Before reading, unfold both pages containing illustrations and
familiarise yourself with all functions of the device.
Przed przeczytaniem proszę rozłożyć obie strony z ilustracjami,
a następnie proszę zapoznać się z wszystkimi funkcjami urządzenia.
Pred branjem obe strani s slikami odprite navzven in se nato
seznanite z vsemi funkcijami naprave.
Před čtením si odklopte obě dvě strany s obrázky a potom se
seznamte se všemi funkcemi přístroje.
Pred čítaním si odklopte obidve strany s obrázkami a potom sa
oboznámte so všetkými funkciami prístroja.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen
aus und machen Sie sich anschließend mit allen Funktionen des
Gerätes vertraut.
GB Operating instructions Page 5
PL Instrukcja obsługi Strona 35
SI Navodila za uporabo Stran 65
CZ Návod k obsluze Strana 93
SK Návod na obsluhu Strana 121
DE / AT / CH Bedienungsanleitung Seite 149
A
14923
5
6
78
1011
B
24
22
20
25
23
21
19
18
12
13
14
15
16
17
SET 12hr
(12/24)
SET 24hr
(12/24)SET hourSET minute
SET YearSET monthSET day
SET sleep
disable
C
DE
FG
Table of Contents
Introduction
Intended use ..................................................Page 7
Scope of delivery ..........................................Page 8
Description of parts .......................................Page 8
Technical data ...............................................Page 9
Safety
General safety instructions ...........................Page 11
The following pictograms are used in these
directions for use or on the device itself:
Read the directions for use!
Please observe the warning and
safety instructions!
Risk of explosion!
V
mA
2013-01
6 GB
Direct current (type of current and voltage)
Milliampere
Danger to life and danger of accidents
for infants and children!
Medical device type B
Year and month of manufacture
Dispose of the packaging and appliance
in an environmentally friendly way!
Introduction
Forehead & Ear Thermometer
Introduction
Congratulations on the purchase of your new
appliance. You have clearly decided in favour
of a quality product.
These operating instructions are a part of this product.
They contain important information in regard to safety,
use and disposal. Before starting the device up for the fi rst
time, familiarise yourself with its functions. Read the following directions for use. Please keep these instructions in a
safe place. When handing the device on to a third party,
hand all instructions on, too.
Intended use
The device is intended for use indoors for the measurement
of body temperature on the ear or temple / forehead, the
measurement of room temperature and the measurement
of surface temperatures in the household, as well as a
clock with stopwatch function. In no way does it replace
an examination by a qualifi ed doctor. This appliance is
solely intended for private use. Any use other than that
previously described or any change to the product is not
permitted and may lead to injuries and / or damage to the
product. The manufacturer does not assume any liability
for damage arising from improper use.
7 GB
Introduction
Scope of delivery
1 x Forehead and ear thermometer
(incl. battery and protective head guard
1 x Directions for use
Description of parts
“MEM / SET” button
1
(information retrieval from the memory etc.)
Measuring head
2
“EAR” button
3
(temperature measurement in the ear / scan mode)
“FOREHEAD” button
4
(temperature measurement on the forehead / temple)
LC display
5
LED red: fever 38.0 °C - 42.9 °C (100.4 °F - 109.2 °F)
6
LED orange: slight increase in temperature
7
37.5 °C - 37.9 °C (99.5 °F - 100.2 °F)
LED green: no fever 34.0 °C - 37.4 °C
8
(93.2 °F - 99.3 °F)
Protective head guard
9
Battery compartment lid
10
Battery
11
)
9
8 GB
Introduction
LC display
Battery change symbol
12
Year display symbol
13
Date display symbol
14
Ear mode symbol
15
Standard mode symbol
16
Scan mode symbol
17
Temperature display
18
Forehead mode symbol
19
Sleep mode symbol
20
Setup mode symbol
21
Memory mode symbol
22
PM / AM display
23
Month and hour in standard mode
24
Stopwatch mode symbol
25
Technical data
Measurement
method: Infrared (non-contact)
Electrical
power supply: Lithium battery 3 V
Power consumption: < 30 mA
Memory: 9 temperature measurements with
details of date, time and measurement
method (ear or forehead measurement)
CR2032
9 GB
Introduction
Temperature scale: °C (°Celsius)
°F (°Fahrenheit)
Time display: 12 / 24-hour format
Automatic switch-off : Automatic switch-off after 1 minute
Measurement range
forehead & ear mode: 32°C - 42.9°C (89.6°F - 109.2°F)
Measurement
accuracies: ± 0.2°C (± 0.4°F) in the range
(50.0 °F - 104.0 °F)
Forehead mode: +15.0 °C - +40.0 °C
(59.0 °F - 104.0 °F)
10 GB
Introduction / Safety
Storage temperature: –10.0 °C - +55.0 °C
(14.0°F - 131.0°F) at
20 % RH* - 85 % RH*
Atmospheric pressure: 700 ~ 1060 hPa
Dimensions: approx. 135 x 37 x 58 mm (L x B x H)
Weight: approx. 50 g
*RH = relative humidity
Safety
PLEASE KEEP ALL SAFETY INFORMATION
AND INSTRUCTIONS FOR FUTURE USE!
