Vodafone Smart 4 User Manual

User manual

Smart 4

1. Your mobile ······················································ 1

1.1 Removing the back cover ········································ 1

1.2 Charging the battery ··············································· 2

1.3 SIM card and microSD card ······································ 2

1.4 Powering on/off, Reboot and Aeroplane mode ·········· 3

1.5 Locking/unlocking the screen ································· 3

1.6 Home screen ·························································· 4

1.7 Using the touchscreen ············································ 4

1.8 Using the hard keys················································· 5

1.9 Notification and status icons ··································· 5

1.10 Notification panel ················································· 6

1.11 Managing applications ·········································· 8

1.12 Managing Home screen ········································· 8

1.13 Managing folders ·················································· 9

2. Phone calls ······················································· 9

2.1 Making a call··························································· 9

2.2 Answering or rejecting a call···································· 10

2.3 During a call ··························································· 10

2.4 Conference calls ····················································· 11

2.5 Answering another incoming call····························· 11

2.6 Supplementary services ·········································· 12

2.7 Voicemail ······························································· 12

3. People ······························································ 13

3.1 Adding a contact ····················································· 13

3.2 Quick Contact ························································· 13

3.3 Managing contacts ·················································· 14

3.4 Managing groups ···················································· 15

3.5 Importing contacts from SIM card or storage ············ 16

4. Text input methods ·········································· 16

4.1 Using the text input panel ······································· 16

4.2 Switching input methods ········································· 16

4.3 Editing text ····························································· 17

4.4 Horizontal keyboard ··············································· 18

4.5 Input method settings ············································· 18

5. Messaging ························································ 18

5.1 Creating a message ················································· 18

5.2 Replying to a message ············································ 19

5.3 Searching messages ··············································· 19

5.4 Deleting a message ················································· 19

5.5 Customising message settings ································ 19

6. Email ································································ 19

6.1 Adding an email account ········································· 19

6.2 Switching accounts ················································· 20

6.3 Combined account view ·········································· 20

6.4 Viewing emails ······················································· 20

6.5 Creating and sending emails···································· 20

6.6 Replying to and forwarding emails ··························· 21

6.7 Saving email attachments ······································· 21

6.8 Deleting an email account ······································· 21

6.9 Customising email account settings ························ 21

7. Data service ····················································· 22

7.1 Turning on the data service ····································· 22

7.2 Wi-Fi ······································································· 22

7.3 Sharing your phone's data connection ····················· 24

7.4 Bluetooth ······························································· 26

8. Browser ···························································· 27

8.1 Browsing web pages ················································ 27

8.2 Managing bookmarks ·············································· 28

8.3 Setting a home page ················································ 28

8.4 Customising browser settings ································· 28

9. Camera and video camera ································ 29

9.1 Taking a photo ························································ 29

9.2 Recording a video ··················································· 30

10. Gallery ··························································· 31

10.1 Viewing pictures and videos ·································· 31

10.2 Editing a picture ···················································· 31

11. Google PlayTM Music ······································· 32

11.1 Adding music to a playlist······································ 32

11.2 Playing a playlist ·················································· 33

11.3 Playing a music file ··············································· 33

12. Accounts and syncing ···································· 33

12.1 Adding an account ················································ 34

12.2 Enabling syncing ·················································· 34

13. More applications ·········································· 34

13.1 Calendar ······························································· 34

13.2 Alarm clock ·························································· 36

13.3 Calculator····························································· 36

14. Settings ·························································· 37

14.1 Setting the date and time······································· 37

14.2 Setting the display ················································ 37

14.3 Adjusting the volume ············································ 38

14.4 Changing the phone ringtone ································· 39

14.5 Managing applications ·········································· 39

14.6 Security settings ··················································· 40

15. NFC ································································· 41

16. Location access ·············································· 42

17. Restoring factory settings ····························· 43

18. FOTA (Firmware Over The Air) updating ········· 43
Frequently Asked Questions ······························· 45
Product Safety Information ································· 48
Technical data ····················································· 65
Accessories ························································· 66

Indicator

Auxiliary

microphone

Flash

Camera

Headset

connector

Proximity sensor

Front camera

Back cover

notch

Menu key

Back key

Home

key

Power

key

Receiver

Loudspeaker

Volume

keys

Micro USB port

This is the

back cover notch.

Lift up the back cover
from the notch.

This is the

battery slot notch.

Lift up the battery from
the slot notch.

1. Your mobile

1.1 Removing the back cover

Removing the back cover: Hold the sides of the phone
securely; use a thumbnail to lift up the back cover from
the notch.
Removing the battery: Hold the sides of the phone
securely and lift up the battery from the slot no tch.
Note: Make sure that you turn off the phone befo re
replacing or removing the battery.

1

Insert SIM card.

Insert microSD

card.

1.2 Charging the battery

1. Connect the small end of the supplied U SB

charging/data cable to your phone, using the Micro
USB port at the top.

2. Connect the other end to the supplied plug a nd insert

that into a mains socket to start charging your pho ne.

3. The power LED will glow green w hen battery level is

more than 90%.

Hints:

• You can also charge your phone, though more slowly,

using the powered USB ports on your computer.

• You can view the battery information by tou ching the

battery icon in the quick access panel.

• The phone will power off automatically when the

battery is too low. Charge the battery if this hap pens.
When the battery is critically low, the charging status
may not be displayed immediately (you must wait
before it is displayed). Using the phone to play games
or perform other activities during the charging p rocess
may cause the phone to power off due to low battery.

• The battery will gradually discharge if is left for a long

period of time. Before using the battery again, you
must recharge it in order to power on and use you r
phone as normal.

1.3 SIM card and microSD card

Insert the SIM card and the microSD card as sho wn in the
images below.

2

Notes:

• Take care to keep the SIM card safe. Do not bend it,

damage it, or allow it come into contact with static
electricity or water.

• The SIM card must be inserted correctly accordin g to

the markings on the case.

• Make sure that your SIM card is a micro SIM (3FF) type.

• This phone does not support hot swapping. Unplug the

data cable and power off the phone before in serting or
removing the SIM card and microSD card.

1.4 Powering on/off, Reboot and
Aeroplane mode

Power on: When the phone is off, press and h old the
Power key to turn on the phone.
Power off: When the phone is on, press and hold the
Power key until the options pop up. Select Power off and
then OK to turn off the phone.
Reboot: When the phone is on, press and hold the Pow er
key until the options pop up. Select Reboot to rebo ot the
phone.
Aeroplane mode: When the phone is on, press and ho ld
the Power key until the options pop up. Select A eroplane
mode and the phone will automatically disable al l signal
transmission.

1.5 Locking/unlocking the screen

Locking the phone turns the screen off and stops any
unwanted button presses. To lock the screen while using
the phone, simply press the Power key.

To unlock it, press the Power key, drag to the right,
you can also drag it in other directions.

3

1

2 4 3

Note: Touch > > Security > Screen lock to set

the type of lock screen. You can also find on the
right-most Home screen.

1.6 Home screen

1. Status bar: Displays notifications and status icons.

Gently slide down to open the Notification pan el.

2. Display area: The main display area of the phone.

3. Touch to open the applications list.

4. Shortcut bar: Touch to enter the correspo nding

application.

Hints:

1. Swipe your finger left or right to acc ess other home

screen panels.

2. Go to Settings > Display, mark the Home screen

checkbox to enable the home screen loopin g function.

1.7 Using the touchscreen

Touch: Launch applications and other functions .

4

No signal

No network

Signal strength

Aeroplane mode

HSDPA in use

EDGE in use

GPRS in use

Roaming

GPS is on

Bluetooth is on

Touch and hold: Touch and hold the screen for 2 or
more seconds to open the control options for the current
screen.
Slide/swipe: Slide the screen up, down, left an d right to
view information, applications, web pages, etc.
Drag: Touch and hold the selected application and drag
it to another location.
Pinch/spread: Place two fingers on the scre en and draw
them apart to zoom in or together to zoom out.
Rotate: Automatically change the screen
orientation from portrait to landscape by turning
the ph one sideways.

1.8 Using the hard keys

(Back key): Touch the back key to view the s creen

for the previous operation.

(Home key): Touch the home key to view th e
homescreen. Press and hold the home key to open
Google Now

the menu of applications. Press and hold the menu key
to view the multiple applications.

