Volvo Early S80 2015 Owner's Manual

W E B E D I T I O N

O W N E R ' S M A N U A L

DEAR VOLVO OWNER

THANK YOU FOR CHOOSING VOLVO

We hope you will enjoy many years of driving
pleasure in your Volvo. The car has been
designed for the safety and comfort of you and
your passengers. Volvo is one of the safest cars in
the world. Your Volvo has also been designed to
satisfy all current safety and environmental
requirements.

In order to increase your enjoyment of the car, we
recommend that you familiarise yourself with the
equipment, instructions and maintenance infor­mation contained in this owner's manual.

Table of contents

2

* Option/accessory, for more information, see Introduction.

01

01 Introduction

Owner information.................................... 13

Reading the owner's manual.................... 13

Digital owner's manual in the car.............. 16

Recording data......................................... 18

Accessories and extra equipment............ 18

Information on the Internet....................... 19

Volvo ID..................................................... 19

Volvo Cars' environmental philosophy..... 21

The owner's manual and the environ-

ment.......................................................... 23

Laminated glass........................................ 23

02

02 Safety

General information on seatbelts.............. 25

Seatbelt - putting on................................. 26

Seatbelt - loosening.................................. 26

Seatbelt - pregnancy................................ 27

Seatbelt reminder...................................... 27

Seatbelt tensioner..................................... 28

Safety - warning symbol........................... 28

Airbag system........................................... 29

Driver airbag.............................................. 30

Passenger airbag...................................... 31

Passenger airbag - activating/deactivat-

ing*............................................................ 32

Side airbag (SIPS)..................................... 34

Side airbag (SIPS) - child seat/booster

cushion..................................................... 35

Inflatable Curtain (IC)................................ 35

General information on WHIPS (whiplash

protection)................................................. 36

WHIPS - child seats.................................. 37

WHIPS - seating position.......................... 37

When the systems deploy......................... 38

General information on safety mode......... 39

Safety mode - attempting to start the

car............................................................. 40

Safety mode - moving the car.................. 41

02

General information on child safety.......... 41

Child seats................................................ 42

Child seats - location................................ 46

Child seat - ISOFIX................................... 47

ISOFIX - size classes................................ 47

ISOFIX - types of child seat...................... 49

Child seats - upper mounting points........ 51

Table of contents

* Option/accessory, for more information, see Introduction.

3

03

03 Instruments and controls

Instruments and controls, left-hand drive

car - overview........................................... 53

Instruments and controls, right-hand

drive car - overview................................... 56

Combined instrument panel...................... 59

Analogue combined instrument panel -

overview.................................................... 59

Digital combined instrument panel -

overview.................................................... 60

Eco guide & Power guide*........................ 63

Combined instrument panel - meaning of

indicator symbols...................................... 64

Combined instrument cluster - meaning

of warning symbols................................... 66

Outside temperature gauge...................... 68

Trip meter.................................................. 68

Clock......................................................... 69

Licenses - combined instrument panel..... 69

Symbols in the display.............................. 70

Volvo Sensus............................................ 73

Key positions............................................ 74

Key positions - functions at different lev-

els.............................................................. 74

Seats, front................................................ 76

Seats, front - electrically operated*.......... 77

03

Seats, rear................................................. 78

Steering wheel.......................................... 79

Heating* of the steering wheel.................. 80

Light switches........................................... 81

Position/parking lamps............................. 83

Daytime running lights.............................. 83

Tunnel detection*...................................... 84

Main/dipped beam.................................... 84

Active high beam*..................................... 85

Active Xenon headlamps*......................... 87

Rear fog lamp........................................... 87

Brake lights............................................... 88

Hazard warning flashers........................... 88

Direction indicators................................... 89

Interior lighting.......................................... 90

Home safe light duration........................... 91

Approach lighting...................................... 91

Headlamps - adjusting headlamp pat-

tern............................................................ 92

Wipers and washing.................................. 96

Power windows......................................... 97

Sun blind*.................................................. 99

Door mirrors.............................................. 99

03

Windows and rearview and door mirrors

- heating.................................................. 101

Rearview mirror - interior........................ 101

Compass*............................................... 102

Sunroof*.................................................. 103

Menu navigation - combined instrument

panel....................................................... 105

Menu overview - combined instrument

panel....................................................... 106

Messages................................................ 106

Messages - handling............................... 107

MY CAR.................................................. 108

Trip computer......................................... 109

Trip computer - analogue combined

instrument panel..................................... 110

Trip computer - digital combined instru-

ment panel.............................................. 114

Trip computer - supplementary informa-

tion.......................................................... 118

Trip computer - trip statistics*................ 119

Table of contents

4

* Option/accessory, for more information, see Introduction.

04

04 Climate control

General information on climate control... 121

Actual temperature................................. 122

Sensors - climate control........................ 122

Air cleaning............................................. 122

Air cleaning - passenger compartment fil-

ter............................................................ 123

Air cleaning - Clean Zone Interior Pack-

age (CZIP)*.............................................. 123

Air cleaning - IAQS*................................ 124

Air cleaning - material............................. 124

Menu settings - climate control.............. 124

Air distribution in the passenger com-

partment.................................................. 125

Electronic climate control - ECC............. 127

Heated front seats*................................. 128

Heated rear seat*.................................... 128

Ventilated front seats*............................. 129

Fan.......................................................... 130

Auto-regulation....................................... 130

Temperature control in the passenger

compartment.......................................... 130

Air conditioning....................................... 131

Demisting and defrosting the wind-

screen..................................................... 131

Air distribution - recirculation.................. 132

04

Air distribution - table............................. 134

Engine and passenger compartment

heater*..................................................... 136

Engine block heater and passenger com-

partment heater* - direct start................ 137

Engine block heater and passenger com-

partment heater* - immediate stop......... 138

Engine block heater and passenger com-

partment heater* - timer.......................... 138

Engine block heater and passenger com-

partment heater* - messages................. 140

Additional heater*.................................... 142

Fuel-driven additional heater*................. 142

Electric additional heater*....................... 143

05

05 Loading and storage

Storage spaces....................................... 145

Tunnel console........................................ 147

Tunnel console - cigarette lighter and

ashtray*................................................... 147

Glovebox................................................. 147

Inlay mats*.............................................. 148

Vanity mirror............................................ 148

Tunnel console - 12 V-sockets............... 148

Loading................................................... 149

Loading - long load................................. 150

Loading - ski hatch................................. 151

Roof load................................................. 151

Load retaining eyelets............................. 152

Loading - bag holder*............................. 152

12 V electrical socket, cargo area*......... 153

Table of contents

* Option/accessory, for more information, see Introduction.

5

06

06 Locks and alarm

Remote control key................................. 155

Remote control key - losing ................... 155

Remote control key - personalisation*.... 156

Locking/unlocking - indicator................. 157

Immobiliser.............................................. 157

Remote-controlled immobiliser with

tracking system....................................... 158

Remote control key - functions............... 158

Remote control key - range.................... 160

Remote control key with PCC* - unique

functions................................................. 160

Remote control key with PCC* - range... 161

Detachable key blade............................. 162

Detachable key blade - detaching/

attaching................................................. 162

Detachable key blade - unlocking doors 163

Privacy locking*....................................... 163

Remote control key - replacing the bat-

tery.......................................................... 165

Keyless drive*.......................................... 166

Keyless Drive* - remote control key

range....................................................... 166

Keyless drive* - secure handling of the

remote control key.................................. 167

06

Keyless drive* - interference to remote

control key function................................ 168

Keyless drive* - locking........................... 168

Keyless drive* - unlocking....................... 169

Keyless drive* - unlocking with the key

blade ...................................................... 169

Keyless Drive* - lock settings................. 170

Keyless Drive* - antenna location........... 170

Locking/unlocking - from the outside..... 171

Locking/unlocking - from the inside....... 171

Total airing function................................ 172

Locking/unlocking - glovebox................. 172

Locking/unlocking - boot lid................... 173

Deadlocks*.............................................. 174

Child safety locks - manual activation.... 175

Child safety locks - electrical activation* 175

Alarm....................................................... 176

Alarm indicator........................................ 177

Alarm - automatic re-arming................... 177

Alarm - remote control key not working. 178

Alarm signals........................................... 178

Reduced alarm level............................... 178

Type approval - remote control key sys-

tem.......................................................... 179

07

07 Driver support

Active chassis - Four C*.......................... 181

Electronic stability control (ESC) - gen-

eral.......................................................... 181

Electronic stability control (ESC) - opera-

tion.......................................................... 182

Electronic stability control (ESC) - sym-

bols and messages................................. 183

Road Sign Information (RSI)*.................. 185

Road sign information (RSI)* - operation 185
Road sign information (RSI)* - limitations 187

Cruise control*........................................ 188

Cruise control* - managing speed.......... 188

Cruise control* temporary deactivation

and standby mode.................................. 189

Cruise control* - resume set speed........ 190

Cruise control* - deactivate.................... 190

Adaptive cruise control - ACC*............... 190

Adaptive cruise control* - function......... 191

Adaptive cruise control* - overview........ 193

Adaptive cruise control* - managing

speed...................................................... 194

Adaptive cruise control* - set time inter-

val............................................................ 195

Adaptive cruise control* - temporary

deactivation, and standby mode............ 195

Table of contents

6

* Option/accessory, for more information, see Introduction.

07

Adaptive cruise control* - overtaking

another vehicle........................................ 196

Adaptive cruise control* - deactivate...... 197

Adaptive Cruise Control* - queue assis-

tance....................................................... 197

Adaptive cruise control* - switch cruise

control functionality................................ 199

Radar sensor........................................... 199

Radar sensor - limitations....................... 200

Adaptive cruise control* - fault tracing

and action............................................... 202

Adaptive cruise control* - symbols and

messages................................................ 203

Distance Warning*.................................. 205

Distance Warning* - limitations............... 206

Distance Warning* - symbols and mes-

sages....................................................... 207

City Safety™........................................... 208

City Safety™ - function........................... 208

City Safety™ - operation........................ 209

City Safety™ - limitations....................... 210

City Safety™ - laser sensor.................... 212

City Safety™ - symbols and messages.. 214

Collision warning system*....................... 215

Collision warning system* - function...... 216

07

Collision warning system* - detection of

cyclists.................................................... 217

Collision warning system* - detection of

pedestrians............................................. 218

Collision warning system* - operation.... 219

Collision warning system* - limitations... 220
Collision warning system* - camera sen-

sor limitations.......................................... 221

Collision warning system* - symbols and

messages................................................ 223

Driver Alert System*................................ 225

Driver Alert Control (DAC)*...................... 225

Driver Alert Control (DAC)* - operation... 226
Driver Alert Control (DAC)* - symbols and

messages................................................ 227

Lane Departure Warning (LDW)*............. 229

Lane Departure Warning (LDW) - func-

tion.......................................................... 229

Lane Departure Warning (LDW) - opera-

tion.......................................................... 230

Lane Departure Warning (LDW) - limita-

tions........................................................ 231

Lane Departure Warning (LDW) - sym-

bols and messages................................. 232

Park Assist*............................................. 234

Park assist syst* - function..................... 234

07

Park assist syst* - backward.................. 235

Park assist syst* - forward...................... 236

Park assist syst* - fault indication........... 237

Park assist syst* - cleaning the sensors. 237

Park assist camera*................................ 238

Park assist camera - settings................. 240

Park assist camera - limitations.............. 241

BLIS*....................................................... 241

BLIS* - operation.................................... 242

BLIS - symbols and messages............... 244

Adjustable steering force*....................... 245

Type approval - radar system................. 245

Table of contents

* Option/accessory, for more information, see Introduction.

7

08

08 Starting and driving

Alcolock*................................................. 247

Alcolock* - functions and operation........ 247

Alcolock* - storage.................................. 248

Alcolock* - before starting the engine.... 248

Alcolock* - to bear in mind..................... 250

Alcolock* - symbols and text messages. 251

Starting the engine.................................. 252

Switching off the engine......................... 253

Steering lock........................................... 253

Remote start (ERS)*................................ 254

Remote start (ERS) - operation............... 254

Remote start (ERS) - symbols and mes-

sages....................................................... 256

Starting the engine – Flexifuel................. 257

Jump starting with battery...................... 258

Gearboxes............................................... 259

Manual gearbox...................................... 260

Gear shift indicator*................................ 260

Automatic gearbox -- Geartronic*........... 261

Automatic gearbox -- Powershift*.......... 265

Gear selector inhibitor............................. 267

Hill start assist (HSA)*............................. 268

Start/Stop*.............................................. 268

Start/Stop* - function and operation....... 269

08

Start/Stop* - the engine does not stop... 271

Start/Stop* - the engine auto-starts........ 272

Start/Stop* - the engine does not auto-

start......................................................... 273

Start/Stop* - involuntary stop manual

gearbox................................................... 274

Start/Stop* - settings.............................. 274

Start/Stop* - symbols and messages..... 275

ECO*....................................................... 277

All Wheel Drive - AWD*........................... 279

Foot brake............................................... 279

Foot brake - anti-lock braking system.... 280

Foot brake - emergency brake lights and

automatic hazard warning flashers......... 280

Foot brake - emergency brake assis-

tance....................................................... 281

Parking brake.......................................... 282

Fording.................................................... 286

Overheating............................................. 286

Driving with open tailgate....................... 287

Overload - starter battery........................ 287

Before a long journey.............................. 288

Winter driving.......................................... 288

Fuel filler flap - Opening/closing............. 289

Fuel filler flap - manual opening.............. 289

08

Filling up with fuel................................... 289

Fuel - handling........................................ 290

Fuel - petrol............................................. 291

Fuel - diesel............................................. 291

Catalytic converters................................ 293

Fuel - bioethanol E85.............................. 293

Diesel particle filter (DPF)........................ 294

Economical driving.................................. 295

Driving with a trailer................................ 296

Driving with a trailer - manual gearbox... 297
Driving with a trailer - automatic gearbox 297

Towing bracket/Towbar.......................... 298

Detachable towbar - storage.................. 298

Detachable towbar - specifications........ 298

Detachable towbar - attachment/

removal................................................... 299

Towing.................................................... 301

Towing eye.............................................. 303

Recovery................................................. 304

Table of contents

8

* Option/accessory, for more information, see Introduction.

09

09 Wheels and tyres

Tyres - direction of rotation.................... 306

Tyres - maintenance............................... 306

Tyres - tread wear indicators.................. 308

Wheel bolts............................................. 308

Tools....................................................... 308

Jack*....................................................... 309

Winter tyres............................................. 309

Wheel and wheel rim dimensions........... 310

Tyres - dimensions.................................. 310

Tyres - load index................................... 311

Tyres - speed ratings.............................. 311

Changing wheels - removing wheels...... 312

Changing wheels - fitting........................ 314

Tyres - air pressure................................. 315

Warning triangle...................................... 316

First aid kit*............................................. 317

Tyre pressure monitoring*....................... 317

TPMS (Tyre Pressure Monitoring

System)* - general................................... 318

TPMS (Tyre Pressure Monitoring

System)* - adjusting (recalibration)......... 319

TPMS (Tyre Pressure Monitoring

System)* - status..................................... 320

TPMS (Tyre Pressure Monitoring

System)* - activate/deactivate................ 321

09

TPMS (Tyre Pressure Monitoring

System)* - recommendations................. 321

TPMS (Tyre Pressure Monitoring

System)* - driveable punctured tyres*.... 322

TPMS (Tyre Pressure Monitoring
System)* - rectifying low tyre pressure... 322

TM (Tyre Monitor)*.................................. 323

Emergency puncture repair*................... 325

Emergency puncture repair kit* - loca-

tion.......................................................... 325

Emergency puncture repair kit* - over-

view......................................................... 326

Emergency puncture repair* - operation. 327
Emergency puncture repair* - recheck-

ing........................................................... 328

Emergency puncture repair kit* - inflating

the tyres.................................................. 329

Emergency puncture repair kit* - sealant 330
Type approval - tyre pressure monitoring 331

10

10 Maintenance and service

Volvo service programme....................... 338

Book service and repair*......................... 338

Raising the car........................................ 341

Bonnet - opening and closing................. 343

Engine compartment - overview............. 343

Engine compartment - checking............. 344

Engine oil - general................................. 345

Engine oil - checking and filling.............. 346

Coolant - level......................................... 349

Brake and clutch fluid - level.................. 350

Power steering fluid - level...................... 351

Climate control system - fault tracing and

repair....................................................... 352

Lamp replacement.................................. 352

Lamp replacement - headlamps............. 353

Lamp replacement - cover for main/

dipped beam bulbs................................. 354

Lamp replacement - dipped beam......... 354

Lamp replacement - main beam............. 355

Lamp replacement - extra main beam.... 355

Lamp replacement - direction indicators

front......................................................... 355

Lamp replacement - rear lamp............... 356

Lamp replacement - location of rear

lamps...................................................... 356

Table of contents

9

10

Lamp replacement - number plate light-

ing........................................................... 357

Lamp replacement - lighting in cargo

area......................................................... 357

Lamp replacement - vanity mirror light-

ing........................................................... 358

Lamps - specifications ........................... 358

Wiper blades........................................... 359

Washer fluid - filling................................ 361

Starter battery - general.......................... 361

Battery - symbols.................................... 363

Starter battery - replacement.................. 363

Battery - Start/Stop................................. 365

Electrical system..................................... 367

Fuses - general....................................... 367

Fuses - in engine compartment.............. 369

Fuses - under glovebox.......................... 373

Fuses - in the control module under the

glovebox................................................. 375

Fuses - in cargo area.............................. 377

Fuses - in the engine compartment's

cold zone................................................ 378

Car washing............................................ 380

Polishing and waxing.............................. 381

Water and dirt-repellent coating............. 382

10

Rustproofing........................................... 382

Cleaning the interior................................ 382

Paint damage.......................................... 384

11

11 Specifications

Type designations................................... 387

Dimensions............................................. 390

Weights................................................... 391

Towing capacity and towball load.......... 392

Engine specifications.............................. 395

Engine oil - adverse driving conditions... 396

Engine oil - grade and volume................ 397

Coolant - grade and volume................... 399

Transmission fluid - grade and volume... 400

Brake fluid - grade and volume............... 402

Power steering fluid - grade.................... 402

Washer fluid - quality and volume.......... 402

Fuel tank - volume.................................. 403

Fuel consumption and CO2 emissions... 404

Tyres - approved tyre pressures............. 407

Table of contents

10

12

12 Alphabetical Index

Alphabetical Index.................................. 410

Table of contents

11

INTRODU C T I O N

01 Introduction

01

}}

* Option/accessory, for more information, see Introduction.

