Sony Alpha A7 Mark III User Manual

Download

4-732-950-41(1)

“Help Guide” (Web manual)

Refer to “Help Guide” for in-depth instructions on the many functions of the camera.

« Guide d’aide » (Manuel en ligne)

Consultez le « Guide d’aide » pour obtenir des instructions détaillées au sujet des nombreuses fonctions

E-mount

http://rd1.sony.net/help/ilc/1720/h_zz/

Interchangeable Lens Digital Camera/Instruction Manual GB

Appareil photo à objectif interchangeable/Mode d’emploi FR

Digitalkamera mit Wechselobjektiv/Gebrauchsanleitung DE

de l’appareil.

Cámara Digital de Lentes Intercambiables/Manual de instrucciones

Fotocamera digitale con obiettivo intercambiabile/Istruzioni per l’uso

Câmara Digital de Objetivas intercambiáveis/Manual de instruções

Digitale camera met verwisselbare lens/Gebruiksaanwijzing NL

Aparat cyfrowy z wymiennymi obiektywami/Instrukcja obsługi PL

Цифровой фотоаппарат со сменным объективом/Инструкция по эксплуатации

Цифровий фотоапарат зі змінним об’єктивом/Посібник з експлуатації

Digitalkamera med utbytbart objektiv/Handledning SE

Digitaalinen kamera vaihdettavalla objektiivilla/Käyttöopas FI

Digitalkamera med utskiftbart objektiv/Bruksanvisning NO

Digitalkamera med udskifteligt objektiv/Betjeningsvejledning DK

ILCE-7M3

English

Check out the Help Guide!

The “Help Guide” is an on-line manual that you can read on your computer or smartphone. Refer to it for details on menu items, advanced usage, and the latest information on the camera.

Scan here

http://rd1.sony.net/help/ilc/1720/h_zz/

ILCE-7M3 Help Guide

Instruction Manual

(this book)

This manual introduces some basic functions.

For the quick start guide, see “Startup guide” (page22). The

“Startup guide” introduces the initial procedures from when you open the package until you release the shutter for the first shot.

In-Camera Guide

The [In-Camera Guide] shows explanations of the menu items on the monitor of the camera.

You can quickly pull up information during shooting. To use the [In-Camera Guide] function, some settings must be made beforehand. For details, search “In-Camera Guide” in the Help Guide.

Notes on using your camera

Along with this section, also see “Precautions” in the Help Guide (page2).

Screen language

You can select the language displayed on the screen using the menu (page 70).

Notes on handling the product

• This camera is designed to be dustand moisture-resistant, but is not waterproof or dust-proof.

• When using the power zoom lens, be careful not to get your fingers or any other objects caught in the lens.

• Always attach the lens front cap or body cap when you are not using the camera. To prevent dust or debris from getting inside the camera, remove dust from the body cap before attaching it to the camera.

• Do not leave the lens or the viewfinder exposed to a strong light source such as sunlight. Because of the lens’s condensing function, doing so may cause smoke, fire, or a malfunction inside the camera body or the lens. If you have to leave the camera exposed to a light source such as sunlight, attach the lens cap to the lens.

• When you shoot with backlighting, keep the sun sufficiently far away from the angle of view. Otherwise, the sunlight may enter the focus inside the camera and cause smoke or fire. Even if the sun is slightly away from the angle of view, it may still cause smoke or fire.

• Do not directly expose the lens to beams such as laser beams. That may damage the image sensor and cause the camera to malfunction.

• Do not look at sunlight or a strong light source through the lens when it is detached. This may result in unrecoverable damage to the eyes or cause a malfunction.

• Do not leave the camera, the supplied accessories, or memory cards within the reach of infants. They may be accidentally swallowed. If this occurs, consult a doctor immediately.

Notes on the monitor and electronic viewfinder

• The monitor and electronic viewfinder are manufactured using extremely high-precision technology, and over 99.99% of the pixels are operational for effective use. However, there may be some small black dots and/or bright dots (white, red, blue or green in color) that constantly appear on the monitor and electronic viewfinder. These are imperfections due to the manufacturing process and do not affect the recorded images in any way.

• The image may be slightly distorted near the corners of the viewfinder. This is not a malfunction. When you want to see the full composition with all its details, you can also use the monitor.

• If you pan the camera while looking into the viewfinder or move your eyes around, the image in the viewfinder may be distorted or the color of the image may change. This is a characteristic of the lens or display device and is not a malfunction. When you shoot an image, we recommend that you look at the center area of the viewfinder.

• When shooting with the viewfinder, you may experience symptoms such as eyestrain, fatigue, travel sickness, or nausea. We recommend that you take a break at regular intervals when you are shooting with the viewfinder. In case you may feel uncomfortable, refrain from using the viewfinder until your condition recovers, and consult your doctor as necessary.

• If the monitor or electronic viewfinder is damaged, stop using the camera immediately. The damaged parts may harm your hands, face, etc.

Notes on continuous shooting

During continuous shooting, the monitor or viewfinder may flash between the shooting screen and a black screen. If you keep watching the screen in this situation, you may experience uncomfortable symptoms such as feeling of unwellness. If you experience uncomfortable symptoms, stop using the camera, and consult your doctor as necessary.

Notes on recording for long periods of time or recording 4K movies

• Depending on the camera and battery temperature, you may be unable to record movies or the power may turn off automatically to protect the camera. A message will be displayed on the screen before the power turns off or you can no longer record movies. In this case, leave the power off and wait until the camera and battery temperature goes down. If you turn on the power without letting the camera and battery cool enough, the power may turn off again or you may be unable to record movies.

• When the temperature of the camera rises, the image quality may deteriorate. It is recommended that you wait until the temperature of the camera drops before continuing to shoot.

• Under high ambient temperatures, the temperature of the camera rises quickly.

• Camera body and battery may get warm with use – this is normal.

• If the same part of your skin touches the camera for a long period of time while using the camera, even if the camera does not feel hot to you, it may cause symptoms of a low-temperature burn such as redness or blistering. Pay special attention in the following situations and use a tripod, etc.

–When using the camera in a high-

temperature environment

–When someone with poor

circulation or impaired skin sensation uses the camera

–When using the camera with

the [Auto Pwr OFF Temp.] set to [High].

• Especially during 4K movie shooting, the recording time may be shorter under low temperature conditions. Warm up the battery pack or replace it with a new battery.

Notes on recording/playback

• Before you start recording, make a trial recording to make sure that the camera is working correctly.

• The recorded image may be different from the image you monitored before recording.

• Do not use the camera in areas where strong radio waves or radiation are being emitted. Recording and playback may not function correctly.

• Playback of images recorded with your product on other equipment and playback of images recorded or edited with other equipment on your product are not guaranteed.

• Sony can provide no guarantees in the event of failure to record or loss or damage of recorded images or audio data due to a malfunction of the camera or recording media, etc. We recommend backing up important data.

• Once you format the memory card, all the data recorded on the memory card will be deleted and cannot be restored. Before formatting, copy the data to a computer or other device.

Notes on the Multi Interface Shoe

• When attaching or detaching accessories such as an external flash to the Multi Interface Shoe, first turn the power to OFF. When attaching the accessory, confirm that it is firmly fastened to the camera.

• Do not use the Multi Interface Shoe with a commercially available flash that applies voltages of 250 V or more or has the opposite polarity of the camera. It may cause a malfunction.

Sony lenses/accessories

Using this unit with products from other manufacturers may affect its performance, leading to accidents or malfunction.

On the data specifications described in this manual

The data on performance and specifications are defined under the following conditions, except as described in this manual: at an ordinary ambient temperature of 25ºC (77°F), and using a battery pack that has been fully charged until the charge lamp has turned off.

Warning on copyright

Television programs, films, videotapes, and other materials may be copyrighted. Unauthorized recording of such materials may be contrary to the provisions of the copyright laws.

Notes on location information

If you upload and share an image tagged with a location, you may accidentally reveal the information to a third party. To prevent third parties from obtaining your location information, set [ to [Off] before shooting images.

Loc. Info. Link Set.]

Notes on discarding or transferring this product to others

When discarding or transferring this product to others, make sure to perform the following operation to protect private information.

• Select [Setting Reset]  [Initialize].

Notes on discarding or transferring a memory card to others

Executing [Format] or [Delete] on the camera or a computer may not completely delete the data on the memory card. When transferring a memory card to others, we recommend that you delete the data completely using data deletion software. When discarding a memory card, we recommend that you physically destroy it.

Notes on wireless LAN

If your camera is lost or stolen, Sony bears no responsibility for the loss or damage caused by illegal access or use of the registered access point on the camera.

Notes on security when using wireless LAN products

• Always make sure that you are using a secure wireless LAN to avoid hacking, access by malicious third parties, or other vulnerabilities.

• It is important that you set the security settings when using a wireless LAN.

• If a security problem arises because no security precautions are in place or due to any inevitable circumstances when using a wireless LAN, Sony bears no responsibility for the loss or damage.

How to turn off wireless network functions (Wi-Fi, etc.) temporarily

When you board an airplane, etc., you can turn off all wireless network functions temporarily using [Airplane Mode].

Power Cord

For the customers in the UK, Ireland, Malta, Cyprus and Saudi Arabia Use the power cord (A). For safety reasons, the power cord (B) is not intended for above countries/regions and shall therefore not be used there. For the customers in other EU countries/regions Use the power cord (B).

(A) (B)

For Customers in the U.S.A.

For question regarding your product or for the Sony Service Center nearest you, call 1-800-222-SONY (7669).

Declaration of Conformity

Trade Name: SONY Model No.: WW541200 Responsible Party: Sony Electronics

Inc.

Address: 16535 Via Esprillo, San

Diego, CA 92127 U.S.A.

Telephone Number: 858-942-2230

This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)this device must accept any interference received, including interference that may cause undesired operation.

Notes on this manual

This manual covers several models supplied with different lenses. The model name varies depending on the supplied lens. The available model varies depending on the countries/regions.

Model name Lens

ILCE-7M3 Not supplied ILCE-7M3K FE 28-70 mm F3.5-5.6 OSS

For details on the Wi-Fi functions and NFC One-touch functions, refer to the “Help Guide” (page 2).

Preparations for shooting

Checking the camera and the supplied items

First check the model name of your camera (page7). The accessories supplied differ depending on the model. The number in parentheses indicates the number of pieces.

Supplied with all models

• Camera (1)

• AC Adaptor (1)

The shape of the AC Adaptor may differ depending on the country/ region.

• Power cord (mains lead) (1)*

(supplied in some countries/ regions)

* Multiple power cords may be

supplied with your camera. Use the appropriate one that matches your country/region. See page 7.

• Rechargeable battery pack

NP-FZ100 (1)

• Micro USB cable (1)

• Shoulder strap (1)

• Body cap (1) (Attached to the

camera)

• Shoe cap (1) (Attached to the

camera)

• Eyepiece cup (1) (Attached to

the camera)

• Instruction Manual (1) (this

manual)

• Reference Guide (1)

ILCE-7M3K

• Zoom lens FE 28-70 mm F3.5-

5.6 OSS (1) (including a front lens cap and a rear lens cap)

• Lens hood (1)

Identifying parts

See the pages in parentheses for details.

Front side



ON/OFF (Power) switch

(28)/Shutter button (29)



Front dial

You can quickly adjust the settings for each shooting mode.



Remote sensor



Lens release button (27)



Wi-Fi/Bluetooth antenna

(built-in) (49)



Microphone

Do not cover this part during movie recording. Doing so may cause noise or lower the volume.



AF illuminator (59)/Self-

timer lamp

When the lens is removed



Mounting index (26)



Image sensor*



Mount



Lens contacts*

* Do not directly touch these parts.

Rear side



Eyepiece cup

To remove the eyepiece cup

Push the grips at the bottom of the eyepiece cup to the left and right and lift up the cup.

Remove the eyepiece cup when attaching an angle finder (sold separately). Also, select MENU 

(Camera Settings 2) 

[FINDER/MONITOR], and then switch to [Viewfinder (Manual)] or [Monitor (Manual)].



Viewfinder



C3 button (Custom button 3)

(65)/ (Protect) button



MENU button (56)



Monitor

(For touch operation: Touch panel/Touch pad) (40)

You can adjust the monitor to an easily viewable angle and shoot from any position.



Eye sensor



Diopter-adjustment dial

Adjust the diopter-adjustment dial according to your eyesight until the display appears clearly in the viewfinder. If it is hard to operate the diopter-adjustment dial, remove the eyepiece cup before operating the dial.



