Quadra-Fire QFI30-C, QFI35-C Users guide

Download

Models:

QFI30-C QFI35-C

Owner’s Manual

Installation and Operation

NOTICE

DO NOT DISCARD THIS MANUAL

• Important operating and maintenance instructions included.

WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage.

• DO NOT store or use gasoline or other am- mable vapors and liquids in the vicinity of this or any other appliance.

• What to do if you smell gas

- DO NOT try to light any appliance.

- DO NOT touch any electrical switch. DO

NOT use any phone in your building.

- Leave the building immediately.

• Read, understand and follow these instructions for safe installation and operation.

DO NOT

DISCARD

• Leave this manual with party responsible for use and operation.

DANGER

HOT GLASS WILL

CAUSE BURNS.

DO NOT TOUCH GLASS

UNTIL COOLED.

NEVER ALLOW CHILDREN

TO TOUCH GLASS.

A barrier designed to reduce the risk of

burns from the hot viewing glass is provided with this appliance and shall be installed for

the protection of children and other at-risk

individuals.

- Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

- If you cannot reach your gas supplier, call

the re department.

• Installation and service must be performed

by a qualied installer, service agency, or the

gas supplier.

In the Commonwealth of Massachusetts installation must be

performed by a licensed plumber or gas tter.

A CO detector shall be installed in the room where the appliance in installed.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

This appliance may be installed as an OEM installation in manufactured home (USA only) or mobile home and must be installed in accordance with the manufacturer’s instructions and the Manufactured Home

Construction and Safety Standard, Title 24 CFR, Part 3280 in the United States, or the Standard for Installation in Mobile Homes, CAN/CSA Z240 MH Series, in Canada.

This appliance is only for use with the type(s) of gas indicated on the rating plate. This appliance is not convertible for use with other

gases, unless a certied kit is used.

Read this manual before installing or operating this appliance.

Please retain this owner’s manual for future reference.

A. Congratulations

Congratulations on selecting a Quadra-Fire gas replace, an elegant and clean alternative to wood burning replaces.

The Quadra-Fire gas fireplace you have selected is designed to provide the utmost in safety, reliability, and

efciency.

As the owner of a new replace, you’ll want to read and

carefully follow all of the instructions contained in this Owner’s Manual. Pay special attention to all cautions and

This Owner’s Manual should be retained for future

reference. We suggest that you keep it with your other

important documents and product manuals.

Table of Contents

The information contained in this Owner’s Manual, unless noted otherwise, applies to all models and gas control systems.

Your new Quadra-Fire gas replace will give you years of

durable use and trouble-free enjoyment. Welcome to the

Quadra-Fire family of replace products!

warnings.

Homeowner Reference Information

We recommend that you record the following pertinent

information about your replace.

Model Name: ___________________________________________ Date purchased/installed: __________________

Serial Number: __________________________________________ Location on replace: _____________________

Dealership purchased from: _______________________________ Dealer Phone: __________________________

Notes: _______________________________________________________________________________________

_____________________________________________________________________________________________

Listing Label Information/Location

Type of Gas

Gas and Electric Information

Not for use with solid fuel. (Ne doit pas entre utilise avec un combustible solide).

Type of Gas (Sorte De Gaz):

NATURAL GAS

Minimum Permissible Gas Supply for Purposes of Input Adjustment.

Approved Minimum (De Gaz) Acceptable 0.0 in w.c. (Po. Col. d’eau)

Maximum Pressure (Pression) 0.0 in w.c. (Po. Col. d’eau)

Maximum Manifold Pressure (Pression) 0.0 in w. c. (Po. Col. d’eau)

Minimum Manifold Pressure (Pression) 0.0 in w.c. (Po. Col. d’eau)

Total Electrical Requirements: 000Vac, 00Hz., less than 00 Amperes

ALTITUDE: 0-0000 FT. 0000-0000FT. MAX. INPUT BTUH: 00,000 00,000 MIN. INPUT BTUH: 00,000 00,000 ORIFICE SIZE: #XXXXX #XXXXX

The model information regarding your specic replace can be found on the rating plate usually located in the control area of the replace.

Quadra-Fire, a brand of Hearth & Home Technologies 7571 215th Street West, Lakeville, MN 55044

This appliance must be installed in accordance with local codes, if any; if not, follow ANSI Z223.1 in the USA or CAN/CGA B149 installation codes. (Installer l’appareil selon les codes ou reglements

locaux ou, en l’absence de tels reglements, selon les codes d’installation CAN/CGA-B149.)

ANSI Z21XX-XXXX · CSA 2.XX-MXX

Model Number

Serial Number

IN CANADA

Model:

(Modele):

Serial

(Serie):

MADE IN USA

XXXXXXXX

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/182

Safety Alert Key:

• DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury.

• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury.

• CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury.

• NOTICE: Used to address practices not related to personal injury.

A. Congratulations .................................2

B. Limited Lifetime Warranty .......................... 4

1 Listing and Code Approvals

A. Appliance Certication ............................6



B. Glass Specications ..............................6

C. BTU Specications ...............................6



D. High Altitude Installations .......................... 6

E. Non-Combustible Materials Specication. . . . . . . . . . . . . . 6

F. Combustible Materials Specication .................6

G. Electrical Codes ................................. 6

H. California ......................................6



User Guide

2 Operating Instructions

A. Gas Fireplace Safety .............................7



B. Your Fireplace ..................................7

C. Clear Space ....................................8

D. Decorative Fronts, Surrounds ......................8



E. Fixed Glass Assembly ............................ 8

F. Remote Controls, Wall Controls and Wall Switches ......8

G. IPI Battery Tray/Battery Installation ..................8

H. Control Module Operation ......................... 9

I. Before Lighting Fireplace ..........................9

J. Lighting Instructions (IPI) . . . . . . . . . . . . . . . . . . . . . . . . . 10



K. After Appliance is Lit ............................. 11

L. Frequently Asked Questions ......................11

3 Maintenance and Service

A. Maintenance Tasks-Homeowner ................... 12

B. Maintenance Tasks-Service Technician .............. 13

Installer Guide

4 Getting Started

A. Typical Appliance System. . . . . . . . . . . . . . . . . . . . . . . . . 15

B. Design and Installation Considerations .............. 16

C. Tools and Supplies Needed .......................16

D. Inspect Appliance and Components ................. 16

B. Flue Damper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

C. Gas Line ......................................21

D. Fireplace Conversion Notice ...................... 21

E. Electrical Outlet Box .............................21

8 Installing Vent Pipe and Appliance

A. Vent Limits .................................... 22

B. Venting Components ............................ 22

C. Connecting Vent Pipe ............................ 22

D. Placing, Securing and Leveling the Appliance ......... 23

E. Remote Control ................................ 24

F. Installing Adaptor and Termination Cap ..............25



9 Gas Information

A. Fuel Conversion ................................27

B. Gas Pressure ..................................27

C. Gas Connection ................................27

D. High Altitude Installations ......................... 27

10 Electrical Information

A. Wiring Requirements ............................28

B. IntelliFire™ Plus Ignition System Wiring .............28

C. Optional Accessories Requirements ................ 29

D. Fan Wiring with Remote ..........................30

E. Control Module Operation ........................ 30

11 Finishing

A. Mantel and Wall Projections ....................... 31

12 Appliance Setup

A. Remove Glass Assembly ......................... 32

B. Remove the Shipping Materials ....................32

C. Clean the Appliance ............................. 32

D. Accessories ................................... 32

E. Place the Lava Rock ............................32

F. Ember Placement ............................... 32

G. Install the Log Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . 33

H. Fixed Glass Assembly ...........................39



I. Air Shutter Setting .............................. 39

5 Fireplace Size Requirements

A. Minimum Fireplace Opening ......................17

B. Mantel and Wall Projections ....................... 19

6 Termination Locations

A. Vent Termination Minimum Clearances .............. 20



7 Installation Preparation

A. Cleaning ...................................... 21

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

13 Troubleshooting

A. IntelliFire™ Plus Ignition System ...................40

14 Reference Materials

A. Appliance/Decorative Front Dimension Diagrams ......42

B. Vent Kits Components ........................... 45

C. Service Parts ..................................46

D. Contact Information .............................50



 = Contains updated information.

B. Limited Lifetime Warranty

Wood

listed

Igniters, electronic components,

and glass

X X X X X Factory-installed blowers

X Firepots and burnpots

5 years 1 year X X Castings and baffles

Manifold tubes,

HHT chimney and termination

years

Lifetime

beyond warranty period

3 years

Hearth & Home Technologies

LIMITED LIFETIME WARRANTY

Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet, coal and electric hearth appliances that are purchased from an HHT authorized dealer.

WARRANTY COVERAGE:

HHT warrants to the original owner of the HHT appliance at the site of installation, and to any transferee taking ownership

of the appliance at the site of installation within two years following the date of original purchase, that the HHT appliance

will be free from defects in materials and workmanship at the time of manufacture. After installation, if covered components manufactured by HHT are found to be defective in materials or workmanship during the applicable warranty period,

HHT will, at its option, repair or replace the covered components. HHT, at its own discretion, may fully discharge all of its obligations under such warranties by replacing the product itself or refunding the verified purchase price of the product itself. The maximum amount recoverable under this warranty is limited to the purchase price of the product. This warranty is subject to conditions, exclusions and limitations as described below.

WARRANTY PERIOD:

Warranty coverage begins on the date of original purchase. In the case of new home construction, warranty coverage begins on the date of first occupancy of the dwelling or six months after the sale of the product by an independent, authorized HHT dealer/ distributor, whichever occurs earlier. The warranty shall commence no later than 24 months following the date of product shipment from HHT, regardless of the installation or occupancy date. The warranty period for parts and labor for covered components is produced in the following table.

The term “Limited Lifetime” in the table below is defined as: 20 years from the beginning date of warranty coverage for gas appliances, and 10 years from the beginning date of warranty coverage for wood, pellet, and coal appliances. These time periods reflect the minimum expected useful lives of the designated components under normal operating conditions.

Warranty Period HHT Manufactured Appliances and Venting

Parts Labor Gas Wood Pellet

1 Year

XXXXXXX

XXX

EPA

Coal Electric Venting

2 years

X Molded refractory panels

7 years 3 years X X X

Limited

1 year X Burners, logs and refractory

3 years X X X X X Firebox and heat exchanger

Components Covered

All parts and material except as

covered by Conditions,

Exclusions, and Limitations

Ignition Modules

90 Days

4021-645H 10/15 Page 1 of 2

XXXXXXX

See conditions, exclusions, and limitations on next page.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/184

All replacement parts

B. Limited Lifetime Warranty (continued)

WARRANTY CONDITIONS:

• This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites.

• This warranty is only valid while the HHT appliance remains at the site of original installation.

• This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides.

• Contact your installing dealer for warranty service. If the installing dealer is unable to provide necessary parts, contact

the nearest HHT authorized dealer or supplier. Additional service fees may apply if you are seeking warranty service

from a dealer other than the dealer from whom you originally purchased the product.

• Check with your dealer in advance for any costs to you when arranging a warranty call. Travel and shipping charges

for parts are not covered by this warranty.