13

Owner information

Your car is equipped with a screen where you
can find information about how your car
works (applies to certain car models). For cars
with owner information in the screen, the prin­ted owner's manual is a supplement and con­tains important text, the latest updates, as
well as instructions that can be useful when,
for practical reasons, you are unable to read
the information on the screen.

Changing the screen's language may mean
that certain information is no longer in
accordance with national or local laws and
regulations.

IMPORTANT

The driver is always responsible that the
vehicle is driven safely in traffic and that
applicable laws and regulations are fol­lowed. It is also important that the car is
maintained and handled in accordance
with Volvo's recommendations in the
owner's information.

If there should be a difference between the
information on the screen and in the prin­ted manual then it is always the printed
information that applies.

Reading the owner's manual

A good way of getting to know your new car
is to read the owner's manual, ideally before
your first journey. This will give you the oppor­tunity to familiarise yourself with new func­tions, to see how best to handle the car in dif­ferent situations, and to make the best use of
all the car's features. Please pay attention to
the safety instructions contained in the man­ual.

The specifications, design features and illus­trations in the owner's manual are not bind­ing. We reserve the right to make modifica­tions without prior notice.

©

Volvo Car Corporation

Owner's Manual in mobile devices

NOTE

The owner's manual is available for down­load as a mobile application (applies for
certain car models and mobile devices),
see www.volvocars.com.

The mobile application also includes video
and searchable content and easy naviga­tion between different sections.

Options/accessories

All types of option/accessory are marked with
an asterisk*.

In addition to standard equipment, the
owner's manual also describes options (fac­tory fitted equipment) and certain accessories
(retrofitted extra equipment).

The equipment described in the owner's
manual is not available in all cars - they have
different equipment depending on adapta­tions for the needs of different markets and
national or local laws and regulations.

In the event of uncertainty over what is stand­ard or an option/accessory, contact a Volvo
dealer.

Special texts

WARNING

Warning texts appear if there is a risk of
injury.

||

01 Introduction

01

14

IMPORTANT

"Important" texts appear if there is a risk of
damage.

NOTE

NOTE texts give advice or tips that facili­tate the use of e.g. features and functions.

Footnote

There is footnote information in the owner's
manual that is located at the bottom of the
page. This information is an addition to the
text that it refers to via a number. If the foot­note refers to text in a table then letters are
used instead of numbers for referral.

Message texts

There are displays in the car that show text
messages. These text messages are high­lighted in the owner's manual by means of
the text being slightly larger and printed in
grey. Examples of this are in menu texts and
message texts on the information display
(e.g.

Audio settings).

Decals

The car contains different types of decal
which are designed to convey important
information in a simple and clear manner. The
decals in the car have the following descend­ing degree of importance for the warning/
information.

Warning for personal injury

G031590

Black ISO symbols on yellow warning field,
white text/image on black message field.
Used to indicate the presence of danger
which, if the warning is ignored, may result in
serious personal injury or fatality.

Risk of property damage

G031592

White ISO symbols and white text/image on
black or blue warning field and message field.
Used to indicate the presence of danger
which, if the warning is ignored, may result in
damage to property.

01 Introduction

01

15

Information

G031593

White ISO symbols and white text/image on
black message field.

NOTE

It is not intended that the decals illustrated
in the owner's manual should be exact
replicas of those in the car. They are
included to show their approximate
appearance and location in the car. The
information that applies to your particular
car is available on the respective decals
for your car.

Procedure lists

Procedures where action must be taken in a
certain sequence are numbered in the
owner's manual.

When there is a series of illustrations for
step-by-step instructions each step is
numbered in the same way as the corres­ponding illustration.

There are numbered lists with letters
adjacent to the series of illustrations
where the order of the instructions is not
significant.

Arrows appear numbered and unnum­bered and are used to illustrate a move­ment.

Arrows with letters are used to clarify a
movement when the reciprocal order is of
no relevance.

If there is no series of illustrations for step-by­step instructions then the different steps are
numbered with normal numbers.

Position lists

Red circles containing a number are used
in overview images where different com­ponents are pointed out. The number
recurs in the position list featured in con­nection with the illustration that describes
the item.

Bulleted lists

A bulleted list is used when there is a list of
points in the owner's manual.

Example:

•

Coolant

•

Engine oil

Related information

Related information refers to other sections
containing related information.

Images

The manual's images are sometimes sche­matic and may deviate from the car's appear­ance depending on equipment level and mar­ket.

To be continued

}} This symbol is located furthest down to

the right when an article continues on the fol­lowing page.

Continued from previous page

|| This symbol is located furthest up to the

left when an article continues from the previ­ous page.

Related information

•

The owner's manual and the environment
(p. 23)

•

Information on the Internet (p. 19)

01 Introduction

01

16

Digital owner's manual in the car

The owner's manual can be read on the
screen in the car1. The content is searchable
and it is easy to navigate between different
sections.

Open the digital owner's manual - press the

MY CAR button in the centre console, press
OK/MENU and select

Owner's manual.

For basic navigation, see Operating the sys­tem. See below for a more detailed descrip­tion.

Owner's manual, start page.

There are four options for finding information
in the owner's manual:

•

Search - Search function for finding an

article.

•

Categories - All articles sorted into cate-

gories.

•

Favourites - Quick access to favourite-

bookmarked articles.

•

Quick Guide - A selection of articles for

common functions.

Select the information symbol in the lower
right-hand corner in order to obtain informa­tion about the digital owner's manual.

NOTE

The owner's manual is not available while
driving.

Search

Searching using the daisy wheel.

Character list.

Changing the input mode (see following
table).

Use the daisy wheel to enter a search term,
e.g. "seatbelt".

1. Turn TUNE to the desired letter, press
OK/MENU to confirm. The number and
letter buttons on the control panel in the
centre console can also be used.

2. Continue with the next letter and so on.

1

Applies to certain car models.

01 Introduction

01

17

3. To change the input mode to numbers or
special characters, or to perform a
search, turn TUNE to one of the options
(see explanation in the following table) in
the list for changing the input mode (2),
press OK/MENU.

123/AB
C

Change between letters and
numbers with OK/MENU.

MORE

Change to special characters
with OK/MENU.

OK

Perform the search. Turn TUNE
to select a search result article,
press OK/MENU to go to the
article.

a|A

Changes between lowercase
and uppercase letters with OK/
MENU.

| | }

Changes from the text wheel to
the search field. Move the cur­sor with TUNE. Delete any mis­spelling with EXIT. To return to
the text wheel, press OK/
MENU.

Note that the digit and letter
buttons on the control panel
can be used for editing in the
search field.

Categories

The articles in the owner's manual are struc­tured into main categories and subcategories.
The same article can be in several appropri­ate categories in order to be found more
easily.

Turn TUNE to navigate in the category tree
and press OK/MENU to open a category -

selected

- or article - selected . Press

EXIT to go back to the previous view.

Favourites

Located here are the articles that are saved
as favourites. To select an article as a favour­ite, see the heading "Navigating in an article"
below.

Turn TUNE to navigate in the favourite list
and press OK/MENU to open an article.
Press EXIT to go back to the previous view.

Quick Guide

Located here is a selection of articles for get­ting to know the car's most common func­tions. The articles can also be accessed via
categories, but are collected here for quick
access.

Turn TUNE to navigate in the Quick Guide
and press OK/MENU to open an article.
Press EXIT to go back to the previous view.

Navigating in an article

Home - leads to the start page for the

owner's manual.
Favourite - adds/removes an article as a

favourite. You can also press the FAV
button in the centre console to add/
remove an article as a favourite.

Highlighted link - leads to linked article.

Special texts - if the article contains

warnings, important or note texts then an
associated symbol is shown here as well
as the number of such texts in the article.

Turn TUNE to navigate between the links or
scroll in an article. When the screen has
scrolled to the start/end of an article the
home and favourite options are accessed by
scrolling a further step up/down. Press OK/
MENU to activate the selection/highlighted
link. Press EXIT to go back to the previous
view.

01 Introduction

01

18

* Option/accessory, for more information, see Introduction.

Recording data

Certain information about the vehicle's opera­tion and functionality, and any incidents, are
recorded in the car.

Your vehicle contains a number of computers
whose function is to continuously check and
monitor the vehicle's operation and function­ality. Some of the computers can record
information during normal driving if they
detect an error. In addition, information is
recorded in the event of a collision or inci­dent. Parts of the recorded information are
required so that technicians can diagnose
and rectify faults in the vehicle during servic­ing and maintenance and so that Volvo can
fulfil legal requirements and other regulations.
In addition to this, the information is used for
research purposes by Volvo in order to con­tinually develop quality and safety, as the
information can contribute to a better under­standing of the factors that cause accidents
and injuries. The information includes details
of the status and functionality of various sys­tems and modules in the vehicle with regard
to engine, throttle, steering and brake sys­tems, amongst other things. This information
may include details regarding the way the
driver drives the vehicle, such as vehicle
speed, brake and accelerator pedal use,
steering wheel movement and whether or not
the driver and passengers have used their
seatbelts. For the reasons given this informa­tion may be stored in the vehicle's computers

for a certain length of time, but also as a
result of a collision or incident. This informa­tion may be stored by Volvo as long as it can
help to further develop and further enhance
safety and quality and as long as there are
legal requirements and other regulations that
Volvo needs to consider.

Volvo will not contribute to the above-descri­bed information being disclosed to third par­ties without the vehicle owner's consent.
However, due to national legislation and reg­ulations Volvo may be required to disclose
such information to authorities such as police
authorities, or others who may assert a legal
right to have access to it.

To be able to read and interpret the informa­tion recorded by the computers in the vehicle
requires special technical equipment that
Volvo, and workshops that have entered into
agreements with Volvo, have access to. Volvo
is responsible that the information, which is
transferred to Volvo during servicing and
maintenance, is stored and handled in a
secure manner and that the handling com­plies with applicable legal requirements. For
further information - contact a Volvo dealer.

Accessories and extra equipment

The incorrect connection and installation of
accessories and extra equipment can nega­tively affect the car's electronic system.

Certain accessories only function when asso­ciated software is installed in the car's com­puter system. Volvo therefore recommends
that you always contact an authorised Volvo
workshop before installing accessories or
extra equipment which are connected to or
affect the electrical system.

Heat-reflecting windscreen*

Areas where IR film is not applied.

Dimensions

A 47 mm

B 87 mm

01 Introduction

01

}}

* Option/accessory, for more information, see Introduction.

19

The windscreen is equipped with a heat­reflecting film (IR) that reduces the solar heat
radiation into the passenger compartment.

The positioning of electronic equipment, such
as a transponder, behind a glass surface with
heat-reflecting film may affect its function and
performance.

For the optimal function of electronic equip­ment, it should be positioned on the part of
the windscreen with no heat-reflecting film
(see the highlighted area in the above illustra­tion).

Information on the Internet

At www.volvocars.com there is further infor­mation concerning your car.

With a personal Volvo ID it is possible to log in
to My Volvo web, which is a personal web
page for you and your car.

QR code

A QR code reader is required to read the QR
code, which is available as a supplemental
program (app) for several mobile phones. The
QR code reader can be downloaded from e.g.
App Store, Windows Phone or Google Play.

Volvo ID

Volvo ID is your personal ID that provides
access to various services2.

Examples of services:

•

My Volvo - Your personal web page for
you and your car.

•

In an Internet-connected car* - Certain
functions and services require that you
have registered your car to a personal
Volvo ID, for example to be able to send a
new address from a map service on the
Internet directly to the car.

•

Volvo On Call, VOC* - Volvo ID is used
when logging in to the Volvo On Call
mobile app.

NOTE

Old login accounts must be upgraded to
Volvo ID in order to continue using these
services.

Advantages of Volvo ID

•

One user name and one password to
access online services, i.e. only one user­name and one password to remember.

•

When changing the username/password
for a service (e.g. VOC) it will also be
changed automatically for other services
(e.g. My Volvo)

2

The services available may vary over time and vary depending on equipment level and market.

||

01 Introduction

01

20

* Option/accessory, for more information, see Introduction.

Create a Volvo ID

To create a Volvo ID you need to enter your
personal e-mail address and follow the
instructions in the e-mail message received in
order to complete the registration. It is possi­ble to create a Volvo ID via one of the follow­ing services:

•

My Volvo web - Enter your e-mail address
and follow the instructions.

•

For an Internet-connected car* - Enter
your e-mail address in the app that
requires Volvo ID and follow the instruc­tions. Alternatively, press the Connect

button

in the centre console and

select

Apps, SETUP and follow the

instructions.

•

Volvo On Call, VOC* - Download the lat­est version of the VOC app. Choose to
create a Volvo ID from the start page and
follow the instructions.

Related information

•

Information on the Internet (p. 19)

01 Introduction

01

}}

21

Volvo Cars' environmental philosophy

Your Volvo complies with strict international
environmental standards and is also manufac-

tured in one of the cleanest and most
resource-efficient plants in the world.

G000000

Environmental care is one of Volvo Car Cor­poration's core values which influence all
operations. We also believe that our custom­ers share our consideration for the environ­ment.

Your Volvo complies with strict international
environmental standards and is also manu­factured in one of the cleanest and most
resource-efficient plants in the world. Volvo
Car Corporation has global ISO certification,
which includes the environmental standard
ISO 14001 covering all factories and several
of our other units. We also set requirements

for our partners so that they work systemati­cally with environmental issues.

Fuel consumption

Volvo cars have competitive fuel consump­tion in each of their respective classes. Lower
fuel consumption generally results in lower
emission of the greenhouse gas, carbon diox­ide.

It is possible for the driver to influence fuel
consumption. For more information read
under the heading, Reducing environmental

impact.

Efficient emission control

Your Volvo is manufactured following the
concept "Clean inside and out" – a concept
that encompasses a clean interior environ­ment as well as highly efficient emission con­trol. In many cases the exhaust emissions are
well below the applicable standards.

Clean air in the passenger compartment

A passenger compartment filter prevents dust
and pollen from entering the passenger com­partment via the air intake.

||

01 Introduction

01

22

* Option/accessory, for more information, see Introduction.

A sophisticated air quality system, IAQS*
(Interior Air Quality System) ensures that the
incoming air is cleaner than the air in the traf­fic outside.

The system consists of an electronic sensor
and a carbon filter. The incoming air is moni­tored continuously and if there is an increase
in the level of certain unhealthy gases such as
carbon monoxide then the air intake is
closed. Such a situation may arise in heavy
traffic, queues and tunnels for example.

The entry of nitrous oxides, ground-level
ozone and hydrocarbons is prevented by the
carbon filter.

Interior

The interior of a Volvo is designed to be plea­sant and comfortable, even for people with
contact allergies and for asthma sufferers.
Extreme attention has been given to choosing
environmentally-compatible materials.

Volvo workshops and the environment

Regular maintenance creates the conditions
for a long service life and low fuel consump­tion for your car. In this way you contribute to
a cleaner environment. When Volvo's work­shops are entrusted with the service and
maintenance of your car it becomes part of
our system. Volvo makes clear demands
regarding the way in which our workshops
are designed in order to prevent spills and
discharges into the environment. Our work­shop staff have the knowledge and the tools

required to guarantee good environmental
care.

Reducing environmental impact

You can easily help reduce environmental
impact - here are a few tips:

•

Avoid letting the engine idle - switch off
the engine when stationary for longer
periods. Pay attention to local regula­tions.

•

Drive economically - think ahead.

•

Perform service and maintenance in
accordance with the owner's manual's
instructions - follow the intervals recom­mended in the Service and Warranty
Booklet.

