Xerox DocuColor 12 Parameters Guide

Imation Matchprint™ Professional Server User Guide

2.10 Setting Job Parameters

Job Parameters are set for each Spooler or Hot Folder.

Note: Job Parameter dialog boxes can be viewed from Print File, Hot Folder,
Spoolers, and Edit/View Parameters.

1. Select a job (highlight) in the job queue and click to view job parameters, OR
select a job in the job queue, then select Edit Parameters from the Queue
menu, OR select File > Print File and pick a file to print. The Job Parameter
screen appears with the following tabs: Printer, Color, Output, PDF, Preview,
and Summary.

2. Go through each tabbed section and select the desired Job Parameters.

2.10.1 Printer Tab

Printer identifies the Xerox DocuColor 12 as the printer.

Resolution lists 600 x 600 DPI for the printer.

30

Input Tray is used to select the input media tray. See Xerox DocuColor 12

Imation Corp. 2001

Imation Matchprint™ Professional Server User Guide

User's Guide for more information on paper weight, sizes and proper paper
tray selection.

Media Type is used to view and select Media Type.

Media Size is used to view and select Media Size.

Require Calibration is checked if the user needs to be notified when the

printer requires calibration. If a printer requires calibration, jobs are put on
hold and a message to the user appears stating, "Printer is out of calibration:
please calibrate the printer to continue." Jobs are released after the printer is
calibrated.

Note: For PostScript jobs submitted via a Print File, job parameter settings
for Number of Copies, Input Tray and Media Type override the PostScript
file codes. For all other settings, the PostScript file settings override the job
parameter settings.

For jobs submitted through a spooler or hot folder, the values in the
PostScript file always override the default job parameters for that spooler or
hot folder.

2.10.2 Color Tab

Mode: Select Basic or Advanced. Basic mode is the default. When the
user selects a Color Target Adjustment file in either Basic or Advanced
mode, the color transformation is performed using the associated device
link/profile or by allowing the users to select their own custom ICC color
profiles. Advanced mode allows the user more color control of the final
proof.

Basic Mode Controls

Imation Corp. 2001

31

Imation Matchprint™ Professional Server User Guide

RGB Color Space is used to select an RGB Source profile if a Color Space
Array (CSA) is not present in the PostScript stream. The four RGB source
profiles provided are: Adobe™ RGB 1998, Apple™ RGB, ColorMatch™ RGB,
sRGB.

RGB Link is used to select the RGB device link used on incoming RGB Raster
files.

CMYK Link is used to select the CMYK device link used on incoming CMYK
files.

Note: Color Target Adjustment (CTA) files appear in the CMYK Link menu when
the CTA was created to adjust a link.

Gray Adjust is used to select an optional grayscale adjustment. See
Grayscale Target Adjustment for more information. Select a grayscale

adjustment file to modify grayscale color processing.

Print a small "proof mark" when Imation-approved color settings are
used. When this box is checked, a proof mark will appear on Co-Branded

Matchprint™ Color Laser Proofing Paper and color targets.

Supplied ICC Device Links - Basic Mode

The device link drop-down list allows the user to select a pre-built ICC device
link profile that maps the CMYK output of the RIP to the output device.

The following list contains the supplied ICC Device Links available in Basic
mode:

Japanese Press Color - A CMYK ICC device link, targeted to DIC
color. This color target is intended for use on Xerox Color Xpressions
bond paper.

Short Run Color - A CMYK ICC device link, targeted to Imation
Matchprint Classic SWOP color. This color target is intended for use on
Xerox Color Xpressions bond paper.

Newsprint Color - A CMYK ICC device link, targeted to newsprint
color. This color target is intended for use on Xerox Color Xpressions
bond paper.

Internet Graphics - An RGB or CMYK ICC device link, targeted to
sRGB color space. This color target is intended for use on Xerox Color
Xpressions bond paper. Internal code ensures the device link (RGB or
CMYK) maps to your selected media.

32

Business Graphics - An RGB or CMYK ICC device link, targeted to
saturated or vivid color. This color target is intended for use on Xerox
Color Xpressions bond paper or Transparency. Internal code ensures
the device link (RGB or CMYK) maps to your selected media.

Uncorrected - No color correction, output runs to 400% total ink, this

Imation Corp. 2001

Imation Matchprint™ Professional Server User Guide

option will not be an available selection when setting up a spooler or
hot folder. A warning will be displayed if user selects this target at the
server. This target should only be used to create an ICC profile of the
device.

Matchprint US Web Standard - A CMYK ICC device link, targeted to
Imation Matchprint™ Classic SWOP® colors. This color target is
intended for use on the glossy, heavier weight Co-Branded
Matchprint™ Color Laser Proofing Commercial and Publication Paper.

Matchprint US Web Low Gain - A CMYK ICC device link, targeted to
Imation Matchprint™ SWOP® Lo-Gain colors. This color target is
intended for use on the glossy, heavier weight Co-Branded
Matchprint™ Color Laser Proofing Commercial and Publication Paper.

US Web SWOP® - A CMYK ICC device link, targeted to a certified
SWOP® press sheet. This color target is intended for use on the
glossy, heavier weight Co-Branded Matchprint™ Color Laser Proofing
Publication Paper.

Matchprint US Sheetfed - A CMYK ICC device link, targeted to
Imation Matchprint™ Commercial Lo-Gain colors. This color target is
intended for use on the glossy, heavier weight Co-Branded
Matchprint™ SuperWhite or Commercial paper. Internal code ensures
the device link maps to your selected media.

Matchprint Euro Low Gain - A CMYK ICC device link, targeted to
Imation Matchprint™ Euro Commercial Lo-Gain with Opaque Cyan
colors. This color target is intended for use on the glossy, heavier
weight Co-Branded Matchprint™ SuperWhite or Commercial paper.

Matchprint Euro Med Gain - A CMYK ICC device link, targeted to
Imation Matchprint™ Euro Standard colors with Opaque Cyan colors.
This color target is intended for use on the glossy, heavier weight Co­Branded Matchprint™ SuperWhite or Commercial paper.

Imation Corp. 2001

33
