Vodafone Smart First 7 Owner's Guide
User manual
Smart rst 7
VFD 200
About this manual
Thank you for choosing this mobile device. In order to keep
your device in its best condition, please read this manual and
keep it for future re ference.
Copyright
Copyright © 2016 ZTE CORPORATION
All rights reserved.
No part of this publication may be quoted, reproduced,
translated or used in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without the
prior written permission of ZTE Corporation.
Notice
ZTE Corporation reserves the right to make modifications on
print errors or update specifications in this guide without prior
notice. This manual has been designed with the utmost care to
ensure the accuracy of its content. However, all statements,
information and recommendations contained therein do not
constitute a warranty of any kind, either expressed or implied.
Please refer to For your safety to be sure to use your phone
properly and safely. We offer self-service for our smart terminal
device users.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and
damages caused by unauthorised modifications of the
software.
Images and screenshots used in this manual may differ from
the actual product. Content in this manual may differ from the
actual product or software.
1
Trademarks
ZTE and the ZTE logos are trademarks of ZTE Corporation.
Google and Android are trademarks of Google, Inc.
The
Bluetooth SIG, Inc. and any use of such trademarks by ZTE
Corporation is under license.
Other trademarks and trade names are the property of their
respective owners.
Version No.: R1.0
Edition Time: January 20, 2016
®
Bluetooth
trademark and logos are owned by the
microSD Logo is a trademark of SD-3C, LLC.
2
Contents
1. Getting started ............................................... 8
1.1 Getting to know your phone ........................................ 8
1.2 Knowing the keys ............................................................. 9
1.3 Installing your micro-SIM card and the Battery .. 10
1.4 Installing an optional microSD™ Card .................... 12
1.5 Charging the battery .................................................... 12
1.6 Extending the battery life ........................................... 14
1.7 Powering on/off ............................................................. 14
1.8 Setting up for the first time ........................................ 15
1.9 Locking/unlocking the screen and keys ............... 15
1.10 Using the touch screen ............................................ 16
1.11 Getting to know the home screen ........................ 17
2. Personalising ................................................ 18
2.1 Changing the system language ............................... 18
2.2 Setting the date and time ........................................... 18
2.3 Changing ringtone and notification sound .......... 18
2.4 Turning on/off touch sound ...................................... 19
2.5 Adjusting volume........................................................... 19
2.6 Switching to silent or vibration mode .................... 19
2.7 Applying new wallpapers ............................................ 20
2.8 Changing screen brightness ...................................... 20
2.9 Protecting your phone with screen locks ............. 21
2.10 Protecting your phone with encryption ............. 22
3. Knowing the basics ..................................... 24
3.1 Monitoring the phone status .................................... 24
3.2 Managing notifications ................................................ 25
3
3.3 Managing shortcuts and widgets ............................ 27
3.4 Organising with folders ................................................ 28
3.5 Rearranging the primary icons ................................. 29
3.6 Editing text ....................................................................... 29
3.7 Opening and switching apps ..................................... 30
4. Connecting to networks and devices .... 31
4.1 Connecting to mobile networks .............................. 31
4.2 Connecting to Wi-Fi ....................................................... 33
4.3 Using Wi-Fi Direct® ......................................................... 36
4.4 Connecting to Bluetooth devices ............................ 36
4.5 Connecting to your computer via USB .................. 38
4.6 Sharing your mobile data connection ................... 40
4.7 Connecting to virtual private networks ................. 43
5. Phone calls .................................................... 45
5.1 Placing and ending calls ............................................. 45
5.2 Answering or rejecting calls ...................................... 46
5.3 Working with the call log ............................................ 47
5.4 Calling your contacts ................................................... 48
5.5 Checking voicemail ...................................................... 48
5.6 Using options during a call ........................................ 49
5.7 Managing multi-party calls ........................................ 49
5.8 Adjusting your call settings ....................................... 50
6. Contacts .......................................................... 54
6.1 Checking contact details ............................................ 54
6.2 Adding a new contact .................................................. 54
6.3 Setting up your own profile ....................................... 55
6.4 Importing, exporting and sharing contacts ......... 55
4
6.5 Working with favourite contacts .............................. 56
6.6 Searching for a contact ............................................... 57
6.7 Editing contacts ............................................................. 57
7. Accounts ......................................................... 59
7.1 Adding or removing accounts ................................... 59
7.2 Configuring account sync .......................................... 60
8. Email ................................................................ 61
