R
FP-G50J
“Plasmacluster” and “Device of a cluster of grapes” are
trademarks of Sharp Corporation.
AIR PURIFIER
OPERATION MANUAL
*The number in this technology mark indicates an
approximate number of ions supplied into air of 1 cm
which is measured around the center of a room with
the “high-density plasmacluster 7000” applicable oor
area (at 1.2 m height above the oor) at the medium
wind volume in air purifying mode, when an air purier
using the high-density plasmacluster ion evolving
device is placed close to a wall. This product is
equipped with a device corresponding to this capacity.
3
,
Free standing type
OM_FP-G50J_EN.indd 1 2017/01/10 16:47:14
Please read before operating your new Air Purier
The air purier draws in room air from the air intake, passes the air through a Back
Panel, a Deodorizing Filter and a HEPA Filter inside of the unit, then discharges the air
through the air outlet. The HEPA Filter can remove 99.97% of dust particles as small
as 0.3 microns that pass through the lter and also helps absorb odors.
The Deodorizing Filter gradually absorbs odors as they pass through the lter.
Some odors absorbed by the lters may break down over time, resulting in additional
odor. Depending on the usage environment, especially when the product is used in
extreme environments (significantly more severe than normal household use), this
odor may become strong in a shorter period than expected. If the odor persists, the
lters should be replaced.
NOTE
• The air purier is designed to remove air-suspended dust and odor, but not harmful gases (for example, carbon monoxide contained in cigarette smoke). If the source of the odor still exists, the air
purier may not completely remove the odor.
HEPA Filter
Deodorizing Filter
Back Panel
OM_FP-G50J_EN.indd 2 2017/01/10 16:47:15
ENGLISH
FEATURES
Unique Combination of Air Treatment
Technologies
Triple Filtration System + Plasmacluster
TRAPS DUST*
Pre-filter traps dust and other large
airborne particles.
DECREASES ODORS
Deodorizing filter absorbs many common
household odors.
REDUCES POLLEN & MOLD*
HEPA filter traps 99.97% of particles as
small as 0.3 microns.
FRESHENS
Plasmacluster treats the air similar to the
way nature cleans the environment by
emitting a balance of positive and negative
ions.
*When air is drawn through the lter
system.
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
PART NAMES
FILTER INSTALLATION
OPERATION
CARE AND MAINTENANCE
TROUBLESHOOTING
SPECIFICATIONS
FOR CUSTOMER ASSISTANCE
...............................................
.............................
.................................................
.....................
..............................
......................................
............
.....
E-2
E-4
E-5
E-6
E-8
E-10
E-11
E-12
Sensor Technology continuously monitors
air quality, and automatically adjusting
operation based on detected air purity.
Thank you for purchasing the SHARP
Air Purier. Please read this manual carefully.
Before using this product, be sure to read the
section: “Important Safety Instructions.”
After reading this manual, keep it in a
convenient location for future reference.
For your reference, we recommend to keep
this manual in the place where you can read
at any time.
E-1
OM_FP-G50J_EN.indd 1 2017/01/10 16:47:15
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic safety precautions should be followed, including the following:
WARNING
• Read all instructions before using the unit.
• Use only a 220-240 volt outlet.
• Do not use the unit if the power cord or plug is damaged or the connection to the
wall outlet is loosened.
• Periodically remove dust from the power plug.
• Do not insert ngers or foreign objects into the intake or air outlet.
• When removing the power plug, always hold the plug and never pull the cord.
Electrical shock and/or re from short circuit may occur as a result.
• Be careful not to damage the power cord, it may cause electric shock, excess heat or
res.
• Do not remove the plug when your hands are wet.
• Do not use this unit near gas appliances or replaces.
• Remove the power plug from the wall outlet before cleaning the unit and when not
using the unit.
Electrical shock from bad insulation and/or re from short circuit may occur as a result.
• When cleaning the unit, or when the unit is not in use, be sure to unplug the unit. Electrical
shock and/or re from a short circuit may result.
• If the power cord is damaged, it must be replaced by the manufacturer, its service
agent, Sharp Approved Service Centre or similarly qualified person in order to
avoid a hazard.
• Do not operate when using aerosol insecticides or in rooms where there is oily residue,
incense, sparks from lit cigarettes, chemical fumes in the air or in very high humidity conditions, such as a bathroom.
• Be cautious when cleaning the unit. Corrosive cleansers may damage the exterior.
• Only a Sharp Authorized Service Centre should service this air purier. Contact the near-
est Service Centre for any problems, adjustments, or repairs.