•

If the car is equipped with an engine
block heater*, use it before starting from
cold - it improves starting capacity and
reduces wear in cold weather and the
engine reaches normal operating tem­perature more quickly, which lowers con­sumption and reduces emissions.

•

High speed increases consumption con­siderably due to increased wind resis­tance - a doubling of speed increases
wind resistance 4 times.

•

Always dispose of environmentally hazar­dous waste, such as batteries and oils, in
an environmentally safe manner. Consult
a workshop in the event of uncertainty
about how this type of waste should be
discarded - an authorised Volvo work­shop is recommended.

Following this advice can save money, the
planet's resources are saved, and the car's
durability is extended. For more information
and further advice, see Eco guide (p. 63),
Economical driving (p. 295) and Fuel con­sumption (p. 404).

Recycling

As a part of Volvo's environmental work, it is
important that the car is recycled in an envi­ronmentally sound manner. Almost all of the
car can be recycled. The last owner of the car
is therefore requested to contact a dealer for
referral to a certified/approved recycling
facility.

Related information

•

The owner's manual and the environment
(p. 23)

01 Introduction

01

* Option/accessory, for more information, see Introduction.

23

The owner's manual and the environment

The paper pulp in a printed owner's manual
comes from FSC

®

certified forests or other

controlled sources.

The Forest Stewardship Council® symbol
shows that the paper pulp in a printed
owner's manual comes from FSC® certified
forests or other controlled sources.

Related information

•

Volvo Cars' environmental philosophy
(p. 21)

Laminated glass

Laminated glass

The glass is reinforced which pro­vides better protection against
break-ins and improved sound insu-

lation in the passenger compart­ment. The windscreen and the side windows*
have laminated glass.

SAFETY

02 Safety

02

25

General information on seatbelts

Heavy braking can have serious consequen­ces if the seatbelts are not used. Ensure that
all passengers are using their seatbelts during
the journey.

Tension the hip strap over the lap by pulling the
diagonal shoulder belt up towards the shoulder.
The hip strap must be positioned low down (not
over the abdomen).

It is important that the seatbelt lies against
the body so it can provide maximum protec­tion. Do not lean the backrest too far back.
The seatbelt is designed to protect in a nor­mal seating position.

Unbelted occupants will be reminded to fas­ten their (p. 26) seatbelt by means of an
audio and visual reminder (p. 27).

Remember

•

Do not use clips or anything else that can
prevent the seatbelt from fitting properly.

•

The seatbelt must not be twisted or
caught on anything.

WARNING

The seatbelts and airbags interact. If a
seatbelt is not used or is used incorrectly,
this may diminish the protection provided
by the airbag in the event of a collision.

WARNING

Each seatbelt is designed for only one per­son.

WARNING

Never modify or repair the seatbelts your­self. Volvo recommends that you contact
an authorised Volvo workshop.

If a seatbelt has been subjected to a major
load, such as in conjunction with a colli­sion, the entire seatbelt must be replaced.
Some of the protective characteristics of
the seatbelt may have been lost, even if it
appears to be undamaged. In addition,
replace the seatbelt if the belt is worn or
damaged. The new seatbelt must be type­approved and intended for installation in
the same position as the replaced seatbelt.

Related information

•

Seatbelt - pregnancy (p. 27)

•

Seatbelt - loosening (p. 26)

•

Seatbelt tensioner (p. 28)

02 Safety

02

26

Seatbelt - putting on

Put on the seatbelt (p. 25) before driving
starts.

Pull the belt out slowly and secure it by
pressing its locking tab into the seatbelt
buckle. A loud "click" indicates that the belt
has locked.

Correctly fitted seatbelt.

Incorrectly fitted seatbelt. The belt must rest on
the shoulder.

The buckles only fit the intended lock in the
rear seat1.

Remember

The seatbelt locks and cannot be withdrawn:

•

if it is pulled out too quickly

•

during braking and acceleration

•

if the car leans heavily.

Related information

•

Seatbelt - pregnancy (p. 27)

•

Seatbelt - loosening (p. 26)

•

Seatbelt tensioner (p. 28)

•

Seatbelt reminder (p. 27)

Seatbelt - loosening

Loosen the seatbelt (p. 25) when the car is
stationary.

Press the red button on the seatbelt buckle
and then let the belt retract. If the seatbelt
does not retract fully, feed it in by hand so
that it does not hang loose.

Related information

•

Seatbelt - putting on (p. 26)

•

Seatbelt reminder (p. 27)

1

Certain markets.

02 Safety

02

}}

27

Seatbelt - pregnancy

Seatbelt (p. 25) must always be worn during
pregnancy. But it is crucial that it be worn in
the correct way.

G020998

The diagonal section should wrap over the
shoulder then be routed between the breasts
and to the side of the abdomen.

The lap section should lay flat over the thighs
and as low as possible under the abdomen. –
It must never be allowed to ride upward.
Remove the slack from the seatbelt and
ensure that it fits as close to the body as pos­sible. In addition, check that there are no
twists in the seatbelt.

As the pregnancy progresses, pregnant dri­vers must adjust the seat (p. 76) and steer­ing wheel (p. 79) such that they can easily
maintain control of the vehicle as they drive
(which means that they must be able to easily
operate the foot pedals and steering wheel).

The aim should be to position the seat with as
large a distance as possible between abdo­men and steering wheel.

Related information

•

Seatbelt - putting on (p. 26)

•

Seatbelt - loosening (p. 26)

Seatbelt reminder

Unbelted occupants will be reminded to fas­ten their (p. 26) seatbelt by means of an audio
and visual reminder.

G017726

The audio reminder is speed dependent, and
in some cases time dependent. The visual
reminder is located in the roof console and in
the combined instrument panel (p. 59).

Child seats are not covered by the seatbelt
reminder system.

Rear seat

The seatbelt reminder in the rear seat has two
subfunctions:

•

Provides information on which seatbelts
(p. 25) are being used in the rear seat. A
message appears in the combined instru­ment panel when the seatbelts are in use,
or if one of the rear doors has been
opened. The message is cleared auto-

||

02 Safety

02

28

matically after driving for approximately
30 seconds or after pressing the indicator
stalk OK button (p. 105).

•

Provides a warning if one of the rear seat­belts is unfastened during travel. This
warning takes the form of a message in
the combined instrument panel along with
the audio/visual signal. The warning stops
when the seatbelt is re-fastened, or it can
also be acknowledged manually by
pressing the OK button.

The message in the combined instrument
panel showing which seatbelts are in use is
always shown. Press the OK button to see
stored messages.

Certain markets

An acoustic signal and indicator lamp remind
the driver and front seat passenger to use a
seatbelt if either of them is not wearing one.
At low speed, the audible reminder will sound
for the first 6 seconds.

Seatbelt tensioner

All the seatbelts (p. 25) are equipped with belt
tensioners. A mechanism in the seatbelt ten­sioner tightens the seatbelt in the event of a
sufficiently violent collision. The seatbelt then
provides more effective restraint for the occu­pants.

WARNING

Never insert the tongue of the passenger's
seatbelt into the buckle on the driver's
side. Always insert the tongue of the seat­belt into the buckle on the correct side. Do
not make any damages on seatbelts nor
insert any foreign objects into a buckle.
The seatbelts and buckles would then
possibly not function as intended in the
event of a collision. There is a risk of
serous injury.

Safety - warning symbol

The warning symbol is shown if a fault is
detected during fault tracing or if a system
has been activated. Where required, the
warning symbol is shown together with a
message in the combined instrument panel
(p. 59) information display.

Warning triangle and warning symbol for the air­bag system (p. 29) in the analogue combined
instrument panel.

02 Safety

02

}}

29

Warning triangle and warning symbol for the air­bag system in the digital combined instrument
panel.

The warning symbol in the combined instru­ment panel illuminates when the remote con­trol key is in key position II (p. 74). The sym­bol is extinguished after approx. 6 seconds
provided the airbag system is fault-free.

WARNING

If the warning symbol for the airbag sys­tem remains illuminated or illuminates
while driving, it means that the airbag sys­tem does not have full functionality. The
symbol indicates a fault in the seatbelt ten­sioner system, SIPS, the IC system or
some other fault in the system. Volvo rec­ommends that you contact an authorised
Volvo workshop immediately.

If the warning symbol malfunctions, the warn­ing triangle illuminates and

SRS airbag

Service required

or SRS airbag Service

urgent appears in the display. Volvo recom-

mends that you contact an authorised Volvo
workshop immediately.

Related information

•

General information on safety mode
(p. 39)

Airbag system

In the event of a frontal collision the airbag
system helps to protect the head, face and
chest of the driver and passenger.

G018665

Airbag system viewed from above, left-hand­drive car.

G018666

Airbag system viewed from above, right-hand­drive car.

||

02 Safety

02

30

The system consists of airbags and sensors.
A sufficiently violent collision trips the sensors
and the airbag(s) are inflated and become
hot. The airbag cushions the initial collision
impact for the occupant. The airbag deflates
when compressed by the collision. When this
occurs, smoke escapes into the car. This is
completely normal. The entire process,
including inflation and deflation of the airbag,
occurs within tenths of a second.

WARNING

Volvo recommends that you contact an
authorised Volvo workshop for repair.
Defective work in the airbag system could
cause malfunction and result in serious
personal injury.

NOTE

The detectors react differently depending
on the nature of the collision and whether
or not the seatbelts are fastened. Applies
to all belt positions.

It is therefore possible that only one (or
none) of the airbags may inflate in a colli­sion. The detectors sense the force of the
collision on the vehicle and the action is
adapted accordingly so that one or more
airbags are deployed.

Related information

•

Driver airbag (p. 30)

•

Passenger airbag (p. 31)

•

Safety - warning symbol (p. 28)

Driver airbag

To supplement the protection afforded by the
seatbelt (p. 25) the car is equipped on the
driver's side with an airbag (p. 29).

This airbag is fitted into the centre of the
steering wheel. The steering wheel is marked

AIRBAG.

WARNING

The seatbelts and airbags interact. If the
belt is not used or is used incorrectly, this
may diminish the protection provided by
the airbag in the event of a collision.

Related information

•

Passenger airbag (p. 31)

02 Safety

02

}}

31

Passenger airbag

To supplement the protection afforded by the
seatbelt (p. 25) on the passenger side, the car
is equipped with an airbag (p. 29).

The airbag is folded up into a compartment
above the glovebox. Its cover panel is
marked AIRBAG.

Location of the front passenger airbag in a left­hand drive car.

Location of the front passenger airbag in a right­hand drive car.

The warning label for the passenger airbag is
fitted in one of the following two locations in
the car:

Alternative 1: Position of airbag label on passen­ger side sun visor.

Alternative 2: Position of airbag label on passen­ger side door pillar. The label becomes visible
when the passenger door is opened.

WARNING

Never use a rear-facing child seat on a
seat protected by an activated airbag. Fail­ure to follow this advice can lead to death
or serious injury to the child.

WARNING

The seatbelts and airbags interact. If the
belt is not used or is used incorrectly, this
may diminish the protection provided by
the airbag in the event of a collision.

To minimise the risk of injury if the airbag
deploys, passengers must sit as upright as
possible with their feet on the floor and
backs against the backrest. Seatbelts
must be secured.

||

02 Safety

02

32

* Option/accessory, for more information, see Introduction.

WARNING

Do not put objects in front of or above the
dashboard where the passenger airbag is
located.

WARNING

Never place a child in a child seat or on a
booster cushion in the front seat if the air­bag is activated.

Never allow anybody to stand or sit in front
of the front passenger seat.

No one shorter than 140 cm should ever
sit in the front passenger seat if the airbag
is activated.

Failure to follow the advice given above
can endanger life.

Switch - PACOS*

The front passenger airbag can be deacti­vated (p. 32) if the car is equipped with a
switch, PACOS (Passenger Airbag Cut Off
Switch).

WARNING

If the car is equipped with a front passen­ger airbag, but does not have a PACOS
switch (Passenger Airbag Cut Off Switch),
then the airbag will always be activated.

Related information

•

Driver airbag (p. 30)

•

Child seats (p. 42)

Passenger airbag - activating/
deactivating*

Front passenger airbag (p. 31) can be deacti­vated if the car is equipped with a switch,
PACOS (Passenger Airbag Cut Off Switch).

Switch - PACOS

The switch for the passenger airbag (PACOS)
is located on the passenger end of the instru­ment panel and is accessible when the pas­senger door is open.

Check that the switch is in the required posi­tion. The remote control key's key blade
(p. 162) should be used to change position.

Location of airbag switch.

The airbag is activated. With the switch in
this position, persons taller than 140 cm
can sit in the front passenger seat, but

never children in a child seat or on a
booster cushion.

The airbag is deactivated. With the switch
in this position, children in a child seat or
on a booster cushion can sit in the front
passenger seat, but never persons taller
than 140 cm.

WARNING

Activated airbag (passenger seat):

Never place a child in a child seat or on a
booster cushion on the front passenger
seat when the airbag is activated. This
applies to everyone shorter than 140 cm.

Deactivated airbag (passenger seat):
No one taller than 140 cm should ever sit

in the front passenger seat when the air­bag is deactivated.

Failure to follow the advice given above
can endanger life.

NOTE

When the remote control key is in key
position II (p. 74) the warning symbol
(p. 28) for the airbag is shown in the com­bined instrument panel for
approx. 6 seconds.

Following which, the indicator in the roof
console is illuminated showing the correct
status for the front passenger seat airbag.

02 Safety

02

33

G017800

Indicator showing that the passenger airbag is
activated.

A warning symbol in the roof console indi­cates that the airbag for the front passenger
seat is activated (see preceding illustration).

WARNING

Never place a child in a child seat or on a
booster cushion in the front seat if the air-

bag is activated and the symbol

in
the roof console is illuminated. Failure to
follow this advice could endanger the life
of the child.

2

2

G017724

Indicator showing that the passenger airbag is
deactivated.

A text message and a symbol in the roof con­sole indicate that the airbag for the front pas­senger seat is deactivated (see preceding
illustration).

WARNING

Do not allow anyone to sit in the front pas­senger seat if the message in the roof con­sole indicates that the airbag is deacti­vated, and if the warning symbol(p. 28) for
the airbag system is also displayed on the
combined instrument panel. This indicates
that there has been a severe malfunction.
Visit a workshop as soon as possible.
Volvo recommends that you contact an
authorised Volvo workshop.

WARNING

Failure to follow the advice given above
can endanger the lives of passengers in
the car.

Related information

•

Child seats (p. 42)

02 Safety

02

34

Side airbag (SIPS)

In a side impact collision a large proportion of
the collision force is transferred by the SIPS
(Side Impact Protection System) to beams,
pillars, the floor, the roof and other structural
parts of the body. The side airbags at the driv­er's and front passenger seats protect the
chest area and the hip and are an important
part of the SIPS.

G032949

The SIPS bag system consists of two main
components, side airbag and sensors. The
side airbags are located in the front seat's
backrests.

A sufficiently violent collision trips the sensors
and the side airbags are inflated. The airbag
inflates between the occupant and the door
panel and thereby cushions the initial impact.
The airbag deflates when compressed by the
collision. The side airbag is normally only
deployed on the side of the collision.

Driver's seat, left-hand drive.

Front passenger seat, left-hand drive.

WARNING

•

Volvo recommends that repairs are
only carried out by an authorised Volvo
workshop. Defective work in the SIPS­bag system could cause malfunction
and result in serious personal injury.

•

Do not put objects in the area between
the outside of the seat and the door
panel, since this area is required by
the side airbag.

•

Volvo recommends the use only of car
seat covers approved by Volvo. Other
seat covers may impede the operation
of the side airbags.

•

Side airbags are a supplement the
seatbelts. Always use a seatbelt.

Related information

•

Driver airbag (p. 30)

•

Passenger airbag (p. 31)

•

Side airbag (SIPS) - child seat/booster
cushion (p. 35)

•

Inflatable Curtain (IC) (p. 35)

02 Safety

02

35

Side airbag (SIPS) - child seat/booster cushion

The protection provided by the car to children
seated in a child seat or on a booster cushion
is not diminished by the side airbag (p. 34).

Child seat/booster cushion (p. 42) can be
placed on the front passenger seat provided
that the car does not have an activated airbag
(p. 32) on the front passenger side.

Related information

•

Passenger airbag (p. 31)

•

General information on child safety
(p. 41)

Inflatable Curtain (IC)

The inflatable curtain helps to prevent the
driver and passengers from striking their
heads on the inside of the car during a colli­sion.

Inflatable curtain IC (Inflatable Curtain) is part
of the SIPS system (p. 34) and the airbag sys­tem (p. 29). It is fitted in the headlining along
both sides of the roof and protects the car's
occupants sitting in the outer seats. A suffi­ciently violent collision trips the sensors and
the inflatable curtain is inflated.

WARNING

Never hang or attach heavy items onto the
handles in the roof. The hook is only
designed for light clothing (not for solid
objects such as umbrellas for example).

