*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 2

Operating Instructions

MultyFocus

Made in Germany!

TechniSat Satellitenfernsehprodukte GmbH · Postfach 560 · 54541 Daun

VCRTV

DECODER

LNB 1

LNB 2

OC 13/18V 2x0,4A max

ANT

MADE IN GERMANY

AUDIO

185-265V 50 Hz max.70W

POLARIZER

PULSE

FERR.

max

45mA

MOTOR SENSOR

+5V

FERR.

+34V

+5V : max 200m A+34V : max 1,3A

Netz

TechniSat

PROGR

Multyfocus

TechniSat

INDEXTV/RADIO VCR

STOP

Umschlag INNEN engl. 14.12.1999 10:52 Uhr Seite 1

TV output modulator

LNB inputs

Sound on/off (P.18)

Ten-key keypad (P.18)

Volume (P.18) up

TV/RADIO (S.19)

Menu control (function keys)

down

On/Standby

(P.18)

Channel selection

(P.18)

Video cassette

recorder/play (P.20)

Satellite/Channel

Menu display

Previous menu

Antenna

input

modulator

Audio outputs (cinch jacks)

LCD display

left right

SCART connections

ferritischer

Polarizer

mech.

polarizer

sensor

motor

Channel selection (p.18)

list

Power on switch (p.18)

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 3

Contents

1 ILLUSTRATIONS 2 Please read first! 3 Safety precautions 4 Connections

4.1 Outdoor unit

4.2 Television

4.3 Hifi Amplifier

4.4 Video Cassette Recorder (VCR)

4.5 Decoder

5 Installation

5.1 Basic setting

5.1.1 Deleting all

5.1.2 Loading the pre-programmation

5.2 Language

5.3 Outdoor unit

5.4 Satellite scan

5.5 Automatic satellIte scan

5.6 Correcting all satellite positions

5.7 Decoder/OSD

5.8 Childproof control feature

5.9 External programmation

5.10 Menu overview

6.3 Selecting a satellite

6.4 Volume control

6.5 TV/Radio control

6.6 Displaying time and date

6.7 Setting the timer

6.8 Childproof control feature

6.9 Playing the video recorder

6.10 Setting the clock

6.11 Menu overview

7 Changing the basic programmation

7.1 Copying channels

7.2 Changing channels

7.3 Deleting/recalling channels

7.4 Renaming channels

7.5 Renaming satellites

7.6 Configuring a decoder

7.7 Setting up new channels

7.8 Setting up new satellites

7.9 Menu overview

8 Pre-programmed channels

8.1 Television channels

8.2 Radio channels

9 Troubleshooting notes 10 Technical terms

6 operation

6.1 Switching on and off

6.2 Selecting a channel

11 Technical data

2 Please read first!

Reading the operation instructions

Chapters 4 and 5 explain how to connect and adapt the receiver to the outdoor unit (reflector, LNB, etc.), the TV set, etc. This set-up is required only once; you only need to make amendments in case the outdoor unit installation has changed or additional equipment has Been connected, e.g. decoder.

Chapter 6 describes all functions necessary for every-day use, such as channel selection or volume control.

Chapter 7 will give you information on how you set up new channels and satellites or how you change the channel sort order.

Chapter 8 lists all the pre-programmed channels.

Important notes on device control

Using a so-called „On Screen Display“ simplifies receiver control and reduces the number of keys on the remote control.All features are displayed on the TV monitor and can be controlled by little key action.

Related features have been collected to a „MENU“.

A „POINTER“ marks the function you can activate at a time.

Example:

The last menu line always displays the „function keys“. Use these to:

- move the pointer,

- start a function,

- change values,

- store changes, and

- to quit the menus.

Press the MENU key to change the background of some menus from coloured display to normal TV screen.

Main menu

> set timer

set time childproof control feature channel menu

^/v/OK/STOP

Pointer

Functions

Function keys

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 4

MADE IN GERMANY

I G TEST VIDEO

ANT

LNB

DC 13/18V MAX 0,4A

( )

KANAL

230-240V

50 Hz

max. 24 VA

CODER

DECODER

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 5

3 Safety precautions

For your own protection, carefully read the safety precautions before starting to use your new device.

The manufacturer is not liable to damage caused by improper

>80%

<+15°C

handling or by disregarding the safety precautions.

Take care that empty remote control batteries are not put into the household waste but disposed off properly (return to specialist stores, special waste)

Styrofoam packing harmful to the environment has not been used. The packing which can be recycled corresponds to the requirements of the new packing regulations.

Never open the device. There is danger of an electric shock. Repairs should only be carried out by qualified specialists.

Operational breaks: during a storm or when operation is interrupted for a long time disconnect the device from mains.

230V/

In the following cases disconnect the device from mains and ask a specialist for help:

- the power supply cord or the connector are damaged

- the device was exposed to humidity or a liquid has flown into the device

- in case of considerable malfunctions

- in case of considerable external damage.

50Hz

+35°C

4 Connections

4.1 Outdoor unit

a) Use an appropriate coax cable to connect the receiver’s input LNB 1 with the receiving equipment’s LNB input.

You may connect a second LNB to LNB input 2. For further details,see chapter 5, „installation“.

b) Connect the ferrite polarizer to the POLARIZER terminals marked FERR. (You can connect older mechanical

polarizer models to the terminals marked PULSE, +5V and ).

c) Connect the actuator to the terminals marked MOTOR/+34V and the sensor to the terminals SENSOR/ .

4.2 Television

d) Connect the receiver to a 230 V/50 Hz wall socket. Press the power-on switch to set it to standby mode,

and press the remote control key to turn it on.Press the MENU key briefly.

e) Use a SCART cord to connect the receiver (SCART TV) with the TV (SCART input).If your television does not switch to

AV operation (audio/video) automatically, you will need to switch over manually.

f) If your television set is not equipped with a SCART connector you can also use an antenna cable to connect the

TV output of the modulator with the TV’s antenna input. Plug the cable coming from the antenna in the modulator’s antenna input.

Your television set has to be adjusted to the transmission channel of the receiver. Select a free channel on your TV set and adjust it to channel 39. If channel 39 is occupied by a channel that can be received via antenna, you can adjust a different transmission channel in the range of 21 to 45.

> Press to switch the receiver to standby mode.

> Press and on the receiver at the same time and hold the key down approx.2 seconds.

display:

> Press briefly

display: Channel no 39

> Press to select

display:

> Set your TV to the same channel

> Press to store the transmission channel and to turn off

4.3 Amplifier

g) In order to achieve maximum sound quality the receiver can be connected to a Hifi amplifier. Use an adequate

amplifier input (e.g. CD, Aux; Warning, the „phono“ input is not appropriate!) to link it with the receiver’s audio R/L cinch jacks.

Netz

PROGR

v Mod System ^

Channel no 45

Channel no 39

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 6

VCRTV

DECODER

LNB 1

LNB 2

OC 13/18V 2x0,4A max

ANT

MADE IN GERMANY

AUDIO

185-265V 50 Hz max.70W

POLARIZER

PULSE

FERR.

max

45mA

MOTOR SENSOR

+5V

FERR.

+34V

+5V : max 200m A+34V : max 1,3A

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 7

Actuat or and sensor

LNB

Ferrite polarizer

TV-Set

HiFi amplifier

Video recorder

Decoder

4.4 Video Cassette Recorder

h) Connect the video recorder to the SCART input marked „VCR“.

If the receiver is turned on, press the VCR key to play a video cassette. If the receiver is in standby mode (see 6.1) all audio and video signals are directed to the SCART output TV, provided the VCR produces an adequate switching signal.

4.5 Decoder

i) Plug the additional decoder to the SCART input marked „DECODER“.

You can toggle between four decoder signals to adapt to different decoding types.

A: „flat“,B: Baseband, C: Video unapplied, D: Video.

Consult the decoder’s user manual to find out which signals are required and select the signal type according to the description in chapter 7.6, „Setting up the decoder“.

5 Installation

Calling the installation menu

> Press to switch the receiver to standby mode. > Press and on the receiver at the same time and hold the keys down for appr. 2

secs. > Press briefly. > Press after terminating the settings to return to standby mode.

5.1 Basic setting

You can use the following settings to reset the receiver to its „original state“. Consequently, all the changes and settings you have chosen will be undone. The pre-programmation (see 8) is permanently stored and can be re-called anytime.

> Display the installation menu (see above)

> Press to set pointer to „Basic Setting“

> Press .

Installation menu

> basic setting

language outdoor unit satellite scan autom. satellite scan decoder/OSD childproof control feature ext. programmation

^/v/OK/STANDBY

Basic setting > delete all

load the pre-programmation

^/v/OK/STOP

VCR

Netz

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 8

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 9

5.1.1 Deleting all

All satellite positions and channel settings you have made will be deleted.You should not use this function other than when setting up your receiver for the first time.

> Press to set pointer to „delete all“

> Press .

> Press again.

> After a few seconds, the receiver automatically returns to the installation menu.

5.1.2 Loading the pre-programmation

When loading the pre-programmation data,all your channel settings are deleted. The stored satellite positions will be retained, though. You should also use this function upon initial receiver set-up after you have deleted all settings.

> Press to set pointer to „basic setting“

> Press

> Press to set pointer to „load pre-programmation“

> Press

> Press again.

> Display the installation menu (see p. 8).

> Press to set pointer to „Sprache“ (language).

> Press .

> After a few seconds, the receiver automatically returns to the installation menu.

Language > English

Francais Deutsch

^/v/OK/STOP

> After a few seconds, the receiver automatically returns to the installation menu.

5.2 Language

The OSD display allows you to toggle between English,French, and German.

5.3 Outdoor unit

Both LNB inputs can be configured to use separate outdoor units. Example: CombySat LNB set-up to accommodate the entire Ku band (between 10.7 and 12.75 GHz). (This LNBis also

pre-configured)

> Display the installation menu (see p. 8).

> Press to set pointer to „Ausseneinheit“ (outdoor unit).

> Press . > Press to set

pointer to „Band“ (band).

> Press to select

Ku band.

If you select C band, the receiver automatically uses inverted video polarity.

> Press to set

pointer to „LNB-Typ“

> Press to select „CombySat“.

The receiver loads all the related local oscillator frequencies (LOFs) automatically.

> Press to set pointer to „Polarizer“.

> Press to toggle between „ferrite“ and „mechanical“.

This setting depends on the polarizer type you are using.

> Press to set pointer to „Autofocus“.

> Press to select „on“.

If you activate the auto-focus feature, the receiver detects the best antenna position upon each change of satellites.

You can also customise the receiver’s LNBs to different LOFs.

> Press to set pointer to „LOF“.

> Press to switch to „Andere“ (other)

> Press to set pointer to „Obere LOF“ (upper LOF).

> Press or use the ten-key keypad to select LOF.

> Press .

The selected values are stored and the same menu is displayed to set up the second LNB input.

> Select the values accordingly for the second LNB input.

> Press to store.

> The receiver automatically returns to the installation menu.

Outdoor unit 1

band Ku

> LNB typ CombySat

auto-focus on polarizer ferrite LOF normal upper LOF 10750 MHz lower LOF 9750 MHz

^/v/</>/0-9/MENU/OK/STOP

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 10

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 11

5.4 Satellite scan

The description of the scan feature assumes the following:

a) The antenna trajectory has been duly adjusted. b) You have set up the right outdoor unit (see 5.3, „Outdoor unit“). c) You have mounted the linear/circular polarizer (part no. 2206 or

2207) according to the instructions.

d) You know the westernmost and the easternmost satellites

through antenna orientation.

e) The actuator’s limit sensors have been adjusted such that the

motor is switched off before the mechanical limits of the antenna retaining system are exceeded in order to avoid damage on the paraboloidal-type reflector or the retaining system.

> Display the installation

menu (see p. 8).

> Press to set pointer

to „satellite scan“.

> Press

> Press to set pointer

to „Satellit“.

> Press to select the easternmost satellite

(the example shows ASTRA 19.2° East)

> Press to set pointer to „Antennen-Posit“

(antenna position).

> Press to turn off background.

Satellite scan

> satellite ASTRA 19.0

channel PRO7 11.406 GHz

stored position antenna position 5000 west limit 0000 east limit 9999 antenna control LNB 1 optimise skew 117

^/v/</>/MENU/OK/STOP

Moving the antenna: Upon start-up the antenna begins to move slowly, but speeds up until you press the same key again.

> Briefly press .

Now, the antenna should move East. If the antenna moves West, press to halt and change the order of the wire connections.

> Press briefly when you have found a satellite.