TM

.

(Menu key): Touch the menu key to display or hide

1.9 Notification and status icons

5

Battery is charging

Battery is full

Battery is very low

Missed call

New message

An open Wi-Fi
network is available

Connected to a Wi-Fi
network

Uploading data

Downloading data

microSD card is full

Problem with sign-in
or synchronisation

USB tethering is on

Portable Wi-Fi
hotspot is on

Google Play Music is
running

Battery Saver

Alarm is set

Data Roaming is on

Data Roaming is off

Headset connected

1.10 Notification panel

Pull down the Status bar to open the Notification pan el.
You can view phone network information, new events,
etc.

6

From the Notification panel, you can do an y of the
following:

• Quickly open or close relevant applications.

• Touch to clear all notifications.

• Pull up from the bottom of the panel to close the

Notification panel.

Using the Quick Settings button

Open the Notification panel and touch to switch to
the Quick Settings button panel. You can a lso use 2
fingers to drag down the status bar does the s ame
operation.

In the Quick Settings button panel, you can c onfigure the
following settings:

• Touch to set the brightness.

• Touch to open the Settings.

• Touch to check the Wi-Fi settings, and long press

to turn Wi-Fi on or off quickly.

• Touch to change mobile data usage.

• Touch to check the battery status.

• Touch to turn Aeroplane Mode on or off.

7

• Touch to open the Bluetooth settings, and long

press to turn Bluetooth on or off quickly.

• Touch to open the Location settings, and long

press to turn Location on or off quickly.

• Touch to open the Battery Saver settings, and

long press to turn Battery Saver on or off quic kly.

• Touch to turn Data Roaming on or off.

1.11 Managing applications

On the Home screen, touch to enter the
applications list. In the applications list, you can do an y of
the following:

• Touch an application icon to open it.

• Swipe left or right to view another list screen.

• Touch and hold an application icon, and drag it onto

the Home screen.

1.12 Managing Home screen

• On the Home screen, touch (Menu key) > to

enter the widgets list.

• In the widgets list, touch and hold a widget, and drag it

onto the Home screen.

• On the Home screen, touch (Menu key), touch

and hold a Home screen panel to rearrange t he order.

• On the Home screen, touch and hold a shortcut or

widget and drag it to the to delete it.

Tip: To help you set up your phone the way yo u like it,

drag from the right-most Home screen to th e main
Home screen, so you can access it more easil y.

8

1.13 Managing folders

• Add folders: On the Home screen, touch and ho ld an

application icon and stack it on top of another
application icon to create a folder.

• Rename folders: On the Home screen, touc h a folder

and then touch the folder name in the popup to
rename the folder.

• Delete folders: On the Home screen, touch and h old

a folder and drag it to the to delete it.

• Move folders to the shortcut bar: When th ere is

space on the shortcut bar at the bottom of the screen,
touch and hold a folder and drag it to the shortcut bar.

2. Phone calls

You can make a phone call from the keypad, People or
the Call log. While you are in a call, you can also answer
another incoming call, send it to your voicemail or
conduct a conference call.

Touch at the bottom of the Home screen or touch

> to open the dial application.

2.1 Making a call

• On the dial application screen, touch to open the

keypad.

• Touch the number keys to enter the telephone

number.

• Touch at the bottom of the screen to dial the

number.

Hint: To avoid affecting the quality of the call, do no t
touch the receiver or loudspeaker when m aking or
answering a call.

9

Making a call from Contacts

• On the dial application screen, touch to open the

All contacts list.

• Touch a contact to make the call.

Making a call from Call log

• On the dial application screen, touch to view the

call log.

• Touch on the right side of the Call log to make

the call.

2.2 Answering or rejecting a call

When you receive an incoming call, you can do an y of the
following:

• Answer the call: Slide to on the right to answer

the call.

• Reject the call: Slide to on the left to reject

the cal l.

• Rejection SMS: Slide to upward to reject the call

and send an SMS message to the caller.

Hint: On the dial application screen, press (Menu
key) > Settings > Quick responses to edit the rejection
SMS.

2.3 During a call

On the call screen, you can do any of the following:

• Hang up the call: Touch to han g up the call.

• Enter another number: Touch to open the keypad

and enter another number.

• Turn on Speakerphone: Touch to hear the caller on

the loudspeaker (so you don’t need to hold it to your

ear).

10

• Mute: Touch to mute the call so that the other

person cannot hear your voice.

• Hold the call: Touch to put the current call on

hold.

• Add a third person to the call: Touch to enter the

dial screen and add a third person to the call.

Hint: You can touch and use other functions during a call.
To return to the call screen, open the Notificatio n panel
and touch the current call.

2.4 Conference calls

You can hold a conference call with multiple participants.

• Place a call to the first participant.

• Touch during the call with the first participant.

• Use the keypad to enter the phone number of the

second participant you want to add, or touch or

to select the number.

• After connecting with the second participant, tou ch

to start the conference call.

• Touch to end the conference call.
Hint: You can have up to 6 participants in conference cal l
mode. See the Vodafone website or contact V odafone
customer services for details.

2.5 Answering another incoming call

If you receive another incoming call while you are in a
call, you can accept the incoming call and au tomatically
place the current call on hold without hanging up.
Hint: You need to enable call waiting before you can use
this service. See the Vodafone website or co ntact
Vodafone customer services for details.

11

2.6 Supplementary services

Your phone supports a variety of supplementary services.
These include call forwarding and call waiting.
Hint: These services require network support. See the
Vodafone website or contact Vodafone customer
services for details.

Setting up call forwarding

If you are unable to answer calls, you can set up this
function to forward incoming calls to another number.

• On the dial ap plication screen, touch (Menu key) >

Settings > Call forwarding.

• Select a forwarding type, enter the number yo u want

to forward calls to.

• Select Enable to enable this function.

Setting up call waiting

After setting up this function, the phone will notify you if
you receive an incoming call while already in a call. It will
also inform the incoming caller to wait for you to end
your current call before they are connected. You can also
answer the incoming call and switch between the two
calls.

• On the dial ap plication screen, touch (Menu key) >

Settings > Additional settings > Call waiting.

• Mark the Call waiting checkbox to enable this functio n.

2.7 Voicemail

If you activate and set up voicemail, your phone will
automatically send unanswered calls to voicemai l
(including calls that are unanswered when yo u are in
another call and when your phone is off).

• On the dial ap plication screen, touch (Menu key) >

Settings > Voicemail > Setup.

12

• Touch Voicemail number, enter your voicemail

number and then touch OK to set up voicemail.

• To listen to your voicemail, press and hold the 1 key

on the dial keypad screen and follow the server
instructions.

Hint: Before using this function, contact Vo dafone
customer services to activate voicemail. See the
Vodafone website or contact Vodafone customer
services for details.

3. People

You can use the People application to save and m anage
phone numbers, addresses and other information.
To open the People application, swipe the main Hom e
screen to the right to reveal another Home screen, then

touch . You can also touch > .

3.1 Adding a contact

• On the Contacts screen, touch .

• Select where to save the contact.

• Enter the contact information.

• Touch to save the contact information.

Hint: In the Call log, touch a phone num ber you want to
save to save it directly as a contact.

3.2 Quick Contact

On the Contacts screen, touch the avatar (im age) of a
contact and select the icon for the way you want to
communicate with the contact. You can quickly call the
contact or send them an SMS or email. The ic ons
available depend on the information you have for the
contact and the applications and accounts on your
phone.

13

3.3 Managing contacts

Adding a contact to Favourites

On the Contacts screen, select the contact you want to

add to Favourites and then touch the at the right of

the contact name. The star will fill color ( ) to indicate
that the contact has been added to Favourites .

Searching for a contact

• On the Contacts screen, touch .

• Enter the name of the contact you want to search fo r.

Search results will be displayed below the search bar.

Hint: You can also slide the scroll bar at the ri ght of
Contacts to quickly search for a contact.

Editing a contact

• On the Contacts screen, select the contact you want

to edit then touch (Menu key) > Edit.

• Edit relevant information and then touch to

save the contact. Alternatively, touch (Menu
key) > Discard to cancel your changes.

Deleting a contact

• On the Contacts screen, select the contact you want

to delete then touch (Menu key) > Delete.