WARRANTY EXCLUSIONS:

This warranty does not cover the following:

• Changes in surface finishes as a result of normal use. As a heating appliance, some changes in color of interior and exterior surface finishes may occur. This is not a flaw and is not covered under warranty.

• Damage to printed, plated, or enameled surfaces caused by fingerprints, accidents, misuse, scratches, melted items, or other external sources and residues left on the plated surfaces from the use of abrasive cleaners or polishes.

• Repair or replacement of parts that are subject to normal wear and tear during the warranty period. These parts

include: paint, wood, pellet and coal gaskets, firebricks, grates, flame guides, batteries and the discoloration of glass.

• Expansion, contraction, or movement of certain parts causing noise. These conditions are normal and complaints related to this noise are not covered by this warranty.

• Damages resulting from: (1) failure to install, operate, or maintain the appliance in accordance with the installation instructions, operating instructions, and listing agent identification label furnished with the appliance; (2) failure to install the appliance in accordance with local building codes; (3) shipping or improper handling; (4) improper operation, abuse, misuse, continued operation with damaged, corroded or failed components, accident, or improperly/ incorrectly performed repairs; (5) environmental conditions, inadequate ventilation, negative pressure, or drafting

caused by tightly sealed constructions, insufficient make-up air supply, or handling devices such as exhaust fans or

forced air furnaces or other such causes; (6) use of fuels other than those specified in the operating instructions; (7) installation or use of components not supplied with the appliance or any other components not expressly authorized and approved by HHT; (8) modification of the appliance not expressly authorized and approved by HHT in writing; and/or (9) interruptions or fluctuations of electrical power supply to the appliance.

• Non-HHT venting components, hearth components or other accessories used in conjunction with the appliance.

• Any part of a pre-existing fireplace system in which an insert or a decorative gas appliance is installed.

• HHT’s obligation under this warranty does not extend to the appliance’s capability to heat the desired space. Information is provided to assist the consumer and the dealer in selecting the proper appliance for the application. Consideration must be given to appliance location and configuration, environmental conditions, insulation and air tightness of the structure.

This warranty is void if:

• The appliance has been over-fired or operated in atmospheres contaminated by chlorine, fluorine, or other damaging chemicals. Over-firing can be identified by, but not limited to, warped plates or tubes, rust colored cast iron, bubbling,

cracking and discoloration of steel or enamel finishes.

• The appliance is subjected to prolonged periods of dampness or condensation.

• There is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited to, improper chimney or venting installation.

LIMITATIONS OF LIABILITY:

• The owner’s exclusive remedy and HHT’s sole obligation under this warranty, under any other warranty, express or implied, or in contract, tort or otherwise, shall be limited to replacement, repair, or refund, as specified above. In no event will HHT be liable for any incidental or consequential damages caused by defects in the appliance. Some states do not allow exclusions or limitation of incidental or consequential damages, so these limitations may not apply to you. This warranty gives you specific rights; you may also have other rights, which vary from state to state. EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE.

4021-645H 10/15 Page 2 of 2

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Listing and Code Approvals

A. ApplianceCertication

MODELS: QFI30-C, QFI35-C

LABORATORY: Underwriters Laboratories, Inc. (UL)

TYPE: Direct Vent Heater

STANDARD: ANSI Z21.88-2017 CSA 2.33-2017



Vented Gas Fireplace Heaters

This product is listed to ANSI standards for “Vented Gas Fireplace Heaters” and applicable sections of “Gas Burning Heating Appliances for Manufactured Homes and Recreational Vehicles”, and “Gas Fired Appliances for Use at High Altitudes”.

Quadra-Fire gas inserts are designed for installations into

solid fuel masonry or factory built replaces that have been

installed in accordance with the National, Provincial, State and local building codes. Fireplaces are to be constructed of non-combustible materials and, in the absence of local or regional codes, meet criteria of NFPA 211. No additional outside air source is required.

NOTICE: This installation must conform with local codes.

In the absence of local codes you must comply with the

National Fuel Gas Code, ANSI Z223.1-latest edition in the U.S.A. and the CAN/CGA B149 Installation Codes in Canada.

NOT INTENDED FOR USE AS A PRIMARY HEAT SOURCE.

This appliance is tested and approved as either supplemental room heat or as a decorative appliance. It should not be factored as primary heat in residential heating calculations.

B. GlassSpecications

This appliance is equipped with 5 mm ceramic glass. Replace glass only with 5 mm ceramic glass. Please contact your dealer for replacement glass.

C. BTUSpecications



Models

(U.S. or Canada)

QFI30-C (NG)

QFI35-C (NG)

QFI30-C (Propane)

QFI35-C (Propane)

(0-2000 FT)

CANADA

(2000-4500 FT)

(0-2000 FT)

CANADA

(2000-4500 FT)

(0-2000 FT)

CANADA

(2000-4500 FT)

(0-2000 FT)

CANADA

(2000-4500 FT)

Maximum

Input

BTU/h

32,000 18,000 #35

28,800 16,200 #36

35,000 18,500 #33

33,250 18,250 #34

31,000 15,500 #51

27,500 14,500 #52

35,000 17,000 #50

31,000 15,500 #51

Minimum

Input

BTU/h

Orice

Size

(DMS)

D. High Altitude Installations

NOTICE: If the heating value of the gas has been reduced,

these rules do not apply. Check with your local gas utility or authorities having jurisdiction.

When installing above 2000 feet elevation:

• In the USA: Reduce input rate 4% for each 1000 feet above 2000 feet.

• In CANADA: Reduce input rate 10% for elevations between 2000 feet and 4500 feet. Above 4500 feet, consult local gas utility.

Check with your local gas utility to determine proper orice size.

E. Non-CombustibleMaterialsSpecication

Material which will not ignite and burn. Such materials are

those consisting entirely of steel, iron, brick, tile, concrete,

slate, glass or plasters, or any combination thereof.

Materials that are reported as passing ASTM E 136,

Standard Test Method for Behavior of Materials in a Vertical Tube Furnace at 750 ºC shall be considered

non-combustible materials.

F. CombustibleMaterialsSpecication

Materials made of or surfaced with wood, compressed pa-

per, plant bers, plastics, or other material that can ignite and burn, whether ame proofed or not, or plastered or

unplastered shall be considered combustible materials.

G. Electrical Codes

NOTICE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code ANSI/NFPA

70-latest edition or the Canadian Electric Code CSA C22.1.

• A 120 VAC circuit for this product must be protected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in

locations such as in bathrooms or near sinks.

H. California

WARNING: This product and the fuels used to

operate this product (liquid propane or natural

gas), and the products of combustion of such fuels, can expose you to chemicals including benzene, which is

known to the State of California to cause cancer and

reproductive harm. For more information go to: www. P65Warnings.ca.gov.



Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/186

User Guide

Operating Instructions

A. Gas Fireplace Safety

WARNING! DO NOT operate replace before reading and understanding operating instructions. Failure

to operate replace according to operating instructions could cause re or injury.

DANGER

HOT GLASS WILL

CAUSE BURNS.

DO NOT TOUCH GLASS

UNTIL COOLED.

NEVER ALLOW CHILDREN

TO TOUCH GLASS.

• Keep children away.

• CAREFULLY SUPERVISE children in same room

as replace.

• Alert children and adults to hazards of high temperatures.

High temperatures could ignite clothing or other

ammablematerials.

• Clothing, furniture, draperies, and other ammable

materials must not be placed on or near the appliance.

A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance and shall be installed for the protection of children and other at-risk individuals. DO NOT operate the appliance with the barrier removed. If the barrier becomes damaged, the barrier shall be replaced with the manufacturer’s barrier for this appliance.

Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one.

• Teach children to NEVER touch the replace.

• Consider not using the replace when children will be

present.

Contact your dealer for more information, or visit: www. hpba.org/Product-Info/Fireplace-Stove-Heater/GlassFronts-Safety.

To prevent unintended operation when not using your replace for an extended period of time (summer months, vacation/trips, etc):

• Remove batteries from remote controls.

• Turn off wall controls.

WARNING: This product and the fuels used to operate this product (liquid propane or natural

gas), and the products of combustion of such fuels, can expose you to chemicals including benzene, which is

known to the State of California to cause cancer and

reproductive harm. For more information go to: www. P65Warnings.ca.gov.

B. Your Fireplace

WARNING! DO NOT operate replace before reading and understanding operating instructions. Failure

to operate replace according to operating instructions could cause re or injury.

APPLIANCE INSTALLED IN EXISTING

SOLID FUEL FIREPLACE

DECORATIVE DOORS

(NOT SHOWN)

SECTION 2.D.



Young children should be carefully supervised when they are in the same room as the appliance. Toddlers, young children and others could be susceptible to accidental contact burns.

• A physical barrier is recommended if there are at risk

individuals in the house.

• To restrict access to a replace or stove, install an

adjustable safety gate to keep toddlers, young children and other at risk individuals out of the room and away

from hot surfaces.

• Install a switch lock or a wall/remote control with child

protection lockout feature.

• Keep remote controls out of reach of children.

• Never leave children alone near a hot replace, whether

operating or cooling down.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

FIXED GLASS ASSEMBLY

(NOT SHOWN) SECTION 12.H.

HEARTH

Figure 2.1 General Operating Parts

CLEAR SPACE

SECTION 2.C.

MANTEL

SECTION

5.B AND

11.A

C. Clear Space

WARNING! DO NOT place combustible objects in front

of the replace or block louvers. High temperatures could start a re. See Figure 2.2.

Avoid placing candles and other heat-sensitive objects on mantel or hearth. Heat could damage these objects.

APPLIANCE INSTALLED IN EXISTING

SOLID FUEL FIREPLACE

3 FT. IN FRONT OF FIREPLACE

CLEAR SPACE

E. Fixed Glass Assembly

See Section 12.H.

F. Remote Controls, Wall Controls and Wall

Switches

Follow the instructions supplied with the control installed

to operate your replace:

For safety:

• Install a switch lock or a wall/remote control with child protection lockout feature.

• Keep remote controls out of reach of children.

See your dealer if you have questions.

G. IPI Battery Tray/Battery Installation

The IntelliFireTM Plus system has a battery backup option. Battery longevity and performance will be affected by the service temperatures of this appliance. Batteries should only be used as a power source in the event of an emergency such as an outage.

NOTICE: Batteries should only be used as a power source in the event of an emergency such as an outage.

Figure 2.2 Clear Space

D. Decorative Fronts, Surrounds

WARNING! Risk of Fire! Install ONLY decorative fronts

or surrounds approved by Hearth & Home Technologies.

Unapproved decorative fronts could cause appliance to

overheat.

This appliance has been supplied with an integral barrier to prevent direct contact with the xed glass panel. DO NOT operate the appliance with the barrier removed.

Contact your dealer or Hearth & Home Technologies if the barrier is not present or help is needed to properly install one.