General safety instructions
children alone and unsupervised with the packaging
material. Danger of suff ocation. Children often
underestimate risks. Always keep children away
from the product.
DANGER TO LIFE! Batteries can be swallowed,
which may represent a danger to life. If a battery has
been swallowed, medical help is required immediately.
WARNING!
AND DANGER OF ACCIDENTS FOR
INFANTS AND CHILDREN! Never leave
DANGER TO LIFE
11 GB
Safety
This device is not designed to be used by people
(including children) with limited physical, sensory or
mental abilities or who lack the experience and / or
knowledge to use it, unless they are supervised by a
person responsible for safety or receive instructions
from such a person as to how the device should be
used. Children have to be supervised to ensure that
they do not play with the device.
Do not expose the device to
- extreme temperatures,
- strong vibrations,
- heavy mechanical loads,
- direct sunlight.
Otherwise there is a danger that the device will be
damaged.
Please note that the guarantee does not cover damage
caused by incorrect handling, non-compliance with the
operating instructions or interference with the device
by unauthorised individuals.
Under no circumstances should you take the device
apart. Improper repairs may place the user in considerable danger. Repairs should only be carried out by
specialist personnel.
Do not use the device if it is damaged. Otherwise
the consequence may be injuries and / or inaccurate
readings.
12 GB
Safety
Please consult a doctor if the thermometer indicates
that the body temperature measured is high. With this
measuring method, a fever is indicated if the temperature is above 38.0 °C (100.4 °F). The red LED
warning. Please take several measurements at intervals
of 0.5 to 1 hour in order to follow the progression of
the temperature. The values you measure will help
your doctor make a diagnosis.
Do not use the temperature under extreme temperature
conditions and / or outdoors. This will result in inaccurate
measuring results. Please observe the details regarding
ambient and storage temperatures (see “Technical data”).
The measurement sensor should not be touched directly
or be blown on. This will result in inaccurate measuring
results.
Mobile telephones should not be used in the immediate
vicinity when the thermometer is being used. Otherwise
the consequence may be inaccurate measurement
results.
Safety instructions
This appliance is solely intended for private use. That
is why it is not subject to mandatory verifi cation.
Discontinue using the appliance if it is damaged or if
you feel that the measured values are unrealistic. Consult the chapter “Functions/Error analysis - Troubleshooting” for advice or contact our service centre.
6
is a
13 GB
Safety
Safety Instructions
for the Battery
Remove the battery from the device if it is not going
to be used for a prolonged period.
Ensure correct polarity when inserting the battery!
This is indicated in the battery compartment.
If necessary, clean the battery and device contacts
before inserting the battery.
Batteries must not be disposed of in the normal
domestic waste!
Every consumer is legally obliged to dispose
of batteries in the proper manner!
CAUTION! RISK OF EXPLOSION!
the batteries and do not take them apart.
Avoid contact with the skin, eyes and mucous mem-
branes. Any parts of the body coming into contact with
battery acid should be rinsed off with copious amounts
of water and / or a doctor contacted if necessary!
Avoid contact with skin, eyes and mucous membranes.
