Issued by Information and Communication mobile Haidenauplatz 1 D-81667 Munich

Siemens Aktiengesellschaft www.my-siemens.com

mobile

Be inspired

A60

Table of Contents 1

Safety precautions ..................... 3

Phone overview ......................... 4

Display symbols (selection) ....... 6

Getting started ........................... 8

Insert SIM card/battery ............. 9

Charge battery ....................... 10

Switch on/off/ PIN ..................... 11

Switching on your phone

for the first time ..................... 11

Signal strength ...................... 12

Without SIM card ................... 12

General Instructions ................ 13

Menu Control ......................... 13

Standby mode ....................... 13

Security .................................... 14

Codes .................................... 14

Preventing accidental

activation ............................... 15

My phone ................................. 16

Making a phone call ................. 17

Dialling with number keys ...... 17

End call .................................. 17

Set volume ............................ 17

Redial previous numbers ........ 17

Sendcontrol code (DTMF) ...... 17

When a number is busy .......... 18

Accept call ............................. 19

Reject call .............................. 19

Handsfree .............................. 19

Swapping between 2 calls ...... 20

Conference ............................ 21

Direct call ............................... 22

Text entry ................................. 24

Predef. texts ........................... 27

Phonebook ...............................28

<New entry> .......................... 28

Call (search for an entry) ........ 29

Edit entry ............................... 29

Assign picture ........................30

<Special books> ..................... 31

Groups ...................................32

Control codes (DTMF) .............33

Records .....................................34

Durat/charges ........................... 35

Voice mail/mailbox ...................36

SMS ...........................................38

Writing and sending

text messages (SMS) .............. 38

Picture&sound ........................39

SMS to group .........................40

Receiving SMS ........................ 41

Lists .......................................42

SMS archive ...........................43

SMS profiles ........................... 43

T9 settings ............................. 44

CB services ................................45

Surf & fun .................................46

Internet browser (WAP) ..........46

Games ....................................49

See also Index at the end of this User Guide

2 Table of Contents

Setup ........................................ 50

Display ................................... 50

Screensaver ........................... 51

Call setup ............................... 52

Divert .................................... 53

Clock ..................................... 55

Connectivity .......................... 56

Security ................................. 57

Network ................................ 59

Profiles ..................................... 61

Ring tones ................................ 63

Extras ....................................... 65

SIM services

(optional) .............................. 65

Alarm clock ............................ 65

Calculator .............................. 66

Stopwatch ............................. 66

Fast access key .........................67

Own stuff .................................. 69

Data Exchange Software ..........70

Questions & Answers ...............71

Customer Care .......................... 74

Care and

Maintenance ............................76

Product data ............................. 77

Accessories ...............................79

Battery quality statement ........ 81

Guarantee certificate (UK) ....... 82

Guarantee certificate (IRL) .......83

Menu tree ................................. 85

SAR - European Union (RTTE) ...89

SAR – International (ICNIRP) .... 90

Index .........................................91

See also Index at the end of this User Guide

Safety precautions

Information for parents

Please read the operating instructions and safety precautions carefully before use. Explain the content and the hazards associated with using the phone to your children.

Remember to comply with legal requirements and local restrictions when using the phone. For example in aeroplanes, petrol stations, hospitals or while driving.

Mobile phones can interfere with the functioning of medical devices such as hearing aids or pacemakers. Keep at least 20 cm/9 inches between phone and pacemaker. When using the mobile phone hold it to the ear which is further away from the pacemaker. For more information consult your doctor.

Small parts such as the SIM card, sealing stop, lens ring and lens cap can be dismantled and swallowed by small children. The phone must therefore be stored out of the reach of small children.

The mains voltage specified on the power supply unit (Volt) must not be exceeded. Otherwise the charging device may be destroyed.

The ringtone (p. 63), info tones a nd handsfree talking are reproduced through the loudspeaker. Do not hold the phone to your ear when it rings or when you have switched on the handsfree function (p. 19). Otherwise you risk serious permanent damage to your hearing.

Important:

Improper use will invalidate the guarantee! These safety instructions also apply to Siemens original accessories.

Only use original Siemens batteries (100 % mercury-free) and – charging devices. Otherwise you risk serious damage to health and property. The battery could explode, for instance.

You may only open the phone to replace the battery (100 % mercuryfree) or SIM card. You must not open the battery under any circumstances. All other changes to this device are strictly prohibited and will invalidate the operating licence.

Please dispose of unwanted batteries and phones as permitted by the laws in your country.

The phone may cause interference in the vicinity of TV sets, radios and PCs.

Use only Siemens original accessories. This will avoid potential risks to health or property and ensure compliance with all relevant regulations.

3Safety precautions

Phone overview4

Phone overview

Call key

Dial phone number /name displayed, take calls. Show last phone numbers dialled in standby mode.

On/Off/End key

• Switched off: Hold down to switch on.

• During a call or in use: press briefly to fin-

ish.

• In menus: Press briefly: one level back. Press and hold: return to standby mode.

• In standby mode: Hold down, to switch off phone.

3 Control key

In lists and menus:

G Scroll up and down. D C

During a call:

In standby mode:

F D C

Function call.

Back a menu level.

Open call menu.

Open Phonebook.

Open menu.

GPRS info

_ªg

Service provider

01.10.2003 10:10

NewSMS Menu

1 Integrated antenna

Do not interfere unnecessarily with the phone above the battery cover. This reduces reception quality.

2 Loudspeaker

5Phone overview

3 Display symbols

Signal strength/ GPRS available/ battery level.

4 Soft keys

The current functions of these keys are shown in the bottom line of the display as

§text§ / symbol (e.g. d) .

5Input keys

Numbers, letters.

• In standby mode: switch on/off all signal

• For incoming calls: only switch off ring

In standby mode: Switch key lock on/off-.

Press and hold

tones (except alarm).

tones.



Press and hold

8 Microphone

9 Plug socket

Connection for charger, headset etc.

_ªg

Service provider

01.10.2003 10:10

NewSMS Menu

Display symbols (selection)6

Display symbols (selection)

Display symbols

Signal strength.

Charging.

Battery charging status, e.g., 50 %.

Phonebook

Call records

Surf & Fun

Ring tones

Messages

] ~

Profiles

Extras

Own files

Setup

All calls are diverted.

Ringer off.

Short ringer (beep) only.

Ringer only, if the caller is stored

in the Phonebook.

Alarm set.

Alarm clock active.

Key lock active.

¢ ¡

p,o

ABC/

Abc/abc

™ «





Depending on the service provider, some of the symbols displayed here may differ from those in the phone.

Phone numbers/names:

On the SIM card

On the SIM card (PIN 2 protected).

In the phone memory.

No network access.

Function activated/deactivated.

Phonebook.

Indicates whether upper- or lower case letters are active.

Text input with T9.

Activated and available.

Registered.

Temporarily interrupted.

GPRS download.

WAP Online.

WAP via GPRS online.

WAP No network.

Headset active.

Auto answer feature on.

Soft keys

…



—

–





Message received.

Voice mail

Data received.

Picture received.

Melody received.

Unanswered call.

Store in Phonebook.

Retrieve from Phonebook.

received.

7Display symbols (selection)

Getting started8

Getting started

The front and back covers of the casing, as well as the keypad can be changed in a matter of seconds – no tools required (CLIPit™, p. 79). Please switch the phone off first:

Assembling

12 3

Dismantling

45 6

Additional notes

Your phone’s display and the camera lens on the back are covered with a protective film when delivered. Remove this film before getting started.

To avoid damage to the display, the phone should not be used without the top shell.

9Getting started

Insert SIM card/battery

The service provider supplies you with a SIM card on which all the important data for your subscription is stored. If the SIM card has been delivered in credit-card size, snap the smaller segment out and remove any rough edges.

• Remove the cover in the direction of the arrow

• Insert the SIM card in the opening with the contact area facing down- wards and push gently until it engages below the holder (make sure the angled corner is in the correct position

2).

• Insert the battery sideways into the phone wards

3, then press down-

4 until it engages.

• To remove, press the retaining tab

5 then lift the battery out.

• Slide cover over the phone until it latches into place.

Additional notes

Always switch off phone before removing the battery!

Only 3V SIM cards are supported. Please contact your service provider if you have an older card.

Functions without SIM card ...............p. 12

Getting started10

Charge battery

The battery is not fully charged when delivered. Plug charger cable into the bottom of the phone, plug power supply unit into a mains power socket and charge for at least

two hours.

Display when charging is in progress

h During charging.

Charging time

An empty battery is fully charged after about 2 hours. Charging is only possible within a temperature range of +5 °C to +40 °C. If the temperature rises/falls 5 °C above/below this, the charge symbol flashes a warning. The voltage specified on the power supply unit must not be exceeded.

Charge icon not visible

If the battery was fully discharged, the chargin symbol will not be immediately visible on connection to the power supply unit. It will appear after up to two hours. In this case the battery is fully charged after 3-4 hours.

Only use the charger provided! Display while in service

Charge level display during operation (empty-full):

adg

A beep sounds when the battery is nearly empty. The charge level of the battery is displayed correctly only after uninterrupted charging/discharging. You should therefore not remove the battery unnecessarily and where possible not finish the loading

process prematurely.

Additional notes

The power supply unit will become heat up after extended use. This is normal and not dangerous.

Switch on/off/ PIN

11Switch on/off/ PIN

Activate/deactivate

Hold down On/Off/End key to switch on or off.

Enter PIN

The SIM card can be protected with a 4- to 8-digit PIN.

§OK§ Confirm entry with right

Enter the PIN using the number keys. The characters ensure nobody can read your PIN on the display. Correct errors with §Clear§.

soft key. Logging on to the network will take a few seconds.

appear to

****

Please enter your

PIN:

* * * *

Clear OK

Switching on your phone for the first time

Time/Date

The clock must be set to the right time once at start-up.

§Yes§ Press.

§OK§ Press. The time and date

Time zones

Specify your current time zone.

§Set§ ... Apply it.

Additional notes

Change PIN.......................................p. 14

Clear SIM card barring ......................p. 15

Additional clock settings ....................p. 55

}

First enter the date (day/month/year), then the time (24 hours, including seconds).

are updated.

Select the desired time zone from the list ...

SIM services (optional) ..............p. 65

Switch on/off/ PIN12

Language

On start-up, you are asked to specify up to two languages for T9 input (p. 25).

To free up more space for your own pictures and sounds, the dictionaries for all unselected languages are deleted from the phone.

You can also make this selection at a later time. If you decide to do this, you will be asked to make the selection again the next time you turn on the phone.

G Select language.

§Change§ Activate/deactivate selec-

§OK§ Confirm selection.

Additional information

If all dictionaries are deleted (no language is selected), T9 input is deactivated and you cannot reactivate it.

If you want to load a dictionary in another language, you will find a large selection to download from the Internet as well as installation instructions under:

www.siemens-mobile.com/t9

Selection of Input language...............p. 25

tion. A maximum of two languages can be selected simultaneously.

Emergency number (SOS)

Only to be used in real emergencies!

By pressing the soft key §SOS§ you can make an emergency call on any network without a SIM card and without entering a PIN (not available in all countries).

Signal strength

_ Strong receive signal. ^ A weak signal reduces the

call quality and may lead to loss of the connection. Change your location.

Without SIM card

If you switch on the phone without a SIM card you can still use some phone functions.

§Menu§ Press soft key. The func-

tions are displayed.

§SOS§ Emergency, SOS.

13General Instructions

General Instructions

User guide

The following symbols are used to explain operation:

Enter numbers or letters.

B A



< >

§Menu§

On/Off/End key.

Call key.

Press the control key on the

side indicated.

Soft keys

Displays a soft-key function.

Function depends on the

service provider, special registration may be necessary.

Menu speed dialling

All menu functions are numbered internally. A function may be selected directly by entering these numbers in sequence.

E.g. write new SMS:

§Menu§ Press.

for Messages

1 for New SMS

Menu Control

The steps needed to reach a functions are shown in a condensed form in this user guide.

For example. A condensed version of the steps for

calling the call list of missed calls:

§Menu§

¢ Z ¢

This consists of the following steps:

§Menu§ Open main menu.

§Select§ Confirm.

Calls missed

Select menu Z Records, then the Calls missed function.

Standby mode

When the name of the service provider appears on the display, the phone is in standby mode and ready for use.

The left soft key may have different functions pre-assigned.

Hold down the On/Off/End key to return to standby mode from any situation.

Security14

Security

Codes

The phone and SIM card are protected against misuse by several security codes.

