CD-40
Owner’s manual
GB
Safety instructions
Keep the unit away from heat sources such as radiators, heaters or other appliances that produce heat.
Ensure that the unit is not placed in such a way as to interfere with proper ventilation. For example the unit should not
be placed on soft furnishings that may block ventilation openings or placed in an enclosed unit such as a bookcase or
cabinet that may impede the flow of air through the ventilation openings.
Do not expose the unit to direct sunlight.
Do not use the unit near water.
Avoid objects or liquids getting into the unit.
Do not remove screws from or open the unit casing.
Ensure that foreign objects are prevented from obstructing the cooling fan on the rear of the unit.
Do not use the unit with the rear fan cover or filter removed.
Care instructions
Legato main unit and speaker casings (where supplied) have a wood veneer covering. As with other wood products care
must be taken when handling and cleaning to protect the wood from damage.
Do not expose the casings to detergents, solvents or abrasive materials
Do not expose the casings to sources of direct heat such as hot drinks.
Wipe over gently with a soft cloth to clean the casings.
Occasional use of light furniture polish (applied via a soft cloth) will help protect the surface.
The cooling fan on the rear of the unit has a removeable cover and filter fitted to help prevent dust entering the unit. We
recommend periodically checking that the filter is clear by removing the cover. If the filter appears blocked rinse the filter
in water, leave to dry thoroughly then replace the filter and protective cover.
Copyright
Copyright 2006 by Imagination Technologies Limited. All rights reserved. No part of this publication may be copied or distributed, transmitted, transcribed,
stored in a retrieval system, or translated into any human or computer language, in any form or by any means, electronic, mechanical, magnetic, manual or
other wise, or disclosed to third parties without the express written permission of Imagination Technologies Limited.
Disclaimer
Imagination Technologies Limited makes no representation or warranties with respect to the content of this document and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose. Further, Imagination Technologies Limited reserves the right to revise this publication
and to make changes in it from time to time without obligation of Imagination Technologies Limited to notify any person or organization of such revisions or
changes.
Trademarks
Legato, the Legato logo, ReVu, the ReVu logo, PURE, the PURE logo, PURE Digital, the PURE Digital logo, Imagination Technologies, and the Imagination
Technologies logo are trademarks or registered trademarks of Imagination Technologies Limited. All other product names are trademarks of their respective
companies.
Warranty information
Imagination Technologies Ltd. warrants to the end user that this product will be free from defects in materials and workmanship in the course of normal use
for a period of two years from the date of purchase. This guarantee covers breakdowns due to manufacturing or design faults; it does not apply in cases such
as accidental damage, however caused, wear and tear, negligence, adjustment, modification or repair not authorised by us. Please register your product on
our website at www.pure.com/register or by filling in and returning your warranty card. Should you have a problem with your unit please contact your supplier
or contact PURE Suppor t at the address shown on the rear of this manual.
Credits
This manual was written by Bruce Murray. It is a product of PURE Digital, Imagination Technologies Ltd., Imagination House, Home Park Estate, Kings Langley,
Herts, WD4 8LZ, UK. Version 5 January 2006
Great Britain
1
GB
Contents
Getting started ................................................................... 2
Overview diagrams ................................................................................... 2
Connecting speakers ................................................................................ 4
Switch on and off ....................................................................................... 4
Changing the volume ................................................................................ 4
Navigating menus ..................................................................................... 4
Listening to DAB radio ........................................................ 5
Selecting a station .................................................................................... 5
Changing the information displayed ......................................................... 5
ReVu™ - Pausing and rewinding radio ...................................................... 5
Storing and recalling presets ................................................................... 6
Changing DAB options ............................................................................... 6
Playing a CD ........................................................................ 8
Selecting a track ....................................................................................... 8
Changing the information displayed ......................................................... 8
Changing CD options ................................................................................. 8
Playing an MP3 CD ............................................................ 10
Changing the information displayed ........................................................10
Changing MP3 options ..............................................................................10
Listening to FM radio ........................................................ 11
Selecting a station ...................................................................................11
Changing the information displayed ........................................................11
Storing and recalling presets ..................................................................11
Changing FM options ................................................................................12
Listening to another source .............................................. 13
General setup options ...................................................... 14
Audio ........................................................................................................14
Screen ......................................................................................................14
Alarm ......................................................................................................14
Sleep timer ..............................................................................................14
S/W version .............................................................................................15
Hints and tips .................................................................... 16
Technical specifications .................................................... 17
Great Britain
2
Overview diagrams
These diagrams show the function of controls, the connectors on the rear panel, the remote control and screen icons.
