M ULTIFUNCTION C OLOR DOCUMENT SYSTEMS

MX-6201N
MX-7001N

UNPARALLELED WORKGROUP PERFORMANCE WITH ON-DEMAND COLOR.

With best-in-class features and the versatility of high-quality, on-demand color, the new Sharp MX-6201N/MX-7001N Document

Systems deliver all the muscle you need to keep up with the pace of your business. These powerful multifunction document

systems can streamline your document workflow like never before. Enhance your capabilities with added functionality and a 1 GHz

multi-tasking controller for large-volume tasks. Standard features like copy, print, scan and document filing deliver versatile

functionality that saves time. Ideal for larger workgroups, the MX-6201N/MX-7001N Document Systems offer an array of paper

handling capabilities and optional finishing features that get the job done. Add impact to your communications without breaking

the bank with the flexibility of brilliant, on-demand color. And with support for Sharp OSA™ technology, Sharp’s innovative

development platform, you can boost productivity with one-touch access to your business applications right from the LCD display.

The large color touch-screen display features customizable “short cut” keys for increased efficiency in high-volume environments.

For unprecedented security, the MX-6201N/MX-7001N Document Systems deliver several sophisticated options that protect your data

by securing walk-up, scan and network access—so your documents remain secure.

A NEW DIMENSION OF PRODUCTIVITY...

WITH THE ADDED VALUE OF

DAZZLING

, HIGH-IMPACT COLOR

MX-6201N/MX-7001N SERIES

U NPRECEDENTED PERFORMANCE FOR

HIGH

-VOLUME WORKGROUPS

• High quality color output up to 50-ppm and crisp B/W output up to 62/70-ppm

• Performance-driven 1 GHz Multi-tasking Color Document System with

optional EFI™ Fiery® controller to manage your unique environment

• Versatile application integration with Sharp OSA technology enables users
to access network applications right from the LCD panel

• Sharp’s award-winning multi-level network security

• Customizable icon-driven color touch-screen display

• One-touch ImageSEND™ technology facilitates scans to USB devices,
network folders, e-mail and more

• Standard 150-sheet Duplexing Document Feeder with Color Scan

2

™

technology

• Large 6,600-sheet maximum on-board paper supply (3,100 standard)

• Efficient Cardshot, Page Stamp and Tandem Copy

• Built-in PCL6/PCL5c printing with Direct Print and PostScript® 3™ option

• Standard 80 GB HDD offers enhanced job spooling and Document Filing

• Advanced web-based Device Management and on-board user manuals

• Optional external keyboard for enhanced convenience *

• Environmentally focused; supports Energy Star® and RoHS

• Optional Finishing, Page Inserter and Hole-punch accessories to reduce
paper handling and increase productivity

• A choice of large-capacity paper trays for high-volume workgroups

• Super G3 Fax option offers PC Faxing and Inbound Routing

• My Sharp™ web-based 24/7 training

* Available Summer 2007

Productive

Flexible

Easy-to-Use

Accessible

Secure

VERSATILE PAPER HANDLING

At an impressive 62/70-ppm in
B&W and a speedy 50-ppm in
Color, the new MX-6201N/7001N
Series delivers high-quality
lightning-fast output, perfect for
busy workgroups. Sharp’s new
multi-tasking controller is at
the heart of it all. With more
speed and processing power,
you can complete tasks
simultaneously for improved
efficiency. With a standard

paper capacity of 3,100 sheets
(upgradable to 6,600 sheets) and a standard 150-sheet duplex
single pass document feeder, these advanced performers can

manage large-scale projects with ease...so your workflow virtually
never slows down. For even more power and versatility, you can add
the 3,000 or 3,500-sheet large capacity tray, available in either
tabloid or letter-only models. Additional paper-handling features
including trayless duplexing, electronic sorting and integrated
offset stacking make it easy to produce more booklets, proposals
and presentations...without relying on external sources. The result?
More control over your workflow, and more peace of mind.

HIGH-EFFICIENCY SCANNING WITH COLOR SCAN

2

To maximize productivity, the new Sharp
MX-6201N/7001N Series offers Sharp’s award­winning Color Scan

2

technology. Now you can

blaze through duplexed originals...whether they are B&W or
color, with simultaneous 2-sided scanning. And since the document
is scanned in a single pass, it takes only half the time to process!
Simply load your document into the tray, press a few buttons, and
walk away. Scan

2

technology makes it faster and easier to duplicate

virtually any type of multi-page document. Produce employee
booklets, company newsletters—almost anything your business
needs to communicate—quickly and easily.

EXTERNAL KEYBOARD OPTION FOR ENHANCED INTERACTION

If your workgroup performs a significant amount of data entry at
the LCD, you can easily add the optional external keyboard
for more convenience.* Ideal for environments that handle
repetitive scanning and archiving of documents, a keyboard
significantly speeds up the process and saves time.