Keep these confidential numbers in a safe place where you can access them again if required.

PIN2

PUK PUK2

Phone code

Protects your SIM card (personal identification number).

This is needed to set the charge detail display and to access additional functions on special SIM cards.

Key code. Used to unlock SIM cards after the wrong PIN has been entered repeatedly.

Protects your phone. Must be entered at the first security setting.

§Menu§

¢m ¢

¢ ¢

Security

Codes

Select a function

PIN control

The PIN is usually requested each time the phone is switched on. You can deactivate this feature but you risk unauthorised use of the phone. Some service providers do not permit deactivating the control.

§Select§ Press.

J Enter PIN.

§OK§ Confirm input.

§Change§ Press.

§OK§ Confirm.

Change PIN

You can change the PIN to any 4-8 digit number you may find easier to remember.

J Enter current PIN.

§OK§ Press.

§OK§ Enter new PIN.

§OK§ Re-enter new PIN.

15Security

§Menu§

¢m ¢

¢ ¢

Security

Codes

Select a function

Change PIN2

(Display only if PIN 2 is available). Proceed as with Change PIN.

Change phonecode

You define the phone code (4-8 digits) when you call up a phone-code protected function for the first time (e.g. direct call p. 22). It is then valid for all phone-code protected functions. Following the third unsuccessful attempt, access to the phone code and the functions that use it is denied. In such an instance contact Siemens Service (p. 74).

Clear SIM card barring

If the PIN is entered incorrectly three times, the SIM card is barred. Enter the PUK (MASTER PIN), provided by your service provider with the SIM card, according to instructions. If the PUK (MASTER PIN) has been lost, please contact your service provider.

Preventing accidental activation

Even if PIN entry is deactivated (p. 14) confirmation is required to switch on phone.

This prevents accidental activation of the phone, e.g. when you are carrying it in a bag or when you are travelling in an aircraft.

§OK§ Press. The phone switches

§Cancel§ Press or take no action.

Additional notes

Screensaver ......................................p. 51

Key lock...............................................p. 5

Further security settings ....................p. 57

Hold down:

Please confirm switch on

OK Cancel

on.

The phone does not switch on.

My phone16

My phone

Change your phone to match your personal requirements.

Ring tones

Assign individual ring tones to caller groups or for special dates (p. 63).

Own greeting

Select a customised greeting (p. 50).

Screensaver

Choose a digital clock or a personal picture (p. 51).

(Provider) Logo

Choose an individual picture (to be displayed in standby mode) (p. 50).

Wallpaper image

Choose your own permanent wallpaper image (p. 50).

Colour scheme

Choose a colour scheme for the entire service system (p. 50).

Where do I get what?

You can order additional ring tones, logos and screensavers on the Internet at

www.siemens-mobile.com

and receive them via SMS or download them directly via WAP:

wap.siemens-mobile.com

Siemens City Portal

You can find additional services for your mobile phone at:

www.siemens-mobile.com/city

The Siemens City Portal also offers a list of countries in which these services are available.

17Making a phone call

Making a phone call

Dialling with number keys

The phone must be switched on (standby mode).

End call

Set volume

G Set volume and confirm

If a Car Kit is used, its volume setting will not affect the usual setting on the phone.

Dial number (always with area code, if necessary with international dialling code).

§Clear§ A short press clears

the last digit, a long press clears the entire phone number.

Press the Call key. The phone number displayed is dialled.

Press the End key briefly. The call is ended. Press this key even if the person on the other end of the line has hung up first.

Use the control key (top) to start adjusting the volume during conversation.

with §OK§.

Redial previous numbers

To redial the phone number last called:

To redial other numbers that were dialled previously:

Press the Call key twice.

Press the Call key once.

Pick out the required phone number from the list, then press ...

A Press ...

Sendcontrol code (DTMF)

You can, for example, enter control codes (numbers) for remote access to an automatic answering machine while another connection exists. These entries are transmitted directly as DTMF codes (control codes).

y menu§ Open the call menu.

Send DTMF

Select.

Making a phone call18

Additional notes

 Save number in Phonebook

save ..................................................p. 28

§Options§ call lists ............................p. 34

§Hold§................................................. p. 20

§Divert§ Set divert .............................p. 53

y menu§ Call menu.........................p. 22

§Handsfr.§ Handsfree .......................p. 19

Microphone off ..................................p. 22

Key lock...............................................p. 5

Transmit phone number on/off

(Hide ID)............................................ p. 52

International dialling codes

§+List§ Press and select country.

Phone number memo

You can use the keypad to enter a phone number during a conversation. The person to whom you are speaking can hear these entries. When the connection has ended you can save or dial the phone number.

Hold down until a "+"-is displayed.

When a number is busy

If the called number is busy or cannot be reached because of network problems several options are available (depending on the service provider). An incoming call or any other use of the phone interrupts these functions.

Either

Auto. Redial previous numbers

§Auto dial§ Press. The phone number

is automatically dialled ten times at increasing time intervals. End with:

B End key.

Call back b

§Call back§ Press. Your phone rings

when the busy number is free. Press the Call key to dial the number.

Reminder

§Prompt§ Press. A beep reminds you

to redial the displayed phone number after 15 minutes.

19Making a phone call

Accept call

The phone must be switched on (standby mode). An incoming call will interrupt any other use of the phone.

+5552764556

Answer Reject

§Answer§ Press.

A Press.

If the phone number has been transmitted by the network, it is displayed. If the caller's name also appears in the Phonebook, this will appear instead of the number. If set, a picture can be displayed instead of the bell icon (p. 30).

Warning

Please make sure you have accepted the call before holding the phone to your ear. This will prevent a loud ring tone from damaging your hearing!

Reject call

§Reject§ Press. The call will be

diverted if this has been set previously (p. 53).

B Press briefly.

Additional notes

 Missed calls.................................p. 34

Accept call using any key ..................p. 52

Switch off ringer...................................p. 5

Handsfree

You can put the phone aside during a call. You can then hear the caller via the loudspeaker.

Carol

Handsfr.  menu

§Handsfr.§ Activate handsfree func-

§Yes§ Switch on.

tion.

Making a phone call20

Handsfr.  menu

§Handsfr.§ Switch off.

Warning! Always switch off "handsfree talking"

before holding the phone to your ear! This will avoid damage to your hearing.

y menu§ Call menu ..........................p. 22

Use the control key to adjust the volume.

Swapping between 2calls

Establish a second connection

You can call another number during a call.

y menu§ Open the call menu

Hold The current call is put on

Now dial the new phone number (Phonebook F).

When the new connection is established:

y menu§ Open the call menu

Swap Swap back and forth

• End current call

hold.

Call held

between both calls.

End the current call and confirm with §Yes§. You are now connected to the caller.

Back

21Making a phone call

Incoming calls during a call

You may need to register for this service with your service provider and set your phone accordingly (p. 52).

During a call, you may be advised that there is another call waiting. You will hear a special tone during the call. You have the following options:

• accept the waiting call

§Swap§ Accept the waiting call,

• Reject waiting call

§Reject§ Reject the waiting call.

§Divert§ The waiting call is

putting the current call on hold to do so. Always proceed as above to swap between the two calls.

Ending call(s):

Press the End key following query is displayed: Return to held call?

Accept the waiting call by pressing §Yes§.

End the second call also by pressing §No§.

diverted, for example, to the mailbox.

. The

• Accept the waiting call and end the current call

§Answer§ Accept new call.

End the current call.

Conference b

Call up to 5 parties one by one and link them together in a conference call. Some of the functions described may not be supported by your service provider or may have to be enabled specially. You have established a connection:

y menu§ Open the menu and select

y menu§ ... Open the menu and

Repeat procedure until all participants are linked together (up to 5participants).

End

Hold. The current call is

put on hold. Now dial a new number.

When the new connection is established ...

select Conference. The held call is joined.

All calls in the conference are ended simultaneously when the End key is pressed .

Making a phone call22

Call menu

The following functions are only available during a call:

y menu§ Open menu.

Hold Microphone

Handsfree Volume Conference Durat/charges

Send DTMF Call transfer

Main menu

Call status

(p. 20)

Switch microphone on/off. If switched off, the person on the other end of the line cannot hear you (muting).

* Hold down.

Also:

(p. 19)

Adjust handset volume.

(See above)

Display call duration and (if set, p. 35) costs accruing during the call.

(p. 17)

The original call is connected to the second one. For you, both calls are now ended .

Access to the main menu.

List all held and active calls (e.g. conference call participants).

Direct call

If this is active, only one phone number can be dialled.

Switch on

§Menu§ ¢ m ¢ Security

¢ Direct call

§Select§ Press.

When first prompted you define and enter the phone code (4- to 8-digit). Please ensure you take a note of the code (see also p. 15).

§OK§ Confirm input.

§Change§ Press.

·/J Select phone number

§OK§ Confirm "On".

Enter phone code.

from Phonebook (p. 29) or enter again.

Apply

23Making a phone call

Service provider

01.10.2003 10:10

Carol

> Use the right soft key and

hold it down to dial (e.g. Carol's phone number).

Switch off

 Hold down:

J Enter phone code.

§OK§ Confirm input.

§Change§ Press.

§OK§ Confirm "Off".

Additional notes

Change phone code..........................p. 15

Text entry24

Text entry

Text entry without T9

Press number key repeatedly until the required letter appears. The cursor advances after a short delay. Example:

Ä,ä,1-9 Umlauts and numbers are

§Clear§ Press briefly to delete the



Pressing briefly once types the letter a, twice the letter b, etc.

Hold down to write the number.

displayed after the relevant letters.

letter before the cursor, hold down to erase the whole word.

Move the cursor (forwards/back).

Press briefly: Swap between abc, Abc, T9abc,

Abc, T9ABC, 123. Status

indicator in the top line of the display.

Hold down: All input modes are displayed.

Press briefly: Special characters are shown.

Hold down: Open input menu.

Press once/repeatedly:

. , ? ! ’ " 0 - ( ) @ / : _

Hold down: Writes 0.

Writes blank. Press twice = skip line.

Special characters

) ¿¡_;.,?!+-

"’ : €@\ &#[] {}%~ <=> | ^ § Γ ∆ Θ Λ Ξ

Π Σ Φ Ψ Ω

) Line skip

G,H Navigate to characters.

§Select§ Press.

Press briefly. The character map is displayed:

* /()

¤¥

25Text entry

Input menu

With text input:

Hold down: The input menu is displayed:

Text format (SMS only) Input language Mark text Copy/Add

Text entry with T9

T9 deduces the correct word from the individual key entries by making comparisons with an extensive dictionary.

Activate, deactivate T9

§Options§ Open text menu.

T9 input Select. T9 preferred

§Change§ Activate T9.

Select Input language

Select the language in which you want to compose your message.

§Options§ Open text menu.

T9 input Select. Input language

Select.

§Select§ Confirm, the new lan-

§Delete§ Delete T9 dictionary for

guage is set. Languages with T9 support are marked by the T9 symbol. You can specify which languages are T9-supported when you first turn on your phone (see also p. 12).

the selected language.

Create a word using T9

Since the display changes as you proceed,

it is best if you finish a word without looking at the display.

Simply press the keys once only where the relevant letter is located. For "hotel", for example:

Press briefly for T9Abc



then

4 6 8 3 5

Do not use special characters such as Ä but rather use the standard characters, e.g. A; T9 will do the rest for you.

Press. A blank ends a word.

Text entry26

Additional notes



Setting a full stop. Word is ended when followed by a blank space. Within a word, a full stop represents an apostrophe or hyphen:

e.g. §provider.s§ = provider’s. Move to the right. Ends a word.

Press briefly: Swap between:

abc, Abc, T9abc, T9Abc, 123.

Status indicator in the top line of the display .

Hold down: All input modes are displayed.

Press briefly: Select special characters (p. 24).

Hold down: Open input menu (p. 25).

T9 word suggestions

If several options are found in the dictionary for a key sequence (a word), the most probable is displ ay ed fi rst. If the wo rd yo u wan t ha s not been recognised, the next suggestion from T9 may be correct.

The word must be displayed as

§inverted§. Then press

If the word you wa nt is not in the dictionary, it may be written without T9.

To add a word to the dictionary:

§Spell§ Select.

The last suggestion is deleted and the word may now be entered without T9 support. Press §Save§ to add it automatically to the dictionary.

buttons. The displayed word is replaced with a different word. If this word is also incorrect,

buttons. Repeat until the correct word is displayed.

