Sony CDXGT-200-E Service manual

CDX-GT20W/GT200/GT200E/

GT200S/GT250S

SERVICE MANUAL

Ver. 1.0 2005. 09

• The tuner and CD sections have no adjustments.

AUDIO POWER SPECIFICATIONS (US MODEL)

POWER OUTPUT AND TOTAL HARMONIC DISTORTION

23.2 watts per channel minimum continuous average power into
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more
than 5% total harmonic distortion.

SPECIFICATIONS

US Model

Canadian Model

CDX-GT20W/GT200

AEP Model

UK Model

CDX-GT200/GT200E/GT200S

E Model

CDX-GT250S

Model Name Using Similar Mechanism NEW
CD Drive Mechanism Type MG-611WA-186//C
Optical Pick-up Name KSS1000E

CD Player section

Signal-to-noise ratio: 120 dB
Frequency response: 10 – 20,000 Hz
Wow and flutter: Below measurable limit

Tuner section

FM

Tuning range: CDX-GT20W/GT200 (US, Canadian):

87.5 – 107.9 MHz
CDX-GT200 (AEP, UK)/GT200E/GT200S:

87.5 – 108.0 MHz
CDX-GT250S:

87.5 – 108.0 MHz (at 50 kHz step)

87.5 – 107.9 MHz (at 200 kHz step)

FM tuning interval (CDX-GT250S only):

50 kHz/200 kHz switchable
Antenna terminal: External antenna connector
Intermediate frequency: 10.7 MHz/450 kHz
Usable sensitivity: 9 dBf
Selectivity: 75 dB at 400 kHz
Signal-to-noise ratio: 67 dB (stereo), 69 dB (mono)
Harmonic distortion at 1 kHz:

0.5 % (stereo), 0.3 % (mono)
Separation: 35 dB at 1 kHz
Frequency response: 30 – 15,000 Hz

AM (CDX-GT20W/GT200 (US, Canadian)/GT250S)

Tuning range: CDX-GT20W/GT200 (US, Canadian):

530 – 1,710 kHz
CDX-GT250S:
531 – 1,602 kHz (at 9 kHz step)
530 – 1,710 kHz (at 10 kHz step)

AM tuning interval (CDX-GT250S only):

9 kHz/10 kHz switchable
Antenna terminal: External antenna connector
Intermediate frequency: 10.7 MHz/450 kHz
Sensitivity: 30 µV

MW/LW (CDX-GT200 (AEP, UK)/GT200E/GT200S)

Tuning range: MW: 531 – 1,602 kHz

LW: 153 – 279 kHz
Aerial terminal: External aerial connector
Intermediate frequency: 10.7 MHz/450 kHz
Sensitivity: MW: 30 µV, LW: 40 µV

Power amplifier section

Outputs: Speaker outputs (sure seal connectors)
Speaker impedance: 4 – 8 ohms
Maximum power output: CDX-GT20W/GT200 (US, Canadian)/GT250S:

52 W × 4 (at 4 ohms)

CDX-GT200 (AEP, UK)/GT200E/GT200S:

50 W × 4 (at 4 ohms)

– Continued on next page –

FM/AM COMPACT DISC PLAYER

CDX-GT20W/GT200: US,CND/GT250S

9-879-862-01

2005I04-1
© 2005. 09

FM/MW/LW COMPACT DISC PLAYER

CDX-GT200: AEP,UK/GT200E/GT200S

Sony Corporation

e Vehicle Group
Published by Sony Engineering Corporation

1

CDX-GT20W/GT200/GT200E/GT200S/GT250S

General

Outputs: Audio outputs terminal (sub/rear switchable)

Power antenna relay control terminal
Power amplifier control terminal

Inputs: Antenna input terminal

AUX input jack (stereo mini jack)

Tone controls: Low: ±10 dB at 60 Hz (XPLOD)

Mid: ±10 dB at 1 kHz (XPLOD)
High: ±10 dB at 10 kHz (XPLOD)

Power requirements: 12 V DC car battery (negative ground)
Dimensions: Approx. 178 × 50 × 179 mm

(7 1/8 × 2 × 7 1/8 in) (w/h/d)

Mounting dimensions: Approx. 182 × 53 × 161 mm

(7 1/4 × 2 1/8 × 6 3/8 in) (w/h/d)

Mass: Approx. 1.2 kg (2 lb 11 oz)
Supplied accessories: Parts for installation and connections (1 set)

Card remote commander: RM-X151 (CDX-GT20W/

GT200/GT250S)

Design and specifications are subject to change
without notice.

SERVICE NOTES

CAUTION

Use of controls or adjustments or performance of procedures other
than those specified herein may result in hazardous radiation
exposure.

NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK
OR BASE UNIT

The laser diode in the optical pick-up block may suffer electrostatic
breakdown because of the potential difference generated by the
charged electrostatic load, etc. on clothing and the human body.
During repair, pay attention to electrostatic breakdown and also use
the procedure in the printed matter which is included in the repair
parts.
The flexible board is easily damaged and should be handled with
care.

NOTES ON LASER DIODE EMISSION CHECK

The laser beam on this model is concentrated so as to be focused on
the disc reflective surface by the objective lens in the optical pick­up block. Therefore, when checking the laser diode emission, ob­serve from more than 30 cm away from the objective lens.

Notes on Chip Component Replacement

•Never reuse a disconnected chip component.

• Notice that the minus side of a tantalum capacitor may be dam­aged by heat.

If the optical pick-up block is defective, please replace the whole
optical pick-up block.
Never turn the semi-fixed resistor located at the side of optical
pick-up block.

optical pick-up

Case of CDX-GT200: AEP, UK/GT200E/GT200S/GT250S

This compact disc player is classified as a CLASS 1 LASER
product. The CLASS 1 LASER PRODUCT label is located on the
exterior.

This label is located on the bottom of the chassis.

semi-fixed resistor

TEST DISCS

This set can playback CD-R and CD-ROM discs. The following
test discs should be used to check the capability:

CD-R test disc TCD-R082LMT (Part No. J-2502-063-1)
CD-RW test disc TCD-W082L (Part No. J-2502-063-2)

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0 OR DOTTED LINE
WITH MARK 0 ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY P ARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.

2

ATTENTION AU COMPOSANT AYANT RAPPORT

À LA SÉCURITÉ!!

LES COMPOSANTS IDENTIFIÉS P AR UNE MARQUE 0 SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES
SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT.
NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES
SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL
OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.

CDX-GT20W/GT200/GT200E/GT200S/GT250S

D

• CD playback

You can play CD-DA (also containing CD TEXT*), CD-R/CD­RW (MP3/WMA files also containing Multi Session and ATRA C
CD (ATRAC3 and ATRAC3plus format).

Type of discs Label on the disc

CD-DA

MP3

WMA

ATRAC CD

*A CD TEXT disc is a CD-DA that includes information such as

disc, artist and track name.

EXTENSION CABLE AND SERVICE POSITION

When repairing or servicing this set, connect the jig (extension cable)
as shown below.

z

UNLEADED SOLDER

Boards requiring use of unleaded solder are printed with the lead
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)

: LEAD FREE MARK

Unleaded solder has the following characteristics.

• Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!

• Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.

• Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.

• Connect the MAIN board (CNP301) and the SER VO board (CN2)
with the extension cable (Part No. J-2502-076-1).

MAIN BOARD
CNP301

J-2502-076-1

SERVO BOAR
CN2

3

CDX-GT20W/GT200/GT200E/GT200S/GT250S

TABLE OF CONTENTS

1. GENERAL

Location of controls and basic operations ...............................5

Connections .............................................................................7

2. DISASSEMBL Y

2-1. Sub Panel Assy.................................................................. 10

2-2. CD Mechanism Block ....................................................... 10

2-3. Main Board .......................................................................11

2-4. Chassis (T) Sub Assy ........................................................ 11

2-5. Roller Arm Assy ................................................................ 12

2-6. Chassis (OP) Assy............................................................. 12

2-7. Optical Pick-up .................................................................13

2-8. SL Motor Assy (M902) ..................................................... 13

2-9. LE Motor Assy (M903)..................................................... 14

2-10. Servo Board....................................................................... 14

3. DIAGRAMS

3-1. Block Diagram – CD Section –......................................... 15

3-2. Block Diagram – Main Section –...................................... 16

3-3. Block Diagram – Display Section –.................................. 17

3-4. Circuit Boards Location .................................................... 17

3-5. Printed Wiring Boards – CD Mechanism Section – ......... 19

3-6. Schematic Diagram – CD Mechanism Section (1/2) – ..... 20

3-7. Schematic Diagram – CD Mechanism Section (2/2) – ..... 21

3-8. Printed Wiring Board – Main Section –............................ 22

3-9. Schematic Diagram – Main Section (1/3) – ...................... 23

3-10. Schematic Diagram – Main Section (2/3) –...................... 24

3-11. Schematic Diagram – Main Section (3/3) –...................... 25

3-12. Printed Wiring Boards – Key Section – ............................ 26

3-13. Schematic Diagram – Key Section – ................................ 27

4. EXPLODED VIEWS

4-1. Main Section ..................................................................... 34

4-2. Front Panel Section ........................................................... 35

4-3. CD Mechanism Section (1) (MG-611WA-186//C) ........... 36

4-4. CD Mechanism Section (2) (MG-611WA-186//C) ........... 37

4-5. CD Mechanism Section (3) (MG-611WA-186//C) ........... 38

4-6. CD Mechanism Section (4) (MG-611WA-186//C) ........... 39

5. ELECTRICAL PARTS LIST ........................................ 40

4

• CDX-GT20W/GT200: US, Canadian

Location of controls and basic operations

Main unit

CDX-GT200
CDX-GT20W

Card remote commander
RM-X151

(CDX-GT200 only)

OFF

ATT

SEL

SOURCE

MODE

+

–

SCRL

DSPL

132

465

+

VOL

–

Refer to the pages listed for details.

A OFF button

To po wer off; stop the source.

B Volume control dial/select button 9

To ad ju st volume (rotate); select setup items
(press and rotate).

C EQ3 (equalizer) button 9

To select an equalizer type (XPLOD,
VOCAL, CLUB, JAZZ, NEW AGE, ROCK,
CUSTOM or OFF).

D Disc slot

To i n sert the disc (label side up), playback
starts.

E Display window
F Z (eject) button

To ej ec t the disc.

G SCRL (scroll) button 8

To sc ro ll the display item.

H DSPL (display)/DIM (dimmer) button

4, 8

To ch ange display item s (press); change the
display brightness (press and hold ).

1

I GP*

/ALBM*2 +/– buttons

To sk ip groups/albums (press); skip gr oups/
albums continuously (press and hold).

J (front panel release) button 4

CDX-GT20W/GT200/GT200E/GT200S/GT250S

SECTION 1

GENERAL

K SEEK –/+ buttons

CD:
To sk ip tracks (press); skip tracks
continuously (press, then press again within
about 1 second and hold); reverse/fast­forward a track (press and hold).
Radio:
To tune in stations automatically (press); f ind
a station manually (press and hold).

L SOURCE button

To po wer on; change the source (Radio/CD/
AUX).

M BTM button 8

To st art the BTM function (press and hold).

N MODE button 8

To se le ct the radio band (FM/AM).

O RESET button (located behind the front

panel) 4

P Number buttons

CD:

(3): REP 8
(4): SHUF 8
(6): PAUS E

To p ause playback. To cancel, press

again.
Radio:
To re ce ive stored stations (press); store
stations (press and hold).

Q SENS button

To im prove weak reception: LOCAL/
MONO.

R Receptor for the card remote

commander 10

S AUX input jack 10

To co nnect a portable audi o device.

This section is extracted
from instruction manual.

The following buttons on the card remote
commander have also different buttons/functions
from the unit.

w; < (.)/, (>) buttons

CD:
To control CD/Radio, the same as
(SEEK) –/+ on the unit.

wa VOL (volume) +/– button

To adju st volume.

ws AT T ( attenuate) button

To atte nuate the sound. To cancel, press
again.

wd SEL (select) button

To s e lect items.

wf M (+)/m (–) buttons

To control CD, the same as (GP/ALBM) –/+
on the unit.

wg Number buttons

To r e ceive stored stations (press); store
stations (press and hold).

*1

When an ATRAC CD is played.

*2

When an MP3/WMA is played.

Note

If the unit is turned off and the display disappears, it
cannot be operated with the card remote commander

(SOURCE)

unless
inserted to activate the unit first.

Tip

For details on how to replace the battery, see
“Replacing the lithium battery” on page 12.

on the unit is pressed, or a disc is

6

• CDX-GT200: AEP, UK/GT200S • CDX-GT200E

Location of controls and basic operations

Main unit

CDX-GT200S
CDX-GT200

Refer to the pages listed for details.

A OFF button

To p ower off; stop the source.

B Volume control dial/select button 9

To a dj ust volume (rotate); select setup items
(press and rotate).

C EQ3 (equalizer) button 9

To s el ec t a n equalizer type (XPLOD,
VOCAL, CLUB, JAZZ, NEW AGE, ROCK,
CUSTOM or OFF).

D Disc slot

To i ns ert the di sc (label side up), playback
starts.

E Display window
F Z (eject) button

To e ject the d is c.

G AF (Alternative Frequencies)/TA

(Traffic Announcement) button 7

To s et AF and TA/TP in RDS.

H DSPL (display)/DIM (dimmer) button

4, 6

To c hange display items (press); change the
display brightness (press and hold).

1

/ALBM*2 +/– buttons

I GP*

To s ki p g ro ups/albums (press); skip groups/
albums continuously (press and hold).

J (front panel release) button 4
K SEEK –/+ buttons

CD:
To s kip tracks (press); skip tracks
continuously (press, then press again within
about 1 second and hold); reverse/fast­forward a track (press and hold).

L SOURCE button

M PTY (Programme Type) button 8

N MODE button 6

O RESET button (located behind the front

P Number buttons

Q SENS/BTM button

R Receptor for the card remote

S AUX input jack 10

*1
*2

Radio:
To tune in stations automatically (press); find
a station manually (press and hold).

To po wer on; change the source (Radio/CD/
AUX).

To se lect PTY in RDS.

To se le ct the r adio band (FM/MW/LW).

panel) 4

CD:

(3): REP 6
(4): SHUF 6
(6): PAUSE

To p ause playback. To cancel, press

again.
Radio:
To r e ce ive stored stations (press); store
stations (press and hold).

To improve weak reception: LOCAL/MONO
(press); start the BTM function (press and
hold).

commander 10

To co nnect a portable audi o device.

When an ATRAC CD is played.
When an MP3/WMA is played.

5

Location of controls and basic operations

Main unit

Refer to the pages listed for details.

A OFF button

To po wer off; stop the source.

B Volume control dial/select button 7

To ad ju st vol ume (rotate); select setup items
(press and rotate).

C EQ3 (equalizer) button 7

To se le ct an equalizer type (XPLOD,
VOCAL, CLUB, JAZZ, NEW AGE, ROCK,
CUSTOM or OFF).

D Disc slot

To in se rt the disc (label side up), playback
starts.

E Display window
F Z (eject) button

To ej ect the disc.

G SCRL (scroll) button 6

To sc ro ll the dis play item.

H DSPL (display)/DIM (dimmer) button

4, 6

To ch ange display items (press); change the
display brightness (press and hol d).

1

I GP*

/ALBM*2 +/– buttons

To sk ip gr oups/albums (press); skip groups/
albums continuously (pre ss and hold).

J (front panel release) button 4
K SEEK –/+ buttons

CD:
To sk ip tracks (press); skip tracks
continuously (press, then press again within
about 1 second and hold); reverse/fast­forward a track (press and hold).

CDX-GT200E

Radio:
To tune in stations automatically (press); find
a station manually (press and hold).

L SOURCE button

To power on; change the source (Radio/CD/
AUX).

M BTM button 6

To star t the BTM function (press and hold).

N MODE button 6

To sele ct the radio band (FM/MW/LW).

O RESET button (located behind the front

panel) 4

P Number buttons

CD:

(3): REP 6
(4): SHUF 6
(6): PAUS E

To pa use playback. To cancel, press

again.
Radio:
To r e ce ive stored stations (press); store
stations (press and hold).

Q SENS button

To improve weak reception: LOCAL/
MONO.

R Receptor for the card remote

commander 8

S AUX input jack 8

To conn ect a portable audio device.

*1

When an ATRAC CD is played.

*2

When an MP3/WMA is played.

7

5

5

CDX-GT20W/GT200/GT200E/GT200S/GT250S

• CDX-GT250S

Location of controls and basic operations

Main unit

CDX-GT250S

Card remote commander
RM-X151

OFF

ATT

SEL

SOURCE

MODE

+

–

SCRL

DSPL

132

465

+

VOL

–

Refer to the pages listed for details. The
corresponding buttons on the card remote
commander control the same functions as those
on the unit.

A OFF button

To po wer off; stop the source.

B Volume control dial/select button 9

To ad ju st vol ume (rotate); select setup items
(press and rotate).

C EQ3 (equalizer) button 9

To se le ct an equalizer type (XPLOD,
VOCAL, CLUB, JAZZ, NEW AGE, ROCK,
CUSTOM or OFF).

D Disc slot

To i n sert the disc (label side up), playback
starts.

E Display window
F Z (eject) button

To ej ec t the disc.

G SCRL (scroll) button 8

To sc ro ll the display item.

H DSPL (display)/DIM (dimmer) button

4, 8

To ch ange display item s (p ress); change the
display brightness (press and hold).

1

I GP*

/ALBM*2 –/+ buttons

To sk ip groups/albums (press); skip gr oups/
albums continuously (press and hold).

J (front panel release) button 4

K SEEK –/+ buttons

CD:
To sk ip tracks (press); skip tracks
continuously (press, then press again within
about 1 second and hold); reverse/fast­forward a track (press and hold).
Radio:
To tune in stations automatically (press); f ind
a station manually (press and ho ld).

L SOURCE button

To po wer on; change the source (Radio/CD/
AUX).

M BTM button 8

To st art the BTM function (press and hold).

N MODE button 8

To se le ct the radio band (FM/AM).

O RESET button (located behind the front

panel) 4

P Frequency select switch (located on

the bottom of the unit)

See “Frequency select switch” in t h e
supplied installation/connections manual.

Q Number buttons

CD:

(3): REP 8
(4): SHUF 8
(6): PAUS E

To p ause playback. To cancel, press

again.
Radio:
To re ce ive stored stations (press); store
stations (press and hold).

R SENS button

To im prove weak reception: LOCAL/
MONO.

S Receptor for the card remote

commander

T AUX input jack 10

To co nnect a portable audi o device .

The following buttons on the card remote
commander have also different buttons/functions
from the unit.

wa < (.)/, (>) buttons

To control CD/Radio, the same as (SEEK)
–/+ on the unit.

ws VOL (volume) +/– button

To adju st volume.

wd AT T ( attenuate) button

To atte nuate the sound. To cancel, press
again.

wf SEL (select) button

To s e lect items.

wg M (+)/m (–) buttons

To control CD, the same as (GP/ALBM) –/+
on the unit.

wh Number buttons

To r e ce ive stored stations (press); store
sations (press and hold).

*1

When an ATRAC CD is played.

*2

When an MP3/WMA is played.

Note

If the unit is turned off and the display disappears, it
cannot be operated with the card remote commander
unless

(SOURCE)

inserted to activate the unit first.