* Available Summer 2007

EASY ACCESS TO SHARED FILES

With convenient Document Filing, you can standardize, share and
store frequently-used files such as fax cover sheets, distribution
order forms, HR forms, and more...right on the MFP. A 40 GB hard
drive partition provides plenty of storage capacity, so everyone
can access the same files. In environments where security is
required, you can easily restrict access to select users. With private
storage features, PIN-code access, and My Folders, you can rest
assured that your document security is not compromised. Sharp’s
new Quick Folders feature enables you to temporarily store and
retrieve documents quickly and easily. Plus, an integrated backup
utility automatically backs up your data.

HIGH-QUALITY NETWORK PRINTING

Out-of-the-box, the MX-6201N/7001N
Series offers 600 x 600 dpi B&W and
Color printing right from your desktop.
Simple plug-n-play operation makes it
easy to take advantage of advanced
feature sets in a snap. The watermark
feature automatically prints messages
on the pages, so drafts and confidential
documents can easily be identified. And
with cover page printing, overlay print
and pamphlet mode, you can produce
many jobs internally, minimizing outsourcing. With drag-n-drop
simplicity, integrated PDF printing lets you print a PDF without
even opening the file. The optional Postscript driver delivers
extensive color control options, so you can manage color
consistency right from your desktop.

DUPLICATE ID CARDS IN A SNAP

For increased efficiency in healthcare and insurance environments,
the convenient Cardshot feature saves time and resources
by copying both sides of a license or ID card onto a single
sheet of paper.

H IGH-PERFORMANCE FEATURES

P OWER- UP YOUR WORKGROUP

WITH IMPRESSIVE FEATURES AND

WORLD

- FAMOUS RELIABILITY

A 6,600-sheet online paper capacity
is available with options.

INTUITIVE TOUCH- SCREEN DISPLAY

DAZZLING IMAGE QUALITY

Bring your business communications to life with brilliant,
on-demand color and crisp, B&W text. With best-in-class

multifunction features, the MX-6201N/7001N Series virtually
eliminates the need for separate peripherals, so you can reduce
office hardware and minimize their associated costs. These
multi-tasking performers can produce just about anything—
booklets, newsletters, proposals, marketing collateral, and
more—giving you all the power and control you need.
Add Sharp’s advanced Micro-fine Toner Technology and
Image Stabilizing System, and you get consistent image
quality throughout the entire run, so your documents always
look professional.

ENVIRONMENTALLY-FRIENDLY

Designed to minimize downtime and reduce environmental impact,
the MX-6201N/7001N Series’ Micro-fine Toner Technology offers
longer replacement intervals and utilizes less packaging material.
Plus, it’s RoHS and Energy Star compliant. In fact, new modes to
reduce operational power give the MX-6201N/7001N Series one of
the lowest power consumption ratings in the industry.

PROFESSIONAL-QUALITY FINISHING

The MX-6201N/7001N Series offers several modular finishing
options to automate paper handling as well as give your documents
a professional appearance. Presentations, new employee welcome
kits and customized sales and marketing collateral can be easily
printed and finished in-house. The optional 4,000-Sheet Finisher
speeds through large projects, giving you complete control over
deadlines. The robust Saddle-Stitch Finisher delivers 3-position
stapling, center folding, 50-sheet stapling capacity, and more.
To add flair and organization to your jobs, you can insert covers,
tabs or special media with the Post-Sheet Inserter. And for even
more versatility, add the hole-punch unit for two- and
three-hole punching.

The new MX-6201N/7001N Series offers a unique
Customizable User Interface that’s ideal for
large enterprises. With the ability to display three
virtual “short-cut” keys on the LCD display, you
can access the most widely-used commands in
an instant. These “short-cut” keys can also be
customized so that different users can access
unique “short-cuts” based on their specific needs.
The interface can even display different
languages based on the user’s login. With a large

10.4-inch (diagonally measured) color LCD
touch-screen, the intuitive, icon-driven graphics

provide access and instructional guidance to
advanced features, so even occasional users will
find it easy to use.

iSelect from two large
capacity trays: The
MX-LCX2 holds 3,500
sheets of letter-sized
paper. The MX-LCX3
accommodates 3,000
sheets and adjusts to
letter-R, legal, or
tabloid-sized papers.

A choice of finishers with
optional hole-punching and
inserting makes it easy to reduce
costs on professional printing
and finishing.

In addition to being environmentally
friendly, the front-loading color-coded
toner cartridges are easy to replace.
You can even change the black toner
cartridge while the system is running.

ADVANCED FUNCTIONALITY

The large 10.4" (diagonally measured) Color LCD touch-screen
display is intuitive and easy to use. New customizable “short-cut”
keys recall frequently used documents or settings in a flash.

