TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
1
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
D
8-Bit Resolution A/D Converter
D
Microprocessor Peripheral or Stand-Alone
Operation
D
On-Chip 12-Channel Analog Multiplexer
D
Built-in Self-Test Mode
D
Software-Controllable Sample and Hold
D
T otal Unadjusted Error... ±0.5 LSB Max
D
TLC541 is Direct Replacement for Motorola
MC145040 and National Semiconductor
ADC0811. TLC540 is Capable of Higher
Speed
D
Pinout and Control Signals Compatible
with TLC1540 Family of 10-Bit A/D
Converters
D
CMOS Technology
PARAMETER TLC540
TLC541
Channel Acquisition Sample Time
Conversion Time (Max)
Samples per Second (Max)
Power Dissipation (Max)
2 µs
9 µs
75 x 10
3
12.5 mW
3.6 µs
17 µs
40 x 10
3
12.5 mW
description
The TLC540 and TLC541 are CMOS A/D
converters built around an 8-bit switchedcapacitor successive-approximation A/D
converters. They are designed for serial interface
to a microprocessor or peripheral via a 3-state
output with up to four control inputs, including
independent SYSTEM CLOCK, I/O CLOCK, chip
select (CS
), and ADDRESS INPUT. A 4-MHz
system clock for the TLC540 and a 2.1-MHz
system clock for the TLC541 with a design that
includes simultaneous read/write operation allow high-speed data transfers and sample rates of up to
75,180samples per second for the TLC540 and 40,000 samples per second for the TLC541. In addition to the
high-speed converter and versatile control logic, there is an on-chip 12-channel analog multiplexer that can be
used to sample any one of 11 inputs or an internal self-test voltage, and a sample-and-hold that can operate
automatically or under microprocessor control. Detailed information on interfacing to most popular
microprocessors is readily available from the factory.
AVAILABLE OPTIONS
PACKAGE
T
A
SO PLASTIC DIP
(DW)
PLASTIC DIP
(N)
CHIP CARRIER
(FN)
–40°C to 85°C
—
TLC541IDW
TLC540IN
TLC541IN
TLC540IFN
TLC541IFN
–55°C to 125°C — TLC541MN —
Copyright 1995, Texas Instruments Incorporated
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
INPUT A0
INPUT A1
INPUT A2
INPUT A3
INPUT A4
INPUT A5
INPUT A6
INPUT A7
INPUT A8
GND
V
CC
SYSTEM CLOCK
I/O CLOCK
ADDRESS INPUT
DATA OUT
CS
REF+
REF–
INPUT A10
INPUT A9
DW OR N PACKAGE
(TOP VIEW)
3 2 1 20 19
910111213
4
5
6
7
8
18
17
16
15
14
I/O CLOCK
ADDRESS INPUT
DATA OUT
CS
REF+
INPUT A3
INPUT A4
INPUT A5
INPUT A6
INPUT A7
FN PACKAGE
(TOP VIEW)
INPUT A2
INPUT A1
INPUT A0
INPUT A10
REF–
SYSTEM CLOCK
INPUT A8
GND
INPUT A9
V
CC
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
2
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
The converters incorporated in the TLC540 and TLC541 feature differential high-impedance reference inputs
that facilitate ratiometric conversion, scaling, and analog circuitry isolation from logic and supply noises. A
switched-capacitor design allows low-error (± 0.5 LSB) conversion in 9 µs for the TLC540 and 17 µs for the
TLC541 over the full operating temperature range.