Access lamp



For shooting: C4 button

(Custom button 4) (65) For viewing:

(Delete) button

(30)



(Playback) button (30)



MOVIE (Movie) button (30)



For shooting: AF-ON (AF On)

button For viewing:

(Enlarge Image)

button



Rear dial

You can quickly adjust the settings for each shooting mode.



For shooting: AEL button

For viewing:

(Image Index)

button



Multi-selector (18)



Media slot cover switch



For shooting: Fn (Function)

button (18, 65) For viewing:

(Send to Smartphone)

button

You can display the screen for [Send to Smartphone] by pressing this button.



Control wheel (17)

Top side/Side view



Image sensor position

mark

• The image sensor is the sensor that converts light into an electric signal. The

mark shows the location

of the image sensor. When you measure the exact distance between the camera and the subject, refer to the position of the horizontal line.

• If the subject is closer than the minimum shooting distance of the lens, the focus cannot be confirmed. Make sure you put enough distance between the subject and the camera.



Speaker



(Microphone) jack

When an external microphone is connected, the builtin microphone turns off automatically. When the external microphone is a plugin-power type, the power of the microphone is supplied by the camera.



(Headphones) jack



HDMI micro jack



USB Type-C™ terminal (14,

52)



Charge lamp



Multi/Micro USB Terminal*

(14, 52)

This terminal supports Micro USB-compatible devices.



Multi Interface Shoe*

Some accessories may not go in all the way and protrude backward from the Multi interface shoe. However, when the accessory reaches the front end of the shoe, the connection is completed.



Mode dial (30)



C2 button (Custom button 2)

(65)



C1 button (Custom button 1)

(65)



Exposure compensation dial



Hooks for shoulder strap

Attach both ends of the strap onto the camera.



(N mark) (49)

• This mark indicates the touch point for connecting the camera and an NFC-enabled Smartphone.

• NFC (Near Field Communication) is an international standard of short-range wireless communication technology.



SLOT 1 (Memory card slot 1)

(24)

Supports SD cards only (compatible with UHS-I and UHS-II)



SLOT 2 (Memory card slot 2)

(25)

Supports SD cards (compatible with UHS-I) and Memory Stick PRO Duo media

* For details on compatible

accessories for the multi interface shoe and the Multi/Micro USB Terminal, visit the Sony website, or consult your Sony dealer or local authorized Sony service facility. Accessories for the Accessory Shoe can also be used. Operations with other manufactures’ accessories are not guaranteed.

Notes on USB terminals

You can use either the USB Type-C terminal or the Multi/ Micro USB Terminal for supplying power, charging the battery, and USB communications. However, you cannot conduct these operations with both terminals simultaneously.

• The battery charging time does not change according to the terminal you use.

• You can use accessories for the Multi/Micro USB Terminal, such as a remote commander (sold separately), while supplying power or performing PC Remote shooting using the USB Type-C terminal.

Bottom



Battery insertion slot (22)



Battery cover (22)



Tripod socket hole

Use a tripod with a screw less than 5.5mm (7/32inches) long. Otherwise, you cannot firmly secure the camera, and damage to the camera may occur.



Battery cover release lever

Lens FE 28-70 mm F3.5-5.6 OSS (Supplied with ILCE-7M3K)



Focusing ring



Zoom ring



Focal-length scale



Focal-length index



Lens contacts

Do not touch this part directly.



Mount index

Basic operations

Using the control wheel

• You can select setting items by turning or pressing the top/bottom/left/ right side of the control wheel. Your selection is determined when you press the center of the control wheel.

• The DISP (Display Setting), are assigned to the top/left/right side of the control wheel. In addition, you can assign selected functions to the left/right/bottom side and the center of the control wheel, and to the rotation of the control wheel.

• During playback, you can display the next/previous image by pressing the right/left side of the control wheel or by turning the control wheel.

/ (Drive Mode), and ISO (ISO) functions

Using the multi-selector

• Put your finger right on top of the multi-selector to manipulate it more precisely.

• When [Focus Area] is set to [Zone], [Flexible Spot], or [Expand Flexible Spot], you can move the focus area by pressing the multi-selector up/down/left/right.

• The [Focus Standard] function is assigned to the center of the multiselector in the default settings.

Using the Fn (Function) button

You can register frequently used functions to the Fn (function) button and recall them while shooting. Up to 12 frequently used functions can be registered to the Fn (Function) button.

Press the DISP on the control wheel repeatedly to display a screen mode other than [For viewfinder], and then press the Fn (Function) button.

Select the desired function by pressing the top/bottom/left/ right side of the control wheel.

Fn button

Select the desired setting by turning the front dial, and press the center of the control wheel.

• Some functions can be fine-tuned using the rear dial.

To adjust settings from the dedicated setting screens

Select the desired function in step 2, then press the center of the control wheel. The dedicated setting screen for the function will appear. Follow the operating guide to adjust settings.

Operation guide

How to use the Quick Navi screen

The Quick Navi screen is a function optimized for shooting with the viewfinder, that lets you control settings directly.

Select MENU  (Camera Settings 2)  [DISP Button]  [Monitor].

Place a mark on [For viewfinder] and then select [Enter].

Press the DISP on the control wheel to set the screen mode to [For viewfinder].

Press the Fn button to switch to the Quick Navi screen.

• The displayed contents and their positions in the illustrations are just guidelines, and may differ from the actual displays.

Auto mode/Scene Selection mode

P/A/S/M mode

Select a function to set by pressing the top/bottom/left/right side of the control wheel.

Select the desired setting by turning the front dial.

• Some functions can be fine-tuned using the rear dial.

To adjust settings from the dedicated setting screens

Select the desired function in step 5, then press the center of the control wheel. The dedicated setting screen for the function will appear. Follow the operating guide to adjust settings.

Operation guide

Note

• Items that are gray on the Quick Navi screen are not adjustable.

• When using functions such as [Creative Style] or [Picture Profile], some

settings can only be controlled from the dedicated screen.

Startup guide

Step 1: Inserting the battery pack into the camera

Open the battery cover.

Insert the battery pack while pressing the lock lever with the tip of the battery until the battery locks into place.

Lock lever

Close the cover.

To remove the battery pack

Make sure that the access lamp (page 11) is not lit, and turn off the camera. Then, slide the lock lever and remove the battery pack. Be careful not to drop the battery pack.

Lock lever

Step 2: Charging the battery pack while it is inserted in the camera

Turn the power off.

Connect the camera with the battery pack inserted to the AC Adaptor (supplied) using the USB cable, and connect the AC Adaptor to the wall outlet (wall socket).

Charge lamp on the camera (orange)

Lit: Charging Off: Charging finished Flashing: Charging error or charging paused temporarily because the camera is not within the proper temperature range

• Charging time (full charge): approximately 285 min (when charging a fully depleted battery pack at a temperature of 25°C (77°F))

• When you use a completely new battery pack or a battery pack that has not been used for a long time, the charge lamp may flash quickly when the battery is charged. If this happens, remove the battery pack or disconnect the USB cable from the camera and then re-insert it to recharge.

• Be sure to use only genuine Sony brand battery packs and AC Adaptors (supplied).

• Use the USB cable (supplied) or a USB-standard cable.

• The charging time will be the same if you use a USB Type-C cable.

Step 3: Inserting a memory card

For details on memory cards that can be used with this camera, refer to page 81.

Open the memory card cover.

Insert the SD card into the slot 1.

Slot 1 (lower): Supports SD cards (compatible with UHS-I and UHS-II) Slot 2 (upper): Supports SD cards (compatible with UHS-I) and Memory Stick PRO Duo media

• With the notched corner facing in the direction illustrated, insert the memory card until it clicks into place.

• You can change which memory card slot to use by selecting MENU 

(Setup)  [Rec. Media Settings]  [Prioritize Rec. Media].

The slot 1 is used in the default settings.

• Use the slot 1 when you are only using one SD card.

• Use the slot 2 when you are using Memory Stick media. In this case, set [Prioritize Rec. Media] to [Slot 2].

Close the cover.

Slot 2 Slot 1

Hint

• When you use a memory card with the camera for the first time, it is

recommended that you format the card on the camera for more stable performance of the memory card (page 71).

Note

• Do not insert a Memory Stick media into the slot 1. It may cause a malfunction.

To remove the memory card

Open the memory card cover. Make sure that the access lamp (page11) is not lit, and then push in the memory card once to remove it.

Access lamp

To record to memory cards in two slots

The slot 1 is used in the default settings. If you do not intend to change the settings and will only use one memory card, use the slot 1. By inserting another memory card into the slot 2, you can record the same images to two memory cards simultaneously or record a different type of image (still images/movies) to each memory card ([Recording Mode] under [Rec. Media Settings]) (page

71).

Step 4: Attaching a lens

Remove the body cap from the camera and the rear lens cap from the rear of the lens.

• When changing the lens, work quickly in a dust-free environment to keep dust or debris from getting inside the camera.

• It is recommended that you attach the front lens cap when you have done shooting.

Mount the lens by aligning the two white index marks (mounting indexes) on the lens and camera.

• Hold the camera with the lens facing down to prevent dust or debris from entering the camera.

While pushing the lens lightly toward the camera, turn the lens slowly in the direction of the arrow until it clicks into the locked position.

Front lens cap

Body cap

Rear lens cap

Note

• Be sure to hold the lens straight and do not use force when attaching a lens.

• Do not press the lens release button when attaching a lens.

• The Mount Adaptor (sold separately) is required to use an A-mount lens

(sold separately). For details, refer to the operating manual supplied with the Mount Adaptor.

• If you want to shoot full-frame images, use a full-frame size compatible lens.

• When carrying the camera with a lens attached, hold both the camera and the

lens firmly.

• Do not hold the part of the lens that is extended for zoom or focus

adjustment.

To remove the lens

Keep pressing the lens release button and turn the lens in the direction of the arrow until it stops.

Lens release button

Compatible lenses

Lenses compatible with this camera are as follows:

Lens Compatibility with the camera

Lens compatible with 35mm full-

A-mount lens

E-mount lens

* Images will be recorded in APS-C size. The angle of view will correspond to

approximately 1.5 times the focal length indicated on the lens. (For example, the angle of view will correspond to 75mm when a 50mm-lens is attached.)

frame format

APS-C size dedicated lens

Lens compatible with 35mm fullframe format

APS-C size dedicated lens

(An optional Mount Adaptor

(sold separately) compatible with

full-frame format is required)

(An optional Mount Adaptor (sold separately) is required)



*



*

Step 5: Setting the language and the clock

Set the ON/OFF (Power) switch to “ON” to turn on the camera.

Select the desired language and then press the center of the control wheel.

Make sure that [Enter] is selected on the screen and then press the center.

Select the desired geographic location and then press the center.

Select [Date/Time] using the top/bottom of the control wheel or by turning the control wheel, and then press the center.

ON/OFF (Power) switch

Control wheel

Select the desired item by pressing the top/bottom/left/right side of the control wheel, and then press the center.

Repeat steps 5 and 6 to set other items, then select [Enter] and press the center.

Hint

• To reset the date and time setting, use MENU (page 71).

Note

• This camera does not have a function for inserting the date into images.

You can insert the date into images and then save and print them using PlayMemories Home (for Windows only).

Step 6: Shooting images in auto mode

Turn the mode dial to set to .

The shooting mode will be set to (Intelligent Auto).

Look into the viewfinder or the monitor and hold the camera.

Set the size of the subject by rotating the zoom ring of the lens when a zoom lens is attached.

Press the shutter button halfway down to focus.

• When the image is in focus, an indicator (such as ) will light up.

Press the shutter button all the way down.

To shoot movies

Press the MOVIE button to start/stop recording.

To play back images

Press the desired image using the control wheel.

(Playback) button to play back images. You can select the

To delete displayed image

Press the [Delete] using the control wheel on the confirmation screen, and then press the center of the control wheel to delete the image.

(Delete) button while an image is displayed to delete it. Select

To shoot images in various shooting modes

Set the mode dial to the desired mode depending on the subject or the functions you want to use.

Shooting

Focusing

Focus Mode

Selects the focus method to suit the movement of the subject.

MENU  (Camera Settings 1)  [Focus Mode]  desired setting.

(Single-shot AF): The product locks the focus once focusing is

complete. Use this when the subject is motionless.

