Contents
GETTING STARTED
Features ……………………………………………………… 4
What’s Included ……………………………………………… 5
Getting to know your Monitoring system …………………… 6
INSTALLATION & NETWORK CONNECTION
Installation …………………………………………………… 8
Network Connection and Settings …………………………… 13
MONITORING
Registration …………………………………………………… 16
Live Video …………………………………………………… 21
Setup ………………………………………………………… 23
Event Alarm ………………………………………………… 30
Information …………………………………………………… 30
APPENDIX
Specifications ………………………………………………… 32
Troubleshooting ……………………………………………… 35
GETTING STARTED
Features 4
What’s Included 5
Getting to know your Monitoring
system 6
Power Supply 7
Network connection 7
01
Features
• Easy to install
- With the help of WPS (Wi-Fi Protected Setup), wireless sharing and easy
connection are enabled.
- Simply visit the home page (www.samsungsmartcam.com) and download and
install the program without a separate installer program.
• Remote monitoring
- Whenever and wherever if you are in the Internet enabled environment, remote
monitoring is ready for you.
- PC, laptop or smart phone can be used for monitoring.
• Real-time alarm
- When a motion and sound are detected, your smartphone will generate real time
alarms.
• Cloud Storage
- Upload the event video and images to the user’s YouTube (video) or Picasa
(images) account automatically.
- Anytime anywhere you can enjoy the video and images stored in the cloud
storage.
• Two-way Audio
- With the built-in speakers and microphone, you can make Two-way
communications.
However, it is available only with the smart phone. (Not applicable to the PC or
laptop computer.)
• SNS (Social Networking Service) Alarm supported
- Provide the event alarm (message, video, image) via YouTube, Picasa or Twitter.
- Share special video footage and images with your friends.
• IR LED
- In a low contrast scene, you can use IR LED for the monitoring purpose.
4
· English
What’s Included
Check for components when opening the product package.
Camera & Bracket bodyPower AdaptorNetwork CableQuick Start Guide
` Please save the packaging. You will need the serial number later to register the camera.
n
5
Getting to know your Monitoring system
Built-in IR LEDs for night vision
High quality camera lens
Luminance Sensor
Detects light levels where the camera is placed.
Night vision mode changes according to detection
result.
Power / Wi-Fi status LED
Built-in Mic
6
· English
RESET
DC IN 5V
NETWORK
SAMSUNG SMARTCAM
DC 5V Power Input
Network port
Used if WPS is not supported on the Wireless
Access Point or if you do not have a Wireless
Access Point
Built-in speaker
Produces sound transferred from a smart phone.
Reset button
Resets the camera settings to the default.
Press and hold for about 5 seconds to reboot the
system.
WPS button
Used to pairing the camera with the Wireless Access
Point.
Power Supply
Network connection
Plug-in the camera power adapter to the wall outlet and connect the camera as
shown.
` Make sure to use the provided power adaptor. Otherwise, the product may not operate
n
properly.
` It will take about 1min for the camera to boot-up completely.` When the boot-up is complete, the power LED color will change from red to blue.
DC IN 5V
NETWORK
SAMSUNG SMARTCAM
RESET
UNLOCK
◀
▶
LOCK
Connect the provided network cable to the camera’s network terminal.
For further details on network configuration, refer to “Network Connection and
Settings”. (Page 13)
LED status
LED indicator shows operational status with colors.
Refer to table below for detailed meaning of the LED indicator.
ColorStatus
RedBooting up
Red BlinkingBooting completed / Establishing network connection
Blue BlinkingPairing WPS (0.5 seconds) / In Network Setting (1 second)
BlueLocal connection established
GreenConnection to server completed / Normal operation
MagentaUpdating firmware
01
Getting Started
7
INSTALLATION &
NETWORK CONNECTION
Installation 8
Precautions 8
Wall Mounting Using Double-sided adhesive tape 9
Wall Mounting with Screws 11
Desktop mounting 12
Network Connection and Settings 13
Precautions 13
Connecting via network cable 13
Connecting via Wi-Fi without WPS feature 14
Conneting using Wi-Fi WPS feature 14
02
Installation
Precautions
1. Install the camera in a place where the Wi-Fi signal can be reached and
without interference.
2. Keep it away from humidity such as around the humidifier.
3. Keep it away from direct sunlight, strong light or dust; install it in a place with
clear view.