™

SMS 1 748

Spell

___

At 8 h we are

27Text entry

Correct a word

Words written with T9:

§Clear§ Deletes the character to

Words not created using T9:

§Clear§ Deletes the letter to the

Additional notes

Within a "T9 word", individual letters may not be edited without removing T9 first. In most cases it is better to rewrite the complete word.

T9® Text Input is licensed under one or more of the following: U.S. Pat. Nos. 5,818,437, 5,953,541, 5,187,480, 5,945,928, and 6,011,554; Canadian Pat. No. 1,331,057; United Kingdom Pat. No. 2238414B; Hong Kong Standard Pat. No. HK0940329; Republic of Singapore Pat. No. 51383; Euro.Pat. No. 0 842 463 (96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE, GB; and additional patents are pending worldwide.

Move left or right, word by word, until the required word is §inverted§.

Scroll through the T9 word suggestions again.

the left of the cursor and displays a new possible word!

Move letter by letter to the left/right.

left of the cursor. Letters are inserted at the

cursor position.

Predef. texts

The phone contains predefined texts that you can add to your messages (SMS). You can also create and store up to 5 personal stored texts. Each stored text can contain up to 32 characters.

Unlike personal stored texts, predefined texts cannot be changed or deleted.

Write personal stored texts

§Menu§ ¢ ] ¢ Predef. texts

§Options§ <New entry> Select.

§Save§ Press. The text is saved.

Use predefined texts

§Options§ Open text menu.

G G

§Select§ Confirm. The predefined

Write personal stored text.

Write message text (SMS).

Select Predef. texts.

Select predefined text from the list.

text is inserted into the text to the left of the cursor.

Phonebook28

Phonebook

Enter frequently used phone numbers in the Phonebook with a special name. To dial them, simply highlight the name. If a phone number is stored with a name, it appears on the display when you are called. Important numbers can be assigned to different groups.

<New entry>

§Select§ Display of entry fields.

G J

Open Addressbook (in standby mode).

N Phonebook Ú

Select

Select input field.

Fill in input field. The maximum number of characters available is shown at the top of the display.

Number:

Always enter phone number with an area dialling code.

Name:

Enter first and/or last names.

Group:

Default: No group

§Change§ Entries can be organised

Family, Friends, VIP, Other Location:

Default: SIM

Record no.:

Each entry is automatically assigned a record number. You can also dial using the record number (p. 29).

§Save§ Press to store the new

Additional Information

§+List§ International dialling code......p. 18

Store control codes............................p. 33

Text entry ..........................................p. 24

by groups, (p. 32) e.g.:

Select location: Mobile, SIM or Protected SIM (p. 31).

Change the record number.

entry.

29Phonebook

Call (search for an entry)

Call using record no.

A record number is automatically assigned to every new entry in the Phonebook.

 A

Open Phonebook.

Select a name with the

first letter and/or scroll. Number is dialled.

Enter input number.

Press.

Edit entry

§Options§ Press and select Edit.

G J

§Save§ Press.

Select entry in Phonebook.

Select desired input field.

Make change.

Phonebook menu

The following functions are available, depending on the current situation. Some functions may be applied to the current entry as well as multiple highlighted entries:

§Options§

View Edit New entry Delete Delete all


Send SMS...

Capacity

Open menu.

Display entry.

Open entry for editing.

Create new entry.

Delete entry.

Delete all entries after confirmation.

Assign a picture to a Phonebook entry.

Send as Phonebook entry or text.

Display maximum and available free capacity.

Phonebook30

Assign picture

Assign a max. of 50 phone numbers to an individual picture. This picture will appear in the display when there is a call from this number.

§Options§ Open menu.

§Open§ Picture is displayed.

§Select§ The picture is assigned to

Open Phonebook.

Select entry.

Select Picture. A picture list is displayed.

Select picture.

the phone number and it appears with a in the Phonebook.

› symbol

Delete/change image

If a picture is assigned to a phone number, it can be deleted or replaced.

§Options§ Press.

§Select§ Select

§Delete§ The assignment is cleared

Additional notes

One picture can be assigned to multiple phone numbers.

Add pictures ......................................p. 69

Siemens City Portal ...........................p. 16

Select entry with picture

›

in Phonebook.

p Picture.

after confirmation.

31Phonebook

<Special books>

Enter "own" phone numbers in Phonebook (e.g., fax) for information. These numbers can be changed, deleted and also sent as an SMS message.

There might be phone numbers saved in your Phonebook that have been provided by your service provider. They may be used to call local or national information services or to use services offered by your service provider.

<SIM phonebook> (Standard)

Entries that are stored in the Phonebook on the SIM card can also be used on a different GSM phone.

Open Phonebook.

Select.

<Protected SIM> b

On special SIM cards, phone numbers can be stored in a protected location. PIN 2 is required for editing (p. 15).

Activate with the function Only ‚ (p. 57).

Phonebook entries are stores in the phone memory if the SIM card is full.

Phone number addition in Phonebook.

Digits may be replaced by a "?" when phone numbers are entered in the Phonebook:

* Hold down.

These wildcards must be replaced with numbers before dialling (e.g., with the extension numbers in a phone system).

To make a call, select the phone number from the Phonebook.

A Press. J A

Replace "?" with digits.

Press, number is dialled.

Phonebook32

Groups

Four groups are specified in your phone to enable you to arrange your Phonebook entries clearly. You can rename these groups.

<Groups> Select (the number of

§Select§

§Rename§ Select and give group a

Additional notes

No group: Contains all Phonebook entries

that do not belong to a group (name cannot be changed).

SMS to group ....................................p. 40

Open Addressbook (in standby mode).

entries is listed behind the group name).

N Groups

Family (5)

Friends (23)

VIP (11)

Rename Select

Select a group.

Open group.

name.

Groups menu

§Options§

Open menu. See "Phonebook menu", p. 29, for details.

Ring tone for group

If you assign a ring tone to a group, it sounds when one of the group members rings.

§Menu§

¢ ç ¢Group calls

§Select§ Confirm.

Select a group.

Select ring tone.

Control codes (DTMF)

You can, for example, enter control codes (numbers) for remote access to an automatic answering machine while a connection exists. These entries are transmitted directly as DTMF codes (control codes).

y menu§ Open the call menu.

Send DTMF Select.

Use Phonebook

Store phone numbers and control codes (DTMF codes) in the Phonebook in the same way as a normal entry.

§Save§ Press.

You may also store just the DTMF codes (numbers) and then send them during the call.

Enter phone number.

Press until a "+" appears in the display (wait for the connection to be established).

Enter DTMF codes (numbers).

If necessary, wait again for three seconds at a time for the receiver to process the entries safely.

Enter a name.

33Phonebook

Records34

Records

Your phone stores the phone numbers of calls for convenient redialling.

§Menu§

§Select§ Press.

G Select call list.

§Select§ Press.

G Select phone number. A Dial phone number.

§View§ Display information on

10 phone numbers can be stored in each call list:

Calls missed

The phone numbers of calls that you have received but not answered are stored for call back purposes.



Requirement: The network supports the "Caller Identity" feature.

¢ Z

the phone number.

Icon for missed call (in standby mode). Press the control key (on the left) to display phone number.

Calls received

Accepted calls are listed.

Calls dialled

Access to the last numbers dialled.

Erase records

The records are deleted.

Call list menu

The call list menu can be called up if an entry is highlighted.

§Options§ Open list menu.

View Correct no.

Copy into d Delete

Delete all

Fast access in standby mode.

Read entry.

Load number into display and correct it there if necessary.

Save entry in Phonebook.

Delete entry after confirmation.

Delete all entries of the call list after confirmation.

35Durat/charges

Durat/charges

You can display charge details and the duration of different types of calls while you speak, as well as setting a unit limit for outgoing calls.

§Menu§

¢Z ¢ Durat/charges

Select type of call:

Last call All outgoing All incoming Remain. units

§Select§ Display data.

When displayed, you can:

§Reset§ clear display.

§OK§ end display.

Charge sett.

§Menu§ ¢

Conv.

(PIN 2 prompt)

Enter the currency in which the charge details are to be shown.

Personal rate

(PIN 2 prompt)

Enter the charges per unit/period.

¢ Durat/charges

Charge sett.

A/c limit

(PIN 2 prompt)

Special SIM cards allow you or the service provider to define a credit or period after which the phone is barred for outgoing calls.

§Change§ Press, enter PIN 2.

A/c limit Switch on.

§OK§ Confirm.

Then confirm the credit or reset the counter. The status display for prepaid cards may vary, depending on the service provider.

Auto display

Call duration and call charges are automatically displayed for each call.

Enter number of units.

Voice mail/mailbox36

Voice mail/mailbox

§Menu§ ¢ ] ¢ Msg. setup

Voice message

Most service providers offer you an external answering service. In this mailbox, a caller may leave a voice message for you

• if your phone is switched off or not ready to receive,

• if you do not want to answer,

• if you are making a phone call (and Call Waiting is not activated, p. 52).

If voice mail is not part of your service provider's package, you will need to register and settings may have to be made manually. The procedure described below may vary slightly depending on the service provider.

Settings: b

Your service provider supplies you with two phone numbers:

Save mailbox number

You call this phone number to listen to the voice mails left for you.

§Menu§

¢] ¢ Msg. setup

Voice message

/JSelect or enter/change

§OK§ Confirm.

Save call divert number

Calls are diverted to this phone number.

§Menu§

Enter call divert number.

§OK§ Registration with net-

Further information on call divert can be found on p. 53.

phone number

¢m ¢ Divert

e. g. Unanswered ¢ Set

work. Divert will be confirmed after a few seconds.

Play back messages b

A new voice mail can be announced as follows, depending on the service provider:

\ Icon including beep.

…

You receive a call with an automatic announcement.

Call your mailbox and play the message(s) back.

Outside your home network, you may need to dial a different mailbox number and enter a password to access your mailbox.

An SMS message announces a new voice mail.

Hold down (if necessary enter mailbox number once only). Depending on your service provider confirm with §OK§ and

§Mailbox§.

37Voice mail/mailbox

SMS38

SMS

You can transmit and receive very long messages (up to 760 characters) on your phone. They are automatically composed of several "normal" SMS messages (note higher charges).

Additionally you can insert pictures and sounds in an SMS.

Depending on the service provider, e-mails and faxes can also be sent and e-mails received via SMS (change setting if necessary, p. 43).

Writing and sending text messages (SMS)

§Menu§ ¢ ] ¢ New SMS

Text input using "T9" (p. 25) allows you to create longer messages very quickly using just a few key strokes.

§Clear§ Press briefly to

delete letter-by-letter, hold down to delete by word.

A Press.

/JDial number or pick out

from the Phonebook.

§Group§ SMS to group

(p. 40).

§OK§ Confirm. Send the SMS to

§OK§ Back to text input.

Display in the uppermost line:

™

abc/Abc/ ABC/123

SMS 1

739

Additional notes

Insert pictures & sounds into text.......p. 39

SMS profile........................................p. 43

The following may be Message type,

Validity period, Service centre

queried ..............................................p. 43

Enter special characters ....................p. 24

the service centre for transmission. The sent SMS is saved in the "Sent" list.

SMS

™

We start at 8 a.m.

T9 active.

Switch between uppercase/lower-case letters and digits.

Display title.

Number of the required SMS messages.

Number of characters still available.

1 739

39SMS

Text menu

§Options§ Open text menu.

Send

Save

Picture&sound

Predef. texts

Format Line feed

Clear text Insert from...

T9 input

(p. 24)

Send via ...

Enter recipient's phone number/retrieve it from the Phonebook, then send.

Save composed text in draft list.

Add pictures, animations and sounds into message (see following text).

Predef. texts insert (p. 27).

Small font, Medium font, Large font

Underline Def. alignment: Left,

Right, Centre (align) Mark text (highlight text

using control key)

Delete the whole text.

Insert entry from Phonebook.

T9 preferred Acti-

vate/deactivate T9 input.

Input language Select

language for text.

Select an SMS profile for transmission (p. 43).

Picture&sound

Insert pictures and sounds into message.

§Options§ Open text menu at the

§Select§ Confirm.

For Fix animations/Fix sounds:

§Select§ The selection is added to

For Own anim./Own pictures/Own

sounds:

§Load§ The selection is dis-

§Select§ The selection is added to

Write message.

end of a word. Select Picture&sound . The menu contains:

Fix animations Fix sounds Own anim. Own pictures Own sounds

Select area.

The first entry of the selected area is displayed.

