s
mobile
Issued by
Information and Communication mobile
Haidenauplatz 1
D-81667 Munich
© Siemens AG 2004
All rights reserved. Subject to availability.
Rights of modification reserved.
Siemens Aktiengesellschaft
www.siemens-mobile.com/a65
s
mobile
A65
Table of Contents 1
Legal notices ......................................2
Safety precautions ............................. 4
Phone overview ..................................5
Display symbols (selection) ................7
Getting started ...................................8
Using the SIM card/battery ...............8
Charging the battery ........................8
Switching on/off, PIN ..........................9
Enter PIN .........................................9
Strong reception signal ....................9
Emergency number (SOS) ..............10
Without a SIM card ........................10
General information ......................... 10
User guide .....................................10
Menu control .................................10
Standby mode ...............................10
Security ............................................10
Codes ............................................10
Clear SIM card barring ....................11
Making a phone call .........................11
Text entry .........................................12
Text entry without T9 ....................12
Text entry with T9 ..........................13
Predef. texts ..................................14
Phonebook .......................................14
<New entry> ..................................14
Call (search for an entry) ................ 14
Edit entry .......................................14
Assign picture ................................15
Groups ..........................................15
Call log ..............................................15
Durat/charges ...................................15
Camera ............................................. 16
Voicemail/CB services .......................16
SMS ...................................................17
MMS ................................................. 18
Message lists/
Message settings .............................19
Surf & fun ......................................... 19
Internet browser (WAP) ................. 19
Games & more .............................. 20
Setup ................................................ 21
Profiles .......................................... 21
Display .......................................... 21
Call setup ...................................... 22
Clock ............................................. 23
Connectivity .................................. 23
Security ......................................... 23
Network ........................................ 24
Accessories ................................... 24
Ringtones ......................................... 25
Extras ............................................... 25
Alarm clock ................................... 25
Calculator ...................................... 25
Stopwatch ..................................... 25
SIM services (optional) .................. 26
Fast access ....................................... 26
Own stuff ......................................... 26
Questions & Answers ....................... 27
Customer Care ................................. 30
Care and maintenance ..................... 31
Product data ..................................... 32
U.S. FDA ........................................... 33
FCC/Industry Canada Notice ............ 39
Ten driving safety tips ..................... 40
Intellectual property ........................ 42
Accessories ...................................... 43
SAR (A65) ......................................... 44
End user license agreement ............ 46
Menu tree ........................................ 51
Index ................................................ 55
See also Index at the end of this User Guide
Legal notices2
Legal notices
The mobile phone described in this guide is approved for use on the GSM and
GPRS networks operating on the GSM 900, 1800 (DCS/PCN) and 1900 (PCS)
bands. It is approved for use in the country where it was originally sold and
may be approved for use in other countries.
© 2004 Siemens Information and Communication Mobile, LLC.
All rights reserved.
Siemens and the A65 model phone
are trademarks or registered trademarks of Siemens AG and/or its affiliates in the United States and/or
other countries.
T9® is a registered trademark of
America Online, Inc. in the United
States. Java and all Java-based trademarks and logos are trademarks or
registered trademarks of Sun Microsystems, Inc. in the U.S and other
countries. The names of actual companies and products mentioned
herein may be the trademarks of
their respective owners.
Disclaimer
THE INFORMATION CONTAINED IN
THE USER GUIDE IS WRITTEN FOR
THE A65 PHONE. SIEMENS RESERVES
THE RIGHT TO MAKE CHANGES AND
IMPROVEMENTS TO THE PRODUCTS
AND ANY OF THE FEATURES OF THE
PRODUCTS DESCRIBED IN THIS DOCUMENT WITHOUT PRIOR NOTICE.
THE CONTENTS OF THE USER GUIDE
ARE PROVIDED "AS IS". EXCEPT AS
REQUIRED BY APPLICABLE LAW, NO
WARRANTIES OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION
TO THE ACCURACY, RELIABILITY OR
CONTENTS OF THIS DOCUMENT.
SIEMENS RESERVES THE RIGHT TO
REVISE THE USER GUIDE OR WITHDRAW IT AT ANY TIME WITHOUT
PRIOR NOTICE. UNDER NO CIRCUMSTANCES SHALL SIEMENS BE
RESPONSIBLE FOR ANY LOSS OF
DATA OR INCOME OR ANY SPECIAL,
INCIDENTAL, CONSEQUENTIAL OR
INDIRECT DAMAGES HOWSOEVER
CAUSED.
Export Information
The mobile phone may be subject to
export regulation of the United
States and other countries. Diversion
contrary to law is prohibited. You
must comply with all applicable
export laws, restrictions and regulations of the United States foreign
3Legal notices
agencies or authorities, and may not
export, or transfer for the purpose of
re-export, the mobile phone or any
part of the phone in violation of any
applicable restrictions, laws or regulations, or without all necessary
approvals.
Network Services
A number of features included in this
guide are called Network Services.
They are special services provided by
wireless service providers. In order
to use any of these Network Services, you must subscribe to these
service(s) from your service provider
and obtain instructions for their use.
Some of these Network Services may
not be available when roaming on a
network other than your home network.
Standby and
Talk Time Information
The mobile phone incorporates features that are new to the mobile
phone world. These may include
color displays and lighting, graphic
games, music reproduction and
browsing the Internet. The way you
use the display and the features will
affect the performance of the battery and how long it lasts between
charge cycles. The quoted standby
times and talk times show the minimum and maximum performance
that can be expected from the battery under normal network conditions and with the default settings as
set by the factory. However, playing
games (particularly with the backlight continuously switched on) and
listening to music will shorten the
time available for standby and to
make and receive telephone calls.
Operation times also vary depending
on network conditions, SIM settings,
charging and battery condition, how
you use your phone and other factors.
Memory
The mobile phone contains an internal memory device that stores the
software required to operate the
mobile phone, communicate with
the GSM/GPRS network and provide
the user interface. Some features in
the internal memory run additional
devices and some additional games
and utilities. The amount of memory
available in the mobile phone is
finite and may be insufficient to
store large numbers of applications
and files.
Warning!
Remember to back up your data and to do
so frequently. Always back up all data and
programs before sending the mobile phone
in for repair.
Safety precautions4
Safety precautions
Information for parents
Please read the operating instructions and safety precautions carefully before use.
