Vodafone Smart Mini User Manual

Quick start guide

Vodafone Smart mini

Some services and apps may not be available in all countries.

Facebook is a trademark of Facebook, Inc. Google, Android, YouTube
and other marks are trademarks of Google, Inc.

© Vodafone Group 2013. Vodafone and the Vodafone logos are
trade marks of Vodafone Group. Any product or company names
mentioned herein may be the trade marks of their respective owners.

English - CJB26NNVDAAA

IP4464_VF875_QG_Eng_GB_30_130520.indd 2-3 2013-5-20 11:59:18

1 2

For more information about how to use this phone, please go to
www.vodafone.com/smartmini to download full user manual. At this
website, you can also view the FAQs, check for software updates, and
more.

Your mobile 1

Keys and connectors1.1

Proximity sensor

Touch screen

LED light

Back key

Home key

Multitask key

Headset connector

Power key

micro-USB connector

Volume up

Volume down

Camera

Multitask key

On the Home screen, a short press shows all running apps.•
Quick menu: pressing and holding the Multitask key can •

bring up a quick menu for settings and managing apps. To
enable this, go to Settings > Display > Menu appearance
and select

Home key

Press to return to the central Home screen. •
Use a long press to access "Google Now" and "Voice •

Search".

Back key

Press to go back to the previous menu or screen.•

IP4464_VF875_QG_Eng_GB_31_130520.indd Sec1:1-Sec1:2IP4464_VF875_QG_Eng_GB_31_130520.indd Sec1:1-Sec1:2 2013-5-20 14:48:292013-5-20 14:48:29

3 4

Power key

Short press: Lock the screen.•

Light up the screen.

Long press: If your phone is off, this powers it on.•

If your phone is on, this brings up the Power
option menu: Power off, Restart, Aeroplane
mode, and icons for ringing modes.

Volume Key

Press to adjust the volume (in call/media playing mode)•
Press to adjust the ring tone volume in general mode.•

Getting started1.2

Set-up1.2.1

Removing or installing the back cover

Inserting or removing the SIM card

You must insert your SIM card to make phone calls. Please power off
your phone and remove the battery before inserting or removing the
SIM card.

Place the SIM card with the chip facing downwards and slide it into its
housing. Make sure that it is correctly inserted. To remove the card,
press and slide it out.

Inserting or removing the battery

Please power off your phone before removing the battery.

Insert and click the battery into place, then close the phone cover.•
Unclip the cover, then remove the battery.•

Inserting and removing the microSD card

To release the microSD card holder, slide it in the direction of the
arrow and lift it. Then insert the microSD card with the golden contact
downward. Finally, fold down the microSD holder and slide it in the
opposite direction to lock it.

Charging the battery

Connect the battery charger to your phone and the mains socket
respectively.

IP4464_VF875_QG_Eng_GB_31_130520.indd Sec1:3-Sec1:4IP4464_VF875_QG_Eng_GB_31_130520.indd Sec1:3-Sec1:4 2013-5-20 14:48:292013-5-20 14:48:29

5 6

To reduce energy wastage, disconnect your charger from the

plug when the battery is fully charged.

To reduce your phone's power consumption switch off Wi-Fi,
GPS, Bluetooth or applications running in the background when
not needed. You can also reduce the backlight brightness, and
shorten the time before the phone goes into sleep mode.

Power on your phone1.2.2

Hold down the Power key until the phone powers on. It will take some
seconds before the screen lights up.

Set up your phone for the first time

The first time you power on the phone, you will be asked to choose
following options: language, date & time, Google account, Input
method, etc. You can always make changes later using Settings in
the main menu

(1)

.

If you don't have a SIM card inserted you can still connect to a Wi-Fi
network from the Power on screen, which will let you sign on to your
Google account and use some features.

Power off your phone1.2.3

Hold down the Power key until the phone options appear. Tap Power
off, then tap OK.

Sleep mode1.2.4

After a set time, your phone will go into a sleep mode to save power.
You can also press the Power key once to send the phone to sleep
mode.

To wake your phone from sleep mode, just press the Power key.

Lock/Unlock the screen1.2.5

When you wake your phone from sleep mode you'll see a Lock screen,
which prevents accidental key presses.

(1)

Application availability depends on country and operator.