Tip

For details on how to replace the battery, see
“Replacing the lithium battery of the card remote
commander” on page 12.

on the unit is pressed, or a disc is

6

7

6

• CONNECTIONS

• CDX-GT20W/GT200: US, Canadian/GT250S

from car antenna
à partir de l’antenne de la voiture

CDX-GT20W/GT200/GT200E/GT200S/GT250S

1

BUS

AUDIO

IN

*

L

R

Fuse (10 A)
Fusible (10 A)

1

*

RCA pin cord (not supplied)

2

*

AUDIO OUT can be switched to SUB

or REAR.

For details, see the supplied

Operating Instructions.

1

*

Cordon à broche RCA (non fourni)

2

*

AUDIO OUT peut être commuté sur

SUB ou REAR.

Pour obtenir plus de détails, reportez-

vous au mode d’emploi fourni.

AMP REM

Max. supply current 0.3 A
Courant max. fourni 0,3 A

Left
Gauche

Right
Droit

Left
Gauche

Right
Droit

Connection diagram

1 To a metal surface of the car

First connect the black ground lead, then connect the yellow
and red power input leads.

2 To the power antenna control lead or power

supply lead of antenna booster amplifier

Notes

•

It is not necessary to connect this lead if there is no power
antenna or antenna booster, or with a manually-operated
telescopic antenna.

•

When your car has a built-in FM/AM antenna in the rear/
side glass, see “Notes on the control and power supply
leads.”

3 To AMP REMOTE IN of an optional power

amplifi er

This connection is only for amplifi ers. Connecting any other
system may damage the unit.

4 To the +12 V power terminal which is

energized in the accessory position of the
ignition key switch

Notes

•

If there is no accessory position, connect to the +12 V
power (battery) terminal which is energized at all times.

Be sure to connect the black ground lead to a metal

surface of the car fi rst.

•

When your car has a built-in FM/AM antenna in the rear/
side glass, see “Notes on the control and power supply
leads.”

5 To the +12 V power terminal which is

energized at all times

Be sure to connect the black ground lead to a metal surface
of the car fi rst.

Notes on the control and power supply leads

•

The power antenna control lead (blue) supplies +12 V DC
when you turn on the tuner.

•

When your car has built-in FM/AM antenna in the rear/side
glass, connect the power antenna control lead (blue) or the
accessory power input lead (red) to the power terminal of the
existing antenna booster. For details, consult your dealer.

•

A power antenna without a relay box cannot be used with this
unit.

Memory hold connection

When the yellow power input lead is connected, power will
always be supplied to the memory circuit even when the ignition
switch is turned off.

Notes on speaker connection

•

Before connecting the speakers, turn the unit off.

•

Use speakers with an impedance of 4 to 8 ohms, and with
adequate power handling capacities to avoid its damage.

•

Do not connect the speaker terminals to the car chassis, or
connect the terminals of the right speakers with those of the
left speaker.

•

Do not connect the ground lead of this unit to the negative (–)
terminal of the speaker.

•

Do not attempt to connect the speakers in parallel.

•

Connect only passive speakers. Connecting active speakers
(with built-in amplifi ers) to the speaker terminals may damage
the unit.

•

To avoid a malfunction, do not use the built-in speaker leads
installed in your car if the unit shares a common negative (–)
lead for the right and left speakers.

•

Do not connect the unit’s speaker leads to each other.

Note on connection

If speaker and amplifi er are not connected correctly, “FAILURE”
appears in the display. In this case, make sure the speaker and
amplifi er are connected correctly.

Blue/white striped
Rayé bleu/blanc

White
Blanc

White/black striped
Rayé blanc/noir

Gray
Gris

Gray/black striped
Rayé gris/noir

Green
Vert

Green/black striped
Rayé vert/noir

Purple
Mauve

Purple/black striped
Rayé mauve/noir

2

Black
Noir

Blue
Bleu

Max. supply current 0.1 A
Courant max. fourni 0,1 A

Red
Rouge

Yellow
Jaune

Schéma de raccordement

1 À un point métallique de la voiture

Branchez d’abord le câble de mise à la masse noir et,
ensuite, les câbles d’entrée d’alimentation jaune et rouge.

2 Vers le câble de commande d’antenne

électrique ou le câble d’alimentation de
l’amplifi cateur d’antenne

Remarques

•

Il n’est pas nécessaire de raccorder ce câble s’il n’y a pas
d’antenne électrique ni d’amplifi cateur d’antenne, ou avec
une antenne télescopique manuelle.

•

Si votre voiture est équipée d’une antenne FM/AM
intégrée dans la vitre arrière/latérale, voir « Remarques
sur les câbles de commande et d’alimentation ».

3 Au niveau de AMP REMOTE IN de

l’amplifi cateur de puissance en option

Ce raccordement s’applique uniquement aux amplifi cateurs.
Le branchement de tout autre système risque
d’endommager l’appareil.

4 À la borne +12 V qui est alimentée quand la

clé de contact est sur la position accessoires

Remarques

•

S’il n’y a pas de position accessoires, raccordez la borne
d’alimentation (batterie) +12 V qui est alimentée en
permanence.
Raccordez d’abord le câble de mise à la masse noir à un
point métallique du véhicule.

•

Si votre voiture est équipée d’une antenne FM/AM
intégrée dans la vitre arrière/latérale, voir « Remarques
sur les câbles de commande et d’alimentation ».

5 À la borne +12 V qui est alimentée en

permanence

Raccordez d’abord le câble de mise à la masse noir à un
point métallique du véhicule.

Remarques sur les câbles de commande et d’alimentation

•

Le câble de commande d’antenne électrique (bleu) fournit une
alimentation de +12 V CC lorsque vous mettez la radio sous
tension.

•

Lorsque votre voiture est équipée d’une antenne FM/AM
intégrée dans la vitre arrière/latérale, raccordez le câble de
commande d’antenne (bleu) ou l’entrée d’alimentation des
accessoires (rouge) à la borne d’alimentation de l’amplifi cateur
d’antenne existant. Pour plus de détails, consultez votre
détaillant.

•

Une antenne électrique sans boîtier de relais ne peut pas être
utilisée avec cet appareil.

Raccordement pour la conservation de la mémoire

Lorsque le câble d’entrée d’alimentation jaune est raccordé, le
circuit de la mémoire est alimenté en permanence même si la clé
de contact est sur la position d’arrêt.

Remarques sur le raccordement des haut-parleurs

•

Avant de raccorder les haut-parleurs, mettez l’appareil hors
tension.

•

Utilisez des haut-parleurs ayant une impédance de 4 à 8 ohms
avec une capacité électrique adéquate pour éviter de les
endommager.

•

Ne raccordez pas les bornes du système de haut-parleurs au
châssis de la voiture et ne raccordez pas les bornes des haut­parleurs droit à celles du haut-parleur gauche.

•

Ne raccordez pas le câble de mise à la masse de cet appareil
à la borne négative (–) du haut-parleur.

•

N’essayez pas de raccorder les haut-parleurs en parallèle.

•

Raccordez uniquement des haut-parleurs passifs. Le
raccordement de haut-parleurs actifs (avec amplifi cateurs
intégrés) aux bornes des haut-parleurs peut endommager
l’appareil.

•

Pour éviter tout dysfonctionnement, n’utilisez pas les câbles
des haut-parleurs intégrés installés dans votre voiture si
l’appareil partage un câble négatif commun (–) pour les haut­parleurs droit et gauche.

•

Ne raccordez pas entre eux les cordons des haut-parleurs de
l’appareil.

Remarque sur le raccordement

Si les haut-parleurs et l’amplifi cateur ne sont pas raccordés
correctement, le message « FAILURE » s’affi che. Dans ce cas,
assurez-vous que les haut-parleurs et l’amplifi cateur sont bien
raccordés.

ANT REM

7

CDX-GT20W/GT200/GT200E/GT200S/GT250S

• CDX-GT200: AEP, UK/GT200E/GT200S

1

from car aerial

*

von Autoantenne
de l’antenne de la voiture
dall’antenna dell’auto
van een auto-antenne

Max. supply current 0.3 A
max. Versorgungsstrom 0,3 A
Courant d’alimentation maximum 0,3 A
Alimentazione massima fornita 0,3 A
Max. voedingsstroom 0,3 A

See “Power connection diagram” on the reverse side for details.
Näheres dazu fi nden Sie im „Stromanschlussdiagramm“. Blättern

Sie dazu bitte um.
Voir le « Schéma de raccordement d’alimentation » au verso pour

plus de détails.
Per ulteriori informazioni, vedere “Diagramma dei collegamenti di

alimentazione” che si trova sul retro.
Zie "Voedingsaansluitschema" op de achterkant voor meer details.

2

AMP REM

ATT

*

2

Fuse (10 A)
Sicherung (10 A)
Fusible (10 A)
Fusibile (10 A)
Zekering (10 A)

Blue/white striped
Blauweiß gestreift
Rayé bleu/blanc
Rigato blu e bianco
Blauw/wit gestreept

Light blue
Hellblau
Bleu ciel
Azzurro
Lichtblauw

AUDIO OUT REAR

L

L
R

R

3

3

*

1

*

Note for the aerial connecting

If your car aerial is an ISO (International
Organization for Standardization) type,
use the supplied adaptor 2 to connect
it. First connect the car aerial to the
supplied adaptor, then connect it to the
aerial jack of the master unit.

2

*

RCA pin cord (not supplied)

3

*

AUDIO OUT can be switched to SUB
or REAR. For details, see the supplied
Operating Instructions.

from the car’s speaker connector
vom Lautsprecheranschluss des Fahrzeugs
du connecteur de haut-parleur de la voiture
dal connettore del diffusore dell’auto
van de autoluidsprekerstekker

from the car’s power connector
vom Stromanschluss des Fahrzeugs
du connecteur d’alimentation de la voiture
dal connettore di alimentazione dell’auto
van de autovoedingsstekker

1

*

Hinweis zum Anschließen der Antenne

Wenn Ihre Fahrzeugantenne der
ISO-Norm (ISO = International
Organization for Standardization

- Internationale Normungsgemeinschaft)
entspricht, schließen Sie sie mithilfe des
mitgelieferten Adapters
Sie zuerst die Fahrzeugantenne mit dem
mitgelieferten Adapter und verbinden Sie
diesen dann mit der Antennenbuchse
des Hauptgeräts.

2

*

Cinchkabel (nicht mitgeliefert)

3

*

AUDIO OUT kann zwischen SUB
und REAR umgeschaltet werden.
Näheres hierzu fi nden Sie in der
Bedienungsanleitung.

2

an. Verbinden

13 57

24 68

1

*

Remarque sur le raccordement de

l’antenne
Si votre antenne de voiture est de type
ISO (Organisation internationale de
normalisation), utilisez l’adaptateur fourni

2

pour la raccorder. Raccordez d’abord
l’antenne de voiture à l’adaptateur fourni
et, ensuite, à la prise d’antenne de
l’appareil principal.

2

*

Cordon à broche RCA (non fourni)

3

*

AUDIO OUT peut être commuté sur SUB
ou REAR. Pour obtenir plus de détails,
reportez-vous au mode d’emploi.

57

48

1

*

Nota per il collegamento dell’antenna

Se l’antenna dell’auto è di tipo
ISO (International Organization for
Standardization), utilizzare l’adattatore

2

in dotazione per collegarla. Collegare
prima l’antenna della macchina
all’adattatore in dotazione, quindi
collegarla alla presa dell’antenna
dell’apparecchio principale.

2

*

Cavo a piedini RCA (non in dotazione)

3

*

AUDIO OUT può essere impostato
su SUB o su REAR. Per ulteriori
informazioni, consultare il manuale di
istruzioni per l’uso.

Speaker, Rear, Right

+

Purple
Violett
Mauve

Viola

Paars

+

Grey
Grau

Gris

Grigio

Grijs

Yellow

continuous power supply

Gelb

permanente Stromversorgung
Jaune
Giallo

Geel
Blue

Blau

Motorantennensteuerung

Bleu

Blu

comando dell’antenna elettrica
Blauw

Lautsprecher hinten rechts

Haut-parleur, arrière, droit

Diffusore, posteriore, destro

Luidspreker, achter, rechts

Speaker, Rear, Right

Lautsprecher hinten rechts

Haut-parleur, arrière, droit

Diffusore, posteriore, destro

Luidspreker, achter, rechts

Speaker, Front, Right

Lautsprecher vorne rechts

Haut-parleur, avant, droit

Diffusore, anteriore, destro

Luidspreker, voor, rechts

Speaker, Front, Right

Lautsprecher vorne rechts

Haut-parleur, avant, droit

Diffusore, anteriore, destro

Luidspreker, voor, rechts

alimentation continue

alimentazione continua

continu voeding

power aerial control

antenne électrique

automatische antenne

5

6–

7

8–

7

Rouge
Rosso
Rood

Black

Schwarz

8

Zwart

1

2–

3

4–

Negative polarity positions 2, 4, 6, and 8 have striped leads.
An den negativ gepolten Positionen 2, 4, 6 und 8 be nden sich gestreifte Adern.
Les positions de polarité négative 2, 4, 6 et 8 sont dotées de cordons rayés.
Le posizioni a polarità negativa 2, 4, 6 e 8 hanno cavi rigati.
De posities voor negatieve polariteit (2, 4, 6 en 8) hebben gestreepte kabels.

4

5

Positions 1, 2, 3, and 6 do not have pins.
An Position 1, 2, 3 und 6 befi nden sich keine Stifte.
Les positions 1, 2, 3 et 6 ne comportent pas de broches.
Le posizioni 1, 2, 3 e 6 non hanno piedini.
De posities 1, 2, 3 en 6 hebben geen pins.

+

White

Weiß

Blanc

Bianco

Wit

+

Green

Grün
Vert

Verde

Groen

Red

switched power supply

Rot

geschaltete Stromversorgung

alimentation commutée

alimentazione commutata

Noir
Nero

*

*
*

geschakelde voeding

1

Opmerking bij de antenne-aansluiting

Indien uw auto is uitgerust met een
antenne van het type ISO (International
Organisation for Standardization),
moet u die aansluiten met behulp
van de bijgeleverde adapter
eerst de auto-antenne aan op de
meegeleverde adapter en vervolgens de
antennestekker op het hoofdtoestel.

2

Tulpstekkersnoer (niet bijgeleverd)

3

AUDIO OUT kan worden ingesteld
op SUB of REAR. Raadpleeg de
handleiding met gebruiksaanwijzingen
voor meer informatie.

Lautsprecher vorne links
Haut-parleur, avant, gauche
Diffusore, anteriore, sinistro

Luidspreker, voor, links

Lautsprecher vorne links
Haut-parleur, avant, gauche
Diffusore, anteriore, sinistro

Luidspreker, voor, links

Lautsprecher hinten links

Haut-parleur, arrière, gauche
Diffusore, posteriore, sinistro

Luidspreker, achter, links

Lautsprecher hinten links

Haut-parleur, arrière, gauche
Diffusore, posteriore, sinistro

Luidspreker, achter, links

Masse
masse

aarding

Speaker, Front, Left

Speaker, Front, Left

Speaker, Rear, Left

Speaker, Rear, Left

earth

terra

2

. Sluit

Connection diagram

A To AMP REMOTE IN of an optional power

amplifi er

This connection is only for amplifi ers. Connecting any other
system may damage the unit.

B To the interface cable of a car telephone

Warning

If you have a power aerial without a relay box,
connecting this unit with the supplied power connecting
lead 3 may damage the aerial.

Notes on the control power and suppy leads

•

The power aerial control lead (blue) supplies +12 V DC when
you turn on the tuner, or when you activate the AF (Alternative
Frequency) or TA (Traffi c Announcement) function.

•

When your car has built-in FM/MW/LW aerial in the rear/side
glass, connect the power aerial control lead (blue) or the
accessory power input lead (red) to the power terminal of the
existing aerial booster. For details, consult your dealer.

•

A power aerial without a relay box cannot be used with this
unit.

Memory hold connection

When the yellow power input lead is connected, power will
always be supplied to the memory circuit even when the ignition
switch is turned off.

Notes on speaker connection

•

Before connecting the speakers, turn the unit off.

•

Use speakers with an impedance of 4 to 8 ohms, and with
adequate power handling capacities to avoid its damage.

•

Do not connect the speaker terminals to the car chassis, or
connect the terminals of the right speakers with those of the
left speaker.

•

Do not connect the earth lead of this unit to the negative (–)
terminal of the speaker.

•

Do not attempt to connect the speakers in parallel.

•

Connect only passive speakers. Connecting active speakers
(with built-in amplifi ers) to the speaker terminals may damage
the unit.

•

To avoid a malfunction, do not use the built-in speaker leads
installed in your car if the unit shares a common negative (–)
lead for the right and left speakers.

•

Do not connect the unit’s speaker leads to each other.

Note on connection

If speaker and amplifi er are not connected correctly, “FAILURE”
appears in the display. In this case, make sure the speaker and
amplifi er are connected correctly.

Anschlussdiagramm

A An AMP REMOTE IN des gesondert

erhältlichen Endverstärkers

Dieser Anschluss ist ausschließlich für Verstärker gedacht.
Schließen Sie nichts anderes daran an. Andernfalls kann
das Gerät beschädigt werden.

B An Schnittstellenkabel eines Autotelefons

Warnung

Wenn Sie eine Motorantenne ohne Relaiskästchen
verwenden, kann durch Anschließen dieses Geräts mit
dem mitgelieferten Stromversorgungskabel 3 die
Antenne beschädigt werden.

Steuer- und Stromversorgungsleitungen

•

Die Motorantennen-Steuerleitung (blau) liefert +12 V
Gleichstrom, wenn Sie den Tuner einschalten oder die
AF- (Alternativfrequenzsuche) oder die TA-Funktion
(Verkehrsdurchsagen) aktivieren.

•

Wenn das Fahrzeug mit einer in der Heck-/
Seitenfensterscheibe integrierten FM (UKW)/MW/LW­Antenne ausgestattet ist, schließen Sie die Motorantennen­Steuerleitung (blau) oder die Zubehörstromversorgungsleitung
(rot) an den Stromversorgungsanschluss des vorhandenen
Antennenverstärkers an. Näheres dazu erfahren Sie bei Ihrem
Händler.

•

Es kann nur eine Motorantenne mit Relaiskästchen
angeschlossen werden.

Stromversorgung des Speichers

Wenn die gelbe Stromversorgungsleitung angeschlossen ist,
wird der Speicher stets (auch bei ausgeschalteter Zündung) mit
Strom versorgt.

Hinweise zum Lautsprecheranschluss

•

Schalten Sie das Gerät aus, bevor Sie die Lautsprecher
anschließen.

•

Verwenden Sie Lautsprecher mit einer Impedanz zwischen 4 und
8 Ohm und ausreichender Belastbarkeit. Ansonsten können die
Lautsprecher beschädigt werden.

•

Verbinden Sie die Lautsprecheranschlüsse nicht mit dem
Wagenchassis und verbinden Sie auch nicht die Anschlüsse
des rechten mit denen des linken Lautsprechers.

•

Verbinden Sie die Masseleitung dieses Geräts nicht mit dem
negativen (–) Lautsprecheranschluss.

•

Versuchen Sie nicht, Lautsprecher parallel anzuschließen.

•

An die Lautsprecheranschlüsse dieses Geräts dürfen nur
Passivlautsprecher angeschlossen werden. Schließen Sie
keine Aktivlautsprecher (Lautsprecher mit eingebauten
Verstärkern) an, da das Gerät sonst beschädigt werden
könnte.