(Automatic AF): [Single-shot AF] and [Continuous AF] are switched according to the movement of the subject. When the shutter button is pressed halfway down, the product locks the focus when it determines that the subject is motionless, or continues to focus when the subject is in motion. During continuous shooting, the product automatically shoots with Continuous AF from the second shot.

(Continuous AF): The product continues to focus while the shutter button is pressed and held halfway down. Use this when the subject is in motion. In [Continuous AF] mode, there is no beep when the camera focuses.

(DMF): You can make fine adjustments manually after performing auto focusing, letting you focus on a subject more quickly than when using the manual focus from the beginning. This is convenient in situations such as macro shooting.

(Manual Focus): Adjusts the focus manually. If you cannot focus on the intended subject using auto focus, use manual focus.

Focus indicator

(lit): The subject is in focus and the focus is locked. (flashing): The subject is not in focus.

(lit): The subject is in focus. The focus will be adjusted continuously

according to the movements of the subject.

(lit): Focusing is in progress.

Subjects on which it is difficult to focus using auto focus

• Dark and distant subjects

• Subjects with poor contrast

• Subjects seen through glass

• Fast-moving subjects

• Reflective light or shiny surfaces

• Flashing light

• Back-lit subjects

• Continuously repetitive patterns, such as the facades of buildings

• Subjects in the focusing area with different focal distances

Hint

• In [Continuous AF] mode, you can lock the focus by pressing and holding the button that has been assigned the [Focus Hold] function (page 65).

• When you set the focus to infinity in the manual focus mode or the direct manual focus mode, make sure that the focus is on a sufficiently distant subject by checking the monitor or the viewfinder.

Note

• [Automatic AF] is available only when you are using a lens that supports phase detection AF.

• When [Continuous AF] or [Automatic AF] is set, the angle of view may change little by little while focusing. This does not affect the actual recorded images.

• Only [Continuous AF] and [Manual Focus] are available when shooting movies or when the mode dial is set to

Auto focus

Focus Area

Selects the focusing area. Use this function when it is difficult to focus properly in the auto focus mode.

MENU  (Camera Settings 1)  [Focus Area]  desired setting.

Wide: Focuses on a subject covering the whole range of the screen automatically. When you press the shutter button halfway down in the still image shooting mode, a green frame is displayed around the area that is in focus.

Zone: Select a zone on the monitor on which to focus, and the product will automatically select a focus area.

Center: Focuses automatically on a subject in the center of the image. Use together with the focus-lock function to create the composition you want.

Flexible Spot: Allows you to move the focusing frame to a desired point on the screen and focus on an extremely small subject in a narrow area.

Expand Flexible Spot: If the product cannot focus on a single selected point, it uses focus points around the flexible spot as a secondary priority area for focusing.

Lock-on AF: When the shutter button is pressed and held halfway down, the product tracks the subject within the selected autofocus area. This setting is available only when the [Focus Mode] is set to [Continuous AF]. Point the cursor at [Lock-on AF] on the [Focus Area] setting screen, and then adjust the desired area to start tracking using the left/right sides of the control wheel. You can also move the tracking start area to the desired point by designating the area as a zone, flexible spot or expand flexible spot.

Examples of the focusing frame display

The focusing frame differs as follows.

When focusing on a larger area

When focusing on a smaller area

• When [Focus Area] is set to [Wide] or [Zone], the focusing frame may switch between “When focusing on a larger area” and “When focusing on a smaller area” depending on the subject or situation.

• When you attach an A-mount lens with a Mount Adaptor (LA-EA1 or LA-EA3) (sold separately) and [ [Phase Detection AF], the focusing frame for “When focusing on a smaller area” may be displayed.

When focus is achieved automatically based on the whole range of the monitor

AF System] is set to

• When you use a zoom function other than the optical zoom, the [Focus Area] setting is disabled and the focusing frame is shown by the dotted line. The AF operates with priority on and around the center area.

To move the focus area

• You can move the focus area in [Flexible Spot], [Expand Flexible Spot], or [Zone] by operating the multi-selector. If you assign [Focus Standard] to the center of the multi-selector beforehand, you can move the focusing frame back to the center of the monitor by pressing the center of the multi-selector.

• You can move the focusing frame quickly by touching and dragging it on the monitor. Set [Touch Operation] to [On] beforehand (page40).

Hint

• In the default settings, [Focus Area] is assigned to the C2 button.

Note

• [Focus Area] is locked to [Wide] in the following situations:

–[Intelligent Auto] –[Scene Selection]

• The focus area may not light up during continuous shooting or when the

shutter button is pressed all the way down at once.

• When the mode dial is set to

[Lock-on AF] cannot be selected as the [Focus Area].

(Movie) or , or during movie shooting,

Manual Focus

When it is difficult to focus properly in the autofocus mode, you can adjust the focus manually.

MENU  (Camera Settings 1)  [Focus Mode]  [Manual Focus].

Rotate the focusing ring to achieve sharp focus.

• When you rotate the focusing ring, the focus distance is displayed on the screen. The focus distance is not displayed when the Mount Adaptor (sold separately) is attached.

Press the shutter button fully down to shoot an image.

Note

• When you use the viewfinder, adjust the diopter level to obtain the correct focus on the viewfinder (page11).

Direct manual focus (DMF)

You can make fine adjustments manually after performing auto focusing, letting you focus on a subject more quickly than when using the manual focus from the beginning. This is convenient in situations such as macro shooting.

MENU  (Camera Settings 1)  [Focus Mode]  [DMF].

Press the shutter button halfway down to focus automatically.

Keep the shutter button pressed halfway down, and then rotate the focusing ring to achieve a sharper focus.

• When you rotate the focusing ring, the focus distance is displayed on the screen. The focus distance is not displayed when the Mount Adaptor (sold separately) is attached.

Press the shutter button fully down to shoot an image.

Continuous shooting

Shoots images continuously while you press and hold down the shutter button.

Select / (Drive Mode) on the control wheel  [Cont. Shooting].

• You can also set the drive mode by selecting MENU  (Camera Settings 1)  [Drive Mode].

Select the desired mode using the right/left side of the control wheel.

Continuous Shooting: Hi+: Images are shot continuously at the

maximum speed while you press and hold down the shutter button.

Continuous Shooting: Hi/ Continuous Shooting: Mid/

Continuous Shooting: Lo: Subjects are easier to track because

the subject is displayed in real-time on the monitor or viewfinder during shooting.

Hint

• To continuously adjust the focus and exposure during continuous shooting, set as follows:

–[Focus Mode]: [Continuous AF]

AEL w/ shutter]: [Off] or [Auto]

–[

Note

• The shooting speed during continuous shooting becomes slower when RAW File Type] is set to [Uncompressed].

[

• The shooting speed during continuous shooting becomes slower

when [e-Front Curtain Shut.] is set to [Off] in [Continuous Shooting: Hi], [Continuous Shooting: Mid] or [Continuous Shooting: Lo] mode.

• When the F-value is greater than F11 in [Continuous Shooting: Hi+],

[Continuous Shooting: Hi] or [Continuous Shooting: Mid] mode, the focus is locked to the setting in the first shot.

• The subject is not displayed in real-time on the monitor or viewfinder when

shooting in [Continuous Shooting: Hi+] mode.

• Continuous shooting is unavailable in the following situations:

–The shooting mode is set to [Scene Selection] and a scene other than

[Sports Action] is selected. –[Picture Effect] is set to [Rich-tone Mono.]. –[DRO/Auto HDR] is set to [Auto HDR].

Displaying continuous shooting remaining time indicator (Cont. Shoot. Length)

Sets whether to display an indicator of the remaining time for which continuous shooting can be performed at the same shooting speed.

MENU  [Cont. Shoot. Length]  desired setting.

Always Display: Always displays the

indicator when the drive mode is set to [Cont. Shooting].

Shoot.-Only Display: Displays the indicator only

while continuous shooting is performed.

Not Displayed: Does not display the indicator.

(Camera Settings 2) 

Hint

• When the internal camera memory for buffering is full, “SLOW” will be displayed and the continuous shooting speed will decrease.

Using touch function

Touch Operation

Sets whether to activate or not the touch operation of the monitor. Touch operations when shooting with the monitor are referred to as “touch panel operations,” and touch operations when shooting with the viewfinder are referred to as “touch pad operations.”

MENU  (Setup)  [Touch Operation]  desired setting.

On: Activates the touch operation. Off: Deactivates the touch operation.

Touch Panel/Pad

Selects whether to activate touch panel operation when shooting with the monitor, or touch pad operation when shooting with the viewfinder.

MENU  (Setup)  [Touch Panel/Pad]  desired setting.

Touch Panel+Pad: Activates both the touch panel operations when

shooting with the monitor and touch pad operations when shooting with the viewfinder.

Touch Panel Only: Activates only the touch panel operations when

shooting with the monitor.

Touch Pad Only: Activates only the touch pad operations when shooting

with the viewfinder.

Touch Focus

You can select a subject on which to focus using touch operations in the still image and movie recording modes.

MENU  (Setup)  [Touch Operation]  [On].

Specifying the position where you want to focus in the still image mode

You can focus on the desired position by touching the monitor.



Select a [Focus Area] other than [Flexible Spot] or

[Expand Flexible Spot].



MENU 

[Off].



Touch the monitor.

• When shooting with the monitor, touch the subject to focus.

• When shooting with the viewfinder, you can move the position of the focus by touching and dragging on the monitor while looking through the viewfinder.

• When the shutter button is pressed halfway down, the camera focuses on the focusing frame. Press the shutter button all the way down to shoot images.

• To cancel focusing with touch operations, touch center of the control wheel if shooting with the monitor, and press the center of the control wheel if shooting with the viewfinder.

(Camera Settings 1)  [Center Lock-on AF] 

or press the

Specifying the position where you want to focus in the movie recording mode (spot focus)

The camera will focus on the touched subject. Spot focus is not available when shooting with the viewfinder.



Select a [Focus Area] other than [Flexible Spot] or

[Expand Flexible Spot].



MENU 

[Off].



Touch the subject on which you want to focus before or

during recording.

• When you touch the subject, the focus mode temporarily switches to manual focus and the focus can be adjusted using the focus ring.

• To cancel spot focus, touch wheel.

Hint

• In addition to the touch focus function, touch operations such as the following are also available.

–When [Focus Area] is set to [Flexible Spot] or [Expand Flexible Spot], the

focusing frame can be moved using touch operations.

–When the [Focus Mode] is set to [Manual Focus], the focus magnifier can be

used by double-tapping the monitor.

Note

• The touch focus function is not available in the following situations:

–When [Focus Mode] is set to [Manual Focus]. –When using the digital zoom –When using the LA-EA2 or LA-EA4 –When using the LA-EA1 or LA-EA3, and the shooting mode is set to [Movie]

(Camera Settings 1)  [Center Lock-on AF] 

or press the center of the control

Selecting a still image size/image quality

JPEG Image Size

The larger the image size, the more detail will be reproduced when the image is printed on large-format paper. The smaller the image size, the more images can be recorded.

MENU  (Camera Settings 1)  [ JPEG Image Size]  desired setting.

When [ Aspect Ratio] is set to 3:2 When [ Aspect Ratio] is set to 16:9 L: 24M M: 10M S: 6.0M

6000×4000 pixels 3936×2624 pixels 3008×2000 pixels

L: 20M M: 8.7M S: 5.1M

6000×3376 pixels 3936×2216 pixels 3008×1688 pixels

When recording in the APS-C-equivalent size

When [ Aspect Ratio] is set to 3:2 When [ Aspect Ratio] is set to 16:9 L: 10M M: 6.0M S: 2.6M

Note

• When [ File Format] is set to [RAW] or [RAW & JPEG], the image size for RAW images corresponds to “L.”

3936×2624 pixels 3008×2000 pixels 1968×1312 pixels

L: 8.7M M: 5.1M S: 2.2M

3936×2216 pixels 3008×1688 pixels 1968×1112 pixels

JPEG Quality

Selects the JPEG image quality when [ [RAW & JPEG] or [JPEG].

File Format] is set to

MENU  (Camera Settings 1)  [ JPEG Quality]  desired setting.

Extra fine/Fine/Standard: Since the compression rate increases from

[Extra fine] to [Fine] to [Standard], the file size decreases in the same order. This allows more files to be recorded on one memory card, but the image quality is lower.

File Format

Sets the file format for still images.

MENU  (Camera Settings 1)  [ File Format]  desired setting.

RAW: Digital processing is not performed on this file format. Select this

format to process images on a computer for professional purposes.