8.1 Setting up the first email account ........................... 61
8.2 Checking your emails .................................................. 61
8.3 Responding to an email .............................................. 62
8.4 Writing and sending an email .................................... 63
8.5 Adding and editing email accounts ........................ 63
8.6 Changing general email settings ............................. 64
9. Messaging ...................................................... 65
9.1 Opening the Messaging screen ................................ 65
9.2 Sending a message ....................................................... 65
9.3 Replying to a message ................................................ 66
9.4 Forwarding a message ................................................. 66
9.5 Changing Messaging. settings .................................. 66
10. Web Browser .................................................. 67
10.1 Opening the Browser ................................................. 67
10.2 Downloading files ....................................................... 67
10.3 Changing Chrome settings ..................................... 67
11. Camera ............................................................ 68
11.1 Capturing a photo ....................................................... 68
11.2 Recording a video ....................................................... 68
11.3 Customising camera/camcorder settings ......... 69
5
12. Gallery ............................................................. 70
12.1 Opening gallery ........................................................... 70
12.2 Working with albums ................................................. 70
12.3 Working with pictures ................................................ 70
12.4 Retouching your pictures ........................................ 72
12.5 Playing videos .............................................................. 72
13. Play music ...................................................... 73
13.1 Playing your music ..................................................... 73
13.2 Managing playlists ...................................................... 75
14. Video player ................................................... 77
14.1 Opening the video library ........................................ 77
14.2 Playing and controlling videos .............................. 77
14.3 Managing video files .................................................. 77
15. FM radio .......................................................... 79
15.1 Scanning and saving channels .............................. 79
15.2 Listening to FM radio ................................................. 79
15.3 Recording radio programs ....................................... 80
15.4 Editing a saved channel ............................................ 80
15.5 Other options and settings ...................................... 80
16. Sound recorder ............................................. 81
16.1 Recording a voice memo ......................................... 81
16.2 Playing a voice memo ............................................... 81
17. More apps ....................................................... 82
17.1 Clock ................................................................................ 82
17.2 Calculator ...................................................................... 83
17.3 Downloads ..................................................................... 83
17.4 File manager ................................................................. 83
6
17.5 Google apps .................................................................. 84
18. Settings ........................................................... 85
18.1 Wireless and networks .............................................. 85
18.2 Device .............................................................................. 86
18.3 Personal .......................................................................... 89
18.4 System ............................................................................ 93
19. Troubleshooting ........................................... 94
20. For your safety .............................................. 99
General safety ........................................................................ 99
RF exposure ...........................................................................100
Distraction .............................................................................101
Product handling ................................................................102
Power supply ........................................................................103
Protect your hearing ..........................................................105
Electrical safety ...................................................................105
Battery Handling & Safety ...............................................106
Interference ..........................................................................106
Explosive environments ...................................................108
21. Declaration of RoHS Compliance ........ 109
22. Disposal of Your Old Appliance ............ 110
23. EC DECLARATION OF CONFORMITY ..... 111
7
y
1. Getting started
1.1 Getting to know your phone
Earpiece
Touch screen
Light
Back key
Recents ke
Home key
8
p
Headset port
Volu me key
Power key
1.2 Knowing the keys
Key Function
Power ke y
Home key
Press and hold to power on, select phone
modes, turn on/off flight mode, restart or
power off.
Press to turn off or on the screen display.
Touch to return to the home screen from
any application or screen.
Touch and hold to get Google Search.
Camera
Charging /
ort
micro-USB
9
Key Function
Recents key Touch to see recently used apps.
Back key Touch to go to the previous screen.
Volume key Press or hold either end to turn the volume up
or down.
1.3 Installing your micro-SIM card and the
Battery
Switch off your phone before installing or replacing the battery
or the micro-SIM card. You can install the micro-SIM cards into
the slots.
