Operating Instructions
Controller in field housing for a continuously measuring analogue level sensor
VEGAMET 841
4 … 20 mA
Document ID: 58864
Contents
Contents
1 About this document................................................................................................................ |
4 |
|
1.1 |
Function............................................................................................................................ |
4 |
1.2 |
Target group...................................................................................................................... |
4 |
1.3 |
Symbols used................................................................................................................... |
4 |
2 For your safety.......................................................................................................................... |
5 |
|
2.1 |
Authorised personnel........................................................................................................ |
5 |
2.2 |
Appropriate use................................................................................................................ |
5 |
2.3 |
Warning about incorrect use............................................................................................. |
5 |
2.4 |
General safety instructions................................................................................................ |
5 |
2.5 |
Installation and operation in the USA and Canada............................................................ |
6 |
2.6 |
Safety instructions for Ex areas......................................................................................... |
6 |
3 Product description.................................................................................................................. |
7 |
|
3.1 |
Configuration.................................................................................................................... |
7 |
3.2 |
Principle of operation........................................................................................................ |
9 |
3.3 |
Adjustment........................................................................................................................ |
9 |
3.4 |
Packaging, transport and storage................................................................................... |
10 |
3.5 |
Accessories.................................................................................................................... |
11 |
4 |
Mounting.................................................................................................................................. |
12 |
||
|
4.1 |
General instructions........................................................................................................ |
12 |
|
|
4.2 |
Mounting instructions...................................................................................................... |
12 |
|
5 |
Connecting to power supply................................................................................................. |
15 |
||
|
5.1 |
Preparing the connection................................................................................................ |
15 |
|
|
5.2 |
Sensor input mode active/passive.................................................................................. |
15 |
|
|
5.3 |
Connecting..................................................................................................................... |
16 |
|
|
5.4 |
Wiring plan...................................................................................................................... |
17 |
|
|
5.5 |
Switch-on phase............................................................................................................. |
17 |
|
6 |
Access protection................................................................................................................... |
19 |
||
|
6.1 |
Bluetooth radio interface................................................................................................. |
19 |
|
|
6.2 |
Protection of the parameterization.................................................................................. |
19 |
|
|
6.3 |
Storing the codes in myVEGA......................................................................................... |
20 |
|
7 |
Set up with the integrated display and adjustment unit..................................................... |
21 |
||
|
7.1 |
Adjustment system.......................................................................................................... |
21 |
|
|
7.2 |
Measured value and menu item display.......................................................................... |
22 |
|
|
7.3 |
Menu overview................................................................................................................ |
23 |
|
|
7.4 |
Setup steps..................................................................................................................... |
24 |
|
8 |
Setup with smartphone/tablet (Bluetooth).......................................................................... |
30 |
||
|
8.1 |
Preparations................................................................................................................... |
30 |
|
|
8.2 |
Connecting..................................................................................................................... |
30 |
|
|
8.3 |
Parameter adjustment..................................................................................................... |
31 |
|
9 |
Setup with PC/notebook (Bluetooth).................................................................................... |
32 |
||
|
9.1 |
Preparations................................................................................................................... |
32 |
|
|
9.2 |
Connecting..................................................................................................................... |
32 |
|
|
9.3 |
Parameter adjustment..................................................................................................... |
33 |
|
10 |
Applications and functions................................................................................................... |
34 |
||
|
|
|
|
|
2 |
|
|
VEGAMET 841 • 4 … 20 mA |
<![endif]>210225-EN-58864
<![endif]>58864-EN-210225
|
|
|
|
Contents |
|
|
10.1 |
Level measurement in storage tanks with overfill protection/dry run protection............... |
34 |
||
|
10.2 |
Pump station with pump control function......................................................................... |
37 |
||
|
10.3 |
Flow measurement flume/weir........................................................................................ |
44 |
||
11 |
Diagnostics and servicing..................................................................................................... |
48 |
|||
|
11.1 |
Maintenance................................................................................................................... |
48 |
||
|
11.2 |
