SHB 3078 KARIfiTIRICI
EN
1
2
3
4
6
7
8
10
9
5
11
- 1 -
Children being supervised not to play with the appliance.
This appliance is not intended for use by persons (including children) with reduced physical,sensory
or mental capabilities, or lack of experience and knowledge, unless they havebeen given supervision
or instruction concerning use of the appliances by a personresponsible for their safety. Children
should be supervised to ensure that they do not play with the appliance.
- 2 -
ENGLISH
SINBO SHB 3078 HAND BLENDER
INSTRUCTION MANUAL
Please read this manual thoroughly before operating this unit!
IMPORTANT SAFETY INSTRUCTION:
Please follow all the precautions listed below for safety and to reduce the risk of fire, injury or electrical
shock.
1)
Read all instructions carefully before using your blender and keep them for future reference.
2) Unplug the appliance from the mains supply when not in use, when removing or attaching accessories,
or before cleaning any part of the appliance.
3) This appliance is for occasional household use only.
4) Do not immerse the Motor Unit or the electrical cord or plug in any liquids.
5) Do not use outdoors or in damp conditions.
6) Do not use near a source of heat or on an unstable surface. Ensure that the power cord does not
touch any hot surface and that it does not overhang the edge of your work surface.
7) When unplugging the power cord, hold the plug top, not the power cord.
8) Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or
is dropped or damaged in any manner. Return the appliance to the nearest authorized service facility
for examination, repair or electrical or mechanical adjustment.
9) Do not use attachments or accessories which are not recommended by the manufacture. They may
cause malfunction or injury.
10) Do not attempt to replace the power cord on this appliance. This should only be carried out by
authorized service personnel with specialist tools.
11) Store the appliance away from direct sunlight and out of the reach of children.
12) There are no user serviceable parts in your appliance Unauthorized dismantling or servicing will
void the product warranty.
13) This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
14) Children should be supervised to ensure that they do not play with the appliance.
There is a protective device against super high temperature, when the temperature is too high, the
power will be shut down automatically, and will run again automatically when the motor is cool. (It
takes about 15 minutes).
WHEN OPERATING YOUR BLENDER:
1) When the blender is not in use make sure that it is safely unplugged from the mains supply.
2) To reduce the risk of injury, never operate the blender unless the blade is immersed in liquid within
a properly sited receptacle.
3) When using the blender ensure there is adequate room in the vessel to avoid splashing the contents.
4) After each operation, allow the blender to cool for 3 minutes before using it again.
5) The blade on this blender is sharp. Treat it with care a all times and never allow fingers, hair, or
clothing to come into contact with the blade.
6) If you wish to scrape the contents of a bowl with a spatula, remove the blender first.
7) Do not use the blender with hot liquids.
8) If the blade gets clogged, switch off, unplug from the mains and allow the unit to stop before clearing
the obstruction.
9) Make sure the blow is on a sturdy work surface. If the bowl is not heavy enough, hold it or support
it properly.
10) Do not yank or pull the cord as this may damage it and eventually cause a risk of electric shock.
11) To protect against fire, do not operate the unit in the presence of explosive and / or flammable
- 7 -
fumes.
12) Keep the blender out of the reach of children.
NOTE: Never process very hot liquids. This is dangerous. DANGER OF SCALDING!
ELECTRICAL INFORMATION
Before using this appliance ensure that the voltage of your electricity supply is the same as that indicated
on the rating plate of the appliance.
WARNING: If the mains power cord is damaged in any way it must be replaced by a qualified technician.
SPECIFICTIONS
Model: SHB3078 (Hand blender Set)
Power: AC230V, 50Hz, 750W
Recommended Duty Cycle:
1 minute ON; 1 minute OFF for Stick Blender & Whisk functions.
15 seconds ON; 15 seconds OFF for Processor Bowl related functions.
KNOW YOUR HAND BLENDER (page 1)
This Hand Blender is designed to blend the vegetable or fruit with liquid, and to chop the meat, and to
slice /shred the carrot etc. and to beating the egg white. and have adjustable speed and turbo speed
for selecting.
1. Main Unit, 2. Adjustable Knob, 3. Speed Button, 4. Turbo Button, 5. Stick Blender, 6. Chopping Blade
7. Shredding Blade, 8. Slicing Blade, 9. Processor Cup, 10. Whisk, 11. Blending Cup
HOW TO USE YOUR HAND BLENDER
1. How to use the Stick Blender:
- Cut the vegetable or fruit into smaller cubes (about 2x2x2cm max), and add these cubes with suitable
amount of liquid (water, juice, milk etc.) into blending cup.