Explain the content and the hazards associated with using the phone to your children.
Remember to comply with legal requirements and local restrictions
when using the phone. For example
in aeroplanes, petrol stations, hospitals or while driving.
Mobile phones can interfere with the
functioning of medical devices such
as hearing aids or pacemakers.
Keep at least 20 cm/9 inches between phone and pacemaker. When
using the mobile phone hold it to the
ear which is further away from the
pacemaker. For more information
consult your doctor.
Small parts such as the SIM card,
sealing stop, lens ring and lens cap
can be dismantled and swallowed
by small children. The phone must
therefore be stored out of the reach
of small children.
The mains voltage specified on the
power supply unit (Volt) must not be
exceeded. Otherwise the charging
device may be destroyed.
The ringtone (S. 25), info tones and
handsfree talking are reproduced
through the loudspeaker. Do not
hold the phone to your ear when it
rings or when you have switched on
the handsfree function (S. 12). Otherwise you risk serious permanent
damage to your hearing.
Important:
Improper use will invalidate the guarantee! These
safety instructions also apply to Siemens original
accessories.
Only use original Siemens batteries
(100 % mercury-free) and – charging devices. Otherwise you risk serious damage to health and property.
The battery could explode, for
instance.
You may only open the phone to replace the battery (100 % mercuryfree) or SIM card. You must not
open the battery under any
circumstances. All other changes to
this device are strictly prohibited and
will invalidate the operating licence.
Please dispose of unwanted batteries and phones as permitted by the
laws in your country.
The phone may cause interference
in the vicinity of TV sets, radios and
PCs.
Use only Siemens original accessories. This will avoid potential risks to
health or property and ensure compliance with all relevant regulations.
Phone overview
A
1
Call key (press lower part of button)
Dial phone number /name displayed, take
calls. Show last phone numbers dialed in
standby mode.
B
2
On/Off/End key
(press lower part of button)
• Switched off: press and hold to
switch on.
• During a call or in use: press briefly
to finish.
• In menus: press briefly: one level back.
Press and hold: return to standby mode.
• In standby mode: Press and hold to
switch off phone.
3 Control key
In lists and menus:
G Scroll up and down.
D
C
During a call:
D
In standby mode:
F
D
C
Select function.
Back a menu level.
Open call menu.
Open Phonebook.
Open menu.
GPRS info.
5Phone overview
_ªg
Service provider
01.10.2004 10:10
NewMMS Menu
Phone overview6
1 Integrated antenna
Do not interfere unnecessarily with the
phone above the battery cover. This reduces reception quality.
2 Loudspeaker
3 Display symbols
Signal strength/GPRS available/battery
level.
4 Display keys (press upper part of button)
The current functions of these keys are
shown in the bottom line of the display
as
§text§/symbol (e. g. d).
5 Input keys
Numbers, letters.
6
Press and hold
*
• In standby mode: switch on/off all signal tones (except alarm).
• For incoming calls: switch off ring
tones only.
7
Press and hold
In standby mode: switch key lock on/off.
8 Microphone
9 Plug socket
Connection for charger, headset,
camera etc.
_ªg
Service provider
01.10.2004 10:10
NewMMS Menu
Display symbols (selection)
Display symbols
Signal strength.
_
Charging.
h
Battery charging status, e.g., 50%.
d
Phonebook
è
Call log
Z
Surf & fun
É
Ringtones
ç
Messages
]
Camera
Extras
y
Own stuff
Ñ
Setup
m
All calls are diverted.
n
Ringer off.
j
Short ring (beep) only.
k
Ring only if the caller is stored in the
l
Phonebook.
Ø
Alarm set.
Alarm clock active.
Ö
µ
Key lock active.
Phone numbers/names:
On the SIM card
¢
¡
On the SIM card (PIN 2 protected).
In the phone memory.
v
²
No network access.
p,o
Function activated/deactivated.
Soft keys
Phonebook.
N
ABC/
Indicates whether upper- or lower case
letters are active.
Abc/abc
™
Text input with T9.
«
Activated and available.
ª
Registered.
Temporarily interrupted.
©
GPRS download.
WAP Online.
Ê
WAP via GPRS online.
Ë
WAP No network.
Ì
Headset active.
±
Auto answer feature on.
Depending on your service provider, some of the
symbols displayed here may differ from those on
the phone.
…
Message received.
MMS received.
MMS notification.
Voice mail
\
—
–
·
received.
Data received.
Picture received.
Melody received.
Unanswered call.
Store in Phonebook.
Retrieve from Phonebook.
7Display symbols (selection)
Getting started8
Getting started
Using the SIM card/battery
Your phone's display is delivered with a
protective film. Remove this film before get-
ting started. To avoid damage to the display, the phone should not be used without the front cover. The service provider
supplies you with a SIM card on which all
the important data for your account is
stored. If the SIM card is credit card-sized,
snap out the smaller segment and trim
any rough edges.
Remove the battery cover upwards
1
Insert SIM card
the locating slot (make sure the angled
corner is in the correct position
push the retaining catch over the top of
the SIM card
2 and push it fully into
4.
2
4
Insert the battery sideways into the
5, then press downwards 6
phone
until it engages.
1.
3). Then
3
6
5
7
To remove, press the retaining tab
then lift the battery out.
Insert the battery cover by the tabs at the
8, then press downwards 9,
bottom
until it engages.
7
9
8
Always switch off phone before removing
the battery!
Only 3V SIM cards are supported. Please
contact your service provider if you have
an older card.
Functions without SIM card p. 10.
Charging the battery
The battery is not supplied fully charged.
Plug the charger cable into the bottom of
the phone, plug the power supply unit
into a mains power socket and charge for
at least two hours. The power supply unit
will become hot after extended use. This
is normal and is not dangerous.
Display when charging is in progress
h
Charging time
An empty battery is fully charged after
about 2 hours. Charging is only possible
within a temperature range of +5 °C to
+40 °C. If the temperature rises/falls 5 °C
above/below this, the charge symbol flashes a warning. The voltage specified on the
power supply unit must not be exceeded.
Charge icon not visible
If the battery was fully discharged, the
charging symbol will not be immediately
visible on connection to the power supply
unit. It will appear after up to two hours.
In this case the battery is fully charged after 3 - 4 hours.
Only use the power supply unit provided!