Do not screw or install anything onto the
car's headlining, door pillars or side pan­els. This could compromise the intended
protection. Volvo recommends that you
only ever use Volvo genuine parts that are
approved for placement in these areas.

WARNING

Do not load the car higher than 50 mm
under the top edge of the door windows.
Otherwise, the intended protection of the
inflatable curtain, which is concealed in the
headlining, may be compromised.

WARNING

The inflatable curtain is a supplement to
the seatbelts.

Always use a seatbelt.

Related information

•

General information on seatbelts (p. 25)

02 Safety

02

36

General information on WHIPS (whiplash protection)

WHIPS (Whiplash Protection System) is a pro­tection against whiplash injuries. The system
consists of energy absorbing backrests and
specially designed head restraints in the front
seats.

The WHIPS system is actuated by a rear-end
collision, where the angle and speed of the
collision, and the nature of the colliding vehi­cle all have an influence.

WARNING

The WHIPS system is a supplement to the
seatbelts. Always use a seatbelt.

Seat properties

When the WHIPS system is deployed, the
front seat backrests are lowered backward to
change the seating position of the driver and
front seat passenger. This reduces the risk of
whiplash injury.

WARNING

Never modify or repair the seat or WHIPS
system yourself. Volvo recommends that
you contact an authorised Volvo work­shop.

Related information

•

WHIPS - child seats (p. 37)

•

WHIPS - seating position (p. 37)

•

General information on seatbelts (p. 25)

02 Safety

02

}}

37

WHIPS - child seats

The protection provided by the car to children
seated in a child seat or on a booster cushion
is not diminished by the WHIPS system
(p. 36).

Child seat/booster cushion (p. 42) can be
placed on the front passenger seat provided
that the car does not have an activated airbag
(p. 32) on the front passenger side.

Related information

•

General information on child safety
(p. 41)

WHIPS - seating position

For optimum protection from the WHIPS sys­tem (p. 36) the driver and passenger must
have the correct seating position and make
sure that the system's function is not obstruc­ted.

Seating position

Set the correct seating position in the front
seat (p. 76) before driving starts.

Driver and front seat passenger should sit in
the centre of the seat with as little space as
possible between the head and the head
restraint.

Function

Do not leave any objects on the floor behind the
driver's seat/passenger seat that may prevent the
WHIPS system from functioning.

WARNING

Do not squeeze rigid objects between the
rear seat cushion and the front seat's
backrest. Make sure you do not to
obstruct the function of the WHIPS sys­tem.

Do not place objects on the rear seat that may
prevent the WHIPS system from functioning.

WARNING

If a rear seat backrest is folded down, the
corresponding front seat must be moved
forward so that it does not make contact
with the folded backrest.

02 Safety

02

38

WARNING

If a seat has been subjected to extreme
forces, such as due to a rear-end collision,
the WHIPS system must be checked.
Volvo recommends that it is checked by
an authorised Volvo workshop.

Part of the WHIPS system's protective
capacity may have been lost even if the
seat appears to be undamaged.

Volvo recommends that you contact an
authorised Volvo workshop to have the
system checked even after a minor rear­end collision.

When the systems deploy

In the event of a collision Volvo's different
personal safety systems work together in
order to minimise injury.

System Triggered

Seatbelt ten­sioner (p. 28) front
seat

In the event of a
frontal collision,
and/or side-impact
collision, and/or
rear-end collision
and/or overturning

Seatbelt tensioner,
rear seat

In a frontal collision
and/or side-impact
accident and/or
overturning

Airbags
(Steering

wheel(p. 30) and
passenger airbag
(p. 31))

In a frontal colli­sion

A

Side airbags
(SIPS) (p. 34)

In a side-impact
accident

A

System Triggered

Inflatable Curtain
IC (p. 35)

In the event of a
side-impact colli­sion and/or certain
frontal collisions

A

Whiplash protection
WHIPS (p. 36)

In a rear-end colli­sion

A

The bodywork of the car could be greatly deformed in a
collision without airbag deployment. A number of factors
such as the rigidity and weight of the object hit, the speed
of the car, the angle of the collision etc. affects how the
different safety systems of the car are activated.

If the airbags (p. 29) have deployed, the fol­lowing is recommended:

•

Recovering the car. Volvo recommends
that you have it conveyed to an author­ised Volvo workshop. Do not drive with
deployed airbags.

•

Volvo recommends that you engage an
authorised Volvo workshop to handle the
replacement of components in the car's
safety systems.

•

Always contact a doctor.

NOTE

The airbags and belt tensioner system are
deployed only once during a collision.

02 Safety

02

}}

39

WARNING

The airbag system's control module is
located in the centre console. If the centre
console is drenched with water or other
liquid, disconnect the battery cables. Do
not attempt to start the car since the air­bags may deploy. Recovering the car.
Volvo recommends that you have it con­veyed to an authorised Volvo workshop.

WARNING

Never drive with deployed airbags. They
can make steering difficult. Other safety
systems may also be damaged. The
smoke and dust created when the airbags
are deployed can cause skin and eye irrita­tion/injury after intensive exposure. In case
of irritation, wash with cold water. The
rapid deployment sequence and airbag
fabric may cause friction and skin burns.

General information on safety mode

Safety mode is a protective state that is
enforced when the collision may have dam­aged any of the car's vital functions, such as
the fuel lines, sensors for one of the safety
systems, or the brake system.

Warning triangle in the analogue combined
instrument panel.

Warning triangle in the digital combined instru­ment panel.

If the car is involved in a collision, the text

Safety mode See manual may appear in the

combined instrument panel (p. 59) informa­tion display. This means that the car has
reduced functionality.

WARNING

Never attempt to repair your car or reset
the electronics yourself if the car has been
in safety mode. This could result in per­sonal injury or the car not functioning as
normal. Volvo recommends that you
engage an authorised Volvo workshop to
check and restore the car to normal status
after

Safety mode See manual has been

displayed.

||

02 Safety

02

40

Related information

•

Safety mode - attempting to start the car
(p. 40)

•

Safety mode - moving the car (p. 41)

Safety mode - attempting to start the car

If the car is set in safety mode (p. 39) then an
attempt to start the car can be made if every­thing seems normal and the absence of fuel
leakage has been checked.

First, check that no fuel is leaking from the
car. There must be no smell of fuel either.

If everything seems normal and you have
checked for indications of fuel leakage, you
may attempt to start the car.

Remove the remote control key and open the
driver's door. If a message is now shown to
the effect that the ignition is on, press the
start button. Then close the door and reinsert
the remote control key. The car's electronics
will now try to reset themselves to normal
mode. Then try to start the car.

If the message

Safety mode See manual is

still shown on the display then the car must
not be driven or towed but a vehicle recovery
service (p. 304) used instead. Even if the car
appears to be driveable, hidden damage may
make the car impossible to control once mov­ing.

WARNING

Never, under any circumstances, attempt
to restart the car if it smells of fuel when
the

Safety mode See manual message

is displayed. Leave the car at once.

WARNING

If the car is in safety mode it must not be
towed. It must be transported from its
location. Volvo recommends that it is
transported to an authorised Volvo work­shop.

Related information

•

Safety mode - moving the car (p. 41)

02 Safety

02

* Option/accessory, for more information, see Introduction.

41

Safety mode - moving the car

If Normal mode is shown after Safety mode

See manual has been reset after attempting

to start the car (p. 40) , the car can be moved
carefully out of a dangerous position.

Do not move the car further than necessary.

Related information

•

General information on safety mode
(p. 39)

General information on child safety

Children of all ages and sizes must always sit
correctly secured in the car. Never allow a
child to sit on the knee of a passenger.

Volvo recommends that children travel in
rear-facing child seats until as late an age as
possible, at least until 3-4 years of age, and
then front-facing booster cushions/child seats
until up to 10 years of age.

The position of a child in the car and the
choice of equipment are dictated by the
child's weight and size; see Child seats
(p. 42).

NOTE

Regulations regarding the placement of
children in cars vary from country to coun­try. Check what does apply.

Volvo has child safety equipment (child seats,
booster cushions & attachment devices)
which is designed for your particular car.
Using Volvo's child safety equipment pro­vides you with optimum conditions for your
child to travel safely in the car. Furthermore,
the child safety equipment fits and is easy to
use.

NOTE

In the event of questions when fitting child
safety products, contact the manufacturer
for clearer instructions.

Child safety locks

The rear doors and rear door windows* can
be blocked manually (p. 175) or electronically
(p. 175)* from opening from the inside.

Related information

•

Child seats - location (p. 46)

•

Child seat - ISOFIX (p. 47)

•

Child seats - upper mounting points
(p. 51)

02 Safety

02

42

Child seats

Children should sit comfortably and safely.
Make sure that the child seat is being used
correctly.

G020739

Child seats and airbags are not compatible.

NOTE

When using child safety products it is
important to read the installation instruc­tions included.

WARNING

Do not secure the straps of the child seat
to the seat's horizontal adjustment bar,
springs or the rails and beams under the
seat. Sharp edges may damage the straps.

Look in the installation instructions for the
child seat for the correct fitting.

02 Safety

02

}}

43

Recommended child seats

2

Weight Front seat (with deactivated airbag) Outer rear seat Centre rear seat

Group 0
max 10 kg
Group 0+
max 13 kg

Volvo infant seat (Volvo Infant Seat) - rear-facing
child seat, secured with the ISOFIX fixture sys­tem.

Type approval: E1 04301146
(L)

Group 0
max 10 kg
Group 0+
max 13 kg

Volvo infant seat (Volvo Infant Seat) - rear­facing child seat, secured with the car's
seatbelt.

Type approval: E1 04301146
(U)

Volvo infant seat (Volvo Infant Seat) - rear-facing
child seat, secured with the car's seatbelt.

Type approval: E1 04301146
(U)

Volvo infant seat (Volvo Infant
Seat) - rear-facing child seat,
secured with the car's seatbelt.

Type approval: E1 04301146
(U)

Group 0
max 10 kg
Group 0+
max 13 kg

Rear-facing child seat (Child Seat) - rear­facing child seat, secured with the car's
seatbelt and straps.

Type approval: E5 03135
(L)

Rear-facing child seat (Child Seat) - rear-facing
child seat, secured with the car's seatbelt and
straps.

Type approval: E5 03135
(L)

Rear-facing child seat (Child
Seat) - rear-facing child seat,
secured with the car's seatbelt
and straps.

Type approval: E5 03135
(L)

Group 0
max 10 kg
Group 0+
max 13 kg

Child seats which are universally
approved.

(U)

Child seats which are universally approved.
(U)

Child seats which are universally
approved.

(U)

2

With regard to other child seats your car should be included in the manufacturer's enclosed list of vehicles or be universally approved in accordance with the ECE R44 legal requirement.

||

02 Safety

02

44

Weight Front seat (with deactivated airbag) Outer rear seat Centre rear seat

Group 1
9-18 kg

Volvo rear-facing/turnable child seat (Volvo
Convertible Child Seat) - rear-facing child
seat, secured with the car's seatbelt and
straps.

Type approval: E5 04192
(L)

Volvo rear-facing/turnable child seat (Volvo
Convertible Child Seat) - rear-facing child seat,
secured with the car's seatbelt and straps.

Type approval: E5 04192
(L)

Group 1
9-18 kg

Rear-facing child seat (Child Seat) - rear­facing child seat, secured with the car's
seatbelt and straps.

Type approval: E5 03135
(L)

Rear-facing child seat (Child Seat) - rear-facing
child seat, secured with the car's seatbelt and
straps.

Type approval: E5 03135
(L)

Rear-facing child seat (Child
Seat) - rear-facing child seat,
secured with the car's seatbelt
and straps.

Type approval: E5 03135
(L)

Group 1
9-18 kg

Britax Fixway – rear-facing child seat, secured
with the ISOFIX fixture system and straps.

Type approval: E5 03171
(L)

Group 1
9-18 kg

Child seats which are universally
approved.

(U)

Child seats which are universally approved.
(U)

Child seats which are universally
approved.

(U)

Group 2
15-25 kg

Volvo rear-facing/turnable child seat (Volvo
Convertible Child Seat) - rear-facing child
seat, secured with the car's seatbelt and
straps.

Type approval: E5 04192
(L)

Volvo rear-facing/turnable child seat (Volvo
Convertible Child Seat) - rear-facing child seat,
secured with the car's seatbelt and straps.

Type approval: E5 04192
(L)

02 Safety

02

45

Weight Front seat (with deactivated airbag) Outer rear seat Centre rear seat

Group 2
15-25 kg

Volvo rear-facing/turnable child seat (Volvo
Convertible Child Seat) - front-facing child
seat, secured with the car's seatbelt.

Type approval: E5 04191
(U)

Volvo rear-facing/turnable child seat (Volvo
Convertible Child Seat) - front-facing child seat,
secured with the car's seatbelt.

Type approval: E5 04191
(U)

Volvo rear-facing/turnable child
seat (Volvo Convertible Child
Seat) - front-facing child seat,
secured with the car's seatbelt.

Type approval: E5 04191
(U)

Group 2/3
15-36 kg

Booster cushion with and without backrest
(Booster Cushion with and without
backrest).

Type approval: E5 04216
(UF)

Booster cushion with and without backrest
(Booster Cushion with and without backrest).

Type approval: E5 04216
(UF)

Booster cushion with and without
backrest (Booster Cushion with
and without backrest).

Type approval: E5 04216
(UF)

Group 2/3
15-36 kg

Volvo booster seat with backrest (Volvo
Booster Seat with backrest).

Type approval: E1 04301169
(UF)

Volvo booster seat with backrest (Volvo Booster
Seat with backrest).

Type approval: E1 04301169
(UF)

Volvo booster seat with backrest
(Volvo Booster Seat with
backrest).

Type approval: E1 04301169
(UF)

L: Suitable for specific child seats. These child seats may be intended for use in a special car model, limited or semi-universal categories.
U: Suitable for universally approved child seats in this weight class.
UF: Suitable for front-facing universally approved child seats in this weight class.

Related information

•

Child seats - location (p. 46)

•

Child seats - upper mounting points
(p. 51)

•

Child seat - ISOFIX (p. 47)

•

General information on child safety (p. 41)

02 Safety

02

46

Child seats - location

Always fit child seats/booster cushions (p. 42)
in the rear seat if the passenger airbag is acti­vated (p. 32). If a child is sitting on the front
passenger seat then he/she could suffer seri­ous injury if the airbag deploys.

The warning label for the passenger airbag is
fitted in one of the following two locations in
the car:

Alternative 1: Position of airbag label on passen­ger side sun visor.

Alternative 2: Position of airbag label on passen­ger side door pillar. The label becomes visible
when the passenger door is opened.

You may place:

•

a child seat/booster cushion on the front
passenger seat provided there is no acti­vated airbag on the front passenger side.

•

one or more child seats/booster cushions
in the rear seat.

WARNING

Never use a rear-facing child seat on a
seat protected by an activated airbag. Fail­ure to follow this advice can lead to death
or serious injury to the child.

WARNING

Never place a child in a child seat or on a
booster cushion in the front seat if the air­bag is activated.

Never allow anybody to stand or sit in front
of the front passenger seat.

No one shorter than 140 cm should ever
sit in the front passenger seat if the airbag
is activated.

Failure to follow the advice given above
can endanger life.

WARNING

Booster cushions/child seats with steel
braces or some other design that could
rest on the seatbelt buckle's opening but­ton must not be used, as they could cause
the seatbelt buckle to open accidentally.

Do not allow the upper section of the child
seat to rest against the windscreen.

Related information

•

General information on child safety (p. 41)

•

Child seats - upper mounting points
(p. 51)

•

Child seat - ISOFIX (p. 47)

02 Safety

02

}}

47

Child seat - ISOFIX

ISOFIX is a fixture system for car child seats
(p. 42) that is based on an international stand­ard.

Mounting points for the ISOFIX fixture system
are concealed behind the lower section of the
rear seat backrest, in the outer seats.

The location of the mounting points is indi­cated by symbols in the backrest upholstery
(see preceding illustration).

Press the seat cushion down to access the
mounting points.

Always follow the manufacturer's installation
instructions when connecting a child seat to
the ISOFIX mounting points.

Related information

•

ISOFIX - size classes (p. 47)

•

ISOFIX - types of child seat (p. 49)

•

General information on child safety (p. 41)

ISOFIX - size classes

There is a size classification for child seats
using the ISOFIX (p. 47) fixture system in
order to assist users in choosing the correct
type of child seat (p. 49).

Size

class

Description

A Full size, front-facing child

seat

B Reduced size (alt. 1), front-

facing child seat

B1 Reduced size (alt.2), front-fac-

ing child seat

C Full size, rear-facing child seat

D Reduced size, rear-facing

child seat

E Rear-facing infant seat

F Transverse infant seat, left-

hand

G Transverse infant seat, right-

hand

||

02 Safety

02

48

WARNING

Never place the child in the passenger
seat if the car is fitted with an activated air­bag.

NOTE

If an ISOFIX child seat has no size classifi­cation, the car model must be included on
the vehicle list for the child seat.

NOTE

Volvo recommends that you contact an
authorised Volvo dealer for recommenda­tions about which ISOFIX child seats Volvo
recommends.