> Press to make an exact set-up.

> Press to set pointer to „Gesp. Position“ (stored position).

> Press to store (press to delete).

> Press to set pointer to „Ostgrenze“ (East limit).

> Press or to store (the East limit is stored 10 pulses further

East automatically).

> Press to set pointer to „Satellit“.

> Press to select the westernmost satellite

(the example shows Hispasat 1 at 30° West).

> Press to set pointer

to „antenna-position“. (antenna position)

> Briefly press .

> Briefly press when you

have found a satellite.

satellite scan

>satellite ASTRA 19,2O

channel PRO7 11.406 GHz stored position 5048 antenna pos. 5048 West limit 0000 East limit 5058 antenna control LNB 1 optimise skew 175

^/v/</>/MENU/OK/STOP

> Press to make exact set-up.

> Press to set pointer to „Gesp. Position“ (stored position). > Press or to store.

> Press to set pointer to „Westgrenze“ (West limit).

> Press or to

store (the West limit is stored 10 pulses further West automatically).

Now you can find additional satellites using the automatic satellite scan feature (see 5.5).

If you start the „optimise skew“ feature,the optimal skew value is automatically selected.

> Press to set pointer to „optimise skew“.

> Press to optimise.

Warning: The calculated value is not stored. It is only used to simplify the satellite scan. Your polarizer should be

mounted such that the pre-programmed skew values are correct for most of the channels (e.g. controlled for ASTRA). This is why only a few channels need skew correction. (see 7.7)

Adjusting to different outdoor units

> Press to set pointer to „antenna control“.

> Press or to select between:

„LNB 1“: Antenna only moves when receiving channels via LNB input 1 (e.g.: positioning mechanism on LNB

input 1, fixed position antenna on LNB input 2).

„LNB 2“: Antenna only moves when receiving channels via LNB input 2 (e.g.: positioning mechanism on LNB

input 2, fixed position antenna on LNB input 1).

„LNB 1 and 2“: Antenna moves when receiving channels via LNB inputs 1 or 2 (e.g.: positioning mechanism with 2

LNBs, such as Ku and C band).

„off“: Antenna does not move (e.g.: fixed position antenna).

> Press to store and to return to the installation menu.

Satellite scan

satellite Hispasat 1 30W channel Tdeporte 12.149 GHz stored position 4816 antenna posit. 4816

>West limit 4806

East limit 5058 antenna control LNB 1 optimise skew 132

^/v/</>/MENU/OK/STOP

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 12

5.5 Automatic satellite scan

The automatic satellite scan feature only works from West to East. The following explanation assumes that the reflector has been oriented towards the westernmost satellite (Hispasat 1 at 30° West in our example) after having set up the East and West limits (see 5.4).

Satellites which are located beyond the East and West limits can not be selected by the automatic satellite scan. For this, you may need to extend the trajectory limits (see 5.4).

First of all, select the type of motor you Are using: A for PFA reflectors with actuator, or B for offset reflectors with H/H mount.

> Press to set pointer to „Decoder/OSD“.

> Press .

> Press to set

pointer to „motor type“.

> Press to

toggle between A and B

> Press to return to

the installation menu.

> Press to set

pointer to „automatic satellite scan“.

> Press .

> Press to set

pointer to „satellite“.

> Press to switch

over to the next satellite West (Intelsat 601 at 27.5° West in our example).

> Press to turn off

background.

> Briefly press .

The antenna moves West to search for channels on the selected satellite. Once the receiver has found a satellite, it stops to find the best peak position (auto-focus).

> Press to set pointer to „Programm“ (channel).

> Press to select and check if the receiver has found the desired satellite.

Warning: Not all satellite channels have permanent broadcasts. Also, the frequency mapping may vary from time to

time. Check the most recent publications, such as the „Infosat“ magazine which is issued monthly.

When the desired satellite has been found:

> Press to set pointer to „Gesp. Position“ (stored position).

> Press to store.

> Scan and store additional satellites east of the previous one, and follow the instructions above.

Decoder/OSD

MAC/Eurocrypt no Videopcrypt no TV scart PAL

> motor type A

^/v/</>/OK/STOP

Automatic satellite scan

>satellite Hispasat 1 30W

channel TDeporte 12.149 GHz stored position 4816 antenna position 4816 start scan auto-focus LNB input 1 optimise skew 132

^/v/</>/MENU/OK/STOP

Automatic satellite scan

satellite Intels.601 27,5W channel TravelCh 11.175 GHz stored position antenna position 4816 start scan auto-focus LNB input 1 optimise skew 132

^/v/</>/MENU/OK/STOP

*M-Focus 2.6.95 14.12.1999 10:33 Uhr Seite 13

If the desired satellite has not been found:

> Press to set pointer to „Suche starten“ (start scan).

> Press to start again.

If, due to bad receive conditions, a satellite cannot be found using the automatic scan feature, you can search and store it manually (see 5.4), and proceed with the automatic scanning afterwards.

If you also use LNB input 2,you can assign it to a stored satellite.

> Press to set pointer to „LNB-Eingang“.

> Press to select.

The „optimise skew“ feature is identical to the one described in chapter 5.4.

You can activate the automatic selection of the best receive position (auto-focus) manually, as well:

> Press to set pointer to „Autofokus“ (auto-focus).

> Press to turn on.

For a description of how to select satellites which are not part of the pre-programmation, refer to chapter 7.8, „Setting up new satellites“.

5.6 Correcting all satellite positions

If none of your stored satellite positions is peaked properly, you may need to correct the current antenna position.

Use this option with extra care since it may shift the satellites to incorrect positions.

> Display the installation menu (see p. 8).

> Set pointer to satellite scan

> Call feature with OK.

> Press to set

pointer to antenna position.

> Press to turn

the reflector until you have found the best receive quality for the satellite set up above.

> Press .

> Press to confirm the message „Sure?“

> Press to return without saving.

The stored position is finally used as the current antenna position.

If possible you should use a satellite with a poor receive quality to correct the positions of all satellites since this will be the most exact satellite to correct.

satellite scan

satellit Hispasat 1 30W channel Tdeporte 12.149 GHz stored position 4816

>antenna position 4816

west limit 4806 east limit 5058 antenna control LNB 1 optimise skew 132

^/v/</>/MENU/OK/STOP

INDEX

STOP

*M-Focus 2.6.95 14.12.1999 10:34 Uhr Seite 14

5.7 Decoder/OSD

If your television is equipped with RGB inputs you can select the OSD display to achieve optimal quality of character display. Warning: This requires a correctly wired (21-pin) SCART cord!

> Display the installation menu (see p. 8).

> Press to set pointer to „Decoder/OSD“

> Press .

> Press to set

pointer to “TV SCART“.

> Press to select „RGB“.

> Press to return to the installation menu.

The „MAC/Eurocrypt“ and „Videocrypt“ functions are intended for service purposes only.

5.8 Childproof control feature

To secure the receiver against unauthorised use you can enter a secret code. Later on, this secret number is requested during normal operationany time you want to watch channels which are marked accordingly (see 6.8, „Childproof control feature“), or if you change your settings, e.g. when displaying the installation menu. To be able to control the receiver in cases where you have forgotten your secret number, you can use the global access number which is valid all the time. Check the last page of this manual to find out your global access number.

> Display the installation menu (see p. 8).

> Press to set pointer to „Kindersicherung“ (childproof control feature).

> Press .

> Enter the four digit secret code over the ten-key keypad (identical with the global access number if you have not

defined any other number, so far).

> Enter the new four

digit secret number over the ten-key keypad.

> Repeat the secret

number over the tenkey keypad.

> After a few seconds the receiver automatically returns to the installation menu.

Decoder/OSD

MAC/Eurocrypt no Videopcrypt no

>TV scart PAL

motor type A

^/v/</>/OK/STOP

STOP

Childproof control

>access code

new access code repeat new access code

0-9/STOP

*M-Focus 2.6.95 14.12.1999 10:34 Uhr Seite 15

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 16

5.9 External Programmation

You can copy programmation changes to a second receiver.

The data transfer between both receivers requires an authentic SCART cord (21 pins).

> Connect the SCART 3 output of receiver 1 with the SCART 3 input

of receiver 2.

On both receivers:

> display the installation menu (see p.8).

> press to set pointer to „ext. programmation“

> press .

On target receiver to be re-programmed:

> press to set pointer to „Ziel“ (target)

> press to begin.

During the data transfer the screen displays a number between 1 and 127.

On the receiver with the new programmation data:

> press on the receiver.

On both receivers:

> press to return tothe installation menu.

STOP

On source receiver to copy programmation from:

> press to set pointer to „Quelle“ (source)

> press to begin.

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 17

5.10 Menu overview

Installation menu

>basic setting

language outdoor unit satellite scan autom. satellite scan decoder/OSD childpro.contr.feat. ext. programmierung

^/v/OK/STANDBY

STOP

Basic setting

>delete all

load pre-programmtion

^/v/OK/STOP

Language

>English

Francais Deutsch

^/v/OK/STOP

Outdoor unit 1

band Ku

>LNB type CombySat

auto -focus on polarizer ferrite LOF standard upper LOF 10750 MHz lower LOF 9750 MHz

^/v/</>/0-9/MENU/OK/STOP

Satellite scan

>satellit ASTRA 19,2O

channel PRO7 11.406 GHz stored position antenna position 5000 West limit 0000 East limit 9999 antenna control LNB 1 optimise skew 117

^/v/</>/MENU/OK/STOP

Installation menu

>basic setting

language outdoor unit satellite scan autom. satellite scan decoder/OSD childpro.contr.feat. ext. programmierung

^/v/OK/STANDBY

Autom.satellite scan

> satellite Hispasat 1 30W

channel TDeporte 12.149 GHz stored position 4816

STOP

antenna position 4816 start scan auto-focus LNB input 1 optimise skew 132

^/v/</>/MENU/OK/STOP

Decoder/OSD

MAC/Eurocrypt no

videopcrypt no

>TV SCART PAL

motortype A

STOP

^/v/</>/OK/STOP

Childpro. contr.feat.

>secret number

new secret number

STOP

repeat new secret number

0-9/STOP

External programmation

STOP

>target

source

^/v/</>/OK/STOP

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 18

6 Operation

STOP

6.1 Switching on and off

Preferably use the power-on switch to turn the receiver on and off.This saves power and the environment.

For brief operational breaks use the remote control function:

> Press to turn on and to switch to standby mode.

6.2 Selecting a channel

a) Using the ten-key keypad

1 2 3

Channel position 3

b) Press on the remote control

c) Using channel lists

> press twice for TV channels, or three times for radio channels

> press to set pointer to desired channel.

0 0 3

(wait 2 sec) Channel position 1

PROGR

or on the receiver

INDEX

Channel position 123

Netz

0 0 3

INDEX

STOP

> press or

> press to return to the channel previously selected.

The receiver only displays the channels of all stored satellites. Deleted channels (see 7.3) Are not displayed.

6.3 Selecting a satellite

a) By selecting a related channel, e.g.:

> Reflector peaks ASTRA and selects channel position 3.

b) Using the satellite list

> press once.

> press to set pointer to the desired satellite.

> press or

> press to return to the channel selected previously.

The receiver only displays the channels of all stored satellites.

6.4 Volume control

> press to turn down, or to turn up

> press to turn off completely.

6.5 TV/Radio control

The pre-programmed set of channels consists of 300 television and 200 radio channels. When receiving a radio channel,the TV screen is turned off and displays only the channel name on coloured background.

> Press .

Press this button to change from a TV channel back to the most recently selected radio channel, and vice versa.

Warning: If the most recent TV or radio channel belongs to a different satellite, the dish moves to the respective

satellite.

6.6 Displaying time and date

> Press .

6.7 Setting the timer

You may define up to 4 different power-on and power-off times (timer). For each timer setting, you can choose between a single,daily or weekly event. Check if the clock has been set correctly and correct the time,if necessary (see 6.10).

> Press .

> Press to set pointer to „Timer stellen“

> set timer

> Press .

> Press to set

pointer to e.g. “Timer 1“

> Press .

Example: Turn on PRO 7,ASTRA, on 21. January 1995 between 20.15 hrs and 22.00 hrs

> Press to set pointer successively to:

„channel“

„month“ „date“ „start“

„stop“

> Use or the

ten-key keypad to select.

> Press to turn off the timer and to quit the menu.

> Press twice to return to normal operation.

> Press for standby mode.

The display shows t 1 to symbolise timer mode.

If a timer has powered up the receiver you can only use the key to terminate the timer.