•

Um Fehlfunktionen zu vermeiden, verwenden Sie nicht die
im Fahrzeug installierten, integrierten Lautsprecherleitungen,
wenn am Ende eine gemeinsame negative (–) Leitung für den
rechten und den linken Lautsprecher verwendet wird.

•

Verbinden Sie nicht die Lautsprecherkabel des Geräts
miteinander.

Hinweis zum Anschließen

Wenn Lautsprecher und Verstärker nicht richtig angeschlossen
sind, erscheint „FAILURE“ im Display. Vergewissern Sie sich
in diesem Fall, dass Lautsprecher und Verstärker richtig
angeschlossen sind.

Schémas de raccordement

A Au niveau du AMP REMOTE IN d’un

amplifi cateur de puissance facultatif

Ce raccordement existe seulement pour les amplifi cateurs.
Le raccordement à tout autre système peut endommager
l’appareil.

B Vers le cordon de liaison d’un téléphone de

voiture

Avertissement

Si vous disposez d’une antenne électrique sans boîtier
de relais, le branchement de cet appareil au moyen du
cordon d’alimentation fourni 3 risque d’endommager
l’antenne.

Remarques sur les câbles de commande et de puissance

•

Le câble de commande (bleu) fournit du courant continu de
+12 V lorsque vous mettez le tuner sous tension ou lorsque
vous activez la fonction AF (fréquence alternative) ou TA
(informations circulation).

•

Lorsque votre voiture est équipée d’une antenne FM/MW
(GO)/LW (PO) intégrée dans la vitre arrière/latérale,
raccordez le câble de commande d’antenne (bleu) ou
l’entrée d’alimentation des accessoires (rouge) au bornier
de l’amplifi cateur d’antenne existant. Pour plus de détails,
consultez votre revendeur.

•

Une antenne électrique sans boîtier de relais ne peut pas être
utilisée avec cet appareil.

Raccordement pour la conservation de la mémoire

Lorsque le câble de commande d’antenne jaune est connecté,
le circuit de la mémoire est alimenté en permanence même si la
clé de contact est en position d’arrêt.

Remarques sur le raccordement des haut-parleurs

•

Avant de raccorder les haut-parleurs, mettre l’appareil hors
tension.

•

Utiliser des haut-parleurs ayant une impédance de 4
à 8 ohms et une capacité adéquate sous peine de les
endommager.

•

Ne pas raccorder les bornes du système de haut-parleurs au
châssis de la voiture et ne pas connecter les bornes du haut­parleur droit à celles du haut-parleur gauche.

•

Ne pas raccorder le câble de mise à la masse de cet appareil
à la borne négative (–) du haut-parleur.

•

Ne pas tenter de raccorder les haut-parleurs en parallèle.

•

Connectez uniquement des haut-parleurs passifs. La
connexion de haut-parleurs actifs (avec des amplifi cateurs
intégrés) aux bornes des haut-parleurs pourrait endommager
l’appareil.

•

Pour éviter tout dysfonctionnement, n’utilisez pas les câbles
des haut-parleurs intégrés installés dans votre voiture si
l’appareil dispose d’un câble négatif commun (–) pour les
haut-parleurs droit et gauche.

•

Ne raccordez pas entre eux les cordons des haut-parleurs de
l’appareil.

Remarque sur le raccordement

Si les enceintes et l’amplifi cateur ne sont pas raccordés
correctement, le message « FAILURE » s’affi che. Dans ce cas,
assurez-vous que les enceintes et l’amplifi cateur sont raccordés
correctement.

Schema di collegamento

A A AMP REMOTE IN di un amplifi catore di

potenza opzionale

Questo collegamento è riservato esclusivamente agli
amplifi catori. Non collegare un tipo di sistema diverso onde
evitare di causare danni all’apparecchio.

B Al cavo interfaccia di un telefono per auto

Avvertenza

Quando si collega l’apparecchio con il cavo di
alimentazione in dotazione 3, si potrebbe danneggiare
l’antenna elettrica se questa non dispone di scatola a relè.

Note sui cavi di controllo e di alimentazione

•

Il cavo (blu) di controllo dell’antenna elettrica fornisce
alimentazione pari a +12 V CC quando si attiva il sintonizzatore
oppure la funzione TA (notiziario sul traffi co) o AF (frequenza
alternativa).

•

Se l’automobile è dotata di antenna FM/MW/LW incorporata
nel vetro posteriore/laterale, collegare il cavo (blu) di
controllo dell’antenna elettrica o il cavo (rosso) di ingresso
dell’alimentazione accessoria al terminale di alimentazione
del preamplifi catore dell’antenna esistente. Per ulteriori
informazioni, consultare il proprio fornitore.

•

Non è possibile usare un’antenna elettrica senza scatola a relè
con questo apparecchio.

Collegamento per la conservazione della memoria

Quando il cavo di ingresso alimentazione giallo è collegato, viene
sempre fornita alimentazione al circuito di memoria anche quando
l’interruttore di accensione è spento.

Note sul collegamento dei diffusori

•

Prima di collegare i diffusori spegnere l’apparecchio.

•

Usare diffusori di impedenza compresa tra 4 e 8 ohm e con
capacità di potenza adeguata, altrimenti i diffusori potrebbero
venir danneggiati.

•

Non collegare i terminali del sistema diffusori al telaio dell’auto
e non collegare i terminali del diffusore destro a quelli del
diffusore sinistro.

•

Non collegare il cavo di terra di questo apparecchio al terminale
negativo (–) del diffusore.

•

Non collegare i diffusori in parallelo.

•

Assicurarsi di collegare soltanto diffusori passivi, poiché il
collegamento di diffusori attivi, dotati di amplifi catori incorporati,
ai terminali dei diffusori potrebbe danneggiare l’apparecchio.

•

Per evitare problemi di funzionamento, non utilizzare i cavi dei
diffusori incorporati installati nell’automobile se l’apparecchio
condivide un cavo comune negativo (–) per i diffusori destro e
sinistro.

•

Non collegare fra loro i cavi dei diffusori dell’apparecchio.

Nota sui collegamenti

Se l’amplifi catore e il diffusore non sono collegati correttamente,
“FAILURE” viene visualizzato nel display. In tal caso, accertarsi
che l’amplifi catore e il diffusore siano collegati correttamente.

Aansluitschema

A Naar AMP REMOTE IN van een optionele

eindversterker

Deze aansluiting is alleen bedoeld voor versterkers. Door
een ander systeem aan te sluiten kan het apparaat worden
beschadigd.

B Naar het interface-snoer van een

autotelefoon

Waarschuwing

Indien u een elektrische antenne heeft zonder relaiskast,
kan het aansluiten van deze eenheid met het bijgeleverde
netsnoer 3 de antenne beschadigen.

Opmerkingen over de bedienings- en voedingskabels

•

De antennevoedingskabel (blauw) levert +12 V gelijkstroom
wanneer u de tuner inschakelt of de AF (Alternative
Frequency) of TA (Traffi c Announcement) functie activeert.

•

Wanneer uw auto is uitgerust met een FM/MW/LW-antenne
in de achterruit/voorruit, moet u de antennevoedingskabel
(blauw) of de hulpvoedingskabel (rood) aansluiten op de
voedingsingang van de bestaande antenneversterker.
Raadpleeg uw dealer voor meer details.

•

Met dit apparaat is het niet mogelijk een automatische antenne
zonder relaiskast te gebruiken.

Instandhouden van het geheugen

Zolang de gele stroomdraad is aangesloten, blijft de
stroomvoorziening van het geheugen intact, ook wanneer het
contact van de auto wordt uitgeschakeld.

Opmerkingen betreffende het aansluiten van de luidsprekers

•

Zorg dat het apparaat is uitgeschakeld, alvorens de
luidsprekers aan te sluiten.

•

Gebruik luidsprekers met een impedantie van 4 tot 8 Ohm
en let op dat die het vermogen van de versterker kunnen
verwerken. Als dit wordt verzuimd, kunnen de luidsprekers
ernstig beschadigd raken.

•

Verbind in geen geval de aansluitingen van de luidsprekers
met het chassis van de auto en sluit de aansluitingen van de
rechter- en linkerluidspreker niet op elkaar aan.

•

Verbind de aarddraad van dit apparaat niet met de negatieve
(–) aansluiting van de luidspreker.

•

Probeer nooit de luidsprekers parallel aan te sluiten.

•

Sluit geen actieve luidsprekers (met ingebouwde versterkers)
aan op de luidspreker-aansluiting van dit apparaat. Dit zal
leiden tot beschadiging van de actieve luidsprekers. Sluit dus
altijd uitsluitend luidsprekers zonder ingebouwde versterker
aan.

•

Om defecten te vermijden mag u de bestaande
luidsprekerbedrading in uw auto niet gebruiken wanneer er een
gemeenschappelijke negatieve (–) draad is voor de rechter- en
linkerluidsprekers.

•

Verbind de luidsprekerdraden niet met elkaar.

Opmerking over aansluiten

Als de luidspreker en versterker niet correct zijn aangesloten,
wordt "FAILURE" in het display weergegeven. In dit geval moet u
zorgen dat de luidspreker en versterker correct zijn aangesloten.

8

CDX-GT20W/GT200/GT200E/GT200S/GT250S

SECTION 2

DISASSEMBLY

Note : This set can be disassemble according to the following sequence.

SET

2-1. SUB PANEL ASSY

(Page 10)

2-2. CD MECHANISM BLOCK

(Page 10)

2-3. MAIN BOARD

(Page 11)

2-7. OPTICAL PICK-UP

(Page 13)

2-4. CHASSIS (T) SUB ASSY

(Page 11)

2-5. ROLLER ARM ASSY

(Page 12)

2-6. CHASSIS (OP) ASSY

(Page 12)

2-8. SL MOTOR ASSY (M902)

(Page 13)

2-10. SERVO BOARD

(Page 14)

2-9. LE MOTOR ASSY (M903)

(Page 14)

9

CDX-GT20W/GT200/GT200E/GT200S/GT250S

s

)

Note : Follow the disassembly procedure in the numerical order given.

2-1. SUB PANEL ASSY

3

two claws

1

two

screws

(+PTT 2.6

×

6)

2-2. CD MECHANISM BLOCK

7

CD mechanism block

4

sub panel assy

6

bracket (CD)

5

two

screws

(+PTT 2.6

2

two claw

×

4)

10

2

screw

(+PTT 2.6

4

CNP301

×

6)

3

1

screw

(+PTT 2.6

×

6

2-3. MAIN BOARD

1

(+BTT 2.6

three

screws

×

CDX-GT20W/GT200/GT200E/GT200S/GT250S

5)

2

two

screws

×

8)

3

MAIN board

(+PTT 2.6

2-4. CHASSIS (T) SUB ASSY

2

two

screws

(+P 1.7

5

SENSOR board

3

claw

×

2.2)

4

claw

1

two

screws

×

(+P 1.7

6

2.2)

chassis (T) sub assy

11

CDX-GT20W/GT200/GT200E/GT200S/GT250S

2-5. ROLLER ARM ASSY

3

washer (1.1-2.5)

5

4

gear (RA1)

1

spring (RAL)

roller arm assy

2

spring (RAR)

2-6. CHASSIS (OP) ASSY

0

coil spring (damper)

4

washer

5

gear (LE1)

lever (D)

6

8

qa

chassis (OP) assy

1

CN1

9

two coil springs (damper)

7

slider (R)

12

2

Remove the six solders.

3

tension spring (KF60)

2-7. OPTICAL PICK-UP

)

)

5

claw

CDX-GT20W/GT200/GT200E/GT200S/GT250S

2

chucking arm sub assy

1

tension coil spring (CHKG

7

optical pick-up

2-8. SL MOTOR ASSY (M902)

6

main shaft

4

rack (SL)

3

screw

(+B 1.4

×

5)

2

SL motor assy (M902)

1

screw

(+P 1.4

×

1.8

13

CDX-GT20W/GT200/GT200E/GT200S/GT250S

2-9. LE MOTOR ASSY (M903)

8

(+M 1.7

qf

two toothed lock

(+M 1.4

bracket (LEM-N)

qs

(+M 1.7

screw

)

×

2.5)

6

(+P 1.7

screw

screws

×

qa

(+M 1.7

qd

2.2)

screw

0

gear (LE) assy

×

2.5)

qg

LE motor assy

(M903)

7

leaf spring (LE)

screw

×

9

bearing (LEB-N)

2

washer

3

gear (LE1)

lever (D)

2.5)

4

5

slider (R)

2-10. SERVO BOARD

1

Remove the eight solders.

1

Remove the solders.

6

2

4

(M 1.7

SERVO board

Remove the three solders.

toothed lock

5

claw

×

screw

2.5)

14

3

CN1

3-1. BLOCK DIAGRAM — CD SECTION —

DETECTOR

PD1

PD2

E

F

LASER DIODE

PICK-UP BLOCK

(KSS1000E)

2-AXIS DEVICE

(FOCUS)

(TRACKING)

PD LD

OPTICAL

PD2

PD1

I-V AMP

MON OUT

FCS+

FCS–

TRK+

TRK–

RFEQO

FPI2

96

FNI2

94

FPI1

97

FNI1

95

E

F

LD

AUTOMATIC

POWER

CONTROL

M902

(SLED)

Q21

M

100

98

91

16

15

18

17

14

13

RFRP

TNI

TPI

LDO

FOCUS/TRACKING COIL DRIVE,

SLED/SPINDLE/LOADING

MOTOR DRIVE

VO4–

VO4+

VO3–

VO3+

VO1+

VO1–

SECTION 3

DIAGRAMS

83

3

TEI

6

92

MDI

IC1

OPIN4–

26

OPOUT4

25

OPIN3–

23

OPOUT3

22

OPOUT1

4

OPOUT2

7

CDX-GT20W/GT200/GT200E/GT200S/GT250S

• R-ch is omitted due to same as L-ch.

• Signal Path

: CD PLAY

RFO

RFI

81

RFRPI

82

RFZI

2

TEZI

7

89

RF AMP,DIGITAL SERVO,

DIGITAL SIGNAL PROCESSOR

IC2

AGCI

88

F0O

9

TRO

10

FMO

12

DMO

13

PIO3
PIO0

MSTBY

ZDET

/RST

/CCE

BUCK

BUS3
BUS2
BUS1
BUS0

30

LO

27

RO

XI

XO

R-CH

UNISI

56

RXD

25

UNISO

57

TXD

26

UNICKI

58

BUS ON

DEC XMUTE

51
48
36
58
37
43
42
41
40
39
38

23

24

X2

16.9344MHz

SW1

(DOWN)

SW2

(SELF)

SW3

(DISC IN)

X1

12MHz

37

DEC INT

30

DEC SSTBY

27

CD ZDET

15

CD XRST

14

CD XCCE

13

CD BUCK

12

CD BUS3

11

CD BUS2

10

CD BUS1

8

CD BUS0

7

X1

81

X0

80

MEC_DSW

46

MEC_SELFSW

53

MEC_INSW

45

CD

SYSTEM CONTROL

IC3

MECON CHK

BU IN
A ATT

RSTX

EJECT OK

MECON

CDON

ZMUTE

CDON CHK

CDON

1500MV

50
51
60

75

SYSTEM CONTROL

61
63
64
66

67

68

+1.5V

1

MECHA+6V

D+3.3V

+1.5V ON/OFF

SWITCH

Q2,3

+1.5V

EJECT OK SW

89

CDM ON

99

CD ON

98

Z MUTE

93

+1.5V REG

VOUT

IC6

UNI SI

UNI SO

UNI CLK
BUS ON
B/U CHECK
ATT

SYS RST

IC501 (1/3)

VDD

CE

CD-L

15
3

MAIN

A

SECTION

(Page 16)

MAIN

B

SECTION

(Page 16)

DISPLAY

C

SECTION

(Page 17)

BU+3.3V

12

M901

(SPINDLE)

M903

(LOADING)

M

M

VO2+

11

VO2–

10

VOL+

9

VOL–

CDX-GT20W/GT200/GT200E/GT200S/GT250S

MUTE

FWD

REV

SW4

(LIMIT)

21

1

28

42

6

43

44

MEC_LIMIT

DRVON

MEC LOAD

MEC EJECT

15 15

CDX-GT20W/GT200/GT200E/GT200S/GT250S

3-2. BLOCK DIAGRAM — MAIN SECTION —

ELECTRONIC VOLUME

IC401

J1

(ANTENNA)

(TUNER UNIT)

1

ANT

MUTE CONDITION

TU1

L-CH
R-CH

TU VDD

E2P VDD

TU-SCL
TU-SDA

S-METER
TU MUTE

E2P SCL

E2P SDA

QUALITY

CD

SECTION

(Page 15)

VCC

RDS

4
3

10
11
15

13
14

6
7

16
17

8
5

9

GT200:AEP,UK
/GT200S

B

AUDIO+8.3V
TU+5V

BU+3.3V

SCL
SDA

X51

8.664MHz

UNI SI

UNI SO

UNI CLK
BUS ON

B/U CHECK
ATT

J901

AUX

9

XTI SCL

10

XTO

16

MPX

CD

SECTION

(Page 15)

R-CH

RDS DEMODULATOR

IC51

VDDA VDDD

1 7

A

SDA

INTN

NS MASK

CONTROL

CD-L

AUX

BUFFER

IC901

Q22

SCL

11

SDA

12

15

RDS POWER

CONTROL

Q51

D512

R-CH

R-CH

BU+3.3V

9

CD LCH

8

CD RCH

5

AUX LCH

3

AUX RCH

7

TU LCH

6

TU RCH

SYSTEM CONTROL

39

VSM

12

TU ATT

25

EEP CKO

24

EEP SIO

53

TU ATT IN

38

QUALITY

NS MASK

13

56

DAVN

30

RDS ON

58

UNISI

59

UNISO

60

UNISCK

87

BUS ON

OUT SUB-L

OUT SUB-R

IC501 (2/3)

OUT FL

OUT RL

OUT FR

OUT RR

MUTE

SCL
SDA

I2C CKO

I2C SIO

VOL ATT

ATT

BEEP

AMP STB

DIAG

TEL ATT

ACC IN

TEST IN

BU IN

17
18

23

22

25
24

29

30
31

33
34

9

86

5

26

8

74

72

73

54

R-CH

R-CH (FRONT)
R-CH (REAR)

SCL
SDA

SCL
SDA

R-CH

MUTE

Q481

MUTE

Q441

D511

AEP,UK

TEL ATTENATION

D479

CHECK

Q651

D580,581

MUTE DRIVE

Q478,479

BATTERY CHECK

Q580-582

• R-CH is omitted due to same as L-CH.