02 Safety

02

}}

49

ISOFIX - types of child seat

Child seats are in different sizes – cars are in
different sizes. This means that not all child

seats are suitable for all seats in all car mod­els.

Type of child seat Weight Size class Passenger seats for ISOFIX installation of child seats

Front seat Outer rear seat

Infant seat transverse max 10 kg F X X

G X X

Infant seat, rear-facing max 10 kg E X OK

(IL)

Infant seat, rear-facing max 13 kg E X OK

(IL)

D X OK

(IL)

C X OK

(IL)

Child seat, rear-facing 9-18 kg D X OK

(IL)

C X OK

(IL)

||

02 Safety

02

50

Type of child seat Weight Size class Passenger seats for ISOFIX installation of child seats

Front seat Outer rear seat

Front-facing child seat 9-18 kg B X

OK

A

(IUF)

B1 X

OK

A

(IUF)

A X

OK

A

(IUF)

X: The ISOFIX position is not suitable for ISOFIX child seats in this weight class and/or size class.
IL: Suitable for specific ISOFIX child seats. These child seats may be intended for use in a special car model, limited or semi-universal catego-

ries.
IUF: Suitable for front-facing ISOFIX child seats that are universally approved in this weight class.

A

Volvo recommends rear-facing child seats for this group.

Make sure you select the right size class
(p. 47) of child seat with ISOFIX (p. 47) fixture
system.

02 Safety

02

51

Child seats - upper mounting points

The car is equipped with upper mounting
points for child seats (p. 42). These mounting
points are located on the parcel shelf and are
concealed by plastic covers. Bend aside the
plastic covers to access each respective
mounting point.

For cars with folding head restraints on the
outside seats, the head restraints should be
folded to facilitate installation.

The upper mounting points are primarily
intended for use with front-facing child seats.
Volvo recommends that small children should
sit in rear-facing child seats for as long as
possible.

For detailed information on how the child seat
should be tensioned in the upper mounting
points, see the seat manufacturer's instruc­tions.

WARNING

The child seat's straps must always be
drawn through the hole in the head
restraint leg before they are tensioned at
the attachment point.

Related information

•

General information on child safety (p. 41)

•

Child seats - location (p. 46)

•

Child seat - ISOFIX (p. 47)

INSTRUM E N T S A N D CONTROLS

03 Instruments and controls

03

}}

53

Instruments and controls, left-hand drive car - overview

The overview shows where the car's displays
and controls are located.

||

03 Instruments and controls

03

54

Overview, left-hand drive cars

03 Instruments and controls

03

* Option/accessory, for more information, see Introduction.

55

Function See

Menus and mes­sages, direction
indicators, main/
dipped beam, trip
computer

(p. 105),
(p. 107),
(p. 89),
(p. 84) and
(p. 118).

Manual gear chang­ing in an automatic
gearbox*

(p. 261).

Cruise control* (p. 188) and

(p. 190).

Horn, airbags (p. 79) and

(p. 29).

Combined instru­ment panel

(p. 59).

Menu navigation,
audio control,
phone control*

(p. 108) and
the Sensus
Infotainment
supplement.

START/STOP
ENGINE button

(p. 252).

Ignition switch (p. 74).

Screen for infotain­ment system and
display of menus

(p. 108) and
the Sensus
Infotainment
supplement.

Function See

Hazard warning
flashers

(p. 88).

Door handle –

Control panel (p. 171),

(p. 175),
(p. 97) and
(p. 99).

Control panel for
infotainment system
and menu naviga­tion

(p. 108) and
the Sensus
Infotainment
supplement.

Control panel for cli­mate control

(p. 127).

Gear selector (p. 260),

(p. 261) or
(p. 265).

Controls for active
chassis (Four-C)*

(p. 181).

Wipers and washing (p. 96).

Steering wheel
adjustment

(p. 79).

Parking brake (p. 282).

Bonnet opener (p. 343).

Function See

Seat adjustment* (p. 77).

Headlamp control,
opener for fuel filler
flap and boot lid

(p. 81),
(p. 289) and
(p. 173).

Related information

•

Outside temperature gauge (p. 68)

•

Trip meter (p. 68)

•

Clock (p. 69)

03 Instruments and controls

03

56

Instruments and controls, right-hand drive car - overview

The overview shows where the car's displays
and controls are located.

03 Instruments and controls

03

}}

57

Overview, right-hand drive cars

||

03 Instruments and controls

03

58

* Option/accessory, for more information, see Introduction.

Function See

Hazard warning
flashers

(p. 88).

Screen for infotain­ment system and
display of menus

(p. 108) and
the Sensus
Infotainment
supplement.

START/STOP
ENGINE button

(p. 252).

Ignition switch (p. 74).

Manual gear chang­ing in an automatic
gearbox*

(p. 261).

Cruise control* (p. 188) and

(p. 190).

Combined instru­ment panel

(p. 59).

Horn, airbags (p. 79) and

(p. 29).

Menu navigation,
audio control,
phone control*

(p. 108) and
the Sensus
Infotainment
supplement.

Wipers and washing (p. 96).

Function See

Headlamp control,
opener for fuel filler
flap and boot lid

(p. 81),
(p. 289) and
(p. 173).

Door handle –

Control panel (p. 171),

(p. 175),
(p. 97) and
(p. 99).

Seat adjustment* (p. 77).

Bonnet opener (p. 343).

Parking brake (p. 282).

Steering wheel
adjustment

(p. 79).

Menus and mes­sages, direction
indicators, main/
dipped beam, trip
computer

(p. 105),
(p. 107),
(p. 89),
(p. 84) and
(p. 118).

Controls for active
chassis (Four-C)*

(p. 181).

Gear selector (p. 260),

(p. 261) or
(p. 265).

Function See

Control panel for cli­mate control

(p. 127).

Control panel for
infotainment system
and menu naviga­tion

(p. 108) and
the Sensus
Infotainment
supplement.

Related information

•

Outside temperature gauge (p. 68)

•

Trip meter (p. 68)

•

Clock (p. 69)

03 Instruments and controls

03

}}

59

Combined instrument panel

The combined instrument panel's information
display shows information on some of the
car's functions, as well as messages.

•

Analogue combined instrument panel ­overview (p. 59)

•

Digital combined instrument panel - over­view (p. 60)

•

Combined instrument panel - meaning of
indicator symbols (p. 64)

•

Combined instrument cluster - meaning
of warning symbols (p. 66)

Analogue combined instrument panel

- overview

The combined instrument panel's information
display shows information on some of the
car's functions, e.g. cruise control and trip
computer, as well as messages. The informa­tion is shown with symbols and text.

Information display

Information display, analogue instrument panel.

The combined instrument panel's information
display shows information on some of the
car's functions, e.g. cruise control and trip
computer, as well as messages. The informa­tion is shown with symbols and text. There
are further descriptions under the functions
that use the display.

Gauges and indicators

Fuel gauge. When the indicator lowers to
only one white marking1, the yellow indi­cator symbol for low level in the fuel tank
is illuminated. See also Trip computer ­supplementary information (p. 118) and
Filling up with fuel (p. 289).

Eco meter The meter provides an indica­tion of how economically the car is being
driven. The higher the reading on the
scale, the more economical it is.

Speedometer

1

When the display's message "Distance to empty fuel tank:" starts to show "

----", the marking becomes red.

||

03 Instruments and controls

03

60

* Option/accessory, for more information, see Introduction.

Tachometer. The meter indicates engine
speed in thousands of revolutions per
minute (rpm).

Gear shift indicator2/Gear position indica­tor3 See also Gear shift indicator*
(p. 260), Automatic gearbox -­Geartronic* (p. 261) or Automatic gear­box -- Powershift* (p. 265).

Indicator and warning symbols

Indicator and warning symbols, analogue instru­ment panel.

Indicator symbols

Indicator and warning symbols

Warning symbols

4

Functionality check

All indicator and warning symbols, apart from
symbols in the centre of the information dis­play, illuminate in key position II or when the
engine is started. When the engine has
started, all the symbols should go out except
the parking brake symbol, which only goes
out when the brake is disengaged.

If the engine does not start or if the function­ality check is carried out in key position II
then all symbols go out within a few seconds
except the symbol for faults in the car's emis­sions system and the symbol for low oil pres­sure.

Related information

•

Combined instrument panel (p. 59)

•

Combined instrument panel - meaning of
indicator symbols (p. 64)

•

Combined instrument cluster - meaning
of warning symbols (p. 66)

Digital combined instrument panel ­overview

The combined instrument panel's information
display shows information on some of the
car's functions, e.g. cruise control and trip
computer, as well as messages. The informa­tion is shown with symbols and text.

Information display

Information display, digital instrument panel*.

The combined instrument panel's information
display shows information on some of the
car's functions, e.g. cruise control and trip
computer, as well as messages. The informa­tion is shown with symbols and text. There
are further descriptions under the functions
that use the display.

2

Manual gearbox.

3

Automatic gearbox.

4

Certain engine variants do not have systems to warn of oil pressure loss. In cars with these variants the symbol for low oil pressure is not used. Warning for low oil level is via display text. For
more information, see Engine oil - general (p. 345).

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

61

Gauges and indicators

Alternative themes can be selected for the
digital combined instrument panel. Possible
themes are "Elegance", "Eco" and
"Performance".

A theme can only be selected when the
engine is running.

To select the theme, press the left-hand stalk
switch's OK button and select the

Themes

menu option by turning the thumbwheel on
the lever. Press the OK button. Turn the
thumbwheel to select the theme and confirm
the selection by pressing the OK button.

On certain model variants, the appearance of
the centre console's screen follows the theme
selected for the combined instrument panel.

The contrast mode and colour mode for the
instrument can also be set using the left-hand
stalk switch.

For more information on menu navigation,
see Menu navigation - combined instrument
panel (p. 105).

The choice of theme and setting of contrast
mode and colour mode can be stored for
each remote control key in the car key mem­ory*, see Remote control key - personalisa­tion* (p. 156).

Gauges and indicators, theme "Elegance".

Fuel gauge. When the indicator lowers to
only one white marking5, the yellow indi­cator symbol for low level in the fuel tank
is illuminated. See also Trip computer ­supplementary information (p. 118) and
Filling up with fuel (p. 289).

Temperature gauge for engine coolant

Speedometer

Tachometer. The meter indicates engine
speed in thousands of revolutions per
minute (rpm).

Gear shift indicator6/Gear position indica­tor7 See also Gear shift indicator*
(p. 260), Automatic gearbox --

Geartronic* (p. 261) or Automatic gear­box -- Powershift* (p. 265).

Gauges and indicators, theme "Eco".

Fuel gauge. When the indicator lowers to
only one white marking5, the yellow indi­cator symbol for low level in the fuel tank
is illuminated. See also Trip computer ­supplementary information (p. 118) and
Filling up with fuel (p. 289).

Eco guide. See also Eco guide & Power
guide* (p. 63).

Speedometer

5

When the display's message "Distance to empty fuel tank:" starts to show "

----", the marking becomes red.

6

Manual gearbox.

7

Automatic gearbox.

||

03 Instruments and controls

03

62

* Option/accessory, for more information, see Introduction.

Tachometer. The meter indicates engine
speed in thousands of revolutions per
minute (rpm).

Gear shift indicator6/Gear position indica­tor7. See also Gear shift indicator*
(p. 260), Automatic gearbox -­Geartronic* (p. 261) or Automatic gear­box -- Powershift* (p. 265).

Gauges and indicators, theme "Performance".

Fuel gauge. When the indicator lowers to
only one white marking5, the yellow indi­cator symbol for low level in the fuel tank
is illuminated. See also Trip computer ­supplementary information (p. 118) and
Filling up with fuel (p. 289).

Temperature gauge for engine coolant

Speedometer

Tachometer. The meter indicates engine
speed in thousands of revolutions per
minute (rpm).

Power guide. See also Eco guide &
Power guide* (p. 63).

Gear shift indicator6/Gear position indica­tor7. See also Gear shift indicator*
(p. 260), Automatic gearbox -­Geartronic* (p. 261) or Automatic gear­box -- Powershift* (p. 265).

Indicator and warning symbols

Indicator and warning symbols, digital instrument
panel.

Indicator symbols

Indicator and warning symbols

Warning symbols

8

6

Manual gearbox.

7

Automatic gearbox.

5

When the display's message "Distance to empty fuel tank:" starts to show "

----", the marking becomes red.

8

Certain engine variants do not have systems to warn of oil pressure loss. In cars with these variants the symbol for low oil pressure is not used. Warning for low oil level is via display text. For
more information, see Engine oil - general (p. 345).

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

63

Functionality check

All indicator and warning symbols, apart from
symbols in the centre of the information dis­play, illuminate in key position II or when the
engine is started. When the engine has
started, all the symbols should go out except
the parking brake symbol, which only goes
out when the brake is disengaged.

If the engine does not start or if the function­ality check is carried out in key position II
then all symbols go out within a few seconds
except the symbol for faults in the car's emis­sions system and the symbol for low oil pres­sure.

Related information

•

Combined instrument panel (p. 59)

•

Combined instrument panel - meaning of
indicator symbols (p. 64)

•

Combined instrument cluster - meaning
of warning symbols (p. 66)

Eco guide & Power guide*

Eco guide and Power guide are two com­bined instrument panel (p. 59) instruments
which help the driver to drive the car with
optimum driving economy.

The car also stores statistics of journeys
made, which can be viewed in the form of a
block diagram; see Trip computer - trip statis­tics* (p. 119).

Eco guide

This instrument provides an indication of how
economically the car is being driven.

To view this function, select the theme "Eco";
see Digital combined instrument panel - over­view (p. 60).

Instantaneous value

Average value

Instantaneous value

The instantaneous value is shown here - the
higher the reading on the scale, the better.

The instantaneous value is calculated based
on speed, engine speed, engine power uti­lised plus use of the foot brake.

Optimum speed (50-80 km/h) and low engine
speeds are encouraged. The pointers fall dur­ing acceleration and braking.

Very low instantaneous values illuminate the
red zone on the meter (with a short delay),
which means poor driving economy and
hence should be avoided.

Average value

The average value slowly follows the instanta­neous value and describes how the car has
been driven most recently. The higher the
pointers on the scale, the better the economy
achieved by the driver.

Power guide

This instrument shows the relationship
between how much power (Power) is being
taken from the engine and how much power
is available.

To view this function, select the theme
"Performance"; see Digital combined instru­ment panel - overview (p. 60).

||

03 Instruments and controls

03

64

* Option/accessory, for more information, see Introduction.

Available engine power

Engine power utilised

Available engine power

The smaller, upper pointer shows the availa­ble engine power9. The higher the reading on
the scale, the more power is available in the
current gear.

Engine power utilised

The larger, lower pointer shows the engine
power utilised9. The higher the reading on the
scale, the more power is being taken from the
engine.

A large gap between the two pointers indi­cates a large power reserve.

Combined instrument panel ­meaning of indicator symbols

The indicator symbols alert the driver that a
function is activated, that the system is oper­ating, or that an error or failure has occurred.

Indicator symbols

Symbol Specification

ABL fault

Emissions system

ABS fault

Rear fog lamp on

Stability system, see Electronic
stability control (ESC) - general
(p. 181)

Stability system, sport mode,
see Electronic stability control
(ESC) - operation (p. 182)

Engine preheater (diesel)

Low level in fuel tank

Symbol Specification

Information, read display text

Main beam On

Left-hand direction indicator

Right-hand direction indicator

Eco-function on, see ECO*
(p. 277)

Start/Stop, the engine auto­stopped; see Start/Stop* ­function and operation (p. 269)

Tyre pressure system , see
Tyre pressure monitoring*
(p. 317)

ABL fault

The symbol illuminates if a fault has arisen in
the ABL function (Active Bending Lights).

Emissions system

If the symbol illuminates after the engine has
been started then it may be due to a fault in
the car's emissions system. Drive to a work­shop for checking. Volvo recommends that
you seek assistance from an authorised Volvo
workshop.

9

Power is dependent on engine speed.

03 Instruments and controls

03

65

ABS fault

If this symbol illuminates then the system is
not working. The car's regular brake system
continues to work, but without the ABS func­tion.

1. Stop the car in a safe place and turn off
the engine.

2. Restart the engine.

3. If the symbol remains illuminated, drive to
a workshop to have the ABS system
checked. Volvo recommends that you
seek assistance from an authorised Volvo
workshop.

Rear fog lamp on

This symbol illuminates when the rear fog
lamp is switched on.

Stability system

A flashing symbol indicates that the stability
system is operating. If the symbol illuminates
with constant glow then there is a fault in the
system.

Stability system, sport mode

Sport mode allows for a more active driving
experience. The system then detects whether
the accelerator pedal, steering wheel move­ments and cornering are more active than in
normal driving and then allows controlled
skidding of the rear section up to a certain
level before it intervenes and stabilises the
car. The symbol illuminates when the sport
mode is activated.

Engine preheater (diesel)

This symbol illuminates during engine pre­heating. Preheating takes place mostly due to
low temperature.