Rectify faults................................................................................................................... |
48 |
||
|
11.3 |
Diagnosis, fault messages.............................................................................................. |
48 |
||
|
11.4 |
Software update.............................................................................................................. |
50 |
||
|
11.5 |
How to proceed if a repair is necessary.......................................................................... |
51 |
||
12 Dismount................................................................................................................................. |
52 |
||||
|
12.1 |
Dismounting steps.......................................................................................................... |
52 |
||
|
12.2 |
Disposal.......................................................................................................................... |
52 |
||
13 |
Certificates and approvals.................................................................................................... |
53 |
|||
|
13.1 |
Radio licenses................................................................................................................ |
53 |
||
|
13.2 |
Approvals for Ex areas.................................................................................................... |
53 |
||
|
13.3 |
Approvals as overfill protection....................................................................................... |
53 |
||
|
13.4 |
EU conformity................................................................................................................. |
53 |
||
|
13.5 |
Environment management system.................................................................................. |
53 |
||
14 Supplement............................................................................................................................. |
54 |
||||
|
14.1 |
Technical data................................................................................................................. |
54 |
||
|
14.2 |
Overview applications/functionality................................................................................. |
57 |
||
|
14.3 |
Dimensions..................................................................................................................... |
60 |
||
|
14.4 |
Industrial property rights................................................................................................. |
62 |
||
|
14.5 |
Licensing information for open source software.............................................................. |
62 |
||
|
14.6 |
Trademark....................................................................................................................... |
62 |
|
Editing status: 2021-02-25 |
VEGAMET 841 • 4 … 20 mA |
3 |
1 About this document
This instruction provides all the information you need for mounting, connection and setup as well as important instructions for maintenance, fault rectification, the exchange of parts and the safety of the user. Please read this information before putting the instrument into operation and keep this manual accessible in the immediate vicinity of the device.
This operating instructions manual is directed to trained personnel.
The contents of this manual must be made available to the qualified personnel and implemented.
Document ID
This symbol on the front page of this instruction refers to the Document ID. By entering the Document ID on www.vega.com you will reach the document download.
Information, note, tip: This symbol indicates helpful additional information and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions, damage to devices or plants.
Caution: Non-observance of the information marked with this symbol may result in personal injury.
Warning: Non-observance of the information marked with this symbol may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol results in serious or fatal personal injury.
Ex applications
This symbol indicates special instructions for Ex applications.
•ListThe dot set in front indicates a list with no implied sequence.
1Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of batteries and accumulators.
<![if ! IE]><![endif]>210225-EN-58864
4 |
VEGAMET 841 • 4 … 20 mA |
<![endif]>58864-EN-210225
2 For your safety
All operations described in this documentation must be carried out only by trained, qualified personnel authorised by the plant operator.
During work on and with the device, the required personal protective equipment must always be worn.
VEGAMET 841 is a universal controller for connection of a 4 … 20 mA sensor.
You can find detailed information about the area of application in chapter " Product description".
Operational reliability is ensured only if the instrument is properly used according to the specifications in the operating instructions manual as well as possible supplementary instructions.
Inappropriate or incorrect use of this product can give rise to applica- tion-specific hazards, e.g.vessel overfill through incorrect mounting or adjustment. Damage to property and persons or environmental contamination can result. Also, the protective characteristics of the instrument can be impaired.
This is a state-of-the-art instrument complying with all prevailing regulations and directives. The instrument must only be operated in a technically flawless and reliable condition.The operator is responsible for the trouble-free operation of the instrument. When measuring aggressive or corrosive media that can cause a dangerous situation if the instrument malfunctions, the operator has to implement suitable measures to make sure the instrument is functioning properly.
During the entire duration of use, the user is obliged to determine the compliance of the necessary occupational safety measures with the current valid rules and regulations and also take note of new regulations.
The safety instructions in this operating instructions manual, the national installation standards as well as the valid safety regulations and accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device beyond that described in the operating instructions manual may be carried out only by personnel authorised by the manufacturer. Arbitrary conversions or modifications are explicitly forbidden.For safety reasons, only the accessory specified by the manufacturer must be used.
To avoid any danger, the safety approval markings and safety tips on the device must also be observed.
VEGAMET 841 • 4 … 20 mA |
5 |
2 For your safety
This information is only valid for USA and Canada. Hence the following text is only available in the English language.
Installations in the US shall comply with the relevant requirements of the National Electrical Code (ANSI/NFPA 70).
Installations in Canada shall comply with the relevant requirements of the Canadian Electrical Code.
For Ex applications, only devices with corresponding Ex approval may be used.Observe the Ex-specific safety instructions.These are an integral part of the operating instructions and are enclosed with every device with Ex approval.
