Aneroid Sphygmomanometer and
Stethoscopes
Aneroids
Stethoscope Spare Parts Catalog
PN 95P507 Rev B.
© 2001 Welch Allyn Inc.
All Rights Reserved
Welch Allyn Aneroid Sphygmomanometer and Stethoscope Spare Parts Catalog
Revision History
Revision Date Author Description
A 1/24/01 JDB Initial Release of Catalog
B 10/12/01 JDB Removed the columns that
listed the prices of the parts.
Page 2
Welch Allyn Aneroid Sphygmomanometer and Stethoscope Spare Parts Catalog
Table Of Contents
Section 1: Classic Pocket Aneroid Replacement Parts....................................................................................4
Section 2: Classic Hand Aneroid Replacement Parts......................................................................................5
Section 3: 767 Wall/Mobile Aneroid Replacement Parts................................................................................6
Section 4: Classic Wall/Mobile Aneroid Replacement Parts...........................................................................7
Section 5: Economy Aneroid Replacement Parts............................................................................................8
Section 6: Silver Ring Hand Aneroid Replacement Parts................................................................................9
Section 7: Pro Check TR2 Hand Aneroid Replacement Parts.......................................................................10
Section 8: The Elite Stethoscope Replacement Parts.....................................................................................11
Section 9: Harvey DLX Stethoscopes Replacement Parts.............................................................................13
Section 10: Original Harvey Stethoscopes Replacement Parts......................................................................14
Section 11: Spectrum Stethoscopes Replacement Parts ................................................................................15
Section 12: Medallion Stethoscopes Replacement Parts...............................................................................17
Section 13: Meditron Electronic Stethoscope Replacement Parts.................................................................18
Page 3
Welch Allyn Aneroid Sphygmomanometer and Stethoscope Spare Parts Catalog
Section 1: Classic Pocket Aneroid
Replacement Parts
The following are the list of replacement parts for the Pocket Aneroid
Gauge that can be purchased through Welch Allyn Inc.
Part Number
51P52 Clip Assembly
2P1623 Case
32P180 Lock nut
34P760A Crystal
3P831 Bezel
35P804 Screw cap (NS)
61S681 Diaphragm
63S401 Pointer
93S617 Movement
9P1799 Screw,
11P363 Spring
7P689 Pin for Clip
Description
Assembly
Movement
Page 4
Welch Allyn Aneroid Sphygmomanometer and Stethoscope Spare Parts Catalog
Section 2: Classic Hand Aneroid
Replacement Parts
The following are the list of replacement parts for the Classic Hand Aneroid
Gauge that can be purchased through Welch Allyn Inc.
Part Number
12P368 Lure Lock Fitting
9P2651 Screw, Cover
9S132 Thumb Screw
42P252 Valve Body Assembly
5090-30 Screen Assy/Bulb
12P490 Bulb Adapter
2P1627A Case
5086-01 Bulb
2P1628 Cover, Hand Gauge
3P831 Bezel
34P760A Crystal
63S401 Pointer
9P1799 Screw, Movement
93S617 Movement
61S694 Diaphragm Assembly
32P527 Lock Nut
Description
Adapter
Page 5
Welch Allyn Aneroid Sphygmomanometer and Stethoscope Spare Parts Catalog
Section 3: 767 Wall/Mobile Aneroid
Replacement Parts
The following are the list of replacement parts for the 767 Wall/Mobile
Aneroid Gauge that can be purchased through Welch Allyn Inc.
767 Model
Part Number Description
3P844 Bezel
34P768 Crystal
63S412 Pointer
93S617A Movement
61S681 Diaphragm Assembly
2P1138 Mount
32P727 Nut
2P1631 Case
32P763 Lock nut, Case - Not
8P1064 Bushing - Not pictured
96P135 Basket - Not pictured
9P2841 Dial Mounting Screw
pictured