Low level in fuel tank

When the symbol illuminates the level in the
fuel tank is low, refuel as soon as possible.

Information, read display text

When one of the car's systems does not
behave as intended, this information symbol
illuminates and a text appears on the informa­tion display. The message text is cleared with
the OK button, see Menu navigation - com­bined instrument panel (p. 105), or it disap­pears automatically after a time (time
depending on which function is indicated).
The information symbol can also illuminate in
conjunction with other symbols.

NOTE

When a service message is shown, the
symbol and message are cleared using the
OK button, or disappear automatically
after a time.

Main beam On

The symbol illuminates when main beam is on
and with main beam flash.

Left/right-hand direction indicator

Both direction indicator symbols flash when
the hazard warning flashers are used.

Eco function on

This symbol illuminates when the Eco func­tion is activated.

Start/Stop

The symbol shines when the engine is auto­stopped.

Tyre pressure system

The symbol illuminates in the event of low
tyre pressure, or if a fault arises in the tyre
pressure system.

Related information

•

Combined instrument panel (p. 59)

•

Combined instrument cluster - meaning
of warning symbols (p. 66)

•

Digital combined instrument panel - over­view (p. 60)

03 Instruments and controls

03

66

Combined instrument cluster ­meaning of warning symbols

The warning symbols alert the driver that an
important function is activated, or that a seri­ous error or a serious failure has occurred.

Warning symbols

Symbol Specification

Low oil pressure

A

Parking brake applied, digital
instrument panel

Parking brake applied, ana­logue instrument panel

Airbags – SRS

Seatbelt reminder

Alternator not charging

Fault in brake system

Warning

A

Certain engine variants do not have systems to warn of oil
pressure loss. In cars with these variants the symbol for
low oil pressure is not used. Warning for low oil level is via
display text. For more information, see Engine oil - general
(p. 345).

Low oil pressure

If this symbol illuminates during driving then
the engine's oil pressure is too low. Stop the
engine immediately and check the engine oil
level, top up if necessary. If the symbol illumi­nates and the oil level is normal, contact a
workshop. Volvo recommends that you seek
assistance from an authorised Volvo work­shop.

Parking brake applied

This symbol illuminates with a constant glow
when the parking brake is applied. The sym­bol flashes during application, and then
changes over to a constant glow.

A flashing symbol in any other situation
means that a fault has arisen. Read the mes­sage on the information display.

For more information, see Parking brake
(p. 282).

Airbags – SRS

If this symbol remains illuminated or illumi­nates while driving, it means a fault has been
detected in the seatbelt buckle, SRS, SIPS, or
IC systems. Drive immediately to a workshop
to have the system checked. Volvo recom­mends that you seek assistance from an
authorised Volvo workshop.

Seatbelt reminder

This symbol flashes if someone in a front seat
has not put on their seatbelt or if someone in
a rear seat has taken off their seatbelt.

Alternator not charging

This symbol illuminates during driving if a
fault has occurred in the electrical system.
Visit a workshop. Volvo recommends that you
seek assistance from an authorised Volvo
workshop.

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

67

Fault in brake system

If this symbol illuminates, the brake fluid level
may be too low. Stop the car in a safe place
and check the level in the brake fluid reser­voir; see Brake and clutch fluid - level
(p. 350).

If the brake and ABS symbols illuminate at
the same time, there may be a fault in the
brake force distribution system.

1. Stop the car in a safe place and turn off
the engine.

2. Restart the engine.

•

If both symbols extinguish, continue
driving.

•

If the symbols remain illuminated,
check the level in the brake fluid reser­voir; see Brake and clutch fluid - level
(p. 350). If the brake fluid level is nor­mal but the symbols are still illumi­nated, the car can be driven, with great
care, to a workshop to have the brake
system checked. Volvo recommends
that you seek assistance from an
authorised Volvo workshop.

WARNING

If the brake fluid is under the MIN level in
the brake fluid reservoir, do not drive fur­ther before topping up the brake fluid.

The loss of brake fluid must be investiga­ted by a workshop. Volvo recommends
that you contact an authorised Volvo
workshop.

WARNING

If the BRAKE and ABS symbols are lit at
the same time, there is a risk that the rear
end will skid during heavy braking.

Warning

The red warning symbol illuminates when a
fault has been indicated which could affect
the safety and/or driveability of the car. An
explanatory text is shown on the information
display at the same time. The symbol remains
visible until the fault has been rectified but the
text message can be cleared with the OK
button; see Menu navigation - combined
instrument panel (p. 105). The warning sym­bol can also illuminate in conjunction with
other symbols.

Action:

1. Stop in a safe place. Do not drive the car
further.

2. Read the information on the information
display. Implement the action in accord­ance with the message in the display.
Clear the message using the OK button.

Reminder – doors not closed

If one of the doors is not closed properly then
the information or warning symbol illuminates
together with an explanatory image in the
information display. Stop the car in a safe
place as soon as possible and close the door
that is open.

If the car is driven at a speed lower
than approx. 7 km/h then the informa-

tion symbol illuminates.

If the car is driven at a speed higher
than approx. 7 km/h then the warning

symbol illuminates.

If the bonnet10 is not closed properly then the
warning symbol illuminates together with an
explanatory image in the information display.
Stop the car in a safe place as soon as possi­ble and close the bonnet.

If the boot lid is not closed properly then the
information symbol illuminates together with
an explanatory image in the information dis­play. Stop the car in a safe place as soon as
possible and close the boot lid.

10

Only cars with alarm*.

||

03 Instruments and controls

03

68

Related information

•

Combined instrument panel (p. 59)

•

Combined instrument panel - meaning of
indicator symbols (p. 64)

•

Digital combined instrument panel - over­view (p. 60)

Outside temperature gauge

The display for the outside temperature gauge
appears in the combined instrument panel.

Display for outside temperature gauge,
digital instrument panel

Display for outside temperature gauge,
analogue instrument panel

When the temperature lies between +2 °C to

-5 °C a snowflake symbol illuminates in the
display. This warns of icy roads. If the car has
been stationary, the gauge may display a
reading that is too high.

Related information

•

Combined instrument panel (p. 59)

Trip meter

The trip meter display appears in the com­bined instrument panel.

Trip meter, digital instrument.

Display for trip meter

11

The two trip meters

T1 and T2 are used for

measuring short distances. The distance is
shown in the display.

Turn the left stalk switch thumbwheel to show
the required meter.

A long press (until the change occurs) on the
left-hand stalk switch's RESET button resets
the trip meter shown. For more information,
see Trip computer - supplementary informa­tion (p. 118).

Related information

•

Combined instrument panel (p. 59)

11

Display appearance may differ depending on instrument variant.

03 Instruments and controls

03

}}

69

Clock

The clock display appears in the combined
instrument panel.

Clock, digital instrument panel.

Display for showing the time

12

Set the clock

The clock can be adjusted in the menu sys­tem MY CAR, see MY CAR (p. 108).

Related information

•

Combined instrument panel (p. 59)

Licenses - combined instrument panel

A license is an agreement for the right to
operate a certain activity or the right to use
someone else's entitlement according to the
terms and conditions in the agreement. The
following text is Volvo's agreement with the
manufacturer/developer.

Combined Instrument Panel Software

Open Source Software Notice

This product uses certain free / open source
and other software originating from third
parties, that is subject to the GNU Lesser
General Public License version 2 (LGPLv2),
The FreeType Project License ("FreeType
License") and other different and/or additional
copy right licenses, disclaimers and notices.
The links to access the exact terms of
LGPLv2, and the other open source software
licenses, disclaimers, acknowledgements and
notices are provided to you below. Please
refer to the exact terms of the relevant
License, regarding your rights under said
licenses. Volvo Car Corporation (VCC) offers
to provide the source code of said free/open
source software to you for a charge covering
the cost of performing such distribution, such
as the cost of media, shipping and handling,
upon written request. Please contact your
nearest Volvo Dealer.

The offer is valid for a period of at least three
(3) years from the date of the distribution of
this product by VCC / or for as long as VCC
offers spare parts or customer support.

Portions of this product uses software
copyrighted © 2007 The FreeType Project
(www.freetype.org). All rights reserved.

Portions of this product uses software with
Copyright © 1994–2013 Lua.org, PUC-Rio
(http://www.lua.org/)

This product includes software under
following licenses:

LGPL v2.1: http://www.gnu.org/licenses/old­licenses/lgpl-2.1.html

•

・ GNU FriBidi

•

・ DevIL

The FreeType Project License: http://
git.savannah.gnu.org/cgit/freetype/
freetype2.git/tree/docs/FTL.TXT

•

・ FreeType 2

12

The time is shown in the centre of an analogue instrument panel.

03 Instruments and controls

03

70

* Option/accessory, for more information, see Introduction.

MIT License: http: http://opensource.org/
licenses/mit-license.html

•

・ Lua

Symbols in the display

There are a variety of different symbols in the
display in the car. The symbols are divided
into warning, indicator and information sym­bols. Shown below are the most common
symbols with their meanings and a reference
to where in the manual further information can
be found.

- Red warning symbol, illuminates when
a fault has been indicated which could affect
the safety and/or driveability of the car. An
explanatory text is shown in the information
display in the combined instrument panel at
the same time.

- Information symbol, illuminates in
combination with text in the information dis­play in the combined instrument panel, when
a deviation in any of the car's systems has
occurred. The information symbol can also
illuminate in conjunction with other symbols.

Warning symbols in the combined instrument panel

Symbol Specification See

Low oil pressure (p. 66)

Parking brake
applied

(p. 66),
(p. 282)

Symbol Specification See

Parking brake
applied, alterna­tive symbol

(p. 66)

Airbags – SRS (p. 28),

(p. 66)

Seatbelt
reminder

(p. 25),
(p. 66)

Alternator not
charging

(p. 66)

Fault in brake
system

(p. 66),
(p. 279)

Warning, safety
mode

(p. 28),
(p. 39),
(p. 66),
(p. 265)

Control symbols in the combined instrument panel

Symbol Specification See

ABL fault* (p. 64),

(p. 87)

Emissions sys­tem

(p. 64)

ABS fault (p. 64),

(p. 279)

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

71

Symbol Specification See

Rear fog lamp on (p. 64),

(p. 87)

Stability system,
ESC (Electronic
Stability Control)

(p. 64),
(p. 183)

Stability system,
sport mode

(p. 64),
(p. 183)

Engine preheater
(diesel)

(p. 64)

Low level in fuel
tank

(p. 64),
(p. 140)

Information, read
display text

(p. 64)

Main beam On (p. 64),

(p. 84)

Left-hand direc­tion indicators

(p. 64)

Right-hand direc­tion indicators

(p. 64)

Start/Stop*,
engine auto­stopped

(p. 64),
(p. 275)

Symbol Specification See

ECO function* on (p. 64),

(p. 277)

Tyre pressure
system*

(p. 64),
(p. 317)

Information symbols in the combined instrument panel

Symbol Specification See

Cruise control* (p. 188)

Adaptive cruise
control*

(p. 203)

Adaptive cruise
control*, time
interval

(p. 190),
(p. 193)

Adaptive cruise
control*, Distance
Warning* (Dis­tance Alert)

(p. 195),
(p. 205)

Radar sensor* (p. 203),

(p. 207),
(p. 223)

– – –

Symbol Specification See

Windscreen sen­sor*, Camera sen­sor*, Laser sen­sor*

(p. 85),
(p. 214),
(p. 223),
(p. 227),
(p. 232)

Auto Brake*, Dis­tance Warning*
(Distance Alert),
City SafetyTM,
Collision warning
system*

(p. 207),
(p. 214),
(p. 223)

ABL system* (p. 87)

Driver Alert Sys­tem*, Time for a
break

(p. 226)

Driver Alert Sys­tem*, Time for a
break

(p. 227)

Parking brake (p. 282)

Rain sensor* (p. 96)

Active high beam,
AHB (Active High
Beam)*

(p. 85)

||

03 Instruments and controls

03

72

* Option/accessory, for more information, see Introduction.

Symbol Specification See

Start/Stop* (p. 275)

Start/Stop* (p. 275)

Driver Alert Sys­tem*, Lane Depar­ture Warning
(LDW)

(p. 227),
(p. 232)

Driver Alert Sys­tem*, Lane Depar­ture Warning*

(p. 230)

Driver Alert Sys­tem*, Lane Depar­ture Warning*

(p. 232)

Recorded speed
information*

(p. 185)

Engine block and
passenger com­partment heater*

(p. 140)

Symbol Specification See

Engine block
heater and pas­senger compart­ment heater*
Service required

(p. 140)

Activated timer* (p. 140)

Activated timer* (p. 140)

Low battery (p. 140)

Fuel filler flap,
right-hand side

(p. 289)

Gear shift indica­tor

(p. 260)

Gear positions (p. 261)

Measuring the oil
level

(p. 346)

– – –

Information symbols in the roof console display

Symbol Specification See

Seatbelt reminder (p. 27)

Airbag, passenger
seat, activated

(p. 32)

Airbag, passenger
seat, deactivated

(p. 32)

Related information

•

Combined instrument panel - meaning of
indicator symbols (p. 64)

•

Combined instrument cluster - meaning
of warning symbols (p. 66)

•

Messages - handling (p. 107)

03 Instruments and controls

03

* Option/accessory, for more information, see Introduction.

73

Volvo Sensus

Volvo Sensus is the heart of your personal
Volvo experience. It is Sensus that provides
information, entertainment and functions to
simplify your ownership.

When you are sitting in your car you want
control, and in today's interconnected world,
this includes information, communication and
entertainment when it is most suitable for
you. Sensus covers all our solutions that ena­ble connection* to the outside world, at the
same time providing you with intuitive control
over all the car's capabilities.

Volvo Sensus combines and presents many
functions in several of the car's systems on
the centre console's display screen. With
Volvo Sensus the car can be personalised by
means of an intuitive user interface. Settings
can be made in Car settings, Audio and
media, Climate control, etc.

With the centre console buttons and controls
or the steering wheel's right-hand keypad*

functions can be activated or deactivated and
many different settings can be made.

With a press on MY CAR all settings related
to the driving and control of the car are pre­sented, such as City Safety, locks and alarm,
automatic fan speed, setting the clock, etc.

With a press on the respective function
RADIO, MEDIA, TEL*,

*, NAV* and CAM*
other sources, systems and functions can be
activated, e.g. AM, FM, CD, DVD*, TV*,
Bluetooth®*, navigation* and park assist cam­era*.

For more information about all functions/
systems, see the relevant section in the
owner's manual or its supplement.

Overview

Control panel in centre console. The figure is
schematic - the number of functions and layout

of the buttons both vary, depending on the
equipment selected and the market.

Navigation* - NAV, see separate supple­ment (Sensus Navigation).

Audio and media - RADIO, MEDIA, TEL*,
see separate supplement (Sensus Info­tainment).

Function settings - MY CAR, see MY
CAR (p. 108).

Internet-connected car - *, see sepa­rate supplement (Sensus Infotainment).

Climate control system (p. 121).

Park assist camera* (p. 238) – CAM*.

03 Instruments and controls

03

74

* Option/accessory, for more information, see Introduction.

Key positions

The remote control key can be used to set the
vehicle's electrical system in different modes/
levels so that different functions are available;
see Key positions - functions at different lev­els (p. 74).

Ignition switch with remote control key extrac­ted/inserted.

NOTE

For cars with the Keyless* function the
remote control key does not need to be
inserted into the ignition switch but can be
stored in e.g. a pocket. For more informa­tion on Keyless functions, see Keyless
drive* (p. 166).

Insert the remote control key

1. Hold the end of the remote control key
with the detachable key blade and insert

the remote control key in the ignition
switch.

2. Then press the remote control key in the
lock up to its end position.

IMPORTANT

Foreign objects in the ignition switch can
impair the function or destroy the lock.

Do not press in the remote control key
incorrectly turned - hold the end with the
detachable key blade, see Detachable key
blade - detaching/attaching (p. 162).

Remove the remote control key

Push the remote control key, allow it to eject,
then pull it out from the ignition switch.

Key positions - functions at different levels

In order to enable the use of a limited number
of functions with the engine switched off, the
car's electrical system can be set in 3 differ­ent levels (key positions) - 0, I and II - with the
remote control key. Throughout this owner's
manual these levels are described using the
denomination "key positions".

The following table shows the functions avail­able in each key position/level.

03 Instruments and controls

03

* Option/accessory, for more information, see Introduction.

75

Level Functions

0

•

Odometer, clock and tem­perature gauge are illumi­nated.

•

Power seats can be adjusted.

•

The audio system can be
used for a limited time - see
the Sensus Infotainment sup­plement.

I

•

Sunroof, power windows, 12V
socket in the passenger com­partment, navigation, phone,
ventilation fan and wind­screen wipers can be used.

II

•

The headlamps come on.

•

Warning/indicator lamps illu­minate for 5 seconds.

•

Several other systems are
activated. However, heating in
seat cushions and the rear
window can only be activated
after the engine has been
started.

This key position consumes a
lot of current from the starter
battery and should therefore be
avoided!