• This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
- To reduce the risk of electrical shock, re or injury to persons:
NOTE
If this air purier should cause interference to radio or television reception, try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the unit and radio/TV receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
- Radio or TV Interference
E-2
OM_FP-G50J_EN.indd 2 2017/01/10 16:47:15
CAUTIONS CONCERNING OPERATION
• Do not block the intake and/or air outlet.
• Do not use the unit near or on hot objects, such as stoves or heaters or where it may
come into contact with steam.
• Do not lay the unit down when using.
• Always hold the handle on the back of the unit when moving it.
• Do not use without the lters inside the unit.
• Do not wash and reuse the HEPA lter and the deodorizing lter.
Not only does it not improve lter performance, it may cause electric shock or malfunction.
INSTALLATION GUIDELINES
• When using the unit, place it away from equipment utilizing electric waves such as
televisions or radios to avoid electrical interference.
• Avoid use in locations where furniture, fabrics or other items may come in contact
with and restrict the air intake and/or air outlet.
• Avoid use in locations where the unit is exposed to condensation or drastic
temperature changes. Appropriate conditions are when room temperature is
between 0 – 35 ºC.
• Place on a stable surface with sufcient air circulation.
When placing the unit on a heavily carpeted area, the unit may vibrate slightly.
• Avoid locations where grease or oily smoke is generated.
The unit surface may crack as a result.
• Place the unit about 30 cm(1 ft) away from the wall in order to ensure proper
airow.
The dust collecting performance will be the same even if using the unit 3cm away from
the wall, but place it as far as possible(30cm away recommended) because it may dirty
the wall or oor around.
FILTER GUIDELINES
• Follow the instructions in this manual for correct care and maintenance of the lter.
E-3
OM_FP-G50J_EN.indd 3 2017/01/10 16:47:15
PART NAMES
FRONT
2
1
9
PLASMACLUSTER SIGN
blue Plasmacluster ON
off Plasmacluster OFF
3 4 5 6
8
DUST AND ODOR SIGN
Indicates the air purity of the room
in 3 levels with color changes.
Green
Orange
Red
7
Clean
Impure
BACK
12
10
13
14
15
16
(Shape of plug depends on country.)
18
Main Unit
1
Air Outlet
2
OFF TIMER Button / OFF TIMER indicator Light (green)
3
LIGHT ON/OFF Button (Press 3 sec.)
MODE Button / MODE Indicator Light (green)
4
Plasmacluster Ion ON/OFF Button(Press 3 sec.)
CLEAN ION SHOWER Button /
5
CLEAN ION SHOWER indicator Light (green)
POWER ON/OFF Button
6
ODOR sensor
7
DUST AND ODOR SIGN
8
PLASMACLUSTER SIGN
9
17
11
19
Handle
10
Dust Sensor /
11
Dust Sensor Filter
HEPA Filter
12
Deodorizing Filter
13
Upper Tabs
14
Back Panel (Pre-Filter)
15
Bottom Tabs
16
Power Cord
17
Plug
18
Date Label
19
E-4
OM_FP-G50J_EN.indd 4 2017/01/10 16:47:18
Be sure to remove the power plug
Starting date of use
. .
. .
. .. .
. .. .
FZ-F50HFE
HEPA Filter
Deodorizing Filter
FZ-F50DFE
. .. .
. .. .
. .. .
MODEL
MODEL
FILTER INSTALLATION
To maintain the quality of the lter, it is installed in the main unit and packed in plastic
bag. Be sure to remove the lter from the plastic bag before using the unit.
from the wall outlet.
Remove the Back Panel.
1
Upper Tabs
Pull
Remove the lter from the plas-
2
tic bag.
Replace the Back Panel to the
4
main unit.
Push
Push
Bottom Tabs
Fill in the usage start date on the
5
Date Label.
Use the date as a guide for the lter re-
placement schedule.
OM_FP-G50J_EN.indd 5 2017/01/10 16:47:21
Place the Filter within the main
3
unit.
Do not install the lter backwards or the
unit will not operate properly.
HEPA Filter
Deodorizing Filter
Date Label
• Do not operate the unit without the lter.
E-5
OPERATION
CLEAN AIR
START
STOP
• Select the desired fan speed.
• Unless the power cord has been unplugged,
the operation starts in the previous mode it
was operated in.
CLEAN ION SHOWER
Releases high-density Plasmacluster ions and discharges strong air ow for 60 minutes.
START
NOTE
• If Plasmacluster Ion is OFF, Plasmacluster Ion will not be
released.
• When the operation nishes, the unit will return to the prior
operation mode.