The TLC540I and TLC541I are characterized for operation from –40°C to 85°C.The TLC541M is characterized
for operation from –55°C to 125°C.
functional block diagram
1
2
3
4
5
6
7
8
9
11
12
SYSTEM
CLOCK
CS
I/O
CLOCK
ADDRESS
INPUT
8-Bit
Analog-to-Digital
Converter
(Switched-Capacitors)
8
4
2
4
4
8
REF–REF+
DATA
OUT
8-to-1 Data
Selector
and Driver
Control Logic
and I/O
Counters
Output
Data
Register
Input
Multiplexer
Self-Test
Reference
Input
Address
Register
Sample
and
Hold
12-Channel
Analog
Multiplexer
Analog
Inputs
A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
14 13
16
17
18
15
19
typical equivalent inputs
INPUT CIRCUIT IMPEDANCE DURING SAMPLING MODE INPUT CIRCUIT IMPEDANCE DURING HOLD MODE
1 kΩ TYP
Ci = 60 pF TYP
(equivalent input
capacitance)
5 MΩ TYP
INPUT
A0–A10
INPUT
A0–A10
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
3
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
operating sequence
ADDRESS
INPUT
Hi-Z
B7
B0B1B2B3B4B5B6B7
C3 C2 C1 C0
LSBMSB
Conversion Data B
MSBMSB LSB
Hi-Z State
Don’t Care
MSBLSBMSB
(See Note B)
A7
A7 A6 A5 A4 A3 A2 A1 A0
State
LSB
B0B1B2
MSB
B3
Don’t Care
1
1
Sample
Cycle C
Access
Cycle C
See Note A
t
conv
Sample
Cycle B
Access
Cycle B
(see Note C)
88765432765432
I/O
CLOCK
CS
DATA
OUT
Don’t Care
t
wH(CS)
Previous Conversion Data A
NOTES: A. The conversion cycle, which requires 36 system clock periods, is initiated on the 8th falling edge of I/O CLOCK after CS goes low
for the channel whose address exists in memory at that time. If CS
is kept low during conversion, I/O CLOCK must remain low
for at least 36 system clock cycles to allow conversion to be completed.
B. The most significant bit (MSB) will automatically be placed on the DAT A OUT bus after CS
is brought low. The remaining seven
bits (A6–A0) will be clocked out on the first seven I/O CLOCK falling edges.
C. To minimize errors caused by noise at CS
, the internal circuitry waits for three system clock cycles (or less) after a chip select
falling edge is detected before responding to control input signals. Therefore, no attempt should be made to clock-in address data
until the minimum chip-select setup time has elapsed.
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
†
Supply voltage, V
CC
(see Note 1) 6.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage range, V
I
(any input) –0.3 V to VCC +0.3 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output voltage range, V
O
–0.3 V to VCC +0.3 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Peak input current range (any input) ±10 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Peak total input current (all inputs) ±30 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating free-air temperature range, T
A
: TLC540I, TLC541I –40°C to 85°C. . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range, T
stg
–65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Case temperature for 10 seconds: FN package 260°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: DW or N package 260°C. . . . . . . . . . . . . . .
†
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTE 1: All voltage values are with respect to digital ground with REF– and GND wired together (unless otherwise noted).