• Signal Path

: CD PLAY

: FM

: AM/MW/LW

: AUX

MUTE
Q461

BATT

L

R

SDA
SCL

BATT

BATT

J330

REAR

AUDIO OUT

12

IN FL

11

IN RL

2

SDA

4

SCL

16

BEEP

22

STB

25

DIAG

35

VP

IC2-BUS
CONTROLLED
POWER AMP/

MULTIPLE

VOLTAGE

REGULATOR

TU+5V

IC750

OUT FL+
OUT FL–

OUT RL+
OUT RL–

AMP-REM

ANT-REM

AUDIO8.3V

B.UP+B

SERVO3.3V

MECHA6V

PANEL+B

TU+5V REG

Q1

29
27

30
37
31
33
34

5
3

9
7

BATT

AUDIO+8.3V
BU+3.3V
SERVO+3.3V

MECHA+6V
PANEL+B

ACCESSORY

CHECK

Q631

AUDIO+8.3V

R-CH

FU601

CN601

10

12

11

16

13

15

1

FL+

9

FL–

2

RL+
RL–

4

FR+
FR–

3

RR+
RR–

5

AMP-REM

6

ANT-REM

TEL-MUTE

7

ACC

TEST

CDX-GT20W/GT200/GT200E/GT200S/GT250S

1616

3-3. BLOCK DIAGRAM — DISPLAY SECTION — 3-4. CIRCUIT BOARDS LOCATION

t

CDX-GT20W/GT200/GT200E/GT200S/GT250S

CD

SECTION

(Page 15)

KEY MATRIX

LSW901-904,906-920

RE901

PUSH SELECT

(VOLUME)

ROTARY

ENCODER

S502

FREQUENCY

()

SELECTOR

GT250S

SYS RST

C

BU+3.3V

D503

KEY ACKNOWLEDGE

10K

9K

RESET

IC602

2 1

VDD VOUT

SWITCH

Q664

BU+3.3V

D510

X502

32.678kHz

S702

RESET

SYSTEM CONTROL

KEYIN0

41

KEYIN1

40

KEY ACK

52

XKEY ON

76

RE-IN0

31

RE-IN1

32

AREASEL0

3

7

NOSE DET

88

SYS RST

RESET

77

79

XOUT

XIN

80

IC501 (3/3)

LCD SO

LCD CKO

LCD CE

SIRCS

OSC IN

OSC OUT

28
29
27

64

82

83

LCD DRIVER

IC901

64

DI
CL

CLK

63

CE

CE

62

REMOTE CONTROL

SIGNAL REVEIVER

2

18.432MHz

1

IC971

OUT

X501

COM4

COM1

DIMMER

BACK LIGHT

2

LCD BACK LIGHT

5

S1

|

|

55

•

S48

60

51

|

|

54

LED932

LCD BACK

()

LIGHT

DIMMER

LED DRIVE

Q931

LED DRIVE

Q932

IR

LCD901

LIQUID
CRYSTAL
DISPLAY

PANEL

PANEL+B

LED941-944,951
LSW901-904,906-920

SERVO board

SENSOR board

tuner uni
(TU1)

MAIN board

KEY board

JACK board

CDX-GT20W/GT200/GT200E/GT200S/GT250S

17 17

CDX-GT20W/GT200/GT200E/GT200S/GT250S

• NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS

THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed
in each block.)

For schematic diagrams.

Note:

• All capacitors are in µF unless otherwise noted. (p: pF)
50 WV or less are not indicated except for electrolytics
and tantalums.

• All resistors are in Ω and 1/
specified.

f

•

• C : panel designation.

• A : B+ Line.

• B : B– Line.

• H : adjustment for repair.

•Voltages and waveforms are dc with respect to ground

• CD mechanism (1/2) and (2/2) sections

no mark : CD PLAY

• Main (1/3), (2/3), (3/3) and Key sections

no mark : FM

: internal component.

Note:

The components identi­fied by mark 0 or dotted
line with mark 0 are criti-
cal for safety.
Replace only with part
number specified.

under no-signal (detuned) conditions.

(): AM/MW/L W
<>: CD PLAY

4

W or less unless otherwise

Note:

Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.

For printed wiring boards.

Note:

• X : parts extracted from the component side.

• Y : parts extracted from the conductor side.

a

•

• : Pattern from the side which enables seeing.

(The other layers' patterns are not indicated.)

Caution:
Pattern face side: Parts on the pattern face side seen from the
(Side B) pattern face are indicated.
Parts face side: Parts on the parts face side seen from the
(Side A) parts face are indicated.

: Through hole.

C

Q

These are omitted

EB

E

CB

These are omitted

∗ : Impossible to measure

•Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc­tion tolerances.

•Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc­tion tolerances.

• Circled numbers refer to waveforms.

• Signal path.

J : CD PLAY
F : FM
f : AM/MW/LW
L : AUX

C

BE

These are omitted

• WAVEFORMS

— SERVO BOARD — (CD PLAY)

1

IC2 5 (FEI)

0 V

Approx. 100 mVp-p

50 mV/DIV, 5 msec/DIV

2

IC2 6 (TEI)

0 V

Approx. 400 mVp-p

200 mV/DIV, 5 msec/DIV

3

IC2 wd (XI)

0.6 Vp-p

16.9344 MHz

0.2 V/DIV, 0.2 µsec/DIV

— MAIN BOARD —

1

IC51 9 (XTI)

4

IC2 ia (RFI)

0.5 V/DIV, 0.5 µsec/DIV

5

IC2 of (FNI2),

0.5 V/DIV, 0.5 µsec/DIV

6

IC2 oh (FPI2),

0.5 V/DIV, 0.5 µsec/DIV

3

IC501 is (OSC IN)

og (FNI1)

oj (FPI1)

1.5 Vp-p

Approx.
1Vp-p

1.5 Vp-p

7

IC3 ia (X1)

12 MHz

0.5 V/DIV, 0.2 µsec/DIV

1.1 Vp-p

CDX-GT20W/GT200/GT200E/GT200S/GT250S

0.5 V/DIV, 0.1

2

IC501 i; (XIN)

0.2 V/DIV, 0.1 µsec/DIV

µ

sec/DIV 1 V/DIV, 0.1 µsec/DIV

1818

8.664 MHz

32.768 kHz

1 Vp-p

0.7 Vp-p

0.8 Vp-p

18.432 MHz

3-5. PRINTED WIRING BOARDS — CD MECHANISM SECTION — • Refer to page 17 for Circuit Boards Location. : Uses unleaded solder.

CDX-GT20W/GT200/GT200E/GT200S/GT250S

A

B

C

D

E

F

G

1

R44

C15
R43

C46

R55

FMA3

C48

R7

R133

R132

C132

C80

C56

Q2

C18

R17

IC6

C66

R77

234567891011 12 13 14

TP39

IC2

TP72

R63

TP62

R80

TP98

TP15

TP87

C51

C52

R38

R69
R21

R68

C53

R39

R41

R75

R40

R42

C43

R64

TP75

R71

R72

R73

R74

TP38

C49

TP64

R67

R1

TP31

R65

TP3

TP4

TP5

C50

TP32

TP63

C62

R52

TP36

TP35
TP34

C47

C45

C44

TP52

TP61

TP37

TP33

R57

R54

R53

R70

R18

FMB4

SW3

TP65

SW2

(Page 22)

Q3

C133

C67

R5

C71

R8

C14

R78

R24

R79

R10

TP47

R22

R23

R62

IC3

R81

TP68
TP67

R9

C24

C30

TP48

R25

R61

R82

R98

R3

C31

C55

R34

R26

R60

R85

IC1

C17

R58

C72

R27

C29

C68

R16

R30

C54

R33

R35

TP70

R97

R2

R87

C16

TP45

TP46

TP69

R86

R12

R20

FMA4

C69

C70

FB4

FMA6

FB3

C10

FB2

R15

R14

Q21

R144

C13

R147

R141

FMA5

TP21

CN1

C11

TP22

16

TP11

R11

C12

TP25

FMB5

TP28

TP6

TP7

TP1

TP9

TP8

TP10

TP2

TP29

TP92

TP23

TP95

TP99

TP26

TP27

TP88

TP89

TP90

TP91

TP24

TP53

TP96

BP10

CN2

TP30

C22

TP44

FMB3

TP43

C32

TP49

R13

TP41

C19

C20

TP42

C23
C25

C26

R28

C33

X2

R31

R32

C36

TP13

TP86

R29

R19

TP79

TP14

C40

R84

R37

TP50

X1

TP82

TP84

C60

C41

C42

TP71

TP76

R83

C39

TP51

BP60

TP77

TP85

R36

C58

TP74

TP78

TP80

TP81

TP97

TP83

TP12

R96

1-864-903-

H

CDX-GT20W/GT200/GT200E/GT200S/GT250S

SW1

C7

• Semiconductor
Location

Ref. No. Location
IC1 G-2

IC2 B-11
IC3 D-2
IC6 D-2

Q2 C-1
Q3 C-2
Q21 B-4

19 19

CDX-GT20W/GT200/GT200E/GT200S/GT250S

3-6. SCHEMATIC DIAGRAM — CD MECHANISM SECTION (1/2) — • Refer to page 18 for Waveforms.

C18

R55

C46

TP42

C45

TP43

TP44

C22

C29

R57

C47

C49

C48

C50

C51

TP38

C52

C53

TP53

CN1

R12 C16
TP21

TP22

TP23

TP24

TP25

TP26

TP27

TP28

C11

R11

C12

TP39

R58

C54

C55

C56

C24

TP41

C19

R13

R54

R52

R53

C20

R7

R10

R17

C15

IC2

C32

R43

C44R44

TP37

TP35

TP34

TP36

TP33

TP32

R18

TP31

TP52

R42

R22

R23

R41

R24

R40

R25

R39

R26

R38 R27

C43

R29 R19

R33

C42

C41

C40 R37

C58

C39

TP50

TP51

TP49

R36R30

R35

R20

C60

C72

C33

R31

R32

X2

C36

C133

Q2

R132

R133

Q3

IC6

C80

C132

CDX-GT20W/GT200/GT200E/GT200S/GT250S

C30

C13

Q21

TP29 TP30

R14 R15

C14

R16

C17

C31

TP45

TP46

C23

TP47

TP48

R28

C25

C26

FB3

R34

C10

FB2

FB4

(Page 21)

2020

• Refer to page 18 for Waveforms.

• Refer to page 28 for IC Block Diagrams.

3-7. SCHEMATIC DIAGRAM — CD MECHANISM SECTION (2/2) — • Refer to page 30 for IC Pin Descriptions.

(Page 25)

CDX-GT20W/GT200/GT200E/GT200S/GT250S

(Page 20)

SW3

SW2

M903

M901

SW4

SW1

TP74

TP75

TP76

TP77

TP78

TP79

TP80

TP81
TP82

TP83

TP84

TP85

TP86

TP87

TP1

TP2

CN2

TP88

TP89

TP90

TP91

TP92

R144

R147

R141

TP97

TP98

TP99

IC B/D

TP10

TP11

TP7

TP6

TP3

TP4

TP5

BP10

R1

R9

IC1

C7

R5

R8

R6

R2

TP12

TP13

TP14

TP15

R97

R87

R98

C69

X1

R96

C70

TP72

BP60

TP71

R86

C68 C66

TP70

TP69

R85

67

84

81

82

80

TP

TP68

R

R

83

R

60

R21

R

79

R

R

R

IC3

2

R61

R6

R77

R75

67
C

78
R

R74

R73

R72

R71

TP65

R70

C62

TP64

TP63

R69

R68

TP62

TP61

C71

R63

R65

R64

R67

TP8

M902

TP9

CDX-GT20W/GT200/GT200E/GT200S/GT250S

21 21

CDX-GT20W/GT200/GT200E/GT200S/GT250S

3-8. PRINTED WIRING BOARD — MAIN SECTION — • Refer to page 17 for Circuit Boards Location. : Uses unleaded solder.

A

B

C

D

E

F

G

H

J

1

(ANTENN

JW101

C7

JW100

R6

C62

C54

R51

R52

R54

C51

I

JW104

JW105

234567891011 12 13 14

J330

REAR

AUDIO OUT

LR

C484

R482

Q471

R472

Q481

R481

R471

C471

C481

C401

165

JW164

JW

JW124

JW72

JW150

160

162

JW

JW

JW161

JW84

JW85

R910

JW155

JW154

C903

R911

JW128

JW139

D903

CN701

JW21

C452

C455

C441

R441

C431

IC401

166

169

JW

JW

JW156

R61

71
JW

(Page 26)

Q441

R442

C445

R431

JW91

JW129

JW130

R570

76
JW

FB603

167
JW

R662

R664

R661

R663

C474

C465

R451

R461

C412

FB410

JW121

JW122

JW70

C451

C461

R408

R407

R409

R411

Q431

R432

C442

C432

C435

C410

JW108

D719

C462

FB411

JW89

JW83

JW80

R575

R577

JW54

22
JW

C753

Q451

R452

JW20

R462

Q461

JW88

R401

R405

C413

R406

132

131

JW

JW

R410

C411

JW81

JW90

C756

JW123

R557

69
JW

103
JW

FB501

R522

133

126

JW

JW

R505

R513

R514

GT200:AEP,UK/GT200S

JW153

C763

C758

JW92

JW93

C754

R752

C755

GT250S

FREQUENCY

SELECT

9K

R534

10K

R757

R532

GT200:AEP,UK/GT200S

40
JW

67
JW

C504

C503

R510

R521

74
JW

R502

R504

R503

D503

JC795

C751

JW14

JW15

JW16

JW17

C769

C750

JW18

C623

C776

C479

Q479

JW95

JW96

JW97

S502

R694

R544

GT20W/GT200/
GT200S/GT250S

R511

R512

C513

C516

68

86

C501

JW

JW

JC504

R671

GT200:AEP,UK/GT200S

JC754

C771

JW13

D756

D755

Q478

D479

GT20W/GT200/GT200S

GT250S

R545

R551

R549

GT250S

R538

R546

R550

R573

R506

R507

R520

R537

R756

AEP,UK,E.MX

C512

C514

C502

R567

R565

FMB4

C775

JC755

C765

JW10

JW11

JW12

D757

D758

C770

25
JW

24
JW

42
JW

R479

GT200E

66
JW

R531

D511

R677

R681

US,CND

R528

AEP,UK

FMB3

GT200E

EXCEPT
AEP,UK,

IC501

JC501

R561

R558

GT20W/GT200:US,CND/
GT200E/GT250S

IC750

JC753

C622

C774

C764

JC756

JW7

FB605

FB604

118
JW

87
JW

Q664

JW9

JW6

D753

R676

X502

R518

YEL

JW144

JW8

JW137

D751

D754

23
JW

JC681

JW29

R675

R566

C511

C510

R529

D502

C509

R568

R517

141
JW

125
JW

GT200:AEP,UK
/GT200S

JW30

X501

X501

JW5

D752

C507

JW140

26
JW

JW50

L501

C508

R533

L301

C406

JW56

R509

R508

R519

R692

R536

AEP,UK

C309

C407

R672

75
JW

R653

R654

C310

FB304

FB302

C302

JW28

JW148

JC527

R679

D512

R674

R691

R542

R535

C308

R302

FB307

R301

JW99

D510

S702

S702

RESET

D759

JW49

JC533

CN601

FU601

C617

D617

C618

AEP,UK

R651

D651

D609

R652

D760

Q651

AEP,UK

CNP301

C306

JW120

JW146

R578

48
JW

JW149

R547

R556

EXCEPT AEP,UK

JW82

JW65

JW62

JW111

51
JW

R636

R543

C519

JW3

FB305

C312

FB308

JW145

52
JW

63
JW

C343

C305

R563

R601

R609

R564

D761

D762

JW39

C301

JW45

IC602

JW31

JW32

53
JW

R584

C601

JW27

FB303

127
JW

JW119

AEP,UK

JW115

FB309

JW44

FB606

R673

C602

JW106

FB310

JW109

R539

Q631

R540

R541

JW117

58
JW

D601

R634

JW1

JW2

C631

R633

Q582

R585

YEL

R631

R632

Q581

D581

Q580

D580

L601

R583

R582

1-868-117-

CDX-GT20W/GT200:US,CND/GT250S

(Page 19)

11

(11)

BATT

• Semiconductor Location

Ref. No. Location
D1 F-3

D479 E-6
D502 I-7
D503 I-5
D510 H-8
D511 F-6
D512 H-8
D580 F-11
D581 F-11
D601 C-10
D609 D-8
D617 C-9
D651 C-9
D719 I-4
D751 D-7
D752 D-7
D753 D-7
D754 D-7
D755 C-5
D756 C-6
D757 C-6
D758 C-6
D759 D-8
D760 D-8
D761 C-9
D762 D-9

C55

J1

A)

JW143

JW142

JC1

TU1

GT200:AEP.UK

C404

/GT200S

C405

R29

C1

C2

C12

C13

R2

R3

FB1

R12

R13

C56

C53

C57

R53

C58

Q22

R905

IC51

R912

R913

R906

C59

C60

C901

C902

94
JW

R8

L51

R902

C3

102
JW

C5

R7

R5

R9

R4

C917

163
JW

R1

C4

C6

D1

L1

Q1

60
JW

R59

Q51

X51

R55

JW138

R58

R903

R904

R56

C905

R907

JW168

IC901

R57

R901

R60

R914

C918

CDX-GT200:AEP,UK/GT200E/GT200S

Ref. No. Location
D903 I-3

IC51 H-2
IC401 E-3
IC501 H-6
IC602 I-9
IC750 B-6
IC901 H-2

Q1 F-2
Q22 E-2
Q51 G-2
Q431 B-4
Q441 B-4
Q451 C-4
Q461 D-4
Q471 B-3
Q478 E-6
Q479 E-5
Q481 C-3
Q580 F-11
Q581 I-10
Q582 I-10
Q631 H-10
Q651 D-8
Q664 I-7

CDX-GT20W/GT200/GT200E/GT200S/GT250S

2222

• Refer to page 18 for Waveforms.

3-9. SCHEMATIC DIAGRAM — MAIN SECTION (1/3) — • Refer to page 28 for IC Block Diagrams.

CDX-GT20W/GT200/GT200E/GT200S/GT250S

TU1

JC1

J1

C3

JW102

C2 R8 R29

C5

R4

C1

C13

D1

R5

C6

C4

R1

Q1

R52

C57

C55

C56

C54

R51

C12

C53

R2

L1

L51

C51

C58

R54

R53

R13

R3

R12

IC B/D

C411

R405

R406

R407

R408

R409

R411

R410

C902 C901

FB410FB411

C410

C413

C412

R401

C431

C461

C481

C471

C451

C441

R431

R432

R452

R451

R441

R442

R462

R461

R481

R482

R472

R471

R61

Q51

IC51

R6

R7

C7

JW126

R9

R60

R905

R906

R912 R913

IC401

FB1

C405

C406

C404

C407

Q22

JW60

C401

JW169

IC901

IC B/D

R59

C62

R58

R55

R56

R57

85

84

JW

JW

X51

C59

C60

R907

R911

R914

C903

C905

R904 R903

D903

R910

J330

C484 C474

Q431

Q451

Q441

Q461

Q481

Q471

Q478

Q479

C435 C432

C455 C452

C445 C442

C465 C462

(Page 24)

D479

C479

CDX-GT20W/GT200/GT200E/GT200S/GT250S

(Page 25)

23 23

CDX-GT20W/GT200/GT200E/GT200S/GT250S

3-10. SCHEMATIC DIAGRAM — MAIN SECTION (2/3) — • Refer to page 29 for IC Block Diagrams.

C750

C751

JC795

JC754

JC755

C775 C765

C764 C774

IC750

IC B/D

D751

D752

D753

D754

D755

D756

D757

D758

CN601

D760D759

R651

(Page 23)

R479

JC753

C753

JC756

R752

C755

Q631

C754

C756

JC681

R633

C631

R631

R632R634

C623

C622

C776

C758

JW111

JW53

C769

C770

C771

C763

Q651

R654

R653

R652

D609

R609

C618C617

761
D

D651

D762

C602

C601

D617

L601

D601

FU601

CDX-GT20W/GT200/GT200E/GT200S/GT250S

(Page 25)

2424

• Refer to page 18 for Waveforms.