It is able to change the other mode and during this
mode.
FAN SPEED
AUTO SLEEP MED MAX
NOTE
AUTO
• The fan speed is automatically switched depending on the
amount of impurities in the air. The sensors detect impurities
for efcient air purcation.
SLEEP
• The unit will operate very quietly, and the fan speed
is automatically switched depending on the amount of
impurities in the air.
DUST AND ODOR/PLASMACLUSTER SIGN go off
automatically.
Even though the indicator is off, Plasmacluster Ion is
dispersed into air unless Plasmacluster Ion is turned off by
.
E-6
OM_FP-G50J_EN.indd 6 2017/01/10 16:47:26
OFF TIMER
Select the length of time you want, with the unit on. The unit automatically stops once the selected
time is reached.
CANCELLATION
Light Control
You can set the DUST AND ODOR/PLASMACLUSTER SIGN to OFF when their SIGN is bright.
ON
more than 3 sec.
OFF
more than 3 sec.
NOTE
• When the unit restarts its
operation, Light Control
resumes its setting set before
turning off.
• At Sleep Mode, Light Control
is available.
Plasmacluster Ion ON/OFF
When Plasmacluster Ion is ON, the PLASMACLUSTER SIGN will turn on. (blue)
(In operation)
ON OFF
more than 3 sec. more than 3 sec.
ADJUSTMENT OF SENSOR DETECTION SENSITIVITY
Set to “Low” if the DUST AND ODOR SIGN is constantly red to reduce sensitivity, and set to “High” if
the DUST AND ODOR SIGN is constantly green to increase sensitivity.
1
NOTE
more than 3 sec.
(with the unit OFF)
2
High
Standard
• If the power ON/OFF Button is
not pushed within 8 seconds of
adjusting sensor sensitivity, the
setting will be saved automatically.
• The sensor sensitivity setting
will be saved even if the unit is
unplugged.
Low
3
E-7
OM_FP-G50J_EN.indd 7 2017/01/10 16:47:34
CARE AND MAINTENANCE
To maintain optimum performance of this air purier, please clean the unit including the lter
periodically.
Be sure to disconnect the power cord from the wall outlet before performing any maintenance.
BACK PANEL
Back Panel
NOTE How to clean hard to remove dirt
Back Panel
FILTERS
HEPA Filter
Tag
Gently remove dust from HEPA Filter and Deodorizing Filter with a vacuum
cleaner attachment or similar tool.
(Pre-lter)
Gently remove dust from the back panel, using a vacuum
cleaner attachment or similar tool.
CAUTION
Do not apply excessive pressure, when scrubbing the back
panel.
1. Add a small amount of kitchen detergent to water and soak
for about 10 minutes.
2. Rinse off the kitchen detergent with clean water.
3. Completely dry the lter in a well-ventilated area.
CAUTION
Deodorizing Filter
UNIT
Do not WASH in water and DRY in the sun.
The lters are fragile, be careful not to apply too much force.
• HEPA Filter
Apply the maintenance only on the side with the tag.
Do not clean the opposite side; otherwise, the lter will be
damaged.
• Deodorizing Filter
The maintenance can be applied to the both sides.
Wipe with a dry, soft cloth
For stubborn stains or dirt, use a soft cloth dampened with warm water.
CAUTION
•Do not use volatile uids
Benzine, paint thinner, polishing powder, etc., may damage the surface.
•Do not use detergents
Detergent ingredients may damage the unit.
E-8
OM_FP-G50J_EN.indd 8 2017/01/10 16:47:37
Be sure to remove the power plug from the wall outlet.
SENSORS
Dust sensor
1. Remove the Back Panel.
Dust sensor
lter
2. Remove the Dust Sensor Filter.
3. If it is very dirty, wash it with water and dry
it thoroughly.
Odor sensor
Odor sensor
Gently remove dust from the odor sensor,
using a vacuum cleaner attachment or similar
tool.
FILTER REPLACEMENT GUIDELINES
Replacement timing
Do not wash and reuse the lter
The lter life and replacement period are based on the condition of smoking 5 cigarettes per
day and the Dust and odor collection power is reduced by half compared with that of new lter.
Filter life varies depending on the room environment, usage, and location of the unit.
We recommend to replace the lter more frequently if the product is used in a condition significantly severer than normal household use.
REPLACING THE FILTER
About 2 years after operating
Replacement Filter
Model:FZ-F50HFE Model:FZ-F50DFE
• HEPA Filter : 1 unit • Deodorizing Filter : 1 unit
• Please consult your dealer for purchase of replacement lter.
