DVD RDS AV RECEIVER

AVH-P5200BT

English

Contents

Thank you for purchasing this PIONEER product.

To ensure pro per use, please read through this manual before using this product. It is especially important that you read and observe WARNINGs and CAUTIONsin this manual. Please keep the manual in a safe and accessible place for future refer-

ence.

Be sure to read this

! DVD video disc region numbers 6 ! Handling guideline 79

Precautions

IMPORTANT SAFEGUARDS 4 To ensure safe driving 4 To avoid battery exhaustion 5

Before You Start

About this unit 6 Operating environment 6 In case of trouble 6 Protecting your unit from theft 6 Resetting the microprocessor 7 Feature demo mode 7 Adjusting the response positions of the

touch panels (Touch Panel Calibration) 7

What’s what

Head unit 8 Optional remote control 8

Basic Operations

Basic Operations 9 Operating the scroll bar and the scrubber

bar 10 Activating the touch panel keys 10 Common operations for menu settings/

lists 11 Opening and closing the LCD panel 11 Ejecting a disc 12 Ejecting an SD 12 Setting the clock 12

Tuner Introduction of tuner operations 13

Playing moving images

Introduction of video playback

operations 14

Playing audio

Introduction of sound playback

operations 17

Playing still images

Introduction of still image playback

operations 20

Introduction of still image playback as a

slideshow operations 21

Bluetooth Telephone

Introduction of Bluetooth telephone

operations 22

TV tuner Introduction of TV tuner operations 24

Detailed instructions

Storing and recalling stations 25 Displaying radio text 25 Storing and recalling radio text 25 Storing the strongest stations 25 Tuning in to strong signals 25 Receiving traffic announcements 26 Using PTY functions 26 Switching the media file type 27 Operating the DVD menu 27 Operating this unit’s iPod function from your

iPod 27 Random play (shuffle) 28 Playing all songs in random order (shuffle

all) 28 Repeating playback 28 Playing videos from your iPod 28 Browsing for a video/music on the iPod 29 Resume playback (Bookmark) 29 Frame-by-frame playback 30

Contents

Slow motion playback 30 Searching for the part you want to play 30 Changing audio language during playback

(Multi-audio) 30

Changing the subtitle language during

playback (Multi-subtitle) 31

Changing the viewing angle during playback

(Multi-angle) 31 Return to the specified scene 31 Selecting audio output 31 PBC playback 31 Selecting tracks from the track title list 32 Selecting files from the file name list 32 Using advanced sound retriever 32 Changing audiobook speed 32 Displaying lists related to the currently

playing song (Link Search) 32 Playing DivXÒ VOD content 33 Capture an image in JPEG files 33 Changing the wide screen mode 33 Calling a number in the phone book 34 Selecting a number by alphabet search

mode 35 Using the missed, received and dialed call

lists 35 Setting automatic answering 35 Adjusting the other party’s listening

volume 36 Switching the ring tone 36 Using the preset dial lists 36 Making a call by entering phone number 36 Setting the private mode 37 Pairing from this unit 37 Using a Bluetooth device to pair 37 Connecting to a Bluetooth device

automatically 38 Switching visible unit 38 Displaying BD (Bluetooth Device)

address 38

Entering PIN code for Bluetooth wireless

connection 39

Menu operations

Introduction of menu operations 40 Audio Adjustments 41 Digital Signal Processor 44 Setting up the DVD player 54 System settings 58 Entertainment settings 66 Customizing menus 67

Other Functions

Changing the picture adjustment 68 Setting rear monitor output 68 Adjusting the response positions of the

touch panels (Touch Panel

Calibration) 69 Using an AUX source 69 Using an external unit 70

Additional Information

Troubleshooting 71 Error messages 73 Understanding auto EQ/auto TA and EQ error

messages 76 Understanding messages 77 Indicator list 78 Handling guideline 79 Compressed audio compatibility (disc, USB,

SD) 82 iPod compatibility 83 Sequence of audio files 83 Using the display correctly 84 Copyright and trademark 85 Language code chart for DVD 87 Specifications 89

Section

Precautions

IMPORTANT SAFEGUARDS

Please read all of these instructions regarding your display and retain them for future reference.

1 Read this manual fully and carefully be-

fore operating your display.

2 Keep this manual handy as a reference for

operating procedures and safety information.