3-11. SCHEMATIC DIAGRAM — MAIN SECTION (3/3) — • Refer to page 32 for IC Pin Descriptions.

CDX-GT20W/GT200/GT200E/GT200S/GT250S

JC527

FB303

FB305

FB306

R578

C343

D510

JW120

C305

C301

FB309

JW28

JW145

JW146

FB310

C306

C312

FB308

CNP301

(Page 21)

JW45 JW149

JW148
JW127

C308

C302
R302

FB307

C310

C309

R301

JW99

D511

L301

FB304

FB302

D512

R679

JC533

(Page 23)

R901

R902

JW140

D719

C917

(Page 24)

FB603

CN701

(Page 27)

C918

JW128JW141

FB604

R528

L501

C511

R531

C507C508

X502

X501

R508

C510

R509

R566
R675
R676

R539

R681
R677

S502

R573

R549

R537

R545

R546

R506

R520

R538

R507

R551

R550

R564

R674

R636

R563

R756

R757

R556

R557

R534

R533

R672

R529

R544

R694

R577

R519

IC501

R575

R518

D502

R536

R691

R692

R542

C504

C503

FB501

JW49

R535

JW48

JW86

R547

R512

R511

R514

R558

R510

R513

C509

R568

R570

R532

R561

R565

R567

C512

R661

R662

R543

JC501

R517

R671

C501

C513

R522 R521

R663

R664

JW125

D503

C514

R503

R502

C502

Q664

JC504

R505

R504

R673

C516 C516

FB605

R540

R541

R585

R584

S702

Q582

R601

FB606

C519

Q580

Q581

D580

IC602

D581

R582

R583

CDX-GT20W/GT200/GT200E/GT200S/GT250S

25 25

CDX-GT20W/GT200/GT200E/GT200S/GT250S

3-12. PRINTED WIRING BOARDS — KEY SECTION — • Refer to page 17 for Circuit Boards Location. : Uses unleaded solder.

A

B

C

D

902

LSW

OFF

906

LSW
GP/ALBM

+

910

LSW

SEEK–

904

LSW
GP/ALBM

–

1

LSW902

LSW906

R902

R903

LSW904

23456789101112

908

LSW

EQ3

909

LSW

R941

LSW910

R960

R959

LED941-944

(RING ILLUMINATION)

R962

R961

LED941

R954

R953

LED943

LED942

R963

R952

SEEK+

>

M

911

LSW

(GT20W/GT200:US,CND/GT200E/GT250S)

BTM

(GT200:AEP,UK/GT200S)

PTY

LSW908

R957

R964

LED944

LSW
SOURCE

LSW909

R958

LSW911

LSW903

R910

903

R909

LSW912

LED932

LSW912

MODE

LED932

(LCD BACK LIGHT)

52

LSW913

913

LSW

1

LSW914

914

LSW

2

LED951

(DISC SLOT)

LED951

LSW915

LSW

3/REP

LCD901

915

LIQUID CRYSTAL DISPLAY PANEL

LSW916

916

LSW

4/SHUF

LSW917

917

LSW

5

R916

LSW918

918

LSW
6/PAUSE

R917

R918

1

LSW919

919

LSW

(GT20W/GT200:US,CND/GT200E/GT250S)

SENS

SENS/BTM

(GT200:AEP,UK/GT200S)

1-868-118-

R942

LSW920

4

IC971

3

LSW901

LSW907

1

2

IC971

11

(11)

13

901

LSW

907

LSW

/SCRL

z

GT20W/GT200:US,CND/

(

GT200E/GT250S

/AF/TA

z

(GT200:AEP,UK/GT200S)

920

LSW
DSPL/DIM

R972

(

E

F

G

H

J

11

(11)

1-868-119-

J901

AUX

RED

R

BLK

G

(Page 22)

MAIN BOARD

CN701

W

HT

L

1-868-119-

11

(11)

B

R912

R911

C921

C922

R921

1

R956

RE901

R904

I

R905

4

R901

RE901

PUSH SELECT

(VOLUM

R922

3

2

R955

5

E)

R951

R908

R907

R950

Q931

Q932

R934

R906

R913

R949

FM

R948

B3

R914

R947

R915

IC901

R946

C985

FM

B4

C986

R985

C983

R984

R986

C981

D903

C984

R991

R987

D981

CN901

R976

R979

R977

R981

D901

R978

D982

R982

R974

FB903

FB901

FB902

RED

R

BLK

G

R933

L

R931

WHT

944
R

R932

R945

1-868-118-

C971

11

(11)

• Semiconductor
Location

Ref. No. Location
D901 H-10

D903 H-10
D981 I-10
D982 I-10

IC901 I-8
IC971 C-12

LED932 B-5
LED941 C-2
LED942 C-3
LED943 B-3
LED944 C-4
LED951 B-7

Q931 H-5
Q932 H-5

CDX-GT20W/GT200/GT200E/GT200S/GT250S

2626

3-13. SCHEMATIC DIAGRAM — KEY SECTION —

CDX-GT20W/GT200/GT200E/GT200S/GT250S

LED932

R934

Q932

LSW902(2/2)

R931

R932

R933

R941

LED951

R942

LSW901(2/2) LSW920(2/2)

Q931

R991

LSW907(2/2) LSW919(2/2)

LSW918(2/2)

LSW917(2/2)

R944

R945

LSW916(2/2)

LSW915(2/2) LSW912(2/2)

R946

R947 R949

R948 R953

LSW914(2/2)

LSW913(2/2)

R950

R951 R954

LSW903(2/2)

R952

LSW909(2/2)

R955 R957 R959

R956 R958 R960

LSW910(2/2)

LED941

R961 R963

R962 R964

LED942 LED944

LSW908(2/2)

LSW911(2/2)

LED943

LSW904(2/2)

LSW906(2/2)

C981

R981

R982

C971

D981

D982

IC971

R987

C986C985

R972

C983

C984

R977
R978

R979

R984

R985
R986

IC901

(Page 25)

J901

CN901

FB902

D903

R976

R974

FB901

FB903

D901

RE901

R901 R902 R903 R904

901(1/2)

902(1/2)

903(1/2)

LSW

LSW

R906 R907 R908 R910R909 R911 R912 R913 R914 R915 R916

908(1/2)

907(1/2)

LSW

LSW

LSW

909(1/2)

LSW

904(1/2)

LSW

910(1/2)

LSW

911(1/2)

LSW

LSW912(1/2)

913(1/2)

LSW

914(1/2)

LSW

R922

915(1/2)

LSW

R921

C922

C921

916(1/2)

LSW

R905

906(1/2)

LSW

917(1/2)

LSW

R917 R918

LSW918(1/2)

919(1/2)

LSW

LCD901

920(1/2)

LSW

CDX-GT20W/GT200/GT200E/GT200S/GT250S

27 27

CDX-GT20W/GT200/GT200E/GT200S/GT250S

• IC BLOCK DIAGRAMS

IC1 BA5968FP-E2 (SERVO Board (2/2))

1

FWD

FWD

OUTR OUTF

LEVEL

SHIFT

REV

LEVEL
SHIFT

2

LDCTL

3

NC

4

OPOUT1

5

NC

6

NC

7

OPOUT2

8

POWVCC VCC

9

VOL–

VOL+

10

11

VOL2–

12

VOL2+

VO1–

13

14

VO1+

LEVEL
SHIFT

LEVEL
SHIFT

MUTE

28

27

26

25

24

23

22

21
20
19

18

17

16

15

REV

OPIN4+

OPIN4–

OPOUT4

OPIN3+

OPIN3–

OPOUT3

MUTE

VOL+
GND

VOL3–

VOL3+

VOL4–

VOL4+

IC401 BD3806AFS-E2 (MAIN Board (1/3))

DGND

SDA

SCL

MUTE

SEL

ADJ

VCC

32 31 30 29 28 27 26 25 24 23 22

2

C BUS

I

LOGIC

BASS
fo:60,70,80,100,120,140,160,200Hz
Q:0.5,0.75,1,1.25

MIDDLE
fo:500Hz,1kHz
Q:1

TABLE
fo:5,7.5,10,12.5kHz

VCO

FADER

(0~-58,

-∞dB)

TONE
PASS

BASS,TREBLE, MIDDLE

(-15dB~+15dB,1dB STEP)

(+23~-79dB,-∞dB

fc:53.3kHz fc:53.3kHz

ANTI-ALIASING

OUTFROUTRROUTFLOUT

VCC

FADER
(0~-58,

-∞dB)

VOLUME

1dB STEP)

FILTER

TONE
PASS

RL

FADER
(0~-58,

-∞dB)

FADER
(0~-58,

-∞dB)

BASS,TREBLE, MIDDLE

(-15dB~+15dB,1dB STEP)

VOLUME

(+23~-79dB,-∞dB

1dB STEP)

ANTI-ALIASING

FILTER

OUT

NC

NC

21 20 19 18 17

2ND ORDER LPF
fc:OFF,80,120,160Hz
Q: 0.707

MIX

NC

SUB R

GAIN+ATT

(+10~-29,

-∞dB)

2ND ORDER

LPF

OUT

SUB L

IC51 TDA7333013TR (MAIN Board (1/3))

INTERPOLATOR

1

VDDA

REF3

REF2

REF1

VSS

VDDD

RESETN

2

3

4

5

6

TM

7

8

INTN

MPX

RDS

DEMODULATOR &

SYNCHRONIZATION

RDSREG

BAND PASS

FILTER

RAM

BUFFER

&

CONTROL

LOGIC

INPUT GAIN

(0~15dB,1dB STEP)

MUTE

INPUT SELECTOR

(3 STEREO INCLUDE 1 ISOLATION INPUT)

VCC/2

3

RCH

AN

FIL

AUX

SDAOUT
SDAIN
SCK
SPI
TESTREG

SIGMA DELTA

CONVERTER

TEST LOGIC

&

PIN MUX'S

OSCILLATOR

16

MPX

15

INTN

14

CSN

13

SA_DATAOUT

12

SDA_DATAIN

11

SCL_CLK

10

XTO

9

XTI

AGND

SINC4

FILTER

SINC4REG

I2C/SPI

INTERFACE

2

AUX

LCH

6 7 8 9 10 113 4 521

TU

TU

CD

RCH

LCH

RCH

INPUT GAIN

(0~15dB,1dB STEP)

MUTE

CD

LCH

NC

NC

12 14 1613 15

NC

NC

NC

NC

NC

CDX-GT20W/GT200/GT200E/GT200S/GT250S

2828

CDX-GT20W/GT200/GT200E/GT200S/GT250S

IC750 TDA8588BJ/N2/R1 (MAIN Board (2/3))

TAB

1

OUT-FL-

3

PROTECTION/

DIAGNOSTIC

FL

RL

MUTE

MUTE

RR

OUT-FL+

OUT-RL-

OUT-RL+

IN-RL

S-GND

IN-RR

OUT-RR+

OUT-RR-

5

7

9

11

13

15

17

19

2

SDA

I2C BUS

4

SCL

6

VP2

8

PGND3

10

SVR

IN-FL

12

14

IN-FR

16

VP

BEEP

18

PGND2

OUT-FR+

OUT-FR-

DIAG

ANT-REM

AMP-REM

SERVO5V

MECH6V

B.UP+B

VP

21

23

25

27

29

31

33

35

37

CHIP DETECT/

DIAGNOSTIC

SWITCH

SWITCH

REFERENCE

DETECTION

VOLTAGE

FR

BATTERY

STANDBY/

MUTE

TEMPERATURE

PROTECTION

LOADDUMP

PROTECTION

ENABLE

LOGIC

REGULATOR

BACK-UP

SWITCHREGULATOR

20

22

24

26

28

30

32

34

36

VP1

STB

PGND1

RST

CRES

AUDIO8.3V

GND

PANEL+B

CBU

29

CDX-GT20W/GT200/GT200E/GT200S/GT250S

• IC Pin Descriptions

IC3 MB90486BPFV-G-158E1 (CD SYSTEM CONTROL) (SERVO BOARD (2/2))

Pin No. Pin Name I/O Pin Description

1 CDON 1500MV O Servo 1.5 V power supply control signal output

2 to 5 NC — Not used. (Open)

6DRVON O Motor drive on/off control signal output
7 CD BUS0 I/O Bus data signal input/output 0
8 CD BUS1 I/O Bus data signal input/output 1

9 VSS — Ground pin
10 CD BUS2 I/O Bus data signal input/output 2
11 CD BUS3 I/O Bus data signal input/output 3
12 CD BUCK O Bus clock signal output
13 CD XCCE O Chip enable signal output
14 CD XRST O Reset signal output
15 CD ZDET I Zero detection signal input

16 to 20 NC — Not used. (Open)

21 VCC — Power supply pin (+3.3 V)
22 DAC ZDETL I Zero data detection signal input (L-ch)
23 DAC ZDETR I Zero data detection signal input (R-ch)
24 NC — Not used. (Open)
25 RXD I UART RXD data signal input (MCBUS/Flash data input)
26 TXD O UART TXD data signal output (MCBUS/Flash data output)
27 DEC SSTBY O SRAM STANDBY mode control signal output

28, 29 NC — Not used. (Open)

30 DEC INT I Request signal input

31, 32 NC — Not used. (Open)

33 AVCC — Power supply pin (+3.3 V) for A/D converter
34 AVRH — External reference voltage for A/D converter
35 AVSS — Ground pin
36 NC — Not used. (Open)
37 DEC XMUTE O Mute signal output L: mute

38, 39 NC — Not used. (Open)

40 VSS — Ground pin
41 NC — Not used. (Open)
42 MEC LIMIT I Sled limit in detection switch signal input
43 MEC LOAD O Loading motor signal output (Load direction)
44 MEC EJECT O Loading motor signal output (Eject direction)
45 MEC INSW I Pack-in detection signal input
46 MEC DSW I Chucking end detection switch signal input

47, 48 MD0, MD1 I CPU operation mode designation signal input (Connect to Vcc.)

49 MD2 I CPU operation mode designation signal input (Connect to Vss.)
50 BUS ON I Bus on signal input L: bus on
51 BU IN I Backup on/off signal input H: backup on, L: backup off
52 NC — Not used. (Open)
53 MEC SELFSW I Disc insert detection switch signal input L: disc in interruption

54, 55 NC — Not used. (Open)

56 UNISI I Serial data signal input
57 UNISO O Serial data signal output
58 UNICKI I Serial clock signal input
59 LINEOFF O Line off signal output
60 A ATT O Audio attenuation signal output H: ATT on
61 EJECT OK I Front panel open signal input H: eject
62 OPEN REQ O Front panel open/close request signal output H: open request
63 MECON O Mechanism deck power supply control signal output

30

CDX-GT20W/GT200/GT200E/GT200S/GT250S

Pin No. Pin Name I/O Pin Description

64 CDON O Servo power supply control signal output H: power on
65 XUART I Sony-Bus/MC-Bus change signal input H: Sony-Bus, L: MC-Bus
66 ZMUTE O Zero detection mute signal output
67 MECON CHK I MECON rising detection signal input
68 CDON CHK I CDON rising detection signal input

69 to 74 NC — Not used. (Open)

75 RSTX I System reset signal input
76 NC — Not used. (Open)
77 X1A — Sub-clock connect pin Not used in this set. (Open)
78 X0A — Sub-clock connect pin Not used in this set. (Connect to Vss.)
79 VSS — Ground pin
80 X0 I Main-clock connect pin (12 MHz)
81 X1 O Main-clock connect pin (12 MHz)
82 VCC — Power supply pin (+3.3 V)
83 XWD I Not used in this set. (Open)
84 XINIT3 I Not used in this set. (Open)
85 NC — Not used. (Open)

86 XSJIG I Not used in this set. (Open)
87 to 89 XINIT0 to 2 I Not used in this set. (Open)
90 to 96 NC — Not used. (Open)

97 XDES I Mode select pin

98 XLINE I Not used in this set. (Open)
99, 100 NC — Not used. (Open)

31

CDX-GT20W/GT200/GT200E/GT200S/GT250S

IC501 MB90487APF-G-155E1 (SYSTEM CONTROL) (MAIN BOARD (3/3))

Pin No. Pin Name I/O Pin Description

1 AREASEL2 I Destination setting pin
2 AREASEL1 I Destination setting pin
3 AREASEL0 I Destination setting pin
4 COL SW I Illumination color select signal input
5 BEEP O Beep signal output
6 CYRIL SEL I Cyril select signal input
7 NOSE SW I Front panel open/close detect signal input
8 DIAG I Power AMP status signal input

9 VOL ATT O Electronic volume attenuate control signal output
10 NCO O Not used. (Open)
11 VSS — Ground pin
12 TU ATT O Tuner mute control signal output
13 NS MASK O Noise mask signal output (GT200: AEP, UK model/GT200S only)
14 ILLUMI SEL1 I Illumination voltage setting signal input 1
15 ILLUMI SEL2 I Illumination voltage setting signal input 2

16 to 22 NCO O Not used. (Open)

23 VCC5 — Power supply pin (+3.3 V)
24 EEP SIO I/O EEPROM bus serial data input/output
25 EEP CKO O EEPROM bus serial clock output
26 AMP STB O Power AMP satandby signal output
27 LCD CE O LCD driver chip enable signal output
28 LCD SO O LCD driver serial data signal output
29 LCD SCK O LCD driver serial clock signal output
30 RDS ON O RDS ON signal output
31 RE IN0 I Rotary encoder signal input 0
32 RE IN1 I Rotary encoder signal input 1
33 I2C CKO O I2C bus serial clock signal output
34 I2C SIO I/O I2C bus serial data signal input/output
35 DAVDD — A/D converter power supply pin (+3.3 V)
36 AVRH — A/D converter external reference power supply pin (+3.3 V)
37 DAVSS — Ground pin
38 QUALITY I Noise detect signal input
39 VSM I S-meter voltage detect signal input
40 KEY IN1 I Key signal input 1
41 KEY IN0 I Key signal input 0
42 VSS — Ground pin
43 RC IN0 I Rotary commander key signal input

44 to 48 NCO O Not used. (open)

49 MD0 I Operation mode setting pin (Connect to VDD.)
50 MD1 I Operation mode setting pin (Connect to VDD.)
51 MD2 I Operation mode setting pin (Connect to VSS.)