4. Do not install it in a place where there are a lot of obstacles.
5. Keep the lens clean at all times.
Wipe off the dust with a soft cloth.
6. Switching between day and night time is done according to detection result
of the luminance sensor on the left side.
8
· English
Wall Mounting Using Double-sided adhesive tape
TOP
Separating the wall-mount bracket
1. Press and hold [PUSH TO RELEASE] on the left side of bracket and turn the
bracket counterclockwise to separate it.
` You may turn the bracket body counterclockwise without pressing the [PUSH TO
n
RELEASE].
3. Hold the adhesive tape's holder and remove the protective film, and attach it
to the desired spot of the wall-mount bracket while making the [▲ TOP]
marker point upwards (direction of 12 o’clock).
` The tape will lose adhesiveness if used once, do not re-use.
n
` Before attaching tape, clean dust / water / oil off the wall-mount bracket’s adhesive
spot for better result.
TOPTOP
02
UN
LOCK
◀
▶
LOCK
Assembling
1. Take out tape for wall mounting from the zipper bag.
2. Remove the rectangular protective film from
the adhesive tape and attach it to the
bottom of the wall-mount bracket.
Installation & Network Connection
9
Run the provided adaptor wire through the
4.
groove prepared on the wall-mount bracket.
` Match adaptor’s plug part to the direction of 12
n
o’clock.
5. Arrange the wire by using two grooves on the body bracket.
` Make both body bracket’s [UNLOCK LOCK] and wall-mount bracket’s [▲ TOP] marks
n
face the same direction.
6. Fix the body bracket by turning it clockwise until it clicks.
UNLOCK ◀
▶ LOCK
Grooves on the
TOP
body bracket
7. Connect the adaptor’s plug to the power
terminal on the camera’s rear side.
` When done, remove the protective film from
n
the lens.
DC IN 5V
NETWORK
SAMSUNG SMARTCAM
RESET
10
· English
Adjusting the Angle
1. Adjust the camera’s shooting angle as
appropriate.
` Do not put excessive force. Otherwise, it may
n
cause damage to the camera.
Wall Mounting with Screws
LOCK
UNLOCK ◀ ▶
` For more information about step of Separating the wall-mount bracket, refer to “Wall
n
Mounting Using Double-sided adhesive tape”.
Assembling
2. Turn the part shown in the figure clockwise to
lock the bracket’s ball hinge and fix the
shooting angle.
3. Turn it counterclockwise to unlock the ball
hinge and adjust the shooting angle.
` Turning the camera counterclockwise while the
J
bracket body is locked may turn the bracket knob
too, and fail to fix it. In such cases, turn the
bracket knob clockwise.
Bracket knob
1. Take out screws (M3xL20) and Anchor (Φ5x25) from the zipper bag.
2. On a wooden wall, use screws to fix the
wall-mount bracket as shown in the figure.
LOCK
◀ ▶
UNLOCK
Place the wall-mount bracket on the desired
spot while setting its [▲ TOP] mark towards
direction of 12 o’clock and fasten screws
through the 4 holes using screwdriver.
3.
If fixing on a concrete wall, use screws and anchors to fix wall-mount bracket
First, mark on the wall as shown in the figure below.
TOP
02
Installation & Network Connection
.
11
4. Use drill bit of 5mm diameter and drill on the
marked positions, drill to have 3 cm depth
holes. Clean the holes after drilling.
` Be careful not to get injured while drilling.
J
5. Insert an anchor for each hole. Fully insert
anchors by hammering lightly the anchor
head with a hammer/rubber hammer.
6. Place the wall-mount bracket on the desired
spot while setting its [▲ TOP] mark towards
direction of 12 o’clock and fasten screws
through the 4 holes using screwdriver.
` For further steps, refer to the instructions for
n
“Wall Mounting Using Double-sided adhesive
tape”.
Desktop mounting
` For more information about step of Separating the wall-mount bracket, refer to “Wall
n
Mounting Using Double-sided adhesive tape”.
Assembling
1. Assemble body bracket and wall-mount bracket while matching the [▼] and
[▲] marks.
2. Turn the body bracket clockwise until it clicks, use the groove on the body
bracket.
3. Connect the adaptor’s plug to the power terminal on the camera’s rear side.
DC IN 5V
NETWORK
SAMSUNG SMARTCAM
RESET
UNLOCK
◀
▶
LOCK
12
· English
Loading...
+ 25 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