Upon contact with battery acid, rinse the aff ected
area with lots of water and / or consult a doctor!
CAUTION! DANGER OF EXPLOSION!
The battery must never be recharged!
Keep batteries away from children; do not
throw batteries into a fi re; do not short-circuit
14 GB
Before getting started / Operation
Before getting started
Removing the battery fuse
Push the battery compartment lid 10 downwards.
Pull the tab of the protective fi lm out of the battery
compartment.
Push the battery compartment lid 10 onto the battery
compartment until it clicks into place (Fig. A).
– When it is switched on, an internal alignment and a
self-test of the LC display are carried out.
– To verify that all of the bars of the numbers are being
managed correctly, when you switch on check the
display of the LC display
against the example (Fig. B).
Operation
Setting the date / time (Fig. C)
You only have to set the date and time when you operate
the appliance for the fi rst time and after you change the
battery.
1. Press and hold the “MEM / SET” button
two seconds in standard mode. An acoustic signal
will sound. The device is now in set-up mode.
2. Press the “MEM / SET” button
the 12-hour or 24-hour format.
5
on your appliance
1
to choose between
1
down for
15 GB
Operation
3. Press the “FOREHEAD” button 4. The hours will fl ash
and can be corrected with the “MEM / SET” button
4. Press the “FOREHEAD” button
again. The minutes
4
will fl ash and can be corrected with the “MEM / SET”
button
.
1
Repeat steps 3 and 4 to set the values for the year,
month and day or to switch the sleep mode on or off .
Finally, press the “FOREHEAD” button 4. The settings
will be taken over and the appliance reverts to standard mode.
Temperature measurements
Measuring room temperature (standard mode)
When you have fi nished setting the time and date and do
not carry out any further procedures, the device switches
to sleep mode after 1 minute in order to save the battery.
In the condition as supplied to the customer the sleep
mode is activated, as shown by the
display
is completely switched off . When the sleep
5
symbol, and the LC
mode is deactivated, the device remains switched on,
while the time and room temperature are still shown and
updated once a minute. The LC display
shows
5
the time and date alternately (Illustration D).
1
.
Measuring body temperature (ear mode)
IMPORTANT! It is advisable to carry out 3 meas-
urements in a row on the same ear and to take the highest
temperature as the measured value. A new measurement
16 GB
Operation
can be taken when the display “” goes out.
Do not use the thermometer if pain occurs when the meas-
urement is being taken. This could damage the ear canal.
Do not use the thermometer with external ear disorders
(e.g. infl ammation of the ear canal, injuries to the outer
ear). The condition of the aff ected areas could worsen.
Do not use the thermometer straight after bathing or
swimming when the ear canal is wet. This could damage the ear canal.
Due to the risk of contamination of the measuring
head, clean the appliance after every use.
In this mode, only measure the temperature in the ear
and at no other place on the body.
1. If the sleep mode has been activated, activate the
thermometer again by pressing any button before
taking the measurement.
2. Carefully press on the protective cap
it with a gentle rotary motion and without using any
force.
3. Check that the measuring head
sensors are clean.
4. Carefully clean the ear canal with a cotton bud.
5. Pull the outer ear, tilted slightly upwards/to the rear,
towards the back of his head, so that the ear canal is
freely accessible and there are no impediments between the measurement sensor and the eardrum.
and remove
9
and the measuring
2
17 GB
Operation
6. Please keep the outer ear slightly extended and now
carefully insert the measuring head
7. Briefl y press the “EAR” button
appear in the LC display
5
will start after an acoustic signal.
8. The end of the measurement is indicated by means of
2 acoustic signals.
9. Now you can read off the measurement result on the
LC display
. At the same time, one of the 3 LEDs
5
will come on.
Note: LED green
: no fever 34.0 °C - 37.4 °C
8
(93.2 °F - 99.3 °F)
LED orange
: slight increase in temperature
7
37.5 °C - 37.9 °C (99.5 °F - 100.2 °F)
LED red
: fever 38.0 °C - 42.9 °C
6
(100.4 °F - 109.2 °F)
10. Values can be displayed in °C as well as in °F
(see “Functions / error analysis - selecting the
temperature unit”).