Getting started
Six shortcut buttons
Provide quick access to radio presets,
CD/MP3 controls
and menu options
LCD screen
Backlit LCD screen with
variable contrast and brightness
CD tray
For audio and MP3 CDs
CD eject button
Opens and closes the CD tray
Power
Switches between
on and standb
y
Display
Switches
between
display
modes
ReVu
Enters ReVu
mode for DAB
pause and
rewind
Volume/Tuning
Turn for volume,
push and turn to
select stations,
tracks and
menu options
Mode
Switches
between
CD/DAB/FM/
AU
X
Menu
Change audio
and general
setup options
Headphone
3.5 mm
headphone
socket
(mutes speakers)
Infrared receiver
Receives signal
from remote control
PowerDisplay MenuReVu Mode
CD/DAB/FM
Manufactured in China 12B52
Variable Output
Stereo out to recorder,
powered sub or other device
Speaker Connectors
Spring loaded connectors
Connect red socket to red on speak
er
and black socket to black on speak
er
Power Socket
Power lead socket
Cooling fan cover
Remove cover (pull off)
t
o inspect/clean
filter periodically.
USB
Type B
connector
for software
upgrades
Aux Input
Stereo input from
cassette/minidisc etc.
Optical Out
Digital output of
DAB, CD or MP
3
Aerial
F-type connector
for DAB/FM aerial
Rear panel
Front panel
Great Britain
3
GB
Mode Power
Menu
Display
Mut
e
RMT - CD
Shuffle
Repeat
ReVu
/
1
2
3
4
5
6
7
8
9
0
Select
+
-
Save
-/--
Power
Switches between
on and standby
Number keys
Press Save and number to store a preset.
Press number to recall.
Press -/-- first for double digit presets.
Press to quickly access CD or MP3 tracks
ReVu
Enters ReVu mode
for DAB pause and
rewind
Menu
Change audio and
general setup options
Volume
Adjust volume, move slider controls
and move left and right in menus
Eject
Opens and closes
the CD tray
+/-
Mode
Switches between
DA
B/FM/CD/AUX
Display
T
oggles between
display modes
Mute
Mutes output
from speakers
Select and
Select stations/tracks
and menu options
CD controls
Also used for FM
tuning and ReVu
J o Wh il ey Ch an gi ng
T r a ck s - g o on li n e to
n o m in at e th e tu ne s
BBC Radio 1
0 9 : 40
Signal strength
Shows signal strength
for current DAB station
Clock
Time from
DAB signal
Mute
Volume from
speakers muted
Mode
Current
mode (DAB)
Station
name
Scrolling
text
D AB
Alarm
Alarm set
T r a ck 1
0 9 : 40
CD
Skip forward
Fast forwar
d
Stop
Repeat
Repeat all
tracks selected
Shuffle
Random track
order selected
Playlist
Playlist
selected
Mode
Current
mode (CD)
Track
Pause/Play
Rewind
Skip back
Counter
Elapsed track time
Remote control
DAB screen
CD screen
0 9 : 41
F M
Clock
Time from
DA
B signal
Mode
Current
mode (FM)
Station
RDS name or
frequency
RDS
RadioText
Chiltern
Today's Best Mix for Her t s
Beds and Bucks - 97.6
Chiltern FM
Loudness
Loudness on
FM screen
Great Britain
4
Connecting speakers
When connecting speakers connect the red (positive) terminals on Legato to
the red terminals on the speaker and black (negative) to black. The speaker
cable has a stripe on one strand to aid connection.
Ensure that the bared ends of the wires are securely gripped by the spring
clips. Note that the sound from new speakers should improve over the course
of a few days as they are ‘run-in’.
You can also connect an active subwoofer to the Variable out sockets on your
Legato for enhanced bass. See page 14 for more details.
Switch on and off
When you first plug your Legato in it switches to DAB mode and asks you if
you want to perform a UK (UK Band III only) or Full autotune (full Band III)
to find all DAB stations available in your area. These stations are stored in a
station list and ordered alphanumerically.