To unlock the screen, touch and slide the to the right. You can also
slide it in other directions to perform other actions, such as search or
starting the camera.

You can change the type of lock screen so that it unlocks with a
password or by drawing a pattern: press and hold the Multitask key
and touch System settings > Security > Set up screen lock > PIN

or Password or Slide.

Home screen1.3

You can bring all your favourite items (applications, shortcuts, folders
and widgets) to your Home screen for quick access. Touch the Home
key to switch to the main Home screen.

Status bar

Status/Notification indicators •
Touch and Drag down to open the •
Notification panel.

Application tab

Touch to open applications list.

Touch to access Messaging.
Touch to access Browser.

Touch to access Call log if you have missed calls.
Touch to access dial screen.

Touch to access People.

Search bar

Touch a to enter Search options: All,
Web, Apps, Contacts, etc.
Touch b to enter voice search screen.

Touch an icon to open an application,
folder, etc.

a

b

The Home screen extends on either side of the screen to allow more
space for adding applications, shortcuts, etc. Slide the Home screen
horizontally left and right to get a complete view of the Home screen.

IP4464_VF875_QG_Eng_GB_31_130520.indd Sec1:5-Sec1:6IP4464_VF875_QG_Eng_GB_31_130520.indd Sec1:5-Sec1:6 2013-5-20 14:48:312013-5-20 14:48:31

7 8

Using the touchscreen1.3.1

Touch

To open an application, touch it with your finger.

Touch and Hold

Touch and hold your finger on the screen for 2 or more seconds. You
can touch and hold an application, a widget or a blank area to drag the
item or display the corresponding option menus.

Drag

Touch and hold your finger on any item to drag it to another location.

Slide/Swipe

Slide the screen to scroll up and down applications, images, web
pages...

Flick

Similar to swiping, but flicking makes it move quicker.

Pinch/Spread

Place your finger and thumb on the screen surface and draw them
apart or together to scale an element on the screen.

Rotate

Automatically change the screen orientation from portrait to landscape
by turning the phone sideways.

To achieve the best response when using the touchscreen,

all that is needed is a gentle touch for both short or long
press actions.

Status bar1.3.2

From status bar, you can view both phone status (on the right side) and
notification information (on the left side).

Status icons

GPRS connected GPS is on

GPRS in use

Receiving location data
from GPS

EDGE connected Roaming

EDGE in use No signal

3G connected No SIM card installed

3G in use Vibrate mode

HSPA (3G+) connected Ringer is silenced

HSPA (3G+) in use

Phone microphone is
muted

Connected to a Wi-Fi
network

Battery is very low

Bluetooth is on Battery is low

Connected to a
Bluetooth device

Battery is partially
drained

Airplane mode Battery is full

Alarm is set Battery is charging

Signal strength Headset connected

IP4464_VF875_QG_Eng_GB_31_130520.indd Sec1:7-Sec1:8IP4464_VF875_QG_Eng_GB_31_130520.indd Sec1:7-Sec1:8 2013-5-20 14:48:312013-5-20 14:48:31

9 10

Notification icons

New Gmail TM message

Both USB tethering and
portable hotspot are on

New text or multimedia
message

Call in progress

Problem with text or
multimedia message
delivery

Call in progress using
Bluetooth headset

New Google Talk TM
message

Missed call

New voicemail Call on hold

Upcoming event Call forwarding is on

Data is synchronising Uploading data

Problem with sign-in or
synchronisation

Downloading data

microSD card is full Download finished

No microSD card
installed

An open Wi-Fi network is
available

Connected to VPN

Phone is connected via
USB cable

Disconnected from VPN Radio is on

Song is playing System update available

USB tethering is on

Portable Wi-Fi hotspot
is on

Notification panel

Touch and drag down the Status bar to open the Notification panel.
Touch and drag up to close it. From the Notification panel, you can
open items and other reminders indicated by notification icons or view

wireless service information.

Widget bar: swipe left to see more
widgets. Touch an icon to change its
function.

Settings

Touch

to clear all event–based notifications (other ongoing

notifications will remain).

Search bar1.3.3

The phone provides a Search bar on the main Home screen which can
be used to find information in applications, search for apps and data on
your phone or search the web.

a Touch or press the keypads to

searce by text

b Touch to search by voice
c Touch to enter the suggested

text for quick search

d Touch to search the web

a

c

b

d