32

CDX-GT20W/GT200/GT200E/GT200S/GT250S

Pin No. Pin Name I/O Pin Description

52 KEY ACK I Key acknowledgment detect signal input
53 TU ATT IN I Tuner mute zero cross detect signal input
54 BU IN I Back-up power supply detect signal input
55 NCO O Not used. (Open)
56 DAVN I RDS data block synchronized detect signal input
57 NCO O Not used. (Open)
58 UNISI I SONY bus data signal input
59 UNI SO O SONY bus data signal output
60 UNI SCK O SONY bus clock signal output
61 611 SEL I Mechanism deck select signal input
62 WMA I WMA select signal input
63 NCO O Not used. (Open)
64 SIRCS I Remote control signal input

65 to 67 NCO O Not used. (Open)

68 FLASH W I Memory mode select signal input

69, 70 NCO O Not used. (Open)

71 RC IN1 I Rotary commander shift key signal input
72 ACC IN I Accessory power supply detect signal input
73 TEST IN I Test mode detect signal input
74 TEL ATT I Telephone attenuate detect signal input
75 NCO O Not used. (Open)
76 XKEY ON O A/D converter power supply control signal output
77 RESET I CPU reset signal input
78 NCO O Not used. (Open)
79 XOUT O Sub-clock output (32.768 kHz)
80 XIN I Sub-clock input (32.768 kHz)
81 VSS1 — Ground pin
82 OSC IN I Main-clock input (3.68 MHz)
83 OSC OUT O Main-clock output (3.68 MHz)
84 VCC3 — Power supply pin (+3.3 V)
85 DEMOSEL I DEMO select signal input
86 ATT O Audio mute control signal output
87 BUS ON O Bus on signal output
88 SYS RST O System reset signal output
89 EJECT OK SW O Eject OK signal output

90 to 92 NCO O Not used. (Open)

93 Z-MUTE I CD zero cross mute detect signal input

94 to 97 NCO O Not used. (Open)

98 CD ON I CD mechanism power control request signal input
99 CDM ON I CD mechanism deck power control request signal input

100 NCO O Not used. (Open)

33

CDX-GT20W/GT200/GT200E/GT200S/GT250S

SECTION 4

EXPLODED VIEWS

NOTE:

• The mechanical parts with no reference
number in the exploded views are not supplied.

• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.

• -XX and -X mean standardized parts, so
they may have some difference from the
original one.

4-1. MAIN SECTION

• Color Indication of Appearance Parts
Example :

KNOB, BALANCE (WHITE) ... (RED)

Parts Color Cabinet’s Color

• Accessories are given in the last of this
parts list.

RR

A

The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.

Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.

#1

A

A

MG-611WA-186//C

B

8

#2

not supplied

FU601

5

#3

4

6

3

#1

TU1

not supplied

B

7

2

#1

1

Ref. No. Part No. Description Remark

1 X-2067-566-1 PANEL ASSY, SUB
2 2-583-939-01 SCREW (+B 2X4)
3 X-2055-203-2 LOCK ASSY (S)
4 3-246-006-31 COVER
5 2-583-940-01 SCREW +BTT 2.6X5

6 A-1134-479-A MAIN BOARD, COMPLETE (US,CND)
6 A-1134-494-A MAIN BOARD, COMPLETE (GT250S)
6 A-1134-507-A MAIN BOARD, COMPLETE

(GT200:AEP,UK/GT200S)

6 A-1134-514-A MAIN BOARD, COMPLETE (GT200E)

34

#1

not supplied

Ref. No. Part No. Description Remark

7 2-345-298-01 PLATE (TU), GROUND
8 1-776-206-21 CORD (WITH CONNECTOR) (POWER)

(EXCEPT AEP,UK)

8 1-776-527-61 CORD (WITH CONNECTOR) (ISO) (POWER)

(AEP,UK)
FU601 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A
TU1 A-3220-961-A TUNER UNIT (TUX-032)

#1 7-685-792-09 SCREW +PTT 2.6X6 (S)
#2 7-685-790-01 SCREW +PTT 2.6X4 (S)
#3 7-685-793-09 SCREW +PTT 2.6X8 (S)

4-2. FRONT PANEL SECTION

CDX-GT20W/GT200/GT200E/GT200S/GT250S

LCD901

not supplied

not supplied

RE901

58

60

57

56

not supplied

59

63

not
supplied

not supplied

63

61

64

62

51

55

65

66

51 X-2067-610-1 BUTTON ASSY (S)

51 X-2067-611-1 BUTTON ASSY (S) (GT200:AEP,UK)
51 X-2067-612-1 BUTTON ASSY (S) (GT250S)
51 X-2102-533-1 BUTTON ASSY (S) (GT200S)
52 A-1134-211-A JACK BOARD, COMPLETE

53 2-631-526-01 PLATE (CD), LIGHT GUIDE
54 A-1134-482-A PANEL ASSY, FRONT (GT200:US,CND)
54 A-1134-488-A PANEL ASSY, FRONT (GT20W)
54 A-1134-503-A PANEL ASSY, FRONT (GT250S)
54 A-1134-510-A PANEL ASSY, FRONT (GT200:AEP,UK)

54 A-1134-516-A PANEL ASSY, FRONT (GT200S)
54 A-1134-517-A PANEL ASSY, FRONT (GT200E)
55 X-2102-730-1 KNOB (VOL) (SV) ASSY
56 2-349-626-01 SPRING (RELEASE)
57 1-780-199-11 CONDUCTIVE BOARD, CONNECTION

(GT20W/GT200:US,CND/GT200E)

not supplied

not supplied

53

54

52

Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark

60 A-1134-484-A KEY BOARD, COMPLETE (GT200:US,CND)
60 A-1134-490-A KEY BOARD, COMPLETE (GT20W)
60 A-1134-499-A KEY BOARD, COMPLETE

(GT200:AEP,UK/GT200S/GT250S)
60 A-1134-519-A KEY BOARD, COMPLETE (GT200E)
61 2-631-511-02 PANEL, FRONT BACK

62 X-2024-133-3 CASE ASSY (for FRONT PANEL) (EXCEPT US)
63 3-250-543-91 SCREW (+B P-TITE M2)
64 3-040-315-01 COVER (AC OUT)
65 X-2067-573-1 PANEL SUB ASSY, FRONT (GT200:US,CND)
65 X-2067-574-1 PANEL SUB ASSY, FRONT (GT20W)

65 X-2067-575-1 PANEL SUB ASSY, FRONT (GT200S)
65 X-2067-576-1 PANEL SUB ASSY, FRONT (GT250S)
65 X-2067-577-1 PANEL SUB ASSY, FRONT (GT200:AEP,UK)
65 X-2067-578-1 PANEL SUB ASSY, FRONT (GT200E)
66 3-251-320-01 EMBLEM (NO. 2.5), SONY

58 2-634-438-01 ILLUMINATOR (LCD)
59 X-2067-569-1 HOLDER (LCD) ASSY

LCD901 1-805-919-11 DISPLAY PANEL, LIQUID CRYSTAL

(AEP,UK,E,MX)
LCD901 1-805-920-11 DISPLAY PANEL, LIQUID CRYSTAL (US,CND)
RE901 1-478-474-12 ENCODER, ROTARY (PUSH SELECT/VOLUME)

35

CDX-GT20W/GT200/GT200E/GT200S/GT250S

4-3. CD MECHANISM SECTION (1)

(MG-611WA-186//C)

not supplied

not supplied

not supplied
(SENSOR board)

not supplied

not supplied

101

#4

103

104

106

105

102

107

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

101 A-1088-624-A CHASSIS (T) SUB ASSY
102 A-1132-415-A SERVO BOARD, COMPLETE
103 2-345-865-11 SPRING (DAMPER), COMPRESSION (BLACK)
104 2-345-865-01 SPRING (DAMPER), COMPRESSION

(NATURAL)

105 2-345-767-21 SPRING (KF60), TENSION
106 3-253-748-11 DAMPER (S)
107 3-352-758-31 SCREW (M1.7X2.5), TOOTHED LOCK
#4 7-627-552-87 SCREW, PRECISION +P 1.7X2.2

36

4-4. CD MECHANISM SECTION (2)

(MG-611WA-186//C)

154

(including M901)

CDX-GT20W/GT200/GT200E/GT200S/GT250S

155

156

157

#5

SW4

151

not supplied

M902

160

159

158

153

not supplied

152

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

151 A-1088-612-A CHASSIS (OP) COMPLETE ASSY
152 3-316-938-91 SCREW (B1.4X5), TAPPING

0153 8-820-207-12 OPTICAL PICK-UP (KSS1000E/K1RP)

154 A-1088-615-A CHASSIS (OP) SUB ASSY (including M901)
155 A-1088-616-A ARM SUB ASSY, CHUCKING

156 A-1088-613-A LEVER (SL) SUB ASSY
157 X-2024-784-3 LEVER (SL) ASSY

158 3-261-959-21 SPRING (SL), TORSION
159 3-253-736-21 SPRING (CHKG), TENSION
160 3-253-742-21 WHEEL (SL), WORM
M902 A-1088-614-A MOTOR ASSY, SL (SLED)
SW4 1-786-339-11 SWITCH (M) (LIMIT)

#5 7-627-850-77 SCREW, PRECISION +P 1.4X1.8

37

CDX-GT20W/GT200/GT200E/GT200S/GT250S

4-5. CD MECHANISM SECTION (3)

(MG-611WA-186//C)

209

207

208

201

202

207

#4

M903

206

207

210

203

211

204

205

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

201 3-262-755-11 WASHER (1.1-2.5)
202 2-186-699-21 GEAR (RA1)
203 A-1088-618-A ARM ASSY, ROLLER
204 3-259-455-21 SPRING (RAL)
205 3-253-713-21 SPRING (RAR)

206 3-259-469-21 SPRING (LE), LEAF
207 2-134-636-51 SCREW (M1.7X2.5)

208 2-186-696-21 BRACKET (LEM-N)
209 3-345-648-91 SCREW (M1.4), TOOTHED LOCK
210 A-1088-623-A GEAR (LE) ASSY
211 2-186-697-21 BEARING (LEB-N)
M903 A-1088-622-A MOTOR ASSY, LE (LOADING)

#4 7-627-552-87 SCREW, PRECISION +P 1.7X2.2

38

4-6. CD MECHANISM SECTION (4)

(MG-611WA-186//C)

258

CDX-GT20W/GT200/GT200E/GT200S/GT250S

254

255

252

256

251

253

257

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

251 2-186-700-21 GEAR (CHK1)
252 3-344-223-01 WASHER
253 3-259-470-23 GEAR (LE1)
254 3-253-755-21 LEVER (D)

255 3-899-829-01 WASHER (SLIT)
256 2-590-545-21 GEAR (LE2-M)
257 A-1088-620-A CHASSIS (M) BLOCK ASSY
258 3-262-755-11 WASHER (1.1-2.5)

39

CDX-GT20W/GT200/GT200E/GT200S/GT250S

SECTION 5

JACK KEY

NOTE:

• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.

• -XX and -X mean standardized parts, so
they may have some difference from the
original one.

• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

A-1134-211-A JACK BOARD, COMPLETE

*********************

< JACK >

J901 1-819-732-11 JACK (SMALL TYPE) (DIA. 3.5) (AUX)

*************************************************************

A-1134-484-A KEY BOARD, COMPLETE (GT200:US,CND)
A-1134-490-A KEY BOARD, COMPLETE (GT20W)
A-1134-499-A KEY BOARD, COMPLETE

(GT200:AEP,UK/GT200S/GT250S)

A-1134-519-A KEY BOARD, COMPLETE (GT200E)

********************

< CAPACITOR >

C921 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C922 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C971 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C981 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C983 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

ELECTRICAL PARTS LIST

• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.

• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA..: µPA..
uPB.. : µPB.. uPC..: µPC.. uPD.. : µPD..

• CAPACITORS
uF : µF

• COILS
uH : µH

LED932 6-501-339-01 LED NESW505CT-AST (LCD BACK LIGHT)
LED941 6-500-450-01 LED CL-195SR-CD-T (RING ILLUMINATION)

LED941 6-500-510-01 LED CL-195PG-CD-T (RING ILLUMINATION)

LED942 6-500-450-01 LED CL-195SR-CD-T (RING ILLUMINATION)

LED942 6-500-510-01 LED CL-195PG-CD-T (RING ILLUMINATION)

LED943 6-500-450-01 LED CL-195SR-CD-T (RING ILLUMINATION)

LED943 6-500-510-01 LED CL-195PG-CD-T (RING ILLUMINATION)

LED944 6-500-450-01 LED CL-195SR-CD-T (RING ILLUMINATION)

LED944 6-500-510-01 LED CL-195PG-CD-T (RING ILLUMINATION)

LED951 6-500-450-01 LED CL-195SR-CD-T (DISC SLOT)

The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.

Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.

When indicating parts by reference
number, please include the board.

< DIODE >

(GT200/GT200S/GT250S)

(GT20W/GT200E)

(GT200/GT200S/GT250S)

(GT20W/GT200E)

(GT200/GT200S/GT250S)

(GT20W/GT200E)

(GT200/GT200S/GT250S)

(GT20W/GT200E)

(GT200/GT200S/GT250S)

C984 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C985 1-131-664-11 CERAMIC CHIP 0.15uF 10% 10V
C986 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V

< CONNECTOR >

CN901 1-819-758-11 PLUG, CONNECTOR 15P

< DIODE >

D901 6-500-886-01 DIODE RSA6.1ENTR
D903 6-501-180-01 DIODE UDZW-TE17-18B
D981 6-501-167-01 DIODE UDZW-TE17-5.1B
D982 6-501-193-01 DIODE 1SS355WTE-17

< JUMPER RESISTOR >

FB901 1-216-864-11 SHORT CHIP 0
FB902 1-216-864-11 SHORT CHIP 0
FB903 1-216-295-11 SHORT CHIP 0

< IC >

IC901 6-707-063-01 IC LC75826WH-US-E
IC971 6-600-163-01 IC RS-770 (IR)

LED951 6-500-510-01 LED CL-195PG-CD-T (DISC SLOT)

(GT20W/GT200E)

< SWITCH >

LSW901 1-786-805-11 SWITCH, TACTILE (WITH LED) (Z)

(GT200/GT200S/GT250S)

LSW901 1-786-806-11 SWITCH, TACTILE (WITH LED) (Z)

(GT20W/GT200E)

LSW902 1-786-805-11 SWITCH, TACTILE (WITH LED) (OFF)

(GT200/GT200S/GT250S)

LSW902 1-786-806-11 SWITCH, TACTILE (WITH LED) (OFF)

(GT20W/GT200E)

LSW903 1-786-805-11 SWITCH, TACTILE (WITH LED) (SOURCE)

(GT200/GT200S/GT250S)

LSW903 1-786-806-11 SWITCH, TACTILE (WITH LED) (SOURCE)

(GT20W/GT200E)

LSW904 1-786-805-11 SWITCH, TACTILE (WITH LED) (GP/ALBM –)

(GT200/GT200S/GT250S)

LSW904 1-786-806-11 SWITCH, TACTILE (WITH LED) (GP/ALBM –)

(GT20W/GT200E)

LSW906 1-786-805-11 SWITCH, TACTILE (WITH LED) (GP/ALBM +)

(GT200/GT200S/GT250S)

40

CDX-GT20W/GT200/GT200E/GT200S/GT250S

KEY

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

LSW906 1-786-806-11 SWITCH, TACTILE (WITH LED) (GP/ALBM +)

(GT20W/GT200E)

LSW907 1-786-805-11 SWITCH, TACTILE (WITH LED) (z/SCRL)

(GT200:US,CND/GT250S)

LSW907 1-786-805-11 SWITCH, TACTILE (WITH LED) (z/AF/TA)

(GT200:AEP,UK/GT200S)

LSW907 1-786-806-11 SWITCH, TACTILE (WITH LED) (z/SCRL)

(GT20W/GT200E)

LSW908 1-786-805-11 SWITCH, TACTILE (WITH LED) (EQ3)

(GT200/GT200S/GT250S)

LSW908 1-786-806-11 SWITCH, TACTILE (WITH LED) (EQ3)

(GT20W/GT200E)

LSW909 1-786-805-11 SWITCH, TACTILE (WITH LED)

(M > SEEK +) (GT200/GT200S/GT250S)

LSW909 1-786-806-11 SWITCH, TACTILE (WITH LED)

(M > SEEK +) (GT20W/GT200E)

LSW910 1-786-805-11 SWITCH, TACTILE (WITH LED)

(. m SEEK –) (GT200/GT200S/GT250S)

LSW910 1-786-806-11 SWITCH, TACTILE (WITH LED)

(. m SEEK –) (GT20W/GT200E)

LSW920 1-786-806-11 SWITCH, TACTILE (WITH LED) (DSPL/DIM)

(GT20W/GT200E)

< TRANSISTOR >

Q931 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q932 8-729-027-58 TRANSISTOR DTC143ZKA-T146

< RESISTOR >

R901 1-216-819-11 METAL CHIP 680 5% 1/10W
R902 1-216-819-11 METAL CHIP 680 5% 1/10W
R903 1-216-819-11 METAL CHIP 680 5% 1/10W
R904 1-216-821-11 METAL CHIP 1K 5% 1/10W
R905 1-216-823-11 METAL CHIP 1.5K 5% 1/10W

R906 1-216-819-11 METAL CHIP 680 5% 1/10W
R907 1-216-819-11 METAL CHIP 680 5% 1/10W
R908 1-216-819-11 METAL CHIP 680 5% 1/10W
R909 1-216-821-11 METAL CHIP 1K 5% 1/10W
R910 1-216-823-11 METAL CHIP 1.5K 5% 1/10W

LSW911 1-786-805-11 SWITCH, TACTILE (WITH LED) (BTM)

(GT200:US,CND/GT250S)

LSW911 1-786-805-11 SWITCH, TACTILE (WITH LED) (PTY)

(GT200:AEP,UK/GT200S)

LSW911 1-786-806-11 SWITCH, TACTILE (WITH LED) (BTM)

(GT20W/GT200E)

LSW912 1-786-805-11 SWITCH, TACTILE (WITH LED) (MODE)

(GT200/GT200S/GT250S)

LSW912 1-786-806-11 SWITCH, TACTILE (WITH LED) (MODE)

(GT20W/GT200E)

LSW913 1-786-805-11 SWITCH, TACTILE (WITH LED) (1)

(GT200/GT200S/GT250S)

LSW913 1-786-806-11 SWITCH, TACTILE (WITH LED) (1)

(GT20W/GT200E)

LSW914 1-786-805-11 SWITCH, TACTILE (WITH LED) (2)

(GT200/GT200S/GT250S)

LSW914 1-786-806-11 SWITCH, TACTILE (WITH LED) (2)

(GT20W/GT200E)

LSW915 1-786-805-11 SWITCH, TACTILE (WITH LED) (3/REP)

(GT200/GT200S/GT250S)

LSW915 1-786-806-11 SWITCH, TACTILE (WITH LED) (3/REP)

(GT20W/GT200E)

LSW916 1-786-805-11 SWITCH, TACTILE (WITH LED) (4/SHUF)

(GT200/GT200S/GT250S)

LSW916 1-786-806-11 SWITCH, TACTILE (WITH LED) (4/SHUF)

(GT20W/GT200E)

LSW917 1-786-805-11 SWITCH, TACTILE (WITH LED) (5)

(GT200/GT200S/GT250S)

LSW917 1-786-806-11 SWITCH, TACTILE (WITH LED) (5)

(GT20W/GT200E)

LSW918 1-786-805-11 SWITCH, TACTILE (WITH LED) (6/PAUSE)

(GT200/GT200S/GT250S)

LSW918 1-786-806-11 SWITCH, TACTILE (WITH LED) (6/PAUSE)

(GT20W/GT200E)

LSW919 1-786-805-11 SWITCH, TACTILE (WITH LED) (SENS)

(GT200:US,CND/GT250S)

LSW919 1-786-805-11 SWITCH, TACTILE (WITH LED) (SENS/BTM)

(GT200:AEP,UK/GT200S)

LSW919 1-786-806-11 SWITCH, TACTILE (WITH LED) (SENS)

(GT20W/GT200E)

LSW920 1-786-805-11 SWITCH, TACTILE (WITH LED) (DSPL/DIM)

(GT200/GT200S/GT250S)

R911 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R912 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R913 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R914 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R915 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W