Scroll to entry required.

the SMS.

played/played back.

the SMS.

SMS40

Additional information EMS (Enhanced Messaging Service)

This service allows you to send pictures and sounds as ring tones and screensavers (except formatted text). Playback only occurs if the destination phone supports the EMS standard.

This can result in messages that are longer than a single SMS. If this happens the individual SMS messages are linked together to form a single message.

SMS status report

If the message cannot be transmitted to the service centre you are offered the chance to repeat the transmission. If this also fails, contact your service provider.

The Message sent! message only indicates transmission to the service centre. This will then attempt to relay the message within a certain period.

SMS to group

You can send an SMS message as a "circular" to a recipient group.

§Options§ Open menu.

Send Select.

§Group§ Press. The Phonebook is

opened. There are the following options:

• Highlight individual entries.

• Select <Groups>, open a group and

highlight individual entries/all entries there.

• Select <Groups>. Select a group.

§Send§ Press. The first of the

highlighted recipients is displayed. If this recipient has several phone numbers, one number can be selected.

§Skip§ Skip recipient.

§Send§ Transmission is started

after confirmation.

41SMS

Receiving SMS

…

Arrival of new SMS announced on display.

Service provider

01.10.2003 10:10

…

< To read the SMS, press left

soft key.

Date/time

No./sender

Message

§Reply§ See below.

§Options§ See p. 42.

01.10.2003 10:10

55536989876

What about meeting tomorrow?

Reply Options

Scroll through message line by line.

Phone number/URL in SMS

Phone numbers §inverted§ in the text can be dialled or saved in the Phonebook. You can also mark URLs (Internet addresses), call them directly and run them. To this end the WAP profile (p. 48) must be set and activated.

Press to dial phone number/download.

T Message memory full

If the message icon flashes the SIM memory is full. No more SMS messages can be received. Delete or file text messages (p. 43).

Reply menu

§Reply§ Open reply menu.

Write mess.

Edit

Answer is YES Answer is NO Call back

Delay Thank you

Once the SMS has been edited, it can be saved or sent with §Options§.

Create a new reply text.

Edit received SMS or add new text.

Add YES to the SMS. Add NO to the SMS.

Add a standard text as a reply to the SMS.

SMS42

Lists

All SMS messages are stored in one of the following lists according to status.

Inbox

§Menu§ ¢ ] ¢ Inbox

The list of received SMS messages is displayed.

]

Inbox

ƒ 0555123454 … Carol … Mike

View Options

Outbox

§Menu§ ¢ ] ¢ Outbox

The list of sent SMS messages is displayed.

Lists menu

Each list offers different functions:

§Options§ Open menu.

View Reply

Delete

Delete all

Send

Edit

Capacity

Mark a.unread

Save to d

SMS archive

§Menu§ ¢ ] ¢ SMS archive

The list of SMS messages stored in the phone is displayed.

Unread.

…

Read

Draft.

‚

Sent.

„

Entry on SIM card.

Concatenated message.

Different functions are available depending on the context:

Archive menu

§Options§ Open menu.

View Send

Edit

Read entry.

Dial number or select from the Phonebook, then send.

Open text input for editing.

SMS profiles

§Menu§ ¢

A maximum of 3 SMS profiles can be set. They define the transmission characteristics for an SMS. The presetting depends on the SIM card inserted.

]

¢ Setup

¢ SMS profiles

G Select profile.

§Options§ Open menu.

Change sett.

Service centre

Recipient

Message type

Select.

Enter or change the servicecentre phone numbers as supplied by service provider.

Enter the standard recipient for this transmission profile or select from the Phonebook.

Manual

The message type is requested for each message.

Standard text

Normal SMS message.

Fax

Transmission via SMS.

E-mail

Transmission via SMS.

New

You may need to obtain the required code number from your service provider.

SMS44

Validity period

Status report

Direct reply L

SMS via GPRS

Save aft. send

Activate profile

Select the period in which the service centre tries to deliver the message:

Manual, 1 hour, 3 hours, 6 hours, 12 hours, 1 day, 1 week, Maximum

* Maximum period that the service provider permits.

You will receive confirmation whether delivery of a message has been successful or unsuccessful. This service may be subject to a charge.

The reply to your SMS message is handled via your service centre when Direct Answer is activated (for information please contact your service provider).

Send SMS automatically by GPRS (if available).

Requirement: GPRS is activated (p. 56). Ensure that your service provider offers this function.

Sent SMS messages are saved in the Sent list.

G Select profile.

§Activate§ Press to activate profile.

T9 settings

§Menu§ ¢ ] ¢ Setup

¢ Select a function.

T9 preferred

Activate/deactivate intelligent text entry (see also p. 25).

Input language

Select language for text entry. Languages with T9 support are marked by the T9 symbol(see also p. 12).

45CB services

CB services

§Menu§ ¢ ] ¢ Msg. setup

¢ CB services

Some service providers offer information services (info channels, Cell Broadcast). If reception is activated, your Topic list will supply you with messages on the activated topics.

Receive CB

You can activate and deactivate the CB service. If the CB service is activated, standby time for the phone will be reduced.

CB messages are displayed in standby mode, longer messages are automatically scrolled.

Topic list

Enter these in your list of interesting topics.

New topic Select.

Enter topic with channel number and name and confirm with §OK§ .

§Channel: Select

§Options§ Open list menu.

If a topic is selected in the list you can view it, activate/ deactivate it, edit it or delete it.

To switch to "full page view":

 press, then press §View CB§.

Displays

p,o Topic activated/deactivated.

…

New messages received on the topic.

ƒ Messages already read.

Surf & fun46

Surf & fun

Internet browser (WAP)

§Menu§ ¢

Get the latest information from the Internet that is specifically adapted to the display options of your phone. Internet access may required registration with your service provider.

Home b

A connection is established with the Internet provider’s portal (may be specified/configured by default by your service provider).

Bookmarks

List of URLs for fast access.

Internet b

The browser is activated as soon as you call up the function. The functions of the soft keys vary, depending on the internet page, for example "link" or "menu". The contents of the option menus are also variable. If necessary, set the way in which WAP access should be made (see browser

menu, Setup, Start with..., p. 47).

¢ Select function

For example the start menu appears:

Í Start menu É 1 Home

2§Bookmarks§

Resume

Select

§Select§ Confirm.

Select desired function.

Start menu

Home

Bookmarks

Resume

Inbox

Profiles

Exit browser

The connection to the Internet provider's portal is established (may be set/preset by the service provider).

List of URLs for fast access.

Call up recently visited pages that are still in the memory.

Inbox for messages from the WAP server (WAP push).

The list of profiles is displayed for activation/setting (p. 48).

Close the browser and shutdown the connection.

47Surf & fun

End connection

Your Internet browser is licensed by:

Hold down to clear down the connection and close the browser.

Browser menu

If the browser is active, the menu can be activated as follows:

Home

Bookmarks

Resume

Go to...

Press

Í confirm.

A connection is established with the Internet provider’s portal (may be specified/configured by default by your service provider).

Up to 50 URLs stored in the phone for fast access.

Call up recently visited pages that are still in the memory.

Enter URL to access WAP page directly, e.g.

wap.siemens-mobile.com

Select from list of most recently visited WAP addresses.

Reload Inbox

Disconnect Save bitmap

More ... Exit browser

Reload page.

Inbox for messages from the WAP server (WAP push).

End connection.

Save picture(s) of displayed page.

See below.

Close the browser and shutdown the connection.

More ... (in menu)

Profiles

Setup Font size

The list of profiles is displayed for activation/setting (p. 48).

Protocol parameters

•Push

• Push can force online

• Timeout for unanswered network requests

Security

• Secure prompt

• Current certificate

• CA certificates

• Private Key PINs

• Authentication

Start with...

•Start menu

• Browser menu

•Home

•Resume

• Bookmarks

Surf & fun48

Reset

About Openwave

Additional notes

Í Browser menu.

Restart session and clear cache.

Display browser version.

É Offline. Ê Online. Ë GPRS online.

Ì No network.

Select special characters, such as @, ~, \ , see p. 24

0 press repeatedly for:

. , ? ! ’ " 0 - ( ) @ / : _

WAP profiles

¢É

§Menu§

Preparation of the phone for WAP Internet access depends on your service provider:

• The settings have already been installed by your provider. You can start immediately.

• Access profiles for a number of service providers have already been set. Then select and activate profile.

• The access profile must be set manually.

Check with your service provider if necessary.

Profiles

Internet

Activate WAP profile

You can change the current profile each time before accessing the Internet.

§Select§ Activate. The current pro-

WAP profile setting

Up to 5 WAP profiles can be configured (may be limited by the service provider). The specifications may vary according to service provider:

Select profile.

file is selected.

G Select profile.

§Edit§ Open to make settings.

Profile name

WAP param.

IP address: Port: Homepage:

GPRS lingertime

CSD lingertime

Conn.profile:

§Save§ Save settings.

Enter/change name.

Enter IP- address.

Enter port number.

Enter homepage, if not set by the service provider.

Time in seconds after which a connection should be ended if no input or data exchange takes place.

Select or set access profile (p. 56).

Games

The phone includes a number of games. Select the desired game from the list.

§Menu§

¢É ¢ Games

Select game.

There are special instructions and/or notes in the Options menu of each game.

Key control

6 9

4 7

Function depends on the game.

49Surf & fun

or with the key

Setup50

Setup

Display

§Menu§

Select a function.

Language

Set the language of the display text. When "automatic" is set, the language of your home service provider is used. If a language that you do not understand happens to be set, the phone can be reset to the language of your service provider with the following input (in standby mode):

* # 0 0 0 0 #

Wallpaper

Set wallpaper graphic for display or .

Download new

Download new wallpaper images from the Internet.

Display

Logo

Choose picture to be displayed instead of the provider logo, or

Download new

Download new logo from the Internet.

Colour scheme

Select colour scheme for the user interface.

Activate colour scheme

§Activate§ Activate.

Select colour scheme.

Own greeting

Enter greeting to be displayed instead of animation when phone is switched on.

§Change§ Switch on/off.

§OK§ Confirm changes.

Delete old greeting and create new greeting.

§Menu§

Select a function.

Display

Big letters

You can choose between two font sizes for the display.

Illumination

Set display light brighter/darker. The darker the setting the longer the standby time.

Press the control key repeatedly to adjust up or down.

Contrast

Set display contrast.

Press the control key repeatedly to adjust up or down.

Screensaver

§Menu§

The screensaver shows a picture on the display as soon as a period that can be set by you has elapsed. The function is ended by an incoming call or by pressing any key.

Enable

Style

Preview Timeout

Code protect.

Additional notes

You can also receive individual logos and screensavers by SMS (p. 38) or WAP (p. 46). See also Own stuff, (p. 69) and

My phone, (p. 16).

Screensaver

Activate/deactivate screensaver.

Digital clock, Bitmap or Energy saving.

Display the screensaver.

Set period after which the screensaver starts.

Phone code protected termination of the screensaver.

51Setup

Setup52

Call setup

§Menu§

Select a function.

Call setup

Hide ID b

When you make a call, your phone number can be displayed on the recipient's display (depending on the service providers).

To suppress this display, you can enable the "Hide ID" mode for all subsequent calls or just for the next call. You may need to register separately with your service provider for these functions.

Call waiting b

If you are registered for this service, you can check whether it is set and you can activate/deactivate it (see also p. 20).

Any to answer

Incoming calls can be accepted by pressing any key

(except for

Minute beep

During the call, you will hear a beep after each minute as a reminder of the time elapsed. The recipient does not hear this beep.

Car Kit

Only in combination with an original Siemens handsfree Car Kit (p. 80). If an original Siemens Car Kit Portable is used the profile is activated automatically as soon as the phone is inserted into the cradle.

Auto answer

(factory default: off)

Calls are accepted automatically after a few seconds. Eavesdropping is possible!

Auto phone off

(factory default: 2 hours)

The phone is powered by the car. The time taken for the phone to switch off when the ignition is turned off can be configured.

Car loudspeaker

Select another audio setting as needed for your car kit for better acoustics.

Automatic settings:

• Permanent illumination:

• Key lock: switched off.

• Charging the phone battery.

• Automatic activation of the Car Kit

Shown on the display.

switched on.

profile when phone is inserted in cradle.

§Menu§

Select a function.

Call setup

Headset

Only in conjunction with an original Siemens headset (p. 79). If an original Siemens Headset is used the profile is automatically activated when the headset is plugged in.