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
4
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
recommended operating conditions
TLC540 TLC541
MIN NOM MAX MIN NOM MAX
UNIT
Supply voltage, V
CC
4.75 5 5.5 4.75 5 5.5 V
Positive reference voltage, V
ref+
(see Note 2) 2.5 VCCVCC+0.1 2.5 V
CCVCC
+0.1 V
Negative reference voltage, V
ref–
(see Note 2) –0.1 0 2.5 – 0.1 0 2.5 V
Differential reference voltage, V
ref+
– V
ref–
(see Note 2) 1 VCCVCC+0.2 1 V
CCVCC
+0.2 V
Analog input voltage (see Note 2) 0 V
CC
0 V
CC
V
High-level control input voltage, V
IH
2 2 V
Low-level control input voltage, V
IL
0.8 0.8 V
Setup time, address bits at data input before I/O CLOCK↑,
t
su(A)
200 400 ns
Hold time, address bits after I/O CLOCK↑,t
h(A)
0 0 ns
Setup time, CS low before clocking in first address bit, t
su(CS)
(see Note 3)
3 3
System
clock
cycles
CS high during conversion, t
wH(CS)
36 36
System
clock
cycles
I/O CLOCK frequency, f
clock(I/O)
0 2.048 0 1.1 MHz
Pulse duration, SYSTEM CLOCK frequency, f
clock(SYS)
f
clock(I/O)
4 f
clock(I/O)
2.1 MHz
Pulse duration, SYSTEM CLOCK high, t
wH(SYS)
110 210 MHz
Pulse duration, SYSTEM CLOCK low, t
wL(SYS)
100 190 MHz
Pulse duration, I/O clock high, t
wH(I/O)
200 404 ns
Pulse duration, I/O clock low, t
wL(I/O)
200 404 ns
f
clock(SYS)
≤ 1048 kHz 30 30
Clock transition time
System
f
clock(SYS)
> 1048 kHz 20 20
(see Note 4)
f
clock(I/O)
≤ 525 kHz 100 100
ns
I/O
f
clock(I/O)
> 525 kHz 40 40
Operating free-air temperature, TATLC540I, TLC541I –40 85 –40 85 °C
NOTES: 2. Analog input voltages greater than that applied to REF + convert as all “1”s (11111111), while input voltages less than that applied
to REF– convert as all “0”s (00000000). For proper operation, REF+ voltage must be at least 1 V higher than REF– voltage. Also,
the total unadjusted error may increase as this differential reference voltage falls below 4.75 V.
3. To minimize errors caused by noise at CS
, the internal circuitry waits for three SYSTEM CLOCK cycles (or less) after a chip select
falling edge is detected before responding to control input signals. Therefore, no attempt should be made to clock in an address until
the minimum chip select setup time has elapsed.
4. This is the time required for the clock input signal to fall from VIH min to VIL max or to rise from VIL max to VIH min. In the vicinity
of normal room temperature, the devices function with input clock transition time as slow as 2 µs for remote data acquisition
applications where the sensor and the A/D converter are placed several feet away from the controlling microprocessor.
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
5
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
electrical characteristics over recommended operating temperature range, VCC = V
ref+
= 4.75 V to
5.5 V , f
clock(I/O)
= 2.048 MHz for TLC540 or f
clock(I/O)
= 1.1 MHz for TLC541 (unless otherwise noted)
PARAMETER
TEST CONDITIONS MIN TYP†MAX UNIT
V
OH
High-level output voltage, DATA OUT VCC = 4.75 V , IOH = 360 µA 2.4 V
V
OL
Low-level output voltage VCC = 4.75 V , IOL = 1.6 mA 0.4 V
p
p
VO = VCC, CS at V
CC
10
IOZOff-state (high-impedance state) output current
VO = 0, CS at V
CC
–10
µ
A
I
IH
High-level input current VI =V
CC
0.005 2.5 µA
I
IL
Low-level input current VI = 0 –0.005 –2.5 µA
I
CC
Operating supply current CS at 0 V 1.2 2.5 mA
Selected channel at VCC,
Unselected channel at 0 V
0.4 1
Selected channel leakage current
Selected channel at 0 V ,
Unselected channel at V
CC
–0.4 –1
µ
A
ICC + I
ref
Supply and reference current V
ref+
= VCC, CS at 0 V 1.3 3 mA
p
p
Analog inputs 7 55
p
CiInput capacitance
Control inputs 5 15
pF
†
All typical values are at TA = 25°C.