Display while in service
Charge level display during operation
(empty-full):
adg
A beep sounds when the battery is nearly
empty. The charge level of the battery is
displayed correctly only after uninterrupted charging/discharging. You should
therefore not remove the battery unnecessar-
ily and where possible not interrupt charging prematurely.
Switching on/off, PIN
Turning the phone on/off
Press and hold the On/Off/End key B to
switch on or off.
Enter PIN
The SIM card can be protected with a 4- to
8-digit PIN.
Enter the PIN using the number keys. The
characters
can read your PIN on the display. Correct
errors with
Confirm your input with
to the network will take a few seconds.
Switching on your phone for the
first time
Time/date
The clock must be set to the right time
once at start-up.
§Yes§. First enter the date (day/month/
Press
year), then the time (24 hours, including
seconds). Press
are updated.
If the battery is removed for longer than
30 seconds, the clock must be reset.
Time zones
Specify your current time zone.
Select the desired time zone from the list
with
F. Apply it with §Set§.
Strong reception signal
_ Strong receive signal.
^ A weak signal reduces the call-
appear to ensure nobody
****
Clear§
§
.
§OK§. Logging on
§OK§. The time and date
quality and may lead to loss of
the connection. Change your
location.
9Switching on/off, PIN
General information10
Emergency number (SOS)
Use only in real emergencies!
By pressing the soft key
make an emergency call on any network
without a SIM card and without entering a
PIN (not available in all countries).
§SOS§ you can
Without a SIM card
If you switch on the phone without a
SIM card you can still use some phone
functions.
Press
§Menu§. The functions are displayed
(f.e. Emergency, SOS).
General information
User guide
The following symbols are used to explain
operation:
J
Enter numbers or letters
On/Off/End key
B
Call key
A
Press the control key on the side
D
indicated
< Soft key left
> Soft key right
§Menu§ Displays a soft-key function
Function depends on the service
L
provider, special registration
may be necessary
Menu control
The steps needed to reach a function are
shown in concise form in this user guide.
E. g. to display call list for missed calls:
§Menu§ ¢
press
This corresponds to:
Open the main menu, select the Call log
¢ Calls missed
Z
menu, then select the function Calls
missed. You have to confirm with
§Select§.
Standby mode
When the name of the service provider
appears on the display, the phone is in
standby mode and ready for use.
The left soft key may have different functions pre-assigned to it.
Press and hold the On/Off/End key
return to standby mode from any menu
option.
B to
Security
Codes
The phone and SIM card are protected
against misuse by several security codes.
Keep these confidential numbers in a safe
place where you can access them again if
required.
§Menu§ ¢ m ¢ Security ¢ Codes
¢ Select a function
PIN control
The PIN is usually requested each time
the phone is switched on. You can deactivate this feature but you risk unauthorised use of the phone. Some service providers do not permit deactivating the
control.
Change PIN
You can change the PIN to any 4-8 digit
number you may find easier to
remember.
Change PIN2
(Display only if PIN 2 is available). Proceed
as with Change PIN.
11Making a phone call
Change phonecode
You define the phone code (4 to 8 digits)
when calling up a phone-code protected
function for the first time. It is then valid
for all phone-code protected functions.
Following the third unsuccessful attempt,
access to the phone code and the functions that use it is denied. In such an instance contact Siemens Service (p. 30).
Clear SIM card barring
If the PIN is entered incorrectly three
times, the SIM card is barred. Enter the
PUK (MASTER PIN), provided by your service provider with the SIM card, according
to instructions. If the PUK (MASTER PIN)
has been lost, please contact your service
provider.
Preventing accidental activation
Even if PIN entry is deactivated (p. 10)
confirmation is required to switch on
phone.
This prevents accidental activation of the
phone, e.g. when you are carrying it in
a bag or when you are travelling in an
aircraft.
After long press of the On/Off/End key
to switch on the phone or abort the
B
operation with
§Cancel§.
Making a phone call
Dialing with number keys
The phone must be switched on (standby
mode). Dial number (always with area
code, if necessary with international dialing code). To dial International dialing
codes press and hold
played. Press
0 until a "+"-is dis-
§+List§ and select country.
Short press
long press clears the entire phone
number. To dial press the
§Clear§ to clear the last digit, a
A key.
End call
Press the End key B briefly. Press this
key even if the person on the other end of
the line has hung up first.
Set volume
Use the control key E to start adjusting
the volume during conversation. Set volume with
If a Car Kit is used, its volume setting will
not affect the usual setting on the phone.
G and confirm with §OK§.
Redial previous numbers
For redialing previously dialed numbers
press the Call key
required phone number from the list
G, then press A again.
with
A once, pick out the
If number busy
Press §Auto dial§ for automatically dialing
the phone number ten times at increasing time intervalls or press
for phone ringing when the busy number
is free. Press
mind you to redial the dispayed phone
number after 15 minutes.
§Prompt§ and a beep will re-
§Call back§ (
L
Accept call
The phone must be switched on (standby
mode). An incoming call will interrupt
any other use of the phone. Press
A.
or
Please make sure you have accepted the call
before holding the phone to your ear. This will
prevent a loud ring tone from damaging your
hearing!
§Answer§
)
Text entry12
If the phone number has been transmitted by the network, it is displayed. If the
caller's name also appears in the Phonebook, this will appear instead of the
number. If set, a picture can be displayed
instead of the bell icon.
Reject call
§Reject§ or B press briefly.
Speakerphone
You can put the phone down during a
call. You can then hear the caller via the
loudspeaker.
Activate handsfree function with
and switch on with
Adjust the volume with
§Speaker.§ switches off "handsfree talking".
Always switch off "handsfree talking" before
holding the phone to your ear! This will avoid
damage to your hearing!
§Yes§.
G
§Speaker.§
. Pressing
Swapping between 2 calls
Make a new connection during a call with
y menu§ ¢ Hold ¢
number). With
swap back and forth between both calls.
If you are called during a phone call and
you can hear the "call waiting tone"
(p. 22), you can accept the waiting call
§Swap§,putting the current call on
with
hold to do so. Swap back and forth between the calls as previously described or
end the current call with
the new call with
J
(dial a new phone
y menu§ ¢ Swap you can
Band accept
§Answer§.
Multi Party
Make a new connection during a call with
y menu§ ¢ Hold ¢
number). With
can join the held call.