• Touch OK to confirm that you want to delete the

contact.

Sending a contact vCard

You can send a “.vcf ” format vCard via email, Bluetooth
or MMS. Before using email to send a vCard, you need to
set up an email account on the phone. (Read the “6.1
Adding an email account” section of this u ser manual, on
page 19.)

14

• Touch a contact on the Contacts screen.

• Touch (Menu key) > Share.

• Select how to send the vCard.

3.4 Managing groups

Creating a group

• On the Contacts screen, touch to switch to the

Groups screen.

• Touch an d select an account.

• Enter the group name.

• Touch , select one or m ultiple contacts and then

touch .

• Touch to save the group information.

Editing a group

You can always make changes to the information you
have stored for a group.

• Select a group and touch (Menu key) > Edit.

• Edit the group name and add or delete members.

• Touch .

Adding a contact to your groups

To add a contact to your groups, you can do any of the
following:

• When editing contact information, touch the grou p

names below GROUPS to select groups.

• When editing a group, enter a contact name. The

phone will automatically display the names of stored
contacts as you enter the name. Touch the contact
you want to add to the group.

15

3.5 Importing contacts from SIM card or
storage

• On the People screen, touch (Menu key) >

Import/export, and select the corresponding option .

• Select one or multiple contacts.

• Touch to finis h copying the contact(s).

Hint: Read the “Frequently Asked Questions” s ection of

this user manual to get more information abou t how to
import contacts from another phone by using the
microSD card, on page 45.)

4. Text input methods

4.1 Using the text input panel

The input panel can be used to enter text. When you
need to enter text, touch the text input area to o pen the
input panel. Touch Back key to hide the inpu t panel.

4.2 Switching input methods

When you installed other different input metho ds, you
can switch the input methods.

• When the keyboard is displayed on the screen, gently

slide down the Status bar to open the Notificatio n

16

Panel.

• Touch Select Input Method and select the input

method you want to use.

Hint: Touch > > Language & inpu t > Default,
then select which input method to set as the default.

4.3 Editing text

Touch and hold the text you have entered and select th e
content you want to edit. You can use the icons that
appear on the top right of the screen to quickly edit the
text.

• : Select all text.

• : Cut selected text. Touch and hold the text you

have entered, move the cursor to select the text you
want to edit and touch this icon to cut the text. After
cutting, you can touch and hold a blank area in the

text field until appears. Move to
the location where you want to paste the text and then

touch to paste the text you previously cut.

• : Copy selected text. Touch and hold the text you

have entered. Move the cursor to select the text you
want to copy and touch this icon to copy the text. After
copying, you can touch and hold a blank area in the

text field until appears. Move to
the location where you want to paste the text and then

touch to paste the text you previously copied

• : Replace text. Touch and hold the text you have

entered. Move the cursor to select the text you want to
replace and touch this icon to replace the selected
text with the text you previously cut or copied.

17

4.4 Horizontal keyboard

If you have enabled auto-rotate (in > Display), rotate
the phone when entering text to switch to a h orizontal
onscreen keyboard for easier input.

4.5 Input method settings

After selecting an input method, you can configure its
specific settings.

• On the right-most Home screen touch >

Language & input, or touch > > Language &
input.

• In Keyboard & Input Methods, touch next to an

input method to configure its settings.

5. Messaging

Touch at the bottom of the Home screen or touch

> to open the Messaging.

5.1 Creating a message

• On the Messaging screen, touch .

• Enter the recipient's number or you can tou ch to

select contacts.

• Add your message. Touch to attach media files

such as photo, audio and slides.

• Touch to send th e message.
Hint: An SMS will be sent as an MMS when media files ar e
added.

18

5.2 Replying to a message

• On the Messaging screen, select the message you

want to reply to.

• Compose your message and touch to send it.

5.3 Searching messages

On the Messaging screen, you can touch and enter
message content or keywords to quickly search fo r the
message you need.

5.4 Deleting a message

On the Messaging screen, touch and hold the message

conversation you want to delete. Touch to delete
the message conversation.

5.5 Customising message settings

On the Messaging screen, touch (Menu key) >
Settings to configure SMS, MMS, message notifications
and other settings.

6. Email

You can use the email application to send and receive
emails.

Touch on the Ho me screen or touch > to
open the Email.

6.1 Adding an email account

You must configure an email account before you can
send and receive emails. Sending and receivi ng emails
requires you to have a Vodafone data service for your
phone. This is usually part of your Vodafone price plan.

19

• Select an account, enter the email address and

password, and then touch Next. Follow the onscreen
instructions to configure the relevant settings.

Hints:

1. After creating your initial email acco unt, from the

Inbox screen you can touch (Menu key) >
Settings > ADD ACCOUNT to add another em ail
account.

2. Set up your email account according to the

instructions provided by your email service provid er.
Log on to the email service provider's website for
specific settings.

6.2 Switching accounts

On the Inbox screen, touch the email address field at the
top of the screen. Select an email account fro m the list
that is displayed. After making your selection, the Inbo x
for the selected account will be opened automatically.

6.3 Combined account view

You can show the Inbox emails from all your accounts on
one screen. On the Inbox screen, touch the email address
field at the top of the screen, then select Combined v iew.

6.4 Viewing emails

On the Inbox screen, touch the email you want to v iew to
open it.

6.5 Creating and sending emails

• On the Inbox screen, touch .

• Touch the To field and enter the recipient's email

address. Or you can touch to select contacts.

• Enter the subject and content of the message in the

20

relevant fields.

• Touch to send th e email.

6.6 Replying to and forwarding emails

On the Inbox screen, touch the email you want to repl y
to.

• Touch to reply directly to the sender.

• Touch > Reply all to reply to everyone.

• Touch > Forward to forward the email.

6.7 Saving email attachments

• On the Inbox screen, touch the email you want to v iew.

• Slide down to find the attachments after the content.

• Touch > Save to download the attachment.

Hints:

1. If your phone has a microSD card installed, the

downloaded file will save to the download fol der
(/storage/external_sd/Download) in microSD card by
default.

2. You can change the default storage location in

Settings > Storage > DEFAULT WRITE DISK.

6.8 Deleting an email account

• On the Settings screen (On the Home screen touch

> ).

• In ACCOUNTS, touch an email account.

• Touch the name of account, then touch (Menu

key) > Remove account to delete the account.

6.9 Customising email account settings

• On the Inbox screen, touch (Menu key) > Settings

to enter the account settings screen.

21

• Touch an email account.

• Change account settings such as data usage,

notification settings, server settings, etc.

7. Data service

7.1 Turning on the data service

• Touch > .

• In WIRELESS & NETWORKS, touch More... > Mobile

networks.

• Mark the Data enabled checkbox to turn on t he data

service.

• Mark the Data Roaming checkbox to turn on the data

roaming service.

Hints:

1. To extend standby time and save data u sage, switch

off the data service when network services are not
needed.

2. Using mobile networks while roamin g may incur

additional charges. See the Vodafone website fo r
details.

3. The phone's access points have already be en

configured for you. Do not change access point
parameters without permission; otherwise you may be
unable to access networks.

7.2 Wi-Fi

You can use the phone's Wi-Fi function to acc ess the
Internet and pick up and send emails.

• Touch > .

• In WIRELESS & NETWORKS, touch Wi-Fi switc h to turn

on/off Wi-Fi.

• In WIRELESS & NETWORKS, touch Wi-Fi to en ter the

Wi-Fi settings screen. The phone will search f or and list

22

nearby Wi-Fi hotspots.

• Select the Wi-Fi hotspot you want to connect to . If the

network you selected is secured, you are required to
enter a password before you can connect.

Hints:

1. If you turn on Wi-Fi and the data serv ice

simultaneously, the phone will automatically use the
Wi-Fi connection. If Wi-Fi is disconnected, the phone
will use the data service to continue the data
connection.

2. On the Wi-Fi settings screen, to uch and configure

authentication to add a new Wi-Fi hotspot SSI D
(service set identifier).

3. Wi-Fi signals may be obstructed an d weakened by

obstacles like walls.

