2015 Jetta Hybrid Quick-Start Guide
European model shown.
A Volkswagen isn’t like any other car. And a
Jetta Hybrid isn’t like any other Volkswagen. Here’s
where you’ll learn some simple tips for higher
mileage* and better driving.
knowingyourvw.com
On-demand videos
When you see this symbol, you can discover more with your smart
phone by texting the letter keys to the code provided. A video tutorial
will be sent to further explain the topic.
Text* KYVW22 to 38981 to watch the Introduction to
knowingyourvw.com video. Standard text and data rates apply.
The information within this guide must be used in conjunction with the information in the Volkswagen Owner’s Manual. Refer to your vehicle’s Owner’s Manual for all information and warnings. By using this guide,
you acknowledge that you are aware of and have read the warnings and information provided in the Owner’s Manual on the topics in this guide and will use this information to augment that material.
*See back cover for mpg information.
European model shown.
*Do not text while driving.
Table of Contents
Hybrid Functions and Features
®
Bluetooth
Premium VIII Audio
RNS 315 Audio and Navigation
Windshield Wipers
Setting the Clock
Cruise Control
Keyless Entry
Tire Pressure Monitoring System (TPMS)
Volkswagen Car-Net
Additional Resources
Technology
®
1
13
17
19
21
22
23
25
26
27
29
Before Driving Your Jetta Hybrid
1
There are a few things you should know before taking your new hybrid out for a spin
When starting your vehicle
To start your vehicle, step on the brake pedal and
press the START/STOP button in the center console (or
turn the ignition key, depending on your vehicle’s trim).
A chime will sound, the instrument needles will
sweep, and READY will appear in the instrument cluster.
Depending on the battery status, the gas engine will start
or you can drive off with electric energy alone.
LEARN MORE AT
knowingyourvw.com
Hybrid
Functions & Features
Important Safety Instructions and Warnings, which you must read, are listed on the last panel under HYBRID DRIVE.
Before leaving your vehicle
Your Jetta Hybrid includes a special safety feature.
Suppose your vehicle is in READY mode and the vehicle
is in Park or Neutral:
N,74=C743A8E4A>?4=BC743>>A0F0A=8=6278<4
will sound. That’s because the electric motor is so silent,
you may not be aware that the vehicle is operable.
2
Energy Flow Diagram
3
“Energy flow” refers to the direction that energy is moving
through your vehicle’s drivetrain. While driving, diagrams
in your multifunction and touchscreen displays will show
one of five “energy modes,” depending on the direction
of the energy flow.
Stationary vehicle mode: No energy flow.
Charge mode: From wheels to battery.
Electric motor mode: From battery to wheels.
Engine mode: From gas engine to wheels (and to battery,
depending on speed and battery charge level).
Boost mode: From combustion engine and battery to wheels.
Important Safety Instructions and Warnings, which you must read, are listed on the last panel under HYBRID DRIVE.
Energy flow diagram
Using the multifunction display
Press the button on the right side of the
steering wheel repeatedly until you see the energy
flow diagram.
Three images will be displayed, representing the gas
engine, drivetrain, and battery. Arrows between the
icons will indicate the direction of the Energy flow.
To change the default Premium VIII
display
Press the SETUP hard key, then press Veh ic l e on the touchscreen.
Using the touchscreen
A color-coding system will show you the direction of
energy flow through the drivetrain.
Press the CAR hard key. The screen will default to the
“Energy flow” option. Different modes will display the
energy flow to the wheels.
Text* ENERGY22 to 38981 to watch
the Energy Display video.
Standard text and data rates apply.
*Do no text while driving.
To make “Energy flow” the default
RNS 315 display
Press the CAR hard key.
Press the SETUP hard key.
Check “Initial display: Hybrid.”
You may have to wait a few moments for the
default to activate.
To show your Zero Emission
driving
If “Initial display: Hybrid” is checked, the initial display will
be the vehicle’s Energy flow. If it is unchecked, the display will
default to the most recently viewed setting.
LEARN MORE AT
knowingyourvw.com
Hybrid
Functions & Features
During the last thirty minutes of your current
trip, press Hybrid on the touchscreen, then
press Zero Emission on the touchscreen.
Zero Emission Driving Time. Premium VI II display shown.
Important Safety Instructions and Warnings, which you must read, are listed on the last panel under HYBRID INFOTAINMENT SYSTEM.
4
Tips for Fuel-Efficient Driving
Here are a few hints to help you receive the best mileage* out of your Jetta Hybrid
5
Overall power usage: Keep an eye on the power meter
gauge, and try to drive within the 30 percent power range
(blue ECO range).
Starting from stop: Shift into Drive, remove your foot from
the brake pedal, and slowly press the accelerator. Quick
acceleration can reduce fuel economy by up to 33 percent
on the highway and 5 percent in the city.