The first station on the station list is selected.
To switch your unit off (standby) - press the Power button on the unit or
remote control. You see the standby symbol and clock on the screen. Push
the Display button to change between a small clock, large clock and day/date
time display in standby.
To switch your Legato back on press the Power button again. Your unit starts
in whatever mode you were in when you switched off.
Changing the volume
The Volume/Tuning dial operates as a volume control by default except when
you are in a menu or browsing the station or track lists. When you adjust the
volume you temporarily see the volume scale on screen indicating the current
level. You can also use the volume buttons on the remote control to adjust
the volume.
Navigating menus
You turn the Tuning dial to scroll through menu options or station or track lists
and push to select options. In most menus if you do not select anything you
return to the previous screen. Alternatively use the equivalent remote control
buttons. You can also press a shortcut button to select the option shown on
screen next to that button.
D AB Au t o t u n e Me nu
U K
S el e c t D AB r e gi on :
F ul l
Initial startup screen
V o l u m e
Adjust ing volume
Au t o t u n e UK
S ta t i o n s f o u nd : 21
S ca n n i n g ...
Autotune UK
Nominal impedance 6 ohms
Maximum power rating 30W
Manufactured in China
Part number 12A67
Nominal impedance 6 ohms
Maximum power rating 30W
Manufactured in China
Part number 12A67
Great Britain
5
GB
To listen to DAB radio push the Mode button until you see DAB in the top left of the
screen.
When you first switch on your Legato it automatically enters DAB mode, autotunes to
find all the DAB stations available in your area and lists them in alphanumeric order.
Selecting a station
To change stations, push the Tuning dial and turn to scroll through the station
list, then push the Tuning dial again to tune to the highlighted station.
The currently selected station is shown in the box at the top of the screen.
Changing the information displayed
Legato has five DAB display modes which change what you see on screen
while you listen to DAB radio. Push the Display button to switch between the
modes.
Text Dynamic text broadcast by most stations.
Reception info DAB channel and frequency of the station you are listening
to, signal strength meter and signal quality reading. As a
guide, values from 85 to 100 indicate good reception, 70 to
84 average reception and 0 to 69 poor reception.
Broadcast info Name of the multiplex the current station belongs to.
Multiplexes are groups of stations broadcast by a single
operator. Description of the content broadcast by the
station, Stereo or Mono indicator and data rate at which the
station is being transmitted. This rate is set by the stations
to suit the type of material being transmitted. High rates
generally mean higher quality.
Presets DAB presets for quick access to your favourite stations using
the six shortcut buttons.
Date and time Date and time broadcast by the multiplex.
ReVu™ - Pausing and rewinding radio
ReVu mode lets you pause and rewind live DAB digital radio.
Legato constantly stores audio and text from the station you are tuned to in
its memory. The amount stored depends on how long you have been listening
to that station and the data rate of the broadcast. You can access this stored
audio and pause or rewind live radio over short periods (approximately 20 to
40 minutes depending on data rate).
Once the memory is full, ReVu keeps adding to the memory but starts to
overwrite the oldest stored audio and text.
You can enter ReVu mode in two ways which you select as follows:
Paused - press and release the ReVu button or pause button on the remote
Fast forward/rewind - press and hold the ReVu button for three seconds or
press the fast forward/rewind or skip forward/back buttons on the remote
Listening to DAB radio
J o W h i l e y' s Cha ng i n g
T r a c k s - go o nl i n e t o
n o m i n a t e t he t un e s
BBC Radio 1
0 9 : 4 0
D AB
Default DAB screen
D AB St a t i o n L is t
BBC Londo n
BBC Radio 1
BBC Radio 2
BBC Radio 1
S
i g n a l Qu a l i t y 9 6%
1 2 B 2 2 5 .6 48 MH z
BBC Radio 1
0 9 : 4 0
D A
B
BBC N a t i o n a l D AB
P o p M u s i c
1 2 8 k b p s
S te r e o
BBC Radio 1
0 9 : 4 0
D A
B
P a u s e d
0 9 : 4 0
D AB
0 9 : 4 0
Selecting a station
Display modes - Reception info
ReVu mode - paused
Display modes - Broadcast info
BBC Radio 1
0 9 : 4 0
D AB
2 2/ 0 7/ 04
Display modes - Date and time
Great Britain
6
When you enter ReVu mode you see the ReVu icon on the screen and a timer
shows how many minutes and seconds behind the live broadcast you are.