J
(dial a new phone
y menu§ ¢ Multi Party you
Repeat this procedure until all participants
are linked together (up to 5 participants).
All calls in the conference are ended simultaneously when the End key
pressed.
B is
Text entry
Text entry without T9
Press number key repeatedly until the required letter appears. The cursor advances after a short delay. Example:
Pressing briefly once types the
2
letter a, twice the letter b, etc.
Press and hold to write the
number.
Ä,ä,1-9 Umlauts and numbers are dis-
played after the relevant letters.
§Clear§ Press briefly to delete the letter
before the cursor, press and hold
to erase the whole word.
Move the cursor
H
(forwards/back).
Press briefly: Switch between abc,
Abc, ABC, T9abc, T9Abc, T9ABC,
123. Status indicator in the top
line of the display.
Press and hold: All input modes
are displayed.
Press briefly: Special characters
*
are shown.
Press and hold: Open input
menu.
Press once/repeatedly:
0
. , ? ! ’ " 0 - ( ) @ / : _
Press and hold: Writes 0.
Writes blank. Press twice = skip
1
line.
13Text entry
Special characters
Press briefly *. The character map is
displayed:
1
) ¿¡_;.,?!+-
"’ :
€@\ &#[] { } %~
<=> | ^ § Γ ∆ Θ Λ Ξ
Π Σ Φ Ψ Ω
1
) Line skip
Navigate to characters with
press
* /()
§Select§.
$
¤¥
G,Hand
£
Input menu
Press and hold * with text input.
The input menu ist displayed:
Text format (SMS only)
Input language
Mark text
Copy/Add
Text entry with T9
T9 deduces the correct word from the individual key entries by making comparisons with an extensive dictionary.
Activate, deactivate T9
§Options§ ¢T9 input ¢ T9 preferred
¢ §Change§ (activate or deactivate T9)
Select Input language
Select the language in which you want to
compose your message.
§Options§ ¢T9 input ¢ Input language
¢ §Select§ (the new language can be se-
lected) or
lected language will be deleted).
Type a word using T9
The display changes as you proceed.
Therefore, it is best if you finish a word
without looking at the display.
§Delete§ (T9 dictionary for the se-
Simply press the keys once only where the
relevant letter is located. For "hotel", for
example:
Press briefly
46835
word).
Do not use special characters such as Ä
but rather use the standard characters,
e.g. A; T9 will do the rest for you.
Additional notes
0
D
*
for T9Abc then
and 1 (the blank ends a
Setting a full stop. Word is ended
when followed by a blank space.
Within a word, a full stop represents an apostrophe or hyphen:
e.g.
§provider.s§ = provider’s.
Move to the right. Ends a word.
Press briefly: Swap between: abc,
Abc, T9abc, T9Abc, 123. Status in-
dicator in the top line of the display.
Press and hold: All input modes
are displayed.
Press briefly: Select special characters.
Press and hold: Open input
menu.
T9 word suggestions
If several options are found in the dictionary for a key sequence (a word), the most
probable is displayed first. The word must
be highlighted as
press
»
placed with a different word. If this is also
incorrect, repeat until the correct word is
displayed.
To add a word to the dictionary,
§Spell§. Now write the word without
select
T9-support and accept with
dictionary.
§inverted§. Then
. The displayed word is re-
§Save§ into the
Phonebook14
Correct a word
Words written with T9:
With
H move left or right, word by
word, until the required word is
With
suggestions again.
acter to the left of the cursor and displays
a new possible word!
Words not created using T9:
With
left/right.
left of the cursor. New characters are inserted at the cursor position.
T9
the following: U.S. Pat. Nos. 5,818,437,
5,953,541, 5,187,480, 5,945,928, and 6,011,554;
Canadian Pat. No. 1,331,057; United Kingdom
Pat. No. 2238414B; Hong Kong Standard Pat.
No. HK0940329; Republic of Singapore Pat.
No. 51383; Euro.Pat. No. 0 842 463 (96927260.8)
DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide.
scroll through the T9 word
»
H
move letter by letter to the
®
Text Input is licensed under one or more of
§Clear§ deletes the char-
§Clear§ deletes the letter to the
§inverted§.
Predef. texts
The phone contains predefined texts that
you can add to your messages (SMS,
MMS). You can also create and store up to
5 personal stored texts. Each stored text
can contain up to 32 characters.
Unlike personal stored texts, predefined
texts cannot be changed or deleted.
Write personal stored texts
§Menu§ ¢ ] ¢ Predef. texts ¢§Options§
¢ <New entry> ¢
stored text)
¢ §Save§
J
(write personal
Use predefined texts
J (write message text) ¢ §Options§
¢ Insert text ¢ G (select predefined
text from the list)
¢ §Select§
The predefined text is inserted into the
text to the left of the cursor.
Phonebook
Enter frequently used phone numbers in
the Phonebook with a special name. To
dial them, simply highlight the name. If a
phone number is stored with a name, it
appears on the display when you are
called. Important numbers can be assigned to different groups.
<New entry>
Open Addressbook (in standby mode)
G
¢ §Select§ ¢ Select entry fields
Number: Always enter phone number with
prefix.
Name: Enter first name or surname.
E-mail: Enter email address for MMS
(max. for 50 addresses).
Group: Organise entries in groups, select
§Change§.
with
Location: Select location: Mobile, SIM or
Protected SIM.
Record no.: This is automatically assigned
to the entry.
Press
§Save§ to store the new entry.
Call (search for an entry)
Open phonebook F, select name and
select phone number with
Edit entry
F ¢ Select entry ¢ §Options§ ¢ Edit
¢ Make changes ¢ §Save§.
A.
15Call log
Assign picture
Assign a maximum of 50 phone numbers
to an individual picture. This picture will
appear in the display when there is a call
from this number.
F ¢Select entr y ¢§Options§ ¢ Picture
¢ Select picture ¢ §Open§ (the picture is
displayed)
The picture is assigned to the
phone number and it appears with
a
Delete/change image
If a picture is assigned to a
phone number, it can be deleted
or replaced.
G
¢ §Select§
› symbol in the Phonebook.
¢ Select entry with picture›
¢ §Options§ ¢ §Select§ ¢ p Picture
¢ §Delete§
Groups
Four groups are specified in your phone
to enable you to arrange your Phonebook
entries clearly. You can rename these
groups.