MX-FNX3

4,000-sheet Finisher

MX-FNX4

4,000-sheet

Saddle-Stitch Finisher

MX-LCX2

3,500-sheet

Large Capacity Tray

MX-LCX3

3,000-sheet

Large Capacity Tray

A DVANCED SECURITY

To help protect your data, the MX-6201N/7001N Series offers six
layers of security, making Sharp the optimum choice to protect
employee privacy and intellectual property. As the leader in office
equipment security, Sharp makes it easy for any business or
government entity to safely deploy digital copying, printing,
scanning and faxing.

AUTHORITY GROUPS

Advanced account management enables administrators
to set authority groups for access to features of the
MX-6201N/7001N Series. Administrators can control which
department, for instance, has full access to copying, printing,
scanning and/or fax. Walk up users enter a 5-8 digit code,
Local Name and Password, or LDAP User Authentication to
access their features assigned to their group.

DOCUMENTS REMAIN CONFIDENTIAL

To help protect your printed documents from unauthorized
viewing, the MX-6201N/7001N Series offers Confidential
Printing that requires users to enter a PIN code in order to
print a queued document. Additionally, Secure Fax Release
ensures received fax documents are held in memory until an
authorized user enters a PIN code, so compliance with
healthcare regulations like HIPAA is easier.

NETWORK SCANNING ACCESS

To help protect your network from unauthorized e-mail
communications, the MX-6201N/7001N Series supports user
authentication, requiring users to login before performing any
network scanning operations.

CONTROL DEVICE ACCESS OVER THE NETWORK

To help restrict access to the device over the network,
the MX-6201N/7001N Series offers Secure Sockets Layer
(SSL Encryption) IP/MAC address filtering, protocol
enable/disable and port management for maximum security.

DATA ERASE AND ENCRYPTION

*

To help protect your data, the MX-6201N/7001N Series
offers an optional data security kit that encrypts document
data using AES (Advanced Encryption Standard) 128-bit
encryption. Additionally, the data security kit erases the
memory on the hard drive by overwriting the encrypted
data up to seven times, offering an unprecedented level
of assurance.

TRACKING AND AUDITING INFORMATION

Legislation and industry policies require companies to
be more aware of information flow from their offices.
Sharp offers hardware and software accessories that help
you control, access, and track usage across your entire
office equipment fleet.

These scalable security offerings aim to protect your intellectual
property, preserve confidential information and help your business
to meet regulatory requirements, such as the Health Insurance
Portability and accountability Act (HIPAA), and the Gramm Leach
Bliley Act (GLB). For additional information visit:

www.sharpusa.com/security

*

Data Security Kit not available at time of launch

V ERSATILE SCALABILITY

The MX-6201N/7001N Series modular design enables you to fully
leverage your investment in data management infrastructure. While
others are limited to a small circle of productivity, Sharp’s newest
innovation, Sharp OSA™ technology, allows users to utilize the
power of their back-end systems right from the control panel.
It’s really a new way of thinking with “power at the panel” for more
automated tasks and a streamlined workflow.

STREAMLINE DOCUMENT WORKFLOW

Virtually seamless to the user, Sharp OSA technology can help save
time and increase the efficiency of everyday tasks. This technology
allows the MX-6201N/7001N Series to display choices that were once
only available on a desktop PC. With one-touch access to business
applications via Sharp OSA integration, you can start and finish a
document distribution task in just a few steps.

ROBUST PERFORMANCE

The Sharp OSA Development Platform is the logical choice to
compliment your existing infrastructure by providing fast, flexible
access to documents and applications—no matter where you are
in the office. With tighter integration with network security and
accounting applications, you can control access and track jobs more
efficiently. A comprehensive set of management tools delivers the
ability to control your workflow easily, efficiently, and more securely.

EASY TO CUSTOMIZE

Sharp OSA technology also provides another crucial component to
your workflow: customization. With the ability to personalize
applications and processes specific to your business, Sharp OSA
technology can help eliminate redundancy and streamline workflow,
helping to save time and optimize productivity. And since Sharp OSA
technology utilizes industry-standard network protocols such as SOAP,
XML, and XHTML, third-party software developers can deliver
customized solutions to your business faster than ever.

SHARP OSA TECHNOLOGY AT A GLANCE

• Automate tasks and save time with seamless
integration between the MX-6201N/7001N Series
and network applications

• Minimize set-up and installation of multiple Sharp
products with centralized applications

• Helps eliminate repetitive tasks and streamline
workflow, increasing efficiency

• Maximize your return on investment with tighter
integration among IT assets

• Deploy new solutions faster with industry-standard
programming

LEVERAGE YOUR INVESTMENT

WITH INCREASED FUNCTIONALITY

D OCUMENT WORKFLOW

POWERFUL MULTI-TASKING

The new MX Series has all the power you need for high-volume
environments. The 1 GHz multi-tasking controller delivers plenty
of muscle when you need it most...at crunch time. Most controllers
perform one single
operation at a time,
so jobs build up in
the queue, causing
bottlenecks. In contrast,
the MX-6201N/7001N
Series continually
processes incoming jobs
even while existing jobs
are output, increasing
overall productivity.