- Assemble the Stick Blender onto Main-unit according to the marks properly.
Main Unit
Stick-Blender
- Connect the appliance into power source.
- Place the Stick-Blender into the food, and press the ON/OFF-button or Turbo-button, the appliance
will start working. Speeds could be adjusted by dialing the Adjustable-Knob under “Speed-Control”
mode, and will reach the maximum speed once Turbo-Button is pressed.
Warning: While operating sticker blender, do not run this appliance continuously more than 1min per
cycle. Do not put stick knife, metal spoons, fork etc. into blending-cup when operating.
2. How to use the shredding/slicing blade.
- Assemble the Shredding/Slicing blade onto The Disc-bracket.
- Put the Disc-bracket in the Cup, and then assemble the cup-cover.
- Assemble the Main unit according to marks properly.
- Connect the appliance into power source.
- Press the Speed-control or Turbo-button, the appliance will start working.
- Push the food (carrot etc.) through feeding chute with the provided pusher
- 8 -
Warning: While operating shredding or slicing blade, do not run this appliance continuously more than
15secs per cycle.
1. Slicing / Shredding
2. Disc Bracket
3. Main Unit
4. Cup Cover
5. Cup
6. Food Pusher
3. How to use the Chopping blade:
- Put the chopping blade into the bowl.
- Cut the meat into smaller cubes (about 3x3x3cm max), and put the meat into bowl and assemble the
cover.
- Assemble the Main unit according to marks properly.
- Connect the appliance into power source.
- Press the Speed- control or Turbo-button, the appliance will start working.
Warning: While operating chopping blade, do not run this appliance continuously more than 15secs per
cycle.
1
2
3
4
5
6
1
1. Chopping Blade
2. Meat
4. How to use the Whisk.
- Place the egg white into the Blending cup.
- Assemble whisk into Main-unit by pressing, it is installed properly by hearing a click sound.
- Connect the appliance into power source.
- Press the Speed-button or Turbo-button, the appliance will start working.
Warning: While operating Whisk, do not run this appliance continuously more than 1 min per cycle.
NOTE: When operating the appliance, make sure that there is slack in the power cord. Never operate
2
- 9 -
the appliance in a location where the power cord can get snagged on kitchen units, or appliances or
utensils. The power cord should lie outside your operating hand.
AFTER USE
Switch the main unit OFF, lift the main unit out of the mixture and switch off at the mains before
unplugging the unit. Change speed to lowest as a safety measure. Unplug the appliance. Remove the
attached accessories.
Cleaning and Maintenance
1. When cleaning the motor unit, if the motor is warm, allow it to cool down first. Wipe the outer surface
of the motor unit with a damp cloth. Never use abrasive cleaner or scouting creams. Never immerse
the motor unit in water. Wipe any excess food particles from the power cord. Dry all components
thoroughly.
2. Wash the blender stem under running water, without the use of abrasive cleaners or detergents.
3. Do not use a pointed or sharp object to remove items of food lodged in the blade bush any debris out
with a plastic brush.
4. Do not immerse the stem in water because over time the lubrication on the bearings will deteriorate.
5. After cleaning the blender stem, place it upright to drain.
6. Blades are very sharp, handle with care. When all components are dry, reassemble the blender.
7. After cleaning, coil the cable loosely around the motor unit, and stow the blender out of direct sunlight
and out of the reach of children.
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working electrical equipments to
an appropriate waste disposal center
Made in China
- 10 -
- GARANT‹ fiARTLARI -
1) Garanti süresi,mal›n teslim tarihinden itibaren bafllar ve 2 y›ld›r.
2)
Mal›n bütün parçalar› dahil olmak üzere tamam› Firmam›z›n garanti kapsam›ndad›r.
3) Mal›n garanti süresi içerisinde ar›zalanmas› durumunda, tamirde geçen süre garanti
süresine eklenir. Mal›n tamir süresi, 20 iflgününü geçemez. Bu süre mala iliflkin ar›zan›n
servis istasyonuna, servis istasyonunun olmamas› durumunda, mal›n sat›c›s›, bayii,
acentesi, temsilcili¤i, ithalatç›s› veya imalatç›s›-üreticisinden birine bildirim tarihinden
itibaren bafllar. Tüketicinin ar›za bildirimini; telefon, faks, e-posta, iadeli taahhütlü mektup
veya benzeri bir yolla yapmas› mümkündür. Ancak, uyuflmazl›k halinde ispat yükümlülü¤ü
tüketiciye aittir. Mal›n ar›zas›n›n 10 ifl günü içerisinde giderilememesi halinde, imalatç›üretici veya ithalatç›; mal›n tamiri tamamlan›ncaya kadar, benzer özelliklere sahip baflka
bir mal› tüketicinin kullan›m›na tahsis etmek zorundad›r.