Once in ReVu mode you can toggle between paused and playing by pushing
the ReVu button again or pressing the pause/play ( / ) button. To exit
ReVu mode and return to the live broadcast press the stop ( ) or skip
forward ( ) button to catch up with the live broadcast but remain in ReVu
mode.
To pause and replay live radio
Push the ReVu button. The screen shows Paused and the timer shows how far
behind the live broadcast you are.
Push the ReVu button again to start replaying the stored audio and text
from where you left off. The timer stops counting, showing that you are now
listening that many minutes and seconds behind real time. You can listen in
this way for as long as you like, or press the fast forward, skip forward or stop
shortcut button to catch up to real time.
To rewind radio
Press the ReVu button twice. Use the Rewind ( ) button to move back in
the recorded audio or the skip back ( ) button to return to the start.
Storing and recalling presets
You can store up to 99 of your favourite stations as presets which you can
then access quickly using the shortcut buttons or remote control. You can
store and access presets while listening to radio but not if in ReVu mode.
Push any shortcut button or set the Display mode to show the presets as
described on page 5. This shows the first page of presets on the screen.
Flick through the other pages of presets using the left ( )and right ( )
shortcut buttons or skip buttons on the remote.
To store a preset - Hold down the shortcut button you want to store the
current station under until the station name appears or press the Save button
and numbered buttons on the remote. The preset is stored.
To recall a preset - Push the shortcut button next to the preset you want to
listen to or press the number buttons on the remote
Changing DAB options
To customise the way your Legato works in DAB mode push the Menu button,
select DAB and choose from the following:
Autotune UK
Scans all UK frequencies for DAB stations and adds any new ones to the
station list.
Autotune full
Scans the full range of digital frequencies in Band III. This option is for use
outside the UK where other Band III stations may be available.
BBC Ra di o 1
0 9 : 4 0
D AB
0 9 : 4 0
ReVu mode - playing
BBC Radio 1
0 9 : 4 0
D A
B
P r e s e t s 0 1 - 0 4
1 X t r a BBCAs i a n
Ab D AB BBCW or l d
Presets 1 to 4
Autotu n e UK
Autotu n e full
St a t i on or d e r
D AB M e n u
M a n u al t u n e
D R C[OFF ]
DAB options
Great Britain
7
GB
Station order
Change the order of stations on your station list using this option. The current
order is shown at the top of the screen. Choose from the following:
Alphanumeric Displays all stations in alphanumeric order.
Favourite Displays your eight most listened to stations at the top of the
station list and the others below. Your favourite stations are
selected by how long you listen to each station and indicated
by a heart next to the name in the station list.
Active Displays active stations at the top of the station list and
inactive ones at the bottom, in alphanumeric order. Inactive
stations are those on your station list but not currently
available, marked with a ’?’.
Multiplex Lists stations in groups according to their multiplex.
Multiplexes are groups of stations owned and broadcast by a
multiplex operator.
Trim stn list Removes inactive stations from the station list.
Favs presets Available only when Favourite station order (above) has been
selected. Transfers your eight favourite stations to presets.
Manual tune
Find new stations or fine tune your reception using this option.
You see a list of channels and frequencies. Each multiplex has a different
channel and frequency (E.g., BBC is channel 12B and Digital One is 11D),
contact the DRDB (Digital Radio Development Bureau) by phone on 08707
74 74 74 or at www.digitalradionow.com for information on multiplexes.
1. Select the channel you want from the list.
You see a signal strength display. The marker indicates the minimum
required level for reception and the filled blocks indicate the current
level.
2. Move your aerial and try to raise the current level to the marker or
beyond. You see the multiplex name at the top of the screen if a good
signal is received and the stations in that multiplex are listed below and
added to the station list.
DRC
Make the quieter sounds in a broadcast easier to hear at low volume or in
a noisy environment using this option. The DRC (Dynamic Range Control)
level of a broadcast is set by the station and sent with the signal. At the time
of writing only stations such as BBC Radio 3 and 4 regularly broadcast a
DRC level. Check with the broadcasters to find out if they use DRC on their
stations.
Select one of the following options:
DRC OFF DRC is switched off. Any DRC level broadcast is ignored. This is
the default setting.
