Bold
Courier-Oblique Courier Oblique Courier, Italic
Courier-BoldOblique Courier BoldOblique Courier, Bold Italic
Eurostile Eurostile Eurostile
Eurostile-Bold Eurostile Bold Eurostile Bold
Eurostile-ExtendedTwo Eurostile ExtendedTwo Eurostile ExtendedTwo
style
EurostileBoldExtendedTwo
Eurostile
BoldExtendedTwo
Eurostile ExtendedTwo,
Bold
GillSans GillSans GillSans
GillSans-Bold GillSans Bold GillSans, Bold
GillSans-Italic GillSans Italic GillSans, Italic
GillSans-BoldItalic GillSans BoldItalic GillSans, Bold Italic
GillSans-Light GillSans Light GillSans Light
GillSans-LightItalic GillSans LightItalic GillSans Light, Italic
GillSans-Condensed GillSans Condensed GillSans Condensed
GillSans-BoldCondensed GillSans BoldCondensed GillSans Condensed,
Bold
GillSans-ExtraBold GillSans ExtraBold GillSans ExtraBold
Goudy Goudy Goudy
Goudy-Bold Goudy Bold Goudy, Bold
Goudy-Italic Goudy Italic Goudy, Italic
Goudy-BoldItalic Goudy BoldItalic Goudy Bold Italic
Goudy-ExtraBold Goudy ExtraBold Goudy, ExtraBold
Helvetica Helvetica Helvetica
Helvetica-Bold Helvetica Bold Helvetica, Bold
Helvetica-Oblique Helvetica Oblique Helvetica, Italic
Helvetica-BoldOblique Helvetica BoldOblique Helvetica, Bold Italic
Helvetica-Narrow Helvetica Narrow Helvetica-Narrow
Helvetica-Narrow-Bold Helvetica Narrow Bold Helvetica Narrow, Bold
26-8 Xerox DocuColor 2006
26. Technical Data
PostScript name Mac OS menu name Windows menu name,
style
Helvetica-NarrowOblique
Helvetica-NarrowBoldOblique
Helvetica Narrow
Oblique
Helvetica Narrow
BoldObl
Helvetica-Narrow, Italic
Helvetica-Narrow, Bold
Italic
Helvetica-Condensed Helvetica Condensed Helvetica Condensed
Helvetica-CondensedBold
Helvetica-CondensedOblique
Helvetica-CondensedBoldObl
HelveticaCondensedBold
HelveticaCondensedOblique
HelveticaCondensedBoldObl
Helvetica Condensed,
Bold
Helvetica Condensed,
Italic
Helvetica Condensed,
Bold Italic
HoeflerText-Ornaments Hoefler Text Ornaments Hoefler Text Ornaments
JoannaMT Joanna MT Joanna MT
JoannaMT-Bold Joanna MT Bd Joanna MT, Bold
JoannaMT-Italic Joanna MT It Joanna MT, Italic
JoannaMT-BoldItalic Joanna MT Bd It Joanna MT, Bold Italic
LetterGothic Letter Gothic Letter Gothic
LetterGothic-Bold Letter Gothic Bold Letter Gothic, Bold
LetterGothic-Slanted Letter Gothic Slanted Letter Gothic, Italic
LetterGothic-BoldSlanted Letter Gothic
Letter Gothic, Bold Italic
BoldSlanted
LubalinGraph-Book Lubalin Graph LubalinGraph
LubalinGraph-Demi Lubalin Graph Demi LubalinGraph, Bold
LubalinGraphBookOblique
LubalinGraphDemiOblique
Lubalin Graph
BookOblique
Lubalin Graph
DemiOblique
Lubalin Graph, Italic
Lubalin Graph, Bold Italic
Marigold Marigold Marigold
MonaLisa-Recut Mona Lisa Recut Mona Lisa Recut
NewCenturySchlbk-
New Century Schlbk NewCenturySchlbk
Roman
NewCenturySchlbk-Bold New Century Schlbk Bd NewCenturySchlbk, Bold
