Pelco CM1450 Specsheet

PRODUCT SPECIFICATION

2.68

(6.80)

2.84

(7.21)

1.40

(3.56)

10.71

(27.20)

1.50

(3.81)

5.49

(13.73)

3.48

(8.84)

9.72

(24.69)

3.55

(9.02)

1/4-20 X 0.25 (0.635)

NOTE: VALUES IN PARENTHESES ARE CENTIMETERS;

ALL OTHERS ARE INCHES.

CM1450 Mount

WALL MOUNT, CAMERA

Product Features

• Low Cost Wall Mount

• Decorator Styling

• Supports up to 7 Pounds (3.2 kg)

• Adjustable Swivel Head

• Accommodates Light-Duty Cameras

• Can be Adapted for Pole Mount Applications With Use of

PA101 Adapter

camera site

The CM1450 is a light-duty camera mount designed for wall mount
applications.

The CM1450 is manufactured from aluminum and die-cast for low
cost efficiency. It features an easily adjustable swivel head, which
allows for 360-degree pan rotation and 90-degree tilt adjustments.
The CM1450 utilizes a set screw for final positioning of the swivel
assembly.

The CM1450 will accommodate cameras weighing up to 7 pounds
(3.2 kg).

The CM1450 can also be adapted for pole mount applications when
used with a Pelco PA101 adapter.

C201 / REVISED 1-06

International Standards

Organization Registered Firm;

ISO 9001 Quality System

TECHNICAL SPECIFICATIONS

0.875

(2.22)

2X

Ø0.25 X 0.75 SLOT

(0.64 X 1.91), 4X

5.00

(12.70)

2.86

(7.26)

1.00

(2.54)

0.75

(1.91)

2X

1/4-20 X 3/4 STUD, 3X

4.00

(10.16)

2.725
(6.92)

REF.

0.425

(1.08)

1.30

(3.30)

NOTE: VALUES IN PARENTHESES ARE CENTIMETERS;

ALL OTHERS ARE INCHES.

PA101 POLE ADAPTER

PA101 DIMENSION DRAWING

MODEL

CM1450 Light-duty camera mount with adjustable

RELATED PRODUCT

PA101 Pole mount adapter for CM1450 mount.

MECHANICAL

Pan Adjustment 360°
Tilt Adjustment 90°
Locking Method Set screw secures swivel assembly
Camera Mounting 1/4-20 threaded stud and nut
Mounting Method Secure with three 1/4-inch diameter

GENERAL

Construction Aluminum
Finish Gray polyester powder coat
Maximum Load 7 lb (3.2 kg)
Unit Weight

CM1450 1.2 lb (0.5 kg)
PA101 0.88 lb (0.4 kg)

Shipping Weight

CM1450 2 lb (0.9 kg)
PA101 2 lb (0.9 kg)

swivel head for wall mount applications

Stainless steel straps supplied. Straps fit
3-inch (7.62 cm) to 8-inch (20.32 cm) diameter
pole.

fasteners to solid surface or use one
5/16-inch diameter and one 1/4-inch diameter
fastener where wall studs are encountered.
(Fasteners not supplied.)

CERTIFICATIONS

• UL Listed