11. Wait until the display “
” goes out before you
start taking a new measurement.
Note: The appliance automatically switches off if it is not
operated for longer than 1 minute. When the sleep mode
has been activated, the LC display
When the sleep mode has been deactivated, the appliance
switches to standard mode. If the thermometer has been
operated under normal conditions, the result of the last
measurement taken before the appliance was switched off
into the ear canal.
2
. The symbol will
3
and the measurement
switches itself off .
5
18 GB
Operation
is stored. The measured value is available again along
with information on the date, time and measurement mode
when the “MEM / SET” button
device has 9 storage spaces (see section on “Functions /
error analysis - the memory function”).
Measuring the body temperature
(forehead mode)
IMPORTANT! It is advisable to carry out 3 meas-
urements in a row at the same place and to take the
highest temperature as the measured value.
With diff erent room temperatures, let the appliance
lie in the room where the temperature is to be taken
for at least 30 minutes to “acclimatise” it.
Before measuring your body temperature, you should
relax for about 5 minutes.
If you have done any physical activity or taken a
bath, wait for at least 30 minutes before taking a
measurement in order to get a measurement that is
as accurate as possible.
Ensure that the forehead or temple is clean, free of
injuries and not covered with sweat, cosmetics or
ointment.
Take a note of what measurement method you used to
measure the temperature and inform your doctor of it.
1. If the sleep mode has been activated, activate the
thermometer again by pressing any button before
taking the measurement.
is pressed again. The
1
19 GB
Operation
2. Carefully press on the protective cap 9 and remove
it with a gentle rotary motion and without using any
force.
3. Check that the measuring head
sensors are clean.
4. Hold the measuring sensor 1 cm away from the
forehead or temple.
5. To start the measurement, press on the “FOREHEAD”
button
5
. The symbol will appear in the LC display
4
and the measurement will start after an acoustic
signal.
6. The end of the measurement is indicated by 2 acoustic
signals.
7. Now you can read off the measurement result on the
LC display
. At the same time, one of the 3 LEDs
5
will come on.
Note: LED green
no fever 34.0 °C - 37.4 °C
8
(93.2 °F - 99.3 °F)
LED orange
slight increase in temperature
7
37.5 °C - 37.9 °C (99.5 °F - 100.2 °F)
LED red fever
38.0 °C - 42.9 °C
6
(100.4 °F - 109.2 °F)
8. Values can be displayed in °C as well as in °F
(see “Functions / error analysis - selecting the
temperature unit”).
9. Repeat steps 3 to 6 to carry out further measurements.
and the measuring
2
20 GB
Operation
Note: The appliance automatically switches off if it is not
operated for longer than 1 minute. When the sleep mode
has been activated, the LC display
When the sleep mode has been deactivated, the appliance
switches to standard mode. If the thermometer has been
operated under normal conditions, the result of the last
measurement taken before the appliance was switched off
is stored. The measured value is available again along
with information on the date, time and measurement mode
when the “MEM / SET” button
appliance has 9 storage spaces (see “Functions / error
analysis - the memory function”).
Use as a household thermometer (scan mode)
The thermometer can also be used in the house for
non-contact temperature measurements in the range of
–22.0 °C - 80.0 °C (–7.6 °F - 176.0 °F).
Attention! Do not use this mode for measuring
body temperature.
– With this measurement, the current surface temperature
of the object is displayed. It can be diff erent from its
internal temperature, especially if the surface is exposed
to direct sunlight or a draught!
Due to its design, the thermometer measures the precise
value when its casing has adjusted to room temperature.
That is why you should not hold it in the hand for a
long time when you want to take a measurement and
why you should keep it away from direct sunlight!
switches itself off .
5
is pressed again. The
1
21 GB
Operation
Do not use the appliance immediately after cleaning
the measuring head
of the detergent may falsify the measuring result.
Sample applications:
- The temperature of milk in baby bottles
- The temperature of bathwater
1. If the sleep mode has been activated, activate the
thermometer again by pressing any button before
taking a measurement.
2. Carefully press on the protective cap
it with a gentle rotary motion and without using any
force.
3. Make sure that the measuring head
measuring sensor are clean.
