Ope
rating Instructions
VEGAPULS 61
Foundation F
ieldbus
Document ID:
28449
R
adar
Contents
Conten
1 About this document
2 For your safety
3 Product description
4 Mounting
ts
1.1 Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Target group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Symbolism used . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Authorised personnel . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Appropriate use . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Warning about misuse . . . . . . . . . . . . . . . . . . . . . . .
2.4 General safety instructions . . . . . . . . . . . . . . . . . . . .
2.5 Safety label on the instrument . . . . . . . . . . . . . . . . . .
2.6 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.7 Fulfillment of NAMUR recommendations . . . . . . . . . .
2.8 FCC/IC conformity (only for USA/Canada) . . . . . . . . .
2.9 Safety instructions for Ex areas . . . . . . . . . . . . . . . . .
2.10 Environmental instructions. . . . . . . . . . . . . . . . . . . . .
3.1 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Principle of operation . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Packaging, transport and storage . . . . . . . . . . . . . . .
4.1 General instructions . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Mounting preparations, mounting strap. . . . . . . . . . . .
4.3 Mounting instructions . . . . . . . . . . . . . . . . . . . . . . . .
4
4
4
5
5
5
5
6
6
6
6
7
7
8
10
11
11
12
14
15
5 Connecting to power supply
5.1 Preparing the connection . . . . . . . . . . . . . . . . . . . . .
5.2 Connection procedure. . . . . . . . . . . . . . . . . . . . . . . .
5.3 Wiring plan, single chamber housing . . . . . . . . . . . . .
5.4 Wiring plan, double chamber housing . . . . . . . . . . . .
5.5 Wiring plan with double chamber housing Ex d . . . . .
5.6 Wiring plan - version IP 66/IP 68, 1 bar . . . . . . . . . . .
5.7 Switch on phase. . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Set up with the indicating and adjustment module P LICSCOM
6.1 Short description . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2 Insert indicating and adjustment module. . . . . . . . . . .
6.3 Adjustment system . . . . . . . . . . . . . . . . . . . . . . . . . .
6.4 Setup procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.5 Menu schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.6 Saving the parameter adjustment data . . . . . . . . . . . .
7 Setup with PACTware and other adjustment programs
7.1 Connecting the PC . . . . . . . . . . . . . . . . . . . . . . . . . .
2 VE
24
25
26
28
30
33
33
34
34
36
37
43
45
46
GAPULS 61 • Foundation Fieldbus
28449-EN-100426
Contents
7.2 Para
meter adjustment with PACTware . . . . . . . . . . . .
7.3 Parameter adjustment with AMS™ . . . . . . . . . . . . . .
7.4 Saving the parameter adjustment data . . . . . . . . . . . .
8 Maintenance and fault rectification
8.1 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.2 Rectify malfunctions . . . . . . . . . . . . . . . . . . . . . . . . .
8.3 Exchanging the electronics module . . . . . . . . . . . . . .
8.4 Software update . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8.5 Instrument repair . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Dismounting
9.1 Dismounting steps . . . . . . . . . . . . . . . . . . . . . . . . . .
9.2 Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10 Supplement
10.1 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
10.2 Foundation Fieldbus . . . . . . . . . . . . . . . . . . . . . . . . .
10.3 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
47
47
47
48
48
50
51
51
53
53
54
61
66
28449-EN-100426
VEGAPULS 61 • Foun
Supplementary documentation
tion:
Informa
Supplementary documents appropriate to the ordered version come
with the delivery. You can find them listed in chapter "Product
description".
Instructions manuals for accessories and replacement parts
p:
Ti
To ensure reliable setup and operation of your VEGAPULS 61, we
offer accessories and replacement parts. The corresponding documentations are:
l 27835 - Indicating and adjustment module PLICSCOM
l 32628 - Interface adapter VEGACONNECT
l 27720 - External indication VEGADIS 61
l 34296 - Protective cover
l 30176 - Electronics module VEGAPULS series 60
dation Fieldbus 3
1 Abou
t this document
1 Abou
t this document
1.1 Function
This operating instructions manual provides all the information you
need for mounting, connection and setup as well as important
instructions for maintenance and fault rectification. Please read this
information before putting the instrument into operation and keep this
manual accessible in the immediate vicinity of the device.
1.2 Target group
This operating instructions manual is directed to trained qualified
personnel. The contents of this manual should be made available to
these personnel and put into practice by them.
1.3 Symbolism used
Inform
ation, tip, note
This symbol indicates helpful additional information.
Cauti
on: If this warning is ignored, faults or malfunctions can
result.
Warning: If this warning is ignored, injury to persons and/or serious
damage to the instrument can result.
Danger: If this warning is ignored, serious injury to persons and/or
destruction of the instrument can result.
applications
Ex
This symbol indicates special instructions for Ex applications.
l List
The dot set in front indicates a list with no implied sequence.
à Action
Th
is arrow indicates a single action.
1 Sequence
Numbers set in front indicate successive steps in a procedure.
4 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
your safety
2 For
or your safety
2 F
2.1 Authorised personnel
All operations described in this operating instructions manual must be
carried out only by trained specialist personnel authorised by the plant
operator.
During work on and with the device the required personal protective
equipment must always be worn.
2.2 Appropriate use
VEGAPULS 61 is a sensor for continuous level measurement.
You can find detailed information on the application range in chapter
"Product description".
Operational reliability is ensured only if the instrument is properly used
according to the specifications in the operating instructions manual as
well as possible supplementary instructions.
For safety and warranty reasons, any invasive work on t he device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbitrary
conversions or modifications are explicitly forbidden.
2.3 Warning about misuse
Inappropriate or incorrect use of the instrument can give rise to
application-specific hazards, e.g. vessel overfill or damage to system
components through incorrect mounting or adjustment.
28449-EN-100426
VEGAPULS 61 • Foun
2.4 General safety instructions
This is a high-tech instrument requiring the strict observance of
standard regulations and guidelines. The user must take note of the
safety instructions in this operating instructions manual, the countryspecific installation standards as well as all prevailing safety
regulations and accident prevention rules.
Depending on the model, the emitting frequencies of all radar sensors
are either in the C or K band range. The low transmitting power lies far
below the internationally permitted limit values. When the instrument is
used correctly, it presents no danger to human health. It may be
operated without restriction outside of closed metallic vessels.
The instrument must only be operated in a technically flawless and
reliable condition. The operator is responsible for trouble-free
operation of the instrument.
dation Fieldbus 5
2 For
your safety
the entire duration of use, the user is obliged to determine the
During
compliance of the necessary occupational safety measures with the
current valid rules and regulations and also take note of new
regulations.
2.5 Safety label on the instrument
The safety approval markings and safety tips on the device must be
observed.
2.6 CE conformity
This device fulfills the legal requirements of the applicable EC
guidelines. By attaching the CE mark, VEGA provides a confirmation
of successful testing. You can find the CE conformity declaration in the
download area of
www.vega.com.
2.7 Fulfillmen
With respect to compatibility, the NAMUR recommendation NE 53 is
fulfilled. This applies also to the corresponding indicating and
adjustment components. VEGA instruments are generally upward and
downward compatible.
l Sensor software to DTM VEGAPULS 61
l DTM VEGAPULS 61 for adjustment software PACTware
l Indicating and adjustment module for sensor software
The parameter adjustment of the basic sensor functions is independent of the software version. The range of available functions depends
on the respective software version of the individual components.
t of NAMUR recommendations
2.8 FCC/IC conformity (only for USA/Canada)
VEGAPULS sensors with all antenna versions are FCC/IC approved.
Modifications not expressly approved by VEGA will lead to expiry of
the operating licence as per FCC/IC.
VEGAPULS 61 is in conformity with part 15 of the FCC directives and
fulfills the RSS-210 regulations. Note the corresponding regulations for
operation:
l The instrument must not cause any interfering emissions
l The device must be insensitive to interfering immissions, including
those that may cause undesirable operating conditions.
According to chapter "Dimensions" of this operating instructions
manual, the instrument is designed for operation with an antenna with
a max. amplification of 33 dB. The instrument must not be operated
with antennas not listed therein or those having an amplification of
more than 33 dB. The required antenna impedance is 50 Ω.
28449-EN-100426
6 VE
GAPULS 61 • Foundation Fieldbus
2 For
your safety
2.9 Safety
Please note the Ex-specific safety information for installation and
operation in Ex areas. These safety instructions are part of the
operating instructions manual and come with the Ex-approved
instruments.
instructions for Ex areas
2.10 Environmental instructions
Protection of the environment is one of our most important duties. That
is why we have introduced an environment management system with
the goal of continuously improving company environmental protection.
The environment management system is certified according to DIN
EN ISO 14001.
Please help us fulfil this obligation by observing the environmental
instructions in this manual:
l Chapter "Packaging, transport and storage"
l Chapter "Disposal"
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 7
3 Produc
t description
Versions
Scope of delivery
3 Produc
t description
3.1 Configuration
The VEGAPULS 61 radar sensor is available in two electronics
versions:
l Standard electronics type PS60KF
l Electronics with increased sensitivity type PS60KL
The respective version can be determined by means of the type label
on the electronics.
The electronics version influences the CE conformity, the factory
setting for the medium selection and vessel form, the accuracy as well
as the approvals of VEGAPULS 61. The differences are listed in the
respective sections of this operating instructions manual.
The scope of delivery encompasses:
l VEGAPULS 61 radar sensor
l Documentation
- this operating instructions manual
- Operating instructions manual 27835 "Indicating and adjust-
ment module PLICSCOM" (optional)
- Supplementary instructions manual 31708 "Heating for in-
dicating and adjustment module" (optional)
- Supplementary instructions manual "Plug connector for con-
tinuously measuring sensors" (optional)
- Ex-specific "Safety instructions" (with Ex versions)
- if necessary, further certificates
Components
8 VE
The VEGAPULS 61 consists of the components:
l Process fitting with encapsulated antenna system
l Housing with electronics, optionally available with plug connector,
optionally available with connection cable
l Housing cover, optionally available with indicating and adjustment
module PLICSCOM
The components are available in different versions.
