BATTERY CHARGER 20V 2.4A PLG 20 C1
BATTERY CHARGER 20V 2.4A
Translation of the original instructions
AKKU-LADEGERÄT 20 V 2,4 A
Originalbetriebsanleitung
ΦΟΡΤΙΣΤΗΣ ΕΠΑΝΑΦΟΡΤΙΖΟΜΕΝΩΝ ΜΠΑΤΑΡΙΩΝ 20 V 2,4 A
Μετάφραση των αυθεντικών οδηγιών
λειτουργίας
IAN 380775_2110
Before reading, unfold both pages containing illustrations and familiarise
yourself with all functions of the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τις δυο σελίδες με τις εικόνες και
εξοικειωθείτε με όλες τις λειτουργίες της συσκευής.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und
machen Sie sich anschließend mit allen Funktionen des Gerätes vertraut.
GB / IE / NI /CY Translation of the original instructions Page 1
GR / CY Μετάφραση των αυθεντικών οδηγιών
λειτουργίας Σελίδα 15
DE / AT / CH Originalbetriebsanleitung Seite 29
A
All Parkside tools and the chargers
PLG20 A1/A4/C1/A2/C2/A3/C3/
PDSLG 20 A1 of the X20V Team series
are compatible with the PAP 20 A1/A2/
A3/B1/B3/PAPS 204 A1/PAPS 208 A1
battery pack.
Charging times
Charging currents
2 Ah PAP 20 A1/B1
Battery pack
3 Ah PAP 20 A2
Battery pack
4 Ah PAP 20 A3/B3
Battery pack
4 Ah PAPS 204 A1
Battery pack
8 Ah PAPS 208 A1
Battery pack
max. 2,4 A
Charger
PLG 20 A1/A4/C1
max. 3,5 A
Charger
PLG 20 A2/C2
max. 4,5 A
Charger
PLG 20 A3/C3
max. 4,5 A
Charger
PDSLG 20 A1
60 min
2,4 A
90 min
2,4 A
120 min
2,4 A
120 min
2,4 A
210 min
2,4 A
45 min
3,5 A
60 min
3,5 A
80 min
3,5 A
80 min
3,5 A
165 min
3,5 A
35 min
3,8 A
45 min
4,5 A
60 min
4,5 A
50 min
4,5 A
120 min
4,5 A
35 min
3,8 A
45 min
4,5 A
60 min
4,5 A
50 min
4,5 A
120 min
4,5 A
Contents
Introduction ...................................2
Intended use ..........................................2
Features .............................................3
Package contents ......................................3
Technical specifications .................................3
General safety instructions ......................4
Extended safety guidelines ...............................5
Safety guidelines for battery chargers ......................6
Before use ....................................7
Charging the battery pack (see fig. A) ......................7
Checking the battery charge level .........................8
Cleaning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Maintenance and storage .......................8
Kompernass Handels GmbH warranty ............9
Service ......................................12
Importer ....................................12
Disposal .....................................13
Notes on the EC declaration of conformity .........14
PLG 20 C1
GB│IE│NI│CY
│
1 ■
Introduction
Congratulations on the purchase of your new appliance. You have
chosen a high-quality product. The operating instructions are part of
this product. They contain important information about safety, usage
and disposal. Before using the product, please familiarise yourself
with all the operating and safety instructions. Use the product only
as described and for the range of applications specified. Please
also pass these operating instructions on to any future owner.
Intended use
This charger is intended exclusively for charging PARKSIDE
PAP20A1/A2/A3/B1/B3/PAPS204A1/PAPS208A1 series
batteries.
This appliance is suitable for:
The appliance is not intended for commercial use. Any other
usage or modification of the appliance is deemed to be improper
and carries a significant risk of accidents. The manufacturer
accepts no responsibility for damage attributable to misuse.
■ 2 │ GB
│IE│NI│
CY
PLG 20 C1
Features
Battery pack (not included)
High-speed charger
Red charge control LED
Green charge control LED
Battery charge level button (not supplied)
Battery display LED (not supplied)
Package contents
1 battery charger 20V 2.4A
1 set of operating instructions
Technical specifications
Battery Charger 20V 2.4A PLG 20 C1
INPUT
Rated voltage 230–240 V ∼ (AC), 50 Hz
Rated power consumption 65 W
Fuse (internal) 3.15 A
OUTPUT
Rated voltage 21.5 V (DC)
Rated current 2.4 A
Charging time approx. 60 min (2 Ah – 100%)
Protection class II /
T3.15A
approx. 90 min (3 Ah)
approx. 120 min (4 Ah)
approx. 210 min (8 Ah)
(double insulation)
PLG 20 C1
GB│IE│NI│CY
│
3 ■
General safety instructions
WARNING!
■ Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire
and/or serious injury. Save all warnings and instructions for
future reference.
a) Charge a rechargeable battery unit using only the charger
recommended by the manufacturer. Chargers are often designed
for a particular type of rechargeable battery unit. There is the
danger of fire if other types of rechargeable battery units are
used.
b) Only the rechargeable battery units supplied are to be used
with an electrical power tool. The use of other rechargeable
battery units may lead to the danger of injury or fire.
c) When they are not being used, store rechargeable battery
units away from paperclips, coins, keys, nails, screws or
other small metal objects that could cause the contacts to be
bridged.