Open Addressbook (in standby mode)
G
¢ <Groups> (the number of entries
is listed behind the group name)
¢ Select a group ¢ §Select§ (open group)
or
§Rename§ (give group a name)
Ring tone for group
If you assign a ring tone to a group, it
sounds when one of the group members
rings.
§Menu§ ¢ ç ¢ Group calls
¢ Select a group ¢ §Select§
¢ Select ring tone ¢ §Select§
Call log
Your phone stores the phone numbers of
calls for convenient redialing.
§Menu§ ¢
¢ §Select§
Z
¢ Select call record ¢ §Select§
¢ Select phone number ¢A
Calls missed b
The phone numbers of calls that you have
not accepted are stored for call-back purposes, if the network supports the "Caller
Identity" feature.
Symbol for acc. call.
Calls received b
Accepted calls are listed, if the network
supports the "Caller Identity" feature.
Calls dialed
In standby mode you have access to the
last numbers dialed with
Delete calls
The records are deleted.
Call list menu
§Options§ ¢ Edit entries.
A.
Durat/charges
You can display the charges and the duration of a call and set a unit limit for outgoing calls.
§Menu§ ¢
Select a function: Last call, All outgoing,
All incoming, Remain. units
§Select§ Display data.
§Reset§ Clear display.
§OK§ End display.
¢ Durat/charges ¢
Z
Camera16
Charge sett.
Z
§Menu§ ¢
¢ Charge sett.
¢ Durat/charges
Currency b
(PIN 2 prompt)
Currency for charge display.
Personal rate b
(PIN 2 prompt)
Charges per unit/period.
A/c limit b
(PIN 2 prompt)
Fix a credit/usage period on a special
SIM card.
Auto display
Call duration and call charges are
automatically displayed for each call.
Camera
You can use the phone to immediately
view, save and send photos you have taken with the "QuickPic Camera". Pictures
can be taken in two different formats:
• Low resolution:
QQVGA 160x120 pixels, memory size
up to 6 KB for sending as an MMS image (p. 18).
• High resolution:
VGA 640x480 pixels, memory size of
one picture up to 40 KB – e.g. for further editing on PC. To allow the picture
to be viewed on the phone display, a
QQVGA picture is created for every
VGA picture.
In standby mode press
or
First the number of shots still available is
shown (depends on resolution chosen).
Confirm with
§Menu§ ¢
§Camera§
§OK§ (the last picture taken is
shown) and scroll through photos
G
.
with
A picture requires a few seconds to be
processed.
§Take§. You will hear an advisory tone
Press
when the exposure time has expired. The
photo is shown on the display and saved
automatically.
Flashlight
In the option menu the flashlight function can be switched on/off.
If the flash is switched on, a command is
given to charge the flashlight before taking a picture:
Press
§Load§ briefly. The flashlight is charged
(battery capacity at least approx. 30%).
§Take§ and the photo is taken.
Press
Sending a photo by MMS
You can easily send a photo as an MMS
immediately after taking it.
§Options§ ¢ Send via MMS ¢ §Select§
(select the desired resolution)
(skip recording a melody, p. 18)
¢ §Skip§
Voicemail/CB services
Voice mail/mailbox
§Menu§ ¢ ] ¢ Msg. setup
¢ Voice message
Most service providers offer you an external answering service. In this mailbox, a
caller may leave a voice message for you
• if your phone is switched off or not
ready to receive,
• if you do not want to answer,
• or if you are making a phone call.
17SMS
You may have to register for this service
with your service provider and perform
some manual settings.
Settings: b
Your service provider supplies you with
two phone numbers:
Save mailbox number
You call this phone number to listen to
the voice mails left for you.
]
§Menu§ ¢
¢ Voice message
Enter mailbox phone number and
confirm with
Save call divert number
Calls are diverted to this phone number.
§Menu§ ¢
¢ e. g. Unanswered ¢Set
Enter call divert number and log on
network. Divert will be confirmed after a
few seconds (see also p. 22).
¢Msg. setup
§OK§.
m
¢Call setup
§OK§ to
Play back messages b
A new voice mail can be announced as
follows:
A
\ symbol with beep or
indicates a new voice mail or that you are
receiving an automatic announcement.
Dial into your mailbox and listen to your
message(s).
Press and hold
box number once only). Confirm with
§Mailbox§ depending on your service
and
provider.
(if necessary enter mail-
1
]
an SMS
§OK§
CB services
§Menu§ ¢ ] ¢ Msg. setup
¢ CB services
Some service providers offer information
services (info channels,). If reception is
activated, your Topic list will supply you
with messages on the activated topics.
SMS
You can transmit and receive very long
messages (up to 760 characters) on your
phone. They are automatically composed
of several "normal" SMS messages (note
higher charges).
Additionally you can insert pictures and
sounds in an SMS.
Writing/sending SMS messages
§Menu§ ¢ ] ¢ New SMS ¢
text)
¢ A ¢ · /
number or select from Phonebook)
¢ §OK§
The SMS is sent to the service centre for
transmission.
Receiving SMS
An arrival of a new SMS is announced on
with…. To read the SMS, press
display
left soft key.
G you scroll through message line
With
by line. Select
SMS archive
§Menu§ ¢ ] ¢ SMS archive
The list of SMS messages stored in the
phone is displayed.
Special functions
SMS to group
Send SMS as a "circular" to a group.
§Options§ ¢ Send ¢ §Group§ ¢ Select
group members and send SMS.
Picture&Sound
Insert pictures and sounds into message.
§Options§ ¢ Picture&Sound select.
The menu contains:
Fix animations, Fix sounds, Own animat.,
Own pictures, Own sounds
§Reply§ for a direct reply.
(enter phone
J
J
(write
MMS18
MMS
The Multimedia Messaging Service enables you to send texts, pictures (also photos) and sounds in a combined message
to another mobile phone or to an e-mail
address. All elements of an MMS message
are merged to form a "slide show".
Depending on your phone's settings, you
will receive either the complete message
automatically or notification that an MMS
has been saved in the network, giving
sender and size details. You may then
download it to your phone to read it.
Ask your service provider whether this
service is available. You may need to register for this service separately.
Writing/sending MMS messages
An MMS consists of the address header
and the content.