4) Mal›n garanti süresi içerisinde gerek malzeme ve iflçilik, gerekse montaj hatalar›ndan
dolay› ar›zalanmas› halinde, iflçilik masraf›, de¤ifltirilen parça bedeli ya da baflka herhangi
bir ad alt›nda hiçbir ücret talep etmeksizin tamiri yap›lacakt›r.
5) Tüketicinin onar›m hakk›n› kullanmas›na ra¤men mal›n;
• Tüketiciye teslim edildi¤i tarihten itibaren, garanti süresi içinde kalmak kayd›yla, bir y›l
içerisinde en az dört defa veya imalatç›-üretici ve/veya ithalatç› taraf›ndan belirlenen
garanti süresi içerisinde alt› defa ar›zalanmas›n›n yan› s›ra, bu ar›zalar›n maldan
yararlanamamay› sürekli k›lmas›,
• Tamiri için gereken azami süresinin afl›lmas› ,
• Firman›n servis istasyonunun, servis istasyonunun mevcut olmamas› halinde s›rayla
sat›c›s›, bayii, acentesi temsilcili¤i ithalatç›s› veya imalatç›-üreticisinden birisinin
düzenleyece¤i raporla ar›zan›n tamirini mümkün bulunmad›¤›n›n belirlenmesi, durumlar›nda
tüketici mal›n ücretsiz de¤ifltirilmesini, bedel iadesi veya ay›p oranda bedel indirimi talep
edebilir.
6 ) Mal›n kullanma k›lavuzunda yer alan hususlara ayk›r› kullan›lmas›ndan kaynaklanan
ar›zalar garanti kapsam› d›fl›ndad›r.
7 ) Garanti Belgesi ile ilgili olarak ç›kabilecek sorunlar için Gümrük ve Ticaret Bakanl›¤›
Tüketicinin Korunmas› ve Piyasa Gözetimi Genel Müdürlü¤ü’ne baflvurabilir.
‹THALATÇI F‹RMA
DE‹MA ELEKTROMEKAN‹K ÜRÜNLER ‹NfiAAT SPOR MALZEMELER‹ ‹MALAT SAN. VE T‹C. A.fi.
Cihangir Mh. Güvercin Cd. No:4 Haramidere Mevkii Avcılar - ‹stanbul - Türkiye
Ça¤rı Merkezi: 444 66 86
www.sinbo.com.tr - info@sinbo.com.tr
- 47 -
- SHB 3078 KARIfiTIRICI -
- GARANT‹ BELGES‹ -
Garanti Belge No : 105029
SSHY Belge No : 35274
‹THALATÇI F‹RMA
Ünvanı : DE‹MA ELEKTROMEKAN‹K ÜRÜNLER‹ ‹Nfi. SPOR MALZ.
‹MALAT SAN. ve T‹C. A.fi.
Adresi : Cihangir Mah. Güvercin Cad. No:4 Haramidere Mevkii
Avc›lar / ‹STANBUL
Tel. : Ça¤rı Merkezi: 444 66 86
Yetkili Kifli :
Yönetim Kurulu Baflkan›
Ürünün Cinsi : KARIfiTIRICI
Markası : S‹NBO
Modeli : SHB 3078
Alt Modeli : Bandrol ve Seri No :
Teslim Tarihi ve Yeri :
Garanti Süresi : 2 Yıldır
Azami Tamir Süresi : 20 ‹fl Günü
Kullanım Ömrü : Bakanl›kça belirlenen ve ilan edilen kullan›m ömrü 7 y›ld›r.
(Ürünün fonksiyonlar›n› yerine getirebilmesi için gereken yedek parça temin süresi)
SATICI F‹RMA
Ünvanı :
Adresi :
Tel.Fax :
Fatura Tarihi ve No :
Teslim Tarihi ve Yeri :
‹mza ve Kafle :
Bu bölüm, ürünü sat›n ald›¤›n›z Yetkili Sat›c› taraf›ndan imzalanacak ve kaflelenecektir.