RAW & JPEG: A RAW image and a JPEG image are created at the same

time. This is suitable when you need two image files, a JPEG for viewing, and a RAW for editing.

JPEG: The image is recorded in the JPEG format.

Shooting movies

Changing settings for movie recording

File Format

Selects the movie file format.

MENU  (Camera Settings 2)  [ File Format]  desired setting.

File Format Characteristics

XAVC S 4K

XAVC S HD

AVCHD

For details on memory cards that can be used for these formats, refer to page 81.

Records movies in 4K resolution (3840×2160).

Records movies in crisper quality than AVCHD with larger amounts of data.

The AVCHD format has a high degree of compatibility with storage devices other than computers.

You can save movies on a computer using the PlayMemories Home software.

You can save movies on a computer or create a disc that supports this format using the PlayMemories Home software.

Note

• When [ File Format] is set to [AVCHD], the file size of movies is limited to approx. 2GB. If the movie file size reaches approx. 2GB during recording, a new movie file will be created automatically.

• Images will not appear on the monitor of the camera if you record movies while the camera is connected to an HDMI device with [ [XAVC S 4K].

File Format] set to

Record Setting

Selects the frame rate and bit-rate for movie recording.

MENU  (Camera Settings 2)  [ Record Setting]  desired setting.

• The higher the bit-rate, the higher the image quality.

• For estimates of the maximum recordable movie time with each recording setting, refer to page 84.

When [

* Only when [NTSC/PAL Selector] is set to NTSC

File Format] is set to [XAVC S 4K]

Record Setting Bit-rate Description

30p 100M/25p 100M

30p 60M/25p 60M

24p 100M*

24p 60M*

Approx. 100 Mbps

Approx. 60 Mbps

Approx. 100 Mbps Records movies in 3840×2160 (24p). Approx. 60 Mbps Records movies in 3840×2160 (24p).

Records movies in 3840×2160 (30p/25p).

When [ File Format] is set to [XAVC S HD]

Record Setting Bit-rate Description

60p 50M/50p 50M

60p 25M/50p 25M

30p 50M/25p 50M

30p 16M/25p 16M

24p 50M*

120p 100M/100p 100M

120p 60M/100p 60M

* Only when [NTSC/PAL Selector] is set to NTSC

When [

File Format] is set to [AVCHD]

Record Setting Bit-rate Description

60i 24M (FX)/ 50i 24M (FX)

60i 17M (FH)/ 50i 17M (FH)

Approx. 50 Mbps Records movies in 1920×1080

Approx. 25 Mbps Records movies in 1920×1080

Approx. 50 Mbps Records movies in 1920×1080

Approx. 16 Mbps Records movies in 1920×1080

Approx. 50 Mbps Records movies in 1920×1080 (24p). Approx. 100 Mbps Records high-speed movies in

Approx. 60 Mbps Records high-speed movies in

24 Mbps at maximum

Approx. 17 Mbps on average

(60p/50p).

(30p/25p).

1920×1080 (120p/100p). You can record movies in 120 fps or 100 fps.

• You can create smoother slow-motion movies by using compatible editing devices.

1920×1080 (120p/100p). You can record movies in 120 fps or 100 fps.

• You can create smoother slow-motion movies by using compatible editing devices.

Records movies in 1920×1080 (60i/50i).

Note

• Creating an AVCHD recording disc from movies that were recorded with [60i 24M (FX)]/[50i 24M (FX)] as the [ because the image quality of movies is converted. If you want to store movies without converting them, use a Blu-ray Disc.

• [120p]/[100p] cannot be selected for the following settings.

–[Intelligent Auto] –[Scene Selection]

• In full-frame shooting, the angle of view will be narrower under the following conditions:

–When [

to [30p]

File Format] is set to [XAVC S 4K] and [ Record Setting] is set

Record Setting] takes a long time

Using network functions

Using the Wi-Fi/One-touch (NFC)/ Bluetooth functions

You can perform the following operations using the camera’s Wi-Fi, NFC One-touch, and Bluetooth functions.

• Saving images to a computer

• Transferring images from the camera to a smartphone

• Using a smartphone as a remote control for the camera

• Viewing still images on a TV

• Recording location information from a smartphone to images

• Transferring images to the FTP server

For details, refer to the “Help Guide” (page 2).

Installing PlayMemories Mobile

PlayMemories Mobile is required to connect the camera and a smartphone. If PlayMemories Mobile is already installed on your smartphone, be sure to update it to the latest version. For details on PlayMemories Mobile, refer to the support page (http://www.sony.net/pmm/).

Note

• To use the camera’s NFC One-touch function, an NFC-enabled Android smartphone or tablet is required.

• The Wi-Fi functions introduced in this manual are not guaranteed to operate on all smartphones or tablets.

• The Wi-Fi functions of this camera are not available when connected to a public wireless LAN.

• Depending on future version upgrades, the operational procedures or screen displays are subject to change without notice.

Recording location information to captured images

By using PlayMemories Mobile, you can obtain location information from a connected smartphone (via Bluetooth communication) and record it to captured images.

Transferring images to the FTP server

You can use the camera’s Wi-Fi function to transfer images to the FTP server. For details, refer to the “FTP Help Guide.” http://rd1.sony.net/help/di/ftp/h_zz/

• Basic knowledge of FTP servers is required.

Connecting the camera to a wireless access point

Connect the camera to your wireless access point. Before starting the procedure, make sure you have the SSID (name of the access point) and password of your wireless access point with you.

MENU  (Network)  [Wi-Fi Settings]  [Access Point Set.].

Use the control wheel to select the access point to which you want to connect. Press the center of the control wheel and enter the password for the wireless access point, then select [OK].

Note

• If a connection is not established, see the wireless access point operating instructions or contact the administrator of the access point. To save images to a computer, install PlayMemories Home on your computer.

PlayMemories Home http://www.sony.net/pm/

Using a computer

Connecting the camera to a computer

Connecting to a computer

Insert a sufficiently charged battery pack into the camera.

Turn on the camera and the computer.

Check that [USB Connection] under (Setup) is set to [Mass Storage].

Connect the camera to the computer using the USB cable.

• When you connect the camera to the computer for the first time, the procedure for recognizing the camera may start automatically on the computer. Wait until the procedure is finished.

• If you connect the camera to your computer using the USB cable when [USB Power Supply] is set to [On], power is supplied from your computer. (Default setting: [On])

• Use a USB 3.1-compatible computer and the USB Type-C cable (sold separately) for higher-speed communications.

To a USB terminal

To the Multi/Micro USB Terminal

USB cable

Disconnecting the camera from the computer

Perform steps 1 and 2 below before performing the following operations:

• Disconnecting the USB cable.

• Removing a memory card.

• Turning off the product.

Click (Safely Remove Hardware and Eject Media) in the taskbar.

Click the displayed message.

Note

• On Mac computers, drag and drop the memory card icon or the drive icon into

the “Trash” icon. The camera will be disconnected from the computer.

• On Windows 7/Windows 8 computers, the disconnection icon may not

appear. In that case, you can skip the steps above.

• Do not remove the USB cable from the camera while the access lamp is lit. The

data may be damaged.

Introduction to computer software

We offer the following computer software to enhance your enjoyment of photos/movies. Access one of the following URLs using your Internet browser and then download the software by following the onscreen instructions. If one of these software is already installed on your computer, update it to the latest version before use.

Windows:

http://www.sony.co.jp/imsoft/Win/

Mac:

http://www.sony.co.jp/imsoft/Mac/

You can check the recommended operating environment for the software from the following URL: http://www.sony.net/pcenv/

Image management software (PlayMemories Home)

PlayMemories Home allows you to import still images and movies to your computer and view or use them. You need to install PlayMemories Home to import XAVC S movies or AVCHD movies to your computer. You can access the download website directly from the following URL:

http://www.sony.net/pm/

• When you connect the camera to your computer, new functions may be added to PlayMemories Home. Connecting the camera to your computer is therefore recommended even if PlayMemories Home has already been installed on the computer.

RAW processing/remote camera control software

• You can develop and edit RAW images using various adjustment functions like tone curve and sharpness.

• With the software, you can change the camera settings or release the shutter from a computer connected via a USB cable. To control the camera using the software, first select MENU 

(Setup)  [USB Connection]  [PC Remote], then connect the

camera to a computer via a USB cable.

MENU items/List of icons

Using MENU items

You can change settings related to all the camera operations including shooting, playback, and operating method. You can also execute camera functions from the MENU.

Press the MENU button to display the menu screen.

Select the desired setting you want to adjust using the top/ bottom/left/right sides of the control wheel or by turning the control wheel, and then press the center of the control wheel.

Select an icon at the top of the screen and press the left/right side of the control wheel to move to another MENU item.

Press the MENU button to go back to the previous screen.

MENU button

Select the desired setting value, and press the center to confirm your selection.

List of MENU items

For details on each MENU items, refer to the reference page in the last column or the Help Guide.

(Camera Settings 1)

Quality/Image Size

File Format

RAW File Type

JPEG Quality

JPEG Image Size

Aspect Ratio

APS-C/Super 35mm

Long Exposure NR

High ISO NR

Color Space

Lens Comp.

Shoot Mode/Drive Scene Selection

Red tab

Sets the file format for still images. ([RAW]/ [JPEG], etc.)

Selects the file type for RAW images. Help

Selects the JPEG image quality for [RAW & JPEG] or [JPEG] under

File Format].

[ Selects the size of still images.

(L/ M/ S) Selects the aspect ratio for still

images.

Sets whether to record in APS-C-equivalent size for still images and Super 35 mm-equivalent size for movies.

Sets noise reduction processing for shots with a shutter speed of 1 second or longer.

Sets noise reduction processing for high-sensitivity shooting.

Changes the color space (range of reproducible colors).

Selects the type of lens compensation.

Selects pre-set settings to match various scene conditions. ([Portrait] / [Sports Action], etc.)

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Drive Mode

Bracket Settings

/ Recall

/ Memor y

Select Media

Reg Cust Shoot Set

AF Focus Mode

Priority Set in AF-S

Priority Set in AF-C

Focus Area

Focus Settings

Swt. V/H AF Area

Sets the drive mode, such as for continuous shooting. ([Self-timer]/ [Cont. Bracket], etc.)

Sets self-timer shooting in bracket mode, shooting order for exposure bracketing, and white balance bracketing.

Calls up settings pre-registered to

 / Memory].

[ Registers the desired modes and

camera settings. Selects the memory card slot from

which settings are recalled or to which settings are registered for M1 through M4.

Assign functions to the custom key to recall when shooting.

Selects the focus mode. ([Single-shot AF]/ [Continuous AF], etc.)

Sets the timing of the shutter release when [Focus Mode] is set to [Single-shot AF], [DMF] or [Automatic AF] with a still subject.

Sets the timing of the shutter release when [Focus Mode] is set to [Continuous AF] or [Automatic AF] with a moving subject.

Selects the area of focus. ([Wide]/ [Flexible Spot], etc.)

Allows you to focus using the front dial, rear dial or control wheel.

Sets whether to adjust the [Focus Area] and the position of the focusing frame based on the camera’s position (horizontal or vertical).

38,

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

AF Illuminator

Center Lock-on AF

Set. Face Prty in AF

AF Track Sens

AF System

AF w/ shutter

Pre-AF

Eye-Start AF

AF Area Regist.

Del. Reg. AF Area

AF Area Auto Clear

Disp. cont. AF area

Sets the AF illuminator, which provides light to aid focusing in dark scenes.

Sets the function to track a subject and continue focusing when pressing the center of the control wheel in the shooting screen.

Sets whether the camera focuses based on detected faces.

Sets the AF tracking sensitivity for the still image mode.

Sets the auto focus method when an LA-EA1/LA-EA3 Mount Adaptor (sold separately) is attached.

Sets whether to perform auto focusing when the shutter button is pressed halfway down. This is useful when you want to adjust the focus and exposure separately.

Sets whether or not to perform auto focus before the shutter button is half pressed.

Sets whether to use auto focus when you look through the viewfinder if an LA-EA2/LA-EA4 Mount Adaptor (sold separately) is attached.

Sets whether to move the focusing frame to a preassigned position when shooting still images.

Deletes the focusing frame position information that was registered using

AF Area Regist.].

[ Sets whether the focus area is

displayed all the time or disappears automatically shortly after focusing.

Sets whether or not to display the focus area in [Continuous AF] mode.

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

AF Micro Adj.

Exposure Exposure Comp.

Reset EV Comp.