DRC HALF DRC level is set to half that sent with the broadcast.
DRC FULL Applies the DRC level as sent with the broadcast.
0 9 : 4 0
D AB
1 2 A 2 2 3 . 93 MH z
1 2 B 2 2 5 . 64 MH z
1 2 C 2 2 7 . 36 MH z
0 9 : 4 0
Manual tune
Great Britain
8
Playing a CD
To listen to a CD push the Mode button until you see CD in the top left of the screen.
Push the eject button ( ) and place your CD label side up in the CD tray. Push the
eject button again to load the CD. Legato checks the CD type and loads a track list. If
you insert a CD with MP3 files on it Legato enters MP3 mode, see page 10.
If you close the CD tray by pushing the tray or pressing play the CD automatically
starts playing. You see the standard CD controls, track title and time into track on the
screen.
Selecting a track
To change tracks on a CD, either:
• push the Tuning dial and turn to scroll through the track list, then push
the Tuning dial again to play the track
• use the skip forward or skip back shortcut buttons on screen or remote
• select a track number using the numbered buttons on the remote
Changing the information displayed
To change what you see on screen while you listen to a CD push the Display
button. Choose from the following options:
Track elapsed Time the current track has been playing, or if stopped total
time and number of tracks on the CD.
Track remaining Time remaining of the current track.
Disc remaining Time remaining of current CD.
CD text Displays album name, track information, artist, etc., if
included on the CD.
Date and time Obtained from the DAB signal.
Changing CD options
To customise the way Legato works in CD mode push the Menu button, select
CD and choose from the following:
Play
Choose whether to play all tracks on the CD [ALL] or just those on a playlist
you have created [LIST]. See Set playlist below for details of creating a CD
playlist. If you select LIST you see the playlist icon ( ).
Shuffle
Choose whether to play CD tracks in the order they appear on the disc [OFF]
or in a random order [ON]. If you select ON you see the shuffle icon ( ).
Repeat
Choose to repeat the current track [TRACK] when it ends or the whole disc
[ALL]. This loops continuously until you set it to [OFF]. If you select TRACK
you see the repeat track icon ( ), if you select ALL you see the repeat all
icon ( ).
T r a c k 1
0 9 : 4 0
CD
0 9 : 4 0
CD mode
CD T r a c k Li st
Track 1 03:58
Track 2 04:31
T o t a l T r ac ks : 15
Selecting a track
T r a c k 1
CD
0 9 : 4 0
CD time into track
Pl a y [ AL L]
Sh u f f le [O F F ]
Re p e a t [OF F ]
CD M e n u
Set p l aylis t
CD options
T r a c k 5
0 9 : 4 0
CD
O r b i t al
Y o u L ot
0 9 : 4 0
CD text
Great Britain
9
GB
Set playlist
Create a playlist containing the order in which to play up to 20 tracks from
the current CD.
To create a playlist:
1. Turn the Tuning dial and push to set the first track on your playlist.
2. Repeat until you have completed your playlist and push the bottom right
shortcut button (OK) to set your playlist and exit. This automatically sets
the Play mode to [LIST].
You see the playlist icon ( ).
Alternatively press the left middle shortcut button (Clear) to delete the
current playlist order or bottom left shortcut button (Cancel) to exit the
screen without saving any changes made
Your playlist is now set and if you play your CD it plays the tracks you
specified in the order you specified.
The playlist remains available for as long as the CD inserted. If you eject the
CD or change CDs the playlist you created is no longer available.
Great Britain
10
Push the Mode button until you see CD in the top left of the screen to listen to a CD
with MP3 files stored on it. Legato automatically detects if a CD has MP3 files on it
and changes to MP3 mode.
MP3 files can be in folders on the CD if desired and MP3 playlist files are also
supported. MP3 playlist files are simple text files (usually with a .M3U extension)
specifying an order in which to play a selection of MP3 files on the CD.
The following icons on the track list help you identify tracks, folders and playlist files:
MP3 files Open folder
Playlist file Closed folder
Push the eject button and place your MP3 CD label side up in the CD tray. Push the
eject button again to load the CD. Legato checks the CD type, changes the mode to
MP3 and displays the normal CD controls.
If you close the CD tray by pushing the tray or pressing play the CD automatically
starts playing. You see the standard CD controls, track title and time into track on the
screen.