§Menu§ ¢ ] ¢New MMS
Input fields:
· /
To:
e-mail address of recipient/s.
Subject: Enter MMS heading (up to
40 characters)
§Insert§. The picture list is opened
Picture:
for selection.
Additional information
You can also easily send an image by
MMS immediately after taking it with the
QuickPic Camera (p. 16).
§Edit§. Write text with the help
Text:
of T9.
Tones/Alerts:
record a new melody.
Slide duration:
Enter length of display for individual pages
(minimum 0.1 seconds).
Phone number/
J
§Insert§. Select a melody or
Record new melody (ring tone) for MMS
If you press
when completing the input fields, you
have the option of recording a new melody for sending messages by MMS.
Press
maximum available time and recording
duration are displayed. To end recording,
press
Insert additional pages
§Options§ Open menu.
New slide Select.
Send MMS
§Options§ Open menu.
Send Select.
§Insert§ in the Tones/Alerts: field
§Record§. Recording starts, and the
§Stop§.
Receive/read MMS b
/Indicates reception or notifica-
tion of an MMS.
Depending on the profile setting (p. 19):
• Receive complete MMS
• Open the message. Press
order to receive the complete MMS,
§Play§ automatic MMS presenta-
with
tion. Cancel with any key.
Functions for editing MMS can be found
§Options§.
under
§Receiving§ , in
19Message lists/ Message settings
Message lists/
Message settings
All SMS/MMS messages are stored in one
of the following lists according to status.
Inbox
§Menu§ ¢ ] ¢Inbox ¢ SMS/MMS
The list of received SMS or MMS messages is displayed.
Draft
§Menu§ ¢ ] ¢Draft ¢SMS /MMS
The list of unsent SMS or MMS messages
is displayed.
Unsent
§Menu§ ¢ ] ¢Unsent ¢SMS /MMS
The list of SMS or MMS messages not yet
successfully sent is displayed.
Sent
§Menu§ ¢ ] ¢Sent ¢SMS /MMS
The list of sent SMS or MMS messages is
displayed.
T9 settings
§Menu§ ¢ ] ¢Msg. setup
¢ Select a function
T9 preferred
Activate/deactivate intelligent text entry
(see also p. 13).
Input language
Select language for text entry. Languages
with T9 support are marked by the
T9 symbol.
SMS profiles, MMS profiles
§Menu§ ¢ ] ¢Msg. setup
¢ SMS profiles/MMS profiles
Profiles have to be created for SMS and
MMS. The transmission characteristics are
defined in these. The data for these may
already have been entered. If not, your
service provider will supply you with the
relevant information. Additional information is available in the comprehensive operating instructions on the Internet at:
www.siemens-mobile.com/a65
Surf & fun
Internet browser (WAP)
É
§Menu§ ¢
Get the latest information from the Internet that is specifically adapted to the display options of your phone. Internet access may required registration with your
service provider.
Home b
A connection is established with the Internet provider’s portal (may be specified/configured by default by your service
provider).
Bookmarks
List of URLs for fast access.
Internet b
The browser is activated as soon as you
call up the function. The functions of the
soft keys vary, depending on the internet
page, for example "link" or "menu". The
contents of the option menus are also
variable. If necessary set how the Internet
access should be made. To this end open
the browser menu with
Setup/Start with... .
¢ Select a function
A and select
Surf & fun20
Additional notes
Browser menu.
Í
É Offline.
Ê
Online.
Ë
GPRS online.
No network.
Ì
Select special characters, such as
*
@, ~, \ , see p. 13 or
press repeatedly for:
0
. , ? ! ’ " 0 - ( ) @ / : _
End connection
Press and hold B to end the connection
and close the browser.
WAP profiles
É
§Menu§ ¢
Preparation of the phone for WAP Internet
access depends on your service provider.
If these settings have already been applied by the service provider, select and
activate profile. If you have to configure
the access profile manually, consult your
service provider if necessary.
Activate WAP profile
You can change the active profile each
time before you access the Internet (if the
profile has been set already). For this,
select profile, then
WAP profile setting
Up to 5 WAP profiles can be configured
(may be limited by the service provider).
The specifications may vary according to
service provider. Select profile, then
and fill in the data fields.
Select the connection profile: see p. 23.
¢ Internet ¢Profiles
§Select§.
§Edit§
Games & more
Download games and other applications.
You are advised about relevant applications on the Internet. Once you have selected a game or application you can start
to download it immediately. Then you
can use the application. Most applications
include instructions. Applications and
games can be found at:
wap.siemens-mobile.com or on the Internet
at www.siemens-mobile.com
Additional information
To download applications, the WAP profile, HTTP profile and access must be configured (p. 23).
Depending on the service provider, the
access and functionality could differ from
the present description.
Games and applications
Applications and links that are already
stored on the phone are found under:
É
§Menu§ ¢
Different functions are available
depending on which entry is highlighted:
Download new
§Internet§ The selected Internet page is
§
§Select§ Loadable application can be
¦ Load game/application online
§Select§ Only description file, application
You will find special instructions or information for each game in the option
menu.
¢ Games & more
loaded.
Carry out game/application offline
started immediately.
has still to be loaded.
21Setup
Key control
The following key control is used for
many games (virtual joystick):
13
function
depends on
the game
or use the key
I.
2
4
7
6
5
9
8
Setup
Profiles
§Menu§ ¢ m ¢Profiles
Several settings can be stored in a phone
profile in order, for example, to adapt the
phone to the surrounding level of noise.
• Five profiles are standard with default
settings, they can be changed however: Normal envi., Quiet environ.,
Noisy environ., Car Kit, Headset
• You can set two personal profiles
(<No Title>).
• The special profile Aircraft mode cannot
be changed.
Activate
Select default profile or personal profile
¢ §Activate§.
Setup
Select profile ¢ §Options§ ¢ Change sett.
The list of available functions is displayed.
Car Kit
The profile is only activated automatically
as soon as the phone is inserted into the
cradle if a Siemens original Car Kit is used.
Headset
The profile is only activated automatically
if used with an original Siemens headset.
Aircraft mode
The alarm tone is deactivated. An alarm is
only shown on the display. It is not possible
to modify this profile. The phone will automatically switch off if you select this
profile.
Normal mode
The next time you switch on the phone
and return to normal operation the default profile will be activated.