For more information refer to the instructions supplied with your decorative front.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/188

H. Control Module Operation

NG/LP GAS-TYPE SELECTOR SWITCH

SELECTOR

SWITCH

FLAME HI/LOW

SWITCH

STATUS

INDICATOR LED

MODULE

1. The control module has an ON/OFF/REMOTE selector switch that must be set. See Figure 2.3.

OFF Position: Appliance will ignore all power inputs and

will not respond to any commands from a wall switch or remote. The unit should be in the OFF position during installation, service, battery installation, fuel conversion, and in the event that the control goes into LOCK-OUT mode as a result of an error code.

ON Position: Appliance will ignite and run continuously

in the HI ame setting, with no adjustment in ame

output. This mode of operation is primarily used for initial installation or power outage operation with battery

backup.

REMOTE Position: Appliance will initiate commands

from an optional wired wall switch and/or the wireless remote (RC300).

2. If using a wired wall switch with the module in REMOTE

mode, the ame output can be adjusted with the HI/LO

selector switch on the module. See Figure 2.3. Note

that the ame HI/LO selector switch will become inactive

once an optional remote control (RC200/RC300) is programmed to the control module. Note that the control

module will always ignite the replace on HI and remain

so for the initial 10 seconds of operation. If the HI/LO

is switched to the LO position, the ame output will automatically drop to the lowest setting after the ame

has been established for 10 sec. After this 10 second

period, the ame can be adjusted from HI to LO with

the switch.

3. The control module has safety feature that automatically

shuts down the replace after 9 hours of continuous

operation without receiving a command from the RC300 remote.

4. If you intend to use both an optional wired wall switch

and the RC300 remote control to operate your replace,

the wall switch will override any commands given by the remote.

5. Module Reset

This module may lock-out under certain conditions.

When this occurs, the appliance will not ignite or

respond to commands. The module will go into lock-out

mode by emitting three audible beeps, then continuously displaying a RED/GREEN error code at its status indicator LED.

• Check battery tray. Remove batteries if installed.

Batteries should only be installed for use during power outages. See Section G.

• Locate the module selector switch. (See Figure 2.3).

• Set the module selector switch to the OFF position.

• Wait ve (5) minutes to allow possible accumulated gas

to clear.

• Set the module selector switch to ON or REMOTE position.

• Start the appliance.

WARNING! Risk of Explosion! DO NOT reset the mod-

ule more than one time within a ve minute time period. Gas could accumulate in rebox. Call a qualied service technician.

Nine Hour Safety Shutdown Feature

The appliance has a safety feature that automatically

shuts down the replace after nine hours of continuous

operation without receiving a command from the wall switch or optional remote.

I. Before Lighting Fireplace

Before operating this replace for the rst time, have a

qualiedtechnician:

• Verify all shipping materials have been removed from

inside and/or underneath the rebox.

• Review proper placement of logs, ember material and/

or other decorative materials.

• Check the wiring.

• Check the air shutter adjustment.

• Ensure that there are no gas leaks.

• Ensure that the glass is sealed and in the proper position

and that the integral barrier is in place.

WARNING! Risk of Fire/Asphyxiation! DO NOT oper-

ate replace with xed glass assembly removed.

Figure 2.3 Control Module

• An Intellire™ Plus ignition system is standard with this

appliance.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

J. Lighting Instructions (IPI)



WARNING

A. This appliance is equipped with an intermittent pilot ignition (IPI) device which

automatically lights the burner. DO NOT try to light the burner by hand.

B. BEFORE LIGHTING, smell all around the appliance area for gas. Be sure to smell

WHAT TO DO IF YOU SMELL GAS

• DO NOT try to light any appliance.

• DO NOT touch any electric switch; do not use any phone in your building.

1. This appliance is equipped with an ignition device which automatically lights the burner. DO NOT try to light the burner by hand.

GAS

VALVE

1. Equipped with wall switch: Turn ON/OFF switch to OFF. Equipped with remote or wall control: Press OFF button. Equipped with thermostat: Set temperature to lowest setting.

FOR YOUR SAFETY READ BEFORE LIGHTING

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.

•

C. Use only your hand to push in or turn the gas control knob. Never use tools. If

the knob will not push in or turn by hand, DO NOT

D. DO NOT use this appliance if any part has been under water. Immediately call

the control system and any gas control which has been under water.

LIGHTING INSTRUCTIONS (IPI)

top of this label. If you do not smell gas, go to next step.

3. To light the burner:

Equipped with wall switch: Turn ON/OFF switch to ON. Equipped with remote or wall control: Press ON or FLAME button.

Equipped with thermostat: Set temperature to desired setting.

4. If the appliance does not light after three tries, call your service technician or gas

supplier.

TO TURN OFF GAS TO APPLIANCE

2. Service technician should turn off electric power to the control when performing

service.

DANGER

HOT GLASS WILL CAUSE BURNS.

DO NOT TOUCH GLASS UNTIL COOLED.

NEVER ALLOW CHILDREN TO TOUCH GLASS.

A barrier designed to reduce the risk of burns from the hot viewing glass is provided with this appliance and shall be installed for the protection of children and other at-risk individuals.

WARNING:

DO NOT CONNECT LINE VOLTAGE (110/120 VAC OR 220/240 VAC) TO THE CONTROL VALVE.

Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to the owner’s information manual provided with this ap-

agency or the gas supplier.

This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate combustion and ventilation air.

WARNING: This product and the fuels used to operate this product (liquid propane or natural gas), and the products of combustion of such fuels, can expose you to chemicals

including benzene, which is known to the State of California to cause

cancer and reproductive harm. For more information go to: www. P65Warnings.ca.gov.

Keep burner and control compartment clean. See installation and operating instructions accompanying appliance.

CAUTION:

Hot while in operation. DO NOT touch. Keep children, clothing, furniture, gasoline

DO NOT operate the appliance with removed, cracked or broken. Replacement of the

NOT FOR USE WITH SOLID FUEL

For use with natural gas and propane. A conversion kit, as supplied by the manufacturer, shall be used to convert this appliance to the alternate fuel.

This appliance must be installed in accordance with local codes, if any; if none, follow the National Fuel Gas Code, ANSIZ223.1/ NFPA 54, or the National Gas and

Propane Installation code, CSA B149.1.

For additional information on operating your

refer to www.hearthnhome.com.

should be done by a licensed or

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1810

K. After Appliance is Lit

Initial Break-in Procedure

• The appliance should be run three to four hours continuously on high.

• Turn the appliance off and allow it to completely cool.

• Remove xed glass assembly. See Section 12.H.

• Clean xed glass assembly. See Section 3.

• Replace the xed glass assembly and run continuously

on high an additional 9 hours.

This cures the materials used to manufacture the replace.

NOTICE! Open windows for air circulation during appliance break-in.

• Some people could be sensitive to smoke and odors.

• Smoke detectors could activate.

L. Frequently Asked Questions

ISSUE SOLUTIONS

Condensation on the glass

Blue ames

Odor from appliance

Film on the glass

Metallic noise

Is it normal to see the pilot ame burn

continually?

This is a result of gas combustion and temperature variations. As the appliance warms, this condensation will disappear.

This is a result of normal operation and the ames will begin to yellow as the appliance is allowed to burn for 20 to 40 minutes.

When rst operated, this appliance may release an odor for the rst several hours. This is caused

by the curing of the paint and the burning off of any oils remaining from manufacturing. Odor may

also be released from nishing materials and adhesives used around the appliance.

This is a normal result of the curing process of the paint and logs. Glass should be cleaned within 3 to 4 hours of initial burning to remove deposits left by oils from the manufacturing

process. A non-abrasive cleaner such as gas replace glass cleaner may be necessary. See

your dealer.

Noise is caused by metal expanding and contracting as it heats up and cools down, similar to the sound produced by a furnace or heating duct. This noise does not affect the operation or longevity of the appliance.

In an intermittent pilot ignition system (IPI), the pilot ame should turn off when appliance is turned off. Some optional control systems available with IPI models may allow pilot ame to

remain lit.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Maintenance and Service

Any safety screen or guard removed for servicing must be replaced prior to operating the appliance.

When properly maintained, your appliance will give you many years of trouble-free service. We recommend an-

nual service by a qualied technician.

A. Maintenance Tasks-Homeowner

Installation and repair should be done by a qualied technician only. The appliance should be inspected before use and at least annually by a professional service person.

The following tasks may be performed annually by the

homeowner. If you are uncomfortable performing any of the listed tasks, please call your dealer for a service appointment.

More frequent cleaning may be required due to lint from carpeting or other factors. Control compartment, burner and circulating air passageway of the appliance must be

kept clean.

CAUTION! Risk of Burns! The appliance should be

turned off and cooled before servicing.

Glass Cleaning

Frequency: Seasonally

By: Homeowner

Tools Needed: Protective gloves, glass cleaner, drop

cloth and a stable work surface.

CAUTION! Handle xed glass assembly with care.

Glass is breakable.

• Avoid striking, scratching or slamming glass

• Avoid abrasive cleaners

• DO NOT clean glass while it is hot

• Prepare a work area large enough to accommodate xed glass assembly and door frame by placing a drop cloth

on a at, stable surface.

Note: Fixed glass assembly and gasketing may have residue that can stain carpeting or oor surfaces.

• Remove decorative front from appliance and set aside

on work surface.

• See Section 12.H for instructions to remove xed glass

assembly.

• Clean glass with a non-abrasive commercially available cleaner.

- Light deposits: Use a soft cloth with soap and water

- Heavy deposits: Use commercial fireplace glass

cleaner (consult with your dealer)

• Carefully set xed glass assembly in place on appliance.

Hold glass in place with one hand and secure glass latches with the other hand.

• Reinstall decorative front.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1812

Surrounds, Decorative Fronts

Frequency: Annually

By: Homeowner

Tools needed: Protective gloves, stable work surface

• Assess condition of screen and replace as necessary.

• Inspect for scratches, dents or other damage and repair as necessary.

• Check that louvers are not blocked.

• Vacuum or dust surfaces.

Remote Control

Frequency: Seasonally

By: Homeowner

Tools needed: Replacement batteries and remote con-

trol instructions.

• Locate remote control transmitter and receiver.

• Verify operation of remote. Refer to remote control operation instructions for proper calibration and setup procedure.

• Place batteries as needed in remote transmitters and battery-powered receivers.

• Place remote control out of reach of children.

If not using your replace for an extended period of time

(summer months, vacations/trips, etc), to prevent unintended operation:

• Remove batteries from remote controls.

Venting

Frequency: Seasonally

By: Homeowner

Tools needed: Protective gloves and safety glasses.

• Inspect venting and termination cap for blockage or

obstruction such plants, bird nests, leaves, snow, debris, etc.

• Verify termination cap clearance to subsequent construc-

tion (building additions, decks, fences, or sheds). See

Section 6.

• Inspect for corrosion or separation.

• Verify weather stripping, sealing and ashing remains

intact.

• Inspect draft shield to verify it is not damaged or missing.

B. Maintenance Tasks-Service Technician

The following tasks must be performed by a qualied technician.

Gasket Seal and Glass Assembly Inspection

Frequency: Annually

By: Service Technician

Tools needed: Protective gloves, drop cloth and a stable

work surface.

• Inspect gasket seal and its condition.

• Inspect xed glass assembly for scratches and nicks that can lead to breakage when exposed to heat.

