VTech CS6619-2, CS6619-15, CS6619-16, CS6519-14, CS6519-15 User Manual

1

Abridged user’s manual

CS6519/CS6519-14/
CS6519-15/CS6519-16/
CS6519-17/CS6519-19/
CS6519-2

DECT 6.0 cordless telephone

Introduction

To help protect the environment, this Abridged user’s manual provides you with
the basic installation and use instructions. A limited set of features are described in
abbreviated form.

Please refer to the online User’s manual for a full set of installation and operation
instructions at www.vtechphones.com.

Before using this VTech product, please read Important safety instructions on
page 11 of this user’s manual.

The ENERGY STAR® program (www.energystar.gov) recognizes
and encourages the use of products that save energy and help
protect our environment. We are proud to mark this product with
the ENERGY STAR

®

label indicating it meets the latest energy

efficiency guidelines.

Telephones identified with this logo have reduced noise and
interference when used with most T-coil equipped hearing aids and
cochlear implants. The TIA-1083 Compliant Logo is a trademark of
the Telecommunications Industry Association. Used under license.

T

Compatible with

Hearing Aid T-Coil

TIA-1083

BC

Register online to get an additional 3-month warranty!

Go to www.vtechphones.com to register your product for enhanced warranty
support and latest VTech product news.

2

Parts checklist

Your telephone package contains the following items. Save your sales receipt and
original packaging in the event warranty service is necessary.

Telephone
line cord

Battery

(

1 for CS6519/CS6519­14/CS6519-15/CS659-16/
CS6519-17/CS6519-19)
(2 for CS6519-2)

Telephone base
power adapter

Battery compartment
cover

(

1 for CS6519/CS6519­14/CS6519-15/CS659-16/
CS6519-17/CS6519-19)
(2 for CS6519-2)

Charger and
charger adapter

(1 for CS6519-2)

Wall mount
bracket

Handset

(1 for CS6519/CS6519­14/CS6519-15/CS659-16/
CS6519-17/CS6519-19)
(2 for CS6519-2)

Telephone base

Abridged user’s manual

Abridged user’s manual

3

Telephone base and charger installation

Install the telephone base and charger as shown below.

Use only the power adapters and batteries supplied with this product. To
order a replacement, visit our website at www.vtechphones.com or call
1 [phone]. In Canada, go to www.vtechcanada.com or call
1 [phone].

Battery charging

Once you have installed the battery, the screen indicates the battery status (see
the table below).

Battery indicators Battery status Action

The screen is blank, or
displays Put in charger
and flashes.

The battery has no or very little
charge. The handset cannot
be used.

Charge without interruption
(at least 30 minutes).

The screen displays
Low battery and flashes.

The battery has enough charge
to be used for a short time.

Charge without interruption
(about 30 minutes).

The screen displays
HANDSET X.

The battery is charged.

To keep the battery charged,
place it in the telephone base
or charger when not in use.

Battery installation

Install the battery as shown below.

Plug the battery connector
securely into the socket.

1. Place the battery with the label
THIS SIDE UP facing up and
the wires inside the battery
compartment.

2.

Slide the battery compartment cover
towards the center of the handset until
it clicks into place.

3. Place the handset in the telephone
base or charger to charge.

4.

CHARGE
light remains on
when charging.

Telephone base

Charger

Electrical outlet
(not controlled
by a wall switch)

Telephone base
power adapter

Telephone line cord

Telephone wall jack

Charger
adapter

Electrical outlet
(not controlled
by a wall switch)

A DSL filter (not
included) is required
if you have DSL
high-speed Internet
service.

The DSL filter must
be plugged into the
telephone wall jack.

For best performance, keep the handset in the telephone base or charger when
not in use.

The battery is fully charged after 11 hours of continuous charging.

•

•

4

Wall mounting (optional)

To mount your telephone on a wall:

Route the telephone line cord
through the hole on the wall mount
bracket and plug it into the telephone
wall jack. Route the power cord out
of the telephone base and plug it into
an electrical outlet not controlled by
a wall switch.

3. Align the holes on the bracket with
the standard wall plate and slide the
bracket down until it locks securely.
Bundle the telephone line cord
and power adapter cord neatly
with twist ties.

4.

Position the telephone base against
the wall mount bracket with the
extended tabs marked B on top.
Insert the extended tabs marked B
on the wall mount bracket into the
slots marked B on the back of the
telephone base. Push the telephone
base down until it clicks securely.

2.Remove the telephone line cord
from the telephone wall jack, and the
telephone base power adapter from
the electrical outlet (if necessary).