<![if ! IE]><![endif]>210225-EN-58864
6 |
VEGAMET 841 • 4 … 20 mA |
|
3 |
Product description |
|
3.1 Configuration |
|
Scope of delivery |
The scope of delivery encompasses: |
|
|
• |
Controller VEGAMET 841 |
|
• |
Mounting plate |
|
• |
Screws/plugs for mounting |
|
• |
Cable glands/Blind plugs (optional) |
|
• |
Information sheet " Documents and software" with: |
|
–– Instrument serial number |
|
|
• |
–– QR code with link for direct scanning |
|
Information sheet " PINs and Codes" with: |
|
|
• |
–– Bluetooth access code |
|
Information sheet " Access protection" with: |
|
|
–– Bluetooth access code |
–– Emergency Bluetooth unlock code –– Emergency device code
The further scope of delivery encompasses:
•Documentation
––Ex-specific " Safety instructions" (with Ex versions)
––Radio licenses
––If necessary, further certificates
Note:
Optional instrument features are also described in this operating instructions manual. The respective scope of delivery results from the order specification.
Scope of this operating |
This operating instructions manual applies to the following instrument |
|
instructions |
versions: |
|
|
• |
Hardware version from 1.0.0 |
|
• |
Software version from 1.10.0 |
<![endif]>58864-EN-210225
VEGAMET 841 • 4 … 20 mA |
7 |
3 Product description
Constituent parts
|
|
1 |
|
|
2 |
|
|
3 |
|
|
4 |
|
Fig. 1: VEGAMET 841 |
|
|
1 |
Display and adjustment unit |
|
2 |
Housing with cable glands and connection compartment |
|
3 |
Mounting plate |
|
4 |
Ventilation/pressure compensation |
Type label |
The type label contains the most important data for identification and |
|
|
use of the instrument: |
|
|
• |
Instrument type |
|
• |
Information about approvals |
|
• |
Technical data |
|
• |
Serial number of the instrument |
|
• |
QR code for device documentation |
|
• |
Number code for Bluetooth access |
|
• |
Manufacturer information |
Documents and software Move to " www.vega.com" and enter in the search field the serial number of your instrument.
There you can find the following information about the instrument:
• Order data
• Documentation
• Software
Alternatively, you can find all via your smartphone:
•Scan the QR-code on the type label of the device or
•Enter serial number manually in the VEGA Tools app (available free of charge in the respective stores)
Information:
If the serial number or the QR code on the type label cannot be read, they can be found additionally on the display cover inside the device.
8 |
VEGAMET 841 • 4 … 20 mA |
<![endif]>210225-EN-58864
|
|
|
3 Product description |
|
|
3.2 |
Principle of operation |
Application area |
The VEGAMET 841 controller feeds the connected 4 … 20 mA |
||
|
|
sensor, processes the measured values and displays them. A large |
|
|
|
display for data visualisation is integrated in the housing designed for |
|
|
|
rough field conditions. |
|
|
|
It enables simple implementation of pump controls, flow measure- |
|
|
|
ments on open channels and weirs and totalizers. With the VEGAMET |
|
|
|
841, limit values can be reliably monitored and relays can be |
|
|
|
switched, e.g.for an overfill protection according toWHG. |
|
|
|
Due to its various possibilities it is suitable for many industrial |
|
|
|
branches. |
|
Functional principle |
The VEGAMET 841 controller can power the connected sensor and |
||
|
|
process its measurement signals. The requested parameter is shown |
|
|
|
on the display and also output to the integrated current output for fur- |
|
|
|
ther processing. The measurement signal can thus be transferred to a |
|
|
|
remote display or a superordinate control system. Operating relays for |
|
|
|
control of pumps or other devices are also integrated. |
|
|
|
3.3 |
Adjustment |
Local adjustment |
On-site adjustment of the device is carried out via the integrated |
||
|
|
display and adjustment unit. |
Wireless adjustment The optionally integrated Bluetooth module enables in addition a wireless adjustment of VEGAMET 841 via standard adjustment tool:
•Smartphone/tablet (iOS or Android operating system)
•PC/notebook with Bluetooth LE or Bluetooth USB adapter (Windows operating system)
Information:
Certain setting options are not possible or only possible to a limited extent with the integrated display and adjustment unit, for example the settings for flow measurement or pump control.For these applications, the use of PACTware/DTM or the VEGA Tools app is recommended. An overview of the available applications and functions as well as their adjustment options can be found in the appendix.
