The Roland VR-760 is a keyboard player’s dream. Imagine an instrument that combines the sound and feel of a vintage organ with top-quality piano sounds, SRXpandable synthesizer sounds and an amazing new collection of electric pianos—all playable from a 76-note waterfall keyboard. Now add expressive controllers like the futuristic D Beam, and V-LINK for integrating video, and you’ve got a powerful new performance keyboard with capabilities beyond anything else.

Keyboard Sound Generator Part Maximum Polyphony Wave Memory Organ Section

Piano Section

■

Tones

●

Piano

Acoustic Piano

Electric Piano

Other Piano

■

MFX Effects (Synth Section)

1 2 3 4 5 6 7 8 9 10

Waterfall 76 keys (with velocity and aftertouch) Organ: Virtual ToneWheel, Piano / Synth / Rhythm: PCM Organ, Piano, Synth, Rhythm Organ: Full Polyphony, Piano / Synth / Rhythm: 128 voices 96 MB (16-bit linear equivalent)

Harmonic Bar: 16', 5-1/3', 8', 4', 2-2/3', 2', 1-3/5', 1-1/3', 1'

•

ToneWheel: VINTAGE 1, VINTAGE 2, CLEAN •Vibrato

•

and Chorus: V-1, V-2, V-3, C-1, C-2, C-3 •Percussion: SECOND, THIRD, SOFT, SLOW •Amplifier: TYPE 1, TYPE 2, TYPE 3, TYPE 4, OVERDRIVE •Rotary: SLOW/FAST, BRAKE

Tones: 9 (3 variations by each A.PIANO, E.PIANO,

•

OTHERS categories) •Mic/Amp: TYPE 1, TYPE 2, DISTANCE/EQ •Piano MFX: CHORUS, TREMOLO, WAH, PHASER, DEPTH, RATE

No.

1 2 3 1 2 3 1 2 3

STEREO EQ OVERDRIVE DISTORTION PHASER SPECTRUM ENHANCER AUTO WAH ROTARY COMPRESSOR LIMITER

Patch Name

ConcertGrand Classical Pf European Pf Rhodes Mark 1 Rhodes Mark 2 Dyno Rhodes Wurly Piano Clav Harpsichord

11 12 13 14 15 16 17 18 19 20

●

Synth

Strings

Choir/Scat

Brass

HEXA-CHORUS TREMOLO CHO SPACE-D STEREO CHORUS ST.FLANGER STEP FLANGER STEREO DELAY MOD DELAY TRI TAP DLY QUAD TAP DLY

Synth Section

Rhythm Section Internal Memory D Beam

Reverb Master EQ Expansion Slot External Memory

Rear Panel

Specifications

Tones: 18 (3 variations by each STRINGS, CHOIR/SCAT,

•

BRASS, SYNTH LEAD, SYNTH PAD, BASS categories), SRX EXPANSION •Tone Modify: ATTACK, RELEASE, CUTOFF, RESO •Synth MFX: ON/OFF, CONTROL •Active Expression: FADE, TIMBRE

Rhythm Pattern: 20 Registration: 64

ORGAN: ROTARY SLOW/FAST •PIANO: OCTAVE

•

SYNTH: GLIDE

•

ROOM, HALL, CHURCH, DEPTH LOW, MIDDLE (FREQ, LEVEL), HIGH Wave Expansion Board SRX Series: 2 slots CompactFlash Memory*

No.

Patch Name

1 2 3 1 2 3 1 2 3

21 22 23 24 25 26 27 28 29 30

Orch Strings European Str Jupiter8 Str Real Choir Female Vox Jazz Scat BrassSection Concert Brass Ob Fat Brass

TIME CTRL DLY 2V PCH SHIFT FBK PCH SHIFT REVERB GATED REVERB OD ➔ CHORUS OD ➔ FLANGER OD ➔ DELAY DIST ➔ CHORUS DIST ➔ FLANGER

Synth Lead

Synth Pad

Bass

Options

Other Functions Display Connectors

Power Supply Power Consumption Dimensions

Weight Accessories

No.