• Conrm there is no damage to glass or glass frame.

Replace as necessary.

• Verify that xed glass assembly is properly retained and

attachment components are intact and not damaged. Replace as necessary.

Control Compartment and Firebox Top

Frequency: Annually

By: Service Technician

Tools needed: Protective gloves, vacuum cleaner, dust

cloths

• Vacuum and wipe out dust, cobwebs, debris or pet hair. Use caution when cleaning these areas. Screw tips that have penetrated the sheet metal are sharp and should be avoided.

• Remove all foreign objects.

• Verify unobstructed air circulation.

Logs

Frequency: Annually

By: Service Technician

Tools needed: Protective gloves.

• Inspect for damaged or missing logs. Replace as necessary. Refer to Section 12 for log placement instructions.

• Verify correct log placement and no ame impingement

causing sooting. Correct as necessary.

Firebox

Frequency: Annually

By: Service Technician

Tools needed: Protective gloves, sandpaper, steel wool,

cloths, mineral spirits, primer and touch-up paint.

• Inspect for paint condition, warped surfaces, corrosion or perforation. Sand and repaint as necessary.

• Replace appliance if rebox has been perforated.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Burner Ignition and Operation

Frequency: Annually

By: Service Technician

Tools needed: Protective gloves, vacuum cleaner, whisk

broom, ashlight, voltmeter, indexed drill bit set, and a

manometer.

• Verify burner is properly secured and aligned with pilot or igniter.

• Clean off burner top, inspect for plugged ports, corrosion or deterioration. Replace burner if necessary.

• Replace Glowing embers with new dime-size pieces.

DO NOT block ports or obstruct lighting paths. Refer to

Section 12 for proper ember placement.

• Verify batteries have been removed from battery back-up IPI systems to prevent premature battery failure or

leaking. For optimal battery life, locate the battery pack outside of the control cavity on the hearth. This

placement will reduce the chances of overheating the batteries during extended burns which could result in reduced battery life or degradation.

• Check for smooth lighting and ignition carryover to all



ports. Verify that there is no ignition delay. Inspect and ensure the lighting of the main burner occurs within four seconds of the main gas valve opening.

• Inspect for lifting or other ame problems.

• Verify air shutter setting is correct. See Section 12 for required air shutter setting. Verify air shutter is clear of dust and debris.

• Inspect orice for soot, dirt and corrosion. Verify orice size is correct. See Service Parts List for proper orice

sizing.

• Verify manifold and inlet pressures. Adjust regulator as required.

• Check all accessible gas-carrying tubes, connections,



pipes and other components for leaks.

• Inspect pilot ame pattern and strength. See Figure 3.1 for proper pilot ame pattern. Clean or replace orice

spud as necessary.

• Inspect thermocouple/thermopile or IPI ame sensing rod for soot, corrosion and deterioration. Polish with ne

steel wool or replace as required.

• Verify that there is not a short in ame sense circuit by checking continuity between pilot hood and ame sense

rod. Replace pilot as necessary. (IPI only)

Figure 3.1 IPI Pilot Flame Patterns

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1814

Installer Guide

A. Typical Appliance System

NOTICE: Illustrations and photos reect typical installations and are for design purposes only. Illustrations/diagrams are not drawn to scale. Actual product may vary from pictures in manual

Getting Started

VERTICAL TERMINATION CAP (SECTION 8.F)

VENT PIPE (SECTION 8)

3 INCH FLEX LINERS (SECTION 8)

MANTEL AND MANTEL LEG SECTION 5.B AND 11.A

SURROUND OR FRONT

NOT SHOWN

SECTION 2.D AND 8.D.

HEARTH EXTENSION

GAS LINE (SECTION 9) ACCESS THROUGH EXISTING MASONRY OR WOODBURNING FIREPLACE

Figure 4.1 Typical System

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

B. Design and Installation Considerations

Heat & Glo gas inserts are designed for installations into

solid fuel masonry or UL127 listed factory built replaces.

No additional outside air source is required.

Installation MUST comply with local, regional, state and national codes and regulations. Consult insurance carrier, local building inspector, re ofcials or authorities having jurisdiction over restrictions, installation inspection and permits.

Prior to installing the gas insert:

• Ensure chimney is constructed of non-combustible materials.

• Ensure chimney is clean and in good working order.

• Ensure that all chimney cleanouts t properly to prevent air leakage into chimney.

• Ensure combustible mantel and surround clearances comply with insert requirements.

• Ensure all joints are properly engaged and the chimney is properly secured.

• Determine minimum replace size. See Section 5.A.

• Determine gas supply piping requirements.

• Determine electrical wiring requirements.

• Determine nishing details.

• Determine whether optional accessories—devices such as a wall switch or remote control—are desired.

Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. For

assistance or additional information, consult a qualied

technician, service agency or your dealer.

Installation and service of this appliance should be performed by

qualied personnel. Hearth & Home Technologies recommends HHT Factory Trained or NFI certied professionals.

C. Tools and Supplies Needed

Before beginning the installation be sure that the following tools and building supplies are available.

Tape measure Framing material Pliers Flat blade screwdriver Hammer Phillips screwdriver Gloves Framing square Voltmeter Electric drill and bits (1/4 in.) Plumb line Safety glasses Level Reciprocating saw

Manometer Noncorrosive leak check solution

1/2 - 3/4 inch length, #6 or #8 Self-drilling screws

Caulking material (300 ºF minimum continuous exposure

rating)

D. Inspect Appliance and Components

• Carefully remove the appliance and components from

the packaging.

• The vent system components and decorative fronts may

be shipped in separate packages.

• If packaged separately, the log set and appliance grate

must be installed.

• Report to your dealer any parts damaged in shipment, particularly the condition of the glass.

• Read all of the instructions before starting the instal-

lation. Follow these instructions carefully during the

installationtoensuremaximumsafetyandbenet.

WARNING! Risk of Fire or Explosion! Damaged parts

could impair safe operation. DO NOT install damaged, in- complete or substitute components. Keep appliance dry.

Hearth & Home Technologies disclaims any responsibility for, and the warranty will be voided by, the following actions:

• Installation and use of any damaged appliance or vent

system component.

• Modication of the appliance or vent system.

• Installation other than as instructed by Hearth & Home

Technologies.

• Improper positioning of the gas logs or the glass door.

• Installation and/or use of any component part not approved

by Hearth & Home Technologies.

Anysuchactioncouldcausearehazard.

WARNING! Risk of Fire,/Explosion/Electric Shock! DO NOT use this appliance if any part has been under

water. Call a qualied technician to inspect the appliance

and to replace any part of the control system and/or gas

control which has been under water.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1816

Fireplace Size Requirements

A. Minimum Fireplace Opening

Minimum replace opening requirements for a standard 3/4

inch deep surround are shown in Figure 5.2. For smaller openings, an optional 1-1/2 inch deep surround is available and dimensions are shown in Figure 5.3.

WARNING! Risk of Fire or Burns! Provide adequate clearance around air openings and for service access.

Due to high temperatures, the appliance should be located out of trafc and away from furniture and draperies.

• The rebrick (refractory), glass doors, screen rails, screen

mesh and log grates can be removed from a factory

built rebox in order to gain minimum gas insert opening

requirements.

• Any smoke shelves, shields and bafes may be removed from the factory built rebox if attached with mechanical

fasteners.

SIDE VIEW

9 IN.

• The metal oor of the solid fuel rebox may be removed

to facilitate the installation of the insert.

• Cutting of any sheet metal parts of the replace in which the gas replace insert is to be installed is prohibited, except the oor as tested for and as noted above and in

Figure 5.1.

• A minimum 1/2 inch gap from the bottom of the

appliance to the metal oor of the solid fuel rebox is

RECOMMENDED for optimal fan performance. See side view in Figure 5.1

TOP VIEW

METAL FLOOR OF EXISTING

SOLID FUEL FIREBOX

1/2 IN. MINIMUM LEVELING HEIGHT

(RECOMMENDED) 1/4 IN. REQUIRED

METAL FLOOR OF EXISTING SOLID FUEL FIREBOX

9 IN.

Figure 5.1-A

Figure 5.1-B

• The appliance may not be placed directly on the base of the outer wrap, a 1/4 inch airspace MUST be provided

between the insert and the oor of the outer wrap. Use

the leveling legs to raise the insert a minimum of 1/4 inch.

The original replace may never be returned to solid

fuel in this condition. The sidewalls and top structure

of the rebox may not be altered with the exception of removable bafes and dampers.

5 IN.

3 IN.

6 IN.

REMOVE THIS SECTION OF METAL FLOOR

FACTORY BUILT FIREBOX

METAL INSERT

5 IN.

3 IN.

REMOVE THIS SECTION OF METAL FLOOR

6 IN.

• If a minimum 1/2 inch gap can not be achieved, a section

of the factory-built metal oor can be removed. See

Figure 5.1-B.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

TOP VIEW

FRONT VIEW SIDE VIEW

MINIMUM FIREBOX OPENING

QFI35-C QFI30-C

Location

Inches Millimeters Inches Millimeters

A Rear Width 24 610 20-3/4 527

B Front Width 35-1/8 892 31-1/8 791

C Height-Front 24-3/8 619 20-3/4 527

D Height-Rear 21-1/8 537 17-5/8 448

E** Unit Depth 16 406 14-7/8 378

F Venting Depth 10-5/8 270 9-1/2 241

Note: Dimensions assume 1/4 inch clearance on all sides.

Note: If exhaust collar on insert and replace damper do not line up, add 4 inches (102 mm) to minimum

replace height for bends in vent pipe.

**Unit depth is measured to the back of the surround to give the depth needed for installation.

In addition to these dimensions, also reference Clearances and Mantel Projections (Section 5.B).

Figure 5.2 Firebox Opening - Standard Surround

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1818

SIDE VIEW

TOP VIEW

1-1/2 IN.

SURROUND

APPLIANCE

APPLIANCESURROUND

MINIMUM FIREBOX OPENING

QFI35-C QFI30-C

Location

Inches Millimeters Inches Millimeters

Alternate Unit Width 33-1/2 851 29-1/2 749

Alternate Unit Depth 15-1/8 384 14 356

Alternate Unit Height 23 584 19-3/8 492

Note: Dimensions assume 1/4 inch clearance on all sides.

Note: If exhaust collar on insert and replace damper do not line up, add 4 inches (102 mm) to minimum

replace height for bends in vent pipe.

Figure 5.3 Firebox Opening - Deep Surround

B. Mantel and Wall Projections

WARNING! Risk of Fire! Comply with all minimum clear-

ances to combustibles as specied. Framing or nishing

material closer than the minimums listed must be construct-

ed entirely of noncombustible materials (i.e., steel studs, concrete board, etc).

Clearance to combustible material under the insert is 1/4 inch (6 mm). Clearance from top of replace opening for combustibles extending 12 inches max. is 12 inches.

• Use leveling legs to raise insert minimum 1/4 inch (6 mm)

above combustible material or outer wrap of factory built

rebox.

Combustible facings must not extend behind the insert surround. For non-combustible material specications refer to section 1.E.

