VTech CS6509-15, CS6509-14, CS6509-16, CS6509-17, CS6509-19 User Manual

1

CS6509/CS6509-14/
CS6509-15/CS6509-16/
CS6509-17/CS6509-19

DECT 6.0 accessory handset
for use with VTech models
CS6519/CS6529

User’s manual

Congratulations

on purchasing your new VTech product. Before using this telephone, please read
Important safety instructions on page 5 of this manual.

This manual has instructions on how to set up and register your new handset.
For complete instructions on using the handset, see the Abridged user’s manual
that came with your telephone base.

Please refer to the User’s manual for a full set of installation and operation
instructions at www.vtechphones.com.

The ENERGY STAR® program (www.energystar.gov) recognizes
and encourages the use of products that save energy and help
protect our environment. We are proud to mark this product with
the ENERGY STAR® label indicating it meets the latest energy
efficiency guidelines.

Telephones identified with this logo have reduced noise and
interference when used with most T-coil equipped hearing
aids and cochlear implants. The TIA-1083 Compliant Logo is
a trademark of the Telecommunications Industry Association.
Used under license.

Register online to get an additional 3-month warranty!
Visit www.vtechphones.com.

Registration

Register your product online for enhanced warranty support.

Product news

Learn about the latest VTech products.

BC

T

Compatible with

Hearing Aid T-Coil

2

Battery installation

Install the battery as shown below.

Plug the battery connector
securely into the socket.

1.

Place the battery with the label
THIS SIDE UP facing up and
the wires inside the battery
compartment.

2.

Slide the battery compartment cover
towards the center of the handset
until it clicks into place.

3. Place the handset in the telephone
base or charger to charge.

4.

CHARGE
light remains
on when
charging.

If the handset will not be used for a long time, disconnect and remove the battery
to prevent possible leakage.

To purchase a replacement battery, visit our website at www.vtechphones.com or
call 1 [phone]. In Canada, go to www.vtechcanada.com or dial
1 [phone].

•

•

Parts checklist

Your telephone package contains the following items. Save your sales receipt and
original packaging in the event warranty service is necessary.

Battery

Battery compartment
cover

Charger and
charger adapter

Handset

User’s manual

User’s manual

3

Add and register a handset

You can add new handsets (CS6509/CS6509-14/CS6509-15/CS6509-16/
CS6509-17/CS6509-19, purchased separately) to your telephone system. Each

handset must be registered with the telephone base before use. When first
purchased, each expansion handset displays To register HS and See manual
alternately. You may need to charge the handset before registering it to the
telephone base.

To register a handset:

Place the new (non-registered) handset in the telephone base.

2. After about 10 seconds, the handset displays Registering... When the

registration process completes, the handset displays Registered and you
hear a beep. The registration process takes about 90 seconds to complete.

Deregister handsets

If you want to replace a handset or reassign the designated handset number of
a registered handset, you must deregister all the handsets and then individually
register each handset.

To deregister all handsets:

Press and hold FIND HANDSET on the telephone base for about 10 seconds
until the IN USE light on the telephone base turns on and starts to flash.

Immediately press FIND HANDSET again. You must press FIND HANDSET
while the IN USE light is still flashing. The IN USE light flashes for approximately
five seconds.

All handsets display To register HS and See manual alternately when the
deregistration process completes. The deregistration process takes about
10 seconds to complete.

1.

1.

2.

3.

CS6519 base CS6529 base

Do not place the handset
in the charger.

Battery charging

Once you have installed the battery, the screen indicates the battery status
(see the table below).

Battery indicators Battery status Action

The screen is blank, or
displays Put in charger
and flashes.

The battery has no or very little
charge. The handset cannot
be used.

Charge without interruption
(at least 30 minutes).

The screen displays
Low battery and flashes.

The battery has enough charge
to be used for a short time.

Charge without interruption
(about 30 minutes).

The screen displays
HANDSET X.

The battery is charged. To keep the battery charged,

place it in the telephone
base or charger when not
in use.

For best performance, keep the handset in the telephone base or charger when
not in use.

The battery is fully charged after 11 hours of continuous charging.
If you place the handset in the telephone base or the charger without plugging

in the battery, the screen displays NO BATTERY.

•

•

•

When the battery is fully charged, you can expect the following performance:

Operation Operating time
While in handset use (talking*) Up to 7 hours

While in speakerphone mode (talking*) Up to 3.5 hours
While not in use (standby**) Up to 5 days

*Operating times vary depending on your actual use and the age of the battery.
**Handset is not charging or in use.