Daily or weekly timer events

Timer 1

timer off satellite ASTRA 19.2E

> channel 003 PRO7

month 01 1995 date 21 Saturday start 20:15 stop 22:00 type once

^/v/</>/0-9/OK/STOP

TV/RADIO

Main menu

>set timer

set time childproof control feature channel menu

^/v/OK/STOP

Set timer

>timer 1 off

timer 2 off timer 3 off timer 4 off

^/v/OK/STOP

0 0 3

0 1

2 1

1 9 9 5

2 0 1 5

2 2 0 0

STOP

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 19

> select timer (see above)

> press

to set pointer to „type“

> press

to select „daily“ or „weekly“

> press to set pointer to „terMinating date“

> press or use ten-key keypad to select.

> choose further settings as above.

The receiver powers up and down daily or weekly at the same time until the terminating date is reached.

Warning: Do not press (mains) to turn off the receiver while it is in timer mode!

6.8 Childproof control feature

Start by entering your secret code in the installation menu (see 5.8). The menu described below allows you to choose which radio and TV channels you want to protect. After this, all protected channels can only be accessed if the correct secret code has been entered. For easier control you only need to enter the secret code once. From then on, the number is valid until the receiver is switched to standby mode.

Example: You want to protect ARD, ASTRA,channel 001:

> press .

> press to set

pointer to „childproof control feature“.

> press .

> press to set

pointer to „TV channel list“

> press .

> press to jump

to channel 001

> press to protect (press to undo the protection)

Protected channels are marked with an L. Open the „radio channel list“ to protect radio channels in the same manner.

> press to return to normal operation.

6.9 Playing the video recorder

Receiver in standby mode:

> press the video recorder’s play button

Receiver in operational mode:

> press the video recorder’s play button.

Netz

STOP

Timer 1

timer off satellite ASTRA 19.2E channel 001 ARD month 01 1995 date 21 Sunday start 20:00 stop 20:15

>type daily

terminating date 27 12 1995

^/v/</>/0-9/OK/STOP

Childproof control feature

>TV channel list

radio channel list

^/v/OK/STOP

TV channel list

> L 001 ARD Astra 19,2O

002 ZDF Astra 19,2O 003 Pro Astra 19,2O 004 Sat Astra 19,2O 005 RTL Astra 19,2O

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 20

> press .

> press to terminate.

6.10 Setting the clock

The time and date settings are also retained after longer operational breaks.

> press .

> press to set

pointer to „set time“

> press .

Example: How to set the clock to 31.December 1995, 20.00 hrs

> press to set pointer successively to:

„hour“

„minute“

„month“

„date“

„year“

> press or use ten-key keypad to select.

> press to initialise clock.

> press to return to normal operation.

STOP

1 9 9

0 0

2 0

1 2

3 1

Set time

hour : 20 min : 00 month : 12 date : 31 Sunday year : 1995

^/v/</>/0-9/OK/STOP

TV/RADIO

VCR

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 21

Open the channel menu:

> press .

> press to set pointer to „channel menu“

> p

> press after making your changes to return to normal operation.

7.1 Copying channels

You can copy individual channels to different channel positions,e.g. to customise the channel sort order. The satellite settings will be retained, though; e.g.: if you copy an ASTRA channel to a position which has been occupied by a Kopernikus channel, the position is now related to the ASTRA satellite.

Example: how to copy Channel 3,Pro 7, to channel position 4

> select channel 3

> open the channel menu (see

above)

> press to set pointer to „copy

channel“

> press .

> press or use the ten-key keypad to choose the target (004 in example)

> press to copy

> after a few seconds

the receiver automatically returns to the channel menu.

> press to return to normal operation.

7.2 Changing channels

When changing the channels, all satellite settings will be retained.

Example: how to change channel 3, Pro 7, with channel 4,Sat 1

> select channel 3

> call the channel menu

(see page 23)

> press to set

the pointer to „changing channels“

> press .

> press or use the ten-key keypad to select the second channel (004 in example).

> after a few seconds the receiver automatically returns to the channel menu

> press to return to normal operation.

STOP

Set time

hour : 20 min : 00 month : 12 date : 31 Sunday year : 1995

^/v/</>/0-9/OK/STOP

Timer 1

timer off satellite ASTRA 19.2E

> channel 003 PRO7

month 01 1995 date 21 Saturday start 20:15 stop 22:00 type once

^/v/</>/0-9/OK/STOP

Main menu

>set timer

set time childproof control feat. channel menu

^/v/OK/STOP

Set timer

>timer 1 off

timer 2 off timer 3 off timer 4 off

^/v/OK/STOP

Childproof control feature

>TV channel list

radio channel list

^/v/OK/STOP

TV channel list

> L 001 ARD Astra 19,2O

002 ZDF Astra 19,2O 003 Pro Astra 19,2O 004 Sat Astra 19,2O 005 RTL Astra 19,2O

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 22

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 23

7 Changing the basic programmation

You cannot select a channel using the keys on the receiver or the keys of the remote control, once it is deleted. Neither does it appear in the list of channels (see 6.2). Deleted channels can only be

STOP

accessed when entering their channel number over the ten-

Channel menu

>outdoor unit

video settings audio settings copy channel change channel delete/open channel rename channel rename satellite new channels and satellites

^/v/OK/STOP

key keypad.

Example: How to delete channel 3, Pro 7

> select channel 3

> call the channel menu (see page 23)

> press to set pointer to „delete/open channe“

> press .

> press to delete

> after few seconds, the

receiver returns to the channel menu automatically.

Copy channel

from 003 Pro 7

>to 004 Sat 1

^/v/</>/0-9/OK/STOP

> select the channel using the ten-key keypad.

> proceed as described above.

7.4 Renaming channels

Example: how to rename channel 3, Pro 7, to Pro 8

> select channel 3.

> call up the channel menu (see page 23).

> press to set pointer to „rename channel“.

> press .

> press to select the

> press to activate the

> press to select the second letter („r“ in our example).

> press to activate the next letter,etc.

When all letters are set:

> press to store.

STOP

first letter („P“ in our example).

second letter.

Change channels

003 Pro 7

> with 004 Sat 1

^/v/</>/0-9/OK/STOP

How to recall a deleted channel:

> after a few seconds the receiver automatically returns to the

STOP

channel menu.

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 24

7.3 Deleting/recalling channels

> press to return to normal operation.

PROGR

Delete/call channel

delete channel ?

OK/STOP

Rename change

old name Pro 7

>new name Pro 8***

^/v/</>/OK/STOP

Delete/call channel

call channel ?

OK/STOP

STOP

7.5 Renaming satellites

Example: how to rename Astra to Astra 1

> select the Astra satellite.

> call up the channel menu (see page 23).

> press to set pointer to „rename satellite“

> press .

> select the

first letter („A“ in our example).

> press

to activate the second letter.

> press to select the second letter

(„s“ in our example).

> press for the next letter,etc.

When all letters are set:

> press to store.

> after a few seconds the receiver automatically returns to the channel menu.

> press to return to normal operation.

7.6 Configuring a decoder

Example: how to set up the Premiere decoder to receive Premiere channel at position 22, Astra (refer to 4.5 for

connection details)

> select channel 22.

> call up the channel menu (see page 23).

> press to set

pointer to „Videostellungen“ (video settings)

> press .

> press to set

pointer to „Decoder“

> press to switch to „Ext“ (external).

> press to set pointer to „Decodersignal“

(decoder signal).

> press to select „D4“.

Different decoders may require other decoder signal settings (refer to decoder instructions).

> press to store and to return to the installation menu.

> press to return to normal operation.

STOP

Rename satellite

old name Astra 19,2O

>new name Astra 1*********

^/v/</>/OK/STOP

Video settings

brightness 3 polarity Normal

>decoder Int

decoder signal D4

^/v/</>/MENU/OK/STOP

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 25

7.7 Setting up new channels

If required, you can add new channels to the pre-programmed set of channels. For this purpose, each satellite provides blank channel positions (marked by ********).

Example: How to programme RTL to channel position 143 (Hotbird 13° East). The information to do this is collected in the table of chapter 8, „Pre-programmed channels“, channel 128:

Transponder frequency: 11.596 MHz Polarisation level: Hor. skew + 100 Tuner bandwidth 36 MHz LNB input 1 Polarity: Normal Brightness: 2 Audio bandwidth: 130 kHz Deemphasis: TMSP Volume: 6 Audio frequency left channel: 7.02 MHz Audio frequency right channel: 7.20 Mhz Audio mode: Stereo

Warning: In all the menus described below, press the key to turn off the coloured screen background which is used to check the settings.

> select channel 143.

> call the channel menu (see page 23).

> press to set pointer to „new channels and satellites“.

> press . > press to set pointer to „channel“.

> press or use

the ten-key keypad to select 11.596 MHz.

> press to set

pointer to „LNB input“

> press to select 1.

> press to set pointer to „tuner bandwidth“

> press to select „36 MHz“.

> press to set pointer to „additional settings“.

> press to select the menu „outdoor unit“.

> press to set pointer to „AFC“.

> press to turn off.

> press to set

pointer to „optimise skew“.

> press to optimise.

> press to set pointer to „AFC“

> press to turn on. >

press to store the parameters selected in this menu and to turn to the menu „video settings“.

Press to select the next menu without memorising the settings. > press to set pointer to „brightness“.

> press to select 2.

New channels and satellites

satellite Hotbird-II F 1 13a

>channel ******** 11.221 GHz

stored position 5068 antenna position 5068 LNB input 1 tuner bandwidht 27 MHz additional settings signal level 077

^/v/</>/Index/MENU/OK/STOP

Outdoor unit

>skew +100

polarisation Skew 22 kHz Aus AFC An optimise skew signal level 175

^/v/</>/MENU/OK/STOP

STOP

*M-Focus 2.6.95 14.12.1999 10:36 Uhr Seite 26

> press to set

pointer to „polarity“.

> press to select „Normal“.

> press to store the

parameters selected in this menu and to turn to the menu „Audioeinstellungen“ (audio settings).

Press to select the next menu without memorising the settings.

> press to set

pointer to „audio bandwidth“.

> press to

select „130 kHz“.

> press to set

pointer to „Deemphase“

> press to select „TMSP“.

> press to set pointer to „basic volume“.

> press to select 6.

> press to set pointer to „mode“

> press to select „Stereo“.

> press to set pointer to „Freq. left“.

> press to select „7.02 MHz“.

As the „Voreinstellungen“ (pre-adjustments) function has been turned On, the audio frequency of the right channel automatically changes to 7.20 MHz. Turn off the „Voreinstellung“ (pre-adjustment) setting to select separate frequencies and smaller increments on both audio channels.

> press to store the parameters selected in this menu and to return to the menu „Neue Programme und

Satelliten“.

Press to select the next menu without memorising the settings.

> press to set pointer to „Programm“ (channel).

> press .

> press to select a new name and press to store.

> press to store and to return to the channel menu.

> press to revert to normal operation.

The new name appears once you have changed channels.

Video settings

brightness 3

> polarity Normal

decoder Int decoder signal D4

^/v/</>/MENU/OK/STOP

INDEX

STOP

Audio settings

>audio bandwidth 130 kHz

deemphasis TMSP basic volume 6 pre-adjustments An mode Stereo freq. left 7.02 MHz freq. right 7.20 MHz

^/v/</>/0-9/MENU/OK/STOP

*M-Focus 2.6.95 14.12.1999 10:37 Uhr Seite 27

7.8 Setting up new satellites

The pre-programmed set of channels consists of 300 television and 200 radio channels broadcast by the 18 most popular satellites. Those can be set up very easily using the installation menu (see 5.4). However, the pre-programmation also covers another 26 satellite names without channel assignations. Moreover, you can set up other satellites which are not covered in the preprogrammation. This assumes that you know the broadcasting data of at least one of the satellite’s channels and its position. Since all channel positions are already covered by satellites you may need to overwrite the channels.

General procedure:

> peak a pre-programmed satellite whose position is close to the new one.

> select unwanted channels on the peaked satellite.

> open the menu „new channels and satellites“ to select a new satellite name.

> change the channel settings.

> scan the satellite.

> store its position.

> set up further channels by copying them,as desired.

Example: This assumes that Eutelsat II F3 at 16° East has already been selected.The new satellite to set up

is Astra at 19.2° East.

Warning: In all the menus described below, press the key to turn off the coloured screen background

which is used to check the settings.

> select channel 127.

The receiver selects Eutelsat II F3 at 16° East,displaying channel „********“.

> call the channel menu (see page 23).

> press to set pointer to „Neue Programme und Satelliten“ (new channels and satellites).