DIST ➔ DELAY

ENHAN ➔ CHORUS

ENHAN ➔ FLANGER

ENHANCR ➔ DELAY

CHORUS ➔ DELAY

FLANGER ➔ DELAY

CHORUS ➔ FLANGR

CHORUS/DELAY

FLANGER/DELAY

CHORUS/FLANGER

1 2 3 1 2 3 1 2 3

V-LINK, ONE TOUCH, SPLIT, H-BAR MANUAL 16 characters, 2 lines (Backlit LCD), 7 segments, 2 characters LED Output Jacks (L/MONO, R), Output Jacks (XLR type),

Phones Jack, Expression Pedal Jack, Damper Pedal Jack, Control Pedal Jack, MIDI Connectors (IN, OUT, THRU), AC Inlet

AC 117 V, AC 230 V, AC 240 V 20 W 1,291 (W) x 400 (D) x 121 (H) mm / 50-7/8 (W) x 15-3/4 (D) x

4-13/16 (H) inches 17 kg / 37 lbs 8 oz Music Rest, Owner's Manual, Power Cord

■

Rhythm Patterns

Patch Name

Vintage Lead Dual Lead Retro Lead OB Pad

2.3 Pad Glassy Pad Ac Bass FretlessBass Hefty Bass

Jazz Funk 1 Jazz Funk 2 Jazz Funk 3 Acid Jazz 8 Beat Pop 1 8 Beat Pop 2 16 Beat Pop 1 16 Beat Pop 2 4 Beat Pop Fusion Pop Ballad Blues 1 Blues 2 2 Beat Rock 4 Beat Rock R&B 1 R&B 2 R&B 3 Swing Jazz Slow Jazz 4 Beat Jazz 5/4 Bar Jazz 7/8 Bar Jazz Latin Jazz

EV-7

Expression Pedal

A durable expression pedal with an extended range appropriate for organ playing.

SRX-01

Dynamic Drum Kits

SRX-02

Concert Piano

Once a musical instrument generates sound vibrations, it reaches the human ear through various mediating objects, each of which significantly affects the sound. The material and configuration of the instrument, the electric/electronic/magnetic amplifying system, the air and the reverberation of the room all affect the final sound. Sound modeling, the latest DSP technology, "virtually" reconstructs these objects. Roland's breakthrough Composite Object Sound Modeling (COSM)uses the advantages of multiple modeling methods and succeeds in accurately emulating existing sounds, as well as producing sounds that have never before been created.

EV-5

Expression Pedal

SRX-03

Studio SRX

FV-300L

Volume/Expression Pedal

Roland Corporation U.S.

5100 S. Eastern Avenue, P.O.Box 910921, Los Angeles, CA90091-0921 Phone: (323)890-3700 Fax: (323)890-3701

Visit us online at www.RolandUS.com

DP-8

Damper Pedal

With half-pedal recognition, this pedal is ideal when playing the VR-760's acoustic piano sounds.

SRX Series Wave Expansion Board

SRX-04

Symphonique Strings

SRX-05

Supreme Dance

DP-2

Pedal Switch

SRX-06

Complete Orchestra

SRX-07

Ultimate Keys

All trademarks used in this catalog are the property of their respective companies.

FS-5U

Foot Switch

SRX-08

Platinum Trax

Roland’s V-LINK makes it possible to control video clips when used with an Edirol DV-7PR Digital Video Workstation (sold separately).

All specifications and appearances are subject to change.

KS-12

Keyboard Stand

SRX-09

World Collection

Printed in Japan JAN. 2003 RAM-3667 ERK-GEN-SE B-4

■ Organ Section

●

Amp Types

Type 1 Type 2 Type 3 Type 4

Faithful simulation of the most popular rotary speaker Simulates the characteristics of a large tube guitar amp Variation of a rotary speaker simulation Features an incredible gain stage for sharper distortion sounds

●

Wheel Types

Vintage 1 Vintage 2 Clean

Modeling of a '70s combo organ with all noise eliminated,including leakage Faithful modeling of a '62 classic combo organ Modeling of a '70s combo organ with motor noise eliminated

Here players can adjust the nine harmonic bars and basic settings for the organ sounds. Everything from the overall volume to ToneWheel type, Vibrato/Chorus, Percussion, COSM Amp Modeling and Rotary can be set using dedicated buttons and knobs.

■ Synth Section

Here players can select among the different tone variations in the synth section. Dedicated Tone Modify knobs make it easy to adjust basic sound parameters. There are also controls for multi-effects settings, Active Expression and overall volume.

With organ sounds based on Roland’s acclaimed VK-Series, the VR-760 can sound just like a vintage organ—complete with a range of spectacular COSM

amp and rotary speaker models.