Choosing key position/level

•

Key position 0 - Unlock the car - This
means that the car's electrical system is
at level 0.

•

Key position I - With the remote control
key fully inserted into the ignition switch

13

- Briefly press START/STOP ENGINE.

NOTE

To reach level I or II without starting the
engine - do not depress the brake/clutch
pedal when these key positions are due to
be selected.

•

Key position II - With the remote control
key fully inserted into the ignition switch

13

- Give a long14 press on START/STOP
ENGINE.

•

Back to key position 0 - To return to key
position 0 from position II and I - Briefly
press on START/STOP ENGINE.

Audio system

For information on audio system functions
with remote control key removed, see the
Sensus Infotainment supplement.

Starting and stopping the engine

For information about starting/stopping the
engine, see Starting the engine (p. 252).

Towing

For important information about the remote
control key during towing, see Towing
(p. 301).

Related information

•

Key positions (p. 74)

13

Not necessary for cars with the Keyless* function.

14

Approx. 2 seconds.

03 Instruments and controls

03

76

* Option/accessory, for more information, see Introduction.

Seats, front

The car's front seats have different setting
options for optimum seating comfort.

Raise/lower the seat, pump up/down.

Forward/backward: lift the handle to
adjust the distance to the steering wheel
and pedals. Check that the seat is locked
after changing position.

Raise/lower* front edge of seat cushion,
pump up/down.

Adjust backrest rake, turn the wheel.

Change the lumbar support*, press the
button.

Control panel for power seat*, see Seats,
front - electrically operated* (p. 77).

WARNING

Adjust the position of the driver's seat
before setting off, never while driving.
Make sure that the seat is in locked posi­tion in order to avoid personal injury in the
event of sudden braking or an accident.

Lowering the passenger seat backrest*

The passenger seat's backrest can be folded
forward to make room for long loads.

Move the seat as far back/down as possi­ble.

Adjust the backrest to an upright position.

Lift the catches on the rear of the back­rest and fold it forward.

4. Push the seat forward so that the head
restraint "locks" in under the glovebox.

Raising takes place in reverse order.

WARNING

Grasp the backrest and make sure that it
is properly locked after being folded up in
order to avoid personal injury in the event
of sudden braking or an accident.

Related information

•

Seats, front - electrically operated*
(p. 77)

•

Seats, rear (p. 78)

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

77

Seats, front - electrically operated*

The car's front seats have different setting
options for optimum seating comfort. The
power seat can be moved forward/backward
and up/down. The front edge of the seat
cushion can be raised/lowered. The backrest
angle and lumbar support* can be changed.

Power seat

Front edge of seat cushion up/down

Raise/lower seat

Seat, forward/backward

Backrest rake

Lumbar support* is adjusted inward and
outward

The power seats have overload protection
which is tripped if a seat is blocked by an

object. If this should happen, set the car's
electrical system in key position I or 0 and
wait a short time before adjusting the seat
again.

Only one movement (forward/back/up/down/
inward/outward) can be made at a time.

Preparations

The seat can be adjusted for a certain time
after unlocking the door with the remote con­trol key without the key in the ignition switch.
Seat adjustment is normally made in key
position I and can always be made when the
engine is running.

Seat with memory function*

The memory function stores settings for the
seat and the door mirrors.

Store setting

Memory button

Memory button

Memory button

Button for storing settings

1. Adjust the seat and the door mirrors.

2. Press and hold button M while pressing
button 1, 2 or 3 simultaneously. Hold the
buttons depressed until the acoustic sig­nal is heard and text is shown in the com­bined instrument panel.

The seat must be adjusted again before a
new memory can be set.

The setting for lumbar support is not stored.

Using a stored setting

Press one of the memory buttons 1-3 until the
seat and the door mirrors stop. If the button
is released, the movement of the seat and
door mirrors will be interrupted.

Key memory* in remote control key

All remote control keys can be used by differ­ent drivers to store the settings for the driv­er's seat and door mirrors15, see Remote
control key - personalisation* (p. 156).

15

Only if the car is equipped with power seat with memory and retractable power rearview and door mirrors. The setting for lumbar support is not stored.

||

03 Instruments and controls

03

78

* Option/accessory, for more information, see Introduction.

Emergency stop

If the seat accidentally begins to move, press
one of the setting buttons for the seat or
memory buttons in order to stop the seat.

Restarting to reach the seat position stored in
the key memory is performed by pressing the
unlock button on the remote control key. The
driver's door must then be open.

WARNING

Risk of crushing! Make sure that children
do not play with the controls. Check that
there are no objects in front of, behind or
under the seat during adjustment. Ensure
that none of the rear seat passengers is in
danger of becoming trapped.

Heated/ventilated seats*

For heated seats/ventilated, see Heated front
seats* (p. 128) and Heated rear seat*
(p. 128).

Related information

•

Seats, front (p. 76)

•

Seats, rear (p. 78)

Seats, rear

The rear seat backrest and the outer seat
head restraints can be folded. The centre seat
head restraint can be adjusted to suit the
height of the passenger.

Lowering the rear seat backrest

IMPORTANT

There must be no objects on the rear seat
when the backrest is to be folded down.
The seat belts must not be connected
either. Otherwise there is a risk of damag­ing the rear seat upholstery.

The backrest is in two parts. The parts can be
folded forward, together or separately.

1. Pull the handle/handles.

2. Fold the backrest forward. Lower the
centre head restraint fully if the backrest's
wide section shall be lowered.

WARNING

Take hold of the backrests and make sure
they are locked properly after opening
them out in order to prevent injury under
hard braking or in the event of an accident.

Head restraint, centre seat, rear

The head restraint can be adjusted vertically
to suit the height of the passenger. The upper
edge of the head restraint should be aligned
with middle of the back of the head. Slide it
up as required.

To lower the head restraint again, the button
by the left-hand shaft must be pressed in
while the head restraint is pressed down
carefully.

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

79

Electrical lowering of the rear seat's
outer head restraints*

1. The remote control key must be in key
position II.

2. Press the button to lower the rear outer
head restraints to improve rearward visi­bility.

WARNING

Do not lower the outer head restraints if
there are any passengers using of the
outer seats.

Move the head restraint back manually until a
click is heard.

WARNING

The head restraints must be in locked
position after being raised.

Related information

•

Seats, front (p. 76)

•

Seats, front - electrically operated* (p. 77)

Steering wheel

The steering wheel can be adjusted in differ­ent positions and has controls for horn and
cruise control, as well as menu, audio and
phone control.

Adjusting

Adjusting the steering wheel.

Lever - releasing the steering wheel

Possible steering wheel positions

The steering wheel can be adjusted for both
height and depth:

1. Pull the lever towards you to release the
steering wheel.

2. Adjust the steering wheel to the position
that suits you.

||

03 Instruments and controls

03

80

* Option/accessory, for more information, see Introduction.

3. Push back the lever to fix the steering
wheel in place. If the lever is stiff, press
the steering wheel lightly at the same time
as you push the lever back.

WARNING

Adjust the steering wheel and fix it before
driving away.

With speed related power steering* the level
of steering force can be adjusted, see Adjust­able steering force* (p. 245).

Keypads* and paddles*

Keypads and paddles in the steering wheel.

Cruise control* (p. 188)

Adaptive cruise control - ACC* (p. 190)

Paddle for manual gear changing in an
automatic gearbox, see Automatic gear­box -- Geartronic* (p. 261)

Audio and phone control, see supple­ment, Sensus Infotainment

Horn

Horn.

Press the centre of the steering wheel to sig­nal.

Related information

•

Heating* of the steering wheel (p. 80)

Heating* of the steering wheel

The steering wheel can be heated with elec­tric heating.

Function

Button position may vary depending on equip­ment selected and market.

Repeatedly press the button to switch
between the following functions:

Function Indicator

Switched off Button lamp extinguished

Heating Button lamp illuminated

Automatic steering wheel heating

With activated automatic start of steering
wheel heating, the heating of the steering
wheel starts when the engine is started. Auto­matic start takes place when the car is cold
and the ambient temperature is below

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

81

approx. 10 °C. Activate/deactivate the func­tion in the menu system MY CAR (p. 108).

Light switches

The headlamp control activates and adjusts
the external lighting. It is also used to adjust
display and instrument lighting and mood
lighting (p. 90).

Overview, light switches

Overview, light switches.

Thumbwheel for adjusting display and
instrument lighting as well as ambient
lighting*

Button for rear fog lamp

Knob for daytime running lights and park­ing lamps

Thumbwheel16 for headlamp levelling

Knob positions

Posi-

tion

Specification

Daytime running lightsA when
the car's electrical system is in
key position II or the engine is
running.

Main beam flash can be used.

Daytime running lights, side
marker lamps rear and position/
parking lamps when the car's
electrical system is in key posi­tion II or the engine is running.

Side marker lamps rear and
position/parking lamps when
the car is parked.

Main beam flash can be used.

Daytime running lights, side
marker lamps rear and position/
parking lamps in daylight when
the car's electrical system is in
key position II or the engine is
running.

Dipped beam, side marker
lamps rear and position/parking
lamps in weak daylight or dark­ness, or when the rear fog lamp

16

Not available for cars equipped with active Xenon headlamps*.

||

03 Instruments and controls

03

82

* Option/accessory, for more information, see Introduction.

Posi-

tion

Specification

or windscreen wipers with con­tinuous wiping are activated.

The tunnel detection (p. 84)*
function is activated.

The active high beam (p. 85)*
function can be used.

Main beam can be activated
when dipped beam is switched
on.

Main beam flash can be used.

Dipped beam, side marker
lamps rear and position/parking
lamps.

Main beam can be activated.
Main beam flash can be used.

A

Fitted in or under the front bumper.

Volvo recommends that

mode is used
when the car is being driven, as long as traffic
situations or weather conditions are unfavour­able for the Active high beam* function.

Instrument lighting

Different display and instrument lighting is
switched on depending on key position; see
Key positions - functions at different levels
(p. 74).

The display lighting is automatically subdued
in darkness - the sensitivity is set with the
thumbwheel.

The intensity of the instrument lighting is
adjusted with the thumbwheel.

Headlamp levelling

The load in the car changes the vertical align­ment of the headlamp beam, which could
dazzle oncoming motorists. Avoid this by
adjusting the height of the beam. Lower the
beam if the car is heavily laden.

1. Leave the engine running, or have the
car's electrical system in key position I.

2. Roll the thumbwheel up/down to raise/
lower beam alignment.

Thumbwheel positions for different load cases.

Only driver

Driver and passenger in the front passen­ger seat

Occupants in all seats

Occupants in all seats and maximum load
in the cargo area

The driver and maximum load in the
cargo area

Cars with active Xenon headlamps* have
automatic headlamp levelling and are there­fore not equipped with the thumbwheel.

Related information

•

Position/parking lamps (p. 83)

•

Daytime running lights (p. 83)

•

Main/dipped beam (p. 84)

03 Instruments and controls

03

83

Position/parking lamps

Position/parking lamps are switched on with
the headlamp control's knob.

Knob for headlamp control in the position for
position/parking lamps.

Turn the knob to the position for

(num­ber plate lighting is switched on at the same
time).

If the car's electrical system is in key position
II or the engine is running then the daytime
running lights also switch on.

When it is dark outside and the boot lid is
opened the rear position/parking lamps illumi­nate to alert traffic behind. This takes place
irrespective of what position the knob is in or
what key position the car's electrical system
is in.

Related information

•

Light switches (p. 81)

Daytime running lights

With the knob for headlamp control in
position, and the car's electrical system in key
position II or the engine running, the daytime
running lights are activated automatically in
daylight.

Daytime running lights during the day. DRL

Knob for headlamp control in AUTO position.

With the knob for headlamp control in
position the daytime running lights (Daytime
Running Lights - DRL) are activated automati­cally when the car is driven in daylight. A light
sensor on the top of the instrument panel
changes from daytime running lights to
dipped beam at twilight or when daylight
becomes too weak. Switching to dipped
beam also takes place when the windscreen
wipers or rear fog lamps are activated.

WARNING

This system help to save energy - it cannot
determine in all situations when daylight is
too weak or sufficiently strong, e.g. in mist
and rain.

The driver is always responsible for ensur­ing that the car is driven with the correct
beam pattern for the traffic situation and in
accordance with applicable traffic regula­tions.

03 Instruments and controls

03

84

* Option/accessory, for more information, see Introduction.

Tunnel detection*

Tunnel detection changes the lighting from
daytime running lights to dipped beam when
the car is driven into a tunnel. Approx. 20 sec­onds after the car has left the tunnel, the light­ing returns to daytime running lights.

The tunnel detection function is available in
cars with rain sensor*. The sensor detects the
entrance to a tunnel and resets the lighting
from daytime running lights to dipped beam.
Approx. 20 seconds after the car has left the
tunnel, the lighting returns to daytime running
lights. If the car is driven into another tunnel
within this time period then dipped beam is
kept switched on. This avoids repeated
changes to the car's lighting.

Note that the headlamp control's knob must
remain in

position for tunnel detection

to work.

Related information

•

Main/dipped beam (p. 84)

•

Light switches (p. 81)

Main/dipped beam

With the knob for headlamp control in posi­tion

and the car's electrical system in
key position II or the engine running, the
dipped beam is activated automatically in
poor light conditions.

With the knob for headlamp control in posi­tion

dipped beam is always switched on
when the engine is running or when key posi­tion II is active.

Stalk switch and knob for headlamp control.

Position for main beam flash

Position for main beam

Dipped beam

With the knob in position, dipped beam
is activated automatically at twilight or when
daylight becomes too weak. Dipped beam is
also activated automatically if the windscreen
wipers or rear fog lamps are activated.

With the knob in position

dipped beam
is always switched on when the engine is run­ning or when key position II is active.

Main beam flash

Move the stalk switch gently towards the
steering wheel to the position for main beam
flash. Main beam comes on until the stalk
switch is released.

Main beam

Main beam can be activated when the knob
is in position

17

or

. Activate/deac­tivate main beam by moving the stalk switch
towards the steering wheel to the end posi­tion and then releasing.

When main beam has been activated the

symbol illuminates in the combined

instrument panel.

Auxiliary lamps*

If the car has auxiliary lamps, the driver can
use the MY CAR menu system to choose
whether they should be deactivated or

17

When dipped beam is switched on.

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

85

switched on/off simultaneously with the main
beam18, see MY CAR (p. 108).

Related information

•

Active Xenon headlamps* (p. 87)

•

Active high beam* (p. 85)

•

Light switches (p. 81)

•

Headlamps - adjusting headlamp pattern
(p. 92)

•

Tunnel detection* (p. 84)

Active high beam*

The Active High Beam function detects the
headlamp beams of oncoming traffic or the
rear lights of vehicles in front, and switches
the lighting from main beam to dipped beam.
The lighting returns to main beam when the
incoming light has stopped.

Active high beam - AHB

Active high beam (Active High Beam - AHB) is
a function which uses a camera sensor at the
top edge of the windscreen to detect the
headlamp beams of oncoming traffic or the
rear lights of vehicles in front, and then
switches from main beam to dipped beam.
The function can also take streetlights into
account.

The lighting returns to main beam about a
second after the camera sensor no longer
detects the headlamp beams from oncoming
traffic or the rear lights from vehicles in front.

Activating/deactivating

AHB can be activated when the headlamp
control's knob is in position

(provided
that the function has not been deactivated in
the menu system MY CAR, see MY CAR
(p. 108)).

Stalk switch and knob for headlamp control in
AUTO position.

The function can start while driving in the
dark when the car's speed is 20 km/h or
higher.

Activate/deactivate AHB by moving the left­hand stalk switch towards the steering wheel
to the end position and then releasing. Deac­tivation when main beam is on means that the
lights are reset directly to dipped beam.

Car with analogue combined instrument
panel

When AHB is activated the

symbol illu­minates in the instrument's information dis­play.

When main beam is switched on the
symbol also illuminates in the combined
instrument panel.

18

Auxiliary lamps must be connected to the electrical system by a workshop. Volvo recommends that you contact an authorised Volvo workshop.

||

03 Instruments and controls

03

86

* Option/accessory, for more information, see Introduction.

Car with digital combined instrument panel

When AHB is activated the

symbol
turns white in the instrument's information
display.

When main beam is activated, the symbol
turns blue.

Manual operation

NOTE

Keep the windscreen surface in front of the
camera sensor free from ice, snow, mist
and dirt.

Do not stick or attach anything to the
windscreen in front of the camera sensor
as this may reduce effectiveness or cause
one or more of the systems dependent on
the camera to stop working.

If the message Active main beam

Temporary unavailable Switch manually is

shown in the combined instrument panel's
information display then you have to switch
manually between main and dipped beam.
However, the knob for headlamp control can

still remain in position

. The same

applies if the message

Windscreen sensors

blocked See manual

and the symbol

are shown. The symbol goes out when
these messages are shown.

AHB may be temporarily unavailable e.g. in
situations with dense fog or heavy rain. When
AHB becomes available again, or the wind­screen sensors are no longer blocked, the

message extinguishes and the

symbol

illuminates.

