VTech CS6409 User Manual
User’s manual
Accessory handset for
use with VTech models
CS6419/CS6428/CS6429
www.vtechphones.com
Model: CS6409
Congratulations
T
Compatible with
Hearing Aid T-Coil
TIA-1083
on purchasing your new VTech product. Before using this
telephone, please read Important safety instructions
on pages 9-10 of this manual.
This manual has instructions on how to set up and register your
new handset. For complete instructions on using the handset, see
the user’s manual that came with your telephone base.
If you cannot nd your user’s manual, you can view or download it at
www.vtechphones.com. In Canada, go to www.vtechcanada.com.
The ENERGY STAR® program (www.energystar.gov)
recognizes and encourages the use of products that save
energy and help protect our environment. We are proud to
mark this product with the ENERGY STAR® label indicating it
meets the latest energy efciency guidelines.
Telephones identied with this logo have reduced noise and
interference when used with most T-coil equipped hearing
aids and cochlear implants. The TIA-1083 Compliant Logo is
a trademark of the Telecommunications Industry Association.
Used under license.
Table of contents
Getting started ............................................................................1
Parts checklist ..............................................................................1
Battery installation ........................................................................2
Battery charging ...........................................................................3
Add and register a handset .........................................................4
Replace a handset........................................................................5
Handset layout .............................................................................6
Appendix .....................................................................................8
Battery ..........................................................................................8
Important safety instructions.........................................................9
Precautions for users of implanted cardiac pacemakers ............11
Operating range..........................................................................11
Maintenance ...............................................................................12
About cordless telephones .........................................................13
The RBRC® seal .........................................................................13
Limited warranty .........................................................................14
FCC, ACTA and IC regulations ..................................................17
Technical specications..............................................................19
i
Getting started
Parts checklist
Your telephone package contains the following items. Save your
sales receipt and original packaging in case it is necessary to ship
your telephone for warranty service.
Battery compartment
cover
Charger and charger adapter
To purchase a replacement battery or power adapters, visit our
website at www.vtechphones.com or call 1 (800) 595-9511. In
Canada, go to www.vtechcanada.com or call 1 (800) 267-7377.
Battery
User’s manual
1
Handset
Getting started
Battery installation
Install the battery as shown below.
Plug the battery connector securely into the socket inside the
1.
handset battery compartment.
Place the battery with the label THIS SIDE UP facing up and the
2.
wires inside the battery compartment.
Align the cover flat against the battery compartment, then slide it
3.
towards the center of the handset until it clicks into place.
Charge the handset by placing it in the telephone base or
4.
charger. The CHARGE light is on when the handset is charging.
1
3 4
CHARGE light
remains on when
charging.
If the handset will not be used for a long time, disconnect
•
and remove the battery to prevent possible leakage.
To purchase a replacement battery, visit our website at
•
www.vtechphones.com or call 1 (800) 595-9511. In Canada,
go to www.vtechcanada.com or dial 1 (800) 267-7377.
2
2
Getting started
Battery charging
Once you have installed the battery, the screen indicates the
battery status (see the table below). If necessary, place the
handset in the telephone base or charger to charge the battery.
For best performance, keep the handset in the telephone base or
charger when not in use. The battery is fully charged after
10 hours of continuous charging. See the table on page 8 for
battery operating times.
If the screen is blank, you need to charge the handset without
interruption for at least 30 minutes to give the handset enough
charge to use the telephone for a short time. When the battery is
low, the handset plays four short beeps and shows LOW BATTERY
along with a flashing icon. When you are on a call in low battery
mode, the handset plays four short beeps every 50 seconds.
The following table summarizes the battery charge indicators and
actions to take.
Battery indicators Battery status Action
The screen is blank,
or shows
PLACE IN CHARGER
and flashes.
The screen shows
LOW BATTERY and
flashes.
The screen shows
HANDSET X.
Battery has no
charge or very
little charge. The
handset cannot
be used.
Battery has
enough charge to
be used for a
short time.
Battery is charged. To keep the battery
Charge without
interruption (at least
30 minutes).
Charge without
interruption (at least
30 minutes).
charged, place it in the
telephone base or charger
when not in use.
If you place the handset in the telephone base or charger without
plugging in a battery, the screen displays NO BATTERY.
After you install your telephone or power
returns following a power outage, the handset
will prompt you to set the date and time. To skip
setting the date and time, press OFF/CANCEL.
3
SET DATE
--/--/--
Getting started
Add and register a handset
Each new handset (CS6409) must be registered with the
telephone base before use. When first purchased, each
expansion handset shows 1.PRESS FIND HS ON BASE 4 SEC
and 2.THEN PRESS # ON HANDSET alternately. You may need
to charge the handset before registering it to the telephone base.
For more details on battery charging, see the table on page 3.
To register a handset:
Place the unregistered handset in the telephone base or
1.
charger. If 1.PRESS FIND HS ON BASE 4 SEC and
2.THEN PRESS # ON HANDSET do not appear alternately
on the handset screen after a few seconds, remove the
handset and place it in the telephone base or charger again.
On the telephone base, press and hold
2.
/FIND HANDSET for about four seconds
until the red IN USE light on the telephone base
turns on.
On the handset, press # (pound key) and the
3.
handset shows REGISTERING.....
PLEASE WAIT. The handset shows HANDSET REGISTERED
and you hear a beep when the registration process completes.
It takes about 60 seconds to complete.
When the registration process is complete, the newly registered
handset is assigned the next available handset registration
number. For instance, if you already have HANDSET 1, the next
registered handset will be HANDSET 2.
If the registration fails, the handset shows REGISTRATION
•
FAILED, then the handset shows 1.PRESS FIND HS ON BASE
4 SEC and 2.THEN PRESS # ON HANDSET alternately. To
reset the handset, remove the handset from the telephone
base and place it back in. Try the registration process again.
You cannot register a handset if any other system handset
•
is in use.
To reset the telephone, unplug the power and the battery for
•
a few seconds then plug them back in.
Only one handset can register to the telephone base at a time.
•
4