1.

Handset overview

CID/ /VOLUME

Review the caller ID log when
the phone is not in use.

Decrease the listening volume
during a call.

Scroll down while in a menu,
or in the directory, caller ID log
or redial list.

Move the cursor to the left
when entering numbers or
names.

•

•

•

•

/FLASH

Make or answer a call.
Answer another incoming call

during a call.

•

•

MUTE/DELETE

Mute the microphone during
a call.

Delete digits or characters
while using the dialing keys.

Silence the ringer temporarily
while the handset is ringing.

Delete the displayed entry
while in the directory, caller ID
log or redial list.

•

•

•

•

CHARGE light

On when the handset is
charging.

•

TONE

Switch to tone dialing
temporarily during a call.

•

Dialing keys

Enter numbers or characters.•

/ /VOLUME

Review the directory when the
phone is not in use.

Increase the listening volume
during a call.

Scroll up while in a menu, or
in the directory, caller ID log or
redial list.

Move the cursor to the right
when entering numbers or
names.

•

•

•

•

MENU/SELECT

Show the menu.
While in a menu, press to

select an item, or save an
entry or setting.

•

•

OFF/CANCEL

Hang up a call.
Silence the ringer temporarily

while the handset is ringing.
Press and hold to erase the

missed call indicator while the
phone is not in use.

Press to return to the previous
menu, or press and hold to
return to idle mode, without
making changes.

•

•

•

•

REDIAL/PAUSE

Press repeatedly to review the
redial list.

Press and hold to insert a
dialing pause while dialing or
entering a number.

•

•

QUIET#

Press and hold to set and turn
on

the quiet mode, or turn it off.

Press repeatedly to show other
dialing options when reviewing a
caller ID log entry.

•

•

Make or answer a call using the
handset speakerphone.

During a call, press to switch
between the speakerphone and
the handset.

•

•

INT

Start an intercom conversation
or transfer a call (for
multi-handset models only).

•

1

Press repeatedly to add or
remove 1 in front of the
caller ID

log entry before dialing

or saving it to the directory.
Press and hold to set or dial

your voicemail number.

•

•

5

Telephone base overview

Using the menu

Press MENU when the handset is not in use.
Press or until the screen displays the desired feature menu.
Press SELECT.

To return to the previous menu, press CANCEL.
To return to idle mode, press and hold CANCEL.

Telephone settings

Default settings are indicated by asterisks (*).

Menu setting Description Options

LCD language

Set the screen display language.

English*
Français
Español

Voicemail #

Set the speed dial voicemail number.

Voicemail #

-

Clr voicemail

Turn off the voicemail indicators (see the note
below).

Reset VM Icon?

Key tone

Set whether the handset beeps whenever a
key is pressed.

Key tone:On*
Key tone:Off

Home area code

Set the home area code so that the caller ID
log stores only seven digits for local
telephone numbers.

Home area code
_ _ _

Dial mode

Set the telephone to be touch-tone or pulse
dialing.

Touch-tone*
Pulse

The following are some of the telephone features you may wish to set. Refer to
Telephone settings in the online Complete user’s manual for complete instructions
on setting all telephone features.

Ringer volume

You can adjust the ringer volume level, or turn the ringer off.

Press MENU when the handset is not in use.
Scroll to Ringers and then press SELECT twice.
Press or to sample each volume level, then press SELECT to save.

When the ringer volume is set to Off, the handset still rings when you press

/FIND HANDSET on the telephone base.

Set date and time

If you subscribe to caller ID service, the day, month and time are set automatically
with each incoming call. You can also set the date and time manually.

Press MENU when the handset is not in use.
Scroll to Set date/time and then press SELECT.
Use the dialing keys (0-9) to enter the month (MM), date (DD) and year (YY).

Then press SELECT.
Use the dialing keys (0-9) to enter the hour (HH) and minute (MM).

Then press or to choose AM or PM.
Press SELECT to save.

1.

2.

3.

•

•

1.

2.

3.

1.

2.

3.

4.

5.

Use the Clr voicemail feature when the telephone indicates there is new

voicemail but there is none. For example, when you have accessed your voicemail
while away from home. The Clr voicemail feature only turns off the indicators;
it does not delete your voicemail messages. As long as you have new voicemail
messages, your telephone service provider continues to send the signal that turns

IN USE light

Flashes when there is an incoming call, or
another telephone sharing the same line is
in use.

On when the handset is in use.

•

•

/FIND HANDSET

Press to page all system handsets.•