Xerox DocuColor 2006 26-9
26. Technical Data
PostScript name Mac OS menu name Windows menu name,
style
NewCenturySchlbk-Italic New Century Schlbk
NewCenturySchlbk, Italic
Italic
NewCenturySchlbkBoldItalic
New Century Schlbk
BoldIt
NewCenturySchlbk, Bold
Italic
Optima Optima Optima
Optima-Bold Optima Bold Optima, Bold
Optima-Italic Optima Italic Optima, Italic
Optima-BoldItalic Optima BoldItalic Optima, Bold Italic
Oxford Oxford Oxford
Palatino-Roman Palatino Palatino
Palatino-Bold Palatino Bold Palatino, Bold
Palatino-Italic Palatino Italic Palatino, Italic
Palatino-BoldItalic Palatino BoldItalic Palatino, Bold Italic
StempelGaramondRoman
StempelGaramond
Roman
StempelGaramond
Roman
StempelGaramond-Bold StempelGaramond Bold StempelGaramond
Roman, Bold
StempelGaramond-Italic StempelGaramond Italic StempelGaramond
Roman, Italic
StempelGaramondBoldItalic
StempelGaramond
BoldItalic
StempelGaramond
Roman, Bold Italic
Symbol Symbol Symbol
Tekton Tekton Tekton
Times-Roman Times Times
Times-Bold Times Bold Times, Bold
Times-Italic Times Italic Times, Italic
Times-BoldItalic Times BoldItalic Times, Bold Italic
TimesNewRomanPS-
Times New Roman Bold Times New Roman, Bold
BoldMT
TimesNewRomanPSBoldItalicMT
Times New Roman Bold
Italic
Times New Roman, Bold
Italic
26-10 Xerox DocuColor 2006
26. Technical Data
PostScript name Mac OS menu name Windows menu name,
style
TimesNewRomanPS-
Times New Roman Italic Times New Roman, Italic
ItalicMT
TimesNewRomanPSMT Times New Roman Times New Roman
Univers-Extended Univers Extended Univers Extended
Univers-BoldExt Univers BoldExt Univers Extended, Bold
Univers-ExtendedObl Univers ExtendedObl Univers Extended, Italic
Univers-BoldExtObl Univers BoldExtObl Univers Extended, Bold
Italic
Univers-Light Univers 45 Light Univers 45 Light
Univers-Bold Univers 65 Bold Univers 45 Light, Bold
Univers-LightOblique Univers 45 LightOblique Univers 45 Light, Italic
Univers-BoldOblique Univers 65 BoldOblique Univers 45 Light, Bold
Italic
Univers Univers 55 Univers 55
Univers-Oblique Univers 55 Oblique Univers 55, Italic
Univers-CondensedBold Univers 67
CondensedBold
UniversCondensedBoldOblique
Univers 67
CondensedBoldObl
Univers 47
CondensedLight, Bold
Univers 47
CondensedLight, Bold
Italic
Univers-Condensed Univers 57 Condensed Univers 57 Condensed
UniversCondensedOblique
ZapfChancery-
Univers 57
CondensedOblique
Univers 57 Condensed,
Italic
ZapfChancery ZapfChancery
MediumItalic
ZapfDingbats ZapfDingbats ZapfDingbats
Xerox DocuColor 2006 26-11
26. Technical Data
PostScript TrueType fonts
The DocuColor 2006 includes 10 PostScript TrueType fonts:
PostScript name Mac OS menu name Windows menu name,
Apple-Chancery Apple Chancery Apple Chancery
Chicago Chicago Chicago
Geneva Geneva Geneva
HoeflerText-Black Hoefler Text Black Hoefler Text Black
HoeflerText-BlackItalic Hoefler Text Black Hoefler Text Black, Italic