1. Inser t your fingernail into the slot at the bottom right of
the back cover and lift it up gently.
2. Hold the micro-SIM card with the cut corner oriented as
shown and slip them into the card holders.
10
WARN ING!
To avoid damage to the phone, do not use any other kind of SIM
card, or any non-standard micro-SIM card cut from a SIM card.
Yo u can get a standard micro-SIM card by contacting your
service provider.
3. Inser t the battery by aligning the metal contacts in the
battery compartment. Gently push down on the battery
until it clicks in to place.
4. Align the back cover with the back of the phone and press
the cover back into place.
11
1.4 Installing an optional microSD™ Card
An optional microSD card can be inst alled. Unmount the
microSD card before removing it (see Erase and format t he
microSD card).
1. Remove the back cover and the battery.
2. Hold your microSD card with the metal contacts facing
down and slide it in.
3. Replace the back cover.
1.5 Charging the battery
Your phone’s battery should have enough power for the phone
to turn on, find a signal, and make a few calls. You should f ully
charge the battery as soon as possible.
If the battery is low, there will be a pop-up message on the
screen. As you charge your phone, the screen will tell you the
exact battery level on the lock screen. See Locking/u nlocking
the screen and keys.
12
WARN ING!
Use only approved chargers and cables for your pho ne.
Connecting with incompatible accessories could physically
damage your phone, or lead to excessive electrical current and
cause battery explosion. The working temperature of the
charger should be lower than 45°C.
CAUTION:
Do not change the built-in rechargeable battery in your phone
by yourself. If your battery needs to be replaced, please contact
your service provider.
1.
Connect the adapter to the charging port. Ensure that the
adapter is inserted with the correct orientation. Do not
force the connector into the charging port.
2. Connect the charger to a standard AC power outlet. If the
phone is on, you’ll see a charging icon, such as or
, appear on the status bar.
Disconnect the charger when the screen indicates that the
3.
battery is fully charged.
13
NOTE:
If the battery is seriously depleted, you may be unable to power
on the phone even when it is being charged. In this case, try
again after charging the phone for at least 20 minutes. Contact
customer service if you still cannot power on the phone after
prolonged charging.
1.6 Extending the battery life
Active applications, screen brightness levels, Bluetooth, Wi-Fi,
and GPS functionality can drain your battery. You can follow the
tips below to conserve your battery power:
Enable the Battery s aver. See Battery for details.
Reduce the screen backlight time.
Lower the screen brightness.
Turn auto-sync, Wi-Fi, and Bluetooth off when not in use.
Disable the GPS function when not in use. Most
applications using this function will periodically check the
GPS satellites for your current location; each check drains
your battery.
1.7 Powering on/off
Press and hold the Power key to turn on your phone.
To power off, press and hold the Power key to open the
options menu. Touch Shut down.
NOTE:
If the phone freezes or takes too long to respond, you can press
and hold the Power key for about 16 seconds to power the
phone off, and then turn it on again.
14
1.8 Setting up for the first time
When you first power on your phone after you purchase it or
reset it to factory settings (see
finish some basic settings before using it.
Flick the language field to select the language. Then follow the
on-screen prompts to set up your phone.
NOTE:
To help you get used to some of the great new features, your
phone can display Help Tips on certain screens when you first
encounter these interfaces. You can turn off or on Help Tips
during set up, or touch to close a tip.
Backup & reset), you need to
1.9 Locking/unlocking the screen and keys
Your phone allows you to quickly lock the screen and keys (put
the phone into sleep mode ) when not in use and to turn the
screen back on and unlock it when you need it.
To lock the screen and keys:
To quickly turn the screen off and lock the keys, press the
Power Ke y.
NOTE:
To save battery power, the phone automatically turns off the
screen after some time of inactivity (see “Sleep” in Display
will still be able to receive messages and calls while the phone
screen is off.
To unlock the screen and keys:
1. Press the Power key to turn the screen on.
2. Touch the screen and swipe up.
- or Touch the Phone icon at the bottom left and swipe right to
open the Phone app.
15
). You
- or Touch the Camera icon at the bottom right and swipe left
to open the Camera app.