Selecting a track, playlist or folder
To change tracks on an MP3 CD, either:
• push the Tuning dial and turn to scroll through the track list, then push
the Tuning dial again to play the track or playlist or open a folder
• use the skip forward or skip back shortcut buttons on screen or remote
• select a track number using the numbered buttons on the remote
Changing the information displayed
To change what you see on screen while you listen to an MP3 push the
Display button. Choose from the following options:
Time into track Time the current track has been playing
ID3 text Displays ID3 text – album name, track information artist
etc., if included with file
Date and time Obtained from the DAB signal
Changing MP3 options
To customise the way Legato works in MP3 CD mode push the Menu button,
select MP3 and choose from the following:
Shuffle
Choose whether to play MP3 tracks in the order they appear on the disc,
current selected folder or playlist [OFF], or in random order [ON]. If you select
ON you see the shuffle icon ( ).
Repeat
Choose to repeat the current track [TRACK] when it ends or the whole disc,
currently selected folder or playlist [ALL]. This loops continuously until you set
it to [OFF]. If you select TRACK you see the repeat track icon ( ), if you
select ALL you see the repeat all icon ( ).
Playing an MP3 CD
F i r e s t a r te r
0 9 : 4 0
MP3
0 9 : 4 0
MP3 mode
M P 3 T r a c k Li st
Rock t r a cks
Blues t r acks
Layl a
MP3 track list
L a y l a
A r t i s t : Er ic C la p t o n
A l b u m : B es t of E r i c
0 9 : 4 0
MP3
0 9 : 4 0
MP3 ID3 text
Sh u f f le [O F F ]
Re p e a t [OF F ]
M P 3
S et u p M e n u
MP3 options
Great Britain
11
GB
To listen to FM radio push the Mode button until you see FM in the top left of the
screen. The first time you enter FM mode Legato asks you to select the FM tuning
mode you want. Use the shortcut buttons or Tuning dial to select one of the following:
Autotune Finds all the stations available in your area and lists them in
alphanumerical order using RDS (Radio Data System) station
names where available.
Manual Tune Lets you tune manually either in steps of 0.05 MHz or using a
seek to find the next station.
Selecting a station
You select a station in different ways depending on which tuning mode you
have chosen:
Autotune To change stations, push the Tuning dial and turn to scroll
through the station list, then push the Tuning dial again to
tune to the highlighted station or use the shortcut buttons on
screen.
Manual Tune To change stations, push the Tuning dial and turn right or left
to step up or down the frequency range or use the shortcut
buttons on screen to step or scan to the next
station.
If you scan, the scan stops when the next station is found.
The frequency display changes to show the RDS station name
if available.
Changing the information displayed
To change what you see on screen while you listen to FM radio push the
Display button. Choose between the following options:
RadioText Dynamic text broadcast by some RDS stations.
Broadcast info Description of the content broadcast by the station and its
frequency. RDS stations only.
Presets FM presets for quick access to your favourite stations using
the six shortcut buttons.
Date and time Date and time obtained from the DAB signal.
Storing and recalling presets
You can store up to 99 of your favourite stations as presets which you can
then access quickly using the shortcut buttons or remote control.
Push any shortcut button or set the Display mode to show the presets as
described above. This shows the first page of presets on the screen. Flick
through the other pages of presets using the left ( )and right ( )
shortcut buttons or skip buttons on the remote.
To store a preset - Hold down the shortcut button you want to store the
current station under until the station name or frequency appears or press the
Save button and numbered buttons on the remote. The preset is stored.
To recall a preset - Push the shortcut button next to the preset you want to
listen to or press the number buttons on the remote
Listening to FM radio
Chilte r n
1 1 : 4 0
F M
Today' s Best Mix f o r Herts
Beds a n d Bucks - 9 7 .6
Chilte r n FM
FM mode
C h i l t e r n
1 1 : 4 0
F M
P o p M u s i c
9 7
.6 0
FM - Broadcast info
Radio 1
0 9 : 4 0
F M
-
-
- P r e s e t s 0 1 - 0 4
FM - Presets
C h i l t e r n
C h i l t e r n
B B C R 2
H e a r t F M
F M
S ta t i o n L i s t
FM station list
Great Britain
12
Changing FM options
To customise the way your Legato works in FM mode push the Menu button,
select FM and choose from the following:
Tune
Push the Tuning dial to choose between [BYNAME] which shows stations
in a station list (similar to the DAB station list) using RDS station names or
[MANUAL] to manually step through the FM frequencies in steps of 0.05 MHz
or scan to next station.