ISO

ISO AUTO Min. SS

Metering Mode

Face Prty in Mlti Mtr

Spot Metering Point

Exposure step

AEL w/ shutter

Finely adjusts the autofocused position, when using the LA-EA2 or LA-EA4 Mount Adaptor (sold separately).

Compensates for the brightness of the entire image.

Sets whether to maintain the exposure value set using [Exposure Comp.] when you turn off the power when the exposure compensation dial position is set to “0.”

Sets the ISO sensitivity. ([ISO AUTO], etc.)

Sets the slowest shutter speed at which ISO sensitivity will start to change in [ISO AUTO] mode.

Selects the method for measuring brightness. ([Multi]/ [Spot], etc.)

Sets whether the camera measures brightness based on detected faces when [Metering Mode] is set to [Multi].

Sets whether to coordinate the spot metering point with the focus area when [Focus Area] is set to [Flexible Spot] or [Expand Flexible Spot].

Selects the size of the increment step for shutter speed, aperture, and exposure compensation values.

Sets whether to lock the exposure when the shutter button is pressed halfway down. This is useful when you want to adjust the focus and exposure separately.

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Exposure Std. Adjust

Flash Flash Mode

Flash Comp.

Exp. comp. set

Wireless Flash

Red Eye Reduction

Color/WB/Img. Processing White Balance

Priority Set in AWB

DRO/Auto HDR

Creative Style

Picture Effect

Adjusts the standard for the correct exposure value for each metering modes.

Sets the flash settings. Help

Adjusts the intensity of flash output. Help

Sets whether to reflect exposure compensation value to flash compensation.

Sets whether to shoot with the wireless flash.

Reduces the red-eye phenomenon when using flash.

Corrects the tone effect of the ambient light to shoot whitish objects in a white tone. ([Auto]/ [Daylight], etc.)

Selects which tone to prioritize when shooting under lighting conditions such as incandescent light with [White Balance] set to [Auto].

Analyzes the contrast of light and shadow between the subject and the background by dividing the image into small areas, and creates an image with the optimal brightness and gradation.

Selects the desired image processing. You can also adjust contrast, saturation, and sharpness. ([Vivid]/ [Portrait], etc.)

Shoots images with a texture unique to the selected effect. ([Toy Camera]/ [Rich-tone Mono.], etc.)

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Picture Profile

Focus Assist Focus Magnifier

Focus Magnif. Time

Initial Focus Mag.

AF in Focus Mag.

MF Assist

Peaking Setting

Shoot Assist

Anti-flicker Shoot.

Face Registration

Regist. Faces Priority

Changes settings such as color and tone when recording images.

* This function is for skilled movie

creators.

Enlarges the image before shooting so that you can check the focus.

Sets the length of time the image will be shown in an enlarged form.

Sets the initial magnification scale when using [Focus Magnifier].

Sets whether or not to autofocus when an enlarged image is being displayed. While the enlarged image is being displayed, you can focus within a smaller area than the flexible spot.

Displays an enlarged image when focusing manually.

Sets the peaking function, which enhances the outline of in-focus areas when focusing manually.

Detects flickering/blinking from artificial light sources such as fluorescent lighting and times the shooting of images to moments when flickering will have less of an impact.

Registers or changes the person to be given priority when focusing.

Detects the registered face with higher priority using [Face Registration].

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

(Camera Settings 2)

Movie

Exposure Mode

File Format

Record Setting

S&Q Settings

Proxy Recording

AF drive speed

AF Track Sens

Auto Slow Shut.

Audio Recording

Audio Rec Level

Audio Level Display

Audio Out Timing

Wind Noise Reduct.

Marker Display

Purple tab

Sets the exposure mode when shooting movies.

Sets the exposure mode when shooting slow-motion/quick-motion movies.

Selects the movie file format. ([XAVC S 4K]/ [AVCHD], etc.)

Selects a frame-rate and bit-rate for the movie.

Changes the settings for slow-motion and quick-motion movie shooting.

Records low-bit-rate proxy files simultaneously when recording XAVC S movies.

Switches focusing speed when using autofocus in movie mode.

Sets the AF tracking sensitivity for the movie mode.

Sets the function that automatically adjusts the shutter speed following the brightness of the environment in movie mode.

Sets whether to record audio when shooting a movie.

Adjusts the audio recording level during movie recording.

Sets whether to display the audio level.

Sets the timing of audio output during the movie recording.

Reduces wind noise during movie recording.

Sets whether to display markers on the monitor when recording movies.

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Marker Settings

Video Light Mode

Movie w/ shutter

Shutter/SteadyShot

Silent Shooting

e-Front Curtain Shut.

Release w/o Lens

Release w/o Card

SteadyShot

SteadyShot Settings

Zoom Zoom

Zoom Setting

Zoom Ring Rotate

Display/Auto Review DISP Button

Sets which markers to display on the monitor when recording movies.

Sets the illumination setting for the HVL-LBPC LED light (sold separately).

Records movies using the shutter button.

Shoots images without the shutter sound.

Sets whether to use the electronic front curtain shutter function.

Sets whether to release the shutter when the lens is not attached.

Sets whether to release the shutter when a memory card is not inserted.

Sets whether to activate SteadyShot for shooting.

Sets SteadyShot settings. Help

Sets the zoom scale for zoom functions other than the optical zoom.

Sets whether to use the Clear Image Zoom and Digital Zoom when zooming.

Assigns the zoom in/out to the rotational direction of the zoom lens. This function is only available with a power zoom lens that is compatible with this function.

Sets the type of information to be displayed on the monitor or in the viewfinder when the DISP button is pressed.

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

FINDER/MONITOR

Zebra Setting

Grid Line

Exposure Set. Guide

Live View Display

Cont. Shoot. Length

Auto Review

Custom Operation

Custom Key

Function Menu Set.

Sets the method for switching the display between the electronic viewfinder and the monitor.

Sets the stripes displayed to adjust brightness.

Displays grid lines for adjusting the image composition.

Sets the guide displayed when exposure settings are changed in the shooting screen.

Sets whether to reflect settings such as exposure compensation in screen display.

Sets whether to display an indicator of the remaining time for which continuous shooting can be performed at the same shooting speed.

Sets auto review to display the captured image after shooting.

Assigns functions to the various keys so that you can perform operations more quickly by pressing the keys when shooting still images.

Assigns functions to the various keys so that you can perform operations more quickly by pressing the keys when shooting movies.

Assigns functions to the keys so that you can perform operations more quickly by pressing the keys when playing back images.

Customizes the functions displayed when the Fn (Function) button is pressed.

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Dial Setup

Av/Tv Rotate

Dial Ev Comp

MOVIE Button

Lock Operation Parts

Audio signals

Sets the functions of the front and rear dials when the exposure mode is set to M. Dials can be used for adjusting shutter speed and aperture value.

Sets the direction of turning the front or rear dial or the control wheel to adjust the aperture value or shutter speed.

Sets whether to compensate the exposure with the front or rear dial.

Enables or disables for the MOVIE button.

Sets whether to disable the multiselector, control wheel, or front and rear dials temporarily when the Fn button is pressed and held down.

Selects whether the camera beeps during auto focus and self-timer operations.

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

(Network)

Snd to Smrtphn Func

Send to Computer

FTP Transfer Func.

View on TV

Ctrl w/ Smartphone

Sets movies to be transferred to a smartphone, or transfers images to a smartphone.

Backs up images by transferring them to a computer connected to a network.

Sets image transfer using FTP and executes it.

* Basic knowledge of FTP server is

required.

Allows you to view images on a network-enabled TV.

Sets the condition for connecting the camera to a smartphone.

Green tab

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Airplane Mode

Wi-Fi Settings

Bluetooth Settings

Loc. Info. Link Set.

Edit Device Name

Imp Root Certificate

Reset Network Set.

Disables wireless communications from the device such as Wi-Fi, NFC, and Bluetooth function.

Allows you to register your access point and check or change the Wi-Fi connection information.

Controls the settings for connecting the camera with a smartphone via a Bluetooth connection.

Obtains location information from the paired smartphone and records it to captured images.

Changes the device name under Wi-Fi Direct, etc.

Imports a root certificate to the camera.

Resets all the network settings. Help

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

(Playback)

Protect

Rotate

Delete

Rating

Rating Set (Cust Key)

Specify Printing

Blue tab

Protects recorded images against accidental erasure.

Rotates the image. Help

Deletes images. Help

Assigns rating to recorded images on a scale from

Sets the rating (number of can be selected using the custom key to which [Rating] has been assigned with [

Specifies in advance on the memory card which still images to print out later.

to .

) that

Custom Key].

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Copy

Photo Capture

Enlarge Image

Enlarge Init. Mag.

Enlarge Initial Pos.

Slide Show

Select PB Media

View Mode

Image Index

Disp Cont Shoot Grp

Display Rotation

Image Jump Setting

Copies images from the memory card in the memory card slot designated in [Select PB Media] to the memory card in the other slot.

Captures a chosen scene in a movie to save as a still image.

Enlarges the playback images. Help

Sets the initial magnification scale when playing back enlarged images.

Sets the initial magnification area when playing back enlarged images.

Plays a slide show. Help

Selects the memory card slot of the memory card to be played back.

Plays back images from a specified date or specified folder of still images and movies.

Displays multiple images at the same time.

Sets whether to display continuously shot images as a group.

Sets the playback orientation for images shot vertically.

Sets which dial and method to use for jumping between images during playback.

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

(Setup)

Yellow tab

Monitor Brightness

Viewfinder Bright.

Finder Color Temp.

Gamma Disp. Assist

Volume Settings

Delete confirm.

Display Quality

Pwr Save Start Time

Auto Pwr OFF Temp.

NTSC/PAL Selector*

Cleaning Mode

Touch Operation

Adjusts the brightness of the screen. Help

Sets the brightness of the electronic viewfinder.

Sets the color temperature of the viewfinder.

Adjusts the screen to make monitoring easier when displaying an S-Log or HLG movie.

Sets the volume for movie playback. Help

Sets whether [Delete] or [Cancel] is preselected in the delete confirmation screen.

Sets the display quality.

* When [High] is selected, the battery

is consumed more quickly.

* When the temperature of the

camera is high, [Display Quality] may be locked to [Standard].

Sets the time intervals to automatically switch to power save mode.

Sets the camera temperature at which the camera turns off automatically during shooting. When shooting in

hand-held mode, set to [Standard]. Changes the TV format of the device

so that you can shoot in a different movie format.

Starts the cleaning mode to clean the image sensor.

Sets whether or not to activate the touch operation of the monitor.

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Touch Panel/Pad

Touch Pad Settings

Demo Mode

TC/UB Settings

Remote Ctrl

HDMI Settings

4K Output Sel.

USB Connection

USB LUN Setting

USB Power Supply

PC Remote Settings

Language

Selects whether to activate touch panel operation when shooting with the monitor, or touch pad operation when shooting with the viewfinder.

Adjusts settings related to touch pad operation.

Sets demonstration playback of movies to on or off.

Sets the time code (TC) and user bit (UB).

* This function is for skilled movie

creators.

Sets whether to use the infrared remote control.

Sets the HDMI settings.

* Images will not appear on the

monitor of the camera if you record movies while the camera is connected to an HDMI device with

File Format] set to [XAVC S 4K].

[

Sets how to record and output 4K movies via HDMI when the camera is connected to an external recorder/ player that supports 4K.

Sets the USB connection method. Help

Enhances compatibility by limiting the functions of USB connection. Set to [Multi] in normal conditions and to [Single] only when the connection cannot be established.

Sets whether to supply power via USB connection when the camera is connected to a computer or USB device.

Controls the PC remote shooting settings.

Selects the language. 28

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Date/Time Setup

Area Setting

Format

File Number

Set File Name

Rec. Media Settings

Select REC Folder

New Folder

Folder Name

Recover Image DB

Display Media Info.

Version

Setting Reset

Sets the date, time, and daylight savings.

Sets the location of use. Help

Sets copyright information for still images.

Formats the memory card. Help

Sets the method used to assign file numbers.

Changes the first 3 characters of the file names for still images.

Sets the method for recording images to two memory card slots.

Changes the folder selected for storing still images.

Creates a new folder for storing still images.

Sets the folder format for still images. Help

Recovers the image database file and enables recording and playback.

Displays the remaining recording time of movies and the recordable number of still images on the memory card.

Displays the camera software version. Help

Restores settings to their defaults. Select [Initialize] to restore all settings to their default values.