NOTE:
If you have set an unlock pattern, PIN or password for your phone
(see
Protecting your phone with screen locks), you’ll need to draw
the pattern or enter the PIN/password to unlock your screen.
1.10 Using the touch screen
Your phone’s touch screen lets you control actions through a
variety of touch gestures.
Touch
When you want to type using the onscreen keyboard , select
onscreen items such as application and settings icons, or
press onscreen buttons, simply touch them with your finger.
Touch and Hold
To open the available options for an item (for example, a
message or link in a web page), touch and hold the item.
Swipe or Slide
To swipe or slide means to quickly drag your finger
vertically or horizontally across the screen.
Drag
To drag, press and hold your finger with some pressure before
you start to move your finger. While dragging, do not release
your finger until you have reached the target position.
Pinch
In some apps (such as Maps, Chrome, and Gallery), you can
zoom in and out by placing two fingers on the screen at
once and pinching them together (to zoom out) or
spreading them apart (to zoom in).
16
r
1.11 Getting to know the home screen
The home screen is the star ting point for your phone’s
applications, functions, and menus. You can customise your
home screen by adding shortcuts, folders, widgets, and more.
Extended Home Screens
Your home screen is extendable, providing more space for
shortcuts, folders, widgets, and more. Simply swipe left or right
on the screen to see the extended panels.
See Managing shortcuts and widgets
how to add or remove additional home screen panels.
NOTE:
In addition to the standard home screen above, you can also
use the simple home screen. See Home.
Status &
notification bar
Google search
Widgets
Folde
Shortcut
Favo urit es tr ay
shortcuts
for more informatio n on
17
2. Personalising
2.1 Changing the system language
1. To uc h th e Home key > > Settings > Language &
input > Language.
2. Select the language you need.
2.2 Setting the date and time
1. To uc h th e Home key > > Settings > Date & time.
2. Uncheck Automatic date & time and Automatic time
zone if you want to set the date, time and time zone by
yourself.
3. Set the date, time, time zone, and date/time format.
2.3 Changing ringtone and notification sound
You can customise the default incoming call ringtone and the
default notification sound.
1. To uc h th e Home key > > Settings > Sound &
notification.
2. To u ch Default notification ringtone or Phone ringtone.
3. Scroll through the ringtone list and select the ringtone
you want to use. You can touch more ringtone s to select
songs and voice memos from the storage.
4. To u ch OK.
NOTE:
See Set a ringtone for a contact for how to assign a special
ringtone to an individual contact.
18
2.4 Turning on/off touch sound
1. Tou ch the Home key > > Settings > Sound &
notification > Other sounds.
2. Tou c h To uch so und s.
2.5 Adjusting volume
1. Tou ch the Home key > > Settings > Sound &
notification.
2. Drag the sliders below Media volume, Alarm volume,
Ring volume to adjust the volume for each type of audio.
NOTE:
You can adjust the media volume when a media application is in
use by pressing the Volume Key. If no media application is
active, press the Volume Key to adjust ringtone volume (or the
earpiece volume during a call).
2.6 Switching to silent or vibration mode
You can set the phone to silent or vibration mode by using one
of the following methods.
Press and hold the Power key and then touch to
enable silent mode, touch to enable silent mode
with vibration, or touch to disable silent mode.
Press the Volu me ke y when no media application is active
to show the ringtone sound manage ment window. Touch
ALL and drag the slider to the left to switch the phone to
silent mode with vibration. Touch NO NE to switch the
phone to silent mode.
19
To uch th e Home key > > Settings > Sound &
notification > Interruptions > When calls and
notifications arrive, and touch Don’t interrupt to switch
the phone to silent mode.
NOTE:
In addition to silent mode and vibration, you can also allow
priority apps to send out notifications when you switch the
phone to priority interruption mode.
2.7 Applying new wallpapers
You can set the wallpaper for the home screen.
1. Tou ch the Home key.
2. Touch and hold an empty area of the home screen.
3. In the window that appears at the bottom, touch
WALLPAPERS to pick an image as the wallpaper.
NOTE:
In addition, you can touch the Home ke y > > Settings >
Display > Wallpaper to pick an image from Gallery, Photos,
Wallpapers, or an animation from Live Wallpapers.