EXISTING NON-COMBUSTIBLE FACING

12 IN. MAX.

2 IN. MAX.

10 IN. MIN.

12 IN. MIN.

Figure 5.4 Mantel Clearances

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Termination Locations

A. Vent Termination Minimum Clearances

WARNING

Fire Risk.

Maintain vent clearance to combustibles as

specied.

• DO NOT pack air space with insulation or other materials.

Failure to keep insulation or other materials away from vent pipe could cause re.

HORIZONTAL

OVERHANG

2 FT. MIN.

GAS DIRECT VENT TERMINATION CAP

Roof Pitch H (Min.) Ft.

Flat to 6/12...........................................................1.0*

Over 6/12 to 7/12 .................................................1.25*

Over 7/12 to 8/12 .................................................1.5*

Over 8/12 to 9/12 .................................................2.0*

Over 9/12 to 10/12 ...............................................2.5*

Over 10/12 to 11/12 .............................................3.25

Over 11/12 to 12/12 .............................................4.0

Over 12/12 to 14/12 .............................................5.0

Over 14/12 to 16/12 .............................................6.0

Over 16/12 to 18/12 .............................................7.0

Over 18/12 to 20/12 .............................................7.5

Over 20/12 to 21/12 .............................................8.0

20 INCHES MIN.

LOWEST

DISCHARGE

OPENING

ROOF PITCH

IS X/ 12

H (MIN.) - MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING

VERTICAL

WALL

* H minimum may vary depending on regional snowfall.

Refer to local codes.

Figure 6.1 Minimum Height From Roof To Lowest Discharge



Opening

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1820

Installation Preparation

Prepare the existing solid fuel masonry or factory built

non-combustible rebox for installation.

A. Cleaning

Prior to installing the gas insert:

• Ensure that the woodburning replace cavity is clean

and free of ash, soot, and other debris.

B. Flue Damper

Fully lock the solid fuel replace’s ue damper in the open

position, OR completely remove it.

C. Gas Line

Note: If the factory built replace has no gas access hole

provided, an access hole of 1 inch (25 mm) diameter or less may be drilled through the lower sides or bottom of the rebox in a proper workmanship - like manner. This access hole must be plugged with non-combustible insulation after the gas supply line has been installed.

• Install gas line into rebox cavity.

• Check local codes and gas line sizing requirements

following NFPA51. See Section 9.

• It is recommended that extra length of gas line be installed within the existing wood burner or masonry

replace to allow removal of the insert for future servicing

needs.

D. Fireplace Conversion Notice

Permanently attach the label with the following warning to

the inside lower back of the replace rebox into which the

insert is being installed. Silicone or mechanical fasteners may be required to properly secure the label.

WARNING! Risk of Fire! This replace has been con- verted for use with a gas replace insert only and cannot

be used for burning wood or solid fuels unless all original

parts have been replaced, and the replace re-approved by the authority having jurisdiction.

E. Electrical Outlet Box

An outlet box may be installed in a bottom back corner of

the existing solid fuel masonry or factory built replace to power the appliance. Each unit ships standard with a cord assembly to permit blowers or other optional accessories to be used. The accessories plug into the new outlet box or may be routed out onto the hearth to a nearby outlet.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Installing Vent Pipe and Appliance

A. Vent Limits

The abbreviations listed in this vent table key are used in

the vent diagrams.

Description

Minimum Vertical Run Length 10 ft.

Maximum Vertical Run Length 50 ft.

Horizontal venting is NOT allowed.

Vertical terminations are measured to top of chimney.

This appliance is listed for use with LINK-DV systems and components only. It is permissible to extend venting above existing chimney (within specied maximum vertical limits) using SLP series or Dura Vent GS series 4 in. x 6-5/8 in. gas direct-vent pipe. Connection is made using DV-46DVA-GK.

WARNING! Risk of Fire/Explosion/Asphyxiation! Do

NOT connect this gas appliance to a chimney ue serving a separate solid fuel or gas burning appliance.

• Could impair safe operation of this appliance or other

appliances connected to the ue.

• Vent this appliance directly outside.

• Use separate vent system for this appliance.

CAUTION! ALL vent specications MUST be followed.

This product is tested and listed to these specications. Appliance performance will suffer if specications are not followed.

B. Venting Components

CAUTION! Risk of Cuts/Abrasions/Flying Debris.

Wear protective gloves and safety glasses during instal-

lation. Sheet metal edges are sharp.

The vertical vent termination system installed on this model includes:

• Flexible vent pipe for exhaust air (included with vent kit).

• One length of 3-inch exible vent pipe for combustion air (included with vent kit).

• One pipe-to-cap adaptor (included with vent kit).

• One vertical termination cap (included with vent kit).

C. Connecting Vent Pipe

Reference instructions in the termination kit.

• Install the 3-inch exible vent pipe(s) down through the

chimney.

• Secure the exhaust exible vent pipe to the exhaust

starting collar on top of the appliance with three screws. See Figure 8.1.

• Use 3 screws to attach the section of inlet air vent to the inlet collar on the collar slide plate. See Figure 8.1. NOTE: The collar slide plate may be removed from appliance to aid installation.

Figure 8.1

HANDLE

ADAPTER

V = 10 FT. MINIMUM 50 FT. MAXIMUM

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1822

TERMINATION

CAP

INLET

COLLAR

EXHAUST

COLLAR

EXHAUST

AIR

VENT PIPE

INLET AIR VENT PIPE

INLET AIR STARTING COLLAR

STARTING COLLAR BRACKET

EXHAUST STARTING COLLAR

INLET AIR STARTING COLLAR

LOCKING TAB

STARTING COLLAR BRACKET

EXHAUST STARTING COLLAR

NOTE: TO ACHIEVE OPTIMUM PERFORMANCE OF INSERT, MINIMIZE OR AVOID BENDS IN EXHAUST VENT PIPE.

CUT AND BEND

FLASHING AS NEEDED

TO FIT CHIMNEY

• Attach surround. Follow instructions for surround installation included with the front.

• Push insert into the opening so that it tightly overlaps the

replace opening.

SEALANT

ADHESIVE

Figure 8.2

• Trim chimney top plate to minimize excess overhang or

bend over ue tile (see Figure 8.2).

• Place 3/8 inch bead of 300ºF silicone on ue tile top.

D. Placing, Securing and Leveling the

Appliance

WARNING! Risk of Explosion/Combustion Fumes!

Connect vent sections per installation instructions.

• Connect exhaust vent pipe ONLY to exhaust starting collar and termination cap center collar.

• Connect inlet air vent ONLY to inlet air collar on appliance

and the termination cap inlet air collar.

• DO NOT allow vent to sag below connection point to

appliance.

• Remove rear leveling legs from shipping position and relocate to one of the positions shown in Figure 8.3. Remove both screws that secure the leveling leg to the side of the appliance. Turn the leveling leg around so that the foot is facing out and downward. Line up the two holes on the leg with the holes on the appliance and secure with screws. See Figure 8.3.

• Install insert (without surround attached) into existing

replace while pulling collar slide plate forward.

• Install gas line into hole provided on side.

• If applicable install remote control wires into insert side See Section 8.E.

• Secure collar slide plate to appliance by placing locking handle into position with locking tabs (see Figure 8.1)

and secure with #8 screw.

• Level the appliance from side to side and front to back.

Adjust leveling bolts to desired vertical position so appliance is level. Use the leveling bolts included with the manual bag.

• A minimum 1/2 inch gap from the bottom of the appliance to a metal surface is RECOMMENDED for optimal fan performance. See Figure 5.1.

• Position any excess exible vent pipe back up into

chimney without sagging. Twist and push flex vent together to shorten.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

WARNING! Risk of Fire! Only an approved Hearth & Home Technologies surround may be used to cover inte-

gral grills on solid fuel burning replaces. No other components such as shrouds, sheetmetal plates, etc., may be used to seal off vents.

WARNING! Risk of Explosion! Failure to position the parts in accordance with these diagrams or failure to use

only parts specically approved with this appliance may result in property damage or personal injury.

REAR LEVELING LEGS SHIPPED IN THIS POSITION

REAR LEVELING LEGS MAY BE RELOCATED TO LOCATION A OR LOCATION B

LOCATION A

LOCATION B

Figure 8.3

E. Remote Control

IPI Models:

If a remote control kit is used to control blower function,

the Auxiliary 300 module can only be placed in the control cavity to the right of the control panel. See Figure 8.4.

AUXILIARY 300 MODULE

Figure 8.4 Location of AUX300 for Remote Control Blower Function - IPI

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1824

F. Installing Adaptor and Termination Cap

CLASS A PIPE

GAS DIRECT VENT TERMINATION CAP

For installation of termination cap see minimum vent heights for various pitched roofs (see Figure 8.5) .

To install adaptor see Figure 8.6.

HORIZONTAL

OVERHANG

2 FT.

MIN.

20 INCHES MIN.

LOWEST

DISCHARGE

OPENING

H (MIN.) - MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING

ROOF PITCH

VERTICAL

WALL

IS X/ 12

CAUTION! Risk of Cuts/Abrasions/Flying Debris.

Wear protective gloves and safety glasses during instal-

lation. Sheet metal edges are sharp.

Damper Flashing Kit (Optional)

For use with LINK-DV30B, LINKSQ-DV30, LINK-DV430B or LINKSQ-DV4-30 Liner Kit.

Note: Damper may have to be removed to use this kit.

• Run ex liners through 3 in. holes in damper ashing.

• Attach damper ashing to rebox roof with self tapping screws included in kit.

Roof Pitch H (Min.) Ft.

Flat to 6/12....................1.0*

Over 6/12 to 7/12 ........1.25*

Over 7/12 to 8/12 ..........1.5*

Over 8/12 to 9/12 ..........2.0*

Over 9/12 to 10/12 ........2.5*

Over 10/12 to 11/12 .....3.25

* H minimum may vary depending on regional snowfall.

Figure 8.5 Minimum Height from Roof to Lowest Discharge



Opening

Refer to local codes.

Roof Pitch H (Min.) Ft.

Over 11/12 to 12/12 .......4.0

Over 12/12 to 14/12 ....... 5.0

Over 14/12 to 16/12 ....... 6.0

Over 16/12 to 18/12 ....... 7.0

Over 18/12 to 20/12 ....... 7.5

Over 20/12 to 21/12 ....... 8.0

Figure 8.6

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

OPTIONAL LINK-ZC-ADPB

FOR USE WITH CLASS A

WOODBURNING PIPE

EXHAUST

AIR

VENT PIPE

TERMINATION

CAP

LINK-DV30B

LINKSQ-DV30

Installation*

LINK-DV4-30B

LINKSQ-DV4-30

Installation**

INLET AIR

VENT PIPE

WARNING:

DO NOT BLOCK

THIS PIPE END!

INLET AIR

VENT PIPE

EXHAUST

AIR

VENT PIPE

To prevent odors and cold air drafts, it may be necessary to

place non-combustible insulation or eld fabricated metal plates around the vent pipe ues as they go through the

damper.

Note: The LINK-DV4-30B and LINKSQ-DV4-30 systems

REQUIRE this insulation.