> press .

> press to set pointer to „Satellit“.

> press to select a blank satellite name („********“).

> press .

> press

to select a new

name and to press

to store.

New channels and satellites

satellite Eutels.II F3 16O

>channel ******** 11.678 GHz

stored position 5037 antenna position 5037 LNB input 1 tuner bandwidth 27 MHz additional settings signal level 175

^/v/</>/Index/MENU/OK/STOP

New channels and satellites

satellite Astr************

>channel ******** 11.678 GHz

stored position 5037 antenna position 5037 LNB input 1 tuner bandwidth 27 MHz additional settings signal level 175

^/v/</>/Index/MENU/OK/STOP

INDEX

*M-Focus 2.6.95 14.12.1999 10:37 Uhr Seite 28

*M-Focus 2.6.95 14.12.1999 10:37 Uhr Seite 29

Channel data (taken from table in chapter 8, „Vorprogrammierte Programme“ (pre-programmed channels),channel 3, Pro 7)

Transponder frequency: 11.406 MHz Polarisation level: Vert. skew 000 Tuner bandwidth 27 MHz LNB input 1 Polarity: Normal Brightness: 3 Audio bandwidth: 130 kHz Deemphasis: TMSP Volume: 6 Audio frequency left channel: 7.02 MHz Audio frequency right channel: 7.20 MHz Audio mode: Stereo

> select channel data of Pro 7 (see 7.7).

Turn off the AFC option and set the skew parameter to 0.

> press to set pointer to „antenna position“

> press to turn off background.

> press briefly.

The reflector moves East.

> briefly press when satellite has been found.

> press to set pointer to „channel“.

> press .

> press to select a new name and press to

INDEX

store.

> open the menu „Ausseneinheit“ (outdoor unit) to optimise the

skew value,turn on the AFC option and store.

> press to return to the channel menu.

> press to return to normal operation.

STOP

The new channel name is displayed once you have changed channels.

> press to set up exact position.

> press to set pointer to „stored position“.

> press to store.

*M-Focus 2.6.95 14.12.1999 10:37 Uhr Seite 30

7.9 Menu overview

STOP

Main menu

>set timer

set time childproof control feat. channel menu

^/v/OK/STOP

STOP

Channel menu

>outdoor unit

video settings audio settings copy channel change channel delete/open channel rename channel rename satellite new channels and satellites

^/v/OK/STOP

STOP

Delete/call channel

Rename satellite

Copy channel

from 003 Pro 7

>to 004 Sat 1

^/v/</>/0-9/OK/STOP

delete channel ?

OK/STOP

old name Astra 19,2O

>new name Astra 1*********

^/v/</>/OK/STOP

STOP

Change channels

003 Pro 7

> with 004 Sat 1

^/v/</>/0-9/OK/STOP

Rename channel

old name Pro 7

>new name Pro 8***

^/v/</>/OK/STOP

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 31

STOP

Main menu

>set timer

set time childproof control feat. channel menu

^/v/OK/STOP

STOP

Channel menu

>outdoor unit

video settings audio settings copy channel change channel delete/open channel rename channel rename satellite new channels and satellites

^/v/OK/STOP

STOP

outdoor unit

>skew +100

polarisation skew 22 kHz off AFC on optimise skew signal level 175

^/v/</>/MENU/OK/STOP

New channels and satellites

satellite Astra 19,2O

>channel Cartoon/ 11.023 GHz

stored position 5048 antenna position 5048 LNB input 1

tuner bandwidth 27 MHz additional sett. signal level 175

^/v/</>/Index/MENU/OK/STOP

STOP

Video settings

brightness 3

>polarity normal

decoder Int decoder level D4

^/v/</>/MENU/OK/STOP

Outdoor unit

STOP

>skew +100

polarisation skew 22 kHz off AFC on optimise skew signal levell 175

^/v/</>/MENU/OK/STOP

Audio settings

>audio bandwidth 130 kHz

deemphase TMSP basic volume 6 pre-adjustments on mode stereo freq. left 7.02 MHz freq. right 7.20 MHz

^/v/</>/0-9/MENU/OK/STOP

STOP

Audio settings

>audio bandwidth 130 kHz

deemphase TMSP basic volume 6 pre-adjustments on mode stereo freq. left 7.02 MHz freq. right 7.20 MHz

^/v/</>/0-9/MENU/OK/STOP

STOP

Video settings

brightness 3

>polarity normal

decoder Int decoder signal D4

^/v/</>/MENU/OK/STOP

STOP

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 32

8 Pre-programmed channels

8.1 Television channels

AudioVideo

Frequency

Position

Channel

name

Transponder

freq.(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

ASTRA 19,2° East

1 ARD 11494 27 H 3 7,02 7,2 130 S TMSP 5 2 ZDF 10964 27 H 3 7,02 7,2 130 S TMSP 5 3 Pro 7 11406 27 V 3 7,02 7,2 130 S TMSP 5 4 Sat 1 11288 27 V 3 7,02 7,2 130 S TMSP 5 5 RTL 11229 27 V 3 7,02 7,2 130 S TMSP 5 6 RTL 2 11214 27 H 3 7,02 7,2 130 S TMSP 5 7 Vox 11273 27 H 3 7,02 7,2 130 S TMSP 5 8 3 Sat 11347 27 V 3 7,02 7,2 130 S TMSP 5

9 West 3 11053 27 H 3 7,02 7,2 130 S TMSP 5 10 Bayern 3 11141 27 H 3 7,02 7,2 130 S TMSP 5 11 S 3 11186 27 V 3 7,02 7,2 130 S TMSP 5 12 N 3 11582 27 H 3 7,02 7,2 130 S TMSP 5 13 MDR 3 11112 27 H 3 7,02 7,2 130 S TMSP 5 14 DSF 11523 27 H 3 7,02 7,2 130 S TMSP 5 15 Eurosport 11259 27 V 3 7,2 7,2 130 M TMSP 5 16 n-tv 11641 27 H 3 7,02 7,2 130 S TMSP 5 17 MTV Euro 11421 27 H 3 7,02 7,2 130 S TMSP 5 18 Cartoon/TNT 11023 27 H 3 7,02 7,2 130 S TMSP 5 19 CNN 11627 27 V 3 7,02 7,02 130 M TMSP 5 20 Sky News 11377 27 V 3 7,02 7,2 130 S TMSP 5 21 Galavision 11127 27 V 3 7,02 7,2 130 S TMSP 5 22 Premiere 11464 27 H 3 7,02 7,2 130 S TMSP 5 23 Teleclub 11332 27 H 3 7,02 7,2 130 S TMSP 5 24 RTL 4 11391 27 H 3 7,02 7,2 130 S TMSP 5 25 RTL 5 10936 27 V 3 7,02 7,2 130 S TMSP 5 26 S Movies 11436 27 V 3 7,02 7,2 130 S TMSP 5 27 MovieCh. 11479 27 V 3 7,02 7,2 130 S TMSP 5

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Volume

AudioVideo

Frequency

name

Position

Channel

28 S.M.Gold 11597 27 V 3 7,02 7,2 130 S TMSP 5 29 S.Sports 11509 27 V 3 7,02 7,2 130 S TMSP 5 30 SSports2 11171 27 H 3 7,02 7,2 130 S TMSP 5 31 Sky One 11318 27 V 3 7,02 7,2 130 S TMSP 5 32 Nickelodeon 11156 27 V 3 7,02 7,2 130 S TMSP 5 33 Bravo/Ad 11097 27 V 3 7,02 7,2 130 S TMSP 5 34 Discover 11082 27 H 3 7,02 7,2 130 S TMSP 5 35 TCC/F.Ch 10994 27 H 3 7,02 7,2 130 S TMSP 5 36 UK Gold 11553 27 H 3 7,02 7,2 130 S TMSP 5 37 QVC 11038 27 V 3 7,02 7,2 130 S TMSP 5 38 UK Living 10979 27 V 3 7,02 7,2 130 S TMSP 5 39 JSTV/CMT 11568 27 V 3 7,02 7,2 130 S TMSP 5 40 VH 1 11538 27 V 3 7,02 7,2 130 S TMSP 5 41 Mini Max 11009 27 V 3 7,02 7,2 130 S TMSP 5 42 Cine Classics 11068 27 V 3 7,02 7,2 130 S TMSP 5 43 Cinemania 11656 27 V 3 7,02 7,2 130 S TMSP 5 44 Documania 11686 27 V 3 7,02 7,2 130 S TMSP 5 45 FilmNet 10921 27 H 3 7,02 7,2 130 S TMSP 5 46 FilmNet+ 11362 27 H 3 - - - - - 47 TV 1000 11303 27 H 3 - - - - - 48 TV3 Schw 11244 27 H 3 - - - - - 49 TV3 Daen 11612 27 H 3 - - - - - 50 TV3 Norw 11671 27 H 3 - - - - - 51 Arte 10714 27 H 3 7,02 7,2 130 S TMSP 5 52 NBC Super 10729 27 V 3 7,02 7,2 130 S TMSP 5 53 RTL Disney 10744 27 H 3 7,02 7,2 130 S TMSP 5 54 RTL 4 10758 27 V 3 7,02 7,2 130 S TMSP 5 55 Sky Mov. 2 10773 27 H 3 7,02 7,2 130 S TMSP 5 56 TV Asia 10788 27 V 3 7,02 7,2 130 S TMSP 5 57 Teleclub 10803 27 H 3 7,02 7,2 130 S TMSP 5 58 H.O.T. 10817 27 V 3 7,02 7,2 130 S TMSP 5 59 Movie Ch.2 10832 27 H 3 7,02 7,2 130 S TMSP 5 60 Sky Arts 10847 27 V 3 7,02 7,2 130 S TMSP 5 61 VH 1 Germ. 10862 27 H 3 7,02 7,2 130 S TMSP 5

Transponder

freq.(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Volume

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 33

AudioVideo AudioVideo

Frequency

name

Position

Channel

62 RTL Veron. 10876 27 V 3 7,02 7,2 130 S TMSP 5 63 Beta Spart. 10891 27 H 3 7,02 7,2 130 S TMSP 5 64 Kabel Plus 10906 27 V 3 7,02 7,2 130 S TMSP 5

Transponder

freq.(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Intelsat 602 63° East

65 RETE 4 11011 36 H 2 6,6 6,6 350 M J17 0 66 Cinques. 11055 36 H 2 6,6 6,6 350 M J17 0 67 Italia 1 11137 36 H 2 6,6 6,6 350 M J17 0 68 Canale 5 11173 36 H 2 6,6 6,6 350 M J17 0 69 IRIB TV1 11155 36 V 2 6,8 6,8 350 M J17 0 70 IRIB TV2 11002 36 V 2 6,8 6,8 350 M J17 0 71 IRIB TV3 11100 36 V 2 6,8 6,8 350 M J17 0 72 ******** 11406 36 V 2 7,02 7,2 130 S TMSP 5 73 ******** 11406 36 V 2 7,02 7,2 130 S TMSP 5 74 ******** 11173 36 H 2 6,6 6,6 350 M J17 0 75 ******** 11173 36 H 2 6,6 6,6 350 M J17 0

Intelsat 604 60° East

76 TRT 1 11647 36 H 2 6,8 6,8 350 M J17 0 77 TRT 2 11683 36 H 2 6,8 6,8 350 M J17 0 78 TRT 3 11138 36 H 2 6,8 6,8 350 M J17 0 79 TRT 4 10974 36 H 2 6,8 6,8 350 M J17 0 80 ******** 11010 36 H 2 6,6 6,6 350 M J17 0 81 ******** 11034 36 H 2 6,8 6,8 350 M J17 0

Türksat 1B 42° East

82 Show TV 11175 36 H 2 6,6 6,6 350 M J17 0 83 Kanal 6 11080 36 H 2 6,6 6,6 350 M J17 0 84 TRT Avr. 11472 36 V 2 6,6 6,6 350 M J17 0 85 ******** 10970 36 V 2 6,6 6,6 350 M J17 0 86 Kanal D 11012 36 V 2 6,6 6,6 350 M J17 0 87 TRT 1 11556 36 H 2 6,6 6,6 350 M J17 0 88 TRT 2 11592 36 H 2 6,6 6,6 350 M J17 0 89 TRT 3 11644 36 H 2 6,6 6,6 350 M J17 0

Volume

Frequency

name

Position

Channel

90 TRT 4 11680 36 H 2 6,6 6,6 350 M J17 0 91 Kanal D 11030 36 H 2 6,6 6,6 350 M J17 0 92 ******** 10980 36 H 2 6,6 6,6 350 M J17 0 93 ******** 11130 36 H 2 6,6 6,6 350 M J17 0 94 ******** 11678 36 V 2 6,6 6,6 350 M J17 0