Short-circuiting the contacts of a rechargeable battery unit may
result in heat damage or fire.
d) Fluids may leak out of rechargeable battery units if they are
misused. If this happens, avoid contact with the fluid. If contact
occurs, flush the affected area with water. Seek additional
medical help if any of the fluid gets into your eyes. Escaping
battery fluid may cause skin irritation or burns.
■ 4 │ GB
│IE│NI│
CY
PLG 20 C1
CAUTION! RISK OF EXPLOSION!
Never charge non-rechargeable batteries.
Protect the rechargeable battery from
heat; for example, from continuous exposure to sunlight, fire,
water and moisture. There is a risk of explosion.
Extended safety guidelines
■ Do not use a damaged or modified battery. Damaged or
modified batteries may behave unexpectedly and cause fires,
explosions or pose a risk of injury.
■ Do not expose a battery to fire or excessively high tempera-
tures. Fire or temperatures in excess of 130°C (265°F) can
cause an explosion.
■ Follow all instructions regarding charging and never charge
the battery or the cordless tool outside the temperature range
given in the operating instructions.
Incorrect charging or charging outside of the approved temperature range can destroy the battery and increase the risk of fire.
■ Ensure that the mains voltage corresponds to the specifications
on the charger type plate.
There is a risk of electric shock.
PLG 20 C1
GB│IE│NI│CY
│
5 ■
Safety guidelines for battery chargers
■ This appliance may be used by children aged
8years and above and by persons with limited
physical, sensory or mental capabilities or lack of
experience and knowledge, provided that they
are under supervision or have been told how to
use the appliance safely and are aware of the
potential risks. Do not allow children to use the
appliance as a toy. Cleaning and user maintenance tasks may not be carried out by children
unless they are supervised.
■ To avoid potential risks, damaged mains cables
should be replaced by the manufacturer, their
customer service department or asimilarly quali-
fied person.
The charger is suitable for indoor use only.
ATTENTION!
► This charger can only charge the following batteries:
PAP 20 A1/PAP 20 A2/PAP 20 A3/PAP 20 B1/PAP 20 B3/
PAPS 204 A1/PAPS 208 A1.
► A current battery compatibility list can be found at
www.lidl.de/akku.
■ 6 │ GB
│IE│NI│
CY
PLG 20 C1
WARNING!
■ To avoid potential risks, damaged mains cables should be
replaced by the manufacturer, their customer service department or a similarly qualified person.
Before use
Charging the battery pack (see fig. A)
CAUTION!
► Always unplug the appliance before you remove the battery
pack from or connect the battery pack to the charger.
NOTE
► Never charge the battery pack at an ambient temperature of
below 10°C or above 40°C. If a lithium-ion battery is to be
stored for an extended period, the charge level should be
checked regularly. The optimum charge level is between 50%
and 80%. The storage climate should be cool and dry and the
ambient temperature should be between 0°C and 50°C.
♦ Connect the battery pack
(see fig. A).
♦ Insert the power plug into the socket. The control LED
up red.
♦ The green control LED
complete and the battery pack is ready.
to the high-speed battery charger
indicates that the charging process is
lights
PLG 20 C1
GB│IE│NI│CY
│
7 ■
ATTENTION!
♦ If the red control LED
pack has overheated and cannot be charged.
♦ If the red and green control LEDs
that the battery pack is defective.
♦ Push the battery pack
♦ Switch off the charger for at least 15 minutes between successive
charging sessions. Also disconnect the power plug from the mains
power socket.
flashes, this means that the battery
both flash, this means
into the appliance.
Checking the battery charge level
♦ Press the battery charge level button to check the status of
the battery (see also main diagram). The status/remaining
charge will be shown on the battery display LED as follows:
RED/ORANGE/GREEN = maximum charge
RED/ORANGE = medium charge
RED = low charge – charge the battery
Cleaning
CAUTION!
► Always unplug the charger before cleaning it.
► Do not clean the charger with water.
■ Clean the appliance with a dry cloth or brush. Do not use water
or metallic objects.
Maintenance and storage
■ If you do not intend to use the appliance for an extended period,
remove the batteries and store it in a clean, dry place away from
direct sunlight.
■ 8 │ GB
│IE│NI│
CY
PLG 20 C1
Kompernass Handels GmbH warranty
Dear Customer,
This appliance has a 3-year warranty valid from the date of purchase.
If this product has any faults, you, the buyer, have certain statutory
rights. Your statutory rights are not restricted in any way by the warranty described below.
Warranty conditions
The warranty period starts on the date of purchase. Please keep your
receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years of the
date of purchase of the product, we will either repair or replace the
product for you or refund the purchase price (at our discretion). This
warranty service requires that you present the defective appliance
and the proof of purchase (receipt) within the three-year warranty
period, along with a brief written description of the fault and of
when it occurred.
If the defect is covered by the warranty, your product will either be
repaired or replaced by us. The repair or replacement of a product
does not signify the beginning of a new warranty period.
X 12 V and X 20 V Team Series battery packs come with a 3-year
warranty valid from the date of purchase.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the
warranty. This also applies to replaced and repaired components.
Any damage and defects present at the time of purchase must be
reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.
PLG 20 C1
GB│IE│NI│CY
│
9 ■
Loading...