4. Press the “FOREHEAD” button
3
button
repeatedly at the same time until “Food”
is shown in the LC display
5. Hold the measuring head at a distance of 1 cm from
the liquid and / or surface whose temperature you
want to measure.
6. Press the “EAR” button
7. Now you can read off the measurement result on the
LC display
(Illustration E).
5
8. Values can be displayed in °C as well as in °F
(see “Functions / error analysis - selecting the
temperature unit”).
. The evaporative cooling eff ect
2
and remove
9
and the
2
4
and the “EAR”
5
(Illustration E).
to start the measurement.
3
22 GB
Operation
9. Press the “EAR” button 3 again to carry out further
measurements.
10. The appliance automatically switches off if it is not
operated for longer than 1 minute. This application is
not stored in the device.
In order to return to standard mode, proceed as follows:
1. Press the “FOREHEAD” button
3
button
display
repeatedly at the same time until the LC
5
again shows the room temperature, date
and time, as well as the
2. You are now back in standard mode.
Measuring time (stopwatch mode)
The integrated watch can be used as a stopwatch in the
range of 0.01 seconds to 3 minutes. This function is required
to calculate the pulse rate. The appliance has to be switched
over to stopwatch mode to do so.
1. If the sleep mode has been activated, activate the
thermometer again by pressing any button before
taking a measurement.
2. Press the “FOREHEAD” button
3
button
display
repeatedly at the same time until the LC
5
shows the symbol (Illustration F).
3. The stopwatch is started by pressing the “FOREHEAD”
button
and stopped by pressing it again.
4
4
and the “EAR”
symbol (Illustration D).
4
and the “EAR”
23 GB
Operation / Functions / error analysis
4. You can start a new measurement by pressing the
“MEM / SET” button
measured time.
In order to return to standard mode, proceed as follows:
1. Press the “FOREHEAD” button
3
button
display
repeatedly at the same time until the LC
5
again shows the room temperature, date
and time, as well as the
2. You are now in standard mode again.
Functions / error analysis
Selecting the temperature unit
Press and hold down the “EAR” button 3 and the
“FOREHEAD” button
appears behind the temperature display. Switching
from “°F” to “°C” is possible with the same procedure.
The memory function (memory mode)
IMPORTANT!
The current measurement is always stored in the last storage
space. When all storage spaces have been occupied, the
oldest measurement is always deleted from the memory.
to delete the previously
1
4
and the “EAR”
symbol (Illustration D).
4
at the same time until “°F”
24 GB
Functions / error analysis
Measurements taken in ear and forehead mode are
automatically stored in the appliance. The measured
values are available again along with information on the
date, time and measurement mode when the “MEM / SET”
button
SET” button
measurement. The “Memory” symbol (memory mode), the
number of the measurement, date, time and measurement
mode will appear in the LC display
the “MEM / SET” button
with its associated measured value will appear. A maximum
of 9 measurements can be stored.
In order to return to standard mode, proceed as follows:
1. Press the “FOREHEAD” button
2. You are now in standard mode again.
The appliance is fi tted with a lithium battery (CR2032,
3 V
the battery is empty, you will be made aware of that by
means of an appropriate error message (see “Functions /
error analysis - problem-solving”).
is operated in standard mode. Press the “MEM /
1
once to retrieve the value of the last
1
(Fig. G). By pressing
5
the next storage space along
1
4
and the “EAR”
3
button
display
and time, as well as the
repeatedly at the same time until the LC
5
again shows the room temperature, date
symbol (Illustration D).
Changing the battery
) that allows a lot of measurements to be taken. If
25 GB
Functions / error analysis
Push the battery compartment lid 10 downwards.
Lever the battery
Avoid short-circuiting the battery at all cost. A short-
circuit can occur if the screwdriver comes into contact
with the battery and the live parts in the battery
compartment at the same time.
Insert the new battery into the battery compartment.
Note: Ensure correct polarity. The plus sign on the
battery must point upwards.
Push the new battery under the metal nose and press
it down until it clicks into place.
Push the battery compartment lid 10 onto the battery
compartment until it clicks into place (Fig. A).
Problem-solving
If the appliance cannot take a measurement in the
designated range, it will generate an error message.