Display
§Menu§ ¢ m ¢ Display
¢ Select a function
Language
Set the language of the display text. "Automatic" will set the language of your
home service provider. Reset to this language in standby status:
# 0 0 0 0 #
*
Background
Logo
Color scheme
Own greeting
Big letters
Illumination
Contrast
Screensaver
The screensaver shows a picture on the
display as soon as a period that can be set
by you has elapsed. The function is ended
by an incoming call or by pressing
any key.
Setup22
Call setup
§Menu§ ¢ m ¢Call setup
¢ Select a function
Hide ID b
When switched on, the display of the calling party shows your phone number (dependent on service provider).
Call waiting b
If you are registered for this service, you
can check whether it is set and you can
activate/deactivate it with Call waiting.
Call Forward
You can set the conditions for which calls
are diverted to your mailbox or other
numbers.
Set up call divert (example):
• All calls
All calls are diverted.
top line of the display in standby mode.
•Unanswered
Includes Unanswered, Not reachable,
No reply, Busy.
§Select§ ¢ Set ¢ J (Enter the phone
number, to which the call should be
diverted)
¢ §OK§
After a short pause, the setting is confirmed by the network.
Other divert options: Not reachable,
No reply, Busy
• Status check
After a short pause the current information is shown.
p Condition set.
o Not set.
Display if status is unknown
s
(e. g. with a new SIM card).
• Clear all
All set diversions are cleared.
n is shown in the
Any to answer
Incoming calls can be accepted by pressing any key
(except for
B
).
Minute beep
During the call, you will hear a beep after
each minute as a reminder of the time
elapsed. The recipient does not hear this
beep.
23Setup
Clock
§Menu§ ¢m ¢Clock ¢ Select a function
Time/date
§Change§ ¢ Enter the date first, then the
time.
Time format:
Select Format 24h or Format 12h.
Time zones
Specify your current time zone.
Format date
DD.MM.YYYY or MM/DD/YYYY or
MM-DD-YYYY
Show clock
Switch on/off time display.
Buddhist year
Change to Buddhist date (not available in
all phones).
Connectivity
§Menu§ ¢ m ¢Connectivity
¢ Select a function
GPRS b
§Yes§ / §No§ Switch GPRS on /off.
Data counter
Display connection information.
Data services
§Menu§ ¢m ¢ Connectivity ¢Connection
¢ Select function
profiles
For the MMS, Wap and Java application at
least one connection profile must be set
up and activated. If necessary enter CSD
settings and GPRS settings (your service
provider will supply you with information
on this or www.siemens-mobile.com/
mobilescustomercare under "FAQ").
§Options§ ¢ Change sett. ¢ §Edit§
¢ Enter data ¢ §Save§
HTTP profile
Select profile with G. Enter or modify
settings. If necessary, check with your
service provider for details.
Authentication
§Menu§ ¢ m ¢ Connectivity
¢ Authentication ¢ §Change§
¢ Activate encrypted WAP dial-up
Security
§Menu§ ¢ m ¢ Security
¢ Select function
Auto key lock
If activated, the keypad is locked automatically if no key has been pressed for
one minute in standby mode. This prevents the phone from being used accidentally. However, you can still be called
and you can still make an emergency call.
Direct call
Only one phone number can be dialed.
To do so press and hold the right soft key.
Only ‚ b
Restrict calls to SIM-protected numbers in
the Phonebook.
Last 10 only b
Limit calls tocall list of "dialed numbers"
(p. 15).
Codes
(see p. 10)
This SIM only b
Your phone is prevented from being used
with a different SIM card.
§Menu§ ¢ m ¢ Security
¢ Select a function
Setup24
Barrings
Network barring restricts the use of your
SIM card.
All outgoing: Outgoing calls, except emer-
gency 999 calls, are blocked.
Outgo internat: Only domestic calls are
possible.
Outgo internat. x home barred: International
calls are not permitted, ecept for calls to
your home country.
All incoming calls: The phone is blocked
from receiving all incoming calls.
When roaming: You do not receive any calls
outside your home network.
Status check: Query the status of your
barrings.
Clear all: Remove all barrings.
b
Phone identity
Display the phone identity number (IMEI)
and software version.
Filesystem clean up
(Phone code is protected)
The file system is defragmented.
Master reset
Rest phone to standard values
(factory setting).
Network
§Menu§ ¢ m ¢Network
¢ Select a function
Line b
Two independent phone numbers have to
be registered.
Network info
The list of GSM networks currently available is displayed.
Auto network
If activated, the next network is dialed in
the order of your "preferred networks".
Choose network
The network search is restarted.
Preferred network
Set the service providers you prefer when
you leave your home network.
Fast search
When this function is active, network reconnection is speeded up (standby time is
reduced).
Accessories
§Menu§ ¢ m ¢ Accessories
¢ Select a function
Car Kit
Only in combination with an original
Siemens handsfree Car Kit. If an original
Siemens Car Kit Portable is used the profile is activated automatically as soon as
the phone is inserted into the cradle.
Auto answer
Calls are accepted automatically after a
few seconds. Eavesdropping is possible!
Headset
Only in conjunction with an original
Siemens headset. If an original Siemens
Headset is used the profile is automatically activated when the headset is plugged
in. Accept call with the Call key when the
key lock is activated.
Auto answer
Calls are accepted automatically after a
few seconds. Eavesdropping is possible!
If you do not notice that your phone has accepted a call, there is the danger that the caller
may eavesdrop.
25Ringtones
/
Ringtones
§Menu§ ¢ ç ¢Select function
You can set the tones to match your
needs.
Ringer setting
Activate/deactivate the ringer or reduce it
to a short beep.
Vibrating alert
Activate/deactivate the silent alert (functions in addition to ringer).
Vol ume
Set the same volume for all ring tones.
d Calls, Group calls, Other calls:, Alarm
clock, Messages
The ring tones for the stated types of
call/functions can be set separately.
More tones...
§Menu§ ¢ ç ¢More tones...
¢ Select a function
Call screening b
Only calls from numbers that are in the
Phonebook or in a predefined group are
signalled audibly or by silent alert. Other
calls are only displayed.
Key tones
Set acoustic key acknowledge: Click or
Tone or Silent
Minute beep
During the call, you will hear a beep once
a minute as a reminder.
Info tones
Set service and alarm tones.