Transponder

freq.(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

DSF Kopernikus 2 28,5° East

95 ******** 11486 36 H 2 6,6 6,6 350 M J17 0 96

Niedersachsen 97 NordLive 12625 36 H 2 6,65 6,65 200 M 50uS 2 98 ******** 11525 36 H 2 6,65 6,65 200 M 50uS 2 99 ******** 11475 36 H 2 6,65 6,65 200 M 50uS 2

12725 36 V 2 6,65 6,65 200 M 50uS 2

DSF Kopernikus 1 23,5° East

100 PRO 7 12559 36 H 2 7,38 7,56 130 S TMSP 5 101 ******** 11625 36 H 2 7,38 7,56 130 S TMSP 5 102 SAT1 11475 36 H 2 7,02 7,2 130 S TMSP 5 103 ******** 11675 36 H 2 7,38 7,56 130 S TMSP 5 104 ******** 11525 36 H 2 7,02 7,2 130 S TMSP 5 105 Vox 11600 36 V 2 7,02 7,2 130 S TMSP 5 106 ARTE 11549 36 V 2 7,02 7,2 130 S TMSP 5 107 DSF 12692 36 H 2 7,38 7,56 130 S TMSP 5 108 Premiere 12591 36 V 2 7,02 7,2 130 S TMSP 5 109 ******** 12725 36 V 2 7,02 7,2 130 S TMSP 5 110 ******** 12524 36 V 2 6,65 6,65 200 M 50uS 2

Eutelsat II-F3 16° East

111 RTM Mar. 10972 36 V 2 6,6 6,6 280 M 50uS 1 112 Canal+ 11617 36 V 2 6,6 6,6 280 M 50uS 5 113 TV7 Tun. 11659 36 V 2 6,6 6,6 280 M 50uS 1 114 EUROSTEP 10987 36 H 2 6,65 6,65 200 M 50uS 2 115 TGRT 11095 36 V 2 6,65 6,65 280 M 50uS 1 116 EgyptSat 11178 36 V 2 6,6 6,6 280 M 50uS 1 117 Muslim TV 11575 36 V 2 6,5 6,5 280 M 50uS 1

Volume

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 34

AudioVideo AudioVideo

Frequency

name

Position

Channel

118 Duna TV 11596 36 H 2 6,6 6,6 280 M 50uS 1 119 Polonia 11081 36 H 2 7,02 7,2 130 S TMSP 5 120 Polsat 11638 36 H 2 6,65 6,65 280 M 50uS 1 121 TV Plus 11556 36 H 2 - - - - - 122 Business-TV 11163 36 H 2 6,6 6,6 280 M 50uS 1 123 Algerian 11678 36 H 2 6,6 6,6 280 M 50uS 1 124 Nile TV 11145 36 V 2 6,65 6,65 280 M 50uS 1 125 TGRT-Zus 11063 36 V 2 6,65 6,65 280 M 50uS 1 126 ******** 11678 36 H 2 6,6 6,6 280 M 50uS 1 127 ******** 11678 36 H 2 6,6 6,6 280 M 50uS 1

Transponder

freq.(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Hotbird und Eutelsat II-F1 13° East

128 RTL 11596 36 H 2 7,02 7,2 130 S TMSP 5 129 RTL 2 11095 36 H 2 7,02 7,2 130 S TMSP 5 130 D.W. TV 11163 36 V 2 6,65 6,65 200 M 50uS 2 131 MTV Euro 11659 36 V 2 7,02 7,2 130 S TMSP 5 132 VIVA 11005 36 H 2 7,02 7,2 130 S TMSP 5 133 Eurosport 10972 36 H 2 7,2 7,2 130 M TMSP 5 134 Euronews 11575 36 V 2 6,65 6,65 280 M 50uS 1 135 BBC News 11617 36 V 2 7,02 7,2 130 S TMSP 5 136 Kabelkanal 11055 36 H 2 7,02 7,2 130 S TMSP 5 137 TRT int 11181 36 H 2 6,65 6,65 200 M 50uS 2 138 mbc 11555 36 H 2 7,02 7,2 130 S TMSP 5 139 EDTV 11638 36 H 2 7,02 7,2 130 S TMSP 5 140 Polonia1 11678 36 H 2 6,6 6,6 280 M 50us 1 141 Super Ch 10987 36 V 2 7,2 7,2 130 M TMSP 5 142 TV5 Euro 11080 36 V 2 6,6 6,6 280 M 50us 1 143 TVE int. 11221 36 H 2 7,02 7,2 130 S TMSP 5 144 MTV Euro 11232 36 V 2 7,02 7,2 130 S TMSP 5 145 EBN 11262 36 H 2 7,02 7,2 130 S TMSP 5 145 Sci-Fi/ART 11283 36 V 2 7,02 7,2 130 S TMSP 5 147 MCM Euro 11304 36 H 2 - - - - - 148 TV 5 Euro 11325 36 V 2 7,02 7,2 130 S TMSP 5 149 Premiera 11345 36 H 2 7,02 7,2 130 S TMSP 5

Volume

Frequency

name

Position

Channel

150 Super RTL 11366 36 V 2 7,02 7,2 130 S TMSP 5 151 Eurosport 11387 36 H 2 7,02 7,2 130 S TMSP 5 152 C. Horizons 11408 36 V 2 - - - - - 153 TV Pol. 11428 36 H 2 7,02 7,2 130 S TMSP 5 154 RAI UNO 11449 36 V 2 7,02 7,2 130 S TMSP 5 155 NPT Pol. 11471 36 H 2 7,02 7,2 130 S TMSP 5 156 RAI DUE 11492 36 V 2 7,02 7,2 130 S TMSP 5 157 EDTV 11513 36 H 2 7,02 7,2 130 S TMSP 5 158 RTL 7 11534 36 V 2 7,02 7,2 130 S TMSP 5 159 Reuters 12521 36 H 2 6,65 6,65 200 M 50uS 2 160 Kindera. 12563 36 H 2 6,65 6,65 200 M 50uS 2 161 UberTra. 12584 36 V 2 6,65 6,65 200 M 50uS 2 162 ******** 11534 36 V 2 7,02 7,2 130 S TMSP 5 163 ******** 11596 36 H 2 7,02 7,2 130 S TMSP 5 164 ******** 12725 36 V 2 7,02 7,2 130 S TMSP 5 165 ******** 12725 36 V 2 7,02 7,2 130 S TMSP 5 166 ******** 11678 36 H 2 7,02 7,2 130 S TMSP 5 167 ******** 11678 36 H 2 7,02 7,2 130 S TMSP 5 168 ******** 11138 36 V 2 6,65 6,65 200 M 50uS 2 169 ******** 12583 36 V 2 6,65 6,65 200 M 50uS 2 170 ******** 12583 36 V 2 6,65 6,65 200 M 50uS 2

Transponder

freq.(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Eutelsat II-F2 10° East

171 RAI UNO 10972 36 V 2 6,6 6,6 350 M J17 0 172 RAI DUE 11095 36 V 2 6,6 6,6 350 M J17 0 173 ******** 11575 36 V 2 6,65 6,65 280 M 50uS 1 174 Int.STAR 11617 36 V 2 6,65 6,65 280 M 50uS 1 175 RTP 11659 36 V 2 6,6 6,6 280 M 50uS 1 176 Aktif TV 10987 36 H 2 6,65 6,65 280 M 50uS 1 177 TVE Int. 11149 36 H 2 6,65 6,65 280 M 50uS 1 178 ******** 11077 36 H 2 6,65 6,65 280 M 50uS 2 179 AFN TV 11178 36 V 2 6,65 6,65 200 M 50uS 2 180 Satel 2 11017 36 H 2 6,65 6,65 280 M 50uS 1 181 ******** 11596 36 H 2 6,65 6,65 200 M 50uS 2

Volume

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 35

AudioVideo

Frequency

Position

Channel

name

Transponder

freq.(MHz)

Tuner band-

Polarisation

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Eutelsat II-F4 7° East

182 ******** 12583 36 V 2 6,65 6,65 200 M 50uS 2 183 RIK Nik. 11144 36 H 2 6,6 6,6 280 M 50uS 1 184 EPT-ET 1 11178 36 H 2 6,6 6,6 280 M 50uS 1 185 ******** 11133 36 V 2 6,6 6,6 280 M 50uS 1 186 ******** 11575 36 V 2 6,6 6,6 280 M 50uS 1

Tele X und Sirius 5° East

187 TV3 Sve. 11785 27 R 3 6,5 6,5 200 M 50uS 2 188 TV4 Sve. 11938 27 R 3 7,02 7,2 130 S TMSP 5 189 TV 6 11862 27 R 3 6,5 6,5 200 M 50uS 2 190 Z-TV 12092 27 R 3 6,5 6,5 200 M 50uS 2 191 Femman 12475 27 L 3 7,02 7,2 130 S TMSP 5 192 FilmMax 12015 27 R 3 - - - - - 193 STV 2 12322 27 L 3 - - - - - 194 ******** 11658 36 V 2 6,65 6,65 200 M 50uS 2 195 ******** 11638 36 H 2 6,65 6,65 200 M 50uS 2 196 ******** 11747 27 L 3 7,02 7,2 130 S TMSP 5 197 ******** 11823 27 L 3 7,02 7,2 130 S TMSP 5 198 ******** 11900 27 L 3 7,02 7,2 130 S TMSP 5 199 ******** 12054 27 L 3 7,02 7,2 130 S TMSP 5 200 ******** 11977 27 L 3 7,02 7,2 130 S TMSP 5 201 ******** 11617 36 V 2 6,65 6,65 200 M 50uS 2

Thor und Intelsat 702 1° West

202 CNN Nor. 11785 27 R 3 - - - - - 203 Eurosport 11862 27 R 3 - - - - - 204 Filmnet 12015 27 R 3 - - - - - 205 Discover 11938 27 R 3 - - - - - 206 MTV Euro 12092 27 R 3 - - - - - 207 ******** 11783 36 R 2 - - - - - 208 ******** 11783 36 R 2 - - - - - 209 TV Norge 11016 27 H 3 6,6 6,6 280 M 50uS 1 210 TV3Norge 11096 27 H 3 - - - - - -

Volume

AudioVideo

Frequency

name

Position

Channel

211 NRK 11176 27 H 3 7,02 7,2 130 S TMSP 5 212 Norsk TV 11555 27 H 3 - - - - - 213 Kanal 1 11679 27 H 3 - - - - - 214 TV 1000 11054 27 V 3 - - - - - 215

TV1000 Cinema

216 TV3 Danmark 11597 27 V 3 - - - - - 217 ******** 11013 27 V 3 - - - - - 218 ******** 11016 36 H 2 - - - - - -

Transponder

freq.(MHz)

11478 27 V 3 - - - - - -

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Telecom 2B 5° West

219 M6 12522 36 V 2 5,8 5,8 280 M J17 0 220 France 2 12564 36 V 2 5,8 5,8 280 M J17 0 221 La Cinq 12606 36 V 2 5,8 5,8 280 M J17 0 222 TF1 12690 36 V 2 5,8 5,8 280 M J17 0 223 RTL Fr. 12732 36 V 2 6,6 6,6 280 M J17 0 224 LaChaine 12585 36 H 2 6,6 6,6 280 M J17 0 225 T.M.C. 12648 36 V 2 5,8 5,8 280 M J17 0 226 Cinefil 12627 36 H 2 5,8 5,8 280 M J17 0 227 Cinemas 12669 36 H 2 - - - - - 228 RTL 12544 36 H 2 6,6 6,6 280 M J17 0 229 ******** 12544 36 H 2 5,8 5,8 280 M J17 0

Telecom 2A 8° West

230 MCM Euro 12543 36 H 2 7,02 7,2 130 S TMSP 5 231 Planete 12585 36 H 2 5,4 6,6 130 S TMSP 5 232 Cinefil 12627 36 H 2 6,6 6,6 130 M TMSP 5 233 Cinemas 12669 36 H 2 6,6 6,6 130 M TMSP 5 234 Eurosport 12711 36 H 2 6,6 6,6 130 M TMSP 5 235 ParisPlu 12564 36 V 2 6,6 6,6 130 M TMSP 5 236 Canal + 12648 36 V 2 6,6 6,6 130 M TMSP 5 237 Canal J 12732 36 V 2 6,6 6,6 130 M TMSP 5 238 Canal + 12522 36 V 2 - - - - - 239 Fr.S.Vis 12606 36 V 2 7,02 7,2 130 S TMSP 5 240 CineCine 12690 36 V 2 - - - - - -