Auto answer

(factory default: off) Calls are accepted automatically

after a few seconds (except where the ringer is switched off or set to beep). You should therefore be wearing the headset. Eavesdropping is possible!

Automatic setting

Accept call with the Call key or PTT key (Push To Talk) when the key lock is activated.

Auto answer

If you do not notice that you phone has accepted a call, there is the danger that the caller may eavesdrop.

Divert

§Menu§

You can set the conditions for which calls are diverted to your mailbox or other numbers.

Select a function.

Divert

Set up call divert (example):

The most common condition for call divert is, for example:

All calls

All calls are diverted.

Unanswered

§Select§ Press.

Set Select.

Symbol in the top line of the display in standby mode.

Select Unanswered. (Includes the conditions

Not reachable, No reply, Busy see below)

Enter the phone number to which the caller will be diverted (if not already done)

· Select this phone number

from the Phonebook or via §Mailbox§.

§OK§ Confirm. After a short

pause, the setting is confirmed by the network.

53Setup

Setup54

Not reachable

Di ve rt o cc urs if p ho ne i s s wit ch ed o ff or is out of range.

No reply

A call is only diverted after a delay that is determined by the network. The period can be set to a maximum of 30 seconds in 5 second intervals.

Busy

Divert occurs if a call is in progress. If

Call waiting is activated (p. 52), you

will hear the call waiting tone during a call.

Status check

You can check the current divert status for all conditions.

After a short pause, the current situation is transmitted by the network and displayed.

p Condition set. o Not set.

Clear all

All set diversions are cleared.

Display if status is unknown (e.g. with a new SIM card).

Additional notes

Note that the divert is stored in the network and not in the phone (when the SIM card is changed for example).

Check condition or delete it

First select the condition.

§Select§ Press.

Check status

Delete Select.

Reactivate divert

The last divert has been stored. Proceed as with Setting. The stored phone number is displayed. Confirm phone number.

Edit phone number

Proceed as with "Set divert". When the stored phone number is displayed:

§Delete§ Press. The phone number is

Enter new number and confirm.

Select.

deleted.

55Setup

Clock

§Menu§

Select a function.

Time/Date

The clock must be set correctly once at start-up.

§Change§ Press.

Additional notes

If the battery is removed for longer than 30 seconds, the clock must be reset.

Setting of the date format to: DD: Day (2-digit) MM: Month (2-digit) YYYY: Year (4-digit)

First enter the date (day/month/year), then the time (12 hours, including seconds).

Time format

Select 24h or 12h.

Time zones

Specify your current time zone.

§Set§ ... Apply it.

§Options§

Select the desired time zone from the list ...

Open menu.

Clock

DST

View

Set Rename Auto

timezone

Activate/deactivate selection. A sun is displayed when summer time is activated.

Display selected time zone with date and time.

Set time zone.

Rename the time zone.

The time zone is automatically converted to local time by the network.

Date format

DD.MM.YYYY or MM/DD/YYYY or YYYY-MM-DD

Show clock

Activate/deactivate time display in standby mode.

Buddhist year

Switch to the Buddhist calendar (not available in all models).

Setup56

Connectivity

§Menu§

Select a function.

Connectivity

GPRS b

For GPRS (General Packet Radio Service)

GPRS is a new method for transmitting data faster in the mobile network. Use GPRS and if the network has sufficient capacity, you can be connected to the Internet permanently. Only the actual transmission time is charged by the network operator.

Some service providers do not yet support this service.

§Yes§ / §No§ Switch GPRS function

Shown in display:

on/off

« Activated and available. ª Registered.  Connection briefly lost. © Download

GPRS info

Display of connection data.

Connection profiles

At least one connection profile must have been set up and activated for the WAP application. The current settings for the respective provider can be found on the Internet under

www.siemens-mobile.com/ mobilescustomercare

in the “FAQ” section.

G Select profile.

§Options§ Open menu.

Change sett.

For CSD (Circuit Switched Data)

CSD settingsSelect.

If it has not been pre-installed, enter the data or enter the required settings (your service provider will supply you with information on this):

§Edit§ Press.

Dial-up number

Call type:

§Save§ Save settings.

Press, then:

Enter ISP number.

Select ISDN or analogue.

Enter login name.

Enter password (shown as a series of asterisks).

57Setup

For GPRS (General Packet Radio Service)

Select GPRS settings. You can activate GPRS for the profile

and change the settings here. You can only start to use GPRS once you have activated GPRS on your phone (p. 56).

§Edit§ Press.

APN: Login name: Password:

DNS1 / DNS 2:

§Save§ Save settings.

Enter provider address.

Enter login name.

Enter password (shown as a series of asterisks).

(optional).

Authentication

§Menu§

§Change§ Activate or deactivate

Authentication

encrypted WAP dial-up (CSD connections only) (PAP: Personal Authentication Procedure, CHAP: Challenge Authentication Procedure).

Connectivity

Security

§Menu§

The phone and SIM card are protected against misuse by several security codes.

Select a function

Direct call

(Phone code is protected) Only one phone number can be dialled. Hold down the right soft key (p. 22).

Only ‚ b

(PIN2-protected) Restricts dialing options to SIM-protected numbers in the Phonebook. If only area codes are entered, relevant phone numbers can be added to these manually before dialling.

If the SIM card does not support PIN 2 input, the whole Phonebook can be protected with the phone code.

Last 10 only b

(Phone-code protected) Only phone numbers from the call list of "dialled numbers" (p. 34) can be dialled. This list can be filled with phone numbers specifically for this purpose. First delete the call list, then create "new entries" by dialling phone numbers and cancelling before the connection is established.

Security

Setup58

§Menu§

Select a function

Security

Codes

PIN control, Change PIN, Change PIN2, Change phonecode, (p. 14).

This SIM only b

(Phone-code protected) The phone can be connected to a SIM card when the phone code is entered. Unless the phone code is known the phone will not operate with a different SIM card.

If the phone is to be used with a different SIM card, enter the phone code when requested.

Barrings b

Barring restricts the use of your SIM card (not supported by all service providers). You need a 4-digit password which your service provider will give you. You may need to be registered separately for each barring.

All outgoing

All outgoing calls, except emergency calls, are blocked.

Outgo internat

(Outgoing international): Only domestic calls are possible.

Outgo internat. x home barred

(Outgoing international except home) International calls are barred. However you can make calls to your home country when abroad.

All incoming calls

The phone is barred for all incoming calls (the forwarding of all calls to the mailbox offers a similar effect).

When roaming

You do not receive calls when you are outside your home network. This means that no charges are incurred for incoming calls.

Status check

The following information can be displayed after a status check:

p Barring set. o Barring not set.

Clear all

All barrings are deleted. A password supplied by your service provider is required for this function.

Status unknown (e.g. new SIM card).

§Menu§

Select a function

Security

Phone identity

The phone identity number (IMEI) is displayed. This information may be useful for customer service.

Alternatively enter in standby mode:

# 0 6 #

Software version

Display of software version in standby mode:

# 0 6 # , then press §Info§.

Filesystem clean up

(Phone code is protected) The file system is defragmented.

Master reset

The phone is reset to the default values (factory setting) (does not apply to SIM card and network settings).

Alternatively enter in standby mode:

# 9 9 9 9 #

Network

§Menu§

Select a function

Network

Line b

This function is only displayed if it is supported by the service provider. Two independent phone numbers must be registered on the phone.

Select

Select the currently used phone number.

‘

Block line

(Phone code is protected) You may limit usage to one phone number.

Additional notes

Special settings may be made for each phone number (e.g., melody, call divert etc.) To do this, first switch to the required phone number. Change phone number/connection in standby mode:

Display the current phone number.

0 Press.

§Line 1§ Press.

59Setup

Setup60

§Menu§

Select a function

Network

Network info

The list of GSM networks currently available is displayed.

Indicates forbidden service providers (depending on SIM card).

Auto network

Activate/deactivate, see also Choose

network above. If "Automatic net-

work" is activated, the next network on the list is dialled in ranking order of your "preferred networks". Otherwise a different network can be selected manually from the list of the available GSM networks.

Choose network

The network search is restarted. This is useful if you are not on your home network or want to register on a dif- ferent network. The network list is rebuilt when Auto network is set.

Preferred network

Enter your preferred service providers here for when you leave your home network (e.g. if there are differences in price).

Additional information

If you are outside your home network, your phone automatically dials another GSM network .

If the field strength of the preferred network is not strong enough when you switch the phone on, the mobile phone may register with a different network. This can change when the telephone is next switched on or if you manually select another network.

Your service provider is displayed:

§List§ Display list of preferred

Create new entry:

• Select empty line, press §Entry§

Change/delete entry:

• Select entry, press §Change§, then

networks.

then select another entry from the list of service providers and confirm.

select a different entry from the list of service providers and confirm it or press §Clear§.

Fast search

When this function is active, network reconnection is speeded up (standby time is reduced).

61Profiles

Profiles

¢~

§Menu§

Several settings can be stored in a phone profile in order, for example, to adapt the phone to the surrounding level of noise.

• Five profiles are standard with default settings, they can be changed however:

Normal envi. Quiet environ. Noisy environ. Car Kit Headset

• You can set two personal profiles (<No Title>).

• The special profile Aircraft mode is fixed and cannot be changed, (p. 62).

Activate

§Activate§ Activate profile.

Select default profile or personal profile.

Quiet environ.

Setup

Edit a default profile or create a new personal profile:

G Select profile.

§Options§ Open menu.

Change sett.

Select.

The list of available functions is displayed:

Ringer setting ...................................S. 63

Silent alert......................................... S. 63

Volume ............................................. S. 63

Call screening................................... S. 64

Key tones.......................................... S. 64

Info tones.......................................... S. 64

Big letters.......................................... S. 51

Illumination .......................................S. 51

When you have finished setting a function, you return to the profile menu where you can change a further setting.

Additional notes

½ Active profile

Activate Options

Profiles62

Profile menu

§Options§ Open menu.

Activate

Change sett.

Copy from

Rename

Activate selected profile.

Change profile settings.

Copy settings from another profile.

Change personal profile (except default profiles).

Car Kit

If a Siemens original Car Kit is used (p. 80) the profile is activated automatically as soon as the phone is inserted into the cradle (p. 52).

Headset

If an original Siemens headset is used (p. 79), the profile is activated automatically when the headset is used.

Aircraft mode

The alarm tone is deactivated. An alarm is only shown on the display. This profile cannot be modified. The phone will switch off if you select this profile.

Activate

§Select§ Switch on profile.

Normal operation

The next time you switch on the phone and return to normal operation the default profile will be activated.

Scroll to Aircraft mode.

A security prompt must be confirmed.

The phone switches itself off automatically.

63Ring tones

Ring tones

§Menu§

You can set the tones to match your needs.

Ringer setting

On/Off Activate/deactivate all

Beep Reduce ring tone to a

Additional notes

k j Displays: Ringer off.

Silent alert

To avoid the disturbance caused by a ringing phone, you can activate the silent alert function as an alternative. The silent alert can also be activated in addition to the ringer (e.g. in noisy environments). This function is deactivated when the battery is being charged.

Volume

You can set the same volume for all ring tones.

§OK§ Confirm.

Select function.

ring tones.

short signal (beep).

Displays: Beep.

Set volume.

Additional notes

Please make sure you have accepted the call before holding the phone to your ear. This will prevent a loud ring tone from damaging your hearing!

Calls, Group calls, Other calls,

Alarm clock, Messages

Here you can set the ring tone separately for the stated call types/functions.

§OK§ Confirm.

With Download new you can download new ring tones from the Internet.

Additional notes

Individual ring tone melodies can be sent to you via SMS or you can download them via

WAP (p. 46). See also Own stuff, p. 69

and My phone, p. 16.

Select ring tone.

Ring tones64

More tones...

§Menu§

Call screening

Only calls from numbers that are in the Phonebook or in a predefined group are signalled audibly or by silent alert. Other calls are only displayed.

If you do not accept these calls, they are diverted to your mailbox (if set, p. 53).

Key tones

You can set the acoustic key acknowledge tone:

Click or Tone or Silent

Minute beep

During the call, you will hear a beep after each minute as a reminder of the time elapsed. The recipient does not hear this beep.

Info tones

Set service and alarm tones:

On/Off Activate/deactivate tones.

Screen display in standby mode: when call screening is activated.

More tones...

Select a function.

65Extras

Extras

§Menu§ ¢

SIM services (optional) b

Your service provider may offer special applications such as mobile banking, share prices, etc. via the SIM card.