SCAN IT. SAVE IT. SEND IT.

It really is that simple with Sharp ImageSEND technology. With up
to seven destinations—E-mail, Desktop, FTP, Network Folder (SMB),
USB, Fax and Internet Fax—getting your document where it needs
to go is as easy as pushing a button. There’s no need to walk to
different peripherals to get the job done, simply scan your your
document, select the destination and hit start. The Send to Group*
mode allows you to mix group broadcasts to E-mail, Fax, and
Internet Fax...perfect for increasing efficiency in larger environments.
ImageSEND technology centralizes the entire document distribution
process, saving valuable time. And with recent postal increases,
ImageSEND technology can significantly reduce mail costs as well.

INTEGRATED USB SUPPORT

Designed to support today’s mobile
workforce, the MX-6201N/7001N
Series is USB compatible and works
with a variety of popular memory
devices. Scan files directly to a USB device
or simply plug-in and print. Most industry­standard protocols are supported, including
TIFF, JPEG, PDF, and Encrypted PDF.*

SECURITY AT YOUR FINGERTIPS

To help reduce security breaches in today’s marketplace the
MX-6201N/7001N Series supports LDAP with integrated User
Authentication. Ideal for larger environments, administrators can
manage access to users and features, resulting in complete control
over the MFP usage and costs. With PIN-code authorization and
controls for up to three levels of identification, you can help protect
sensitive documents —so your data is not compromised.

CONVENIENT DISTRIBUTION WITH LDAP

With LDAP, there’s no need to manually enter a recipient’s complete
address or phone number. Simply enter the first few characters and
the MX-6201N/7001N Series automatically searches and displays a list
of names to select from. And with Unique File Naming, you can enter
specific filenames with custom subject fields, so it’s easier than ever
to recall files when you need them.

SUPER-FA ST, SUPER G3 FAXING

Centralize communications and reduce
peripherals by adding the optional Super
G3 Fax Kit. Designed for busy workgroups,
the MX-6201N/7001N Series delivers
lightning-fast walk-up faxing, as well as the
convenience of PC Faxing directly from your desktop. With an
optional Finisher installed, faxes are automatically stapled and/or
collated, so they’re ready to distribute. Innovative Inbound Fax
Routing sends faxes directly to an e-mail address, giving mobile
users the ability to check on incoming orders, purchase orders, and
more. Parameters can be easily managed through the user-friendly
web page. And for additional savings, the optional B&W Internet Fax
expansion kit can help reduce long-distance phone costs.

ADVANCED DISTRIBUTION FEATURES TO

JUMP

-START YOUR PRODUCTIVITY

*Some features require optional equipment

In contrast to the MX-6201N/7001N Series’ robust functionality, the
systems are incredibly intuitive and easy to use. To enhance your
investment, Sharp’s Administration Utility Suite provides integrated
tools and utilities to simplify usage and set-up. This collection of tools
delivers everything you need to streamline processes in sophisticated
network environments.

EASY MANAGEMENT WITH THE MX SERIES WEB PAGE

Integrated web-based management makes it easy to
customize scan destinations, profiles, web links, and fax
distribution features right from your desktop. Sharp’s
easy-to-use Web Page also provides access to My Sharp,
a dedicated website that provides support and training tools
to help you maximize the features of your MX-6201N/7001N Series.

SIMPLIFY NETWORK TASKS WITH PRINTER ADMINISTRATION UTILITY (PAU)

Designed for administrators, PAU provides a “snapshot” of activity of all
devices on your network, enabling you to monitor status from one single
interface. Easily install updates to different devices remotely, distribute
drivers and set print priorities to expedite workflow.

VIEW DEVICES REMOTELY WITH PRINTER STATUS MONITOR

Designed for both managers and desktop users, Printer Status Monitor
allows you to check the status of each printer on the network. Check
paper levels, toner and more...all through a user-friendly interface.

OPTIMIZE SCANNED FILES WITH SHARPDESK™ SOFTWARE

With Sharpdesk document management software, you can easily
integrate scanned documents into your everyday workflow. Organize,
edit, enhance—even combine several scanned files from different
applications into one document. Intuitive search functionality enables
users to retrieve documents quickly and easily.

ENHANCE PRODUCTIVITY WITH REMOTE E-MAIL DIAGNOSTICS

Managers can stay on top of device productivity with remote E-mail
Diagnostics. Administrators automatically receive meter reads and other
diagnostic information critical to maximizing uptime.