<![if ! IE]><![endif]>58864-EN-210225
VEGAMET 841 • 4 … 20 mA |
9 |
3 Product description
2
1
3
Fig. 2: Wireless connection to standard adjustment tools with integrated
Bluetooth LE or alternatively Bluetooth USB adapter.
1 |
VEGAMET 841 |
2 |
Smartphone/Tablet |
3 |
PC/Notebook |
|
3.4 Packaging, transport and storage |
Packaging |
Your instrument was protected by packaging during transport. Its |
|
capacity to handle normal loads during transport is assured by a test |
|
based on ISO 4180. |
|
The packaging consists of environment-friendly, recyclable card- |
|
board. For special versions, PE foam or PE foil is also used. Dispose |
|
of the packaging material via specialised recycling companies. |
Transport |
Transport must be carried out in due consideration of the notes on the |
|
transport packaging. Nonobservance of these instructions can cause |
|
damage to the device. |
Transport inspection |
The delivery must be checked for completeness and possible transit |
|
damage immediately at receipt. Ascertained transit damage or con- |
|
cealed defects must be appropriately dealt with. |
Storage
Storage and transport temperature
Up to the time of installation, the packages must be left closed and stored according to the orientation and storage markings on the outside.
Unless otherwise indicated, the packages must be stored only under the following conditions:
•Not in the open
•Dry and dust free
•Not exposed to corrosive media
•Protected against solar radiation
•Avoiding mechanical shock and vibration
•Storage and transport temperature see chapter " Supplement - Technical data - Ambient conditions"
•Relative humidity 20 … 85 %
10 |
VEGAMET 841 • 4 … 20 mA |
<![endif]>210225-EN-58864
|
|
3 Product description |
|
|
3.5 Accessories |
Sun shade |
The sun protection protects the device from direct sunlight and thus |
|
|
|
prevents overheating of the electronics. It also improves the readabil- |
|
|
ity of the display when exposed to sunlight. The sun protection can be |
|
|
used for wall and pipe mounting. |
Pipe mounting set |
The pipe mounting set is used for optimal and safe mounting of the |
|
|
|
devices in horizontal and vertical mounting on pipes. |
<![endif]>58864-EN-210225
VEGAMET 841 • 4 … 20 mA |
11 |
|
4 |
Mounting |
|
4.1 |
General instructions |
Mounting options |
The field housing of theVEGAMET 841 is equally suitable for outdoor |
|
|
or indoor installation due to its degree of protection IP66/IP67 and |
|
|
Type 4X. The standard version is designed for wall mounting. A |
|
|
mounting adapter for pipe mounting is available as an option. |
|
Ambient conditions |
The instrument is suitable for standard and extended ambient condi- |
|
|
tions acc. to DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1. It can be used |
|
|
indoors as well as outdoors. |
|
|
Avoid direct sunlight or use the optionally available sun shade. |
|
|
Make sure that the environmental and ambient conditions specified in |
|
|
chapter " Technical data" are maintained. |
Protection against mois- Protect your instrument against moisture ingress through the following |
||
ture |
measures: |
|
|
• |
Use the recommended connection cable (see chapter " Connect- |
|
ing to power supply") |
|
|
• |
Tighten the cable gland |
|
• |
Mount the instrument in such a way that the cable glands point |
|
downward |
|
|
• |
Loop the connection cable downward in front of the cable gland |
|
This applies mainly to outdoor installations, in areas where high |
|
|
humidity is expected (e.g. through cleaning processes) and on cooled |
|
|
or heated vessels. |
|
|
The visible area of the front panel must be protected from knocks, |
|
|
otherwise water can penetrate through breaking of the front foil. In this |
|
|
case, protection against accidental contact can no longer be ensured. |
|
|
Caution: |
|
|
Make sure that during installation or maintenance no moisture or dirt |
|
|
can get inside the instrument. |
|
|
To maintain the housing protection, make sure that the housing lid is |
|
|
closed during operation and locked, if necessary. |
Pressure compensation The pressure compensation for the housing is realized via a breather
|
element. |
|
|
Note: |
|
|
Make sure that the pressure equalization element is always free of |
|
|
buildup during operation. A high-pressure cleaner may not be used |
|
|
for cleaning. |
|
|
4.2 Mounting instructions |
|
Wall mounting |
Fix the mounting plate to the wall using the screws and dowels sup- |
|
|
plied as shown in the figure below.Make sure that the arrows on the |
|
|
mounting plate point upwards. |
|
|
|
|
12 |
VEGAMET 841 • 4 … 20 mA |
<![endif]>210225-EN-58864
4 Mounting
Loosen the four screws in the housing cover and open it to the left. Fasten the device to the mounting plate using the screws (M5) supplied.