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
3
2
1
3
4
2
1
3 Produc
t description
Fig. 1: VEGAPULS 61 - threaded
plastic housing
1 Housing cover with integrated PLICSCOM (optional)
2 Housing with electronics
3 Process fitting with encapsulated antenna system
Fig. 2: VEGAPULS 61 - threaded
housing
1 Housing cover with integrated PLICSCOM (optional)
2 Housing with electronics
3 Process fitting with plastic horn antenna
version with encapsulated antenna system and
version with plastic horn antenna and plastic
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 9
3 Produc
t description
Application area
Functional principle
Power supply and bus
communication
DD/CFF
3.2 Princi
ple of operation
VEGAPULS 61 is a radar sensor in K-band (emitting frequency
approx. 26 GHz) for continuous level measurement.
The version with encapsulated antenna system is particularly
suitable for level measurement of aggressive liquids in small vessels.
The version with plastic horn antenna is particularly suitable for flow
measurement in open flumes or gauge measurement in bodies of
water.
The electronics with increased sensitivity enables the use of
VEGAPULS 61 also in applications with very poor reflective properties
or products with low ε
value.
r
The antenna of the radar sensor emits short radar pulses with a
duration of approx. 1 ns. These pulses are reflected by the product
and received by the antenna as echoes. The running time of the radar
pulses from emission to reception is proportional to the distance and
hence to the level. The determined level is converted into an
appropriate output signal and outputted as measured value.
Power is supplied via the H1 Fieldbus. A two-wire cable according to
Fieldbus specification serves as carrier of both power and digital data
for multiple sensors. This cable can be operated in two versions:
l via an H1 interface card in the control system and additional power
supply
l via a Linking device with HSE (High speed Ethernet) and
additional power supply according to IEC 61158-2
The DD (Device Descriptions) and CFF (capability files) necessary for
planning and configuration of your FF (Foundation Fieldbus) communication network are available in the download area of the VEGA
homepage
www.vega.co
m under "Services - Downloads - Software -
Foundation Fieldbus". The appropriate certificates are also available
there. A CD with the appropriate files and certificates can be ordered
via e-mail under info@de.vega.com or by phone from one of the VEGA
agencies under the order number "DRIVER.S".
The backlight of the indicating and adjustment module is powered by
the sensor. Prerequisite is a certain level of operating voltage.
The data for power supply are specified in chapter "Technical data".
The optional heating requires its own operating voltage. You can find
detailed information in the supplementary instructions manual "Heating
for indicating and adjustment module". This function is generally not
available for approved instruments.
28449-EN-100426
10 VE
GAPULS 61 • Foundation Fieldbus
3 Produc
t description
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature
3.3 Operatio
n
VEGAPULS 61 can be adjusted with different adjustment media:
l with indicating and adjustment module
l with the suitable VEGA DTM in conjunction with an adjustment
software according to the FDT/DTM standard, e.g. PACTware and
PC
l a configuration tool
3.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
according to DIN EN 24180.
The packaging of standard instruments consists of environmentfriendly, recyclable cardboard. For special versions, PE foam or PE foil
is also used. Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out under consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or
concealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
l Not in the open
l Dry and dust free
l Not exposed to corrosive media
l Protected against solar radiation
l Avoiding mechanical shock and vibration
l Storage and transport temperature see chapter "Supplement -
Technical data - Ambient conditions"
l Relative humidity 20 … 85 %
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 11
4 M
ounting
Mounting position
Screwing in
Moisture
4 Moun
ting
4.1 General instructions
Select an installation position you can easily reach for mounting and
connecting as well as later retrofitting of an indicating and adjustment
module. The housing can be rotated by 330° without the use of any
tools. You can also install the indicating and adjustment module in four
different positions (each displaced by 90°).
War
ning:
With threaded versions, the housing must not be used to screw in the
instrument! Applying tightening forces on the housing can damage its
internal parts.
Use the recommended cables (see chapter "Connecting to power
supply") and tighten the cable gland.
You can give your instrument additional protection against moisture
penetration by leading the connection cable downward in front of the
cable entry. Rain and condensation water can thus drain off. This
applies mainly to outdoor mounting as well as installation in areas
where high humidity is expected (e.g. through cleaning processes) or
on cooled or heated vessels.
Fig. 3: Measures
Measuring range
12 VE
The reference plane for the measuring range of the sensor depends on
the antenna version.
With encapsulated antenna system, the reference plane is the seal
surface of the thread.
against moisture penetration
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
1 3
4
2
100%
0%
4 M
ounting
Polarisation plane
Fig. 4: Measuring
encapsulated antenna system
1 full
2 empty (max. measuring distance)
3 Measuring range
4 Reference plane
range (operating range) and max. measuring distance with
With the Plastic horn antenna, the reference plane is the contact
surface on the side of the focusing lens. With the version with adapter
flange, the reference plane is the lower side of the flange.
Informa
tion:
If the medium reaches the antenna, buildup can form on it and cause
faulty measurements later on.
The emitted radar pulses of VEGAPULS 61 are electromagnetic
waves. The polarisation plane is the direction of the electrical wave
component. Its position is marked on the instrument.
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 13
1
1
4 M
ounting
Suitability for the process conditions
Fig. 5: Position
antenna system
1 Marking hole
Fig. 6: Position
antenna
1 Marking bars
of the polarisation plane with VEGAPULS 61 with encapsulated
of the polarisation plane with VEGAPULS 61 with plastic horn
Make sure that all parts of the instrument exposed to the process, in
particular the sensor element, process seal and process fitting, are
suitable for the existing process conditions. These include above all
the process pressure, process temperature as well as the chemical
properties of the medium.
You can find the specifications in chapter "Technical data" or on the
type label.
4.2 Mounting preparations, mounting strap
The optionally available mounting strap is used to fasten the radar
14 VE
sensor over open vessels or flumes. It is suitable for mounting on
walls, ceilings or brackets. The strap is supplied unassembled and
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
> 200 mm
(7.87
")
4 M
ounting
Mounting position
must be screwed to the sensor with the three hexagon socket screws
M5 x 10 and
spring washers before setup. Max. torque see chapter
"Technical data". Necessary tools: Allen wrench size 4.
Screwing on is possible in two ways. Depending on the selected
version, the sensors can be swivelled in the strap as follows:
l Single chamber housing
- 180° infinitely variable
- in three steps 0°, 90° and 180°
l Double chamber housing
- 90° infinitely variable
- in two steps 0° and 90°
4.3 Mounting instructions
When mounting the sensor, keep a distance of at least 200 mm
(7.874 in) from the vessel wall. If the sensor is installed in the center of
dished or round vessel tops, multiple echoes can arise. These can,
however, be suppressed by an appropriate adjustment (see chapter
"Setup").
If you cannot keep this distance you should carry out a false echo
storage before setup. This applies mainly if buildup on the vessel wall
is expected. In this case, we recommend repeating a false echo
storage later with existing buildup.
28449-EN-100426
VEGAPULS 61 • Foun
Fig. 7: Mounting
1 Reference plane
2 Vessel center or symmetry axis
on round vessel tops
dation Fieldbus 15
4 M
ounting
vessels with conical bottom it can be advantageous to mount the
In
sensor in the center of the vessel, as measurement is then possible
down to the lowest point of the vessel bottom.
Inflowing medium
Socket
Fig. 8: Vessel
with conical bottom
Do not mount the instruments in or above the filling stream. Make sure
that you detect the product surface, not the inflowing product.
Fig. 9: Inflowing
liquid
The socket piece should be dimensioned in such a way that the
antenna end protrudes at least 10 mm (0.4 in) out of the socket.
28449-EN-100426
16 VE
GAPULS 61 • Foundation Fieldbus
ca. 10 mm
d
h
d
h
1½"
50 mm/2"
80 mm/3"
100 mm/4"
150 mm/6"
200 mm
250 mm
300 mm
500 mm
800 mm
4 M
ounting
Orientation of the sensor
Fig. 10: Recommended
socket mounting
If the reflective properties of the medium are good, you can mount
VEGAPULS 61 on sockets which are higher than the length of the
antenna. You will find recommended values for socket heights in the
following illustration. The socket end should be smooth and burr-free, if
possible also rounded. After installation you must carry out a false
echo storage.
Fig. 11: Deviating
socket dimensions
In liquids, align the sensor as vertical as possible to the product
surface to achieve optimum measuring results.
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 17
4 M
ounting
Vessel installations
Agitators
Fig. 12: Alignment
in liquids
The mounting location of the radar sensor should be a place where no
other equipment or fixtures cross the path of the microwave signals.
Vessel installations such as for example, ladders, limit switches,
heating spirals, struts etc. can cause false echoes that interfere with
the useful echo. Make sure when planning your measuring site that the
radar signals have a "clear view" to the measured product.
In case of existing vessel installations, a false echo storage should be
carried out during setup.
If large vessel installations such as struts or supports cause false
echoes, these can be attenuated through supplementary measures.
Small, inclined sheet metal baffles above the installations scatter the
radar signals and prevent direct interfering reflections.
Fig. 13: Cover
smooth profiles with deflectors
If there are agitators in the vessel, a false echo storage should be
carried out with the agitators in motion. This ensures that the interfering
reflections from the agitators are saved with t he blades in different
positions.
18 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
Fig. 14: Agitators
4 M
ounting
Foam generation
Measurement in the
standpipe (surge or bypass tube)
Th
rough the action of filling, stirring and other processes in the vessel,
dense foams which considerably damp the emitted signals may form
on the product surface.
If foams lead to measurement errors, you should use the biggest
possible radar antennas and low frequency radar sensors (C-band).
As an alternative, sensors with guided microwave can be used. These
are unaffected by foam generation and are best suited for such
applications.
By using a standpipe, the influence of vessel installations and
turbulence can be excluded. Under these prerequisites, the measurement of products with low dielectric values (from DK value 1.6) is
possible.
Note:
rement in a standpipe is not recommended for very adhesive
Measu
products.
Surge or bypass tubes must extend all the way down to the requested
min. level, as measurement is only possible within the tube.