2.8 Changing screen brightness
1. Tou ch the Home key > > Settings > Display >
Brightness level.
2. Drag the slider to manually adjust the screen brightness.
20
2.9 Protecting your phone with screen locks
You can protect your phone by creating a screen lock. When it is
enabled, you need to swipe the screen, draw a pattern or enter a
numeric PIN or a password to unlock the phone’s screen and
keys.
1. Tou ch the Home key > > Settings > Security >
Screen lock.
2. Tou c h None, Swipe, Pattern, PIN or Pas sword.
Touch None to disable the screen lock.
Touch Swipe to enable screen lock and allow
unlocking with a ‘swipe’ gesture. You can unlock the
screen by touching the display and swiping up.
Touch Pattern to draw and redraw a pattern that you
must draw to unlock the screen.
Touch PIN or Password to set a numeric PIN or a
password that you must enter to unlock the screen.
3. For Pattern, PIN, or Password lock, select how you want
notifications and their contents to show when the phone is
locked. Then touch DONE.
If you fail to draw the correct pattern on the screen after five
attempts, you will be prompted to wait for 30 seconds before you
can try again. If you still cannot recall the unlock pattern, you can
touch Forget pattern? and enter your Google account user name
and password. The phone will then connect to the Internet to
verify your account and prompt you to reset the screen lock.
NOTE:
You must sign in or create a Google account on your phone
before using the above method to reset the screen lock.
Otherwise, contact customer service of your phone dealer to
upgrade the phone software. Doing so will erase all your
personal data on the phone.
21
2.10 Protecting your phone with encryption
You can encrypt all the data on your phone: your accounts,
application data, music and other media, downloaded
information, and so on. If you do, you must draw a pattern or
enter a numeric PIN or a password each time you power on your
phone.
WARNING!
Encryption is irreversible. The only way to revert to an
unencrypted phone is to perform a factor y data reset which
erases all your data.
Encryption provides additional protection in case your phone is
stolen and may be required or recommended in some
organisations. Consult the IT administrator of your organisation
before turning it on. In many cases the PIN or password you set
for encryption is controlled by the IT administ rator.
Before turning on encryption, prepare as follows:
Set a lock screen pattern, PIN, or password.
Charge the battery.
Keep the phone connected to the charger.
Schedule an hour or more for the encryption process. You
must not interrupt it or yo u will lose some or all of your
data.
When you're ready to turn on encryption:
1. Tou ch the Home key > > Settings > Security >
Encrypt phone.
2. Tou c h ENCRYPT PHONE.
The ENCRYPT PHONE button is dimmed if your battery is
not charged or your phone is not plugged in.
If you change your mind about encrypting your phone,
touch the Back Key.
22
WARN ING!
If you interrupt the encryption process, you will lose data.
Read the information about encr yption carefully.
3. Draw the lock screen pattern, or enter your lock screen PIN
or password and touch NEXT.
4. Tou c h ENCRYPT PHONE.
The encryption process starts and displays its progress.
Encryption can take an hour or more, during which time your
phone may restart several times.
When encryption is completed, you're prompted to draw the
pattern or enter your PIN or password.
Subsequently you must draw the pattern, enter your PIN or
password each time you power on your phone in order to
decrypt it.
23
3. Knowing the basics
3.1 Monitoring the phone status
The status bar at the top of the home screen provides phone
and service status icons on the right side. Below are the most
common icons you may see.
GPRS connected
EDGE connected
3G connected
Battery low
Battery full
/
Battery charging
HSPA+ connected
HSDPA/HSUPA/HSPA
connected
Flight mode
No signal
Signal strength
Alarm set
GPS on
No interrupt ions mode
Vibration mode
Priority mode
Bluetooth on
Bluetooth connected
Connected to a Wi-Fi®
network
24
3.2 Managing notifications
Notification icons
The status bar at the top of the home screen provides
notification icons on the left. Below are some of the icons you
may see.