Masonry

OR

*LINK-DV30B/LINKSQ-DV30: This installation may perform better

and allow less cold air inltration in negative pressure settings.

Note: Untwist the pipe while extending it, to achieve full 30’ length.

Factory Built

Wood Burning

Remove 18 inch x 18 inch ashing on cap by removing

3 screws. Connect both the LINK-ZC-ADPB to Class A Pipe and the termination cap to the LINK-ZC-ADPB with the self tapping screws provided.

**LINK-DV430B/LINKSQ-DV4-30:

• This installation may be more susceptible to cold air inltration and

the effects of negative pressure on the appliance’s performance.

• Depending on the chimney cleanliness, consider using the

full length intake so as to lessen the possibility of sense rod contamination and ame rectication issues.

Figure 8.7

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1826

Gas Information

A. Fuel Conversion

• Make sure the appliance is compatible with available gas

types.

• Conversions must be made by a qualied technician (NFI certied or factory-trained) using Hearth & Home Technologies specied and approved parts.

B. Gas Pressure

• Optimum appliance performance requires proper input pressures.

• Gas line sizing requirements will be determined in ANSI Z223.1 National Fuel Gas Code in the USA and CAN/ CGA B149 in Canada.

• Pressure requirements are:

Gas Pressure Natural Gas Propane

Minimum inlet pressure 5.0 in. w.c. 11.0 in. w.c.

Maximum inlet pressure 10.0 in. w.c. 13.0 in. w.c.

Manifold pressure 3.5 in. w.c. 10.0 in. w.c.

WARNING! Risk of Fire/Explosion! High pressure will

damage valve. Low pressure could cause explosion.

• Verify inlet pressures. Verify minimum pressures when other household gas appliances are operating.

• Install regulator upstream of valve if line pressure is greater than 1/2 psig.

WARNING

Fire Risk.

Explosion Hazard.

High pressure will damage valve.

• Disconnect gas supply piping BEFORE pressure testing gas line at test pressures above 1/2 psig.

• Close the manual shutoff valve BEFORE pressure testing gas line at test pressures equal to or less than 1/2 psig.

Note: Have the gas supply line installed in accordance with local codes, if any. If not, follow ANSI 223.1. Installation

should be done by a qualied installer approved and/or

licensed as required by the locality. (In the Commonwealth of Massachusetts installation must be performed by a

licensed plumber or gas tter).

Note: A listed (and Commonwealth of Massachusetts approved) 1/2 inch (13 mm) T-handle manual shut-off valve

and exible gas connector are connected to the 1/2 inch

(13 mm) control valve inlet.

• If substituting for these components, please consult local codes for compliance.

C. Gas Connection

• Refer to Reference Section 14 for location of gas line access in appliance.

• Gas line may be run through knockout(s) provided.

• The gap between supply piping and gas access hole may be caulked with caulk with a minimum of 300ºF continuous exposure rating or stuffed with non-combustible, unfaced

insulation to prevent cold air inltration.

• Ensure that gas line does not come in contact with outer wrap of the appliance. Follow local codes.

• Pipe incoming gas line into valve compartment.

• Connect incoming gas line to the 1/2 in. (13 mm) connection on manual shutoff valve.

WARNING! Risk of Fire/Explosion! Support control

when attaching pipe to prevent bending gas line.

• A small amount of air will be in the gas supply lines.

WARNING! Risk of Fire/Explosion! Gas build-up during

line purge could ignite.

• Purge should be performed by technician certied by

NFI or factory-trained.

• Ensure adequate ventilation.

• Ensure there are no ignition sources such as sparks

or open ames.

Light the appliance. It will take a short time for air to purge

from lines. When purging is complete the appliance will light and operate normally.

WARNING! Risk of Fire, Explosion or Asphyxiation!

Check all ttings and connections with a non-corrosive commercially available leak-check solution. DO NOT use open ame. Fittings and connections could have loosened during shipping and handling.

WARNING! Risk of Fire! DO NOT change valve settings. This valve has been preset at the factory.

D. High Altitude Installations

NOTICE: If the heating value of the gas has been reduced,

these rules do not apply. Check with your local gas utility or authorities having jurisdiction.

When installing above 2000 feet elevation:

• In the USA: Reduce burner orice 4% for each 1000 feet

above 2000 feet.

• In the CANADA: Reduce burner orice 10% for elevations

between 2000 feet and 4500 feet. Above 4500 feet, consult local gas utility.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Electrical Information

A. Wiring Requirements

NOTICE: This appliance must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code

ANSI/NFPA 70-latest edition or the Canadian Electric Code CSA C22.1.

• This appliance comes standard with a 120 VAC cord assembly which has a female plug in to accommodate all control options and accessories. See Figure 10.2. This is required for proper operation of the appliance (IntelliFire™ Plus Ignition). An outlet box may be installed

in a bottom back corner of the existing solid fuel masonry or factory built replace to plug in the cord assembly,

or the supplied power cord may be routed out onto the hearth to a nearby outlet.

• A 120 VAC circuit for this product must be protected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in

locations such as in bathrooms or near sinks.

• Low voltage and 120 VAC voltage cannot be shared within the same wall box.

WARNING! Risk of Shock or Explosion! DO NOT wire

120V to the valve or to the appliance wall switch. Incorrect wiring will damage controls.

• An Intellire™ Plus Ignition System is standard with this appliance.

B. IntelliFire™ Plus Ignition System Wiring

• Wire an outlet box (120VAC) in the bottom back corner of

the existing solid fuel masonry or factory built replace to plug in the cord assembly. The supplied cord assembly may also be routed out onto the hearth to a nearby outlet.

WARNING! Risk of Shock or Explosion! DO NOT wire

IPI controlled appliance junction box to a switched circuit. Incorrect wiring will override IPI safety lockout.

• Refer to Figure 10.1, IPI Wiring Diagram.

• This appliance is equipped with an IntelliFire™ Plus control valve which operates on a 6 volt/1.5 AMP system.

• Plug the 6 volt transformer plug into the cord assembly to supply power to the unit OR install 4 AA cell batteries

(not included) into the battery pack before use.

ON/OFF Switch

• An ON/OFF switch is included with the appliance surround and should be attached to surround/facing. (See Installation instructions for remote control/fronts).

• If desired an additional wall switch or thermostat may be added to system as shown in Figure 10.1.

TO CORD ASSEMBLY

120VAC

ORANGE

(PILOT)

FLAME

MODULATION

GREEN

(MAIN)

MODULE

RED

BLK

BROWN

INTERMITTENT PILOT IGNITOR

ORG WHT

RED

BLK

EMC FILTER UNIT

RC100 RC200 RC300

(OPTIONAL WIRELESS REMOTE CONTROLS)

AUX300 MODULE

WALL SWITCH

OR REMOTE

FAN

AUX2

AUX1

BATTERY PACK

6V DC

INSTALL

AUX2 NOT USED FOR INSERT MODELS.

PROTECTIVE COVER INCLUDED

TO CORD

ASSEMBLY

(110V)

ROCKER SWITCH

Figure 10.1 IPI Wiring Diagram

GROUND

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1828

GROUND

C. Optional Accessories Requirements

• This appliance may be used with a wall switch, wall mounted thermostat and/or a remote control.

• To connect optional accessories, the supplied cord assembly should be used. See Figure 10.2 for a wiring

diagram for a blower or remote.

Wiring for optional Hearth & Home Technologies approved accessories should be done now to avoid reconstruction. Follow instructions that come with those accessories.

• Plug the cord into a convenient outlet.

• Must use cord supplied.

• An IntelliFire™ Plus Wireless Controls or WSK-21 wired wall switch may be used with the IntelliFire™ Plus Ignition System. Hearth & Home Technologies recommends that IntelliFire™ Plus wireless controls be used for their features and functionality with the IntelliFire™ Plus ignition system.

• A standard ON/OFF switch is compatible.

WARNING! Risk of Shock! Label all wires prior to dis-

connection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing.

WARNING! Risk of Shock! Replace damaged wire with

type 105° C rated wire. Wire must have high temperature insulation.

NOTE: IF ANY OF THE ORIGINAL WIRE AS SUPPLIED WITH THE APPLIANCE MUST BE REPLACED, IT MUST BE REPLACED WITH TYPE 1050 C RATED WIRE.

NOTE: USE ZIP TIES TO RESTRAIN THE LOOSE WIRES UNDERNEATH THE APPLIANCE AND KEEP THEM AWAY FROM THE BLOWER WHEEL (FAN BLADES).

PLUG INTO 120V EXISTING OUTLET

BLOWER

BLK (2) GRN (2) BLK (2)

WHT (2) GRN (2) BLK (2)

BRN

BLK

RED

TEMPERATURE

SENSOR SWITCH

TO VALVE ORG BLK

GRN

TO VALVE BRACKET (GROUND)

PLUG 120V EXISTING OUTLET

JUMPER WIRE

SPEED CONTROL (RHEOSTAT)

VARIABLE SPEED

CONTROL

BLK

TEMPERATURE

SENSOR SWITCH

Figure 10.2 Fan Wiring Diagram

BLK

DC REGULATOR RECEPTACLE

WHT

GRN

BLOWER RECEPTACLE

GRN

WHT

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

BLK

FUSE WIRE ASSEMBLY

BLK

GRN

BLK

BLOWERS

BLK

GRN

BLK

PLUG 120V EXISTING OUTLET

GRN (2)

BLK (2)

GRN (2)

BLK (2)

STEPS

3 & 4

WHT (2)

BLOWER

SPEED CONTROL (RHEOSTAT)

SENSOR SWITCH

STEPS

1 & 2

STEP 5

D. Fan Wiring with Remote

This appliance may be used with an RC200 or RC300

remote control. See Figure 10.3.

1. Remove cord assembly spades from rheostat and sensor switch.

NOTICE: Fan speed and operation are controlled by the

remote control. The sensor switch and rheostat are no longer needed.

NOTE: IF ANY OF THE ORIGINAL WIRE AS SUPPLIED WITH THE APPLIANCE MUST BE REPLACED, IT MUST BE REPLACED WITH TYPE 1050 C RATED WIRE.

NOTE: USE ZIP TIES TO RESTRAIN THE LOOSE WIRES UNDERNEATH THE APPLIANCE AND KEEP THEM AWAY FROM THE BLOWER WHEEL (FAN BLADES).

2. Plug two cord assembly spade connectors together.

3. Unplug fan cord assembly from standard cord assembly.

4. Plug fan cord assembly into AUX300 module.

5. Plug AUX300 module into the standard cord assembly.

E. Control Module Operation

See Section 2.H for control module operation instructions.

NOTE: SENSOR SWITCH AND RHEOSTAT SPEED CONTROL MUST BE REMOVED FROM CIRCUIT IF SYSTEM IS CONTROLLED WITH RC200/RC300 REMOTE.