Surge pipe
Make sure you provide the necessary upper vent hole in the surge
pipe. The hole must be aligned so that it and the polarisation marking
on the sensor are in the same plane (see illustration: "Pipe antenna
system in a tank").
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 19
max.
min.
2
1
4 M
ounting
Fig. 15: Pipe
in one plane with the polarisation marking on the sensor.
1 Marking of the polarisation direction
2 Vent hole max. ø 5 mm (0.2 in)
antenna system in a tank. The vent hole in the surge pipe must be
If possible, the antenna diameter of the sensor should correspond to
the inner diameter of the tube. With VEGAPULS 61 this is approx.
40 mm (1.575 in). The sensor can be used with tube diameters
between 40 … 80 mm (1.575 … 3.15 in).
Bypass tube
As an alternative to the surge pipe in the vessel, a tube system outside
of the vessel is possible as a bypass tube. Select during setup the
function "Bypass tube".
Align the sensor in such a way that the polarisation marking on the
process fitting is in the same plane as the tube holes or the tube
connection openings (see illustration: "VEGAPULS in a bypass tube").
28449-EN-100426
20 VE
GAPULS 61 • Foundation Fieldbus
100%
0%
1
> 500 mm
4 M
ounting
Flow measurement
Fig. 16: VEGAPULS 61 in
process fitting must be in one plane with the tube holes or the tube connection
openings.
1 Marking of the polarisation direction
a bypass tube. The polarisation marking on the
When the sensor is mounted on a bypass tube, the distance from
VEGAPULS 61 to the upper tube connection should be approx.
500 mm (19.69 in) or more. In case of extremely rough tube inner
walls, you should use an inserted tube (tube in tube) or a radar sensor
with tube antenna.
The short examples are meant to give only introductory information on
the flow measurement. Planning information is available from flume
manufacturers and in special literature.
Meas. wall with rectangular flume
In general, the following points must be observed:
l Install the sensor on the headwater side
l Installation in the centre of the flume and vertical to the liquid
surface
l Distance to the overfall orifice
l Distance of orifice opening above ground
l Min. distance of the orifice opening to bottom water
l Min. distance of the sensor to max. storage level
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 21
h
max
d
min
≥ 2 mm x h
max
90°
4
3 ... 4 h
max
≥ 50 mm
90
°
2 3
1
2
3 ... 4 x h
max
90°
h
max
d
1
B
4 M
ounting
Fig. 17: Flow
sensor; h
measurement with rectangular flume: d = min. distance of the
= max. filling of the rectangular flume
max.
1 Overflow orifice (side view)
2 Headwater
3 Tail water
4 Overfall orifice (view from bottom water)
Khafagi-Venturi flume
In general, the following points must be observed:
l Installation of the sensor at the inlet side
l Installation in the centre of the flume and vertical to the liquid
surface
l Distance to the Venturi flume
l Min. distance of the sensor to max. storage level
22 VE
Fig. 18: Flow
sensor; h
1 Position sensor
2 Venturi flume
measurement with Khafagi-Venturi flume: d = Min. distance to
= max. filling of the flume; B = tightest constriction in the flume
max.
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
4 M
ounting
Gauge measurement
general, the following points must be observed:
In
l Installation of the sensor in a protected area
l Installation vertical to the liquid surface
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 23
ecting to power supply
5 Conn
Safety instructions
Voltage supply
Connection cable
5 Conn
ecting to power supply
5.1 Preparing the connection
Always keep in mind the following safety instructions:
l Connect only in the complete absence of line voltage
l If overvoltage surges are expected, overvoltage arresters should
be installed according to Foundation Fieldbus specification.
Ti
p:
We recommend VEGA overvoltage arrester B63-32.
In
hazardous areas you should take note of the appropriate regulations,
conformity and type approval certificates of the sensors and power
supply units.
The instrument requires a operating voltage of 9 … 32 V DC.
Operating voltage and the digital bus signal are carried on the same
two-wire connection cable. Power is supplied via the H1 power supply.
Connection is carried out with screened cable according to Fieldbus
specification.
Use cable with round cross-section. A cable outer diameter of 5 … 9 mm
(0.2 … 0.35 in) ensures the seal effect of the cable gland. If you are
using cable with a different diameter or cross-section, exchange the
seal or use a suitable cable gland.
Make sure that the entire installation is carried out according to the
Fieldbus specification. In particular, make sure that the termination of
the bus is done with appropriate terminating resistors.
Cable gland ½ NPT
Cable screening and
grounding
24 VE
On the instrument with cable entry ½ NPT and plastic housing there is
a metallic ½" threaded insert moulded into the plastic housing.
Caution:
grease should be used when screwing the NPT cable gland or
No
steel tube into the threaded insert. Standard grease can contain
additives that corrode the connection between threaded insert and
housing. This would influence the stability of the connection and the
tightness of the housing.
In systems with p otential equalisation, connect the cable screen
directly to ground potential at the power supply unit, in the connection
box and at the sensor. The screen in the sensor must be connected
directly to the internal ground terminal. The ground terminal outside on
the housing must be connected to the potential equalisation (low
impedance).
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
ecting to power supply
5 Conn
systems without potential equalisation, connect the cable screen
In
directly to ground potential at the power supply unit and at the sensor.
In the connection box or T-distributor, the screen of the short stub to
the sensor must not be connected to ground potential or to another
cable screen. The cable screens to the power supply unit and to the
next distributor must be connected to each other and also connected
to ground potential via a ceramic capacitor (e.g. 1 nF, 1500 V). The low
frequency potential equalisation currents are thus suppressed, but the
protective effect against high frequency interference signals remains.
Th
e total capacitance of the cable and of all capacitors must not exceed
10 nF in Ex applications.
Ta
ke note of the corresponding installation regulations for Ex
applications. In particular, make sure that no potential equalisation
currents flow over the cable screen. In case of grounding on both sides
this can be achieved by the use of a capacitor or a separate potential
equalisation.
5.2 Connection procedure
Proceed as follows:
1 Unscrew the housing cover
2 If an indicating and adjustment module is installed, remove it by
turning it slightly to the left.
3 Loosen compression nut of the cable entry
4 Remove approx. 10 cm (4 in) of the cable mantle, strip approx.
1 cm (0.4 in) of insulation from the ends of the individual wires
5 Insert the cable through the cable gland into the sensor
6 Lift the opening levers of the terminals with a screwdriver (see
following illustration)
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 25
ecting to power supply
5 Conn
7 Insert
Fig. 19: Connection
8 Press down the opening levers of the terminals, you will hear the
9 Check the hold of the wires in the terminals by lightly pulling on
10 Connect the screen to the internal ground terminal, connect the
11 Tighten the compression nut of the cable entry. The seal ring must
12 Screw the housing cover on
The electrical connection is finished.
the wire ends into the open terminals according to the wiring
plan
steps 6 and 7
terminal spring closing
them
outer ground terminal with potential equalisation
completely encircle the cable
5.3 Wiring plan, single chamber housing
e following illustrations apply to the non-Ex as well as to the Ex-ia
Th
version.
26 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
5
5
5
5
1 2
4
3
Housing overview
ecting to power supply
5 Conn
Fig. 20: Material
1 Plastic
2 Aluminium
3 Stainless steel, investment casting
4 Stainless steel, electro-polished
5 Filter element for air pressure compensation of all material versions. Blind
stopper with version IP 66/IP 68, 1 bar for Aluminium and stainless steel
versions, single chamber housing
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 27
I²C
3
4
5
1
2
Display
Ty p:
1 2 5 6 7 8
Bus
Sim.
I2C
Display
1
1 2 5
6 7 8
ecting to power supply
5 Conn
Electronics and connection compartment
Wiring plan
Fig. 21: Electronics
1 Plug connector for VEGACONNECT (I²C interface)
2 Spring-loaded terminals for connection of the external indication VEGADIS
61
3 Ground terminal for connection of the cable screen
4 Spring-loaded terminals for Foundation Fieldbus connection
5 Simulation switch ("on" = mode for simulation release)
Fig. 22: Wiring
1 Voltage supply/Signal output
and connection compartment with single chamber housig
plan, single chamber housing
5.4 Wiring plan, double chamber housing
Th
e following illustrations apply to the non-Ex as well as to the Ex-ia
version.
28449-EN-100426
28 VE
GAPULS 61 • Foundation Fieldbus
1 2 3
4
5
I²C
2
3
1
Display
Typ :
1 2 5 6 7 8
Bus
Sim.
Housing overview
ecting to power supply
5 Conn
Electronics compartment
Fig. 23: Double
1 Housing cover, connection compartment
2 Blind stopper or plug M12 x 1 for VEGADIS 61 (optional)
3 Housing cover, electronics compartment
4 Filter element for air pressure compensation
5 Cable gland
Fig. 24: Electronics
1 Simulation switch ("on" = mode for simulation release)
2 Connection for VEGACONNECT (I²C interface)
3 Internal connection cable to the connection compartment
chamber housing
compartment, double chamber housing
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 29
3
1
2
Display
1 2
I²C
I2C
1
1 2
ecting to power supply
5 Conn
Connection compartment
Wiring plan
Fig. 25: Connection
1 Plug connector for VEGACONNECT (I²C interface)
2 Ground terminal for connection of the cable screen
3 Spring-loaded terminals for voltage supply
Fig. 26: Wiring
1 Voltage supply/Signal output
compartment, double chamber housing
plan with double chamber housing
5.5 Wiring plan with double chamber housing Ex d
Informa
tion:
Instruments in Ex d version with hardware revision …- 01 or higher as
well as with national approvals such as e.g. according to FM or CSA at
a later date.
28449-EN-100426
30 VE
GAPULS 61 • Foundation Fieldbus
1 2 3
4
5
I²C
2
3
1
Display
Typ :
1 2 5 6 7 8
Bus
Sim.