New message microSD card unmounted
New email Upcoming event
New Gmail
message
Missed call
Call in progress Downloading data
Call on hold Sending data
/
Song is playing USB tethering is on
Wired headset
connected
Open/close the notification panel
Notifications report the arrival of new messages, calendar
events, and alarms, as well as ongoing events, such as when
you've configured your phone as a Wi-Fi hotspot. You can open
the notification panel to view the details of notifications.
To open the notification panel, swipe your finger down
from the top of the screen.
To close the notification panel, swipe your finger up on the
screen or touch the Back key.
Incoming file via
Bluetooth
New Wi-Fi network
detected
Portable Wi-Fi hotspot or
Wi-Fi direct is on
25
Respond to or remove a notification
In the notification panel, you can respond to a notification or
remove the notifications. The notification panel also supports
expandable notifications that let you perform additional actions
right from the notification itself.
To respond to a notification, just touch it.( Not available in
lock screen)
To remove a notification, swipe it left or right.
Slide down with one finger to expand certain notifications.
You can also swipe two fingers vertically or pinch-zoom to
expand or collapse certain notifications.
To remove all notifications, touch below all the
notifications.
To manage notifications you have received, touch and hold
a notification to identify the application that created it. You
can then touch and select Block to hide future
notifications from this app, or touch Priority to show them
in priority mode.
NOTE:
If you turn off notifications for an app, you may miss its
important alerts and updates. The notifications of some apps
cannot be turned off.
Use quick settings
The Quick Settings make it convenient to view or change the
most common settings for your phone.
Open the notification panel by dragging the panel downwards
to find the following Quick Settings on the screen.
26
Brightness: Drag the brightness slider to adjust the screen
brightness.
Wi-Fi: Touch the icon to turn on or off Wi-Fi.
Bluetooth: Touch the icon to turn on or off Bluetooth.
Flight mode: Touch to turn on or off the flight mode.
Locatio n: Touch to turn on or off the GPS function.
Battery saver: Touch to turn on or off the battery saver.
NOTE:
Additional Quick Setting buttons may appear after you use
at least once the functions they control.
In the Quick Settings screen, touch at the top to get
to the Settings menu; touch the battery icon to open the
battery settings screen.
3.3 Managing shortcuts and widgets
Add shortcuts and widgets
1. Tou ch the Home key.
To add a widget, touch and hold an empty area of the home
2.
screen and select WIDGETS. The Widgets panel appears.
To add an application shortcut, touch .
3.
Slide left or right to view all available widgets or
applications. Touch and hold a widget or an application
icon and drag it to a home screen panel.
Move shortcuts or widgets
1. Touch and hold a widget or shortcut on the home screen.
2.
Drag it to the place you need.
27
Remove shortcuts or widgets
1. Touch and hold a widget or shortcut on the home screen.
2. Drag it to to remove it.
Adjust widget size
1. Touch and hold a widget on the home screen and then
release it.
2. An outline appears around the widget. Drag the outline to
resize the widget.
NOTE:
Not all widgets can be resized.
3.4 Organising with folders
You can create folders on a home screen and put several icons
in a folder.
Create a folder
1. Touch and hold a shortcut on the home screen.
2. Drag the shortcut icon over another and release your finger.
A new folder is created and both shortcuts are added into
the folder.
Rename a folder
1. Touch a folder to open it. The old folder name is displayed
above the icons.
2. Touch the folder name and enter a new name.
3. Tou c h OK.
28
Add more icons to a folder
1. Touch and hold an icon and then drag it onto a folder ico n.
2. Release the icon and it will be put into the folder.
3. If needed, drag more shortcuts and drop them into the
folder.
Remove icons from a folder
1. Touch a folder to open it.
2. Touch and hold the icon you want to remove and then drag
it to the home screen.
3. Release the icon and it will be removed from the folder.
3.5 Rearranging the primary icons
The home screen includes a customisable primary icons area at
the bottom visible from all home screen panels. You can keep
at most five items in the area. Drag icons or folders in or out of
the area to rearrange it.
3.6 Editing text
Move the insertion point: Touch where you want to type.
The cursor blinks in the new position, and a tab appears
below it. Drag the tab to move the cursor.
Select text: Touch and hold or double-tap within the text.
The nearest word highlights, with a tab at each end of the
selection. Drag the tabs to change the selection.
29
Loading...