Connecting to Wi-Fi using WPS

WPS (Wi-Fi Protected Setup), also called quick secure
setup, is an operation that can simplify Wi- Fi connection
settings. You can simply press the WPS button o r enter a
PIN number to automatically establish a secure
connection. There is no need to configure complicated
settings in the Wi-Fi hotspot administration software.
Hint: When using WPS to connect to a Wi- Fi hotspot,
make sure that the Wi-Fi hotspot supports WPS; otherwise
you will be unable to use this function.

WPS button connection

• Enable Wi-Fi.

• On the Wi-Fi settings screen, touch .

• Press the WPS button on the Wi-Fi hotspot de vice.

23

WPS PIN number connection

• Enable Wi-Fi.

• On the Wi-Fi settings screen, touch (Menu key) >

WPS Pin Entry. The phone will automatically create a
PIN number.

• Enter this PIN number into the Wi-Fi hotspot device.
Hint: You can also connect by creating a PIN n umber
using the Wi-Fi device and entering this PIN num ber into
the phone.

7.3 Sharing your phone's data connection

You can share your phone's mobile network with a single
computer via a USB data cable. This is called U SB
tethering. You can also share your phone’s mobile
network as a portable Wi-Fi hotspot or Bluetoo th.
Hint: Using this function may incur addition al data
charges, depending on your data plan. See the Vo dafone
website for more details, or contact Vodafone custo mer
support.

Sharing your phone's mobile network via USB

If your computer's operating system is Windows X P or a
later or a new release of Linux (e.g. Ubuntu 10.4), you can
use USB tethering without changing any settings o n your
computer. If you use USB tethering with computers with
different operating systems, you may need to es tablish
corresponding network connections on each com puter.

• Touch > .

• In WIRELESS & NETWORKS, touch More... > Teth ering

& portable hotspot.

• Mark the USB tethering checkbox to share your

phone's mobile network with a computer and use the
computer to connect to the internet.

24

Hint: While you are sharing your phone's data conn ection
via USB tethering, you cannot set the microSD card as a
mass storage device.

Sharing your phone's data connection as
a portable Wi-Fi hotspot

By setting your phone as a Wi-Fi hotspot you can connect
up to eight wireless devices at most.

• Touch > .

• In WIRELESS & NETWORKS, touch More... > Teth ering

& portable hotspot.

• Touch the Portable Wi-Fi hotspot chec kbox to activate

the Wi-Fi hotspot and share your mobile network.

Hints:

1. You can touch Set up Wi-Fi hotspo t to set the name,

security and password for the Wi-Fi hotspot. T o protect
your network, it is recommended that you secure it
using WPA2 PSK.

2. You cannot use Wi-Fi hotspot and Wi-Fi at the same

time.

Sharing your phone's data connection via
Bluetooth

You can also use the Bluetooth to sharing your mobile
networks.

• Touch > .

• In WIRELESS & NETWORKS, touch More... > Tethering

& portable hotspot.

• Touch the Bluetooth tethering checkbox to s hare your

mobile network.

• In WIRELESS & NETWORKS, touch Bluetooth, in

PAIRED DEVICES list, touch of device that you
want to share the mobile network. In device settings

25

screen, touch the Internet access checkbox to allow
the internet access.

7.4 Bluetooth

Your phone supports Bluetooth, which allows you to
create a wireless connection with other com patible
devices so you can share data.
Hint: Bluetooth has a maximum reception distance of 10
meters. Keep devices connected by Bluetooth within 10
meters of each other. Obstacles like walls or o ther
electronic equipment may interfere with Bluetoo th
signals.

Turning on Bluetooth

• Touch > .

• In WIRELESS & NETWORKS, touch the Blueto oth

switch to turn on Bluetooth. The Status bar will display
the Bluetooth icon.

• If you need to change the device name of your ph one,

touch (Menu key) > Rename phone. Enter a
name and touch Rename to save your change.

Searching for and pairing with other
Bluetooth devices

You need to pair with a Bluetooth device before you can
share data with it. Once a device is paired wit h your
phone, it will automatically connect to your phone
whenever it is turned on.

• Check your phone's settings to make sure that the

Bluetooth is enabled.

• In WIRELESS & NETWORKS, touch Bluetooth list to

enter the Bluetooth settings screen. The pho ne will
automatically scan for nearby Bluetooth devices.

• Touch the one that you want to pair with and follow

26

the onscreen instructions to pair with it. If yo u don’t
know the password for the device you’re trying to pair
with, try 0000 (this is the default password fo r most BT
devices).

• If you want to unpair, in Paired devices touch >

Unpair to stop it connecting automatically. Yo u can
always go through the pairing process again if you
change your mind.

• To stop a connection with a Bluetooth device, the

simplest way is to turn the device off. Otherwise, ju st
turn Bluetooth off on your phone using the Quick
Settings menu.

Sending files via Bluetooth

With Bluetooth, you can share pictures, videos o r music
files with your family and friends.

• In ES File Explorer application, touch and ho ld the file

you want to send. After the file has been sele cted,

touch > Share, on the options menu that pops up,
select Bluetooth.

• The screen will list the Bluetooth devices tha t have

been found. Select the device you want to send the
file to.

8. Browser

Touch at the bottom of the Home screen or touch

> to open the Browser.

8.1 Browsing web pages

• Enter a web page address in the URL field at the to p.

• Touch on the to p right of the screen to browse

thumbnails of multiple open web pages and switch to

27

any web page window.

• Touch to o pen a new window.

Hint: If you have installed other browsers, it will pop up a
selection for choosing browsers when you click a web
link.

8.2 Managing bookmarks

Adding a bookmark

• Use the browser to open the web page you want to

bookmark.

• Touch (Menu key) > Save to bookmarks.

• Enter the bookmark name and touch OK to add the

bookmark.

Opening a bookmark

• On the browser screen, touch (Menu key) >

Bookmarks.

• Select the bookmark of the website you want to v iew.

• On the Bookmarks screen, touch the History tab to

view the web pages you have visited.

8.3 Setting a home page

• On the browser screen, touch (Menu key) >

Settings > General > Set homepage.

• Select a home page from the list or touch Other to

enter a web address and then touch OK to save th e
home page.

8.4 Customising browser settings

• On the browser screen, touch (Menu key) >

Settings.

• On the Settings list, you can select menus to

28

customise the browser.

9. Camera and video camera

You can use your phone to shoot and share both ph otos
and videos. Your camera supports num erous modes.

Touch at the bottom of the Home screen or touch

> to open the Camera. On the Lock screen,
slide from right side of screen to left, can ope n the
Camera quickly.

9.1 Taking a photo

• Open the camera and aim the lens at the subject.

• Pinch or spread in the viewfinder, you can change the

focal length.

• Touch to take the photo.

• Before you take a photo you can touch and h old

anywhere on the screen to see the camera o ptions.
You have to keep touching and slide onto the o ption
button, then select the option or value.

Hint: For a better result, you can open the settings menu
and adjust camera parameters before taking the ph oto.

29

The viewfinder will change accordingly after you hav e
adjusted the settings.

9.2 Recording a video

• Open the camera and aim the lens at the subject.

• Touch the Camera icon on the lower left of t he screen,

and select to activate video mode.

• Pinch or spread in the viewfinder, you can change the

focal length.

• Touch to start recording.

• Touch to stop when you finish recording.

• Before you record a video you can touch and hold

anywhere on the screen to see the options. Y ou have
to keep touching and slide onto the option b utton,
then select the option or value.

Hints:

1. To share the video via MMS, the video s ize should be

less than 300K.

2. For a better result, you can open the settings menu

and adjust camera parameters before recording the
video. The viewfinder will change accordingly after you
have adjusted the settings.

After taking your photo or video, you can s lide from right
to left to view the photo or video you jus t took.
When viewing a photo or video, you can do a ny of the
following:

• Touch to send the photo or video to a friend via

MMS, email, Bluetooth or another method.

• Touch to delete the photo or video.

30

10. Gallery

You can use the Gallery to manage picture and video
files.

On the Home screen touch > to open the
Gallery.

10.1 Viewing pictures and videos

• On the library screen, touch the folder you want to

view.

• Touch the picture or video you want to view.

10.2 Editing a picture

When viewing a picture, touch to edit it.

On the editing screen, you can do any of the following:

• : Perform ph oto effects such as Punch, Vintage,

B/W, Bleach, etc. on the image.

• : Perform pho to border on the images.