HoeflerText-Italic Hoefler Text Hoefler Text, Italic
HoeflerText-Regular Hoefler Text Hoefler Text
Monaco Monaco Monaco
style
New York New York New York
Wingdings-Regular Wingdings Wingdings
26-12 Xerox DocuColor 2006
PCL printer fonts
The DocuColor 2006 includes 46 PCL fonts:
• Albertus Medium, Albertus Extra Bold
• Antique Olive, Antique Olive Bold, Antique Olive Italic
• Arial, Arial Bold, Arial Italic, Arial Bold Italic
• CG Omega, CG Omega Bold, CG Omega Italic, CG Omega Bold Italic
• CG Times, CG Times Bold, CG Times Italic, CG Times Bold Italic
• Clarendon Condensed
• Coronet
• Courier, Courier Bold, Courier Italic, Courier Bold Italic
• Garamond Antiqua, Garamond Halbfett, Garamond Kursiv, Garamond
Kursiv Halbfett
• Letter Gothic, Letter Gothic Bold, Letter Gothic Italic
26. Technical Data
• Line Printer
• Marigold
• Symbol
• Times New Roman, Times New Roman Bold, Times New Roman Italic,
Times New Roman Bold Italic
• Univers Medium, Univers Bold, Univers Medium Italic, Univers Bold
Italic, Univers Medium Condensed, Univers Bold Condensed, Univers
Medium Condensed Italic, Univers Bold Condensed Italic
• Wingdings
Xerox DocuColor 2006 26-13
26. Technical Data
Sorter/Stacker specifications
Dimensions
Width 17.2 inches (437mm)
Height 28 inches (710 mm)
Depth 19.1 inches (484 mm)
An additional 14 inches (356 mm) must be allowed to the left of the
Sorter/Stacker to enable jam clearance.
Weight: 37.5 lbs (17 kg)
Power
DC Input Power 24 V
Peak current 1A
Average current 0.5A or less
Environment
Temperature
(operating)
Humidity
(operating)
Temperature
(non-operating)
Humidity
(non-operating)
10-35º C
15-80 RH
0-40º C
15-90 RH
26-14 Xerox DocuColor 2006
Output Bins
Maximum output
• Exit Tray (Bin 1): All Modes, 100 Sheets maximum
• Bins 2-10: Plain Paper Mode Only, 30 Sheets maximum
• High Capacity Bin: All Modes, 500 Sheets maximum
Transparencies
• Exit Tray (Bin 1)
• High Capacity Bin
Standard paper sizes
26. Technical Data
Exit Tray
(Bin 1)
Bins 2-10
High
Capacity
Bin
(gsm) (gsm ) (gsm )
64-220 N/A N/A A3 Oversize SEF 12.2 x 17 309.88 x 432
64-220 64-128 64-220 A3 SEF 11.7 x 16.5 297 x 420
64-220 64-128 64-220 Ledger SEF 11 x 17 279.4 x 431.8
64-220 64-128 64-220 B4 SEF 10.1 x 14.3 257.0 x 364.0
64-220 64-128 64-220 LGL SEF 8.5 x 14 215.9 x 355.6
64-220 64-128 64-220 A4 LEF 11.7 x 8.3 297 x 210.0
64-220 64-128 64-220 A4-R SEF 8.3 x 11.7 210 x 297
64-220 64-128 64-220 LTR LEF 11 x 8.5 279.4 x 215.9
64-220 64-128 64-220 LTR-R SEF 8.5 x 11 215.9 x 279.4
64-98 64-98 64-98 B5 LEF 257.0 x 182.0
64-80 64-80 64-80 A5 LEF 210.0 x 148.5
Size SEF/
LEF
Dimensions
(inches)
Dimensions
(mm)
Custom sizes
• Width = 3.9 to 11.7 inches (100 to 297 mm)
• Length = 7.5 to 17.7 inches (191 to 450 mm)
Xerox DocuColor 2006 26-15
26. Technical Data
26-16 Xerox DocuColor 2006
Loading...