3 Pay close attention to all warnings in this

manual and follow the instructions carefully.

4 Do not allow other persons to use this sys-

tem until they have read and understood the operating instructions.

5 Do not install the display where it may (i)

obstruct the driver’s vision, (ii) impair the performance of any of the vehicle’s operating systems or safety features, including air bags, hazard lamp buttons or (iii) impair the driver’s ability to safely operate the vehicle.

6 Do not operate this display if doing so in

any way will divert your attention from the safe operation of your vehicle. Always observe safe driving rules and follow all existing traffic regulations. If you experience difficulty in operating the system or reading the display, park your vehicle in a safe location and make necessary adjustments.

7 Please remember to wear your seat belt at

all times while operating your vehicle. If you are ever in an accident, your injuries can be considerably more severe if your seat belt is not properly buckled.

8 Never use headphones while driving. 9 To promote safety, certain functions are

disabled unless the parking brake is on, and the vehicle is not in motion.

10 Never set the volume of your display so

high that you cannot hear outside traffic and emergency vehicles.

WARNING

! Do not attempt to install or service your

display by yourself. Installation or servicing of the display by persons without training and experience in electronic equipment and automotive accessories may be dangerous and could expose you to the risk of electric shock or other hazards.

To ensure safe driving

WARNING

! LIGHT GREEN LEAD AT POWER CON-

NECTOR IS DESIGNED TO DETECT PARKED STATUS AND MUST BE CONNECTED TO THE POWER SUPPLY SIDE OF THE PARKING BRAKE SWITCH. IMPROPER CONNECTION OR USE OF THIS LEAD MAY VIOLATE APPLICABLE LAW AND MAY RESULT IN SERIOUS INJURY OR DAMAGE.

! To avoid the risk of damage and injury and the

potential violation of applicable laws, this unit is not for use with a video screen that is visible to the driver.

! To avoid the risk of accident and the potential

violation of applicable laws, no viewing of front seat video should ever occur while the vehicle is being driven. Also, rear displays should not be in a location where they are visibly distracting to the driver.

! In some countries or states the viewing of

images on a display inside a vehicle even by persons other than the driver may be illegal. Where such regulations apply, they must be obeyed and this unit’s DVD features should not be used.

When you attempt to watch a DVD, Video CD or TV while driving, the warning Viewing of

front seat video source while driving is strictly prohibited. will appear on the front

display.

Precautions

Section

To watch a DVD, Video CD or TV on the front display, park your vehicle in a safe place and apply the parking brake.

When using a display connected to REAR MONITOR OUTPUT

Passengers in the rear seat can also watch DVDs or the TV if you connect this unit to a display using the REAR MONITOR OUTPUT.

WARNING

NEVER install the rear display in a location

where the driver can watch a DVD or TV while driving.

When using the rear view camera

With an optional rear view camera, this unit can be used as an aid to keep an eye on trailers, or when backing into a tight parking spot.

WARNING

! SCREEN IMAGE MAY APPEAR RE-

VERSED.

! USE INPUT ONLY FOR REVERSE OR

MIRROR IMAGE REAR VIEW CAMERA. OTHER USE MAY RESULT IN INJURY OR DAMAGE.

To avoid battery exhaustion

Keep the vehicle engine running when using this unit to avoid draining the battery power. ! When no power is supplied to this unit,

such as when the vehicle battery is being replaced, the microcomputer of this unit returns to its initial condition. We recommend that you transcribe the audio adjustment data.

WARNING

Do not use with vehicles that do not feature an ACC position.

Precautions

CAUTION

! The rear view camera function is to be used

as an aid to keep an eye on trailers, or while backing up. Do not use for entertainment purposes.

! Please note that the edges of the rear view

camera images may differ slightly according to whether full screen images are displayed when backing up, and whether the images are used for checking the rear when the vehicle is moving forward.

Section

Before You Start

About this unit

The tuner frequencies on this unit are allocated for use in Western Europe, Asia, the Middle East, Africa and Oceania. Use in other areas may result in poor reception. The RDS (radio data system) function only operates in areas with broadcasting RDS signals for FM stations.

CAUTION

! Do not allow this unit to come into contact

with liquids. Electrical shock could result. Also, damage to this unit, smoke, and overheating could result from contact with liquids.