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

(My Menu)

Gray tab

Add Item

Sort Item

Delete Item

Delete Page

Delete All

*1 If you change this item, you will need to format the memory card for

compatibility with the PAL or NTSC system. Also, note that it may not be possible to play back movies recorded for the NTSC system on PAL system TVs.

Adds desired MENU items to

(My Menu).



Sorts the MENU items added to

(My Menu).



Deletes MENU items added to

(My Menu).



Deletes all the MENU items on a page

(My Menu).



Deletes all the MENU items added to

(My Menu).



Help

Guide

Help

Guide

Help

Guide

Help

Guide

Help

Guide

List of icons on the monitor

The displayed contents and their positions in the illustrations are just guidelines, and may differ from the actual displays.

Icons on the shooting screen

Monitor mode



Shooting mode/

Scene recognition

P P A S M

Shooting mode (29)

Scene Recognition icons

Scene Selection

Viewfinder mode



Camera settings

NO CARD

Memory card status (24, 81)

100

Remaining number of recordable images (83)

Writing data / Number of images left to write

Aspect ratio of still images (57)

24M 20M 10M 8.7M 6.0M 5.1M

2.6M 2.2M

Image size of still images (43)

RAW

RAW recording (compressed/ uncompressed) (44)

X.FINE FINE STD

JPEG Quality (44)

XAVCS4K XAVCSHD AVCHD

File format of movies (45)

Record setting of movies (46)

120p 60p 60i 30p 24p 100p 50p 50i 25p

Frame rate of movies (46)

Proxy Recording (63)

120fps 60fps 30fps 15fps 8fps 4fps 100fps 50fps 25fps 12fps 6fps 3fps 2fps 1fps

Frame rate for slow/quick motion shooting (63)

Setting Effect OFF (65)

AF Illuminator (59)

Flicker

Flickering detected (62)

SteadyShot off/on, Camera shake warning (64)

SteadyS. Focal Len./ Camera shake warning (64)

Smart Zoom/ Clear Image Zoom/ Digital Zoom (64)

—P C—

PC remote (70)

Bright Monitoring

Silent Shooting (64)

Infrared remote control

APS-C/Super 35mm (57)

Flash charge in progress

No audio recording of movies (63)

Wind Noise Reduct. (63)

Gamma Disp. Assist (69)



Battery

Remaining battery (22)

Remaining battery warning

Focus Cancel (41)

Lock-on AF Cancel

Spot Focus

Performing [Spot Focus] (42)

NFC active (49)

Bluetooth connection available/ Bluetooth connection unavailable (67)

Connected to smartphone/ Not connected to smartphone

Obtaining location information/ Location information cannot be obtained (67)

Airplane Mode(67)

Overheating warning

Database file full/Database file error

USB power supply (70)



Shooting settings

Drive Mode (38)

Flash Mode (61)/ Wireless Flash (61)/ Red Eye Reduction (61)

±0.0

Flash Comp. (61)

Focus Mode (31)

Focus Area (33)

JPEG RAW RAW+J +J

File Format (44)

Metering Mode (60)

AWB

7500K A5 G5

White Balance (Auto, Preset, Underwater Auto, Custom, Color temperature, Color filter) (61)

D-Range Opt./Auto HDR (61)

+3 +3 +3

Creative Style (61)/Contrast, saturation, and sharpness

Picture Effect(61)

Face Priority in AF (59)

Picture Profile (62)

Prioritize Rec. Media (71)



Focus indicator/exposure

settings



Focus indicator (32)

1/250

Shutter speed

F3.5

Aperture value

Exposure compensation (60)/ Metered Manual

ISO400 ISO AUTO

ISO sensitivity (60)

AE lock/ FEL lock



Guides/other

Lock-on AF Lock-on AF Cancel

Guide display for Lock-on AF (59)

Focus Cancel

Guide display for canceling focusing (41)

Bracket indicator

Spot metering area (60)

Exposure Setting Guide (65)

Shutter speed indicator

Aperture indicator

Histogram

Digital level gauge

STBY REC

Movie recording standby/Movie recording in progress

1:00:12

Actual movie recording time (hours: minutes: seconds)

Audio Level Display (63)

REC Control(70)

00:00:00:00

Time code (hours: minutes: seconds: frames) (70)

00 00 00 00

User Bit (70)

Icons on the playback screen

Single-image playback display



Basic information

Playback media (68)

View Mode(68)

Rating (67)



Protect (67)

DPOF

DPOF set (67)

3/7

File number/Number of images in the view mode

NFC active (49)

Histogram display

Proxy movie included (63)



Camera settings

Refer to “Icons on the shooting screen” (page73).



Shooting settings

Picture Effect error

Auto HDR error (61)

35mm

Lens focal length

HLG

HDR recording (Hybrid LogGamma)

Remaining battery (22)

Continuous shooting group

(68)

Refer to “Icons on the shooting screen” (page73) for other icons displayed in this area.



Image information

Latitude/longitude information (67)

2018 - 1 - 1 10:37AM

Date of recording (28)

100-0003

Folder number  File number (71)

Histogram (Luminance/R/G/B)

About this product

Specifications

Battery life and number of recordable images

Battery life Number of images

Shooting (still images)

Actual shooting (movies)

Continuous shooting (movies)

• The above estimates for battery life and number of recordable images apply when the battery pack has been fully charged. The battery life and number of images may decrease depending on the conditions of use.

• The battery life and number of recordable images are estimates based on shooting with the default settings under the following conditions:

– Using the battery pack at an ambient temperature of 25°C (77°F). – Using a Sony SDXC memory card – Using a lens FE 28-70 mm F3.5-5.6 OSS

• The numbers for “Shooting (still images)” are based on the CIPA standard and shooting under the following conditions: (CIPA: Camera & Imaging Products Association)

– One picture is taken every 30 – The power is turned on and off once every ten times.

Screen mode Viewfinder mode Screen mode Viewfinder mode Screen mode Viewfinder mode

(U3) (sold separately)

seconds.

― Approx. 710 ― Approx. 610

Approx. 125 min. ―

Approx. 115 min. ― Approx. 210 min. ― Approx. 200 min.

―

• The number of minutes for movie shooting is based on the CIPA standard and shooting under the following conditions:

– The image quality is set to XAVC S HD 60p 50M / 50p 50M. – Actual shooting (movies): Battery life based on repeated shooting,

zooming, shooting stand-by, turning on/off, etc.

– Continuous shooting (movies): Battery life based on non-stop

shooting until the limit (29

minutes) has been reached, and then

continued by pressing the MOVIE (Movie) button again. Other functions, such as zooming, are not operated.

Memory cards that can be used

When using microSD memory cards or Memory Stick Micro media with this camera, be sure to use the appropriate adaptor.

SD memory cards

Recording format Supported memory card

Still image

AVCHD

4K 60 Mbps* HD 50 Mbps or lower*

XAVC S

* Including when recording proxy movies at the same time

HD 60 Mbps 4K 100 Mbps*

HD 100 Mbps

Memory Stick media

Recording format Supported memory card

Still image

AVCHD

4K 60 Mbps* HD 50 Mbps or lower*

XAVC S

* Including when recording proxy movies at the same time

HD 60 Mbps 4K 100 Mbps*

HD 100 Mbps

SD/SDHC/SDXC card SD/SDHC/SDXC card

(Class 4 or faster, or U1 or faster)

SDHC/SDXC card (Class 10, or U1 or faster)

SDHC/SDXC card (U3)

Memory Stick PRO Duo/ Memory Stick PRO-HG Duo

Memory Stick PRO Duo (Mark 2)/ Memory Stick PRO-HG Duo

Memory Stick PRO-HG Duo

—

Note

• Use the slot1 when you are using a UHS-II memory card. Also, select MENU  (Setup)  [Rec. Media Settings]  [Prioritize Rec. Media]  [Slot 1].

• Memory Stick PRO Duo media cannot be used in the slot1.

• When an SDHC memory card is used to record an XAVC S movie over

extended periods of time, the recorded movies will be divided into files 4GB in size. The divided files can be handled as a single file by importing them to a computer using PlayMemories Home.

• When recording a movie on memory cards in both the slot1 and the slot2

with following camera settings, insert two memory cards with the same file system. XAVC S movies cannot be recorded simultaneously when using a combination of the exFAT file system and FAT32 file system.

File Format] is set to [XAVC S 4K] or [XAVC S HD]

–[ –[Recording Mode] under [Rec. Media Settings] is set to [Simult.(

[Simult.(

SDXC memory card Memory Stick PRO Duo (Mark2)

Memory Stick PRO-HG Duo SDHC memory card

• Charge the battery pack sufficiently before attempting to recover the

database files on the memory card.

/ )]

Memory card File system

ex FAT

FAT32

)] or

Number of recordable images

When you insert a memory card into the camera and set the ON/OFF (Power) switch to “ON,” the number of images that can be recorded (should you continue to shoot using the current settings) is displayed on the screen.

Note

• When “0” (the number of recordable images) flashes in orange, the memory card is full. Replace the memory card with another one, or delete images from the current memory card.

• When “NO CARD” flashes in orange, it means no memory card has been inserted. Insert a memory card.

The number of images that can be recorded on a memory card

The following table shows the approximate number of images that can be recorded on a memory card formatted with this camera. The values are defined using Sony standard memory cards for testing. The values may vary depending on the shooting conditions and the type of memory card used.

JPEG Image Size]: [L: 24M]

[

Aspect Ratio]: [3:2]*

[

JPEG Quality/ File Format Standard Fine Extra fine RAW & JPEG (Compressed RAW)* RAW (Compressed RAW) RAW & JPEG (Uncompressed RAW)* RAW (Uncompressed RAW)

When [

images than the numbers shown in the table (except when [RAW] is selected).

[

Aspect Ratio] is set to other than [3:2], you can record more

JPEG Quality] when [RAW & JPEG] is selected: [Fine]

8 GB 32 GB 64 GB 256 GB

1100 4600 9200 36000 790 3200 6400 25000 435 1750 3500 14000

215 870 1750 7000

295 1200 2400 9600

125 510 1000 4100

150 610 1200 4950

(Units: Images)

Note

• Even if the number of recordable images is higher than 9999 images, “9999” will appear.

• The numbers shown are when using a Sony memory card.

Recordable movie times

The table below shows the approximate total recording times using a memory card formatted with this camera. The values may vary depending on the shooting conditions and the type of memory card used. The recording times for when [ [XAVC S 4K] and [XAVC S HD] are recording times when shooting with

Proxy Recording] set to [Off].

[

File Format Record Setting 8 GB 32 GB 64 GB 256 GB

XAVC S 4K 30p 100M/

25p 100M 30p 60M/

25p 60M 24p 100M* 24p 60M*

XAVC S HD 120p 100M/

100p 100M 120p 60M/

100p 60M 60p 50M/

50p 50M 60p 25M/

50p 25M 30p 50M/

25p 50M 30p 16M/

25p 16M 24p 50M*

8m 35m 1h 15m 5h 15m

10m 1h 2h 5m 8h 35m

8m 35m 1h 15m 5h 15m

10m 1h 2h 5m 8h 35m

8m 35m 1h 15m 5h 15m

10m 1h 2h 5m 8h 35m

15m 1h 15m 2h 30m 10h 25m

30m 2h 25m 5h 20h 10m

15m 1h 15m 2h 30m 10h 25m

50m 3h 50m 7h 45m 31h 25m

15m 1h 15m 2h 30m 10h 25m

File Format] is set to

(h (hour), m (minute))

File Format Record Setting 8 GB 32 GB 64 GB 256 GB

AVCHD 60i 24M (FX)/

50i 24M (FX) 60i 17M (FH)/

50i 17M (FH)

* Only when [NTSC/PAL Selector] is set to NTSC

40m 2h 55m 6h 24h 15m

55m 4h 5m 8h 15m 33h 15m

• Continuous shooting is possible for approximately 29 minutes (a product specification limit). The continuous recordable time may differ in the following situations:

– When shooting slow-motion/quick-motion movies: Recording will

automatically stop when the recorded file reaches approximately 29minutes (the played back movie reaches approximately 29 minutes). (Recording will automatically stop when the recorded file reaches approximately 15 minutes if [

Frame Rate] is set to [30fps/25fps].)

and [

Record Setting] is set to [60p/50p]

• The times for slow-motion/quick-motion movies are playback times, not recording times.