Housing overview
ecting to power supply
5 Conn
Electronics compartment
Fig. 27: Double
1 Housing cover, connection compartment
2 Blind stopper or plug M12 x 1 for VEGADIS 61 (optional)
3 Housing cover, electronics compartment
4 Filter element for air pressure compensation
5 Cable gland
Fig. 28: Electronics
1 Simulation switch ("on" = mode for simulation release)
2 Connection for VEGACONNECT (I²C interface)
3 Internal connection cable to the connection compartment
chamber housing
compartment, double chamber housing
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 31
1
2
1 2
1
1 2
ecting to power supply
5 Conn
Connection compartment
Wiring plan
Fig. 29: Connection
1 Spring-loaded terminals for power supply and cable screen
2 Ground terminal for connection of the cable screen
Fig. 30: Wiring
1 Voltage supply/Signal output
compartment double chamber housing Ex d
plan with double chamber housing Ex d
28449-EN-100426
32 VE
GAPULS 61 • Foundation Fieldbus
+
-
1
2
ecting to power supply
5 Conn
Wire assignment, connection cable
Switch on phase
5.6 Wir
Fig. 31: Wire
1 brown (+) and blue (-) to power supply or to the processing system
2 Shielding
ing plan - version IP 66/IP 68, 1 bar
assignment, connection cable
5.7 Switch on phase
After VEGAPULS 61 is connected to voltage supply or after voltage
recurrence, the instrument carries out a self-check for approx. 30
seconds. The following steps are carried out:
l Internal check of the electronics
l Indication of the instrument type, the firmware as well as the
sensor TAGs (sensor designation)
l Status byte goes briefly to fault value
Then the current measured value will be displayed and the
corresponding digital output signal will be outputted to the cable.
1)
28449-EN-100426
VEGAPULS 61 • Foun
1)
The values correspond to the actual measured level as well as to the set-
tings already carried out, e.g. default setting.
dation Fieldbus 33
up with the indicating and adjustment module PLICSCOM
6 Set
Function/Configuration
Mount/Dismount indica-
ting and adjustment module
6 Set
up with the indicating and adjustment
module PLICSCOM
6.1 Short description
The indicating and adjustment module is used for measured value
display, adjustment and diagnosis. It can be mounted in the following
housing versions and instruments:
®
l All sensors of the plics
in the double chamber housing (optionally in the electronics or
connection compartment)
l External indicating and adjustment unit VEGADIS 61
From a hardware version …- 01 or higher of PLICSCOM as well as a
hardware version …- 01, 03 or higher of the corresponding sensor, an
integrated backlight can be switched on via the adjustment menu. The
hardware version is stated on the type label of the PLICSCOM or the
sensor electronics.
Note:
You
can find detailed information on the adjustment in the operating
instructions manual "Indicating and adjustment module".
6.2 Insert indicating and adjustment module
The indicating and adjustment module can be inserted into the sensor
and removed again at any time. It is not necessary to interrupt the
power supply.
Proceed as follows:
1 Unscrew the housing cover
2 Place the indicating and adjustment module in the desired position
on the electronics (you can choose any one of four different
positions - each displaced by 90°)
3 Press the indicating and adjustment module onto the electronics
and turn it to the right until it snaps in.
4 Screw housing cover with inspection window tightly back on
Removal is carried out in reverse order.
The indicating and adjustment module is powered by the sensor, an
additional connection is not necessary.
instrument family, in the single as well as
34 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
up with the indicating and adjustment module PLICSCOM
6 Set
Fig. 32: Insert
indicating and adjustment module
Note:
If
you intend to retrofit the instrument with an indicating and adjustment
module for continuous measured value indication, a higher cover with
an inspection glass is required.
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 35
1.1
2
3
1
up with the indicating and adjustment module PLICSCOM
6 Set
Key functions
Adjustment system
6.3 Adj
Fig. 33: Indicating
1 LC display
2 Indication of the menu item number
3 Adjustment keys
l [OK] key:
ustment system
and adjustment elements
- Move to the menu overview
- Confirm selected menu
- Edit parameter
- Save value
l [->] key to select:
- Menu change
- Select list entry
- Select editing position
l [+] key:
- Change value of the parameter
l [ESC] key:
- interrupt input
- jump to the next higher menu
The sensor is adjusted via the four keys of the indicating and
adjustment module. The LC display indicates the individual menu
items. The functions of the individual keys are shown in the above
illustration. Approx. 10 minutes after the last pressing of a key, an
automatic reset to measured value indication is triggered. Any values
not confirmed with [OK] will not be saved.
28449-EN-100426
36 VE
GAPULS 61 • Foundation Fieldbus
up with the indicating and adjustment module PLICSCOM
6 Set
Switch on phase
Parameter adjustment
6.4 Setup
procedure
After VEGAPULS 61 is connected to voltage supply or after voltage
recurrence, the instrument carries out a self-check for approx. 30
seconds. The following steps are carried out:
l Internal check of the electronics
l Indication of the instrument type, the firmware as well as the
sensor TAGs (sensor designation)
l Status byte goes briefly to fault value
Then the current measured value will be displayed and the
corresponding digital output signal will be outputted to the cable.
2)
As VEGAPULS 61 is a distance measuring instrument, the distance
from the sensor to the product surface is measured. To have the real
product level displayed, an allocation of the measured distance to the
percentage height must be made. To carry out this adjustment, the
distance is entered with full and empty vessel. If these values are not
known, an adjustment with the distance values, e.g. 10 % and 90 % is
also possible. Starting point for these distance specifications is always
the seal surface of the thread or flange. With these settings, the real
level is calculated. Furthermore the operating range of the sensor is
limited from maximum to the required range.
The real product level during this adjustment is not important, because
the min./max. adjustment is always carried out without changing the
product level. These settings can be made ahead of time without the
instrument having to be installed.
Caution:
there is a separation of liquids with different dielectric values in the
If
vessel, e.g. from condensation, VEGAPULS 61 can detect under
certain circumstances only the medium with the higher dielectric value.
Keep in mind that interfaces can cause faulty measurements.
If you want to measure the total height of both liquids reliably, please
contact our service department or use an instrument specially
designed for interface measurement.
Carrying out min. adjustment
28449-EN-100426
VEGAPULS 61 • Foun
In the main menu item "Basic adjustment", the individual submenu
items should be selected one after the other and provided with the
correct parameter values.
Start your parameter adjustment with the following menu items of the
basic adjustment:
Proceed as follows:
2)
The values correspond to the actual measured level as well as to the set-
tings already carried out, e.g. default setting.
dation Fieldbus 37
up with the indicating and adjustment module PLICSCOM
6 Set
e from the measured value display to the main menu by
1 Mov
pushing [OK].
▶
Basic adjustment
Display
Diagnostics
Service
Info
2 Select the menu item "Basic adjustment" with [->] and confirm with
[OK]. Now the menu item "Min. adjustment" is displayed.
Min. adjustment
0.00 %
=
5.000 m(d)
4.000 m(d)
3 Prepare the % value for editing with [OK] and set the cursor to the
requested position with [->]. Set the requested percentage value
with [+] and save with [OK]. The cursor jumps now to the distance
value.
4 Enter the suitable distance value in m for the empty vessel (e.g.
distance from the sensor to the vessel bottom) corresponding to
the percentage value.
5 Save the settings with [OK] and move to "Max. adjustment" with [-
>].
Carrying out max. ad-
Proceed as follows:
justment
Max. adjustment
100.00 %
=
1.000 m(d)
2.000 m(d)
1 Prepare the % value for editing with [OK] and set the cursor to the
requested position with [->]. Set the requested percentage value
with [+] and save with [OK]. The cursor jumps now to the distance
value.
2 Enter the appropriate distance value in m (corresponding to the
percentage value) for the full vessel. Keep in mind that the max.
level must lie below the dead band.
3 Save the settings with [OK] and move to "Medium selection" with
[->].
Medium selection
Each product has different reflective properties. In addition, there are
various interfering factors which have to be taken into account:
agitated product surfaces and foam generation (with liquids); dust
generation, material cones and echoes from the vessel wall (with
solids). To adapt the sensor to these different conditions, you should
first select "Liquid" or "Solid".
38 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
up with the indicating and adjustment module PLICSCOM
6 Set
Medium
Liquid
Informa
tion:
With VEGAPULS 61 with electronics version "Increased safety",
"Solid" is preset as factory setting. However, the instrument should be
used preferably in liquids. In such cases, the medium selection should
be set to "Liquid" during setup.
According to the conductivity and the dielectric value of liquids, the
reflection properties can differ considerably. Therefore additional
options such as "Solvent", "Chem. mixture" and "Water based" are
offered below the menu item Liquid.
With solids, you can also choose between "Powder/Dust", "Granular/
Pellets" or "Ballast/Pebbels".
Through this additional selection, the sensor is adapted perfectly to the
product and measurement reliability, particularly in products with bad
reflective properties, is considerably increased.
Enter the requested parameters via the appropriate keys, save your
settings and jump to the next menu item with the [->] key.
Vessel form
28449-EN-100426
VEGAPULS 61 • Foun
Apart from the medium, the vessel shape can also influence the
measurement. To adapt the sensor to these measuring conditions, this
menu item offers different options depending on whether liquid or bulk
solid is selected. With "Liquids" these are "Storage tank", "Stilling
tube", "Open vessel" or "Stirred vessel", with "Solid", "Silo" or
"Bunker".
Vessel form
Storage tank
tion:
Informa
With VEGAPULS 61 with electronics version "Increased safety",
"Solid" is preset as factory setting. However, the instrument should be
used preferably in liquids. In such cases, the vessel form should be set
to "Storage tank" during setup.
Enter the requested parameters via the appropriate keys, save your
settings and jump to the next menu item with the [->] key.
dation Fieldbus 39
up with the indicating and adjustment module PLICSCOM
6 Set
arization is necessary for all vessels in which the vessel volume
Linearisation curve
A line
does not increase linearly with the level - e.g. with a horizontal
cylindrical or spherical tank - and the indication or output of the volume
is required. Corresponding linearization curves are preprogrammed for
these vessels. They represent the correlation between the level
percentage and vessel volume. By activating the appropriate curve,
the volume percentage of the vessel is displayed correctly. If the
volume should not be displayed in percent but e.g. in l or kg, a scaling
can be also set in the menu item "Display".
