TP-Link TL-WPA4221KIT User Manual

AV600 Powerline Wi-Fi Kit
Instant Wi-Fi & Wired Network Everywhere
TL-WPA4221 KIT
HomePlug AV 600Mbps
300Mbps Wi-Fi
Wi-Fi Auto-Sync
Highlights
Simple Setup with Wi-Fi Clone Settings in Sync with Wi-Fi Move
Copy your wireless network name (SSID) and password from your router
instantly by pressing the Wi-Fi Clone button.
Any changes made to network settings will be automatically applied across the
entire network.
TP-Link AV600 Powerline Wi-Fi Kit
TL-WPA4221 KIT
Highlights
600Mbps over Powerline 300Mbps Wi-Fi
HomePlug AV standard providing up to 600Mbps high speed data transmission
over a home’s existing electrical wiring, ideal for lag-free HD or 3D video
streaming and online gaming.
600Mbps
Extend 300Mbps wireless connections to previously hard-to-reach areas of
your home and oce.
TP-Link AV600 Powerline Wi-Fi Kit
TL-WPA4221 KIT
Features
Speed
· Wireless N Standard – Wi-Fi speed of up to 300Mbps
· HomePlug AV – Provides up to 600Mbps high-speed data
transmission over a home’s existing electrical wiring
· Multiple Ethernet Ports – Create faster connections with PCs,
consoles, STB and more
· Speed Optimization – Supports IGMP managed multicast IP
transmission, optimizing IPTV streaming
Ease of Use
· Wi-Fi Clone – Allows powerline extenders to copy the network
name (SSID) and password from your router with one simple touch
· Wi-Fi Move – Automatically adopts Wi-Fi settings from your
existing powerline network
· TP-Link tpPLC – Allows you to easily manage your network
using the intuitive tpPLC App or the tpPLC Utility
· Plug, Pair and Play – Set up your powerline network in minutes
Security
· Pair Button – Provides a connection with 128-bit AES
encryption, at the touch of “Pair” button
· Parental Controls – Manage when and how connected
devices can access the internet
· Encryptions for Secure Network – WPA-PSK/WPA2-PSK
encryptions provide active protection against security threats
Range
· 300 meters Range – Up to 300 meters/1000 feet range
over existing electrical wiring
TP-Link AV600 Powerline Wi-Fi Kit
TL-WPA4221 KIT
Specications
Hardware
· Transmission Speeds:
Powerline: up to 600 Mbps
Ethernet: 10/100 Mbps
· Standards and Protocols:
HomePlug AV, IEEE 1901, IEEE 802.3, IEEE 802.3u, IEEE 802.11b/g/n
· Interface:
TL-WPA4220: 2 Ethernet Ports
TL-PA411: 1 Ethernet Port
· Plug Type: AU
· Button: Pair, Reset, Wi-Fi Clone
· LED Indicator: Power, Powerline, Ethernet, Wi-Fi
· Dimensions (W x D x H):
TL-WPA4220: 3.7 × 2.1 × 1.6 in. (94 × 54 × 40 mm)
TL-PA411: 2.6 × 2.0 × 1.1 in. (65 × 52 × 28.5 mm)
· IGMP: IGMP v1/v2/v3
Wi-Fi Clone Button
Ethernet Ports
Pair Button
· Power Consumption:
TL-WPA4220: Maximum: 5.6W, Typical: 5.2W
TL-PA411: Maximum: 2.6W, Typical: 2.3W
· Range: Up to 300 meters/1000 feet over existing electrical wiring
· Compatibility:
Compatible with all HomePlug AV & AV2 standard powerline adapters
TP-Link AV600 Powerline Wi-Fi Kit
TL-WPA4221 KIT
Specications
Software
· Modulation Technology: OFDM
· Security:
Wireless: WPA-PSK / WPA2-PSK, WEP Encrptions
Powerline: 128-bit AES Encryption
· Management Tools:
tpPLC-Scan the QR code to download TP-Link tpPLC App
Or download new tpPLC Utility on PCs: www.tp-link.com.
Others
· Package Contents
AV600 Powerline Wi-Fi Kit: TL-WPA4220 & TL-PA411
Ethernet Cable × 2
Quick Installation Guide
· Certication
RCM, RoHS
· System Requirements
Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux
· System Requirements for tpPLC Utility
Windows 10/8.1/8/7/Vista/XP and Mac OS X (10.7 or later)
· Environment
Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
For more information, please visit http://www.tp-link.com/au/products/details/TL-WPA4221KIT.html or scan the QR code on the left.
* Listed AV and Wi-Fi speeds refer to the theoretical maximum physical-layer data transfer rate. Actual data speeds vary and are inuenced by the home’s Wi-Fi/electrical/physical environment, and if adapters are placed on the same home circuit. Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2018 TP-Link Technologies Co., Ltd. All rights reserved.