R916 1-216-833-11 METAL CHIP 10K 5% 1/10W
R917 1-216-835-11 METAL CHIP 15K 5% 1/10W
R918 1-216-837-11 METAL CHIP 22K 5% 1/10W
R921 1-216-025-11 RES-CHIP 100 5% 1/10W
R922 1-216-025-11 RES-CHIP 100 5% 1/10W

R931 1-216-812-11 METAL CHIP 180 5% 1/10W
R932 1-216-812-11 METAL CHIP 180 5% 1/10W
R933 1-216-812-11 METAL CHIP 180 5% 1/10W
R934 1-216-822-11 METAL CHIP 1.2K 5% 1/10W
R941 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R941 1-216-813-11 METAL CHIP 220 5% 1/10W

(GT200/GT200S/GT250S)

R942 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R942 1-216-813-11 METAL CHIP 220 5% 1/10W

(GT200/GT200S/GT250S)
R944 1-216-811-11 METAL CHIP 150 5% 1/10W
R945 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R945 1-216-812-11 METAL CHIP 180 5% 1/10W

(GT200/GT200S/GT250S)
R946 1-216-807-11 METAL CHIP 68 5% 1/10W

(GT20W/GT200E)

R946 1-216-809-11 METAL CHIP 100 5% 1/10W

(GT200/GT200S/GT250S)
R947 1-216-807-11 METAL CHIP 68 5% 1/10W

(GT20W/GT200E)

R947 1-216-809-11 METAL CHIP 100 5% 1/10W

(GT200/GT200S/GT250S)

R948 1-216-811-11 METAL CHIP 150 5% 1/10W
R949 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R949 1-216-812-11 METAL CHIP 180 5% 1/10W

(GT200/GT200S/GT250S)
R950 1-216-807-11 METAL CHIP 68 5% 1/10W

(GT20W/GT200E)

41

CDX-GT20W/GT200/GT200E/GT200S/GT250S

MAINKEY

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

R950 1-216-809-11 METAL CHIP 100 5% 1/10W

(GT200/GT200S/GT250S)

R951 1-216-807-11 METAL CHIP 68 5% 1/10W

(GT20W/GT200E)

R951 1-216-809-11 METAL CHIP 100 5% 1/10W

(GT200/GT200S/GT250S)

R952 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R952 1-216-811-11 METAL CHIP 150 5% 1/10W

(GT200/GT200S/GT250S)

R953 1-216-811-11 METAL CHIP 150 5% 1/10W
R954 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R954 1-216-811-11 METAL CHIP 150 5% 1/10W

(GT200/GT200S/GT250S)
R955 1-216-811-11 METAL CHIP 150 5% 1/10W
R956 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R956 1-216-812-11 METAL CHIP 180 5% 1/10W

(GT200/GT200S/GT250S)
R957 1-216-811-11 METAL CHIP 150 5% 1/10W
R958 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R958 1-216-812-11 METAL CHIP 180 5% 1/10W

(GT200/GT200S/GT250S)
R959 1-216-811-11 METAL CHIP 150 5% 1/10W

R960 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R960 1-216-812-11 METAL CHIP 180 5% 1/10W

(GT200/GT200S/GT250S)
R961 1-216-811-11 METAL CHIP 150 5% 1/10W
R962 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R962 1-216-812-11 METAL CHIP 180 5% 1/10W

(GT200/GT200S/GT250S)

R963 1-216-811-11 METAL CHIP 150 5% 1/10W
R964 1-216-810-11 METAL CHIP 120 5% 1/10W

(GT20W/GT200E)

R964 1-216-812-11 METAL CHIP 180 5% 1/10W

(GT200/GT200S/GT250S)
R972 1-216-809-11 METAL CHIP 100 5% 1/10W
R974 1-216-864-11 SHORT CHIP 0

R976 1-216-864-11 SHORT CHIP 0
R977 1-216-809-11 METAL CHIP 100 5% 1/10W
R978 1-216-809-11 METAL CHIP 100 5% 1/10W
R979 1-216-809-11 METAL CHIP 100 5% 1/10W
R981 1-216-811-11 METAL CHIP 150 5% 1/10W

R982 1-216-811-11 METAL CHIP 150 5% 1/10W
R984 1-216-821-11 METAL CHIP 1K 5% 1/10W
R985 1-216-821-11 METAL CHIP 1K 5% 1/10W
R986 1-216-821-11 METAL CHIP 1K 5% 1/10W
R987 1-216-857-11 METAL CHIP 1M 5% 1/10W

R991 1-216-864-11 SHORT CHIP 0

*************************************************************

C1 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V

C2 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V

C3 1-126-963-11 ELECT 4.7uF 20% 50V

C4 1-126-947-11 ELECT 47uF 20% 35V
C5 1-126-947-11 ELECT 47uF 20% 35V

C6 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C7 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C12 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C51 1-126-947-11 ELECT 47uF 20% 35V

C53 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C54 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C55 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C56 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C57 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C58 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V

C59 1-164-237-11 CERAMIC CHIP 16PF 5% 50V

C60 1-162-916-11 CERAMIC CHIP 12PF 5% 50V

C62 1-162-959-11 CERAMIC CHIP 330PF 5% 50V

C301 1-128-551-11 ELECT 22uF 20% 63V

C302 1-104-665-11 ELECT 100uF 20% 25V
C305 1-104-665-11 ELECT 100uF 20% 25V
C306 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C308 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C309 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V

C310 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C312 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C343 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C401 1-126-964-11 ELECT 10uF 20% 50V
C404 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V

A-1134-479-A MAIN BOARD, COMPLETE (US,CND)
A-1134-494-A MAIN BOARD, COMPLETE (GT250S)
A-1134-507-A MAIN BOARD, COMPLETE

(GT200:AEP,UK/GT200S)

A-1134-514-A MAIN BOARD, COMPLETE (GT200E)

*********************

7-621-284-40 SCREW +P 2.6X10
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)

< CAPACITOR >

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

(GT200:AEP,UK/GT200S)

42

C405 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C406 1-126-960-11 ELECT 1uF 20% 50V
C407 1-126-960-11 ELECT 1uF 20% 50V
C410 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C411 1-162-923-11 CERAMIC CHIP 47PF 5% 50V

CDX-GT20W/GT200/GT200E/GT200S/GT250S

MAIN

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

C412 1-126-934-11 ELECT 220uF 20% 16V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C431 1-126-964-11 ELECT 10uF 20% 50V
C432 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C435 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C776 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C901 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C902 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C903 1-126-961-11 ELECT 2.2uF 20% 50V
C905 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C441 1-126-964-11 ELECT 10uF 20% 50V
C442 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C445 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C451 1-126-964-11 ELECT 10uF 20% 50V
C452 1-165-908-11 CERAMIC CHIP 1uF 10% 10V

C455 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C461 1-126-964-11 ELECT 10uF 20% 50V
C462 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C465 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C471 1-126-964-11 ELECT 10uF 20% 50V

C474 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C479 1-126-947-11 ELECT 47uF 20% 35V
C481 1-126-964-11 ELECT 10uF 20% 50V
C484 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C501 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V

C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C503 1-104-665-11 ELECT 100uF 20% 25V
C504 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C507 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C508 1-162-917-11 CERAMIC CHIP 15PF 5% 50V

C509 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C510 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C511 1-104-665-11 ELECT 100uF 20% 25V
C512 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C513 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V

C514 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C516 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V

(GT200:AEP,UK/GT200S)

C516 1-216-864-11 SHORT CHIP 0

(GT20W/GT200:US,CND/GT200E/GT250S)
C519 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C601 1-131-868-81 ELECT 3300uF 20% 16V

C602 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C617 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C618 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C622 1-126-916-11 ELECT 1000uF 20% 6.3V
C623 1-126-916-11 ELECT 1000uF 20% 6.3V

C917 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V
C918 1-163-017-00 CERAMIC CHIP 0.0047uF 10% 50V

< CONNECTOR >

CN601 1-774-701-21 PIN, CONNECTOR 16P
CN701 1-819-773-11 SOCKET, CONNECTOR 15P
CNP301 1-817-536-11 CONNECTOR, BOARD TO BOARD 28P

< DIODE >

D1 6-501-168-01 DIODE UDZW-TE17-5.6B
D479 6-501-193-01 DIODE 1SS355WTE-17
D502 8-719-060-48 DIODE RB751V-40TE-17
D503 6-501-193-01 DIODE 1SS355WTE-17
D510 6-501-013-01 DIODE BAT54ALT1G

D511 6-500-335-01 DIODE MC2838-T112-1
D512 6-501-051-01 DIODE BAT54CLT1G
D580 6-501-171-01 DIODE UDZW-TE17-7.5B
D581 6-501-180-01 DIODE UDZW-TE17-18B
D601 8-719-049-38 DIODE 1N5404TU

D609 6-501-170-01 DIODE UDZW-TE17-6.8B
D617 6-501-180-01 DIODE UDZW-TE17-18B
D651 6-501-180-01 DIODE UDZW-TE17-18B (AEP,UK)
D719 6-501-180-01 DIODE UDZW-TE17-18B
D751 6-500-522-01 DIODE 10EDB40-TA1B2

D752 6-500-522-01 DIODE 10EDB40-TA1B2
D753 6-500-522-01 DIODE 10EDB40-TA1B2
D754 6-500-522-01 DIODE 10EDB40-TA1B2
D755 6-500-522-01 DIODE 10EDB40-TA1B2
D756 6-500-522-01 DIODE 10EDB40-TA1B2

D757 6-500-522-01 DIODE 10EDB40-TA1B2
D758 6-500-522-01 DIODE 10EDB40-TA1B2
D759 6-500-522-01 DIODE 10EDB40-TA1B2
D760 6-500-522-01 DIODE 10EDB40-TA1B2
D761 6-500-522-01 DIODE 10EDB40-TA1B2

D762 6-500-522-01 DIODE 10EDB40-TA1B2
D903 6-501-170-01 DIODE UDZW-TE17-6.8B

C631 1-126-960-11 ELECT 1uF 20% 50V
C750 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C751 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C753 1-128-551-11 ELECT 22uF 20% 63V
C754 1-126-961-11 ELECT 2.2uF 20% 50V

C755 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C756 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C758 1-126-964-11 ELECT 10uF 20% 50V
C763 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C764 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V

C765 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C769 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C770 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C771 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C774 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V

C775 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V

< FERRITE BEAD >

FB1 1-500-245-11 INDUCTOR, FERRITE BEAD
FB302 1-216-864-11 SHORT CHIP 0
FB303 1-216-864-11 SHORT CHIP 0
FB304 1-216-295-11 SHORT CHIP 0
FB305 1-216-295-11 SHORT CHIP 0

FB307 1-216-864-11 SHORT CHIP 0
FB308 1-216-295-11 SHORT CHIP 0
FB309 1-216-864-11 SHORT CHIP 0
FB310 1-216-864-11 SHORT CHIP 0
FB410 1-216-864-11 SHORT CHIP 0

(GT20W/GT200:US,CND/GT200E/GT250S)

FB410 1-414-595-11 INDUCTOR, FERRITE BEAD

(GT200:AEP,UK/GT200S)

FB411 1-216-864-11 SHORT CHIP 0

(GT20W/GT200:US,CND/GT200E/GT250S)

43

CDX-GT20W/GT200/GT200E/GT200S/GT250S

MAIN

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

FB411 1-414-595-11 INDUCTOR, FERRITE BEAD

(GT200:AEP,UK/GT200S)
FB501 1-216-295-11 SHORT CHIP 0
FB603 1-216-295-11 SHORT CHIP 0
FB604 1-500-245-11 INDUCTOR, FERRITE BEAD
FB605 1-216-864-11 SHORT CHIP 0

FB606 1-216-864-11 SHORT CHIP 0

< FUSE >

FU601 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A

< IC >

IC51 6-803-747-01 IC TDA7333013TR (GT200:AEP,UK/GT200S)
IC401 6-708-880-01 IC BD3806AFS-E2
IC501 6-806-031-01 IC MB90487APF-G-155E1
IC602 8-759-659-13 IC PST3428UL
IC750 6-705-360-02 IC TDA8588BJ/N2/R1

IC901 8-759-681-42 IC NJM12902V(TE2)

< JACK >

J1 1-815-185-13 JACK (ANTENNA)
J330 1-774-698-11 JACK, PIN 2P (AUDIO OUT REAR)

< JUMPER RESISTOR >

JC1 1-216-864-11 SHORT CHIP 0
JC501 1-216-864-11 SHORT CHIP 0
JC504 1-216-864-11 SHORT CHIP 0
JC527 1-216-821-11 METAL CHIP 1K 5% 1/10W
JC533 1-216-864-11 SHORT CHIP 0

Q580 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q581 1-801-806-11 TRANSISTOR DTC144EKA
Q582 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q631 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q651 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (AEP,UK)

Q664 8-729-027-23 TRANSISTOR DTA114EKA-T146

< RESISTOR >

R1 1-216-821-11 METAL CHIP 1K 5% 1/10W
R2 1-414-595-11 INDUCTOR, FERRITE BEAD
R3 1-414-595-11 INDUCTOR, FERRITE BEAD
R4 1-216-839-11 METAL CHIP 33K 5% 1/10W
R5 1-216-843-11 METAL CHIP 68K 5% 1/10W

R6 1-216-839-11 METAL CHIP 33K 5% 1/10W

(GT200:AEP,UK/GT200S)

R7 1-216-843-11 METAL CHIP 68K 5% 1/10W

(GT200:AEP,UK/GT200S)

R8 1-216-839-11 METAL CHIP 33K 5% 1/10W

(GT200:AEP,UK/GT200S)

R9 1-216-843-11 METAL CHIP 68K 5% 1/10W

(GT200:AEP,UK/GT200S)

R12 1-414-595-11 INDUCTOR, FERRITE BEAD

R13 1-414-595-11 INDUCTOR, FERRITE BEAD
R29 1-216-809-11 METAL CHIP 100 5% 1/10W

(GT200:AEP,UK/GT200S)

R51 1-216-797-11 METAL CHIP 10 5% 1/10W

(GT200:AEP,UK/GT200S)

R52 1-216-803-11 METAL CHIP 33 5% 1/10W

(GT200:AEP,UK/GT200S)

R53 1-414-595-11 INDUCTOR, FERRITE BEAD

(GT200:AEP,UK/GT200S)

JC681 1-216-864-11 SHORT CHIP 0
JC753 1-216-296-11 SHORT CHIP 0
JC754 1-216-296-11 SHORT CHIP 0
JC755 1-216-296-11 SHORT CHIP 0
JC756 1-216-864-11 SHORT CHIP 0

JC795 1-216-864-11 SHORT CHIP 0

< COIL >

L1 1-469-844-11 INDUCTOR 2.2uH
L51 1-216-295-11 SHORT CHIP 0 (GT200:AEP,UK/GT200S)
L301 1-216-295-11 SHORT CHIP 0
L501 1-216-295-11 SHORT CHIP 0
L601 1-456-617-11 COIL, CHOKE

< TRANSISTOR >

Q1 6-551-431-01 TRANSISTOR 2SC6027T100
Q22 1-801-806-11 TRANSISTOR DTC144EKA

(GT200:AEP,UK/GT200S)
Q51 8-729-600-22 TRANSISTOR 2SA1235-F

(GT200:AEP,UK/GT200S)
Q431 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q441 8-729-027-44 TRANSISTOR DTC114TKA-T146

Q451 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q461 8-729-027-44 TRANSISTOR DTC114TKA-T146
Q471 6-551-392-01 TRANSISTOR RT6N140C-TP-1
Q478 1-801-806-11 TRANSISTOR DTC144EKA
Q479 8-729-027-23 TRANSISTOR DTA114EKA-T146

Q481 6-551-392-01 TRANSISTOR RT6N140C-TP-1

R54 1-216-833-11 METAL CHIP 10K 5% 1/10W

(GT200:AEP,UK/GT200S)
R55 1-216-864-11 SHORT CHIP 0 (GT200:AEP,UK/GT200S)
R56 1-414-595-11 INDUCTOR, FERRITE BEAD

(GT200:AEP,UK/GT200S)
R57 1-414-595-11 INDUCTOR, FERRITE BEAD

(GT200:AEP,UK/GT200S)
R58 1-216-833-11 METAL CHIP 10K 5% 1/10W

(GT200:AEP,UK/GT200S)

R59 1-216-845-11 METAL CHIP 100K 5% 1/10W

(GT200:AEP,UK/GT200S)
R60 1-216-833-11 METAL CHIP 10K 5% 1/10W

(GT200:AEP,UK/GT200S)
R61 1-216-821-11 METAL CHIP 1K 5% 1/10W

(GT200:AEP,UK/GT200S)
R301 1-216-821-11 METAL CHIP 1K 5% 1/10W
R302 1-216-821-11 METAL CHIP 1K 5% 1/10W

R401 1-216-797-11 METAL CHIP 10 5% 1/10W
R405 1-218-881-11 METAL CHIP 27K 0.5% 1/10W
R406 1-216-809-11 METAL CHIP 100 5% 1/10W
R407 1-216-809-11 METAL CHIP 100 5% 1/10W
R408 1-216-809-11 METAL CHIP 100 5% 1/10W

R409 1-216-809-11 METAL CHIP 100 5% 1/10W
R410 1-216-809-11 METAL CHIP 100 5% 1/10W
R411 1-216-809-11 METAL CHIP 100 5% 1/10W
R431 1-216-821-11 METAL CHIP 1K 5% 1/10W
R432 1-216-841-11 METAL CHIP 47K 5% 1/10W

R441 1-216-821-11 METAL CHIP 1K 5% 1/10W
R442 1-216-841-11 METAL CHIP 47K 5% 1/10W

44

CDX-GT20W/GT200/GT200E/GT200S/GT250S

MAIN

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

R451 1-216-821-11 METAL CHIP 1K 5% 1/10W
R452 1-216-841-11 METAL CHIP 47K 5% 1/10W
R461 1-216-821-11 METAL CHIP 1K 5% 1/10W
R462 1-216-841-11 METAL CHIP 47K 5% 1/10W
R471 1-216-809-11 METAL CHIP 100 5% 1/10W

R472 1-216-841-11 METAL CHIP 47K 5% 1/10W
R479 1-216-805-11 METAL CHIP 47 5% 1/10W
R481 1-216-809-11 METAL CHIP 100 5% 1/10W
R482 1-216-841-11 METAL CHIP 47K 5% 1/10W
R502 1-216-821-11 METAL CHIP 1K 5% 1/10W

R503 1-216-821-11 METAL CHIP 1K 5% 1/10W
R504 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R505 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R506 1-216-845-11 METAL CHIP 100K 5% 1/10W

(GT20W/GT200/GT200S/GT250S)

R507 1-216-845-11 METAL CHIP 100K 5% 1/10W

(EXCEPT AEP,UK)

R508 1-216-864-11 SHORT CHIP 0
R509 1-216-812-11 METAL CHIP 180 5% 1/10W
R510 1-216-821-11 METAL CHIP 1K 5% 1/10W
R511 1-216-821-11 METAL CHIP 1K 5% 1/10W
R512 1-216-821-11 METAL CHIP 1K 5% 1/10W

R513 1-216-845-11 METAL CHIP 100K 5% 1/10W
R514 1-216-845-11 METAL CHIP 100K 5% 1/10W
R517 1-216-841-11 METAL CHIP 47K 5% 1/10W
R518 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R519 1-216-845-11 METAL CHIP 100K 5% 1/10W