Linearisation curve
linear
Enter the requested parameters via the appropriate keys, save your
settings and jump to the next menu item with the [->] key.
Gating out of false signals
High sockets or vessel installations, such as e. g. struts or agitators as
well as buildup and weld joints on the vessel walls cause interfering
reflections which can impair the measurement. A false echo storage
detects and marks these false echoes, so that they are no longer taken
into account for the level measurement. A false echo memory should
be created with low level so that all potential interfering reflections will
be detected.
Gating out of false signals
Change now?
Proceed as follows:
1 Move from the measured value display to the main menu by
pushing [OK].
2 Select the menu item "Service" with [->] and confirm with [OK].
Now the menu item "False signal suppression" is d isplayed.
3 Confirm "False signal suppression - Change now" with [OK] and
select in the below menu "Create new". Enter the actual distance
from the sensor to the product surface. All false signals in this area
are detected by the sensor and saved after confirming with [OK].
Note:
the distance to the product surface, because if an incorrect (too
Check
large) value is entered, the existing level will be saved as false signal.
The filling level would then no longer be detectable in this area.
28449-EN-100426
40 VE
GAPULS 61 • Foundation Fieldbus
Extended setting/Quick
level change
up with the indicating and adjustment module PLICSCOM
6 Set
e menu item "Extended setting" offers the possibility to optimise
Th
VEGAPULS 61 for applications in which the level changes very
quickly. For this reason, select the function "Quick level change > 1 m/
min.".
Extended setting
quick level change > 1 m/min.
Note:
Since
with the function "Quick level change > 1 m/min." the generation
of an average value of the signal processing is considerably reduced,
false reflections by agitators or vessel installations can cause
measured value fluctuations. A false echo memory is thus recommended.
Copy sensor data
Reset
This function enables reading out parameter adjustment data as well
as writing parameter adjustment data into the sensor via the indicating
and adjustment module. A description of the function is available in the
operating instructions manual "Indicating and adjustment module".
The following data are read out or written with this function:
l Measured value presentation
l Adjustment
l Medium
l Standpipe inner diameter
l Vessel form
l Damping
l Linearisation curve
l Sensor-TAG
l Displayed value
l Unit of measurement
l Language
3)
The following safety-relevant data are not read out or written:
l PIN
Copy sensor data
Copy sensor data?
Basic adjustment
If the "Reset" is carried out, the sensor resets the values of the
following menu items to the reset values (see chart):
4)
28449-EN-100426
VEGAPULS 61 • Foun
3)
With standpipe versions.
4)
Sensor-specific basic adjustment.
dation Fieldbus 41
up with the indicating and adjustment module PLICSCOM
6 Set
Function Reset
Max. adjustment 0 m(d)
Min. adjustment 30 m(d) (VEGAPULS 61, 63, 65)
Medium Liquid
Vessel form not known
Damping 0 s
Linearisation linear
Sensor-TAG Sensor
Displayed value AI-Out
Extended settings None
Unit of measurement m(d)
value
35 m(d) (VEGAPULS 62, 66)
70 m(d) (VEGAPULS 68)
The values of the following menu items are not reset to the reset
values (see chart) with "Reset":
Function Reset value
Language no reset
Factory setting
Like basic adjustment, in addition, special parameters are reset to
default values.
5)
Pointer
The min. and max. distance values are reset to the actual value.
Optional settings
Additional adjustment and diagnosis options such as e.g. scaling,
simulation or trend curve presentation are shown in the following menu
schematic. You will find a detailed description of these menu items in
the operating instructions manual "Indicating and adjustment module".
5)
Special parameters are parameters which are set customer-specifically on
the service level with the adjustment software PACTware.
42 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
up with the indicating and adjustment module PLICSCOM
6 Set
Basic adjustment
▶
Basic adjustment
Display
Diagnostics
Service
Info
Min. adjustment
0.00 %
=
30.000 m(d)
0.665 m(d)
Damping
0 s
Display
Basic adjustment
▶
Display
Diagnostics
Service
Info
1.1
1.5
6.5 Menu
schematic
Information:
Depending on the version and application, the light-coloured menu
windows are not always available or offer nor selection possibility.
1
2
Max. adjustment
100.00 %
=
0.000 m(d)
0.665 m(d)
Linearisation curve
linear
▼
1.2
1.6
Medium
Liquid
▼
not known
Sensor-TAG
1.3
▼
1.7
Sensor
Vessel form
not known
1.4
▼
Displayed value
AI-Out
28449-EN-100426
VEGAPULS 61 • Foun
2.1
Lighting
Switched off
2.4
▼
dation Fieldbus 43
up with the indicating and adjustment module PLICSCOM
6 Set
Diagnostics
Basic adjustment
Display
▶
Diagnostics
Service
Info
3
Pointer
Distance min.: 0.234 m(d)
Distance max.: 5.385 m(d)
Service
Basic adjustment
Display
Diagnostics
▶
Service
Info
Gating out of false signals
Change now?
Unit of measurement
m(d)
Info
Basic adjustment
Display
Diagnostics
Service
▶
Info
4
5
Meas. reliability
15 dB
Sensor status
OK
Extended setting
None
Language
Deutsch
3.2
4.2
4.8
▼
3.1
4.1
4.7
▼
Curve selection
Echo curve
▼
Simulation
Start simulation?
Copy sensor data
Copy sensor data?
3.3
4.4
▼
4.7
Echo curve
Presentation of the echo
curve
Reset
Reset now?
PIN
Enable?
3.4
4.4
4.8
Instrument type
Serial number
12345678
5.1
Date of manufacture
21. January 2009
Software version
3.50
5.2
Last change using PC
21. January 2009
44 VE
5.3
Sensor characteristics
Display now?
5.4
GAPULS 61 • Foundation Fieldbus
28449-EN-100426
up with the indicating and adjustment module PLICSCOM
6 Set
6.6 Saving
It is recommended noting the adjusted data, e.g. in this operating
instructions manual and archive them afterwards. They are hence
available for multiple use or service purposes.
If VEGAPULS 61 is equipped with an indicating and adjustment
module, the most important data can be read out of the sensor into
indicating and adjustment module. The procedure is described in the
operating instructions manual "Indicating and adjustment module" in
the menu item "Copy sensor data". The data remain there permanently
even if the sensor power supply fails.
If it is necessary to exchange the sensor, the indicating and adjustment
module is inserted into the replacement instrument and the data are
written into the sensor under the menu item "Copy sensor data".
the parameter adjustment data
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 45
3
1
2
1
2
3
4
OPEN
TWIST
USB
LOCK
7 Setup
with PACTware and other adjustment programs
VEGACONNECT directly
on the sensor
7 Setup
with PACTware and other adjustment
programs
7.1 Connecting the PC
Fig. 34: Connection
1 USB cable to the PC
2 VEGACONNECT
3 Sensor
of the PC via VEGACONNECT directly to the sensor
VEGACONNECT externally
Fig. 35: Connection
1 I²C bus (com.) interface on the sensor
2 I²C connection cable of VEGACONNECT
3 VEGACONNECT
4 USB cable to the PC
46 VE
via VEGACONNECT externally
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
7 Setup
ary components:
Necess
l VEGAPULS 61
l PC with PACTware and suitable VEGA DTM
l VEGACONNECT
l Power supply unit or processing system
with PACTware and other adjustment programs
7.2 Parameter adjustment with PACTware
Further setup steps are described in the operating instructions manual
"DTM Collection/PACTware" attached to each CD and which can also
be downloaded from our homepage. A detailed description is available
in the online help of PACTware and the VEGA DTMs.
Note:
Keep
in mind that for setup of VEGAPULS 61, DTM-Collection in the
actual version must be used.
All currently available VEGA DTMs are included as a DTM Collection
on a CD. They can be purchased for a token fee from the responsible
VEGA agency. In addition, the actual PACTware version is also
available on this CD.
In addition, this DTM Collection incl. the basic version of PACTware
can be downloaded free of charge from the Internet. Move via
vega.com
and "Downloads" to "Software".
www.
7.3 Parameter adjustment with AMS™
For VEGA sensors, instrument descriptions for the adjustment
program AMS™ are available as DD. The instrument descriptions are
already implemented in the current version of AMS™. For older
versions of AMS™, a free-of-charge download is available via Internet.
Go via
www.vega.co
m and "Downloads" to the item "Software".
28449-EN-100426
VEGAPULS 61 • Foun
7.4 Saving the parameter adjustment data
It is recommended to document or save the parameter adjustment
data. That way they are available for multiple use or ser vice purposes.
The VEGA DTM Collection and PACTware in the licensed, professional version provide suitable tools for systematic project documentation and storage.
dation Fieldbus 47
aintenance and fault rectification
8 M
Reaction when malfunctions occur
Causes of malfunction
Fault rectification
24 hour service hotline
8 Maint
enance and fault rectification
8.1 Maintenance
When used as directed in normal operation, VEGAPULS 61 is
completely maintenance free.
8.2 Rectify malfunctions
The operator of the system is responsible for taking suitable measures
to remove interferences.
VEGAPULS 61 offers maximum reliability. Nevertheless, faults can
occur during operation. These may be caused by the following, e.g.:
l Sensor
l Process
l Voltage supply
l Signal processing
The first measures to be taken are to check the output signals as well
as to evaluate the error messages via the indicating and adjustment
module. The procedure is described below. Further comprehensive
diagnostics can be carried out on a PC with the software PACTware
and the suitable DTM. In many cases, the causes can be determined
this way and faults rectified.
However, should these measures not be successful, call the VEGA
service hotline in urgent cases under the phone no. +49 1805 858550.
The hotline is available to you 7 days a week round-the-clock. Since
we offer this service world-wide, the support is only available in the
English language. The service is free of charge, only the standard
telephone costs will be charged.
Checking Foundation
Fieldbus
The following table describes possible errors and helps to remove
them:
Error Cause Removal
When an additional instrument is
connected, the H1
segment fails.