PLUG INTO 120V EXISTING OUTLET

DC REGULATOR RECEPTICLE

BLK

TO CONTROL MODULE

BLOWER RECEPTICLE

AUX 300 MODULE

FAN

WHT

GRN

BLK

GRN WHT

FUSE WIRE ASSEMBLY

BLK

GRN

BLK

BLOWERS

BLK

GRN BLK

Figure 10.3 Wiring Diagram - Fan with RC200/RC300 Remote

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1830

Finishing

A. Mantel and Wall Projections

WARNING! Risk of Fire! Comply with all minimum clear-

ances to combustibles as specied. Framing or nishing

material closer than the minimums listed must be construct-

ed entirely of noncombustible materials (i.e., steel studs, concrete board, etc).

Clearance to combustible material under the insert is 1/4 inch (6 mm). Clearance from top of replace opening for combustibles extending 12 inches max. is 12 inches.

• Use leveling legs to raise insert minimum 1/4 inch (6 mm)

above combustible material or outer wrap of factory built

rebox.

Combustible facings must not extend behind the insert surround. For non-combustible material specications refer to section 1.E.

EXISTING NON-COMBUSTIBLE FACING

12 IN. MAX.

2 IN. MAX.

10 IN. MIN.

12 IN. MIN.

Figure 11.1 Clearances to Mantels or other Combustibles above Appliance

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Appliance Setup

A. Remove Glass Assembly

See Section 12.H.

B. Remove the Shipping Materials

Remove shipping materials from inside or underneath the

rebox.

C. Clean the Appliance

Clean/vacuum any sawdust that may have accumulated

inside the rebox or underneath in the control cavity.

Note: Remove the zip ties on the exterior sides of the appliance that hold the electrical cord and gas line in place for shipping.

D. Accessories

Install approved accessories per instructions included with accessories. Contact your dealer for a list of approved accessories.

WARNING! Risk of Fire and Electric Shock! Use ONLY Hearth & Home Technologies-approved optional acces-

sories with this appliance. Using non-listed accessories could result in a safety hazard and will void the warranty.

E. Place the Lava Rock

F. Ember Placement

WARNING! Risk of Explosion! Follow ember placement

instructions in manual. DO NOT place embers directly over burner ports. Replace ember material annually. Improperly placed embers interfere with proper burner operation.

Ember material is shipped with this gas appliance. To place the ember material:

• Embers CANNOT be placed directly over ports. Care

should be taken not to cover the lighting trail of ports (from back to front).

• Place dime-size pieces of Glowing Embers® just in front of the port trail, but not on or in between the ports (see

Figure 12.2). Care should be taken so that the ports are not covered. Failure to follow this procedure will likely

cause lighting and sooting problems.

• Save the remaining ember materials for use during appliance servicing. The embers provided should be enough for 3 to 5 applications.

EMBERS NOT ALLOWED IN PILOT AREA

WARNING! Risk of Explosion! Follow lava rock place- ment instructions in manual. DO NOT place lava rock on burner. Improperly placed lava rock interferes with proper burner operation.

Lava rock is shipped with this gas appliance. To place the lava rock:

• Lava rock CANNOT be placed on the burner.

• Place lava rock in front of and to the sides of the

burner.

PLACE LAVA ROCK IN SHADED AREA ONLY

Figure 12.2 Placement of Embers

Figure 12.1 Placement of Lava Rock

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1832

G. Install the Log Assembly

Log Set Assembly: LOGS-QFI30 Models: QFI30, QFI30-C

SRV2227-702

SRV2227-705

SRV2227-703

SRV2227-704

LOG SUPPORT

PILOT ASSEMBLY

LOG PIN

RIGHT GRATE TINE

SRV2227-706

Figure 2. Refractory and Logs Installed

LEFT GRATE TINE

SRV2227-701

Figure 1. Reference Points for Log Placement

Figure 3. Install Back Refractory

CAUTION: Logs are fragile, handle with care. Install back refractory by placing it against the back of the rebox. See Figure

3. The back refractory must be held in the upright position until the side refractory is installed. Install the left side refractory

as shown in Figure 4. Bend the refractory tab down as shown in Figure 5. Repeat this step for the right refractory panel.

Figure 4. Install Side Refractory

Figure 5. Bend Refractory Tab

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

FLAT SPOT FOR LOG #5

LOG CORNER ALIGNS

WITH LOG TAB

NOTCH MATES WITH LEFT

GRATE TINE

FLAT SPOT FOR LOG #2

NOTCH

Figure 6. Placement of Log #1

Log #1 (SRV2227-703): Mate the notch located on the bottom of the log, with the left grate tine. See Figure 7. Bend the

tab located to the left of the pilot assembly into the vertical position. Rotate the back end of log clockwise until it contacts

the log tab as shown in Figure 6.

LOG CONTACTS REFRACTORY

Figure 7. Location of Notch on Log #1

LOG GROOVE (FOR LOG #6)

LOG RESTS ON REFRACTORY SUPPORT

LOG CONTACTS LOG SUPPORT

LOG RESTS ON BURNER

Figure 8. Place Log #2

Log #2 (SRV2227-702): Rest left end of log on the at spot of Log 1. See Figure 6 and Figure 8. The left end of the log

should touch the left refractory panel. The right end rests on the burner. Push the right end back, until it touches the edge

of the log support.

Log #3 (SRV2227-701): Mate the notch with the right grate tine as shown in Fig 9. The back of the log should rest on the log support as shown. Rotate the back end of the log clockwise until it contacts the right refractory panel.

Figure 9. Log #3

NOTCH MATES WITH RIGHT GRATE TINE

LOG PIN MATES WITH SLOT

MATE NOTCH

WITH GRATE BAR

Figure 10. Log #4

LOG GROOVE

(FOR LOG #6)

NOTCH

Figure 11. Log #4

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1834

Log #4 (SRV2227-705): Mate the slot on the bottom of the log, shown in Figure 12, with the log pin located on the burner surface. The notch on the right end of the log should mate with the grate bar. See Figure 11.

LOG END RESTS ON FLAT SPOT

LOG END CONTACTS GRATE BAR

SLOT

Figure 12. Log #4

Figure 13. Log #5

Log #5 (SRV2227-706): Place the left end of the log on the at spot of log as shown in Figure 6. The right end of log should

rest on the burner and touches the grate bar as shown in Figure 13.

MATE

NOTCH WITH GRATE BAR

LOG GROOVES

Figure 14. Place Log #6

Log #6 (SRV2227-704): Rest the left end of Log #6 on the burner. Mate the notch on the left end of log with the grate bar.

The log should rest on both log grooves as illustrated in Figure 9 and Figure 10.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

2227-935B

G. Install the Log Assembly

Log Set Assembly: LOGS-QFI35 Models: QFI35, QFI35-C

CAUTION: Logs are fragile, handle with care.

SRV2225-703

SRV2225-704

SRV2225-705

SRV2225-701

SRV2225-702

SRV2225-710SRV2225-706

Figure 1. Refractory and Logs Installed

Figure 2. Install Back Refractory

Install back refractory by placing it against the back of the rebox. The back refractory must be held in the upright position

until the side refractory is installed. Install the left side refractory as shown in Figure 3. Bend the refractory tab down as shown in Figure 4. Repeat this step for the right refractory panel.

REFRACTORY

TAB

Figure 3. Install Side Refractory

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1836

Figure 4. Bend Refractory Tab

LOG SUPPORT

LOG PINS

ANDIRONS

OUTER TINES

Figure 5.

Log #1 (SRV2225-701): Position the groove on the log with the right grate tine as shown in Figure 6. The opposite end of

the log will rest on the log support. Rotate the opposite end of the log clockwise until it contacts the refractory panel.

FLAT SPOTS FOR LOG #6 AND LOG #3

LOG CONTACTS LEFT REFRACTORY PANEL

LOG RESTS ON LOG SUPPORT

Figure 6. Location of Log #1

SLOT

LOG GROOVE CONTACTS GRATE TINE

MATE SLOT WITH GRATE TINE

Figure 7. Place Log #2

Log #2 (SRV2225-703): Mate the grate tine with the slot on the bottom of Log #2. The back end of the log rests on the log

support. The side of the log will contact the left refractory as shown in Figure 7.

POSITION LOG ON FLAT SPOT

FLAT SPOT FOR LOG #7

Figure 8. Slot on Log #2

LOG CONTACTS LEFT REFRACTORY PANEL

LOG RESTS ON LOG SUPPORT

LOG CONTACTS BACK REFRACTORY PANEL

Figure 9. Place Log #3

Log #3 (SRV2225-702): Position the left end of the log on the at spot of Log #2 as shown in Figure 7 and Figure 9. The

right end of the log rests on the log support and touches the back refractory. The left end of the log should contact the left

refractory panel. Log #4 SRV(2225-705): Mate the slot on the bottom of Log #4 with the right log pin. Refer to Figure 11 for location of log

slot. Rotate the right end of the log clockwise until the groove on the end of the log mates with the grate bar.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

MATE LOG PIN WITH LOG SLOT

Figure 10. Place Log #4

MATE GRATE BAR WITH LOG GROOVE

LOG SLOT

FLAT SPOT FOR LOG #6

MATE LOG PINS WITH LOG SLOTS

Figure 11. Log #4

Log #5 (SRV2225-710): Position Log #5 as shown in Figure 12. Mate the middle and left log pins with the two slots located

on the bottom of the log. See Figure 13 for locations of log slots. The smaller end should be pointed toward the right side

of the rebox.

LOG SLOTS

Figure 13. Log #5

Log #6 (SRV2225-706): Rest the wide end of the log on the at spot of Log #5 as shown in Figure 12 and Figure 14. Place

the narrow end on the at spot of Log #2. Flat spot on Log #2 is indicated in Figure 7.

Figure 12. Place Log #5

LOG RESTS ON FLAT SPOT

Figure 14. Place Log #6

LOG RESTS ON FLAT SPOT

Figure 15. Place Log #7

Log #7 SRV2225-704): Note the location of the groove on the underside of the log. Place the opposite end on the at spot

on Log #3. See Figure 9. Mate the groove on the underside of the log with the grate bar as shown in Figure 15, centered between the andirons.

LOG GROOVE MATES WITH GRATE BAR

2225-935C

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1838

H. Fixed Glass Assembly

Removing Fixed Glass Assembly

WARNING! Risk of Asphyxiation! Handle xed glass assembly with care. Inspect the gasket to ensure it is undamaged and inspect the glass for cracks, chips or scratches.

• DO NOT strike, slam or scratch glass.

• DO NOT operate replace with glass removed, cracked, broken or scratched.

• Replace as a complete assembly.

Removing Fixed Glass Assembly

• The glass assembly fastens to the replace in four

places. Four of the fastening mechanisms are springloaded glass latches. An example of the glass latch is shown in Figure 12.3.

• To release glass assembly, pull the two bottom

spring-loaded latches forward and allow them to retract away from the glass assembly. Slide the glass assembly outward and downward until the top latches disengage.

I. Air Shutter Setting

Air shutter settings should be adjusted by a qualied service technician at the time of installation. The air shutter is set at the factory for minimum vertical vent run. Adjust air shutter for longer vertical runs. See Figure 12.4.

NOTICE: If sooting occurs, provide more air by opening

the air shutter.

Figure 12.4 Air Shutter

Replacing Fixed Glass Assembly

• Tilt glass assembly toward replace and slide glass

assembly upward to engage top latches. Verify top latches are fully engaged and then fasten the two bottom latches.