Station order
Change the order of stations on your FM station list using this option. The
current order is highlighted on screen. Choose from the following:
Alphanumeric Displays named stations at the top of the station list and
others below in numerical order
Named stations Displays stations with an RDS name only
Autotune
Performs a scan to find all the stations available in your area and lists them
in alphanumeric order using RDS station names where available.
Tun e [ BYNAME]
S t a t i o n or de r
Au t o t u n e
F M M e n u
FM Setup options
Great Britain
13
GB
Listening to another source
To listen to an audio source such as MiniDisc player attached to the Aux inputs on
your Legato push the Mode button until you see AUX in the top left of the screen.
Au x i l i a r y I np ut
0 2 / 0 8 / 0 4
AU
X
1 1 3 9
AUX mode
/ AUDIO OUT
Manufactured in China 12B52
Great Britain
14
General setup options
Push the Menu button to access general setup options, available at all times,
whether listening to radio or a CD. Choose one of the following options:
Audio
Tone
Turn the Tuning dial to set the Bass output level. Press the Tuning dial again to
set the Treble level.
Loudness
Push the Tuning dial to toggle Loudness [ON] or [OFF]. When Loudness is on
you see the Loudness icon on screen ( ).
Subwoofer
Push the Tuning dial to specify if you have an active subwoofer connected to
your Variable output [YES] or not [NO]. If you specify YES, Variable output will
mute if headphones are inserted.
Contact PURE for details of the SUB-1 active subwoofer.
Balance
Turn the Tuning dial to adjust the audio balance between left and right .
Screen
Active settings
Turn the Tuning dial to set the screen brightness. Press the Tuning dial again
to set the contrast.
Standby settings
Turn the Tuning dial to select the standby screen brightness level.
Alarm
To set an alarm to wake you up:
Turn the Tuning dial or use the +/- shortcut buttons to set an alarm time,
Mode [DAB/FM/Tone] and set the Alarm [On]. Radio alarms tune to the
station you were tuned to last in that mode. When the alarm is set you see
the Alarm icon ( ) on the screen. The alarm icon flashes when the alarm
goes off.
To cancel the alarm and leave the unit switched on press the Tuning dial or
press the Power button to cancel the alarm and switch off.
Sleep timer
To set a sleep timer to switch off your unit:
Turn the Tuning dial or use the +/- shortcut keys to set a time after which you
want your Legato to switch off. Choose between 15, 30, 45, 60, 1hr 15 and
1hr 30 minutes. To switch a sleep timer off use the Clear shortcut button or
set the time to zero.
Au di o M en u
T on e Ba lan ce
L ou d ne ss [ O FF ]
S
u bw o of er [ N O ]
Audio options
S cr e e n Co n t r o ls
B r i g h t n e ss
C o n t r a s t
-
-
Active screen settings
C lear
S le e p T i m e r
-
Sleep timer settings
A larm
[ Of f ]
M ode
[ DAB]
A la r m
- -
h h m m
Alarm settings
J o W h i l e y' s Cha ng i n g
T r a c k s - go o nl i n e t o
n o m i n a t e t he t un e s
BBC Radio 1
0 9 : 4 0
D AB
Alarm set icon
Great Britain
15
GB
S/W version
Displays the current software version installed on your Legato and gives
access to the Software Upgrade option.
Register your product and include an e-mail address to receive notification of
software updates or visit our website at www.pure.com/support.
To upgrade your software, press the Software Upgrade shortcut button and
follow the instructions on screen.
V1.2
S /W up gr a d e E xi t
S/W version screen
Great Britain
16
Hints and tips
(>>/<<) DAB Secondary services
Secondary services accompany some stations, providing extra information or alternative
content and may only be broadcast at certain times. At the time of writing not many
secondary services are available. If a station has secondary services available, the station
shows ‘>>’ next to its name in the station list and the secondary service appears next to the
station in the list. A secondary service has a ‘<<’ before its name in the station list.
