MAMMOMAT 2/3
Service
Modification Instructions
Marking detector positions on compression plates
© Siemens AB 1999
The reproduction, transmission or
use of this document or its contents
is not permitted without express
written authority. Offenders will be
liable for damages. All rights,
including rights created by patent
grant or registration of a utility
model _or_ design,_are_ reserved.
English
Print No.: SPB7-211.092.01.02.02 Doc . Gen. Date: 09.99
Replaces: SPB7-211.092.01.01.02 65 27 183
0 - 2 Revision
Chapter Page Revision
All All 02
MAMMOMAT 2/3 SPB7-211.092.01 Page 2 of 4 Siemens-Elema AB
Service Rev. 02 09.99 SPS-UD Solna, Sweden
Contents 0 - 3
Page
1 _______Prerequisites __________________________________________________1 - 1
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 1
Required tools. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
Parts included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1 - 1
2 _______Procedures____________________________________________________2 - 1
Compression plates 18 x 24 and 24 x 30 . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
Siemens-Elema AB SPB7-211.092.01 Page 3 of 4 MAMMOMAT 2/3
Solna, Sweden Rev . 02 09.99 SPS-UD Service
0 - 4 Contents
Page
This page intentionally left blank.
MAMMOMAT 2/3 SPB7-211.092.01 Page 4 of 4 Siemens-Elema AB
Service Rev. 02 09.99 SPS-UD Solna, Sweden
Prerequisites 1
General 1
These instructions descri bes how to make mar kings of the det ecto r pos itio ns on c ompression plates on MAMMOMAT 2/3.
Required tools 1
Masking Tape
Parts included 1
The modification kit 64 83 668 contains the following parts:
Amount Part No Name
1 65 27 183 Modification Instructions (This document)
1 64 83 304 Stencil for 18 x 24 and 24 x 30
1 65 44 659 Marsh 88
1 - 1
Siemens-Elema AB SPB7-211.092.01 Page 1 of 2 Mammomat 2/3
Solna, Sweden Rev . 02 09.99 SPS-UD Service
1 - 2 Prerequisites
This page intentionally left blank.
Mammomat 2/3 SPB7-211.092.01 Page 2 of 2 Siemens-Elema AB
Service Rev. 02 09.99 SPS-UD Solna, Sweden
Procedures 2
NOTICE
NOTICE
NOTICE
Compression plates 18 x 24 and 24 x 30 2
1. Check for the compression plate alignment.
Make sure that chestwall side of compression plate does not
extend beyond the edge of the bucky table by more than 2 mm. If
the compression plate extend more than 2 mm from the edge of
the bucky table, the compression plate must be reinstalled or
replaced.
2. Place the stencil (Fig. 1) insi de the compression plate (Fig. 2).
18 x 24
2 - 1
24 x 30
Fig. 1 Fig. 2
MAM00526
Mam00550
3. Position the compression plate so that the bottom of the compression plate is
about 6 cm above the bucky table.
4. Using the object illuminator light , position the stencil so that t he flat side of the first
detector position at the chestwall side is aligned with the detector po sition on the
bucky table.
5. Raise or lower the position of compressi on plate using the foot pedal if necessar y.
6. Center the detector position by adjust ing the stencil right or left.
Make sure that the position of the image superimposed on the
bucky table does not change when the compression height is
changed.
7. Tape the stencil to the compression pl ate with masking tape.
Shake the marker before use. Make some test drawings to learn
how the marker works before using it on the compression plates.
To achieve a lasting result, repeat the trace pr ocedure a couple of
times.
Be careful not to smear.
8. Trace the stencil´s detector posi tions on to the compression plate by using a
permanent fine-tipped marker. Each compress ion plate requires two detector
positions only. See the arrows on th e stencil to determine the correct pos itions
according to the format size.
Siemens-Elema AB SPB7-211.092.01 Page 1 of 2 MAMMOMAT 2/3
Solna, Sweden Rev . 02 09.99 SPS-UD Service
2 - 2 Procedures
NOTICE
9. Remove the stencil.
Wait until the markings have dried in, before usi ng the compression plates.
10. Repeat step 1 - 9 above for all 18 x 24 and 24 x 30 compression plates.
11. Repeat the procedure when the markings have faded after a while .
MAMMOMAT 2/3 SPB7-211.092.01 Page 2 of 2 Siemens-Elema AB
Service Rev. 02 09.99 SPS-UD Solna, Sweden