! “CLASS 1 LASER PRODUCT”

This product is a class 1 laser product classified under the Safety of laser products, IEC 60825-1:2007, but this product contains a laser diode higher than Class 1. To ensure continued safety, do not remove any covers or attempt to gain access to the inside of the product. Refer all servicing to qualified personnel.

! The Pioneer CarStereo-Pass is for use only in

Germany.

! Always keep the volume low enough to hear

outside sounds.

! Avoid exposure to moisture. ! If the battery is disconnected or discharged,

any preset memory will be erased.

DVD video disc region numbers

Only DVD video discs with compatible region numbers can be played on this player. You can find the region number of the player on the bottom of this unit and in this manual (refer to Specifications on page 89).

In case of trouble

Should this product fail to operate properly, please contact your dealer or nearest authorized Pioneer Service Station.

Protecting your unit from theft

The front panel can be detached to deter theft. ! If the front panel is not detached from the

head unit within four seconds of turning off the ignition, a warning tone will sound.

! You can turn off the warning tone. Refer to

Switching the warning tone on page 62.

Important

! Handle gently when removing or attaching

the front panel.

! Avoid subjecting the front panel to excessive

shock.

! Keep the front panel out of direct sunlight and

high temperatures.

! If removed, replace the front panel on the unit

before starting up your vehicle.

Removing the front panel

% Pinch the top and bottom of its right side and pull the front panel out.

Take care not pinch it too tightly or to drop it, and also avoid contact with water or other fluids to prevent permanent damage.

Operating environment

This unit should be used within the temperature ranges shown below. Operating temperature range: -10 °C to +60 °C EN300328 ETC test temperature: -20 °C and +55 °C

Before You Start

Section

Re-attaching the front panel

1 Slide the front panel to the left.

Front panel and the head unit are connected on the left side. Make sure that the front panel has been properly connected to the head unit.

2 Press the right side of the front panel until it is firmly seated.

# If you can’t attach the front panel to the head unit successfully, try again. However, forcing the front panel into place may result in damage.

Resetting the microprocessor

By pressing RESET, you can reset the microprocessor to its initial settings without changing the bookmark information. The microprocessor must be reset in the following situations: ! Before using this unit for the first time after

installation

! If the unit fails to operate properly ! When strange or incorrect messages ap-

pear on the display

1 Turn the ignition switch OFF.

2 Press RESET with a pen tip or other pointed instrument.

For this function, verify the following section before operation. Refer to the previous page.

Note

Switch your engine ON or set the ignition switch to ACC ON before pressing RESET in the following situations:

! After completing connections ! When erasing all stored settings ! When resetting the unit to its initial (factory)

settings

Feature demo mode

The feature demo automatically starts when you select Off for the source and continues while the ignition switch is set to ACC or ON. To cancel the feature demo, press and hold MUTE/ restart. Operating the feature demo while the car engine is turned off it may drain the battery power.

Failure to connect the red lead (ACC) of this unit to a terminal coupled with ignition switch on/off operations may lead to battery drain.

. Press and hold MUTE/ again to

Important

Adjusting the response positions of the touch panels (Touch Panel Calibration)

If you feel that the touch panel keys on the screen deviate from the actual positions that respond to your touch, adjust the response positions of the touch panel. Refer to Adjusting

the response positions of the touch panels (Touch Panel Calibration) on page 69.

Before You Start

RESET button

Section

What’s what

Head unit

Part Part

1 MUTE/

Displaying the menu.

Returning to the normal display.

MODE

Turning the information display off.

4 Disc loading slot b

5 SRC/OFF c RESET

6 c/d (TRACK) d

7 h (eject)

8 OPEN/CLOSE

AUX input jack (3.5 mm stereo/video jack)

Use to connect an auxiliary device.

Auto EQ microphone input jack Use to connect an

auto EQ microphone.

USB port When connecting, open the USB connector lid.

SD memory card slot

CAUTION

! Use an optional Pioneer USB cable (CD-U50E)

to connect the USB audio player/USB memory as any device connected directly to the unit will protrude out from the unit and may be dangerous.

! Do not use unauthorized products. ! For details on how to operate a navigation unit

from this unit, refer to its operation manual.

Note

When the navigation unit is connected, press

MODE to switch to the navigation display. Press MODE and hold to turn the display off. Press MODE again to turn the display on.

Optional remote control

The remote contr ol CD-R55 is sold separately.

For details concerning operations, see the remote control manual.

ed 28 may