D OCUMENT MANAGEMENT

INTEGRATED, USER-FRIENDLY SOFTWARE

HELPS YOU MANAGE DOCUMENT WORKFLOW

Printer Administration Utility

Printer Status Monitor

Embedded Web Page Sharpdesk Software

OPTIONAL EFI™ FIERY

®

CONTROLLER

FEATURE-RICH PERFORMANCE

FOR GRAPHIC

-INTENSIVE

WORKGROUPS

THE OPTIONAL EFI FIERY CONTROLLER AND GRAPHIC ARTS PACKAGE

Best-in-class functionality combined with high-quality, on-demand
color make the MX-6201N/7001N Series the perfect compliment to
design firms, central reprographic departments, pre-press

professionals and related marketing services
organizations. Configured with the optional EFI
Fiery Controller, the MX-6201N/7001N Series
delivers state-of-the-art color control and
software enhancements that streamline
workflow and make it easier to predict color

output. Packed with a sophisticated set of
tools and a blazing-fast 2.0 GHz processor, the powerful EFI Fiery
Controller accelerates memory-intensive processing, minimizing
document traffic and bottlenecks. Effortless to control and virtually
seamless to users, the EFI Fiery option delivers consistent, precise
output for the most demanding applications—yours.

USER-FRIENDLY SOFTWARE

The EFI Fiery driver provides efficient and organized access to
print functions and settings through an intuitive and familiar

interface. Pop-up menus display
sub-menu choices in an easy-to­navigate tabbed format. Integrated
features like Drag-and-Drop

Watermark, Job Monitor and
Booklet Maker help you produce

complex jobs without the purchase
of third-party software, so you can
handle the most sophisticated
projects with the ease of a pro.

SEAMLESS INTEGRATION WITH YOUR INFRASTRUCTURE

Designed to connect seamlessly within your existing network
environment, the EFI Fiery controller provides an intuitive and
flexible platform to manage the entire document printing
process from a single interface. All standard network protocols are
supported, simplifying installation and deployment. You also get
advanced security features to manage various levels of user access.
With IP filtering, Port Blocking, Secure Erase options and more,
the EFI Fiery Controller delivers all the features you need to remain
compliant in today’s changing business landscape. And with Fiery
WebTools™, users can access scanned files, jobs and devices
through a single web page.

The EFI Fiery interface features a simplified
tabbed structure that is easy for both occasional
users as well as the most demanding operators.

FIERY CONTROLLER ACCESSORIES

• EFI Desktop Pro® Software

• EFI Graphics Arts Package Software (Includes
Spot-On®, EFI Hot Folders/Virtual Printers, and
Auto Trapping)

• EFI Impose™ Fiery Edition

• EFI Color Profiler

• PrintShop Mail-Fiery® Edition

• PageFlex Persona-Fiery® Edition

• EFI Secure Erase

COLORWISE® SOFTWARE

In production-oriented
environments, EFI Fiery ColorWise
software provides accurate,
consistent color, regardless of
platform, application or media.
Automatic, in-RIP processing
spools jobs to the controller,
resulting in improved workflow.
Parameters are easy to set and save, so even casual users can use
the software confidently. Pre-set profiles can be applied to
individual jobs, resulting in more consistent color quality.

COMMAND WORKSTATION™ SOFTWARE AND WEBTOOLS

Simplify centralized print management in large-scale enterprises.

With extensive features, administrators can monitor devices, or
add, delete and prioritize jobs to optimize workflow in busy
workgroups. With WebTools administrators and users can
remotely access features via the Internet to better manage
jobs for greater efficiency.

FREEFORM™ SOFTWARE

Take advantage of one-to-one marketing opportunities with
FreeForm. Now you can get variable data printing options in a
scalable, easy-to-use interface. The industry’s leading variable data
printing solution, FreeForm works from almost any application and
integrates seamlessly
with most variable data
applications, providing a
cohesive workflow with
improved productivity.

COLOR PROFILER (OPTIONAL)

The optional Fiery Controller
makes is easy to match and save
data that ensures that colors print
consistently on virtually any device
in the organization. Sophisticated
tools can generate printer profiles
for every printer on your network,
drastically reducing the time

spent making color adjustments. The Color Profiler kit also
provides more realistic color on CRT and LCD monitors, so you

can better predict that the color you see will match the color on
printed documents.

HOT FOLDERS/VIRTUAL PRINTERS (OPTIONAL)

For faster, error-free printing, the optional Hot Folders utility can
reduce set-up errors by automating sophisticated tasks. Now users
can easily perform beyond their level of expertise, making it easy to
keep up with demand in busy workgroups.