• : Perform opera tions such as Crop, Straighten,

Rotate and Mirror on the image.

• : Pe rform operations such as Autocolour, Exposure,

31

Vignette, etc.

• : Un do the last step.

• : Redo the operation.

• Touch to save a picture after you have

finished editing it.

11. Google PlayTM Music

On the Home screen touch > to open the
Google Play Music.

On the Google Play Music screen, touch in the
upper left of the screen to switch between Listen Now,
My Library and Playlists.
My Library contains the following tabs: G ENRES, ARTISTS,
ALBUMS and SONGS. You can slide left and ri ght to view
and select the content of each tab.

Hints:

1. You can play music files stored on the micro SD card in

your phone. Music files can be downloaded from
computer to microSD card by using an USB cab le.

2. Touch (Menu key) > Help to get more

introductions from Google Play.

11.1 Adding music to a playlist

• Touch on the music file that you want to add to a

playlist.

• On the options menu that pops up, touch Add to

playlist.

• On the playlist that pops up, select a playlist to add the

song to it.

32

11.2 Playing a playlist

• On the Playlists screen, touch the playlist you want to

play.

• Touch the cover of the playlist to play this playlist.

11.3 Playing a music file

• On the My Library screen, slide to SONGS tab.

• Touch a music file to play it.

• Touch or slide up the bottom of the screen to see the

music playback screen.
On the music playback screen, you can do any of the
following:

• Touch to enter the playlist screen.

• Check music playback progress.

• Touch to pause or touch to resume. Touch

to play the next song. Touch to play the

previous song.

• Touch or slide down the top of the screen to back to

the My Library.
Hints: During music playback, touch the Ho me key to go
back to the Home screen. The music will continu e to play
in the background and you can use other applications .
Open the Status bar and select the currently playing
song to go back to the music playback screen.

12. Accounts and syncing

Use the Accounts settings to add, remove, and man age
your accounts. It includes Corporate, Email, Facebook,
Google, Twitter and other supported accounts. Yo u can
also use these settings to control how and whether all
applications send, receive, and synchro nize data on their
own schedules, and whether all applications can
synchronize user data automatically.

33

Gmail, Google Calendar, and other applications m ay also
have their own settings to control how they synchron ize
data.

On the right-most Home screen touch or touch

> . In A CCOUNTS, you can see the accounts you

already added or manage your accounts.

12.1 Adding an account

• In ACCOUNTS, touch Add account.

• Select the kind of account to add.

• Follow the onscreen instructions to enter the required

information about the account.

• Configure the account. Set what information you want

to sync to the phone.

• When you are finished, the account you configured is

added to ACCOUNTS.
Hint: The information you are able to configu re for
syncing depends on the kind of account you added.

12.2 Enabling syncing

• In ACCOUNTS, select the account you want e nable

syncing for.

• Mark the check box to permit applications to

syncronise data on their own schedule.

13. More applications

13.1 Calendar

You can use Calendar to manage and arrang e events.

On the right-most Home screen touch or touch

> to open the Calendar.

34

Multimode view

On the Calendar screen, you can display the Calenda r in
daily, weekly, monthly, or agenda view. Touch the time in
the upper left of the screen to switch betwee n Day, Week,
Month and Agenda view.

Adding a new event

• On the Calendar screen, touch (Menu key) > New

event.

• Edit upcoming event information such as a name,

location, time, etc.

• Touch to save the event.
Hint: You can double touch any day on the screen to
create a new event. You can also tap and hold fo r a Quick
Event entry.

Customising Calendar settings

On the Calendar screen, touch (Menu key) >
Settings to configure Calendar.

Setting an event reminder

• On any calendar view, touch an event to view its

details or summary.

• Touch Add reminder to add a reminder for the even t.

Alternatively, touch to delete a reminder that has

already been set.

• Touch the reminder time. In the drop-do wn list that

opens, select a time period to set the length of time

before the event when you want to be reminded.

When the time comes, you will receive a notificatio n or

an email about the event.

35

Syncing and displaying the Calendar

Calendar events for accounts (e.g. email accounts) that
have been added to your phone can be synced to and
displayed in your Calendar application.

• On any Calendar view, touch (Menu key) >

Calendars to display.

• Mark the check box to enable or disable s yncing.
Hint: If you hav e already configured an account to sync
events to your phone, that account will appear on the
Calendars to display list.

13.2 Alarm clock

On the Home screen touch > to enter the Clock

screen, and then touch to switch to the Alarm tab.
On the alarm list screen, follow the instructions below to
set your alarm:

• Touch Time to set the time of the alarm.

• Mark the REPEAT check box to set the days when you

want the alarm to sound.

• Touch Ringtone to select a ringtone for the alarm.

• Mark the VIBRATE checkbox to have the pho ne vibrate,

in addition to playing the ringtone.

• Touch Label to enter a name for the alarm.

• Touch the switch of the alarm to turn on the alarm.

13.3 Calculator

On Home screen touch > to open the
Calculator.
On the Calculator screen, swipe the screen right or left to
switch between the Advanced panel and Basic panel.

36

14. Settings

On the right-most Home screen touch or touch

> to configure detailed phone settings.

14.1 Setting the date and time

• On the Settings screen, touch Date & time.

• Unmark the Automatic date & time checkbox.

• Unmark the Automatic time zone checkbox.

• Touch Set date. Slide up and down to adjust the date

and then touch Done.

• Touch Set time. Slide up and down to adjust the time

and then touch Done.

• Touch Select time zone and then select the desired

time zone from the list. Scroll the list to view more

time zones.

• Mark or unmark the Use 24-hour format checkbo x to

switch between 24-hour format and 12-ho ur format.

• Touch Choose date format to select how you want the

date to display on your phone.
Hint: When your phone is using date and time settings
provided automatically by the network, you cann ot
manually set the date, time and time zone.

14.2 Setting the display

On the Settings screen, touch Display to set t he screen
display.

• Brightness: Set the brightness of the display . Touch

AUTO to turn on the auto-brightness, or adjus t the

brightness manually.

• Wallpaper: Change the background picture o f the

Home screen.

• Home screen: Mark or unmark this checkbo x to turn

on or off loop panels function.

37

• Auto-rotate screen: After setting this functio n, the

phone will automatically switch orientation if you

rotate the phone while browsing web pages, viewing

pictures, editing information and performing ot her

operations.

• Sleep: Set the screen sleep time. Your screen will

automatically turn off if no operations are performed

within the time set.

• Key light duration: Set the touch key light d uration

time.

• Daydream: When Daydream is on, your device

displays photos, colors, and more while it is charging

or docked. Set the daydream type or when to

daydream. Touch the daydream switch to turn off this

function.

• Font size: Set the font size according to your

preference.

• Pulse notification light: Mark or unmark thi s

checkbox to control the phone’s light pulse when has

a new notification.

14.3 Adjusting the volume

You can use the Volume key to adjust the volume from
the Home screen or many application screens. For
example, during a call or when playing music or videos.
You can also adjust the volume using the foll owing
method:

• On the Settings screen, touch Sound.

• Select Volumes and drag the slider left to make the

volume lower, or right to make it higher.

• Touch OK to save the adjustment.

38

14.4 Changing the phone ringtone

• On the Settings screen, touch Sound > Phon e

ringtone.

• On the options menu that pops up, select a path of the

ringtone.

• Select the ringtone you want to use.

14.5 Managing applications

On the Settings screen, touch Apps to open a list of all
applications.

Viewing and uninstalling applications

• Touch an application to view its information.

• If you want to uninstall the application, touch Uninstall

and follow the onscreen instructions.

Hints:

1. Some applications are subject to system restrictions

and cannot be uninstalled. The Uninstall option will

not appear on the Application info screen for such

applications.

2. On the list of all applications, tou ch (Menu key) >

Sort by size to rearrange applications by file s ize.

Moving larger applications to microSD

The storage location of some applications can be
changed. Moving larger applications to microSD card can
free up more space to store applications that cann ot be
moved.

• Touch the application you want to move and then

touch Move to SD card to move the entire application

out of the phone's internal storage.

• Touch Move to phone to move the application b ack to

the phone's internal storage.

39

Hints:

1. The Storage list on the Application in fo screen displays

detailed data showing which storage space the

application occupies.

2. If the application can be moved, you can use a move

button.