• Use only lter designed for this product.
See page E-5 for directions on how to
install the lter when replacing.
Date Label
Disposal of Filter
Please dispose of the replaced lter according to the local disposal laws and regulations.
HEPA Filter materials :
•Filter : Polypropylene
•Frame : Polyester
Deodorizing Filter materials :
•Polypropylene, Polyester, Activated charcoal
E-9
OM_FP-G50J_EN.indd 9 2017/01/10 16:47:39
TROUBLESHOOTING
Before calling for service, please review the Troubleshooting chart below, since the problem may not
be a unit malfunction.
SYMPTOM REMEDY (not a malfunction)
Odors and smoke are not removed.
The DUST AND ODOR SIGN
illuminates green even when the
air is impure.
The DUST AND ODOR SIGN illuminates orange or red even when
the air is clean.
A clicking or ticking sound is heard
from the unit.
The discharged air has an odor.
The unit does not operate properly
when cigarette smoke is in the air.
• Replace the lters if they appear to be heavily soiled.
(Ref. E-9)
• The air could be impure at the time the unit was plugged in.
Unplug the unit, wait one minute, and plug the unit in again.
• Sensor operation is affected if the Dust and odor sensor
openings are dirty or clogged. Gently clean the Dust and odor
sensor openings.
(Ref. E-9).
• Clicking or ticking sounds may be audible when the unit is
generating ions.
• Check to see if the lters are heavily soiled.
• Clean or replace the lters.
• Plasmacluster Air Puriers emit small traces of ozone which
may produce an odor.
• Is the unit installed in a location that is difcult for the sensor to
detect cigarette smoke?
• Is the dust and odor sensor opening blocked or clogged?
(In this case, clean the opening.) (Ref. E-9)
The
DUST AND ODOR SIGN
is
turned off.
The DUST AND ODOR SIGN lights
change colour frequently.
• Check to see if the Lights OFF Mode selected.
Press
Check to see if the SLEEP mode is selected.
•
The DUST AND ODOR/PLASMACLUSTER SIGN are turned off
automatically after the SLEEP mode is selected.
• The DUST AND ODOR SIGN lights automatically change
colours as impurities are detected by the Dust and odor sensor.
for 3 seconds to light On. (Ref. E-7)
E-10
OM_FP-G50J_EN.indd 10 2017/01/10 16:47:40
SYMPTOM REMEDY (not a malfunction)
AUTO RESTART
After a power failure, automatically
resume the operation when the
power recovers.
Auto Restart can be set.
• Even when the plug is unplugged or the breaker is thrown
during the operation, the operation resumes at the previous
operation mode and settings if the power recovers.
ON OFF
(with the unit OFF) (with the unit OFF)
(simultaneously for more than 3 sec.) (simultaneously for more than 3 sec.)
If the , , lamp Lights up
for 10 seconds, the setting is completed.
SPECIFICATIONS
Power supply 220-240V 50-60Hz
Fan
Speed
Operation
Recommended Room Size ~40m
High density Plasmacluster ion recommended room size
Cord Length 2.0m
Dimensions 383mm(W)x209mm(D)x540mm(H)
Weight 5.1kg
Fan Speed Adjustment MAX MED SLEEP
Rated Power 47W 16W 4.0~5.5W
Fan Speed 306m
3
/hour 186m3/hour 48~90m3/hour
2 *2
2 *3
~23m
*1
*1 The fan speed is automatically switched depending on the amount of impurities in the air.
*2 Size of a room which is appropriate for operating the unit at maximum fan speed.
• It indicates the space where a certain amount of dust particles can be removed in 30 minutes
(JEM1467).
*3 Size of a room in which approximately 7000 ions can be measured per cubic centimeter in the
center of the room (at a height of approximately 1.2 meters from the oor) when the product is
placed next to a wall and run at the MED operation position.
Standby Power
In order to operate the electrical circuits while the power plug is inserted in the
wall outlet, this product consumes about 1.0W of standby power.
For energy saving, unplug the power cord when the unit is not in use.