Volume

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 36

AudioVideo

Frequency

name

Position

Channel

241 ******** 10500 36 H 2 5,4 6,6 130 S TMSP 5 242 ******** 10500 36 H 2 5,4 6,6 130 S TMSP 5 243 ******** 11016 36 H 2 6,6 6,6 280 M 50uS 2 244 ******** 11133 36 H 2 6,6 6,6 280 M 50uS 2 245 ******** 11177 36 H 2 6,6 6,6 280 M 50uS 2 246 ******** 11539 36 H 2 6,6 6,6 280 M 50uS 2 247 ******** 11681 36 H 2 6,6 6,6 280 M 50uS 2 248 ******** 11681 36 H 2 6,6 6,6 280 M 50uS 2

Transponder

freq.(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

TDF 19° West

249 MCM Euro 12034 27 R 3 - - - - - 250 Canal + 11804 27 R 3 - - - - - 251 ARTE 11881 27 R 3 - - - - - 252 Canal Fr 11727 27 R 3 - - - - - 253 ******** 11958 27 R 3 - - - - - 254 ******** 12034 36 R 2 - - - - - -

Intelsat 601 27,5° West

255 TravelCh 11175 36 H 2 6,65 6,65 200 M 50uS 2 256 Uni.Art. 11052 36 H 2 6,65 6,65 200 M 50uS 2 257 Parl.Ch. 11080 36 H 2 6,65 6,65 200 M 50uS 2 258 CMT Euro 11515 36 V 2 7,02 7,2 130 S TMSP 5 259 FilmMax 11665 36 H 2 - - - - - 260 FilmNet 11647 36 V 2 7,02 7,2 130 S TMSP 5 261 BBC WS. 10995 36 V 2 - - - - - 262 SSVC TV 11562 36 V 2 7,02 7,2 130 S TMSP 5 263 SIS 11591 36 H 2 7,02 7,2 130 S TMSP 5 264 EBU 11055 36 V 2 6,65 6,65 200 M 50uS 2 265 EBU PVS 11476 36 V 2 6,65 6,65 200 M 50uS 2 266 ******** 11155 36 V 2 7,02 7,2 130 S TMSP 5 267 ******** 11135 36 H 2 7,02 7,2 130 S TMSP 5

Hispasat 1 30° West

268 TDeporte 12149 36 L 2 6,6 6,6 280 M 50uS 1 269 Classico 12226 36 L 2 6,6 6,6 280 M 50uS 1

Volume

AudioVideo

Frequency

name

Position

Channel

270 Canal+Es 12303 36 L 2 6,6 6,6 280 M 50uS 1 271 Telesat5 12380 36 L 2 6,6 6,6 280 M 50uS 1 272 Noticias 12456 36 L 2 6,6 6,6 280 M 50uS 1 273 La 2 11649 36 V 2 6,6 6,6 280 M 50uS 1 274 TVE 1 11678 36 V 2 6,6 6,6 280 M 50uS 1 275 Antena 3 12671 36 H 2 6,6 6,6 280 M 50uS 1 276 Canal+Es 12711 36 H 2 6,6 6,6 280 M 50uS 1 277 Tele5 Es 12631 36 V 2 6,6 6,6 280 M 50uS 1 278 ******** 11514 36 H 2 6,6 6,6 280 M 50uS 1 279 ******** 11594 36 H 2 6,6 6,6 280 M 50uS 1 280 ******** 11661 36 H 2 6,6 6,6 280 M 50uS 1 281 ******** 12540 36 H 2 6,6 6,6 280 M 50uS 1 282 ******** 12591 36 H 2 6,6 6,6 280 M 50uS 1 283 ******** 12631 36 H 2 6,6 6,6 280 M 50uS 1 284 ******** 11514 36 V 2 6,6 6,6 280 M 50uS 1 285 ******** 12544 36 V 2 7,02 7,2 130 S TMSP 5 286 ******** 12591 36 V 2 7,02 7,2 130 S TMSP 5 287 ******** 12671 36 V 2 6,65 6,65 200 M 50uS 2 288 ******** 12711 36 V 2 6,65 6,65 200 M 50uS 2

Transponder

freq.(MHz)

Polarisation

Tuner band-

Video control

width (MHz)

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Panamsat 1A

289 Galavision 11515 36 H 2 6,8 6,8 280 M 50uS 1 290 NHK 11675 36 H 2 6,8 6,8 280 M 50uS 1 291 ******** 11596 36 H 2 6,8 6,8 280 M 50uS 1 292 ******** 11639 36 H 2 6,8 6,8 280 M 50uS 1 293 ******** 11479 36 H 2 6,65 6,65 200 M 50uS 2 294 ******** 11560 36 H 2 6,65 6,65 200 M 50uS 2 295 ******** 10972 36 H 2 6,65 6,65 200 M 50uS 2 296 ******** 10987 36 V 2 6,65 6,65 200 M 50uS 2 297 ******** 11006 36 H 2 6,65 6,65 200 M 50uS 2 298 ******** 11055 36 H 2 6,65 6,65 200 M 50uS 2 299 ******** 12725 36 V 2 7,02 7,2 130 S TMSP 5 300 ******** 12725 36 V 2 7,02 7,2 130 S TMSP 5

Volume

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 37

8.2 Radioprogramme

AudioVideo

Frequency

Position

Channel

name

Frequency

(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

ASTRA 19,2° East

1 RadioROPA 11406 27 V 3 7,74 7,92 130 S TMSP 5 2

STAR*SAT Radio 3 D.Welle 11229 27 V 3 7,38 7,56 130 S TMSP 5 4 D.L.F. 11347 27 V 3 7,38 7,56 130 S TMSP 5 5 DRBerlin 11347 27 V 3 7,74 7,92 130 S TMSP 5 6 RTL R. 11391 27 H 3 7,38 7,56 130 S TMSP 5 7 SWF 3 11494 27 H 3 7,38 7,56 130 S TMSP 5 8 WDR1 11053 27 H 3 7,74 7,92 130 S TMSP 5 9 WDR 2 11053 27 H 3 7,38 7,56 130 S TMSP 5

10 NDR 2 11582 27 H 3 7,38 7,56 130 S TMSP 5 11 NDR 4 11582 27 H 3 7,74 7,92 130 S TMSP 5 12 N-Joy R. 11464 27 H 3 7,38 7,56 130 S TMSP 5 13 MDR Spud 11112 27 H 3 7,38 7,56 130 S TMSP 5 14 Virgin 11377 27 V 3 7,38 7,56 130 S TMSP 5 15 BBC 1 10979 27 V 3 7,38 7,56 130 S TMSP 5 16 BBC 2 11553 27 H 3 7,74 7,74 130 M TMSP 5 17 BBC 3 10979 27 V 3 7,74 7,92 130 S TMSP 5 18 BBC 4 11553 27 H 3 7,56 7,56 130 M TMSP 5 19 BBC 5 11553 27 H 3 7,92 7,92 130 M TMSP 5 20 BBC W.S. 11553 27 H 3 7,38 7,38 130 M TMSP 5 21 D.W.Fr.1 11229 27 V 3 7,74 7,74 130 M TMSP 5 22 D.W.Fr.2 11229 27 V 3 7,92 7,92 130 M TMSP 5 23 SRI Mix 11332 27 H 3 7,38 7,38 130 M TMSP 5 24 SRI Eng. 11332 27 H 3 7,56 7,56 130 M TMSP 5 25 Schweden 11597 27 V 3 7,74 7,74 130 M TMSP 5 26 WRN 1 11538 27 V 3 7,38 7,38 130 M TMSP 5 27 WRN D. 11538 27 V 3 7,74 7,74 130 M TMSP 5 28 R.Vlaand 10921 27 H 3 7,38 7,38 130 M TMSP 5 29 RTE R. 1 11538 27 V 3 7,56 7,56 130 M TMSP 5 30 CNN R. 11627 27 V 3 7,92 7,92 130 M TMSP 5

11406 27 V 3 7,38 7,56 130 S TMSP 5

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Mono/Stereo

Volume

Deemphasis

AudioVideo

Frequency

left (MHz)

Frequency

name

Position

Channel

31 R. Eviva 11332 27 H 3 7,74 7,74 130 M TMSP 5 32 Ir.Sat R 11538 27 V 3 7,92 7,92 130 M TMSP 5 33 RTL Rock 11391 27 H 3 7,74 7,92 130 S TMSP 5 34 SKY R. 11318 27 V 3 7,38 7,56 130 S TMSP 5 35 Radio538 11318 27 V 3 7,74 7,92 130 S TMSP 5 36 HitR.Hol 10936 27 V 3 7,56 7,56 130 M TMSP 5 37 R.S.Gold 11171 27 H 3 7,38 7,38 130 M TMSP 5 38 ASDA-FM1 11171 27 H 3 7,56 7,56 130 M TMSP 5 39 RMF FM 11421 27 H 3 7,74 7,92 130 S TMSP 5 40 UCB 11509 27 V 3 7,56 7,56 130 M TMSP 5 41 ERF/TWR 11038 27 V 3 7,38 7,38 130 M TMSP 5 42 SunriseR. 11479 27 V 3 7,38 7,38 130 M TMSP 5 43 IC R. 1 11288 27 V 3 7,74 7,74 130 M TMSP 5 44 IC R. 2 11288 27 V 3 7,92 7,92 130 M TMSP 5 45 IC R. 3 11288 27 V 3 8,15 8,15 130 M TMSP 5 46 IC R. 4 11288 27 V 3 8,24 8,24 130 M TMSP 5 47 IC R. 5 11288 27 V 3 8,35 8,35 130 M TMSP 5 48 IC R. 6 11288 27 V 3 8,48 8,48 130 M TMSP 5 49 ******** 11112 27 H 3 7,38 7,56 130 S TMSP 5 50 ******** 11126 27 V 3 7,38 7,56 130 S TMSP 5 51 ******** 11141 27 H 3 7,38 7,56 130 S TMSP 5 52 ******** 11156 27 V 3 7,38 7,56 130 S TMSP 5 53 ******** 11171 27 H 3 7,38 7,56 130 S TMSP 5 54 ******** 11186 27 V 3 7,38 7,56 130 S TMSP 5 55 ******** 10714 27 H 3 7,38 7,56 130 S TMSP 5 56 ******** 10729 27 V 3 7,38 7,56 130 S TMSP 5 57 ******** 10744 27 H 3 7,38 7,56 130 S TMSP 5 58 ******** 10758 27 V 3 7,38 7,56 130 S TMSP 5 59 ******** 10773 27 H 3 7,38 7,56 130 S TMSP 5

Frequency

(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

right (MHz)

IF band-

width (KHz)

Deemphasis

Mono/Stereo

Intelsat 602 63° East

60 IRIB R.1 11002 36 V 3 5,95 5,95 130 M TMSP 5 61 V.O.IRIB 11155 36 V 3 5,8 6,2 130 S TMSP 5 62 ******** 11095 36 H 3 5,95 5,95 130 M TMSP 5

Volume

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 38

AudioVideoAudioVideo

Frequency

name

Position

Channel

63 ******** 10906 36 V 3 5,95 5,95 130 M TMSP 5

Frequency

(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

left (MHz)

right (MHz)

IF band-

width (KHz)

Deemphasis

Mono/Stereo

Intelsat 604 60° East

TRT Radio Haber

65 R.DenDic 11136 36 H 3 8,28 8,28 130 M TMSP 5 66 H.R.-VoT 11650 36 H 3 8,28 8,28 130 M TMSP 5 67 TRT R.Di 11685 36 H 3 7,5 7,5 130 M TMSP 5 68 H.R.-VoT 11685 36 H 3 8,28 8,28 130 M TMSP 5

10992 36 H 3 8,28 8,28 130 M TMSP 5

Türksat 1B 42° East

69 R.Kuluep 11080 36 H 3 7,02 7,02 130 M TMSP 5 70 R.Kuluep 11080 36 H 3 7,56 7,56 130 M TMSP 5

DSF Kopernikus 2 28,5° East

Niedersachsen

72 Nord Live 12625 36 H 3 6,65 6,65 200 M 50uS 2 73 ******** 12625 36 H 3 6,65 6,65 200 M 50uS 2 74 ******** 12625 36 H 3 6,65 6,65 200 M 50uS 2