(?) Inactive or unavailable DAB stations
Inactive or unavailable stations are those which appear on the station list but are not
currently available because either you are outside the broadcast area, have lost reception or
the station is not currently broadcasting. Unavailable stations have a ‘?’ before their name
on the station list. If you select a station which has this symbol, Legato returns to the last
station you were listening to.
I hear a ‘burbling’ sound on some DAB stations
Although DAB is excellent at providing quality audio from very little signal, the quality can
suffer if the signal strength is too low. If that happens, a ‘burbling’ sound can sometimes
be heard. To help reduce this, check that your aerial is fully extended and upright. If the
problem persists try moving your radio or repositioning your aerial using manual tuning.
Screen says ‘No stations available’ in DAB mode
Check that your aerial is fully extended. Use Autotune to search for stations. Use manual
tuning to adjust your aerial or radio position.
Clock shows the wrong time
This may happen if the DAB multiplex you are tuned to broadcasts an incorrect time signal,
try tuning to a station in another multiplex.
Resetting your unit
Resetting your Legato removes all presets, stored stations and favourite station settings and
resets all options to defaults. To reset:
1. Press and hold the Menu button for three seconds. The screen shows ‘Do you want to
reset?’.
2. Push the ‘Yes’ shortcut button or use the +/- or and select button on the remote to
confirm the reset or press no buttons to cancel the reset.
My speakers don’t sound good
Make sure that the red (positive) terminal on the speakers is connected to the red terminal
on Legato and black (negative) to black .
Ensure the connections are secure and bared ends of the cables are contacting the metal of
the terminals.
Note that from new, the sound from your speakers should improve over the course of a few
days as they are ‘run-in’.
My screen is too bright in standby
To set the brightness of your screen in standby press the Menu button, select Display and
choose Standby settings to alter the brightness.
Alarm bell icon has a cross through it
This happens if you set an alarm but no DAB time has been acquired yet. Check that your
aerial is connected, return to DAB or standby and wait for a shor t period and the normal icon
should appear indicating that the time has been acquired.
Screen says ‘DAB time not available’
This happens in CD/MP3/FM/AUX mode if DAB time has been acquired yet. Check that your
aerial is connected, switch to DAB mode or standby, wait for a short period and the time
should appear.
Great Britain
17
GB
Amplifier
22W RMS per channel power output (into 4 Ohms)
15 Hz to 35 kHz frequency response
Dynamic Virtual Sub Technology™ provides a variable bass boost relative to
volume
Bass and treble tone control
CD player
CD-R and CD-RW playback compatible
Support for CD Text and 20 track audio CD playlist
Multiple playback modes (repeat, shuffle, etc.)
MP3 playback, including support for ID3 tags and M3U playlists
DAB
PURE ReVu™ enables pause and rewind of live DAB digital radio
Full Band III (174 - 240 MHz) reception. Fully compliant with ETS 300 401
and capable of decoding all DAB transmission modes 1-4
Fast autotune feature
DPAC II™ provides a more natural sound from DAB transmissions
FM
Supports RDS and RadioText
Tune by RDS station name
87.5 - 108 MHz frequency range
Speakers (optional)
6 Ohms (nominal) impedance
30W RMS power handling
Twin 3” custom designed full range drive units
Neodymium magnets
Phase correction plugs
Bass reflex ported
Connectors
3.5 mm headphone output
RF F-connector 75 Ohms for DAB aerial connection
Dual phono for external line level audio input
Dual phono for stereo analogue audio output or connection to a subwoofer
Optical Toslink connector for digital S/PDIF output (IEC958 @ 48 kHz)
USB connector for future software upgrades
Stereo spring-clip terminals for speakers
General
Fully featured remote control
Compliant with the EMC and Low Voltage Directives (89/336/EEC and 73/
23/EEC)
Main unit dimensions (excluding controls) 210 (w) x 155 (h) x 215 mm (d)
Speaker dimensions 105 (w) x 215 (h) x 215 mm (d) (where included)
2 x 3m speaker cable supplied
UK and Euro Mains cables supplied
Bootlace aerial supplied
Telephone support hotline and internet website
Two year warranty
Technical specifications
www
.pure.com
PURE Digital, Imagination Technologies Ltd., Home Park Estate, Kings Langley, Herts, WD4 8LZ, UK
+44 (0) 1923 270188 +44 (0) 1923 277477 support
+44 (0) 1923 277488 sales
support@pure.com
sales@pure.com
12P51
Loading...