Note

• The recordable time of movies varies because the camera is equipped with

VBR (Variable Bit-Rate), which automatically adjusts image quality depending on the shooting scene. When you record a fast-moving subject, the image is clearer but the recordable time is shorter because more memory is required for recording. The recordable time also varies depending on the shooting conditions, the subject or the image quality/size settings.

• The times shown are recordable times using a Sony memory card.

Notes on continuous movie recording

• High-quality movie recording and high-speed continuous shooting require large amounts of power. Therefore, if you continue to shoot, the temperature inside the camera will rise, especially that of the image sensor. In such cases, the camera will turn off automatically because the surface of the camera is heated to a high temperature or the high temperature affects the quality of the images or the internal mechanism of the camera.

• The duration of time available for continuous movie recording when the camera records with the default settings after the power has been turned off for a while is as follows. The values indicate the continuous time from when the camera starts recording until the camera stops recording.

Ambient

temperature

20°C (68°F)

30°C (86°F)

40°C (104°F)

Continuous recording time for

movies (HD)

Approx. 29min. Approx. 29min. Approx. 29min. Approx. 29min. Approx. 29min. Approx. 29min.

Continuous recording time for

movies (4K)

[Auto Pwr OFF Temp.]: [Standard] HD: XAVC S HD (60p 50M/50p 50M, when the camera is not connected via Wi-Fi) 4K: XAVC S 4K (24p 60M/25p 60M, when the camera is not connected via Wi-Fi)

• The duration of time available for movie recording varies with the temperature, file format/record setting for movies, Wi-Fi network environment, or condition of the camera before you start recording. If you frequently recompose or shoot images after the power is turned on, the temperature inside the camera will rise and the recording time available will be shorter.

• If the

icon appears, the temperature of the camera has risen.

• If the camera stops movie recording due to a high temperature, leave it for some time with the power turned off. Start recording after the temperature inside the camera drops fully.

• If you observe the following points, you will be able to record movies for longer periods of time.

– Keep the camera out of direct sunlight. – Turn the camera off when it is not being used.

• When [

File Format] is set to [AVCHD], the file size of movies is limited to approx. 2GB. If the movie file size reaches approx. 2GB during recording, a new movie file will be created automatically.

Specifications

Camera

[System]

Camera Type:

Interchangeable Lens Digital Camera

Lens: Sony E-mount lens

[Image sensor]

Image format: 35mm full frame

(35.6mm × 23.8mm), CMOS image sensor

Effective pixel number of camera:

Approx. 24200000 pixels

Total pixel number of camera:

Approx. 25300000 pixels

[SteadyShot]

In-camera sensor shift image

stabilization system

[Auto focus system]

Detection system: Phase detection

system/Contrast detection system

Sensitivity Range: –3EV to +20EV (at

ISO 100 equivalent, F2.0)

[Electronic viewfinder]

Type: 1.3 cm (0.5 type) Electronic

Viewfinder Total number of dots: 2359296dots Magnification: Approx. 0.78× with

50mm lens at infinity, –1m Eye Point: Approx. 23mm from the

eyepiece and approx. 18.5mm

from the eyepiece frame at –1m Diopter Adjustment:

–4.0m–1 to +3.0m

[Monitor]

7.5cm (3.0 type) TFT drive, touch

panel Total number of dots: 921600 dots

–1

[Exposure control]

Metering method: 1200-zone

evaluative metering

Metering Range: –3EV to +20EV (at

ISO 100 equivalent with F2.0 lens)

ISO sensitivity (Recommended

exposure index): Still images: ISO 100 to ISO 51200 (Extended ISO: Minimum ISO 50, maximum ISO 204800) Movies: ISO 100 to ISO 51200 equivalent

[Shutter]

Type: Electronically-controlled,

vertical-traverse, focal-plane type

Speed range:

Still images: 1/8000second to 30seconds, BULB Movies: 1/8000second to 1/4second 108060i-compatible devices (108050i-compatible devices): up to 1/60 (1/50) second in AUTO mode (up to 1/30 (1/25) second in Auto slow shutter mode)

Flash sync speed: 1/250second

(when using a flash manufactured by Sony)

–1

[Recording format]

File format: JPEG (DCF Ver. 2.0, Exif

Ver. 2.31, MPF Baseline) compliant, RAW (Sony ARW 2.3 format)

Movie (XAVC S format):

MPEG-4 AVC/H.264 XAVC S ver.1.0 format compliant Video: MPEG-4 AVC/H.264 Audio: LPCM 2ch (48kHz 16bit)

Movie (AVCHD format):

AVCHD format Ver. 2.0 compatible Video: MPEG-4 AVC/H.264 Audio: Dolby Digital 2ch, equipped with Dolby Digital Stereo Creator

• Manufactured under license from Dolby Laboratories.

[Recording media]

SLOT 1: Slot for SD cards (UHS-I and

UHS-II compatible)

SLOT 2: Multi-slot for

Memory Stick PRO Duo media and SD cards (UHS-I compatible)

[Input/output terminals]

USB Type-C terminal:

SuperSpeed USB (USB 3.1 Gen 1)

Multi/Micro USB Terminal*:

Hi-Speed USB (USB 2.0)

* Supports Micro USB compatible

devices.

HDMI: HDMI type D micro jack  (Microphone) terminal:

3.5mm Stereo mini jack

 (Headphones) terminal:

3.5mm Stereo mini jack

[General]

Model No. WW541200 Rated input: 7.2V Operating temperature:

0 to 40°C (32 to 104°F)

Storage temperature:

–20 to 55°C (–4 to 131°F)

Dimensions (W/H/D) (Approx.):

126.9 × 95.6 × 73.7mm

126.9 × 95.6 × 62.7mm (from grip to monitor) 5 × 37/8 × 3in. 5 × 37/8 × 21/2in. (from grip to monitor)

Mass (CIPA compliant) (Approx.):

650g (1lb 7.0oz) (including battery pack, SD card)

[Wireless LAN]

Supported format: IEEE802.11b/g/n Frequency band: 2.4GHz Security: WEP/WPA-PSK/WPA2-PSK Connection method:

Wi-Fi Protected Setup™ (WPS)/ Manual

Access method: Infrastructure mode

[NFC]

Tag type: NFC Forum Type 3 Tag

compliant

[Bluetooth communications]

Bluetooth standard Ver. 4.1 Frequency band: 2.4GHz

AC Adaptor AC-UUD12/AC-UUE12

Rated input:

100- 240V

Rated output: 5V

, 3.2W

, 50/60Hz, 0.2A

, 1.5A

Rechargeable battery pack NP-FZ100

Rated voltage: 7.2V

Lens FE 28-70 mm F3.5-5.6 OSS (Supplied with ILCE-7M3K)

Focal length: 28mm – 70mm Lens groups–elements: 8–9 Angle of view: 75° – 34° Minimum focus*: 0.3m – 0.45m

(0.99ft. – 1.48ft.)

* Minimum focus is the shortest

distance from the image sensor to

the subject. Maximum magnification: 0.19× Minimum f-stop: f/22 – f/36 Filter diameter: 55mm Dimensions (max. diameter × height):

Approx. 72.5mm × 83mm (Approx. 27/8inches ×

33/8inches) Mass: Approx. 295g (Approx. 10.5oz.) SteadyShot: Available

Design and specifications are subject to change without notice.

On image data compatibility

• This camera conforms with DCF (Design rule for Camera File system) universal standard established by JEITA (Japan Electronics and Information Technology Industries Association).

• Playback of images recorded with your camera on other equipment and playback of images recorded or edited with other equipment on your camera are not guaranteed.

Trademarks

• Memory Stick and are trademarks or registered trademarks of Sony Corporation.

• XAVC S and trademarks of Sony Corporation.

• “AVCHD” and the “AVCHD” logotype are trademarks of Panasonic Corporation and Sony Corporation.

• Mac is a trademark of Apple Inc., registered in the United States and other countries.

• IOS is a registered trademark or trademark of Cisco Systems, Inc.

• iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries.

• Blu-ray Disc™ and Blu-ray™ are trademarks of the Blu-ray Disc Association.

• DLNA and DLNA CERTIFIED are trademarks of Digital Living Network Alliance.

• USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum.

• USB-IF SuperSpeed USB Trident logo is a registered trademark of USB Implementers Forum, Inc.

• Dolby, Dolby Audio and double-D symbol are trademarks of Dolby Laboratories.

• The terms HDMI and HDMI HighDefinition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.

are registered

• Microsoft and Windows are registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

• SDXC logo is a trademark of SD-3C, LLC.

• Facebook and the “f” logo are trademarks or registered trademarks of Facebook, Inc.

• Android and Google Play are trademarks or registered trademarks of Google Inc.

• YouTube and the YouTube logo are trademarks or registered trademarks of Google Inc.

• Wi-Fi, the Wi-Fi logo and Wi-Fi Protected Setup are registered trademarks or trademarks of the Wi-Fi Alliance.

• The N Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries.

• The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license.

• QR code is a trademark of Denso Wave Inc.

• In addition, system and product names used in this manual are, in general, trademarks or registered trademarks of their respective developers or manufacturers. However, the not be used in all cases in this manual.

or  marks may



On GNU GPL/LGPL applied software

The software that is eligible for the following GNU General Public License (hereinafter referred to as “GPL”) or GNU Lesser General Public License (hereinafter referred to as “LGPL”) are included in the product. This informs you that you have a right to have access to, modify, and redistribute source code for these software programs under the conditions of the supplied GPL/LGPL. Source code is provided on the web. Use the following URL to download it. http://oss.sony.net/Products/Linux/ We would prefer you do not contact us about the contents of source code.

Licenses (in English) are recorded in the internal memory of your product. Establish a Mass Storage connection between the product and a computer to read licenses in the “PMHOME” “LICENSE” folder.

Additional information on this product and answers to frequently asked questions can be found at our Customer Support Website.

Français

Consultez le Guide d’aide!

Le «Guide d’aide» est un mode d’emploi en ligne que vous pouvez lire sur votre ordinateur ou smartphone. Consultezle pour en savoir plus sur les éléments du menu, l’utilisation avancée et les plus récentes informations sur l’appareil.

Scannez ici

http://rd1.sony.net/help/ilc/1720/h_zz/

ILCE-7M3 Guide d’aide

Mode d’emploi

(ce livret)

Ce mode d’emploi présente certaines fonctions de base.

Voir «Guide de démarrage» (page23) pour le guide de démarrage rapide. Le «Guide de démarrage» présente les procédures initiales depuis le moment où vous déballez le produit jusqu’au moment où vous déclenchez l’obturateur pour la première prise de vue.

Guide intégr. à l'app.

Le [Guide intégr. à l'app.] donne des explications des éléments du menu sur l’écran de l’appareil.

Vous pouvez facilement obtenir des informations pendant la prise de vue. Pour utiliser la fonction [Guideintégr. à l’app.], certains réglages doivent être effectués au préalable. Pour en savoir plus, recherchez «Guide intégr. à l’app.» dans le Guide d’aide.

Remarques sur l’utilisation de votre appareil

Voir également «Précautions» dans le Guide d’aide (page2) en plus de cette section.

Langue à l’écran

Vous pouvez sélectionner la langue affichée à l’écran à l’aide du menu (page73).

Remarques sur la manipulation du produit

• Cet appareil est conçu pour résister à la poussière et à l’humidité, mais il n’est étanche ni à l’eau ni à la poussière.

• Lorsque vous utilisez l’objectif zoom motorisé, faites attention à ce que rien ne se fasse coincer dans l’objectif, y compris vos doigts.

• Mettez toujours en place le capuchon avant de l’objectif ou le capuchon de boîtier lorsque vous n’utilisez pas l’appareil. Afin d’éviter que de la poussière ou des corps étrangers ne pénètrent dans l’appareil, retirez la poussière du capuchon de boîtier avant de le fixer à l’appareil.

• Ne laissez pas l’objectif ou le viseur exposés à une source de lumière intense, comme les rayons du soleil. En raison de la fonction de condensation de l’objectif, cela pourrait provoquer un dégagement de fumée, un incendie ou un dysfonctionnement à l’intérieur du boîtier de l’appareil ou de l’objectif. Si vous devez laisser l’appareil exposé à une source de lumière comme les rayons du soleil, fixez le capuchon d’objectif sur l’objectif.

• Lorsque vous photographiez en contre-éclairage, maintenez le soleil suffisamment loin de l’angle de champ. Autrement, les rayons du soleil peuvent pénétrer le foyer à l’intérieur de l’appareil et provoquer un dégagement de fumée ou un incendie. Même si le soleil est légèrement éloigné de l’angle de champ, il peut toujours provoquer un dégagement de fumée ou un incendie.

