Q-See QR4074-411 User Manual

Quick Installation Guide

4 Channel H.264 Compressi on DV R with

MMOODDEELL QQRR44007744--441111

Built-in 7” LCD Display Screen,
(CIF) Real-Time Recording and
4 Color CMOS Camera Kits

User’s

PART 1 - PACKAGE CONTENTS:

QR4074 DVR

w/Built-in

7” LCD Display Screen

Power Supply

For DVR

Software

CD

4 - Color CMOS Cameras with Stands

Q-SEE QUICK INSTALLATION GUIDE

MMOODDEELL NNUUMMBBEERR QQRR44007744--44111

(4) QSM1424C (6mm Lens)

(4) QSM1424W (3.6mm Lens)

Power Supply &

4 -Way Splitter

For Cameras

Ethernet

Cable

1 | Page

1

Pre-Installed

Hard Drive

Camera Cables

(4 Included)

USB 2.0

Mouse

Manual

BNC (M) – RCA (F)

Adapter

Remote

Control

Q-SEE QUICK INSTALLATION GUIDE

MMOODDEELL NNUUMMBBEERR QQRR44007744--44111

PART 2 - DVR CAMERA AND POWER CONNECTIONS

Please note that it is STRONGLY recommended to use a surge protector that is UL-1449 rated.
Look for a clamping voltage of 330 or lower, a Joule rating of at least 400 and a response time of
10 nanoseconds or less.

1