E-11
OM_FP-G50J_EN.indd 11 2017/01/10 16:47:43
FOR CUSTOMER ASSISTANCE
North Ryde NSW 2113
FOR CUSTOMER ASSISTANCE
FOR LOCATION ENQUIRIES WITHIN
NEW ZEALAND
REGARDING YOUR LOCAL
SHARP CORPORATION OF NEW ZEALAND LIMITED
VISIT OUR WEBSITE AT
SHARP CUSTOMER SERVICES
TELEPHONE: 09 573 0111
FACSIMILE: 09 573 0113
SPform019(AUGUST 2011)
SHARP APPROVED SERVICE CENTRE
www.sharp.net.nz
CONTACT YOUR SELLING DEALER/RETAILER
OR CALL
FOR LOCATION ENQUIRIES WITHIN
AUSTRALIA
REGARDING YOUR LOCAL
SHARP APPROVED SERVICE CENTRE
VISIT OUR WEBSITE AT
www.sharp.net.au
OR CALL SHARP CUSTOMER CARE
1300 135 022
SHARP CORPORATION OF AUSTRALIA PTY LTD
(LOCAL CALL COSTS APPLY WITHIN AUSTRALIA)
WARRANTY
Consumer Electronic Products
Congratulations on Your Purchase!
This Sharp product is warranted against faults in material and manufacture for the
period as stated in the table below.
If service is required during the warranty period, please contact your nearest Sharp
Approved Service Centre. These repairs would be carried out at no charge to the
owner, subject to the conditions specified herein.
This warranty does not extend to defects or injuries caused by or resulting from causes
not attributable to faulty parts or the manufacture of the product, including but not
limited to, defect or injury caused by or resulting from misuse, abuse, neglect, lack of
maintenance, accidental damage, improper voltage, liquid spillage, vermin infestation,
software, or any alterations made to the product which are not authorised by Sharp.
Please retain your sales documentation, as this should be produced to validate a
warranty claim. This warranty is in addition to and in no way limits, varies or excludes
any implied rights and remedies under any relevant legislation in the country of sale.
This warranty does not cover transportation to and from the Sharp Approved Service
Centre. Goods presented for repair may be replaced by refurbished goods of the same
type rather than being repaired. Refurbished parts may be used to repair the goods.
The repair of your goods may result in the loss of user generated data, please ensure
that you have saved this data elsewhere prior to repair.
Australian customers: Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount
to a major failure. The criteria of a major failure is defined in the Australian
Consumer Law. Should you require any assistance with a major failure please
contact Sharp Customer Care.
WARRANTY PERIODS
Home Theatre Projector 12 months
Audio/Home Theatre 12 months
Microwave Oven 12 months
Steam Oven 12 months
Refrigerator 24 months
DVD/Blu-ray 12 months
Air Conditioner 60 months
Portable Air Conditioner 12 months
LCD Television 36 months
Air Purifier 12 months
(excluding lamps and air filters)
SHARP CORPORATION OF
AUSTRALIA PTY. LIMITED
ABN 40 003 039 405
2 Julius Avenue
SHARP CORPORATION OF
NEW ZEALAND LIMITED
59 Hugo Johnston Drive
Penrose, Auckland
SPform 040 (AUGUST 2011)
IMPORTANT NOTICE: This warranty applies only to products sold in Australia&New Zealand
OM_FP-G50J_EN.indd 12 2017/01/10 16:47:44
E-12
FOR CUSTOMER ASSISTANCE
FOR LOCATION ENQUIRIES WITHIN
AUSTRALIA
REGARDING YOUR LOCAL
SHARP APPROVED SERVICE CENTRE
VISIT OUR WEBSITE AT
www.sharp.net.au
OR CALL SHARP CUSTOMER CARE
1300 135 022
(LOCAL CALL COSTS APPLY WITHIN AUSTRALIA)
SHARP CORPORATION OF AUSTRALIA PTY LTD
FOR LOCATION ENQUIRIES WITHIN
NEW ZEALAND
REGARDING YOUR LOCAL
SHARP APPROVED SERVICE CENTRE
VISIT OUR WEBSITE AT
www.sharp.net.nz
CONTACT YOUR SELLING DEALER/RETAILER
OR CALL
SHARP CUSTOMER SERVICES
TELEPHONE: 09 573 0111
FACSIMILE: 09 573 0113
SHARP CORPORATION OF NEW ZEALAND LIMITED
SPform019(AUGUST 2011)
E-13
OM_FP-G50J_EN.indd 13 2017/01/10 16:47:44
SHARP CORPORATION OF AUSTRALIA PTY.LTD.
A. B. N. 40 003 039 405
2 JULIUS AVENUE, NORTH RYDE, N.S.W. 2113
P.O.BOX 84, MACQUARIE PARK. N.S.W 2113
SHARP CORPORATION OF NEW ZEALAND LIMITED
59 HUGO JOHNSTON DRIVE PENROSE, AUCKLAND
Printed in Thailand
TINS-B009KKRZ 17B- 1
OM_FP-G50J_EN.indd 14 2017/01/10 16:47:44
Loading...