SPOT-ON® COLOR SOFTWARE (OPTIONAL)

Perfect for pre-press
environments, this handy utility
helps operators edit CMYK/RGB
values with easy-to-use
calibration tools, so the color
matches the printed output.

EXPEDITE WORKFLOW WITH VERSATILE EFI SOFTWARE

THE MX-6201N/7001N

DOCUMENT SYSTEMS:

BUILT-IN COLOR FOR

DEMANDING ENVIRONMENTS

Main Specifications

Base Models High-speed color multifunction digital document system; 1 GHz

multi-tasking controller; 80 GB HDD with document filing; PCL5c/PCL6
network printing/scanning, Scan

2

single-pass duplexing feeder,

auto duplex, 3,100-sheet standard paper capacity

Functions Copy, print, network print, network scan, document filing;

Super G3 fax option

Copy System Laser, Dr y Transfer, Organic Photo Conductor Ultra-Fine Toners/Developers,

Magnetic & Heat Process

Copy Size Input: Min. 5 ½" x 8 ½", Max. 11" x 17" Output:

Envelopes, Letter, Letter-R, Legal, Ledger & 12" x 18"

Copy Speed MX-6201N: 62 PPM B/W & 50 PPM Color

MX-7001N: 70 PPM B/W & 50 PPM Color
(based on 8 ½"x11" paper)

First Copy Time Platen glass: 4.5 seconds B&W and 7.2 seconds Color (MX-6201N)

4.0 seconds B&W and 7.2 seconds Color (MX-7001N)

Warm Up Time Approximately 300 Seconds
Copy Data 25% to 400% Zoom (1% increments), 25% to 200% (DSPF);

9 R/E presets; 999 Continuous Copy

Scanning Up to 65 pages/minute with 2-sided B/W originals at standard resolution

(includes Fax & Internet-Fax) Up to 35 pages/minute with Color Copy or
Scan originals at standard resolution

Original Feeder Duplex Single Pass; 150-sheet capacity (using 20 lb. bond)

Sizes: 5 ½" x 8 ½ ", 8 ½" x 11", 8 ½" x 11" R, 8 ½" x 14", 11" x 17"
(13-34 lb. bond)

Paper Feed Standard: 2,000-sheet drawer (letter) and two adjustable 500-sheet

drawers (letter, legal, 12" x 18",ledger, statement size) weights up to
110 lb. index, 100-sheet bypass tray. Optional: 3,500-sheet large capacity
tray (letter) or 3,000-sheet large capacity tray (letter, legal, ledger
or 12" x 18" paper)

Paper Types Paper drawers: 1 & 2: 16-28 lb. bond paper

Paper drawers: 3 & 4: 16 lb. bond–110 lb. index paper
Other paper types include plain, pre-printed, recycled, pre-punched,
letterhead and color paper.

Bypass Tray Capacity: 100 sheets (letter, legal, ledger, statement, 12" x 18"

& envelope size)Categories: Plain paper (16-28 lb. bond 60-105 GSM),
Heavy paper (28-68 lb. Bond / 140 Index / 106-256 GSM) Envelope
(20-24 lb. bond / Monarch / Com-10), Tab paper (letter only). Other
types include label stock, gloss paper, pre-printed, recycled,
pre-punched, letterhead, color, and OHP film.

Output Tray Main output tray (top) 250 sheets (face down)(option);

Standard: Right-side tray 100 sheets (face down)

Duplexing Standard automatic duplex copying and printing of up to 110 Index
Interface Ethernet (10/100BaseT), USB 2.0 (host port), USB 2.0 (device port)
Memory Standard 1.28 GB (copier memory)

1 GB (printer/network scanning) memory

Hard Disk 80 GB HDD;

Document Filing: 40 GB

• Main/Custom: Up to 4,200 pages or 3,000 files

• Quick Folders: Up to 1,400 pages or 1,000 files

Resolution Scan: monochrome / color: Max 600 DPI;

Copy Output (B&W / Color): Max 600 DPI

Halftone Equivalent to 256 gradations/2 levels (mono)
Color modes Auto Color Selection, Full Color, B/W, Dual & Single Color Modes
Copy Features Scan-once Print-many (Electronic Sorting), Offset-stacking, Auto Color

Selection (ACS), Auto Paper Selection (APS), Auto Magnification Selection
(AMS), Auto Tray Switching, Rotation Copy, Job Reservation, Tandem Copy,
Book Copy, Margin Shift, Tab-paper Insertion, Edge Erase, Center Erase,
Dual-page Copy, Cover Pages, Insert Pages, OHP Insertion, Job Build, Card
Shot, Mirror Image, B/W Reversal, Centering, Proof Copy, 2-in-1, 4-in-1,
Pamphlet, Photo Repeat, Multi-page Enlargement, Document Filing,
Account Management, Job Programs, Stamp Mode (Date / Text /

Page B&W / Color)

1

Accounts Up to 1,000 users. Suppor ts user-number authentication

(on device), login name/password (on device) or login
name/password (on device via LDAP or other servers)

Firmware Flash ROM update via USB and/or network
Power Source AC 100-127 VAC, 60 HZ, 20 Amps
Power Consumption Approx. Max: 1.92kw;

Low Power: 288.7w (MX-6201N); 319.5w (MX-7001N);
Sleep Mode: 95w

Weight Approximately 461 lbs.