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
6
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
operating characteristics over recommended operating free-air temperature range,
V
CC
= V
ref+
– 4.75 V to 5.5 V, f
clock(I/O)
= 2.048 MHz for TLC540 or 1.1 MHz for TLC541,
f
clock(SYS)
= 4 MHz for TLC540 or 2.1 MHz for TLC541
TLC540 TLC541
PARAMETER
TEST CONDITIONS
MIN MAX MIN MAX
UNIT
E
L
Linearity error See Note 5 ±0.5 ±0.5 LSB
E
ZS
Zero–scale error See Notes 2 and 6 ±0.5 ±0.5 LSB
E
FS
Full-scale error See Notes 2 and 6 ±0.5 ±0.5 LSB
Total unadjusted error See Note 7 ±0.5 ±0.5 LSB
Self-test output code
Input A11 address = 1011,
(see Note 8)
01111101
(125)
1000001 1
(131)
01111101
(125)
1000001 1
(131)
t
conv
Conversion time See Operating Sequence 9 17 µs
Total access and conversion time See Operating Sequence 13.3 25 µs
t
a
Channel acquisition time (sample cycle) See Operating Sequence 4 4
I/O
clock
cylces
t
v
Time output data remains valid after
I/O CLOCK↓
10 10 ns
t
d
Delay time, I/O CLOCK↓ to data output
valid
300 400 ns
t
en
Output enable time
See Parameter
150 150 ns
t
dis
Output disable time
M
easurement
150 150 ns
t
r(bus)
Data bus rise time
Information
300 300 ns
t
f(bus)
Data bus fall time 300 300 ns
NOTES: 2. Analog input voltages greater than that applied to REF+ convert to all “1”s (1 1111111) while input voltages less than that applied to
REF– convert to all “0”s (00000000). For proper operation, REF+ voltage must be at least 1 V higher than REF– voltage. Also, the
total unadjusted error may increase as this differential reference voltage falls below 4.75 V.
5. Linearity error is the maximum deviation from the best straight line through the A/D transfer characteristics.
6. Zero-scale error is the difference between 00000000 and the converted output for zero input voltage; full-scale error is the difference
between 11111111 and the converted output for full-scale input voltage.
7. Total unadjusted error is the sum of linearity, zero-scale, and full-scale errors.
8. Both the input address and the output codes are expressed in positive logic.
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
7
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
PARAMETER MEASUREMENT INFORMATION
See Note B
0.4 V
2.4 V
t
f
Output
t
r
0.8 V
2.4 V
0.8 V
t
d
DATA OUT
VOLTAGE WAVEFORMS FOR RISE AND FALL TIMES
VOLTAGE WAVEFORMS FOR DELAY TIME
V
CC
3 kΩ
3 kΩ
V
CC
See Note B
SYSTEM
CLOCK
50%
50%
0 V
0 V
t
PLZ
I/O CLOCK
VOLTAGE WAVEFORMS FOR ENABLE AND DISABLE TIMES
Output Waveform 1
(see Note C)
t
PHZ
t
PZH
V
OH
90%
10%
t
PZL
0 V
V
CC
50%
CS
LOAD CIRCUIT FOR
t
PZL
AND t
PLZ
LOAD CIRCUIT FOR
t
PZH
AND t
PHZ
LOAD CIRCUIT FOR
td, tr, AND t
f
See Note B
C
L
(see Note A)
Output
Under Test
Test
Point
3 kΩ
1.4 V
Output Waveform 2
(see Note C)
C
L
(see Note A)
Output
Under Test
Test
Point
C
L
(see Note A)
Output
Under Test
Test
Point
NOTES: A. CL = 50 pF for TLC540 and 100 pF for TLC541.
B. ten = t
PZH
or t
PZL
, t
dis
= t
PHZ
or t
PLZ
.
C. Waveform 1 is for an output with internal conditions such that the output is low except when disabled by the output control.
Waveform 2 is for an output with internal conditions such that the output is high except when disabled by the output control.
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
8
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
APPLICATION INFORMATION
simplified analog input analysis
Using the equivalent circuit in Figure 1, the time required to charge the analog input capacitance from 0 to V
S
within 1/2 LSB can be derived as follows:
The capacitance charging voltage is given by
(1)
where
R
t
= Rs + r
i
VC+
V
S
ǒ
1–e
–tcń
RtC
i
Ǔ
The final voltage to 1/2 LSB is given by
(2)V
C
(1/2 LSB) = VS – (VS/512)
Equating equation 1 to equation 2 and solving for time t
c
gives
(3)
and
t
c
(1/2 LSB) = Rt × Ci × ln(512) (4)
VS*
ǒ
VSń
512Ǔ+
V
S
ǒ
1–e
–tcń
RtC
i
Ǔ
Therefore, with the values given the time for the analog input signal to settle is
(5)
t
c
(1/2 LSB) = (Rs + 1 kΩ) × 60 pF × ln(512)
This time must be less than the converter sample time shown in the timing diagrams.