The VR-760 includes a stunning collection of acoustic piano sounds, plus newly sampled electric pianos that are so realistic, you’ll swear it’s the real thing.

The Sound and Feel of a Classic

The VR-760 uses the same “Virtual ToneWheel” technology found in the popular VK-8 Combo Organ—complete with COSM Amp and Rotary Speaker Modeling— for the most realistic organ tones imaginable. Three tone wheel types (Vintage 1, Vintage 2 and Clean) accurately simulate the sound of clean gospel organs, gritty rock organs and everything in between.

Of course, the sound itself is only half of the story. That’s why Roland gave the VR-760 a 76-note waterfall keyboard— ideal for the distinctive style of organ playing. Seasoned organists will be right at home with these quick-firing keys, which are perfect for playing solos and glissandos. Nine harmonic bars give you full control over the organ tones, which can be played back with full polyphony.

Plug Into COSM Amp and Rotary Speaker Modeling

Four COSM amp models further enhance the VR-760’s organs, delivering a range of distinctive overdriven amp sounds. The VR-760 can even simulate the effect of a vintage rotary speaker with full control over rotary speed and braking. Get those vintage speaker sounds you want without having to hunt down (or move) the real thing!

Unrivaled Electric Piano Sounds

When it comes to classic Rhodes and other electric pianos, the VR-760 is hard to beat. These newly-sampled electric pianos are quite simply the finest Roland has ever offered. And with new COSM Amp Modeling, you can get those classic “suitcase” and “stage” sounds without need for a speaker cabinet— you won’t believe your ears! Dedicated multi-effects let you add anything from rich-sounding chorus to vintage phasing, tremolo and wah effects to create just the electric piano sound you’re after.

■ Piano Section

This panel area provides direct control of the VR-760’s piano sounds. Select among various acoustic and electric piano tones, adjust the overall volume, and even set the mic distance and amp modeling parameters. Multi-effects settings can also be made.

Acoustic Pianos That Are Truly “Grand”

The VR-760 boasts some of Roland’s finest acoustic piano sounds ever, just like our professional digital pianos used on stages the world over. Whether you need expressive grand pianos or bright pop pianos engineered to cut through the mix, the VR-760 has you covered. New COSM Mic Modeling gives these piano sounds natural ambience and resonance— just like a miked grand!

An Expandable Synthesizer with Breathtaking Sounds

With its high-quality synthesizer section, the VR-760 gives players access to just about any sound imaginable. So whether you need rich orchestral sounds or a fat synth lead, you won’t have to search long. Just choose from one of several Tone categories—like Strings, Choir/Scat, Brass, Synth Lead, Synth Pad and Bass— and select the sound you need. Two slots for optional SRX-Series expansions let you add up to 128MB of high-quality sounds tailored for specific genres and applications. These sounds can be further enhanced using the dedicated multi-effects processor, which serves up 40 studio-quality algorithms like distortion, flanging, delay and an enhancer.

■ Reverb Section

This panel section is for making settings to the VR-760’s global reverb effect. Use the button to switch between three reverb types: Room, Hall and Church. Then adjust the effect level using the Depth knob.

Professional Reverb and EQ

With onboard 3-band EQ, the VR-760 lets players tailor their sounds for any live venue. This professional equalizer offers control over the Low, Mid and High frequencies bands—complete with a sweepable mid. Three varieties of reverb (Room, Hall and Church) give the VR-760’s organ, piano and synthesizer sounds just the right amount of ambience.

Innovative New Controllers

The VR-760’s light-sensing D Beam provides realtime control over parameters like octave, glide or rotary speed. And with Active Expression, you can slowly fade in a synth sound while playing an organ tone— or even intensify the sound’s richness and volume— using an optional EV-7 Expression Pedal. And with new V-LINK technology, you can trigger video clips from the VR-760’s keyboard or Registration buttons*. Features like these can only be found in the VR-760.

*Requires Edirol DV-7PR Digital Video Workstation (sold separately) with software version 1.5 or higher.

■ Master EQ Section

With dedicated knobs for each frequency band (including a sweepable Mid), players can instantly adjust the VR-760’s overall tone without having to dive into Edit menus.

D Beam light has been colored for

illustrative purposes only. Actual infrared light beam is invisible.

Synthesizer sounds include lush pads, strings, brass, bass sounds, electronic sounds and more— complete with two SRX expansion slots.