If you have such a SIM card, the SIM services will appear in the main menu under "Extras" or directly above the control key (on the left).

}

Where there are several applications, these are displayed in an SIM services menu.

With the SIM services menu, your phone is ready to support future additions in your service provider's user package. For further information, please contact your service provider.

¢ Select function.

Symbol for SIM services.

Alarm clock

The alarm will ring at the time set by you, even when the phone is switched off.

Setting

Set the time for the alarm call (hh:mm).

§OK§ Confirm settings.

y Alarm clock

11:56:27

z 07:30

On/off OK

§On/off§ Activate/deactivate the

Additional notes

y Alarm clock activated. z

alarm.

Alarm clock deactivated. Screen display in standby

mode: Alarm clock activated.

Extras66

§Menu§ ¢

¢ Select function.

Calculator

—



Calculator functions

§.§=§+§-§*§/§ Press the right soft key

Toggle between "+" and "-". % Convert to percent.

Ï Ð

e Exponent (maximum of two

Special keys:

* 0

Enter number (up to 8 digits).

Select calculate func-

tion.

Repeat procedure with other numbers.

Result is displayed.

repeatedly.

Save the displayed number. Retrieve the number saved.

digits).

Set decimal point. Add (hold down).

Stopwatch

Two intermediate times can be recorded and saved.

Stopwatch

00:00:00.000

Start Options

§Reset§ Reset to zero.

 *

Stopwatch menu

§Options§ Open menu.

Save

Reset Stopwatch

list

Start/stop.

Intermediate time.

Record the time(s) measured and assign a name to them.

Reset stopwatch.

Display the stored times.

View Display the stored

times and intermediate times.

Rename Rename stored

entry.

Delete Delete entry. Delete all Delete list.

67Fast access key

Fast access key

The left soft key and the number keys 2 to 9 (speed dialling numbers) can each be assigned an important phone number or a function. The phone number can then be dialled or the function can be started at the touch of a button.

Additional notes

The left soft key may already have a function allocated by your service provider (e.g. access to "} SIM card services"). It may not be possible to modify this key assignment.

The left soft key may also sometimes be replaced automatically by access a new message.

Available key assignments:

Internet (WAP) ..................................p. 46

Phone number...................................p. 28

Alarm clock........................................p. 65

New SMS ..........................................p. 38

Illumination ........................................p. 51

Hide ID ..............................................p. 52

Calls missed......................................p. 34

Calls received....................................p. 34

Inbox (Messages)..............................p. 42

]

/\ to

Left soft key

Assign a function/phone number to the left soft key for fast access.

Change

Service provider

01.10.2003 10:10

Internet Menu

§Internet§ Press briefly.

§Change§ Scroll to application in the

list.

• Assign a new function

(e.g. New SMS) to the soft key.

•Special case Phone number.

Retrieve a name (e.g. 'Carol') as the default for the soft key.

§Select§ Confirm setting.

Apply

The setting "Carol" is used here only as an example.

§Carol§ Hold down.

Fast access key68

Speed dialling keys

Number keys 2 to 9 can be used as speed dialling numbers for fast access. For available key assignments see p. 67. Number key 1 is reserved for the mailbox number (p. 36).

Change

In standby mode:

§Set§ Press.

§New SMS§ Press briefly (if assigned to

§Change§ Scroll to application in the

§Select§ Confirm setting.

Press number key (2-9). If the key is not yet assigned:

New SMS, for example).

list. Special case Phone num-

ber. Pick out a name from

the Phonebook for assignment to the key.

Special case Bookmarks. Scroll to a URL in the bookmark list for assignment to the key.

Apply

Select a stored phone number or start a stored application (e. g. New SMS).

In standby mode:

The assignment of the number key 3 is displayed above the right soft key e.g.:

§New SMS§ Hold down:

Or simply

Press briefly.

Hold down.

69Own stuff

Own stuff

The following folders are provided or organising your files: Pictures, Animations, Sounds.

§Menu§

¢ Ñ

Files and folders are displayed. You can scroll through these lists

using the control key:

G C

§Open§ Open folder or execute

Index structure

The file system assigns special folders to different data types.

Folders Contents Format

Pictures Images *.bmp

Animations

Sounds

scroll up and down.

jump back from a folder.

file using related application

*.gif *.jpg *.jpeg

Animations *.bmx

Ring tones, melodies, sounds

*.gif *.mid

The following folders are also included in these main folders:

Download new

EMS Files that can be received per

This enables you to download new files from the Internet..

SMS.

File system menu

§Options§ Open menu.

Open Delete Delete all Rename Send via... Attributes

Drive info

Open folder.

Delete current entry.

Delete all entries.

Rename highlighted entry.

Send highlighted entry.

Display information on file or folder selected.

Display the capacity used and available.

Data Exchange Software70

Data Exchange Software

Using this software, you extend the functionality of your mobile phone together with a Windows® PC. The phone and PC are connected to each other by means of a data cable (Accessories, p. 79). To ensure perfect data transmission, it is necessary that the phone is set to the standby mode (e.g. no active application, no incoming call).

The software can be downloaded over the Internet:

www.siemens-mobile.com/a60

The Data Exchange software works with Windows® Explorer like an extra drive and mirrors the contents of the file system (p. 69) on your phone.

You can access the data in the applications on the phone and synchronise these with the PC by simple drag and drop.

Warning!

When you access the file system, please ensure that no files are deleted that are essential to running applications on the mobile phone.

Questions & Answers

If you have any questions regarding the use of your phone, you can contact us at www.siemens-mobile.com/mobilescustomercare at any time. In addition to this we have listed some frequently asked questions and answers below.

Question Possible causes Possible solution

Phone cannot be switched on.

Insufficient standby time.

Charging error (charge icon not displayed).

SIM error. SIM card not correctly inserted. Check that the SIM card is inserted correctly (p. 9).

On/Off key not pressed long enough.

Flat battery. Charge battery. Check charging indicator in the dis-

Battery contacts dirty. Clean contacts.

See also below under: “Charging error”

Frequent use of organiser or games.

Speed search active. Deactivate speed search (p. 60).

Display illumination switched on. Switch off display illumination (p. 51).

Unintentional keystrokes (illumination!).

Battery totally discharged. 1) Plug in charger cable, battery is on charge.

Temperature out of range: 5 °C to 40 °C.

Contact problem. Check power supply and connection to the phone.

No mains voltage. Use different mains power socket, check mains volt-

Wrong charger. Only use original Siemens accessories.

Battery faulty. Replace battery.

SIM card contacts dirty. Use a dry cloth to clean the SIM card.

SIM card with wrong voltage. Use 3 V SIM cards only.

SIM card damaged (e.g. broken). Visually inspect the damage. Have SIM card

Press On/Off key for at least two seconds.

play.

Restrict use if necessary.

Switch on key lock (

2) Charge icon appears after approx. 2 hours.

3) Charge battery.

Make sure the ambient temperature is right, wait a while, then recharge.

Check battery contacts and device plug socket, clean them if necessary, then insert battery again.

age.

replaced by service provider.

 press for long time).

71Questions & Answers

Questions & Answers72

Question Possible causes Possible solution

No connection to network.

Phone loses network.

Calls not possible.

Certain uses of the phone not possible.

No entries possible in Phonebook.

Voice mail does not work

SMS (text mes-

T flash-

sage) ing.

Function cannot be set.

Memory problems for, e.g. messages, ring tones, pictures.

No WAP access, no download possible.

Weak signal. Move to higher location, to a window or open space.

Outside GSM range. Check coverage area of service provider.

SIM card not valid. Contact the service provider.

New network not authorised. Try manual selection or select a different network

Network barring is set. Check barrings (p. 58).

Network overloaded. Try again later.

Signal too weak. Reconnection to another service provider is auto-

2nd line set. Set first line

New SIM card inserted. Check for new restrictions.

Charge limit reached. Reset limit with PIN 2 (p. 35).

Credit used up. Load credit.

Call restrictions are set. Barrings may be set by your service provider. Check

Phonebook is full. Delete entries in Phonebook (p. 28).

Call divert to the mailbox not set. Set call divert to the mailbox (p. 53).

SMS memory full. To free up capacity, delete (p. 42) or file (p. 43) text

Not supported by service provider or registration required.

Phone memory full. Delete files in the applicable areas and unneeded T9

Profile not activated, profile settings wrong/incomplete.

(p. 60).

matic (p. 60). Switching the phone off and on may speed this up.

‘ (p. 59).

barrings (p. 58).

messages (SMS).

Contact your service provider.

dictionaries.

Activate WAP profile (p. 48), set (p. 48). If necessary, ask your service provider.

Question Possible causes Possible solution

Message cannot be sent.

EMS pictures and sounds not displayed at destination phone.

No Internet access possible.

PIN error/ PIN2 error.

Phone code error.

Service provider code- error.

Too few/too many menu entries.

Charge counter does not work.

Service provider does not support this service.

Phone number of the service centre is not set or is wrong.

SIM card contract does not support this service.

Service centre too busy. Repeat message.

Recipient does not have a compatible phone.

Recipient's phone does not support EMS standard.

Wrong WAP profile set or settings wrong, incomplete.

Three wrong entries. Enter the PUK (MASTER PIN) supplied with the SIM

Three wrong entries. Contact Siemens Service (p. 74).

No authorisation for this service. Contact your service provider.

Functions may have been added or removed by your service provider via the SIM card.

Charge pulse is not transmitted. Contact your service provider.

Check with your service provider.

Set service centre (p. 43).

Contact your service provider.

Check.

Check settings, speak to service provider if necessary.

card according to the instructions. If the PUK (MASTER PIN) has been lost, please contact your service provider.

Check with your service provider.

Damage

Severe shock. Remove battery and SIM and insert them again. Do not dismantle phone!

Phone became wet. Remove battery and SIM. Dry immediately with a cloth, but do not apply heat. Dry

Reset settings to factory default (see also p. 59): * # 9 9 9 9 #

connector contacts thoroughly. Set phone to vertical position in air flow. Do not dismantle phone!

73Questions & Answers

Customer Care74

Customer Care

We offer fast, individual advice! You have several options:

Our online support on the Internet:

www.siemens-mobile.com/ mobilescustomercare

We can be reached any time, any place. You are given 24 hour support on all aspects of our products. Here you will find an interactive fault-finding system, a compilation of the most frequently asked questions and answers, plus user guides and current software updates to download.

When calling customer service, please have ready your receipt and the phone identity number (IMEI, to display press

#06#), the software version (to display,

press *#06#, then §More§) and if available, your Siemens Service customer number.

You will also find the most frequently asked questions and answers in the section entitled "Questions & Answers" in this user guide on p. 71.

You can also get personal advice about our range of products on our Premium Hotline:

United Kingdom ............................ 0906 9597500

(0.75 £ per minute)

Qualified Siemens employees are waiting to offer you expert information about our products and installation.

In some countries repair and replace services are impossible where the products are not sold through our authorised dealers.

If repair work is necessary, please contact one of our service centres:

Abu Dhabi .........................................0 26 42 38 00

Argentina .....................................0 80 08 88 98 78

Australia..........................................13 00 66 53 66

Austria.............................................05 17 07 50 04

Bahrain .................................................... 40 42 34

Bangladesh.......................................0 17 52 74 47

Belgium.............................................0 78 15 22 21

Bolivia ...............................................0 21 21 41 14

Bosnia Herzegovina..........................0 33 27 66 49

Brazil............................................0 80 07 07 12 48

Brunei ................................................. 02 43 08 01

Bulgaria............................................... 02 73 94 88

Cambodia ........................................... 12 80 05 00

Canada ........................................1 88 87 77 02 11

China ...........................................0 21 38 98 47 77

Croatia ..............................................0 16 10 53 81

Czech Republic.................................2 33 03 27 27

Denmark ............................................. 35 25 86 00

Dubai ................................................0 43 96 64 33

Egypt.................................................0 23 33 41 11

Estonia................................................ 06 30 47 97

Finland ............................................09 22 94 37 00

France.............................................01 56 38 42 00

Germany *....................................0 18 05 33 32 26

Greece ............................................80 11 11 11 16

Hong Kong .......................................... 28 61 11 18

Hungary ..........................................06 14 71 24 44

Iceland .................................................. 5 11 30 00

India.............................22 24 98 70 00 Extn: 70 40

Indonesia .....................................0 21 46 82 60 81

Ireland.............................................18 50 77 72 77

Italy .................................................02 24 36 44 00

Ivory Coast.......................................... 05 02 02 59

Jordan...............................................0 64 39 86 42

Kenya.................................................... 2 72 37 17

Kuwait ................................................... 2 45 41 78

Latvia .................................................... 7 50 11 18

Lebanon.............................................. 01 44 30 43

Libya ...............................................02 13 50 28 82

Lithuania ...........................................8 52 74 20 10

Luxembourg........................................ 43 84 33 99

* 0,12 Euro/min.