12725 36 V 3 6,65 6,65 200 M 50uS 2

DSF Kopernikus 1 23,5° East

75 Rad.ROPA 11475 36 H 3 7,74 7,92 130 S TMSP 5 76 D L F 11600 36 H 3 7,74 7,92 130 S TMSP 5 77

STAR*SAT Radio

78 RTL R. 11675 36 H 3 7,02 7,2 130 S TMSP 5 79 KlassicR 12591 36 H 3 7,38 7,56 130 S TMSP 5 80 Melodie 12559 36 H 3 7,02 7,2 130 S TMSP 5 81 D.R.BER. 11600 36 V 3 7,38 7,56 130 S TMSP 5 82 JAM FM. 11549 36 V 3 7,38 7,56 130 S TMSP 5 83 P.o.S. 11525 36 V 3 7,38 7,38 130 M TMSP 5 84 P.o.S. 11525 36 V 3 7,56 7,56 130 M TMSP 5 85 P.o.S. 11525 36 V 3 7,74 7,74 130 M TMSP 5 86 Buchm.Infos 11675 36 V 3 7,74 7,74 130 M TMSP 5 87 ******** 11675 36 V 3 6,65 6,65 200 M 50uS 2 88 ******** 11675 36 V 3 6,65 6,65 200 M 50uS 2

11475 36 H 3 7,38 7,56 130 S TMSP 5

Volume

Position

Channel

name

Frequency

(MHz)

Polarisation

Tuner band-

width (MHz)

Video control

Frequency

right (MHz)

left (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Frequency

Eutelsat II-F3 16° East

89 RTM (AB) 10972 36 V 3 7,02 7,02 130 M TMSP 5 90 RTM(Ber) 10972 36 V 3 7,56 7,56 130 M TMSP 5 91 ERTU M.E 11178 36 V 3 7,2 7,2 130 M TMSP 5 92 ERTU(AB) 11178 36 V 3 7,38 7,38 130 M TMSP 5 93 TRGT FM 11095 36 V 3 7,38 7,38 130 M TMSP 5 94 RTT Inte 11659 36 V 3 7,02 7,02 130 M TMSP 5 95 V.o.Arab 11178 36 V 3 7,02 7,02 130 M TMSP 5 96 RTT Arab 11659 36 V 3 7,2 7,2 130 M TMSP 5 97 Hrvatska 10987 36 H 3 7,02 7,02 130 M TMSP 5 98 Polskie 111081 36 H 3 7,38 7,56 130 S TMSP 5

99 Polskie 311081 36 H 3 7,74 7,92 130 S TMSP 5 100 Polskie 411081 36 H 3 8,1 8,1 130 M TMSP 5 101 Polskie 511081 36 H 3 8,28 8,28 130 M TMSP 5 102 Radio 111678 36 H 3 7,02 7,02 130 M TMSP 5 103 Radio 211678 36 H 3 7,2 7,2 130 M TMSP 5 104 LaChaine 11678 36 V 3 7,38 7,38 130 M TMSP 5 105 ******** 10972 36 V 3 6,65 6,65 200 M 50uS 2 106 ******** 10972 36 V 3 6,65 6,65 200 M 50uS 2

Hotbird und Eutelsat II-F1 13° East

107 D W. dt. 11163 36 V 3 7,02 7,2 130 S TMSP 5 108 D W. E2 11163 36 V 3 7,74 7,74 130 M TMSP 5 109 D W. E3 11163 36 V 3 7,92 7,92 130 M TMSP 5 110 D W. Asi 11163 36 V 3 8,28 8,28 130 M TMSP 5 111 D W. Afr 11163 36 V 3 8,46 8,46 130 M TMSP 5 112 R.Fr.Int 11080 36 V 3 7,38 7,38 130 M TMSP 5 113 R.FR.Inf 11080 36 V 3 7,2 7,2 130 M TMSP 5 114 Fr.Cult 11080 36 V 3 7,56 7,56 130 M TMSP 5 115 SRI Fr. 11080 36 V 3 7,74 7,74 130 M TMSP 5 116 VoA Euro 11163 36 V 3 7,38 7,56 130 S TMSP 5 117 RFE Pol. 11095 36 H 3 8,1 8,1 130 M TMSP 5 118 R.MBC FM 11554 36 H 3 7,38 7,56 130 S TMSP 5 119 WRN 2 11554 36 H 3 7,74 7,74 130 M TMSP 5

Volume

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 39

AudioVideoAudioVideo

name

Position

Channel

120 Finnland 11163 36 V 3 8,1 8,1 130 M TMSP 5 121 ******** 11554 36 H 3 7,74 7,74 130 M TMSP 5 122 ******** 11554 36 H 3 7,74 7,74 130 M TMSP 5 123 ******** 11554 36 H 3 7,74 7,74 130 M TMSP 5 124 ******** 11554 36 H 3 7,74 7,74 130 M TMSP 5 125 ******** 11554 36 H 3 7,74 7,74 130 M TMSP 5 126 ******** 11554 36 H 3 7,74 7,74 130 M TMSP 5 127 ******** 11554 36 H 3 7,74 7,74 130 M TMSP 5 128 ******** 11554 36 H 3 7,74 7,74 130 M TMSP 5

Frequency

(MHz)

Tuner band-

width (MHz)

Polarisation

Video control

Frequency

left (MHz)

IF band-

width (KHz)

Mono/Stereo

Deemphasis

Frequency

right (MHz)

Eutelsat II -F2 10° East

129 Glass FM 10987 36 H 3 7,02 7,02 130 M TMSP 5 130 Number 1 FM 10987 36 H 3 7,2 7,2 130 M TMSP 5 131 Yeni R. 10987 36 H 3 7,38 7,38 130 M TMSP 5 132 Kiss FM 10987 36 H 3 7,56 7,56 130 M TMSP 5 133 RNE R. 1 11077 36 H 3 7,38 7,38 130 M TMSP 5 134 RNE R.Ex 11077 36 H 3 7,56 7,56 130 M TMSP 5 135 SHOW R. 11575 36 V 3 7,02 7,2 130 S TMSP 5 136 Best FM 11575 36 V 3 7,38 7,56 130 S TMSP 5 137 R. Maria 11575 36 V 3 7,74 7,74 130 M TMSP 5 138 METRO FM 11617 36 V 3 7,02 7,2 130 S TMSP 5 139 Kral FM 11617 36 V 3 7,38 7,56 130 S TMSP 5 140 Super FM 11617 36 V 3 8,1 8,28 130 S J17 0 141 RTP INTE 11617 36 V 3 7,02 7,2 130 S TMSP 5 142 R.Renac1 11659 36 V 3 7,38 7,56 130 S TMSP 5 143 R.Renac2 11659 36 V 3 7,74 7,92 130 S TMSP 5 144 RDP Ante 11659 36 V 3 8,1 8,28 130 S J17 0 145 R.Comerc 11659 36 V 3 8,46 8,46 130 M J17 0 146 ******** 11659 36 V 3 8,46 8,46 130 M J17 0

Eutelsat II-F2 7° East

147 RIK R.3 11144 36 H 3 7,2 7,2 130 M TMSP 5 148 ******** 11010 36 V 3 7,38 7,56 130 S TMSP 5 149 ******** 11144 36 H 3 7,2 7,2 130 M TMSP 5

Volume

name

Position

Channel

150 ******** 11038 36 V 3 7,38 7,56 130 S TMSP 5

Frequency

(MHz)

Tuner band-

width (MHz)

Polarisation

Video control

Frequency

left (MHz)

IF band-

width (KHz)

Mono/Stereo

Volume

Deemphasis

Frequency

right (MHz)

Tele X und Sirius 5° East

151 Schweden 12475 36 L 3 7,38 7,38 130 M TMSP 5 152 TT News 12475 36 L 3 7,56 7,56 130 M TMSP 5 153 TheVoice 12475 36 L 3 7,74 7,92 130 S TMSP 5 154 ******** 12475 36 L 3 7,74 7,92 130 S TMSP 5 155 ******** 11472 36 H 3 7,38 7,56 130 S TMSP 5

Thor und Intelsat 702 1° West

156 Nettverk 11016 36 H 3 7,38 7,38 130 M TMSP 5 157 ******** 11016 36 H 3 7,38 7,38 130 M TMSP 5 158 ******** 10906 36 V 3 7,38 7,56 130 S TMSP 5

Telecom 2B 5° West

159 Unico 12648 36 V 3 6,4 6,4 130 M J17 0 160 R.M.C. 12648 36 V 3 6,85 8,2 130 S J17 0 161 RTL Fr. 12606 36 V 3 6,85 8,2 130 S J17 0 162 Classiqu 12606 36 V 3 7,75 8,65 130 S J17 0 163 PalapaFM 12564 36 V 3 6,4 6,4 130 M J17 0 164 CherieFM 12564 36 V 3 6,85 6,85 130 M J17 0 165 M 40 12564 36 V 3 7,25 8,2 130 S J17 0 166 Socielle 12564 36 V 3 7,75 8,65 130 S J17 0 167 Nostalgie 12606 36 V 3 7,25 7,25 130 M J17 0 168 Mosquet. 12522 36 V 3 6,4 6,4 130 M J17 0 169 Europe 1 12522 36 V 3 6,85 8,2 130 S J17 0 170 NonstopM 12522 36 V 3 7,25 7,25 130 M J17 0 171 APF R. 12522 36 V 3 7,75 7,75 130 M J17 0 172 Fourvere 12522 36 V 3 8,65 8,65 130 M J17 0 174 ******** 12522 36 V 3 7,38 7,56 130 S TMSP 5

Intelsat 601 27,5° West

175 VirginMR 11175 36 H 3 7,38 7,38 130 M TMSP 5 176 B.H.S. R 11175 36 H 3 7,74 7,74 130 M TMSP 5

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 40

AudioVideo

Frequency

name

Position

Channel

177 Texas FM 11175 36 H 3 8,1 8,1 130 M TMSP 5 178 BFBS 1 11562 36 V 3 7,02 7,02 130 M TMSP 5 179 BFBS 2 11562 36 V 3 6,12 6,12 130 M TMSP 5 180 BFBS 3 11562 36 V 3 6,3 6,3 130 M TMSP 5 181 BBC Ukr. 11562 36 V 3 7,2 7,2 130 M TMSP 5 182 BBC Euro 11562 36 V 3 7,56 7,56 130 M TMSP 5 183 BBC WS.B 11562 36 V 3 7,74 7,74 130 M TMSP 5 184 BBC WS.T 11562 36 V 3 8,1 8,1 130 M TMSP 5 185 ******** 11562 36 V 3 8,1 8,1 130 M TMSP 5 186 ******** 11515 36 V 3 7,38 7,56 130 S TMSP 5

Frequency

(MHz)

Polarisation

Tuner band-

Video control

width (MHz)

right (MHz)

left (MHz)

Mono/Stereo

IF band-

width (KHz)

Deemphasis

Hispasat 1 30° West

187 RNE Radio 2 12149 36 L 3 7,38 7,56 130 S TMSP 5 188 ******** 12631 36 V 3 7,2 7,2 130 M TMSP 5 189 RNE Radio 3 12226 36 L 3 7,38 7,56 130 S TMSP 5 190 Cadena 100 12671 36 H 3 7,02 7,2 130 S TMSP 5 191

Onda CeroRadio 192 Cad. COPE 12711 36 H 3 7,02 7,02 130 M TMSP 5 193

Onda c. Musica 194 Radio Top 40 12711 36 H 3 7,56 7,56 130 M TMSP 5 195

R.Galicia Ant 3 196 ******** 12631 36 V 3 7,2 7,2 130 M TMSP 5 197 ******** 12631 36 V 3 7,2 7,2 130 M TMSP 5

12671 36 H 3 7,38 7,56 130 S TMSP 5

12711 36 H 3 7,2 7,38 130 S TMSP 5

12631 36 V 3 7,2 7,2 130 M TMSP 5

PAS 1

198 Kiss FM 11515 36 H 3 7,4 7,4 130 M TMSP 5 199 ******** 12631 36 V 3 7,2 7,2 130 M TMSP 5 200 ******** 11515 36 H 3 7,4 7,4 130 M TMSP 5

Volume

H: Horizontal polarisation V: Vertical polarisation L: Left-moving polarisation R: Right-moving polarisation TMSP: TechniSat MultySoundProzessor Chip, deemphasis compatible to

Panda/Wegener

All channels: Decoder internal (no external decoder connected)

Decoder signal = D4 (video signal) Polarity = normal (Ku band) 22 kHz modulation disabled AFC option enabled LNB input 1