14.6 Security settings

Turning on screen unlock pattern protection
You can set a screen unlock pattern. Once the screen has
locked, it needs to be drawn correctly in order to u nlock
the screen.

• On the Settings screen, touch Security > Screen lock >

Pattern.

• Follow the onscreen instructions to draw the unlock

pattern.

• Touch Continue.

• Draw the same unlock pattern again and touch

Confirm.

Turning on numeric PIN protection

You can set a numeric PIN to lock your phone. Once th e
screen has locked, it needs to be entered correctly in
order to unlock the phone.

• On the Settings screen, touch Security > Screen lock >

PIN.

• Enter at least four-digit numbers.

• Touch Continue.

• Enter the same number again and touch Confirm.

Turning on SIM card PIN protection

A PIN (personal identification number) can pr event other
people using your SIM card without permission. A PUK
(personal unlock key) can be used to unlock a blocked

40

PIN. If an incorrect PIN is entered three tim es in a row,
your SIM will be blocked. To unblock your SIM, you'll
need to enter your PUK. If the wrong PUK is entered ten
times in a row, your SIM will be blocked permanently. If
these two codes were not provided with your SIM card or
if you forget either one, contact Vodafone cu stomer
services. If you turn on SIM card PIN protec tion, your SIM
card PIN needs to be entered every time you turn o n your
phone.

• On the Settings screen, touch Security > Set up SIM

card lock.

• Mark the Lock SIM card checkbox.

• Enter the SIM card PIN and touch OK to turn on PIN

protection.
Hint: To change your SIM card PIN, touch Change SI M
PIN.

15. NFC

NFC (Near Field Communication) is a new, s hort-range
wireless connectivity technology which allows mobile
users to read and write NFC tags, pair with other NFC
devices, and even make fast and secure mobile
payments. With NFC activated, you can use this
application to open, act on and organize the tags you've
scanned. In Settings > WIRELESS & NETWOR KS, touch
More..., check NFC to turn on/off NFC function.

Tap & pay

When NFC is turned on, you can use the tap & pay feature
to pay for items just by touching your phone to a reader
at a register.
To manage your apps for the tap & pay option, follow
these steps:

• On the Settings screen, touch Tap & pay.

41

• Touch an app to make it your default payment app.
If your device doesn’t have a default app, you can bro wse
Google PlayTM for other payment apps.

Hints:

1. The tap & pay option doesn’t apply to And roid Beam

and won’t include certain apps, such as money transfer

apps.

2. NFC is only available in some countries /areas.

16. Location access

You can let your device access GPS, Wi-Fi n etworks, and
mobile networks to estimate your location. Apps that
have your permission can use this information to deliver
location-based services, such as the ability to check in,
view commute traffic, or find nearby restaurants .

To control what location in formation your device can use,
go to Settings > PERSONAL > Location.
When the Location switch is on, you can do any of the
following:

• Change the location mode between High accuracy,

Battery saving and Device only.

• Check the Recent location requests.

• Check the Location services.

• AGPS Setting: Touch to set the AGPS server add ress

and the port.

Hint: Using location access does make more demands
on your battery. If you need to save battery life then you
can turn it off in Settings, though when the switch is off,
your device won’t be able to find your precise location or
share it with any apps.

42

17. Restoring factory settings

Restoring factory settings erases all of your personal data
stored on the phone, including email accounts, s ystem
settings, application settings, and any applications you
have installed.

• On the Settings screen, touch Backup & reset >

Factory data reset.

• Follow the onscreen instructions and touch Reset

phone. Then touch Erase everything. The ph one will

restore the factory settings and restart automatically.
Warning: Before restoring factory settings, it is vital that
you first back up any important data on the pho ne;
otherwise all data will be lost after factory settings h ave
been restored.

18. FOTA (Firmware Over The
Air) updating

Using the FOTA Upgrade tool you can update your
phone's software.

• On the right-most Home screen touch > About

phone > System updates, or touch > > About

phone > System updates.

• Touch Check for updates, and the phone will s earch

for the latest software. If you want to update the

system, please touch the button Download, af ter it

done please touch Update now to complete the

upgrade. Then your phone's software will have the

latest version.

Hints:

1. During FOTA downloading or updating , do not change

your default storage location, to avoid errors in

locating the correct update packages.

43

2. Upgrading your phone software will not af fect your

mobile phone data.

44

Frequently Asked Questions

How do I free up my phone's internal storage?

• Move files and email attachments to the microSD card.

• In Browser, clear all temporary Internet files and

Browser history information.

• Uninstall any applications that you no longer u se.

• Reset your phone to factory settings.

How can I use the microSD card to import
contacts from another phone onto my phone?

Your phone supports “.vcf” format contact fil es. “.vcf” is
the standard format for storing personal and company
contacts. It usually includes name, address, telephone
number, mobile phone number, email and other con tact
information. It also supports custom fields, pictures and
other media information.

• Back up the contact you want to import as a “.vcf” file

and save it to the microSD card.

• Insert the microSD card into your phone. In E S File

Explorer, find the “.vcf” file saved on the m icroSD card.

• Touch the “.vcf” file. On the window that pops up,

select the account you want to import the contact to.
Hint: Because “.vcf” files backed up by dif ferent systems
may cause compatibility problems, some contact
information may be lost after the contact has been
imported.

How do I turn off auto-rotate?

• On the right-most Home screen touch > Display,

or touch > > Dis play.

• Unmark the Auto-rotate screen checkbox to dis able

this function.

45

How do I set the screen unlock pattern?

• On the right-most Home screen touch > Security >

Screen lock > Pattern, or touch > > Security >

Screen lock > Pattern.

• Follow the onscreen instructions to set the unlock

pattern.

How do I switch input method?

When you installed other different input metho ds, you
can switch the input methods.

• When the keyboard is displayed on the scree n, gently

drag down the Status bar to open the Notification

Panel.

• Touch Choose input method and select the i nput

method you want to use.

How do I stop music playing in the
background?

Gently drag down Status bar to open the Notification
panel. Touch the music playback information bar to enter
the music playback screen and stop playback.

How do I return to the call screen?

If you are in another screen during a phone call, you can
get back to the call screen by gently draggin g down the
Status bar to open the Notification panel and the
touching the current call.

How do I create a shortcut on the Home
screen?

On the applications list, touch and hold an ap plication
icon until the Home screen is displayed. The n drag the
icon where you want it to go and release your finger.

46

How do I hide the keyboard?

Touch Back key to hide the keyboard when it is displayed
on the screen.

How do I forward a message?

Touch and open the message you want to forward. Touch
and hold the message content. On the options m enu that
pops up, touch Forward.

How do I take a quick capture of the current
screen?

Press the Volume key (Down) and Power key at the same
time, and make a little pause to take a captur e of the
current screen.
If your phone has a microSD card installed, th e
screenshots will save to the screenshots fold er
(/storage/external_sd/Pictures/Screensho ts/) in
microSD card by default.

47

Read the Safety
Information section
of this user guide
on page 49

Do not use while
re-fuelling

Do not use
hand-held while
driving

This device may
produce a bright or
flashing light

For body-worn
operation maintain
a separation of
15 mm

Do not dispose of in
a fire

Small parts may
cause a choking
hazard

Avoid contact with
magnetic media

This device
may produce a loud
sound

Avoid Extreme
Temperatures

Keep away from
pacemakers and
other personal
medical devices

Avoid contact with
liquid, keep dry

Switch off when
instructed in
hospitals and
medical facilities

Do not try and
disassemble

Switch off when
instructed in
aircrafts and airports

Do not rely on this
device for
emergency
communications

Switch off in
explosive
environments

Only use approved
accessories

Product Safety Information

Pictograms and Graphic Symbols

48

RF Exposure

General Statement on RF energy

Your phone contains a transmitter and a receiver. When it
is ON, it receives and transmits RF energy. When you
communicate with your phone, the system handling your
call controls the power level at which your phone
transmits.

Specific Absorption Rate (SAR)

Your mobile device is a radio transmitter and receiver. I t is
designed not to exceed the limits for exposure to radio
waves recommended by international guid elines. These
guidelines were developed by the independent scientific
organisation ICNIRP and include safety margins designed
to assure the protection of all persons, regardless of age
and health.