R
s
r
i
V
S
V
C
50 pF MAX
1 kΩ MAX
Driving Source
†
TLC540/1
C
i
V
I
VI= Input Voltage at INPUT A0–A10
VS= External Driving Source Voltage
Rs= Source Resistance
ri= Input Resistance
Ci= Equivalent Input Capacitance
†
Driving source requirements:
• Noise and distortion for the source must be equivalent to the
resolution of the converter.
• Rs must be real at the input frequency.
Figure 1. Equivalent Input Circuit Including the Driving Source
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
9
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
PRINCIPLES OF OPERATION
The TLC540 and TLC541 are each complete data acquisition systems on a single chip. They include such functions
as analog multiplexer, sample and hold, 8-bit A/D converter , data and control registers, and control logic. For flexibility
and access speed, there are four control inputs [two clocks, chip select (CS
), and address]. These control inputs and
a TTL-compatible 3-state output are intended for serial communications with a microprocessor or microcomputer.
With judicious interface timing, with TLC540 a conversion can be completed in 9 µs, while complete
input-conversion-output cycles can be repeated every 13 µs. With TLC541 a conversion can be completed in 17 µs,
while complete input-conversion-output cycles are repeated every 25 µs. Furthermore, this fast conversion can be
executed on any of 11 inputs or its built-in self-test and in any order desired by the controlling processor.
The system and I/O clocks are normally used independently and do not require any special speed or phase
relationships between them. This independence simplifies the hardware and software control tasks for the device.
Once a clock signal within the specification range is applied to SYSTEM CLOCK, the control hardware and software
need only be concerned with addressing the desired analog channel, reading the previous conversion result, and
starting the conversion by using I/O CLOCK. SYSTEM CLOCK will drive the conversion crunching circuitry so that
the control hardware and software need not be concerned with this task.
When CS
is high, DA TA OUT is in a 3-state condition and ADDRESS INPUT and I/O CLOCK are disabled. This feature
allows each of these terminals, with the exception of CS
, to share a control logic point with their counterpart terminals
on additional A/D devices when additional TLC540/541 devices are used. In this way, the above feature serves to
minimize the required control logic terminals when using multiple A/D devices.
The control sequence has been designed to minimize the time and effort required to initiate conversion and obtain
the conversion result. A normal control sequence is:
1. CS
is brought low. To minimize errors caused by noise at CS, the internal circuitry waits for two rising edges
and then a falling edge of SYSTEM CLOCK after a low CS
transition, before the low transition is recognized.
This technique is used to protect the device against noise when the device is used in a noisy environment.
The MSB of the previous conversion result automatically appears on DATA OUT.
2. A new positive-logic multiplexer address is shifted in on the first four rising edges of I/O CLOCK. The MSB
of the address is shifted in first. The negative edges of these four I/O clock pulses shift out the second, third,
fourth, and fifth most significant bits of the previous conversion result. The on-chip sample and hold begins
sampling the newly addressed analog input after the fourth falling edge. The sampling operation basically
involves the charging of internal capacitors to the level of the analog input voltage.
3. Three clock cycles are then applied to I/O CLOCK and the sixth, seventh, and eighth conversion bits are
shifted out on the negative edges of these clock cycles.
4. The final eighth clock cycle is applied to I/O CLOCK. The falling edge of this clock cycle completes the
analog sampling process and initiates the hold function. Conversion is then performed during the next 36
system clock cycles. After this final I/O clock cycle, CS
must go high or the I/O CLOCK must remain low
for at least 36 system clock cycles to allow for the conversion function.