82 mm (3.23")
|
<![if ! IE]> <![endif]>82 mm (3.23") |
|
ø7 mm |
|
(0.28") |
|
ø13 mm |
|
(0.51") |
|
Fig. 3: Mounting plate for wall mounting VEGAMET 841 |
Tube mounting |
The optionally available mounting accessories are required for tube |
|
mounting. The kit consists of two pairs of mounting brackets and four |
|
mounting screws M6 x 100. |
|
The mounting brackets are screwed to the mounting plate and the |
|
tube as shown in the following illustration. |
|
Loosen the four screws in the housing cover and open it to the left. |
|
Fasten the device to the mounting plate using the screws (M5) sup- |
|
plied. |
<![endif]>58864-EN-210225
VEGAMET 841 • 4 … 20 mA |
13 |
4 Mounting
Mounting sun shade
14
1 |
2 |
3 |
4 |
5 |
Fig. 4: Tube mounting
1VEGAMET 841
2Mounting plate
34 screws M6 x 100
4Mounting brackets
5Pipe for diameter 29 … 60 mm (1.14" to 2.36")
The optional sun protection can be used to protect against direct sunlight. The sunshade is simply mounted between the mounting plate and the controller, this is possible for both wall and pipe mounting.
1 |
2 |
3 |
4 |
5 |
6 |
|
|
|
|
|
Fig. 5: Mounting sun protection with pipe mounting |
<![if ! IE]> <![endif]>-58864 |
||
2 |
Sun shade |
||
1 |
VEGAMET 841 |
|
|
3 |
Mounting plate |
<![if ! IE]> <![endif]>-EN |
|
4 |
4 screws M6 x 100 |
||
5 |
Mounting brackets |
<![if ! IE]> <![endif]>210225 |
|
6 |
Pipe for diameter 29 … 60 mm (1.14" to 2.36") |
||
|
VEGAMET 841 • 4 … 20 mA
<![endif]>58864-EN-210225
Safety instructions
Voltage supply
Connection cable
Cable glands
5 Connecting to power supply
Always keep in mind the following safety instructions:
•The electrical connection must only be carried out by trained, qualified personnel authorised by the plant operator.
•If overvoltage surges are expected, overvoltage arresters should be installed.
Warning:
Only connect or disconnect in de-energized state.
The data for power supply are specified in chapter " Technical data".
The instrument belongs to protection class I, hence connection of an earth conductor is required.
Use cable with round cross section. The cable diameter must be suitable for the cable gland used to ensure the seal effect of the cable gland (IP protection).
The voltage supply is connected with standard cable according to the national installation standards.
Standard two-wire cable can be used to connect the sensors.
Note:
If the temperatures are too high, the cable insulation can be damaged. Hence keep apart from the ambient temperature also the selfheating of the instrument for the temperature resistance of the cable in the connection compartment in mind. 1)
When used in the USA/Canada, only cables with copper conductors may be used.
Warning:
In delivery status, all openings are fitted with dust protection caps.
These caps are only for protection during transport and are not suitable for protection during operation! Instead, all openings must be closed with cable glands/blind plugs.
Cable glands, NPT adapters or blind plugs that are not included in the scope of delivery must meet the applicable requirements in order to ensure the environmental compatibility of the housing. For outdoor applications, the weather resistance of the accessories to be used must be taken into account. The cable glands, NPT adapters and blind plugs must have a metric thread M20 to be compatible with the threaded openings of the metal plate in the housing.
Through the selection of the terminals, you can choose between active and passive operation of the sensor input.
1)With an ambient temperature ≥ 50 °C (122 °F) the connection cable should be suitable for an ambient temperature which is at least 20 °C (36 °F) higher.
VEGAMET 841 • 4 … 20 mA |
15 |
5 Connecting to power supply
•In active mode, the controller provides the power for the connected sensors. Power and measurement data are transmitted over the same two-wire cable. This mode is provided for connection of measuring transducers without separate power supply (sensors in two-wire version).