The guidelines use a unit of measurement known as th e
Specific Absorption Rate, or SAR. The SAR limit for mobile
devices is 2 W/kg and the highest SAR value f or this
device when tested at the ear was 0.656 W/kg and when
tested near the body (at a distance of 15mm) the highest
SAR value was 0.829 W/kg. As mobile device s offer a
range of functions, they can be used in other positions,
such as on the body as described in this user guide.

As SAR is measured utilising the device’s highest

transmitting power, the actual SAR of this device while
operating is typically below that indicated ab ove. This is
due to automatic changes to the power level of the
device to ensure it only uses the minimum power
required to communicate with the network.

Body worn operation

Important safety information regarding radio frequency
radiation (RF) exposure.

To ensure compliance with RF exposure guidelines the
phone must be used with a minimum of 15 mm
separation from the body.

Failure to observe these instructions could result in your
RF exposure exceeding the relevant guidelin e limits.

49

Limiting exposure to radio frequency (RF)
fields

For individuals concerned about limiting their exposure
to RF fields, the World Health Organisation (WHO)
provides the following advice:

Precautionary measures: Present scientific inform ation
does not indicate the need for any special precaution s for
the use of mobile phones. If individuals are co ncerned,
they might choose to limit their own or their children’s RF
exposure by limiting the length of calls, or using
‘hands-free’ devices to keep mobile phones a way from
the head and body.

Further information on this subject can be obtained fro m
the WHO home page http://www.who.int/peh -emf WHO
Fact sheet 193: June 2000.

Regulatory information

The following approvals and notices apply in specific
regions as noted.

50

Declaration of Conformity

51

Distraction

Driving

Full attention must be given to driving at all times in
order to reduce the risk of an accident. Using a ph one
while driving (even with a hands free kit) causes
distraction and can lead to an accident. You mu st comply
with local laws and regulations restricting the us e of
wireless devices while driving.

Operating machinery

Full attention must be given to operating the mach inery
in order to reduce the risk of an accident.

Product Handling

General Statement on handling and use

You alone are responsible for how you use your ph one
and any consequences of its use.

You must always switch off your phone wherever the us e
of a phone is prohibited. Use of your phone is subject to
safety measures designed to protect users and their
environment.

• Always treat your phone and its accessories with care

and keep it in a clean and dust-free place.

• Do not expose your phone or its accessories to open

flames or lit tobacco products.

• Do not expose your phone or its accessories to liquid,

moisture or high humidity.

• Do not drop, throw or try to bend your phone or its

accessories.

• Do not use harsh chemicals, cleaning solvents, o r

aerosols to clean the device or its accessories.

• Do not paint your phone or its accessories.

• Do not attempt to disassemble your phone or its

accessories, only authorised personnel must do so .

• Do not expose your phone or its accessories to

extreme temperatures, minimum 0 and maxi mum +45
degrees Celsius.

52

• Please check local regulations for disposal of

electronic products.

• Do not carry your phone in your back pocket as it

could break when you sit down.

Small Children

Do not leave your phone and its accessories within the
reach of small children or allow them to p lay with it.

They could hurt themselves or others, or could
accidentally damage the phone.

Your phone contains small parts with sharp edges that
may cause an injury or which could become detached
and create a choking hazard.

Demagnetisation

To avoid the risk of demagnetisation, do not allow
electronic devices or magnetic media close to your
phone for a long time.

Electrostatic discharge (ESD)

Do not touch the SIM card’s metal connectors.

Power supply

Do not connect your device to the power supply or
switch it on until instructed to do so in the installation
instructions.

Antenna

Do not touch the antenna unnecessarily.

Normal use position

When placing or receiving a phone call, hold your phon e
to your ear, with the bottom towards your mouth o r as
you would a fixed line phone.

53

Air Bags

Do not place a phone in the area over an air bag or in th e
air bag deployment area.

Store the phone safely before driving your vehicle.

Seizures/Blackouts

This phone is capable of producing bright flashing lights .

Repetitive Motion Injuries

To minimise the risk of RSI, when Texting or playing
games with your phone:

• Do not grip the phone too tightly.

• Press the buttons lightly.

• Make use of the special features in the handset which

minimise the number of buttons which have to be
pressed, such as message templates and predictiv e
text.

• Take lots of breaks to stretch and relax.

Emergency Calls

This phone, like any wireless phone, operates using radio
signals, which cannot guarantee connection in all
conditions. Therefore, you must never rely solely on any
wireless phone for emergency communications .

54

Loud Noise

This phone is capable of producing loud noises which
may damage your hearing. Prolonged exposure to mus ic
at full volume on the music player may dama ge the
listener's hearing. Use the recommended headph ones
only.

PROTECT YOUR HEARING

To prevent possible hearing damage, do
not listen at high volume levels for long
peroids. Exercise caution when holding
your device near your ear while the

Bright Light

This phone is capable of producing flash of light or u se as
a torch, do not use it too close to the eyes.

Phone Heating

Your phone may become warm during charging and
during normal use.

Electrical Safety

Accessories

Use only approved accessories.
Do not connect with incompatible products

or accessories .
Take care not to touch or allow metal objects, s uch as

coins or key rings, to contact or short-circuit t he battery
terminals.

Connection to a Car

Seek professional advice when connecting a phone
interface to the vehicle electrical system.

loudspeaker is in use.

55

Faulty and Damaged Products

Do not attempt to disassemble the phone or its
accessory.

Only qualified personnel must service or repair the
phone or its accessory.

If your phone or its accessory has been submerged in
water, punctured, or subjected to a severe fa ll, do not
use it until you have taken it to be checked at an
authorised service centre.

Battery Handling & Safety

Always switch the device off and disconnect the charger
before removing the battery.

Only use the battery and charger supplied, or
manufacturer approved replacements intended for use
with your phone. Using other batteries and chargers
could be dangerous.

Do not disassemble or short-circuit the bat tery.
Accidental short-circuiting can occur if a metallic object
such as a key, paper clip, or pen touches the terminals of
the battery.

Improper battery use may result in a fire, explo sion, or
other hazard. If you believe the battery has been
damaged, do not use it, take it to a service ce ntre for
testing.

Interference

General statement on interference

Care must be taken when using the phone in close
proximity to personal medical devices, such as
pacemakers and hearing aids.

Pacemakers

Pacemaker manufacturers recommend that a minimum
separation of 15 cm be maintained between a mo bile
phone and a pacemaker to avoid potential interferen ce
with the pacemaker. To achieve this use the pho ne on

56

the opposite ear to your pacemaker and do not car ry it in
a breast pocket.

Hearing Aids

People with hearing aids or other cochlear implants may
experience interfering noises when using wireless
devices or when one is nearby.

The level of interference will depend on the type o f
hearing device and the distance from the int erference
source, increasing the separation between them may
reduce the interference. You may also consult your
hearing aid manufacturer to discuss alternatives.

Medical devices

Please consult your doctor and the device manufactu rer
to determine if operation of your phone may interfere
with the operation of your medical device.

Hospitals

Switch off your wireless device when requested to do so
in hospitals, clinics or health care facilities. These
requests are designed to prevent possible int erference
with sensitive medical equipment.

Aircraft

Switch off your wireless device whenever you are
instructed to do so by airport or airline staff.

Consult the airline staff about the use of wireless dev ices
on board the aircraft, if your device offers a ‘flight mode’
this must be enabled prior to boarding an aircraft.

Interference in cars

Please note that because of possible interferen ce to
electronic equipment, some vehicle manufacturers
forbid the use of mobile phones in their vehicles unless a
handsfree kit with an external antenna is included in the
installation.

57

Explosive environments

Petrol stations and explosive atmospheres

In locations with potentially explosive atmospheres, obey
all posted signs to turn off wireless devices such as your
phone or other radio equipment.

Areas with potentially explosive atmospheres include
fuelling areas, below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contain s
chemicals or particles, such as grain, dust, or metal
powders.

Blasting Caps and Areas

Turn off your mobile phone or wireless device when in a
blasting area or in areas posted turn off “two -way radios”

or “electronic devices” to avoid interfering with blasting

operations.

Protection against theft

Your telephone is identified by an IMEI (phone serial
number) shown on the packaging label and in the

product’s memory. We recommend that you no te the

number the first time you use your telephone by
entering * # 0 6 # and keep it in a safe place. It may be
requested by the police or your operator if your
telephone is stolen. This number allows your mo bile
telephone to be blocked preventing a third person from
using it, even with a different SIM card.