• N’exposez pas directement l’objectif à des rayons tels que les faisceaux laser. Vous risquez d’endommager le capteur d’image et de provoquer un dysfonctionnement de l’appareil.

• Ne regardez pas le soleil ou une source de lumière intense à travers l’objectif après l’avoir retiré de l’appareil. Vous risquez des blessures oculaires irréversibles et de provoquer un dysfonctionnement.

• Ne laissez pas l’appareil, les accessoires fournis ou les cartes mémoire à la portée des jeunes enfants. Ils pourraient être avalés accidentellement. Le cas échéant, consultez immédiatement un médecin.

Remarques sur l’écran et le viseur électronique

• La fabrication de l’écran et du viseur électronique fait appel à une technologie de très haute précision, et plus de 99,99% des pixels sont opérationnels pour une utilisation effective. Quelques petits points noirs et/ou lumineux (de couleur blanche, rouge, bleue ou verte) peuvent toutefois être visibles en permanence sur l’écran et le viseur électronique. Ces imperfections sont inhérentes au procédé de fabrication et n’affectent aucunement les images enregistrées.

• L’image peut être légèrement déformée près des coins du viseur. Il ne s’agit pas d’une anomalie. Vous pouvez aussi utiliser l’écran pour observer en détail la totalité de la composition.

• Si vous faites un panorama avec l’appareil tout en regardant dans le viseur ou bougez vos yeux tout autour, l’image dans le viseur peut être déformée ou les couleurs de l’image peuvent changer. Il s’agit d’une caractéristique de l’objectif ou du dispositif d’affichage et pas d’une anomalie. Lorsque vous photographiez une image, nous vous recommandons de regarder au centre du viseur.

• Lorsque vous effectuez des prises de vue en utilisant le viseur, il se peut que vous présentiez les symptômes suivants : fatigue visuelle, fatigue, mal des transports ou nausée. Nous vous recommandons de faire des pauses régulières lorsque vous effectuez des prises de vue en utilisant le viseur. Si vous ressentez une gêne, évitez d’utiliser le viseur jusqu’à ce que vous alliez mieux, et consultez votre médecin si nécessaire.

• Si l’écran ou le viseur électronique est endommagé, cessez immédiatement d’utiliser l’appareil photo. Les pièces endommagées peuvent blesser vos mains, votre visage, etc.

Remarques sur la prise de vue en continu

Pendant la prise de vue en continu, l’écran ou le viseur peuvent clignoter entre l’écran de prise de vue et un écran noir. Si vous continuez à regarder l’écran dans cette situation, vous pourriez ressentir des symptômes désagréables comme un malaise. Si vous ressentez des symptômes désagréables, arrêtez d’utiliser l’appareil photo et consultez un médecin si nécessaire.

Remarques sur l’enregistrement prolongé et sur l’enregistrement de films 4K

• Selon la température de l’appareil et de la batterie, il se peut que vous n’arriviez pas à enregistrer des films ou que l’alimentation se coupe automatiquement afin de protéger l’appareil. Un message s’affiche sur l’écran avant que l’appareil se mette hors tension ou que vous ne puissiez plus enregistrer de film. Dans ce cas, laissez l’appareil hors tension et attendez que la température de l’appareil et de la batterie diminue. Si vous mettez l’appareil sous tension sans laisser l’appareil et la batterie refroidir suffisamment, il se peut que l’alimentation se coupe à nouveau ou que vous ne puissiez pas enregistrer de films.

• Lorsque la température de l’appareil augmente, la qualité de l’image peut se détériorer. Nous vous recommandons de patienter jusqu’à ce que la température de l’appareil diminue avant de poursuivre la prise de vue.

• À une température ambiante élevée, la température de l’appareil augmente rapidement.

• Le boîtier de l’appareil-photo et la batterie peuvent chauffer en cours d’utilisation. Cela est normal.

• Si une partie de votre peau est en contact prolongé avec l’appareil pendant que vous l’utilisez, et même si l’appareil ne vous semble pas chaud, vous risquez de présenter des symptômes de brûlures superficielles à basse température (rougeurs, cloques). Faites particulièrement attention dans les situations suivantes, et utilisez un trépied ou un autre dispositif adéquat:

–Lorsque vous utilisez l’appareil à

température ambiante élevée;

–Lorsqu’une personne souffrant

de troubles circulatoires ou d’une perte de sensibilité cutanée utilise l’appareil;

–Lorsque vous utilisez l’appareil

avec [Tmp HORS tens. aut.] réglé sur [Élevé].

• La durée d’enregistrement peut être réduite à basse température, en particulier pour les films 4K. Réchauffez la batterie ou remplacez-la par une batterie neuve.

Remarques sur l’enregistrement/ la lecture

• Avant de commencer à enregistrer, effectuez un essai afin de vous assurer que l’appareil fonctionne correctement.

• L’image enregistrée peut être différente de l’image contrôlée avant l’enregistrement.

• N’utilisez pas l’appareil à proximité d’une forte source d’ondes radioélectriques ou de radiations. L’enregistrement et la lecture pourraient en être affectés.

• Nous ne pouvons garantir la lecture sur d’autres équipements d’images enregistrées avec votre produit, pas plus que la lecture sur votre produit d’images enregistrées ou modifiées avec d’autres équipements.

• Sony ne saurait accorder de garanties dans le cas d’un échec de l’enregistrement ou de la perte ou de la détérioration d’images ou de données audio enregistrées dus à un dysfonctionnement de l’appareil ou du support d’enregistrement, etc. Nous vous recommandons d’effectuer une sauvegarde de vos données importantes.

• Le formatage de la carte mémoire supprime définitivement toutes les données enregistrées sur la carte mémoire, il est impossible de les restaurer. Copiez vos données sur un ordinateur ou un autre support de stockage avant de réaliser le formatage.

Remarques sur la griffe multiinterface

• Lorsque vous installez des accessoires, par exemple un flash externe, sur la griffe multi-interface et lorsque vous les retirez, mettez d’abord l’appareil hors tension (OFF). Lorsque vous installez l’accessoire, confirmez qu’il est solidement fixé à l’appareil.

• N’utilisez pas la griffe multiinterface avec un flash en vente dans le commerce appliquant des tensions de 250V ou plus ou ayant une polarité opposée à celle de l’appareil photo. Cela pourrait provoquer un dysfonctionnement.

Accessoires/Objectifs Sony

L'utilisation de cet appareil avec des produits d'autres fabricants risque de nuire à ses performances, entraînant des accidents ou des dysfonctionnements.

À propos des spécifications techniques décrites dans ce manuel

Les données indiquées pour les performances et les spécifications sont définies dans les conditions suivantes, sauf mention contraire dans ce manuel : à une température ambiante de 25 ºC (77 °F) et en utilisant une batterie complètement chargée (charge poursuivie jusqu’à extinction du témoin de charge).

Avertissement sur les droits d’auteur

Les émissions de télévision, films, cassettes vidéo et autres œuvres peuvent être protégés par des droits d’auteur. L’enregistrement non autorisé de telles œuvres peut constituer une infraction à la loi sur les droits d’auteur.

Remarques sur les informations sur l’emplacement

Si vous téléchargez et partagez une image marquée avec un emplacement, vous pourriez accidentellement révéler les informations à un tiers. Pour empêcher des tiers d’avoir accès à vos informations de géolocalisation,

Régl. liais. inf. empl] sur

réglez [ [OFF] avant d’effectuer les prises de vue.

Remarques sur la mise au rebut ou le transfert de ce produit à autrui

Lorsque vous mettez ce produit au rebut ou que vous le transférez à un tiers, veillez à réaliser les opérations suivantes afin de protéger vos données personnelles.

• Sélectionnez [Rétablir le réglage] 

[Initialiser].

Remarques sur la mise au rebut ou le transfert d’une carte mémoire à autrui

L’exécution de la fonction [Formater] ou [Supprimer] sur l’appareil ou un ordinateur risque de ne pas supprimer complètement les données de la carte mémoire. Lorsque vous transférez une carte mémoire à une autre personne, nous vous recommandons de supprimer complètement les données à l’aide d’un logiciel de suppression de données. Lorsque vous mettez une carte mémoire au rebut, nous vous recommandons de la détruire physiquement.

À propos des réseaux locaux sans fil

Si votre appareil est perdu ou volé, Sony n’assume aucune responsabilité quant à la perte ou au préjudice causés par l’accès ou l’utilisation illicites du point d’accès enregistré sur l’appareil.

Remarques relatives à la sécurité lors de l’utilisation d’un réseau local sans fil

• Assurez-vous toujours que vous utilisez un réseau local sans fil sécurisé afin de vous protéger contre tout piratage, accès par des tiers malveillants ou autres vulnérabilités.

• Il est important de régler les paramètres de sécurité lorsque vous utilisez un réseau local sans fil.

• Sony ne saurait être tenu responsable des pertes ou dommages causés par un problème de sécurité en l’absence de précautions de sécurité ou en cas de circonstances inévitables lorsque vous utilisez un réseau local sans fil.

Comment désactiver provisoirement les fonctions réseau sans fil (Wi-Fi, etc.)

Lorsque vous montez à bord d’un avion ou autre, vous pouvez désactiver provisoirement toutes les fonctions réseau sans fil au moyen de [Mode avion].

Cordon d’alimentation

Pour les clients au Royaume-Uni, en Irlande, à Malte, à Chypre et en Arabie saoudite Utilisez le cordon d’alimentation (A). Pour des raisons de sécurité, le cordon d’alimentation (B) ne doit pas être utilisé dans les pays/régions, pour lesquels il n’est pas conçu. Pour les clients dans les autres pays/ régions de l’UE Utilisez le cordon d’alimentation (B).

(A) (B)

Remarques sur ce manuel

Ce manuel couvre plusieurs modèles fournis avec différents objectifs. Le nom du modèle varie selon l’objectif fourni. Le modèle disponible varie selon les pays/régions.

Nom du modèle

ILCE-7M3 Non fourni ILCE-7M3K FE 28-70 mm F3.5-5.6 OSS

Objectif

Pour en savoir plus sur les fonctions Wi-Fi et les fonctions par simple contact NFC, reportez-vous au «Guide d’aide» (page 2).

Préparatifs pour la prise de vue

Vérification de l’appareil et des éléments fournis

Commencez par vérifier le nom du modèle de votre appareil photo (page8). Les accessoires fournis diffèrent selon le modèle. Le nombre indiqué entre parenthèses correspond au nombre d’éléments fournis.

Fourni avec tous les modèles

• Appareil photo (1)

• Adaptateur secteur (1)

La forme de l’adaptateur secteur peut varier selon le pays/la région.

• Cordon d’alimentation (1)*

(fourni dans certains pays/ régions)

* Plusieurs cordons d’alimentation

peuvent être fournis avec l’appareil photo. Utilisez le cordon approprié qui correspond à votre pays ou région. Voir page8.

• Batterie rechargeable NP-FZ100

(1)

• Câble micro-USB (1)

• Bandoulière (1)

• Capuchon de boîtier (1) (fixé à

l’appareil photo)

• Capuchon de la griffe (1) (fixé à

l’appareil photo)

• Oculaire de visée (1) (fixé à

l’appareil photo)

• Mode d’emploi (1) (le présent

manuel)

• Guide de référence (1)

ILCE-7M3K

• Objectif zoom FE 28-70 mm

F3.5-5.6 OSS (1) (y compris un capuchon d’objectif avant et un capuchon d’objectif arrière)

• Pare-soleil (1)

Identification des pièces

Voir les pages entre parenthèses pour en savoir plus.

Avant



Interrupteur ON/OFF

(Alimentation) (29)/ Déclencheur (31)



Sélecteur avant

Vous pouvez rapidement ajuster les réglages pour chaque mode de prise de vue.



Capteur à distance



Bouton de déverrouillage de

l’objectif (28)



Antenne Wi-Fi/Bluetooth

(intégrée) (51)



Microphone

Ne couvrez pas cette pièce pendant l’enregistrement de films. Sinon, cela risque de se traduire par du bruit ou par une baisse du volume sonore.



Illuminateur AF (61)/Témoin

de retardateur

Lorsque l’objectif est retiré



Repère de montage (27)



Capteur d’image*



Monture



Contacts de l’objectif*

* Ne touchez pas directement ces

pièces.

Sony Alpha A7 Mark III User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

English

Français