WARNING

AHB is an aid for using the optimum beam
pattern when conditions are favourable.

The driver always bears responsibility for
manually switching between main and
dipped beam when traffic situations or
weather conditions so require.

IMPORTANT

Examples of when manual switching
between main and dipped beam may be
required:

•

In heavy rain or dense fog

•

In freezing rain

•

In snow flurries or slush

•

In moonlight

•

When driving in poorly lit built-up
areas

•

When the traffic ahead has weak light­ing

•

If there are pedestrians on or beside
the road

•

If there are highly reflective objects
such as signs in the vicinity of the road

•

When the lighting from oncoming traf­fic is obscured by e.g. a crash barrier

•

When there is traffic on connecting
roads

•

On the brow of a hill or in a hollow

•

In sharp bends.

For more information on the limitations of the
camera sensor, see Collision warning system*

- camera sensor limitations (p. 221).

Related information

•

Main/dipped beam (p. 84)

•

Light switches (p. 81)

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

87

Active Xenon headlamps*

Active Xenon headlamps are designed to pro­vide maximum illumination in bends and junc­tions and so provide increased safety.

Active Xenon headlamps ABL

Headlamp pattern with function deactivated (left)
and activated (right) respectively.

If the car is equipped with active Xenon head­lamps (Active Bending Lights – ABL) the light
from the headlamps follows the steering
wheel movement in order to provide maxi­mum lighting in bends and junctions and so
provide increased safety.

The function is activated automatically when
the car is started (provided that it has not
been deactivated in the menu system
MY CAR, see MY CAR (p. 108)). In the event

of a fault in the function the

symbol illu-

minates in the combined instrument panel at
the same time as the information display
shows an explanatory text and a further illu­minated symbol.

Symbol Message Specification

Headlamp
system
malfunc­tion Serv­ice
required

The system is
disengaged. Visit
a workshop if
the message
remains. Volvo
recommends
that you contact
an authorised
Volvo workshop.

The function is only active in twilight or dark­ness and only when the car is moving.

The function19 can be deactivated/activated
in the menu system MY CAR, see MY CAR
(p. 108).

For headlamp pattern adjustment, see Head­lamps - adjusting headlamp pattern (p. 92).

Related information

•

Main/dipped beam (p. 84)

•

Active high beam* (p. 85)

•

Light switches (p. 81)

Rear fog lamp

When visibility is reduced by fog the rear fog
lamp can be used so that other road users
shall notice vehicles in front at an early stage.

Button for rear fog lamp.

The rear fog lamp can only be switched on
when key position II is active or the engine is
running and the headlamp control's knob is in

position

or .

Press the button for On/Off. The rear fog
lamp's indicator symbol in the com-

bined instrument panel and the light in the
button both illuminate when the rear fog lamp
is switched on.

The rear fog lamp is switched off automati­cally when the engine is switched off or when

19

Activated on delivery from the factory.

||

03 Instruments and controls

03

88

the headlamp control's knob is turned to
position

or .

NOTE

Regulations on the use of rear fog lamps
vary from country to country.

Related information

•

Light switches (p. 81)

Brake lights

The brake light automatically comes on during
braking.

The brake light is switched on when the brake
pedal is depressed. In addition, it is switched
on when one of driving support systems
Adaptive cruise control (p. 190), City Safety
(p. 208) or Collision warning system (p. 215)
brakes the car.

For information on emergency brake lights
and automatic hazard warning flashers, see
Foot brake - emergency brake lights and
automatic hazard warning flashers (p. 280).

Hazard warning flashers

The hazard warning flashers warn other road
users by means of all of the car's direction
indicator lamps flashing simultaneously when
this function is activated.

When the hazard warning flashers are acti­vated both direction indicator symbols flash in
the combined instrument panel.

Button for hazard warning flashers.

Press the button to activate the hazard warn­ing flashers. Both direction indicator symbols
in the combined instrument panel flash when
the hazard warning flashers are used.

The hazard warning flashers are activated
automatically when the car has been braked
so suddenly that the emergency brake lights
have been activated at a speed below
10 km/h. The hazard warning flashers remain
on when the car has stopped and are deacti­vated automatically when the car is driven off

03 Instruments and controls

03

89

again or the button is depressed. For more
information on emergency brake lights and
automatic hazard warning flashers, see Foot
brake - emergency brake lights and auto­matic hazard warning flashers (p. 280).

Related information

•

Direction indicators (p. 89)

Direction indicators

The car's direction indicators are operated
with the left-hand stalk switch. The direction
indicator lamps flash three times or continu­ously, depending on how far up or down the
stalk switch is moved.

Direction indicators.

Short flash sequence

Move the stalk switch up or down to the
first position and release. The direction
indicator lamps flash three times. The
function can be activated/deactivated in
the menu system MY CAR, see MY
CAR (p. 108).

Continuous flash sequence

Move the stalk switch up or down to the
outer position.

The stalk switch remains in its position and is
moved back manually, or automatically by the
steering wheel movement.

Direction indicator symbols

For direction indicator symbols, see Com­bined instrument panel - meaning of indicator
symbols (p. 64).

Related information

•

Hazard warning flashers (p. 88)

03 Instruments and controls

03

90

Interior lighting

The passenger compartment lighting is acti­vated/deactivated with the buttons in the con­trols above the front seats and the rear seat.

G021149

Controls in roof console for the front reading
lamps and passenger compartment lighting.

Reading lamp, left-hand side

Reading lamp, right-hand side

Interior lighting

All lighting in the passenger compartment can
be switched on and off manually within
30 minutes from when:

•

the engine has been switched off and the
car's electrical system is in key position 0

•

the car has been unlocked but the engine
has not been started.

Front roof lighting

The front reading lamps are switched on or
off by pressing the relevant button in the roof
console.

Rear roof lighting

G021150

Rear roof lighting.

The lamps are switched on or off by pressing
each respective button.

Courtesy lighting

Courtesy lighting (and passenger compart­ment lighting) is switched on and off respec­tively when a side door is opened or closed.

Glovebox lighting

Glovebox lighting is switched on and off
respectively when the lid is opened or closed.

Vanity mirror lighting

The lighting for the vanity mirror (p. 148) is
switched on and off respectively when the
cover is opened or closed.

Automatic lighting

The switch for passenger compartment light­ing has three positions for the lighting in the
passenger compartment:

•

Off – right-hand side pressed in, auto­matic lighting deactivated.

•

Neutral position – automatic lighting
activated.

•

On – left-hand side pressed in, passenger
compartment lighting switched on.

Neutral position

When the button is in neutral position the
passenger compartment lighting is switched
on and off automatically in accordance with
the following.

The passenger compartment lighting is
switched on and remains on for 30 seconds
if:

•

the car is unlocked with the remote con­trol key or key blade, see Remote control
key - functions (p. 158) or Detachable
key blade - unlocking doors (p. 163)

•

the engine has been switched off and the
car's electrical system is in key position

0.

Passenger compartment lighting is switched
off when:

•

the engine is started

•

the car is locked.

03 Instruments and controls

03

* Option/accessory, for more information, see Introduction.

91

The passenger compartment lighting comes
on and remains on for two minutes if one of
the doors is open.

If any lighting is switched on manually and
the car is locked then it will be switched off
automatically after two minutes.

Mood lights*

When the normal passenger compartment
lighting is switched off and the engine is run­ning, a number of LEDs illuminate, including
one in the ceiling lighting, in order to provide
a low-light and enhance the mood while driv­ing. The light also makes it easier to see
objects in storage compartments etc. during
the darker hours of the day. This lighting goes
out for a little while after the normal passen­ger compartment lighting when the car is
locked. The brightness is controlled using the
thumbwheel on the headlamp control (p. 81).

Home safe light duration

Home safe lighting consists of dipped beam,
parking lamps, lamps in the door mirrors,
number plate lighting, interior roof lighting as
well as courtesy lighting.

Some of the exterior lighting can be kept
switched on to work as home safe lighting
after the car has been locked.

1. Remove the remote control key from the
ignition switch.

2. Move the left-hand stalk switch toward
the steering wheel to the end position and
release it. The function can be activated
in the same way as with main beam flash;
see Main/dipped beam (p. 84).

3. Get out of the car and lock the door.

When the function is activated, dipped beam,
parking lamps, door mirror lamps, number
plate lighting, interior roof lamps and courtesy
lighting are switched on.

The length of time for which the home safe
lighting should be kept on can be set in the
menu system MY CAR, see MY CAR (p. 108).

Related information

•

Approach lighting (p. 91)

Approach lighting

Approach lighting consists of parking lamps,
lamps in the door mirrors, number plate light­ing, interior roof lighting as well as courtesy
lighting.

Approach lighting is switched on with the
remote control key, see Remote control key ­functions (p. 158), and is used to switch on
the car's lighting at a distance.

When the function is activated with the
remote control, the parking lamps, door mir­ror lamps, number plate lighting, interior roof
lamps and courtesy lighting are switched on.

The length of time for which the approach
lighting should be kept on can be set in the
menu system MY CAR, see MY CAR (p. 108).

Related information

•

Home safe light duration (p. 91)

03 Instruments and controls

03

92

* Option/accessory, for more information, see Introduction.

Headlamps - adjusting headlamp pattern

The headlamp pattern must be adjusted to
avoid dazzling oncoming motorists and can
be set for right or left-hand traffic.

G021151

Headlamp pattern, left-hand traffic.

G021152

Headlamp pattern, right-hand traffic.

Active Xenon headlamps*

G019442

Headlamp control for adjusting headlamp pat­tern.

Normal position – the headlamp pattern is
correct for the country in which the car
was delivered.

Adapted position – designed for opposite
headlamp pattern.

WARNING

The headlamps must be handled with
extreme caution due to the Xenon lamp
being supplied by a high-voltage unit.

The country in which the car is delivered
determines whether normal position is
designed for right or left-hand traffic.

Example 1

If a car that is delivered in Sweden shall be
driven in the UK then the headlamps must be

set to the adjusted position, see preceding
illustration.

Example 2

A car that is delivered in the UK is designed
for left-hand traffic and is driven there with
the headlamps in normal position, see pre­ceding illustration.

Halogen headlamps

The headlamp pattern for halogen headlamps
is readjusted by masking the headlamp lens.
The headlamp pattern may not be as good.

03 Instruments and controls

03

}}

93

Masking the headlamps

1. Copy the A and B templates for left-hand
drive cars or the C and D templates for
right-hand drive cars, see the later sec­tion "Templates for halogen headlamps":

•

A = LHD Right (left-hand drive, right
lens)

•

B = LHD Left (left-hand drive, left lens)

•

C = RHD Right (right-hand drive, right
lens)

•

D = RHD Left (right-hand drive, left
lens)

2. Transfer the template to a self-adhesive
waterproof material and cut it out.

3. Start from the design line on the head­lamp lenses; see the dotted line in the fol­lowing figure. Position the self-adhesive
templates at the right distance from each
design line using the illustration and the
dimensions in the following list:

•

A = LHD Right - approx. 86 mm

•

B = LHD Left - approx. 40 mm

•

C = RHD Right - 0 mm

•

D = RHD Left - approx. 96 mm

||

03 Instruments and controls

03

94

Upper row: left-hand drive cars, templates A and B. Lower row: right-hand drive cars, templates C and D.

03 Instruments and controls

03

95

Templates for halogen headlamps

03 Instruments and controls

03

96

* Option/accessory, for more information, see Introduction.

Wipers and washing

Wipers and washers clean the windscreen
and rear window. The headlamps are cleaned
with high-pressure washing.

Windscreen wipers

20

Windscreen wipers and windscreen washers.

Rain sensor, on/off

Thumbwheel sensitivity/frequency

Windscreen wipers off

Move the stalk switch to position 0
to switch off the windscreen wipers.

Single sweep

Raise the stalk switch and release to
make one sweep.

Intermittent wiping

Set the number of sweeps per time
unit with the thumbwheel when
intermittent wiping is selected.

Continuous wiping

The wipers sweep at normal speed.

The wipers sweep at high speed.

IMPORTANT

Before activating the wipers during winter ­ensure that the wiper blades are not frozen
in, and that any snow or ice on the wind­screen is scraped away.

IMPORTANT

Use plenty of washer fluid when the wipers
are cleaning the windscreen. The wind­screen must be wet when the windscreen
wipers are operating.

Service position wiper blade

For cleaning the windscreen/wiper blades
and replacement of wiper blades, see Wiper
blades (p. 359) and Car washing (p. 380).

Rain sensor*

The rain sensor automatically starts the wind­screen wipers based on how much water it

detects on the windscreen. The sensitivity of
the rain sensor can be adjusted using the
thumbwheel.

When the rain sensor is activated a lamp in
the button is illuminated and the rain sensor

symbol

is shown in the combined

instrument panel.

Activating and setting the sensitivity

When activating the rain sensor, the car must
be running or the remote control key in posi­tion I or II while the windscreen wiper stalk
switch must be in position 0 or in the position
for a single sweep.

Activate the rain sensor by pressing the but­ton

. The windscreen wipers make one

sweep.
Press the stalk switch up for the wipers to

make an extra sweep.
Turn the thumbwheel upward for higher sen-

sitivity and downward for lower sensitivity.
(An extra sweep is made when the thumb­wheel is turned upward.)

Deactivate

Deactivate the rain sensor by pressing the
button

or move the stalk switch down

to another wiper program.

20

For replacing the wiper blades and service position wiper blades, see Wiper blades (p. 359). For filling washer fluid, see Washer fluid - filling (p. 361).

03 Instruments and controls

03

}}

* Option/accessory, for more information, see Introduction.

97

The rain sensor is automatically deactivated
when the remote control key is removed from
the ignition switch or five minutes after the
engine has been switched off.

IMPORTANT

The windscreen wipers could start and be
damaged in an automatic car wash.
Switch off the rain sensor while the car is
in motion or when the remote control key
is in position I or II. The symbol in the
combined instrument panel and the lamp
in the button go out.

Washing the headlamps and windows

Washing function.

Washing the windscreen

Move the stalk switch toward the steering
wheel to start the windscreen and headlamp
washers.

The windscreen wipers will make several
more sweeps and the headlamps are washed
once the stalk switch has been released.

Heated washer nozzles*

The washer nozzles are heated automatically
in cold weather to prevent the washer fluid
freezing solid.

High-pressure headlamp washing*

High-pressure headlamp washing consumes
a large quantity of washer fluid. To save fluid,
the headlamps are washed automatically at
every fifth windscreen wash cycle.

Reduced washing

If only approx. 1 litre of washer fluid remains
in the reservoir and the message that you
should fill the washer fluid is shown in the
combined instrument panel, then the supply
of washer fluid to the headlamps is switched
off. This is in order to prioritise cleaning the
windscreen and the visibility through it.

Related information

•

Washer fluid - filling (p. 361)

•

Washer fluid - quality and volume
(p. 402)

Power windows

All power windows can be operated using the
control panel for the driver's door - the con­trol panels for the other doors operate their
respective power window.

Driver's door control panel.

Switch for electric child safety locks* and
disengaging rear power window buttons;
see Child safety locks - electrical activa­tion* (p. 175).

Rear window controls

Front window controls

WARNING

Check that no rear seat passengers are
trapped when the windows are closed
from the driver's door.

||

03 Instruments and controls

03

98

WARNING

Check that children or other passengers
are not trapped if the windows are closed,
even when the remote control key is used.

WARNING

If there are children in the car - remember
to always switch off the power supply to
the power windows by selecting key posi­tion 0 and then take the remote control key
with you when leaving the car. For infor­mation on key positions - see Key posi­tions - functions at different levels (p. 74).

Operating

Operating the power windows.

Operating without auto

Operating with auto

All power windows can be operated using the
control panel for the driver's door - the con­trol panels for the other doors can only each
operate their respective power window. Only
one control panel can be operated at a time.

In order for the power windows to be used,
the key position must be at least I - see Key
positions - functions at different levels (p. 74).
The power windows can be operated for a
few minutes after the engine has been
switched off and after the remote control key
has been removed - although not after a door
has been opened.

Closing of the windows is stopped and the
window is opened if anything prevents its
movement. It is possible to force the pinch
protection when closing has been interrupted,
e.g. with ice, by continuously holding the but­ton up until the window is closed. The pinch
protection is reactivated after a brief pause.

NOTE

One way to reduce the pulsating wind
noise when the rear windows are open is
to also open the front windows slightly.

Operating without auto

Move one of the controls up/down gently.
The power windows move up/down as long
as the control is held in position.

Operating with auto

Move one of the controls up/down to the end
position and release it. The window runs
automatically to its end position.

Operating with the remote control key and central locking

To remotely operate the power windows from
the outside with the remote control key or
from inside with central locking, see Remote
control key (p. 155) and Locking/unlocking ­from the inside (p. 171).

Resetting

If the battery is disconnected then the func­tion for automatic opening must be reset so
that it can work correctly.

1. Gently raise the front section of the but­ton to raise the window to its end position
and hold it there for one second.

2. Release the button briefly.

3. Raise the front section of the button again
for one second.

WARNING

A reset must take place for pinch protec­tion to work.