Max. supply current of the segment coupler
exceeded
48 VE
Measure the current consumption,
reduce size of segment
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
aintenance and fault rectification
8 M
Error Cause Removal
value
Measured
on the indicating
and adjustment
module does not
correspond to the
value in the PLC
Instrument does
not appear during
connection setup
In Ex
applications, the regulations for the wiring of intrinsically safe
The menu item
"Display - Dis-
play value" is
not set to "AI-
Out"
Profibus DP cable pole-reversed
Incorrect termination
Instrument not
connected to the
segment
Check values and correct, if necessary
Check cable and correct, if necessary
Check termination at the beginning
and end points of the bus and terminate, if necessary, according to the
specification
Check and correct, if necessary
circuits must be observed.
Fault messages via the
indicating/adjustment
module
28449-EN-100426
VEGAPULS 61 • Foun
? E013
l no measured value available
à Sensor in boot phase
à Sensor does not find an echo, e.g. due to faulty installation or
wrong parameter adjustment
? E017
l Adjustment span too small
à Carry out a fresh adjustment and increase the distance
between min. and max. adjustment
? E036
l no operable sensor software
à Carry out a software update or send instrument for repair
? E041, E042, E043
l Hardware error, electronics defective
à Exchange the instrument or send it in for repair
? E113
l Communication conflict
à Exchange the instrument or send it in for repair
dation Fieldbus 49
aintenance and fault rectification
8 M
Reaction after fault rectification
Sensor serial number
Assignment
ing on the failure reason and measures taken, the steps
Depend
described in chapter "Set up" must be carried out again, if necessary.
8.3 Exchanging the electronics module
If the electronics module is defective, it can be replaced by the user.
In Ex
applications only one instrument and one electronics module with
respective Ex approval may be used.
If there is no electronics module available on site, one can be ordered
from the VEGA agency serving you.
The new electronics module must be loaded with the settings of the
sensor. These are the options:
l At the factory by VEGA
l Or on site by the user
In both cases, the sensor serial number is needed. The serial numbers
are stated on the type label of the instrument, inside the housing or on
the delivery note.
Informa
tion:
When loading on site, first of all the order data must be downloaded
from the Internet (see operating instructions manual "Oscillator").
The electronics modules are adapted to the respective sensor and
distinguish also in the signal output or power supply.
Foundation Fieldbus
Oscillator PS-E.60KF suitable for K band VEGAPULS 61, 62, 63 -
Foundation Fieldbus. The following versions are available which differ
in the approvals:
l PS-E.60KFX (X = without approvals)
l PS-E.60KFA (A = approvals CA, DA, EA according to product list)
l PS-E.60KFD (D = approvals KX, KF according to product list)
l PS-E.60KFE (E = approvals CX, DX, CK, DI, EX, GI, UX, UF
according to product list)
Foundation Fieldbus
with increased sensitivity
Oscillator PS-E.60KL suitable for K band VEGAPULS 61, 62, 63 -
Foundation Fieldbus. The following versions, which differ in their
approvals, are available:
l PS-E.60KLX (X = without approvals)
l PS-E.60KLA (A = approvals CA, DA, EA according to product list)
l PS-E.60KLD (D = approvals KX, KF according to product list)
l PS-E.60KLE (E = approvals CX, DX, CK, DI, EX, GI, UX, UF
according to product list)
50 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
aintenance and fault rectification
8 M
Load sensor software to
PC
Prepare update
Load software into sen-
sor
8.4 Softwa
re update
The software version of VEGAPULS 61 can be determined as follows:
l on the type label of the electronics
l via the indicating and adjustment module
l via PACTware
You can view all software histories on our website
Mak
e use of this advantage and get registered for update information
www.vega.com.
via e-mail.
The following components are required to update the sensor software:
l Sensor
l Voltage supply
l VEGACONNECT
l PC with PACTware
l Current sensor software as file
www.vega.co
At "
m/downloads" go to "Software". Select under "plics
instruments and sensors" the suitable instrument series. Load the zip
file via the right mouse key with "Save target as" e.g. on the desktop of
your PC. Extract all files available in the zip file, e.g. to the desktop.
Connect the sensor to power supply and provide connection from PC
to the instrument via VEGACONNECT. Start PACTware and provide
connection to the sensor, e.g. via the VEGA project assistant. Close
the parameter window of the sensor, as far as open.
Go in the PACTware menu bar to "Instrument data", "Additional
functions" and "Update instrument software".
PACTware now checks the actual hardware and software version of
the sensor and displays the data. This procedure lasts approx. 60 s.
Push the button "Update software" and select the previously
extracted hex file. Then the software update can be started. The
additional files are installed automatically. Depending on the sensor,
this procedure can last approximately 1 h.
28449-EN-100426
VEGAPULS 61 • Foun
8.5 Instrument repair
If a repair is necessary, please proceed as follows:
You can download a return form (23 KB) from our Internet homepage
www.vega.com
form".
By doing this you help us carry out the repair quickly and without
having to call back for needed information.
l Print and fill out one form per instrument
l Clean the instrument and pack it damage-proof
dation Fieldbus 51
under: "Downloads - Forms and certificates - Repair
aintenance and fault rectification
8 M
ch the completed form and, if need be, also a safety data
l Atta
sheet outside on the packaging
l Please ask the agency serving you for the address of your return
shipment. You can find the respective agency on our website
www.vega.com under: "Company - VEGA worldwide"
52 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
9 Dismoun
ting
9 Dismou
nting
9.1 Dismounting steps
Warning:
Before dismounting, be aware of dangerous process conditions such
as e.g. pressure in the vessel, high temperatures, corrosive or toxic
products etc.
Take note of chapters "Mounting" and "Connecting to power supply"
and carry out the listed steps in reverse order.
9.2 Removal
The instrument consists of materials which can be recycled by
specialised recycling companies. We use recyclable materials and
have designed the electronics to be easily separable.
WEEE directive 2002/96/EG
This instrument is not subject to the WEEE directive 2002/96/EG and
the respective national laws. Pass the instrument directly on to a
specialised recycling company and do not use the municipal collecting
points. These may be used only for privately used products according
to the WEEE directive.
Correct disposal avoids negative effects to persons and environment
and ensures recycling of useful raw materials.
Materials: see chapter "Technical data"
If you have no way to dispose of the old instrument properly, please
contact us about return and disposal.
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 53
10 Suppl
ement
10 Supplem
ent
10.1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 304 corresponds to 1.4301
Materials, wetted parts with encapsulated antenna system
- Threaded fitting G1½ A and 1½ NPT PVDF
- Hygienic fitting Adapter of 316L
- Antenna PVDF
- Seal thread FKM (Viton)
- Seal, bolting FKM (Viton)
Materials, wetted parts with plastic horn antenna
- Horn antenna PBT-GF30
- Focussing lens PP
- Adapter flange PPH
- Seal, adapter flange FKM (Viton)
Materials, non-wetted parts
- Compression flange PPH
- Mounting strap 316L
- Fixing screws, mounting strap 316L
- Fixing screws, adapter flange 304
- Housing Plastic PBT (polyester), Alu die-casting powder-
- Seal between housing and housing
cover
- Inspection window in housing cover for
PLICSCOM
- Ground terminal 316Ti/316L
Max. torque, mounting screws - strap on the
sensor housing
Weight depending on process fitting and
housing material
coated, 316L
NBR (stainless steel housing), silicone (Alu/plastic
housing)
Polycarbonate (UL-746-C listed)
4 Nm
0.7 … 3.4 kg (1.543 … 7.496 lbs)
Output variable
Output
- Signal digital output signal, Foundation Fieldbus protocol
- Physical layer according to IEC 61158-2
Cycle time min. 1 s (dependent on the parameter setting)
- Damping (63 % of the input variable) 0 … 999 s, adjustable
- Fulfilled NAMUR recommendations NE 43
Channel Numbers
54 VE
GAPULS 61 • Foundation Fieldbus
28449-EN-100426
10 Sup
plement
- Channe
l 1 Primary value
- Channel 2 Secondary value 1
- Channel 3 Secondary value 2
Transmission rate 31.25 Kbit/s
Current value 10 mA, ±0.5 mA
Resolution, digital > 1 mm (0.039 in)
Input variable
Measured variable distance between process fitting and product sur-
face
Min. distance from antenna end 50 mm (1.969 in)
Recommended measuring range, encapsu-
up to 10 m (32.81 ft)
6)
lated antenna system
Recommended measuring range plastic horn
up to 20 m (65.62 ft)
antenna
Reference conditions to measuring accuracy (similar to DIN EN 60770-1)
Reference conditions according to DIN EN 61298-1
- Temperature +18 … +30 °C (+64 … +86 °F)
- Relative humidity 45 … 75 %
- Air pressure 860 … 1060 mbar/86 … 106 kPa (12.5 … 15.4 psig)
Other reference conditions
- Reflector ideal reflector, e.g. metal plate 2 x 2 m
- False reflections Largest false echo 20 dB smaller than the useful
echo
Characteristics and performance data
Frequency K-band (26 GHz technology)
Meas. interval approx. 1 s
Beam angle -3 dB
7)
- Encapsulated antenna system 22°
- Plastic horn antenna 10°
Step response or adjustment time
8)
< 1 s (dependent on the parameter settings)
Max. level change Adjustable up to 1 m/min. (dependent on the
parameter settings)
Max. emitted HF power of the antenna system
- Pulse peak power < 2 mW
6)
In products with low dielectric value up to 50 cm (19.69 in).
7)
Corresponds to the range with 50 % of the emitted power
8)
Time to output the correct level (with max. 10 % deviation) after a sudden
level change.
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 55
10 Suppl
ement
- Pulse
duration < 2 ns
- Average power < 5 µW
- Average power with 1 m distance < 200 nW/cm
2
Max. emitted HF power of the antenna system - Version with increased sensitivity
- Pulse peak power < 10 mW
- Pulse duration < 2 ns
- Average power < 25 µW
- Average power with 1 m distance < 1 µW/cm
2
Measuring accuracy
Resolution, general < 1 mm (0.039 in)
Deviation
9)
see diagrams
9)
Incl. non-linearity, hysteresis and non-repeatability.