Bu belgenin kullan›lmas›na; 4077 say›l› Tüketicinin Korunması Hakkında Kanun ve bu Kanun’a dayan›larak yürürlü¤e konulan Garanti Belgesi
Uygulama Esaslar›na Dair Yönetmelik uyar›nca, TC Gümrük ve Ticaret Bakanlı¤ı, Tüketicinin Korunması ve Piyasa Gözetimi Genel Müdürlü¤ü
tarafından izin verilmifltir.
Garanti Belge Onay Tarihi : 07/09/2011
Garanti Belge Vize Tarihi : 23/08/2013
SSHY Belge Onay Tarihi : 04/04/2012
- 48 -
MÜfiTER‹ H‹ZMETLER‹
De¤erli Müflterimiz,
En uygun fiyata en iyi ürünü vermenin yan› s›ra; en iyi hizmeti vermenin de
önemli oldu¤una inan›yoruz. Bu nedenle siz bilinçli tüketicilere daha yak›n
olabilmek için, internet adresimizdeki eriflim formlar›n›n yan› s›ra, tüketici
dan›flma hattımızı da hizmetinize açm›fl durumday›z.
TÜKET‹C‹
DANIfiMA HATTI
444 66 86
Tüketici Dan›flma Hattımızı,
- Hafta içi her gün 08.00-18.00 saatleri aras›nda arayabilir; istek, öneri ve
flikayetlerinizi firmam›za iletebilirsiniz.
Tüketicinin Dikkatine:
Ürünlerimizle ilgili hizmetleri tam olarak alabilmek için afla¤›daki önerilere
uyman›z› rica ederiz:
1. Ürünü ald›¤›n›zda Garanti Belgesini mutlaka yetkili sat›c›n›za onaylatt›r›n›z.
2. Ürünü kullanma k›lavuzunda belirtilen hususlara göre kullan›n›z.
3. Ürününüzle ilgili hizmet talebiniz oldu¤unda yukar›daki telefon
numaralar›ndan, Tüketici Danıflma Hattına baflvurunuz.
4. Ürünü promosyon arac›l›¤› ile edinmiflseniz, ürüne ait garanti belgesini en
yak›n yetkili servisimize giderek onaylatt›r›n›z.
5. Teknik servisteki ifliniz bitti¤inde "Yetkili Servis Hizmet Fifli" almay›
unutmay›n›z. Alaca¤›n›z bu Hizmet Fifli, ileride ürününüzde meydana
gelebilecek herhangi bir sorunda size yarar sa¤layacakt›r.
www.sinbo.com.tr
0800 211 50 21
KAPIDAN KAPIYA
ÜCRETS‹Z
SERV‹S
Kap›dan Kap›ya Ücretsiz Servis Kampanyam›z dâhilinde Yurtiçi Kargo Firmas› ile iflbirli¤i içerindeyiz. Tüketicimiz
taraf›ndan sat›n al›nan ürünün fiyat› ne olursa olsun, Tüketicimiz ürün ile ilgili garanti kapsam›na giren herhangi
bir problem yaflad›¤›nda, 444 66 86 numaral› Tüketici Danıflma Hattımızı aramas› ve kay›t b›rakmas› yeterlidir.
Bu süreçten sonra Tüketicimizin ürünü ücretsiz olarak Yurtiçi Kargo taraf›ndan Tüketicimizin bulundu¤u adresten
al›n›p, 7• ifl günü içerisinde ürün çal›fl›r bir vaziyette, yine Tüketicimize Yurtiçi Kargo arac›l›¤› ile adresine teslim
edilmektedir. 7 ifl günü içerisinde sorunu çözülemeyen ürünler ise, yenisi ve/veya bir üst modeli ile de¤ifltirilmektedir.
Tüm bu süreçte Tüketicilerimizden hiçbir ücret talep edilmemektedir.
(•Ürünün servis garanti süresi, Yurtiçi Kargo ürünü Sinbo Fabrikas›’na teslim ettikten sonra bafllar.)
- 49 -
7 GÜNDE
TESL‹MAT
GARANT‹S‹
(•)
- TEDAR‹KÇ‹ F‹RMA / EXPORTER United Favour Development Limited
Unit B, 10/F Lee May Building 788-790
Nathan Road, Mongkok, Kowloon, HK.
- UYGUNLUK BEYANI / CE Intertek Testing Services Shenzhen
Ltd. Guangzhou Branch
Block E, No.7-2 Guangdong Software
Science Park, Caipin Road, Guangzhou
Science City, GETDD Guangzhou, China
GZ12081442-1
EEE Yönetmeli¤ine uygundur.
AEEE Yönetmeli¤ine uygundur.
Made in P.R.C.
‹mal Y›l› : 2013
Loading...