•In passive mode the sensors are not powered, only the measured value is transmitted. This input is for connection of transmitters with their own separate voltage supply (sensors in four-wire version). The VEGAMET 841 can also be looped into the existing circuit like a normal ammeter.
Note:
With a VEGAMET 841 in Ex version, the passive input is not available.
5.3Connecting
Connection technology The voltage supply and inputs and outputs are connected via the spring-loaded terminals.
Information:
Solid cores as well as flexible cores with wire end sleeves are
inserted directly into the terminal openings.In case of flexible cores without end sleeves, a small screwdriver must be pressed into the rectangular opening so that the terminal opening is then free. When the screwdriver is pulled out, the terminals are closed again.
You can find further information on the max.wire cross-section in the technical data.
Connecting |
Connect the device as described in the following wiring plan. |
<![endif]>210225-EN-58864
16 |
VEGAMET 841 • 4 … 20 mA |
<![endif]>58864-EN-210225
5 Connecting to power supply
|
|
Relay Output |
Current |
|
|
|
||
Power |
1 |
2 |
3 |
Output |
Sensor |
|||
91 92 |
61 62 63 64 65 66 67 68 69 |
41 42 |
1 |
2 |
3 |
|||
+ |
- |
|
|
|
+ - |
|
|
|
L |
N |
|
|
|
|
|
|
|
|
1 |
|
2 |
|
3 |
|
4 |
|
|
5 |
|
|
|
|
|
|
|
Fig. 6: Wiring plan VEGAMET 841
1Voltage supply of the controller
2Relay outputs 1 … 3
3Current output
4Sensor input (active/passive) with HART communication sockets
5Ground terminal for protective conductor
Detail sensor connection 1
|
1 |
2 |
3 |
6 |
1 |
2 |
3 |
|
|
1 |
|
|
|
|
|
|
2 |
3 |
+ |
|
- |
|
|
+ |
- |
4 |
|
|
|
|
|
|
|
|
5 |
Fig. 7: Sensor input 1 for two-wire/four-wire sensor (active/passive)
1Active input with sensor supply for two-wire sensor
2Passive input without sensor supply for four-wire sensor 2)
3Two-wire sensor
4Four-wire sensor
5Voltage supply for four-wire sensor
6HART communication sockets for connection of a VEGACONNECT
5.5Switch-on phase
After switching on, the device first carries out a short self-check.
•Internal check of the electronics
•Output signals are set to failure, background lighting of the display lights red
2) Passive input not available for Ex version
VEGAMET 841 • 4 … 20 mA |
17 |
5 Connecting to power supply
The current measured values are then displayed and transmitted to the outputs. The background lighting of the display changes to white.
<![if ! IE]><![endif]>210225-EN-58864
18 |
VEGAMET 841 • 4 … 20 mA |
<![endif]>58864-EN-210225
|
|
|
6 |
Access protection |
|
|
|
|
6.1 |
Bluetooth radio interface |
|
|
|
|
|
Devices with a Bluetooth radio interface are protected against un- |
|
|
|
|
|
wanted access from outside. This means that only authorized persons |
|
|
|
|
|
can receive measured and status values and change device settings |
|
|
|
|
|
via this interface. |
|
|
|
|
|
Information: |
|
|
|
|
|
If no Bluetooth connection to the device should be possible, Bluetooth |
|
|
|
|
|
communication can be deactivated. Access via app or DTM is thus no |
|
|
|
|
|
||
|
|
|
|
longer possible. The Bluetooth function can be deactivated/activated |
|
|
|
|
|
in the menu item " Extended functions" under " Access protection - |
|
|
|
|
|
Bluetooth communication". |
|
Bluetooth access code |
|
A Bluetooth access code is required to establish Bluetooth com- |
|||
|
|
|
|
munication via the adjustment tool (smartphone/tablet/notebook). |
|
|
|
|
|
This code must be entered once when Bluetooth communication is |
|
|
|
|
|
established for the first time in the adjustment tool.It is then stored in |
|
|
|
|
|
the adjustment tool and does not have to be entered again. |
|
|
|
|
|
The Bluetooth access code is individual for each device. It is printed |
|
|
|
|
|
on the device housing and is also supplied with the device in the |
|
|
|
|
|
information sheet " PINs and Codes". The Bluetooth access code can |
|
|
|
|
|
also be read out via the display and adjustment unit. |
|
|
|
|
|
The Bluetooth access code can be changed by the user after the first |
|
|
|
|
|
connection is established. If the Bluetooth access code is entered |
|
|
|
|
|
incorrectly, the new entry is only possible after a waiting period has |