This message should help to solve the problem.
ErrorProblemSolution
Appliance
does not react / automatically resets
itself when
protective fi lm
is removed
out with a small screwdriver.
11
Empty battery?Insert a new
Wrong battery
polarity?
Faulty battery
contact?
battery
Removing bat-
tery and insert it
correctly
26 GB
Functions / error analysis
ErrorProblemSolution
Battery sym-
bol on the LC
display
5
“Lo” on the
LC display
(measured
value below
32.0°C or
89.6°F)
“Hi” on the
LC display
(measured
value above
42.9°C or
109.2°F)
“ErrE” on the
LC display
Weak batteryInsert a new
Thermometer
correctly posi-
5
tioned in the ear
or on the forehead/temple?
Check the measurement mode.
5
Ambient temperature outside the
5
range of 15.0 °C
- 40.0 °C /
59.0 °F -
104.0 °F (forehead mode) and
10.0 °C -
40.0 °C /50.0 °F
- 104.0 °F (ear
and scan mode).
battery
Pay heed to the
operating instructions in regard to positioning in the ear or
on the forehead/temple.
Please observe
the directions
for use with regard to taking
correct measurements.
Please ensure an
ambient temperature in the range
of 15.0 °C -
40.0 °C /
59.0 °F -
104.0 °F (forehead mode) and
10.0 °C -
40.0 °C/
50.0 °F -
104.0 °F (ear
and scan mode)
27 GB
Functions / error analysis / Cleaning and care
ErrorProblemSolution
“ErrU” on the
LC display
No measurement result after
5
measurement.
“ErrH” on the
LC display
“ErrP” in LC
display
5
Cleaning and care
Error detected
during self-test.
5
Hardware
problem
The lens in the opening of the measuring sensor is the most
sensitive part of the appliance.
Be very careful when you have to clean it. In order to avoid
contamination with germs, the lens has to be rubbed after
every use with a soft cloth that has been moistened with
70% medical alcohol. The use of hygiene attachments is,
therefore, not necessary. After that, wait for at least
30 minutes before taking another measurement. Please
keep in mind that due to the evaporative cooling eff ect of
the alcohol, even the smallest amounts can falsify the result.
Clean the housing with a soft, slightly damp cloth. In the
case of more severe soiling a mild detergent can also be
added to the water.
Please observe
the directions
for use with regard to taking
correct measurements.
Contact the
service centre.
Contact the
service centre.
28 GB
Cleaning and care / Guarantee and Service
Keep the appliance in a dry environment and protect from
direct sunlight. The appliance can be stored at temperatures
of –10.0 °C - 55.0 °C (14.0 °F - 131.0 °F). Temperatures
over 80.0 °C are to be avoided! In order to measure with
it, however, it is necessary to let the appliance adjust to
room temperature for a suffi cient length of time - otherwise
an error message will be generated (see “Functions / Fault
Analysis - Correction of Problems”). A room temperature of
5.0°C - 59.0°C (41.0°F - 138.2°F) should also be main-
tained for the purposes of measurement. If the temperature
is outside this range, an error message is shown (see
“Functions / Fault Analysis - Correction of Problems”).
Remove the battery when not using the appliance for any
length of time.
Guarantee and Service
This appliance is guaranteed for 3 years from
the date of purchase. It has been carefully
produced and meticulously checked before
delivery. Please keep your receipt as proof
of purchase. Contact your service centre by
telephone in case of questions pertaining to
the warranty. Your goods can be transmitted
free of cost only in this manner.
29 GB
Guarantee and Service
The warranty covers only material or manufacturing faults,
not normal wear or damage to fragile parts such as
switches or rechargeable batteries. The appliance is
intended solely for private, not commercial, use.
If this product has been subjected to improper or inappropriate handling, abuse, or interventions not carried out
by one of our authorised sales and service outlets, the
warranty will be considered void. This warranty does
not aff ect your statutory rights.
The guarantee period is not extended by the warranty.
This also applies to replaced and repaired parts. Any
damage or defects present when the device is purchased
must be reported immediately upon unpacking, and not
later than two days after the date of purchase. All repairs
required after the guarantee period has expired are
subject to a charge.