Macedonia ...........................................02 13 14 84

Malaysia....................................+ 6 03 77 12 43 04

Malta.......................................+ 35 32 14 94 06 32

Mauritius ................................................2 11 62 13

Mexico .......................................01 80 07 11 00 03

Morocco...............................................22 66 92 09

Netherlands .................................0 90 03 33 31 00

New Zealand...................................08 00 57 43 63

Nigeria ..............................................0 14 50 05 00

Norway.................................................22 70 84 00

Oman....................................................... 79 10 12

Pakistan..........................................02 15 66 22 00

Paraguay ..........................................8 00 10 20 04

Philippines ........................................0 27 57 11 18

Poland.............................................08 01 30 00 30

Portugal ............................................8 08 20 15 21

Qatar....................................................04 32 20 10

Romania .........................................02 12 04 60 00

Russia..........................................8 80 02 00 10 10

Saudi Arabia .....................................0 22 26 00 43

Serbia .............................................01 13 07 00 80

Singapore ............................................62 27 11 18

Slovak Republic ..............................02 59 68 22 66

Slovenia............................................0 14 74 63 36

South Africa ....................................08 60 10 11 57

Spain.................................................9 02 11 50 61

Sweden.............................................0 87 50 99 11

Switzerland .....................................08 48 21 20 00

Taiwan ............................................02 23 96 10 06

Thailand............................................0 27 22 11 18

Tunisia .................................................71 86 19 02

Turkey..........................................0 21 65 79 71 00

Ukraine ........................................8 80 05 01 00 00

United Arab Emirates........................0 43 66 03 86

United Kingdom ...........................0 87 05 33 44 11

USA .............................................1 88 87 77 02 11

Vietnam...........................................84 89 30 01 21

Zimbabwe ............................................04 36 94 24

75Customer Care

Care and Maintenance76

Care and Maintenance

'Your phone has been designed and manufactured to the highest of standards and should be treated with the greatest of care. The suggestions below will help you to enjoy your phone for many years.

• Protect your phone from moisture and humidity! Precipitation, humidity and liquids contain minerals that will corrode electronic circuits. Nevertheless, should your phone become wet, disconnect it immediately from the power supply and remove the battery!

• Do not use or store the phone in dusty, dirty areas. Its moving parts may become damaged.

• Do not store your phone in hot areas. High temperatures can shorten the life of electronic devices, damage batteries and warp or melt certain plastics.

• Do not store your phone in cold areas. When the phone warms up again (to its normal ambient temperature), moisture can form inside the phone, which may damage electronic circuit boards.

• Do not drop, knock or shake your phone. Rough handling can damage internal circuit boards!

• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean the phone!

The suggestions given above apply equally to your phone, battery, charger and all accessories. If any of these parts are not working properly, take them to your nearest qualified service outlet. The personnel there will assist you and, if necessary, repair the device.

77Product data

Product data

Declaration of conformity

Siemens Information and Communication mobile hereby declares that the phone described in this user guide is in compliance with the essential requirements and other relevant provisions of European Directive 1999/5/EC (R&TTE).

The declaration of conformity (DoC) concerned has been signed. Please call the company hotline if you require a copy of the original.

Technical data

GSM class: 4 (2 watt)

Frequency range: 880 - 960 MHz

GSM class: 1 (1 watt)

Frequency range: 1.710 - 1.880 MHz

GSM class: 1 (1 watt)

Frequency range: 1,850 - 1,990 MHz

Weight: 85 g

Size: 110x47x23 mm

Li-ion battery: 700 mAh

Operating temperature:

SIM card: 3.0 V

(91 ccm)

-10 °C - 55 °C

Operating time

A full battery will deliver 60 to 250 hours of standby time or 100 to 300 minutes of talktime.

The operating time depends upon the use:

Action taken Time

Making a phone call

Light * 1 40 minutes

Network search

* Keypad entry, games etc.

Extreme temperatures reduce the phone's standby time considerably. You should therefore avoid the leaving the phone in the sun or on a radiator.

Reduces standby

(min)

time by

1 30 - 90 minutes

1 5 - 10 minutes

Product data78

Phone ID

You will need the following details if you lose your phone or SIM card. Please enter here:

the number of the SIM card (on the card):

..............................................................

15-the 15-digit serial number of the phone (under the battery):

..............................................................

the service provider’s Customer Service number:

..............................................................

Lost phone

If you lose your phone or SIM card contact your service provider immediately to prevent misuse.

79Accessories

Accessories

Energy

Li-Ion Battery 700mAh EBA-510

Spare battery.

Travel Charger

ETC-500 (Euro) ETC-510 (UK) Travel charger with an extended input

voltage range of 100-240V.

Car Charger ECC-500

Charger for the cigarette lighter socket in the car.

Desk Top Charger EDC-510

The desk top charger enables the phone to be charged easily as well as an additional battery.

Handsfree Portable

Headset PTT HHS-510

Headset with PTT key for accepting or ending calls.

Fashion & Mobility

Carrying Cases

You can buy different carrying cases in stores or from our online shop.

CLIPit Covers

You can buy exchangable front and back covers in stores or from our online shop.

Office

Data Cable DCA-500

For connecting the phone to the serial RS232 port of the PC.

Data Cable USB DCA-510

For connecting the phone to the USB port of the PC. With charge function.

Original Siemens Accessories

www.siemens.com/ mobilestore

Accessories80

Car Solutions

Car Kit Portable HKP-500

Handsfree kit with integrated loudspeaker and microphone and auto answer feature. Simply plug into the cigarette lighter socket. Particularly ideal for easy transfer between vehicles.

Mobile Holder HMH-630

Die Telefonhalterung ohne Antennenanschluss. Can also be used as a phone holder for upgrading your handsfree kit (55 series).

Basic Car Pack HKB-500

Allows in-car charging of your mobile phone as well as handsfree talking. Contains a Car Charger, a Headset PTT and a Y adapter.

Car Kit Comfort HKC-630

Handsfree kit with first-class digital call quality and supreme ease of use. Includes all components needed for installation. Individual antenna solutions can be obtained in specialist shops.

Car Kit Upgrade HKO-630

Mobile phone holder for upgrading your handsfree Car Kit Comfort.

Optional Car Kit accessories

VDA Adapter Cable HKO-560

Products can be obtained in specialist shops or you can visit our online shop at:

Original Siemens Accessories

www.siemens.com/ mobilestore

Battery quality statement

The capacity of your mobile phone battery will reduce each time it is charged/emptied. Storage at too high or low temperatures will also result in a gradual capacity loss. As a result the operating time of your mobile phone may be considerably reduced, even after a full recharge of the battery.

Regardless of this, the battery has been designed and manufactured so that it can be recharged and used for six months after the purchase of your mobile phone. After six months, if the battery is clearly suffering from loss of performance, we recommend that you replace it. Please buy only Siemens original batteries.

81Battery quality statement

Guarantee certificate (UK)82

Guarantee certificate (UK)

Without prejudice to any claim the user (customer) may have in relation to the dealer or retailer, the customer shall be granted a manufacturer's Guarantee under the conditions set out below:

• In the case of new devices and their components exhibiting defects resulting from manufacturing and/or material faults within 24 months of purchase, Siemens shall, at its own option and free of charge, either replace the device with another device reflecting the current state of the art, or repair the said device. In respect of parts subject to wear and tear (including but not limited to, batteries, keypads, casings, small parts on casings, protective coverings where included in the scope of delivery), this warranty shall be valid for six months from the date of purchase.

• This Guarantee shall be invalid if the device defect is attributable to improper treatment and/or failure to comply with information contained in the user manuals.

• This Guarantee shall not apply to or extend to services performed by the authorised dealer or the customer themselves (e.g. installation, configuration, software downloads). User manuals and any software supplied on a separate data medium shall be excluded from the Guarantee.

• The purchase receipt, together with the date of purchase, shall be required as evidence for invoking

the Guarantee. Claims under the Guarantee must be submitted within two months of the Guarantee default becoming evident.

• Ownership of devices or components replaced by and returned to Siemens shall vest in Siemens.

• This Guarantee shall apply to new devices purchased in the European Union. For Products sold in the United Kingdom the Guarantee is issued by Siemens plc, Siemens House, Oldbury, Bracknell, Berkshire, RG12 8FZ.

• Any other claims resulting out of or in connection with the device shall be excluded from this Guarantee. Nothing in this Guarantee shall attempt to limit or exclude a Customers Statutory Rights, nor the manufacturer's liability for death or personal injury resulting from its negligence.

• The duration of the Guarantee shall not be extended by services rendered under the terms of the Guarantee.

• Insofar as no Guarantee default exists, Siemens reserves the right to charge the customer for replacement or repair.

• The above provisions does not imply a change in the burden of proof to the detriment of the customer.

To invoke this Guarantee, please contact the Siemens telephone service. The relevant number is to be found in the accompanying user guide.

Guarantee certificate (IRL)

Without prejudice to any claim the user (customer) may have in relation to the dealer or retailer, the customer shall be granted a manufacturer’s Guarantee under the conditions set out below:

• This Guarantee shall be invalid if the device defect is attributable to improper care or use and/or failure to comply with information contained in the user manuals. In particular claims under the Guarantee cannot be made if:

• The device is opened (this is

classed as third party intervention)

• Repairs or other work done by

persons not authorised by Siemens.

• Components on the printed cir-

cuit board are manipulated

• The software is manipulated

• Defects or damage caused by

• Devices fitted with accessories

• The purchase receipt, together with the date of purchase, shall be required as evidence for invoking the Guarantee. Claims under the Guarantee must be submitted within two months of the Guarantee default becoming evident.

• Ownership of devices or components replaced by and returned to Siemens shall vest in Siemens.

• This Guarantee shall apply to new devices purchased in the European Union. For Products sold in the Republic of Ireland the Guarantee is issued by Siemens Ireland Limited, Ballymoss Road, Sandyford Industrial Estate, Dublin 18 - The Republic of Ireland.

• Any other claims resulting out of or in connection with the device shall be excluded from this Guarantee. Nothing in this Guarantee

dropping, breaking, lightning or ingress of moisture. This also applies if defects or damage was caused by mechanical, chemical, radio interference or thermal factors (e.g.: microwave, sauna etc.)

not authorised by Siemens

83Guarantee certificate (IRL)

Guarantee certificate (IRL)84

shall attempt to limit or exclude a Customers Statutory Rights, nor the manufacturer’s liability for death or personal injury resulting from its negligence.

• The duration of the Guarantee shall not be extended by services rendered under the terms of the Guarantee.

• Insofar as no Guarantee default exists, Siemens reserves the right to charge the customer for replacement or repair.

• The above provisions does not imply a change in the burden of proof to the detriment of the customer.

To invoke this Guarantee, please contact the Siemens helpdesk on 1850 777 277. This number is also to be found in the accompanying user guide.

Menu tree

Phonebook

Records

Surf & fun

ç Ring tones

Calls missed

Calls received

Calls dialled

Erase records

Durat/charges

Homepage Personal rate

Bookmarks A/c limit

Internet Auto display

Games

Ringer setting

Silent alert

Volume

Last call

All outgoing

All incoming

Remain. units

Charge sett.

Conv.

d Calls

Group calls

Other calls

Alarm clock

Messages

More tones...