|
|
|
|
|
elapsed. The waiting time increases with each further incorrect entry. |
|
Emergency Bluetooth |
|
The emergency Bluetooth access code enables Bluetooth communi- |
|||
unlock code |
|
cation to be established in the event that the Bluetooth access code |
|||
|
|
|
|
is no longer known. It can't be changed. The emergency Bluetooth |
|
|
|
|
|
access code can be found in information sheet " Access protection". |
|
|
|
|
|
If this document is lost, the emergency Bluetooth access code can |
|
|
|
|
|
be retrieved from your personal contact person after legitimation. |
|
|
|
|
|
The storage and transmission of Bluetooth access codes is always |
|
|
|
|
|
encrypted (SHA 256 algorithm). |
|
|
|
|
|
6.2 Protection of the parameterization |
|
|
|
|
|
The settings (parameters) of the device can be protected against un- |
|
|
|
|
|
wanted changes. The parameter protection is deactivated on delivery, |
|
|
|
|
|
all settings can be made. |
|
Device code |
|
To protect the parameterization, the device can be locked by the user |
|||
|
|
|
|
with the aid of a freely selectable device code. The settings (param- |
|
|
|
|
|
eters) can then only be read out, but not changed. The device code |
|
|
|
|
|
is also stored in the adjustment tool. However, unlike the Bluetooth |
|
|
|
|
|
access code, it must be re-entered for each unlock. When using the |
|
|
|
|
|
adjustment app or DTM, the stored device code is then suggested to |
|
|
|
|
|
the user for unlocking. |
|
|
|
|
|
|
|
VEGAMET 841 • 4 … 20 mA |
|
|
19 |
6 Access protection
Emergency device code The emergency device code allows unlocking the device in case the device code is no longer known. It can't be changed. The emergency device code can also be found on the supplied information sheet " Access protection". If this document is lost, the emergency device code can be retrieved from your personal contact person after legitimation. The storage and transmission of the device codes is always encrypted (SHA 256 algorithm).
If the user has a " myVEGA" account, then the Bluetooth access code as well as the device code are additionally stored in his account under " PINs and Codes".This greatly simplifies the use of additional adjustment tools, as all Bluetooth access and device codes are automatically synchronized when connected to the " myVEGA" account
<![if ! IE]><![endif]>210225-EN-58864
20 |
VEGAMET 841 • 4 … 20 mA |
|
7 Set up with the integrated display and adjustment unit |
|
|
7 Set up with the integrated display and |
|
|
adjustment unit |
|
|
7.1 Adjustment system |
|
Function |
The integrated display and adjustment unit is used for measured val- |
|
|
ue display, adjustment and diagnosis of the VEGAMET 841. Display |
|
|
and adjustment are carried out via four keys and a graphic-capable |
|
|
display with background lighting. |
|
|
Certain setting options are not possible or only possible to a limited |
|
|
extent with the integrated display and adjustment unit, for example the |
|
|
settings for flow measurement or pump control.For these applica- |
|
|
tions, the use of PACTware/DTM or the VEGA Tools app is recom- |
|
|
mended. A tabular overview of the corresponding applications and |
|
Display and adjustment |
functions can be found in the appendix. |
|
|
|
|
elements |
|
|
|
1 |
3 |
|
|
|
|
|
4 |
|
2 |
5 |
|
|
<![endif]>58864-EN-210225
HART communication sockets
Key functions
Fig. 8: Display and adjustment elements
1LC display
2Adjustment keys
3Status indication relay
4Status indication fault signal
5Status indication operation
Via the HART communication sockets integrated in the terminals, a parameter adjustment of the connected HART sensors can be carried out without interrupting the measuring circuit. The resistor required for this purpose (230 Ω) is already integrated inVEGAMET 841.The sockets have an inner diameter of 2 mm for direct connection of a VEGACONNECT or other HART modems. The adjustment of the connected sensor is carried out via the VEGA Tools app or via PACTware and appropriate DTM.
Key |
Function |
[OK] |
Entry to the menu level |
|
Jump to selected menu item |
|
Edit parameter |
|
Save value |
VEGAMET 841 • 4 … 20 mA |
21 |