Dimensions 31-19/64"(w) x 28-9/64" (d) x 48-7/32" (h)

Network Printing System (standard)

Emulation PCL6 / PCL5c compatible, optional PS3

Resolution 1,200 dpi (monochrome), 600 DPI, 300 DPI

2

OS Support Windows® 98, Windows Me, Windows XP, Windows NT®4 (SP5 or later),

Windows 2000, Windows Server® 2003, Windows Vista

TM

, Unix®, Novell®

NetWare® 3.x/4.x/5.x, MAC OS® 9.x, MAC® OSX

Software Print drivers, Printer Status Monitor and Printer Administration Utility
Features Continuous, Duplex, Pamphlet, N-up, Image Rotation, Different Cover

Page/Last Page, Transparency Inserts, Tabs, Carbon-copy Print,
Fit-to-page, Poster, Margin Shift, Mirror Image, Watermarks, Overlay,
Confidential, Confidential Batch, Release from Hold, Proof, Bypass, Job
Priority, Job Control, Tandem and Direct printing (Note: some features not

available on all print drivers)

1

Direct Printing File Types: TIFF, JPEG, PCL, TXT, PDF, Encr ypted PDF, and PostScript ®

2

Methods: FTP, Web page, E-mail and USB memory

Interface Ethernet; 10/100 BaseT; USB 2.0
Network Protocols TCP/IP, IPv6, IPsec, SSL, SMTP, FTP, SMB, IPX/SPX, and AppleTalk®

for Macintosh® environments

Print Protocols LPR, IPP, PAP, Raw TCP (port 9100), FTP, Novell® Pserver/Rprinter
Print Drivers Windows 98, Windows Me, Windows NT4.0 (SP5 or later), Windows 2000,

Windows XP, Windows Server 2003, Windows Vista, MAC PPD (optional),
MAC OS9, MAC OSX

Security SSL, IPP, IP/MAC address filtering, protocol filtering, port management and

user authentication with account control

Network Scanning System (standard)

Scan Output Resolution: 600, 400, 300, 200 or 100 DPI
Image Formats Monochrome: TIFF, PDF, Encrypted PDF

Color / Grayscale: TIFF, JPG, PDF, Encrypted PDF
Internet Fax (options): TIFF-FX, TIFF-F, TIFF-S

Compression Mono: Uncompressed, G3 (MH), G4(MR/MMR)

Color/ Grayscale: JPEG (high, middle, low)
Internet Fax: MH/MMR (option)

Destinations E-mail, Desktop, FTP, Folder (SMB), USB memory, Internet fax (option),

Super G3 fax (option)

One-Touch Up to 999 destinations (combined with scan destinations)

and up to 500 Groups

Programs 48 total
Scanning Protocols TCP/IP (includes SMTP, LDAP, FTP, SMB, SMTPS, POP3S, FTPS)
Security SSL, user authentication with account control, comprehensive access control,

e-mail Audit control and Document Administration.

Configuration Web-based management; user/administrator level login security
Method with 32 alpha-numeric characters
Software Sharpdesk desktop document management software (1 user license) with

secure FTPS support

B&W Super G3 Fax Kit (option)

Transmission Super G3, G3 (33.6 KBPS)with JBIG, MMR,
Data MR or MH Compression by sheets fed simplex, duplex or off the glass;

Max 400 DPI (ultra-fine) at approximately 2 seconds; JBIG

3

Auto Dialing Up to 999 destinations (combined with scan destinations)

and up to 500 Groups

Inbound Routing Forwards received fax data to E-mail
Originals Up to 31.5" (for transmission)
Programs 48 (combined)
Memory 8 MB (exclusive)
Features Quick on-line transmission, direct transmission, F-Code

transmission/reception, rotate transmission, anti-junk fax reception,
automatically staple received faxes, secure fax release, out of paper
memory reception, auto redial, 2-in-1 transmission, duplex reception
transaction reports, activity reports and PC fax

1

Security Secure fax release, junk fax filter and separation between fax lines and

network ports

3-Position Finisher (option)

Typ e Console finisher with dual exit trays
Output Capacity Upper Tray: 1,550 sheets (letter size, non-stapled)

Lower Tray: 2,450 sheets (letter size, non-stapled)