Pre-programmed skew values

Satellit Horizontal/11GHz Horizontal/12 GHz

DFS Kopernikus 2 28,5° East 100 100 DFS Kopernikus 1 23,5° East 75 46 ASTRA 80 Eutelsat II F3 16° East 75 Hotbird/Eut. II F1 13° East 90 90 Eutelsat II F2 10° East 100 Eutelsat II F4 7° East 100 5° East -85 (left-moving) 115 (right-moving) 1° West 100 115 (right-moving) Telecom 2B 5° West - 58 Telecom 2A 8° West - 58 TDF 19° West 126 (right-moving) Intelsat 601 27,5° West 75 Hispasat 1A/1B 30° West 53 53

50 (left-moving)

PanAmSat 1 45° West 100 -

skew value,vertical polarisation for all channels 0

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 41

9 Troubleshooting notes

Error Possible cause Measures

No picture, no sound, display is off

No picture, no sound, display is on

Screen display „Pulse count error“

Screen display „Motor overload“

Screen display „Auto-focus error“

Outdoor unit moves in wrong direction

The automatic satellite scan feature does not find any satellites

The automatic satellite scan feature does not find a number of satellites

Outdoor unit moves but does not find any satellite positions

No supply voltage

cable connection is broken or missing

television set is set to the wrong channel

wrong outdoor unit selected

cable connection is broken or missing

you have reached the East or West limit

The power requirements of the connected motor are too high

Due to a weak receive signal,auto-focus could not detect optimal positioning; receiver uses the stored position

motor connections M1 and M2 exchanged

automatic scan only works from West to East

Low receive quality Other satellites are using the same broadcasting frequencies

wrong outdoor unit selected outdoor unit trajectory adjusted incorrectly polarizer mounted incorrectly

check mains cable and connector

check all cable connections (see 4 „Connections“)

set channel 39 on the television set (see operating instructions of the TV set)

select the right outdoor unit

check all cable connections (see 4 „Connections“)

move dish in reverse direction

Use an appropriate motor

not necessary

change motor connections M1 and M2

first of all, select the westernmost satellite (see 5.4)

select manually (see 5.4) select manually (see 5.4)

consult a specialist to have the trajectory adjusted correctly

mount the polarizer according to the instructions

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 42

Error Possible cause Measures

Some satellites have good others have a bad receive quality

The channels of a particular satellite have different receive qualities

Some channels of a particular satellite cannot be received at all

Some satellites and channels are missing in the list of satellites or channels, resp.

The receive quality of some satellites has become lower

All satellite channels display “wavy lines“

A channel that is received via antenna displays “wavy lines“

The picture is full of black and white points (“little fish“)

Sound ok., no picture

Picture ok., no sound

Channel picture or sound disturbed, though working ok. before

Some channels cannot be selected pressing PROGR

incorrect skew setting

outdoor unit trajectory adjusted incorrectly reflector is too small for the satellite

The channels are broadcast at different power levels

your LNB is not apt to receive at such frequencies

the satellite positions have not been stored

the outdoor unit has moved

receiver transmits on a channel which is used for reception via antenna

heavy rain or snow

you have selected a radio channel channel is encoded

television is set to mute mode receiver set to mute mode or volume to low

audio or video settings have been modified channel is encoded now channel is no longer broadcasting

channels has been deleted

mount the polarizer according to the instructions and correct the skew parameters (see 7.7) consult a specialist to have the trajectory adjusted correctly use a larger reflector

use a larger reflector

Use a different LNB

store the satellite positions (see 5.4 and 5.5)

re-adjust the outdoor unit

change transmit channEl on the receiver (see 4.2)

change transmit channel on the receiver (see 4.2)

remove the snow from the outdoor unit

switch to TV mode (see 6.5) connect adequate decoder (see 4.5)

check the volume on the television set check the volume on the receiver (see 6.4)

set up channel again (see 7.7) connect adequate decoder (see 4.4 „Decoder“) no measures

select channel (see 7.3)

A connected decoder does not decode

key or SmartCard is not valid wrong SCART connection wrong decoder signal selected

Check the decoder’s instructions check the connections (see 4.5) correct the setting (see 7.6)

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 43

10 Technical terms

Actuator

Motor with gears and push bars to drive medium to large-sized paraboloidal reflectors

Antenna cable

Cable connection between modulator and satellite receiver and antenna input of the television set, may be used alternatively when there is no SCART connector attached.

Audio bandwidth:

Option that separates two subcarriers; it is determined by the broadcasting parameters of each satellite.An excessive audio bandwidth results in an interference between the desired subcarrier and an adjacent subcarrier; a very small bandwidth may lead to distortions.

Outdoor unit:

Term used to describe the entire system which is mounted outdoors. It consists of a paraboloidal reflector and one or more LNBs which are used to receive the broadcasts from one or more satellites.

See SCART

Combysat LNB

LNB used to receive the entire frequency range between 10.7 and

12.75 GHz. The supply voltage is used to switch from the 11 GHz range (14V) to the DBS/12 GHz range (18V).The polarizer toggles between the polarisation levels.

DBS:

Direct Broadcasting Satellite; refers to satellites with a very high broadcasting power in the DBS frequency range, e.g.TDF.

Decoder:

Individual device or electronic circuit incorporated in the satellite receiver which is used to decode encoded channels (e.g. Premiere).

Deemphasis:

Adaptation of the audio frequency waveform to the broadcast signalling; determined by the satellite’s broadcasting parameters.

Single LNB: LNB used to receive on one polarisation level.

Frequency: a) Satellite or LNB: 11 GHz range 10.7 to 11.7 GHz

DBS range 11.7 to 12.5 GHz

12.5 GHz range 12.5 to 12.75 GHz

b) Receiver: Intermediate frequency or 1st I F 950 to 2050 MHz

H/H mount

Motor with gears and integrated support mechanism to drive small to medium-sized paraboloidal reflectors.

Hz:

Frequency unit of measurement

1 Hz (Hertz) = 1 vibrations per second 1 kHz (Kilohertz) = 1,000 vibrations per second 1 MHz (Megahertz) = 1,000,000 vibrations per second 1 GHz (Gigahertz) = 1,000,000,000 vibrations per second

Horizontal polarisation:

See polarisation level

Coax cable:

Cable connection between the LNB and satellite receiver which is used to transfer the received signals and for the power supply of the LNB.

LNB (Low Noise Block Converter):

Receiving unit centred in the focus of the paraboloidal reflector.It converts the frequency range of the satellite into the intermediate frequency of the receiver.

LOF:

Local Oscillator Frequency; specified in MHz or GHz,depending on the LNB and the received frequency range. Receive frequency of the receiver = Broadcast frequency of satellite - LOF Correlation between frequency range and LOF: 11 GHz range LOF 9.75 or 10 GHz DBS range LOF 10.75 GHz

12.5 GHz range LOF 10.75 or 11.475 GHz

Modulation at 22 kHz: Additional control signal, e.g. for an external switching device used to toggle between two LNBs.

Modulator Electronic circuit in the satellite receiver or video recorder which is used to connect to a television via antenna cable.

Mode:

determines if a channel is received in mono or stereo quality.

Multyfeed: Outdoor unit consisting of a paraboloidal reflector and multiple LNBs for the reception of multiple satellites.

OSD:

„On-Screen Display“; alphanumeric representation of information on the TV scree

Offset reflector

Special type of paraboloidal reflector which is primarily used for small to medium-sized reflectors.

Paraboloidal reflector:

Reflector of paraboloidal shape made of metal or plastic-coated which is used to focus the electromagnetic waves which are broadcast by a satellite.

Polarisation level:

For an efficient use of the available frequency range satellites broadcast adjacent channels with opposite polarities (alternately horizontal and vertical, or left-moving and right-moving). The reception of both polarisation levels requires two single LNBs or a V/H LNB.

Polarizer

An equipment which is used to switch the polarisation levels by means of an actuator motor drive (mechanical) or through a direct current (ferrite or magnetic).This allows the reception of both polarisation levels over a single LNB.

Radio channels:

Apart from the television channels, satellites also broadcast radio channels which are transported on subcarriers.In addition to the subcarrier’s frequency further parameters have to be set:

Audio bandwidth, Deemphasis,and Mode.

Receiver:

See satellite receiver.

Satellite:

Name and position of the satellite relative to the orbit,e.g.: Name: Eutelsat Position: 13° East or -13°

Telecom 2B 5° West or +5°

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 44

Satellite receiver:

The signals received and converted by the LNB cannot be used by the television. The satellite receiver re-processes the signals so that its outputs provide common audio and video signals (AV) that can be transferred to the television.

SCART:

Connector on television sets, video cassette recorders, satellite receivers and other consumer electronic equipment used to produce audio and video signals (AV).

Sensor

Produces impulses during a reflector movement that the receiver uses to calculate the reflector position.

Skew

Offset angle of the polarizer. The skew parameter’s value is fairly proportional to the angle of the receive signal in degrees.

Timer:

Programmable device that enables the receiver to switch to a desired channel for a defined period of time.

TV:

Television set.

TWIN LNB:

LNB with two outputs that allows independent operation of two satellite receivers (=2V/H LNBs).

Subcarrier:

Carrier frequencies for television sound or radio channels which are broadcast together with the television picture; a stereo channel requires two subcarriers, e.g.7.38 and 7.56 MHz.

V/H LNB:

LNB which allows the reception of both polarisation levels on one or two frequency ranges. The supply voltage of 14/18V (18V = horizontal level, 14V = vertical level) switches between polarities, the 22 kHz modulation toggles between the frequency ranges (off = 11 GHz range, on = DBS range and 12.5 GHz range).

VCR:

Video cassette recorder

Supply voltage: LNBs are powered via the coax cable; in addition,the receiver transfers a voltage of 14 or 18 volts.

Vertical polarisation:

See polarisation level

Intermediate frequency:

The frequency range used for satellite broadcasts cannot be transported over cabling systems; this is why the LNB converts these frequencies to an intermediate range between 950 and 2050 MHz.This makes frequency transfer and processing in the receiver possible.

1. IF

= Intermediate frequency

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 45

11 Specifications

Tuner

Input frequency 950 - 2050 MHz Input resistance 75 Ω Input level 47 - 77 dbuV Connector F female, 2 pieces LNB control

DC 18 V ± 0.5 V max. 400 mA1)

13.5 V ± 0.5 V, max. 400 mA1)

AC 22 kHz, 0.5 Vp-p Bandwidth 27/36 MHz Tuning PLL frequency synthesis

TV connection

Output SCART TV Video

Deemphasis CCIR Rec.405-1; 625 lines Bandwidth 5 MHz (3 dB) Output level 1 Vp-p at 75 W, adjustable to 4 levels

Audio

Frequency range DF 5.4 - 8.7 MHz, adjustable collectively or separately with 180 kHz or 10 kHz increments

Bandwidths 130, 180,200, and 380 kHz

Deemphases 50 µs, 75 µs,J17, Panda1

Frequency range NF 100 Hz ... 14 kHz Output level 1.7 Vp-p at nominal peak; 1 kHz adjustable to 6 levels 1) Distortion typ.0.5 %, max. 1 % at 1.5 Vp-p, 1 kHz

VCR connection

Output SCART VCR Video see above Audio see above Input signal

Video FBAS, 2 Vp-p ± 2 dB at 1 kΩ

Audio 2 V p-p

Decoder connection

Output SCART DECODER Video adjustable to four modes 1)

Baseband, 1 Vp-p with 75 Ω at 1.5 MHz Baseband with deemphasis

Baseband with deemphasis and filter with deemphasis, filter and clamping FBAS signal Audio see above Input signal

Video FBAS 2 Vp-p ± 2 dB at 1 kΩ Audio 2 Vp-p

HF modulator

UHF range channel 21 to 45 selectable, preset to channel 39 Standard G Output level 74 ± 4 dBuV Output IEC male Input IEC female Output resistance 75 Ω

Motor

Permanent power max. 1.3 A

Polarizer

Ferrite

Output power ± 60 mA

Mechanical

5 V supply max. 200 mA Pulse width 0.8 ms - 2.2 ms Pulse break 15 ms

Power supply

Supply voltage 185 V - 265 V, 50 Hz Power requirements max. 70 W (with 2 LNBs and with running motor)

General data

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 46

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 47

Temperature range + 15° C to + 35° C Humidity < 80% Dimensions 43.5 x 6.5 x 27 cm (width x height x depth) Weight 2.9 kg

1) storable with each channel position

*M-Focus 2.6.95 14.12.1999 10:39 Uhr Seite 48

Made in Germany!

611/95

TechniSat MultyFocus User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