Extras
§Menu§ ¢ y ¢ Select function
Alarm clock
The alarm will ring at the time set by you,
even when the phone is switched off.
§On/off§ Switch on/off.
Setting
Set the time for the alarm call (hh:mm),
§OK§.
then
Calculator
Enter number (maximum of
J
8characters).
—
J
§.§=§+§-§*§/§ Press the right display key re-
± Toggle between "+" and "–".
% Convert to percent.
Ï
, ÐSave, recall number.
e Exponent (maximum of
Special keys:
*
0
Stopwatch
Two intermediate times can be recorded
and saved.
§Reset§ Reset to zero.
*
Select calculate function.
I
+
x
Repeat procedure with other
numbers.
Result is displayed.
peatedly.
two digits).
Set decimal point.
Add (press and hold).
Start/stop.
Intermediate time.
Fast access26
SIM services (optional) b
Your service provider may offer special
applications such as mobile banking,
share prices, etc. via the SIM card. If you
have such a SIM card, the SIM services
will appear in the main menu under
"Extras" or directly above the control key
(on the left) with symbol
With the SIM services menu, your phone
is ready to support future additions in
your service provider's user package. For
further information, please contact your
service provider.
}
.
Fast access
The left soft key and the number
keys 2 to 9 (speed dialing numbers) can
each be assigned an important phone
number or a function. The phone number
can then be dialed or the function can be
started at the touch of a button.
Left soft key
Assign an Assign function/phone number
to this key.
Change (example)
§Internet§ ¢ §Change§
¢ Search for application, e.g. New SMS,
Phone number
Apply (example)
Key assigned with Phone number/name.
Press and hold
Speed dialing keys
Only possible for keys 2 to 9. Key 1 is
reserved for the mailbox.
Change (example)
¢ §Set§ ¢ Select application, e.g. New
3
SMS, Phone number
¢ §Select§
§Carol§.
¢ §Select§
Apply (example)
Press and hold key
.
3
Own stuff
The following folders are provided for organizing your photos: Pictures, Animations,
Sounds.
§Menu§ ¢ Ñ
Files and folders are displayed.
You can scroll through these lists
using
and
To open a folder or execute a file using
related application press
Index structure
Special folders are provided in the file
system for the different data types.
The following folders are also included in
these main folders:
(to scroll up and down)
G
(to jump back from a folder).
C
§Open§.
Folders Contents Format
Pictures Images *.bmp
Camera Own Photos (p. 16) *.png
Anima-
tions
Sounds
Download
new
EMS Files that can be received per
Animations *.bmx
Ring tones, melodies,
sounds
This enables you to download new
files from the Internet.
SMS/MMS.
*.mid
Questions & Answers
If you have any questions regarding the use of your phone, you can contact us at
www.siemens-mobile.com/mobilescustomercare at any time. In addition to this we have listed some
frequently asked questions and answers below.
Question Possible causes Possible solution
Phone cannot be
switched on.
Insufficient standby
time.
Charging error (charge
icon not displayed).
SIM error. SIM card not correctly inserted. Check that the SIM card is inserted correctly
No connection to
network.
Phone loses network. Signal too weak. Reconnection to another service provider is
On/Off key not pressed long
enough.
Flat battery. Charge battery. Check charging indicator in
Speed search active. Deactivate speed search (p. 24).
Display illumination switched on. Switch off display illumination (p. 21).
Battery totally discharged. 1) Plug in charger cable, battery is on charge.
Contact problem. Check power supply and connection to the
No mains voltage. Use different mains power socket, check
Wrong charger. Only use original Siemens accessories.
Battery faulty. Replace battery.
SIM card contacts dirty. Use a dry cloth to clean the SIM card.
SIM card with wrong voltage. Use 3 V SIM cards only.
SIM card damaged (e.g. broken). Visually inspect the damage. Have SIM card
Weak signal. Move to higher location, to a window or open
Outside GSM range. Check coverage area of service provider.
SIM card not valid. Contact the service provider.
New network not authorised. Try manual selection or select a different net-
Network barring is set. Check barrings (p. 24).
Network overloaded. Try again later.
Press On/Off key for at least two seconds.
the display.
2) Charge icon appears after approx. 2 hours.
3) Charge battery.
phone. Check battery contacts and device
plug socket, clean them if necessary, then insert battery again.
mains voltage.
(p. 8).
replaced by service provider.
space.
work (p. 24).
automatic (p. 24). Switching the phone off and
on may speed this up.
27Questions & Answers
Questions & Answers28
Question Possible causes Possible solution
Calls not possible. 2nd line set. Set first line ‘ (p. 24).
New SIM card inserted. Check for new restrictions.
Charge limit reached. Reset limit with PIN 2 (p. 16).
Credit used up. Load credit.
Certain uses of the
phone not possible.
No entries possible in
Phonebook.
Voice mail does not
work
SMS (text message)
T
flashing.
Function cannot be
set.
Memory problems for,
e.g. messages, ring
tones, pictures.
No WAP access, no
download possible.
Message cannot be
sent.
EMS pictures and
sounds not displayed
at destination phone.
No Internet access
possible.
PIN error/
PIN2 error.
Call restrictions are set. Barrings may be set by your service provider.
Phonebook is full. Delete entries in Phonebook.
Call divert to the mailbox not set. Set call divert to the mailbox (p. 22).
SMS memory full. To free up capacity, delete or file messages
Not supported by service provider
or registration required.
Phone memory full. Delete files in the applicable areas and un-
Profile not activated, profile settings wrong/incomplete.
Service provider does not support
this service.
Phone number of the service centre is not set or is wrong.
SIM card contract does not support this service.
Service centre too busy. Repeat message.
Recipient does not have a com-
patible phone.
Recipient's phone does not sup-
port EMS standard.
Wrong WAP profile set or settings
wrong, incomplete.
Three wrong entries. Enter the PUK (MASTER PIN) supplied with
Check barrings (p. 24).
(SMS).
Contact your service provider.
needed T9 dictionaries.
Activate WAP profile (p. 20), set (p. 20). If necessary ask your service provider.
Check with your service provider.
Set service centre (p. 19).
Contact your service provider.
Check.
Check settings, speak to service provider if
necessary.
the SIM card according to the instructions. If
the PUK (MASTER PIN) has been lost, please
contact your service provider.
Loading...