• Inspect and operate all glass latches to ensure they move



freely and no obstructions are present.

• Reinstall door or decorative front.

Air Shutter Settings

NG Propane

QFI30-C 3/8 in. 1/2 in.

QFI35-C 3/8 in. 1/2 in.

Figure 12.3 Fixed Glass Assembly

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Troubleshooting

With proper installation, operation, and maintenance your gas appliance will provide years of trouble-free service. If you

do experience a problem, this troubleshooting guide will assist a qualied technician in the diagnosis of a problem and the corrective action to be taken. This troubleshooting guide can only be used by a qualied technician. Contact your dealer to arrange a service call by a qualied technician.

A. IntelliFire™ Plus Ignition System

Symptom Possible Cause Corrective Action

1. Pilot won’t light. The ignitor/module

makes noise, but no spark.

2. Pilot won’t light, there is no noise or

spark.

3. Pilot sparks, but

Pilot will not light.

A. Incorrect wiring. Verify “S” wire (white) for sensor and “I” wire (orange) for ignitor are

connected to correct terminals on module and pilot assembly.

B. Loose connections or electrical

shorts in the wiring.

C. Ignitor gap is too large. Verify gap of igniter to right side of pilot hood. The gap should be

A. No power, transformer installed

incorrectly, or depleted batteries.

B. A shorted or loose connection in

wiring conguration or wiring harness.

C. Improper wall switch wiring. Verify that 120/VAC power is “ON” to junction box.

D. Module not grounded. Verify black ground wire from module wire harness is grounded to

A. Gas supply. Verify that incoming gas line ball valve is “open”. Verify that inlet

Verify no loose connections or electrical shorts in wiring from module to pilot assembly. Verify connections underneath pilot assembly

are tight; also verify igniter and ame sense wires are not grounding

out to metal chassis, pilot burner, pilot enclosure, mesh screen if present, or any other metal object.

approximately .095 in. (2.41 mm) to .135 in. (3.43 mm).

Verify that transformer is installed and plugged into module. Check

voltage of transformer at connection to module. Acceptable readings of a good transformer are between 6.4 and 6.6 volts DC. Battery power supply voltage must be at least 4 volts. If below 4 volts, replace batteries.

Remove and reinstall the wiring harness that plugs into module. Verify there is a tight t. Verify pilot assembly wiring to module. Remove and verify continuity of each wire in wiring harness. Replace any damaged components.

metal chassis of appliance.

pressure reading is within acceptable limits.

B. Ignitor gap is too large. Verify gap of igniter to right side of pilot hood. The gap should be

approximately .095 in. (2.41 mm) to .135 in. (3.43 mm).

C. Module is not grounded. Verify module is securely grounded to metal chassis of appliance.

D. Pilot valve solenoid Verify that 1.5 to 1.8 VDC is supplied to pilot solenoid from module.

If below 1.5 volts, replace module. If 1.5 volts or greater, replace valve.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1840

IntelliFire™ Plus Ignition System (continued)

Symptom Possible Cause Corrective Action

4. Pilot lights but contin-

ues to spark, and main

burner will not ignite. (If the pilot continues

to spark after the pilot ame has been lit, ame rectication has

not occurred.)

5. Appliance lights and

runs for a few minutes and then shuts down and/or appliance cycles on and off.

A. A shorted or loose connection in ame

sensing rod.

B. Poor ame rectication or contaminated

ame sensing rod.

C. Module is not grounded. Verify module is securely grounded to metal chassis of ap-

D. Damaged pilot assembly or contami-

nated ame sensing rod.

A. A shorted or loose connection in ame

sensing rod.

Verify all connections to wiring diagram in manual. Verify connections underneath pilot assembly are tight. Verify

ame sense or igniter wires are not grounding out to metal

chassis, pilot burner, pilot enclosure or screen if present, or any other metal object.

With xed glass assembly in place, verify that ame is engulng ame sensing rod on left side of pilot hood. Flame

sensing rod should glow shortly after ignition. With a multimeter, verify that current in series between module and sense lead is at least 0.14 microamps. Verify correct pilot

orice is installed and gas inlet is set to pressure specications. Polish ame sensing rod with ne steel wool to

remove any contaminants that may have accumulated on

ame sensing rod.

pliance. Verify that wire harness is rmly connected to the

module.

Verify that ceramic insulator around the ame sensing rod is not cracked, damaged, or loose. Verify connection from ame sensing rod to white sensor wire. Polish ame sensing rod with ne steel wool to remove any contaminants that may have accumulated on ame sensing rod. Verify

continuity with a multi-meter with ohms set at lowest range. Replace pilot if any damage is detected.

Verify all connections to wiring diagram in manual. Verify connections underneath pilot assembly are tight. Verify

ame sense or igniter wires are not grounding out to metal

chassis, pilot burner, pilot enclosure or screen if present, or any other metal object.

B. Poor ame rectication or contaminated

ame sensing rod.

C. Logs are set up incorrectly. Remove and reinstall logs per the log placement

D. Damaged pilot assembly or contami-

nated ame sensing rod.

With xed glass assembly in place, verify that ame is engulng ame sensing rod on left side of pilot hood. Flame

sensing rod should glow shortly after ignition. With a multimeter, verify that current in series between module and sense lead is at least 0.14 microamps. Verify correct pilot

orice is installed and gas inlet is set to pressure specications. Polish ame sensing rod with ne steel wool to

remove any contaminants that may have accumulated on

ame sensing rod.

instructions.

continuity with a multi-meter with ohms set at lowest range. Replace pilot if any damage is detected.

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

Reference Materials

A. Appliance/Decorative Front Dimension Diagrams

Dimensions are actual appliance dimensions. Use for reference only.

GAS LINE ACCESS

MODEL DIMENSIONS

Location

QFI35-C QFI30-C

Inches Millimeters Inches Millimeters

A 23-7/16 595 20-3/16 513

B 34-5/8 879 30-5/8 778

C 31-5/8 803 27-1/2 699

D 15-11/16 398 12-3/16 310

E 24-1/16 611 20-7/16 519

F 21-1/8 537 17-5/8 448

G* 15-11/16 403 14-5/8 372

H 11-3/4 298 10-1/16 256

I 20-7/16 518 17 432

J 1-3/4 44 1-3/4 44

ELECTRICAL ACCESS

MODEL DIMENSIONS

Location

QFI35-C QFI30-C

Inches Millimeters Inches Millimeters

K 4-13/16 122 4-13/16 122

L 10-1/16 256 9-1/8 232

M 2-7/16 62 2-7/16 62

N 5 127 4-1/16 103

O 5-1/8 130 5-1/8 130

P 8-15/16 227 8-15/16 227

Q 1-13/16 46 1-15/16 49

R 3-1/4 83 3-1/4 83

S 5-5/16 135 4-15/16 125

T 10-5/8 270 9-1/2 235

U 4-11/16 119 4-5/8 118

*Note: Location G on Figure 14.1 is measuring the appliance depth, for installation depth reference Location G on Figure 5.2.

Figure 14.1 Appliance Dimensions

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1842

AF-QFI30, AF-QFI35 DECORATIVE FRONTS

A B C D E F G

AF-QFI30

AF-QFI35

in. 30 13-1/2 4-5/8 36 23-11/16 23-3/16 1/2

mm 762 343 11 7 914 602 589 13

in. 32 16 4-5/8 38 25-11/16 25-3/16 1/2

mm 813 406 11 7 965 652 640 13

FSP-QFI30, FSP-QFI35 DECORATIVE FRONTS

FSP-QFI30

FSP-QFI35

Figure 14.2 Decorative Front Dimensions

in. 27 11-5/8 5-1/2 36 23-11/16 23-3/16 1/2

mm 686 279 140 914 602 589 13

in. 29-1/4 16-1/16 4-15/16 38 25-11/16 25-3/16 1/2

mm 743 408 125 965 652 640 13

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

A B C D E F G

TP-QFI30/TP-QFI35 DECORATIVE FRONTS

E F

TP-QFI30

TP-QFI35

A B C D E F G

in. 32-15/16 12-9/16 4-5/8 36 23-1/2 23 1/2

mm 837 319 11 7 914 597 584 13

in. 35 15-9/16 4-11/16 38-1/16 26-1/2 26 1/2

mm 889 395 11 9 967 673 660 13

Figure 14.3 Decorative Front Dimensions

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1844

B. Vent Kits Components

Direct Vent Flex Liner Kits (see Figure 14.4)

LINK-DV30B: Masonry 3 inch ex liner kit. Expands to 30 feet. Includes: two liners, termination cap and ashing.

LINK-DV4-30B: Masonry 3 inch ex liner kit. Expands to 30

feet and 4 feet respectively. Includes: two liners, termination

cap and ashing.

LINKSQC-DV30, LINKSQB-DV30: Masonry 3 inch ex liner kit. Expands to 30 feet. Includes: two liners, termination cap and ashing.

LINKSQC-DV4-30, LINKSQB-DV4-30: Masonry 3 inch

ex liner kit. Expands to 30 feet and 4 feet respectively. Includes: two liners, termination cap and ashing.

LINK-ZC-ADPB

DV-46DVA-GK

LINK-DV30B

LINK-DV4-30B

Figure 14.4 Direct Vent Flex Liner Kits

LINKSQC-DV30 (COPPER)

LINKSQB-DV30 (BLACK)

LINKSQC-DV4-30 (COPPER)

LINKSQB-DV4-30 (BLACK)

Direct Vent Flex Liner Accessory Kits (see Figure 14.5)

LINK-ZC-ADPB: Zero clearance chimney adapter

DV-46DVA-GK: Adapter kit - It is permissible to use DV46DVA-GK to connect collinear ex vent to SLP vent pipe

to extend the run.

FLEX3-30: One 3 inch exible liner expands to 30 feet.

FLEX-CNCT: Connector kit - 3 inch liner to 3 inch liner, one connector per kit.

FLEX3-30

FLEX-CNCT

Figure 14.5 Direct Vent Flex Liner Accessory Kits

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/18

D. Contact Information

Quadra-Fire, a brand of Hearth & Home Technologies

7571 215th Street West, Lakeville, MN 55044

www.quadrare.com

Please contact your Quadra-Fire dealer with any questions or concerns.

For the location of your nearest Quadra-Fire dealer,

please visit www.quadrare.com.

- NOTES -

________________________________________________________________________________

NOTICE

DO NOT DISCARD THIS MANUAL

• Important operating and maintenance instructions included.

• Read, understand and follow these instructions for safe installation and operation.

• Leave this manual with party responsible for use and operation.

This product may be covered by one or more of the following patents: (United States) 5613487, 6006743, 6019099,



6053165, 6145502, 6374822, 6484712, 6601579, 6769426, 6863064, 7077122, 7074035, 7098269, 7258116, 7322819, 7470729, 7726300, 8147240, 9625149 or other U.S. and foreign patents pending.

2000-945D

Quadra-Fire • QFI30-C, QFI35-C • 2227-901 Rev. AA • 7/1850

Quadra-Fire QFI30-C, QFI35-C Users guide

Specifications and Main Features

Frequently Asked Questions

User Manual