CS
can be kept low during periods of multiple conversion. When keeping CS low during periods of multiple
conversion, special care must be exercised to prevent noise glitches on I/O CLOCK. If glitches occur on I/O CLOCK,
the I/O sequence between the microprocessor/controller and the device loses synchronization. Also, if CS
is taken
high, it must remain high until the end of the conversion. Otherwise, a valid falling edge of CS
causes a reset condition,
which aborts the conversion in progress.
A new conversion can be started and the ongoing conversion simultaneously aborted by performing steps 1 through
4 before the 36 system clock cycles occur. Such action yields the conversion result of the previous conversion and
not the ongoing conversion.
TLC540I, TLC541I
8-BIT ANALOG-TO-DIGITAL CONVERTERS
WITH SERIAL CONTROL AND 11 INPUTS
SLAS065A – OCTOBER 1983 – REVISED MARCH 1995
10
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
PRINCIPLES OF OPERATION
It is possible to connect SYSTEM CLOCK and I/O clock together in special situations in which controlling circuitry
points must be minimized. In this case, the following special points must be considered in addition to the requirements
of the normal control sequence previously described.
1. The first two clocks are required for this device to recognize CS
is at a valid low level when the common clock
signal is used as an I/O CLOCK. When CS
is recognized by the device to be at a high level, the common clock
signal is used for the conversion clock also.
2. A low CS
must be recognized before the I/O CLOCK can shift in an analog channel address. The device
recognizes a CS
transition when the SYSTEM CLOCK terminal receives two positive edges and then a
negative edge. For this reason, after a CS
negative edge, the first two clock cycles do not shift in the address.
Also, upon shifting in the address, CS
must be raised after the eighth valid (10 total) I/O CLOCK. Otherwise,
additional common clock cycles are recognized as I/O CLOCKS and will shift in an erroneous address.
For certain applications, such as strobing applications, it is necessary to start conversion at a specific point in time.
This device accommodates these applications. Although the on-chip sample and hold begins sampling upon the
negative edge of the fourth valid I/O clock cycle, the hold function is not initiated until the negative edge of the eighth
valid I/O clock cycle. Thus, the control circuitry can leave the I/O clock signal in its high state during the eighth valid
I/O clock cycle until the moment at which the analog signal must be converted. The TLC540/TLC541 continues
sampling the analog input until the eighth falling edge of the I/O clock. The control circuitry or software then
immediately lowers the I/O clock signal and holds the analog signal at the desired point in time and start conversion.
Detailed information on interfacing to most popular microprocessors is readily available from the factory.
IMPORTANT NOTICE
T exas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgement, including those
pertaining to warranty, patent infringement, and limitation of liability.
TI warrants performance of its semiconductor products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are utilized to the extent
TI deems necessary to support this warranty. Specific testing of all parameters of each device is not necessarily
performed, except those mandated by government requirements.
CERT AIN APPLICATIONS USING SEMICONDUCTOR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF
DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE (“CRITICAL
APPLICATIONS”). TI SEMICONDUCTOR PRODUCTS ARE NOT DESIGNED, AUTHORIZED, OR
WARRANTED TO BE SUITABLE FOR USE IN LIFE-SUPPORT DEVICES OR SYSTEMS OR OTHER
CRITICAL APPLICATIONS. INCLUSION OF TI PRODUCTS IN SUCH APPLICA TIONS IS UNDERST OOD TO
BE FULLY AT THE CUSTOMER’S RISK.
In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.
TI assumes no liability for applications assistance or customer product design. TI does not warrant or represent
that any license, either express or implied, is granted under any patent right, copyright, mask work right, or other
intellectual property right of TI covering or relating to any combination, machine, or process in which such
semiconductor products or services might be or are used. TI’s publication of information regarding any third
party’s products or services does not constitute TI’s approval, warranty or endorsement thereof.
Copyright 1999, Texas Instruments Incorporated
Loading...