56 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
0,5 m (1.6 ft) 10 m (32.80 ft)
10 mm (0.394 in)
5 mm (0.197 in)
- 5 mm (- 0.197 in)
- 10 mm (- 0.394 in)
0
30 mm (1.180 in)
15 mm (0.590 in)
0
-15 mm (- 0.590 in)
- 30 mm (- 1.180 in)
1,0 m (3.280 ft)
10 m (32.80 ft)
0,5 m (1.6 ft) 10 m (32.80 ft)
10 mm (0.394 in)
5 mm (0.197 in)
- 5 mm (- 0.197 in)
- 10 mm (- 0.394 in)
0
10 Sup
plement
Fig. 36: Deviation VEGAPULS 61 with
Fig. 37: Deviation VEGAPULS 61 with
encapsulated antenna system
encapsulated antenna system and increased sensitivity
Fig. 38: Deviation VEGAPULS 61 with
28449-EN-100426
VEGAPULS 61 • Foun
plastic horn antenna
dation Fieldbus 57
30 mm (1.180 in)
15 mm (0.590 in)
0
-15 mm (- 0.590 in)
- 30 mm (- 1.180 in)
1,0 m (3.280 ft)
10 m (32.80 ft)
10 Suppl
ement
Fig. 39: Deviation VEGAPULS 61 with
Influence of the ambient temperature to the sensor electronics
Average temperature coefficient of the zero
plastic horn antenna and increased sensitivity
10)
0.03 %/10 K
signal (temperature error)
Ambient conditions
Ambient, storage and transport temperature -40 … +80 °C (-40 … +176 °F)
Process conditions
Vessel pressure
- Encapsulated antenna system -100 … 300 kPa/-1 … 3 bar (-14.5 … 43.5 psi)
- Plastic horn antenna -100 … 200 kPa/-1 … 2 bar (-14.5 … 29.0 psig)
Process temperature (measured on the
-40 … +80 °C (-40 … +176 °F)
process fitting)
Vibration resistance
11)
- Encapsulated antenna system mechanical vibrations up to 4 g in the frequency
range 5 … 200 Hz
- Plastic horn antenna with compression
or adapter flange
mechanical vibrations up to 2 g in the frequency
range 5 … 200 Hz
- Plastic horn antenna with mounting strap mechanical vibrations up to 1 g in the frequency
range 5 … 200 Hz
Electromechanical data - version IP 66/IP 67 and IP 66/IP 68; 0.2 bar
Cable entry/plug
12)
- Single chamber housing l 1 x cable gland M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5
10)
Relating to the nominal measuring range, in the temperature range
58 VE
-40 … +80 °C .
11)
Tested according to the guidelines of German Lloyd, GL directive 2.
12)
Depending on the version M12 x 1, according to DIN 43650, Harting, 7/
8" FF.
GAPULS 61 • Foundation Fieldbus
28449-EN-100426
plement
10 Sup
or:
closing cap M20 x 1.5; 1 x blind stopper
l 1 x
M20 x 1.5
or:
l 1 x closing cap ½ NPT, 1 x blind plug ½ NPT
or:
l 1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5
- Double chamber housing l 1 x cable entry M20 x 1.5 (cable: ø 5 … 9 mm),
1 x blind stopper M20 x 1.5; 1 x blind stopper
M16 x 1.5 or optionally available with 1 x plug
M12 x 1 for VEGADIS 61
or:
l 1 x closing cap ½ NPT, 1 x blind stopper
½ NPT, 1 x blind stopper M16 x 1.5 or
optionally 1 x plug M12 x 1 for VEGADIS 61
or:
l 1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5; 1 x blind stopper M16 x 1.5
or optionally available with 1 x plug M12 x 1 for
VEGADIS 61
Spring-loaded terminals for wire cross-sec-
> 2.5 mm² (AWG 14)
tion
Electromechanical data - version IP 66/IP 68 (1 bar)
Cable entry
- Single chamber housing 1 x IP 68 cable gland M20 x 1.5; 1 x blind stopper
M20 x 1.5
- Double chamber housing 1 x IP 68 cable gland M20 x 1.5; 1 x blind stopper
M20 x 1.5; 1 x blind stopper M16 x 1.5
Connection cable
- Wire cross-section 0.5 mm² (AWG 20)
- Wire resistance < 0.036 Ω/m
- Tensile strength < 1200 N (270 lbf)
- Standard length 5 m (16.4 ft)
- Max. length 1000 m (3280 ft)
- Min. bending radius 25 mm (0.984 in) with 25 °C (77 °F)
- Diameter approx. 8 mm (0.315 in)
- Colour - standard PE Black
- Colour - standard PUR Blue
- Colour - Ex-version Blue
Indicating and adjustment module
Voltage supply and data transmission through the sensor
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 59
10 Suppl
ement
Indication LC display in dot matrix
Adjustment elements 4 keys
Protection rating
- unassembled IP 20
- mounted into the sensor without cover IP 40
Materials
- Housing ABS
- Inspection window Polyester foil
Voltage supply
Operating voltage
- Non-Ex instrument 9 … 32 V DC
- EEx-ia instrument 9 … 24 V DC
- EEx-d instrument 16 … 32 V DC
Operating voltage with lighted indicating and adjustment module
- Non-Ex instrument 12 … 32 V DC
- EEx-ia instrument 12 … 24 V DC
- EEx-d instrument 20 … 32 V DC
Power supply by/max. number of sensors
- H1 power supply max. 32 (max. 10 with Ex)
Electrical protective measures
Protection, depending on housing version
- Housing plastic IP 66/IP 67
- Aluminium housing, stainless steel
IP 66/IP 68 (0.2 bar)
13)
housing - investment casting, stainless
steel housing - electro-polished
- Aluminium and stainless housing, in-
IP 66/IP 68 (1 bar)
vestment casting (optionally available)
Overvoltage category III
Protection class II
Approvals
Depending on the version, instruments with approvals can have different technical data.
For these instruments, the corresponding approval documents have to be taken into account.
These are part of the delivery or can be downloaded under
www.vega.com
via "VEGA Tools" and
"serial number search" as well as via "Downloads" a nd "Approvals".
13)
A suitable cable is the prerequisite for maintaining the protection rating.
60 VE
GAPULS 61 • Foundation Fieldbus
28449-EN-100426
t
i
Simulate
ALARMS
OutPV
FIELD-VALUE
Mode & Status
PVF-TIME
LO
W
-CUTOFF
L-TYPE
OUT-SCALE
PV-SCALE
DIRECT
INDIRECT
INDIRECT
SQRT
m(d)
% Lin%
Primary
Value
Secondary
Value 2
Secondary
Value 1
AI 2
AI 1
TB
Sensor_Value
min/max
adjustment
Linearization
Channel = 1: Primary Value
Channel = 2: Secondary Value 1
Channel = 3: Secondary Value 2
10 Sup
plement
10.2 F
oundation Fieldbus
Block diagram, measured value processing
The following illustration shows the Transducer Block and Function block in simplified form.
Fig. 40: VEGAPULS 61 measured
28449-EN-100426
VEGAPULS 61 • Foun
value processing
dation Fieldbus 61
Secondary_value_1
Calibration
Lowest Point
Calibration
Highest Point
Sensor_value
cal_level_lo
cal_level_hi
Calibration
Lowest Point
Calibration
Highest Point
Sensor reference plane
cal_level_lo [%]
cal_level_hi [%]
10 Suppl
ement
Diagram, adjus
The following illustration shows the function of the adjustment.
tment
Fig. 41: Adjustment VEGAPULS 61
eter list
Param
The following list contains the most important parameters and their meaning:
l primary_value
- Process value after min/max-adjust
'Channel' = 1. Unit derives from 'Primary_value_unit'
l primary_value_unit
- Selected unit code for "primary_value"
l secondary_value_1
- Value after min/max-adjus
'Channel' = 2. Unit derives from 'Secondary_value_1_unit'
l secondary_value_1_unit
tment (level + level offset). Selected as input to AIFB by setting
- Selected unit code for "secon
l secondary_value_2
- Sensor
62 VE
value + senso
from 'Secondary_value_2_unit'
r offset. Selected as input to AIFB by setting 'Channel' = 3. Unit derives
ment and linearization. Selected as input to AIFB by setting
dary_value_1"
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
10 Sup
plement
l secon
- Unit code of 'Secon
l sensor_value
dary_value_2_unit
dary_value_2'
- Raw sensor value, i.e. the uncalibrated measurement value from the sensor. Unit d erives from
'Sensor_range.unit'
l sensor_range
- 'Sensor_range.unit' refe
l simulate_primary_value
l simulate_secondary_value_1
l simulate_secondary_value_2
l device_status
l Linearization Type
- Possible types of linearization are: linear, user
container
l curve_points_1_10
- X and Y values for
l curve_points_11_20
rs to 'Sensor_value', 'Max/Min_peak_sensor_value', 'Cal_point_hi/lo'
defined, cylindrical lying container, spherical
the user defined linearization curve
- X and Y values for the user defined linearization curve
l curve_points_21_30
- X and Y values for
l curve_points_31_33
the user defined linearization curve
- X and Y values for the user defined linearization curve
l curve status
- Resul
l SUB_DEVIC
l SENSOR_ELEMENT_TYPE
l display_source_selector
- Selec
l max_peak_sensor_value
- Holds the maximum sensor value. Wri
l min_peak_sensor_value
- Holds the minimum sensor value. Write
l Calibration Highest Point
- Min./max.-adjust
l Calibration Lowest Point
- Min./max.-adjustme
l cal_level_hi
- Min./max-adjustme
t of table plausibility check
E_NUMBER
ts the type of value, which is displayed on the indication and adjustment module
te access resets to current value. Unit derives from
'Sensor_range.unit'
access resets to current value. Unit derives from
'Sensor_range.unit'
ment: Upper calibrated point of the sensor. It refers to 'Cal_level_hi'. The unit is
defined in 'Sensor_range.unit'
nt: Lower calibrated point of the sensor. It refers to 'Cal_level_lo'. The unit is
defined in 'Sensor_range.unit'
nt: Level at 'Cal_point_hi'. When writing 'Cal_level_hi' and 'Cal_type' = 1
(Online) the 'Cal_point_hi' is automatically set to the current sensor value. The unit is defined in
'Level_unit'
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 63
10 Suppl
ement
l cal_leve
- Min./max.-adjustme
l cal_type
l_lo
nt: Level at 'Cal_point_lo'. When writing 'Cal_level_lo' and 'Cal_type' = 1
(Online), the 'Cal_point_lo' is automatically set to the current sensor value. The unit is defined in
'Level_unit'
- Min./max.-adjustment: Defines type of calibration: Dry: no influence of sensor value. Online:
current sensor value determines 'Cal_point_hi/lo'
l level
- Value after min./max.-ad
l level_unit
- Unit code of 'Level', 'Level_offset', 'Cal_le
l level_offset
- Offset
l SENSOR_OFFSET
that is added to the 'Level' value. Unit derives from 'Level_unit'
- Offset that is added to the 'Senso
l end_of_operation_range
justment
vel_hi', 'Cal_level_lo'
r_value'. Unit derives from 'Sensor_range.unit'
- Set up to suit the process conditions
l begin_of_operation_range
- Set up to suit the process conditions
l produ
ct_type
- Set up to suit the process conditions. If Special-Parameter adjustment has been utilized this
parameter cannot be written
l liquids_medium_type
- Set up to suit the process conditions. If Spec
parameter cannot be written
l solids_medium_type
ial-Parameter adjustment has been utilized this
- Set up to suit the process conditions. If Special-Parameter adjustment has been utilized this
parameter cannot be written
l liquids_vessel_type
- Set up to suit the process conditions. If Spec
parameter cannot be written
l solids_vessel_type
- Set up to suit the process conditions. If Spec
parameter cannot be written
l fast_level_change
ial-Parameter adjustment has been utilized this
ial-Parameter adjustment has been utilized this
- Set up to suit the process conditions. If Special-Parameter adjustment has been utilized this
parameter cannot be written
l first_echo_factor
- Set
up to suit the process conditions.