Everyday driving: Refrain from heavy acceleration or
braking abruptly. Avoid idling whenever possible.
Charging the battery: Brake early and steadily with short
pedal movements. Let the vehicle coast to a stop.
*See back cover for mpg information.
1
Driving More Efficiently: Drive Sensibly, www.fueleconomy.gov
Driving with the Gasoline Engine
Your Jetta Hybrid will use the
gasoline engine alone when:
Accelerating to or driving at higher speeds.**
The battery charge level is low.
The gasoline engine will also
automatically switch on when:
Driving on highways and expressways: Coast as
often as possible when conditions allow. When driving
at higher speeds, increased wind resistance reduces
fuel economy.
Cold weather and frequent short trips: The engine
1
does not operate efficiently until it is warmed up.
Differences in terrain: Hilly, mountainous, or unpaved
roads reduce fuel economy.
o
NOTE: When using the AC, set the temperature to 72
AUTO button for greater fuel efficiency.
F and press the
Boost mode
Driving under both gasoline and electric power.
Your Jetta Hybrid will use the gasoline engine and
electric motor at the same time when the accelerator
is pressed down completely. This uses a large amount
of energy.**
**Always obey speed and traffic laws.
The AC system requires a high amount of power.
The engine temperature is cold.
More braking power is needed (using the brake booster).
LEARN MORE AT
knowingyourvw.com
Hybrid
Functions & Features
Important Safety Instructions and Warnings, which you must read, are listed on the last panel under HYBRID INFOTAINMENT SYSTEM, HYBRID FUNCTIONS & MODES.
6
Hybrid Power Operation
7
Electric or gasoline power, or both?
Your Jetta Hybrid adapts to your driving needs by
seamlessly switching its power source.
Driving with the electric motor
Depending on the battery charge level, your Jetta
Hybrid will operate solely under electric power when:
N(C0AC8=6D?>ABC>??8=6
NA8E8=60C;>FB?443B
N>0BC8=6>A1A0:8=6
Text* EMODE22 to 38981 to watch
the Driving in E-MODE video.
Standard text and data rates apply.
Recharging the battery
Your Jetta Hybrid will turn off the gasoline engine
and charge the battery when:
N>0BC8=6
NA0:8=6
NA8E8=63>F=78;;
E-MODE is available under these
conditions:
You are driving under 42 mph.
Driving with E-MODE
In extended electro-mode drive (E-MODE), the electric
motor is used as much as possible.
While the car is in “Drive,” push the E-MODE button in
the center console.
Your Jetta Hybrid will be able to use the electric motor
longer before switching to the gas engine.
The “E-MODE” icon will appear on the multifunction
display, indicating that E-MODE is active.
LEARN MORE AT
knowingyourvw.com
Hybrid
Functions & Features
®
The transmission is not in Sport (S) or Tiptronic
The hybrid battery is adequately charged.
If you accelerate too heavily or the battery falls below
a certain charge level, the icon will become smaller,
indicating that E-MODE is in standby. After slowing
your speed below 42 mph (or allowing the battery to
charge), push the E-MODE button again to activate.
E-MODE icon
Important Safety Instructions and Warnings, which you must read, are listed on the last panel under HYBRID INFOTAINMENT SYSTEM, HYBRID FUNCTIONS & MODES.
At higher speeds, or while driving in Tiptronic
Sport (S) mode, the “E-MODE currently unavailable”
message will appear on the multifunction display.
*Do no text while driving.
mode.
®
or
8
Digital E-Power Meter
To stay in electric mode, keep an eye on the digital E- Power meter in your
multifunction display.
As you accelerate under electric power, you will see the horizontal gauge move
closer to the E-Max setting.
When the gauge reaches E-Max, the electric motor is operating at full power.
The gas engine will then activate to provide more power.
9
To help increase fuel efficiency*, keep the gauge under E- Max to stay in
electric mode.
*See back cover for mpg information.
Analog Power Meter
The analog power meter needle on the left gauge
in the instrument cluster indicates your vehicle’s
power status.
As you drive, the needle will point to different areas
of the color-coded dial.
Numbers on the power meter show the percentage
of the vehicle’s power currently in use.
E-Power meter
The green area (while coasting or braking) — the
battery is charging. Note that the vehicle does not
charge at OFF or while completely stopped.
The blue area (economic driving) — the vehicle is using
either the electric motor or the gas engine, depending on
the battery’s charge level.
The white area (acceleration or driving at high
speeds**) — the vehicle is powered by the gas engine.
LEARN MORE AT
knowingyourvw.com
Hybrid
Functions & Features
The BOOST area (hard acceleration) — the vehicle is
using both the electric motor and gas engine.
**Always obey speed and traffic laws.
Important Safety Instructions and Warnings, which you must read, are listed on the last panel under HYBRID INSTRUMENT CLUSTER.