Staple Positions 1-point front, 1-point back or 2-point stitching
Output Data Face down; 50 sheets (letter) or 30 sheets (mixed sizes)

for stapling 20 lb. Bond; Maximum: 48 sheets (20 lb. Bond) + 2 covers (140 lb. Index)

Saddle-Stitch Finisher (option)

Typ e Console finisher with dual exit trays (mounts on left side of host machine)
Output Trays Upper/Lower Tray: Offset Stack; Saddle Tray: Saddle Stitch Tray
Output Capacity Upper Tray: 1,550 sheets

Lower Tray: 2,450 sheets (letter size-non stapled)

Output Data Face down, 50 sheets (Letter size - 20 lb. Bond); Face down, 30 sheets
for Stapling (Mixed types/sizes of the same width - 20 lb. Bond); Max: 48 sheets 20 lb.

Bond with 2 covers (140 lb. Index)

Saddle-Stitch Up to 15 sheets (20 lb. Bond); Up to 14 sheets (20 lb. Bond) plus one page

of 140 lb. Index; Max Sets - 25 bundles (1-5 sheets), 20 bundles (6-10
sheets), 10 bundles (11-15 sheets)

Paper Pass Unit (option)

Typ e Installed into main unit (required for all output options)

Large Capacity Tray (option 1)

Typ e Large capacity Ledger tray
Paper Size Letter, Letter-R, Legal, Ledger or 12"x 18"
Capacity 3,000 sheets
Paper Types Plain paper, pre-printed, recycled, letterhead,

pre-punched and colored paper up to 110 lb. index

Large Capacity Tray (option 2)

Typ e Large capacity Letter tray
Paper Size Le tter size
Capacity 3,500 sheets
Paper Types Plain paper, pre-printed, recycled, letterhead,

pre-punched and colored paper up to 110 lb. index

Punch Unit (option)

Typ e Floor style module
Ability 3-hole (portrait), 2-hole (short edge)
Dimensions 4-9/16" (w) x 23-5/8" (d) x 39-3/16" (h)
Weight Approximately 17.6 lbs.

Inserter Unit (option)

Typ e Floor style module
Capacity 100 sheets (20 lb. Bond)
Dimensions 17-15/16" (w) x 23-7/16" (d) x 41-11/32" (h)
Weight Approximately 50.7 lbs.

Optional Equipment List

MX-LCX2 Large Capacity Letter Tray
MX-LCX3 Large Capacity Ledger Tray
MX-FNX3 Finisher (three-position stapling, 4,000-sheet stacking)
MX-FNX4 Saddle-stitch Finisher (three-position stapling,

saddle-stapled, 4,000-sheet stacking)

MX-PNX2B Hole Punch Unit (requires MX-FNX3 or MX-FNX4)
MX-PEX2 Fiery Controller (includes PostScript 3)
MX-RBX2 Paper Pass Unit (required for MX-FNX3, MX-FNX4)
MX-CFX1 Inserter (requires MX-FNX4 or MX-FNX3 + MX-PNX2B)
MX-PKX1 PostScript 3 Kit
MX-FWX1 Internet Fax Expansion Kit
MX-FXX1 Facsimile Expansion Kit

MX-AMX1 Application Integration Module

1

MX-AMX2 Application Communication Module

1

MX-AMX3 External Accounting Module

1

MX-FRX9U Data Security Kit

4

AR-PF1 Bar Code Font
MX-USX5 Sharpdesk – 5 User License Kit

Supplies

MX-71NTBA Black Toner Cartridge
MX-70NTCA Cyan Toner Cartridge
MX-70NTMA Magenta Toner Cartridge
MX-70NTYA Yellow Toner Cartridge
MX-71NVBA Black Developer
MX-71NVSA Cyan/Magenta/Yellow D eveloper
MX-70NRBA Black OPC Drum
MX-27NRSA OPC Drum for Cyan/Magenta/Yellow

1

Some features require optional equipment

2

1,200 DPI and Postscript Printing requires
optional PS3 Expansion Kit

3

Actual transmission time will vary based on line conditions.
Based on Sharp Standard Test Chart with approximately

700 characters, letter size in standard resolution

4

Option not available at time of launch

MX-6201N/MX-7001N SPECIFICATIONS

SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, NJ 07430-1163
1-800-BE-SHARP • www.sharpusa.com

7/07 • CPD-3795

Design and specifications subject to change without notice. Sharp, Sharp OSA,
Sharpdesk, My Sharp and all related trademarks are trademarks or registered
trademarks of Sharp Corporation and/or its affiliated companies. Windows,
Windows NT, Windows Server and Windows Vista are trademarks or registered
trademarks of Microsoft Corporation. All other trademarks are the property of
their respective owners.

© 2007 Sharp Electronics Corporation

Printed in U.S.A.