Recycling information

This symbol on your telephone, the
battery and the accessories means that
these products must be taken to
collection points at the end of their life:

- Municipal waste disposal centres with
specific bins for these items of
equipment

- Collection bins at points of sale.

58

They will then be recycled, preventing substan ces being
disposed of in the environment, so that their
components can be reused.

In European Union countries:

These collection points are accessible free of charge.
All products with this sign must be brought to these

collection points.

In non European Union jurisdictions:

Items of equipment with this symbol are not to be
thrown into ordinary bins if your jurisdiction or your
region has suitable recycling and collection facilities;
instead they are to be taken to collection poi nts for them
to be recycled.

CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLA CED
BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES
ACCORDING TO THE INSTRUCTIONS.

FCC Regulations

• This mobile phone complies with part 15 of the FCC

Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmfu l
interference, and (2) this device must accept any
interference received, including interference that m ay
cause undesired operation.

• This mobile phone has been tested and fou nd to

comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection agains t
harmful interference in a residential installation. Th is
equipment generates, uses and can radiated radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause h armful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation If this equipment does cau se
harmful interference to radio or television reception,
which can be determined by turning the equipm ent off

59

and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:

a) Reorient or relocate the receiving antenna.

b) Increase the separation between the equipment

and receiver.

c) Connect the equipment into an outlet on a circuit

different from that to which the receiver is
connected.

d) Consult the dealer or an experienced radio/TV

technician for help.

Caution: Changes or modifications not expressly
approved by the party responsible for compliance could
void the user‘s authority to operate the equipment.

• The antenna(s) used for this transmitter must not be

co-located or operating in conjunction with a ny other
antenna or transmitter.

RF Exposure Information (SAR)

This phone is designed and manufactured not to exceed
the emission limits for exposure to radio frequ ency (RF)
energy set by the Federal Communications Commis sion
of the United States.

During SAR testing, this device was set to transmit at its
highest certified power level in all tested frequency
bands, and placed in positions that simulate RF exposure
in usage against the head with no separation, and near
the body with the separation of 10 mm. Alth ough the
SAR is determined at the highest certified power level,
the actual SAR level of the device while operatin g can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels so
as to use only the power required to reach the network.
In general, the closer you are to a wireless bas e station
antenna, the lower the power output.

The exposure standard for wireless devices employing a
unit of measurement is known as the Specific Abso rption
Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg for
an uncontrolled environment.

60

FCC ID:

R38YLVODAFONE888N

(NFC)

Highest SAR for

head

1.215 W/kg

Highest SAR for

body

0.818 W/kg

FCC ID:

R38YLVODAFONE888

(non-NFC)

Highest SAR for

head

1.215 W/kg

Highest SAR for

body

0.818 W/kg

Tests for SAR are conducted using standard operating
positions accepted by the FCC with the device
transmitting at its highest certified power level in al l
tested frequency bands.

The FCC has granted an Equipment Authorization fo r this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines.

SAR information on this model phone:

While there may be differences between the SAR levels
of various phones and at various positions, they all meet
the government requirements.

SAR compliance for body-worn operation is bas ed on a
separation distance of 10 mm between the unit and the
human body. Carry this device at least 10 mm away from
your body to ensure RF exposure level compliant or
lower to the reported level. To support bod y-worn
operation, choose the belt clips or holsters, which do
not contain metallic components, to maintain a
separation of 10 mm between this device an d your body.

RF e xposure compliance with any body- worn accessory,
which contains metal, was not tested and cer tified, and
use such body-worn accessory should be avoid ed.

Licences

61

Some services and apps may not be available in all
countries.

Please ask in-store for details.

Android, Google, Google Play and other marks are
trademarks of Google Inc.

© Vodafone Group 2014. Vodafone and th e Vodafone
logos are trade marks of Vodafone Group. Any produ ct or
company names mentioned herein may be the trade
marks of their respective owners.

Notice

The information in this manual is subject to change
without notice. Every effort has been made in the
preparation of this manual to ensure accuracy of the
contents, but all statements, information, and
recommendations in this manual do not constitute a
warranty of any kind, expressed or implied. Read the
safety precautions and safety information carefu lly to
ensure that you use this wireless device in a co rrect and
safe manner.

Yulong Computer Telecommunication Scientific
(Shenzhen) Co., Ltd.

Address:

Coolpad Information Harbor, 2nd Mengxi Road, Northern
Part of Science&Technology Park, Nanshan d istrict,
Shenzhen, P.R.China

62

Telephone warranty

WARRANTY TERMS AND CONDITIONS

1. Vodafone undertakes the warranty of this Mobile

Phone for a period of two (2) years from the date o f
Purchase by the original owner (not transferable)
under normal use.

2. The Battery has a limited warranty for twelve (12)

months, and Charger for twenty-four (24) mo nths
against manufacturing defects. Other accesso ries have
a limited warranty for twenty-four (24) months against
manufacturing defects.

3. This Warranty does not cover damage r esulting from:

a) Normal wear & tear of the equipment;
b) Defects and damages due to the equipment being

used other than its normal and customary manner;

c) An unauthorized disassembly, repair, alterati on or

modification being carried out;

d) Misuse, abuse, negligence or accident howsoever

caused;

e) Defects or damage arising from improper testing,

operation, maintenance, installation, or any
alteration or modification;

f) D efects or damage due to spillage of food or liquids,

corrosion, rust or the use of wrong voltage;

g) Scratches or damage to plastic surfaces and all

other externally exposed parts that are due to
normal customer use;

4. The Handset requiring service/repair mus t be

delivered at the user's cost.

5. This warranty will be null and void in any of the

following events:
a) If the serial number or warranty seal on the

equipment has been defaced or removed.

b) If any term contained in this warranty has been

altered or modified in any way without prior written
consent of Vodafone.

6. The limited warranty extends onl y to customer who

purchase the product in one of the countries (or areas)
set forth at the end of this document. The lim ited

63

warranty is only valid in Vodafone's intended country
(or area) of sale of the Product.

7. If the product is returned to Vodafone aft er the

expiration of the warranty period, Vodafone's no rmal
service policies shall apply and the Consumer will be
charged accordingly.

a) Vodafone neither assumes for it any other

obligation or liability beyond that which is expressly
provided for in this limited warranty.

b) All warranty information, product features and

specifications are subject to change without notice.

8. THIS WARRANTY IS IN LIEU OF ANY A ND OTHER

WARRANTIES EXPRESSED OR IMPLIED, SPECIFICALLY
INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILlTY OR FITNESS FOR A PARTICULAR
PURPOSE. VODAFONE ASSUMES NO LIABILITY FO R
THE BREACH OF THE WARRANTY BEYOND
CORRECTING THE BREACH IN THE MANNER
DESCRIBED ABOVE. IN NO EVENT SHALL VODAFONE
BE LIABLE FOR CONSEQUENCES.

64

Basic specifications

Dimensions

134.7 × 66 × 10.6 mm

Form factor

Bar

Antenna

Internal

SIM card

Micro-SIM

Network

GSM (900/1800/1900MHz)
WCDMA (900/2100MHz)

WLAN

2.4 GHz

Camera

Front 0.3M pixel + Rear 5M pixel FF

Headset
connector

Ф3.5mm CTIA standard

Screen parameters

Type

Dimensions

Resolution

LCD, FWVGA

4.5-inch

480× 854

Accessories

Battery

Battery name

Lithium-ion
polymer
rechargeabl
e battery

Rated capacity

1,880 mAh

Nominal voltage

3.7 V

Technical data

65

No.

Name

Quantity 1 Phone

1 2 Battery

1 3 Travel charger

1 4 USB charge/data cable

1 5 Headset

1

6

Quick start guide

1

7

Safety & warranty information

1

8

NFC TAG guide with 2 TAGs

(This is only available in some

countries/areas)

1

Accessories

Note: Accessories included are dependent on the fina l
seller. Contact the retailer for details.

66

© Vodafone Group 2014. Vodafone and the Vodafone
logos are trade marks of Vodafone Group. Any
product or company names mentioned herein may
be the trade marks of their respective owners.