R520 1-216-845-11 METAL CHIP 100K 5% 1/10W

(GT200E)
R521 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R522 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R528 1-216-845-11 METAL CHIP 100K 5% 1/10W
R529 1-216-821-11 METAL CHIP 1K 5% 1/10W

R531 1-216-845-11 METAL CHIP 100K 5% 1/10W
R532 1-216-845-11 METAL CHIP 100K 5% 1/10W
R533 1-216-845-11 METAL CHIP 100K 5% 1/10W
R534 1-216-833-11 METAL CHIP 10K 5% 1/10W
R535 1-216-833-11 METAL CHIP 10K 5% 1/10W

R556 1-216-833-11 METAL CHIP 10K 5% 1/10W

(EXCEPT AEP,UK)
R557 1-216-809-11 METAL CHIP 100 5% 1/10W
R558 1-216-821-11 METAL CHIP 1K 5% 1/10W

(GT20W/GT200:US,CND/GT200E/GT250S)
R561 1-216-845-11 METAL CHIP 100K 5% 1/10W
R563 1-216-845-11 METAL CHIP 100K 5% 1/10W

R564 1-216-845-11 METAL CHIP 100K 5% 1/10W

(AEP,UK)
R565 1-216-845-11 METAL CHIP 100K 5% 1/10W
R566 1-216-845-11 METAL CHIP 100K 5% 1/10W
R567 1-216-845-11 METAL CHIP 100K 5% 1/10W
R568 1-216-821-11 METAL CHIP 1K 5% 1/10W

(GT20W/GT200:US,CND/GT200E/GT250S)

R570 1-216-817-11 METAL CHIP 470 5% 1/10W
R573 1-216-845-11 METAL CHIP 100K 5% 1/10W

(AEP,UK)
R575 1-216-845-11 METAL CHIP 100K 5% 1/10W
R577 1-216-845-11 METAL CHIP 100K 5% 1/10W
R578 1-216-821-11 METAL CHIP 1K 5% 1/10W

R582 1-216-821-11 METAL CHIP 1K 5% 1/10W
R583 1-216-821-11 METAL CHIP 1K 5% 1/10W
R584 1-216-841-11 METAL CHIP 47K 5% 1/10W
R585 1-216-849-11 METAL CHIP 220K 5% 1/10W
R601 1-216-845-11 METAL CHIP 100K 5% 1/10W

R609 1-216-821-11 METAL CHIP 1K 5% 1/10W
R631 1-249-425-11 CARBON 4.7K 5% 1/4W
R632 1-216-841-11 METAL CHIP 47K 5% 1/10W
R633 1-216-841-11 METAL CHIP 47K 5% 1/10W
R634 1-216-829-11 METAL CHIP 4.7K 5% 1/10W

R636 1-216-845-11 METAL CHIP 100K 5% 1/10W
R651 1-216-821-11 METAL CHIP 1K 5% 1/10W

(AEP,UK)
R652 1-216-841-11 METAL CHIP 47K 5% 1/10W

(AEP,UK)
R653 1-216-833-11 METAL CHIP 10K 5% 1/10W

(AEP,UK)
R654 1-216-833-11 METAL CHIP 10K 5% 1/10W

(AEP,UK)

R536 1-216-845-11 METAL CHIP 100K 5% 1/10W
R537 1-216-845-11 METAL CHIP 100K 5% 1/10W

(AEP,UK,E,MX)

R538 1-216-845-11 METAL CHIP 100K 5% 1/10W

(US,CND)
R539 1-216-821-11 METAL CHIP 1K 5% 1/10W
R540 1-216-845-11 METAL CHIP 100K 5% 1/10W

R541 1-216-845-11 METAL CHIP 100K 5% 1/10W
R542 1-216-821-11 METAL CHIP 1K 5% 1/10W
R543 1-216-821-11 METAL CHIP 1K 5% 1/10W
R544 1-216-821-11 METAL CHIP 1K 5% 1/10W
R545 1-216-845-11 METAL CHIP 100K 5% 1/10W

(GT250S)

R546 1-216-845-11 METAL CHIP 100K 5% 1/10W

(GT250S)
R547 1-216-864-11 SHORT CHIP 0
R549 1-216-845-11 METAL CHIP 100K 5% 1/10W

(GT200E)
R550 1-216-845-11 METAL CHIP 100K 5% 1/10W
R551 1-216-845-11 METAL CHIP 100K 5% 1/10W

(GT20W/GT200/GT200S)

R661 1-216-821-11 METAL CHIP 1K 5% 1/10W
R662 1-216-845-11 METAL CHIP 100K 5% 1/10W
R663 1-216-821-11 METAL CHIP 1K 5% 1/10W
R664 1-216-845-11 METAL CHIP 100K 5% 1/10W
R671 1-216-809-11 METAL CHIP 100 5% 1/10W

R672 1-216-809-11 METAL CHIP 100 5% 1/10W
R673 1-216-833-11 METAL CHIP 10K 5% 1/10W
R674 1-216-845-11 METAL CHIP 100K 5% 1/10W
R675 1-216-821-11 METAL CHIP 1K 5% 1/10W
R676 1-216-821-11 METAL CHIP 1K 5% 1/10W

R677 1-216-821-11 METAL CHIP 1K 5% 1/10W
R679 1-216-821-11 METAL CHIP 1K 5% 1/10W
R681 1-216-864-11 SHORT CHIP 0
R691 1-216-845-11 METAL CHIP 100K 5% 1/10W
R692 1-216-845-11 METAL CHIP 100K 5% 1/10W

R694 1-216-821-11 METAL CHIP 1K 5% 1/10W

(GT200:AEP,UK/GT200S)
R752 1-216-811-11 METAL CHIP 150 5% 1/10W
R756 1-216-841-11 METAL CHIP 47K 5% 1/10W
R757 1-216-864-11 SHORT CHIP 0
R901 1-216-817-11 METAL CHIP 470 5% 1/10W

45

CDX-GT20W/GT200/GT200E/GT200S/GT250S

SENSOR SERVOMAIN

Ref. No. Part No. Description Remark

R902 1-216-817-11 METAL CHIP 470 5% 1/10W
R903 1-216-834-11 METAL CHIP 12K 5% 1/10W
R904 1-216-834-11 METAL CHIP 12K 5% 1/10W
R905 1-216-841-11 METAL CHIP 47K 5% 1/10W
R906 1-216-841-11 METAL CHIP 47K 5% 1/10W

R907 1-216-845-11 METAL CHIP 100K 5% 1/10W
R910 1-216-789-11 METAL CHIP 2.2 5% 1/10W
R911 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R912 1-216-864-11 SHORT CHIP 0
R913 1-216-864-11 SHORT CHIP 0

R914 1-216-825-11 METAL CHIP 2.2K 5% 1/10W

< SWITCH >

S502 1-571-478-11 SWITCH, SLIDE (FREQUENCY SELECTOR)

(GT250S)

S702 1-786-826-11 SWITCH, TACTILE (RESET)

< TUNER UNIT >

TU1 A-3220-961-A TUNER UNIT (TUX-032)

< VIBRATOR >

X51 1-813-173-11 VIBRATOR, CRYSTAL (8.664MHz)

(GT200:AEP,UK/GT200S)
X501 1-813-524-21 VIBRATOR, CERAMIC (18.432MHz)
X502 1-813-202-11 VIBRATOR, CRYSTAL (32.768kHz)

*************************************************************

SENSOR BOARD

**************

< SWITCH >

SW2 1-529-566-61 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-61 SWITCH, PUSH (1 KEY) (DISC IN)

*************************************************************

Ref. No. Part No. Description Remark

C32 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C33 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C36 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C39 1-126-208-21 ELECT CHIP 47uF 20% 4V
C40 1-126-395-11 ELECT CHIP 22uF 20% 16V

C41 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C42 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C43 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C44 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C45 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C46 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C47 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C48 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C49 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C50 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V

C51 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C52 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C53 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C54 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C55 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C56 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C58 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C60 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C62 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C66 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V

C67 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C68 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C69 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C70 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C71 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C72 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C80 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C132 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C133 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V

A-1132-415-A SERVO BOARD, COMPLETE

**********************

< CAPACITOR >

C7 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C10 1-126-208-21 ELECT CHIP 47uF 20% 4V
C11 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C12 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C13 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V

C14 1-104-609-11 ELECT CHIP 100uF 20% 4V
C15 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C16 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C17 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C18 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C19 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C20 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C22 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C23 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C24 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

C25 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C26 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C29 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C30 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C31 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V

< CONNECTOR >

CN1 1-691-380-21 CONNECTOR, FFC/FPC 16P
CN2 1-817-275-21 CONNECTOR, BOARD TO BOARD 28P

< JUMPER RESISTOR >

FB2 1-216-864-11 SHORT CHIP 0
FB3 1-216-864-11 SHORT CHIP 0
FB4 1-216-864-11 SHORT CHIP 0

< IC >

IC1 6-707-327-01 IC BA5968FP-E2
IC2 6-708-729-01 IC TC94A70FG-002
IC3 6-806-019-01 IC MB90486BPFV-G-158E1
IC6 6-708-728-01 IC BH15LB1WG

< TRANSISTOR >

Q2 6-551-120-01 TRANSISTOR 2SA2119K
Q3 8-729-928-90 TRANSISTOR DTC114EE
Q21 8-729-904-87 TRANSISTOR 2SB1197K-R

< RESISTOR >

R1 1-218-965-11 RES-CHIP 10K 5% 1/16W
R2 1-218-977-11 RES-CHIP 100K 5% 1/16W

46

CDX-GT20W/GT200/GT200E/GT200S/GT250S

SERVO

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

R5 1-218-969-11 RES-CHIP 22K 5% 1/16W
R6 1-218-969-11 RES-CHIP 22K 5% 1/16W
R7 1-218-990-81 SHORT CHIP 0
R8 1-218-965-11 RES-CHIP 10K 5% 1/16W
R9 1-218-965-11 RES-CHIP 10K 5% 1/16W

R73 1-218-973-11 RES-CHIP 47K 5% 1/16W
R74 1-218-941-81 RES-CHIP 100 5% 1/16W
R75 1-218-941-81 RES-CHIP 100 5% 1/16W
R77 1-218-973-11 RES-CHIP 47K 5% 1/16W
R78 1-218-941-81 RES-CHIP 100 5% 1/16W

R10 1-218-990-81 SHORT CHIP 0
R11 1-218-941-81 RES-CHIP 100 5% 1/16W
R12 1-218-969-11 RES-CHIP 22K 5% 1/16W
R13 1-218-969-11 RES-CHIP 22K 5% 1/16W
R14 1-218-929-11 RES-CHIP 10 5% 1/16W

R15 1-218-929-11 RES-CHIP 10 5% 1/16W
R16 1-218-953-11 RES-CHIP 1K 5% 1/16W
R17 1-218-990-81 SHORT CHIP 0
R18 1-218-941-81 RES-CHIP 100 5% 1/16W
R19 1-218-935-11 RES-CHIP 33 5% 1/16W

R20 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
R21 1-218-941-81 RES-CHIP 100 5% 1/16W
R22 1-218-977-11 RES-CHIP 100K 5% 1/16W
R23 1-218-977-11 RES-CHIP 100K 5% 1/16W
R24 1-218-977-11 RES-CHIP 100K 5% 1/16W

R25 1-218-977-11 RES-CHIP 100K 5% 1/16W
R26 1-218-977-11 RES-CHIP 100K 5% 1/16W
R27 1-218-977-11 RES-CHIP 100K 5% 1/16W
R28 1-218-945-11 RES-CHIP 220 5% 1/16W
R29 1-218-989-11 RES-CHIP 1M 5% 1/16W

R30 1-218-989-11 RES-CHIP 1M 5% 1/16W
R31 1-218-989-11 RES-CHIP 1M 5% 1/16W
R32 1-218-947-11 RES-CHIP 330 5% 1/16W
R33 1-218-990-81 SHORT CHIP 0
R34 1-216-864-11 SHORT CHIP 0

R35 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
R36 1-218-947-11 RES-CHIP 330 5% 1/16W
R37 1-218-947-11 RES-CHIP 330 5% 1/16W
R38 1-218-941-81 RES-CHIP 100 5% 1/16W
R39 1-218-941-81 RES-CHIP 100 5% 1/16W

R40 1-218-941-81 RES-CHIP 100 5% 1/16W
R41 1-218-941-81 RES-CHIP 100 5% 1/16W
R42 1-218-977-11 RES-CHIP 100K 5% 1/16W
R43 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R44 1-218-977-11 RES-CHIP 100K 5% 1/16W

R79 1-218-941-81 RES-CHIP 100 5% 1/16W
R80 1-218-941-81 RES-CHIP 100 5% 1/16W
R81 1-218-941-81 RES-CHIP 100 5% 1/16W
R82 1-218-941-81 RES-CHIP 100 5% 1/16W
R83 1-218-977-11 RES-CHIP 100K 5% 1/16W

R84 1-218-941-81 RES-CHIP 100 5% 1/16W
R85 1-218-977-11 RES-CHIP 100K 5% 1/16W
R86 1-218-941-81 RES-CHIP 100 5% 1/16W
R87 1-218-977-11 RES-CHIP 100K 5% 1/16W
R96 1-218-941-81 RES-CHIP 100 5% 1/16W

R97 1-220-200-81 RES-CHIP 30K 5% 1/16W
R98 1-218-971-11 RES-CHIP 33K 5% 1/16W
R132 1-218-969-11 RES-CHIP 22K 5% 1/16W
R133 1-218-953-11 RES-CHIP 1K 5% 1/16W
R141 1-216-864-11 SHORT CHIP 0

R144 1-216-864-11 SHORT CHIP 0
R147 1-216-864-11 SHORT CHIP 0

< SWITCH >

SW1 1-529-565-61 SWITCH, PUSH (1 KEY) (DOWN)

< VIBRATOR >

X1 1-813-678-11 OSCILLATOR, CERAMIC (CHIP TYPE) (12MHz)
X2 1-795-561-21 VIBRATOR, CERAMIC (16.9344MHz)

*************************************************************

MISCELLANEOUS

***************

8 1-776-206-21 CORD (WITH CONNECTOR) (POWER)

(EXCEPT AEP,UK)

8 1-776-527-61 CORD (WITH CONNECTOR) (ISO) (POWER)

(AEP,UK)

57 1-780-199-11 CONDUCTIVE BOARD, CONNECTION

0153 8-820-207-12 OPTICAL PICK-UP (KSS1000E/K1RP)

154 A-1088-615-A CHASSIS (OP) SUB ASSY (including M901)

R52 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
R53 1-218-979-11 RES-CHIP 150K 5% 1/16W
R54 1-218-990-81 SHORT CHIP 0
R55 1-218-973-11 RES-CHIP 47K 5% 1/16W
R57 1-218-967-11 RES-CHIP 15K 5% 1/16W

R58 1-218-969-11 RES-CHIP 22K 5% 1/16W
R60 1-218-941-81 RES-CHIP 100 5% 1/16W
R61 1-218-941-81 RES-CHIP 100 5% 1/16W
R62 1-218-941-81 RES-CHIP 100 5% 1/16W
R63 1-218-977-11 RES-CHIP 100K 5% 1/16W

R64 1-218-977-11 RES-CHIP 100K 5% 1/16W
R65 1-218-977-11 RES-CHIP 100K 5% 1/16W
R67 1-218-941-81 RES-CHIP 100 5% 1/16W
R68 1-218-941-81 RES-CHIP 100 5% 1/16W
R69 1-218-941-81 RES-CHIP 100 5% 1/16W

R70 1-218-965-11 RES-CHIP 10K 5% 1/16W
R71 1-218-973-11 RES-CHIP 47K 5% 1/16W
R72 1-218-973-11 RES-CHIP 47K 5% 1/16W

LCD901 1-805-919-11 DISPLAY PANEL, LIQUID CRYSTAL

(AEP,UK,E,MX)
LCD901 1-805-920-11 DISPLAY PANEL, LIQUID CRYSTAL (US,CND)
M902 A-1088-614-A MOTOR ASSY, SL (SLED)
M903 A-1088-622-A MOTOR ASSY, LE (LOADING)
RE901 1-478-474-12 ENCODER, ROTARY (PUSH SELECT/VOLUME)

SW4 1-786-339-11 SWITCH (M) (LIMIT)

*************************************************************

47

CDX-GT20W/GT200/GT200E/GT200S/GT250S

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

ACCESSORIES

************

PARTS FOR INSTALLATION AND CONNECTIONS

***************************************

1-479-077-12 REMOTE COMMANDER (RM-X151)

(GT20W:US/GT200:US,CND/GT250S)

2-548-729-01 LID, BATTERY CASE (for RM-X151)

(GT20W:US/GT200:US,CND/GT250S)

2-651-185-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH)

(GT20W:CND/GT200:US,CND)

2-651-185-21 MANUAL, INSTRUCTION (ENGLISH,GERMAN,

FRENCH,ITALIAN,DUTCH)

(GT200:AEP,UK/GT200S)

2-651-185-31 MANUAL, INSTRUCTION (ENGLISH,RUSSIAN)

(GT200E)

2-651-185-41 MANUAL, INSTRUCTION (ENGLISH,SPANISH,

SIMPLIFIED CHINESE)

(GT250S)

2-651-185-51 MANUAL, INSTRUCTION (ENGLISH,SPANISH)

(GT20W:US)

2-651-186-11 MANUAL, INSTRUCTION, INSTALL (ENGLISH,

FRENCH)

(GT20W:CND/GT200:US,CND)

2-651-186-21 MANUAL, INSTRUCTION, INSTALL (ENGLISH,

GERMAN,FRENCH,ITALIAN,DUTCH)

(GT200:AEP,UK/GT200S)

2-651-186-31 MANUAL, INSTRUCTION, INSTALL (ENGLISH,

RUSSIAN)

(GT200E)

2-651-186-41 MANUAL, INSTRUCTION, INSTALL (ENGLISH,

SPANISH,SIMPLIFIED CHINESE)

(GT250S)

2-651-186-51 MANUAL, INSTRUCTION, INSTALL (ENGLISH,

SPANISH)

(GT20W:US)

X-2024-133-3 CASE ASSY (for FRONT PANEL) (EXCEPT US)

*************************************************************

301 X-3382-647-1 FRAME ASSY, FITTING
302 2-187-743-02 COLLAR
303 3-246-011-01 KEY (FRAME)
304 A-1082-993-A SCREW ASSY (BS4), FITTING

304 X-3366-972-2 SCREW ASSY (EXP), FITTING

305 3-259-776-01 SCREW (+K 5X8 TP)

306 1-465-459-41 ADAPTOR, ANTENNA (AEP,UK)
307 1-776-206-21 CORD (WITH CONNECTOR) (POWER)

308 1-776-527-61 CORD (WITH CONNECTOR) (ISO) (POWER)

301

(GT20W/GT200:US,CND/GT200E/GT250S)

302

(GT200E/GT250S)

(GT200:AEP,UK/GT200S)

(EXCEPT AEP,UK)

(AEP,UK)

303

× 2

304

305

× 4

306

307

308

48

MEMO

CDX-GT20W/GT200/GT200E/GT200S/GT250S

49

CDX-GT20W/GT200/GT200E/GT200S/GT250S

REVISION HISTORY

Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper on the revised page allows you to jump to the next revised page.

Ver. Date Description of Revision

1.0 2005. 09 New

50