Call screening

Key tones

Minute beep

Info tones

85Menu tree

Menu tree86

] Messages

~ Profiles

New SMS

Predef. texts

Inbox

Outbox

SMS archive

Setup

T9 preferred

Input language

SMS profiles

Voice message

CB services

Receive CB

Topic list

Extras

Ñ Own stuff

m Setup

SIM services

Alarm clock

Calculator

Stopwatch

Display

Screensaver

Language

Wallpaper

Logo

Colour scheme

Own greeting

Big letters

Illumination

Contrast

Enable

Style

Preview

Timeout

Security

87Menu tree

m Setup

Call setup

Divert

Clock

Connectivity

Hide ID

Call waiting

Any to answer

Minute beep

Car Kit

Headset

All calls

Unanswered

Not reachable

No reply

Busy

Status check

Clear all

Time/Date

Time format

Time zones

Date format

Buddhist year

Show clock

GPRS

GPRS info

Connection profiles

Authentication

Menu tree88

m Setup

Security

Network

Direct call Only ‚

Last 10 only

Codes

This SIM only

Barrings

Phone identity Outgo internat

Filesystem clean up Out.int.x home

Master reset All incoming

Line

Network info Block line

Auto network

Choose network

Pref. network

Fast search

PIN control

Change PIN

Change PIN2

Chg.phonecode

All outgoing

When roaming

Status check

Clear all

Select

SAR - European Union (RTTE)

INFORMATION ON RF EXPOSURE /SPECIFIC ABSORPTION RATE (SAR)

THIS MOBILE PHONE MEETS THE LIMITS SET BY THE EU (1999/519/EC) FOR PROTECTION OF THE HEALTH OF THE PUBLIC FROM THE EFFECTS OF EXPOSURE TO ELECTROMAGNETIC FIELDS

These limits are part of comprehensive recommendations for the protection of the public. The recommendations were developed and confirmed by independent scientific organisations through periodic and thorough evaluation of scientific studies*. The limits include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

Before a radio equipment may be placed on the market, compliance with the European laws and the respective technical limit requirements must be demonstrated. Only then the CE mark may be affixed**. The limit for mobile phones recommended by the Council of the European Union employs a unit of measurement known as the Specific Absorption Rate, or SAR. This SAR limit is

2.0 W/kg***. This corresponds with the

requirements of the International Commission for Non-Ionizing Radiation Protection ICNIRP and was adopted into the European Norm for Mobile Radio Equipment EN 50360. The SAR of mobile phones is determined in accordance with the European Norm EN 50361. This involves measuring the maximum value in all frequency bands of the mobile phone with the phone transmitting at its highest power level. The actual SAR level of the phone during normal operation may be well below the maximum value. This is because the phone is designed to operate

at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a base station, the lower the power output.

The highest SAR value for this model phone when tested for compliance against the norm is

0.67 W/kg****. The SAR information can also be found on

the Siemens web site at www.siemens-mobile.com While there may be differences between the SAR levels of various phones and at various positions, all Siemens products meet the legal requirements.

* The World Health Organization (WHO,

CH-1211 Geneva 27, Switzerland) states that present scientific information does not indicate the need for any special precautions for use of mobile phones.

Further information:

www.who.int/peh-emf, www.mmfai.org, www.siemens-mobile.com

** The CE mark confirms that the product is in

compliance with the legal requirements of the European Union as a prerequisite for the placing on the market and the free movement of

goods within the European internal market. *** averaged over 10g body tissue. **** SAR values may vary depending on national

requirements and frequency bands. SAR infor-

mation for different regions can be found at

www.siemens-mobile.com

89SAR - European Union (RTTE)

SAR – International (ICNIRP)90

SAR – International (ICNIRP)

INFORMATION ON RF EXPOSURE /SPECIFIC ABSORPTION RATE (SAR)

THIS MOBILE PHONE MEETS THE LIMITS FOR PROTECTION OF THE HEALTH OF THE PUBLIC FROM THE EFFECTS OF EXPOSURE TO ELECTROMAGNETIC FIELDS

Your mobile phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the limits for exposure to radio frequency (RF) energy recommended by international guidelines from the International Commission on Non-Ionizing Radiation Protection (ICNIRP). These limits are part of comprehensive guidelines for the protection of the public and establish permitted levels of RF energy for the population. The guidelines were confirmed by independent scientific organisations through periodic and thorough evaluation of scientific studies*. The limits include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure limit for mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit stated in the international guidelines is 2.0 W/kg**. Tests for SAR are conducted in all frequency bands using standard operating positions with the phone transmitting at its highest power level. The actual SAR level of the phone during operation can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a base station, the lower the power output.

The highest SAR value for this model phone when tested for use at the ear is

0.67 W/kg***. SAR information can also be found at

www.siemens-mobile.com While there may be differences between the SAR levels of various phones and at various positions, they all meet the international guidelines for safe RF exposure.

* The World Health Organization (WHO,

CH-1211 Geneva 27, Switzerland) states that

present scientific information does not indicate

the need for any special precautions for use of

mobile phones.

Further information:

www.who.int/peh-emf, www.mmfai.org,

www.siemens-mobile.com

** averaged over 10g of tissue. *** SAR values may vary depending on national

requirements and frequency bands. informa-

tion for different regions can be found at

www.siemens-mobile.com

Index

Accessories........................... 52, 79

Account limit.............................. 35

Aircraft mode ............................. 62

Alarm

Alarm clock............................. 65

Alarm clock ................................ 65

Alarm tones................................ 64

All calls (call time/charge) ........... 35

All calls (diversion) ..................... 53

All incoming (Barrings) ............... 58

Answering service

(in the network) ......................... 36

Any key answer (answer call)...... 52

Archive (SMS)............................. 43

Authentication ........................... 57

Auto display

Clock ...................................... 55

Duration/charges .................... 35

Auto timezone............................ 55

Automatic Redial previous

numbers..................................... 18

Battery

charge.................................... 10

insert........................................ 9

operating time........................ 77

quality declaration .................. 81

Battery operating time................ 77

Bookmarks (WAP) ....................... 46

Browser, WAP ............................. 47

Busy number .............................. 18

91Index

Calculator ................................... 66

Calculator functions ....................66

Call

accept/end .............................. 19

barred..................................... 58

charges ...................................35

conference.............................. 21

divert ......................................53

End .........................................17

held ........................................ 20

menu......................................22

reject ......................................19

Call back ..................................... 18

Call divert ...................................53

Call records................................. 34

Call transfer ................................ 22

Call transfer (incoming call)......... 22

Call waiting.................................21

Calls dialled (call list)...................34

Calls received (call list) ................34

Car Kit

Accessories ............................. 80

Setting.................................... 52

Car kit accessories ....................... 80

Care of phone .............................76

CB Service................................... 61

CB service ................................... 45

CB services............................ 45, 61

Cell Broadcast (CB)...................... 45

Charge battery ............................ 10

Charge rate................................. 35

Charges ...................................... 35

Clock ..........................................55

Colour schemes .......................... 50

Conference .................................21

Connection profile ...................... 56

Index92

Contrast

(message on display) .................. 51

Control code (DTMF) ............ 17, 33

CSD

Data ....................................... 56

Data Connection (Settings) ......... 56

Data exchange (settings) ............ 56

Data Exchange Software ............. 70

Date format................................ 55

Dialling with number keys .......... 17

Direct call ................................... 22

Display

Colour schemes ...................... 50

contrast.................................. 51

illumination ............................ 51

Symbols.................................... 6

Upper-case letters................... 51

Display (settings)........................ 50

Divert ......................................... 53

DTMF codes

(control codes) ..................... 17, 33

Duration/charges ........................ 35

Emergency number .................... 12

EMS ........................................... 40

Entry no. (phonebook)................ 28

Extras................................... 65, 76

Factory settings .......................... 59

Fast access ................................. 67

Fast search ................................. 60

Filter

Incoming calls......................... 64

Games ........................................ 49

Getting started..............................8

GPRS

Switch on/off...........................56

Group .........................................32

SMS to group .......................... 40

Guarantee certificate ..................82

Handsfree function ..................... 19

Headset

Accessories ............................. 79

Setting.................................... 53

Headset volume .......................... 17

Held call......................................20

Hide ID .......................................52

Home network............................ 60

Hotline .......................................74

Identity number (IMEI) ................59

Illumination (display) .................. 51

IMEI number ...............................59

Inbox

SMS ........................................42

Information services (CB) ............ 45

Input language (T9) .................... 25

International dialling code...........18

Internet ......................................46

Key tones....................................64

Last 10 only ................................ 57

Limit (call time/charge) ...............35

logo, provider logo......................50

Loss of phone, SIM card ..............78

93Index

Mailbox ...................................... 36

Maintenance of phone................ 76

Making a phone call.................... 17

Menu control/speed dialling........ 13

Menu tree .................................. 85

Message

CB .......................................... 45

SMS.................................. 38, 41

Message memory ....................... 41

Messages

CB .......................................... 45

SMS........................................ 38

Microphone on/off...................... 22

Minute beep......................... 52, 64

Missed calls (call list) .................. 34

Muting (microphone) ................. 22

My phone................................... 16

Network

barrings.................................. 58

connection ............................. 59

Setup...................................... 60

Only ‚..................................... 57

Only this SIM .............................. 58

Own (phone) numbers ............... 31

Own files.................................... 69

Own greeting ............................. 50

Own stuff................................... 69

Phone (settings) ......................... 52

Phone barrings ........................... 57

Phone code ................................ 14

Phone data................................. 77

Phone identity number (IMEI) ..... 59

Phone number transfer on/off..... 52

Phonebook

call an entry ............................ 29

new entry ...............................28

Picture in Phonebook .................. 30

Pictures & sounds (SMS)..............39

Change ................................... 14

control ....................................14

enter....................................... 11

error .......................................73

PIN 2...........................................14

Pocket calculator.........................66

Predefined text ........................... 27

Prefix..........................................17

Preventing accidental

activation....................................15

Product data ............................... 77

Profiles

Connection profile...................56

phone ..................................... 61

SMS ........................................43

WAP........................................ 48

Provider logo ..............................50

PUK, PUK2 ..................................14

Questions & Answers .................. 71

Redial previous numbers .............17

Reminder ....................................18

Ring tones ..................................63

Ringer setting .............................63

Safety precautions ........................ 3

Screensaver ................................ 51

Second phone number................ 59

Security ................................ 14, 57

Security codes.............................14

Service centre (SMS) ...................43

Index94

Service tones.............................. 64

Setup

Clock ...................................... 55

Data connection ..................... 56

Divert ..................................... 53

Network ................................. 59

phone..................................... 52

Security .................................. 57

Short message (SMS).................. 38

Shown in the display .................... 6

Siemens City Portal..................... 16

Signal strength ........................... 12

Silent alert.................................. 63

SIM card

clear barring ........................... 15

insert........................................ 9

problems ................................ 71

SIM services (optional)................ 65

SMS

Archive................................... 43

lists ........................................ 42

Picture & sounds ..................... 39

Profile..................................... 43

read........................................ 41

T9 input.................................. 25

to group ................................. 40

write....................................... 38

SOS............................................ 12

Special characters....................... 24

Speech time (battery) ................. 77

Speed dialling (menu) ................ 13

Speed dialling keys ..................... 68

Standard values.......................... 59

Standby mode ............................ 13

Standby time.............................. 77

Start menu (WAP)....................... 46

Surf & Fun .................................. 46

Swapping calls............................ 20

Switch on ................................... 11

Symbols ....................................... 6

Text entry ...............................25

word suggestions .................... 26

Technical data.............................77

Text entry with T9....................... 25

Text entry without T9..................24

Time zones ........................... 11, 55

Time/Date setting........................55

Unanswered ...............................53

Upper, lowercase letters..............24

Upper-case letters

(message on display) .................. 51

Validity period

SMS ........................................44

Voice message (mailbox) ............ 36

Volume, handset

Headset volume ...................... 17

Profiles....................................61

Ring tone ................................ 63

Wallpaper ...................................50

WAP

browser ..................................47

parameters..............................48

Siemens A60 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents 1

Safety precautions

Phone overview

Display symbols (selection)

Getting started

Insert SIM card/battery

Charge battery

Switching on your phone for the first time

Signal strength

Without SIM card

General Instructions

Menu Control

Standby mode

Security

Codes

Preventing accidental activation

My phone

Making a phone call

Dialling with number keys

End call

Set volume

Redial previous numbers

Sendcontrol code (DTMF)

When a number is busy

Accept call

Reject call

Handsfree

Conference b

Direct call

Text entry

Predef. texts

Phonebook

<New entry>

Call (search for an entry)

Edit entry

Assign picture

<Special books>

Groups

Control codes (DTMF)

Records

Durat/charges

Voice mail/mailbox

Writing and sending text messages (SMS)

Picture&sound

SMS to group

Receiving SMS

Lists

SMS archive

SMS profiles

T9 settings

CB services

Surf & fun

Internet browser (WAP)

Games

Setup

Display

Screensaver

Call setup

Divert

Clock

Connectivity

Security

Network

Profiles

Ring tones

Extras

SIM services (optional) b

Alarm clock

Calculator

Stopwatch

Fast access key

Own stuff

Data Exchange Software70

Questions & Answers

Customer Care

Product data