l pulse_velo
- Set
l echo_qua
- Signal/Noise rat
city_correction
up to suit the process conditions.
lity
io
28449-EN-100426
64 VE
GAPULS 61 • Foundation Fieldbus
10 Sup
plement
l empty_vessel_cur
ve_corr_dist
- Distance from the sensor to the product surface. Unit
l empty_vessel_curve_corr_op_code
- Update, create new or delete the empty vessel curve
l tube diameter
- Set up to suit the process conditions
derives from 'Sensor_range.unit'
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 65
~ 69 mm
(2.72")
ø 77 mm
(3.03")
112 mm (4
13
/
32
")
M20x1,5/
½ NPT
~ 69 mm
(2.72")
ø 77 mm
(3.03")
117 mm (4.61")
M20x1,5/
½ NPT
~ 87 mm (3.43")
M16x1,5
ø 84 mm
(3.31")
120 mm (4.72")
M20x1,5/
½ NPT
~ 116 mm (4.57")
ø 84 mm (3.31")
116 mm (4.57")
M20x1,5M20x1,5/
½ NPT
~ 59 mm
(2.32")
ø 80 mm
(3.15")
112 mm (4.41")
M20x1,5/
½ NPT
1
3
3
2
2
10 Suppl
ement
10.3 Dim
ensions
Housing in protection IP 66/IP 68 (0.2 bar)
Fig. 42: Housing
versions in protection IP 66/IP 68 (0.2 bar) - with integrated indicating and adjustment module the
housing is 9 mm/0.35 in higher
1 Housing plastic
2 Aluminium housing
3 Aluminium double chamber housing
4 Stainless steel housing, electropolished
5 Stainless steel housing - precision casting
66 VE
GAPULS 61 • Foundation Fieldbus
28449-EN-100426
g in protection IP 66/IP 68 (1 bar)
117 mm (4.61")
~ 103 mm
(4.06")
ø 77 mm
(3.03")
116 mm (4.57")
~ 150 mm (5.91")
ø 84 mm (3.31")
M20x1,5
2
M20x1,5M20x1,5
1
SW 50 mm
(1.97")
43 mm
(1.69")
20 mm
(0.79")
78 mm (3.07")
ø 39 mm
(1.54")
G1½A / 1½ NPT
Housin
10 Sup
plement
Fig. 43: Housing
versions in protection IP 66/IP 68 (1 bar) - with integrated indicating and adjustment module the
housing is 9 mm/0.35 in higher
1 Aluminium housing
2 Stainless steel housing - precision casting
VEGAPULS 61 - threaded version
Fig. 44: VEGAPULS 61 - Threaded
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 67
version G1½ A and 1½ NPT
1 2
3
1 2
3
SW 50 mm
(1.97")
SW 50 mm
(1.97")
SW 50 mm
(1.97")
121 mm (4.76")121 mm (4.76")
121 mm (4.76")
ø 64 mm (2.52")
ø 91 mm (3.58")
ø 78 mm (3.07")
ø 95 mm (3.74")
ø 39 mm
(1.54")
ø 68 mm
(2.68")
ø 84 mm
(3.31")
ø 39 mm
(1.54")
10 Suppl
ement
VEGAPULS 61 - hy
gienic fitting
Fig. 45: VEGAPULS 61 - hygienic fitting
1 Tri-Clamp 2" and 3"
2 Bolting
according to DIN 11851 DN 50 and DN 80
3 Tuchenhagen Varivent DN 32
68 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
125 mm
(4.92")
2,5 mm
(0.10")
75 mm
(2.95")
107 mm
(4.21")
115 mm
(4.53")
300 mm
(11.81")
19 mm
(0.75")
98 mm
(3.86")
15 mm
(0.59")
8,5 mm
(0.34")
9 mm
(0.35")
85 mm
(3.35")
12 mm
(0.47")
9 mm
(0.35")
12 mm
(0.47")
PP
PBT-GF30
1.4301
10 Sup
plement
VEGAPULS 61 - vers
ion with mounting strap
Fig. 46: VEGAPULS 61 - version
28449-EN-100426
VEGAPULS 61 • Foun
with mounting bracket 170 or 300 mm in length
dation Fieldbus 69
126 mm
(4.96")
10,5 mm
(0.41")
19 mm
(0.75")
ø 75 mm (2.95")
ø 115 mm (4.53")
ø 156 mm (6.14")
ø 200 mm (7.87")
ø 21 mm
(0.83")
ø 107 mm
(4.21")
10 Suppl
ement
VEGAPULS 61 - vers
ion with compression flange
Fig. 47: VEGAPULS 61 - compression flange DN 80/3"/JIS80
70 VE
GAPULS 61 • Foundation Fieldbus
28449-EN-100426
2
1
DN100 PN16
DN150 PN16
ASME 4" 150psi
ASME 6" 150psi
JIS DN100 10K
JIS DN150 10K
øD
220
285
228,6
279,4
210
280
øk
180
240
190,5
241,3
175
240
ød
18
22
19,1
22,4
19
23
8x45°(=360°)
8x45°(=360°)
8x45°(=360°)
8x45°(=360°)
8x45°(=360°)
8x45°(=360°)
DN100 PN16
DN150 PN16
ASME 4" 150psi
ASME 6" 150psi
JIS DN100 10K
JIS DN150 10K
øD øk
ød
8x45°(=360°)
8x45°(=360°)
8x45°(=360°)
8x45°(=360°)
8x45°(=360°)
8x45°(=360°)
inch
mm
8.66" 7.09" 0.71"
0.87"
0.75"
0.88"
0.75"
0.91"
9.45"
7.50"
9.50"
6.89"
9.45"
11.22"
9.00"
11.00"
8.27"
11.02"
15 mm
(0.59")
138 mm (5.43")
31 mm
(1.22")
20 mm
(0.79")
8 mm
(0.32")
ø 75 mm (2.95")
ø 98 mm (3.86")
ø 115 mm (4.53")
ø 126 mm (4.96")
ø 143 mm
(5.63")
ø 107 mm
(4.21")
k
D
ø d
10 Sup
plement
VEGAPULS 61 - vers
Fig. 48: VEGAPULS 61 - adapter flange DN 100/DN 150
1 Adapter flange
2 Seal
ion with adapter flange
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 71
10 Suppl
ement
10.4 In
VEGA product lines are global protected by industrial property rights.
Further information see http://www.vega.com.
Only in U.S.A.: Further information see patent label at the sensor
housing.
VEGA Produktfamilien sind weltweit geschützt durch gewerbliche
Schutzrechte.
Nähere Informationen unter http://www.vega.com.
Les lignes de produits VEGA sont globalement protégées par des
droits de propriété intellectuelle.
Pour plus d'informations, on pourra se référer au site http://www.vega.
com.
VEGA lineas de productos están protegidas por los derechos en el
campo de la propiedad industrial.
Para mayor información revise la pagina web http://www.vega.com.
Линии продукции фирмы ВЕГА защищаются по всему миру
правами на интеллектуальную собственность.
Дальнейшую информацию смотрите на сайте http://www.vega.com.
VEGA系列产品在全球享有知识产权保护。
进一步信息请参见网站<http://www.vega.com>。
dustrial property rights
10.5 Trademark
All the brands as well as trade and company names used are property
of their lawful proprietor/originator.
72 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
10 Sup
plement
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 73
10 Suppl
ement
74 VE
28449-EN-100426
GAPULS 61 • Foundation Fieldbus
10 Sup
plement
28449-EN-100426
VEGAPULS 61 • Foun
dation Fieldbus 75
VEGA Grieshaber KG
ISO 9001
Am Hohenstein 113
77761 Schiltach
Germany
Phone +49 7836 50-0
Fax +49 7836 50-201
E-mail: info@de.vega.com
www.vega.com
Printing date:
statements concerning scope of delivery, application,
All
practical use and operating conditions of the sensors and
processing systems correspond to the information avail-
able at the time of printing.
© VEGA Grieshaber KG, Schiltach/Germany 2010
Subject to change without prior notice 28449-EN-100426
Loading...
